RC513/514-FE (Rev. A)
10/100M Auto-negotiation
Copper-to-Fiber
Media Converter
User Manual
Raisecom Technology Co., Ltd.
Dec, 2005
Beijing Raisecom Science & Technology Co., Ltd.
CONTENT
1. SAFETY NOTICE .................................................................................................................2
2. OVERVIEW............................................................................................................................3
2.1. INTRODUCTION.................................................................................................................3
2.2. MODEL DESCRIPTION.......................................................................................................4
3. TECHNICAL SPECIFICATION...........................................................................................5
3.1. OPTICAL PARAMETERS ..................................................................................................... 5
4. CONSTRUCTION & INDICATOR......................................................................................6
4.1. FRONT VIEW AND INDICATORS..........................................................................................6
4.1.1. The Indicators on the Front Panel......................................................................6
4.1.2. The Definition of Indicators .................................................................................6
4.1.3. 16-Slot Chassis (for RC514) Front Panel Sketch............................................7
5. FUNCTION & APPLICATION.............................................................................................8
5.1. INTERCONNECTING MEDIA CONVERTERS .........................................................................8
5.2. CONNECTING MC WITH OTHER DEVICES (AT RJ45 PORT)................................................8
5.3. FULL DUPLEX CONFIGURATION (RJ45 PORT)...................................................................9
5.3.1. RC513/514-FE Series RJ45 Interface Auto-negotiation............................9
5.3.2. RC513/514-FE Series RJ45 in Forced Status ..............................................9
5.4. CONNECTION WITH OTHER EQUIPMENT (AT OPTICAL PORT)............................................9
6. INST ALLATION & INSPECTION.....................................................................................10
6.1. MATCHIN G FIBER-OPTIC CABLE WITH MEDIA CONVERTER ...........................................10
6.2. TYPES OF FIBER-OPTIC CABLE.......................................................................................10
6.3. RJ45 INTERFACE ............................................................................................................10
6.4. INSTALLATION OF CHASSIS (FOR RC514).......................................................................10
6.5. INSTALLATION OF DC POWER SUPPLY (FOR RC514) ......................................................11
6.6. AMBIENCE...................................................................................................................... 11
6.7. POWER SUPPLY...............................................................................................................11
6.8. DIMENSIONS................................................................................................................... 11
7. DIP-SWITCH CONFIGURATION .....................................................................................12
7.1. EXPLANATION FOR SW20 SETUP....................................................................................12
7.2. EXPLANATION FOR SW21 SETUP....................................................................................12
8. NETWORK MANAGEMENT.............................................................................................13
8.1. CARD/MODULE INFORMATION REVIEW..........................................................................13
8.2. MODULE CONFIGURATION .............................................................................................13
8.3. LOOP-BACK TEST...........................................................................................................13
8.4. SHOW MODULE INFO RESET...........................................................................................14
1
Beijing Raisecom Science & Technology Co., Ltd.
1. Safety Notice
Please read the following notice carefully before installing
and using the device, Raisecom shall not be responsible for
any loss that caused by violating safety notice.
RC513/514-FE (Rev. A) has high sensitivity optical interface,
so the power of optical transceiver output interface must be
checked before connecting. To avoid damaging, it is not
allowed that the optical power of transceiver’s output
interface is higher than that of RC513/514-FE.
RC513/514-FE (Rev. A) is an integrated device which has
precise elements, please avoid violent shake and impact, and
do not disassemble or maintain the device yourself. If it is
required, please do it under the guide of our technical staff
following anti static steps. Please contact us if there is any
need.
There must be grounding protection for the sake of safety;
do not disassemble the device yourself, we regard this as
you waiver your rights of repair guarantee.
2
Beijing Raisecom Science & Technology Co., Ltd.
2. Overview
2.1. Introduction
RC513/514 series remote-end managed, bandwidth adjustable Ethernet media
converters are new generation media converters developed by Raisecom.
The remote-end management means that the network administrators can manage both
the host-end and the remote-end equipments to conduct such operations as working
status review, equipment control, loop-back test, and data flow statistics, etc.
The bandwidth adjustment means that the administrator can adjust the sending and
receiving bandwidth of copper ports by N X 32kbps.
Operations to host-end equipment are as follows:
1. Working status review of host-end equipment:
The working status that can be reviewed is:
a. Copper port: upstream link, port ON/OFF, auto-sensing, full/half
duplex;
b. Fiber port: link receive (RLK), link transmit (TLK), port ON/OFF;
c. Others: Fault-pass-through enable/disable, management status of
remote-end equipment, loop-back test status, loop-back test success report,
configuration application.
2. Configuration of host-end equipment:
The configurable items include:
Copper port auto-negotiation, copper port duplex mode, copper port ON/OFF,
Fault-pass-through enable/disable, remote-end management functions, reset of copper
and fiber port, loop-back test enable and forbid, sending and receiving bit rate at N x
32kbps.
Operations to remote-end equipment are as follows:
1. Working status review of remote-end equipment:
The working status that can be reviewed is:
a. Copper port: link up, port ON/OFF, auto-sensing, full/half duplex;
b. Fiber port: link receive (RLK), link transmit (TLK);
c. Others: fault pass through enable, abnormal upper/lower limit of power
voltage, feedback to configuration application, temperature of chassis
ambience.
2. Configuration of remote-end equipment:
The configurable items include:
Copper port auto-negotiation, copper port duplex mode, copper port ON/OFF,
Fault-pass-through enable/disable, reset of copper and fiber port, sending and receiving
bit rate at N*32kbps.
3
Beijing Raisecom Science & Technology Co., Ltd.
2.2. Model Description
Part Number Description
RC513-FE-S1
Standalone, remote managed, 10/100Mbps auto-sensing, single mode, single strand,
dual wavelengths, 0-25Km, RJ45/SC
RC514-FE-S1
Module, remote managed, 10/100Mbps auto-sensing, single mode, single strand, dual
wavelengths, 0-25Km, RJ45/SC
Note: RC514-FE and RC513-FE must be deployed in pairs.
4
Beijing Raisecom Science & Technology Co., Ltd.
3. Technical Specification
3.1. Optical Parameters
PART NUMBER
Interface Wavelength
(nm)
Launch
Power
(dBmW)
Receiving
Sensitivity
(dBmW)
Typical
Range
(Km)
Attenuation
(dB/Km)
RC513-FE-S1 SC/PC-RJ45 1310 -12 ~ -3 < -30 0 ~ 25 0.5
RC513-FE-S2 SC/PC-RJ45 1310 -5 ~ 0 < -32 10 ~ 50 0.5
RC514-FE-S1 SC/PC-RJ45 1550 -12 ~ -3 < -30 0 ~ 25 0.5
RC514-FE-S2 SC/PC-RJ45 1550 -5 ~ 0 < -32 10 ~ 50 0.5
5
Beijing Raisecom Science & Technology Co., Ltd.
4. Construction & Indicator
4.1. Front view and indicators
4.1.1. The Indicators on the Front Panel
RLK
FDX
COL
PWRTLK
ACT
LNK
ACT
RMD 100M
Optical RX Link
Optical Data
TX/RX Action
ETH Data
TX/RX Action
Optical TX Link Bit Rate
Duplex mode
/Collision
Power Supply
Remote
Equipment
4.1.2. The Definition of Indicators
Interface
Indicator
Name
Indicator The Status Explanation
Optical Receive
Link
RLK
ON: Optical receive link works in good condition;
OFF: Optical receive link fails.
Optical
Transmit Link
TLK
ON: Optical transmit link works in good condition;
OFF and RLK ON: Optical transmit link fails.
Optical
Interface
Optical Data
Active
ACT Flashing: Transmitting data in Optical interface.
Remote
Management
Device
RMD
ON: Remote media converter supports remote SNMP
management;
OFF: Remote media converter does not support remote SNMP
management.
Fast flashing: host and remote-end managed;
Slow flashing: remote-end management prohibited by the
remote-end device, or at the status of fault-pass-through
Duplex Mode
/Collision
FDX/COL
ON: RJ45 works at full duplex mode;
OFF: RJ45 works at half duplex mode;
Flashing: Half duplex and collision occurs.
RJ45 Link
Receive and
Transmit
LNK/ACT
ON: RJ45 works in normal conditions;
OFF: RJ45 link fails;
Flashing: Transmitting data in RJ45 interface.
RJ45 Interface
Bit Rate 100M ON: Rate is 100M; OFF: Rate is 10M.
6
Beijing Raisecom Science & Technology Co., Ltd.
Power Supply Power PWR
ON: Power supply works in good condition;
OFF: Power supply disconnected.
4.1.3. 16-Slot Chassis (for RC514) Front Panel Sketch
PWR PS1 PS2
5V 12V 5V 12V
RAISECOM
The working conditions indicated by each indicator are as follows:
PWR: steady ON, the power supply of chassis is working in good condition.
PS1-5V: steady OFF, the PS1 power supply to modules is in good condition.
PS1-12V: steady OFF, the PS1 power supply to the electric fans is in good condition.
PS2-5V: steady OFF, the PS2 power supply to modules is in good condition.
PS2-12V: steady OFF, the PS2 power supply to the electric fans is in good condition.
7
Beijing Raisecom Science & Technology Co., Ltd.
5. Function & Application
5.1. Interconnecting Media Converters
When connecting with other media converters, it is required to comply with the specific
connecting requirements according to the following table. Otherwise, link faults or
abnormal data transmission will occur.
Host Site Remote Site
RC514-FE-S1 RC513-FE-S1
RC514-FE-S2 RC514-FE-S2
5.2. Connecting MC with Other Devices (at RJ45 Port)
1. When RC513/514 media converters are connected with other equipment, the copper
port of the other equipment shall be configured to 10/100Mbps auto-sensing.
Media Converter Other Equipment RJ45 UTP Cable Type
Media Converter Switch Straight-through/Crossover
Media Converter HUB Straight-through/Crossover
Media Converter Router Crossover/Straight-through
Media Converter Network Interface Card Crossover/Straight-through
2. When RJ45 interface of RC513/514 series media converters works on the forced status,
the “auto MDI/MDIX crossover” function may fail. So it is advised to adopt the following
connection modes in the forced status.
Media Converter Other Equipment RJ45 UTP Cable Type
Media Converter Switch Straight-through
Media Converter HUB Straight-through
Media Converter Router Crossover
Media Converter Network Interface Card Crossover
8
Beijing Raisecom Science & Technology Co., Ltd.
5.3. Full Duplex Configuration (RJ45 Port)
5.3.1. RC513/514-FE Series RJ45 Interface Auto-negotiation
The copper port/RJ45 of other network equipment must be configured to
“auto-negotiation” to ensure normal data transmission.
5.3.2. RC513/514-FE Series RJ45 in Forced Status
The RJ45 duplex mode of other network equipment must be configured as the following
table to ensure normal data transmission.
Media Converter
RJ45 Mode
Other Equipment
RJ45 Mode
100M/Full Duplex 100M/Full Duplex
100M/Half Duplex 100M/Half Duplex
10M/Full Duplex 10M/Full Duplex
10M/Half Duplex 10M/Half Duplex
5.4. Connection with Other Equipment (at Optical Port)
Several mandatory conditions are required:
1. The same wavelength (single strand dual-wavelength media converters are not
included)
2. The same bit rate
3. Matched optical power
4. Fast Ethernet protocol (IEEE 802.3u Fast Ethernet)
Note: when the fiber port of RC513/514 series media converters is connected with other
equipment, the remote-end SNMP management does not work.
9
Beijing Raisecom Science & Technology Co., Ltd.
6. Installation & Inspection
6.1. Matching Fiber-Optic Cable with Media Converter
RC513/514-FE-S1 series shall adopt single strand single-mode fiber. The connector of
fiber shall be SC/PC.
6.2. Types of Fiber-Optic Cable
Fiber-optic cable for multi-mode fiber port: 62.5/125um multi-mode fiber or 50/125um
multi-mode fiber.
Fiber-optic cable for single mode fiber port: 9/125um single mode fiber.
6.3. RJ45 Interface
Cat.5 of twisted-pair shall be used. Please note that twisted-pair cables shall not be
longer than 100 meters. For connection configuration, please see Chapter 2, Connection
with Other Equipment (at RJ45 Port).
6.4. Installation of Chassis (for RC514)
The chassis can be fixed onto 19” rack. The fixing accessories of chassis are in the
accessory box. If fixing the chassis with the rear hole, there’ll be 3cm space between the
front edge of chassis and the front edge of the rack; if fixing with the front hole, the front
edges will be in the same vertical level.
19" Standard Chassis Frame
10
Beijing Raisecom Science & Technology Co., Ltd.
6.5. Installation of DC Power Supply (for RC514)
DC power supply provides three connectors: –48V, ground and 0V. These three
connectors are connected respectively with –48V power cable, ground protection and 0V
power cable.
-48V 地 0V
6.6. Ambience
Working temperature: -20-60℃
Humidity: 5%~90% non-condensing
6.7. Power Supply
Chassis: 115/230V AC or –48V DC
6.8. Dimensions
Modular: 91(width)*25(height)*155(depth) mm
11
Beijing Raisecom Science & Technology Co., Ltd.
7. DIP-switch Configuration
7.1. Explanation for SW20 Setup
SW20 switch has 8 bits and the functions for each bit are as follows in sequence:
Auto-negotiation enable/disable, rate 100M/10M, full duplex/half duplex, reserved
(vacant), frame length 1916 bytes/1536 bytes, remote network management
enable/disable, reserved (vacant), Fault-pass-through disable/enable.
Switch Contents Status Configuration Details
ON RJ45 is configured as manual setup
1 RJ45 auto-sensing or manual setup
OFF RJ45 is configured as auto sensing
ON RJ45 manual setup: bit rate is 10M
2 RJ45 manual 100M/10M setup
OFF RJ45 manual setup: bit rate is 100M
ON RJ45 manual setting: Half duplex
3
RJ45 manual setup:
Full Duplex/Half Duplex
OFF RJ45 manual setting: Full duplex
4 Vacant (Reserved)
ON Over-sized frame up to 1536 bytes
5 Over-sized frame configuration
OFF Over-sized frame up to 1916 bytes
ON Disable remote network management
6
Remote network management
enable/disable
OFF Enable remote network management
7 Vacant (Reserved)
ON
Enabled: If the optical link is disconnected,
the RJ45 interface will be disabled
8 Fault-pass-through disable/enable
OFF Disabled: host RJ45 will always work
Note: When SW20-1 is OFF (auto-sensing status)，SW20-2 will be disabled.
7.2. Explanation for SW21 Setup
SW21-1 SW21-2 Module Types
OFF ON RC513/514-FE-S1
ON OFF RC513/514-FE-S2
12
Beijing Raisecom Science & Technology Co., Ltd.
8. Network Management
8.1. Card/Module Information Review
With network management software, the status of RC513/RC514 series can be reviewed
at the host site, and controlled/configured. The status information on “Show Module Info”
is as follows:
No. Status Name/Control & Configure Items Options Control & Configure Features
1 Module type S1, S2 Uncontrollable, non-configurable
2 Fault-Pass-Through Enable/disable Configurable
3 Remote network management (Only used for RC514) Enable/disable Configurable
4 Loop back control (Only used for RC514) Perform/No perform Controllable
5 Loop back result (Only used for RC514) Success/failure Uncontrollable, non-configurable
6 Frame length 1916B, 1536B Configurable
7 Receive rate (Only used for RC514) N*32kb/s N is Configurable
8 Transmit rate (Only used for RC514) N*32kb/s N is Configurable
9
Module voltage beyond upper limitati on (Only used for
RC513)
Normal/beyond upper
limitation
Uncontrollable, non-configurable
10
Module voltage beyond lower limitation (Only used for
RC513)
Normal/beyond lower
limitation
Uncontrollable, non-configurable
11 Module temperature (Only used for RC513) Actual temperature Uncontrollable, non-configurable
12 RJ45: Link status Up, Down Uncontrollable, non-configurable
13 RJ45: auto-negotiation Enable/manual Configurable
14 RJ45: control Turn on/off Configurable
15 RJ45: duplex status Full/half duplex Configurable
16 RJ45: rate 10M, 100M Configurable
17 Optical Interface: transmit Link Up, Down Uncontrollable, non-configurable
18 Optical Interface: receive Link Up, Down Uncontrollable, non-configurable
19 Optical Interface: control Turn on/off Uncontrollable, non-configurable
20 Optical Interface: signal Normal/abnormal Uncontrollable, non-configurable
8.2. Module Configuration
Options such as receiving rate, transmitting rate and RJ45 interface, etc. can be
configured through “Configure Card”.
8.3. Loop-back Test
Modules in the host site can perform the test of loop-back enable/disable through the
13
Beijing Raisecom Science & Technology Co., Ltd.
command “Show Module Info. Loop-back”. The results of test can be shown through
Show Module Info.
8.4. Show Module Info Reset
The host or remote-end modules can be reset through “Host Module Reset”. The frame
length after the reset is 1,916Bytes, and the working mode of port RJ45 is
auto-negotiation.
14
Beijing Raisecom Science & Technology Co., Ltd.
@2005 Raisecom Technology Co., Ltd.
All trademarks are the property of their respective owners.
Technical information may be subject to change without prior notification.
－V36
15
Loading...
