General Description
The MAX3540 complete single-conversion television
tuner is designed for use in analog/digital terrestrial applications and digital set-top boxes. This television tuner
draws only 760mW of power from a +3.3V supply voltage.
The MAX3540 is designed to convert NTSC or ATSC signals in the 54MHz to 860MHz band to a 44MHz intermediate frequency (IF).
The MAX3540 includes a variable-gain low-noise amplifier (LNA), multiband tracking filters, a harmonic-rejection mixer, a low-noise IF amplifier, an IF power detector,
and a variable-gain IF amplifier. The MAX3540 also
includes fully monolithic VCOs and tank circuits as well
as a complete frequency synthesizer. This highly integrated design allows for low-power tuner-on-board
applications without the cost and power-dissipation
issues of dual-conversion tuner solutions.
The MAX3540 is specified for operation in the 0°C to
+85°C temperature range and is available in a leadless
48-pin flip-chip (fcLGA) package.
Applications
Televisions
Analog/Digital Terrestrial Receivers
Digital Set-Top Boxes
Cable Modems
VOIP Gateways
Features
♦ Low Power Consumption: 760mW (typ) from a
+3.3V Supply Voltage
♦ Integrated Tracking Filters
♦ ATSC A/74 Compliant
♦ 40dB Adjacent Channel Protection Ratio (ACPR)
♦ 4.4dB (typ) Low Noise Figure
♦ Small, 7mm x 7mm, fcLGA Leadless Package
♦ 256-QAM-Compatible Phase-Noise Performance
♦ IF Overload Detector Controls RF Variable-Gain
Amplifier
♦ 2-Wire I
2
C-Compatible Serial Control Interface
MAX3540
Complete Single-Conversion Television Tuner
________________________________________________________________
Maxim Integrated Products
1
Pin Configuration
Ordering Information
19-0848; Rev 0; 10/07
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
*
EP = Exposed paddle.
EVALUATION KIT
AVAILABLE
PART
TEMP
RANGE
PINPACKAGE
PKG
CODE
MAX3540ULM#G42 0°C to +85°C 48 fcLGA-EP* L4877A-E
SCL
SDA
V
UHF_IN
VHF_IN
RFGND2
LEXT
RFGND3
RFAGC
V
GND
GND
GND
MUX
VCO
DIVIDER
GND
CC
V
GND
VTUNE
40414243 39 38 37464748
GND
XTALP
GND
÷
16 21201918 22 23 24151413
XTALN
4445
R
MAX3540
17
GND
VCCCP
PD CP
÷
N
EP
GND
ADDR2
ADDR1
+
1
2
3
CC
4
5
6
7
8
9
10
CC
11
12
GND
SERIAL
INTERFACE
GND
LDO
GND_TUNE
V
+
-
CC
V
GND
REF
CC
V
IFOUT2-
36
IFOUT1-
35
IFOUT1+
34
IFOVLD
33
V
CC
V
32
CC
31
GND
30
IFIN+
IFIN-
29
28
V
CC
27
GND
26
IFAGC
25
IFOUT2+
MAX3540
Complete Single-Conversion Television Tuner
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(MAX3540 Evaluation Kit, VCC= +3.1V to +3.5V, no RF signals at RF inputs, default register settings, V
RFAGC
= V
IFAGC
= +3V (minimum
attenuation), T
A
= 0°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.3V, TA= +25°C, unless otherwise noted.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
VCCto GND..............................................................-0.3V, +3.6V
RFIN, IFIN_, IFOUT1_, IFOUT2_, IFAGC, RFAGC,
VTUNE, LDO, MUX, CP, XTAL to GND ..-0.3V to (V
CC
+ 0.3V)
SDA, SCL, ADDR2, ADDR1 to GND......................-0.3V to +3.6V
IFOUT__ Short-Circuit Duration .....................................Indefinite
RF Input Power ...............................................................+10dBm
Continuous Power Dissipation (T
A
= +70°C)
48-Pin fcLGA (derate 25mW/°C above +70°C) ...............1.4W
Operating Temperature Range...............................0°C to +85°C
Junction Temperature......................................................+150°C
Storage Temperature Range .............................-65°C to +165°C
Lead Temperature (soldering, 10s) .................................+240°C
CAUTION! ESD SENSITIVE DEVICE
SUPPLY VOLTAGE AND CURRENT
Supply Voltage +3.1 +3.5 V
Supply Current
RF and IF AG C Inp ut Bi as C ur r ent At +0.5V and +3V -50 +50 μA
RF and IF AGC Control Voltage
(Note 1)
Digital Input Logic-Level Low
Digital Input Logic-Level High
SERIAL INTERFACE
Input Logic-Level Low
Input Logic-Level High
Input Hysteresis
SDA, SCL Input Current -10 +10 μA
Output Logic-Level Low 3mA sink current 0.4 V
Output Logic-Level High
PARAMETER CONDITIONS MIN TYP MAX UNITS
Receive mode 240 275
Shutdown mode 5
Minimum attenuation +3
Maximum attenuation +0.5
0.7 x
V
CC
0.7 x
V
CC
V
CC
0.5
0.05 x
V
-
CC
0.3 x
V
CC
0.3 x
V
CC
mA
V
V
V
V
V
V
V
MAX3540
Complete Single-Conversion Television Tuner
_______________________________________________________________________________________ 3
AC ELECTRICAL CHARACTERISTICS
(MAX3540 Evaluation Kit, VCC= +3.1V to +3.5V, 75Ω system impedance, default register settings, V
RFAGC
= V
IFAGC
= +3V (minimum
attenuation), T
A
= 0°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.3V, TA= +25°C, unless otherwise noted.)
RF INPUT TO IFOUT1_ OUTPUT
Operating Frequency Range
(See Table 7)
Output Frequency
Voltage Gain
Operating Frequency Range
Input Return Loss Worst case, selected channel 8 dB
Noise Figure Maximum gain, V
Input IP2
(In-Band and Out-of-Band Tones)
Input IP3
(In-Band and Out-of-Band Tones)
Input P
Beats Within Output 0dBmV PIX carrier level (Note 1) -60 dBc
Gain Flatness 54MHz to 60MHz 1.5 dB
Isolation
Port-to-Port Isolation Isolation between RF input ports at 215MHz 30 dB
Image Rejection
Spurious Leakage at RF Input
Output Return Loss Balanced 50Ω load 9 dB
PARAMETER CONDITIONS MIN TYP MAX UNITS
VHF_IN, LPF enabled, INPT = 00 54 100
VHF_IN, LPF disabled, INPT = 01 100 300
UHF_IN, INPT = 10 300 860
Analog channel PIX carrier 45.75
Digital channel center frequency 44
Source impedance =
Ω, load impedance =
75
200
Ω
Gain specification met
across these frequency
bands
RFVGC
Maximum gain, V
RFVGC
Maximum gain, V
54MHz to 860MHz
Maximum gain, V
broadcast channels
M i ni m um g ai n, V
VHF_IN 54 300
UHF_IN 300 860
= 3V (Note 1) 4.4 dB
= 3V 15
= 3V,
RFAGC
= 3V,
RFAGC
= 0.5V -11
R FA GC
At 12.5dB of gain 29
Maximum gain, V
= 3V -13
RFVGC
At 12.5dB of gain 5 11
Maximum gain, V
1dB At 12.5dB of gain, CW tone at f
69 in UHF band
VHF_IN from 150MHz to 960MHz -60
VHF_IN from 960MHz to 1400MHz -40Beats, Converted to Output
UHF_IN from 600MHz to 1400MHz -40
5MHz to 50MHz, RF input to IF output, relative to desired
channel
Measured at 91.5MHz
above desired channel’s
center frequency
5MHz to 65MHz -40
65MHz to 878MHz -40
10kHz offset -85
100kHz offset, 1.5kHz loop bandwidth -105Phase Noise (Single-Sideband)
1MHz offset, 1.5kHz loop bandwidth -125
= 3V -24.5
RFVGC
- 36MHz, tested at Ch
C
54MHz to 860MHz 70
Broadcast channels,
T
= +25°C
A
28.0 34 45.5
66
34
-3
60 dBc
MHz
MHz
dB
MHz
dBm
dBm
dBm
dBc
P-P
dBc
dBmV
dBc/Hz
MAX3540
Complete Single-Conversion Television Tuner
4 _______________________________________________________________________________________
AC ELECTRICAL CHARACTERISTICS (continued)
(MAX3540 Evaluation Kit, VCC= +3.1V to +3.5V, 75Ω system impedance, default register settings, V
RFAGC
= V
IFAGC
= +3V (minimum
attenuation), T
A
= 0°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.3V, TA= +25°C, unless otherwise noted.)
Note 1: Guaranteed by design and characterization.
IF VARIABLE-GAIN AMPLIFIER
Input Impedance Balanced 2000 Ω
Output Impedance Balanced (Note 1) 300 Ω
Passband Voltage Gain
Passband Gain Flatness 40MHz to 48MHz (Note 1) 1.2 dB
Output Voltage V
AGC Gain Slope V
Equivalent Input Voltage
Noise Density
Noise Figure Change vs.
Attenuation
IM3 V
IF OVERLOAD DETECTOR (see the IF Overload Detector section)
Output Overload Attack Point 0.7 V
Attack-Point Accuracy ±1 dB
Detector Output Voltage Range
Detector Gain 70 V/V
FREQUENCY SYNTHESIZER
REFERENCE OSCILLATOR
Frequency 4 MHz
DIVIDERS
RF N-Divider Ratio 256 32,767
RF R-Divider Ratio 8 127
LO PHASE DETECTOR AND CHARGE PUMP
Comparison Frequency 31.50 250.00 kHz
Charge-Pump Current
C har g e- P um p Thr ee- S tate C ur r ent ±5 nA
Charge-Pump Current Matching 5%
LOCAL OSCILLATOR (OSCILLATOR WITH NARROW BAND LOOP)
VCO Tuning Range Tank frequency 2160 4400 MHz
VCO Tuning Gain Tank oscillator gain 500 MHz/V
2-WIRE SERIAL INTERFACE
Clock Frequency 400 kHz
PARAMETER CONDITIONS MIN TYP MAX UNITS
Maximum gain setting,
= 3V
V
S our ce l oad = 300Ω ,
outp ut l oad = 300Ω
= 3V (Note 1) 2 V
IFAGC
= 3V to 0.5V (Note 1) 30 dB/V
IFAGC
At 44MHz, maximum gain, V
= 1.5V
OUT
Negative polarity, overload reduces V
(open collector, 0.3mA sink)
CP = 00 0.5
CP = 01 1
CP = 10 1.5
CP = 11 2
, 40dB < gain < 60dB (Note 1) -54 dBc
P-P
IFAGC
Minimum gain setting,
= 0.5V
V
IFAGC
= 3V (Note 1) 7.3 nV/√Hz
IFAGC
DET
54 56 65
0.5 3.0 V
< 0.35 dB/dB
dB
21
P-P
P-P
mA
MAX3540
Pin Description
Complete Single-Conversion Television Tuner
_______________________________________________________________________________________ 5
PIN NAME FUNCTION
1 SCL 2-Wire Serial-Clock Interface. Requires a pullup resistor to VCC.
2 SDA 2-Wire Serial-Data Interface. Requires a pullup resistor to VCC.
3, 10, 23,
28, 32, 33,
37, 41, 44
4 UHF_IN UHF RF Input. Matched to 75Ω over the operating band. Requires a DC-blocking capacitor.
5 VHF_IN VHF RF Input. Matched to 75Ω over the operating band. Requires a DC-blocking capacitor.
6 RFGND2
7 LEXT RF VGA Supply Voltage. Connect through a 270nH pullup inductor to VCC.
8 RFGND3
9RFAGCRF AG C G ai n- C ontr ol V ol tag e. Accep ts a D C vol tag e fr om 0.5V ( m i ni m um g ai n) to 3V ( m axi m um g ai n) .
11–22,
27, 31
24 IFOUT2- Inver ti ng IF- V G A Outp ut. C onnect to the i np ut of an anti - al i asi ng fi l ter . Req ui r es a D C - b l ocki ng cap aci tor .
25 IFOUT2+
26 IFAGC IF AGC Gain-Control Voltage. Accepts a DC voltage from 0.5V (minimum gain) to 3V (maximum gain).
29 IFIN- Inverting IF-VGA Input. Connect to the output of an IF-SAW filter.
30 IFIN+ Noninverting IF-VGA Input. Connect to the output of an IF-SAW filter.
34 IFOVLD IF Power Detector Open-Collector Output. Requires a 10kΩ pullup resistor to VCC.
35 IFOUT1+ N oni nver ti ng IF- LN A Outp ut. Req ui r es a D C - b l ocki ng cap aci tor .
36 IFOUT1- Inverting IF-LNA Output. Requires a DC-blocking capacitor.
38 LDO VCO LDO Bypass. Bypass to ground with a 0.47μF capacitor.
39 GND_TUNE
40 VTUNE VCO Tuning Input. Connect to the PLL loop filter output.
42 MUX Test Output. Leave this pin unconnected during normal operation.
43 CP Charge-Pump Output. Connect to the PLL loop filter input.
45 XTALN Crystal Oscillator Feedback. See the Typical Application Circuit.
46 XTALP Crystal Input. Requires a DC-blocking capacitor.
47 ADDR1
48 ADDR2
EP EP Exposed Paddle. Solder evenly to the PCB ground plane for proper operation.
V
CC
GND Ground. Connect to the PCB’s ground plane.
Power-Supply Connections. Bypass each supply pin to ground with a 1000pF capacitor.
RF Ground. Bypass to the PCB’s ground plane with a 1000pF capacitor. Do not connect RFGND2
and RFGND3 together.
RF Ground. Bypass to the PCB’s ground plane with a 1000pF capacitor. Do not connect RFGND2
and RFGND3 together.
Noninverting IF-VGA Output. Connect to the input of an anti-aliasing filter. Requires a DC-blocking
capacitor.
VTUNE Ground Connection. Connect to the PCB ground plane. All loop filter component GND must
be connected to this pin (see the Typical Application Circuit).
2-Wire Serial-Interface Address Line 1. This pin along with ADDR2 sets the device address for the
2
C-compatible serial interface.
I
2-Wire Serial-Interface Address Line 2. This pin along with ADDR1 sets the device address for the
2
C-compatible serial interface.
I
MAX3540
Complete Single-Conversion Television Tuner
6 _______________________________________________________________________________________
Detailed Description
Register Descriptions
The MAX3540 includes 11 programmable registers and
two read-only registers. The 11 programmable registers
include two N-divider registers, an R-divider register, a
VCO register, an RSSI/charge-pump/filter-select register, a control register, a shutdown register, and tracking-
filter control registers. These 11 programmable registers are also readable. The read-only registers include
a status register and a ROM table data register.
Recommended default bit settings are provided for
user convenience only and are not guaranteed. The
user must write all registers after power-up and no earlier than 100μs after power-up.
Table 1. Register Configuration
Table 2. N-DIV High Register (Address: 0000b)
REGISTER
NAME
N-DIV High Both 0x00 0 N14 N13 N12 N11 N10 N9 N8
N-DIV Low Both 0x01 N7 N6 N5 N4 N3 N2 N1 N0
R-DIV Both 0x02 0 R6 R5 R4 R3 R2 R1 R0
VCO Both 0x03 VCO4 VCO3 VCO2 VCO1 VCO0 LD VDIV1 V D IV 0
IFOVLD,
Charge
Pump, and
Filter Select
Control Both 0x05 0 0 0 0 SHDN_RF SHDN_IFAGC INPT1 IN P T0
Shutdown Both 0x06 S H D N _M IX 1 S H D N _M IX 0 S H D N _I F S H D N _P D S H D N _S Y N 0 0 0
Tracking
Filter Series
Cap
Tracking
Filter
Parallel Cap
Tracking
Filter ROM
Address
Reserved Both 0x0A X X X X X X X X
ROM Table
Data
Readback
Status Read 0x0C POR LD2 LD1 LD0 X X X X
R EA D /
W R I T E
Read 0x0B TFR7 TFR6 TFR5 TFR4 TFR3 TFR2 TFR1 TFR0
REGISTER
ADDRESS
Both 0x04 0 IFOVLD2 IFOVLD1 IFOVLD0 CP1 CP0 TF1 TF0
Both 0x07 TFS7 TFS6 TFS5 TFS4 TFS3 TFS2 TFS1 TFS0
Both 0x08 FLD 0 TFP5 TFP4 TFP3 TFP2 TFP1 TFP0
Both 0x09 0 0 0 0 TFA3 TFA2 TFA1 TFA0
MSB LSB
D7 D6 D5 D4 D3 D2 D1 D0
DATA BYTE
BIT NAME BIT LOCATION (0 = LSB)
RESERVED 7 0 Must be set to 0.
N[14:8] 6–0 001 0010
RECOMMENDED
DEFAULT
FUNCTION
Sets the most significant bits of the PLL integer divider (N). Default
integer divider value is N = 4688. N can range from 256 to 32,767.
MAX3540
Complete Single-Conversion Television Tuner
_______________________________________________________________________________________ 7
Table 4. R-DIV Register (Address: 0010b)
Table 5. VCO Register (Address: 0011b)
Table 3. N-DIV Low Register (Address: 0001b)
BIT NAME BIT LOCATION (0 = LSB)
N[7:0] 7–0 0101 0000
RECOMMENDED
DEFAULT
FUNCTION
Sets the least significant bits of the PLL integer divider (N). Default
integer divider value is N = 4688. N can range from 256 to 32,767.
BIT NAME BIT LOCATION (0 = LSB)
RESERVED 7 0 Must be set to 0.
R[6:0] 6–0 100 0000
BIT NAME BIT LOCATION (0 = LSB)
VCO[4:3] 7, 6 01
VCO[2:0] 5, 4, 3 101
LD 2 1
VDIV[1:0] 1, 0 01
RECOMMENDED
DEFAULT
Sets the PLL reference div ider (R). Default reference divider value
is R = 64. R can range from 16 to 127.
RECOMMENDED
DEFAULT
VCO select. Selects one of three possible VCOs.
00 = VCOs shut down
01 = selects VCO1
10 = selects VCO2
11 = selects VCO3
VCO sub-band select. Selects one of eight possible VCO sub-bands.
000 = selects SB0
001 = selects SB1
010 = selects SB2
011 = selects SB3
100 = selects SB4
101 = selects SB5
110 = selects SB6
111 = selects SB7
Lock-detect enable.
0 = disabled
1 = enabled
VCO divider ratio select.
00 = sets V C O d i vi d er to 4
01 = sets V C O d i vi d er to 8
10 = sets VCO divider to 16
11 = sets VCO divider to 32
FUNCTION
FUNCTION
MAX3540
Complete Single-Conversion Television Tuner
8 _______________________________________________________________________________________
Table 6. RSSI, Charge Pump, and Filter Select Register (Address: 0100b)
Table 7. Control Register (Address: 0101b)
BIT NAME BIT LOCATION (0 = LSB)
RESERVED 7 0 Must be set to 0.
IFO V LD [ 2:0] 6, 5, 4 000 Write content of ROM register OD[2:0] to this location.
CP[1:0] 3, 2 00
TF[1:0] 1, 0 00
BIT NAME BIT LOCATION (0 = LSB)
RESERVED 7–4 0000 Must be set to 0000.
SHDN_RF 3 0
SHDN_IFV
GA
INPT[1:0] 1, 0 00
2 1
RECOMMENDED
DEFAULT
RECOMMENDED
DEFAULT
FUNCTION
Selects the typical charge-pump current.
00 = 0.5mA
01 = 1mA
10 = 1.5mA
11 = 2mA
Selects the tracking filter band of operation.
00 = VHF low
01 = VHF high
10 = UHF
11 = factory use only
FUNCTION
RF shutdown.
0 = RF circuitry enabled
1 = RF circuitry disabled
IF VGA shutdown.
0 = IF VGA enab led
1 = IF VGA disabled
Select s the RF input.
00 = selects VHF_IN with LPF
01 = selects VHF_IN, no LPF
10 = select s UHF_IN
11 = factory use on l y
MAX3540
Complete Single-Conversion Television Tuner
_______________________________________________________________________________________ 9
Table 8. Shutdown Register (Address: 0110b)
Table 9. Tracking-Filter Series Cap Register (Address: 0111b)
Table 10. Tracking-Filter Parallel Cap Register (Address: 1000b)
Table 11. Tracking-Filter ROM Address Register (Address: 1001b)
Table 12. Reserved Register (Address: 1010b)
*
See the RF Tracking Filter section.
BIT NAME BIT LOCATION (0 = LSB)
SHDN_MIX 7, 6 0
SHDN_IF 5 0
SHDN_PD 4 0
SHDN_SYN 3 0
RESERVED 2, 1, 0 000 Must be set to 000.
BIT NAME BIT LOCATION (0 = LSB)
TFS[7:0] 7–0 00000000* Programs series capacitor values in the tracking filter.
RECOMMENDED
DEFAULT
RECOMMENDED
DEFAULT
FUNCTION
Mixer shutdown.
00 = mixer enabled
01, 10 = factory use only
11 = mixer disabled
IF shutdown.
0 = IF section enabled
1 = IF section disabled
IF OVLD shutdown.
0 = power detector enabled
1 = power detector disabled
Frequency synthesizer shutdown.
0 = synthesizer enabled
1 = synthesizer disabled
FUNCTION
BIT NAME BIT LOCATION (0 = LSB)
FLD 7 0
Reserved 6 0 Must be set to 0.
TFP[5:0] 5–0 000000* Programs parallel capacitor values in the tracking filter.
BIT NAME BIT LOCATION (0 = LSB)
Reserved 7–4 0000 Must be set to 0000.
TFA[3:0] 3–0 0000* Address bits of the ROM register to be read.
BIT NAME BIT LOCATION (0 = LSB)
Reserved 7–0 N/A Reserved. Do not program these bits during normal operation.
RECOMMENDED
DEFAULT
RECOMMENDED
DEFAULT
RECOMMENDED
DEFAULT
FUNCTION
Filter load bit. A 0 to 1 transition of this bit forces the loading of the
ROM table data readback register.
FUNCTION
FUNCTION
MAX3540
Complete Single-Conversion Television Tuner
10 ______________________________________________________________________________________
2-Wire Serial Interface
The MAX3540 uses a 2-wire I2C-compatible serial interface consisting of a serial-data line (SDA) and a serialclock line (SCL). SDA and SCL facilitate bidirectional
communication between the MAX3540 and the master at
clock frequencies up to 400kHz. The master initiates a
data transfer on the bus and generates the SCL signal to
permit data transfer. The MAX3540 behaves as a slave
device that transfers and receives data to and from the
master. Pull SDA and SCL high with external pullup
resistors (1kΩ or greater) for proper bus operation.
One bit is transferred during each SCL clock cycle. A
minimum of nine clock cycles is required to transfer a
byte in or out of the MAX3540 (8 data bits and an
ACK/NACK). The data on SDA must remain stable during
the high period of the SCL clock pulse. Changes in SDA
while SCL is high and stable are considered control signals (see the
START and STOP Conditions
section). Both
SDA and SCL remain high when the bus is not busy.
START and STOP Conditions
The master initiates a transmission with a START condition (S), which is a high-to-low transition on SDA while
SCL is high. The master terminates a transmission with
a STOP condition (P), which is a low-to-high transition
on SDA while SCL is high.
Acknowledge and Not-Acknowledge Conditions
Data transfers are framed with an acknowledge bit
(ACK) or a not-acknowledge bit (NACK). Both the master and the MAX3540 (slave) generate acknowledge
bits. To generate an acknowledge, the receiving device
must pull SDA low before the rising edge of the
acknowledge-related clock pulse (ninth pulse) and
keep it low during the high period of the clock pulse.
To generate a not-acknowledge condition, the receiver
allows SDA to be pulled high before the rising edge of
the acknowledge-related clock pulse, and leaves SDA
high during the high period of the clock pulse. Monitoring
the acknowledge bits allows for detection of unsuccessful
data transfers. An unsuccessful data transfer happens
if a receiving device is busy or if a system fault has
occurred. In the event of an unsuccessful data transfer,
the bus master must reattempt communication at a
later time.
Slave Address
The MAX3540 has a 7-bit slave address that must be
sent to the device following a START condition to initiate communication. The slave address is determined
by the state of the ADDR2 and ADDR1 pins and is
equal to 11000[ADDR2][ADDR1]. The 8th bit (R/W) following the 7-bit address determines whether a read or
write operation will occur. Table 15 shows the possible
address configurations.
Table 13. ROM Table Data Readback Register (Address: 1011b)
Table 14. Status Register (Address: 1100b)
Table 15. MAX3540 Address Configurations
*
See the RF Tracking Filter section.
BIT NAME BIT LOCATION (0 = LSB)
TFR[7:0] 7–0 00000000* Tracking-filter data bits read from the device’s ROM table.
BIT NAME BIT LOCATION (0 = LSB)
POR 7 0
LD[2:0] 6, 5, 4 000
Reserved 3–0 0000 Reserved.
RECOMMENDED
DEFAULT
RECOMMENDED
DEFAULT
Power-on reset.
0 = status register has been read
1 = power reset since last status register read
VCO tuning voltage indicators.
000 = PLL not in lock, tune to the next lowest sub-band
001–110 = PLL in lock
111 = PLL not in lock, tune to the next higher sub-band
ADDR2 ADDR1 WRITE ADDRESS READ ADDRESS
0 0 0xC0 0xC1
0 1 0xC2 0xC3
1 0 0xC4 0xC5
1 1 0xC6 0xC7
FUNCTION
FUNCTION
MAX3540
Complete Single-Conversion Television Tuner
______________________________________________________________________________________ 11
The MAX3540 continuously awaits a START condition
followed by its slave address. When the device recognizes its slave address, it acknowledges by pulling the
SDA line low for one clock period. It is ready to accept
or send data depending on the R/W bit (Figure 1).
Write Cycle
When addressed with a write command, the MAX3540
allows the master to write to a single register or to multiple successive registers.
A write cycle begins with the bus master issuing a
START condition followed by the 7 slave address bits
and a write bit (R/W = 0). The MAX3540 issues an ACK
if the slave address byte is successfully received. The
bus master must then send to the slave the address of
the first register it wishes to write to. If the slave
acknowledges the address, the master can then write
one byte to the register at the specified address. Data
is written beginning with the most significant bit. The
MAX3540 again issues an ACK if the data is successfully written to the register. The master can continue to
write data to the successive internal registers with the
MAX3540 acknowledging each successful transfer, or it
can terminate transmission by issuing a STOP condition. The write cycle does not terminate until the master
issues a STOP condition.
Figure 2 illustrates an example in which registers 0
through 2 are written with 0x0E, 0xD8, and 0xE1,
respectively.
Read Cycle
A read cycle begins with the bus master issuing a
START condition followed by the seven slave address
bits and a write bit (R/W = 0). The MAX3540 issues an
ACK if the slave address byte is successfully received.
The master then sends the 8-bit address of the first register that it wishes to read. The MAX3540 then issues
another ACK. Next, the master must issue a START condition followed by the 7 slave address bits and a read
bit (R/W = 1). The MAX3540 issues an ACK if it successfully recognizes its address and begins sending data
from the specified register address starting with the
most significant bit (MSB). Data is clocked out of the
MAX3540 on the rising edge of SCL. On the 9th rising
edge of SCL, the master can issue an ACK and continue reading successive registers or it can issue a NACK
followed by a STOP condition to terminate transmission.
The read cycle does not terminate until the master
issues a STOP condition. Figure 3 illustrates an example
in which registers 0 and 1 are read back.
Figure 1. MAX3540 Slave Address Byte
Figure 2. Example: Write registers 0 through 2 with 0x0E, 0xD8, and 0xE1, respectively.
Figure 3. Example: Read data from registers 0 through 1.
SLAVE ADDRESS
S 11000ADDR2 ADDR1 R/W
SDA
SCL
NOTE: TIMING PARAMETERS CONFORM WITH I
WRITE DEVICE
START
START
ADDRESS
11000[ADDR2][ADDR1] 0 — 0x00 — 0x0E — 0xD8 — 0xE1 —
WRITE DEVICE
ADDRESS
110000[ADDR2][ADDR1] 0 — 0x00 —
123456789
2
C BUS SPECIFICATIONS.
R/W ACK
R/W ACK
WRITE REGISTER
ADDRESS
WRITE 1st REGISTER
ADDRESS
ACK
WRITE DATA TO
ACK
REGISTER 0x00
WRITE DEVICE
START
ADDRESS
110000[ADDR2][ADDR1] 1 — D7–D0 — D7–D0 —
ACK
WRITE DATA TO
REGISTER 0x01
R/W ACK
ACK
READ DATA
REG 0
WRITE DATA TO
REGISTER 0x02
READ DATA
ACK
ACK
REG 1
ACK
NACK
P
STOP
STOP
MAX3540
Complete Single-Conversion Television Tuner
12 ______________________________________________________________________________________
Applications Information
RF Inputs
The MAX3540 features separate UHF and VHF inputs
that are matched to 75Ω. Both inputs require a DC-blocking capacitor. The input registers select the active inputs.
In addition, the input registers enable or disable the lowpass filter, which can be used when the VHF input is
selected. For 54MHz to 100MHz, select the VHF_IN with
the LPF filter enabled (INPT = 00). For 100MHz to
300MHz, select VHF_IN with LPF disabled (INPT = 01).
For 300MHz to 860MHz, select UHF_IN (INPT = 10).
RF Gain Control
The gain of the RF low-noise amplifier can be adjusted
over a typical 45dB range by the RFAGC pin. The
RFAGC input accepts a DC voltage from 0.5V to 3V,
with 3V providing maximum gain. This pin can be controlled with the IF power-detector output to form a
closed RF gain-control loop. See the
Closed-Loop RF
Gain Control
section for more information.
RF Tracking Filter
The MAX3540 includes a programmable tracking filter for
each band of operation to optimize rejection of out-ofband interference while minimizing insertion loss for the
desired received signal. VHF low, VHF high, or UHF tracking filter is selected by the TF register. The center fre-
quency of each tracking filter is selected by a switchedcapacitor array, which is programmed by the TFS[7:0]
bits in the Tracking-Filter Series Cap register and the
TFP[5:0] bits in the Tracking-Filter Parallel Cap register.
To accommodate part-to-part variations each part is factory-calibrated by Maxim. During calibration the y-intercept and slope for the series and parallel tracking
capacitor arrays is calculated and written into an internal
ROM table. The user must read the ROM table upon
power-up and store the data in local memory (8 bytes
total) to calculate the optimal TFS[7:0] and TFP[5:0] settings for each channel. Table 16 shows the address and
bits for each ROM table entry. See the
Interpolating
Tracking Filter Coefficients
section for more information
on how to calculate the required values.
Reading the ROM Table
Each ROM table entry must be read using a two-step
process. First, the address of the ROM bits to be read
must be programmed into the TFA[3:0] bits in the
Tracking Filter ROM Address register (Table 11).
Once the address has been programmed, the data
stored in that address is transferred to the TFR[7:0] bits
in the ROM Table Data Readback register (Table 13).
The ROM data at the specified address can then be
read from the TFR[7:0] bits and stored in the microprocessor’s local memory.
Table 16. ROM Table
DESCRIPTION ADDRESS
IFOVLD 0x0 OD2 OD1 OD0 X X X X X
VHF Low Series/
Parallel Y-Intercept
VHF High Series/
Parallel Y-Intercept
UHF Series/
Parallel Y-Intercept
VHF Low Series Slope 0x4 HS1[3] HS1[2] HS1[1] HS1[0] HP0[3] HP0[2] HP0[1] HP0[0]
VHF High Parallel Slope 0x5 HP1[3] HP1[2] HP1[1] HP1[0] US0[7] US0[6] US0[5] US0[4]
VHF Low Parallel Slope 0x6 US0[3] US0[2] US0[1] US0[0] US1[5] US1[4] US1[3] US1[2]
VHF High Parallel Slope 0x7 US1[1] US1[0] UP0[7] UP0[6] UP0[5] UP0[4] UP0[3] UP0[2]
UHF Parallel Slope 0x8 UP0[1] UP0[0] UP1[5] UP1[4] UP1[3] UP1[2] UP1[1] UP1[0]
0x1 LS0[5] LS0[4] LS0[3] LS0[2] LS0[1] LS0[0] LS1[3] LS1[2]
0x2 LS1[1] LS1[0] LP0[5] LP0[4] LP0[3] LP0[2] LP0[1] LP0[0]
0x3 LP1[3] LP1[2] LP1[1] LP1[0] HS0[3] HS0[2] HS0[1] HS0[0]
MSB LSB
DATA BYTE
D7 D6 D5 D4 D3 D2 D1 D0
MAX3540
Complete Single-Conversion Television Tuner
______________________________________________________________________________________ 13
Interpolating Tracking Filter Coefficients
The TFS[7:0] and TFP[5:0] bits must be reprogrammed
for each channel frequency to optimize performance.
The optimal settings for each channel can be calculated
from the ROM table data using the equations below.
VHF LO filter:
VHF High filter:
UHF filter:
Where:
fRF= operating frequency in MHz
TFS = decimal value of the optimal TFS[7:0]
setting (Table 9) for the given operating frequency
TFP = decimal value of the optimal TFP[5:0] setting
(Table 10) for the given operating frequency
LS0, LS1, LP0, LP1, HS0, HS1, HP0, HP1, US0, US1,
UP0, and UP1 = the decimal values of the ROM
table coefficients (Table 16).
IF Overload Detector
The MAX3541 includes a broadband IF overload detector, which provides an indication of the total power present at the RF input. The overload-detector output
voltage is compared to a reference voltage and the difference is amplified. This error signal drives an opencollector transistor whose collector is connected to the
IFOVLD pin, causing the IFOVLD pin to sink current.
The nominal full-scale current sunk by the IFOVLD pin
is 300μA. The IFOVLD pin requires a 10kΩ pullup resistor to V
CC
.
The IF overload detector is calibrated at the factory to
attack at 0.6V
P-P
at IFOUT1. Upon power-up, the baseband processor must read OD[2:0] from the ROM table
and store it in the IFVOLD register.
Closed-Loop RF Gain Control
Closed-loop RF gain control can be implemented by
connecting the IFOVLD output to the RFAGC input.
Using a 10kΩ pullup resistor on the IFOVLD pin, as
shown in the
Typical Application Circuit
, results in a
nominal 0.5V to 3V control voltage range.
VCO and VCO Divider Selection
The MAX3540 frequency synthesizer includes three VCOs
and eight VCO sub-bands to guarantee a 2160MHz to
4400MHz VCO frequency range. The frequency synthesizer also features an additional VCO frequency divider,
which must be programmed to either 4, 8, 16, or 32
through the VDIV[1:0] bits in the VCO register based on
the channel being received. Table 5 describes how the
VDIV[1:0] bits should be programmed for each band of
operation.
To ensure PLL, lock the proper VCO and VCO sub-band
for the channel being received, which must be chosen by
iteratively selecting a VCO and VCO sub-band then reading the LD[2:0] bits to determine if the PLL is locked. Any
reading from 001 to 110 indicates the PLL is locked. If
LD[2:0] reads 000, the PLL is unlocked and the selected
VCO is at the bottom of its tuning range; a lower VCO subband must be selected. If LD[2:0] reads 111, the PLL is
unlocked and the selected VCO is at the top of its tuning
range; a higher VCO sub-band must be selected. The
VCO and VCO sub-band settings should be progressively
increased or decreased until the LD[2:0] reading falls in
the 001 to 110 range.
Due to overlap between VCO sub-band frequencies, it is
possible that multiple VCO settings can be used to tune to
the same channel frequency. System performance at a
given channel should be similar between the various possible VCO settings, so it is sufficient to select the first VCO
and VCO sub-band that provides lock.
Layout Considerations
The MAX3540 EV kit can serve as a guide for PCB layout.
Keep RF signal lines as short as possible to minimize
losses and radiation. Use controlled impedance on all
high-frequency traces. The exposed paddle must be soldered evenly to the board’s ground plane for proper
operation. Use abundant vias beneath the exposed paddle for maximum heat dissipation. Use abundant ground
vias between RF traces to minimize undesired coupling.
⎣
⎦
⎡
TFS 10 (2.4
=+×+−+××
TFP INT 10
=
LS0
⎢
⎣
⎡
[(1.6
⎢
⎢
⎢
0.6)
64
LP0
0.4)
+×+−+×(6 ))f 10 ]
64
(.85
LS1
16
LP1
16
2) f
2
RF 1
××
RF
⎤
-3
⎥
×
00
⎦
⎤
-3
⎥
⎥
⎥
⎤
-3
⎥
−
⎥
⎥
⎦
⎤
-3
⎥
−
⎥
⎥
⎦
⎤
-3
⎥
−
20
⎥
⎥
⎦
⎤
-3
⎥
⎥
⎥
⎦
TFS INT 10
=
TFP INT 10
=
TFS INT 10
TFP INT 10
=
⎡
⎢
⎢
⎢
⎣
⎡
⎢
⎢
⎢
⎣
=
⎡
⎢
⎢
⎢
⎣
HS0
⎡
⎢
⎢
⎢
⎣
[(2.8
[(1.6
[(3
[(1.6
0.8)
+×+−+×(.42 ×××
16
HP0
0.8)
+×+−+×(.15 00.6 ) f 10 ]
16
US0
)
++−+××(.26 f 10 ]
256
UP0
0.8)
+×+−+(.14
256
US1
64
HS1
16
HP1
16
UP1
6
0.8 )
44
0.8 )
0.8 ) f 10 ]
×××
f10]
RF
××
RF
×
RF
RF
20
10
−
10
MAX3540
Complete Single-Conversion Television Tuner
14 ______________________________________________________________________________________
Typical Application Circuit
To minimize coupling between different sections of the
IC, the ideal power-supply layout is a star configuration, which has a large decoupling capacitor at the
central VCCnode. The VCCtraces branch out from this
node, with each trace going to separate VCCpins of
the MAX3540. Each VCCpin must have a bypass
capacitor with a low impedance to ground at the frequency of interest. Do not share ground vias among
multiple connections to the PCB ground plane.
22pF
ADDRESS1
V
CC
ADDRESS2
ADDR2
ADDR1
2.7kΩ2.7kΩ
SCL
SDA
V
UHF_IN
VHF_IN
RFGND2
LEXT
RFGND3
RFAGC
V
GND
GND
1
2
CC
3
4
5
6
7
8
9
CC
10
11
12
1000pF
IFOVLD
1000pF
SCLK
V
CC
SDATA
100Ω
1000pF
V
CC
1000pF
1000pF
V
CC
470nF
2.7Ω
0.1μF
100pF
XTALP
SERIAL
INTERFACE
1000pF
100pF
XTALN
÷
270Ω
CC
470pF
*
LDO
GND_TUNE
+
-
1000pF
47μF
V
CC
1000pF
1000pF
CC
V
IFOUT1-
36
IFOUT1+
35
IFOVLD
34
V
CC
33
V
CC
32
GND
31
V
REF
IFIN+
30
IFIN-
29
V
CC
28
GND
27
IFAGC
26
IFOUT2+
25
SAW
DRIVER
AMPLIFIER
V
CC
10kΩ
V
CC
1000pF
2.2pF
2.7kΩ
0.1μF
4700pF
R
1.3kΩ
**
0.033μF
VCCCP
4445
PD CP
÷
N
V
CC
1000pF
MUX
VCO
DIVIDER
V
*
CC
V
VTUNE
40414243 39 38 37464748
MAX3540
EP
680nH
IF-SAW
V
FILTER
IFAGC
0.1μF
IFOVLD
V
CC
1000pF
V
CC
1000pF
16 21201918 22 23 24151413
17
CC
GND
V
GND
CC
V
IFOUT2-
1000pF
ANTI-ALIASING
FILTER
*CONNECT TO COMMON GROUND POINT AT PIN 39.
GND
GND
GND
GND
GND
GND
GND
GND
IFOUT+
IFOUT-
MAX3540
Complete Single-Conversion Television Tuner
______________________________________________________________________________________ 15
Package Information
(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information
go to www.maxim-ic.com/packages
.)
48L LGA.EPS
MAX3540
Complete Single-Conversion Television Tuner
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
16
____________________Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600
© 2007 Maxim Integrated Products is a registered trademark of Maxim Integrated Products, Inc.
Package Information (continued)
(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information
go to www.maxim-ic.com/packages
.)
Loading...
