General Description

The MAX13042E–MAX13045E 4-channel, bidirectional level translators provide the level shifting necessary for 100Mbps data transfer in multivoltage systems. The MAX13042E–MAX13045E are ideally suited for level translation in systems with four channels. Externally applied voltages, VCCand VL, set the logic levels on either side of the device. Logic signals present on the VLside of the device appear as a high-voltage logic signal on the VCCside of the device and vice-versa.

The MAX13042E–MAX13045E operate at full speed with external drivers that source as little as 4mA output current or larger. Each input/output (I/O) channel is pulled up to V

or VLby an internal 30µA current source, allowing the MAX13042E–MAX13045E to be driven by either push-pull or open-drain drivers.

The MAX13042E–MAX13045E feature an enable (EN) input that places the devices into a low-power shutdown mode when driven low. The MAX13042E–MAX13045E feature an automatic shutdown mode that disables the part when VCCis less than VL. The state of I/O V

CC_

and I/O VL_during shutdown is chosen by selecting the appropriate part version. (See the Ordering Information/ Selector Guide).

The MAX13042E–MAX13045E operate with VCCvoltages from +2.2V to +3.6V and VLvoltages from +1.62V to +3.2V, making them ideal for data transfer between low-voltage ASIC/PLDs and higher voltage systems. The MAX13042E–MAX13045E are available in 12-bump UCSP™ (1.54mm x 2.12mm) and 14-pin TDFN (3mm x 3mm) packages, and operate over the extended -40°C to +85°C temperature range.

Applications

Features

♦ Compatible with 4mA Input Drivers or Larger

♦ 100Mbps Guaranteed Data Rate

♦ Four Bidirectional Channels

♦ Enable Input

♦ ±15kV ESD Protection on I/O V

CC_

Lines

♦ +1.62V ≤ VL≤ +3.2V and +2.2V ≤ VCC≤ +3.6V

Supply Voltage Range

♦ 12-Bump UCSP (1.54mm x 2.12mm) and

14-Pin TDFN (3mm x 3mm) Lead-Free Packages

MAX13042E–MAX13045E

1.62V to 3.6V Improved High-Speed LLT

________________________________________________________________ Maxim Integrated Products 1

19-0792; Rev 0; 4/07

For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at 1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.

Ordering Information/Selector Guide

GND GND GND

+1.8V

SYSTEM

CONTROLLER

+3.3V

SYSTEM

I/O V

CC_

DATA

+3.3V

+1.8V

1µF

0.1µF

MAX13042E–

MAX13045E

Typical Operating Circuit

PART

PINPACKAGE

I/O VL_ STATE DURING

SHUTDOWN

I/O V

CC_

STATE DURING

SHUTDOWN

TOP

PKG CODE

MAX13042EEBC+T

12 UCSP-12 High Impedance High Impedance

B12-3

MAX13042EETD+T

High Impedance High Impedance ADE T1433-2

Note: All devices operate over the -40°C to +85°C temperature range. +Denotes a lead-free package.

*Future product—contact factory for availability. **EP = Exposed paddle.

Pin Configurations appear at end of data sheet.

UCSP is a trademark of Maxim Integrated Products, Inc. SPI is a trademark of Motorola, Inc. MICROWIRE is a trademark of National Semiconductor Corp.

Ordering Information/Selector Guide continued at end of data sheet.

CMOS Logic-Level Translation

Low-Voltage ASIC Level Translation

Cell Phones

SPI™, MICROWIRE™ Level Translation

Portable POS Systems

Portable Communication Devices

GPS

Telecommunications Equipment

14 TDFN-EP**

MARK

ADQ

MAX13042E–MAX13045E

1.62V to 3.6V Improved High-Speed LLT

2 _______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

(All voltages referenced to GND.) V

, VL.....................................................................-0.3V to +4V

I/O V

CC_

..................................................... -0.3V to (VCC+ 0.3V)

I/O V

...........................................................-0.3V to (VL+ 0.3V)

EN.............................................................................-0.3V to +4V

Short-Circuit Duration I/O V

, I/O V

CC_

to GND .......Continuous

Continuous Power Dissipation (T

= +70°C)

12-Bump UCSP (derate 6.5mW/°C above +70°C) ......519mW

14-Pin TDFN (derate 24.4mW/°C above +70°C) .......1951mW

Operating Temperature Range ...........................-40°C to +85°C

Storage Temperature Range .............................-65°C to +150°C

Junction Temperature......................................................+150°C

Lead Temperature (soldering, 10s) .................................+300°C

ELECTRICAL CHARACTERISTICS

(VCC= +2.2V to +3.6V, VL= +1.62V to +3.2V, EN = VL, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.3V, V

= +1.8V, and TA= +25°C.) (Notes 1, 2)

PARAMETER

CONDITIONS MIN TYP

UNITS

POWER SUPPLIES

VL Supply Range V

1.62 3.2 V

VCC Supply Range V

2.2 3.6 V

Supply Current from V

QVCC

I/O V

CC_

= VCC, I/O VL_ = V

25 µA

Supply Current from V

QVL

I/O V

CC_

= VCC, I/O VL_ = V

10 µA

VCC Shutdown Supply Current

TA = +25°C, EN = GND 0.1 1 µA

TA = +25°C, EN = GND 0.1 1

VL Shutdown-Mode Supply Current

SHDN-VL

TA = +25°C, EN = VL, VCC = GND 0.1 4

µA

I/O V

CC_

, I/O VL_ Tri-State

Leakage Current

LEAK

TA = +25°C, EN = GND 0.1 2 µA

EN Input Leakage Current I

LEAK_ENTA

= +25°C1µA

VL - VCC Shutdown Threshold High

TH_H

VCC rising (Note 3) 0

0.8 V

VL - VCC Shutdown Threshold Low

TH_L

VCC falling (Note 3) 0

0.8 V

I/O V

CC_

Pulldown Resistance

During Shutdown

MAX13043E/MAX13045E 10 16.5 23 kΩ

I/O VL_ Pulldown Resistance During Shutdown

MAX13044E/MAX13045E 10 16.5 23 kΩ

I/O VL_ Pullup Current I

VL_PU_

I/O VL_ = GND, I/O V

CC_

= GND 20 65 µA

I/O V

CC_

Pullup Current I

VCC_PU_

I/O V

CC_

= GND, I/O V

= GND 20 65 µA

I/O V

to I/O V

CC_

Resistance

(Note 4) 3 kΩ

SYMBOL

MAX

SHDN-VCC

VCC_PD_SD

VL_PD_SD

IOVL_IOVCC

0.1V

0.12V

MAX13042E–MAX13045E

1.62V to 3.6V Improved High-Speed LLT

_______________________________________________________________________________________ 3

PARAMETER

SYMBOL

CONDITIONS MIN TYP

MAX

UNITS

ESD PROTECTION

I/O VL_, EN Human Body Model ±2 kV

Human Body Model, C

VCC

= 1µF ±15

IEC 61000-4-2 Air-Gap Discharge, C

VCC

= 1µF

±15

I/O V

CC_

IEC 61000-4-2 Contact Discharge, C

VCC

= 1µF

±8

LOGIC LEVELS

I/O VL_ Input-Voltage High Threshold

IHL

(Note 5)

I/O VL_ Input-Voltage Low Threshold

ILL

(Note 5) 0.15 V

I/O V

CC_

Input-Voltage High

Threshold

IHC

(Note 5)

0.4

I/O V

CC_

Input-Voltage Low

Threshold

ILC

(Note 5) 0.2 V

EN Input-Voltage-High Threshold

EN Input-Voltage-Low Threshold

0.4 V

I/O VL_ Output-Voltage High V

OHL

I/O VL_ source current = 20µA

I/O VL_ Output-Voltage Low V

OLL

I/O V

CC_

Output-Voltage High V

OHC

I/O V

CC_

source current = 20µA

I/O V

CC_

Output-Voltage Low V

OLC

I/O V

C C _

si nk cur r ent = 20µA,

I/O V

L _

< 0.15V

RISE-/FALL-TIME ACCELERATOR STAGE

On falling edge 3.5

Accelerator Pulse Duration

On rising edge 3.5

VL = 1.62V 24

VL Output Accelerator Source Impedance

= 3.2V 11

Ω

VCC = 2.2V 13

VCC Output Accelerator Source Impedance

= 3.6V 9

Ω

VL = 1.62V 14

VL Output Accelerator Sink Impedance

= 3.2V 10

Ω

VCC = 2.2V 11

VCC Output Accelerator Sink Impedance

= 3.6V 9

Ω

ELECTRICAL CHARACTERISTICS (continued)

(VCC= +2.2V to +3.6V, VL= +1.62V to +3.2V, EN = VL, TA= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.3V, V

= +1.8V, and TA= +25°C.) (Notes 1, 2)

I/O V

si nk cur r ent = 20µA, I/O V

L _

C C _

VL - 0.2

VL - 0.4

2/3 V

< 0.2V 1/3 V

2/3 V

1/3 V

MAX13042E–MAX13045E

1.62V to 3.6V Improved High-Speed LLT

4 _______________________________________________________________________________________

PARAMETER

CONDITIONS

UNITS

I/O V

CC_

Rise Time t

RVCC

Figure 1 2.5 ns

I/O V

CC_

Fall Time t

FVCC

Figure 1 2.5 ns

I/O VL_ Rise Time t

RVL

Figure 2 2.5 ns

I/O VL_ Fall Time t

FVL

Figure 2 2.5 ns

Propagation Delay (Driving I/O V

)

Figure 1 6.5 ns

Propagation Delay (Driving I/O V

CC_

)

Figure 2 6.5 ns

Channel-to-Channel Skew t

SKEW

(Note 4) 0.7 ns

to I/O V

CC_

after EN

Figure 3 5 µs

Propagation Delay From I/O V

CC_

to I/O VL_ after EN

EN-VL

Figure 3 5 µs

Maximum Data Rate Push-pull operation

Mbps

TIMING CHARACTERISTICS

(+2.2V ≤ VCC≤ +3.6V, +1.62V ≤ VL≤ +3.2V; C

IOVL_

≤ 15pF, C

IOVCC_

≤ 10pF; R

SOURCE

< 150Ω, rise/fall time < 3ns, EN = VL,

= -40°C to +85°C, unless otherwise noted. Typical values are at VCC= +3.3V, VL= +1.8V, and TA= +25°C.) (Notes 1, 2)

Note 1: All units are 100% production tested at T

= +25°C. Limits over the operating temperature range are guaranteed by

correlation and design and not production tested.

Note 2: V

must be less than or equal to VCCduring normal operation. However, VLcan be greater than VCCduring startup and

shutdown conditions.

Note 3: When V

is below VLby more than the VL- VCCshutdown threshold, the device turns off its pullup generators and the I/Os

enter their respective shutdown states.

Note 4: Guaranteed by design. Note 5: Input thresholds are referenced to the boost circuit.

Typical Operating Characteristics

(VCC= 3.3V, VL= 1.8V, C

IOVCC_

= 10pF, C

IOVL_

= 15pF, R

SOURCE

= 150Ω, data rate = 100Mbps, push-pull driver, TA= +25°C,

unless otherwise noted.)

350

360

380

370

390

400

2.2 2.62.4 2.8 3.0 3.2

VL SUPPLY CURRENT vs. VCC SUPPLY

VOLTAGE (DRIVING ONE I/O V

)

MAX13042E toc01

VCC SUPPLY VOLTAGE (V)

SUPPLY CURRENT (µA)

340

330

320

310

300

3.4 3.6

1.6 2.42.0 2.8 3.2

VL SUPPLY CURRENT vs. VL SUPPLY

VOLTAGE (DRIVING ONE I/O V

CC_

)

MAX13042E toc02

VL SUPPLY VOLTAGE (V)

SUPPLY CURRENT (mA)

VCC = 3.6V

2.2 2.8 3.0 3.2

VCC SUPPLY CURRENT vs. VCC SUPPLY

VOLTAGE (DRIVING ONE I/O V

)

MAX13042E toc03

VL SUPPLY VOLTAGE (V)

SUPPLY CURRENT (mA)

2.4

2.6 3.4

3.6

SYMBOL

PVL-VCC

PVCC-VL

MIN TYP MAX

Propagation Delay From I/O V

EN-VCC

100

MAX13042E–MAX13045E

1.62V to 3.6V Improved High-Speed LLT

_______________________________________________________________________________________ 5

Typical Operating Characteristics (continued)

(VCC= 3.3V, VL= 1.8V, C

IOVCC_

= 10pF, C

IOVL_

= 15pF, R

SOURCE

= 150Ω, data rate = 100Mbps, push-pull driver, TA= +25°C,

unless otherwise noted.)

VCC SUPPLY CURRENT vs. VL SUPPLY VOLTAGE

(DRIVING ONE I/O V

VL SUPPLY VOLTAGE (V)

SUPPLY CURRENT (mA)

MAX13042E toc04

1.6 2.0 2.4 2.8 3.2

VCC = 3.6V

SUPPLY CURRENT vs. TEMPERATURE

(DRIVING ONE I/O V

CC_

)

TEMPERATURE (°C)

SUPPLY CURRENT (mA)

MAX13042E toc05

-40 -15 10 35 60 85

VCC

-40 35

SUPPLY CURRENT vs. TEMPERATURE

(DRIVING ONE I/O V

)

MAX13042E toc06

TEMPERATURE (°C)

SUPPLY CURRENT (mA)

VCC

-15

CAPACITIVE LOAD (pF)

SUPPLY CURRENT (µA)

MAX13042E toc07

10 15 20 25 30 35 40

1000

2000

3000

4000

5000

VL SUPPLY CURRENT vs. CAPACITIVE

LOAD ON I/O V

(DRIVING ONE I/O V

CC_

)

SUPPLY CURRENT vs. CAPACITIVE

LOAD ON I/O V

CC_

(DRIVING ONE I/O VL_)

CAPACITIVE LOAD (pF)

SUPPLY CURRENT (mA)

MAX13042E toc08

10 15 20 25 30 35 40

CAPACITIVE LOAD (pF)

RISE/FALL TIME (ns)

MAX13042E toc09

10 15 20 25 30 35 40

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

RISE/FALL TIME vs. CAPACITIVE LOAD ON

I/O V

CC_

(DRIVING I/O VL_)

RVCC

FVCC

CAPACITIVE LOAD (pF)

RISE/FALL TIME (ns)

MAX13042E toc10

10 15 20 25 30 35 40

0.5

1.0

1.5

2.0

2.5

3.0

RISE/FALL TIME vs. CAPACITIVE LOAD ON

I/O V

(DRIVING I/O V

CC_

)

FVL

RVL

PROPAGATION DELAY vs. CAPACITIVE

LOAD ON I/O V

CC_

(DRIVING I/O VL_)

CAPACITIVE LOAD (pF)

PROPAGATION DELAY (ns)

MAX13042E toc11

10 15 20 25 30 35 40

1.0

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

PHL

PLH

2.0

3.5

3.0

4.5

5.0

10 25 30

PROPAGATION DELAY vs. CAPACITIVE

LOAD ON I/O V

(DRIVING I/O V

CC_

)

MAX13042E toc12

CAPACITIVE LOAD (pF)

PROPAGATION DELAY (ns)

20 35

4.0

2.5

1.5

1.0

0.5

PHL

PLH
