GENERAL DESCRIPTION

The DS31256 Envoy is a 256-channel HDLC controller capable of handling up to 64 T1 or E1 data streams or two T3 data streams. Each of the 16 physical ports can handle one, two, or four T1 or E1 data streams. The Envoy is composed of the following blocks: Layer 1, HDLC processing, FIFO, DMA, PCI bus, and local bus.

There are 16 HDLC engines (one for each port) that are each capable of operating at speeds up to 8.192Mbps in channelized mode and up to 10Mbps in unchannelized mode. The Envoy also has three fast HDLC engines that only reside on Ports 0, 1, and 2. They are capable of operating at speeds up to 52Mbps.

APPLICATIONS

Channelized and Clear-Channel

(Unchannelized) T1/E1 and T3/E3 Routers with Multilink PPP Support High-Density Frame-Relay Access xDSL Access Multiplexers (DSLAMs) Triple HSSI High-Density V.35 SONET/SDH EOC/ECC Termination

ORDERING INFORMATION

PART TEMP RANGE PIN-PACKAGE

DS31256 0°C to +70°C

256 PBGA

DEMO KIT AVAILABLE

DS31256 Envoy

256-Channel, High-Throughput

HDLC Controlle

FEATURES

§ 256 Independent, Bidirectional HDLC channels

§ Up to 132Mbps Full-Duplex Throughput

§ Supports Up to 64 T1 or E1 Data Streams

§ 16 Physical Ports (16 Tx and 16 Rx) That

Can Be Independently Configured for Channelized or Unchannelized Operation

§ Three Fast (52Mbps) Ports; Other Ports Capable of Speeds Up to 10Mbps (Unchannelized)

§ Channelized Ports Can Each Handle One, Two, or Four T1 or E1 Lines

§ Per-Channel DS0 Loopbacks in Both Directions

§ Over-Subscription at the Port Level

§ Transparent Mode Supported

§ On-Board Bit Error-Rate Tester (BERT)

with Automatic Error Insertion Capability

§ BERT function Can Be Assigned to Any HDLC Channel or Any Port

§ Large 16kB FIFO in Both Receive and Transmit Directions

§ Efficient Scatter/Gather DMA Maximizes Memory Efficiency

§ Receive Data Packets are Time-Stamped

§ Transmit Packet Priority Setting

§ V.54 Loopback Code Detector

§ Local Bus Allows for PCI Bridging or Local

Access

§ Intel or Motorola Bus Signals Supported

§ Backward Compatibility with DS3134

§ 33MHz 32-Bit PCI (V2.1) Interface

§ 3.3V Low-Power CMOS with 5V Tolerant

I/O

§ JTAG Support IEEE 1149.1

§ 256-Pin Plastic BGA (27mm x 27mm)

Features continued on page 6.
