Rainbow Electronics DS26503 User Manual

www.maxim-ic.com

GENERAL DESCRIPTION

The DS26503 is a building-integrated timingsupply (BITS) clock-recovery element. The receiver portion can recover a clock from T1, E1, and 6312kHz synchronization timing interfaces. In T1 and E1 modes, the Synchronization Status Message (SSM) can also be recovered. The transmit portion can directly interface to T1 or E1 interfaces as well as source the SSM in T1 and E1 modes. The DS26503 can translate between any of the supported inbound synchronization clock rates to any supported outbound rate. A separate output is provided to source a 6312kHz clock. The device is controlled through a parallel, serial, or hardware controller port.

APPLICATIONS

BITS Timing Rate Conversion Basic Transceiver

ORDERING INFORMATION

PART TEMP RANGE PIN-PACKAGE

DS26503L 0°C to +70°C 64 LQFP

DS26503LN -40°C to +85°C 64 LQFP

DS26503

T1/E1/J1 BITS Element

FEATURES

§ G.703 2048kHz Synchronization Interface

Compliant

§ G.703 6312kHz Japanese Synchronization

Interface Compliant

§ Interfaces to Standard T1/J1 (1.544MHz) and

E1 (2.048MHz)

§ Interface to CMI-Coded T1/J1 and E1

§ Short- and Long-Haul Line Interface

§ Transmit and Receive T1 and E1 SSM

Messages with Message Validation

§ Crystal-Less Jitter Attenuator with Bypass

Mode

§ Fully Independent Transmit and Receive

Functionality

§ Internal Software-Selectable Receive- and

Transmit-Side Termination for 75Ω/100Ω/110Ω/120Ω

§ Monitor Mode for Bridging Applications

§ Accepts 16.384MHz, 8.192MHz, 4.096MHz,

2.048MHz, or 1.544MHz (T1 Only) Master Clock

§ 8-Bit Parallel Control Port, Multiplexed or

Nonmultiplexed, Intel or Motorola

§ Serial (SPI) Control Port

§ Hardware Control Mode

§ Provides LOS, AIS, and LOF Indications

Through Hardware Output Pins

§ Fast Transmitter-Output Disable Through

Device Pin for Protection Switching

§ IEEE 1149.1 JTAG Boundary Scan

§ 3.3V Supply with 5V-Tolerant Inputs and

Outputs

Note: Some revisions of this device may incorporate deviations from published specifications known as errata. Multiple revisions of any device may be simultaneously available through various sales channels. For information about device errata, click here: www.maxim-ic.com/errata

1 of 123

REV: 070904

DS26503 T1/E1/J1 BITS Element

TABLE OF CONTENTS

1. FEATURES.......................................................................................................................7

1.1 GENERAL ........................................................................................................................7

1.2 LINE INTERFACE ...............................................................................................................7

1.3 J

1.4 F

1.5 TEST AND DIAGNOSTICS ...................................................................................................8

1.6 CONTROL PORT ...............................................................................................................8

2. SPECIFICATIONS COMPLIANCE ...................................................................................9

3. BLOCK DIAGRAMS .......................................................................................................12

4. PIN FUNCTION DESCRIPTION .....................................................................................15

4.1 TRANSMIT PLL...............................................................................................................15

4.2 TRANSMIT SIDE..............................................................................................................15

4.3 RECEIVE SIDE................................................................................................................16

4.4 CONTROLLER INTERFACE................................................................................................17

4.5 JTAG ...........................................................................................................................21

4.6 LINE INTERFACE .............................................................................................................21

4.7 POWER .........................................................................................................................22

ITTER ATTENUATOR ........................................................................................................7

RAMER/FORMATTER .......................................................................................................8

5. PINOUT...........................................................................................................................23

6. HARDWARE CONTROLLER INTERFACE....................................................................26

6.1 TRANSMIT CLOCK SOURCE .............................................................................................26

6.2 INTERNAL TERMINATION..................................................................................................26

6.3 LINE BUILD-OUT.............................................................................................................27

6.4 RECEIVER OPERATING MODES........................................................................................27

6.5 TRANSMITTER OPERATING MODES ..................................................................................28

6.6 MCLK PRE-SCALER ......................................................................................................28

6.7 OTHER HARDWARE CONTROLLER MODE FEATURES .........................................................29

7. PROCESSOR INTERFACE............................................................................................30

7.1 PARALLEL PORT FUNCTIONAL DESCRIPTION.....................................................................30

7.2 SPI SERIAL PORT INTERFACE FUNCTIONAL DESCRIPTION .................................................30

7.2.1 Clock Phase and Polarity ................................................................................................... 30

7.2.2 Bit Order............................................................................................................................. 30

7.2.3 Control Byte ....................................................................................................................... 30

7.2.4 Burst Mode......................................................................................................................... 30

7.2.5 Register Writes................................................................................................................... 31

7.2.6 Register Reads ..................................................................................................................31

7.3 REGISTER MAP ..............................................................................................................32

7.3.1 Power-Up Sequence .......................................................................................................... 34

7.3.2 Test Reset Register............................................................................................................ 34

7.3.3 Mode Configuration Register.............................................................................................. 35

7.4 I

7.5 S

NTERRUPT HANDLING ....................................................................................................38

TATUS REGISTERS .......................................................................................................38

7.6 INFORMATION REGISTERS ...............................................................................................39

7.7 I

NTERRUPT INFORMATION REGISTERS ..............................................................................39

2 of 123

DS26503 T1/E1/J1 BITS Element

8. T1 FRAMER/FORMATTER CONTROL REGISTERS ....................................................40

8.1 T1 C

ONTROL REGISTERS ...............................................................................................40

9. E1 FRAMER/FORMATTER CONTROL REGISTERS....................................................46

9.1 E1 CONTROL REGISTERS ...............................................................................................46

9.2 E1 I

NFORMATION REGISTERS..........................................................................................48

10. I/O PIN CONFIGURATION OPTIONS ............................................................................52

11. T1 SYNCHRONIZATION STATUS MESSAGE ..............................................................55

11.1 T1 BIT-ORIENTED CODE (BOC) CONTROLLER ................................................................55

11.2 TRANSMIT BOC.............................................................................................................55

11.3 RECEIVE BOC...............................................................................................................56

12. E1 SYNCHRONIZATION STATUS MESSAGE..............................................................64

12.1 S

12.2 A

A/SI BIT ACCESS BASED ON CRC4 MULTIFRAME...........................................................64

LTERNATE SA/SI BIT ACCESS BASED ON DOUBLE-FRAME...............................................74

13. LINE INTERFACE UNIT (LIU) ........................................................................................77

13.1 LIU OPERATION ............................................................................................................78

13.2 LIU RECEIVER ..............................................................................................................78

13.2.1 Receive Level Indicator...................................................................................................... 78

13.2.2 Receive G.703 Section 10 Synchronization Signal............................................................. 79

13.2.3 Monitor Mode ..................................................................................................................... 79

13.3 LIU TRANSMITTER .........................................................................................................79

13.3.1 Transmit Short-Circuit Detector/Limiter............................................................................... 80

13.3.2 Transmit Open-Circuit Detector.......................................................................................... 80

13.3.3 Transmit BPV Error Insertion.............................................................................................. 80

13.3.4 Transmit G.703 Section 10 Synchronization Signal (E1 Mode) .......................................... 80

13.4 MCLK PRE-SCALER......................................................................................................80

13.5 JITTER ATTENUATOR......................................................................................................80

13.6 CMI (CODE MARK INVERSION) OPTION ...........................................................................81

13.7 LIU CONTROL REGISTERS .............................................................................................82

13.8 R

ECOMMENDED CIRCUITS ..............................................................................................90

13.9 COMPONENT SPECIFICATIONS ........................................................................................92

14. LOOPBACK CONFIGURATION.....................................................................................96

15. 6312KHZ SYNCHRONIZATION INTERFACE................................................................97

15.1 R

15.2 T

ECEIVE 6312KHZ SYNCHRONIZATION INTERFACE OPERATION ........................................97

RANSMIT 6312KHZ SYNCHRONIZATION INTERFACE OPERATION.......................................97

16. JTAG BOUNDARY SCAN ARCHITECTURE AND TEST ACCESS PORT ...................98

16.1 INSTRUCTION REGISTER...............................................................................................102

16.2 T

EST REGISTERS.........................................................................................................103

16.3 BOUNDARY SCAN REGISTER.........................................................................................103

16.4 B

16.5 I

YPASS REGISTER ......................................................................................................103

DENTIFICATION REGISTER............................................................................................103

3 of 123

DS26503 T1/E1/J1 BITS Element

17. FUNCTIONAL TIMING DIAGRAMS .............................................................................106

17.1 P

17.1.1 Parallel Port Mode............................................................................................................ 106

17.1.2 SPI Serial Port Mode........................................................................................................ 106

ROCESSOR INTERFACE ...............................................................................................106

18. OPERATING PARAMETERS.......................................................................................109

19. AC TIMING PARAMETERS AND DIAGRAMS ............................................................111

19.1 MULTIPLEXED BUS.......................................................................................................111

19.2 NONMULTIPLEXED BUS ................................................................................................114

19.3 SERIAL BUS ................................................................................................................117

19.4 RECEIVE SIDE AC CHARACTERISTICS ...........................................................................119

19.5 TRANSMIT SIDE AC CHARACTERISTICS .........................................................................121

20. REVISION HISTORY ....................................................................................................122

21. PACKAGE INFORMATION ..........................................................................................123

4 of 123

DS26503 T1/E1/J1 BITS Element

LIST OF FIGURES

Figure 3-1. Block Diagram..................................................................................................................... 12

Figure 3-2. Loopback Mux Diagram....................................................................................................... 13

Figure 3-3. Transmit PLL Clock Mux Diagram....................................................................................... 13

Figure 3-4. Master Clock PLL Diagram.................................................................................................. 14

Figure 13-1. Basic Network Connection................................................................................................. 77

Figure 13-2. Typical Monitor Application................................................................................................ 79

Figure 13-3. CMI Coding ....................................................................................................................... 81

Figure 13-4. Basic Interface................................................................................................................... 90

Figure 13-5. Protected Interface Using Internal Receive Termination.................................................... 91

Figure 13-6. E1 Transmit Pulse Template ............................................................................................. 93

Figure 13-7. T1 Transmit Pulse Template.............................................................................................. 93

Figure 13-8. Jitter Tolerance (T1 Mode) ................................................................................................ 94

Figure 13-9. Jitter Tolerance (E1 Mode) ................................................................................................ 94

Figure 13-10. Jitter Attenuation (T1 Mode) ............................................................................................ 95

Figure 13-11. Jitter Attenuation (E1 Mode) ............................................................................................ 95

Figure 16-1. JTAG Functional Block Diagram........................................................................................ 98

Figure 16-2. TAP Controller State Diagram ......................................................................................... 101

Figure 17-1. SPI Serial Port Access, Read Mode, CPOL = 0, CPHA = 0............................................. 106

Figure 17-2. SPI Serial Port Access, Read Mode, CPOL = 1, CPHA = 0............................................. 106

Figure 17-3. SPI Serial Port Access, Read Mode, CPOL = 0, CPHA = 1............................................. 106

Figure 17-4. SPI Serial Port Access, Read Mode, CPOL = 1, CPHA = 1............................................. 107

Figure 17-5. SPI Serial Port Access, Write Mode, CPOL = 0, CPHA = 0 ............................................. 107

Figure 17-6. SPI Serial Port Access, Write Mode, CPOL = 1, CPHA = 0 ............................................. 107

Figure 17-7. SPI Serial Port Access, Write Mode, CPOL = 0, CPHA = 1 ............................................. 108

Figure 17-8. SPI Serial Port Access, Write Mode, CPOL = 1, CPHA = 1 ............................................. 108

Figure 19-1. Intel Bus Read Timing (BTS = 0 / BIS[1:0] = 00)............................................................. 112

Figure 19-2. Intel Bus Write Timing (BTS = 0 / BIS[1:0] = 00).............................................................. 112

Figure 19-3. Motorola Bus Timing (BTS = 1 / BIS[1:0] = 00)................................................................ 113

Figure 19-4. Intel Bus Read Timing (BTS = 0 / BIS[1:0] = 01).............................................................. 115

Figure 19-5. Intel Bus Write Timing (BTS = 0 / BIS[1:0] = 01).............................................................. 115

Figure 19-6. Motorola Bus Read Timing (BTS = 1 / BIS[1:0] = 01)....................................................... 116

Figure 19-7. Motorola Bus Write Timing (BTS = 1 / BIS[1:0] = 01)....................................................... 116

Figure 19-8. SPI Interface Timing Diagram, CPHA = 0, BIS[1:0] = 10 ................................................. 118

Figure 19-9. SPI Interface Timing Diagram, CPHA = 1, BIS[1:0] = 10 ................................................. 118

Figure 19-10. Receive Timing, T1/E1 .................................................................................................. 120

Figure 19-11. Transmit Timing, T1/E1 ................................................................................................. 122

5 of 123

DS26503 T1/E1/J1 BITS Element

LIST OF TABLES

Table 2-1. T1-Related Telecommunications Specifications...................................................................... 9

Table 2-2. E1-Related Telecommunications Specifications ................................................................... 10

Table 5-1. LQFP Pinout......................................................................................................................... 23

Table 6-1. Transmit Clock Source ......................................................................................................... 26

Table 6-2. Internal Termination.............................................................................................................. 26

Table 6-3. E1 Line Build-Out ................................................................................................................. 27

Table 6-4. T1 Line Build-Out.................................................................................................................. 27

Table 6-5. Receive Path Operating Mode.............................................................................................. 27

Table 6-6.Transmit Path Operating Mode.............................................................................................. 28

Table 6-7. MCLK Pre-Scaler for T1 Mode.............................................................................................. 28

Table 6-8. MCLK Pre-Scaler for E1 Mode ............................................................................................. 29

Table 6-9. Other Operational Modes ..................................................................................................... 29

Table 7-1. Port Mode Select.................................................................................................................. 30

Table 7-2. Register Map Sorted By Address.......................................................................................... 32

Table 8-1. T1 Alarm Criteria .................................................................................................................. 45

Table 9-1. E1 Sync/Resync Criteria....................................................................................................... 47

Table 9-2. E1 Alarm Criteria .................................................................................................................. 49

Table 10-1. TS Pin Functions ................................................................................................................ 53

Table 10-2. RLOF Pin Functions ........................................................................................................... 53

Table 11-1. T1 SSM Messages ............................................................................................................. 55

Table 12-1. E1 SSM Messages ............................................................................................................. 64

Table 13-1. Transformer Specifications ................................................................................................. 92

Table 15-1. Specification of 6312kHz Clock Signal at Input Port........................................................... 97

Table 15-2. Specification of 6312kHz Clock Signal at Output Port......................................................... 97

Table 16-1. Instruction Codes for IEEE 1149.1 Architecture................................................................ 102

Table 16-2. ID Code Structure............................................................................................................. 103

Table 16-3. Device ID Codes............................................................................................................... 103

Table 16-4. Boundary Scan Control Bits.............................................................................................. 104

Table 18-1. Thermal Characteristics.................................................................................................... 109

Table 18-2. Theta-JA (q

Table 18-3. Recommended DC Operating Conditions ......................................................................... 109

Table 18-4. Capacitance ..................................................................................................................... 109

Table 18-5. DC Characteristics............................................................................................................ 110

Table 19-1. AC Characteristics, Multiplexed Parallel Port.................................................................... 111

Table 19-2. AC Characteristics, Non-Mux Parallel Port ....................................................................... 114

Table 19-3. AC Characteristics, Serial Bus.......................................................................................... 117

Table 19-4. Receive Side AC Characteristics ...................................................................................... 119

Table 19-5. Transmit Side AC Characteristics ..................................................................................... 121

) vs. Airflow.................................................................................................. 109

6 of 123

DS26503 T1/E1/J1 BITS Element

1. FEATURES

1.1 General

§ 64-pin, 10mm x 10mm LQFP package

§ 3.3V supply with 5V-tolerant inputs and outputs

§ Evaluation kits

§ IEEE 1149.1 JTAG Boundary Scan

§ Driver source code available from the factory

1.2 Line Interface

§ Requires a single master clock (MCLK) for E1, T1, or J1 operation. Master clock can be

2.048MHz, 4.096MHz, 8.192MHz, or 16.384MHz. Option to use 1.544MHz, 3.088MHz,

6.176MHz, or 12.352MHz for T1-only operation.

§ Fully software configurable

§ Short- and long-haul applications

§ Automatic receive sensitivity adjustments

§ Ranges include 0dB to -43dB or 0dB to -12dB for E1 applications; 0dB to -36dB or 0dB to -15dB

for T1 applications

§ Receive level indication in 2.5dB steps from -42.5dB to -2.5dB

§ Internal receive termination option for 75Ω, 100Ω, 110Ω, and 120Ω lines

§ Monitor application gain settings of 20dB, 26dB, and 32dB

§ G.703 receive-synchronization signal mode

§ Flexible transmit-waveform generation

§ T1 DSX-1 line build-outs

§ E1 waveforms include G.703 waveshapes for both 75Ω coax and 120Ω twisted cables

§ AIS generation independent of loopbacks

§ Alternating ones and zeros generation

§ Square-wave output

§ Open-drain output option

§ Transmitter power-down

§ Transmitter 50mA short-circuit limiter with exceeded indication of current limit

§ Transmit open-circuit-detected indication

1.3 Jitter Attenuator

§ 32-bit or 128-bit crystal-less jitter attenuator

§ Requires only a 2.048MHz master clock for both E1 and T1 operation with the option to use

1.544MHz for T1 operation

§ Can be placed in either the receive or transmit path or disabled

§ Limit trip indication

7 of 123

1.4 Framer/Formatter

§ Full receive and transmit path transparency

§ T1 framing formats include D4 and ESF

§ E1 framing formats include FAS and CRC4

§ Detailed alarm and status reporting with optional interrupt support

§ RLOF, RLOS, and RAIS alarms interrupt on change of state

§ Japanese J1 support includes:

- Ability to calculate and check CRC6 according to the Japanese standard

- Ability to generate yellow alarm according to the Japanese standard

1.5 Test and Diagnostics

§ Remote and Local Loopback

1.6 Control Port

§ 8-bit parallel or serial control port

§ Multiplexed or nonmultiplexed buses

§ Intel or Motorola formats

§ Supports polled or interrupt-driven environments

§ Software access to device ID and silicon revision

§ Software-reset supported with automatic clear on power-up

§ Hardware controller port

§ Hardware reset pin

DS26503 T1/E1/J1 BITS Element

8 of 123

DS26503 T1/E1/J1 BITS Element

2. SPECIFICATIONS COMPLIANCE

The DS26503 meets all applicable sections of the relevant latest telecommunications specifications. The following table provides the T1 and E1 specifications and relevant sections that are applicable to the DS26503.

Table 2-1. T1-Related Telecommunications Specifications

ANSI T1.102- Digital Hierarchy Electrical Interface AMI Coding B8ZS Substitution Definition DS1 Electrical Interface. Line rate ±32ppm; Pulse Amplitude between 2.4V to 3.6V peak; power level between 12.6dBm to 17.9dBm; the T1 pulse mask is provided that we comply. DSX-1 for cross connects if the return loss is greater than -26dB. The DSX-1 cable is restricted up to 655 feet. This specification also provides cable characteristics of DSX-Cross Connect cable—22 AVG cables of 1000 feet. ANSI T1.231- Digital Hierarchy- Layer 1 in Service Performance Monitoring BPV Error Definition; Excessive Zero Definition; LOS description; AIS definition ANSI T1.403- Network and Customer Installation Interface- DS1 Electrical Interface Description of the Measurement of the T1 Characteristics—100W. Pulse shape and template compliance according to T1.102; power level 12.4dBm to 19.7dBm when all ones are transmitted. LBO for the Customer Interface (CI) is specified as 0dB, -7.5dB, and -15dB. Line rate is ±32ppm. Pulse Amplitude is 2.4 to 3.6V. AIS generation as unframed all ones is defined. The total cable attenuation is defined as 22dB. The DS26503 will function with up to -36dB cable loss. Note that the pulse template defined by T1.403 and T1.102 are different --- specifically at Times 0.61,

-0.27, -34 and 0.77. The DS26524 is complaint to both templates. Pub 62411 This specification has tighter jitter tolerance and transfer characteristics than other specifications. The jitter transfer characteristics are tighter than G.736 and Jitter Tolerance is tighter the G.823. (ANSI) “Digital Hierarchy – Electrical Interfaces” (ANSI) “Digital Hierarchy – Formats Specification” (ANSI) “Digital Hierarchy – Layer 1 In-Service Digital Transmission Performance Monitoring” (ANSI) “Network and Customer Installation Interfaces – DS1 Electrical Interface” (AT&T) “Requirements for Interfacing Digital Terminal Equipment to Services Employing the Extended Super frame Format” (AT&T) “High Capacity Digital Service Channel Interface Specification” (TTC) “Frame Structures on Primary and Secondary Hierarchical Digital Interfaces” (TTC) “ISDN Primary Rate User-Network Interface Layer 1 Specification”

9 of 123

DS26503 T1/E1/J1 BITS Element

Table 2-2. E1-Related Telecommunications Specifications

ITUT G.703 Physical/Electrical Characteristics of G.703 Hierarchical Digital Interfaces Defines the 2048kbps bit rate—2048 ±50ppm; the transmission media are 75W coax or 120W twisted

pair; peak-to-peak space voltage is ±0.237V; nominal pulse width is 244ns. Return loss 51Hz to 102Hz is 6dB; 102Hz to 3072Hz is 8dB; 2048Hz to 3072Hz is 14dB. Nominal peak voltage is 2.37V for coax and 3V for twisted pair. The pulse template for E1 is defined in G.703. ITUT G.736 Characteristics of Synchronous Digital Multiplex Equipment operating at 2048kbps The peak-to-peak jitter at 2048kbps has to be less than 0.05 UI at 20Hz to 100Hz. Jitter transfer between 2.048 synchronization signal and 2.048 transmission signal is provided. ITUT G.742 Second-Order Digital Multiplex Equipment Operating at 8448kbps The DS26503 jitter attenuator is complaint with Jitter transfer curve for sinusoidal jitter input. ITUT G.772 This specification provides the method for using receiver for transceiver 0 as a monitor for the remainder of the seven transmitter/receiver combinations. ITUT G.775 A LOS detection criterion is defined. ITUT G.823 The control of jitter and wander within digital networks, which are based on 2.048kbps hierarchy G.823 provides the jitter amplitude tolerance at different frequencies, specifically 20Hz, 2.4kHz, 18kHz, and 100kHz. ETSI 300 233 This specification provides LOS and AIS signal criteria for E1 mode. Pub 62411 This specification has tighter jitter tolerance and transfer characteristics than other specifications. The jitter transfer characteristics are tighter than G.736 and jitter tolerance is tighter then G.823. (ITU) “Synchronous Frame Structures used at 1544, 6312k, 2048, 8488, and 44,736kbps Hierarchical Levels” (ITU) “Frame Alignment and Cyclic Redundancy Check (CRC) Procedures Relating to Basic Frame Structures Defined in Recommendation G.704” (ITU) “Characteristics of primary PCM Multiplex Equipment Operating at 2048kbps” (ITU) Characteristics of a synchronous digital multiplex equipment operating at 2048kbps” (ITU) “Loss Of Signal (LOS) and Alarm Indication Signal (AIS) Defect Detection and Clearance Criteria” (ITU) “The Control of Jitter and Wander Within Digital Networks Which are Based on the 2048kbps Hierarchy” (ITU) “Primary Rate User-Network Interface – Layer 1 Specification” (ITU) “Error Performance Measuring Equipment Operating at the Primary Rate and Above” (ITU) “In-service code violation monitors for digital systems” (ETSI) “Integrated Services Digital Network (ISDN); Primary rate User-Network Interface (UNI); Part 1/ Layer 1 specification” (ETSI) “Transmission and multiplexing; Physical/electrical characteristics of hierarchical digital interfaces for equipment using the 2048kbps-based plesiochronous or synchronous digital hierarchies” (ETSI) “Integrated Services Digital Network (ISDN); Access digital section for ISDN primary rate” (ETSI) “Integrated Services Digital Network (ISDN); Attachment requirements for terminal equipment to connect to an ISDN using ISDN primary rate access”

10 of 123

DS26503 T1/E1/J1 BITS Element

Table 2-3. E1-Related Telecommunications Specifications (continued)

(ETSI) “Business Telecommunications (BT); Open Network Provision (ONP) technical requirements; 2048lkbps digital unstructured leased lines (D2048U) attachment requirements for terminal equipment interface” (ETSI) “Business Telecommunications (BTC); 2048kbps digital structured leased lines (D2048S); Attachment requirements for terminal equipment interface” (ITU) “Synchronous Frame Structures used at 1544, 6312, 2048, 8488, and 44,736kbps Hierarchical Levels” (ITU) “Frame Alignment and Cyclic Redundancy Check (CRC) Procedures Relating to Basic Frame Structures Defined in Recommendation G.704”

11 of 123

3. BLOCK DIAGRAMS

Figure 3-1. Block Diagram

MCLK

MASTER CLOCK

JA CLOCK

DS26503 T1/E1/J1 BITS Element

DS26503

RCLK

RTIP

RRING

RLOS

RAIS

TTIP

LIU

CLOCK

+ DATA

- DATA

L O C A

ATTENUATOR

O O

ASSIGNED TO

TRANSMIT PATH

OR DISABLED

A C K

U X

ENABLED

AND IN RX

PATH

JITTER

CAN BE

RECEIVE OR

ENABLED

AND IN TX

PATH

R E M O T E

L O O P

A C K

U X

PLL

CLOCK

MUX

TX CLOCK

+ DATA

- DATA

T1/E1 SSM

FRAMER

T1/E1 SSM

FORMATTER

LOF_CCE

RSER

TCLK

PLL_OUT

TSER

JTAG PORT

JTAG PORTJTAG PORTJTAG PORT

PARALLEL/SERIAL CPU I/F HARDWARE CONTROLLER

JTDOJTDIJTCLKJTMS JTRST BIS1 BIS0

PARALLEL, SERIAL, OR

HARDWARE

CONTROLLER

12 of 123

TSTRST

Figure 3-2. Loopback Mux Diagram

FROM RX

LIU

TO TX

LIU

CLOCK

+ DATA

- DATA

CLOCK

+ DATA

- DATA

ATTENUATOR

ENABLED AND

ATTENUATOR

ENABLED AND

REMOTE

LOOPBACK

(LBCR.4)

JITTER

IN RX PATH

LOCAL

LOOPBACK

(LBCR.3)

JITTER

IN TX PATH

DS26503 T1/E1/J1 BITS Element

RCLK

+ DATA

TO RX

FRAMER

- DATA

TX CLOCK

+ DATA

FROM TX

FORMATTER

- DATA

Figure 3-3. Transmit PLL Clock Mux Diagram

TPCR.2

RECOVERED CLOCK

TCLK PIN

JA CLOCK

(HARDWARE MODE PIN NAME)

TPCR.3 TPCR.4

SEL

TX PLL

OUTPUT = 1.544MHz,

2.048MHz, 6.312MHz

TPCR.6 TPCR.7

OUT SEL

TPCR.0

(TCSS0)

TPCR.1

(TCSS1)

TPCR.5

PLL_OUT PIN

TX CLOCK

13 of 123

Figure 3-4. Master Clock PLL Diagram

MCLK PIN

PRE-SCALER

DIVIDE BY 1, 2, 4,

OR 8

DS26503 T1/E1/J1 BITS Element

LIC4.6

(MPS0)

LIC4.7

(MPS1)

X12,X16

MULTIPLIER

PLL

TO CLOCK AND DATA

RECOVERY ENGINE IN

RECEIVE LIU

2.048MHz to

1.544MHz PLL

(HARDWARE MODE PIN NAME)

JA CLOCK

LIC2.3

(JACKS)

14 of 123

4. PIN FUNCTION DESCRIPTION

4.1 Transmit PLL

NAME TYPE FUNCTION

PLL_OUT O

Transmit PLL Output. 1544kHz, 2048kHz, 64kHz, or 6312kHz output from the internal TX PLL. Transmit Clock Input. A 64kHz, 1.544MHz, 2.048MHz, or 6312kHz

TCLK I

primary clock. May be selected by the TX PLL mux to provide a clock to the transmit section.

4.2 Transmit Side

NAME TYPE FUNCTION

TSER I

TS I/O

TCLKO O

TPOSO O

TNEGO O

Transmit Serial Data. Source of transmit data sampled on the falling edge of the selected transmit clock. TSYNC. When in “input” mode, a pulse at this pin will establish either frame or multiframe boundaries for the transmit side. In output mode, the pin can be programmed to output a frame or multiframe sync pulse useful for aligning data. Transmit Clock Output. Buffered clock that is used to clock data through the transmit-side formatter (i.e., either TCLK or RCLK). Transmit Positive-Data Output. In T1 or E1 mode, updated on the rising edge of TCLKO with the bipolar data out of the transmit-side formatter. Can be programmed to source NRZ data via the output-data format (IOCR1.0) control bit. In 6312 mode, this pin is low. Transmit Negative-Data Output. In T1 or E1 mode, updated on the rising edge of TCLKO with the bipolar data out of the transmit-side formatter. In 6312 mode, this pin is low.

DS26503 T1/E1/J1 BITS Element

15 of 123

4.3 Receive Side

NAME TYPE FUNCTION

RCLK O

RS O

RSER O

RLOF O

RLOS O

Receive Clock. Recovered 1.544MHz (T1), 2.048MHz (E1), or 6312 kHz (G.703 Synchronization Interface).

Receive Sync

T1/E1 Mode: An extracted pulse, one RCLK wide, is output at this pin that identifies either frame (IOCR1.5 = 0) or multiframe (IOCR1.5 = 1) boundaries. If set to output frame boundaries, then through IOCR1.6, RS can also be set to output double-wide pulses on signaling frames in T1 mode.

6312K Mode: This pin will be in a high-impedance state.

Receive Serial Data

T1/E1 Mode: This is the received NRZ serial data updated on rising edges of RCLK.

6312K Mode: This pin will be in a high-impedance state. Receive Loss Of Frame. This output can be configured to be a Loss Of Transmit Clock indicator via IOCR.4 when operating in T1 or E1 mode.

T1/E1 Mode: Set when the receive synchronizer is searching for frame alignment (RLOF mode), or set when the signal at the TCLK pin has not transitioned for approximately 15 periods of the scaled MCLK (LOTC mode).

6312K Mode: This pin will be in a high-impedance state. Receive Loss Of Signal

T1 Mode: High when 192 consecutive zeros detected.

E1 Mode: High when 255 consecutive zeros detected.

DS26503 T1/E1/J1 BITS Element

6312K Mode: High when consecutive zeros detected for 65ms typically.

Receive Alarm Indication Signal

T1 Mode: Will toggle high when receive Blue Alarm is detected.

RAIS O

E1 Mode: Will toggle high when receive AIS is detected.

6312K Mode: This pin will be in a high-impedance state.

16 of 123

4.4 Controller Interface

NAME TYPE FUNCTION

Interrupt/JA Clock Source Select 1

INT: Flags host controller during events, alarms, and conditions defined in

INT/

JACKS

TMODE1 I

TMODE2 I

TSTRST I

BIS[1:0] I

AD[7]/

RITD

AD[6]/

TITD

AD[5]/

RMODE1

I/O

the status registers. Active-low open-drain output. JACKS: Hardware Mode: JA Clock Select. Set this pin high for T1 mode operation when either a 2.048MHz, 4.096MHz, 8.192MHz or 16.382MHz signal is applied at MCLK. Transmit Mode Select 1. In Hardware Mode (BIS[1:0] = 11), this bit is used to configure the transmit operating mode. Transmit Mode Select 2. In Hardware Mode (BIS[1:0] = 11), this bit is used to configure the transmit operating mode. Tri-State Control and Device Reset. A dual-function pin. A zero-to-one transition issues a hardware reset to the DS26503 register set. Configuration register contents are set to the default state. Leaving TSTRST high tri-states all output and I/O pins (including the parallel control port). Set low for normal operation. Useful for in-board level testing. Processor Interface Mode Select 1, 0. These bits select the processor interface mode of operation.

BIS[1:0] : 00 = Parallel Port Mode (Multiplexed) 01 = Parallel Port Mode (Nonmultiplexed) 10 = Serial Port Mode 11 = Hardware Mode

Data Bus D[7] or Address/Data Bus AD[7]/Transmit Termination Select

A[7]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data bus D[7]. AD[7]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[7]. RITD: In Hardware Mode (BIS[1:0] = 11), it disables the internal receive termination.

Data Bus D[6] or Address/Data Bus AD[6]/Transmit Termination Select

A[6]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data bus D[6]. AD[6]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[6]. TITD: In Hardware Mode (BIS[1:0] = 11), it disables the internal transmit termination.

Data Bus D[5] or Address/Data Bus AD[5]/Receive Framing Mode Select Bit 1

A[5]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data bus D[5]. AD[5]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[5]. RMODE1: In Hardware Mode (BIS[1:0] = 11), it selects the receive side operating mode.

DS26503 T1/E1/J1 BITS Element

17 of 123

NAME TYPE FUNCTION

Data Bus D[4] or Address/Data Bus AD[4]/Receive Framing Mode Select Bit 0

A[4]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data

AD[4]/

RMODE0

I/O

bus D[4]. AD[4]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[4]. RMODE0: In Hardware Mode (BIS[1:0] = 11), it selects the receive side operating mode.

Data Bus D[3] or Address/Data Bus AD[3]/TS Mode Select

A[3]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data bus D[3].

AD[3]/TSM I/O

AD[3]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[3]. TSM: In Hardware Mode (BIS[1:0] = 11), this pin selects the function of TS. Please see the register descriptions for more detailed information.

Data Bus D[2] or Address/Data Bus AD[2]/RS Mode Select/Serial Port Clock

A[2]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data

AD[2]/RSM/

SCLK

I/O

bus D[2]. AD[2]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[2]. RSM: In Hardware Mode (BIS[1:0] = 11), this pin selects the function of RS. Please see the register descriptions for more detailed information. SCLK: In Serial Port mode this is the serial clock input.

Data Bus D[1] or Address/Data Bus AD[1]/Receive Mode Select 3/Master Out-Slave In

A[1]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data

AD[1]/

RMODE3/

MOSI

I/O

bus D[1]. AD[1]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[1]. RMODE3: In Hardware Mode (BIS[1:0] = 11), this pin selects the receive side operating mode. MOSI: Serial data input called Master Out-Slave In for clarity of data transfer direction.

Data Bus D[0] or Address/Data Bus AD[0]/Transmit Clock Source Select 0/Master In-Slave Out

A[0]: In nonmultiplexed bus operation (BIS[1:0] = 01), it serves as the data

AD[0]/

TCSS0/

MISO

I/O

bus D[0]. AD[0]: In multiplexed bus operation (BIS[1:0] = 00), it serves as the multiplexed address/data bus AD[0]. TCSS0: Transmit Clock Source Select 0. MISO: In serial bus mode (BIS[1:0] = 10), this pin serves as the serial data output Master In-Slave Out.

DS26503 T1/E1/J1 BITS Element

TCSS1

Transmit Clock Source Select. Transmit Clock Source Select 1

18 of 123

NAME TYPE FUNCTION

Address Bus Bit A[6]/MCLK Prescale Select

A6: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[6].

A6/MPS0 I

In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and should be tied low. MPS0: In Hardware Mode (BIS[1:0] = 11), MCLK prescale select is used to set the prescale value for the PLL.

Address Bus Bit A[5]/Serial Port Clock Polarity Select/Transmit Mode Select 0

A5: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[5].

A5/CPOL/

TMODE0

In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and should be tied low. CPOL: In Serial Port Mode (BIS[1:0] = 10), this pin selects the serial port clock polarity. Please see the functional timing diagrams for the Serial Port Interface for more information. TMODE0: In Hardware Mode (BIS[1:0] = 11), this pin is used to configure the transmit operating mode.

Address Bus Bit A[4]/Serial Port Clock Phase Select/Line Build-Out Select 2

A4: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[4]. In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and

A4/CPHA/

should be tied low. CPHA: In Serial Port Mode (BIS[1:0] = 10), this pin selects the serial port clock phase. Please see the functional timing diagrams for the Serial Port Interface for more information. L2: In Hardware Mode (BIS[1:0] = 11), this pin selects the line build-out value.

Address Bus Bit A[3]/Line Build-Out Select 1

A3: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[3].

A3/L1 I

In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and should be tied low. L1: In Hardware Mode (BIS[1:0] = 11), this pin selects the line build-out value.

Address Bus Bit A[2]/Line Build-Out Select 0

A2: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[2].

A2/L0 I

In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and should be tied low. L0: In Hardware Mode (BIS[1:0] = 11), this pin selects the line build-out value.

Address Bus Bit A[1]/Transmit AIS

A1: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[1].

A1/TAIS

In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and should be tied low. TAIS: When set to a 1 and in T1/E1 operating modes, the transmitter will transmit an AIS pattern. This pin is ignored in all other operating modes.

DS26503 T1/E1/J1 BITS Element

19 of 123

NAME TYPE FUNCTION

Address Bus Bit A[0]/E1 Termination Select

A0: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[0].

A0/E1TS I

In multiplexed bus operation (BIS[1:0] = 00), these pins are not used and should be tied low. E1TS: In Hardware Mode (BIS[1:0] = 11), selects the E1 internal termination value (0 = 120W, 1 = 75W).

Bus Type Select/Transmit and Receive B8ZS/HDB3 Enable

BTS: Strap high to select Motorola bus timing; strap low to select Intel bus timing. This pin controls the function of the RD (DS), ALE (AS), and WR

BTS/HBE I

(R/W) pins. If BTS = 1, then these pins assume the function listed in parentheses (). HBE: In Hardware Mode (BIS[1:0] = 11), this pin enables transmit and receive B8ZS/HDB3 when in T1/E1 operating modes.

Read Input-Data Strobe/Receive Mode Select Bit 2

RD(DS)/

RMODE2

RD (DS): These pins are active-low signals. DS is active high when BIS[1:0] = 01. See the bus timing diagrams. RMODE2: In Hardware Mode (BIS[1:0] = 11), this pin selects the receive side operating mode.

Chip Select/Remote Loopback Enable

CS: This active-low signal must be low to read or write to the device. This

CS/RLB

signal is used for both the parallel port and the serial port modes. RLB: In Hardware Mode (BIS[1:0] = 11), when high, remote loopback is enabled. This function is only valid when the transmit side and receive side are in the same operating mode.

Address Latch Enable (Address Strobe)/Address Bus Bit 7/MCLK Prescale Select 1

ALE (AS)/

A7/MPS1

ALE (AS): In multiplexed bus operation (BIS[1:0] = 00), it serves to demultiplex the bus on a positive-going edge. A7: In nonmultiplexed bus operation (BIS[1:0] = 01), this pin serves as A[7]. MPS1: In Hardware Mode (BIS[1:0] = 11), MCLK prescale select, used to set the prescale value for the PLL.

Write Input (Read/Write)/Transmit Mode Select 3

WR (R/W)/

TMODE3

WR: In Processor Mode, this pin is the active-low write signal. TMODE3: In Hardware Mode, this pin selects the transmit-side operating mode.

DS26503 T1/E1/J1 BITS Element

20 of 123

4.5 JTAG

NAME TYPE FUNCTION

JTCLK I

JTMS I

JTDI I

JTDO O

JTRST I

JTAG Clock. This clock input is typically a low frequency (less than 10MHz) 50% duty cycle clock signal. JTAG Mode Select (with Pullup). This input signal is used to control the JTAG controller state machine and is sampled on the rising edge of JTCLK. JTAG Data Input (with Pullup). This input signal is used to input data into the register that is enabled by the JTAG controller state machine and is sampled on the rising edge of JTCLK. JTAG Data Output. This output signal is the output of an internal scan shift register enabled by the JTAG controller state machine and is updated on the falling edge of JTCLK. The pin is in the high-impedance mode when a register is not selected or when the JTRST signal is high. The pin goes into and exits the high impedance mode after the falling edge of JTCLK JTAG Reset (Active Low). This input forces the JTAG controller logic into the reset state and forces the JTDO pin into high impedance when low. This pin should be low while power is applied and set high after the power is stable. The pin can be driven high or low for normal operation, but must be high for JTAG operation.

DS26503 T1/E1/J1 BITS Element

4.6 Line Interface

NAME TYPE FUNCTION

Master Clock Input. A (50ppm) clock source. This clock is used internally for

both clock/data recovery and for the jitter attenuator for both T1 and E1 modes.

MCLK I

RTIP I

RRING I

TTIP O

TRING O

THZE I

The clock rate can be 16.384MHz, 8.192MHz, 4.096MHz, or 2.048MHz. When using the DS26503 in T1-only operation, a 1.544MHz (50ppm) clock source can be used. Receive Tip. Analog input for clock recovery circuitry. This pin connects via a 1:1 transformer to the network. See the Line Interface Unit section for details. Receive Ring. Analog input for clock recovery circuitry. This pin connects via a 1:1 transformer to the network. See the Line Interface Unit section for details. Transmit Tip. Analog line-driver output. This pin connects via a 1:2 step-up transformer to the network. See the Line Interface Unit section for details. Transmit Ring. Analog line-driver output. This pin connects via a 1:2 step-up transformer to the network. See the Line Interface Unit section for details. Transmit High-Impedance Enable. When high, TTIP and TRING will be placed into a high-impedance state.

21 of 123

DS26503 T1/E1/J1 BITS Element

4.7 Power

NAME TYPE FUNCTION

DVDD —

RVDD —

TVDD —

DVSS — Digital Signal Ground. 0.0V. Should be tied to the RVSS and TVSS pins.

Digital Positive Supply. 3.3V ±5%. Should be tied to the RVDD and TVDD pins. Receive Analog Positive Supply. 3.3V ±5%. Should be tied to the DVDD and TVDD pins. Transmit Analog Positive Supply. 3.3V ±5%. Should be tied to the DVDD and RVDD pins.

RVSS —

TVSS —

Receive Analog Signal Ground. 0.0V. Should be tied to the DVSS and TVSS pins. Transmit Analog Signal Ground. 0.0V. Should be tied to the DVSS and RVSS pins.

22 of 123

5. PINOUT

Table 5-1. LQFP Pinout

MODE

PIN TYPE

1 I/O AD2 SCLK RSM

2 I/O AD3 — TSM

3 I/O AD4 — RMODE0

4 I/O AD5 — RMODE1

5 I/O AD6 — TITD

6 I/O AD7 — RITD

7, 24,

8, 22,

9 I A0 — E1TS

10 I A1 — TAIS

11 I A2 — L0

12 I A3 — L1

13 I A4 CPHA L2

14 I A5 CPOL TMODE0

15 I A6 — MPS0

16 I ALE (AS)/A7 — MPS1

I DVDD DVDD DVDD Digital Positive Supply

I DVSS DVSS DVSS Digital Signal Ground

PARALLEL

PORT

SERIAL

PORT

HARDWARE

DS26503 T1/E1/J1 BITS Element

FUNCTION

Parallel Port Mode: Address/Data Bus Bit 2 Serial Port Mode: Serial Clock Hardware Mode: RS Mode Select

Parallel Port Mode: Address/Data Bus Bit 3 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: TS Mode Select Parallel Port Mode: Address/Data Bus Bit 4 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: Receive Mode Select 0 Parallel Port Mode: Address/Data Bus Bit 5 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: Receive Mode Select 1 Parallel Port Mode: Address/Data Bus Bit 6 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: Transmit Internal Termination Disable

Parallel Port Mode: Address/Data Bus Bit 7 Serial Port Mode: Unused, should be connected to V Hardware Mode: Receive Internal Termination Disable

Parallel Port Mode: Address Bus Bit 0 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: E1 Internal Termination Select Parallel Port Mode: Address Bus Bit 1 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: Transmit AIS Parallel Port Mode: Address Bus Bit 2 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: Line Build-Out Select 0 Parallel Port Mode: Address Bus Bit 3 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: Line Build-Out Select 1

Parallel Port Mode: Address Bus Bit 4 Serial Port Mode: Serial Port Clock Phase Select Hardware Mode: Line Build-Out Select 2

Parallel Port Mode: Address Bus Bit 5 Serial Port Mode: Serial Port Clock Polarity Select Hardware Mode: Transmit Mode Select 0 Parallel Port Mode: Address Bus Bit 6 Serial Port Mode: Unused, should be connected to VSS. Hardware Mode: MCLK Prescaler Select 0 Parallel Port Mode: Address Latch Enable/Address Bus Bit 7 Serial Port Mode: Unused, should be connected to V Hardware Mode: MCLK Prescaler Select 1

23 of 123

DS26503 T1/E1/J1 BITS Element

MODE

PIN TYPE

PARALLEL

PORT

SERIAL

PORT

HARDWARE

FUNCTION

17 I TCLK TCLK TCLK External Transmit Clock Input 18 O TCLKO TCLKO TCLKO Transmit Clock Output 19 O TNEGO TNEGO TNEGO Transmit Negative-Data Output 20 O TPOSO TPOSO TPOSO Transmit Positive-Data Output 21 I TSER TSER TSER Transmit Serial Data 23 I/O TS TS TS T1/E1 Mode: Transmit Frame/Multiframe Sync 25 O RCLK RCLK RCLK Receive Clock 26 O RS RS RS T1/E1 Mode: Receive Frame/Multiframe Boundary 27 — N.C. N.C. N.C. No Connect. This pin must be left open. 28 O RSER RSER RSER Receive Serial Data 29 O RAIS RAIS RAIS Receive Alarm Indication Signal 30 O RLOF RLOF RLOF Receive Loss of Frame

Parallel Port Mode: Unused, should be connected to

31 I — — TCSS1

Serial Port Mode: Unused, should be connected to V

Hardware Mode: Transmit Clock Source Select 1 32 O RLOS RLOS RLOS Receive Loss Of Signal 33 I JTMS JTMS JTMS IEEE 1149.1 Test Mode Select 34 I JTCLK JTCLK JTCLK IEEE 1149.1 Test Clock Signal 35 I JTRST JTRST JTRST IEEE 1149.1 Test Reset 36 I JTDI JTDI JTDI IEEE 1149.1 Test Data Input 37 O JTDO JTDO JTDO IEEE 1149.1 Test Data Output 38 I RVDD RVDD RVDD Receive Analog Positive Supply 39 I TSTRST TSTRST TSTRST Test/Reset

40,

43, 45

I RVSS RVSS RVSS Receive Analog Signal Ground

41 I RTIP RTIP RTIP Receive Analog Tip Input 42 I RRING RRING RRING Receive Analog Ring Input 44 I MCLK MCLK MCLK Master Clock Input

Parallel Port Mode: Interrupt 46 I/O INT INT JACKS

Serial Port Mode: Interrupt

Hardware Mode: Jitter Attenuator clock select 47 O PLL_OUT PLL_OUT PLL_OUT Transmit PLL (TX PLL) Clock Output

Parallel Port Mode: Unused, should be connected to

V 48 I — — TMODE2

Serial Port Mode: Unused, should be connected to V

Hardware Mode: Transmit Mode Select 2

Parallel Port Mode: Unused, should be connected to

V 49 I — — TMODE1

Serial Port Mode: Unused, should be connected to V

Hardware Mode: Transmit Mode Select 1 50 I THZE THZE THZE Transmit High-Impedance Enable 51 O TTIP TTIP TTIP Transmit Analog Tip Output 52 I TVSS TVSS TVSS Transmit Analog Signal Ground 53 I TVDD TVDD TVDD Transmit Analog Positive Supply 54 O TRING TRING TRING Transmit Analog Ring Output

Parallel Port Mode: Bus Type Select (Motorola/Intel)

55 I BTS — HBE

Serial Port Mode: Unused, should be connected to V

Hardware Mode: Receive and Transmit DB3/B8ZS

Enable 57 I BIS0 BIS0 BIS0 Bus Interface Select Mode 0 59 I BIS1 BIS1 BIS1 Bus Interface Select Mode 1

24 of 123

MODE

PIN TYPE

PARALLEL

PORT

SERIAL

PORT

HARDWARE

Parallel Port Mode: Chip Select (Active Low) 60 I CS CS RLB

Serial Port Mode: Chip Select (Active Low)

Hardware Mode: Remote Loopback Enable

Parallel Port Mode: Read Input (Data Strobe), Active

61 I RD (DS) — RMODE2

Low.

Serial Port Mode: Unused, should be connected to V

Hardware Mode: Receive Mode Select 2

Parallel Port Mode: Write Input (Read/Write), Active

62 I WR (R/W) — TMODE3

Low

Serial Port Mode: Unused, should be connected to V

Hardware Mode: Transmit Mode Select 3

Parallel Port Mode: Address/Data Bus Bit 0

63 I/O AD0 MIS0 TCSS0

Serial Port Mode: Serial Data Out (Master In-Slave

Out)

Hardware Mode: Transmit Clock Source Select 0

Parallel Port Mode: Address/Data Bus Bit 1 64 I/O AD1 MOSI RMODE3

Serial Port Mode: Serial Data In (Master Out-Slave In)

Hardware Mode: Receive Mode Select 3

DS26503 T1/E1/J1 BITS Element

FUNCTION

25 of 123

DS26503 T1/E1/J1 BITS Element

6. HARDWARE CONTROLLER INTERFACE

In Hardware Controller mode, the parallel and serial port pins are reconfigured to provide direct access to certain functions in the port. Only a subset of the device’s functionality is available in hardware mode. Each register description throughout the data sheet indicates the functions that may be controlled in hardware mode and several alarm indicators that are available in both hardware and processor mode. Also indicated are the fixed states of the functions not controllable in hardware mode.

6.1 Transmit Clock Source

Refer to Figure 3-3. In Hardware Controller mode, the input to the TX PLL is always TCLK PIN. TX CLOCK is selected by the TCSS0 and TCSS1 pins, as shown in Table 6-1 the same signal as select for TX CLOCK. If the user wants to slave the transmitter to the recovered clock, then the RCLK pin must be tied to the TCLK pin externally.

. The PLL_OUT pin is always

Table 6-1. Transmit Clock Source

TCSS1 PIN 31

0 0 The TCLK pin is the source of transmit clock.

0 1 The PLL_CLK is the source of transmit clock.

1 0

1 1 The signal present at RCLK is the transmit clock.

TCSS0 PIN 63

TRANSMIT CLOCK SOURCE

The scaled signal present at MCLK as the transmit clock.

6.2 Internal Termination

In Hardware Controller mode, the internal termination is automatically set according to the receive or transmit mode selected. It can be disabled via the TITD and RITD pins. If internal termination is enabled in E1 mode, the E1TS pin is use to select 75W or 120W termination. The E1TS pin applies to both transmit and receive.

Table 6-2. Internal Termination

PIN NAME FUNCTION

TITD PIN 5

RITD PIN 6

E1TS PIN 9

Transmit Internal Termination Disable. Disables the internal transmit

termination. The internal transmit termination value is dependent on the state of the TMODEx pins. Receive Internal Termination Disable. Disables the internal receive termination. The internal receive termination value is dependent on the state of the RMODEx pins.

E1 Termination Select. Selects 120W or 75W internal termination when one of the E1 modes is selected and internal termination is enabled. IF E1 is selected for both transmit and receive, then both terminations will be the same.

0 = 75W 1 = 120W

26 of 123

6.3 Line Build-Out

Table 6-3. E1 Line Build-Out

DS26503 T1/E1/J1 BITS Element

PIN 13

0 0 0 75Ω normal 1:2 N.M. 0 0 0 1 120Ω normal 1:2 N.M. 0 1 0 0 75Ω with high return loss* 1:2 21dB 6.2Ω 1 0 1 120Ω with high return loss* 1:2 21dB 11.6Ω 1 1 0 Reserved — — — 1 1 1 Reserved — — —

PIN 12

PIN 11

APPLICATION N (1) RETURN LOSS Rt (1)

*TTD pin must be connected high in this mode.

N.M. = not meaningful

Table 6-4. T1 Line Build-Out

PIN 13

0 0 0 DSX-1 (0 to 133 feet)/0dB CSU 1:2 N.M. 0 0 0 1 DSX-1 (133 to 266 feet) 1:2 N.M. 0 0 1 0 DSX-1 (266 to 399 feet) 1:2 N.M. 0 0 1 1 DSX-1 (399 to 533 feet) 1:2 N.M. 0 1 0 0 DSX-1 (533 to 655 feet) 1:2 N.M. 0 1 0 1 Reserved — — — 1 1 0 Reserved — — — 1 1 1 Reserved — — —

PIN 12

PIN 11

APPLICATION N (1)

RETURN

LOSS

Rt (1)

6.4 Receiver Operating Modes

Table 6-5. Receive Path Operating Mode

RMODE3

PIN 64

0 0 0 0 T1 D4 0 0 0 1 T1 ESF 0 0 1 0 J1 D4 0 0 1 1 J1 ESF 0 1 0 0 E1 FAS 0 1 0 1 E1 CAS 0 1 1 0 E1 CRC4 0 1 1 1 E1 CAS and CRC4 1 0 0 0 E1 G.703 2048kHz Synchronization Interface 1 0 0 1 Reserved 1 0 1 0 Reserved 1 0 1 1 6312kHz Synchronization Interface 1 1 0 0 Reserved 1 1 0 1 Reserved 1 1 1 0 Reserved 1 1 1 1 Reserved

RMODE2

PIN 61

RMODE1

PIN 4

RMODE0

PIN 3

RECEIVE PATH OPERATING MODE

27 of 123

6.5 Transmitter Operating Modes

Table 6-6.Transmit Path Operating Mode

DS26503 T1/E1/J1 BITS Element

TMODE3

PIN 62

0 0 0 0 T1 D4 0 0 0 1 T1 ESF 0 0 1 0 J1 D4 0 0 1 1 J1 ESF 0 1 0 0 E1 FAS 0 1 0 0 E1 FAS + CAS (Note 1) 0 1 0 1 Reserved 0 1 1 0 E1 CRC4 0 1 1 0 E1 CRC4 + CAS (Note 1) 0 1 1 1 Reserved 1 0 0 0 E1 G.703 2048kHz Synchronization Interface 1 0 0 1 Reserved 1 0 1 0 Reserved 1 0 1 1 6312kHz Synchronization Interface (Note 2) 1 1 0 0 Reserved 1 1 0 1 Reserved 1 1 1 0 Reserved 1 1 1 1 Reserved

TMODE2

PIN 48

TMODE1

PIN 49

TMODE0

PIN 14

TRANSMIT PATH OPERATING MODE

Note 1:

Note 2:

The DS26503 does not have an internal source for CAS signaling and multiframe alignment generation. CAS signaling, and the multiframe alignment word, must be embedded in the transmit data (in the TS16 position) present on the TSER pin and frame aligned to sync signal on the TS pin.

In addition to setting the TMODE bits to 6312kHz Synchronization Interface mode, the Transmit PLL must also be configured to transmit a 6312kHz signal through the Transmit PLL Control Register (TPCR.6 and TPCR.7).

6.6 MCLK Pre-Scaler

Table 6-7. MCLK Pre-Scaler for T1 Mode

MPS1

PIN 16

0 0 0 1.544 0 1 0 3.088 1 0 0 6.176 1 1 0 12.352 0 0 1 2.048 0 1 1 4.096 1 0 1 8.192 1 1 1 16.384

MPS0

PIN 15

JACKS

PIN 46

MCLK

(MHz)

28 of 123

Table 6-8. MCLK Pre-Scaler for E1 Mode

DS26503 T1/E1/J1 BITS Element

MPS1

PIN 16

0 0 0 2.048 0 0 1 Reserved 0 1 0 4.096 0 1 1 Reserved 1 0 0 8.192 1 0 1 Reserved 1 1 0 16.384 1 1 1 Reserved

MPS0

PIN 15

JACKS

PIN 46

MCLK

(MHz)

6.7 Other Hardware Controller Mode Features

Table 6-9. Other Operational Modes

NAME

RSM

PIN 1

TSM PIN2

RLB

PIN 60

TAIS

PIN 10

HBE

PIN 55

RS Mode Select: Selects frame or multiframe pulse at RS pin.

0 = frame mode 1 = multiframe mode

TS Mode Select: In T1 or E1 operation, selects frame or multiframe mode for the TS pin.

0 = frame mode

1 = multiframe mode Remote Loopback Enable: In this loopback, data input to the framer portion of the DS26503 will be transmitted back to the transmit portion of the LIU. Data will continue to pass through the receive side framer of the DS26503 as it would normally and the data from the transmit side formatter will be ignored.

0 = loopback disabled

1 = loopback enabled

Transmit AIS

0 = normal transmission 1 = transmit AIS alarm

Receive and Transmit HDB3/B8ZS Enable

0 = HDB3/B8ZS disabled

1 = HDB3/B8ZS enabled

DESCRIPTION

29 of 123

DS26503 T1/E1/J1 BITS Element

7. PROCESSOR INTERFACE

The DS26503 is controlled via a nonmultiplexed (BIS[1:0] = 01) or a multiplexed (BIS[1:0] = 00) parallel bus. There is also a serial bus mode option, as well as a hardware mode of operation. The bus interface type is selected by BIS1 and BIS0 as shown in Table 7-1.

Table 7-1. Port Mode Select

BIS1 BIS0 PORT MODE

0 0 Parallel Port Mode (Multiplexed) 0 1 Parallel Port Mode (Nonmultiplexed) 1 0 Serial Port Mode (SPI) 1 1 Hardware Mode

7.1 Parallel Port Functional Description

In parallel mode, the DS26503 can operate with either Intel or Motorola bus timing configurations. If the BTS pin is tied low, Intel timing will be selected; if tied high, Motorola timing will be selected. All Motorola bus signals are listed in parentheses (). See the timing diagrams in the AC Electrical Characteristics section for more details.

7.2 SPI Serial Port Interface Functional Description

A serial SPI bus interface is selected when bus select is 10 (BIS[1:0] = 10). In this mode, a master/slave relationship is enabled on the serial port with three signal lines (SCK, MOSI, and MISO) and a chip select (CS), with the DS26503 acting as the slave. Port read/write timing is not related to the system read/write timing, thus allowing asynchronous, half-duplex operation. See the AC Electrical Characteristics section for the AC timing characteristics of the serial port.

7.2.1 Clock Phase and Polarity

Clock Phase and Polarity are selected by the CPHA and CPOL pins. The slave device should always be configured to match the bus master. See the SPI Serial Port Mode section for detailed functional timing diagrams.

7.2.2 Bit Order

The most significant bit (MSB) of each byte is transmitted first.

7.2.3 Control Byte

The bus master will transmit two control bytes following a chip select to a slave device. The MSB will be a R/W bit (1=read, 0=write). The next 6 bits will be padded with 0s. The LSB of the first byte will be A[7]. The second control byte will be the address bits (A[6:0]) of the target register, followed by a Burst bit in the LSB position (1=Burst, 0=Non-burst).

7.2.4 Burst Mode

The last bit of the second control byte (LSB) is the Burst mode bit. When the Burst bit is enabled (set to

1) and a read operation is performed, the register address is automatically incremented after the LSB of the previous byte read to the next register address. Data will be available on the next clock edge following the LSB of the previous byte read. When the Burst bit is enabled (set to 1) and a write operation is performed, the register address will be automatically incremented to the next byte boundary following the LSB of the previous register write, and 8 more data bits will be expected on the serial bus. Burst accesses

30 of 123

DS26503 T1/E1/J1 BITS Element

are terminated when CS is removed. If CS is removed before all 8 bits of the data are read, the remaining data will be lost. If CS is removed before all 8 bits of data are written to the part, no write access will occur and the target register will not be updated.

Note: During a Burst read access, data must be fetched internally to the part as the LSB of the previous byte is transmitted out. If this pre-fetch read access occurs to a Clear-On-Read register or a FIFO register address, and the Burst access is terminated without reading this byte out of the port, the data will be lost and/or the register cleared. Users should not terminate their Burst Read accesses at the address byte proceeding a Clear-On-Read register or a FIFO register. Data loss could occur due to the internal prefetch operation performed by the interface.

7.2.5 Register Writes

The register write sequence is shown in the functional timing diagrams in Section 17. After a CS, the bus master transmits a write control byte containing the R/W bit, the target register address, and the Burst bit. These two control bytes will be followed by the data byte to be written. After the first data byte, if the Burst bit is set, the DS26503 auto-increments its address counter and writes each byte received to the next higher address location. After writing address FFh, the address counter rolls over to 00h and continues to auto-increment.

7.2.6 Register Reads

The register read sequence is shown in Section 17. After a CS, the bus master transmits a read control byte containing the R/W bit, the target register address, and the Burst bit. After these two control bytes, the DS26503 responds with the requested data byte. After the first data byte, if the Burst bit is set, the DS26503 auto-increments its address counter and transmits the byte stored in the next higher address location. Note the warning mentioned above as data loss could potentially occur due to the data pre-fetch that is required to support this mode. After reading address FFh, the address counter rolls over to 00h and continues to auto-increment.

31 of 123

7.3 Register Map

Table 7-2. Register Map Sorted By Address

DS26503 T1/E1/J1 BITS Element

ADDRESS TYPE REGISTER NAME

00 R/W Test Reset Register TSTRREG 01 R/W I/O Configuration Register 1 IOCR1 02 R/W I/O Configuration Register 2 IOCR2 03 R/W T1 Receive Control Register 1 T1RCR1 04 R/W T1 Receive Control Register 2 T1RCR2 05 R/W T1 Transmit Control Register 1 T1TCR1 06 R/W T1 Transmit Control Register 2 T1TCR2 07 R/W T1 Common Control Register T1CCR 08 R/W Mode Configuration Register MCREG 09 R/W Transmit PLL Control Register TPCR

0A — Reserved — 0B — Reserved — 0C — Reserved — 0D — Reserved — 0E — Reserved —

0F — Reserved — 10 R Device Identification Register IDR 11 R Information Register 1 INFO1 12 R Information Register 2 INFO2 13 R Interrupt Information Register IIR 14 R Status Register 1 SR1 15 R/W Interrupt Mask Register 1 IMR1 16 R Status Register 2 SR2 17 R/W Interrupt Mask Register 2 IMR2 18 R Status Register 3 SR3

19 R/W Interrupt Mask Register 3 IMR3 1A R Status Register 4 SR4 1B R/W Interrupt Mask Register 4 IMR4 1C R Information Register 3 INFO3 1D R/W E1 Receive Control Register E1RCR 1E R/W E1 Transmit Control Register E1TCR

1F R/W BOC Control Register BOCC

20 R/W Loopback Control Register LBCR

21-2F — Reserved —

30 R/W Line Interface Control 1 LIC1

31 R/W Line Interface Control 2 LIC2

32 R/W Line Interface Control 3 LIC3

33 R/W Line Interface Control 4 LIC4

34 R/W Transmit Line Build-Out Control TLBC

35-3F — Reserved —

40 R/W Transmit Align Frame Register TAF

41 R/W Transmit Non-Align Frame Register TNAF

42 R/W Transmit Si Align Frame TSiAF

ABBREVIATION

32 of 123

DS26503 T1/E1/J1 BITS Element

ADDRESS TYPE REGISTER NAME

ABBREVIATION

43 R/W Transmit Si Non-Align Frame TSiNAF

44 R/W Transmit Remote Alarm Bits TRA

45 R/W Transmit Sa4 Bits TSa4

46 R/W Transmit Sa5 Bits TSa5

47 R/W Transmit Sa6 Bits TSa6

48 R/W Transmit Sa7 Bits TSa7

49 R/W Transmit Sa8 Bits TSa8 4A R/W Transmit Sa Bit Control Register TSACR

4B-4F — Reserved —

50 R Receive FDL Register RFDL

51 R/W Transmit FDL Register TFDL

52 R/W Receive Facility Data Link Match Register 1 RFDLM1

53 R/W Receive Facility Data Link Match Register 2 RFDLM2

54-55 — Reserved —

56 R Receive Align Frame Register RAF

57 R Receive Non-Align Frame Register RNAF

58 R Receive Si Align Frame RSiAF

59 R Receive Si Non-Align Frame RSiNAF 5A R Receive Remote Alarm Bits RRA 5B R Receive Sa4 Bits RSa4 5C R Receive Sa5 Bits RSa5 5D R Receive Sa6 Bits RSa6 5E R Receive Sa7 Bits RSa7

5F R Receive Sa8 Bits RSa8

60-EF — Reserved —

F0 R/W Test Register 1 TEST1*

F1 R/W Test Register 2 TEST2*

F2 R/W Test Register 3 TEST3*

F3 R/W Test Register 4 TEST4*

F4 R/W Test Register 5 TEST5*

F5 R/W Test Register 6 TEST6*

F6 R/W Test Register 7 TEST7*

F7 R/W Test Register 8 TEST8*

F8 R/W Test Register 9 TEST9*

F9 R/W Test Register 10 TEST10* FA R/W Test Register 11 TEST11* FB R/W Test Register 12 TEST12* FC R/W Test Register 13 TEST13* FD R/W Test Register 14 TEST14* FE R/W Test Register 15 TEST15* FF R/W Test Register 16 TEST16*

*TEST1 to TEST16 registers are used only by the factory.

33 of 123

DS26503 T1/E1/J1 BITS Element

7.3.1 Power-Up Sequence

The DS26503 contains an on-chip power-up reset function, which automatically clears the writeable register space immediately after power is supplied to the device. The user can issue a chip reset at any time. Issuing a reset will disrupt signals flowing through the DS26503 until the device is reprogrammed. The reset can be issued through hardware using the TSTRST pin or through software using the SFTRST function in the master mode register. The LIRST (LIC2.6) should be toggled from zero to one to reset the line interface circuitry. (It will take the DS26503 about 40ms to recover from the LIRST bit being toggled.)

7.3.2 Test Reset Register

Bit # 7 6 5 4 3 2 1 0 Name — — TEST1 TEST0 — — — SFTRST Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Software Issued Reset (SFTRST). A zero-to-one transition causes the register space in the DS26503 to be cleared. A reset clears all configuration and status registers. The bit automatically clears itself when the reset has completed.

Bits 1-3/Unused, must be set = 0 for proper operation.

Bits 4-5/Test Mode Bits (TEST0, TEST1). Test modes are used to force the output pins of the DS26503 into known states.

This can facilitate the checkout of assemblies during the manufacturing process and also be used to isolate devices from shared buses.

TEST1 TEST0 Effect On Output Pins

0 0 Operate normally 0 1 Force all output pins into tri-state (including all I/O pins and parallel port pins) 1 0 Force all output pins low (including all I/O pins except parallel port pins) 1 1 Force all output pins high (including all I/O pins except parallel port pins)

Bits 6-7/Unused, must be set = 0 for proper operation.

X X X X X X X X

TSTRREG Test Reset Register 00h

34 of 123

DS26503 T1/E1/J1 BITS Element

7.3.3 Mode Configuration Register

Bit # 7 6 5 4 3 2 1 0 Name TMODE3 TMODE2 TMODE1 TMODE0 RMODE3 RMODE2 RMODE1 RMODE0 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0-3/Receive Mode Configuration (RMODE[3:0]). Used to select the operating mode of the receive path for the DS26503.

TMODE3

PIN 62

RMODE3 RMODE2 RMODE1 RMODE0 Receive Path Operating Mode

MCREG Mode Configuration Register 08h

TMODE2

PIN 48

TMODE1

PIN 49

TMODE0

PIN 14

RMODE3

PIN 64

RMODE2

PIN 61

RMODE1

PIN 4

RMODE0

PIN 3

35 of 123

DS26503 T1/E1/J1 BITS Element

Bit 4-7/ Transmit Mode Configuration (TMODE[3:0]). Used to select the operating mode of the transmit path for the DS26503.

TMODE3 TMODE2 TMODE1 TMODE0 Transmit Path Operating Mode

0 0 0 0 T1 D4 0 0 0 1 T1 ESF (Note: In this mode the TFSE (T1TCR2.6) bit should be

set = 0.) 0 0 1 0 J1 D4 0 0 1 1 J1 ESF 0 1 0 0 E1 FAS 0 1 0 0 E1 FAS + CAS (Note 1) 0 1 0 1 Reserved 0 1 1 0 E1 CRC4 0 1 1 0 E1 CRC4 + CAS (Note 1) 0 1 1 1 Reserved 1 0 0 0 E1 G.703 2048 kHz Synchronization Interface 1 0 0 1 Reserved 1 0 1 0 Reserved 1 0 1 1 6312kHz Synchronization Interface (Note 2) 1 1 0 0 Reserved 1 1 0 1 Reserved

Note 1:

Note 2:

The DS26503 does not have an internal source for CAS signaling and multiframe alignment generation. CAS signaling, and the

multiframe alignment word, must be embedded in the transmit data (in the TS16 position) present on the TSER pin and frame aligned to sync signal on the TS pin.

In addition to setting the TMODE bits to 6312kHz Synchronization Interface mode, the Transmit PLL must also be configured to

transmit a 6312kHz signal through the Transmit PLL Control Register (TPCR.6 and TPCR.7)

TPCR Transmit PLL Control Register 09h

Bit # 7 6 5 4 3 2 1 0 Name TPLLOFS0 TPLLOFS1 PLLOS TPLLIFS0 TPLLIFS1 TPLLSS TCSS1 TCSS0 Default 0 0 0 0 0 0 0 0 HW Mode

0 0 0 0 0 0

TCSS1 PIN 31

TCSS0 PIN 63

For more information on all the bits in the Transmit PLL control register, refer to Figure 3-3

Bit 0-1/Transmit Clock (TX CLOCK) Source Select (TCSS[1:0]). These bits control the output of the TX PLL Clock Mux function. See Figure 3-3

TCSS1 TCSS0

Transmit Clock (TX CLOCK) Source

(See Figure 3-3

)

0 0 The TCLK pin is the source of transmit clock. 0 1 The PLL_CLK is the source of transmit clock. 1 0 The scaled signal present at MCLK as the transmit clock. 1 1 The signal present at RCLK is the transmit clock.

Bit 2/Transmit PLL_CLK Source Select (TPLLSS). Selects the reference signal for the TX PLL. 0 = Use the recovered network clock. This is the same clock available at the RCLK pin (output). 1 = Use the externally provided clock present at the TCLK pin.

36 of 123

DS26503 T1/E1/J1 BITS Element

Bit 3-4/Transmit PLL Input Frequency Select (TPLLIFS[1:0]). These bits are used to indicate the reference frequency being input to the TX PLL.

TPLLIFS1 TPLLIFS0 Input Frequency

0 0 1.544MHz 0 1 2.048MHz 1 0 — 1 1 6312kHz

Bit 5/ PLL_OUT Select (PLLOS). This bit selects the source for the PLL_OUT pin. See Figure 3-3

0 = PLL_OUT is sourced directly from the TX PLL. 1 = PLL_OUT is the output of the TX PLL mux.

Bit 6-7/Transmit PLL Output Frequency Select (TPLLOFS[1:0]). These bits are used to select the TX PLL output frequency.

TPLLOFS1 TPLLOFS0 Output Frequency

0 0 1.544MHz 0 1 2.048MHz 1 0 — 1 1 6312kHz

37 of 123

DS26503 T1/E1/J1 BITS Element

7.4 Interrupt Handling

Various alarms, conditions, and events in the DS26503 can cause interrupts. For simplicity, these are all referred to as events in this explanation. All STATUS registers can be programmed to produce interrupts. Each status register has an associated interrupt mask register. For example, SR1 (Status Register 1) has an interrupt control register called IMR1 (Interrupt Mask Register 1). Status registers are the only sources of interrupts in the DS26503. On power-up, all writeable registers are automatically cleared. Since bits in the IMRx registers have to be set = 1 to allow a particular event to cause an interrupt, no interrupts can occur until the host selects which events are to product interrupts. Since there are potentially many sources of interrupts on the DS26503, several features are available to help sort out and identify which event is causing an interrupt. When an interrupt occurs, the host should first read the IIR register (interrupt information register) to identify which status register(s) is producing the interrupt. Once that is determined, the individual status register or registers can be examined to determine the exact source.

Once an interrupt has occurred, the interrupt handler routine should clear the IMRx registers to stop further activity on the interrupt pin. After all interrupts have been determined and processed, the interrupt hander routine should restore the state of the IMRx registers.

7.5 Status Registers

When a particular event or condition has occurred (or is still occurring in the case of conditions), the appropriate bit in a status register will be set to a one. All the status registers operate in a latched fashion, which means that if an event or condition occurs a bit is set to a one. It will remain set until the user reads that bit. An event bit will be cleared when it is read and it will not be set again until the event has occurred again. Condition bits such as RLOS, etc., will remain set if the alarm is still present.

The user will always precede a read of any of the status registers with a write. The byte written to the register will inform the DS26503 which bits the user wishes to read and have cleared. The user will write a byte to one of these registers, with a one in the bit positions he or she wishes to read and a zero in the bit positions he or she does not wish to obtain the latest information on. When a one is written to a bit location, the read register will be updated with the latest information. When a zero is written to a bit position, the read register will not be updated and the previous value will be held. A write to the status registers will be immediately followed by a read of the same register. This write-read scheme allows an external microcontroller or microprocessor to individually poll certain bits without disturbing the other bits in the register. This operation is key in controlling the DS26503 with higher-order languages.

Status register bits are divided into two groups: condition bits and event bits. Condition bits are typically network conditions such as loss of frame, or all-ones detect. Event bits are typically markers such as the one-second timer. Each status register bit is labeled as a condition or event bit. Some of the status registers have bits for both the detection of a condition and the clearance of the condition. For example, SR2 has a bit that is set when the device goes into a loss of frame state (SR2.0, a condition bit) and a bit that is set (SR2.4, an event bit) when the loss of frame condition clears (goes in sync). Some of the status register bits (condition bits) do not have a separate bit for the “condition clear” event but rather the status bit can produce interrupts on both edges, setting, and clearing. These bits are marked as “double interrupt bits.” An interrupt will be produced when the condition occurs and when it clears.

38 of 123

DS26503 T1/E1/J1 BITS Element

7.6 Information Registers

Information registers operate the same as status registers except they cannot cause interrupts. INFO3 register is a read-only register and it reports the status of the E1 synchronizer in real time. INFO3 information bits are not latched, and it is not necessary to precede a read of these bits with a write.

7.7 Interrupt Information Registers

The Interrupt Information Registers provide an indication of which Status Registers (SR1 through SR3) are generating an interrupt. When an interrupt occurs, the host can read IIR to quickly identify which of the three status registers are causing the interrupt.

Bit # 7 6 5 4 3 2 1 0 Name — — — — SR4 SR3 SR2 SR1 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Status Register 1 (SR1).

Bit 1/Status Register 2 (SR2).

Bit 2/Status Register 3 (SR3).

Bit 3/Status Register 4 (SR4).

Bit 4/Unused.

Bit 5/Unused.

Bit 6/Unused.

Bit 7/Unused.

X X X X X X X X

0 = Status Register 1 interrupt not active. 1 = Status Register 1 interrupt active.

IIR Interrupt Information Register 13h

39 of 123

DS26503 T1/E1/J1 BITS Element

8. T1 FRAMER/FORMATTER CONTROL REGISTERS

The T1 framer portion of the DS26503 is configured via a set of five control registers. Typically, the control registers are only accessed when the system is first powered up. Once the DS26503 has been initialized, the control registers will only need to be accessed when there is a change in the system configuration. There are two receive control registers (T1RCR1 and T1RCR2), two transmit control registers (T1TCR1 and T1TCR2), and a common control register (T1CCR). Each of these registers is described in this section.

8.1 T1 Control Registers

Bit # 7 6 5 4 3 2 1 0 Name — ARC OOF1 OOF2 SYNCC SYNCT SYNCE RESYNC Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Resynchronize (RESYNC). When toggled from low to high, a resynchronization of the receive side framer is initiated. Must be cleared and set again for a subsequent resync.

Bit 1/Sync Enable (SYNCE).

0 = auto resync enabled 1 = auto resync disabled

Bit 2/Sync Time (SYNCT).

0 = qualify 10 bits 1 = qualify 24 bits

Bit 3/Sync Criteria (SYNCC).

In D4 Framing Mode:

0 = search for Ft pattern, then search for Fs pattern 1 = cross couple Ft and Fs pattern In ESF Framing Mode: 0 = search for FPS pattern only 1 = search for FPS and verify with CRC6

Bits 4 to 5/Out Of Frame Select Bits (OOF2, OOF1).

OOF2 OOF1 Out Of Frame Criteria

0 0 2/4 frame bits in error 0 1 2/5 frame bits in error 1 0 2/6 frame bits in error 1 1 2/6 frame bits in error

Bit 6/Auto Resync Criteria (ARC).

0 = resync on OOF or RLOS event 1 = resync on OOF only

Bit 7/Unused, must be set = 0 for proper operation.

0 0 0 0 0 0 0 0

T1RCR1 T1 Receive Control Register 1 03h

40 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — — RB8ZS — — — RJC RD4YM Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive Side D4 Yellow Alarm Select (RD4YM).

Bit 1/Receive Japanese CRC6 Enable (RJC).

Bit 2/Unused, must be set = 0 for proper operation.

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/Unused, must be set = 0 for proper operation.

Bit 5/Receive B8ZS Enable (RB8ZS).

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/Unused, must be set = 0 for proper operation.

0 0

0 = zeros in bit 2 of all channels 1 = a one in the S-bit position of frame 12 (J1 Yellow Alarm Mode)

0 = use ANSI/AT&T/ITU CRC6 calculation (normal operation) 1 = use Japanese standard JT–G704 CRC6 calculation

0 = B8ZS disabled 1 = B8ZS enabled

T1RCR2 T1 Receive Control Register 2 04h

HBE

PIN55

0 0 0 0 0

41 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TJC TFPT TCPT — — — — TYEL Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Transmit Yellow Alarm (TYEL).

Bit 1/Unused, must be set = 0 for proper operation.

Bit 2/Unused, must be set = 0 for proper operation.

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/Unused, must be set = 0 for proper operation.

Bit 5/Transmit CRC Pass-Through (TCPT).

Bit 6/Transmit F-Bit Pass-Through (TFPT).

Bit 7/Transmit Japanese CRC6 Enable (TJC).

RMODEx

PINS

0 = do not transmit yellow alarm 1 = transmit yellow alarm

0 = source CRC6 bits internally 1 = CRC6 bits sampled at TSER during F-bit time

0 = F bits sourced internally 1 = F bits sampled at TSER

0 = use ANSI/AT&T/ITU CRC6 calculation (normal operation) 1 = use Japanese standard JT–G704 CRC6 calculation

T1TCR1 T1 Transmit Control Register 1 05h

0 0 0 0 0 0 0

42 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TB8ZS TFSE — FBCT2 FBCT1 TD4YM — TB7ZS Default 0 1 0 0 0 0 0 0 HW Mode

Bit 0/Transmit-Side Bit 7 Zero-Suppression Enable (TB7ZS).

Bit 1/Unused, must be set = 0 for proper operation.

Bit 2/Transmit-Side D4 Yellow Alarm Select (TD4YM).

Bit 3/F-Bit Corruption Type 1 (FBCT1). A low-to-high transition of this bit causes the next three consecutive Ft (D4

framing mode) or FPS (ESF framing mode) bits to be corrupted causing the remote end to experience a loss of frame (loss of synchronization).

Bit 4/F-Bit Corruption Type 2 (FBCT2). Setting this bit high enables the corruption of one Ft (D4 framing mode) or FPS (ESF framing mode) bit in every 128 Ft or FPS bits as long as the bit remains set.

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Transmit Fs-Bit Insertion Enable (TFSE). Only set this bit to a 1 in D4 framing applications. Must be set to 1 to

source the Fs pattern from the TFDL register. In all other modes this bit must be set = 0.

Bit 7/Transmit B8ZS Enable (TB8ZS).

HBE

PIN 55

0 = no stuffing occurs 1 = bit 7 forced to a 1 in channels with all 0s

0 = 0s in bit 2 of all channels 1 = a 1 in the S-bit position of frame 12

0 = Fs-bit insertion disabled 1 = Fs-bit insertion enabled

0 = B8ZS disabled 1 = B8ZS enabled

T1TCR2 T1 Transmit Control Register 2 06h

1 0 0 0 0 0 0

43 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — — — TRAI-CI TAIS-CI — PDE — Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Unused, must be set = 0 for proper operation.

Bit 1/Pulse-Density Enforcer Enable (PDE). The framer always examines the transmit and receive data streams for

violations of these, which are required by ANSI T1.403: No more than 15 consecutive zeros and at least N ones in each and every time window of 8 x (N + 1) bits, where N = 1 through 23. When this bit is set to one, the DS26503 forces the transmitted stream to meet this requirement no matter the content of the transmitted stream. When running B8ZS, this bit should be set to zero, as B8ZS encoded data streams cannot violate the pulse-density requirements.

Bit 2/Unused, must be set = 0 for proper operation.

Bit 3/Transmit AIS-CI Enable (TAIS-CI). Setting this bit causes the AIS-CI code to be transmitted from the framer to the

LIU, as defined in ANSI T1.403.

Bit 4/Transmit RAI-CI Enable (TRAI-CI). Setting this bit causes the ESF RAI-CI code to be transmitted in the FDL bit position.

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/Unused, must be set = 0 for proper operation.

0 0 0 0 0 0 0 0

0 = disable transmit pulse-density enforcer 1 = enable transmit pulse-density enforcer

0 = do not transmit the AIS-CI code 1 = transmit the AIS-CI code

0 = do not transmit the ESF RAI-CI code 1 = transmit the ESF RAI-CI code

T1CCR T1 Common Control Register 07h

44 of 123

Table 8-1. T1 Alarm Criteria

ALARM SET CRITERIA CLEAR CRITERIA

DS26503 T1/E1/J1 BITS Element

Blue Alarm (AIS) (Note 1) Over a 3ms window, five or

fewer zeros are received

Yellow Alarm (RAI)

D4 Bit-2 Mode (T1RCR2.0 = 0)

D4 12th F-bit Mode (T1RCR2.0 = 1; this mode is also referred to as the “Japanese Yellow Alarm”)

ESF Mode

Bit 2 of 256 consecutive channels is set to zero for at least 254 occurrences

12th framing bit is set to one for two consecutive occurrences

16 consecutive patterns of

00FF appear in the FDL Red Alarm (RLOS) (Also referred to as Loss Of Signal)

192 consecutive zeros are

received

Over a 3ms window, six or more zeros are received

Bit 2 of 256 consecutive channels is set to zero for less than 254 occurrences

12th framing bit is set to zero for two consecutive occurrences

14 or fewer patterns of 00FF hex out of 16 possible appear in the FDL 14 or more ones out of 112 possible bit positions are received, starting with the first one received

Note: The definition of Blue Alarm (or Alarm Indication Signal) is an unframed, all-ones signal. Blue Alarm detectors should be able to operate properly in the presence of a 10E-3 error rate, and they should not falsely trigger on a framed, all-ones signal. The Blue Alarm criteria in the DS26503 has been set to achieve this performance.

45 of 123

DS26503 T1/E1/J1 BITS Element

9. E1 FRAMER/FORMATTER CONTROL REGISTERS

The E1 framer portion of the DS26503 is configured via a set of two control registers. Typically, the control registers are only accessed when the system is first powered up. Once the DS26503 has been initialized, the control registers will only need to be accessed when there is a change in the system configuration. There is one receive control register (E1RCR) and one transmit control register (E1TCR). There are also two information registers and a status register, as well as an interrupt mask register. Each of these registers is described in this section.

9.1 E1 Control Registers

Bit # 7 6 5 4 3 2 1 0 Name — RLOSA RHDB3 — — FRC SYNCE RESYNC Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Resync (RESYNC). When toggled from low to high, a resync is initiated. Must be cleared and set again for a subsequent resync.

Bit 1/Sync Enable (SYNCE).

Bit 2/Frame Resync Criteria (FRC).

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/Unused, must be set = 0 for proper operation.

Bit 5/Receive HDB3 Enable (RHDB3).

Bit 6/Receive Loss Of Signal (RLOS). Alternate Criteria (RLOSA). Defines the criteria for a Receive Loss Of Signal condition.

Bit 7/Unused, must be set = 0 for proper operation.

0 0

0 = auto resync enabled 1 = auto resync disabled

0 = resync if FAS received in error three consecutive times 1 = resync if FAS or bit 2 of non-FAS is received in error three consecutive times

0 = HDB3 disabled 1 = HDB3 enabled

0 = RLOS declared upon 255 consecutive zeros (125µs) 1 = RLOS declared upon 2048 consecutive zeros (1ms)

E1RCR E1 Receive Control Register 1Dh

HBE

PIN 55

0 0 0 0 0

46 of 123

DS26503 T1/E1/J1 BITS Element

Table 9-1. E1 Sync/Resync Criteria

FRAME OR

MULTIFRAME

LEVEL

FAS FAS present in frame N and

CRC4 Two valid MF alignment

CAS Valid MF alignment word

Bit # 7 6 5 4 3 2 1 0 Name TFPT — — TSiS — — THDB3 — Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Unused, must be set = 0 for proper operation.

Bit 1/Transmit HDB3 Enable (THDB3).

Bit 2/Unused, must be set = 0 for proper operation.

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/ Transmit International Bit Select (TSiS)

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/ Transmit Time Slot 0 Pass-Through (TFPT)

0 0 0 0 0 0

0 = HDB3 disabled 1 = HDB3 enabled

0 = sample Si bits at TSER pin 1 = source Si bits from TAF and TNAF registers (in this mode, E1TCR1.7 must be set to 0)

0 = FAS bits/Sa bits/remote alarm sourced internally from the TAF and TNAF registers 1 = FAS bits/Sa bits/remote alarm sourced from TSER

SYNC CRITERIA RESYNC CRITERIA ITU SPEC.

Three consecutive incorrect FAS N + 2, and FAS not present in frame N + 1

received

Alternate: (E1RCR.2 = 1) The above

criteria is met or three consecutive

incorrect bit 2 of non-FAS received

915 or more CRC4 code words out of words found within 8ms

1000 received in error

4.2 and 4.3.2

Two consecutive MF alignment found and previous time slot

words received in error 16 contains code other than all zeros

E1TCR E1 Transmit Control Register 1Eh

HBE

PIN 55

G.732 5.2

G.706

4.1.1

4.1.2

G.706

47 of 123

DS26503 T1/E1/J1 BITS Element

9.2 E1 Information Registers

Bit # 7 6 5 4 3 2 1 0 Name — — — — — CRCRC FASRC CASRC Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/CAS Resync Criteria Met Event (CASRC). Set when two consecutive CAS MF alignment words are received in error.

Bit 1/FAS Resync Criteria Met Event (FASRC. Set when three consecutive FAS words are received in error.

Bit 2/CRC Resync Criteria Met Event (CRCRC). Set when 915/1000 codewords are received in error.

Bit 3/Unused.

Bit 4/Unused.

Bit 5/Unused.

Bit 6/Unused.

Bit 7/Unused.

Bit # 7 6 5 4 3 2 1 0 Name CSC5 CSC4 CSC3 CSC2 CSC0 FASSA CASSA CRC4SA Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/CRC4 MF Sync Active (CRC4SA). Set while the synchronizer is searching for the CRC4 MF alignment word.

Bit 1/CAS MF Sync Active (CASSA). Set while the synchronizer is searching for the CAS MF alignment word.

Bit 2/FAS Sync Active (FASSA). Set while the synchronizer is searching for alignment at the FAS level.

Bit 3-7/CRC4 Sync Counter Bits (CSC0 and CSC2 to CSC4). The CRC4 sync counter increments each time the 8ms-CRC4

multiframe search times out. The counter is cleared when the framer has successfully obtained synchronization at the CRC4 level. The counter can also be cleared by disabling the CRC4 mode (E1RCR.3 = 0). This counter is useful for determining the amount of time the framer has been searching for synchronization at the CRC4 level. ITU G.706 suggests that if synchronization at the CRC4 level cannot be obtained within 400ms, then the search should be abandoned and proper action taken. The CRC4 sync counter will rollover. CSC0 is the LSB of the 6-bit counter. (Note: The second LSB, CSC1, is not accessible. CSC1 is omitted to allow resolution to >400ms using 5 bits.)

X X X X X X X X

INFO2 Information Register 2 12h

INFO3 Information Register 3 (Real Time) 1Ch

48 of 123

Table 9-2. E1 Alarm Criteria

DS26503 T1/E1/J1 BITS Element

ALARM SET CRITERIA CLEAR CRITERIA

RLOF

An RLOF condition exists on power-up

ITU

SPEC.

prior to initial synchronization, when a resync criteria has been met, or when a manual resync has been initiated via E1RCR.0

RLOS

RRA

255 or 2048 consecutive zeros received as determined by E1RCR.0

Bit 3 of non-align frame set to one for three consecutive occasions

In 255-bit times, at least 32 ones are received

Bit 3 of non-align frame set to zero for three consecutive

G.775/G.962

O.162

2.1.4

occasions

RUA1

RDMA

Fewer than three zeros in two frames (512 bits)

Bit 6 of time slot 16 in frame 0 has been

More than two zeros in two frames (512 bits)

O.162

1.6.1.2

set for two consecutive multiframes

V52LNK

Two out of three Sa7 bits are zero G.965

Bit # 7 6 5 4 3 2 1 0 Name ID7 ID6 ID5 ID4 ID3 ID2 ID1 ID0 Default 0 0 0 1 N N N N HW Mode

Bits 0-3/Chip Revision Bits (ID0 to ID3). The lower four bits of the IDR are used to display the die revision of the chip. IDO is the LSB of a decimal code that represents the chip revision.

Bits 4-7/Device ID (ID4 to ID7). The upper four bits of the IDR are used to display the DS26503 ID. The DS26503 ID is

0001.

X X X X X X X X

IDR Device Identification Register 10h

49 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name RYELC RAISC RLOSC RLOFC RYEL RAIS RLOS RLOF Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive Loss of Frame Condition (RLOF). Set when the DS26503 is not synchronized to the received data stream.

Bit 1/Receive Loss Of Signal Condition (RLOS). Set when 255 (or 2048 if E1RCR.6 = 1) E1 mode or 192 T1 mode

consecutive zeros have been detected. In 6312kHz Synchronization Interface Mode, this bit will be set when the signal received is out of range as defined by the G.703 Appendix II specification.

Bit 2/Receive Alarm Indication Signal (T1= Blue Alarm, E1= AIS) Condition (RAIS). Set when an unframed all-ones code is received.

Bit 3/Receive Yellow Alarm Condition (RYEL). (T1 only) Set when a yellow alarm is received.

Bit 4/Receive Loss of Frame Clear Event (RLOFC). Set when the framer achieves synchronization; will remain set until

read.

Bit 5/Receive Loss Of Signal Clear Event (RLOSC). Set when loss of signal condition is no longer detected.

Bit 6/Receive Alarm Indication Signal Clear Event (RAISC). Set when the unframed all-ones condition is no longer

detected.

Bit 7/Receive Yellow Alarm Clear Event (RYELC). (T1 only) Set when the yellow alarm condition is no longer detected

X X X X X

SR2 Status Register 2 16h

RAIS

PIN 29

RLOS

PIN 32

LOF

PIN 30

50 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name RYELC RAISC RLOSC RLOFC RYEL RAIS RLOS RLOF Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive Loss of Frame Condition (RLOF). 0 = interrupt masked 1 = interrupt enabled–interrupts on rising edge only

Bit 1/Receive Loss Of Signal Condition (RLOS).

1 = interrupt enabled–interrupts on rising edge only

Bit 2/Receive Alarm Indication Signal Condition (RAIS).

1 = interrupt enabled–interrupts on rising edge only

Bit 3/Receive Yellow Alarm Condition (RYEL).

1 = interrupt enabled–interrupts on rising edge only

Bit 4/Receive Loss of Frame Clear Event (RLOFC).

1 = interrupt enabled

Bit 5/Receive Loss Of Signal Condition Clear (RLOSC).

1 = interrupt enabled

Bit 6/Receive Alarm Indication Signal Clear Event (RAISC).

1 = interrupt enabled

Bit 7/Receive Yellow Alarm Clear Event (RYELC).

1 = interrupt enabled

X X X X X X X X

0 = interrupt masked

IMR2 Interrupt Mask Register 2 17h

51 of 123

DS26503 T1/E1/J1 BITS Element

10. I/O PIN CONFIGURATION OPTIONS

Bit # 7 6 5 4 3 2 1 0 Name — RSMS2 RSMS1 RLOFF TSDW TSM TSIO ODF Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Output Data Format (ODF).

0 = bipolar data at TPOS and TNEG 1 = NRZ data at TPOS; TNEG = 0

Bit 1/TS I/O Select (TSIO). This bit determines whether the TS pin is an input or and output. See Table 10-1

0 = TS is an input 1 = TS is an output

Bit 2/TS Mode Select (TSM). In T1 or E1 operation, selects frame or multiframe mode for the TS pin. In 6312kHz mode, this bit should be set = 0. See Table 10-1

0 = frame mode 1 = multiframe mode

Bit 3/Transmit Signaling Double-Wide Sync (TSDW). In T1 mode, setting this bit = 1 and setting TSIO = 1 will cause the sync-pulse output on TS to be two clocks wide during signaling frames. In E1 or 6312kHz mode, this bit should be set = 0. See

Table 10-1

0 = (T1) normal sync pulses 1 = (T1) double-wide sync pulses during signaling frames

Bit 4/ RLOF Output Function (RLOFF). In T1 or E1 receive mode this bit determines the function of the RLOF pin. In 6312kHz receive mode, this bit should be set = 0.

0 = receive loss of frame (RLOF) 1 = loss-of-transmit clock (LOTC)

Bit 5/RS Mode Select 1(RSMS1). In T1 or E1 receive mode, this bit selects a frame or multiframe output pulse at RS pin. IOCR.6 may be used to select other function for the RS pin.

0 = frame mode 1 = multiframe mode

Bit 6/RS Mode Select 2 (RSMS2). In T1 and E1 receive mode, this bit along with IOCR.5 selects the function of the RS pin.

T1 Mode: (when IOCR.5 set = 0)

E1 Mode: (when IOCR.5 set = 1)

Bit 7/Unused, must be set = 0 for proper operation

0 0

0 = do not pulse double-wide in signaling frames 1 = do pulse double-wide in signaling frames

0 = RS outputs CAS multiframe boundaries 1 = RS outputs CRC4 multiframe boundaries

IOCR1 I/O Configuration Register 1 01h

RSM

PIN 1

0 0

TSM

PIN 2

0 0

52 of 123

Table 10-1. TS Pin Functions

DS26503 T1/E1/J1 BITS Element

TRANSMIT

MODE

T1/E1 0 0 0 Frame sync input T1/E1 0 0 1 Frame sync output T1/E1 0 1 0 Multiframe sync input T1/E1 0 1 1 Multiframe sync output

IOCR.3 IOCR.2 IOCR.1

FUNCTION

Table 10-2. RLOF Pin Functions

RECEIVE

MODE

T1/E1 0 Indicate loss of frame T1/E1 1 Indicates loss of transmit clock

IOCR.4 RLOF PIN FUNCTION

53 of 123

DS26503 T1/E1/J1 BITS Element

IOCR2 I/O Configuration Register 2 02h

Bit # 7 6 5 4 3 2 1 0 Name

RCLKINV TCLKINV RSINV

TSINV — — — —

Default 0 0 0 0 0 0 0 0 HW Mode

0 0 0 0 0 0 0 0

Bit 0/Unused, must be set = 0 for proper operation.

Bit 1/Unused, must be set = 0 for proper operation.

Bit 2/Unused, must be set = 0 for proper operation.

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/TS Invert (TSINV).

0 = no inversion 1 = invert

Bit 5/RS Invert (RSINV).

0 = no inversion 1 = invert

Bit 6/TCLK Invert (TCLKINV).

0 = no inversion 1 = invert

Bit 7/RCLK Invert (RCLKINV).

0 = no inversion 1 = invert

54 of 123

11. T1 SYNCHRONIZATION STATUS MESSAGE

The DS26503 has a BOC controller to handle SSM services in T1 mode.

Table 11-1. T1 SSM Messages

DS26503 T1/E1/J1 BITS Element

QUALITY

LEVEL

1 Stratum 1 Traceable 0000010011111111 2 Synchronized Traceablity Unknown 0000100011111111 3 Stratum 2 Traceable 0000110011111111 4 Stratum 3 Traceable 0001000011111111 5 SONET Minimum Clock Traceable 0010001011111111 6 Stratum 4 Traceable 0010100011111111 7 Do Not Use For Synchronization 0011000011111111

User Assignable Reserved For Network Synchronization Use 0100000011111111

DESCRIPTION BOC CODE

11.1 T1 Bit-Oriented Code (BOC) Controller

The DS26503 contains a BOC generator on the transmit side and a BOC detector on the receive side. The BOC function is available only in T1 mode. In typical BITS applications, the BOC controller would be used to transmit and receive Synchronization Status Messages in T1 mode over the data link.

11.2 Transmit BOC

Bits 0 through 5 in the TFDL register contain the BOC or synchronization status message to be transmitted. Setting BOCC.0 = 1 causes the transmit BOC controller to immediately begin inserting the BOC sequence into the FDL bit position. The transmit BOC controller automatically provides the abort sequence. BOC messages will be transmitted as long as BOCC.0 is set. TFSE (T1TCR2.6) must be set = 0 when using the transmit BOC function.

To transmit a BOC, use the following:

1) Write 6-bit code into the TFDL register.

2) Set SBOC bit in BOCC register = 1.

55 of 123

DS26503 T1/E1/J1 BITS Element

11.3 Receive BOC

The receive BOC function is enabled by setting BOCC.4 = 1. The RFDL register will now operate as the receive BOC message and information register. The lower six bits of the RFDL register (BOC message bits) are preset to all ones. When the BOC bits change state, the BOC change of state indicator, SR3.0 will alert the host. The host will then read the RFDL register to get the BOC message. A change of state will occur when either a new BOC code has been present for time determined by the receive BOC filter bits, RBF0 and RBF1, in the BOCC register.

To receive a BOC, use the following:

1) Set integration time via BOCC.1 and BOCC.2.

2) Enable the receive BOC function (BOCC.4 = 1).

3) Enable interrupt (IMR3.0 = 1).

4) Wait for interrupt to occur.

5) Read the RFDL register.

6) The lower six bits of the RFDL register is the message.

56 of 123

DS26503 T1/E1/J1 BITS Element

BOCC BOC Control Register 1Fh

Bit # 7 6 5 4 3 2 1 0 Name — — — RBOCE RBR RBF1 RBF0 SBOC Default 0 0 0 0 0 0 0 0 HW Mode

0 0 0 0 0 0 0 0

Bit 0/Send BOC (SBOC). Set = 1 to transmit the BOC code placed in bits 0 to 5 of the TFDL register.

Bits 1-2/Receive BOC Filter Bits (RBF0, RBF1). The BOC filter sets the number of consecutive patterns that must be

received without error prior to an indication of a valid message.

RBF1 RBF0

CONSECUTIVE BOC CODES FOR VALID

SEQUENCE IDENTIFICATION

0 0 None 0 1 3 1 0 5 1 1 7

Bit 3/Receive BOC Reset (RBR). A 0-to-1 transition will reset the BOC circuitry. Must be cleared and set again for a subsequent reset.

Bit 4/Receive BOC Enable (RBOCE). Enables the receive BOC function. The RFDL register will report the received BOC code. 0 = receive BOC function disabled

1 = receive BOC function enabled. The RFDL register will report BOC messages

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/Unused, must be set = 0 for proper operation.

57 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — — RBOC5 RBOC4 RBOC3 RBOC2 RBOC1 RBOC0 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/BOC Bit 0 (RBOC0).

Bit 1/BOC Bit 1 (RBOC1).

Bit 2/BOC Bit 2 (RBOC2).

Bit 3/BOC Bit 3 (RBOC3).

Bit 4/BOC Bit 4 (RBOC4).

Bit 5/BOC Bit 5 (RBOC5).

Bit 6/This bit position is unused when BOCC.4 = 1.

Bit 7/This bit position is unused when BOCC.4 = 1.

0 0 0 0 0 0 0 0

Receive FDL Register 50h

RFDLM1, RFDLM2 Receive FDL Match Register 1 Receive FDL Match Register 2 52h, 53h

Bit # 7 6 5 4 3 2 1 0 Name RFDLM7 RFDLM6 RFDLM5 RFDLM4 RFDLM3 RFDLM2 RFDLM1 RFDLM0 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive FDL Match Bit 0 (RFDLM0). LSB of the FDL Match Code.

Bit 1/Receive FDL Match Bit 1 (RFDLM1).

Bit 2/Receive FDL Match Bit 2 (RFDLM2).

Bit 3/Receive FDL Match Bit 3 (RFDLM3).

Bit 4/Receive FDL Match Bit 4 (RFDLM4).

Bit 5/Receive FDL Match Bit 5 (RFDLM5).

Bit 6/Receive FDL Match Bit 6 (RFDLM6).

Bit 7/Receive FDL Match Bit 7 (RFDLM7). MSB of the FDL Match Code.

0 0 0 0 0 0 0 0

58 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name RAIS-CI LOTC BOCC RFDLAD RFDLF TFDLE RMTCH RBOC Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive BOC Detector Change-of-State Event (RBOC). Set whenever the BOC detector sees a change of state to a valid BOC. The setting of this bit prompts the user to read the RFDL register.

Bit 1/Receive FDL Match Event (RMTCH). Set whenever the contents of the RFDL register matches RFDLM1 or RFDLM2.

Bit 2/TFDL Register Empty Event (TFDLE). Set when the transmit FDL buffer (TFDL) empties.

Bit 3/RFDL Register Full Event (RFDLF). Set when the receive FDL buffer (RFDL) fills to capacity.

Bit 4/RFDL Abort Detect Event (RFDLAD). Set when eight consecutive ones are received on the FDL.

Bit 5/BOC Clear Event (BOCC). Set when 30 FDL bits occur without an abort sequence.

Bit 6/Loss Of Transmit Clock Event (LOTC). Set when the signal at the TCLK pin has not transitioned for approximately

15 periods of the scaled MCLK.

Bit 7/Receive AIS-CI Event (RAIS-CI) (T1 Only). Set when the receiver detects the AIS-CI pattern as defined in ANSI T1.403.

X X X X X X X X

SR3 Status Register 3 18h

59 of 123

DS26503 T1/E1/J1 BITS Element

IMR3 Interrupt Mask Register 3 19h

Bit # 7 6 5 4 3 2 1 0 Name RAIS-CI LOTC BOCC RFDLAD RFDLF TFDLE RMTCH RBOC Default 0 0 0 0 0 0 0 0 HW Mode

X X X X X X X X

Bit 0/Receive BOC Detector Change-of-State Event (RBOC).

0 = interrupt masked 1 = interrupt enabled

Bit 1/Receive FDL Match Event (RMTCH).

0 = interrupt masked 1 = interrupt enabled

Bit 2/TFDL Register Empty Event (TFDLE).

0 = interrupt masked 1 = interrupt enabled

Bit 3/RFDL Register Full Event (RFDLF).

0 = interrupt masked 1 = interrupt enabled

Bit 4/RFDL Abort Detect Event (RFDLAD).

0 = interrupt masked 1 = interrupt enabled

Bit 5/BOC Clear Event (BOCC).

0 = interrupt masked 1 = interrupt enabled

Bit 6/ Loss Of Transmit Clock Event (LOTC).

0 = interrupt masked 1 = interrupt enabled

Bit 7/Receive AIS-CI Event (RAIS-CI).

0 = interrupt masked 1 = interrupt enabled

60 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — RSA1 RSA0 TMF TAF RMF RCMF RAF Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive Align Frame Event (RAF). (E1 only) Set every 250µs at the beginning of align frames. Used to alert the host that Si and Sa bits are available in the RAF and RNAF registers.

Bit 1/Receive CRC4 Multiframe Event (RCMF). (E1 only) Set on CRC4 multiframe boundaries; will continue to be set every 2ms on an arbitrary boundary if CRC4 is disabled.

Bit 2/Receive Multiframe Event (RMF).

Bit 3/Transmit Align Frame Event (TAF). (E1 only) Set every 250µs at the beginning of align frames. Used to alert the host

that the TAF and TNAF registers need to be updated.

Bit 4/Transmit Multiframe Event (TMF).

Bit 5/Receive Signaling All Zeros Event (RSA0). (E1 only) Set when over a full MF, time slot 16 contains all zeros.

Bit 6/Receive Signaling All Ones Event (RSA1). (E1 only) Set when the contents of time slot 16 contains fewer than three zeros over 16 consecutive frames. This alarm is not disabled in the CCS signaling mode.

Bit 7/Unused.

X X X X X X X X

E1 Mode: Set every 2ms (regardless if CAS signaling is enabled or not) on receive multiframe boundaries. Used to alert the host that signaling data is available.

T1 Mode: Set every 1.5ms on D4 MF boundaries or every 3ms on ESF MF boundaries.

E1 Mode: Set every 2ms (regardless if CRC4 is enabled) on transmit multiframe boundaries. Used to alert the host that signaling data needs to be updated.

T1 Mode: Set every 1.5ms on D4 MF boundaries or every 3ms on ESF MF boundaries.

SR4 Status Register 4 1Ah

61 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — RSA1 RSA0 TMF TAF RMF RCMF RAF Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Receive Align Frame Event (RAF).

Bit 1/Receive CRC4 Multiframe Event (RCMF).

Bit 2/Receive Multiframe Event (RMF).

Bit 3/Transmit Align Frame Event (TAF).

Bit 4/Transmit Multiframe Event (TMF).

Bit 5/Receive Signaling All Zeros Event (RSA0).

Bit 6/Receive Signaling All Ones Event (RSA1).

Bit 7/Unused, must be set = 0 for proper operation.

X X X X X X X X

0 = interrupt masked 1 = interrupt enabled

IMR4 Interrupt Mask Register 4 1Bh

62 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TFDL7 TFDL6 TFDL5 TFDL4 TFDL3 TFDL2 TFDL1 TFDL0 Default 0 0 0 0 0 0 0 0 HW Mode

Note: Also used to insert Fs framing pattern in D4 framing mode.

The transmit FDL register (TFDL) contains the FDL information that is to be inserted on a byte-basis into the outgoing T1 data stream. The LSB is transmitted first.

Bit 0/Transmit FDL Bit 0 (TFDL0). LSB of the transmit FDL code.

Bit 1/Transmit FDL Bit 1 (TFDL1).

Bit 2/Transmit FDL Bit 2 (TFDL2).

Bit 3/Transmit FDL Bit 3 (TFDL3).

Bit 4/Transmit FDL Bit 4 (TFDL4).

Bit 5/Transmit FDL Bit 5 (TFDL5).

Bit 6/Transmit FDL Bit 6 (TFDL6).

Bit 7/Transmit FDL Bit 7 (TFDL7). MSB of the transmit FDL code.

0 0 0 1 1 1 0 0

TFDL Transmit FDL Register 51h

63 of 123

DS26503 T1/E1/J1 BITS Element

12. E1 SYNCHRONIZATION STATUS MESSAGE

The DS26503 provides access to both the transmit and receive Sa/Si bits. In E1, the Sa bits are used to transmit and receive the SSM. The primary method to access the Sa (and Si) bits is based on CRC4 multiframe access. An alternate method is based on double-frame access.

Table 12-1. E1 SSM Messages

QUALITY

LEVEL

0 Quality unknown (existing sync network) 0000 1 Reserved 0001 2 Rec. G.811 (Traceable to PRS) 0010 3 Reserved 0011 4 SSU-A (Traceable to SSU type A, see G.812) 0100 5 Reserved 0101 6 Reserved 0110 7 Reserved 0111 8 SSU-B (Traceable to SSU type B, see G.812) 1000

9 Reserved 1001 10 Reserved 1010 11 Synchronous Equipment Timing Source 1011 12 Reserved 1100 13 Reserved 1101 14 Reserved 1110 15 Do not use for synchronization 01111

DESCRIPTION

Sa BIT

MESSAGE

In E1 operation, SSMs are transmitted using one of the Sa bits—Sa4, Sa5, Sa6, Sa7, or Sa8. The SSM is transmitted MSB first in the first frame of the multiframe. Each multiframe will contain two SSMs, one in each sub-multiframe. An SSM is declared valid when the message in three sub-multiframes are alike.

12.1 Sa/Si Bit Access Based on CRC4 Multiframe

On the receive side, there is a set of eight registers (RSiAF, RSiNAF, RRA, RSa4 to RSa8) that report the Si and Sa bits as they are received. These registers are updated on CRC4 multiframes. A bit in status register 4 (SR4.1) indicates the multiframe boundary. The host can use the SR4.1 bit to know when to read these registers. The user has 2ms to retrieve the data before it is lost. The MSB of each register is the first received. See the following register descriptions for more details.

On the transmit side, there is also a set of eight registers (TSiAF, TSiNAF, TRA, TSa4 to TSa8) that, via the transmit Sa bit control register (TSaCR), can be programmed to insert both Si and Sa data. Data is sampled from these registers with the setting of the transmit multiframe bit in status register 2 (SR4.4). The host can use the SR4.4 bit to know when to update these registers. It has 2ms to update the data or else the old data will be retransmitted. The MSB of each register is the first bit transmitted. See the following register descriptions for details.

64 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name SiF0 SiF2 SiF4 SiF6 SiF8 SiF10 SiF12 SiF14 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Si Bit of Frame 14(SiF14).

Bit 1/Si Bit of Frame 12(SiF12).

Bit 2/Si Bit of Frame 10(SiF10).

Bit 3/Si Bit of Frame 8(SiF8).

Bit 4/Si Bit of Frame 6(SiF6).

Bit 5/Si Bit of Frame 4(SiF4).

Bit 6/Si Bit of Frame 2(SiF2).

Bit 7/Si Bit of Frame 0(SiF0).

Bit # 7 6 5 4 3 2 1 0 Name SiF1 SiF3 SiF5 SiF7 SiF9 SiF11 SiF13 SiF15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Si Bit of Frame 15(SiF15).

Bit 1/Si Bit of Frame 13(SiF13).

Bit 2/Si Bit of Frame 11(SiF11).

Bit 3/Si Bit of Frame 9(SiF9).

Bit 4/Si Bit of Frame 7(SiF7).

Bit 5/Si Bit of Frame 5(SiF5).

Bit 6/Si Bit of Frame 3(SiF3).

Bit 7/Si Bit of Frame 1(SiF1).

X X X X X X X X

RSiAF Receive Si Bits of the Align Frame 58h

RSiNAF Receive Si Bits of the Non-Align Frame 59h

65 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name RRAF1 RRAF3 RRAF5 RRAF7 RRAF9 RRAF11 RRAF13 RRAF15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Remote Alarm Bit of Frame 15(RRAF15).

Bit 1/Remote Alarm Bit of Frame 13(RRAF13).

Bit 2/Remote Alarm Bit of Frame 11(RRAF11).

Bit 3/Remote Alarm Bit of Frame 9(RRAF9).

Bit 4/Remote Alarm Bit of Frame 7(RRAF7).

Bit 5/Remote Alarm Bit of Frame 5(RRAF5).

Bit 6/Remote Alarm Bit of Frame 3(RRAF3).

Bit 7/Remote Alarm Bit of Frame 1(RRAF1).

Bit # 7 6 5 4 3 2 1 0 Name RSa4F1 RSa4F3 RSa4F5 RSa4F7 RSa4F9 RSa4F11 RSa4F13 RSa4F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa4 Bit of Frame 15(RSa4F15).

Bit 1/Sa4 Bit of Frame 13(RSa4F13).

Bit 2/Sa4 Bit of Frame 11(RSa4F11).

Bit 3/Sa4 Bit of Frame 9(RSa4F9).

Bit 4/Sa4 Bit of Frame 7(RSa4F7).

Bit 5/Sa4 Bit of Frame 5(RSa4F5).

Bit 6/Sa4 Bit of Frame 3(RSa4F3).

Bit 7/Sa4 Bit of Frame 1(RSa4F1).

X X X X X X X X

RRA Receive Remote Alarm 5Ah

RSa4 Receive Sa4 Bits 5Bh

66 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name RSa5F1 RSa5F3 RSa5F5 RSa5F7 RSa5F9 RSa5F11 RSa5F13 RSa5F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa5 Bit of Frame 15(RSa5F15).

Bit 1/Sa5 Bit of Frame 13(RSa5F13).

Bit 2/Sa5 Bit of Frame 11(RSa5F11).

Bit 3/Sa5 Bit of Frame 9(RSa5F9).

Bit 4/Sa5 Bit of Frame 7(RSa5F7).

Bit 5/Sa5 Bit of Frame 5(RSa5F5).

Bit 6/Sa5 Bit of Frame 3(RSa5F3).

Bit 7/Sa5 Bit of Frame 1(RSa5F1).

X X X X X X X X

RSa5 Receive Sa5 Bits 5Ch

Bit # 7 6 5 4 3 2 1 0 Name RSa6F1 RSa6F3 RSa6F5 RSa6F7 RSa6F9 RSa6F11 RSa6F13 RSa6F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa6 Bit of Frame 15(RSa6F15).

Bit 1/Sa6 Bit of Frame 13(RSa6F13).

Bit 2/Sa6 Bit of Frame 11(RSa6F11).

Bit 3/Sa6 Bit of Frame 9(RSa6F9).

Bit 4/Sa6 Bit of Frame 7(RSa6F7).

Bit 5/Sa6 Bit of Frame 5(RSa6F5).

Bit 6/Sa6 Bit of Frame 3(RSa6F3).

Bit 7/Sa6 Bit of Frame 1(RSa6F1).

X X X X X X X X

RSa6 Receive Sa6 Bits 5Dh

67 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name RSa7F1 RSa7F3 RSa7F5 RSa7F7 RSa7F9 RSa7F11 RSa7F13 RSa7F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa7 Bit of Frame 15(RSa7F15).

Bit 1/Sa7 Bit of Frame 13(RSa7F13).

Bit 2/Sa7 Bit of Frame 11(RSa7F11).

Bit 3/Sa7 Bit of Frame 9(RSa7F9).

Bit 4/Sa7 Bit of Frame 7(RSa7F7).

Bit 5/Sa7 Bit of Frame 5(RSa7F5).

Bit 6/Sa7 Bit of Frame 3(RSa7F3).

Bit 7/Sa7 Bit of Frame 1(RSa4F1).

X X X X X X X X

RSa7 Receive Sa7 Bits 5Eh

Bit # 7 6 5 4 3 2 1 0 Name RSa8F1 RSa8F3 RSa8F5 RSa8F7 RSa8F9 RSa8F11 RSa8F13 RSa8F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa8 Bit of Frame 15(RSa8F15).

Bit 1/Sa8 Bit of Frame 13(RSa8F13).

Bit 2/Sa8 Bit of Frame 11(RSa8F11).

Bit 3/Sa8 Bit of Frame 9(RSa8F9).

Bit 4/Sa8 Bit of Frame 7(RSa8F7).

Bit 5/Sa8 Bit of Frame 5(RSa8F5).

Bit 6/Sa8 Bit of Frame 3(RSa8F3).

Bit 7/Sa8 Bit of Frame 1(RSa8F1).

X X X X X X X X

RSa8 Receive Sa8 Bits 5Fh

68 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TsiF0 TsiF2 TsiF4 TsiF6 TsiF8 TsiF10 TsiF12 TsiF14 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Si Bit of Frame 14(TsiF14).

Bit 1/Si Bit of Frame 12(TsiF12).

Bit 2/Si Bit of Frame 10(TsiF10).

Bit 3/Si Bit of Frame 8(TsiF8).

Bit 4/Si Bit of Frame 6(TsiF6).

Bit 5/Si Bit of Frame 4(TsiF4).

Bit 6/Si Bit of Frame 2(TsiF2).

Bit 7/Si Bit of Frame 0(TsiF0).

Bit # 7 6 5 4 3 2 1 0 Name TsiF1 TsiF3 TsiF5 TsiF7 TsiF9 TsiF11 TsiF13 TSiF15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Si Bit of Frame 15(TSiF15).

Bit 1/Si Bit of Frame 13(TsiF13).

Bit 2/Si Bit of Frame 11(TsiF11).

Bit 3/Si Bit of Frame 9(TsiF9).

Bit 4/Si Bit of Frame 7(TsiF7).

Bit 5/Si Bit of Frame 5(TsiF5).

Bit 6/Si Bit of Frame 3(TsiF3).

0 0 0 0 0 0 0 0

TSiAF Transmit Si Bits of the Align Frame 42h

TSiNAF Transmit Si Bits of the Non-Align Frame 43h

Bit 7/Si Bit of Frame 1(TsiF1).

69 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TRAF1 TRAF3 TRAF5 TRAF7 TRAF9 TRAF11 TRAF13 TRAF15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Remote Alarm Bit of Frame 15(TRAF15).

Bit 1/Remote Alarm Bit of Frame 13(TRAF13).

Bit 2/Remote Alarm Bit of Frame 11(TRAF11).

Bit 3/Remote Alarm Bit of Frame 9(TRAF9).

Bit 4/Remote Alarm Bit of Frame 7(TRAF7).

Bit 5/Remote Alarm Bit of Frame 5(TRAF5).

Bit 6/Remote Alarm Bit of Frame 3(TRAF3).

Bit 7/Remote Alarm Bit of Frame 1(TRAF1).

0 0 0 0 0 0 0 0

TRA Transmit Remote Alarm 44h

Bit # 7 6 5 4 3 2 1 0 Name TSa4F1 TSa4F3 TSa4F5 TSa4F7 TSa4F9 TSa4F11 TSa4F13 TSa4F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa4 Bit of Frame 15(TSa4F15).

Bit 1/Sa4 Bit of Frame 13(TSa4F13).

Bit 2/Sa4 Bit of Frame 11(TSa4F11).

Bit 3/Sa4 Bit of Frame 9(TSa4F9).

Bit 4/Sa4 Bit of Frame 7(TSa4F7).

Bit 5/Sa4 Bit of Frame 5(TSa4F5).

Bit 6/Sa4 Bit of Frame 3(TSa4F3).

Bit 7/Sa4 Bit of Frame 1(TSa4F1).

0 0 0 0 0 0 0 0

TSa4 Transmit Sa4 Bits 45h

70 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TSa5F1 TSa5F3 TSa5F5 TSa5F7 TSa5F9 TSa5F11 TSa5F13 TSa5F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa5 Bit of Frame 15(TSa5F15).

Bit 1/Sa5 Bit of Frame 13(TSa5F13).

Bit 2/Sa5 Bit of Frame 11(TSa5F11).

Bit 3/Sa5 Bit of Frame 9(TSa5F9).

Bit 4/Sa5 Bit of Frame 7(TSa5F7).

Bit 5/Sa5 Bit of Frame 5(TSa5F5).

Bit 6/Sa5 Bit of Frame 3(TSa5F3).

Bit 7/Sa5 Bit of Frame 1(TSa5F1).

Bit # 7 6 5 4 3 2 1 0 Name TSa6F1 TSa6F3 TSa6F5 TSa6F7 TSa6F9 TSa6F11 TSa6F13 TSa6F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa6 Bit of Frame 15(TSa6F15).

Bit 1/Sa6 Bit of Frame 13(TSa6F13).

Bit 2/Sa6 Bit of Frame 11(TSa6F11).

Bit 3/Sa6 Bit of Frame 9(TSa6F9).

Bit 4/Sa6 Bit of Frame 7(TSa6F7).

Bit 5/Sa6 Bit of Frame 5(TSa6F5).

Bit 6/Sa6 Bit of Frame 3(TSa6F3).

Bit 7/Sa6 Bit of Frame 1(TSa6F1).

0 0 0 0 0 0 0 0

TSa5 Transmit Sa5 Bits 46h

TSa6 Transmit Sa6 Bits 47h

71 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name TSa7F1 TSa7F3 TSa7F5 TSa7F7 TSa7F9 TSa7F11 TSa7F13 TSa7F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa7 Bit of Frame 15(TSa7F15).

Bit 1/Sa7 Bit of Frame 13(TSa7F13).

Bit 2/Sa7 Bit of Frame 11(TSa7F11).

Bit 3/Sa7 Bit of Frame 9(TSa7F9).

Bit 4/Sa7 Bit of Frame 7(TSa7F7).

Bit 5/Sa7 Bit of Frame 5(TSa7F5).

Bit 6/Sa7 Bit of Frame 3(TSa7F3).

Bit 7/Sa7 Bit of Frame 1(TSa4F1).

Bit # 7 6 5 4 3 2 1 0 Name TSa8F1 TSa8F3 TSa8F5 TSa8F7 TSa8F9 TSa8F11 TSa8F13 TSa8F15 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Sa8 Bit of Frame 15(TSa8F15).

Bit 1/Sa8 Bit of Frame 13(TSa8F13).

Bit 2/Sa8 Bit of Frame 11(TSa8F11).

Bit 3/Sa8 Bit of Frame 9(TSa8F9).

Bit 4/Sa8 Bit of Frame 7(TSa8F7).

Bit 5/Sa8 Bit of Frame 5(TSa8F5).

Bit 6/Sa8 Bit of Frame 3(TSa8F3).

Bit 7/Sa8 Bit of Frame 1(TSa8F1).

0 0 0 0 0 0 0 0

TSa7 Transmit Sa7 Bits 48h

TSa8 Transmit Sa8 Bits 49h

72 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name SiAF SiNAF RA Sa4 Sa5 Sa6 Sa7 Sa8 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Additional Bit 8 Insertion Control Bit (Sa8).

Bit 1/Additional Bit 7 Insertion Control Bit (Sa7).

Bit 2/Additional Bit 6 Insertion Control Bit (Sa6).

Bit 3/Additional Bit 5 Insertion Control Bit (Sa5).

Bit 4/Additional Bit 4 Insertion Control Bit (Sa4).

Bit 5/Remote Alarm Insertion Control Bit (RA).

Bit 6/International Bit in Non-Align Frame Insertion Control Bit (SiNAF).

Bit 7/International Bit in Align Frame Insertion Control Bit (SiAF).

0 0 0 0 0 0 0 0

0 = do not insert data from the TSa8 register into the transmit data stream 1 = insert data from the TSa8 register into the transmit data stream

0 = do not insert data from the TSa7 register into the transmit data stream 1 = insert data from the TSa7 register into the transmit data stream

0 = do not insert data from the TSa6 register into the transmit data stream 1 = insert data from the TSa6 register into the transmit data stream

0 = do not insert data from the TSa5 register into the transmit data stream 1 = insert data from the TSa5 register into the transmit data stream

0 = do not insert data from the TSa4 register into the transmit data stream 1 = insert data from the TSa4 register into the transmit data stream

0 = do not insert data from the TRA register into the transmit data stream 1 = insert data from the TRA register into the transmit data stream

0 = do not insert data from the TSiNAF register into the transmit data stream 1 = insert data from the TSiNAF register into the transmit data stream

0 = do not insert data from the TSiAF register into the transmit data stream 1 = insert data from the TSiAF register into the transmit data stream

TSACR Transmit Sa Bit Control Register 4Ah

73 of 123

DS26503 T1/E1/J1 BITS Element

12.2 Alternate Sa/Si Bit Access Based on Double-Frame

On the receive side, the RAF and RNAF registers will always report the data as it received in the Sa and Si bit locations. The RAF and RNAF registers are updated on align frame boundaries. The setting of the receive align frame bit in status register 4 (SR4.0) will indicate that the contents of the RAF and RNAF have been updated. The host can use the SR4.0 bit to know when to read the RAF and RNAF registers. The host has 250ms to retrieve the data before it is lost.

On the transmit side, data is sampled from the TAF and TNAF registers with the setting of the transmit align frame bit in status register 4 (SR4.3). The host can use the SR4.3 bit to know when to update the TAF and TNAF registers. It has 250ms to update the data or else the old data will be retransmitted. If the

TAF an TNAF registers are only being used to source the align frame and non-align frame-sync patterns, then the host need only write once to these registers. Data for the Si bit can come from the Si

bits of the RAF and TNAF registers, the TSiAF and TSiNAF registers, or passed through from the TSER pin.

Bit # 7 6 5 4 3 2 1 0 Name Si FAS6 FAS5 FAS4 FAS3 FAS2 FAS1 FAS0 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Frame Alignment Signal Bit 0 (FAS0). In normal operation this bit will be = 1.

Bit 1/Frame Alignment Signal Bit 1 (FAS1). In normal operation this bit will be = 1.

Bit 2/Frame Alignment Signal Bit 2 (FAS2). In normal operation this bit will be = 0.

Bit 3/Frame Alignment Signal Bit 3 (FAS3). In normal operation this bit will be = 1.

Bit 4/Frame Alignment Signal Bit 4 (FAS4). In normal operation this bit will be = 1.

Bit 5/Frame Alignment Signal Bit 5 (FAS5). In normal operation this bit will be = 0.

Bit 6/Frame Alignment Signal Bit 6 (FAS6). In normal operation this bit will be = 0.

Bit 7/International Bit (Si).

X X X X X X X X

RAF Receive Align Frame Register 56h

74 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name Si 1 A Sa4 Sa5 Sa6 Sa7 Sa8 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Additional Bit 8 (Sa8).

Bit 1/Additional Bit 7 (Sa7).

Bit 2/Additional Bit 6 (Sa6).

Bit 3/Additional Bit 5 (Sa5).

Bit 4/Additional Bit 4 (Sa4).

Bit 5 / Remote Alarm (A).

Bit 6/Frame Nonalignment Signal Bit (1). In normal operation this bit will be = 1.

Bit 7/International Bit (Si).

X X X X X X X X

RNAF Receive Non-Align Frame Register 57h

Bit # 7 6 5 4 3 2 1 0 Name Si 0 0 1 1 0 1 1 Default 0 0 0 1 1 0 1 1 HW Mode

Bit 0/Frame Alignment Signal Bit (1).

Bit 1/Frame Alignment Signal Bit (1).

Bit 2/Frame Alignment Signal Bit (0).

Bit 3/Frame Alignment Signal Bit (1).

Bit 4/Frame Alignment Signal Bit (1).

Bit 5/Frame Alignment Signal Bit (0).

Bit 6/Frame Alignment Signal Bit (0).

Bit 7/International Bit (Si).

0 0 0 1 1 0 1 1

TAF Transmit Align Frame Register 40h

75 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name Si 1 A Sa4 Sa5 Sa6 Sa7 Sa8 Default 0 1 0 0 0 0 0 0

Bit 0/Additional Bit 8 (Sa8).

Bit 1/Additional Bit 7 (Sa7).

Bit 2/Additional Bit 6 (Sa6).

Bit 3/Additional Bit 5 (Sa5).

Bit 4/Additional Bit 4 (Sa4).

Bit 5/Remote Alarm (used to transmit the alarm A).

Bit 6/Frame Nonalignment Signal Bit (1).

Bit 7/International Bit (Si).

TNAF Transmit Non-Align Frame Register 41h

76 of 123

DS26503 T1/E1/J1 BITS Element

13. LINE INTERFACE UNIT (LIU)

The LIU in the DS26503 contains three sections: the receiver, which handles clock and data recovery; the transmitter, which waveshapes and drives the network line; and the jitter attenuator. These three sections are controlled by the line interface control registers (LIC1–LIC4), which are described below.

The DS26503 can switch between T1 or E1 networks without changing any external components on either the transmit or receive side. Figure 13-1 shows a network connection using minimal components. In this configuration the DS26503, using a fixed 120Ω external termination, can connect to T1, J1, E1, or 6312K without any component change. The receiver can adjust the 120Ω termination to 100Ω, 110Ω or 75Ω. The transmitter can adjust its output impedance to provide high return loss characteristics for 75Ω, 100Ω, 110Ω, and 120Ω lines. Other components may be added to this configuration to meet safety and network protection requirements. This is covered in the Recommended Circuits section.

Figure 13-1. Basic Network Connection

TRANSMIT LINE

10mF

2:1

TTIP

TRING

DS26503

BACKPLANE

CONNECTIONS

RECEIVE LINE

RTIP

RRING

1:1

60 60

0.01mF

77 of 123

DS26503 T1/E1/J1 BITS Element

13.1 LIU Operation

The analog AMI/HDB3 waveform off of the E1 line or the AMI/B8ZS waveform off of the T1 line is transformer-coupled into the RTIP and RRING pins of the DS26503. The user has the option to use internal termination, software selectable for 75Ω/100Ω/110Ω/120Ω applications, or external termination. The LIU recovers clock and data from the analog signal and passes it through the jitter attenuation mux. The DS26503 contains an active filter that reconstructs the analog received signal for the nonlinear losses that occur in transmission. The receive circuitry also is configurable for various monitor applications. The device has a usable receive sensitivity of 0dB to -43dB for E1 and 0dB to -36dB for T1, which allows the device to operate on 0.63mm (22AWG) cables up to 2.5km (E1) and 6000 feet (T1) in length. Data from the framer portion of the part is sent via the jitter attenuation MUX to the wave shaping circuitry and line driver. The DS26503 will drive the E1 or T1 line from the TTIP and TRING pins via a coupling transformer. The line driver can handle both CEPT 30/ISDN-PRI lines for E1 and long-haul (CSU) or short-haul (DSX-1) lines for T1.

13.2 LIU Receiver

The DS26503 contains a digital clock recovery system. The DS26503 couples to the receive line via a 1:1 transformer. The DS26503 has the option of using software-selectable termination requiring only a single, fixed pair of termination resistors.

The DS26503’s LIU is designed to be fully software selectable for E1 and T1 without the need to change any external resistors for the receive-side. The receiver will allow the user to configure the DS26503 for 75Ω, 100Ω, 110Ω, or 120Ω receive termination by setting the RT0(LIC4.0), RT1(LIC4.1), and RT2(LIC4.2). When using the internal termination feature, the resistors labeled R in Figure 13-4 should be 60Ω each. If external termination is required, RT0, RT1, and RT2 should be set to zero and the resistors labeled R in Figure 13-4 will need to be 37.5Ω, 50Ω, 55Ω, or 60Ω each, depending on the line impedance.

There are two ranges of receive sensitivity for both T1 and E1, which is selectable by the user. The EGL bit of LIC1 (LIC1.4) selects the full or limited sensitivity.

The resultant E1 or T1 clock derived from MCLK is multiplied by 16 via an internal PLL and fed to the clock recovery system. The clock recovery system uses the clock from the PLL circuit to form a 16 times over-sampler, which is used to recover the clock and data. This over-sampling technique offers outstanding performance to meet jitter tolerance specifications shown in Figure 13-6 and Figure 13-7.

Normally, the clock that is output at the RCLK pin is the recovered clock from the waveform presented at the RTIP and RRING inputs. If the jitter attenuator is placed in the receive path (as is the case in most applications), the jitter attenuator restores the RCLK to an approximate 50% duty cycle. If the jitter attenuator is either placed in the transmit path or is disabled, the RCLK output can exhibit slightly shorter high cycles of the clock. This is due to the highly over-sampled digital clock recovery circuitry. See the Receive AC Timing Characteristics section for more details. When no signal is present at RTIP and RRING, a receive loss of signal (RLOS) condition will occur and the RCLK will be derived from the JACLK source.

13.2.1 Receive Level Indicator

The DS26503 will report the signal strength at RTIP and RRING in 2.5dB increments via RL3-RL0 located in the Information Register 1 (INFO1). This feature is helpful when trouble shooting line performance problems.

78 of 123

DS26503 T1/E1/J1 BITS Element

13.2.2 Receive G.703 Section 10 Synchronization Signal

The DS26503 can receive a 2.048MHz square-wave synchronization clock as specified in Section 10 of ITU G.703. To use the DS26503 in this mode, set the mode configuration bits in the Mode Configuration Register (MCREG).

13.2.3 Monitor Mode

Monitor applications in both E1 and T1 require various flat gain settings for the receive-side circuitry. The DS26503 can be programmed to support these applications via the monitor mode control bits MM1 and MM0 in the LIC3 register.

Figure 13-2. Typical Monitor Application

T1/E1 LINE

PRIMARY T1/E1 TERMINATING DEVICE

Rm Rm

MONITOR PORT JACK

F M R

SECONDARY T1/E1 TERMINATING DEVICE

DS26503

13.3 LIU Transmitter

The DS26503 uses a phase-lock loop along with a precision digital-to-analog converter (DAC) to create the waveforms that are transmitted onto the E1 or T1 line. The waveforms created by the DS26503 meet the latest ETSI, ITU, ANSI, and AT&T specifications. The waveform that is to be generated is set by the transmit mode bits (TMODE[3:0]) in the MCREG register, as well as the L2/L1/L0 bits in register LIC1 if applicable.

ITU specification G.703 requires an accuracy of ±50ppm for both T1 and E1. TR62411 and ANSI specs require an accuracy of ±32ppm for T1 interfaces. The transmit clock can be sourced from the recovered clock (RCLK), the pre-scaled MCLK, the TCLK pin or the TX PLL. See the TX PLL clock mux diagram in Figure 3-3

0.005 UI source. Also, the waveforms created are independent of the duty cycle of TCLK. The transmitter in the DS26503 couples to the transmit twisted pair (or coaxial cable in some applications) via a 1:2 step-up transformer. For the device to create the proper waveforms, the transformer used must meet the specifications listed in Table 13-1 termination.

. Due to the nature of the design of the transmitter in the DS26503, very little jitter (less than

broadband from 10Hz to 100kHz) is added to the jitter present on the selected transmit clock

P-P

. The DS26503 has the option of using software-selectable transmit

79 of 123

DS26503 T1/E1/J1 BITS Element

The transmit line drive has two modes of operation: fixed gain or automatic gain. In the fixed gain mode, the transmitter outputs a fixed current into the network load to achieve a nominal pulse amplitude. In the automatic gain mode, the transmitter adjusts its output level to compensate for slight variances in the network load. See the Transmit Line Build-Out Control (TLBC) register for details.

13.3.1 Transmit Short-Circuit Detector/Limiter

The DS26503 has an automatic short-circuit limiter that limits the source current to 50mA (rms) into a 1W load. This feature can be disabled by setting the SCLD bit (LIC2.1) = 1. TCLE (SR1.2) provides a real-time indication of when the current limiter is activated. If the current limiter is disabled, TCLE will indicate that a short-circuit condition exist. Status Register SR1.2 provides a latched version of the information, which can be used to activate an interrupt when enable via the IMR1 register. When set low, the TPD bit (LIC1.0) will power-down the transmit line driver and tri-state the TTIP and TRING pins.

13.3.2 Transmit Open-Circuit Detector

The DS26503 can also detect when the TTIP or TRING outputs are open circuited. TOCD (SR1.1) will provide a real-time indication of when an open circuit is detected. SR1 provides a latched version of the information (SR1.1), which can be used to activate an interrupt when enable via the IMR1 register.

13.3.3 Transmit BPV Error Insertion

When IBPV (LIC2.5) is transitioned from a zero to a one, the device waits for the next occurrence of three consecutive ones to insert a BPV. IBPV must be cleared and set again for another BPV error insertion.

13.3.4 Transmit G.703 Section 10 Synchronization Signal (E1 Mode)

The DS26503 can transmit the 2.048MHz square-wave synchronization clock. To transmit the 2.048MHz clock, when in E1 mode, set the mode configuration bits in the Mode Configuration Register (MCREG).

13.4 MCLK Pre-Scaler

A 16.384MHz, 8.192MHz, 4.096MHz, 2.048MHz, or 1.544MHz clock must be applied at MCLK. ITU specification G.703 requires an accuracy of ±50ppm for both T1 and E1. TR62411 and ANSI specs require an accuracy of ±32ppm for T1 interfaces. A prescaler will divide the 16MHz, 8MHz, or 4MHz clock down to

2.048MHz. There is a PLL for the jitter attenuator that will convert the 2.048MHz clock to a 1.544MHz rate for T1 applications. Setting JACKS (LIC2.3) to a logic 0 bypasses this PLL.

13.5 Jitter Attenuator

The DS26503’s jitter attenuator can be set to a depth of either 32 bits or 128 bits via the JABDS bit (LIC1.2). The 128-bit mode is used in applications where large excursions of wander are expected. The 32-bit mode is used in delay-sensitive applications. The characteristics of the attenuation are shown in

Figure 13-10

transmit path by appropriately setting or clearing the JAS bit (LIC1.3). If the part is configured for hardware mode and the jitter attenuator is enabled, it will automatically be placed in the receive path. The jitter attenuator can also be disabled (in effect, removed) by setting the DJA bit (LIC1.1). Either the recovered clock from the clock/data recovery block or the clock applied at the TCLK pin is adjusted to create a smooth jitter-free clock that is used to clock data out of the jitter attenuator FIFO. It is acceptable to provide a gapped/bursty clock at the TCLK pin if the jitter attenuator is placed on the transmit side. If the incoming jitter exceeds either 120 UI then the DS26503 will divide the internal nominal 32.768MHz (E1) or 24.704MHz (T1) clock by either

and Figure 13-11. The jitter attenuator can be placed in either the receive path or the

(buffer depth is 128 bits) or 28 UI

P-P

(buffer depth is 32 bits),

P-P

80 of 123

DS26503 T1/E1/J1 BITS Element

15 or 17 instead of the normal 16 to keep the buffer from overflowing. When the device divides by either 15 or 17, it also sets the Jitter Attenuator Limit Trip (JALT) bit in Status Register 1 (SR1.4).

13.6 CMI (Code Mark Inversion) Option

The DS26503 provides a CMI interface for connection to optical transports. This interface is a unipolar 1T2B type of signal. Ones are encoded as either a logical one or zero level for the full duration of the clock period. Zeros are encoded as a zero-to-one transition at the middle of the clock period.

Figure 13-3. CMI Coding

Transmit and receive CMI is enabled via LIC4.7. When this register bit is set, the TTIP pin will output CMI-coded data at normal levels. This signal can be used to directly drive an optical interface. When CMI is enabled, the user can also use HDB3/B8ZS coding. When this register bit is set, the RTIP pin will become a unipolar CMI input. The CMI signal will be processed to extract and align the clock with data.

CLOCK

DATA

CMI

01 11001

81 of 123

DS26503 T1/E1/J1 BITS Element

13.7 LIU Control Registers

Bit # 7 6 5 4 3 2 1 0 Name L2 L1 L0 EGL JAS JABDS DJA TPD Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Transmit Power-Down (TPD).

Bit 1/Disable Jitter Attenuator (DJA).

Bit 2/Jitter Attenuator Buffer Depth Select (JABDS).

Bit 3/Jitter Attenuator Select (JAS).

Bit 4/Receive Equalizer Gain Limit (EGL). This bit controls the sensitivity of the receive equalizer.

Bits 5-7/Line Build-Out Select (L0 to L2). When using the internal termination, the user needs only to select 000 for 75Ω

operation or 001 for 120Ω operation. This selects the proper voltage levels for 75Ω or 120Ω operation. Using TT0 and TT1 of the LICR4 register, users can then select the proper internal source termination. Line build-outs 100 and 101 are for backwards compatibility with older products only.

E1 Mode

L2 L1 L0 APPLICATION N (1) RETURN LOSS Rt (1)

0 0 0 75Ω normal 1:2 N.M. 0 0 0 1 120Ω normal 1:2 N.M. 0 1 0 0 75Ω with high return loss* 1:2 21dB 6.2Ω 1 0 1 120Ω with high return loss* 1:2 21dB 11.6Ω

*TT0 and TT1 of LIC4 register must be set to zero in this configuration.

PIN 13

0 = powers down the transmitter and tri-states the TTIP and TRING pins 1 = normal transmitter operation

0 = jitter attenuator enabled 1 = jitter attenuator disabled

0 = 128 bits 1 = 32 bits (use for delay-sensitive applications)

0 = place the jitter attenuator on the receive side 1 = place the jitter attenuator on the transmit side

T1 Mode: 0 = -36dB (long haul)

1 = -15dB (limited long haul)

E1 Mode: 0 = -43dB (long haul)

1 = -12dB (short haul)

LIC1 Line Interface Control 1 30h

PIN 12

PIN 11

0 0 0 0 1

82 of 123

DS26503 T1/E1/J1 BITS Element

T1 Mode

L2 L1 L0 APPLICATION N (1) RETURN LOSS Rt (1)

Bit # 7 6 5 4 3 2 1 0 Name — AGCE GC5 GC4 GC3 GC2 GC1 GC0 Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0–5/Gain Control Bits 0–5 (GC0–GC5). The GC0 through GC5 bits control the gain setting for the non-automatic gain mode. Use the tables below for setting the recommended values. The LB (line build-out) column refers to the value in the L0–L2 bits in LIC1 (Line Interface Control 1) register.

NETWORK MODE LB GC5 GC4 GC3 GC2 GC1 GC0

T1, Impedance Match Off

T1, Impedance Match On

E1, Impedance Match Off

E1, Impedance Match On

Bit 6/Automatic Gain Control Enable (AGCE).

Bit 7/Unused, must be set = 0 for proper operation.

0 0 0 0 0 0 0 0

0 = use Transmit AGC, TLBC bits 0–5 are “don’t care” 1 = do not use Transmit AGC, TLBC bits 0–5 set nominal level

TLBC Transmit Line Build-Out Control 34h

0 1 0 0 1 1 0 1 0 1 1 0 1 1 2 0 1 1 0 1 0 3 1 0 0 0 0 0 4 1 0 0 1 1 1 5 1 0 0 1 1 1 6 0 1 0 0 1 1 7 1 1 1 1 1 1 0 0 1 1 1 1 0 1 0 1 0 1 0 1 2 0 1 0 1 0 1 3 0 1 1 0 1 0 4 1 0 0 0 1 0 5 1 0 0 0 0 0 6 0 0 1 1 0 0 7 1 1 1 1 1 1 0 1 0 0 0 0 1 1 1 0 0 0 0 1 4 1 0 1 0 1 0 5 1 0 1 0 0 0 0 0 1 1 0 1 0 1 0 1 1 0 1 0

83 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — LIRST IBPV TAIS JACKS — SCLD CLDS Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Custom Line Driver Select (CLDS). Setting this bit to a one will redefine the operation of the transmit line driver. When this bit is set to a one and LIC1.5 = LIC1.6 = LIC1.7 = 0, then the device will generate a square wave at the TTIP and TRING outputs instead of a normal waveform. When this bit is set to a one and LIC1.5 = LIC1.6 = LIC1.7 ¹ 0, then the device will force TTIP and TRING outputs to become open-drain drivers instead of their normal push-pull operation. This bit should be set to zero for normal operation of the device.

Bit 1/Short Circuit Limit Disable (in E1 mode) (SCLD). Controls the 50mA (rms) current limiter.

Bit 2/Unused, must be set = 0 for proper operation.

Bit 3/Jitter Attenuator Mux (JACKS). Controls the source for JA CLOCK. This bit is only used in T1 mode.

Bit 4/Transmit Alarm Indication Signal (TAIS).

Bit 5/Insert BPV (IBPV). A zero-to-one transition on this bit will cause a single BPV to be inserted into the transmit data

stream. Once this bit has been toggled from a zero to a one, the device waits for the next occurrence of three consecutive ones to insert the BPV. This bit must be cleared and set again for a subsequent error to be inserted.

Bit 6/Line Interface Reset (LIRST). Setting this bit from a zero to a one will initiate an internal reset that resets the clock recovery state machine and recenters the jitter attenuator. Normally this bit is only toggled on power-up. Must be cleared and set again for a subsequent reset.

Bit 7/Unused, must be set = 0 for proper operation.

0 0 0

0 = enable 50mA current limiter 1 = disable 50mA current limiter

0 = JA CLOCK sourced from the pre-scaled MCLK 1 = JA CLOCK sourced from internal PLL

0 = transmit an unframed all-ones code 1 = transmit data normally

LIC2 Line Interface Control 2 31h

TAIS

PIN 10

JACKS

PIN 46

0 0 0

84 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name CMIE CMII — MM1 MM0 — — TAOZ Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Transmit Alternate Ones and Zeros (TAOZ). Transmit a …101010… pattern at TTIP and TRING.

0 = disabled 1 = enabled

Bit 1/Unused, must be set = 0 for proper operation.

Bit 2/Unused, must be set = 0 for proper operation.

Bits 3-4/Monitor Mode (MM0 to MM1).

MM1 MM0 INTERNAL LINEAR GAIN BOOST (dB)

0 0 Normal operation (no boost) 0 1 20 1 0 26 1 1 32

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/CMI Invert (CMII).

0 = CMI normal at TTIP and RTIP 1 = invert CMI signal at TTIP and RTIP

Bit 7/CMI Enable (CMIE).

0 = disable CMI mode 1 = enable CMI mode

0 0 0 0 0 0 0 0

LIC3 Line Interface Control 3 32h

85 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name MPS1 MPS0 TT2 TT1 TT0 RT2 RT1 RT0 Default 0 0 0 0 0 0 0 0 HW Mode

Bits 0-2/Receive Termination Select (RT0 to RT1).

RT2 RT1 RT0

0 0 0 Internal Receive-Side Termination Disabled 0 0 1 Internal Receive-Side 75Ω Enabled 0 1 0 Internal Receive-Side 100Ω Enabled 0 1 1 Internal Receive-Side 120Ω Enabled 1 0 0 Internal Receive-Side 110Ω Enabled

MPS1

PIN 16

1 0 1

1 1 0 Internal Receive-Side Termination Disabled 1 1 1 Internal Receive-Side Termination Disabled

Bits 3-5/Transmit Termination Select (TT0 to TT1).

TT2 TT1 TT0

0 0 0 Internal Transmit-Side Termination Disabled 0 0 1 Internal Transmit-Side 75Ω Enabled 0 1 0 Internal Transmit-Side 100Ω Enabled 0 1 1 Internal Transmit-Side 120Ω Enabled 1 0 0 Internal Transmit-Side 110Ω Enabled 1 0 1 Internal Transmit-Side Termination Disabled 1 1 0 Internal Transmit-Side Termination Disabled 1 1 1 Internal Transmit-Side Termination Disabled

Bits 6-7/MCLK Prescaler (MPS0 to MPS1). T1 Mode

MCLK (MHz) MPS1 MPS0 JACKS (LIC2.3)

1.544 0 0 0

3.088 0 1 0

6.176 1 0 0

12.352 1 1 0

2.048 0 0 1

4.096 0 1 1

8.192 1 0 1

16.384 1 1 1

Bits 6-7/MCLK Prescaler (MPS0 to MPS1). E1 Mode

MCLK (MHz) MPS1 MPS0 JACKS (LIC2.3)

2.048 0 0 0

4.096 0 1 0

8.192 1 0 0

16.384 1 1 0

LIC4 Line Interface Control 4 33h

MPS0

PIN 15

Internal Receive-Side Termination Disabled

— — — — — —

INTERNAL RECEIVE

TERMINATION CONFIGURATION

INTERNAL TRANSMIT

TERMINATION CONFIGURATION

86 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — — — — RL3 RL2 RL1 RL0 Default 0 0 0 0 0 0 0 0 HW Mode

Bits 0-3/Receive Level Bits (RL0 to RL3). Real-time bits

RL3 RL2 RL1 RL0 RECEIVE LEVEL (dB)

0 0 0 0 Greater than -2.5 0 0 0 1 -2.5 to -5.0 0 0 1 0 -5.0 to -7.5 0 0 1 1 -7.5 to -10.0 0 1 0 0 -10.0 to -12.5 0 1 0 1 -12.5 to -15.0 0 1 1 0 -15.0 to -17.5 0 1 1 1 -17.5 to -20.0 1 0 0 0 -20.0 to -22.5 1 0 0 1 -22.5 to -25.0 1 0 1 0 -25.0 to -27.5 1 0 1 1 -27.5 to -30.0 1 1 0 0 -30.0 to –32.5 1 1 0 1 -32.5 to -35.0 1 1 1 0 -35.0 to -37.5 1 1 1 1 Less than -37.5

Bit 4/Unused.

Bit 5/Unused.

Bit 6/Unused.

Bit 7/Unused.

X X X X X X X X

INFO1 Information Register 1 11h

87 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — — — JALT — TCLE TOCD — Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Unused, must be set = 0 for proper operation.

Bit 1/Transmit Open Circuit Detect Condition (TOCD). Set when the device detects that the TTIP and TRING outputs are

open-circuited.

Bit 2/Transmit Current Limit Exceeded Condition (TCLE). Set when the 50mA (rms) current limiter is activated whether the current limiter is enabled or not.

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/Jitter Attenuator Limit Trip Event (JALT). Set when the jitter attenuator FIFO reaches to within 4 bits of its useful limit. Will be cleared when read. Useful for debugging jitter-attenuation operation.

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/Unused, must be set = 0 for proper operation.

X X X X X X X X

SR1 Status Register 1 14h

88 of 123

DS26503 T1/E1/J1 BITS Element

Bit # 7 6 5 4 3 2 1 0 Name — — — JALT — TCLE TOCD — Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/ Unused, must be set = 0 for proper operation.

Bit 1/Transmit Open Circuit Detect Condition (TOCD).

Bit 2/Transmit Current Limit Exceeded Condition (TCLE).

Bit 3/Unused, must be set = 0 for proper operation.

Bit 4/Jitter Attenuator Limit Trip Event (JALT).

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/Unused, must be set = 0 for proper operation.

X X X X X X X X

0 = interrupt masked 1 = interrupt enabled–generates interrupts on rising and falling edges

0 = interrupt masked 1 = interrupt enabled

IMR1 Interrupt Mask Register 1 15h

89 of 123

13.8 Recommended Circuits

Figure 13-4. Basic Interface

TRANSMIT LINE

RECEIVE LINE

2:1

1:1

R R

NOTES:

1) All resistor values are ±1%.

2) Resistors R should be set to 60W each if the internal receive-side termination feature is enabled. When this feature is disabled, R = 37.5W for 75W coaxial E1 lines; 60W for 120W twisted pair E1 lines; or 50W for 100W twisted pair T1 lines.

3) C = 10mF ceramic.

0.1mF

DS26503

TTIP

TRING

RTIP

RRING

DS26503 T1/E1/J1 BITS Element

0.1mF

DVDD

DVSS

0.1mF

TVDD

0.01mF

10mF

TVSS

0.1mF

RVDD

10mF

RVSS

90 of 123

DS26503 T1/E1/J1 BITS Element

Figure 13-5. Protected Interface Using Internal Receive Termination

TRANSMIT LINE

RECEIVE LINE

2:1

NOTES:

1) All resistor values are ±1%.

2) X1 and X2 are very low DCR transformers

3) C1 = 10mF ceramic.

4) S1 and S2 are 6V transient suppressers.

5) D1 to D8 are Schottky diodes.

6) The fuses, F1–F4, are optional to prevent AC power-line crosses from compromising the

7) The 68mF is used to keep the local power-plane potential within tolerance during a surge.

1:1

transformers.

0.1mF

60 60

0.1mF

D1 D2

D5 D6

DS26503

TTIP

TRING

RTIP

RRING

0.1mF

DVDD

DVSS

0.1mF

TVDD

TVSS

0.1mF

RVDD

RVSS

0.01mF

10mF

68mF

91 of 123

DS26503 T1/E1/J1 BITS Element

13.9 Component Specifications

Table 13-1. Transformer Specifications

SPECIFICATION RECOMMENDED VALUE

Turns Ratio 3.3V Applications 1:1 (receive) and 1:2 (transmit) ±2% Primary Inductance Leakage Inductance Intertwining Capacitance 40pF maximum Transmit Transformer DC Resistance

Primary (Device Side) Secondary

Receive Transformer DC Resistance

Primary (Device Side) Secondary

600mH minimum

1.0mH maximum

1.0Ω maximum

2.0Ω maximum

1.2Ω maximum

92 of 123

Figure 13-6. E1 Transmit Pulse Template

1.2

1.1

1.0

0.9

0.8

0.7

0.6

0.5

0.4

0.3

SCALED AMPLITUDE

0.2

0.1

(in 75 ohm systems, 1.0 on the scale = 2.37Vpeak

in 120 ohm systems, 1.0 on the scale = 3.00Vpeak)

-0.1

-0.2

194ns

219ns

TIME (ns)

DS26503 T1/E1/J1 BITS Element

269ns

G.703

Template

50 100 150 200 25 0-50-100-150-2 00-250

Figure 13-7. T1 Transmit Pulse Template

1.2

1.1

1.0

0.9

0.8

0.7

0.6

0.5

0.4

0.3

0.2

0.1

NORMALIZED AMPLITUDE

-0.1

-0.2

-0.3

-0.4

-0.5

-500 -300 -100 0 300 500 700

T1.102/87, T1.4 03, CB 119 (Oct. 7 9), & I.431 Template

-400 -200 200 400 600100

TIME (ns)

MAXIMUM CURVE

UI Time Amp.

-0.77

-500

-255

-175

-75 0 175 225 600 750

0.05

0.80

1.15

1.05

-0.07

0.05

-0.39

-0.27

-0.12

0.00

0.27

0.35

0.93

1.16

MINIMUM CURVE

UI Time Amp.

-0.77

-500

-0.23

-150

-0.23

-150

-0.15

-100

0.00

0.15

100

0.23

150

0.23

150

0.46

300

0.66

430

0.93

600

1.16

750

-0.05

0.50

0.95

0.90

0.50

-0.45

-0.20

-0.05

93 of 123

Figure 13-8. Jitter Tolerance (T1 Mode)

100

TR 62411 (Dec. 90)

ITU-T G.823

UNIT INTERVALS (UIpp)

0.1 1

10 100 1K 10K 100K

Tolerance

FREQUENCY (Hz)

DS26503 T1/E1/J1 BITS Element

DS26503

Figure 13-9. Jitter Tolerance (E1 Mode)

100

UNIT INTERVALS (UIpp)

0.1

1.5

Minimum Tolerance

Level as per

ITU G.823

10 100 1k 10k 100k

FREQUENCY (Hz)

DS26503 Tolerance

2.4k

18k

0.2

94 of 123

Figure 13-10. Jitter Attenuation (T1 Mode)

-20

-40

JITTER ATTENUATION (dB)

-60

1 10 100 1K 10K

DS26503

T1 MODE

FREQUENCY (Hz)

DS26503 T1/E1/J1 BITS Element

TR 62411 (Dec. 90)

Prohibited Area

100K

Figure 13-11. Jitter Attenuation (E1 Mode)

TBR12

Prohibited

rea

-20

-40

JITTER ATTENUATION (dB)

-60

10 100 1K 10K 100K

DS26503

E1 MODE

FREQUENCY (Hz)

ITU G.7XX

Prohibited Area

95 of 123

DS26503 T1/E1/J1 BITS Element

14. LOOPBACK CONFIGURATION

Bit # 7 6 5 4 3 2 1 0 Name — — — — LLB RLB — — Default 0 0 0 0 0 0 0 0 HW Mode

Bit 0/Unused, must be set = 0 for proper operation.

Bit 1/Unused, must be set = 0 for proper operation.

Bit 2/ Remote Loopback (RLB). In this loopback, data received at RTIP and RRING will be looped back to the transmit LIU.

Received data will continue to pass through the receive side framer of the DS26503 as it would normally and the data from the transmit side formatter will be ignored.

1 = loopback enabled

Bit 3/Local Loopback (LLB). In this loopback, data will continue to be transmitted as normal through the transmit side of the DS26503. Data being received at RTIP and RRING will be replaced with the data being transmitted. Data in this loopback will pass through the jitter attenuator if enabled.

Bit 4/Unused, must be set = 0 for proper operation.

Bit 5/Unused, must be set = 0 for proper operation.

Bit 6/Unused, must be set = 0 for proper operation.

Bit 7/Unused, must be set = 0 for proper operation.

0 0 0 0 0

0 = loopback disabled

0 = loopback disabled 1 = loopback enabled

LBCR Loopback Control Register 20h

RLB

PIN 60

0 0

96 of 123

DS26503 T1/E1/J1 BITS Element

15. 6312kHz SYNCHRONIZATION INTERFACE

The DS26503 has a 6312kHz Synchronization Interface mode of operation that conforms with Appendix II.2 of G.703, with the exception that the DS26503 transmits a square wave as opposed to the sine wave that is defined in the G.703 specification.

15.1 Receive 6312kHz Synchronization Interface Operation

On the receive interface, a 6312kHz sine wave is accepted conforming to the input port requirements of G.703 Appendix II. Alternatively, a 6312kHz square wave will also be accepted. A 6312kHz square wave is output on RCLK in the receive direction. RS is not driven in this mode and will be tri-stated.

Table 15-1. Specification of 6312kHz Clock Signal at Input Port

Frequency 6312kHz

Signal format Sinusoidal wave

Alarm condition

Alarm should not be occurred against the amplitude ranged

-16dBm to +3dBm

15.2 Transmit 6312kHz Synchronization Interface Operation

On the transmit interface, a nominally 50% duty cycle, 6312kHz square wave at standard logic levels is available from the PLL_OUT pin. In normal operation, the TCLKO pin will output the same signal. However, if remote loopback is enabled then TCLKO will be replaced with the recovered receive clock. See Figure 3-1. The G.703 requirements for the 6312kHz transmitted signal are shown in Table 15-2. The user must provide an external circuit to convert the TCLKO or PLL_OUT signal to the level and impedance required by G.703. The RSER and TS pins are ignored in this mode. TTIP and TRING will be tri-stated in this mode.

Table 15-2. Specification of 6312kHz Clock Signal at Output Port

Frequency 6312kHz

Load impedance

75W resistive

Transmission media Coaxial pair cable

Amplitude

0dBm ± 3dBm

97 of 123

DS26503 T1/E1/J1 BITS Element

16. JTAG BOUNDARY SCAN ARCHITECTURE AND TEST ACCESS PORT

The DS26503 supports the standard IEEE 1149.1 instruction codes SAMPLE/PRELOAD, BYPASS, and EXTEST. Optional public instructions included are HIGHZ, CLAMP, and IDCODE. The DS26503 contains the following as required by IEEE 1149.1 Standard Test Access Port and Boundary Scan Architecture:

§ Test Access Port (TAP)

§ TAP Controller

§ Instruction Register

§ Bypass Register

§ Boundary Scan Register

§ Device Identification Register

Details on Boundary Scan Architecture and the Test Access Port can be found in IEEE 1149.1-1990, IEEE 1149.1a-1993, and IEEE 1149.1b-1994.

The Test Access Port has the necessary interface pins: JTRST, JTCLK, JTMS, JTDI, and JTDO. See the pin descriptions for details.

Figure 16-1. JTAG Functional Block Diagram

BOUNDRY SCAN

IDENTIFICATION

BYPASS

INSTRUCTION

TEST ACCESS PORT

CONTROLLER

VDD VDD VDD

10kW 10kW 10kW

JTDI JTMS JTCLK

TRST

MUX

SELECT

OUTPUT ENABLE

JTDO

98 of 123

DS26503 T1/E1/J1 BITS Element

TAP Controller State Machine

The TAP controller is a finite state machine that responds to the logic level at JTMS on the rising edge of JTCLK. See Figure 16-2.

Test-Logic-Reset

Upon power-up, the TAP controller will be in the test-logic-reset state. The instruction register will contain the IDCODE instruction. All system logic of the device will operate normally.

Run-Test-Idle

The run-test-idle is used between scan operations or during specific tests. The instruction register and test registers will remain idle.

Select-DR-Scan

All test registers retain their previous state. With JTMS LOW, a rising edge of JTCLK moves the controller into the capture-DR state and will initiate a scan sequence. JTMS HIGH during a rising edge on JTCLK moves the controller to the select-IR-scan state.

Capture-DR

Data can be parallel-loaded into the test-data registers selected by the current instruction. If the instruction does not call for a parallel load or the selected register does not allow parallel loads, the test register will remain at its current value. On the rising edge of JTCLK, the controller will go to the shiftDR state if JTMS is LOW or it will go to the exit1-DR state if JTMS is HIGH.

Shift-DR

The test-data register selected by the current instruction will be connected between JTDI and JTDO and will shift data one stage toward its serial output on each rising edge of JTCLK. If a test register selected by the current instruction is not placed in the serial path, it will maintain its previous state.

Exit1-DR

While in this state, a rising edge on JTCLK will put the controller in the update-DR state, which terminates the scanning process, if JTMS is HIGH. A rising edge on JTCLK with JTMS LOW will put the controller in the pause-DR state.

Pause-DR

Shifting of the test registers is halted while in this state. All test registers selected by the current instruction will retain their previous state. The controller will remain in this state while JTMS is LOW. A rising edge on JTCLK with JTMS HIGH will put the controller in the exit2-DR state.

Exit2-DR

A rising edge on JTCLK with JTMS HIGH while in this state will put the controller in the update-DR state and terminate the scanning process. A rising edge on JTCLK with JTMS LOW will enter the shiftDR state.

Update-DR

A falling edge on JTCLK while in the update-DR state will latch the data from the shift register path of the test registers into the data output latches. This prevents changes at the parallel output due to changes in the shift register.

99 of 123

DS26503 T1/E1/J1 BITS Element

Select-IR-Scan

All test registers retain their previous state. The instruction register will remain unchanged during this state. With JTMS LOW, a rising edge on JTCLK moves the controller into the capture-IR state and will initiate a scan sequence for the instruction register. JTMS HIGH during a rising edge on JTCLK puts the controller back into the test-logic-reset state.

Capture-IR

The capture-IR state is used to load the shift register in the instruction register with a fixed value. This value is loaded on the rising edge of JTCLK. If JTMS is HIGH on the rising edge of JTCLK, the controller will enter the exit1-IR state. If JTMS is LOW on the rising edge of JTCLK, the controller will enter the shift-IR state.

Shift-IR

In this state, the shift register in the instruction register is connected between JTDI and JTDO and shifts data one stage for every rising edge of JTCLK toward the serial output. The parallel register as well as all test registers remain at their previous states. A rising edge on JTCLK with JTMS HIGH will move the controller to the exit1-IR state. A rising edge on JTCLK with JTMS LOW will keep the controller in the shift-IR state while moving data one stage thorough the instruction shift register.

Exit1-IR

A rising edge on JTCLK with JTMS LOW will put the controller in the pause-IR state. If JTMS is HIGH on the rising edge of JTCLK, the controller will enter the update-IR state and terminate the scanning process.

Pause-IR

Shifting of the instruction shift register is halted temporarily. With JTMS HIGH, a rising edge on JTCLK will put the controller in the exit2-IR state. The controller will remain in the pause-IR state if JTMS is LOW during a rising edge on JTCLK.

Exit2-IR

A rising edge on JTCLK with JTMS LOW will put the controller in the update-IR state. The controller will loop back to shift-IR if JTMS is HIGH during a rising edge of JTCLK in this state.

Update-IR

The instruction code shifted into the instruction shift register is latched into the parallel output on the falling edge of JTCLK as the controller enters this state. Once latched, this instruction becomes the current instruction. A rising edge on JTCLK with JTMS LOW, will put the controller in the run-test-idle state. With JTMS HIGH, the controller will enter the select-DR-scan state.

100 of 123

Rainbow Electronics DS26503 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Interrupt/JA Clock Source Select 1

Data Bus D[7] or Address/Data Bus AD[7]/Transmit Termination Select

Data Bus D[6] or Address/Data Bus AD[6]/Transmit Termination Select

Data Bus D[3] or Address/Data Bus AD[3]/TS Mode Select

Data Bus D[1] or Address/Data Bus AD[1]/Receive Mode Select 3/Master Out-Slave In

Data Bus D[0] or Address/Data Bus AD[0]/Transmit Clock Source Select 0/Master In-Slave Out

Address Bus Bit A[6]/MCLK Prescale Select

Address Bus Bit A[3]/Line Build-Out Select 1

Address Bus Bit A[2]/Line Build-Out Select 0

Address Bus Bit A[1]/Transmit AIS

Address Bus Bit A[0]/E1 Termination Select

Bus Type Select/Transmit and Receive B8ZS/HDB3 Enable

Read Input-Data Strobe/Receive Mode Select Bit 2

Chip Select/Remote Loopback Enable

Write Input (Read/Write)/Transmit Mode Select 3

TRANSMIT CLOCK SOURCE
