DS1822-PAR

Econo 1-Wire® Parasite-Powe

Digital Thermomete

FEATURES

• Unique 1-wire interface requires only one

port pin for communication

• Derives power from data line (“parasite

power”)—does not need a local power supply

• Multi-drop capability simplifies distributed

temperature sensing applications

• Requires no external components

• ±2.0°C accuracy from –10°C to +85°C

• Measures temperatures from –55°C to

+100°C (–67°F to +212°F)

• Thermometer resolution is user-selectable

from 9 to 12 bits

• Converts temperature to 12-bit digital word in

750 ms (max.)

• User–definable temperature alarm settings

• Alarm search command identifies and

addresses devices whose temperature is
outside of programmed limits (temperature
alarm condition)

• Software compatible with the DS18B20-PAR

• Ideal for use in remote sensing applications

(e.g., temperature probes) that do not have a
local power source

PIN ASSIGNMENT

DALLAS
1822P

2 3

1

DQ

GND

1

2 3

BOTTOM VIEW)

TO-92

DS1822-PAR

PIN DESCRIPTION

GND - Ground
DQ - Data In/Out
NC - No Connect

NC

DESCRIPTION

The DS1822-PAR digital thermometer provides 9 to 12–bit centigrade temperature measurements and has
an alarm function with nonvolatile user-programmable upper and lower trigger points. The DS1822-PAR
does not need an external power supply becaus e it derives power directly from the data line (“parasite
power”). The DS1822-PAR communicates over a 1-wire bus, which by definition requires only one data
line (and ground) for communication with a central microprocessor. It has an operating temperature
range of –55°C to +100°C and is accurate to ±2.0°C over a range of –10°C to +85°C.

Each DS1822-PAR has a unique 64-bit identification code, which allows multiple DS1822-PARs to
function on the same 1–wire bus; thus, it is simple to use one microprocessor to control many
DS1822-PARs distributed over a large area. Applications that can benefit from this feature include
HVAC environmental controls, temperature monitoring systems inside buildings, equipment or
machinery, and process monitoring and control systems.

1 of 19 043001

DETAILED PIN DESCRIPTIONS Table 1

PIN SYMBOL DESCRIPTION

DS1822-PAR

1 GND

Ground.

2 DQ Data Input/Output pin. Open-drain 1-wire interface pin. Also provides power

to the device when used in parasite power mode (see “Parasite Power” section.)

3 NC No Connect. Doesn’t connect to internal circuit.

OVERVIEW

The DS1822-PAR uses Dallas’ exclusive 1-wire bus protocol that implements bus communication using
one control signal. The control line requires a weak pullup resistor since all devices are linked to the bus
via a 3-state or open-drain port (the DQ pin in t he case of the DS1822-PAR). In this bus system, the
microprocessor (the master device) identifies and addresses devices on the bus using each device’s unique
64-bit code. Because each device has a unique code, the number of devices that can be addressed on one
bus is virtually unlimited. The 1-wire bus protocol, including detailed explanations of the commands and
“time slots,” is covered in the 1-WIRE BUS SYSTEM section of this datasheet.

An important feature of the DS1822-PAR is its ability to operate without an external power supply.
Power is instead supplied through the 1-wire pullup resistor via the DQ pin when the bus is high. The
high bus signal also charges an internal capacitor (CPP), which then supplies power to the device when the
bus is low. This method of deriving power from the 1-wire bus is referred to as “parasite power.”

Figure 1 shows a block diagram of the DS1822-PAR, and pin descriptions are given in Table 1. The
64-bit ROM stores the device’s unique serial code. The scratchpad memory contains the 2-byte
temperature register that stores the digital output from the temperature sensor. In addition, the s crat chpad
provides access to the 1-byte upper and lower alarm trigger registers (TH and TL). The TH and T

L

registers are nonvolatile (EEPROM), so they will retain their data when the device is powered down.

DS1822-PAR BLOCK DIAGRAM Figure 1

4.7K

VPU

DQ

GND

PARASITE POWER

CIRCUIT

INTERNAL VDD

CPP

64-BIT ROM

AND

1-wire PORT

MEMORY CONTROL

LOGIC

SCRATCHPAD

DS1822-PAR

TEMPERATURE SENSOR

ALARM HIGH TRIGGER (TH)

REGISTER (EEPROM)

ALARM LOW TRIGGER (TL)

REGISTER (EEPROM)

CONFIGURATION REGISTER

(EEPROM)

2 of 19

8-BIT CRC GENERATOR

DS1822-PAR

R

PARASITE POWER

The DS1822-PAR’s parasite power circuit allows the DS1822-PAR to operate without a local ex ternal
power supply. This ability is especially useful for applications that require remote temper ature s ensing or
that are very space constrained. Figure 1 shows the DS1822-PAR’s parasite-power control circuitry,
which “steals” power from the 1-wire bus via the DQ pin when the bus is high. The stolen charge powers
the DS1822-PAR while the bus is high, and some of the char ge is stored on the parasite power c apacitor
(CPP) to provide power when the bus is low.

The 1-wire bus and CPP can provide sufficient parasite power to the DS1822-PAR for most operations as
long as the specified timing and voltage requirements are met (refer to the DC ELECTRICAL
CHARACTERISTICS and the AC ELECTRICAL CHARACTERISTICS sections of this data sheet).
However, when the DS1822-PAR is performing temperature conversions or copying data from the
scratchpad memory to EEPROM, the operating current can be as high as 1.5 mA. This current can cause
an unacceptable voltage drop across the weak 1-wire pullup resistor and is more current than can be
supplied by C

. To assure that the DS1822-PAR has sufficient supply current, it is necessar y to provide

PP

a strong pullup on the 1-wire bus whenever temperature conversions are taking place or data is being
copied from the scratchpad to EEPROM. This can be accompl ished by using a MOSFET to pull the bus
directly to the rail as shown in Figure 2. The 1-wire bus must be switched to the strong pullup within 10
µs (max) after a Convert T [44h] or Copy Scratchpad [48h] command is issued, and the bus must be held
high by the pullup for the duration of the conversion (t

) or data transfer (t

conv

= 10 ms). No other

wr

activity can take place on the 1-wire bus while the pullup is enabled.

SUPPLYING THE DS1822-PAR DURING TEMPERATURE CONVERSIONS

Figure 2

Micro-

processor

VPU

4.7K

VPU

1-Wire Bus

DS1822-PA

GND

DQ

To Other
1-Wire Devices

OPERATION – MEASURIN G TEMPERATURE

The core functionality of the DS1822-PAR is its direct-to-digital temperature sensor. The resolution of
the temperature sensor is user-configurable to 9, 10, 11, or 12 bits, which corresponds to increments of

0.5°C, 0.25°C, 0.125°C, and 0.0625°C, respectively. The default resolution at power-up is 12-bit.
The DS1822-PAR powers-up in a low-power idle state; to initiate a temperature measurement and A-to-D

conversion, the master must issue a Convert T [44h] command. Following the conv ersion, the resulting
thermal data is stored in the 2-byte temperature register in the scratchpad memory and the DS1822-PAR
returns to its idle state. The DS1822-PAR output data is calibrated in degrees centigrade; for Fahrenheit
applications, a lookup table or conversion routine must be used. The temperature data is stored as a 16­bit sign-extended two’s complement number in the temperature register (see Figure 3). The sign bits (S)
indicate if the temperature is positive or negative: for positive numbers S = 0 and for negative numbers S
= 1. If the DS1822-PAR is configured for 12-bit resolution, all bits in the temperature register will
contain valid data. For 11-bit resolution, bit 0 is undefined. For 10-bit resolution, bits 1 and 0 are
undefined, and for 9-bit resolution bits 2, 1 and 0 are undefined. T able 2 gives ex amples of di gital output
data and the corresponding temperature reading for 12-bit resolution conversions.
3 of 19

TEMPERATURE REGISTER FORMAT Figure 3

LS Byte

MS Byte

bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0

23 2

bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8

2

2

1

2

0

2

S S S S S 26 2

TEMPERATURE/DATA RELATIONSHIP Table 2

-1

2

-2

2

DS1822-PAR

-3

2

5

2

-4

4

TEMPERATURE DIGITAL OUTPUT

(Binary)

DIGITAL OUTPUT

(Hex)

+85°C* 0000 0101 0101 0000 0550h

+25.0625°C 0000 0001 1001 0001 0191h

+10.125°C 0000 0000 1010 0010 00A2h

+0.5°C 0000 0000 0000 1000 0008h

0°C 0000 0000 0000 0000 0000h

-0.5°C 1111 1111 1111 1000 FFF8h

-10.125°C 1111 1111 0101 1110 FF5Eh

-25.0625°C 1111 1110 0110 1111 FE6Fh

-55°C 1111 1100 1001 0000 FC90h

*The power-on reset value of the temperature register is +85°C

OPERATION – ALARM SIGNAL ING

After the DS1822-PAR performs a temperature conversion, the temperature value is compared to the
user-defined two’s complement alarm trigger values stored in the 1-byte TH and TL registers (see Figure

4). The sign bit (S) indicates if the value is positive or negative: for positive numbers S = 0 and for
negative numbers S = 1. The TH and TL registers are nonvolatile (EEPROM) so they will retain data
when the device is powered down. TH and TL can be accessed through b ytes 2 and 3 of the scratchp ad as
explained in the MEMORY section of this datasheet.

TH AND TL REGISTER FORMAT Figure 4

bit 7 b it 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0

S 26 2

5

2

Only bits 11 through 4 of the temperature register are used in the T
are 8-bit registers. If the result of a temperature measurement is higher than TH or lower than TL, an
alarm condition exists and an alarm flag is set inside the DS1822-PAR. This flag is updated after every
temperature measurement; therefore, if the alarm condition goes away, the flag will be turned off after the
next temperature conversion.

The master device can check the alarm flag status of all DS1822-PARs on the bus by issuing an Alarm
Search [ECh] command. Any DS1822-PARs with a set alarm flag will respond to the command, so the
master can determine exactly which DS1822-PARs have experienced an alarm condition. If an alarm
condition exists and the T

or TL settings have changed, another temperature conversion should be done

H

to validate the alarm condition.
4 of 19

5

2

5

2

2

2

and TL comparison since TH and T

H

1

2

0

L

DS1822-PAR

64-BIT LASERED ROM CODE

Each DS1822-PAR contains a unique 64–bit code (see Figure 5) stored in ROM. The least significant 8
bits of the ROM code contain the DS1822-PAR’s 1–wire family code: 22h. The next 48 bits contain a
unique serial number. The most significant 8 bits contain a cyclic redundancy check (CRC) byte that is
calculated from the first 56 bits of the ROM code. A detailed explanation of the CRC bits is provided in
the CRC GENERATION section. The 64–bit ROM code and associated ROM function control logic
allow the DS1822-PAR to operate as a 1–wire device using the protocol detailed in the 1-WIRE BUS
SYSTEM section of this datasheet.

64-BIT LASERED ROM CODE Figure 5

8-BIT CRC 48-BIT SERIAL NUMBER 8-BIT FAMILY CODE (22h)

MSB MSB LSB LSB LSBMSB

MEMORY

The DS1822-PAR’s memory is organized as shown in Figure 6. The memory consists of an SRAM
scratchpad with nonvolatile EEPROM storage for the high and low alarm trigger registers (TH and TL)
and configuration register. Note that if the DS1822-PAR alarm function is not used, the TH and TL
registers can serve as general-purpose memory. All memory commands are described in detail in the
DS1822-PAR FUNCTION COMMANDS section.

DS1822-PAR MEMORY MAP cбЦмкЙ=S

SCRATCHPAD (Power-up State)

byte 0 Temperature LSB (50h)

(85°C)

byte 1 Temperature MSB (05h)

EEPROM

byte 2 TH Register or User Byte 1* TH Register or User Byte 1
byte 3 TL Register or User Byte 2* TL Register or User Byte 2
byte 4 Configuration Register* Configuration Register
byte 5 Reserved (FFh)
byte 6 Reserved (0Ch)
byte 7 Reserved (10h)
byte 8 CRC*

*Power-up state depends on value(s) stored

in EEPROM

Byte 0 and byte 1 of the scratchpad contain the LSB and the MSB of the temperature register,
respectively. These bytes are read-onl y. Bytes 2 and 3 provide access to T

and TL registers. Byte 4

H

contains the configuration register data, which is explained in detail in the CONFIGURATION
REGISTER section of this datasheet. Bytes 5, 6 and 7 ar e reserved for internal use by the device and
cannot be overwritten; these bytes will return all 1s when read.

Byte 8 of the scratchpad is read-only and contains the cyclic redundancy check (CRC) code for bytes 0
through 7 of the scratchpad. The DS1822-PAR generates this CRC using the method described in the
CRC GENERATION section.

5 of 19

DS1822-PAR

Data is written to bytes 2, 3, and 4 of the scratchpad using the W rite Scratchpad [4Eh] command, and the
data must be transmitted to the DS1822-PAR starting with the least significant bit of byte 2. To verify
data integrity, the scratchpad can be read (using the Read Scratchpad [BEh] command) after the data is
written. When reading the scratchpad, data is transferred over the 1-wire bus starting with the least
significant bit of byte 0. To transfer the TH, TL and configuration data from the scratchpad to E EPROM,
the master must issue the Copy Scratchpad [48h] command.

Data in the EEPROM registers is retained when the device is powered down; at power-up the EEPROM
data is reloaded into the corresponding scratchpad locations. Data can also be reloaded from EEPROM
to the scratchpad at any time using the Recall E2 [B8h] command. The master can issue “read time slots”
(see the 1-WIRE BUS SYSTEM section) following the Recall E2 command and the DS1822-PAR will
indicate the status of the recall by transmitting 0 while the recall is in progress and 1 when the recall is
done.

CONFIGURATION REGISTER

Byte 4 of the scratchpad memory contains the configuration register, which is organized as illustrated in
Figure 7. The user can set the conversion resolution of the DS1822-PAR using the R0 and R1 bits in this
register as shown in Table 3. The power-up default of these bits is R0 = 1 and R1 = 1 (12-bit resolution).
Note that there is a direct tradeoff between resolution and conversion time. Bit 7 and bits 0-4 in the
configuration register are reserved for internal use by the device and cannot be overwritten; these bits will
return 1s when read.

CONFIGURATION REGISTER Figure 7

bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0

0 R1 R0 1 1 1 1 1

THERMOMETER RESOLUTION CONFIGURATION Table 3

R1 R0 Resolution Max Conversion Time

0 0 9-bit 93.75 ms (t
0 1 10-bit 187.5 ms (t
1 0 11-bit 375 ms (t
1 1 12-bit 750 ms (t

CONV
CONV
CONV

CONV

/8)
/4)
/2)

)

CRC GENERATION

CRC bytes are provided as part of the DS1822-PAR’s 64-bit ROM code and in the 9th byte of the
scratchpad memory. The ROM code CRC is calculated from the first 56 bits of the ROM code and is
contained in the most significant byte of the ROM. The scratchpad CRC is calculated from the data
stored in the scratchpad, and therefore i t changes when the data in the scratchpad chan ges. The CRCs
provide the bus master with a method of data validation when data is re ad from the DS1822-PAR. To
verify that data has been read correctly, the bus master must re-calculate the CRC from the received data
and then compare this value to either the ROM code CRC (for ROM reads) or to the scratchpad CRC (for
scratchpad reads). If the calculated CRC matches the read CRC, the data has been received error free. The
comparison of CRC values and the decision to continue with an operation are determined entirely by the

6 of 19
