Features

• Serial Peripheral Interface (SPI) Compatible

• Supports SPI Modes 0 (0,0) and 3 (1,1)

• 20 MHz Clock Rate

• Byte Mode and 256-byte Page Mode for Program Operations

• Sector Architecture:

– Two Sectors with 32K Bytes Each (512K)
– Four Sectors with 32K Bytes Each (1M)
– 128 Pages per Sector

• Product Identification Mode

• Low-voltage Operation

– 2.7 (V

• Sector Write Protection

• Write Protect (WP) Pin and Write Disable Instructions for

both Hardware and Software Data Protection

• Self-timed Program Cycle (60 µs/Byte Typical)

• Self-timed Sector Erase Cycle (1 second/Sector Typical)

• Single Cycle Reprogramming (Erase and Program) for Status Register

• High Reliability

– Endurance: 10,000 Write Cycles Typical

• Lead-free Devices Available

• 8-lead JEDEC SOIC and 8-lead SAP Packages

= 2.7V to 3.6V)

CC

SPI Serial
Memory

512K (65,536 x 8)

1M (131,072 x 8)

AT25F512

Description

The AT25F512/1024 provides 524,288/1,048,576 bits of serial reprogrammable Flash
memory organized as 65,536/131,072 words of 8 bits each. The device is optimized
for use in many industrial and commercial applications where low-power and low-volt­age operation are essential. The AT25F512/1024 is available in a space-saving 8-lead
JEDEC SOIC and 8-lead SAP packages.

The AT25F512/1024 is enabled through the Chip Select pin (CS
3-wire interface consisting of Serial Data Input (SI), Serial Data Output (SO), and
Serial Clock (SCK). All write cycles are completely self-timed.

BLOCK WRITE protection for top 1/4, top 1/2 or the entire memory array (1M) or
entire memory array (512K) is enabled by programming the status register. Separate
write enable and write disable instructions are provided for additional data protection.
Hardware data protection is provided via the WP
write attempts to the status register. The HOLD

pin to protect against inadvertent

pin may be used to suspend any serial

communication without resetting the serial sequence.

Pin Configurations

Pin Name Function

CS

SCK Serial Data Clock

SI Serial Data Input

SO Serial Data Output

GND Ground

VCC Power Supply

WP

HOLD

Chip Select

Write Protect

Suspends Serial Input

8-lead SOIC

CS
SO

WP

GND

8-lead SAP

VCC

HOLD

SCK

SI

Bottom View

) and accessed via a

1
2
3
4

8
7
6
5

8
7
6
5

CS

1

SO

2

WP

3

GND

4

VCC
HOLD
SCK
SI

AT25F1024

Rev. 1440P–SEEPR–6/04

1

Absolute Maximum Ratings*

Operating Temperature........................................ −40°C to +85°C

Storage Temperature .........................................−65°C to +150°C

Voltage on Any Pin

with Respect to Ground ........................................ −1.0V to +3.6V

Maximum Operating Voltage ............................................ 3.6V

DC Output Current........................................................ 5.0 mA

Block Diagram

*NOTICE: Stresses beyond those listed under “Absolute

Maximum Ratings” may cause permanent dam­age to the device. This is a stress rating only and
functional operation of the device at these or any
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.

65,536 x 8

or

131,072 x 8

2

AT25F512/1024

1440P–SEEPR–6/04

AT25F512/1024

Pin Capacitance

(1)

Applicable over recommended operating range from TA = 25°C, f = 1.0 MHz, VCC = +3.6V (unless otherwise noted).

Symbol Test Conditions Max Units Conditions

C

OUT

C

IN

Output Capacitance (SO) 8 pF V

Input Capacitance (CS, SCK, SI, WP, HOLD)6pFV

OUT

IN

= 0V

= 0V

Note: 1. This parameter is characterized and is not 100% tested.

DC Characteristics

Applicable over recommended operating range from: TAI = -40°C to +85°C, VCC = +2.7V to +3.6V,
T

= 0°C to +70°C, VCC = +2.7V to +3.6V (unless otherwise noted).

AC

Symbol Parameter Test Condition Min Typ Max Units

V

CC

I

CC1

I

CC2

I

SB

I

IL

I

OL

(1)

V

IL

(1)

V

IH

V

OL

V

OH

Note: 1. V

Supply Voltage 2.7 3.6 V

Supply Current VCC = 3.6V at 20 MHz, SO = Open Read 10.0 15.0 mA

Supply Current VCC = 3.6V at 20 MHz, SO = Open Write 15.0 30.0 mA

Standby Current VCC = 2.7V, CS = V

Input Leakage VIN = 0V to V

CC

CC

-3.0 3.0 µA

2.0 10.0 µA

Output Leakage VIN = 0V to VCC, TAC = 0°C to 70°C -3.0 3.0 µA

Input Low Voltage -0.6 V

x 0.3 V

CC

Input High Voltage VCC x 0.7 VCC + 0.5 V

Output Low Voltage

IOL = 0.15 mA 0.2 V

2.7V ≤ VCC ≤ 3.6V

Output High Voltage IOH = -100 µA VCC - 0.2 V

and VIH max are reference only and are not tested.

IL

1440P–SEEPR–6/04

3

AC Characteristics

Applicable over recommended operating range from TAI = -40°C to +85°C, VCC = +2.7V to +3.6V
C

= 1 TTL Gate and 30 pF (unless otherwise noted).

L

Symbol Parameter Min Typ Max Units

f

SCK

t

RI

t

FI

t

WH

t

WL

t

CS

t

CSS

t

CSH

t

SU

t

H

t

HD

t

CD

t

V

t

HO

t

LZ

t

HZ

t

DIS

t

EC

t

BPC

t

SR

Endurance

(2)

Notes: 1. The programming time for n bytes will be equal to n x t

2. This parameter is characterized at 3.0V, 25°C and is not 100% tested.

3. One write cycle consists of erasing a sector, followed by programming the same sector.

SCK Clock Frequency 0 20 MHz

Input Rise Time 20 ns

Input Fall Time 20 ns

SCK High Time 20 ns

SCK Low Time 20 ns

CS High Time 25 ns

CS Setup Time 25 ns

CS Hold Time 25 ns

Data In Setup Time 5 ns

Data In Hold Time 5 ns

Hold Setup Time 15 ns

Hold Time 15 ns

Output Valid 20 ns

Output Hold Time 0 ns

Hold to Output Low Z 200 ns

Hold to Output High Z 200 ns

Output Disable Time 100 ns

Erase Cycle Time per Sector 1.1 s

Byte Program Cycle Time

(1)

60 100 µs

Status Register Write Cycle Time 60 ms

10K Write Cycles

.

BPC

(3)

4

AT25F512/1024

1440P–SEEPR–6/04

AT25F512/1024

Serial Interface Description

MASTER: The device that generates the serial clock.

SLAVE: Because the Serial Clock pin (SCK) is always an input, the AT25F512/1024

always operates as a slave.

TRANSMITTER/RECEIVER: The AT25F512/1024 has separate pins designated for
data transmission (SO) and reception (SI).

MSB: The Most Significant Bit (MSB) is the first bit transmitted and received.

SERIAL OP-CODE: After the device is selected with CS

received. This byte contains the op-code that defines the operations to be performed.

INVALID OP-CODE: If an invalid op-code is received, no data will be shifted into the
AT25F512/1024, and the serial output pin (SO) will remain in a high impedance state
until the falling edge of CS
communication.

CHIP SELECT: The AT25F512/1024 is selected when the CS
device is not selected, data will not be accepted via the SI pin, and the serial output pin
(SO) will remain in a high impedance state.

HOLD: The HOLD
AT25F512/1024. When the device is selected and a serial sequence is underway,
HOLD

can be used to pause the serial communication with the master device without
resetting the serial sequence. To pause, the HOLD
SCK pin is low. To resume serial communication, the HOLD
SCK pin is low (SCK may still toggle during HOLD
while the SO pin is in the high impedance state.

pin is used in conjunction with the CS pin to select the

is detected again. This will reinitialize the serial

going low, the first byte will be

pin is low. When the

pin must be brought low while the

pin is brought high while the

). Inputs to the SI pin will be ignored

WRITE PROTECT: The 25F512/1024 has a write lockout feature that can be activated
by asserting the write protect pin (WP
sectors will be READ only. The write protect pin will allow normal read/write operations
when held high. When the WP
the status register are inhibited. WP
the status register. If the internal status register write cycle has already been initiated,
WP

going low will have no effect on any write operation to the status register. The WP
pin function is blocked when the WPEN bit in the status register is “0”. This will allow the
user to install the AT25F512/1024 in a system with the WP
able to write to the status register. All WP
is set to “1”.

is brought low and WPEN bit is “1”, all write operations to

). When the lockout feature is activated, locked-out

going low while CS is still low will interrupt a write to

pin tied to ground and still be

pin functions are enabled when the WPEN bit

1440P–SEEPR–6/04

5

SPI Serial Interface

MASTER:

MICROCONTROLLER

DATA OUT (MOSI)

DATA IN (MISO)

SERIAL CLOCK (SPI CK)

SS0

SS1

SS2

SS3

SLAVE:

AT25F512/1024

SI

SO

SCK

CS

SI

SO

SCK

CS

SI

SO

SCK

CS

SI

SO

SCK

CS

6

AT25F512/1024

1440P–SEEPR–6/04

AT25F512/1024

Functional Description

The AT25F512/1024 is designed to interface directly with the synchronous serial periph­eral interface (SPI) of the 6800 type series of microcontrollers.

The AT25F512/1024 utilizes an 8-bit instruction register. The list of instructions and their
operation codes are contained in Table 1. All instructions, addresses, and data are
transferred with the MSB first and start with a high-to-low transition.

Write is defined as program and/or erase in this specification. The following commands,
PROGRAM, SECTOR ERASE, CHIP ERASE, and WRSR are write instructions for
AT25F512/1024.

Table 1. Instruction Set for the AT25F512/1024

Instruction

Instruction Name

WREN 0000 X110 Set Write Enable Latch

WRDI 0000 X100 Reset Write Enable Latch

RDSR 0000 X101 Read Status Register

WRSR 0000 X001 Write Status Register

READ 0000 X011 Read Data from Memory Array

PROGRAM 0000 X010 Program Data Into Memory Array

SECTOR ERASE 0101 X010 Erase One Sector in Memory Array

CHIP ERASE 0110 X010 Erase All Sectors in Memory Array

RDID 0001 X101 Read Manufacturer and Product ID

Format Operation

WRITE ENABLE (WREN): The device will power up in the write disable state when V

CC

is applied. All write instructions must therefore be preceded by the WREN instruction.

WRITE DISABLE (WRDI): To protect the device against inadvertent writes, the WRDI
instruction disables all write commands. The WRDI instruction is independent of the sta­tus of the WP

pin.

READ STATUS REGISTER (RDSR): The RDSR instruction provides access to the sta­tus register. The READY/BUSY and write enable status of the device can be determined
by the RDSR instruction. Similarly, the Block Write Protection bits indicate the extent of
protection employed. These bits are set by using the WRSR instruction. During internal
write cycles, all other commands will be ignored except the RDSR instruction.

Table 2. Status Register Format

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

WPEN X X X BP1 BP0 WEN RDY

1440P–SEEPR–6/04

7

Table 3. Read Status Register Bit Definition

Bit Definition

Bit 0 (RDY)

Bit 1 (WEN)

Bit 2 (BP0) See Table 4.

Bit 3 (BP1) See Table 4.

Bits 4-6 are 0s when device is not in an internal write cycle.

Bit 7 (WPEN) See Table 5.

Bits 0-7 are 1s during an internal write cycle.

Bit 0 = 0 (RDY
write cycle is in progress.

Bit 1 = 0 indicates the device is not WRITE ENABLED. Bit 1 = 1 indicates
the device is WRITE ENABLED.

) indicates the device is READY. Bit 0 = 1 indicates the

READ PRODUCT ID (RDID): The RDID instruction allows the user to read the manufac­turer and product ID of the device. The first byte after the instruction will be the
manufacturer code (1FH = ATMEL), followed by the device code.

WRITE STATUS REGISTER (WRSR): The WRSR instruction allows the user to select
one of four levels of protection for the AT25F1024. The AT25F1024 is divided into four
sectors where the top quarter (1/4), top half (1/2), or all of the memory sectors can be
protected (locked out) from write. The AT25F512 is divided into 2 sectors where all of
the memory sectors can be protected (locked out) from write. Any of the locked-out sec­tors will therefore be READ only. The locked-out sector and the corresponding status
register control bits are shown in Table 4.

The three bits, BP0, BP1, and WPEN, are nonvolatile cells that have the same proper­ties and functions as the regular memory cells (e.g., WREN, t

, RDSR).

WC

Table 4. Block Write Protect Bits

Status Register Bits AT25F512 AT25F1024

Array Addresses

Level

000

1(1/4) 0 1 018000 - 01FFFF Sector 4

2(1/2) 1 0 010000 - 01FFFF Sector 3, 4

3(All) 1 1 000000 - 00FFFF

BP1 BP0

Locked Out

None None

Locked-out

Sector(s)

All sectors

(1 - 2)

Array Addresses

Locked Out

None None

000000 - 01FFFF

Locked-out

Sector(s)

All sectors

(1 - 4)

8

AT25F512/1024

1440P–SEEPR–6/04

AT25F512/1024

The WRSR instruction also allows the user to enable or disable the Write Protect (WP)
pin through the use of the Write Protect Enable (WPEN) bit. Hardware write protection is
enabled when the WP
disabled when either the WP
ware write protected, writes to the Status Register, including the Block Protect bits and
the WPEN bit, and the locked-out sectors in the memory array are disabled. Write is
only allowed to sectors of the memory which are not locked out. The WRSR instruction
is self-timed to automatically erase and program BP0, BP1, and WPEN bits. In order to
write the status register, the device must first be write enabled via the WREN instruction.
Then, the instruction and data for the three bits are entered. During the internal write
cycle, all instructions will be ignored except RDSR instructions. The AT25F512/1024 will
automatically return to write disable state at the completion of the WRSR cycle.

Note: When the WPEN bit is hardware write protected, it cannot be changed back to “0”, as

long as the WP pin is held low.

Table 5. WPEN Operation

WPEN WP WEN ProtectedBlocks UnprotectedBlocks Status Register

0 X 0 Protected Protected Protected

0 X 1 Protected Writable Writable

1 Low 0 Protected Protected Protected

pin is low and the WPEN bit is “1”. Hardware write protection is

pin is high or the WPEN bit is “0.” When the device is hard-

1 Low 1 Protected Writable Protected

X High 0 Protected Protected Protected

X High 1 Protected Writable Writable

READ* (READ): Reading the AT25F512/1024 via the SO (Serial Output) pin requires
the following sequence. After the CS

line is pulled low to select a device, the READ
instruction is transmitted via the SI line followed by the byte address to be read (Refer to
Table 6). Upon completion, any data on the SI line will be ignored. The data (D7-D0) at
the specified address is then shifted out onto the SO line. If only one byte is to be read,
the CS

line should be driven high after the data comes out. The READ instruction can
be continued since the byte address is automatically incremented and data will continue
to be shifted out. For the AT25F1024, when the highest address is reached, the address
counter will roll over to the lowest address allowing the entire memory to be read in one
continuous READ instruction. For the AT25F512, the read command must be termi­nated when the highest address (00FFFF) is reached.

PROGRAM (PROGRAM): In order to program the AT25F512/1024, two separate
instructions must be executed. First, the device must be write enabled via the WREN
instruction. Then the PROGRAM instruction can be executed. Also, the address of the
memory location(s) to be programmed must be outside the protected address field loca­tion selected by the Block Write Protection Level. During an internal self-timed
programming cycle, all commands will be ignored except the RDSR instruction.

The PROGRAM instruction requires the following sequence. After the CS

line is pulled
low to select the device, the PROGRAM instruction is transmitted via the SI line followed
by the byte address and the data (D7-D0) to be programmed (Refer to Table 6). Pro­gramming will start after the CS

pin is brought high. The low-to-high transition of the CS
pin must occur during the SCK low time immediately after clocking in the D0 (LSB) data
bit.

1440P–SEEPR–6/04

9

The READY/BUSY status of the device can be determined by initiating a RDSR instruc­tion. If Bit 0 = 1, the program cycle is still in progress. If Bit 0 = 0, the program cycle has
ended. Only the RDSR instruction is enabled during the program cycle.

A single PROGRAM instruction programs 1 to 256 consecutive bytes within a page if it
is not write protected. The starting byte could be anywhere within the page. When the
end of the page is reached, the address will wrap around to the beginning of the same
page. If the data to be programmed are less than a full page, the data of all other bytes
on the same page will remain unchanged. If more than 256 bytes of data are provided,
the address counter will roll over on the same page and the previous data provided will
be replaced. The same byte cannot be reprogrammed without erasing the whole sector
first. The AT25F512/1024 will automatically return to the write disable state at the com­pletion of the PROGRAM cycle.

Note: If the device is not write enabled (WREN), the device will ignore the Write instruction and

will return to the standby state, when CS is brought high. A new CS falling edge is
required to re-initiate the serial communication.

Table 6. Address Key

Address AT25F512 AT25F1024

A

N

Zeros A

Don’t Care Bits A

Note: 1. For the AT25F512, A16 must be set to zero. If A16 of the AT25F512 is set to ONE,

READ data out are undetermined and PROGRAM, SECTOR ERASE and CHIP
ERASE may incur busy cycles.

A15 - A

(1)

16

- A

23

0

17

A16 - A

-

A

- A

23

0

17

SECTOR ERASE (SECTOR ERASE): Before a byte can be reprogrammed, the sector
which contains the byte must be erased. In order to erase the AT25F512/1024, two sep­arate instructions must be executed. First, the device must be write enabled via the
WREN instruction. Then the SECTOR ERASE instruction can be executed.

Table 7. Sector Addresses

Sector Address AT25F512 Sector AT25F1024 Sector

000000 to 007FFF Sector 1 Sector 1

008000 to 00FFFF Sector 2 Sector 2

010000 to 017FFF N/A Sector 3

018000 to 01FFFF N/A Sector 4

The SECTOR ERASE instruction erases every byte in the selected sector if the sector is
not locked out. Sector address is automatically determined if any address within the sec­tor is selected. The SECTOR ERASE instruction is internally controlled; it will
automatically be timed to completion. During this time, all commands will be ignored,
except RDSR instruction. The AT25F512/1024 will automatically return to the write dis­able state at the completion of the SECTOR ERASE cycle.

CHIP ERASE (CHIP ERASE): As an alternative to the SECTOR ERASE, the CHIP
ERASE instruction will erase every byte in all sectors that are not locked out. First, the
device must be write enabled via the WREN instruction. Then the CHIP ERASE instruc­tion can be executed. The CHIP ERASE instruction is internally controlled; it will
automatically be timed to completion. The CHIP ERASE cycle time typically is 3.5 sec­onds. During the internal erase cycle, all instructions will be ignored except RDSR. The
AT25F512/1024 will automatically return to the write disable state at the completion of
the CHIP ERASE cycle.

10

AT25F512/1024

1440P–SEEPR–6/04

Timing Diagrams (for SPI Mode 0 (0, 0))

Synchronous Data Timing

V

IH

CS

V

IL

t

CSS

V

SCK

SO

IH

V

IL

t

SU

V

IH

SI

V

IL

V

OH

HI-Z

V

OL

VAL ID IN

t

WH

t

H

AT25F512/1024

t

CS

t

CSH

t

WL

t

V

t

HO

t

DIS

HI-Z

WREN Timing

WRDI Timing

1440P–SEEPR–6/04

11

RDSR Timing

CS

WRSR Timing

SCK

SI

SO

01234567891011121314

INSTRUCTION

HIGH IMPEDANCE

76543210

DATA OUT

MSB

15

READ Timing

12

AT25F512/1024

CS

SCK

SI

SO

0123445566778 9 10 11 28

3-BYTE ADDRESS

INSTRUCTION

HIGH IMPEDANCE

23 22 21 3

29 30 31 32 33 34 35 36 37 38

...

21

39

32100

1440P–SEEPR–6/04

PROGRAM Timing

CS

AT25F512/1024

SCK

SI

SO

HOLD Timing

HOLD

0123456789101128

3-BYTE ADDRESS

INSTRUCTION

23 22 21 3 1 0 6 5 4 3 2 1 072

HIGH IMPEDANCE

CS

t

CD

SCK

t

HD

t

SO

29 30 31 32 33 34

1st BYTE DATA-IN

t

HD

HZ

2075

2076

t

CD

t

LZ

2077

2078

2079

256th BYTE DATA-IN

SECTOR ERASE Timing

1440P–SEEPR–6/04

X

X = Don’t Care bit

13

CHIP ERASE Timing

RDID Timing

X

X = Don’t Care bit

12 13 14 15 16 172318 19

X

MANUFACTURER
CODE (ATMEL)

DEVICE CODE

14

AT25F512/1024

1440P–SEEPR–6/04

AT25F512/1024

Ordering Information

Ordering Code Package Operation Range

AT25F512N-10SI-2.7 8S1

AT25F1024N-10SI-2.7 8S1

AT25F512N-10SU-2.7
AT25F512Y4-10YU-2.7

AT25F1024N-10SU-2.7
AT25F1024Y4-10YU-2.7

8S1
8Y4

8S1
8Y4

Lead-free/Halogen Free/Industrial Temperatures

Lead-free/Halogen Free/Industrial Temperatures

Industrial

(-40°C to 85°C)

Industrial

(-40°C to 85°C)

(-40°C to 85°C)

(-40°C to 85°C)

Package Type

8S1 8-lead, 0.150" Wide, Plastic Gull Wing Small Outline Package (JEDEC SOIC)

8Y4 8-lead, 6.00 mm x 4.90 mm Body, Dual Footprint, Non-leaded, Small Array Package (SAP)

Options

-2.7 Low-voltage (2.7V to 3.6V)

1440P–SEEPR–6/04

15

Package Drawing

8S1 – JEDEC SOIC

C

1

E

N

∅

E1

L

Top View

End View

e

D

Side View

B

A

SYMBOL

A1

A 1.35 – 1.75

A1 0.10 – 0.25

b 0.31 – 0.51

C 0.17 – 0.25

D 4.80 – 5.00

E1 3.81 – 3.99

E 5.79 – 6.20

e 1.27 BSC

L 0.40 – 1.27

∅ 0˚ – 8˚

COMMON DIMENSIONS

(Unit of Measure = mm)

MIN

NOM

MAX

NOTE

16

Note:

These drawings are for general information only. Refer to JEDEC Drawing MS-012, Variation AA for proper dimensions, tolerances, datums, etc.

1150 E. Cheyenne Mtn. Blvd.
Colorado Springs, CO 80906

R

TITLE
8S1, 8-lead (0.150" Wide Body), Plastic Gull Wing

Small Outline (JEDEC SOIC)

DRAWING NO.

AT25F512/1024

10/7/03

REV.

8S1 B

1440P–SEEPR–6/04

8Y4 – SAP

AT25F512/1024

PIN 1 INDEX AREA

D

E

1150 E. Cheyenne Mtn. Blvd.

R

Colorado Springs, CO 80817

A

PIN 1 ID

E1

A1

b

e1

A

COMMON DIMENSIONS

(Unit of Measure = mm)

SYMBOL

A – – 0.90

A1 0.00 – 0.05

D 5.80 6.00 6.20

E 4.70 4.90 5.10

D1 2.85 3.00 3.15

E1 2.85 3.00 3.15

b 0.35 0.40 0.45

e 1.27 TYP

e1 3.81 REF

L 0.50 0.60 0.70

TITLE

8Y4, 8-lead (6.00 x 4.90 mm Body) SOIC Array Package
(SAP) Y4

MIN

NOM

MAX

D1

NOTE

DRAWING NO.

8Y4

L

e

5/24/04

REV.

A

1440P–SEEPR–6/04

17

Atmel Corporation Atmel Operations

2325 Orchard Parkway
San Jose, CA 95131, USA
Tel: [phone]
Fax: [phone]

Regional Headquarters

Europe

Atmel Sarl
Route des Arsenaux 41
Case Postale 80
CH-1705 Fribourg
Switzerland
Tel: [phone]
Fax: [phone]

Asia

Room 1219
Chinachem Golden Plaza
77 Mody Road Tsimshatsui
East Kowloon
Hong Kong
Tel: [phone]
Fax: [phone]

Japan

9F, Tonetsu Shinkawa Bldg.
1-24-8 Shinkawa
Chuo-ku, Tokyo 104-0033
Japan
Tel: [phone]
Fax: [phone]

Memory

2325 Orchard Parkway
San Jose, CA 95131, USA
Tel: [phone]
Fax: [phone]

Microcontrollers

2325 Orchard Parkway
San Jose, CA 95131, USA
Tel: [phone]
Fax: [phone]

La Chantrerie
BP 70602
44306 Nantes Cedex 3, France
Tel: [phone]
Fax: [phone]

ASIC/ASSP/Smart Cards

Zone Industrielle
13106 Rousset Cedex, France
Tel: [phone]
Fax: [phone]

1150 East Cheyenne Mtn. Blvd.
Colorado Springs, CO 80906, USA
Tel: [phone]
Fax: [phone]

Scottish Enterprise Technology Park
Maxwell Building
East Kilbride G75 0QR, Scotland
Tel: [phone]
Fax: [phone]

RF/Automotive

Theresienstrasse 2
Postfach 3535
74025 Heilbronn, Germany
Tel: [phone]
Fax: [phone]

1150 East Cheyenne Mtn. Blvd.
Colorado Springs, CO 80906, USA
Tel: [phone]
Fax: [phone]

Biometrics/Imaging/Hi-Rel MPU/
High Speed Converters/RF Datacom

Avenue de Rochepleine
BP 123
38521 Saint-Egreve Cedex, France
Tel: [phone]
Fax: [phone]

Literature Requests

www.atmel.com/literature

Disclaimer: Atmel Corporation makes no warranty for the use of its products, other than those expressly contained in the Company’s standard
warranty which is detailed in Atmel’s Terms and Conditions located on the Company’s web site. The Company assumes no responsibility for any
errors which may appear in this document, reserves the right to change devices or specifications detailed herein at any time without notice, and
does not make any commitment to update the information contained herein. No licenses to patents or other intellectual property of Atmel are
granted by the Company in connection with the sale of Atmel products, expressly or by implication. Atmel’s products are not authorized for use
as critical components in life support devices or systems.

© Atmel Corporation 2004. All rights reserved. Atmel® and combinations thereof, are the registered trademarks of Atmel Corporation or its
subsidiaries. Other terms and product names may be the trademarks of others.

Printed on recycled paper.

1440P–SEEPR–6/04
