RaidSonic IB-HUBA001 User Manual

Quick installation guide IB-HUBA001
Mounting-Adapter for Table-Hubs
Quick installation guide IB-HUBA001
Packing content: 1x IB-HUBA001, 1x quick installation guide
Key features:
• Enables the mounting of 60 mm table hubs in 80 mm feedthroughs
• Small extensions for a secure grip in the tabletop
• Cover outer diameter: 89 mm
• Adapter inner / outer diameter: 59,5 mm / 79 mm
Schnellinstallationsanleitung IB-HUBA001
Verpackungsinhalt: 1x IB-HUBA001, 1x Schnellinstallationsanleitung
Hauptmerkmale:
• Ermöglicht den Einbau von 60 mm Tisch-Hubs in 80 mm Durchführungen
• Kleine Verbreiterungen für sicheren Halt in der Tischplatte
• Gefertigt aus hochwertigem Kunststoff
• Cover Außendurchmesser: 89 mm
• Adapter Außen- / Innendurchmesser: 59,5 mm / 79 mm
Installation / Einbau
1
3
The information contained in this manual is believed to be accurate and reliable. RaidSonic Technology GmbH assumes no responsibility for any errors contained in this manual. RaidSonic Technology GmbH reserves the right to make changes in the specifications and/or design of the above mentioned product without prior notice. The diagrams contained in this manual may also not fully represent the product that you are using and are there for illustration purposes only. RaidSonic Technology GmbH assumes no responsibility for any differences between the product mentioned in this manual and the product you may have.
© Copyright 2019 by RaidSonic Technology GmbH. All Rights Reserved.
