Technology GmbH
www.raidsonic.de
ICY BOX
IB-AC603P-C31
External enclosure for
2.5" SATA HDD/SSD
Key features
• Supports 2.5" SATA III 6 Gbit/s HDD/SSD
• USB 3.1 Type-C™ host interface 10 Gbit/s with UASP
• With HDD protection box and protection sleeve
• Toolless HDD installation
• Supports Windows®, Mac
• Plug & Play and Hot Swap
®
Packing content
USB 3.1 to SATA adapter, protection box, protection sleeve, manual
Two for one
The IB-AC603P-C31 adapter for a 2.5" SATA HDD or SSD consists of an adapter SATA III to USB 3.1 Type-C™ and a plastic enclosure with a silicone mantel.
You can use them separately or together. Use the USB 3.1 interface to connect the adapter directly to a computer, multi media player or to other devices with a
Type-C™ interface and your data transfer can reach up to 6 Gbit/s.
Technical data
Article No.
EAN code
Brand
Colour
Material
HDD interface
HDD height
HDD capacity
Hot Swap
Plug & Play
External data interface
Operating system
Transfer rate
Chipset
LED
60201
4250078165347
ICY BOX
Black
Plastic
1x 2.5" SATA III, 6 Gbit/s
Up to 9.5 mm (within protection box)
No limit
Yes
Yes
1x USB 3.1 Type-C
Windows
USB 3.1 up to 10 Gbit/s
VL716
Power: continuous blue lightning, Access: Blue light flashing
®
, Mac
™
®
with UASP
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
www.raidsonic.de
ICY BOX IB-AC603P-C31
External enclosure for 2.5" SATA HDD/SSD
Always at your side
With the provided protection case (max. HDD height 9.5 mm) your HDD/SSD is protected from schock
and dust. Thanks to the driverless plug & play feature its fast and easy to connect to any PC
Fast data transfer
IB-AC603P-C31 can achieve up to 6 Gbit/s with USB 3.1. This means fast data transfer and reliability!
Easy
The HDD/SSD itself only needs to be connected to the adapter and put into the protection box. Just slip
over the protection sleeve without the need of tools. The HDD/SSD is recognized without extra driver
installation. Its just this easy to handle!
Logistical data
Packing unit:
Total weight::
Gross weight: (with packing):
Net weight:
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
40 pcs./carton
10.4 kg/carton
0.236 kg
0.021 kg
Dimension/Carton:
Dimension (with packing):
Dimension of article:
Country of Origin:
500x420x330 mm
200x150x45 mm
68x22x10 mm
China
