RaidSonic IB-2501U3 User Manual
Technology GmbH
www.raidsonic.de
ICY BOX
IB-2501U3
1 bay USB 3.0 DockingStation
for 2.5" SATA HDD/SSD
Key features
• HDD/SSD DockingStation with integrated USB-cable (50 cm length)
• Support 2.5" SATA HDD/SSD, capacity unlimited
• Support SATA III, up to 6 Gbit/s
• USB 3.0 host interface with up to 5 Gbit/s and UASP
• LED for power and HDD/SSD access
• Plug & Play and HotSwap
Packing content
1x DockingStation, 1x manual
For quick dockings
The ICY BOX IB-2501U3 is a DockingStation specialised for 2.5" SATA HDDs or SSDs. It‘s so easy to dock: simply plug the HDD into the ICY BOX with the SATA
connector down and data can flow – USB 3.0 allows for fast transfer of large files such as movies.
Technical data
Model
Article no.
EAN code
Brand
Colour
Material
Chipset
HDD/SSD interface
HDD height
IB-2501U3
6 0134
4250078164685
ICY BOX
Black
Plastic
JMS578
1x 2.5" SATA
up to 15 mm
External data interface
UASP support
Transfer rate
HDD capacity
HotSwap
Plug & Play
Operating system
LED
1x USB 3.0, integrated cable: USB Type-A (Host PC)
Yes
Up to 5 Gbit/s
Unlimited
Yes
Yes
Windows, macOS
Power and HDD/SSD access
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
Technology GmbH
www.raidsonic.de
ICY BOX IB-2501U3
1 bay USB 3.0 DockingStation for 2.5" SATA HDD/SSD
Dock and load in record time
This DockingStation is a 2.5" specalist. It is able to handle 2.5" HDD/SSDs of with heights up to 15 mm.
Furthermore the IB-2501U3 is always ready, because the cable can‘t be lost and no power supply is
required.
Matt black
This new 2.5" DockingStation presents itself in an elegant matt black design of high quality plastic. A real
visual treat in practical pocket format.
Always up to date
A blue LED gives the user information about the current (power) and the access (read / write) of the hard
disk. Four rubber feet at the bottom ensure a firm grip of the dock on slippery surfaces. Any operating system can communicate with the docking station, and no additional driver is needed for the operation.
Logistical data
Packing unit:
Total weight::
Gross weight: (with packing):
Net weight:
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany
Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
40 pcs./carton
8.7 kg/carton
0.201 kg
0.108 kg
Dimension/Carton:
Dimension (with packing):
Dimension of article:
Country of Origin:
420x255x440 mm
46x103x204 mm
59x94x41 mm
China
