RaidSonic IB-167SSK User Manual

Technology GmbH
www.raidsonic.de
ICY BOX
IB-167SSK
Mobile Rack for 1x 3.5" SATA/SAS drive
• Mobile Rack for 1x 3.5" SATA/SAS HDD
• Easy Swap - Fast HDD installation and exchange without tray
• Supports SATA I/II/III up to 6 Gbit/s
• Fits in a standard 5.25” bay
• Key lock to prevent improper operation
• Power switch for installed HDD and LED for power & access
• Supports Hot Swap
Packing content
1x IB-167SSK, 1x SATA cable, 1x Screws kit, 2x Keys, 1x Manual
One in one
This Mobile Rack is designed for one 3.5" SATA HDD and fits perfectly into a 5.25" and thus offers a unique space saving solution. The trayless design and Hot Swap make the exchange of HDDs faster and more convenient.
Technical data
Model Article no. EAN code Brand Colour Material HDD size HDD interface HDD capacity Transfer rate
IB-167SSK 60622 4250078169642 ICY BOX Black Steel, plastic
3.5" 1x 3.5" SATA/SAS Unlimited SATA III up to 6 Gbit/s
Space required Interface to host computer Power switch HotSwap Plug & Play LED Lock Power supply Operating system
1x 5.25" bay 1x SATA power 15 pin/ 1x SATA data 7 pin Yes Yes Yes Power and access Yes SATA Power 15Pin or MOLEX 4 pin
®
®
, macOS
Windows
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
Technology GmbH
www.raidsonic.de
ICY BOX IB-167SSK Mobile Rack for 1x 3.5" SATA/SAS drive
Outputting!
Fits into a 5.25" bay and offers space for one 3.5" SATA/SAS HDD. Thanks to the innovative eject mecha­nism, even new hard disks with irregular backs can be ejected without any problems.
Safety is taken care of
The hard disk slot can be locked and the installation/exchange is fast and uncomplicated due to the trayless design.
Rest
Depending on whether the HDD is to be used or not, the hard disk can be switched on or off without making any major changes to the hardware.
Logistical data
Packing unit: Total weight:: Gross weight: (with packing): Net weight:
RaidSonic Technology GmbH • Kurt-Fischer-Straße 50 • 22926 Ahrensburg / Germany Telephone: +49-(0)4102 – 468 900 (Sales) • Fax: +49-(0)4102 – 468 901 • info@raidsonic.de • www.raidsonic.de
Offers and deliveries are only done under our General Terms and Conditions. Errors and omissions excepted.
20 pcs./carton
9.5 kg/carton
0.427 kg
0.280kg
Dimension/Carton: Dimension (with packing): Dimension of article: Country of Origin:
455x325x280 mm 50x155x210 mm 190x145x41 mm Taiwan
