Radwin RW5XMOD User Manual

AP0127730, AP0134760
RF Module Operating in the 4.9-5.8 GHz bands
REFERENCE GUIDE
Warning
Avertissement
Regulatory Compliance
FCC/IC - Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and IC RSS standards. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
the receiver is connected.
It is the responsibility of the installer to ensure that when using the outdoor antenna kits, only those antennas certified with the product are used. The use
of any antenna other than those certified with the product is expressly
forbidden by FCC 47 CFR Part 15.204 and IC RSS standards.
Il est de la responsabilité de l'installateur de s'assurer que lorsque vous utilisez les kits d'antennes extérieures, seules les antennes certifiés avec le produit sont utilisés. L'utilisation d'une antenne autre que ceux qui sont certifiés avec le produit est expressément interdite par la réglementation FCC partie 47 CFR 15.204 et IC normes RSS.
AP0127730, AP0134760 Reference Guide i
Outdoor units and antennas should be installed ONLY by experienced installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void the product warranty and
may expose the end user or the service provider to legal and financial
Caution liabilities. Resellers or distributors of this equipment are not liable for injury,
damage or violation of regulations associated with the installation of outdoor units or antennas. The installer should configure the output power level of
antennas according to country regulations and antenna type.
This equipment should be installed and operated with a minimum distance of 354cm between
the radiator and your body.
Warning
The module is granted to operate under FCC certification in the 4.9 GHz,
5.2 / 5.3 / 5.4 / 5.8 GHz bands.
Warning
Prudence
Avertissement
Warning
Devices subject to RSS-247 issue 1 shall not be capable of transmitting in the band 5600-5650 MHz.
Les unités extérieures et les antennes doivent être installés que par des
professionnels expérimentés d'installation qui sont familiers avec les normes locales et les codes de sécurité et, si applicable, sont agréées par les autorités gouvernementales de réglementation compétents. Ne pas le faire peut annuler
la garantie du produit et peuvent exposer l'utilisateur final ou le fournisseur de
services d'obligations juridiques et financiers. Revendeurs ou distributeurs de ces équipements ne sont pas responsables des blessures, des dommages ou violation des règlements liés à l'installation des unités extérieures ou des antennes. L'installateur doit configurer le niveau de puissance de sortie des antennes conformément aux réglementations nationales et le type d'antenne.
Cet équipement doit être installé et utilisé à une distance minimale de 354cm
entre le radiateur et votre corps.
This device complies with Part 15 of the FCC rules and with Industry Canada license-
exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil est conforme la norme d'Industrie Canada exempts de licence RSS (s). Son fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas causer d'interférences, et
2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada
AP0127730, AP0134760 Reference Guide ii
Overview
The AP0127730, AP0134760 is an RF module operating in the 4.9 – 5.8 GHz frequency bands. It is a TDD OFDM radio supporting 5 MHz, 10 MHz, 20 MHz and 40 MHz channel bandwidths. The RF module cannot work as a stand-alone device. It can operate and be controlled only when attached to a digital main board and altogether assembled in an enclosure suitable for outdoor use. The assembly of the RF module attached to the digital main board is hereafter referred to as ‘ODU’. The ODU in its various outdoor enclosures is manufactured by RADWIN. The RF module is certified as a limited modular approval type with the FCC ID: Q3KRW5XMOD and IC: 5100A-RW5XMOD.
Condition of Use
The AP0127730, AP0134760 RF module is a proprietary radio interface and can only be connected to digital boards manufactured by RADWIN. The ODU resides in an outdoor enclosure also manufactured and assembled by RADWIN or its subcontractors. The RF
module is not for sale to the general public.
FCC rules and IC Regulation Restrictions
The ODU firmware is factory programmed to operate under the FCC rules and Industry Canada regulation restrictions. The firmware is locked and inaccessible by any third party. As a result of the above the user interface allows both the installer and the user to control the
ODU only within the boundaries of the regional restrictions.
Antennas
The AP0127730, AP0134760 RF module is certified with various antenna types covering both Point-to-Point and Point-to-Multipoint systems up to 32 dBi gain.
AP0127730, AP0134760 Reference Guide 1
Certified Antennas
Antenna Type
Manufacturer
Model Number
Antenna Max
Gain (dBi)
Sector Dual Pole Integrated 120 Deg
RADWIN Ltd.
MT0128930
11
Sector Dual Pole 120 Deg
RADWIN Ltd.
RW-9061-5004
11
Sector Dual Pole Integrated 95 Deg
RADWIN Ltd.
AM0135060
12
Sector Dual Pole 90 Deg
RADWIN Ltd.
RW-9061-5001
14
Sector Dual Pole 60 Deg
RADWIN Ltd.
RW-9061-5002
16.5
Sector Dual Pole Integrated 90 Deg
RADWIN Ltd.
MT0125250
13
Flat Panel Dual Pole Integrated
RADWIN Ltd.
AM0119960
16
Flat Panel Dual Pole Integrated
RADWIN Ltd.
AM0111760
16.5
Flat Panel Dual Pole Integrated
RADWIN Ltd.
MT0070760
24
Flat Panel Dual Pole External
RADWIN Ltd.
RW-9612-5001
23
Flat Panel Dual Pole External
RADWIN Ltd.
RW-9622-5001
29
Dual Pole Dish
RADWIN Ltd.
RW-9721-5158
29
Dual Pole Dish
RADWIN Ltd.
RW-9732-4958*
32
Shark Fin Monopole
RADWIN Ltd.
RW-9401-5002
12.5
Following is the list of antennas certified for use with the AP0127730, AP0134760 RF
module:
* Not applicable for 4.9 GHz band
Maximum Output Power
5725 – 5850 MHz band - FCC/IC
The maximum output power can be set as follows, when operating in the 5.8 GHz band, under FCC 47 CFR Part 15.247 Rule and IC RSS-247 regulations. The power values are for PtP systems and PtMP systems with 0 to 6 dBi total antenna assembly gain. For PtMP systems the total EIRP is limited to 36 dBm. Therefore the output power of these systems, using higher than 6 dBi total antenna assembly gains will be reduced to comply with 36 dBm EIRP. The highest conducted output power shall be limited to 30 dBm in all channel bandwidths
AP0127730, AP0134760 Reference Guide 2
4940 – 4990 MHz band - FCC/IC
The maximum output power can be set as follows, when operating in the 4.9 GHz band, under FCC 47 CFR Part 90Y Rule and IC RSS-111 regulations. The power values shown below are for systems using 0 to 26 dBi total antenna assembly gain. Systems using 29 dBi gain antenna must reduce output power by 3 dB.
5 MHz: 25.0 dBm 10 MHz: 23.0 dBm 20 MHz: 24.0 dBm
5250 – 5350 MHz band – FCC/IC
The maximum output power can be set as follows, when operating in the 5.2 GHz band, under FCC 47 CFR Part 15.407 New Rules and IC RSS-247 regulations. The total EIRP limit is 30 dBm. The power values are for systems with 0 to 6 dBi total antenna assembly gain. For systems using higher than 6 dBi total assembly gain antennas the output power will be reduced to comply with 30 dBm EIRP.
5 MHz: 18.0 dBm 10 MHz: 20.0 dBm 20 MHz: 23.0 dBm
40 MHz: 24.0 dBm
5470 – 5725 MHz band – FCC/IC
The maximum output power can be set as follows, when operating in the 5.4 GHz band, under FCC 47 CFR Part 15.407 New Rules and IC regulations. The total EIRP limit is 30 dBm. The power values are for systems with 0 to 6 dBi total antenna assembly gain. For systems using higher than 6 dBi total assembly gain antennas the output power will be reduced to comply with 30 dBm EIRP.
5 MHz: 17.0 dBm 10 MHz: 20.0 dBm 20 MHz: 23.0 dBm 40 MHz: 24.0 dBm
5150 – 5250 MHz band – FCC
The maximum output power can be set as follows when transmitting in the 5.1 GHz band, under FCC 47 CFR Part 15.407 New Rules and regulations. The total EIRP limit for PtP applications is 53 dBm. The total EIRP limit for PtMP applications is 36 dBm. The total EIRP limit for PtMP applications when transmitting at elevations above 30° relative to the horizon is 21 dBm.
5 MHz: 24.0 dBm 10 MHz: 27.0 dBm 20 MHz: 28.0 dBm 40 MHz: 23.0 dBm
AP0127730, AP0134760 Reference Guide 3
Channel Bandwidths and Frequency Range
Channel BW
[MHz]
Center Freq. Range
[MHz]
5
5255 - 5345
10
5260 - 5340
20
5265 - 5335
40
5275 - 5320
5
5475 - 57203
10
5475 - 57203
20
5480 - 57153
40
5500 - 56953
5
5727.5 - 5847.5
10
5730 - 5845
20
5735 - 5840
40
5745 - 5830
5
4942.5 – 4987.5
10
4945 – 4985
20
4950 - 4980
5
5157 - 5245
10
5162 – 5245
20
5165 – 5240
40
5172 - 5230
Radio parameters accessed by end-user
The following parameters can be accessed by user:
1. Output Power
2. Frequency channel
3. Channel bandwidth
4. Antenna gain in external antenna type device
AP0127730, AP0134760 Reference Guide 4
