TAD-705
12-Memory Speakerphone
with 16-Minute Digital TAD
and 62-Memory Caller ID
Owner’s Manual
Please read before using this equipment.
43-705.fm Page 2 Tuesday, May 23, 2000 8:54 AM
ˆ
Contents
Features .................................................................................................................................. 5
Preparation ............................................................................................................................. 7
Installing a Backup Battery ................................................................................................ 7
Mounting the TAD ............................................................................................................. 7
On a Desk .................................................................................................................. 8
On a Wall or Wall Plate .............................................................................................. 8
Setting the Dialing Mode ................................................................................................... 9
Setting the Ringer ............................................................................................................. 9
Setting the Display Contrast .............................................................................................. 9
Setting the Long Distance Code ....................................................................................... 9
Setting the Area Code ....................................................................................................... 9
Setting the Day, Time and Date ...................................................................................... 10
Setting the Number of Rings ........................................................................................... 10
Telephone Operation .................................... ... .. ................................................................... 11
Switching Between the Handset and the Speakerphone ................................................ 11
Adjusting the Volume ...................................................................................................... 11
Using Redial .................................................................................................................... 12
Using Flash ............................... ...................................................................................... 12
Using Hold ....................................................................................................................... 12
Using Privacy ................................................................ ..................................... ............. 12
Using Tone Services on a Pulse Line .............................................................................. 12
Memory Dialing ................................. ... .................................... ... .................................... 12
Storing a Number in Memory ................................................................................... 13
Storing Numbers from Caller ID Records ................................................................ 13
Entering a Pause in a Memory Number ................................................................... 13
Reviewing Memory Numbers ................................................................................... 13
Dialing a Memory Number ....................................................................................... 14
Chain-Dialing ...................................................... ... ..................................... ............. 14
Testing Stored Emergency Numbers ....................................................................... 14
Connecting an Optional Headset .................................................................................... 14
TAD Operation ................................ ... ................................. ... ............................................... 15
Recording the Outgoing Messages ................................................................................. 15
Checking the Outgoing Messages .................................................................................. 15
Setting the TAD to Answer Calls ..................................................................................... 15
Announce Only ........................................................................................................ 16
Incoming Message Recording ......................................................................................... 16
Playing Messages ........................................................................................................... 16
Recording a Memo .......................................................................................................... 17
Recording a Conversation ............................................................................................... 17
Deleting Messages .......................................................................................................... 18
Screening Calls ............................................................................................................... 18
©
2000 Tandy Corporation.
RadioShack and RadioShack.com are trademarks used by Tandy Corporation.
2
All Rights Reserved.
43-705.fm Page 3 Tuesday, May 23, 2000 8:54 AM
Using Call Breakthrough ................................................................................................. 18
Changing the CBT Code ......................................................................................... 18
Changing the Remote Operation Security Code ............................................................ 19
Remote Operation .......................................................................................................... 19
Using the Toll-Saver ....................................... ... ... .......................................................... 19
Using Remote Commands ........................................................................................ ... .. 19
Remote Command List ............................................................................................ 19
Caller ID Operation .............................................................................................................. 21
Caller ID Messages ........................................................................................................ 22
Reviewing Caller ID Records .......................................................................................... 22
Reviewing the Call Forwarding Information ............................................................. 23
Deleting Call Records ..................................................................................................... 23
Deleting a Single Call .............................................................................................. 23
Deleting All Calls ..................................................................................................... 23
VIP Call List .................................................................................................................... 23
Marking a Call Record as a VIP Call Record .......................................................... 23
Setting the VIP Alert ................................................................................................ 24
Dialing Number Selections ...................................................................................... 24
Using Dial ................................................ ................................................................ 24
Troubleshooting ................................................................................................................... 26
Resetting the TAD .......................................................................................................... 27
Care ................................................................................................................................ 27
WARNING:
To reduce the risk of fire or shock hazard, do
not expose this product to rain or moisture.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION:
DO NOT REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
PERSONNEL.
TO REDUCE THE RISK OF ELECTRIC SHOCK,
This symbol is intended to alert you to the presence of uninsulated dangerous voltage within
the product’s enclosure that might be of sufficient magnitude to constitute a risk of electric
shock. Do not open the product’s case.
This symbol is intended to inform you that important operating and maintenance instructions are
!
included in the literature accompanying this
product.
!
3
43-705.fm Page 4 Tuesday, May 23, 2000 8:54 AM
Your TAD (Telephone Answering Device) is
ETL listed to UL standards and meets all applicable FCC standards.
IMPORTANT CALLER ID
INFORMATION
To use the TAD’s Caller ID, you must be in
an area where Caller ID service is available,
and you must subscribe to the service.
Where Caller ID is offered, one or more of
the following options are generally available:
• caller's number only
• caller's name only
• caller's name and number
Note:
For the TAD’s Caller ID memory dial
feature to operate, you must receive the caller's number.
READ THIS BEFORE
INSTALLATION
We have designed your TAD to conform to
federal regulations and you can connect it to
most phone lines. However, each device that
you connect to the TAD line draws power
from the line. We refer to this power draw as
the TAD's ringer equivalence number, or
REN. The REN is shown on the bottom of
your TAD.
If you use more than one telephone or other
device on the line, add up all the RENs. If the
total is more than five (three in rural areas),
your TAD might not ring. If ringer operation is
impaired, remove one of the devices from
the line.
FCC STATEMENT
Your TAD complies with Part 68 of
Rules
. Upon request, you must provide the
phone's FCC registration number and REN
FCC
to your telephone company. These numbers
are on the bottom of the base.
Note:
You must not connect your TAD to:
• coin-operated systems
• party-line systems
• most electronic key phone systems
THE FCC WANTS YOU TO
KNOW
In the unlikely event that your TAD causes
problems on the phone line, the phone company can temporarily discontinue your service. If this happens, the phone company
attempts to notify you in advance. If advance
notice is not practical, the phone company
notifies you as soon as possible and advises
you of your right to file a complaint with the
FCC.
Also, the phone company can make changes
to its lines, equipment, operations, or procedures that could affect the operation of this
telephone. The telephone company notifies
you of these changes in advance, so you can
take the necessary steps to prevent interruption of your telephone service.
LIGHTNING
Your TAD has built-in protection circuits to
reduce the risk of damage from surges in
telephone line and power line current. These
protection circuits meet or exceed the FCC
requirements. However, lightning striking the
telephone or power lines can damage your
TAD.
Lightning damage is not common. Nevertheless, if you live in an area that has severe
electrical storms, we suggest that you unplug
your TAD when storms approach to reduce
the possibility of damage.
4
43-705.fm Page 5 Tuesday, May 23, 2000 8:54 AM
ˆ
Features
Your RadioShack 12-Memory Speakerphone
combines a speakerphone, a high-quality fully-digital answering system and a Caller ID
unit in one system. The TAD (Telephone Answering Device) prevents you from missing
incoming calls and messages. Fully digital
means the TAD stores all messages on a
computer chip — there are no tape mechanism to wear out and no tapes to bother with.
This gives you capabilities that tape-based
answering machine do not have. For example, you can listen quickly from message to
message without listening to all of them.
The TAD also shows the caller's telephone
number (and name, if available in your area)
and the current date and time, as provided
by your local phone company to Caller ID
service subscribers. It saves up to 62 Caller
ID records that you can review and call back.
TELEPHONE FEATURES
12-Number Memory Dialing
store up to 12 numbers in memory for easy
dialing.
Speakerphone
phone conversation.
Headset Jack
al headset (available from your local RadioShack store) for hands-free convenience.
Flash
— sends an electronic switchhook signal for use with special phone services such
as Call Waiting.
Privacy
phone from hearing your conversation with
someone in the room.
Hold
— lets you put a call on hold.
— allows hands-free tele-
— lets you connect an option-
— prevents the person on the
— lets you
Pause
— lets you enter a pause for systems
that require an access code (9, for example)
before you dial an outside number.
Redial
— lets you quickly redial the last
number dialed.
Volume Control
ume of the sound you hear through the handset, speakerphone, or headset.
Adjustable Ringer Volume
the ringer to low or high, or even turn it off.
Tone/Pulse Dialing
type of service, and you can easily switch
from pulse to tone dialing for long-distance,
bank-by-phone, or other special services.
Hearing-Aid Compatible
telephone with hearing aids that have a T
(telephone) switch.
— lets you control the vol-
— lets you set
— lets you use either
— lets you use the
TAD FEATURES
Dual Outgoing Messages
record two outgoing messages of up to about
32 seconds each: one for when you want
callers to leave a message, the other for
when you want to play an announcement
without recording callers' messages.
Voice Date/Time Stamp
and time each message was recorded.
Two-Way Recording
sides of your phone conversation.
Memo Recording
sage for yourself or others in your home or
office.
Adjustable Ring Numbe
TAD to answer after two, four, or seven
rings.
— lets you record both
— lets you leave mes-
— lets you
— records the day
r — lets you set the
Features
5
43-705.fm Page 6 Tuesday, May 23, 2000 8:54 AM
Toll-Saver
charges when you call by long-distance to
check your messages.
Remote Operation
tone phone (or rotary phone and pocket ton e
dialer) to operate the TAD and Caller ID
while you are away from your home or office.
Phone Pick-Up Detection
ing when you pick up any phone on the same
line as the TAD.
Call Breakthrough (CBT) with Programmable Code
call when the caller enters a preset code during the outgoing message.
Call Screen
leaves a message so you can decide whether or not to answer the call.
Programmable Remote Operation Security Code
code for remote operation.
Remote Answer-On
TAD from a remote location even when it is
not set to answer calls.
— lets you avoid unnecessary toll
— lets you use a touch-
— stops record-
— alerts you to an important
— lets you listen when a caller
— lets you set your own security
— lets you turn on the
VIP Call List
ID records in a VIP list. Then, when any of
those callers call, the TAD sounds a distinctive tone.
Call Summary
calls you received.
New Call Indicator
glance that you have new calls.
Review Scrolling
through all records in Caller ID memory.
Dialing Option
dialing number from the Caller ID record to
match the different telephone systems.
DIAL
— lets you dial the phone number in a
Caller ID record with the touch of a button.
Message Waiting
have received a voice mail message (i f you
subscribe to a message waiting service from
your local telephone company).
Contrast Control
play contrast for the best readability.
— lets you save up to 10 caller
— displays the number of
— lets you see at a
— lets you easily scroll
— lets you select the usable
— lets you know that you
— lets you adjust the dis-
Room Monitor
mote phone to the room where the TAD is installed.
Memory Backup
stored in memory in case of a power failure.
— lets you listen from a re-
— protects messages
CALLER ID FEATURES
3-Line Display
Caller ID record on one screen.
Caller ID Memory
ID records with name and number or name
only, depending on the information your
phone company provides.
6
— lets you view an entire
— stores up to 62 Caller
Features
!
43-705.fm Page 7 Tuesday, May 23, 2000 8:54 AM
ˆ
Preparation
INSTALLING A BACKUP
BATTERY
You can install an optional 9V backup battery
so if the AC power fails or you unplug the
TAD, the TAD will save the messages, time
and day settings, CBT and remote operation
security codes, and Caller ID records. For
the best performance and longest life, we
recommend you use a RadioShack alkaline
battery.
Cautions:
quired size and recommended type.
1. Use a Phillips screwdriver to remove the
Use only a fresh battery of the re-
two screws on the battery compartment
cover, then remove the cover.
LIFT
Warning:
and properly. Do not burn or bury them.
Caution:
for a month or longer, remove the battery. A
battery can leak chemicals that can destroy
electronic parts.
Dispose of old batteries promptly
If you do not plan to use the TAD
MOUNTING THE TAD
You can place the TAD on a desk or table,
mount it on a standard wall plate, or mount it
directly on a wall. Select a location that is
near both an AC outlet and a modular phone
line jack.
Notes:
• Your TAD connects directly to a modular
telephone line jack. If your phone line
jack is not a modular jack, you can
update the wiring yourself, using jacks
and adapters available at your local
RadioShack store. Or, you can let the
phone company update the wiring for
you.
2. Snap the battery's contacts firmly onto
the battery connector and place the battery in the compartment.
3. Replace the cover and secure it with the
two screws.
Replace the battery when appears.
Cautions:
Preparation
• The USOC number of the jack to be
installed is RJ11C.
You must use a Class 2 power
source that supplies 9V AC
and delivers at least 400 mA.
Its plug must fit the TAD's
jack. The supplied adapter meets these
specifications. Using an adapter that
does not meet these specifications
could damage the TAD or the adapter.
AC 9V 400mA
7
43-705.fm Page 8 Tuesday, May 23, 2000 8:54 AM
• Always connect the AC adapter to the
TAD before you connect it to AC power.
When you finish, disconnect the adapter
from AC power before you disconnect it
from the TAD.
On a Desk
1. Plug one end of the supplied long modular cord into the
TEL. LINE
jack on the
back of the TAD, then plug the cord's
other end into a modular phone line
jack.
2. Plug the supplied AC adapter's barrel
plug into the
AC 9V 400mA
jack on the
back of the T AD, then plug the other end
of the adapter into a standard AC outlet.
When you first connect power, the TAD
beeps once,
MEMORY TEST
appears, and
the message counter counts up from 0 to
22
. Then the TAD beeps. 0
SAGE
appears. OGM1 and OGM2 flash to
CALL 0 MES-
indicate that no outgoing messages are recorded.
On a Wall or Wall Plate
Note:
To mount the TAD directly on a wall,
you need two screws (not supplied) with
heads that fit the keyhole slots on the mounting bracket. Drill two holes 3
mm) apart. Then thread a screw into each
hole, letting the heads extend about 3/16 inch
(5 mm) from the wall.
15
/16 inches (100
1. Plug the supplied short modular line
cord into the
TEL.LINE
jack on the back
of the TAD.
2. Insert the supplied AC adapter's barrel
plug into the
AC 9V 400 mA
jack on the
back of the base.
To moun t the TAD on a wall plate
3.
, route
the adapter cord hanging down and the
other end of the short modular cord
through the center of the bracket. Insert
the tabs on the narrow end of the
bracket into the slots on the bottom of
the base, then push the tab on the wide
end of the bracket into the lower slots on
the bottom of the base.
Plug the short modular cord's other end
into the wall plate jack, align the base's
keyhole slots with the wall plate studs,
and slide the base downward to secure
it.
T o mount the TAD directly on a wall
, with
the power cord and the long modular
cords hanging down, insert the tabs on
the narrow end of the bracket into the
slots on the bottom of the base then
push the tab on the wide end of the
bracket into the lower slot on the bottom
of the base.
Align the TAD's keyhole slots with
screws and slide the TAD down to
secure it, then plug the modular cord
into a modular phone line jack.
4. Slide the handset clip out of its retaining
slot, rotate it 180° then slide it back into
its slot.
5. Plug one end of the supplied coiled
handset cord into the jack on the left
side of the base. Plug the other end into
the handset's jack. Then place the handset on the base.
8
Preparation
43-705.fm Page 9 Tuesday, May 23, 2000 8:54 AM
6. Plug the adapter into a standard AC outlet.
SETTING THE DIALING
MODE
T/P
Set
(Tone/Pulse) for the type of service
you have. If you are not sure which type you
have, do this simple test.
T/P
1. Be sure
2. Lift the handset and listen for a dial tone.
3. Press any number except 0.
Note:
you dial an access code (9, for example)
before you dial an outside number, do
not press the access code either.
If the dial tone stops, you have touchtone service. If the dial tone continues,
you have pulse service.
4. If you have pulse service, set
Otherwise, leave it set to T.
is set to T.
If your phone system requires that
T/P
to P.
SETTING THE RINGER
RINGER OFF.LO.HI
volume. To adjust the ringer volume, set
RINGER OFF.LO.HI
controls the TAD’s ringer
to HI or LO.
SETTING THE DISPLAY
CONTRAST
1. Hold down
once. 3 and
flashes.
2. Repeatedly press
desired display contrast settings.
Note:
contrast settings.
3. Press
press
STOP
until the TAD beeps
LCD CONTRAST
::::/8888
The TAD has ten (0–9) display
DIAL
to confirm the setting, then
STOP
to return to the time display.
appear.
to select the
SETTING THE LONG
DISTANCE CODE
The Long Distance Code has a default setting of 1. You can change the code to “9” if
you use a PBX telephone system or “0” if
your telephone system requires operator assistance to make a long distance call.
Note:
If you do not complete each step within 8 seconds, the TAD exits setup. Start
again at Step 1.
STOP
1. Hold down
once.
2. Press
DIAL
appear. 1 flashes.
until the TAD beeps
once. 1 and
SET LDS CODE
3
If you do not want the ringer to sound, set
RINGER OFF.LO.HI
calls with the ringer off, and you can answer
calls if you hear another phone on the same
phone line ring or if
display.
OFF
to
. You can still make
RING
appears on the
Preparation
::::/8888
3. Repeatedly press
distance code to 1, 9, or 0.
4. Press
DIAL
then press
the time display.
to set the long
STOP
to return to
SETTING THE AREA CODE
Note:
If you do not complete each step within 8 seconds, the TAD exits setup. Start
again at Step 1.
STOP
1. Hold down
once.
until the TAD beeps
9
