43-1130.fm Page 1 Tuesday, May 30, 2000 1:22 PM
TAD 1130
2.4 GHz Digital Spread Spectrum
Cordless Speakerphone
with Digital Answering System
Owner’s Manual
Please read before using this equipment.
43-1130.fm Page 2 Tuesday, May 30, 2000 1:22 PM
ˆ
Contents
Features .................................................................................................................................. 6
Installation .............................................................................................................................. 8
Mounting the Phone .......................................................................................................... 8
On a Desk Top ........................................................................................................... 8
On a Wall Plate or Wall .............................................................................................. 9
Connecting, Charging, and Replacing the Battery Pack ................................................. 10
A Quick Look at the Handset .......................................................................................... 12
Setting the Dialing Mode ................................................................................................. 12
Turning the Base’s Ringer On and Off ............................................................................ 13
Setting the Ringer Tone/Volume ...................................................................................... 13
Setting the Number of Rings ........................................................................................... 13
Setting the Day/Time ....................................................................................................... 13
Telephone Operation .................................... ... .. ................................................................... 14
Making and Receiving Calls with the Handset ................................................................ 14
Adjusting the Handset Volume ........................................................................................ 14
Selecting the Channel ..................................................................................................... 14
Answering Calls with the Speakerphone ......................................................................... 14
Switching Between the Handset and Speakerphone ...................................................... 14
Using Both the Handset and Speakerphone ................................................................... 14
Using Flash ..................................................................................................................... 15
Using Redial .................................................................................................................... 15
Using Mute ................................ ...................................................................... ................ 15
Using Tone Services on a Pulse Line .............................................................................. 15
Paging ............................................................................................................................. 15
Memory Dialing ........................................................ .. ... ..................................... ............. 15
Storing a Number in Memory ................................................................................... 15
Entering a Pause ..................................................................................................... 16
Dialing a Memory Number ....................................................................................... 16
Chain-Dialing Service Numbers ............................................................................... 16
Testing Stored Emergency Numbers ....................................................................... 16
Using a Headset ................................... .................................... ..................................... .. 16
TAD Operation ...................................................... .................................. ... ........................... 17
Selecting the Outgoing Message .................................................................................... 17
Recording/Deleting an Outgoing Message ..................................................................... 17
Setting the Record Time ................................................................................................. 17
Setting the TAD to Answer Calls ..................................................................................... 18
Screening Calls ............................................................................................................... 18
Recording Incoming Messages ....................................................................................... 18
Recording a Memo .......................................................................................................... 18
Recording a Conversation ............................................................................................... 18
Playing Messages ........................................................................................................... 19
©
2000 RadioShack Corporation.
RadioShack and RadioShack.com are trademarks used by RadioShack Corporation.
2
All Rights Reserved.
43-1130.fm Page 3 Tuesday, May 30, 2000 1:22 PM
Adjusting the TAD’S Volume ........................................................................................... 19
Deleting Messages ......................................................................................................... 19
Setting the Remote Operation Pin .................................................................................. 19
Remote Operation .......................................................................................................... 20
Using the Toll-Saver ............................................................. ... ... .................................... 20
Using Remote Commands ........................................... .................................... ... ........... 20
Remote Commands ................................................................................................ 21
Troubleshooting ................................................................................................................... 22
Care ................................................................................................................................ 23
WARNING:
shock hazard, do not expose this product to rain
or moisture.
To reduce the risk of fire or
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION:
ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED PERSONNEL.
!
TO REDUCE THE RISK OF
This symbol is intended to alert
you to the presence of uninsulated dangerous voltage within
the product’s enclosure that might
be of sufficient magnitude to constitute a risk of electric shock. Do
not open the product’s case.
This symbol is intended to inform
you that important operating and
maintenance instructions are
included in the literature accompanying this product.
!
This phone has been tested and found to
comply with all applicable UL and FCC standards.
IMPORTANT SAFETY
INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock
and injury to persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions
marked on the product.
3. Never install telephone wiring during a
lightning storm.
4. Never install telephone jacks in wet
locations unless the jack is specifically
designed for wet locations.
5. Never touch uninsulated telephone
wires or terminals unless the telephone
line has been disconnected at the network interface.
6. Use caution when installing or modifying
telephone lines.
7. Do not affix the AC power supply cord to
building surfaces with metal fittings (if
the product has an AC power cord).
8. Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
3
43-1130.fm Page 4 Tuesday, May 30, 2000 1:22 PM
9. Do not use this product near water, for
example, near a bath tub, wash bowl,
kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
10. Do not place this product on an unstable
cart, stand, or table. The product may
fall, causing serious damage to the
product.
11. Slots and openings in the telephone’s
cabinet and the back or bottom are provided for ventilation. To protect the telephone from overheating, these openings
must not be blocked or covered. The
openings should never be blocked by
placing the product on a bed, sofa, rug,
or other similar surface. This product
should never be placed near or over a
radiator or heat register. This product
should not be placed in a built-in installation unless proper ventilation is provided.
12. This product should be operated only
from the type of power source indicated
on the marking label. If you are not sure
of the type of power supply to your
home, consult your local power company.
13. Do not allow anything to rest on the
power cord. Do not locate this product
where the cord will be stepped on.
14. Do not overload wall outlets and extension cords as this can result in a risk of
fire or electric shock.
15. Never push objects of any kind into this
product through cabinet slots as they
may touch dangerous voltage points or
short out parts that could result in a risk
of fire or electric shock. Never spill liquid
of any kind on the product.
repair work is required. Opening or
removing covers may expose you to
dangerous voltages or other risks. Incorrect reassembly can cause electric
shock when the product is subsequently
used.
17. Unplug this product from the wall outlet
and refer servicing to qualified services
personnel under the following conditions:
• When the power cord plug is damaged
or frayed.
• If liquid has been spilled into the product.
• If the product has been exposed to rain
or water.
• If the product does not operate normally
by following the operating instructions.
Adjust only those controls that are covered by the operating instructions
because improper adjustments of other
controls may result in damage and will
often require extensive work by a qualified technician to restore the product to
normal operation.
• If the product has been dropped or the
cabinet has been damaged.
• If the product exhibits a distinct change
in performance.
18. Avoid using a telephone (other than a
cordless type) during an electrical storm.
There may be a remote risk of electric
shock from lightning.
19. Do not use the telephone to report a gas
leak while in the vicinity of the leak.
16. To reduce the risk of electric shock, do
not disassemble this product. Take it to
a qualified serviceman when service or
4
43-1130.fm Page 5 Tuesday, May 30, 2000 1:22 PM
BATTERY SAFETY
INSTRUCTIONS
CAUTION:
FIRE OR INJURY, READ AND FOLLOW
THESE INSTRUCTIONS.
1. Use only the appropriate type and size
2. Do not dispose of the battery pack in a
3. Do not open or mutilate the battery
4. Exercise care in handing the battery
5. Charge the battery pack provided with or
6. Observe proper polarity orientation
TO REDUCE THE RISK OF
battery pack specified in the instruction
manual provided for this product.
fire. The cell may explode. Check with
local codes for possible special disposal
instructions.
pack. Released electrolyte is corrosive
and may cause damage to the eyes or
skin. It may be toxic if swallowed.
pack in order not to short it with conducting materials such as rings, bracelets
and keys. The battery or conductor may
overheat and cause burns.
identified for use with this product only in
accordance with the instructions and
limitations specified in the instruction
manual provided for this product.
between the battery pack and battery
charger.
SAVE THESE
INSTRUCTIONS
draw as the phone’s ringer equivalence number, or REN. The REN is on the bottom of
your phone.
If you use more than one phone or other device on the line, add up all the RENs. If the
total is more than five (three in rural areas),
your phones might not ring. If ringer operation is impaired, remove one of the devices
from the line.
Important:
• Cordless phones such as this one
require AC power to operate. When the
AC power is off, you cannot dial out or
receive incoming calls using your
phone. To be safe, you should also have
a phone that does not need AC power to
operate (not a cordless phone) so you
can still make and receive calls if there
is an AC power failure.
• When AC power is lost, the phone loses
the security access-protection code connection between the base and the handset. When power is restored, put the
handset on the base briefly to restore
this connection.
FCC STATEMENT
Your telephone complies with Part 68 of
Rules
. Upon request, you must provide the
phone’s FCC registration number and REN
to your telephone company. These numbers
are on the bottom of the base.
Note:
You must not connect your telephone
to:
FCC
READ THIS BEFORE
INSTALLATION
We have designed your phone to conform to
federal regulations and you can connect it to
most phone lines. However, each device that
you connect to the telephone line draws
power from the line. We refer to this power
• coin-operated systems
• party-line systems
• most electronic key phone systems
5
43-1130.fm Page 6 Tuesday, May 30, 2000 1:22 PM
THE FCC WANTS YOU TO
KNOW
In the unlikely event that your phone causes
problems on the phone line, the phone company can temporarily discontinue your service. If this happens, the phone company
attempts to notify you in advance. If advance
notice is not practical, the phone company
notifies you as soon as possible and advises
you of your right to file a complaint with the
FCC.
Also, the phone company can make changes
to its lines, equipment, operations, or procedures that could affect the operation of this
telephone. The telephone company notifies
you of these changes in advance, so you can
take the necessary steps to prevent interruption of your telephone service.
Your phone might cause TV or radio interference even when it is operating properly. To
determine whether your phone is causing the
interference, turn off your phone. If the interference goes away, your phone is causing it.
Try to eliminate the interference by:
• moving your phone away from the
receiver
• connecting your phone to an AC outlet
that is on a different electrical circuit
from the receiver contacting your local
RadioShack store for help
If you cannot eliminate the interference, the
FCC requires that you stop using your
phone.
Some cordless telephones operate on frequencies that might cause interference to
nearby TVs and VCRs. To minimize
or prevent such interference, the base of the
cordless telephone should not be placed
near or on top of a TV or VCR.
LIGHTNING
Your telephone has built-in protection circuits
to reduce the risk of damage from surges in
telephone line and power line current. These
protection circuits meet or exceed the FCC
requirements. However, lightning striking the
telephone or power lines can damage your
telephone.
Lightning damage is not common. Nevertheless, if you live in an area that has severe
electrical storms, we suggest that you unplug
your phone when storms approach to reduce
the possibility of damage.
ˆ
Features
Your RadioShack 2.4 GHz Cordless Speakerphone combines a 2.4 GHz digital cordless
telephone unit and a digital TAD (Telephone
Answering Device). The 2.4 GHz band
means less interference, clearer sound, and
greater range than other types of cordless
telephones.
The TAD stores up to 18 minutes of messages on a computer chip and records each
message’s day and time. This gives you advanced capabilities over tape-based answering machines:
6
• You can delete indi vidual messages an d
save the rest.
• There are no tapes to bother with and no
tape mechanisms to wear out.
The remote operation feature lets you operate your TAD from a touch-tone phone (or
from a rotary phone with an optional pocket
tone dialer).
Features
43-1130.fm Page 7 Tuesday, May 30, 2000 1:22 PM
TELEPHONE FEATURES
10 Number Memory Dialing
store 10 numbers in memory for easy dialing.
Page
— lets you send a paging signal from
the base to the handset to page someone or
locate the handset if you misplace it.
30 Channels
channel when you make or answer a call.
You can also manually change channels during a call.
Security Access-Protection Code
prevent other cordless phone users from using your phone line.
Ringer Volume Control
from four ringer tone/volume settings on the
handset.
Volume Controls
ume you hear through the handset.
Long Battery Life
pack (when fully charged) provides about 6
hours of talk time or 7 days of standby time.
Tone/Pulse Dialing
type of service, and you can easily switch
from pulse to tone dialing for long-distance,
bank-by-phone, or other special services.
— automatically selects a clear
— let you adjust the vol-
— the supplied battery
— lets you use either
— lets you
— helps
— lets you select
ANSWERING SYSTEM
FEATURES
Day/Time Stamp
time each message was recorded.
Two Prerecorded Messages
the option of using one of two prerecorded
outgoing messages or recording your own.
Announcement Only
nouncement for callers to hear, without recording their messages.
Message Counter
messages the TAD has recorded.
Programmable PIN
digit personal identification number (PIN) for
secure remote operation.
Call Screening
leaves a message so you can decide whether or not to answer the call.
Memo Recording
es for yourself or others in your home or office. You can also record your phone
conversation.
Room Monitor
mote phone to the room where the TAD is installed.
— records the day and
— gives you
— lets you play an an-
— shows the number of
— you can set a two-
— lets you listen as a caller
— lets you leave messag-
— lets you listen from a re-
Auto Talk
by lifting the handset from the base.
Any Key Answer
to answer a call when the handset is away
from the base.
Hearing-Aid Compatibility
your phone with hearing aids that have a T
(telephone) switch.
— lets you answer a call simply
— lets you press any key
— lets you use
Phone Pick-Up Detection
ing when you pick up any phone on the same
line as the TAD, and resets to answer the
next call.
Adjustable Ring Number
TAD to answer after three or five rings.
Toll-Saver
charges when you call by long distance to
check your messages.
Digital Volume Control
adjust the speakerphone and message playback volume.
Features
— lets you avoid unnecessary
— stops record-
— lets you set the
— lets you precisely
7
43-1130.fm Page 8 Tuesday, May 30, 2000 1:22 PM
ˆ
Installation
MOUNTING THE PHONE
You can place the TAD’s base on a desk or
table, or mount it on a standard wall plate or
directly on a wall.
Choose a location that is:
• near an AC outlet
• near a modular telephone line jack
• out of the way of normal activities
• away from electrical machinery, electri-
cal appliances, metal walls or filing cabinets, wireless intercoms, alarms, and
room monitors
• away from other cordless phones
The base’s location affects the phone’s
range. If you have a choice of several locations, try each to see which provides the best
performance.
Cautions:
You must use a Class 2 power
source that supplies 9V DC
!
and delivers at least 350 mA.
Its center tip must be set to positive and
its plug must fit the telephone's
jack. The supplied adapter meets these
specifications. Using an adapter that
does not meet these specifications
could damage the telephone or the
adapter.
• Always connect the AC adapter to the
phone before you connect it to AC
power. If you disconnect the power, disconnect the adapter from AC power
before you disconnect it from the phone.
DC IN 9V
Notes:
• Your telephone connects directly to a
modular telephone line jack. If your
phone line jack is not a modular jack,
you can update the wiring yourself,
using jacks and adapters available at
your local RadioShack store. Or, you
can let the phone company update the
wiring for you.
• The USOC number of the jack to be
installed is RJ11C (RJ11W for a wall
plate).
On a Desk Top
1. Insert the bracket’s tabs into the base’s
upper tab slots, then press down on the
bracket’s clips and insert them into the
clip slots.
2. Plug one end of the supplied long modular cord into the
back of the base.
3. Plug the modular cord’s other end into a
modular telephone line jack.
4. Insert the supplied AC adapter’s barrel
plug into the
the base.
5. Route the adapter’s cord through the
strain relief slot on the bracket.
6. Plug the adapter into a standard AC outlet.
TEL LINE
DC IN 9V
jack on the
jack on the back of
8
Installation
43-1130.fm Page 9 Tuesday, May 30, 2000 1:22 PM
7. Lift the base’s antenna to a vertical position.
On a Wall Plate or Wall
1. Insert the bracket’s tabs into the base’s
lower tab slots, then press down on the
bracket’s clips and insert them into the
clip slots.
2. Plug one end of the supplied short modular cord into the
TEL LINE
back of the base.
3. Insert the supplied AC adapter’s barrel
plug into the
DC IN 9V
the base.
4. Route the adapter and modular cords
through the grooves on the bracket.
jack on the
jack on the back of
7. Press and lift out the handset holder, flip
it over, then snap it back into place so it
holds the handset.
8. Lift the base’s antenna to a vertical position.
Note:
To mount the TAD directly on a wall,
you need two screws (not supplied) with
heads that fit into the keyhole slots on the
bottom of the base.
Follow the steps under “On a Wall Plate or
Wall,” then apply these additional instructions for placement on a wall.
15
16
1. Drill two holes 3
/
5
/16"
inches (100 mm) apart.
Then thread a screw into
each hole, letting the
heads extend about
5
315/16"
16
/
inch (8 mm) from the wall.
5. Plug the modular cord’s other end into
the wall plate jack, then align the
bracket’s keyhole slots with the wall
plate studs and slide the base downward to secure it.
6. Plug the adapter into a standard AC outlet.
Installation
2. Plug one end of the supplied long modular cord
into the
TEL LINE
jack at the back of the
base.
3. Align the bracket’s keyhole slots with the
mounting screws and slide the base
downward to secure it.
9
43-1130.fm Page 10 Tuesday, May 30, 2000 1:22 PM
CONNECTING, CHARGING,
AND REPLACING THE
BATTERY PACK
The TAD comes with a rechargeable nickelcadmium battery pack installed in the handset, but not connected. Before using your
phone, you must connect the battery pack,
then charge it for about 24 hours.
1. Press down and slide off the battery
pack compartment cover.
2. Lift the battery pack out of the compartment. Plug the battery pack’s connector
into the socket in the compartment. The
connector fits only one way.
Notes:
• When you first use the phone after
charging or recharging the battery pack,
the phone might not work and you might
hear a five-beep error signal. If this happens, return the handset to the base for
about 5 seconds to reset the security
access-protection code.
• Using a pencil eraser, clean the charging contacts on the handset and the
base about once a month.
• If the phone does not work, recharge the
battery pack. (The battery power might
be too low to flash the TALK/LOW BATT
indicator.)
• If the battery pack becomes weak during
a call, the handset beeps every 3 seconds. When this happens, you cannot
make a call on the phone until you
recharge the battery pack.
• About once a month, fully discharge the
battery pack by keeping the handset off
the base until the TALK/BATT LOW indicator flashes. Otherwise, the battery
pack loses its ability to fully recharge.
3. Put the battery pack in the compartment.
4. Replace the cover.
To charge the battery pack, simply place the
handset on the base, facing either up or
down. The CHARGE/IN USE indicator on the
base lights.
Recharge the battery pack when the TALK/
LOW BATT indicator flashes.
Important:
erly connected before you try to charge it. If
the CHARGE/IN USE indicator flashes slowly when the handset is on the base, the battery pack is not connected properly.
10
Be sure the battery pack is prop-
Installation
• If the battery pack is completely discharged or the base loses power while
the handset is away from it, place the
handset on the base to reset the security access-protection code. If it was the
handset that lost power, recharge the
battery pack.
The supplied battery pack should last about
a year. If the battery pack does not hold a
charge for more than 2 hours after an overnight charge, replace it with a new 3.6-volt,
600 mAh battery pack with a connector that
fits the socket in the battery compartment.
You can order a replacement battery pack
through your local RadioShack store. Install
the new battery pack and charge it for about
24 hours.
43-1130.fm Page 11 Tuesday, May 30, 2000 1:22 PM
Warning:
Dispose of the old battery pack
promptly and properly. Do not burn or bury it
(see “Battery Safety Instructions” on Page 5
for additional information on proper battery
handling).
If you have trouble replacing the battery
pack, take the phone to your local RadioShack for assistance.
Important:
RBRC
The EPA certified
®
Battery Recycling Seal
on the nickel-cadmium (Ni-Cd)
battery indicates RadioShack
is voluntarily participating in an
industry program to collect and recycle these
batteries at the end of their useful life, when
taken out of service in the United States or
Canada. The RBRC program provides a convenient alternative to placing used Ni-Cd batteries into the trash or the municipal waste
stream, which may be illegal in your area.
Please call 1-800-THE-SHACK (1-800-843-
7422) for information on Ni-Cd battery recycling and disposal bans/restrictions in your
area. RadioShack’s involvement in this program is part of the company’s commitment to
preserving our environment and conserving
our natural resources.
Installation
11
43-1130.fm Page 12 Tuesday, May 30, 2000 1:22 PM
A QUICK LOOK AT THE HANDSET
Note:
The handset window has plastic film on it to protect it during shipment. Carefully peel off
the film before using your phone for the first time.
Use MEMORY to store and dial
names and numbers in memory
(see “Memory Dialing” on
Page 15).
Use TALK to make a
call (see “Making
and Receiving Calls
with the Handset”
on Page 14).
Use REDIAL to redial
the last number dialed
(see “Using Redial” on
Page 15).
Use PAUSE to store a pause
in a number (see “Entering a
Pause” on Page 16).
Use VOL
the handset volume (see
“Adjusting the Handset
Volume” on Page 14).
Press TONE to use your phone
company’s special tone services
when you are on a pulse line (see
“Using Tone Services on a Pulse
Line” on Page 15).
to adjust
8888/9999
Use MUTE talk to some in the
room without the person on the
other end of the phone line
hearing your conversation (see
“Using Mute” on Page 15
Use FLASH to select the
phone’s flash function
(see “Using Flash” on
Page 15).
Use CHANNEL to select the
phone’s channels (see “Selecting the Channel” on
Page 14) and other options.
SETTING THE DIALING
MODE
PULSE-TONE
Set
the type of service you have. If you are not
sure which type you have, after you charge
the handset battery pack, do this simple test.
PULSE-TONE
1. Set
2. Lift the handset, press
for a dial tone.
3. Press any number other than 0.
12
on the back of the base for
TONE
to
.
TALK
and listen
Installation
Note:
If your phone system requires that
you dial an access code (9, for example)
before you dial an outside number, do
not press the access code number
either.
If the dial tone stops
tone service. Leave
TONE
.
If the dial tone continues
pulse service. Set
PULSE
.
, you have touch-
PULSE-TONE
set to
, you have
PULSE-TONE
to
43-1130.fm Page 13 Tuesday, May 30, 2000 1:22 PM
4. Press
TALK
or place the handset on the
base to hang up.
TURNING THE BASE’S
RINGER ON AND OFF
To turn off the base’s ringer, set
the back of the base to
make or receive calls using this phone. Telephones on the same line (and the TAD’s
handset if it is away from the base) still ring
when there is an incoming call.
To turn on the base’s ringer, set
ON
.
OFF
RINGER
. You can still
RINGER
on
to
SETTING THE RINGER
TONE/VOLUME
You can select one of four different ringer
tone/volume settings while the phone is not
VOL
8888
9999
or
VOL
to in-
8888
or
in the talk mode. Press
crease or decrease the ringer level setting.
Note:
The setting is not cyclic. If the ringer
does not change when you press
9999
, try pressing the opposite arrow key.
SETTING THE NUMBER OF
RINGS
RING TIME
Set
T/S
(Toll-Saver) to select how long the
or
TAD waits to answer a call (3 rings, 5 rings,
or toll-saver).
Note:
If you plan to check messages by long
distance, set
the Toll-Saver” on Page 20).
on the side of the base to 3, 5,
RING TIME
to
T/S
(see “Using
SETTING THE DAY/TIME
You must set the day of the week and time
so the TAD can record the correct day and
time of each message.
Note:
Enter each key press within about 2
minutes. Otherwise, the TAD exits the time
setting process and you must begin again
with Step 1.
CLOCK
1. Hold down
The TAD announces the currently set
day and displays the day’s number (
for Sunday, 1 for Monday, and so on).
2. To change the day of the week, repeatedly press
REPEAT
correct day, press
3. The TAD announces the hour. To
change the hour, repeatedly press
or
plays, then press
4. The TAD announces the minutes. To
change the minutes, repeatedly press
SKIP
display, then press
5. The TAD announces “AM” or “PM,” and
A
to change this setting. Press
again to set “AM” or “PM.” The TAD
beeps and announces the day and time.
To check the day and time, press
The TAD announces the currently set day
and time.
Note:
current time. When the power is restored, the
clock starts counting again from the time the
power failed. You must reset the time.
to move backward to set the
REPEAT
REPEAT
or
or P appears. Press
When power fails, the clock retains the
until the TAD beeps.
SKIP
to move forward or
CLOCK
.
SKIP
until the correct hour dis-
CLOCK
.
until the correct minutes
CLOCK
.
SKIP
or
REPEAT
CLOCK
CLOCK
0
.
Installation
13
43-1130.fm Page 14 Tuesday, May 30, 2000 1:22 PM
ˆ
Telephone Operation
MAKING AND RECEIVING
CALLS WITH THE HANDSET
To make a call, lift the handset and press
TA LK
. The TALK/LOW BATT indicator on the
handset and the CHARGE/IN USE indicator
on the base light. Dial the number.
To answer a call, lift the handset from the
base or, if the handset is away from base,
press any key to make or answer a call.
To end a call, place the handset on the base
TALK
or press
.
ADJUSTING THE HANDSET
VOLUME
To adjust the volume you hear through the
VOL
8888
9#
9#
handset during a call, press
increase or to decrease the volume.
Note:
If you press
volume is set to the maximum or lowest level, the setting does not change and you hear
three quick beeps.
VOL
8888
or
or
9999
while the
9#9#
SELECTING THE CHANNEL
The phone scans 30 channels (frequency
pairs used between the base and the handset) and automatically selects a clear channel each time you make or receive a call.
If you hear other conversations or excessive
noise during a call, press
a different channel.
Note:
If the handset is too far from the base,
the channel might not change. Move closer
to the base and try again.
CHANNEL
to select
ANSWERING CALLS WITH
THE SPEAKERPHONE
To answer a call using the speakerphone,
SPEAKER
press
lights.
To adjust the speakerphone’s volume, repeatedly press
base. The volume setting from
10
(highest) appears in the message
counter window.
To end a speakerphone call, press
again.
. The SPEAKER indicator
VOLUME
8888
or
SWITCHING BETWEEN THE
HANDSET AND
SPEAKERPHONE
to
To switch to the speakerphone while you are
using the handset, press
base. When you hear the conversation on
the speakerphone, press
set.
To switch to the handset while you are using
the speakerphone, lift the handset off the
base. If the handset is away from the base,
TA LK
press
, then press
SPEAKER
TALK
SPEAKER
USING BOTH THE HANDSET
AND SPEAKERPHONE
If someone else is using the speakerphone,
TALK
press
versation. If someone else is using the handset, press
conversation.
During the call, one person can hang up and
let the call continue at the other keypad. Or,
both people can hang up to end the call.
on the handset to join the con-
SPEAKER
on the base to join the
9999
on the
1
(lowest) to
SPEAKER
on the
on the hand-
.
14
Telephone Operation
43-1130.fm Page 15 Tuesday, May 30, 2000 1:22 PM
Note:
If you hear a high-pitched noise from
the base’s speaker, the handset and the
base are too close together. Move them
away from each other.
USING FLASH
FLASH
performs the electronic equivalent of
a switchhook operation for special services,
such as Call Waiting.
For example, if you have Call Waiting, press
FLASH
to answer an incoming call without
disconnecting the current call. Press
again to return to the first call.
Note:
If you do not have any special phone
FLASH
services, pressing
the current call.
might disconnect
FLASH
USING REDIAL
To quickly dial the last number dialed, lift the
TALK
handset, press
Notes:
• The redial memory holds up to 32 digits,
so you can redial long-distance as well
as local numbers.
• The redial memory also holds pause
entries (see “Entering a Pause” on
Page 16).
, then press
REDIAL
.
USING MUTE
To talk to someone in the room without the
person on the other end of the phone line
MUTE
hearing your conversation, press
TALK/LOW BATT indicator flashes.
MUTE
Press
conversation.
again to resume your phone
. The
USING TONE SERVICES ON
A PULSE LINE
Some special services, such as bank-byphone, require tone signals. If you have
pulse service, you can still use these special
tone services by following these steps.
1. Be sure
2. Dial the service’s main number.
3. When the service answers, press
on the handset. Any additional numbers
you dial are sent as tone signals.
When you hang up, the phone automatically
resets to pulse dialing.
PULSE-TONE
is set to
PULSE
TONE
.
PAGING
To page the person who has the handset or
to locate the handset when the phone is not
PAGE
in use, press
beeps for 5 seconds. For a longer handset
beep, hold down
onds. The handset beeps for 1 minute. To
stop it from beeping sooner, press any key
on the handset except
Note:
The phone rings if a call comes in dur-
ing paging. Press
SPEAKER
on the base to answer the call.
on the base. The handset
PAG E
for at least 5 sec-
TALK
.
TAL K
on the handset or
MEMORY DIALING
You can store up to 10 phone numbers in
memory, then dial a stored number by entering its memory location number. Each stored
number can be up to 20 digits.
Storing a Number in Memory
Notes:
• The phone beeps several times and
exits the storing process if you wait
more than 20 seconds between each
key press.
Telephone Operation
15
43-1130.fm Page 16 Tuesday, May 30, 2000 1:22 PM
• If you receive a call while entering a
number in memory, the TAD exits the
storing process.
1. Lift the handset.
2. Press
MEMORY
. The TALK/BATT LOW
indicator flashes.
3. Enter the phone number and any tone or
pause entries (see “Using T one Services
on a Pulse Line” on Page 15 and “Entering a Pause”).
4. Press
MEMORY
, then select a memory
location (0–9) by pressing the appropriate number on the handset. The handset sounds a tone indicating successful
storage.
For each stored number, write the contact’s
name next to the appropriate location number on the supplied memory directory sticker.
Peel the backing from the sticker and attach
it to the phone.
To replace a stored number, store a new one
in its place.
To delete a number without storing a new
one, press
MEMORY
twice. Then enter the
memory location number you want to clear
using the handset. The handset sounds a
tone indicating the number was cleared from
memory.
Entering a Pause
In some telephone systems, you must dial an
access code (9, for example) and wait for a
second dial tone before you can dial an outside number. You can store the access code
with the phone number. However, you
should also store a pause after the access
code to allow the outside line time to connect. To enter a 2-second pause, press
PAUSE
. You can add more pause entries for
a longer pause.
Dialing a Memory Number
To dial a number stored in memory, lift the
TALK
handset and press
RY
and the memory location number (0–9).
.Then press
MEMO-
Chain-Dialing Service Numbers
For quick recall of numbers for special services (such as bank by phone), store each
group of numbers in its own memory location.
Dial the service’s main number first. Then, at
the appropriate place in the call, press
ORY
and enter the number for the location
MEM-
where the additional information is stored.
Testing Stored Emergency Numbers
If you store an emergency service’s number
(police department, fire department, ambulance) and you choose to test the stored
number, make the test call during the late
evening or early morning hours to avoid peak
demand periods. Also, remain on the line to
explain the reason for your call.
USING A HEADSET
You can talk with hands-free convenience
using an optional headset that has a
inch (2.5-mm) plug. Your local RadioShack
store has a variety of suitable headsets.
To connect the headset, open the rubber
cover with marked
on the side of the handset, then insert the
headset’s plug into the
jack.
When you finish using the headset, disconnect it from the handset and close the rubber
cover to protect the jack.
3
/32 -
16
Telephone Operation
43-1130.fm Page 17 Tuesday, May 30, 2000 1:22 PM
Notes:
• Connecting a headset disconnects the
handset’s earpiece and microphone.
VOL
8888
•
also controls the connected headset’s
volume.
• If you place the handset on the base to
recharge it while the headset is connected, be sure the handset seats properly.
ˆ
or
TAD Operation
9999
or
MUTE
on the handset
SELECTING THE OUTGOING
MESSAGE
The TAD has two prerecorded outgoing messages. One asks the caller to leave a message: “Hello, no one is available to take your
call. Please leave a message after the tone.”
The TAD uses this message when
is set to 1 or 4 (see “Setting the Record
Time”).
The other recording is an announcement and
does not let the caller leave a message: “Hello, no one is available to take your call.” The
TAD uses this message when
ANN
set to
You can also record your own message (see
“Recording/Deleting an Outgoing Message”).
When you record your own outgoing message, the TAD uses it for all
tings.
To switch between your outgoing message
and the TAD’s prerecorded message, press
OGM
play, press
the other message and plays it.
(announcement only).
. When the current message begins to
OGM
again. The TAD switches to
REC TIME
REC TIME
REC TIME
is
set-
• With a headset connected, you can
make or answer calls as usual using the
keys on the handset. You can also
answer calls by pressing
located on the base.
• You can use a handset hol der (availabl e
from your local RadioShack store) to
hang the handset on your belt for
greater convenience.
SPEAKER
RECORDING/DELETING AN
OUTGOING MESSAGE
To record your outgoing message (up to 30
OGM
seconds long), hold down
beeps and -- appears. When you finish
your message, press
The TAD plays back your message.
To delete your outgoing message and use
the TAD’s prerecorded messages, hold
OGM
down
OGM
until the TAD beeps. Then press
again within two seconds.
until the TAD
PLAY/STOP
or
OGM
SETTING THE RECORD
TIME
REC TIME
Set
how the TAD will record incoming messages.
1
— The TAD plays the outgoing message and lets callers leave a message
up to 1 minute long.
4
— The TAD plays the outgoing message and lets callers leave a message
up to 4 minutes long.
to 1, 4, or
ANN
to determine
.
TAD Operation
17
43-1130.fm Page 18 Tuesday, May 30, 2000 1:22 PM
ANN
(announcement only) — The TAD
plays the outgoing message but does
not let callers leave a message.
SETTING THE TAD TO
ANSWER CALLS
To set the TAD to answer calls, press
SWER
on the base. If the TAD is set to record
a caller’s message (see “Setting the Record
Time” on Page 17), it plays the outgoing
message and shows the number of recorded
messages. If the TAD is set to announcement-only, it plays the outgoing message,
A
appears.
and
To set the TAD to not answer calls, press
ANSWER
and the message counter disappears.
. The TAD announces “Answer off”
AN-
SCREENING CALLS
You can let the TAD answer calls while you
listen to the caller’s message through the
base’s speaker. If you decide to answer the
call, press
speakerphone, press
handset is off the base, or lift the handset if it
is on the base. You can also pick up any
phone on the same line. The TAD stops recording and resets to answer the next call.
SPEAKER
to answer using the
TAL K
to answer if the
• The caller hangs up.
• The maximum message length is
reached.
• The TAD detects a busy signal or more
than 7 seconds of silence.
• You pick up the TAD’s handset or any
phone on the same phone line.
Note:
When the TAD’s message memory is
FL
appears on the display and the TAD
full,
announces “No remaining time” when you try
to operate it.
RECORDING A MEMO
A memo is a message you can record at the
TAD for yourself or others in your home or
office. The TAD stores memos as incoming
messages (see “Playing Messages” on
Page 19).
MEMO
––
appears in
on the
To record a memo, hold down
base until the TAD beeps and
the message counter window, then speak
your message. When you finish the memo,
PLAY/STOP
press
Note:
The TAD cannot record a memo less
than two seconds long.
or
MEMO
.
RECORDING INCOMING
MESSAGES
After the TAD answers a call, it plays the outgoing message, beeps, and records the caller’s message.
Each incoming message can be up to 1 or 4
minutes long, depending on how you set
REC TIME
Page 17). The TAD’s maximum recording
capacity is 18 minutes.
The TAD stops recording and resets to answer the next call when:
18
(see “Setting the Record Time” on
TAD Operation
RECORDING A
CONVERSATION
The TAD lets you record both sides of a telephone conversation when you are talking
with the handset.
Important:
tions governing the recording of conversations over the telephone. Be sure to check
your local, state and federal laws before using this product to record any telephone conversation in order to determine that your use
is in compliance with such laws or guidelines.
Every state has different regula-
43-1130.fm Page 19 Tuesday, May 30, 2000 1:22 PM
To start recording a phone conversation,
MEMO
hold down
beeps and –– appears. To stop recording,
PLAY/STOP
press
The TAD stores a recorded conversation as
a message (see “Playing Messages”).
Note:
The TAD does not record conversations less than two seconds long, or that use
the speakerphone.
on the base until the TAD
MEMO
or
.
PLAYING MESSAGES
After the TAD has recorded a message, the
total number of messages stored appears in
the message counter window. If you have
new messages, the message counter flashes.
To play your messages, press
The TAD announces the number of new and
old messages, then plays the new messages. The message number appears in the
message counter window as each message
plays, and the TAD announces the day and
time of the call at the end of each message.
To play all messages after playing the new
messages, press
To skip to the next message, press
ing playback.
To replay the current message from the beginning, press
within about 2 seconds after a message begins playing, the TAD replays the previous
message.
PLAY/STOP
REPEAT
. If you press
PLAY/STOP
again.
SKIP
REPEAT
dur-
ADJUSTING THE TAD’S
VOLUME
To adjust the speaker’s volume, repeatedly
VOLUME
press
volume setting from 1 (lowest) to 10 (highest) appears in the message counter window.
8888
9999
or
on the base. The
DELETING MESSAGES
To delete the current message while it is
playing, hold down
beeps.
To delete all messages at once, while messages are not playing, hold down
the base until the TAD beeps and 0 appears
in the message counter window.
Note:
You cannot delete new (unplayed)
messages. If you try to delete all messages
at once while you still have new messages,
the TAD beeps quickly five times and does
not delete any messages.
DELETE
until the TAD
SETTING THE REMOTE
OPERATION PIN
.
The TAD’s two-digit remote operation PIN
(personal identification number) prevents unauthorized remote access to your messages.
The PIN is preset to 80. Follow these steps
to change the PIN to any number from 00 to
99.
Note:
If you wait more than 2 minutes between each keypress, the TAD exits the PIN
setting process. Start again at Step 1.
PIN
1. Hold down
00
appears in the message counter win-
dow.
2. Press
3. Press
To check your PIN at any time, press
The PIN appears in the message counter
window, and the TAD announces it.
SKIP
higher or
PIN
press
SKIP
digit of the PIN, then press
announces the new PIN.
until the TAD beeps and
to set the first digit of the PIN
REPEAT
.
to set it lower. Then
REPEAT
or
to set the second
PIN
DELETE
. The TAD
PIN
on
.
TAD Operation
19
43-1130.fm Page 20 Tuesday, May 30, 2000 1:22 PM
Note:
If you press
while changing the PIN, the TAD exits. Begin
again with Step 1.
SPEAKER
PLAY/STOP
or
REMOTE OPERATION
While you are away from your home or office, you can use a touch-tone phone, or a
pulse (rotary) phone with a pocket tone dialer
(not supplied and available through your local RadioShack store) to enter your PIN and
do any of the following:
• Set the TAD to answer or not answer
calls.
• Listen to your messages.
• Record a new outgoing message.
• Record a memo.
• Erase messages.
Note:
You cannot remotely operate the TAD
using its handset or another telephone on
the same line as the TAD.
USING THE TOLL-SAVER
RING TIME
If
“Setting the Number of Rings” on Page 13),
the TAD answers after three rings if you have
new messages (ones you have not listened
to). If there are no new messages, the TAD
answers after five rings. This gives you time
to hang up before the TAD answers so you
can avoid unnecessary long-distance charges.
is set to
T/S
(toll-saver), (see
USING REMOTE
COMMANDS
1. Dial your phone number and wait for the
TAD to answer.
2. If the TAD is not set to answer calls, it
will answer after about 10 rings and
sound a series of beeps.
3. When the outgoing message begins (or
the TAD sounds a series of beeps),
#
press
seconds.
If the PIN is correct, the TAD announces the
day and time, then it announces the number
of new and old messages. The TAD plays all
new messages then beeps about once every
two seconds to let you know it is ready to accept remote commands.
Notes:
• If the TAD does not respond, try entering
your pin again. If you enter an incorrect
PIN three times, the TAD beeps and
hangs up.
• When the TAD is in remote operation, it
stops all answering functions and
appears on the base’s display. The TAD
resumes answering functions when it is
no longer in the remote command if you
did not turn it off.
• The remote playback of incoming messages is limited to 4 minutes. If you have
more messages after 4 minutes have
passed, you must press
ten to the rest of the messages.
• When using remote operation, you ca n
only delete the current message during
playback. Y ou cannot delete all the messages stored at one time.
, then enter your PIN within 2
rC
# 2
again to lis-
Follow these steps to operate the TAD from
a remote location.
Note:
If you wait more than 15 seconds between each keypress, the TAD sounds a
long beep and hangs up.
20
TAD Operation
• The maximum length of a memo
recorded by remote operation is 4 minutes.
43-1130.fm Page 21 Tuesday, May 30, 2000 1:22 PM
To enter a remote command, press # and
(within 2 seconds) the number for the command you want.
Note:
The remote operation stops when
someone picks up the handset or any phone
on the same phone line.
Remote Commands
Press #
then
1
2
3
4
5
6
7
8
9
To
Repeat the current message during
playback.
Play messages.
Skip the current message during play-
back.
Delete the current message during
playback.
Stop playback, recording, or room
monitoring.
Set the TAD to answer calls.
Record or stop recording a memo.
Record or stop recording a new out-
going message.
Set the TAD to not answer calls.
Monitor the room where the TAD is
located.
TAD Operation
21
43-1130.fm Page 22 Tuesday, May 30, 2000 1:22 PM
ˆ
Troubleshooting
We do not expect you to have any problems with your TAD, but if you do, these suggestions
might help.
Problem Suggestion
Low volume or unusual sounds. Someone has picked up another phone on the same line. Hang
up the other phone.
Severe noise interference. Press
The phone cannot be operated at a
useful distance from the base
because the signal becomes weak
or noisy (handset’s range has
decreased).
The phone does not work or works
poorly.
The handset battery pack does not
charge.
The handset does not ring or
receive a page.
The handset stops working or
works poorly during a call.
CHANNEL
Keep the handset away from computers, remote control toys,
wireless microphones, alarm systems, intercoms, room monitors,
fluorescent lights, and electrical appliances.
Move the handset to another location or turn off the source of
interference.
Lift the base’s antenna to a vertical position.
Be sure neither antenna is touching a metal surface.
Return the handset to the cradle, and recharge the battery pack.
Replace the battery pack if necessary (see “Connecting, Charging, and Replacing the Battery Pack” on Page 10).
Be sure the base’s phone line cord and AC adapter are correctly
and securely connected, and the battery pack is charged.
Check the charging contacts on the handset and base. If they are
dirty, clean them with a pencil eraser.
Be sure the battery pack is connected correctly.
Replace the battery pack.
Move the handset closer to the base.
Lift the base’s antenna to a vertical position.
Be sure the battery pack is charged. (If the battery power is too
low, it does not have enough power to light the TALK/LOW BATT
indicator.)
Move the base away from other electrical devices and sources of
noise.
Move the handset closer to the base.
Lift the base’s antenna to a vertical position.
Be sure the battery pack is charged. (If the battery power is too
low, it does not have enough power to light the TALK/LOW BATT
indicator.)
to change the channel.
22
Troubleshooting
43-1130.fm Page 23 Tuesday, May 30, 2000 1:22 PM
Problem Suggestion
The handset stops working or
works poorly during a call (continued).
The TAD does not answer calls. Make sure the TAD is turned on.
The TAD does not record callers’
messages.
If the base loses power while the handset is away, the security
access-protection code might change. Restore power to the base,
then place the handset back on the base. The CHARGE/IN USE
indicator lights, indicating that the code is set again.
Check the charging contacts on the handset and base. If they are
dirty, clean them with a pencil eraser.
Make sure the AC adapter is properly connected.
Check all phone line connections.
REC TIME
Delete messages if memory is full.
is set to
ANN
(announcement only). Set it to 1 or 4.
If you still have problems, disconnect the TAD. If other phones on the same line work properly,
the fault is in this phone or its installation. If you cannot find the problem, take your phone to
your local RadioShack store for assistance.
CARE
To enjoy your phone for a long time:
• Keep the phone dry. If it gets wet, wipe it
dry immediately.
• Use and store the phone only in normal
temperature environments.
• Handle the phone gently and carefully.
Do not drop it.
• Keep the phone away from dust and dirt.
• Wipe the phone with a damp cloth occasionally to keep it looking new.
Modifying or tampering with the phone’s internal components can cause a malfunction
and might invalidate its warranty and void
your FCC authorization to operate it. If your
phone is not performing as it should, take it
to your local RadioShack store for assistance. If the trouble is affecting the telephone
lines, the phone company can ask you to disconnect your phone until you have resolved
the problem.
Troubleshooting
23
43-1130.fm Page 24 Tuesday, May 30, 2000 1:22 PM
Limited One-Year Warranty
This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for one (1) year from the date of purchase from Radi oSha ck company- owned
stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING
THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED
HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT T O ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS
OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limit ation of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
In the event of a product defect during the warranty period, take the product and the RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, unless otherwise provided by law: (a) correct the defect by product repair without charge for parts and
labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase
price. All replaced parts and products, and products on which a refund is made, become the property of RadioShack. New or reconditioned parts and products may be used in the performance of
warranty service. Repaired or replaced parts and products are warranted for the remainder of the
original warranty period. You will be charged for repair or replacement of the product made after the
expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,
accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or
maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs
other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as
fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs
of product removal, installation, set-up service adjustment or reinstallat i on.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
We Service What We Sell
12/99
RadioShack Corporation
Fort Worth, Texas 76102
43-1130
UCZZ01691BZ
05A00
Printed in China
Loading...
