Cat. No. 63-955
Traveling Recording Picture Frame/Alarm Clock
Your RadioShack Traveling Recording
Picture Frame/Alarm Clock combines a
clock with a recorder that uses the latest
IC (memory) recording technology to
record sounds without tape or moving
parts. You can easily see the time, and
you can record an important message as
well. At a time you set, you can have the
recorder play the message automatically.
The IC lets you record a new message as
many times as you like.
The clock includes these features.
Large Display
time and alarm settings.
Built-In Photo Frame
picture.
10-Second Solid-State Recorder
records and plays a single message as an
alarm or memo.
Clock Alarm
ing series of four beeps, or announces the
prerecorded message .
— lets you easily see the
— holds a favor ite
—
— alerts you with a repeat-
1. Use a Phillips
screwdriver to
remove the
screw from the
battery compartment cover.
2. Slide off the battery compartment cover.
3. Grasp the white plastic sheet and
gently pull it off.
4. Make sure the batteries are in position, then replace the battery cover
and secure it with the screw.
Framing a Picture
Select a picture or photograph which is
thin enough to fit into the frame’s slot. Trim
the picture to 2
mm), then insert the picture from the top of
the frame and push it down until it touches
the bottom of the frame.
5
/8 × 23/8 inches (66 × 60
Compact Size
or carry wherever you go.
— makes it handy to pack
PREPARATION
Removing the Battery
Insulation Strips
Your picture frame/alarm clock comes
equipped with four type 357A button-cell
batteries already installed. However, before you can use the clock, you must remove the plastic insulation sheet from
inside the battery compartment.
© 1999 Tandy Corporation.
RadioShack is a registered trademark used by Tandy Corporation.
All Rights Reserved.
To replace the picture, slide it up until it
clears the upper edge frame opening.
Page 2
63-955.fm Page 2 Monday, August 9, 1999 5:39 PM
OPERATION
Recording A Message
You can record a message up to 10 seconds long. Follow these steps to record the
message.
Use a straightened paper clip to press in
and hold down
lights. Speak into
away in a normal voice. (Speaking too
closely to
After 10 secon ds, the r ecordi ng stops automatically and the indicator turns off. To stop
recording sooner, release
To record a new message, simply repeat
these steps. The new message replaces the
old one.
distorts your recording.)
MIC
Playing the Message
To listen to the message, press
Setting the Time
. The red indicator
REC
from about 10 inches
MIC
.
REC
PLAY
.
Using the Alarm
Follow these steps to set the alarm.
1. Slide TIME/LOCK/ALM to ALM. The
currently set alarm time, and AL
appear.
2. Repeatedly press
the desired alarm time appears.
3. To have the alarm pla y your recorded
message, slide
. To have the alarm sound a
MSG
series of beeps, slide
to
CHIME
4. Slide
store your selections. To show that the
alarm is turned on, appears.
To check the alarm setting at any time,
press
HOUR
is set to
ALM
Depending upon the alarm you selected, at
the set time, the clock repeatedly announces the message or beeps for 1 minute, then
turns off. To silence the al arm so oner, pre ss
ALM STOP
CHIME
TIME/LOCK/ALM
or
MIN
.
LOCK
.
then
HOUR
OFF/MSG/CHIME
.
when
MIN
OFF/MSG/
to
LOCK
TIME/LOCK/
until
to
to
The clock uses the 12-hour, time format. PM
appears at the left of the display for PM
hours.
Follow these steps to set the time.
1. Slide
2. Repeatedly press (or hold down)
3. Repeatedly press (or hold down)
4. Slide
TIME/LOCK/ALM
to set the current hour.
HOUR
to set the current minute.
TIME/LOCK/ALM
to
to
TIME
LOCK
.
MIN
.
To turn off the alarm so it does not sound
again the next day, slide
to
. disappears.
OFF
2
OFF/MSG/CHIME
Page 3
63-955.fm Page 3 Monday, August 9, 1999 5:39 PM
CARE
To enjoy your Traveling Recording Picture
Frame/Alarm Clock for a long time:
• Keep the clock dry. If it gets wet, wipe it
dry immediately.
• Use and store the clock only in normal
temperature environm ents.
• Handle the clock gently and carefully.
Don't drop it.
• Keep the clock away fro m dus t and dirt .
• Wipe the clock with a damp cloth occasionally to keep it looking new.
Modifying or tampering with the clock's internal components can cause a malfunction
and invalidate its warranty. If your clock is
not performing as it should, take it to your
local RadioShack store for assistance.
REPLACING THE
BATTERIES
Your alarm clock uses four type 357A button-cell batteries (supplied) for power.
When the recorded sound weakens, replace the batteries. (For the best results,
use button-cell batteries available from your
local RadioShack store.) The recorder
keeps the last message recorded in memory while you change batteries.
Follow these steps to replace the batteries.
1. Use a Phillips screwdriver to remove
the screw from the battery compartment cover, then slide the cover off.
2. Use the tip of a pencil or other nonmetallic sharp ob ject to remo ve the batteries. Then insert four fresh batteries
in the compartment with their positive
(+) side up.
3. Replace the cover and secure it with
the screw.
Warnings:
• Dispose of old batteries promptly
and properly. Do not burn or bury
them.
• K eep but ton-cel l batteri es away from
children. Swallowing a button-cell
battery can be fatal.
Cautions:
• Use only fresh batteries of the
required size and type.
• Do not mix old and new batteries, or
different types of batterie s.
• Always remove old or weak batter-
ies. Batteries can leak chemicals
that can destroy electronic parts.
SPECIFICATIONS
Power Source:
Four Type 357A Button-Cell Batteries
Battery Life........... (Typical) About 1 Year
Recording Time.... 10 Seconds (Maximum)
Operating Temperature......... 32° to 104° F
(0 ° to 40° C)
Dimensions...... 33/32 × 2 27/32 × 23/
(79 × 72 × 18 mm)
Weight .............................................2.54 oz
Specifications are typical; individual units
might vary. Specifications are subject to
change and improvement without notice.
3
32
Inches
(72 g)
Page 4
63-955.fm Page 4 Monday, August 9, 1999 5:39 PM
Limited One-Year Warranty
This product is warran ted by RadioShac k against manuf acturing defects in m aterial and work manship under normal use for one (1) year from the date of purchase from RadioShack company-owned
stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING
THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED
HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO AN Y
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS
OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Some states do not allow the limitations on how long an implied warranty lasts or the exclusion of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
In the event of a product defect du ring the warra nty period, take th e product and th e RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, unless otherwise pro vide d b y law: (a) cor re c t th e d efe ct b y pr odu ct r epa ir w it hou t ch arg e fo r p ar ts an d
labor; (b) repla ce the product with one of the same o r similar design; or ( c) refund the purcha se
price. All replac ed part s and pro ducts, and products on whic h a refund is made , become the property of RadioSha ck. New or reconditi oned parts and products may be used in the per formance of
warranty service. Repaired or rep laced parts an d products are wa rranted for the remainder o f the
original warranty period. You will be charged for repair or replacement of the product made after the
expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,
accident, misuse, imprope r or abnor mal usage, fail ure to follo w instru ctions, impr oper i nstallati on or
maintenance, alter ation, lightning or ot her incidence of excess vo ltage or current; (b) an y repairs
other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as
fuses or batteri es; ( d) c osm etic damage; (e) tran spo rta tion, shipping or insu ran ce co sts; or (f) co sts
of product removal, installation, set-up service adjustment or reinstallation.
This warranty give s you specific leg al rights, and yo u may also have other rights whi ch vary from
state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
We Service What We Sell
04/99
RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
08A99 Printed in China
