9KTGNGUU"2QQN15RC"6JGTOQOGVGT
OWNER’S MANUAL —
Please read before using this equipment.
Wall Mount Holder — Use to mount
the thermometer on a wall.
Removeable Stand — Use to set
thermometer on a table or other flat surface.
Channel 1/2/3 — Slide to Channel 1, 2, or 3. Set
to a different channel than the other remote
sensors you are using.
yyyy — Appears if the batteries are weak.
"016'"±"
±
Operation
• Do not set two or more thermometers to the
same channel when using them with one
main unit. Otherwise you will unable to judge
which thermometer the digits represent.
• Your thermometer comes with a protective
film covering the display which should be
removed before use.
Selecting a Location
The construction of your home or office might
affect the transmission range between the
main unit and the thermometer. If you have a
choice of several locations, try each to see
which provides the best performance.
"9#40+0)"
Dispose of old batteries promptly and properly.
R
Do not burn or bury them.
.
"%#76+10"
• Use only fresh batteries of the required size
and recommended type.
• Do not mix old and new batteries, different
types of batteries (standard, alkaline, or
rechargeable), or rechargeable batteries of
different capacities.
• If you do not plan to use the thermometer for
a month or more, remove the batteries.
Batteries can leak chemicals that can
destroy electronic parts.
R
.
POOL SPA
WIRELESS THERMOMETER
Thank you for purchasing the RadioShack
Wireless Pool/Spa Thermometer. Your
thermometer measures water temperature,
and is useful in swimming pools, hot tubs,
and freezers. It is for use with an in/out
thermometer (not supplied, available at your
local RadioShack store or online at
www.radioshack.com). The supplied wall
mount holder and stand let you mount it
wherever you like.
+056#..+0)"
$#66'4+'5
Your thermometer requires two AA batteries
(not supplied) for power. For the best
performance and longest life, we
recommend RadioShack alkaline
batteries.
1. Remove the wall-mount holder from the
back of the thermometer.
2. Use a Phillips screwdriver to loosen the
screws on the battery compartment
cover and remove the cover.
°C/°
Battery
Compartment
Cover
....
RRRRý
F
CHANNEL 1/2/3
RESET
63-1037
Liquid Crystal Display — The
current temperature and selected
channel appear.
Temperature Sensor Probe — Place it in
water to test the temperature.
°C / °F — Select Centigrade (°C) or
Fahrenheit (°F) for your desired degree
format.
3. Slide
4. Slide
5. Place two batteries in the compartment
6. Replace the cover and secure it with the
CHANNEL 1/2/3
setting, then press
channel appears on the display.
to the desired setting.
°°°°C/°°°°
F
as indicated by the polarity symbols
(+ and –) marked inside.
screws.
RRRRý
to the desired
. The selected
RESET
12'4#6+10
Place the temperature sensor probe where
you want to test. The current temperature
and selected channel appear. Signals
transmit to the main unit about every 30
seconds.
±±±±
4'5'66+0)"6*'"5;56'/
If your thermometer stops working properly,
use a pointed object to press
resets the temperature and reinitializes the
sensor transmitter.
RESET
. This
/1706+0)
Place your thermometer on a flat surface
using the supplied stand, or mount it on the
wall using screws (not supplied) and the
supplied holder.
5'.'%6+0)"#".1%#6+10
Choose an indoor or outdoor location for
your thermometer that is within 60 – 90 feet
(20 – 30 meters) of the main unit.
±±±±
"+/2146#06"
If an icon appears at the end of a paragraph, go to the box on that page with the corresponding icon
#
for pertinent information.
— Warning
RRRRý
— Important
#
— Note .
±±±±
#
. — Caution
..
°°°°
— Hint
2002 RadioShack Corporation.
©
RadioShack and RadioShack.com are trademarks used by
All Rights Reserved.
RadioShack Corporation.
.
"%#76+10"
Do not place your thermometer:
• In direct sunlight.
• In water. It is water resistant, not water-proof.
• Near electronic appliances, heating, or air
conditioning vents.
.
75+0)"6*'"56#0&
1. Remove the wall-mount holder.
2. Set the thermometer on a flat surface.
3. Insert the ends of the supplied wire
stand into the holes on the back of the
thermometer.
....
9#.."/1706+0)
1. Drill two holes 13/4 inches apart. Thread
a screw in each hole, letting the heads
extend about
surface.
1
/4 inch from the mounting
(%%"+0(14/#6+10
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
• Consult your local RadioShack store or an
• If you cannot eliminate the interference, the FCC
Changes or modifications not expressly approved by
RadioShack may cause interference and void the user’s
authority to operate the equipment.
This device complies with Part 15 of the
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
FCC Rules
and receiver.
experienced radio/TV technician for help.
requires that you stop using your thermometer.
. These limits are designed to
FCC Rules
.
"016'"±"
±
Care
Keep the thermometer dry; if it gets wet, wipe it
dry immediately. Use and store the
thermometer only in normal temperature
environments. Handle the thermometer
carefully; do not drop it. Keep the thermometer
away from dust and dirt, and wipe it with a
damp cloth occasionally to keep it looking new.
If your thermometer is not performing as it
should, take it to your local RadioShack store
for assistance. Modifying or tampering with the
thermometer’s internal components can cause
a malfunction and might invalidate its warranty
and void your FCC authorization to operate it.
2. Align the keyhole slots on the mounting
holder with the screws and slide the
holder downward to secure it.
3. Slide the thermometer onto the
mounting holder.
52'%+(+%#6+105
Power ................ Two 1.5V Alkaline AA Batteries
Alkaline Batteries .......................... –4
Resolution ................................................... 0.2
Sampling Cycle .......................About 30 Seconds
Weight ( without batteries) .........................3.9 OZ
Dimensions ..................4.05
Operation Temperature Range....... –4
RF Transmission Frequency ....................433MHz
RF Transmission Range.........................98.4 Feet
Sensing Cycle ....................................30 Seconds
Specifications are typical; individual units might
vary. Specifications are subject to change and
improvement without notice.
×
±±±±
°
2.67 × 0.82 Inches
°
Limited One-Year Warranty
This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for one (1) year from the date of purchase from
RadioShack company-owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO
LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, IN CLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you.
In the event of a product defect during the warranty period, take the product and the RadioShack sales receipt as proof of purchase date to any RadioShack store.
RadioShack will, at its option, unless otherwise provided by law: (a) correct the defect by product repair without charge for parts and labor; (b) replace the product with one
of the same or similar design; or (c) refund the purchase price. All replaced parts and products, and products on which a refund is made, become the property of
RadioShack. New or reconditioned parts and products may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for the
remainder of the original warranty period. You will be charged for repair or replacement of the product made after the expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse, accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or maintenance, alteration, light ning or other incidence of excess voltage or current; (b) any repairs other than those provided by a RadioShack
Authorized Service Facility; (c) consumables such as fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs of product removal, installation, set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
F to 140°F
°
F to 140°F
12/99
F
RadioShack Corporation
Fort Worth, Texas 76102
63-1037
08A02
Printed in China
