Radio Shack 20-197 User Manual

Digital Trunking

Desktop/Mobile Radio Scanner

Thank you for purchasing your Digital Trunking Desktop/Mobile Radio Scanner from RadioShack. Please read this user’s guide before installing, setting up, and using your new scanner.

What’s Included

20-197

PRO-197

Scanner

Antenna

Screw (2)

Mounting bracket

DIN sleeve

Keys (2)

Rubber washer (2)

Lock washer (2)

Rubber feet (3)

Knob (2)

AC adapter

DC cable with fuse

User’s Guide

Quick Start Guide

V-Scanner Preprogrammed Data

www.radioshack.com

ontents

Contents

Understanding Your Scanner ............................................................ 6

Understanding the Function Keys ....................................................................6

Understanding the Display ...............................................................................9

Understanding Object Oriented Scanning ................................................... 10

Scanner Features ............................................................................................. 13

Scanner Setup ................................................................................. 16

Installing Your Scanner .................................................................................... 16

Setting up a Mobile Base .............................................................................16

Bracket Mounting .........................................................................................16

Dashboard Installation .................................................................................17

Connecting the Antenna ..............................................................................18

Powering Your Scanner ...................................................................................19

Wall Outlet ....................................................................................................19

Vehicle (Power Socket) ................................................................................. 19

Vehicle (Direct) ..............................................................................................20

Headphones and Speakers ............................................................................20

Listening Safety .............................................................................................20

Transferring Data To or From another Scanner or PC .................................21

Turning on the Scanner and Setting Squelch ................................................21

Squelch and Attenuator ..................................................................................22

Basic Settings ...................................................................................................23

Delay ..............................................................................................................24

Adjusting the LCD Contrast.........................................................................24

Turning the Key Tone On or Off ..................................................................25

Turning Key and Backlight On or Off .......................................................... 25

Creating Scannable Objects ........................................................... 26

Understanding Object Menus ........................................................................26

Conventional Channel Objects ......................................................................28

Essential Parameters ....................................................................................28

Creating a CONV Object .............................................................................29

Changing Text Tags ......................................................................................29

Trunking Talkgroup Objects (TGRP) ............................................................... 30

Essential Parameters ....................................................................................30

Trunking System (TSYS) Objects ..................................................................31

Duplicate (DUPE) .............................................................................................34

Scanning .......................................................................................... 35

Basic Scanning Operation ..............................................................................35

Wildcard Scanning ..........................................................................................35

Manual Mode ...................................................................................................36

Organizing Objects ........................................................................ 38

Object Numbering ..........................................................................................38

Grouping Objects with Scan Lists ..................................................................39

Changing Scan List Membership ................................................................40

New Objects .............................................................................................40

Existing Objects. ...................................................................................... 40

Naming Scan Lists ........................................................................................41

Enabling or Disabling Scan Lists .................................................................41

While Scanning ........................................................................................41

From Global Settings Menu ....................................................................42

NS (Not Scanned) Scan List ......................................................................... 42

Favorite List ................................................................................................... 43

Setting the Default Scan List .......................................................................44

Deleting Objects .............................................................................................44

Searching for Objects using FIND ................................................................. 45

Filtering by Object Type .................................................................................47

Object Lockout ................................................................................................47

Temporary Lockout .......................................................................................48

Permanent Lockout ......................................................................................48

Change L/OUT Key Function.......................................................................49

Search Lockout .............................................................................................49

Talkgroup Lockout ........................................................................................ 50

Object Searches .............................................................................. 51

Limit Search Object (LMIT) .............................................................................51

Essential Parameters ....................................................................................51

ontents

Contents

Service Search Object (SRVC) .........................................................................53

Essential Parameters ....................................................................................53

Signal Stalker II Object (STLK) ........................................................................ 55

Essential Parameters ....................................................................................55

Dedicated Searches ........................................................................ 57

Dedicated LMIT Search ...................................................................................57

Dedicated SRVC Search ..................................................................................58

Dedicated Signal Stalker II .............................................................................60

Dedicated TUNE Search ................................................................................. 61

Tune LED .......................................................................................................63

Weather Scanning ........................................................................... 64

Weather Radio Mode ......................................................................................64

Weather Priority Mode ....................................................................................64

SAME Standby Mode ......................................................................................65

Activating SAME Standby Mode .................................................................68

Scanner Memory ............................................................................. 69

V-Scanner Storage ...........................................................................................69

Using V-Scanners .......................................................................................... 70

Saving Main Memory to a V-Scanner Folder ..............................................70

Loading a V-Scanner Folder to Main Memory ........................................... 71

Erasing V-Scanner Folders ........................................................................... 71

Cloning ............................................................................................................ 71

Memory Report ................................................................................................72

Advanced Settings .......................................................................... 73

Priority Scan .....................................................................................................73

Turning Object Priority On or Off ................................................................73

Turning Priority Scan Mode On or Off ........................................................73

CONV Priority Scan ......................................................................................74

TGRP Priority Scan ........................................................................................74

Hit Counters .....................................................................................................74

Audible Alarms and the Alert LED .................................................................75

Multi-Site Mode on Networked Systems ......................................................77

LTR Home Repeater AutoMove .....................................................................79

Additional Information .................................................................... 80

Power-On Conﬁguration Key Sequences ......................................................80

Power-On Password ........................................................................................81

Birdie Frequencies ...........................................................................................82

FCC Notice ......................................................................................................83

Scanning Legally ..............................................................................................83

Care ..................................................................................................................84

Service and Repair ...........................................................................................84

Speciﬁcations .................................................................................................. 85

Troubleshooting...............................................................................................89

Reset Global Parameters to Factory Defaults ............................................... 90

Initializing the Scanner to Factory Defaults ...................................................92

Appendix A: Search Bands ............................................................. 94

All Sub Bands ...................................................................................................94

PubSafety Band ...............................................................................................94

Aircraft Band ....................................................................................................95

Ham Bands .......................................................................................................95

Appendix B: Detailed Menu Reference .......................................... 96

GLOB Menu .....................................................................................................96

CONV Menu .................................................................................................101

TGRP Menu .................................................................................................... 104

TSYS Menu ..................................................................................................... 106

LMIT Menu .....................................................................................................108

SRVC Menu ...................................................................................................110

STLK Menu .................................................................................................... 113

Appendix C: Text Entry and QuickText ........................................ 115

Text Entry ........................................................................................................115

QuickText .......................................................................................................117

Customizing QuickText ..............................................................................118

Index ............................................................................................. 119

Understanding Your Scanner

Understanding the Function Keys

Five Way Pushbutton Pad

t p q u Navigates while browsing objects and menus. t u Navigates through Scan Lists.

SEL (Select) Activates data entry ﬁelds and toggles Scan List selection in object menus.

FUNC + SEL to activate context sensitive help menus.

Softkeys F1 / F2 / F3

Activates the function shown in the LCD display above the softkey.

Programmable LED

Understanding your Scanner

1-0 / A-Z

Inputs a number or character. Use while scanning to select Scan Lists 1-10 on/off. Press after FUNC to select Scan List 11-20 on/off.

• / DELAY

Inputs decimal point (frequency input), space (text input) or hyphen (Trunking ID input). Toggles delay functions on/off.

ENT (Enter)

Volume / ON/OFF / Squelch

PAUSE

Pauses scan or search.

L/OUT

Toggles temporary Lockout on active or selected object. FUNC + L/OUT for permanent lockout.

SCAN /

Enters Scan Mode for scanning enabled objects.

FUNC + SCAN activates Signal Stalker II.

MAN (Manual)

Places scanner in Manual Mode for monitoring single objects.

PROG (Program)

Puts scanner in Program Mode for editing radio-wide options, adding new objects, or editing existing objects. FUNC + PROG accesses V-Scanner Mode.

ATT (Attenuator)

Toggles Attenuator on and off.

FUNC + ATT toggles Global Attenuator mode.

Connect computer, PRO197 or PRO-106 scanner

Connect Headphones

FUNC (Function)

Activates alternative key

DIM

Controls backlight brightness.

PRI (Priority)

Toggles Priority setting for selected or active object. FUNC + PRI toggles Priority Mode on/off.

SRCH (Search)

Enters Search Mode for dedicated service and frequency searches.

FAV (Favorites)

Activates Favorites Scan Mode. FUNC + FAV adds current object to the Favorite Scan List.

functions.

WX /

Activates Weather Scan. FUNC + WX activates Skywarn mode.

TUNE

Direct tuning of any valid frequency. FUNC + TUNE loads current or most recently scanned frequency into Tune.

CLR (Clear)

Clears an incorrect entry. FUNC + CLR clears entire ﬁeld. Moves back to previous menu.

Understanding your Scanner

DC 13.8V Connect power source.

EXT SP Connect an external speaker.

Understanding your Scanner

Understanding the Display

The LCD provides important information about the status of the radio. The top row of icons provide status information. Beneath this row, there are 4 rows of 16 characters each that provide alphanumeric information such as frequencies and object names. The last row usually contains softkeys for F1, F2, and F3.

ANT Connect the supplied antenna or an external antenna.

SCREW HOLE May be used to mount the scanner in a car.

Alph a n u m er i c I nf o Alph a n u m er i c I nf o Alph a n u m er i c I nf o

F1 F2 F3

The Function Key (FUNC) has been pressed.

The scanner is currently receiving trunking control channel data.

The attenuator is set for Global mode.

The attenuator is currently active.

The radio’s squelch circuit is open.

Signal meter indicating strength of the received signal.

Menu position and search direction indicators.

Understanding your Scanner

Understanding Object Oriented Scanning

Your PRO-197 scanner utilizes an entirely new method of programming called Object Oriented Scanning. In Object Oriented Scanning, all “Scannable Objects” are treated the same. Scannable Objects include talkgroups on trunked radio systems, conventional non-trunked frequencies, limit searches, service searches, and Signal Stalker II conﬁgurations. All these Scannable Objects are created, edited, grouped, scanned and deleted using the same methods. Scannable Objects can also be searched, ﬁltered, and locked out.

Scannable Objects are mapped to Scan Lists, which can be named, enabled, and disabled. There is even a Favorites Scan List. It is easy to search for new frequencies or talkgroups and add them to Scan List groups. It is also easy to delete or deactivate objects and Scan Lists that you do not want to listen to, including a powerful temporary lockout mode that allows you to zero in on activity associated with a speciﬁc incident, then restore your desired conﬁguration when the incident is over.

Object Oriented Scanning is completely different from any prior scanning receiver technology. Accordingly, some users may ﬁnd it difﬁcult to visualize and understand how Object Oriented Scanning works. This may be especially true for users who are familiar with more recent scanning receiver technologies.

We suggest that you keep the following Object Oriented Scanning Tenets in mind as you proceed with your study of this manual.

1. Memory organization is nothing more than a large list of Scannable Objects.

2. A Scannable Object is simply “something that can be scanned,” including conventional channels, trunking talkgroups, limit searches, service searches, and Signal Stalker II setups.

3. There are no “systems,” “banks,” “groups,” “sub-groups,” or “ID lists.” There is simply a very large collection of objects, each

with their own attributes. Scannable Objects all exist at the same level or hierarchy within the scanner—no single type of Scannable Object is more important than another, and Scannable Objects do not have dependencies on or links to other Scannable Objects in order for them to function properly.

4. The primary method of grouping the collection of objects is by mapping them to Scan Lists. Mapping a Scannable Object to one or more Scan Lists does not change the physical location of the object in the memory system. When an object is mapped to one or more Scan Lists, the object itself has not moved nor changed from what it is—a simple, standalone object that is part of a larger collection.

Object abbreviations used in this manual

Object names are abbreviated so that they can easily ﬁt into the 16 character LCD. You should take a moment and become familiar with these abbreviations now.

CONV – Conventional Channel Object

A CONV object is a regular, non-trunked frequency used for radio communications. CONV objects are used to store the parameters for any radio channel that is not a part of a trunked system. For example, if you want to monitor speciﬁc VHF marine channels, they should be programmed as CONV objects. If you want to monitor your favorite amateur radio channel, it should be stored as a CONV object. If your police or ﬁre department uses a channel, or channels that are not trunked, but part of a “plain old radio system,” they should be stored as CONV objects.

TGRP – Trunking Talkgroup Object

Trunking Talkgroups are “virtual” channels that exist on a trunked radio system. A trunked radio system is a radio system where a small group of radio channels are automatically shared between a larger number of users and user groups. This sharing of channels is

Understanding your Scanner

managed automatically by a special computer, called a controller, or by other specialized hardware. If you want to monitor a talkgroup on a trunked radio system, you must store that talkgroup’s parameters in a TGRP object.

TSYS – Trunking System Object

A TSYS is a special object type that is used when creating TGRP objects. A trunking talkgroup must be associated with a speciﬁc trunked radio system in order for it to operate. There are parameters that are associated with trunking systems, such as the type of trunked radio system technology used, the frequencies that the system uses to broadcast control data, etc. Instead of entering these parameters over and over again every time you create a new TGRP, you create a TSYS object with all of the system parameters, then specify that TSYS object for each TGRP you create on the same trunked radio system. A TSYS cannot be scanned by itself and is not considered a Scannable Object. It is a “conﬁguration object” that can be used over and over again when adding talkgroups for a speciﬁed trunked radio system.

LMIT – Limit Search or Search Range Object

LMIT objects contain the parameters necessary for the radio to search a range of individual frequencies between a lower and upper limit frequency.

SRVC – Service Search Object

SRVC objects are further divided into Public Safety, Aircraft, Amateur, CB, Marine, and FRS/GMRS/MURS/DOT. SRVC objects are similar to LMIT objects, but are preprogrammed to search all frequencies associated with the selected service.

STLK – Signal Stalker II Object

STLK objects contain the parameters necessary for the radio to rapidly sweep a range of radio spectrum for strong signals from nearby transmitters.

Scanner Features

Object Oriented User Interface is designed for ease of use, yet is powerful enough to satisfy the most sophisticated experts. Common data entry, browsing and control methods are used for non-trunked conventional channels, trunking talkgroups, search conﬁgurations and Signal Stalker II setups. The radio grows with you—you can start out with a small, easy to manage conﬁguration, then expand it whenever you need to.

Menu Driven Programming with Context Sensitive Help – Each menu item provides a few lines of help text that provide assistance with programming and using the scanner.

Scan List functionality allows you to arrange, group and scan objects according to your preference.

Free-Form Memory Organization – Memory is assigned as objects are created using a sophisticated internal ﬁle management system. You are not constrained to traditional bank or channel scanner memory layouts. The scanner can store over 1,800 conventional channels, trunking talkgroups, search conﬁgurations, and Signal Stalker II objects in any combination.

V-Scanner Technology – Allows you to save complete radio conﬁgurations within the radio, for recall into main memory as needed in the ﬁeld. Twenty one V-Scanner Folders are provided, each capable of storing over 1,800 objects. Total memory capacity of main memory combined with V-Scanners is over 37,800 objects.

Skywarn Storm Spotter Functionality – Instant access to frequencies used by storm spotter networks. You can monitor storm conditions as they occur, and become aware of dangerous conditions before the media or emergency management ofﬁcials announce them to the general public.

SAME and All Hazards Weather Alerting – Your scanner can alert you to severe weather and other hazards in the speciﬁc areas

Understanding your Scanner

that you select. Your scanner can check your local NOAA weather frequency periodically, even while scanning, and alert you when an All Hazards alert occurs.

Multi-System Trunking – Scans most common trunked radio system signaling formats, including Motorola, EDACS, LTR and P25 trunked radio networks. Both talkgroup and individual call monitoring are supported.

Automatic Adaptive Digital Tracking – When monitoring P25 digital systems, instantly adapts the digital decoder to the digital modulation format of the transmitted signal, then analyzes the signal over 50 times each second and adapts to any subtle changes caused by multipath or fading. No cumbersome manual adjustments are required.

Digital AGC – Instantly compensates for low user audio levels that are common on digital systems.

LTR Home Repeater AutoMove – Takes the guesswork out of programming LTR trunking systems when the home repeater order is not known. Enter the LTR system frequencies in any order, and the PRO-197 will automatically move the frequencies to the proper home repeater slots as transmissions are received on the system.

Subaudible Squelch Decoder – CTCSS and DCS subaudible squelch coding is processed by the same powerful DSP chip that is used for P25 digital decoding. Provides fast and reliable decoding of subaudible squelch signaling with squelch tail elimination.

Signal Stalker II – Quickly sweeps the scanner’s frequency ranges for transmissions from nearby sources.

P25 NAC Functionality – P25 Network Access Code (NAC) is used to provide selective squelch operation on conventional digital channels. Your PRO-197 will detect the NAC that is being used on a P25 conventional digital channel, and allow you to program NAC codes to block transmissions that do not have a matching NAC, including analog trafﬁc on the same frequency.

Alert LED – Programmable tri-color LED can be conﬁgured to illuminate or ﬂash when certain objects are active. Eight user-deﬁned colors and brightness levels can be speciﬁed from thousands of possible combinations.

Audible alarms – Programmable audible alarms can be conﬁgured to sound when certain Scannable Objects are active. Can be used in conjunction with, or separately from, the Alert LED described above.

High Speed PC Interface – Use a USB Scanner programming cable for full duplex mode at 6 times the speed of previous scanner models for PC transfer and 8 times the speed of previous models for radio to radio cloning. High speed scanner programming cables are available at your local RadioShack store or RadioShack.com.

Real-time Signal Strength Indicator – Shows relative strength of received signals.

IMPORTANT NOTICE: The PRO-197 Digital Scanner will not receive encrypted radio communications, or radio transmissions that utilize ProVoice digital modulation.

Scanner Setup

Installing Your Scanner

You can mount your scanner in your vehicle or use it as a base station.

Setting up a Mobile Base

You can place your scanner on a desk, shelf, or table to use it as a base station. Because the speaker is on the bottom of the scanner, use the mounting bracket to elevate your scanner off the surface for better sound.

To use the scanner on a ﬂat surface:

1. Attach the three protective rubber feet to the mounting bracket.

2. Slide the scanner into the bracket, aligning the scanner’s side holes with the holes in the bracket, mounting

Bracket Mounting

You can mount your scanner under or on top of the dashboard a desk, shelf, table or other ﬂat surface, using the mount bracket.

1. Use the supplied mounting bracket as a template to make positions for the two mounting screws.

2. At the marked positions, drill holes slightly smaller than the screws. When drilling holes, avoid obstructions behind the mounting surface.

and then screw the

knobs into the scanner.

3. Attach the mounting bracket to your vehicle’s surface using the supplied screws and lockwashers.

Note: Do not use the rubber feet if you are mounting the bracket with screws.

Dashboard Installation

If you are unsure how to install your scanner in your vehicle, consult your automobile manufacturer, dealer, or a qualiﬁed installer.

To mount in your dashboard, you must connect an external antenna and speaker.

1. Before installing, conﬁrm your scanner ﬁts in the desired mounting area and you have all the necessary materials. Your scanner requires a 2 x 7 1/8 x 5 5/16 inch (50 x 180 x 135 mm) space.

2. Remove the four rear screws and pull off the black case before installing your scanner.

3. Install the DIN sleeve into the opening in your dashboard, lip facing out.

4. Push out the top and bottom tabs to hold the sleeve ﬁrmly in place.

5. Slide the scanner into the sleeve until it locks in place.

Scanner Setup

To remove your scanner from the DIN sleeve, insert the two keys straight into the scanner’s front panel and pull the scanner out.

Connecting the Antenna

You must install an antenna before you can operate the scanner. The supplied telescopic antenna helps your scanner receive strong local signals. To install the antenna, align the antenna slots with the tabs on the scanner, and slide the antenna into place. Turn and push down until the antenna locks into place.

To connect an external antenna, follow the installation instructions supplied with the antenna. Use 50-ohm coaxial cable, such as RG-58 or RG-8X, to connect an outdoor antenna. For lengths between 50 and 100 feet, use RG-8X low-loss dielectric coaxial cable. For lengths over 100 feet, use RG8. You also may need a BNC adapter (not supplied).

WARNING: Use extreme caution when you installing or removing an outdoor antenna. If the antenna starts to fall, let it go! It could contact overhead power lines. If the antenna touches a power line, contact with the antenna, mast, cable, or guy wires can cause electrocution and death. Call the power company to remove the antenna. DO NOT attempt to do so yourself.

Powering Your Scanner

You can power your scanner from a wall outlet, or from your vehicle’s battery.

You must use a power source that supplies 12V DC and delivers at least 600 mA. Its center tip must be set to positive and its plug must ﬁt the scanner’s DC 13.8V jack. The supplied AC adapter and DC power cord meet these speciﬁcations. Using a power source that does not meet these speciﬁcations could damage the scanner or the adapter.

Wall Outlet

1. Connect the tip of the supplied AC adapter to the DC 13.8V jack at the rear of your scanner.

2. Plug the AC adapter into your wall outlet.

To prevent electric shock, do not use the AC adapter’s polarized plug with an extension cord, receptacle, or outlet unless you can fully insert the blades to prevent blade exposure.

Note: To avoid injury, do not connect the provided power adapter to a ceiling outlet.

Vehicle (Power Socket)

To power your scanner from a 12V power source in your vehicle, such as a cigarette-lighter socket, you need a 12V, 600 mA DC cigarettelighter adapter (not supplied), available at your local RadioShack store.

1. Insert the adapter’s barrel plug into the scanner’s DC 13.8V jack.

2. Plug the adapter’s other end into your vehicle’s cigarette lighter or power socket.

Note: When you use a cigarette-lighter adapter, you might hear electrical noise from your engine while scanning. This is normal. This is less of a problem if you connect directly to the vehicle fuse box.

Scanner Setup

Vehicle (Direct)

1. Disconnect the cable from your vehicle battery’s negative (–) terminal.

2. Ground the black wire of the supplied DC power cord to your vehicle’s chassis. The grounding screw must make complete contact with your vehicle’s metal frame.

3. Connect the red wire of the supplied DC power cord to a voltage source that turns on and off with the ignition switch, such as a spare accessory terminal in your vehicle’s fuse box.

4. Insert the power cord’s barrel plug into the scanner’s DC 13.8V jack.

5. Reconnect the cable to your vehicle battery’s negative (–) terminal.

Headphones and Speakers

You can plug headphones or an external speaker (neither included) into your scanner.

To use headphones, connect the plug into the headphone jack on the front panel. Headphones automatically mute the scanner’s speaker.

To use an external speaker, connect the plug into the EXT SP jack on the rear panel.

Listening Safety

To protect your hearing, follow these earphone or headphones guidelines:

• Do not listen at extremely high volume levels. Extended highvolume listening can lead to permanent hearing loss.

• Set the volume to the lowest setting before listening. Turn on the scanner, then adjust the volume to a comfortable level.

• After you set the volume, do not increase it. Over time, your ears adapt to the volume level, so a volume level that does not cause discomfort might still damage your hearing.

• Do not wear an earphone or headphones with your scanner when operating a motor vehicle or riding a bicycle in or near trafﬁc. Doing so can create a trafﬁc hazard and could be illegal in some areas.

• Even though some earphones/headphones let you hear some outside sounds when listening at normal volume, they can still be a trafﬁc hazard.

Transferring Data To or From another Scanner or PC

You can transfer the programmed data to and from another PRO-197 or PRO-106 scanner using a connecting cable which has 1/8-inch (3.5mm) stereo (TRS) phone plugs on both ends (not supplied). See “Cloning” on page 71.

You can also upload or download programmed using a USB cable available through your local RadioShack store or at RadioShack.com. To ﬁnd the application software, we recommend using an internet search engine to search for “scanner programming software.”

data to or from a PC

Turning on the Scanner and Setting Squelch

1. Turn the VOLUME and SQUELCH knobs clockwise to about their mid-point (12:00 o’clock) position.

Note: Make sure the scanner’s antenna is connected before you turn it on.

2. Press TUNE.

3. Turn SQUELCH down (counterclockwise) until you hear noise.

4. Turn SQUELCH up (clockwise) a little past where the noise stops. The higher the squelch is set, the stronger the signal required to break the squelch.

5. If noise starts breaking the squelch, turn SQUELCH up to decrease the scanner’s sensitivity. To hear weaker signals, turn SQUELCH down to increase its sensitivity.

Scanner Setup

Squelch and Attenuator

The squelch and attenuator control the scanner sensitivity. If squelch is set too high, the scanner may scan slowly or stop on noise or silence. If this happens, adjust squelch using the steps above, or for conventional channels, set the correct subaudible squelch mode. See “Appendix B: Detailed Menu Reference: Conv Menu” on page 101.

With the attenuator on, the scanner might not receive weak signals, but immunity to adjacent strong signals is improved.

You can reduce interference using two attenuator modes:

• Global – The attenuator setting is applied to all channels, bands, or groups.

• Normal – Lets you set the attenuator in each channel, band, or group.

Note: You cannot set the attenuator while scanning.

To set the attenuator mode in the Global Menu:

1. Press PROG for Program Mode.

2. Press GLOB softkey to access GLOB menu.

3. Press p or q to scroll to Atten Mode.

4. Press t or u to select Global or No rm al.

5. When attenuator is set to Global, you can set Global attenuator on or off. Press p or q to scroll to Global At ten.

6. Press t or u to select on or off.

7. Press SAVE softkey to save the new setting.

To set the attenuator mode using the ATT key:

When the scanner is in Manual Mode, Program Mode, Search Mode, Signal Stalker Mode, or when the scan stops:

• Press ATT to toggle on and off the attenuator setting.

• Press FUNC ATT to toggle on and off the global attenuator setting.

Basic Settings

The Global menu stores all of the radio-wide settings used by the scanner. The Global menu allows you to “tweak” these settings to your liking. The default settings will work ﬁne for most users, but you may want to use the Global menu to personalize the radio to suit your individual tastes. The most common settings are described in the following sections. Refer to “Appendix B: Detailed Menu Reference: GLOB Menu” on page 96 for a description of all the settings.

• The active parameter is always the middle parameter and is indicated by a ﬂashing colon (:).

• Some Global parameter changes do not take effect until the Global menu is saved.

• Help is available for every menu parameter. Press FUNC SEL to view help for the selected parameter. Press SEL to exit help.

• The U ndo softkey appears in ﬁelds where numerical values can be set, allowing you to exit a parameter ﬁeld without saving changes. A note will appear: “Unsav ed Chan ges! Go Back?” Press YES to go back to the ﬁeld and continue editing. Press NO to discard changes and return to the previous menu.

• Each menu parameter features a Dflt softkey that can be used to restore the value to the factory defaults. This can be very useful if you make a change to a parameter but do not like the result.

• You can restore all Global settings to their defaults without affecting your programmed objects or V-Scanners. Power cycle the radio, then press 0, then 2 during the welcome message display. Press ENT to conﬁrm the Global parameter reset.

To access GLOB menu:

1. Press

2. Press GLOB softkey to access Global menu.

PROG for Program Mode.

Scanner Setup

3. Press p or q to scroll to the desired parameter.

Note: Press FUNC p or FUNC q to jump to the top or bottom of the menu.

4. Press t or u to select options for selected ﬁeld.

5. Press SAVE softkey to save new settings to radio conﬁguration memory.

Delay

Sometimes, several seconds can pass between transmissions. To avoid missing a reply, a delay is automatically set for each channel. The scanner stops for 2 seconds after a transmission stops before it resumes scanning or searching.

To turn the delay on or off:

Press FUNC •/Delay when the scanner stops on a transmission. Lowercase d in the display indicates delay is off. Uppercase D indicates delay is on.

Note: Delay and delay time can also be set in each Scannable Object Menu. Search Delay time can be set in the Global menu. Refer to “Appendix B: Detailed Menu Reference” on page 96 for a description of delay settings.

Adjusting the LCD Contrast

You can set the LCD contrast from level 1 to 7.

1. Press PROG for Program Mode.

Turning the Key Tone On or Off

Each time you press any of the scanner’s keys, the scanner beeps.

To turn the scanner’s key tone on or off:

1. Press

2. Press GLOB softkey to access Global menu.

3. Press p or q to scroll to Key Be eps.

4. Press u to select On or Off.

5. Press SAVE softkey to save new setting.

PROG for Program Mode.

Turning Key and Backlight On or Off

1. Press PROG for Program Mode.

2. Press GLOB softkey to access Global menu.

3. Press p or q to scroll to Light Mode.

4. Press u to select backlight operation.

N orml (Normal): Uses the backlight on.

S tlth (Stealth): Disables backlight

5. Press SAVE softkey to save new setting.

To change the backlight mode:

Repeatedly press DIM to adjust backlight from Dark, Light Off, or Light.

2. Press GLOB softkey to access Global menu.

3. Press p or q to scroll CONTRA ST.

4. Press t or u to select contrast level 1 to 7.

5. Press SAVE softkey to save new setting.

Creating Scannable Objects27Creating Scannable Objects

Creating Scannable Objects

Understanding Object Menus

When you turn on your scanner for the ﬁrst time, the scanner is in Program Mode for you to create your ﬁrst object into memory. If you do not see this screen, press PROG.

Press NEW to Creat e objec ts

NEW EDIT GLOB

Press F1 to create a new scannable object.

1. Press F1, the NEW softkey, to begin entering a new object.

Press F1 to create a new Talkgroup Object.

Press F2 to edit existing object.

Selec t objec t type to crea te

TGRP CO NV SRCH

Press F2 to create a new Conventional Object.

Press F3 to change the scanner’s global conﬁguration settings.

Press F3 to create a new Search Object.

2. For the purpose of this explanation, press F2, the CONV softkey.

3. The Conventional Channel menu opens.

Indicates cursor

 CONV C hannel 

Scan Lists: *01 Freq: 25 .000000

Save Exit Dflt

Menu softkeys. Press F1, F2, and F3 to access.

location in menu

Menu name Active menu item Next menu item (Scroll down for more

menu items)

Object menu notes:

• The ﬁrst line of the display shows either:  to indicate the cursor is at the top position of the menu,

to indicate the cursor is at the bottom, or  to indicate



there are menu items above and below the cursor.

• The center (third) line of the display contains the blinking cursor indicating the active menu item.

• To see the help text for the active menu item, press FUNC, then press SEL on the 5-way pushbutton pad. To exit help, press SEL again.

• The last line of the display shows the softkeys, which will change with each menu. In this menu, the Save softkey will save your new object to the ﬁle system, the Exit softkey aborts the creation of the new object, and the Dflt softkey restores the parameter of the

active menu item

to its default setting.

Creating Scannable Objects29Creating Scannable Objects

• If you press the q key on the bottom of the 5-way pushbutton pad, you can scroll down and see all of the parameters that can be speciﬁed for the object.

• Pressing FUNC p or FUNC q will jump to the top or bottom of a menu, respectively.

• As you scroll the object menu, you will see a line that states: 

EXPER T BELOW . This line is found in the object menus and the

Global Conﬁguration menu. It delineates between basic settings and expert settings for advanced users. For more information about the Basic and Expert settings, refer to “Appendix B: Detailed Menu Reference” on page 96.

• When entering data into a numerical ﬁeld, you can start typing as soon as you have scrolled to the desired ﬁeld, which will replace any previous contents with your new entry. Alternatively, you can press the u key, which will preserve the original contents of the ﬁeld so you can make small changes without retyping all of the data.

Conventional Channel Objects

A Conventional Channel Object (CONV) is a record that stores the parameters for a regular, non-trunked conventional AM or FM channel. When you create a CONV object, you are creating an object that will allow you to scan and monitor a “plain old radio channel,” that is, a single frequency and the associated parameters that are necessary for you to receive trafﬁc on that frequency.

Essential Parameters

CONV objects are the simplest objects supported by the radio. However, there are a few essential parameters in the CONV object ﬁelds that must be set correctly. The frequency must be set to match the frequency of the transmitter you want to scan or monitor, and the Modulation (MODE) should be set to Auto (au), AM, FM, or NFM.

Note: When MODE is set for Auto, the scanner will automatically select the default mode based on the frequency you enter. In most cases it will not be necessary to change MODE.

We also recommend labeling your CONV object by giving it a name in the TAG ﬁeld. This makes it easier to ﬁnd the CONV object later and identiﬁes it when the scanner stops to monitor activity.

Creating a CONV Object

1. Press PROG to put scanner in Program Mode.

2. Press NEW softkey to create new object.

3. Press CONV softkey to enter a conventional channel object.

4. Press q to scroll through the conventional channel object parameters until the ﬂashing cursor appears next to the Freq: label.

5. Use the number keys and • to enter the frequency, including the decimal point.

6. Press ENT or the DONE softkey to store the frequency parameter in your conventional object.

Note: Go to www.radioreference.com for up-to-date frequency information.

Changing Text Tags

By default, your new conventional object will be tagged “Channel.” We recommend that you rename your CONV object, making it easier to ﬁnd it later, and identifying it when the scanner stops to monitor activity.

To change the tag:

1. Press

2. Press SEL to edit the tag.

3. Enter the text using the text keys (up to 16 characters).

q until the cursor highlights Tag:.

Creating Scannable Objects31Creating Scannable Objects

• When you press a key, the associated letters appear on the screen. Press the corresponding number. For example, when you press ABC, A, B, and C appear on the display. To select A, press

1. To select B, press 2. To select C, press 3.

• For example, to enter the tag “F IRE”:

Press 3 (DEF), then 3 to choose F Press 4 (GHI), then 3 to choose I Press 7 (PQRS), then 3 to choose R Press 3 (DEF), then 2 to choose E

• To enter a number, press 1, then press the number key.

• To enter lowercase character or second-set character for the 0 key, press the text key and then press FUNC.

• Press t or u to move the cursor to another digit to make adjustments.

• Press CLR to clear text. Press FUNC CLR to clear the entire ﬁeld.

4. Press ENT or the DONE softkey to store new tag information.

See “

Appendix C: Text Entr y and QuickText” on page 115 for more

information on entering text.

Trunking Talkgroup Objects (TGRP)

A Trunking Talkgroup Object (TGRP) is a record that stores the parameters for a trunked talkgroup on a trunked radio system. A TGRP object allows you to scan and monitor a talkgroup on a particular trunked radio system.

Essential Parameters

As a standalone object, a TGRP object is similar to a CONV object. However, for trunking to work, the trunking system (TSYS) and the talkgroup ID must be speciﬁed. We also recommend that you label your TGRP object by giving it a name in the TAG ﬁeld, making it easier to ﬁnd the TGRP object later, and identifying it when the scanner stops to monitor activity.

Trunking System (TSYS) Objects

The ﬁrst time you make a TGRP for a particular trunked radio system, you must also create a TSYS object that contains the system parameters associated with that trunked radio system. Once you create a TSYS, you can use it over and over again without having to re-enter all of the system data.

A TSYS object has its own set of essential parameters, and these parameters vary depending on the type of trunked radio system you plan to monitor. If you are a reasonably experienced user, you probably already know what the essential parameters are for the system you wish to monitor. For example, each TSYS must correctly specify the type of system being monitored, the control channel or LCN frequencies used by the system, and so on. A detailed description of each type of system supported by this radio and the essential parameters required to make them work properly is provided in “Appendix B: Detailed Menu Reference: TSYS Menu” on page

106.

Note: By default all new objects are mapped to “Grouping Objects with Scan Lists” on page 39 for more information on Scan Lists.

To create a new TSYS object.

1. Press

2. Press NEW softkey to create new object.

3. Press TGRP softkey to create a trunking system object.

PROG to put scanner in Program Mode.

Scan List 01. Refer to



> Talkgroup <

Scan Lists: *01 TSYS: NEW Save Exit Dflt

Creating Scannable Objects33Creating Scannable Objects

4. Press p or q to scroll through the talkgroup object parameters until the cursor is at TSYS: .

5. Press SEL.



> Trunked System <

Type: MOT 800/900 Tag: System Save Exit Dflt

6. The cursor should be on TYPE: .

7. Press t or u to select the desired trunking system.

8. Press q to scroll to Tag: and enter a new name for the system. See “Appendix C: Text Entry and QuickText”Appendix C: Text Entr y and QuickText” on page 115 for information on entering text.

9. Press q to scroll to Freque ncies: to enter the control frequencies for the system.

10. Press SEL.

11. At Ch01:, use the number keys and • to enter the ﬁrst control channel frequency for the system.

12. Press q and repeat Step 11 to add any other control channels used by the system.

13. Press the SAVE softkey to save.

14. Press SAVE softkey again to store the new TSYS into memory and return to the TGRP menu.



Scan Lists: *01 TSYS: System ID: Wildcard Save Exit Dflt

15. Press q to scroll to ID:.

By default, the trunking talkgroup ID is set to Wildcard .

To change the ID, press the number keys to enter the speciﬁc

talkgroup ID. Press ENT or DONE softkey to store the ID.

See “Talkgroup Notes” below for more information about wildcard

and other talkgroup conﬁgurations.

16. Press q to scroll down to Tag: and enter a name for your talkgroup that corresponds with its purpose on the trunked radio system. See “Appendix C: Text Entry and QuickText”Appendix C: Text Entr y and QuickText” on page 115 for information on entering text.

17. Press ENT or the DONE softkey to store the name, then press

SAVE softkey to store the TGRP as a new object.

Refer to “Appendix B: Detailed Menu Reference: TSYS Menu” on page 106 for more parameters that can be customized for your system.

Talkgroup Notes:

• A talkgroup object may be conﬁgured in one of four different ways to monitor trafﬁc on a trunked radio system.

Wildcard Talkgroup: will monitor all talkgroup call radio trafﬁc

on the desired trunked radio system. (Press Dflt in the ID : ﬁeld to use Wildc ard for TGRP object.)

Talkgroup with TGID: will only monitor talkgroup call radio trafﬁc

on the speciﬁed TGID. (Enter the desired talkgroup in the ID: ﬁeld of the TGRP object to scan a speciﬁed ID.)

Wildcard Private Call: will monitor all private call radio trafﬁc on

the desired trunked radio system. (Press Dflt in the TG ID ﬁeld to get Wildc ard, and set the Type ﬁeld to Private .)

Private Call with ID: will only monitor private call radio trafﬁc on

the speciﬁed TGID. (Enter the desired Radio ID in the TGID ﬁeld, and set the Type ﬁeld to P rivate. )

Creating Scannable Objects

Scanning

Wildcard Talkgroup Notes:

• Wildcard is a special type of TGRP object that allows you to

monitor all talkgroup call trafﬁc on the associated trunked radio system.

• Wildcard TGRP objects allow you to quickly ﬁnd and store new or unknown talkgroups on a trunked radio system.

• When a Wildcard TGRP object is mapped to an active Scan List and scanned, all talkgroup trafﬁc on the system is monitored, and you have the option to save or lock out new talkgroups as they appear.

• Wildcard objects are easier to ﬁnd and change later if you include an abbreviated name for the system in the tag ﬁeld.

• TGRP objects are also used to receive Private/Individual Calls on trunking systems that support these call types.

Duplicate (DUPE)

Duplicate (DUPE) is useful when entering multiple TGRP objects that are hosted on the same trunked radio system, or multiple CONV objects that have similar parameters or tag names.

1. Press PROG.

2. Press p or q to scroll to the object that you wish to duplicate.

3. Press the EDIT softkey, then press the DU PE softkey.

An exact copy of the object you selected is created, and the

scanner displays the newly created object menu so you can change the parameters that need to be changed. Be sure to change the tag name before saving your new object.

4. Press the SAVE softkey to save the new object.

Note: As soon as you press DUPE, a duplicate of the selected object is created and saved in memory. Be sure to delete any objects that you create accidentally. See “Deleting Objects” on page 44.

Basic Scanning Operation

Before the scanner can begin to scan, you must have created scannable objects. Your scanner will scan any scannable objects that are members of enabled Scan Lists and are not locked out.

1. Press SCAN to start scanning.

Flashing T indicates scanner is receiving control channel data from a trunked radio system



>> Scanning <<

Scan lists 1 to 10 Scan lists 11 to 20

2. Press PAUSE to pause scanner on an active object in scan mode.

Press SCAN or PAUSE to resume scan.

1 ................ Pri

.....................

Wildcard Scanning

A Wildcard TGRP object allows you to receive all radio trafﬁc on a trunked radio system. It works by catching talkgroup calls on the system that are not already stored as objects in the radio’s memory.

In order for the Wildcard TGRP to function properly, the radio needs to be in SCAN Mode. This is what enables the scanner to ﬁnd the previously stored TGRP objects that need to be checked before declaring that the found talkgroup is new and should be scanned as a Wildcard “hit.”

If you park on a Wildcard TGRP object in Manual Mode, the scanner is not able to “see” the previously stored TGRP objects, and every call on the trunked radio system will come up as a wildcard hit.

Scanning

Manual Mode

In Manual Mode, you can browse through the stored objects in your scanner and select an object to monitor.

1. Press MAN during scanning to enter Manual Mode.

2. Press p or q to scroll through the objects assigned to the current Scan List.

3. Press t or u to browse up and down through the Scan Lists.

Only Scan Lists that contain objects are shown when browsing. A quick low-high wrap beep sounds when the scanner reaches the last occupied Scan List and wraps back to the beginning.

The following screen appears when the scanner conventional channel while scanning.

is stopped on a

The following screen appears when the scanner is stopped on a talkgroup channel while scanning.

Organizing Objects

Object Numbering

Your PRO-197 is different from other types of scanners in how it stores your Scannable Objects in memory. Instead of ﬁxed channels and banks, objects are stored in the ﬁrst available block of free memory and an Object ID is assigned. The Object ID is the “address” where the object is stored in memory.

The Object ID and the current Scan List number are displayed whenever an object is selected in Manual Mode and Program Mode. The Object ID is also displayed when the scanner stops on an active object while scanning.

Scan List

Object ID

10-034 8 CON V pID FM 155.9 5000 FIRE CT:12 7.3

For example: 10-0348 means Object ID 0348 is mapped to Scan List 10.

To directly access an object using Object ID:

1. Press

2. Use the number keys to enter the Object ID, then press ENT.

Note: Objects are not really “in” a Scan List. Objects are “mapped” to Scan Lists, meaning that an object can be a member of one or more Scan Lists. Using the p or q keys to scroll up or down while viewing a Scan List, will show all the other objects mapped to that list.

MAN or PROG to enter Manual Mode or Program Mode.

Grouping Objects with Scan Lists

By default, new objects are automatically assigned to Scan List 01. You can divide these objects into separate Scan Lists so that you can easily enable or disable groups of objects depending on what you want to scan.

The number of objects that can be grouped in a Scan List is limited only by the scanner’s memory, and single objects can be members of multiple Scan Lists.

There are 20 regular Scan Lists available, a special “FAV” Scan List for one-button access to your favorite Scannable Objects, and a Skywarn Scan List.

You can also mix and match different object types in Scan Lists as you see ﬁt. There are no limitations as to the type of objects that can exist together in the same Scan List.

How you group objects in Scan Lists is entirely up to you. Here are some examples of how objects can be grouped:

Geographically: You may wish to group your Scannable Objects according to the areas where they are used. This may be useful if you use your scanner while traveling.

By trunking system: It is possible to assign any combination of object types to any Scan List. However, you may wish to assign TGRP objects associated with speciﬁc trunked radio systems to speciﬁc Scan Lists, so you can easily enable or disable monitoring of each system by enabling or disabling the associated Scan List.

By object type: It may be desirable to segregate object types by assigning them to speciﬁc Scan Lists. For example, if you assign a group of LMIT or SRVC searches to a single Scan List, you can easily activate or deactivate searching on those objects by enabling or disabling the associated Scan List.

Organizing Objects

By application: You can group objects by their application. For example, you may wish to place law enforcement related objects for your area in one Scan List, ﬁre and rescue objects in another, and business related objects in yet another Scan List.

By Favorites: The Favorites (FAV) Scan List is a powerful tool that can be used to quickly narrow (or expand) your scanning proﬁle. When you press the FAV key, the radio suspends scanning of all objects in the radio except for those that are mapped to the FAV Scan List.

Changing Scan List Membership

New Objects

1. Press PROG to put scanner in Program Mode.

2. Press NEW softkey to create new object.

3. Press the softkey for the object you want to create.

4. Press p or q to scroll to Scan L ists:.

5. Press t or u to scroll the Scan Lists until you ﬁnd the one you want to enable or disable.

6. Press SEL to select between On or Off. The asterisk (*) next to the Scan List number indicates that the object is a member of that Scan List.

7. Press Save softkey to save the new object.

Existing Objects.

1. Press PROG to put scanner in Program Mode.

2. Press p, q, t or u to scroll to the object you want to change.

3. Press EDIT softkey.

4. Press CURR softkey to edit the current object.

5. Scroll down to Scan Lis ts :

6. Press u to scroll through the Scan Lists.

7. Press SEL to select On or Off for the desired scan list item. The asterisk (*) next to the Scan List number indicates that the object is a member of that Scan List.

8. Press Save softkey to save your changes.

Naming Scan Lists

1. Press PROG to put scanner in Program Mode.

2. Press GLOB softkey.

3. Press p or q to scroll to Scan L ists:.

4. Press SEL.

5. Press u to edit the settings for the selected Scan List.

6. Press p or q to scroll to Tag:, then press u.

7. Use the number keys to enter a name. See “Appendix C: Text EntryAppendix C: Text Entr y and QuickText” on page 115 for information on entering text.

8. Press Done softkey when ﬁnished.

9. Press Save softkey to save changes to the Global menu.

Enabling or Disabling Scan Lists

While Scanning

Scan List 1-10

Press the number keys that corresponds with the Scan List you want to select.

For example, pressing 4 while scanning will toggle the state of Scan List 04 from enabled to disabled, or vice versa if the Scan List is already disabled.

Organizing Objects

Scan List 11-20

Press FUNC, then press a number key, i.e., press FUNC 3 to toggle the status of Scan List 13.

Note: If you enable a Scan List that has no assigned objects, the number for that Scan List will ﬂash in the display while the scanner is scanning.

From Global Settings Menu

1. Press PROG to enter Program Mode.

2. Press GLOB softkey.

3. Press p or q to scroll to Scan L ists: and press SEL.

4. Press p or q to scroll to the Scan List you wish to change then press SEL.

5. Press u to scroll to Enable d: and press t or u to select On or Off.

The asterisk (*) indicates Scan List enabled.

6. Press the Save softkey to save settings.

7. Press Save softkey again to conﬁrm global changes and exit GLOB menu.

NS (Not Scanned) Scan List

If you accidently store an object with no Scan List mappings, the object will be placed in a special “NS” Scan List.

To access NS scan List:

1. Press

2. Press t or u to scroll to the NS Scan List.

3. Press p or q to scroll through the NS objects.

PROG to enter Program Mode or press MAN to enter

Manual Mode.

4. Press

5. Press EDIT softkey.

6. Press CURR softkey to view object menu.

7. Scroll down to Scan Lis ts :

8. Press u to scroll through the Scan Lists.

9. Press SEL to select On or Off the desired scan list item. The

PROG.

asterisk (*) next to the Scan List number indicates that the object is a member of that Scan List.

Favorite List

To add an object to Favorites:

In scan mode, Manual mode or Program mode, press FUNC, then FAV.

Each scannable object menu also has a FAV option. Select YE S to add to Favorites.

When FAV is set to YE S, the object is a member of the Favorites Scan List in addition to any other Scan Lists that it is mapped to.

To activate FAV scan:

Press FAV and the radio suspends scanning of all objects in the radio except for those that are in your Favorites list.

To clear FAV scan list:

1. Press

2. Press the GLOB softkey.

3. Press p or q to scroll to Clear FAV:.

4. Press SEL to set FAV = NO for all objects.

5. Press YES softkey to conﬁrm.

6. Press Save softkey.

PROG to enter Program Mode.

Organizing Objects

Setting the Default Scan List

By default, your scanner will store all new objects, and objects found during Search, Tune, and Stalker as mapped to Scan List 01.

You can easily change the default Scan List to any Scan List you specify, including the special FAV and Skywarn Scan Lists.

1. Press PROG.

2. Press GLOB softkey.

3. Press q to scroll down to Dflt ScanList.

4. Enter new Scan List number to use as default scan list.

0: The “not scanned” (ns) Scan List. Objects with no Scan List

mapping.

1 - 20 : Normal Scan Lists

21: FAV Scan List

22: Skywarn Scan List.

5. Press ENT or the Done softkey to store your new default Scan List value.

6. Press SAVE softkey to save your changes.

Deleting Objects

To delete an object:

1. Press

2. Press p, q, t or u to navigate to the object you wish to delete.

3. Press FUNC CLR to delete the object.

The scanner will ask you to conﬁrm the delete command before

PROG to enter Program Mode.

removing the object from the scanner’s memory. Deletions cannot be un-done.

To delete a TSYS using the FIND feature:

1. See “Searching for Objects using FIND” below.

2. Once the TSYS has been located, press the PROG key, then press FUNC CLR.

3. Press the YES softkey at both warnings to delete the TSYS.

WARNING: All TGRPs associated with the deleted TSYS will be lost.

To delete a TSYS using the TSYS ﬁlter.

1. Press PROG to enter Program Mode.

2. Press the EDIT softkey.

3. Press u u u, and press the TSYS softkey.

4. Press p or q to scroll to the desired TSYS, then press FUNC CLR.

5. Press the YES softkey at both delete warnings to delete the TSYS.

WARNING: All TGRPs associated with the deleted TSYS will be lost.

Searching for Objects using FIND

The FIND feature allows you to search for locked out objects, or for objects containing a text string that you specify. FIND searches for your speciﬁed text in the following places:

• TGRP objects: ID and Tag ﬁelds.

• CONV objects: Frequency and Tag ﬁelds.

• TSYS, LMIT, SRVC and STLK objects: Tag ﬁeld

To ﬁnd locked out objects:

1. Press

2. Press EDIT softkey.

PROG to enter Program Mode.

Organizing Objects

3. Press FIND softkey.

4. Press L/Out softkey. The scanner ﬁnds the ﬁrst locked out object.

5. Press L/Out to toggle lockout status.

6. Press EXIT softkey when ﬁnished.

or Press ED IT softkey to edit object menu for the selected object.

or Press NEXT softkey to ﬁnd the next locked out object.

or Press MAN to begin monitoring the object in Manual Mode.

or Press PROG to exit FIND and execute programming tasks at the

selected object position.

To ﬁnd objects with a speciﬁed text string:

1. Press

2. Press EDIT softkey.

3. Press FIND softkey.

4. Press Text softkey

5. Use the number keys to enter the text string you wish to search

6. Press OK softkey to begin searching.

The radio will stop on any object where your text string is found

7. Press the Exit softkey to cancel the FIND operation.

or Press ED IT softkey to edit object menu for the selected object.

or Press NEXT softkey to ﬁnd the next object.

PROG to enter Program Mode.

for. Or press the Qtxt softkey to use QuickText in your ﬁnd text screen. See “Appendix C: Text Entry and QuickText”Appendix C: Text Entry and QuickText” on page 115 for information on entering text.

in the frequency, tag, or ID ﬁelds as described above.

or Press MAN to begin monitoring the object in Manual Mode.

or Press PROG to exit FIND and execute programming tasks at the

selected object position.

Note: FIND keeps the last search text you speciﬁed stored for subsequent FIND operations.

Filtering by Object Type

When browsing objects in Program Mode, you can ﬁlter the objects that are displayed by their type.

1. Press the PROG to enter Program Mode.

2. Press EDIT softkey.

3. Press t or u to scroll to display the ﬁlter softkeys. The ﬁlter softkeys are as follows:

CONV

TGRP TSYS SRCH STLK

4. Press the softkey that corresponds with that object type to ﬁlter.

5. Press p, q, t or u to browse ﬁltered objects.

Object Lockout

When an object is locked out, trafﬁc is not received on that object until it is unlocked, even if the object is mapped to more than one Scan List. Locking out an object locks it out “radio-wide” until it is enabled by toggling the lockout setting.

Four types of lockout functions are available: temporary lockout, permanent lockout, search lockout, and talkgroup lockout.

Organizing Objects

Temporary Lockout

Temporary lockout locks out an object until the scanner is turned off. When the scanner is powered on again, all objects that have been temporarily locked out are restored.

To temporarily lockout an object:

1. When the scanner stops on an object,

1. In Manual Mode or Program Mode, press p, q, t or u to select an object.

2. Press L/OUT.

The lowercase “l” in the display ﬂashes to indicate the object is temporary lockout.

To unlock a temporary lockout object:

1. In Manual Mode or Program Mode, press p, q, t or u to select an object.

2. Press L/OUT.

HINT: You can also toggle lockout anytime you are viewing an object menu in Program Mode by pressing L/OUT.

press L/OUT.

Permanent Lockout

Permanent lockout locks out an object until you explicitly unlock it. No trafﬁc will be received on the locked out object while permanent lockout is active.

1. When the scanner stops on an object, press FUNC, then L/OUT.

1. In Manual Mode or Program Mode, press p, q, t or u to select an object.

2. Press FUNC, then L/OUT.

To unlock a permanent lockout:

1. In Manual Mode or Program Mode, press p, q, t or u to select an object.

2. Press FUNC, then L/OUT.

Change L/OUT Key Function

By default, the L/OUT key activates temporary lockout when pressed. To change the L/OUT key to activate a permanent lockout when pressed:

1. Press PROG to enter Program Mode.

2. Press GLOB softkey.

3. Press p or q to scroll to TLO=FU NC L/O: .

4. Press u and select YES to change the L/OUT button to be a permanent lockout instead of a temporary lockout.

Search Lockout

Search lockout works with certain search objects, including LMIT searches, some SRVC searches, and STLK objects. Frequency lockout is used to lock out undesired frequencies that are found during searches.

To apply search lockout during a search:

When scanner stops on the undesired frequency, press the FrL/ O softkey.

To edit or clear the search lockout list:

1. Press

2. Press GLOB softkey.

3. Scroll down to SRCH L/O ut s: and press SEL.

4. Scroll to the frequencies you wish to remove from the lockout list

PROG.

and press Del softkey to remove them from the list.

Organizing Objects

Object Searches

5. Scroll to an empty spot and enter any frequency you wish to manually add to the list.

6. To clear the entire list, press FUNC, then the Del softkey.

Talkgroup Lockout

Talkgroup lockout is similar to search lockout, as it allows you to lockout undesired talkgroups while searching for new talkgroup activity with wildcard TGRP objects.

When you lock out an undesired talkgroup that is found by a Wildcard TGRP object, the radio creates a new TGRP object in the radio’s memory, then locks that TGRP object out, so that the next time it appears on the system, the radio will ignore any trafﬁc on that TGRP.

To lockout an undesired wildcard hit:

When the scanner stops on an undesired talkgroup, press the TGL/O softkey.

To unlock or edit talkgroups locked out using the wildcard lockout feature:

1. Press

2. Press p, q, t or u to select a locked out talkgroup.

3. Press FUNC, then L/OUT to remove permanent lockout from the

or Press FUNC, then CLR to delete the TGRP object from the

or Press the ED IT, then the CURR softkey to edit and save the TGRP

PROG to enter Program Mode.

talkgroup.

scanner.

object.

Object Searches

A powerful feature of your PRO-197 is the ability to of frequency searches and process them while scanning. Frequency searches are just another type of Scannable Object in the of the radio’s memory organization, so they can be manipulated and scanned in the same manner talkgroups.

as conventional channels and trunking

Limit Search Object (LMIT)

A Limit Search Object (LMIT) is a search object that stores the parameters necessary for the radio to search each frequency within a lower and an upper limit for activity. A LMIT object can be used for standalone searching—the radio just searches and stops when activity is detected on a frequency, or for searching that is performed while the radio is scanning. The radio treats LMIT objects just like any other Scannable Object when in Scan Mode.

When used in Scan Mode, this capability is best suited for small ranges of frequencies that contain more frequencies than practical to program as individual channels. Any size range can be used, but larger ranges that take more time to search will increase the chances of missed activity on other object types.

Essential Parameters

FrLo: Lower frequency limits to begin search

FrHi: Upper frequency limits to end search

Mode: By default the scanner will automatically choose the receive

mode that most likely applies to the active frequency as the search proceeds.

Tag: (Recommended) Name your LMIT so you can easily ﬁnd or

identify it later.

deﬁne different types

hierarchy

Object Searches

See “Appendix B: Detailed Menu Reference: LMIT Menu” on page 108 for detailed menu information.

To create a new LMIT object:

1. Press

2. Press NEW softkey.

3. Press SRCH softkey to view available Search types.

4. Press LMIT softkey.

5. Press p or q to select FrLo : and F rH i: then press SEL to

6. Use the number keys and • to enter lower and upper search

7. Press p or q to select Tag:.

8. Use the number keys to enter a name for the LMIT object. See

9. Press ENT or the DONE softkey to save.

10. Press Save softkey to store your LMIT search as an object.

PROG for Program Mode.

select the ﬁeld.

units and press ENT or the DONE softkey to save.

“Appendix C: Text Entry and QuickText”Appendix C: Text Entr y and QuickText” on page 115 for information on entering text.

3. Press PAUSE to hold on the active frequency. Press PAUSE again to resume.

Note: It can take some time to process all of the frequencies in a LMIT search. You can experiment with different size frequency ranges to ﬁnd a LMIT search setup that does not interfere excessively with scanning of other object types.

To activate LMIT search:

1. Press

2. Press p or q to scroll through the LMIT objects.

3. Press the SRCH softkey. LMIT search will stop on an active

Note: Be sure to press the SRCH softkey, and not the SRCH key on the keypad.

MAN during scanning to enter Manual Mode.

frequency.

Service Search Object (SRVC)

A Service Search Object (SRVC) is similar to a LMIT search but is optimized for a speciﬁc radio service, and can search for activity associated with a type of service across multiple frequency bands. See “Dedicated SRVC Search” on page 58 or “Appendix A: Search Bands” on page 94 for Service Band frequency information.

Essential Parameters

Service type is the critical parameter needed for a Service Search to function. See “Appendix B: Detailed Menu Reference: SRVC Menu” on page 110 for detailed menu information.

Object Searches

To create a new SRVC object

1. Press

2. Press NEW softkey, then press SRCH softkey to view the available

3. Press the SRVC softkey.

4. Press q to scroll to the Srvc: ﬁeld.

5. Press t or u to select the type of search you want to deﬁne.

6. Press Save softkey to store your SRVC search as an object.

To activate SRVC search:

1. Press

2. Press p or q to scroll through the objects to SRVC.

3. Press the SRCH softkey to activate the SRVC search. SRVC search

PROG for Program Mode.

Search types.

Service types include Public Safety, Aircraft, Amateur, CB, Marine, FRS/GMRS/MURS/DOT and Railroad.

MAN during scanning to enter Manual Mode.

stops when an active frequency is found.

frequency lockout list

Signal Stalker II Object (STLK)

A Signal Stalker Object (STLK) stores the parameters necessary for the radio to rapidly sweep a range of frequencies for strong signals from nearby transmitters. A STLK object can be used for standalone operation—the radio just sweeps and stops when activity is detected, or for stalking that is performed while the radio is scanning. During scanning, the radio will check for activity on all the enabled Scannable Objects: TGRP objects, CONV objects, LMIT objects and STLK objects.

Essential Parameters

By default, a newly created STLK object is ready to go without any changes. In its default conﬁguration, the STLK object will sweep through all of the important land mobile radio bands and look for strong signal activity from nearby transmitters. You may wish to include or exclude some bands in your sweeps in order to check other frequency ranges or to limit the amount of time the scanner spends sweeping frequency ranges where local transmitter activity is less likely. See “Appendix B: Detailed Menu Reference: STLK Menu” on page 113 for detailed menu information.

To create a new STLK object:

1. Press

2. Press NEW softkey, then press SRCH softkey to view the available

3. Press STLK softkey.

4. Scroll down to Type: and press u if you want to change

Refer to “Appendix A: Search Bands” on page 94 for sub-band frequencies.

PROG to place your scanner into Program Mode.

Search types.

between All B ands and Pub lic Saf ety.

4. To resume searching, press p.

If you want to include or exclude sub bands:

1. Scroll down to the sub-bands.

Sub-ba nds: and press t or u to scroll through

Object Searches

Dedicated Searches

2. Press SEL to select On or Off. An asterisk (*) indicates the sub band is enabled.

3. Press p or q to select Tag: to name your STLK object.

4. Use the number keys to enter a name. See “Appendix C: Text EntryAppendix C: Text Entr y and QuickText” on page 115 for information on entering text.

5. Press Save softkey to store your STLK search as an object.

To activate STLK search:

1. Press

2. Press p or q to scroll through the objects to STLK.

3. Press the STLK softkey.

MAN during scanning to enter Manual Mode.

Dedicated Searches

Your scanner provides fast access to dedicated frequency search modes that allow you to execute searches or run Signal Stalker II without having to go through the process of setting up and saving a search object. T his is handy for those times where you need to run a search quickly. Dedicated search modes do not create new search objects or use previously created search objects.

The SRCH key provides immediate access to the dedicated search modes. Pressing the SRCH key cycles through each search mode in this order: Limit, Railroad, Public Safety, Aircraft, Ham, CB, Marine, and FRS/GMRS/MURS/DOT.

Dedicated LMIT Search

Your scanner’s dedicated LMIT search mode provides you with the ability to create a limit search with a search frequency range between upper and lower limit frequencies that you specify and perform the limit search directly without creating a new LMIT object. You can then monitor that frequency range for transmissions.

To enter LMIT mode:

1. Press

2. Press the Lmts softkey to set the lower and upper frequency

Note: When a signal is being received, the Lmts softkey (F1) changes to FrL/O . You can access the Lm ts softkey by pressing FUNC F1 when the F1 key function is FrL/O .

3. Press p or q to change the search direction.

SRCH repeatedly until the display indicates LMIT search.

limits for your limit search.

4. Press the MODE softkey to change the receive mode (AM, FM, NFM) from the default for the current frequency range (auto).

Dedicated Searches

5. Press the FrL/O softkey to add a found frequency to the lockout list.

6. Press the STOR softkey to create a new CONV object using the found frequency.

Dedicated SRVC Search

Your scanner’s dedicated SRVC search modes provide you with the ability to instantly access each of the scanner’s service search ranges without creating a new SRVC object.

To activate dedicated SRVC search mode:

1. Press

• Railroad: Searches the Association of American Railroads (AAR)

• Public Safety (PubSafety): Searches commonly used public

SRCH repeatedly until the desired service search is indicated on the display. The following service searches are available:

VHF railroad frequencies used in the US and Canada

safety frequencies.

Freq. (MHz) Band

0 33.4-46.5 VHF Low Band

1 151-170 VHF High Band

2 453-467 UHF Band

3 764-806 700 MHz Band

4 851-869 800 MHz Band

• Aircraft - Searches civilian and military air frequencies.

Freq. (MHz) Band

0 108-118 Navigation

1 118-137 Civilian Voice

2 138-150 Military Voice

(excludes 2m Amateur)

3 225-400 Military Voice

• Ham - Searches amateur radio frequencies.

Freq. (MHz) Band

0 28.0-29.7 10m Band

1 50-54 6m Band

2 144-148 2m Band

3 222-225 1.25cm Band

4 420-450 70cm Band

5 902-928 33cm Band

6 1240-1300 23cm Band

• CB - Searches the citizen’s band radio frequencies.

• Marine - Searches the VHF-FM marine radio band.

• FRS/GMRS/MURS/DOT/STAR (F/G/MURS) Searches the FRS, GMRS, MURS, DOT and STAR radio frequencies.

2. Use the numeric keypad to toggle the sub bands on and off while searching.

3. Press p or q to change the search direction.

4. Press the FrL/O softkey to add a found frequency to the lockout list.

5. Press the STOR softkey to create a new CONV object using the found frequency.

Dedicated Searches

Dedicated Signal Stalker II

Dedicated STLK mode lets you access and run Signal Stalker II easily and quickly.

In Manual, Program or Scan mode, press FUNC SCAN to access the Signal Stalker II dedicated mode.

Note: When a signal is being received, the Band softkey (F1) changes to FrL/ O. You can access the Band softkey by pressing FUNC F1 when the F1 key function is FrL/O .

Operation of the dedicated Signal Stalker II mode is almost identical to that of the object mode, with one exception. When dedicated Signal Stalker II mode is used, you may press the numeric key on the keypad that corresponds with the sub-band you wish to enable or disable. Disabling a sub-band will cause the Signal Stalker II system to skip the frequencies within that sub-band as it performs its sweeps.

Signal Stalker II sub-bands:

Freq. (MHz) Band

0 25-54 MHz VHF Low Band

1 108-137 VHF Aircraft Band

2 137-174 MHz VHF High Band

3 216-300 220 MHz Commercial/

Amateur Band

4 300-406 UHF Military Air Band

5 406-470 UHF Band

6 470-512 UHF-T Band

7 764-806 700 MHz Band

8 806-869 800 MHz Band

9 896-1300 MHz 900 MHz Band, 23 cm

Amateur Band

Public Safety sub bands:

Freq. (MHz) Band

0 33.4-46.5 VHF Low Band

1 151-170 VHF High Band

2 453-467 UHF Band

3 764-806 700 MHz Band

4 851-869 800 MHz Band

Dedicated TUNE Search

Your scanner’s dedicated TUNE mode provides you with the ability to quickly enter any frequency and monitor that frequency for transmissions, or search up or down from that frequency for activity.

1. To enter TUNE

TUNE

screen.

mode, press TUNE. The scanner displays the

Dedicated Searches

By default,

TUNE

mode is paused when ﬁrst activated.

2. Press PAUSE to begin searching from the current frequency.

3. Press p or q to change the search direction.

or Press FrL/O softkey to add a found frequency to the lockout list.

or Press the MO DE softkey to change the receive mode (AM, FM,

NFM) from the default for the current frequency range (au).

or Press STOR to create a new CONV object using the found

frequency.

or Use the keypad to enter a new frequency, and press ENT to

make that the

TUNE

frequency.

Notes:

• Using FUNC TUNE from any other mode will load the last active frequency from the other mode into

TUNE

. For example, pressing FUNC TUNE while parked on a trunked radio TGRP will load the control channel frequency into the

TUNE

mode if the control channel frequency is the last frequency that the scanner checked while scanning.

• Dedicated

TUNE

mode will always check for the presence of encoded squelch and digital modulation each time it ﬁnds an active frequency. If a valid encoded squelch code is found, it will be shown on the display, and stored automatically when you press STOR to create a new CONV object.

• Dedicated

TUNE

mode also displays information about trunking control channels and trunked voice channels it ﬁnds while tuning through the RF spectrum.

The following information is displayed for each trunking mode:

Trunked Mode Analysis Display

Motorola 3600 baud control channel

P25 9600 BPS control channel

EDACS control channel

LTR home repeater

Motorola analog voice channel

qq% SID :ssss S tt

qq = decoding quality of the control channel data, SID = System ID, and S = Site Number

qq% Nnn n W:www ww Sys:s ss Rrr Stt

qq = decoding quality of the control channel data, N = NAC, W = WACN, SYS = System ID, R = RFSS, and S = Site Number

qq% S: ss h/H s/S a/A

qq = decoding quality of the control channel data, S = Site ID, h/H = not home site/is home site, s/S = not SCAT site/is SCAT site, a/A = not Aux CC/is Aux CC

HR:hh A–HH–GGG

HR = the home repeater number of the tuned frequency, AHH-GGG = the Area, Home Repeater and Group ID of the LTR talkgroup

VC: l sTGID–nn nnn

lsTGID = the decoded talkgroup ID data from the lowspeed data stream Note that the analog lowspeed data protocol does not provide error correction, and some false “VC: lsTGID” readings should be expected.

Tune LED

Tune LED can provide visual indication of signal strength using the tri-color LED.

To activate the Tune LED:

1. Press PROG for Program Mode.

2. Press GLOB softkey.

3. Press q to select Tune LED :.

4. Press t or u to select Tune LED on or off .

5. Press the SAVE softkey to save your changes to the radio’s conﬁguration memory.

Weather Scanning

Note: The weather alert feature is an extremely sensitive, high quality receiver of weather frequencies. However, the included antenna is optimized for general purpose scanning. If you use this scanner as your only means for receiving weather alerts, please check to be sure you are receiving a clear signal on the included antenna or switch to an external antenna that gives you clear reception of a local NOAA weather broadcast.

Weather Radio Mode

Weather radio mode allows you to receive weather broadcasts from your local weather service.

To use weather radio mode:

1. Press

2. Press p or q to look for other weather radio transmitters.

It is generally best to select the weather radio transmitter that

While operating in Weather Radio Mode, your scanner will alert

Weather Priority Mode

Weather Priority mode samples the speciﬁed weather frequency periodically while scanning to see if the All Hazards 1050 Hz Warning Alert Tone (WAT) is present. If the WAT is present, the scanner will sound an alarm and tune to the speciﬁed weather frequency to monitor the nature of the alert.

WX. The scanner will quickly scan and lock on to the ﬁrst

active weather radio frequency it receives.

provides you with the strongest signal. You can use the signal meter to help you chose the best weather radio transmitter for your area.

on SAME messages that match the SAME location codes you have entered, or all SAME messages if you do not enter any SAME location codes.

To activate Weather Priority Mode:

1. Press WX.

2. Press p or q to look for other weather radio transmitters and ﬁnd the strongest weather radio transmitter for your location.

3. Press PRI.

SAME Standby Mode

SAME Standby Mode monitors the speciﬁed weather frequency silently, waiting to receive a Speciﬁc Area Message Encoding (SAME) alert that corresponds with a SAME location code that you have previously entered. If there is a match, the scanner will sound an alarm, display the alert type, and monitor the nature of the alert.

To activate SAME Standby Mode, ﬁrst you should provide at least one SAME location code for your city, county or state. By default, SAME mode will alert on any SAME message received if no SAME location codes are entered.

SAME alerts include FIPS codes to identify areas, established by the US Census bureau. You can set your scanner to alert for all areas or limit weather alerts to up to 10 speciﬁc areas by FIPS code. A list of SAME location codes can be found online at: www.weather.gov.

FIPS codes are formatted as follows:

Subdivisions State Code County Code

0-9 (0=entire area)

Example: 048439 (0=All; 48=Texas; 439=Tarrant County)

In addition to the code for your location, you may wish to enter additional codes for surrounding areas and any other areas of interest so that you can receive advance warning of adverse or dangerous weather that may be headed in your direction.

01-50 (00=all states)

XXX (000=all counties)

Weather Scanning

Your scanner also has a SAME wildcard feature, which allows you to set the radio to alarm on partial matches of the location code.

To enter SAME Location and Event Codes

1. Press

2. Press the SAME softkey to add or edit SAME entries.

3. Press p or q to scroll to the desired SAME code entry.

4. Press SEL to edit the selected SAME entry.

5. With the En try: ﬁeld selected, press u to turn the entry on.

Note: When a SAME location/event code storage location is set for Entry ON, the radio will process the SAME location and event code that is stored there. When a storage location is set for Entry

OFF, that SAME location and event code will be ignored.

6. Scroll to Code: and press u to enter a SAME location code.

7. Press the number keys to enter a SAME code.

Note: The PRO-197 supports entry of Extended SAME codes, which can include numbers and letters. The text entry mode is used to enter both numerical SAME codes and extended SAME codes. To enter a numerical SAME code, simply precede each number in the SAME code with “1”. For example, to enter SAME code 048113, press 10 14 18 11 11 13.

8. Scroll to the Event: ﬁeld. Note the current default of ***,

9. Scroll to Tag: and press u.

10. Input a tag name that corresponds with the SAME location

WX to enter Weather mode.

which will allow all messages for the speciﬁed SAME location code. We recommend that you leave the event code with *** to receive all alerts. A list of event codes can be found at www.weather.gov.

code that you have entered. See “Appendix C: Text Entry andAppendix C: Text Entr y and QuickText” on page 115 for information on entering text.

11. Scroll to SAME entry. We recommend that you use the default setting here for general purpose weather alerting.

12. Scroll to Lockou t:. Default is off. Lockout is a special purpose parameter that can be used to lock out individual event or area codes. We recommend that you leave Lockou t set to off for general purpose weather alerting.

13. When you have ﬁnished editing your SAME entry, press the Save softkey to store the data.

14. Press the Save softkey again to save all SAME changes and return to the Weather mode.

Note: When a SAME location/event code storage location is set for Entry ON and Lock out ON, the radio will process the SAME location/event code that is stored there, and will lock out the speciﬁed event code. A SAME location/event code storage location set for Entry : OFF and L ockout: ON will not be processed, because Entry is set to OFF. In case of a conﬂict (i.e., two identical codes and events are entered, and one is locked out), the locked out entry will take precedence.

To reset SAME code to the default setting:

1. Press

2. Press SAME softkey.

3. Press p or q to select SAME code location.

4. Press SEL.

5. Press q to select code, then press Dflt softkey.

6. Press Save softkey to save the code.

7. Press Save softkey again to save changes.

Alarm :. You can specify different alarm sounds for this

WX.

Weather Scanning

Scanner Memory

Activating SAME Standby Mode

After you have entered your desired SAME codes, you can activate the SAME Standby Mode to begin standby operation. The radio will remain silent until a SAME transmission is received with a code that matches one that you have stored. When a matching SAME message is received, your radio will sound a siren alarm, then will play the audio message that follows the Warning Alert Tone (WAT).

To activate SAME standby mode:

1. Press

2. Press p or q to ﬁnd the best weather radio transmitter for your

The softkey will change to STBY to indicate that SAME Standby

3. Press the STBY softkey again to exit SAME Standby Mode, or

When your local NWS ofﬁce activates a SAME warning that matches a FIPS code stored in your scanner, you will ﬁrst hear a siren alarm and see the LED ﬂash to alert you to the incoming alarm. The LED ﬂashes RED for warnings, YELLOW for watches, and BLUE for tests and administrative messages.

The scanner sounds the siren until the NWS transmission of the 1050 Hz Warning Alert Tone (WAT) begins. Once the WAT begins, the scanner’s speaker will unmute, and you will hear the WAT play as an alert that the voice portion of the SAME warning is about to begin. You will then hear the voice portion of the SAME warning.

Your scanner will resume SAME Standby operation 90 seconds after the SAME warning starts. You may reset standby mode by pressing the STBY softkey twice at any time.

WX.

location, then press the stby softkey.

Mode is active, and the scanner will alert when a matching SAME message is received.

press MAN, SCAN, or PROG.

V-Scanner Storage

Your PRO-197 features two types of memory storage:

• Main memory is used to store programming that is used for everyday monitoring and scanning.

• Virtual Scanner (V-Scanner) memory is used to store complete copies of your scanner’s main memory for later recall. VScanner includes objects, global settings, and dedicated search conﬁgurations. Your scanner has 21 V-Scanner storage locations, each capable of storing a copy of your scanner’s main memory, including all of your object and global settings.

You can custom-tailor a main memory conﬁguration to suit your needs for the type of scanning you do in different situations, then store that conﬁguration for later use. If you travel frequently, you may want to create V-Scanners for the areas where you travel.

V-Scanners are also useful for backing up your conﬁgurations. Once you have main memory conﬁgured the way you like it, you can save it to a V-Scanner where it will remain untouched until you delete, overwrite or recall it. Then, if you happen to make a mistake while using your main memory that you cannot ﬁx, you can recall the backup data and start again.

Your PRO-197 Scanner comes preprogrammed with the frequencies, talkgroups, and conﬁguration data for approximately 350 trunked radio systems in the United States. The preprogrammed data is stored in V-Scanner folder storage locations (01-20). The scanner’s working memory and V-Scanner folder “00” are not preprogrammed with any data. See the included “V-Scanner Preprogrammed Data” booklet for more information.

Scanner Memory

Using V-Scanners

You can save active scanner conﬁgurations (called “working” or “main” memory) to a V-Scanner storage folder for later use. Then recall the stored scanner conﬁgurations from a V-Scanner storage folder to main memory when you want to use them.

When you recall a conﬁguration from a V-Scanner storage folder and use it in main memory, any changes you make while using the conﬁguration will not automatically be transferred to the conﬁguration data stored in the V-Scanner storage folder. You must save your changes back to that folder location if you want to preserve them for later use.

When you load a new conﬁguration into main memory, the contents of main memory are overwritten and lost, unless you save your main memory to a V-Scanner storage folder ﬁrst. Once the conﬁguration data in main memory has been overwritten, it cannot be recovered—there is no “Undo” function.

Saving Main Memory to a V-Scanner Folder

1. Press FUNC, then PROG to enter V-Scanner mode.

2. Press the Stor softkey.

3. Press p or q to scroll to the desired V-Scanner folder, then press the Stor softkey.

4. If the selected V-Scanner folder already contains data, you will be asked if you wish to overwrite the existing data with new data from your current version of main memory. Press the YES softkey to proceed, or the NO softkey to cancel.

5. The scanner will prompt you to enter a name for the stored VScanner. Use the standard text entry method to type the name you wish to use, then press the OK softkey.

6. The scanner will write the contents of main memory to the V-Scanner folder. This will take approximately four seconds to complete.

Loading a V-Scanner Folder to Main Memory

1. Press FUNC, then PROG to enter V-Scanner mode.

2. Press the Load softkey.

3. Press p or q to scroll to the desired V-Scanner folder, then press the Load softkey.

4. The scanner will ask you to conﬁrm that you wish to overwrite the current contents of main memory. Press the YES softkey to proceed, or the NO softkey to abort.

The data transfer takes approximately 4 seconds

to complete.

Erasing V-Scanner Folders

1. Press FUNC, then PROG to enter V-Scanner mode.

2. Press the Eras softkey.

3. Press p or q to scroll to the desired V-Scanner folder, then press the Eras softkey.

4. Press the YES softkey to delete current contents, or press the NO softkey to abort.

Cloning

You can transfer the programmed data to and from another PRO-197 (or PRO-106) scanner using a connecting cable which has 1/ stereo phone plugs on both ends (not supplied).

To clone the scanner data:

1. Turn on both scanners.

2. Connect the connecting cable to each scanner’s

3. Press PROG, then the GLOB softkey to enter the Global Settings menu.

PC/IF jack.

-inch

Scanner Memory

Advanced Settings

4. On the SOURCE radio, scroll to Clone Se nd : then press SEL when you are ready to send data from your SOURCE radio to the TARGET radio.

Both working memory and global settings are transferred.

Note: The contents of working memory on the TARGET radio will be overwritten immediately when SEL is pressed on the SOURCE radio.

Memory Report

To display the memory usage report:

1. Press

2. Press GLOB softkey to access the Global menu.

3. Press p or q to scroll to Memory Info:.

4. Press SEL to view the memory usage report.

5. Press p or q to scroll the display.

PROG.

Advanced Settings

Priority Scan

Priority Scan operation is available for CONV and TGRP objects. When Priority Scan is active, increased priority is given to objects that have their Priority mode set to ON.

Turning Object Priority On or Off

When the scanner stops on the object while active, press PRI to select Object Priority on or off.

Browse to an object in Manual Mode or Program Mode. Press PRI to select Object Priority on or off.

1. Browse to an object in Program Mode.

2. Press EDIT, then CURR softkeys.

3. Press q to scroll to Priori ty.

4. Press t or u to select Priority On or Off.

The plD indicator in the object display will show lower case “p” for Object Priority Off, and upper case “P” for Object Priority On.

Turning Priority Scan Mode On or Off

1. While the radio is scanning, press FUNC.

2. Press PRI to toggle Priority Scan On or Off.

Priority Scan status is shown in the main Scanning status display.

PRI indicates that Priority Scan mode is on, and pr i indicates that

Priority Scan mode is off.

Advanced Settings

CONV Priority Scan

When Object Priority is set to Yes for one or more CONV objects, the scanner will sample the CONV objects for activity periodically while scanning and monitoring other objects. This sampling will cause a brief muting of received audio when it occurs while another object is active. The more CONV objects that are set for Priority, the longer this audio muting will be, since it takes a certain amount of time to sample each Priority CONV object for activity.

TGRP Priority Scan

When Object Priority is set to Yes for one or more TGRP objects, the scanner will give those TGRPs priority over other TGRPs while checking a particular trunking system for activity. TGRPs conﬁgured for Priority are checked for activity before any other TGRPs are checked, and during the reply delay time after non-priority TGRP calls.

Additionally, your PRO-197 decodes the subaudible priority data that is present on analog Motorola talkgroup calls (3600 baud control channel systems only), and will switch to a priority talkgroup when the data for that talkgroup is found in the subaudible priority data.

Hit Counters

The Hit Counter feature that keeps track of how many transmissions are received for each object type. The Hit Counter for an object is incremented each time a transmission is received on an object, making it possible for you to determine the objects that are the least and most active. By default, the Hit Counter feature is turned off.

To turn the Hit Counter on:

1. Press

2. Press GLOB softkey.

PROG.

4. Press t or u to select Yes or No.

5. When ﬁnished, press the SAVE softkey to save your changes to the radio’s conﬁguration memory.

To view Hit Counts:

1. Press

2. Press p, q, t or u to navigate to the desired object, if

3. Press EDIT softkey, then CURR softkey.

4. Scroll to Hit Coun t in the object menu to view the hit counter.

To reset for a single object:

1. Press the

To clear all hit counters:

1. Press the

2. Press GLOB softkey.

3. Press q to scroll to Clear Hits.

4. Press SEL.

5. Press the SAVE softkey to save your changes and exit the Global

PROG.

necessary.

Dflt softkey while the Hit Count item is selected in the

object’s menu.

PROG to enter Program Mode.

settings menu.

Audible Alarms and the Alert LED

Your PRO-197 features an Alert LED with audible alarm capability that allows you to set different visual and audible notiﬁcations for the different types of objects you create.

3. Press q to scroll to Hit Co unts.

Advanced Settings

The menus for each type of object include various settings for LED, Backlight and Alarm. You can use these settings to design custom visual and/or audible alarms that are triggered when activity is detected on the speciﬁed Scannable Object.

Notes:

• The Alert LED utilizes a special tri-color Light Emitting Diode module that mixes light from red, green and blue LED elements to produce thousands of different colors. Eight pre-deﬁned color settings are available for use in object menus. LED COLOR: 0 is normally used for “all colors off” or no Alert LED display.

• Slight variations to LED colors are a normal part of the manufacturing process. You may notice these variations when using the White LED color setting (LED COLOR: 7), or when comparing one PRO-197 to another. You can compensate for these slight variations by ﬁne-tuning the Red/Green/Blue (RGB) LED settings for each color. See the COLOR settings in the GLOB menu in “Appendix B: Detailed Menu Reference: GLOB Menu” on page 96.

To set the Audible Alarm and Alert LED:

In any object menu:

1. Press q to scroll to any of the following settings.

• LED Mode : Solid or Flash controls whether the LED remains on

solid or ﬂashes when the object is active.

• LE D Color : 0-7 sets the color of the LED. By default, color 0 is used for LED off. You can change the preprogrammed LED colors in the Global Settings menu.

• La tch LED Keeps the LED on after activity on the object is ﬁnished. This is useful when you need to know if an object was active while you were away from the scanner.

• Ba cklight : Off, On, Flash controls whether the backlight remains off, comes on solid or ﬂashes when the object is active.

• Al arm: None, Chirp, Hi-Lo, Alert, Ring, 2-Chirp, Fast Hi-Lo, DTMF # are used to set audible alarms that play each time activity is found on the object.

2. Press t or u to select the desired option.

3. When ﬁnished, press SAVE softkey to save your changes to the radio’s conﬁguration memory.

Multi-Site Mode on Networked Systems

Some Motorola and P25 systems include a large number of sites that are networked together to provide radio coverage to a large geographical area. These types of trunked radio systems are more commonly used for large statewide systems, and for some systems that are used in large, rural counties.

As a system user moves around, or “roams,” in the coverage area of the network, their radio will automatically ﬁnd and use the nearest tower site. these channels is used for control channel data, and the remaining channels are used for voice trafﬁc. As a user moves away from the coverage of one site, the radio will search other control channel frequencies for a better site to use.

Multi-site can be enabled by editing the trunking system (TSYS) parameters for a Motorola or P25 system. Multi-site can be set to Off, Stat (Stationary) or Roam. By default, Multi-site is set to Off.

The ROAM setting is ideal for those times when you are driving around in the service area of a networked trunked radio system, as it allows the radio to ﬁnd and use the best tower sites as you move in and out of the coverage footprints of different sites.

The STAT (stationary) setting is ideal for those times when you are not moving and are within range of more than one tower site, as it will allow you to monitor trafﬁc from any tower that you are within range of.

Each tower site includes a number of channels. One of

Advanced Settings

To activate Multi-site mode on a Motorola or P25 networked system:

1. Press

2. Press p, q, t or u to navigate to a talkgroup on the networked

3. Press EDIT softkey, then CURR softkey.

4. Press p, q to scroll to the TSYS item and press the SEL key to

5. Press t or u to scroll to Multi-Site.

6. Press t or u to select Off, Sta t or R oam.

Off: the scanner will ﬁnd the ﬁrst usable control channel in the

Stat (Stationary): the scanner will track the system using any

Roam: the scanner will attempt to locate and use the best

7. Press SAVE softkey to save your changes to the TSYS parameters.

8. Press SAVE softkey again to use the scanner.

PROG to enter Program Mode.

multi-site system.

edit the TSYS parameters.

control channel list and use it until it is no longer usable.

control channel in the list that is usable.

possible control channel and ignore others, until the control channel is no longer usable, then it will locate a new “best control channel” to use. The scanner will always attempt to lock on to control channels where the decoding quality is greater than the Threshold Hi setting, and will search for new control channels when the decoding quality of a control channel drops below Threshold Lo setting. If no new control channels are available that meet the Threshold Hi criteria, the scanner will seek the best control channel to use, and continue checking periodically for a new control channel that meets the Threshold Hi criteria.

You should experiment with the different Multi-site modes and the threshold settings to ﬁnd a combination that works best for your location.

Notes:

• Multi-site functionality is not available in EDACS or LTR trunking.

• Threshold settings are only available when Multi-Site Roam is selected.

• It may be necessary to change the values used for Threshold Hi and Threshold Low in the TSYS object to optimize Multi-site Roam performance.

LTR Home Repeater AutoMove

LTR Home Repeater AutoMove (AutoMove HRs) takes the guesswork out of programming LTR trunking systems when the home repeater order is not known.

By default, AutoMove HRs is turned off and is controlled in the individual LTR TSYS objects. When AutoMove HRs is turned on, you may enter the LTR system frequencies in any order. Your scanner will automatically move the frequencies to the proper home repeater slots as transmissions are received on the system.

To enable LTR Home Repeater AutoMove:

1. Access the menu for the desired TSYS.

2. Press

3. Press t or u to toggle on or off for the selected TSYS.

4. Press Save softkey to save your changes.

q to scroll to AutoMove H Rs.

Additional Information

Power-On Conﬁguration Key Sequences

Power-on keypress sequences are used as shortcuts to conﬁguration items, like attenuator settings, backlight settings and memory information. Power-on key sequences are also used to place your scanner into ﬁrmware upgrade mode for CPU and DSP ﬁrmware upgrades.

The following table lists the power-on key sequences available in the PRO-197. Unless otherwise speciﬁed, each sequence is invoked by pressing and releasing each key in sequence, one at a time. The ﬁrst key must be pressed while the Welcome/Owner screen is being

displayed:

Key Sequence

1 Shortcut to PROG>GLOB>Sound Mode

2 Shortcut to PROG>GLOB>Key Beeps

3 Displays Boot, CPU and DSP versions

DIM Shortcut to PROG>GLOB>Light Mode

ATT Shortcut to PROG>GLOB>Atten Mode

0, 0 Shortcut to PROG>GLOB>Memory Info

0, 1 Destructive, clears working memory and resets all Global

0, 2 Destructive, resets all Global settings to factory defaults.

0, 5

0, CLR Erases DSP APP Upgrade code, restores factory DSP version

0, PROG Places radio in DSP APP ﬁrmware upgrade mode

Hold PROG while

powering on radio

settings to factory defaults. Does not affect V-Scanners.

Does not affect working memory or V-Scanners.

Destructive, executes EEPROM memory test, then clears working memory and resets all Global settings to factory defaults. Does not affect V-Scanners.

Places radio in CPU ﬁrmware upgrade mode

Function

Power-On Password

Setting a power-on password can prevent anyone other than you from using this scanner.

To set the power-on password

1. Press

2. Press GLOB softkey.

3. Scroll to Set pass wo rd, then press SEL key.

4. The conﬁrmation menu for the power-on password setting

5. Enter the four-character (four-digit) password. You can enter the

Note: You can cancel the entry by pressing Cancl softkey.

To operate your scanner with power-on password:

1. Turn

2. After the Welcome message is displayed, the scanner prompts

3. Enter your password.

4. If you entered the correct password, you will be able to operate

To disable the power-on password

1. Press

2. Press GLOB softkey.

3. Scroll to Set pass wo rd, then press SEL key.

PROG to enter Program Mode.

appears. Press YES softkey.

characters using alphanumeric text entry method. When you have ﬁnished entering characters, press OK softkey to save the entry.

VOLUME clockwise to turn power on.

you to enter the password.

your scanner. If you have entered the wrong password, the scanner will generate error beep. Try entering your password again.

PROG to enter Program Mode.

Additional Information

4. The conﬁrmation menu for the power-on password setting appears. Press NO softkey.

5. Enter 0000 in the password setting menu and press OK softkey.

Note: In the initial password setting menu characters “0000” are always displayed. Enter 0000 while these characters “0000” are displayed

If you forget the password

If you forget your password, you must initialize the scanner to be able to operate it. This operation will result in the clearing of your programmed data and the loss of any custom changes you have made to the radio’s global parameters. See “Initializing the Scanner to

Factory Defaults” on page 92.

Birdie Frequencies

Every scanner has birdie frequencies. Birdies are signals created inside the scanner’s receiver, which may interfere with transmissions on the same frequencies. If you program one of these frequencies, you hear only noise on that frequency. If the interference is not severe, you might be able to turn Sqelch clockwise to omit the birdie.

To ﬁnd the birdies in your scanner, disconnect the antenna and moving it away from the scanner. Make sure that no other nearby radio or TV sets are turned on near the scanner. Use the Tune function and scan every frequency range from its lowest frequency to the highest. Occasionally, the searching will stop as if it had found a signal, often without any sound. This is a birdie. Make a list of all the birdies in your scanner for future reference.

FCC Notice

This equipment has been tested and found to comply with the limits for a scanning receiver, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Scanning Legally

Your scanner covers frequencies used by many different groups including police and ﬁre departments, ambulance services, government agencies, private companies, amateur radio services, military operations, pager services, and wireline (telephone and telegraph) service providers. It is legal to listen to almost every transmission your scanner can receive. However, there are some transmissions you should never intentionally listen to. These include:

• Telephone conversations (cellular, cordless, or other private means of telephone signal transmission)

Additional Information

• Pager transmissions

• Any scrambled or encrypted transmissions

According to the Electronic Communications Privacy Act (ECPA), as amended, you are subject to ﬁnes and possible imprisonment for intentionally listening to, using, or divulging the contents of such a transmission unless you have the consent of a party to the communication (unless such activity is otherwise illegal).

This scanner is designed to prevent reception of illegal transmissions, in compliance with the law which requires that scanners be manufactured in such a way as to not be easily modiﬁable to pick up those transmissions. Do not open your scanner’s case to make any modiﬁcations that could allow it to pick up transmissions that are not legal to listen to. Doing so could subject you to legal penalties.

In some areas, mobile use of this scanner is unlawful or requires a permit. Check the laws in your area. We encourage responsible, legal scanner use.

Care

Your scanner is not waterproof. Do not expose it to rain, moisture, or extreme high humidity. If the scanner gets wet, wipe it dry immediately. Use and store the scanner only in normal temperature environments. Handle the scanner carefully; do not drop it. Keep the scanner away from dust and dirt, and wipe it with a damp cloth occasionally to keep it looking new.

Service and Repair

If your scanner is not performing as it should, take it to your local RadioShack store for assistance. To locate your nearest RadioShack, use the store locator feature on RadioShack’s website (www.radioshack.com), or call 1-800-The Shack (800-843-7422) and follow the menu options. Modifying or tampering with the scanner’s internal components can cause a malfunction and might invalidate its warranty and void your FCC authorization to operate it.

Speciﬁcations

Frequency Coverage

25.000-26.960 MHz ............................................................ (in 10 kHz steps/AM)

26.965-27.405 MHz ............................................................ (in 10 kHz steps/AM)

27.410-29.505 MHz .............................................................. (in 5 kHz steps/AM)

29.510-29.700 MHz ............................................................... (in 5 kHz steps/FM)

29.710-49.830 MHz ............................................................. (in 10 kHz steps/FM)

49.835-54.000 MHz ............................................................... (in 5 kHz steps/FM)

108.000-136.9916 MHz ................................................... (in 8.33 kHz steps/AM)

137.000-137.995 MHz ........................................................... (in 5 kHz steps/FM)

138.000-143.9875 MHz .................................................... (in 12.5 kHz steps/FM)

144.000-147.995 MHz ........................................................... (in 5 kHz steps/FM)

148.000-150.7875 MHz .................................................... (in 12.5 kHz steps/FM)

150.800-150.845 MHz ........................................................... (in 5 kHz steps/FM)

150.8525-154.4975 MHz .................................................... (in 7.5 kHz steps/FM)

154.515-154.640 MHz ........................................................... (in 5 kHz steps/FM)

154.650-156.255 MHz ........................................................ (in 7.5 kHz steps/FM)

156.275-157.450 MHz ......................................................... (in 25 kHz steps/FM)

157.470-161.5725 MHz ...................................................... (in 7.5 kHz steps/FM)

161.600-161.975 MHz ........................................................... (in 5 kHz steps/FM)

162.000-174.000 MHz ...................................................... (in 12.5 kHz steps/FM)

216.0025-219.9975 MHz ....................................................... (in 5 kHz steps/FM)

220.000-224.995 MHz ........................................................... (in 5 kHz steps/FM)

225.000-379.99375 MHz ................................................. (in 6.25 kHz steps/AM)

380.000-419.9875 MHz .................................................... (in 12.5 kHz steps/FM)

420.000-450.000 MHz ........................................................... (in 5 kHz steps/FM)

450.00625-469.99375 MHz .............................................. (in 6.25 kHz steps/FM)

470.000-512.000 MHz ...................................................... (in 12.5 kHz steps/FM)

764.000-805.996875 MHz .............................................. (in 3.125 kHz steps/FM)

806.000-823.9875 MHz .................................................... (in 12.5 kHz steps/FM)

849.000-868.9875 MHz .................................................... (in 12.5 kHz steps/FM)

894.000-939.9875 MHz .................................................... (in 12.5 kHz steps/FM)

Additional Information

940.000-960.000 MHz ...................................................... (in 6.25 kHz steps/FM)

1240.000-1300.000 MHz .................................................. (in 6.25 kHz steps/FM)

*Excludes frequencies utilized by the Cellular Mobile Radiotelephone Service: 824-848.9875 MHz and 869-893.9875 MHz

Working Memory

1800 programmed objects using ﬂexible “Scannable Object” system. Program and scan conventional channels, trunking talkgroups, limit searches, service searches, and Signal Stalker II conﬁgurations as “Scannable Objects” that are created, edited, grouped and scanned using common user interface conventions.

Virtual Scanners

21 Virtual Scanner (V-Scanner) folders, each capable of holding the entire contents of working memory, for a total storage capacity of over 37,800 objects.

Searches

Seven preprogrammed dedicated service searches, one dedicated limit search. Any service or limit search can be programmed and scanned as an object alongside conventional channels and trunking talkgroups.

Priority

Talkgroup and conventional channel priority, selectable priority sample rate and priority sample during trunking talkgroup call.

Conventional Receiver Modes

AM, FM, NFM, CTCSS, DCS, P25 NAC

Trunking Receiver Modes

Motorola Type I/II/III Analog and Digital, GE/Ericsson/MA-COM EDACS Narrowband and Wideband, EF Johnson LTR

Receiver System

Triple conversion PLL super-heterodyne

1st IF ...................................................................................................... 380.8 MHz

(The 1st LO uses high side of receive frequency range for VHF and UHF Low/T, and low side of receive frequency range for >512 MHz)

2nd IF ...................................................................................................... 21.4 MHz

(The second LO uses low side of 1st IF)

3rd IF .......................................................................................................... 455 kHz

(The 3rd LO uses the low side of the 2nd IF)

Frequency Range

VHF Low ...................................................................... 25.00000 - 54.00000 MHz

VHF Aircraft ............................................................ 108.00000 - 136.99166 MHz

VHF High ................................................................. 137.00000 - 174.00000 MHz

...................................................................................

.................................................................................

UHF Low/T ............................................................. 300.00000 - 512.00000 MHz

UHF High .............................................................. 764.00000 - 960.00000 MHz*

..............................................................................

*Excludes frequencies utilized by the Cellular Mobile Radiotelephone Service

Preprogrammed Service Searches

Marine, Aircraft, CB, FRS/GMRS/MURS/DOT-STAR, Public Safety, Amateur Radio, Railroad

Weather frequencies

162.400, 162.425, 162.450, 162.475, 162.500, 162.525, 162.550 MHz

Scanning Rate ..................................................Approx. 55 channels per second

Search Rate ........................................................... Approx. 90 steps per second

Display

LCD with amber LED backlight, 4 lines of 16 characters each, plus 13 display icons

Zeromatic

Automatically zeroes receiver on correct frequency during searches

Audio Output ................................................................................................1.8 W

Internal Speaker ............................................................ 77 mm 8 ohms dynamic

Operating Voltage .......... 12-14.4 VDC, 13.8 VDC nominal, 16 VDC maximum

Dimensions (WxDxH) ................................Approximately 7.3 x 5.3 x 2.2 inches

................................................................................................... 185 x 135 x 55 mm

Weight (not including mounting hardware and antenna)

Approximately 42.3 ounces, 1200 grams

216.00250 - 224.9950 MHz

225.00000 - 299.93750 MHz

1240 .00000 - 1300.0000 MHz

Additional Information

Memory backup

No backup battery required, utilizes non-volatile EEPROM memory.

Power

AC Adapter (Class 2; 12V DC; 600 mA; center tip set to positive). Speciﬁcations are typical; individual units might vary. Speciﬁcations and

depictions are subject to change and improvement without notice.

Troubleshooting

Problem Cause Solution

Scanner won’t power on.

The keypad does not work.

Scanner will not scan when SCAN is pressed

The scanner does not receive digital transmission on digital frequencies or trunking systems.

Scanner scans slowly.

Scanner stops on noise or silence.

The AC adapter or DC adapter/cable is not connected.

The scanner may need to be initialized.

Possible “birdie” frequency programmed

The scanner may need to be reset or initialized

No channels programmed, or only one channel programmed, or all channels locked out

SQUELCH control is not adjusted properly

The digital channel or talkgroup is not using APCO-25 digital modulation.

The digital channel or talkgroup is encrypted.

The digital channel or talkgroup is being transmitted from a distant location.

SQUELCH control is set too high.

Subaudible squelch mode not set.

Be sure the adapter’s barrel plug is fully plugged into the DC 13.8V jack.

Follow steps in “Initializing the Scanner to Factory Defaults” below.

Tighten squelch, apply attenuator or lock out the “birdie” frequency

Follow steps in “Initializing the Scanner to Factory Defaults” below.

Ensure that the scanner has more than one channel programmed and enabled for scanning

Turn SQUELCH control clockwise until scanning resumes

The scanner can only receive APCO-25 C4FM/CQPSK IMBE digital signals.

The scanner will not receive encrypted trafﬁc.

Reposition the scanner or use an outdoor antenna to improve reception.

Turn SQUELCH control counter clockwise.

Set the correct subaudible squelch mode. See “Appendix B: Detailed Menu Reference: Conv Menu” on page 101.

Additional Information

Problem Cause Solution

Poor or no reception.

Error message appears when trying to upload or download from a computer.

Weak signals from distant stations.

Attenuator in use on weak signals.

Strong signal overload from nearby transmitter.

Loose or defective antenna.

Incorrect modulation mode selected.

Your computer is using Windows XP and does not have the necessary USB cable driver.

Reposition radio for best reception.

Check performance with and without attenuator activated, u se setting with best reception.

Inspect antenna and connectors and correct any problems found.

Ensure that proper modulation mode is selected for the type o f system being monitored.

Download and install the ﬁle: “Windows XP Driver to resolve PC connection error” from your scanner’s Product Support page or the Software Download page on www.RadioShack.com.

Then make your connection and try again. Be sure the correct COM port is selected in device manager.

Reset Global Parameters to Factory Defaults

If your scanner does not appear to be functioning properly, you can reset the global radio parameters to their factory state without losing any of your programmed data. Any custom changes you have made to the radio’s global parameters will be lost.

Note: This procedure preserves the information you stored in the scanner’s working memory, while resetting all global radio parameters to factory defaults. V-Scanner memory is not affected by this operation.

1. Turn off the scanner, then turn it on again.

The scanner brieﬂy displays the DSP boot version, and then the

Welcome/Owner screen is displayed.

2. Press 0 while the scanner is displaying the Welcome/Owner screen. The scanner displays:

System Tests: Select a Test... Exits if no key is pressed

3. Press 2. The scanner displays:

Init GLOB da ta To fa ctory s tate ENTER if APP ROVE CLEAR to EXI T

4. Press ENT. The scanner displays:

GLOB EEPROM area Initialized to defaults. Press any key.

5. Press any key on the keypad to proceed. The scanner will reboot with ﬁle system and global parameters reset to factory defaults.

Additional Information

Initializing the Scanner to Factory Defaults

If initializing the global parameters to factory defaults does not resolve your problem, you may wish to initialize the entire scanner to factory defaults. This operation will result in the clearing of your programmed data and the loss of any custom changes you have made to the radio’s global parameters. Use this option as a last resort, and, if possible, save your working memory to a V-Scanner folder prior to performing this operation.

Note: This procedure clears all information you stored in the scanner’s working memory, AND resets the global parameters to factory defaults. Initialize the scanner only when you are sure the scanner is not working properly. V-Scanner memory is not affected when the scanner is initialized.

1. Turn off the scanner, then turn it on again.

The scanner brieﬂy displays the DSP boot version, and then the

Welcome/Owner screen is displayed.

2. Press 0 while the scanner is displaying the Welcome/Owner screen. The scanner displays:

System Tests: Select a Test... Exits if no key is pressed

4. Press ENT. The scanner displays:

Initializing the File System

Please Wait.....

File System Initialized to Defaults.

Press any key.

5. Press any key on the keypad to proceed. The scanner displays:

GLOB EEPROM area Initialized to defaults. Press any key.

6. Press any key on the keypad to proceed. The scanner will reboot with ﬁle system and global parameters reset to factory defaults.

3. Press 1. The scanner displays:

Factory Init Erase Memory ENTER if APPROVE CLEAR to EXIT

Search Bands

Appendix A: Search Bands

All Sub Bands

Group. Freq. (MHz) Band

0 25-54 VHF Low

1 108-137 VHF Aircraft

2 137-174 VHF High

3 216-300 220 MHz Commercial/

Amateur

4 300-406 UHF Military Air

5 406-470 UHF

6 470-512 UHF-T

7 764-806 700 MHz

8 806-869 800 MHz

9 896-1300 900 MHz Band, 23 cm

Amateur

PubSafety Band

Searches commonly used public safety frequencies. Groups are as follows:

Group Freq. (MHz) Band

0 33.4-46.5 VHF Low

1 151-170 VHF High

2 453-467 UHF

3 764-806 700 MHz

4 851-869 800 MHz

Aircraft Band

Searches civilian and military air frequencies.

Group. Freq. (MHz) Band

0 108-118 Navigation

1 118-137 Civilian Voice

2 138-150 Military Voice

(excludes 2m Amateur)

3 225-400 Military Voice

Ham Bands

Searches amateur radio frequencies.

Group. Freq. (MHz) Band

0 28.0-29.7 10m

1 50-54 6m

2 144-148 2m

3 222-225 1.25cm

4 420-450 70cm

5 902-928 33cm

6 1240-1300 23cm

Detailed Menu Reference97Detailed Menu Reference

Appendix B: Detailed Menu Reference

• Context sensitive help is available for every menu parameter. Press FUNC SEL to view help for the selected parameter. Press SEL to exit help.

• Each menu parameter includes a D flt softkey, which restores the factory default setting for that parameter.

GLOB Menu

The GLOB menu stores all of the radio-wide settings used by the scanner. The active parameter is always the middle parameter and is indicated by a ﬂashing colon (:).

Notes:

• Some GLOB parameter changes do not take effect until the

GLOB menu is saved.

• You can restore all GLOB settings to their defaults

your programmed objects or V-Scanners. Power cycle the radio, then press 0, then 2 during the welcome message display. ENT to conﬁrm the GLOB parameter reset.

• The Special Global menu (FUNC GLOB)

settings that may adversely affect the performance of your radio if not set properly. We recommend that users not change the settings found in the FUNC GLOB menu without speciﬁc instructions. Should you experience difﬁculties after changing any of these settings, you can restore them to factory defaults by pressing the

Dflt softkey associated with each menu line, or follow the global

reset procedure described above. See the product support page for this scanner on www.RadioShack.com for detailed information on the FUNC GLOB menu.

without affecting

Press

includes parameter

GLOB

Parameter

Contrast 1-7

Owner SEL Enters sub menu to set Welcome Message

Clone Send SEL Press SEL to send data using clone mode.

Alert Mode Both, Tone,

Sound Mode On or Stlth Controls all radio beeps.

Key Beeps On or Off Controls key beeps.

Light Mode Norml, Stlth Controls the backlight operation. Norml

Light Level Brit, Dim, Off

Dim LED Global or Normal When on, DIM key and Light Level GLOB

Atten Mode Global or Normal The attenuator reduces the amount of

Global Atten On or Off When the Atten mode is set to Global, this

Options Description

Sets LCD contrast. Use   keys on 5-way pushbutton pad.

text display.

Light, Off

Controls the Alert LED and Audible Alarm behavior. Both allows the LED and Tone. Tone allows the audible alarm only. Light allows the LED only. Off deactivates the Alert LED and Audible Alarm feature.

(Normal) causes the backlight to remain on all the time. Stlth (Stealth) disables the backlight.

Controls backlight intensity. When Dim LED is set to Yes, it also controls the Alert LED intensity. Accessed from front panel using DIM key.

menu parameter also control intensity of Alert LED.

signal at the receiver input. This helps reduce interference from strong nearby transmitters. Global attenuator mode applies attenuation radio-wide, regardless of individual object settings. In Normal attenuator mode, the attenuator follows the individual object attenuator setting.

controls whether the Global attenuator is on or off.

Detailed Menu Reference99Detailed Menu Reference

GLOB

Parameter

Clear Hits SEL Press SEL to clear all hit counters.

Hit Counts Yes or No Turns the hit counter feature on or off.

Dﬂt ScanList 0-22

Priority On or Off Turns Priority Scan On or Off. Priority Scan

WxPri On or Off Toggles Weather Priority Mode on or off.

Scan Lists SEL Enters sub menu for Scan List settings and

SRCH L/Outs SEL Enters sub menu for review, editing or dele-

Clear FAV SEL Press SEL to clear the Favorites Scan List.

Memory Info SEL Press SEL to see the current memory

EXPERT BELOW

Tune LED On or Off Activates Signal Strength driven LED when

Color 0-7 Red, Green, Blue

Qtxt 1-0 Text value Sets QTXT (QuickText) 0-9 text. Use “$” to

Key Repeat On or Off Toggles key repeat mode when a key is

Options Description

Sets default destination Scan Lists for new objects and CONV Stor from Searches, Signal Stalker II, and Tune. Use 1-20 for “normal” Scan Lists 1-20. Use 0 for the “ns” (not scanned) Scan List (no Scan List mappings are speciﬁed). Use 21 for the FAV Scan List. Use 22 for the Skywarn Scan List.

can also be toggled by pressing FUNC PRI while scanning.

Also accessed by pressing WX, then PRI.

status.

tion of search lockout frequencies.

usage.

in Tune mode.

(RGB) value

Sets intensity of red, green and blue LEDs. Press SEL to edit colors. Press   to scroll to R, G or B LED settings. Use numeric keys to activate preset intensity levels for each LED, or use   keys to ﬁne scroll intensity.

indicate end of text.

held down.

GLOB

Parameter

LCD BlinkOff 1-250 x 10 mS For alternating text displays, sets the

LCD BlinkOn 1-250 x 10 mS For alternating text displays, sets the dis-

LED BlinkOff 1-250 x 10 mS When the Alert LED setting for an object is

LED BlinkOn 1-250 x 10 mS When the Alert LED setting for an object is

Pri Channels 0-250 Number of priority CONV channels to

Pri Interval 2-100 x 100 mS Conventional frequency priority sample

TGRP Pri Int On or Off Toggles priority interrupt scanning during

QuickPriRtn On or Off When on, does not wait for veriﬁcation of

Search Delay 1-250 x 100 ms Sets wait for reply delay for all search

SRCH Dig AGC On or Off Sets digital AGC mode on or off for all

SRCH SuprTrk On or Off Alternative DSP decoding algorithm is

Options Description

display time for the secondary display element.

play time for the primary display element.

set to Flash, this is the amount of time the LED stays turned off.

set to Flash, this is the amount of time the LED stays turned on.

check during a priority scan sampling. “0” samples all CONV priority channels.

interval.

trunked calls.

correct CTCSS, DCS or NAC when returning to an active CONV channel after priority sampling

modes.

search types. Useful to compensate for low or high digital audio levels caused at the system.

applied to all search types. May help reception on some systems.

100

Detailed Menu Reference

101

Detailed Menu Reference

GLOB

Parameter

TLO=FUNC L/O On or Off Controls the operation of the L/OUT key.

DupeChecksSQ Yes or No If set to Yes, dupe checking will check both

TGID Format Norm, DEC,

TGRP Ignore Yes or No If set to Yes, TGRP wildcards will ignore

ShowCCInfo Yes or No For Motorola and P25 systems, shows

Set Password SEL Set Power-on password.

Options Description

When Off, pressing L/OUT performs a Temporary Lockout of the selected object. When On, pressing L/OUT performs a Permanent Lockout of the selected object.

the stored frequency and any encoded squelch settings when checking for duplicate CONV objects.

Selects TGID display format.

or HEX

calls on previously stored TGRPS that are mapped to disabled Scan Lists.

current control channel index (from TSYS frequency list) and frequency alternating with the voice frequency.

0000=none.

CONV Menu

The CONV menu is used when creating new Conventional Channel objects, or editing existing Conventional Channel objects.

CONV

Parameter

Scan Lists On or Off for

Freq Any supported

Tag Alpha-numeric

Sq Mode Search, None,

Squelch Code CTCSS Hz, DCS

L/Out On or Off Permanent lockout for the CONV channel.

Priority On or Off Turns Priority Mode on or off for the CONV

Options Description

Scan Lists 1-22

frequency

text

CTCSS, DCS, P25

Code, P25 NAC

in MHz

Sets membership in Scan Lists. Use   keys to scroll through Scan Lists. Use SEL key to toggle Scan List membership. A “*” next to the Scan List number indicates that the object is mapped to that Scan List.

The frequency that the CONV object will use.

The alphanumeric display name for the CONV channel. Use the standard text entry method or QTXT to name the object.

Sets subaudible squelch mode or Project 25 conventional digital modulation. Use Search to automatically analyze signals to determine squelch mode and code. Use

None to ignore subaudible squelch. Use CTCSS for tone coded squelch, DCS for

digital coded squelch, or P25 for Project 25 conventional digital operation. Used in conjunction with Squelch Code parameter below.

Sets CTCSS tone, DCS code, or P25 NAC depending on Sq Mode setting. Use Search to detect tone or code value for selected squelch type.

Also accessed by pressing FUNC L/OUT while the scanner is stopped on the CONV object.

object.

102

Detailed Menu Reference

103

Detailed Menu Reference

CONV

Parameter

LED Mode Solid or Flash Controls whether the Alert LED ﬂashes

LED Color 0-7 Sets LED color to 0-7 as deﬁned in the

Latch LED On or Off Normally the Alert LED is active only while

Backlight On, Off or Flash Controls whether the backlight should be

Alarm None,

Fav Yes or No When On, the CONV object is a member of

Skywarn Yes or No When On, the CONV object is a member of

EXPERT BELOW

Modulation Auto, AM,

Options Description

or remains on solid when the Alert LED is used.

GLOB menu. By default, 0=LED Off,

1=Red, 2=Yellow, 3=Green, 4=Cyan, 5=Blue, 6=Magenta, 7=White.

the object is receiving a transmission. When Latch is on, the Alert LED will remain lit after the transmission is complete, unless overridden by a subsequent object that is also using the Alert LED.

on or ﬂashing while the object is active. “Off” setting is ignored by the PRO-197.

Sets the Audible Alarm for the CONV Chirp, Hi-Lo, Alert, Ring, 2-Chirp, Fast Hi-Lo, DTMF#

FM, NFM

object. When an Audible Alarm is selected,

the selected alarm will play at the begin-

ning of each transmission on the CONV

object, or anytime the scanner stops for

activity on the CONV object while scanning.

the Favorites Scan List.

the Skywarn Scan List.

Modulation setting for the CONV channel.

In most cases Auto will work ﬁne. Use AM

to override and force AM modulation, FM

to force FM modulation, NFM to force

narrow FM modulation.

CONV

Parameter

Atten On or Off When on, applies 20 dB of attenuation to

Delay On or Off Controls whether a Delay is used to wait

Delay Time 1-250 x 100ms Sets the amount of time (in 100 millisecond

Digital AGC On or Off Controls Digital AGC function for the

Supertrack On or Off Alternative DSP decoding algorithm. May

AudioBoost On or Off Applies a 6 dB boost to audio levels when

Hit Count Numeric value Increments each time a transmission is

Options Description

all transmissions on the CONV channel. Useful in areas where interference from nearby strong signals is present.

for reply trafﬁc after a transmission on the CONV channel.

intervals) for the wait for reply delay if Delay is On, e.g., 20=2 seconds.

CONV channel.

help reception on some systems.

the object is active.

received on the CONV object. Global “Hit Counts” must be set to ON. Press the

Dflt softkey to reset to 0.

104

Detailed Menu Reference

105

Detailed Menu Reference

TGRP Menu

The TGRP menu is used when creating new Trunking Talkgroup objects, or editing existing Trunking Talkgroup objects.

TGRP

Parameter

Scan Lists On or Off for

TSYS New or previously

ID Decimal, hex or

Type Group or Private Use Group for talkgroup ID, Private for

Tag Alpha-numeric

L/Out On or Off Permanent lockout for the TGRP. Also ac-

Priority On or Off Turns Priority Mode on or off for the TGRP

LED Mode Solid or Flash Controls whether the Alert LED ﬂashes

LED Color 0-7 Sets LED color to 0-7 as deﬁned in the

Options Description

Scan Lists 1-22

stored trunking system object (TSYS)

AFS, depending on TSYS type

text

Sets membership in Scan Lists. Use   keys

to scroll through Scan Lists. Use SEL key to

toggle Scan List membership. A “*” next

to the Scan List number indicates that the

object is mapped to that Scan List.

To enter a new trunking system, use the 

 keys to scroll through the stored systems

until NEW appears, then press SEL to enter

the parameters for the new TSYS. To use a

trunking system that you have previously

entered, use the   keys to scroll to the

desired system.

The digital address of the talkgroup or indi-

vidual radio ID on the trunked radio system.

individual radio ID.

The alphanumeric display name for the

TGRP. Use the standard text entry method

or QTXT to name the object.

cessed by pressing FUNC L/OUT while the

scanner is stopped on the TGRP object.

object.

or remains on solid when the Alert LED is

used.

GLOB menu. By default, 0=LED Off,

1=Red, 2=Yellow, 3=Green, 4=Cyan,

5=Blue, 6=Magenta, 7=White.

TGRP

Parameter

Latch LED On or Off Normally the Alert LED is active only while

Backlight On, Off or Flash Controls whether the backlight should be

Alarm None, Chirp,

Fav Yes or No When On, the TGRP object is a member of

Skywarn Yes or No When On, the CONV object is a member of

EXPERT BELOW

Delay On or Off Controls whether a Delay is used to wait

Delay Time 1-250 x 100 ms Sets the amount of time (in 100 millisecond

AudioBoost On or Off Applies a 6 dB boost to audio levels when

Hit Count Numeric value Increments each time a transmission is

Options Description

the object is receiving a transmission. When Latch is on, the Alert LED will remain lit after the transmission is complete, unless overridden by a subsequent object that is also using the Alert LED.

on, off or ﬂashing while the object is active.

Sets the Audible Alarm for the TGRP Hi-Lo, Alert, Ring, 2-Chirp, Fast HiLo, DTMF#

object. When an Audible Alarm is selected,

the selected alarm will play at the begin-

ning of each transmission on the TGRP

object, or anytime the scanner stops for

activity on the TGRP object while scanning.

the Favorites Scan List.

the Skywarn Scan List.

for reply trafﬁc after a transmission on the

TGRP.

intervals) for the wait for reply delay if Delay

is On, e.g., 20=2 seconds.

the object is active.

received on the TGRP object. Global “Hit

Counts” must be set to ON. Press the

Dflt softkey to reset to 0.

106

Detailed Menu Reference

107

Detailed Menu Reference

TSYS Menu

The TSYS menu is used when creating new Trunking System objects, or editing existing Trunking System objects.

TSYS

Parameter

Type MOT

Tag Alpha-

Frequencies SEL Press SEL to enter trunked radio system frequen-

L/Out On or Off Permanent lockout for the TSYS. When On, no

EXPERT BELOW

Atten On or Off When on, applies 20 dB of attenuation to all

Options Description

800/900,

MOT VHF/UHF,

P25 MANUAL,

P25 AUTO,

EDACS STD,

EDACS NAROW,

LTR

numeric text

Sets the trunking system type. Choose MOT 800/900 if the system is a Motorola 800 or 900 MHz analog or digital trunked radio system that uses the 3600 baud control channel. Use P25 AUTO for most Project 25 systems that send channel table information over the system control channel. Use P25 MANUAL if it is necessary to manually set the channel table information or if you wish to use the default 800 MHz table data. Use EDACS STD for most 800 MHz EDACS systems using the 9600 BPS EDACS control channel. Use EDACS NAROW for most 900 MHz and some VHF/UHF EDACS systems using the 4800 BPS EDACS control channel. Use LTR for Logic Trunked Radio (LTR) systems.

The alphanumeric display name for the TSYS. Use the standard text entry method or QTXT to name the object.

cies. Enter control channel frequencies in any order for all Motorola and Project 25 trunking systems. Enter system frequencies in LCN order for all EDACS trunking systems. Enter system frequencies in Home Repeater order for LTR systems.

trafﬁc will be received on any programmed TGRPs for this TSYS.

transmissions on this TSYS. Useful in areas where interference from nearby strong signals is present.

TSYS

Parameter

Narrow FM Yes or No Use Yes when the system is known to use Narrow

AudioBoost On or Off Activates 6 dB audio level boost for all activity on

Dwell 0-200 x

Digital AGC On or Off Controls Digital AGC function for the TSYS.

Supertrack On or Off Alternative DSP decoding algorithm. May help

Multi-Site Off,

Threshold Hi 1-99 Available When Multi-Site is set to ROAM. Sets the

Options Description

FM modulation. Most 900 MHz analog trunked radio systems utilize NFM modulation. This setting has no effect on digital trunked radio system performance.

this TSYS.

100 mS

Roam or Stat

(Stationary)

Sets the amount of time the scanner dwells on a Motorola, P25 or EDACS system control channel for activity on programmed talkgroups. Use 0 for automatic mode, which uses control channel information to determine when all current talkgroup information has been broadcast by the system.

reception on some systems.

Used with networked Motorola and P25 trunked radio systems. When Multi-Site=Off, the scanner will ﬁnd the ﬁrst usable control channel in the control channel list and use it to track the system. When Multi-Site=Roam, the scanner will always attempt to lock on to control channels where the decoding quality is greater than Threshold Hi, and will search for new control channels when the decoding quality of a control channel drops below Threshold Lo. If no control channels are available that meet the Threshold Hi criteria, the scanner will seek the best control channel to use, and continue checking periodically for a new control channel that meets the Threshold Hi criteria. When Multi-Site=STAT, the scanner will track the system using every usable control channel in the control channel list.

control channel decode % threshold for a site to be considered good when looking for a new site.

108

Detailed Menu Reference

109

Detailed Menu Reference

TSYS

Parameter

Threshold Lo 1-99 Available When Multi-Site is set to ROAM. Sets the

T Tables Default,

Fleet Map Type I For Motorola Type I systems only—sets ﬂeet map.

Options Description

control channel decode % threshold for a site to be considered out of range, which will begin the process of looking for a new site.

For Motorola and P25 systems only - sets custom Splinter, Custom

channel tables. Use  , to select option, press SEL

on Custom to enter custom table information.

LMIT Menu

The LMIT menu is used when creating new Limit Search objects, or editing existing Limit Search objects.

LMIT

Parameter

Scan Lists On or Off for Scan

FrLo Any supported

FrHi Any supported

Tag Alpha-

L/Out On or Off Permanent lockout for the LMIT channel.

LED Mode Solid or Flash Controls whether the Alert LED ﬂashes

Options Description

Lists 1-22

frequency in MHz

numeric text

A frequency that will be used as the lower limit for the limit search range.

A frequency that will be used as the upper limit for the limit search range.

The alphanumeric display name for the LMIT search. Use the standard text entry method or QTXT to name the object.

Also accessed by pressing FUNC L/OUT while the scanner is stopped on the LMIT object.

or remains on solid when the Alert LED is used.

LMIT

Parameter

LED Color 0-7 Sets LED color to 0-7 as deﬁned in the

Latch LED On or Off Normally the Alert LED is active only while

Backlight On, Off or Flash Controls whether the backlight should be

Alarm None, Chirp,

Fav Yes or No When On, the LMIT object is a member of

EXPERT BELOW

Modulation Auto, AM,

Atten On or Off When on, applies 20 dB of attenuation to

Delay On or Off Controls whether a Delay is used to wait

Delay Time 1-250 x 100 ms Sets the amount of time (in 100 millisecond

Options Description

GLOB menu. By default, 0=LED Off,

1=Red, 2=Yellow, 3=Green, 4=Cyan, 5=Blue, 6=Magenta, 7=White.

the object is receiving a transmission. When Latch is on, the Alert LED will remain lit after the transmission is complete, unless overridden by a subsequent object that is also using the Alert LED.

on, off or ﬂashing while the object is active.

Sets the Audible Alarm for the LMIT obHi-Lo, Alert, Ring, 2-Chirp, Fast HiLo, DTMF#

FM, NFM

ject. When an Audible Alarm is selected,

the selected alarm will play anytime the

scanner stops for activity on the LMIT

object while scanning.

the Favorites Scan List.

Modulation setting for the LMIT search. In

most cases Auto will work ﬁne. Use AM to

override and force AM modulation, FM to

force FM modulation, NFM to force narrow

FM modulation.

all hits received on the LMIT search. Useful

in areas where interference from nearby

strong signals is present.

for reply trafﬁc after a transmission is

received during the LMIT search.

intervals) for the wait for reply delay if

Delay is On, e.g., 20=2 seconds.

110

Detailed Menu Reference

111

Detailed Menu Reference

LMIT

Parameter

Zeromatic On or Of When on, enhances the scanner’s ability to

Search Dir Up or Down Sets search direction used when LMIT

Hit Count Numeric value Increments each time a transmission is

Options Description

lock on to the actual center frequency of a search hit instead of an adjacent frequency.

object is active.

received on the LMIT object. Global “Hit Counts” must be set to ON. Press the

Dflt softkey to reset to 0.

SRVC Menu

The SRVC menu is used when creating new Service Search objects, or editing existing Service Search objects.

SRVC

Parameter

Scan Lists On or Off for

Srvc Pub Safety,

Options Description

Scan Lists 1-22

Aircraft,

Amateur,

CB,

Marine,

FRS/GM/MURS,

Railroad

Pub Safety (Public Safety) searches commonly used public safety frequencies. Aircraft searches civilian and military air frequencies. Amateur searches amateur radio frequencies. CB searches the citizen’s band radio frequencies. Marine searches the VHF-FM marine radio band. FRS/GMRS/MURS/DOT/STAR (F/G/MURS) searches the FRS, GMRS, MURS, DOT and STAR radio frequencies. Railroad searches the Association of American Railroads (AAR) VHF railroad frequencies used in the US and Canada.

See Appendix A on page 94 for Group frequencies.

Search Band

SRVC

Parameter

Groups

Tag Alpha-numeric

L/Out On or Off Permanent lockout for the SRVC object.

LED Mode Solid or Flash Controls whether the Alert LED ﬂashes

LED Color 0-7 Sets LED color to 0-7 as deﬁned in the

Latch LED On or Off Normally the Alert LED is active only while

Backlight On, Off or Flash Controls whether the backlight should be

Alarm None, Chirp,

Fav Yes or No When On, the SRVC object is a member of

Options Description

Use   to scroll, SEL to toggle on/off

text

Hi-Lo, Alert, Ring, 2-Chirp, Fast HiLo, DTMF#

Toggle search groups when Pub Safety, Aircraft and Amateur service searches are used.

See Appendix A on page 94 for Group frequencies.

The alphanumeric display name for the SRVC search. Use the standard text entry method or QTXT to name the object.

Also accessed by pressing FUNC L/OUT while the scanner is stopped on the SRVC object.

or remains on solid when the Alert LED is used.

GLOB menu. By default, 0=LED Off,

1=Red, 2=Yellow, 3=Green, 4=Cyan, 5=Blue, 6=Magenta, 7=White.

the object is receiving a transmission. When Latch is on, the Alert LED will remain lit after the transmission is complete, unless overridden by a subsequent object that is also using the Alert LED.

on, off or ﬂashing while the object is active.

Sets the Audible Alarm for the SRVC object. When an Audible Alarm is selected, the selected alarm will play anytime the scanner stops for activity on the SRVC object while scanning.

the Favorites Scan List.

Search Band

112

Detailed Menu Reference

113

Detailed Menu Reference

SRVC

Parameter

EXPERT BELOW

Modulation Auto, AM, FM,

Atten On or Off When on, applies 20 dB of attenuation to

Delay On or Off Controls whether a Delay is used to wait

Delay Time 1-250 x 100ms Sets the amount of time (in 100 millisecond

Zeromatic On or Off When on, enhances the scanner’s ability to

Search Dir Up or Down Sets search direction used when SRVC

Hit Count Numeric value Increments each time a transmission is

Options Description

NFM

Modulation setting for the SRVC search. In most cases Auto will work ﬁne. Use AM to override and force AM modulation, FM to force FM modulation, NFM to force narrow FM modulation.

all hits received on the SRVC search. Useful in areas where interference from nearby strong signals is present.

for reply trafﬁc after a transmission on the SRVC search.

intervals) for the wait for reply delay if Delay is On, e.g., 20=2 seconds.

lock on to the actual center frequency of a search hit instead of an adjacent frequency.

object is active.

received on the SRVC object. Global “Hit Counts” must be set to ON. Press the

Dflt softkey to reset to 0.

STLK Menu Menu

The STLK menu is used when creating new Signal Stalker II objects, or editing existing Signal Stalker II objects.

STLK

Parameters

Scan Lists On or Off for

Type All Bands or

Sub-bands

Tag Alpha-numeric

L/Out On or Off Permanent lockout for the STLK search. Also

LED Mode Solid or Flash Controls whether the Alert LED ﬂashes or

LED Color 0-7 Sets LED color to 0-7 as deﬁned in the

Latch LED On or Off Normally the Alert LED is active only while the

Options Description

Scan Lists 1-22

Pub Safety

 , SEL

text

Use   to select All Bands or Public Safety. All Bands covers the entire frequency range of the scanner. Pub Safety covers frequency ranges commonly used for public safety communications.

Sub bands are available when using STLK in All Bands or Public Safety mode.

See Appendix A on page 94 for Group frequencies.

The alphanumeric display name for the STLK object. Use the standard text entry method or QTXT to name the object.

accessed by pressing FUNC L/OUT while the scanner is stopped on the STLK object.

remains on solid when the Alert LED is used.

GLOB menu. By default, 0=LED Off, 1=Red,

2=Yellow, 3=Green, 4=Cyan, 5=Blue, 6=Magenta, 7=White.

object is receiving a transmission. When Latch is on, the Alert LED will remain lit after the transmission is complete, unless overridden by a subsequent object that is also using the Alert LED.

Search Band

114

Detailed Menu Reference

115

Text Entry

STLK

Parameters

Backlight On, Off or Flash Controls whether the backlight should be on,

Alarm None, Chirp,

Fav

EXPERT BELOW

Atten On or Off When on, applies 20 dB of attenuation to all

Delay On or Off Controls whether a Delay is used to wait for

Delay Time 1-250 x 100ms Sets the amount of time (in 100 millisecond

Zeromatic On or Off When on, enhances the scanner’s ability to lock

Special On or Off STLK works by quickly sweeping the RF spec-

Search Dir Up or Down Sets search direction used when STLK object

Hit Count Numeric value Increments each time a transmission is

Options Description

off or ﬂashing while the object is active.

Sets the Audible Alarm for the STLK object. Hi-Lo, Alert, Ring, 2-Chirp, Fast Hi-Lo, DTMF#

Yes or No

When an Audible Alarm is selected, the select-

ed alarm will play anytime the scanner stops

for activity on the STLK object while scanning.

When On, the STLK object is a member of the

Favorites Scan List.

hits received on the STLK search. Useful in

areas where interference from nearby strong

signals is present.

reply trafﬁc after a transmission on the STLK

search.

intervals) for the wait for reply delay if Delay is

On, e.g., 20=2 seconds.

on to the actual center frequency of a search

hit instead of an adjacent frequency.

trum in 1 MHz increments to ﬁnd nearby strong

signals. If the 1 MHz sweep indicates that activ-

ity is present in the 1 MHz range, STLK sweeps

that range to ﬁnd the source.

is active.

received on the STLK object. Global “Hit

Counts” must be set to ON. Press the Dfl t

softkey to reset to 0.

Appendix C: Text Entry and QuickText

Your scanner uses a simple text entry method that allows entry of all uppercase and lowercase letters of the alphabet, numbers, and punctuation symbols. Your scanner also features QuickText, which allows you to store up to 10 commonly used text items for instant recall while editing alphanumeric ﬁelds.

Text Entry

To enter a letter in an alphanumeric text ﬁeld, press the number key below the letter you wish to type ﬁrst, then press the number key that corresponds with the position of the letter in the silk screen group.

For example, the number 2 is used to access the letters A, B and C. To type the letter A, press 2 to select the ABC group, then 1 to select the ﬁrst letter in the group. Likewise, to type the letter B, press 2 to select the ABC group, then press 2 again to select the second letter in the group. And, to type the letter C, press 2, then 3 to select the third letter in the group.

• To enter numbers in alphanumeric text ﬁelds, press 1 ﬁrst, then the number you wish to type.

• To enter punctuation, press 0 ﬁrst to see the ﬁrst set of punctuation, then press the number key that corresponds with the position of the desired punctuation mark in the set.

• To enter a space, press the . (period) key to enter a SPACE.

• While using Standard Text Entry, the FUNC key serves as a shift key.

• For letters, uppercase text is typed by default, and you can shift to lowercase by pressing FUNC before entering a character.

116

Text Entry

117

Text Entry

• For punctuation, FUNC accesses a second set of punctuation marks. The shift action of FUNC remains active until it is pressed again.

• Press t or u to move the cursor to the desired location in edit ﬁelds. Press FUNC t or FUNC u to move the cursor to the beginning or end of an edit ﬁeld.

• Use CLR as a backspace key to erase characters before the cursor, and press FUNC CLR to clear the entire ﬁeld.

Char Press Char Press Char Press Char Press A 21 O 63 3 13 ? 07 B 22 P 71 4 14 -> 08 C 23 Q 72 5 15 ‘ 09 D 31 R 73 6 16 <- 00 E 32 S 74 7 17 . 0(F)1 F 33 T 81 8 18 - 0(F)2 G 41 U 82 9 19 # 0(F)3 H 42 V 83 0 10 _ 0(F)4 I 43 W 91 $ 01 @ 0(F)5 J 51 X 92 % 02 + 0(F)6 K 52 Y 93 ! 03 * 0(F)7 L 53 Z 94 ^ 04 & 0(F)8 M 61 1 11 ( 05 / 0(F)9 N 62 2 12 ) 06 , 0(F)0

Note: Press FUNC for lower case letters.

QuickText

QuickText allows you to store up to 10 commonly used text items for instant recall while editing alphanumeric ﬁelds. For example, as you search, store, and name new CONV or TGRP objects, you may ﬁnd that you type the same words over and over, such as POLICE, FIRE, SHERIFF, STATE, CITY, COUNTY, etc.

• A few common QuickText words are provided for your convenience. You can keep these, edit them to your preferences, or replace them with your own custom QuickText words.

• QuickText can be used while editing any alphanumeric text ﬁeld.

To insert a stored QuickText item:

1. While editing an alphanumeric text ﬁeld, press position the cursor where you want the QuickText inserted, then press the QTXT softkey.

The top row of the display will show the available QuickText

phrases.

2. Press p or q to scroll through the stored QuickText phrases, and press SEL to insert the QuickText phrase at the cursor location.

As a shortcut, press the number key on the numeric keypad that

corresponds with the QuickText item you wish to use, instead of scrolling and pressing SEL.

t or u to

118

Text Entry

119

Index

Customizing QuickText

To edit the QuickText words:

1. Press

2. Press p or q to scroll to QTXT and ﬁnd the QuickText storage

3. Press uto edit the QuickText entry.

4. Use the standard text entry method to enter your desired text.

Note: When you use your QTXT entry in a text ﬁeld, any unused spaces will be ﬁlled with space characters. If you want to leave room for adding text, enter a space after your QTXT, then a dollar sign ($). When you use your QTXT in a text ﬁeld, and the edit cursor will be positioned just after the space so you can continue adding text to the text ﬁeld.

5. Once you are ﬁnished editing your QTXT storage location, press

6. Press the SAVE softkey again to save the changes you made to

PROG, then the GLOB softkey.

location that you wish to change.

the SAVE softkey to save the QTXT.

the GLOB menu.

Index

Alarms

Global Setting.................................................................................................................97

Object Setting ..................................................................75, 99, 102, 105, 109, 111, 114

Weather Alarm ................................................................................................................65

Alert LED

Global Setting.................................................................................................................97

Object Setting ..................................................................75, 99, 102, 104, 108, 111, 113

Antenna .................................................................................................................. 8, 18

Troubleshooting .............................................................................................................90

Weather Scanning ..........................................................................................................64

Attenuator

Global Settings ...............................................................................................................97

Key .....................................................................................................................................6

Setting .............................................................................................................................22

Troubleshooting .............................................................................................................90

Backlight

Alerts ...............................................................................................................................76

Setting .............................................................................................................................25

Birdie Frequencies ..................................................................................................... 82

Clear

Favorite Scan List............................................................................................................43

Hit Counters ....................................................................................................................75

Key .....................................................................................................................................7

Lockouts ..........................................................................................................................49

Memory .....................................................................................................................80, 92

Text ..........................................................................................................................30, 116

Cloning ....................................................................................................................... 71

Conventional Channel Object

Creating ..........................................................................................................................29

Detailed Menu Reference ............................................................................................101

Priority Scan ....................................................................................................................74

120

Index

121

Index

Dashboard .................................................................................................................. 17

Dedicated Searches

Deﬁned ............................................................................................................................57

LMIT .................................................................................................................................57

Signal Stalker II ...............................................................................................................60

SRVC ................................................................................................................................58

TUNE ...............................................................................................................................61

Tune LED .....................................................................................................................63

Delay

Key .....................................................................................................................................7

Object Delay .................................................................................103, 105, 109, 112, 114

Search Delay ...................................................................................................................99

Setting .............................................................................................................................24

Deleting Objects ........................................................................................................ 44

Dim ............................................................................................................................. 25

Display .......................................................................................................................... 9

Duplicate (DUPE) ....................................................................................................... 34

Factory Defaults

Initializing the Scanner ...................................................................................................92

Resetting Global Parameters ........................................................................................90

Favorite List

Adding Objects ..............................................................................................................43

Clearing ...........................................................................................................................43

Deﬁned ............................................................................................................................40

Key .....................................................................................................................................7

FCC Notice ................................................................................................................ 83

Finding

Locked Out Objects .......................................................................................................45

Text Strings .....................................................................................................................46

FIPS Codes ................................................................................................................. 65

FUNC (Function) Key ...................................................................................................7

Text Entry ......................................................................................................................115

Global (GLOB) Menu

Deﬁned ............................................................................................................................23

Detailed Reference ........................................................................................................96

Global Attenuator

Key .....................................................................................................................................6

Help Menu .................................................................................................................. 23

Key .....................................................................................................................................6

Hit Counters ............................................................................................................... 74

Input

Character ...........................................................................................................................7

Decimal Point ...................................................................................................................7

Number .............................................................................................................................7

Text ..........................................................................................................................29, 115

Installing ..................................................................................................................... 16

Keylight

Setting .............................................................................................................................25

Key Tone ..................................................................................................................... 25

LCD Contrast ............................................................................................................. 24

Legal Scanning ........................................................................................................... 83

Limit Search

Creating ..........................................................................................................................51

Dedicated LMIT Search .................................................................................................57

Detailed Menu Reference ............................................................................................108

Lockout

Finding ............................................................................................................................45

Key .....................................................................................................................................6

Object Lockout ...............................................................................................................47

Permanent ...................................................................................................................6, 48

Search ..............................................................................................................................49

Talkgroup ........................................................................................................................50

Temporary ...................................................................................................................6, 48

Wildcard ..........................................................................................................................50

LTR

Display .............................................................................................................................63

Home Repeater AutoMove ...........................................................................................79

122

Index

123

Index

Manual Mode ............................................................................................................. 36

Memory

Object Numbering .........................................................................................................38

Report ..............................................................................................................................72

Saving Main Memory .....................................................................................................70

Scan Lists .........................................................................................................................39

V-Scanner ........................................................................................................................69

Motorola

Custom Channel Tables ...............................................................................................108

Display Information ........................................................................................................63

Dwell Time ....................................................................................................................107

Fleet Map ......................................................................................................................108

Multi-Site .................................................................................................................77, 107

Priority Talkgroups ..........................................................................................................74

Show CC Info ................................................................................................................100

Trunking System Type ..................................................................................................106

Networked Systems ................................................................................................... 77

NS Scan List ............................................................................................................... 42

Object Menus

Detailed Menu Reference ..............................................................................................96

EXPERT BELOW .............................................................................................................28

Understanding ................................................................................................................26

Object Numbering ..................................................................................................... 38

Object Searches ......................................................................................................... 51

P25 Systems

Custom Channel Tables ...............................................................................................108

Display Information ........................................................................................................63

Dwell Time ....................................................................................................................107

Multi-Site .................................................................................................................77, 107

Show CC Info ................................................................................................................100

Subaudible Squelch Mode ..........................................................................................101

Trunking System Type ..................................................................................................106

Pause

Basic Scanning ................................................................................................................35

Key .....................................................................................................................................6

Tune Mode ......................................................................................................................62

Power ..................................................................................................................... 8, 19

Power-On Conﬁguration ............................................................................................ 80

Power-On Password ...................................................................................................81

Priority

CONV Setting ...............................................................................................................101

Global Setting...........................................................................................................98, 99

Key .....................................................................................................................................7

Priority Scan ....................................................................................................................73

TGRP Setting ................................................................................................................104

Weather Priority Mode...................................................................................................64

Programming

CONV Objects ................................................................................................................29

PROG Key .........................................................................................................................6

Storing Memory ..............................................................................................................69

TGRP Objects .................................................................................................................30

TSYS Objects ..................................................................................................................31

QuickText .................................................................................................................115

Customizing ..................................................................................................................118

SAME

Location and Event Codes ............................................................................................66

Standby Mode ................................................................................................................65

Scan Lists

Changing ........................................................................................................................40

Default .......................................................................................................................44, 98

Enabling or Disabling ............................................................41, 101, 104, 108, 110, 113

Grouping Objects ..........................................................................................................39

Naming............................................................................................................................41

Viewing ............................................................................................................................36

Scannable Objects

Creating ..........................................................................................................................26

Grouping .........................................................................................................................39

Numbering ......................................................................................................................38

Scanning..........................................................................................................................35

Scanning .........................................................................................................................

Display Information ........................................................................................................36

Favorites ....................................................................................................................40, 43

124

Index

125

Index

Legally .............................................................................................................................83

Priority .......................................................................................................................73, 98

Weather ...........................................................................................................................64

Wildcard ..........................................................................................................................35

Searching

Dedicated Searches .......................................................................................................57

Search Mode Key .........................................................................................................7

For Birdie Frequencies ...................................................................................................82

For Objects .....................................................................................................................45

Frequency Searches .......................................................................................................51

Limit Search ....................................................................................................................51

Lockout ............................................................................................................................50

Search Bands ..................................................................................................................94

Service Search ................................................................................................................53

Signal Stalker II ...............................................................................................................55

Service and Repair .....................................................................................................84

Service Search

Creating ..........................................................................................................................53

Dedicated Service Search ..............................................................................................58

Detailed Menu Reference ............................................................................................110

Shortcuts .................................................................................................................... 80

Signal Stalker II

Creating ..........................................................................................................................55

Dedicated Signal Stalker II ............................................................................................60

Detailed Menu Reference ............................................................................................113

Key .....................................................................................................................................6

Skywarn

Key .....................................................................................................................................7

Scan List ..........................................................................................................39, 102, 105

Softkeys .................................................................................................................. 6, 27

Speakers ................................................................................................................. 8, 20

Speciﬁcations ............................................................................................................. 85

Squelch ....................................................................................................................... 21

Encoded ..................................................................................................................62, 100

Settings .........................................................................................................................101

Priority Scan ....................................................................................................................74

Types..........................................................................................................................33, 34

Text Entry ................................................................................................................. 115

Text Tags .........................................................................................................................29

Transferring Data ....................................................................................................... 21

Troubleshooting ......................................................................................................... 89

Trunking System Object

Creating ..........................................................................................................................31

Detailed Menu Reference ............................................................................................106

Entering TSYS Menu ....................................................................................................104

Tune

Dedicated Tune Search ..................................................................................................61

Key .....................................................................................................................................7

Tune LED ...................................................................................................................63, 98

V-Scanners

About...............................................................................................................................69

Erasing .............................................................................................................................71

Loading ...........................................................................................................................71

Using................................................................................................................................70

Weather Scanning

Key .....................................................................................................................................7

SAME Standby Mode.....................................................................................................65

Wildcard ......................................................................................................................66

Weather Priority Mode...................................................................................................64

Weather Radio Mode .....................................................................................................64

Wildcard Talkgroup

Deﬁned ............................................................................................................................33

Lockout ............................................................................................................................50

Scanning..........................................................................................................................35

TGRP Ignore .................................................................................................................100

Talkgroup Object

Creating ..........................................................................................................................30

Detailed Menu Reference ............................................................................................104

Global Settings ...............................................................................................................99

Lockout ............................................................................................................................50

126

127

Limited Warranty

This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for one (1) year from the date of purchase from RadioShack companyowned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.

In the event of a product defect during the warranty period, take the product and the RadioShack sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, unless otherwise provided by law: (a) correct the defect by product repair without charge for parts and labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase price. All replaced parts and products, and products on which a refund is made, become the property of RadioShack. New or reconditioned

parts and products may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for the remainder of the original warranty period. You will be charged for repair or replacement of the product made after the expiration of the warranty period.

This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse, accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs of product removal, installation, set-up service adjustment or reinstallation.

This warranty gives you speciﬁc legal rights, and you may also have other rights which vary from state to state.

RadioShack Customer Relations 300 RadioShack Circle Fort Worth, TX 76102 12/99

www.radioreference.com

The RadioReference Database

Includes a complete frequency database, trunked radio system information, FCC license assignments, 10 Code lists, agency maps, les, downloads, and detailed information for most public safety, military, and local government communications systems.

The RadioReference Discussion Forums

Where over 120,000 members discuss radios, scanning, trunking, decoding, antennas, specialty radio topics, and location specic information.

The RadioReference Wiki

The most comprehensive reference source of radio communications reference information – the de-facto encyclopedia for the radio communications community.

RADIOREFERENCE.COM IS THE WORLD’S LARGEST RADIO COMMUNICATIONS

WEBSITE, WITH A COMPLETE FREQUENCY AND TRUNKED RADIO SYSTEM DATABASE.

COME SEE WHAT FREE SERVICES WE HAVE TO OFFER TO THE COMMUNITY:

COME SEE WHY WE ARE THE #1 RES OURCE FOR THE RAD IO COMMUNICATIONS COMM UNITY!

t 5IF3BEJP3FGFSFODFDPN8FCTFSWJDFUPBMMPXTPGUXBSFBQQMJDBUJPOTUPQSPHSBNBTDBOOFS

EJSFDUMZGSPNUIF3BEJP3FGFSFODF%BUBCBTF t 1%'%PXOMPBETPGEBUBCBTFJOGPSNBUJPOGPSFBTZQSJOUJOH t .Z33oQFSTPOBMJ[BUJPOGPSLFFQJOHUSBDLPGZPVSMPDBMJOGPSNBUJPO t 4QFDJBMEBUBCBTFTFBSDIFTUPNBLFöOEJOHSBEJPDPNNVOJDBUJPOTEBUBFBTJFS

FOR ON LY $7. 50 A QUARTE R, RADIORE FERENCE.COM ALSO PROVI DES

PREMIU M SUBSCRIP TIONS, WHICH ENTITLES PAID MEMBERS ACCE SS TO:

RadioReference.com

Your Complete Reference Source

Hypersearch, Hyperscan, and Adaptaplug are trademarks used by RadioShack Corporation.

Motorola, Smartnet, Smartzone, Omnilink, ASTRO and Privacy Plus are registered trademarks of Motorla Inc. EDACS is a registered trademark of MA-COM Inc. LTR is a registered trademark of EF Johnson.

U.S. Pat. Nos. 5,870,405 and 5,517,511

Printed in China

20-197

07A08

GE-08D-0560

Radio Shack 20-197 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Understanding Your Scanner

Understanding the Function Keys

Understanding the Display

Understanding Object Oriented Scanning

Scanner Features

Scanner Setup

Installing Your Scanner

Setting up a Mobile Base

Bracket Mounting

Dashboard Installation

Connecting the Antenna

Powering Your Scanner

Wall Outlet

Vehicle (Power Socket)

Vehicle (Direct)

Headphones and Speakers

Listening Safety

Transferring Data To or From another Scanner or PC

Turning on the Scanner and Setting Squelch

Squelch and Attenuator

Basic Settings

Delay

Adjusting the LCD Contrast

Turning the Key Tone On or Off

Turning Key and Backlight On or Off

Creating Scannable Objects

Understanding Object Menus

Conventional Channel Objects

Essential Parameters

Creating a CONV Object

Changing Text Tags

Trunking Talkgroup Objects (TGRP)

Essential Parameters

Trunking System (TSYS) Objects

Scanning

Duplicate (DUPE)

Basic Scanning Operation

Wildcard Scanning

Manual Mode

Organizing Objects

Object Numbering

Grouping Objects with Scan Lists

Changing Scan List Membership

New Objects

Existing Objects.

Naming Scan Lists

Enabling or Disabling Scan Lists

While Scanning

From Global Settings Menu

NS (Not Scanned) Scan List

Favorite List

Setting the Default Scan List

Deleting Objects

Searching for Objects using FIND

Filtering by Object Type

Object Lockout

Temporary Lockout

Permanent Lockout

Change L/OUT Key Function

Search Lockout

Object Searches

Talkgroup Lockout

Limit Search Object (LMIT)

Essential Parameters

Service Search Object (SRVC)

Essential Parameters

Signal Stalker II Object (STLK)

Essential Parameters

Dedicated Searches

Dedicated LMIT Search

Dedicated SRVC Search

Dedicated Signal Stalker II

Dedicated TUNE Search

Tune LED

Weather Scanning

Weather Radio Mode
