Radio RF Unit Schematics
RF Unit (Lot. 1 ~ 60)
Circuit Diagram
1
RF Unit (Lot. 1 ~ 60)
Note
2
DAN235U TL (M)
(D2001, 2002, 2019, 2020, 2021,
2041, 2042, 2056, 2060, 2067)
DAN202K T146 (N)
(D2065, 2066, 2070)
(D2007, 2013, 2030, 2031, 2037,
HVM17-TR
2039)
SVC341L-TD
(D2033, 2040)
RF Unit (Lot. 1 ~ 60)
A B C D E F GH
1
2
3
I
Parts Layout (Side A)
NJM78L05UA (8C)
FMS1 (S1)
(Q2073, 2074, 2079)
DTC114EK (24)
(Q2009, 2010, 2014, 2071, 2077)
2SA1586Y (SY)
(Q2029)
(Q 2013, 2036, 2063, 2075)
(Q2012)
UPC2711T-E3 (C1G)
BA12T
(Q2081)
2SK210GR (YG)
(Q2016)
3SK228XR (XR-)
(Q2019, 2020, 2021, 2031,
2032, 2033, 2045, 2064)
2SC4116GR (LG)
(Q2006, 2007, 2022, 2028)
2SC3356 (R24)
(Q2030, 2035, 2040, 2041,
2047, 2052, 2067, 2070)
2SC3585 (R42)
(Q2034, 2056)
2SC3120 (HB)
(Q2061)
4
NJU7201U30(TE1)
(Q2038)
5
2SC3420GR
(Q2080)
6
NJM78L09UA (8H)
(Q2011, 2062, 2024)
7
MB15E05PFV1-G-BND-EF
(Q2055)
L78M05T-TL
(Q2017)
M5223AFP 600C
(Q2001, 2002)
MB15A02PFV1
(Q2018)
(Q2039, 2042, 2043, 2048, 2049,
FMC3 (C3)
2053, 2058, 2060, 2065)
8
UPC2710T-E3
(Q2068)
BU4094BCFV-E1
(Q2059, 2072)
3
RF Unit (Lot. 1 ~ 60)
Parts Layout (Side B)
a b c d e f
g
h
i
2SC4116GR (LG)
(Q2023, 2027)
2SA1586Y (SY)
(Q2037)
DTC114EK (24)
(Q2004, 2005, 2015, 2078)
MA28T-A (TX)
(D2008)
1
DAN235U TL (M)
(D2001, 2064, 2072, 2073)
DAN202K (N)
2
3
(D2071, 2078)
SB40W03T-TL
(D2074)
IMD3 (D3)
(Q2008)
UPC2711T-E3 (C1G)
(Q2025)
FMC3 (C3)
(Q2044, 2050, 2051, 2054,
2066, 2069, 2076)
4
5
6
7
M5223AFP 600C
(Q2003)
8
4
RF Unit (Lot. 61 ~)
Circuit Diagram
5
RF Unit (Lot. 61 ~)
Note
6
DAN235U TL (M)
(D2001, 2002, 2019, 2020, 2021,
2041, 2042, 2056, 2060, 2067)
DAN202K T146 (N)
(D2065, 2066, 2070)
(D2007, 2013, 2030, 2031, 2037,
HVM17-TR
2039)
SVC341L-TD
(D2033, 2040)
RF Unit (Lot. 61 ~)
A B C D E F GH
1
2
3
I
Parts Layout (Side A)
NJM78L05UA (8C)
FMS1 (S1)
(Q2073, 2074, 2079)
DTC114EK (24)
(Q2009, 2010, 2014, 2071, 2077)
2SA1586Y (SY)
(Q2029)
(Q 2013, 2036, 2063, 2075)
(Q2012)
UPC2711T-E3 (C1G)
BA12T
(Q2081)
2SK210GR (YG)
(Q2016)
3SK228XR (XR-)
(Q2019, 2020, 2021, 2031,
2032, 2033, 2045, 2064)
2SC4116GR (LG)
(Q2006, 2007, 2022, 2028)
2SC3356 (R24)
(Q2030, 2035, 2040, 2041,
2047, 2052, 2067, 2070)
2SC3585 (R42)
(Q2034, 2056)
2SC3120 (HB)
(Q2061)
4
NJU7201U30(TE1)
(Q2038)
5
2SC3420GR
(Q2080)
6
NJM78L09UA (8H)
(Q2011, 2062, 2024)
7
MB15E05PFV1-G-BND-EF
(Q2055)
L78M05T-TL
(Q2017)
M5223AFP 600C
(Q2001, 2002)
MB15A02PFV1
(Q2018)
(Q2039, 2042, 2043, 2048, 2049,
FMC3 (C3)
2053, 2058, 2060, 2065)
8
UPC2710T-E3
(Q2068)
BU4094BCFV-E1
(Q2059, 2072)
7
RF Unit (Lot. 61 ~)
Parts Layout (Side B)
a b c d e f
g
h
i
2SC4116GR (LG)
(Q2023, 2027)
2SA1586Y (SY)
(Q2037)
DTC114EK (24)
(Q2004, 2005, 2015, 2078)
MA28T-A (TX)
(D2008)
1
DAN235U TL (M)
(D2001, 2064, 2072, 2073)
DAN202K (N)
2
3
(D2071, 2078)
SB40W03T-TL
(D2074)
IMD3 (D3)
(Q2008)
UPC2711T-E3 (C1G)
(Q2025)
FMC3 (C3)
(Q2044, 2050, 2051, 2054,
2066, 2069, 2076)
4
5
6
7
M5223AFP 600C
(Q2003)
8
8
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
PCB with Components CB0907003 PA-28B CE: OFF
CB0907004 PA-28C CE: OFF
CB0907005 PA-28U CE: ON
CB0907006 PA-28A CE: OFF
CB0907007 PA-28U CE: ON
Printed Circuit Board FR004160F 1-
FR004160G 61-
C 2002 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A A4
C 2003 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A B4
C 2004 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A B4
C 2005 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B g3
C 2006 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B3
C 2007 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B e7
C 2008 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A B4
C 2009 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d7
C 2010 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B3
C 2011 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B3
C 2012 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A B4
C 2013 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B4
C 2014 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E7
C 2015 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E7
C 2016 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E7
C 2017 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D7
C 2018 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f3
C 2020 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 1- A B4
C 2021 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A A6
C 2021 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A A6
C 2022 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A B4
C 2023 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B g4
C 2024 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e7
C 2025 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A C3
C 2026 CHIP CAP. 1.5pF 50V CK GRM1884C1H1R5CZ01D K22174258 1- A B4
C 2027 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A A4
C 2027 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A A4
C 2028 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A B4
C 2029 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E7
C 2030 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A B7
C 2030 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A B7
C 2031 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E7
C 2032 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B3
C 2033 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A C4
C 2035 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A B4
C 2036 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A A6
C 2036 CHIP CAP. 0.1uF 25V F GRM188F11E104ZA01D K22145001 3- A A6
C 2037 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A B7
C 2037 CHIP CAP. 0.1uF 25V F GRM188F11E104ZA01D K22145001 3- A B7
C 2038 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A C4
C 2039 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E7
C 2041 FILM CAP. 0.01uF 50V NNM103K50 K50170039 1- A C7
C 2041 FILM CAP. 0.01uF 16V ECHU1C103JB5 K57120007 3- A C7
C 2041 FILM CAP. 0.01uF 16V ECHU1C103JX5 K57120030 70- A C7
C 2042 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C4
C 2043 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- B e6
C 2044 CHIP CAP. 100pF 50V UJ GRM1883U1H101JZ01D K22174332 1- B e5
C 2045 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A G8
C 2045 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A G8
C 2046 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C7
C 2047 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e5
C 2049 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H7
C 2050 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F7
C 2051 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A B6
C 2051 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A B6
C 2052 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C7
C 2052 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C7
C 2053 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C3
9
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2054 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D4
C 2055 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A H7
C 2055 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A H7
C 2057 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A B6
C 2057 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A B6
C 2058 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A C7
C 2058 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A C7
C 2059 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A D5
C 2059 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A D5
C 2060 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F7
C 2060 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 3- A F7
C 2061 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B4
C 2064 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2065 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A D5
C 2065 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A D5
C 2066 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D3
C 2067 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D3
C 2068 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2069 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D4
C 2070 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C4
C 2071 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F7
C 2072 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A H7
C 2072 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A H7
C 2073 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D7
C 2074 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e5
C 2075 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e5
C 2076 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A D6
C 2076 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A D6
C 2077 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H7
C 2078 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A F7
C 2078 CHIP CAP. 27pF 50V UJ GRM1883U1H270JZ01D K22174318 3- A F7
C 2079 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A F7
C 2079 CHIP CAP. 6pF 50V UJ GRM1883U1H6R0DZ01D K22174306 3- A F7
C 2080 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D3
C 2081 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A C3
C 2082 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2084 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2086 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G8
C 2087 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e5
C 2088 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D3
C 2089 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C3
C 2090 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C3
C 2091 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A B2
C 2091 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A B2
C 2092 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- B e7
C 2093 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- B e7
C 2094 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- B e7
C 2095 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F7
C 2095 CHIP CAP. 100pF 50V UJ GRM1883U1H101JZ01D K22174332 3- A F7
C 2096 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A F7
C 2096 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 3- A F7
C 2096 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 5- A F7
C 2097 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B3
C 2098 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F7
C 2098 CHIP CAP. 100pF 50V UJ GRM1883U1H101JZ01D K22174332 3- A F7
C 2100 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- B e5
C 2101 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e5
C 2102 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B3
C 2103 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2103 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2104 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B2
C 2105 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B3
C 2106 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1-2
C 2107 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C7
C 2108 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1-2
10
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2109 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174811 1- A C2
C 2110 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C3
C 2111 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B f3
C 2112 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B2
C 2113 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- B f3
C 2114 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2114 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2116 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G7
C 2117 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-2
C 2118 CHIP CAP. 0.0033uF 50V B GRM188B11H332KA01D K22174815 1- A C2
C 2119 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A C7
C 2120 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A D3
C 2121 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A F7
C 2121 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A F7
C 2122 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D3
C 2123 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A D4
C 2125 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B h3
C 2126 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A C7
C 2127 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A G7
C 2127 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A G7
C 2129 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2129 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2130 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2130 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2131 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A C7
C 2133 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- A C7
C 2134 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A B4
C 2136 CHIP CAP. 0.0027uF 50V B GRM188B11H272KA01D K22174814 1- A C2
C 2138 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A D4
C 2139 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A D3
C 2140 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f5
C 2141 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2141 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2142 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B3
C 2143 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C2
C 2145 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B g3
C 2146 CHIP TA.CAP. 0.1uF 20V TEESVA21D104M8R K78130020 1- A C6
C 2147 FILM CAP. 0.01uF 50V NNM103K50 K50170039 1- A C7
C 2147 FILM CAP. 0.01uF 16V ECHU1C103JB5 K57120007 3- A C7
C 2147 FILM CAP. 0.01uF 16V ECHU1C103JX5 K57120030 70- A C7
C 2148 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e7
C 2150 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A C2
C 2151 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A B4
C 2152 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A D4
C 2153 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f5
C 2154 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f5
C 2155 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A B4
C 2156 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D3
C 2157 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C6
C 2158 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A G7
C 2158 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A G7
C 2159 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C4
C 2160 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A E5
C 2161 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A B4
C 2162 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C6
C 2163 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A B4
C 2164 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f5
C 2165 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C4
C 2166 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2166 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2167 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B b7
C 2168 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A B4
C 2169 CHIP CAP. 10pF 50V CH GRM1882C1H100RZ01D K22174248 1- A D6
C 2170 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B f5
C 2171 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A B4
11
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2172 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1-2
C 2173 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C3
C 2174 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A C6
C 2175 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A F7
C 2175 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A F7
C 2176 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C4
C 2177 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C6
C 2178 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A C6
C 2179 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A B4
C 2180 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D3
C 2181 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E4
C 2182 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A E5
C 2183 CHIP TA.CAP. 0.47uF 25V TEESVA1E474M8R K78140009 1- B b7
C 2184 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- B f5
C 2185 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A E5
C 2186 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A G7
C 2186 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A G7
C 2187 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2187 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2188 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A D2
C 2189 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2189 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2190 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A B4
C 2191 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2
C 2192 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1-60
C 2194 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A E5
C 2195 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B b7
C 2197 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 2198 CHIP TA.CAP. 0.47uF 25V TEESVA1E474M8R K78140009 1- B b7
C 2199 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2199 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2200 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A C6
C 2201 CHIP CAP. 10pF 50V CH GRM1882C1H100RZ01D K22174248 1- A C6
C 2202 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G7
C 2203 CHIP TA.CAP. 0.47uF 25V TEESVA1E474M8R K78140009 1- B a7
C 2204 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C2
C 2205 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C2
C 2205 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C2
C 2206 CHIP CAP. 1.5pF 50V CK GRM1884C1H1R5CZ01D K22174258 1- A B4
C 2207 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2
C 2208 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D3
C 2210 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C4
C 2211 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A D4
C 2212 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A C7
C 2212 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A C7
C 2214 CHIP CAP. 150pF 50V CH GRM1882C1H151JA01D K22174239 1- B g5
C 2215 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B a7
C 2216 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E4
C 2216 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 61- A E4
C 2217 CHIP TA.CAP. 0.47uF 25V TEESVA1E474M8R K78140009 1- B b7
C 2218 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1-5 A F5
C 2218 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 W/ CE 6- A F5
C 2218 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 W/O CE 6- A F5
C 2219 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C3
C 2220 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B7
C 2221 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2222 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2222 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2223 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A C6
C 2224 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2224 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2225 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A E3
C 2227 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E4
C 2228 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B g5
C 2229 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C4
12
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2230 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2
C 2232 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D3
C 2233 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2234 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B b7
C 2235 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C6
C 2236 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C6
C 2237 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D3
C 2238 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D3
C 2239 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A E5
C 2240 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-5 A F3
C 2240 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 W/ CE 6- A F3
C 2240 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 W/O CE 6- A F3
C 2241 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H7
C 2242 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A D4
C 2245 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A E5
C 2246 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D4
C 2247 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A F5
C 2248 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A G5
C 2249 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A B6
C 2250 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D6
C 2252 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2252 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2253 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 W/ CE 6- A E5
C 2255 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D6
C 2256 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A E5
C 2257 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A C4
C 2258 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D1
C 2258 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D1
C 2259 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B c7
C 2260 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G5
C 2261 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1-2
C 2262 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A F3
C 2262 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3-5 A F3
C 2262 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 W/ CE 6- A F3
C 2262 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 W/O CE 6- A F3
C 2263 AL.ELECTRO.CAP. 4.7uF 25V ECEV1ES4R7SR K48140001 1- A G1
C 2263 AL.ELECTRO.CAP. 4.7uF 25V EEE1ES4R7SR K48140017 81- A G1
C 2264 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A G5
C 2265 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C4
C 2266 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D4
C 2267 AL.ELECTRO.CAP. 47uF 16V EEE1CA470SP K48120005 1- A F7
C 2268 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 2269 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E4
C 2270 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2270 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2271 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D6
C 2272 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A C4
C 2273 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 2274 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G4
C 2275 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B6
C 2276 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A D6
C 2277 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A G5
C 2278 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A G5
C 2279 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A D2
C 2279 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A D2
C 2280 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C4
C 2281 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B f4
C 2282 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A C4
C 2283 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D1
C 2285 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A G5
C 2286 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A B6
C 2286 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A B6
C 2287 CHIP CAP. 10pF 50V CH GRM1882C1H100RZ01D K22174248 1- A D6
C 2288 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B b4
C 2289 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D4
13
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2290 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E6
C 2291 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A G1
C 2292 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F5
C 2293 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F7
C 2294 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d3
C 2297 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d3
C 2298 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B g5
C 2299 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B6
C 2304 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d3
C 2305 CHIP CAP. 2.5pF 50V CK GRM1884C1H2R5CZ01D K22174259 1- A A6
C 2307 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G7
C 2308 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A E2
C 2309 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E4
C 2310 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 2311 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A D4
C 2312 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D4
C 2313 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- B d3
C 2314 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A H2
C 2314 CHIP CAP. 0.1uF 25V F GRM188F11E104ZA01D K22145001 3- A H2
C 2315 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B d3
C 2316 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A A6
C 2317 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A G6
C 2318 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E2
C 2320 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B c7
C 2321 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E4
C 2322 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d3
C 2323 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d3
C 2324 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A H2
C 2324 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A H2
C 2325 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A A6
C 2327 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A E2
C 2327 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A E2
C 2328 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A G2
C 2328 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A G2
C 2329 CHIP CAP. 10pF 50V CH GRM1882C1H100RZ01D K22174248 1- A A5
C 2330 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A D6
C 2331 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1-5 A G4
C 2331 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 W/ CE 6-60 A G4
C 2331 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 W/O CE 6- A G4
C 2332 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F5
C 2333 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A F6
C 2335 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A G6
C 2336 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A F6
C 2337 CHIP CAP. 1uF 10V B GRM40B105K10PT K22100802 1- A G2
C 2337 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 3- A G2
C 2338 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A A5
C 2339 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A G5
C 2339 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A G5
C 2340 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G6
C 2341 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A H1
C 2341 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A H1
C 2342 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A G6
C 2343 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A G6
C 2344 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A F6
C 2344 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 46- A F6
C 2345 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E5
C 2346 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A F6
C 2347 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A H1
C 2347 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3-5 A H1
C 2347 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 W/O CE 6- A H1
C 2348 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A F6
C 2348 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 46- A F6
C 2349 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E3
C 2350 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A G6
C 2351 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A F6
14
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2352 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A E3
C 2352 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A E3
C 2353 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A F6
C 2353 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 46- A F6
C 2354 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B c3
C 2354 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- B c3
C 2355 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A E3
C 2356 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A E3
C 2356 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A E3
C 2357 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H5
C 2358 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F6
C 2359 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E6
C 2361 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A G2
C 2361 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A G2
C 2362 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H5
C 2363 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F6
C 2364 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F6
C 2365 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A F6
C 2366 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1- A H5
C 2366 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023 77- A H5
C 2367 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E6
C 2368 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B c3
C 2368 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- B c3
C 2369 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F6
C 2370 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H4
C 2371 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E6
C 2372 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A E3
C 2373 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A H4
C 2374 CHIP CAP. 1.5pF 50V CK GRM1884C1H1R5CZ01D K22174258 1- A F3
C 2374 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 61- A F3
C 2377 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A F6
C 2378 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E6
C 2379 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b6
C 2380 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b5
C 2382 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B g2
C 2383 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- B h3
C 2384 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- B h3
C 2385 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- B h3
C 2386 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C1
C 2386 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C1
C 2387 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C1
C 2387 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- A C1
C 2389 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B f1
C 2389 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- B f1
C 2390 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B g1
C 2391 CHIP CAP. 330pF 50V B GRM188B11H331KD01D K22174803 1- A C2
C 2392 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C2
C 2393 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B f1
C 2393 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- B f1
C 2394 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B f1
C 2394 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- B f1
C 2395 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A H6
C 2396 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A G3
C 2397 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2
C 2398 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B b7
C 2399 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B g1
C 2399 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 3- B g1
C 2401 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-60 A F3
C 2401 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 W/O CE 61- A F3
C 2402 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A E2
C 2403 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1-2 A D2
C 2404 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174809 1- A D2
C 2405 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1-14 A D4
C 2405 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 W/ CE 15- A D4
C 2405 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 W/O CE 15- A D4
15
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
C 2406 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A B3
C 2412 AL.ELECTRO.CAP. 2200uF 25V RE3-25V222MI6# K40149055 1- A H3
C 2414 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- B d3
C 2415 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 1- A B3
C 2416 CHIP CAP. 100pF 50V CH GRM2162C1H101JA01D K22170235 1- B f5
C 2416 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 3- B f5
C 2417 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D3
C 2417 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 61- A D3
C 2418 FILM CAP. 0.01uF 50V NNM103K50 K50170039 1- A G6
C 2418 FILM CAP. 0.01uF 16V ECHU1C103JB5 K57120007 3- A G6
C 2418 FILM CAP. 0.01uF 16V ECHU1C103JX5 K57120030 70- A G6
C 2419 CERAMIC CAP. 0.01uF 50V B DD112B103K50 K10179052 1- B e7
C 2419 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 3- B e7
C 2420 AL.ELECTRO.CAP. 2200uF 10V RE3-10V222MH5# K40109032 1- A B7
C 2421 AL.ELECTRO.CAP. 10uF 16V RC2-16V100MD1#-T58 K46120004 W/PA-28A 3- A H2
C 2421 AL.ELECTRO.CAP. 10uF 16V RC2-16V100MD1#-T58 K46120004 W/PA-28B 3- A H2
C 2421 AL.ELECTRO.CAP. 10uF 16V RC2-16V100MD1#-T58 K46120004 W/PA-28C 3- A H2
C 2421 AL.ELECTRO.CAP. 10uF 16V RC2-16V100MD1#-T58 K46120004 W/PA-28U 3- A H2
C 2422 CHIP CAP. 6pF 50V UJ GRM1883U1H6R0DZ01D K22174306 3- A F7
C 2423 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 4- A D2
C 2424 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 4- A B2
C 2425 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 4- A B3
C 2426 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 W/ CE 6-60 A H3
C 2426 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 61- A H3
C 2427 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 W/ CE 6- A E3
C 2428 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 W/ CE 6- B d3
C 2429 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 W/ CE 61- A F3
C 2430 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 W/ CE 61- A F5
C 2431 CHIP CAP. 470pF 50V B GRM188B11H471KA01D K22174805 74-
D 2001 DIODE DAN235U TL G2070176 1- A B3
D 2002 DIODE DAN235U TL G2070176 1- A B3
D 2004 DIODE HVU355 TRF-E G2070410 1- A B3
D 2005 DIODE HVU355 TRF-E G2070410 1- A B3
D 2006 DIODE 1SS355 TE-17 G2070470 1- B h3
D 2007 DIODE HVM17-TR G2070148 1- A C3
D 2008 VARISTOR MA28T-A(TX) G9090061 1-2
D 2009 DIODE 1SS355 TE-17 G2070470 1- A A2
D 2010 DIODE 1SS355 TE-17 G2070470 1- A A2
D 2011 DIODE HVU355 TRF-E G2070410 1- A C3
D 2012 DIODE HVU355 TRF-E G2070410 1- A C4
D 2013 DIODE HVM17-TR G2070148 1- A C3
D 2014 DIODE HVU359 TRF-E G2070452 1- B d5
D 2015 DIODE HVU359 TRF-E G2070452 1- B e5
D 2016 DIODE 1SS355 TE-17 G2070470 1- B g1
D 2017 DIODE 1SS318 TT11 G2070322 1- A B3
D 2017 DIODE 1SS356TW11 G2070468 14- A B3
D 2018 DIODE 1SS318 TT11 G2070322 1- A D3
D 2018 DIODE 1SS356TW11 G2070468 14- A D3
D 2019 DIODE DAN235U TL G2070176 1- A B3
D 2020 DIODE DAN235U TL G2070176 1- A B2
D 2021 DIODE DAN235U TL G2070176 1- A B1
D 2022 DIODE 1SS318 TT11 G2070322 1- A D3
D 2022 DIODE 1SS356TW11 G2070468 14- A D3
D 2023 DIODE 1SS318 TT11 G2070322 1- A D3
D 2023 DIODE 1SS356TW11 G2070468 14- A D3
D 2024 DIODE HVU350 TRF-E G2070380 1- A F7
D 2025 DIODE HVU350 TRF-E G2070380 1-2
D 2026 DIODE HVU359 TRF-E G2070452 1- A B3
D 2027 DIODE HVU359 TRF-E G2070452 1- A C3
D 2028 DIODE HVR100-8TRU-E G2070540 1- A C2
D 2030 DIODE HVM17-TR G2070148 1- A C3
D 2031 DIODE HVM17-TR G2070148 1- A C2
D 2032 DIODE 1SS355 TE-17 G2070470 1- B f5
D 2033 DIODE SVC341L-TD G2070720 1- A C2
D 2033 DIODE SVC347S-T-TL-E G2071210 96- A C2
16
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
D 2034 DIODE HVU359 TRF-E G2070452 1- A C3
D 2035 DIODE HVU355 TRF-E G2070410 1- A C6
D 2036 DIODE HVU359 TRF-E G2070452 1- A C3
D 2037 DIODE HVM17-TR G2070148 1- A D3
D 2038 DIODE HVR100-8TRU-E G2070540 1- A C2
D 2039 DIODE HVM17-TR G2070148 1- A C2
D 2040 DIODE SVC341L-TD G2070720 1- A D2
D 2040 DIODE SVC347S-T-TL-E G2071210 96- A D2
D 2041 DIODE DAN235U TL G2070176 1- A C2
D 2042 DIODE DAN235U TL G2070176 1- A D2
D 2043 DIODE 1SS318 TT11 G2070322 1- A D2
D 2043 DIODE 1SS356TW11 G2070468 14- A D2
D 2044 DIODE 1SS318 TT11 G2070322 1- A E3
D 2044 DIODE 1SS356TW11 G2070468 14- A E3
D 2045 DIODE 1SS318 TT11 G2070322 1- A C4
D 2045 DIODE 1SS356TW11 G2070468 14- A C4
D 2046 DIODE 1SS318 TT11 G2070322 1- A D2
D 2046 DIODE 1SS356TW11 G2070468 14- A D2
D 2047 DIODE 1SS318 TT11 G2070322 1- A D2
D 2047 DIODE 1SS356TW11 G2070468 14- A D2
D 2048 DIODE 1SS318 TT11 G2070322 1- A D3
D 2048 DIODE 1SS356TW11 G2070468 14- A D3
D 2049 DIODE 1SS318 TT11 G2070322 1-2
D 2050 DIODE 1SS355 TE-17 G2070470 1- B d4
D 2051 DIODE HVU355 TRF-E G2070410 1- A G5
D 2052 DIODE 1SS355 TE-17 G2070470 1- B d4
D 2053 DIODE HVU359 TRF-E G2070452 1- A G5
D 2054 DIODE 1SS318 TT11 G2070322 1- A E1
D 2054 DIODE 1SS356TW11 G2070468 14- A E1
D 2056 DIODE DAN235U TL G2070176 1- A E4
D 2057 DIODE HVU355 TRF-E G2070410 1- A G6
D 2058 DIODE 1SS318 TT11 G2070322 1- A D4
D 2058 DIODE 1SS356TW11 G2070468 14- A D4
D 2059 DIODE HVU355 TRF-E G2070410 1- A G6
D 2060 DIODE DAN235U TL G2070176 1- A E3
D 2061 DIODE HVU355 TRF-E G2070410 1- A G6
D 2062 DIODE 1SS355 TE-17 G2070470 1- A G2
D 2063 DIODE 1SS318 TT11 G2070322 1- A E3
D 2063 DIODE 1SS356TW11 G2070468 14- A E3
D 2064 DIODE DAN235U TL G2070176 1- B c5
D 2065 DIODE DAN202K T146 G2070182 1- A H5
D 2066 DIODE DAN202K T146 G2070182 1- A G4
D 2067 DIODE DAN235U TL G2070176 1- A E5
D 2070 DIODE DAN202K T146 G2070182 1- A C1
D 2071 DIODE DAN202K T146 G2070182 1- B g3
D 2072 DIODE DAN235U TL G2070176 1- B f1
D 2073 DIODE DAN235U TL G2070176 1- B f1
D 2074 DIODE 21DQ04 G2090317 1- B a2
D 2074 DIODE SB40W03T-TL G2070370 3- B a2
D 2075 SURGE ABSORBER DSP201M-S00B Q9000375 1- A D1
D 2076 DIODE 1SS270-E G2090408 1-2
D 2077 DIODE 1SS270-E G2090408 1-2
D 2078 DIODE DAN202K T146 G2070182 3- B e7
D 2079 DIODE GMA01U-BT G2060023 3- A D5
D 2080 DIODE GMA01U-BT G2060023 3- A C5
FB2001 FERRITE BEADS SMB304729 L9190094 W/ CE 6-60 A H1
FB2001 FERRITE BEADS SMB304729 L9190094 61- A H1
FB2002 FERRITE BEADS SMB304729 L9190094 W/ CE 6-60 A H1
FB2002 FERRITE BEADS SMB304729 L9190094 61- A H1
J 2001 CONNECTOR JPJ2545-01-510 P1090633 1- A F1
J 2002 CONNECTOR TMP-J01X-A2 P1090255 1- A E7
J 2002 CONNECTOR TMP-S01X-C1 P1091254 71- A E7
J 2003 CONNECTOR SC25-02WS P0090621 1- A H2
J 2004 CONNECTOR HEC0470-01-630 P1090567 1- A G1
J 2005 CONNECTOR 20FMZ-BT(LF)(SN) P1090903 1- A D7
17
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
J 2006 CONNECTOR TMP-J01X-A2 P1090255 1- A B5
J 2006 CONNECTOR TMP-S01X-C1 P1091254 71- A B5
J 2007 CONNECTOR TMP-J01X-A2 P1090255 1- A F3
J 2007 CONNECTOR TMP-S01X-C1 P1091254 71- A F3
J 2008 WIRE ASSY RED 80 TMP(B1)/TMP(B1) T9318155 1-5 A E5
J 2008 WIRE ASSY GRA 40 */* T9318175 W/ CE 6- A E5
J 2008 WIRE ASSY RED 80 TMP(B1)/TMP(B1) T9318155 W/O CE 6- A E5
J 2010 CONNECTOR TMP-J01X-A2 P1090255 1- A A5
J 2010 CONNECTOR TMP-S01X-C1 P1091254 71- A A5
L 2001 M.RFC 0.0047uH HK1608 4N7S-T L1690512 1- A B4
L 2002 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A B4
L 2003 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A B3
L 2004 M.RFC 0.39uH ELJ-NCR39JF L1690654 1- A B3
L 2005 M.RFC 1.2uH LK2125 1R2K-T L1690320 1- A C3
L 2006 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A B4
L 2007 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A B4
L 2008 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A B4
L 2009 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A B3
L 2010 M.RFC 0.068uH HK1608 68NJ-T L1690526 1- A C3
L 2011 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A C3
L 2012 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A B4
L 2013 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1- A C4
L 2014 M.RFC 0.056uH HK1608 56NJ-T L1690525 1- A C3
L 2015 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A C3
L 2016 M.RFC 0.068uH HK1608 68NJ-T L1690526 1- A C3
L 2018 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A C4
L 2020 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A B4
L 2022 M.RFC 1.2uH LK2125 1R2K-T L1690320 1- A D3
L 2023 M.RFC 0.12uH ELJ-NCR12JF L1690648 1- A C3
L 2024 M.RFC 0.12uH ELJ-NCR12JF L1690648 1- A D4
L 2025 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A C3
L 2026 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A D3
L 2027 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1-2
L 2028 M.RFC 1.2uH LK2125 1R2K-T L1690320 1- A B3
L 2030 M.RFC 5.6uH LK2125 5R6K-T L1690328 1- A C2
L 2032 M.RFC 0.01uH HK1608 10NJ-T L1690516 1-2
L 2033 M.RFC 6.8uH LK2125 6R8K-T L1690329 1- A C2
L 2034 M.RFC 0.0082uH HK1608 8N2J-T L1690515 1- A C3
L 2035 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1- A D3
L 2036 M.RFC 0.47uH ELJ-NCR47JF L1690655 1- A C3
L 2037 M.RFC 3.3uH LK2125 3R3K-T L1690325 1- A C2
L 2038 M.RFC 0.0082uH HK1608 8N2J-T L1690515 1- A C3
L 2039 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- B h3
L 2040 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1- A D3
L 2041 M.RFC 0.0047uH HK1608 4N7S-T L1690512 1- A B4
L 2042 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A D3
L 2043 M.RFC 1.5uH LK2125 1R5K-T L1690321 1- A C2
L 2044 M.RFC 0.18uH ELJ-NCR18JF L1690650 1- A C3
L 2045 M.RFC 1.2uH LK2125 1R2K-T L1690320 1- A C2
L 2046 M.RFC 0.39uH ELJ-NCR39JF L1690654 1- A C3
L 2047 M.RFC 0.0082uH HK1608 8N2J-T L1690515 1- A C3
L 2048 M.RFC 0.0039uH HK1608 3N9S-T L1690511 1- A B4
L 2049 M.RFC 2.7uH LK2125 2R7K-T L1690324 1- A C2
L 2050 M.RFC 0.47uH LK2125 R47K-T L1690315 1- A C3
L 2051 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1- A C4
L 2052 M.RFC 10uH LK2125 100K-T L1690331 1- A C2
L 2053 COIL 0.017uH AS030616-17NK L0022678 1- A C6
L 2054 M.RFC 1uH LK2125 1R0K-T L1690319 1- A C3
L 2055 M.RFC 0.0039uH HK1608 3N9S-T L1690511 1- A B4
L 2056 M.RFC 0.27uH ELJ-NCR27JF L1690652 1- B f5
L 2057 M.RFC 4.7uH LK2125 4R7K-T L1690327 1- A C2
L 2058 M.RFC 8.2uH LK2125 8R2K-T L1690330 1- A D2
L 2059 M.RFC 0.0039uH HK1608 3N9S-T L1690511 1- A B4
L 2060 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1- A E5
L 2061 M.RFC 0.0039uH HK1608 3N9S-T L1690511 1- A B4
18
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
L 2063 M.RFC 0.012uH HK1608 12NJ-T L1690517 1- A E5
L 2064 M.RFC 0.27uH ELJ-NCR27JF L1690652 1- B g5
L 2065 M.RFC 1.2uH LK2125 1R2K-T L1690320 1- A D2
L 2066 M.RFC 1.2uH LK2125 1R2K-T L1690320 1- A D3
L 2067 M.RFC 0.12uH ELJ-NCR12JF L1690648 1- A E3
L 2068 M.RFC 0.12uH ELJ-NCR12JF L1690648 1- A C4
L 2069 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A E5
L 2070 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A C6
L 2071 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- A D3
L 2071 M.RFC 0.056uH HK1608 56NJ-T L1690525 3- A D3
L 2071 M.RFC 0.033uH HK1608 33NJ-T L1690522 61- A D3
L 2075 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- A E5
L 2076 COIL E2 0.28-1.0-3.5T-R-S L0022597 1- A G5
L 2077 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A C4
L 2078 M.RFC 0.018uH HK1608 18NJ-T L1690519 1- A B6
L 2079 M.RFC 0.018uH HK1608 18NJ-T L1690519 1- A D6
L 2080 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- A C4
L 2081 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- A C4
L 2082 M.RFC 0.015uH HK1608 15NJ-T L1690518 1- A D6
L 2083 M.RFC 330uH FLC32T-331J L1690233 1- A D1
L 2084 M.RFC 0.018uH HK1608 18NJ-T L1690519 1- A D1
L 2086 M.RFC 0.018uH HK1608 18NJ-T L1690519 1- A D2
L 2087 M.RFC 0.12uH ELJ-NCR12JF L1690648 1- A D4
L 2088 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A B6
L 2089 M.RFC 0.0068uH HK1608 6N8J-T L1690514 1- B d3
L 2090 M.RFC 0.018uH HK1608 18NJ-T L1690519 1- A E2
L 2091 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A A6
L 2092 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- A F5
L 2094 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A G5
L 2096 M.RFC 0.015uH HK1608 15NJ-T L1690518 1- A A6
L 2097 M.RFC 0.015uH HK1608 15NJ-T L1690518 1- A D6
L 2098 COIL E2 0.26-0.9-2.5T-R-S L0022682 1- A G6
L 2099 M.RFC 0.015uH HK1608 15NJ-T L1690518 1- A A5
L 2100 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A E4
L 2101 M.RFC 0.0033uH HK1608 3N3S-T L1690510 1- A F6
L 2102 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- A F6
L 2103 M.RFC 0.12uH ELJ-NCR12JF L1690648 1- A E3
L 2105 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- A F6
L 2106 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A G6
L 2107 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A E6
L 2108 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A F5
L 2109 M.RFC 0.33uH ELJ-NCR33JF L1690653 1- A E6
L 2110 M.RFC 0.018uH HK1608 18NJ-T L1690519 1- A E3
L 2110 M.RFC 0.022uH HK1608 22NJ-T L1690520 97- A E3
L 2112 M.RFC 0.047uH HK1608 47NJ-T L1690524 1- A E6
L 2113 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- B h3
L 2114 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A E3
L 2114 M.RFC 0.0068uH HK1608 6N8J-T L1690514 97- A E3
L 2115 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- A E3
L 2115 M.RFC 0.018uH HK1608 18NJ-T L1690519 97- A E3
L 2116 M.RFC 0.015uH HK1608 15NJ-T L1690518 1- A D4
L 2116 M.RFC 0.018uH HK1608 18NJ-T L1690519 97- A D4
L 2117 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- A D4
L 2118 M.RFC 0.0047uH HK1608 4N7S-T L1690512 1- A F3
L 2120 M.RFC 0.22uH HK1608 R22J-T L1690940 1- A C6
L 2121 M.RFC 0.39uH LK1608 R39K-T L1690413 1- A B3
L 2122 M.RFC 0.39uH LK1608 R39K-T L1690413 1- A D3
L 2123 M.RFC 0.01uH HK1608 10NJ-T L1690516 1- A F3
L 2124 M.RFC 0.39uH LK1608 R39K-T L1690413 1- A G6
L 2125 M.RFC 0.39uH LK1608 R39K-T L1690413 1- A G5
L 2126 M.RFC 0.39uH LK1608 R39K-T L1690413 1- A G5
L 2127 M.RFC 0.39uH LK1608 R39K-T L1690413 1- A G6
L 2128 M.RFC 0.056uH HK2125 56NJ-T L1690386 3- A D3
L 2129 M.RFC 100uH LAL02NA101K L1190307 W/ CE 6-60 A F3
L 2129 M.RFC 100uH LEM2520T101J L1690635 61- A F3
19
RF Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
L 2130 M.RFC 2.2uH LK1608 2R2K-T L1690634 61- A D2
L 2131 M.RFC 0.22uH HK1608 R22J-T L1690940 61- A D3
L 2132 M.RFC 0.027uH HK1608 27NJ-T L1690521 61- A D3
L 2133 M.RFC 0.01uH HK1608 10NJ-T L1690516 61- A C3
P 1001 TERMINAL B4 AG M3 Q6000114 4-
Q 2001 IC M5223AFP 600C G1092955 1- A G1
Q 2002 IC M5223AFP 600C G1092955 1- A B7
Q 2003 IC M5223AFP 600C G1092955 1- B b7
Q 2004 TRANSISTOR DTC114EK T146 G3070002 1- B e7
Q 2005 TRANSISTOR DTC114EK T146 G3070002 1- B h3
Q 2006 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A D7
Q 2007 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A E7
Q 2008 TRANSISTOR IMD3 T108 G3070053 1- B c1
Q 2009 TRANSISTOR DTC114EK T146 G3070002 1- A A2
Q 2010 TRANSISTOR DTC114EK T146 G3070002 1- A C7
Q 2011 IC NJM78L09UA-TE2 G1091305 1- A B6
Q 2012 IC NJM78L05UA-TE1 G1091325 1- A C7
Q 2013 IC UPC2711T-E3 G1092861 1- A B4
Q 2014 TRANSISTOR DTC114EK T146 G3070002 1- A A1
Q 2015 TRANSISTOR DTC114EK T146 G3070002 1- B g1
Q 2016 FET 2SK210-GR(TE85R.F) G3802107G 1- A F7
Q 2017 IC L78M05T-TL G1091731 1- A H7
Q 2018 IC MB15A02PFV1-G-BND-EFE1 G1092541 1- A D7
Q 2019 FET 3SK228XR-TR G4802287 1- A D3
Q 2019 FET SGM2016AM-T7 G4070012 61- A D3
Q 2020 FET 3SK228XR-TR G4802287 1- A C3
Q 2020 FET SGM2016AM-T7 G4070012 61- A C3
Q 2021 FET 3SK228XR-TR G4802287 1- A C4
Q 2021 FET SGM2016AM-T7 G4070012 61- A C4
Q 2022 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A F7
Q 2023 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B e5
Q 2024 IC NJM78L09UA-TE2 G1091305 1- A H7
Q 2025 IC UPC2711T-E3 G1092861 1- B h3
Q 2027 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B f5
Q 2028 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A G7
Q 2029 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- A F7
Q 2030 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- A C6
Q 2031 FET 3SK228XR-TR G4802287 1- A D2
Q 2031 FET SGM2016AM-T7 G4070012 61- A D2
Q 2032 FET 3SK228XR-TR G4802287 1- A D3
Q 2032 FET SGM2016AM-T7 G4070012 61- A D3
Q 2033 FET 3SK228XR-TR G4802287 1- A E3
Q 2033 FET SGM2016AM-T7 G4070012 61- A E3
Q 2034 TRANSISTOR 2SC3585-T2B R42 G3335857 1- A C4
Q 2035 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- A C6
Q 2036 IC UPC2711T-E3 G1092861 1- A C4
Q 2037 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- B e7
Q 2038 IC NJU7201U30-TE1 G1093167 1- A H7
Q 2039 TRANSISTOR FMC3 T148 G3070046 1- A F3
Q 2040 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- A B6
Q 2041 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- A D6
Q 2042 TRANSISTOR FMC3 T148 G3070046 1- A F2
Q 2043 TRANSISTOR FMC3 T148 G3070046 1- A F3
Q 2044 TRANSISTOR FMC3 T148 G3070046 1- B b3
Q 2045 FET 3SK228XR-TR G4802287 1- A D1
Q 2045 FET SGM2016AM-T7 G4070012 61- A D1
Q 2047 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- A G5
Q 2048 TRANSISTOR FMC3 T148 G3070046 1- A F2
Q 2049 TRANSISTOR FMC3 T148 G3070046 1- A F3
Q 2050 TRANSISTOR FMC3 T148 G3070046 1- B f4
Q 2051 TRANSISTOR FMC3 T148 G3070046 1- B b3
Q 2052 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- A G5
Q 2053 TRANSISTOR FMC3 T148 G3070046 1- A F2
Q 2054 TRANSISTOR FMC3 T148 G3070046 1- B b3
Q 2055 IC MB15E05PFV1-G-BND-EF G1093012 1- A F7
20
Loading...
