Radial Engineering LX3 User's Guide

Line SpLitter

jenSen tranSformer equipped

uSer guide

Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam BC V3C 5M5

Tel: [phone] • Fax: [phone] • Email: [e-mail]

radiaL LX-3 paSSive Line SpLitter
uSer guide

Introduction ....................................................................................... 1

Features ........................................................................................... 2

Overview........................................................................................... 3

Making Connections ......................................................................... 4

Using the Pad ................................................................................... 4

Using the Ground Lift........................................................................ 5

Optional Mounting Accessories ........................................................ 6

FAQ .................................................................................................. 7

Specications ................................................................................... 8

Block Diagram .................................................................................. 9

Radial Limited Warranty ...................................................Back Cover

Thank you for purchasing the Radial LX-3™ line-level audio splitter. We are condent that you will nd that it exceeds all expec­tations in terms of sound quality and reliability.

Before you begin using the LX-3, please take a few minutes to read this short manual and familiarize yourself with the various
connections and features the LX-3 offers. For additional information, please visit the radial website, where we post frequently

asked questions and updates that may answer any questions you have. If you still nd yourself in need of more information, feel

free to send us an email at [e-mail] and we will do our best to respond in short order.

The LX-3 is a high performance splitter that will provide you with years of trouble-free operation while offering the best possible
audio quality. Enjoy!

Radial Engineering Ltd. LX-3™ Line Splitter User Guide

1

FEATURES

1. INPUT PAD: Reduces the input by -12dB to allow for

extra-hot line-level signals to be connected.

2. XLR/TRS INPUT: Combination XLR or ¼” input.

3. THRU GROUND LIFT: Disconnects pin-1 ground at the

XLR output.

4. DIRECT THRU OUTPUT: Direct output to connect to
recording or monitor systems.

5. ISO OUTPUT 1&2: Transformer isolated outputs
eliminates hum & buzz caused by ground loops.

6. BOOK END DESIGN: Creates a protective zone around
the jacks and switches.

7. ISO GROUND LIFTS: Disconnects pin-1 ground at the
XLR outputs.

8. NO SLIP PAD: Provides electrical & mechanical isolation
and keeps the unit from sliding around.

Radial Engineering Ltd. LX-3™ Line Splitter User Guide

2

1 2

6 7 9

3 4

5
