RADEL SUNADAVINODINI ELECTRONIC VEENA
USER MANUAL
INTRODUCTION
Congratulations! You are the proud owner of a quality product - the electronic veena 'Sunadavinodini".
The electronic veena, 'Sunadavinodini' is a completely self-contained, portable veena that can be assembled or
dismantled in seconds.
The features of the electronic veena 'Sunadavinodini' are:
1. Enhanced volume, with the amplifier, loudspeaker and electronic tambura built into the right side gourd
that rests on the ground.
2. Adjustable volume
3. Increased sustenance of notes; thus long passages can be played with fewer plucks
4. Adjustable frets on a wooden fret board, eliminating the more delicate wax fret board
5. Frets can be adjusted easily by the user
6. Imported Guitar keys for easy tuning
7. Built-in electronic tambura for sruti
8. Complete portability, as the sound box of the veena is dispensed with, and replaced by a plank of wood.
9. Easy assembly / disassembly
10. Battery back-up facility
With the Sunadavinodini electronic veena, the vainika can easily carry the instrument anywhere, assemble it in
seconds, and enjoy the music that he / she creates with the enhanced possibilities provided.
ASSEMBLY OF THE SUNADAVINODINI:
The Instrument consists of a fret-board and two detachable gourds ('sorekkai' or 'burude') – one with the
amplispeaker and tambura, and the other a support gourd to place on the lap.
OPERATING INSTRUCTIONS
The Sunadavinodini electronic veena can be used at any voltage from 90V – 260V AC without using any voltage
selector switch.
ASSEMBLY OF VEENA: Fix the detachable gourds to the fret-boards by inserting the three screws on the
bottom of the fret-board into the keyholes on the top of the gourd bracket, control panel facing you in the amplispeaker gourd, and the ‘Sunadavinodini’ label facing you in the other gourd. Twist the gourds into place just like
fixing a light bulb into its socket. Tighten the small locking screw provided below the fixing bracket of the gourd,
to prevent the gourd from detaching accidentally.
Connect the veena to the ampli-speaker gourd with the two connecting cords provided, for the main strings and
taala strings respectively. One end of each connecting cord fits into its socket under the fret-board. The other
end of the cord fits into the respective socket next to the power button on the ampli-speaker gourd. Connect the
mains cord of the ampli-speaker (right side) gourd from the mains socket on the veena to the mains power
supply. Switch ON the ampli-speaker gourd by pressing the power button and adjust the volume to your
requirement. Switch ON the tambura using the controls on the left side of the same gourd, and adjust the volume
by pressing the ▲and ▼ buttons. Tune to the sruti required using the ▲and ▼ buttons.
Page 2
Fine-tune pitch if required by pressing 'MODE' and then ▲and ▼ buttons. Use PA / MA / NI selection if required.
Adjust and tune the veena strings to this sruti, using the guitar keys provided. These keys perform both coarse
and fine-tuning.
Switch off the gourd after use. Disconnect power cord. Carefully detach the connectors on the gourd from the
fretboard.To disassemble, unscrew the locking screws on each gourd. Twist and remove.
USING ON BATTERY: Recommended: Rechargeable Exide 12V battery no. EP 7-12 ( battery not included). In
case of AC Mains power failure, remove the AC Mains cord and connect the battery cord provided to the socket
market 'BAT'. Connect the other end of the cord to a 12V battery pack, ENSURING THAT THE RED LEAD IS
CONNECTED TO THE POSITIVE TERMINAL AND THE BLACK LEAD IS CONNECTED TO THE NEGATIVE
TERMINAL OF THE BATTERY.
MAINTENANCE AND ADJUSTMENT
1. Changing strings: Use only good quality magnetic ('Electro') strings to ensure that all the strings are picked up
evenly. The 'Sunadavinodini' uses strings with a metal bead looped at one end. Hence use only strings specially
made for the Sunadavinodini. (available as accessories on our website www.radel.in). Insert the free end of the
string through the hole on the bridge and pull it right up to the tuning keys at the tail of the veena.
Insert the end of the string into the hole on the tuning shaft. Cut off excess length of the string so that only about
three or four turns of the string are coiled around the tuning rod. Turn the tuning key so that the wire coils around
the rod from the top. Use the correct gauge of wire for each string depending on the pitch.
2. Adjustment of frets: All the frets are adjustable and can be moved to any position along the fret-board. Use a
No.7 spanner (supplied with the instrument) to slightly loosen the nuts below each end of the fret. Move the fret
to any position and check for the correctness of the note. After ascertaining the correct position, tighten the nuts
on both ends of the fret without changing its position. CAUTION: Do not apply excessive force on the nuts as this
is likely to damage the threads of the nut.
WARRANTY
Like all Radel products, the Sunadavinodini carries a warranty of 3 years from the date of sale. (Loudspeakers
and power cords carry a warranty of 12 months). This warranty is subject to the standard terms and conditions of
the manufacturer. All users are advised to ensure that the warranty counterfoils attached to this manual are
returned to Radel Electronics Pvt. Ltd. within 15 days of purchase. In case of any problems, users are advised to
contact the manufacturers without any delay giving details of the problem, date of purchase, dealer’s name and
purchase document reference.
Warranty is applicable only in India.
The manufacturers invite users to feel free to send any feedback, suggestions and special requirements
regarding the product to them.
The manufacturers reserve the right to make changes to the product as part of technology enhancement as and
when they deem fit.
This Radel product is supplied with the following free accessories:
a) Power cord, (b) User Manual, (c ) Soft carry case (d) spare set of strings (e) spare frets (2 nos) (f) spanner (g)
battery cord (h) connection cord pair (g) spare knurling screws to fix gourds –2 pcs
For a video demonstration of all features of the Sunadavinodini, go to this link:
http://www.youtube.com/view_play_list?p=9B2974ADDC7AE55A
E-mail:
General enquiries: [email protected]
Service requests: [email protected]
Website: www.radel.in
