GOOSE & ARM24 INSTALLATION INSTRUCTIONS
Thank you for buying RAB lighting xtures. Our goal is to design the best quality products to get the job done right. We’d like to hear your comments. Call
the Marketing Department at 888-RAB-1000, or email: marketing@rab web .co m
IMPORTANT
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
RAB xtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper
grounding is required for safety. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT
AND THE HAZARDS INVOLVED.
WARNING: Make certain power is OFF before installing or maintaining xture. No user serviceable
parts inside.
GOOSE
CAUTION: Use mounting hardware appropriate for
the mounting surface and weight of the xture.
1. Make supply connections in recessed junction box.
2. Mount Wall Plate to wall through (4) Mounting Holes
using appropriate hardware for your
mounting surface.
3. Mount xture on other end of GOOSE. Works with
any 1/2” NPS threaded mounting.
4. Tighten Set Screws and all other screws
and hardware.
5. To ensure weatherproof seal, apply weatherproof
silicone sealant to all unused plugs and holes and all
along the edge of the Wall Plate. Use Teon tape or
use weatherproof silicone sealant on Goose threads.
Mounting
Holes (4)
GOOSE
ARM24
CAUTION: Use mounting hardware appropriate for
the mounting surface and weight of the xture.
1. Make supply connections in recessed junction box.
2. Mount Wall Plate to wall through (4) Mounting Holes
using appropriate hardware for your
mounting surface.
3. Mount xture on other end of ARM24. Works with
any 1/2” NPS threaded mounting.
4. Tighten Set Screws and all other screws
and hardware.
5. To ensure weatherproof seal, apply weatherproof
silicone sealant to all unused plugs and holes and all
along the edge of the Wall Plate. Use Teon tape or
use weatherproof silicone sealant on Arm24 threads.
Mounting
Holes (4)
Wall Plate
GOOSE ARM24 IN 0612
Set
Screws (2)
ARM24
Set
Screws (2)
Wall Plate
Note: These instructions do not cover all details or variations
in equipment nor do they provide for every possible situation
during installation, operation or maintenance.
Page 2
ARMSV24 INSTALLATION INSTRUCTIONS
Thank you for buying RAB lighting xtures. Our goal is to design the best quality products to get the job done right. We’d like to hear your comments. Call the
Marketing Department at 888-RAB-1000, or email: marketing@ra bwe b.c om
IMPORTANT
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
RAB xtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper
grounding is required for safety. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT
AND THE HAZARDS INVOLVED.
WARNING: Make certain power is OFF before installing or maintaining xture. No user serviceable
parts inside.
ARMSV24
24” Arm with swivel for WPLED10, WPLED13 and WPLED20 (Fixtures sold separately).
CAUTION: Follow mounting orientation restrictions on xture instructions.
1. Remove Door from xture. Remove junction box or mounting plate from xture. Connect leads from ARMSV24 to
xture. Make the wiring connections inside of the xture using UL approved connectors.
2. Mount the Swivel Adaptor to the xture with four Housing Screws. Use the provided nuts and washers for two of the
four Housing Screws as shown below.
3. Replace Door. Tighten all door screws and check seal of door gasket.
4. Make supply wiring connections in recessed junction box with UL approved connectors. Mount Wall Plate and xture
assembly to wall with hardware appropriate for your mounting surface.
5. Tighten set screws and all other screws and hardware. To ensure weatherproof seal, apply weatherproof silicone
sealant to all unused plugs and holes and around the edge of the Wall Plate. Use Teon tape on Arm threads or use
weatherproof silicone sealant between Arm and Swivel Adaptor.
LPACK
(not supplied)
Swivel
Adaptor
Arm24
Housing
Screws (4)
Door
ARMSV24 IN 0712
Wall Plate
Note: These instructions do not cover all details or variations
in equipment nor do they provide for every possible situation
during installation, operation or maintenance.
