RabbitCore RCM2100
1. INTRODUCTION & OVERVIEW
The RCM2100 series is an advanced line of m odules that i ncorporates the powerful Rabbit 2000 microprocessor, flash memory, static RAM and an RJ-45 Ethernet port, all on a PCB the
size of a business card.
The RCM2100 series modules are designed for use on a motherboard that supplies power
and interface to real-world I/O devices. Up to 40 pins of I/O and four serial ports are available for system interfacing.
To accommodate a variety of user and production needs, the RCM2100 family includes
versions with varying amounts of onboard memory. Models with and without the Ethernet
port are available, to permit simultaneous development of Ethernet-capable and cheaper
non-Ethernet versions of production systems. All modules within the family are pin-forpin compatible and may be installed or swapped in a matter of minutes.
1.1 RCM2100 Series Description
There are four production models in the RCM2100 module series, with an additional module that can be ordered in production quantities. If the standard models do not serve a
user’s needs, other variations can be specified and ordered in production quantities. (Con-
tact your Z-World or Rabbit Semiconductor sales representative for details.)
Table 1 below provides a summary of all the models in the RCM2100 family.
Table 1. RCM2100 Versions
Feature RCM2100 RCM2110 RCM2120 RCM2130
Microprocessor Rabbit 2000 running at 22.1 MHz
Flash Memory 512k 128k 512k 128k
Static RAM 512k 256 k 512k 256 k
General-Purpose I/O34344040
Ethernet RJ-45 RJ-45 None None
4, high-speed, CMOS-compatibl e;
Serial P orts
1 clocked port dedicated to programming port use.
2 configurable as clocked ports;
Getting Started 1
1.1.1 Standard Ethernet Versions
There are two RCM2100 series modules that incorporate an Ethernet port:
RCM2100.
The RCM2100 is the most fully-equipped module in the family, with the Ethernet port, 512k
flash memory and 512k static RAM. The Ethernet port uses portions of two of the Rabbit 2000
microprocessor’s parallel p orts, red ucing the availabl e number of I/O pi ns to 34. This is the vers ion
included in the Development Kit.
RCM2110. The RCM2110 is identical to the RCM2100 except that it is equipped with 128k of SRAM
and 256k of flash memory.
1.1.2 Standard Non-Ethernet Versions
To accommodate developers and users who want the RCM2100’s footprint and capabilities other than the integrated Ethernet port, two standard versions of the module areavailable without the Ethernet hardware:
RCM2120.
The RCM2120 is equipped with 512k flash memory and 512k static RAM, but does not
include the Ethernet port hardware. In its place, ports D and E of the Rabbit 2000 microprocessor
are enabl ed, giving this module 40 I/O pins.
RCM2130. The RCM2130 is identical to the RCM2120 except that it is equipped with 128k of SRAM
and 256k of flash memory.
1.1.3 Other Factory Versions
To further accommodate developers with specific needs, an additional version of the
RCM2100 module is available on special order:
RCM2115. The RCM2115 is equipped with 256k flash memory and 128k static RAM as well as the Eth-
ernet port. This version does not include the RJ-45 jack and associated interface transformers. The
Ethernet signals are brought to a header for use by the production system. (Users will have to provide the interface components within their design.)
In addition to these standard models, production quantities of modules with custom configurations of memory, I/O and Ethernet capability can be ordered.
1.1.4 Physical & Electrical Specifications
Table 2 lists the basic specifications for all models in the RCM2100 series.
Table 2. RCM2100 Specifications
Specification Data
Power Supply 4.75–5.25 V DC (140 mA at 22.1 MHz clock speed)
Size 2.0" × 3.5" × 0.85" (51mm × 89 mm × 22 mm)
Environmental
NOTE: For complete product specifications, see Appendix A in the RabbitCore
RCM2100 User’s Manual.
–40
°C to 70°C, 5–95% humidity, noncondensing
2 RabbitCore RCM2100
The RCM2100 modules have two 40-pin headers to which cables can be connected, or
which can be plugged into matching sockets on a production device. The pinouts for these
connectors are shown in Figure 1 below.
VCC
PCLK
PA6
PA4
PA2
PA0
BA11
BA9
BA7
BA5
BA3
BA1
PC0
PC2
PC4
PC6-TXA
PD0
PD2
PD4
PD6
J1
GND
PA7
PA5
PA3
PA1
BA12
BA10
BA8
BA6
BA4
BA2
BA0
PC1
PC3
PC5
PC7-RXA
PD1
PD3
PD5
PD7
These pinouts are as seen on
Note:
the Bottom Side of the module.
PB0
PB2
PB4
PB6
GND
BD6
BD4
BD2
BD0
PE6
PE4
PE2
PE0
VCC
VRAM
SMODE1
/RES_OUT
STATUS
/BIORD
GND
J2
PB1-CLKA
PB3
PB5
PB7
BD7
BD5
BD3
BD1
PE7
PE5
PE3
PE1
GND
VBAT
/WDO
SMODE0
/RES_IN
/BIOWR
/BBUFEN
VCC
Figure 1. RCM2100 Pinout
Getting Started 3
1.2 Development Software
The RCM2100 series of modules uses the Dynamic C development environment for rapid
creation and debugging of runtime applications. Dynamic C provides a complete development environment with integrated editor , compiler and source-level debugger. It interfaces
directly with the target system, eliminating the need for complex and unreliable in-circuit
emulators.
Dynamic C must be installed on a Windows workstation with at least one free serial
(COM) port for communication with the target system. See Chapter 3., “Soft wa re Ins tal lation & Overview,” for complete information on installing Dynamic C.
NOTE: The RCM2100 series modules require Dynamic C v7.04 or later for develop-
ment. A compatible version is included on the Development Kit CD-ROM.
4 RabbitCore RCM2100
1.3 How to Use This Manual
This Getting Started manual is intended to give users a quick but solid start with the
RCM2100 series modules. It does not contain detailed information on the module hardware capabilities, the Dynamic C development environment, or the TCP/IP software support for the integrated Ethernet port. Most users will want more detailed information on
some or all of these topics in order to put the RCM2100 module to effective use.
1.3.1 Additional Product Information
Detailed information about the RCM2100 series will be found in the RabbitCore
RCM2100 User’s Manual, provided on the accompanying CD-ROM in both HTML and
Adobe PDF format.
Some advanced users may choose to skip the rest of this introductory manual and proceed
directly with the detailed hardware and software information in the User’s Manual.
NOTE: We recommend that anyone not thoroughly familiar with Z-World controllers at
least read through the rest of this manual to gain the necessary familiarity to make use
of the more ad vanced information.
1.3.2 Additional Reference Information
In addition to the product-specific information contained in the RabbitCore RCM2100
User’s Manual, several higher-level reference manuals are provided in HTML and PDF
form on the accompanying CD-ROM. Advanced users will find these references valuable
in developing systems based on the RCM2100 series modules:
• Dynamic C Premier User’s Manual
• An Introduction to TCP/IP
• Dynamic C TCP/IP User’s Manual
• Rabbit 2000 Microprocessor User’s Manual
1.3.3 Using Online Documentation
We provide the bulk of our user and reference documentation in two electronic formats,
HTML and Adobe PDF. We do this for several reasons.
We believe that providing all users with our complete library of product and reference
manuals is a useful convenience. However, printed manuals are expensive to print, stock
and ship. Rather than include and charge for manuals that every user may not want, or provide only product-specific manuals, we choose to provide our complete documentation
and reference library in electronic form with every development kit and with our Dynamic
C development environment.
NOTE: The most current version of Adobe Acrobat Reader can always be downloaded
from Adobe’s web site at http://www.adobe.com.
We recommend that you use version 4.0 or later.
Getting Started 5
Providing this documentation in electronic form saves an enormous amount of paper by
not printing copies of manuals that users don’t need. It reduces the number of outdated
manuals we have to discard from stock as well, and it makes providing a complete library
of manuals an almost cost-free option. For one-time or infrequent reference, electronic
doc uments are more convenient than printed ones—after all, they aren’t taking up shelf or
desk space!
Finding Online Documents
The online documentation is installed along with Dynamic C, and an icon for the documentation menu is placed on the workstation’s desktop. Double-click this icon to reach the
menu. If the icon is missing, create a new desktop icon that points to
docs folder, found in the Dynamic C installation folder.
default.htm in the
The latest versions of all documents are always available for free, unregistered download
from our web sites as well.
Printing Electronic Manuals
W e recognize that many users prefer printed manuals for some uses. Users can easily print
all or parts of those manuals provided in electronic form. The following guidelines may be
helpful:
• Print from the Adobe PDF versions of the files, not the HTML versions.
• Print only the sections you will need to refer to more than once.
• Print manuals overnight, when appropriate, to keep from tying up shared resources dur-
ing the work day.
• If your printer supports duplex printing, print pages double-sided to save paper and
increase convenience.
• If you do not have a suitable printer or do not want to print the manual yourself, most
retail copy shops (e.g. Kinkos, AlphaGraphics, etc.) will print the manual from the PDF
file and bind it for a reasonable charge—about what we would have to charge for a
printed and bound manual.
6 RabbitCore RCM2100
2. HARDWARE SETUP
This chapter describes the RCM2100 series hardware in more
detail, and explains how to set up and use the accompanying
prototyping and development board.
NOTE: This chapter (and this manual) assume that you have the RabbitCore RCM2100
Development Kit. If you purchas ed an RCM2100 seri es mo dule by itse lf, yo u will have
to adapt the information in this chapter and elsewhere to your test and development
setup.
2.1 Development Kit Contents
The RCM2100 Development Kit contains the following items:
• RCM2100 module with Ethernet port, 512K flash memory and 512K SRAM.
• RCM2100 Prototyping Board with accessory hardware and components.
• Wall transformer power supply, 12 V DC, 500 mA. (Included only with Development
Kits sold for the North American market. Overseas users will have to substitute a
power supply compatible with their local mains power.)
• 10-pin header to DE9 programming cable with integrated level-matching circuitry.
• Dynamic C SE CD-ROM, with complete product documentation on disk.
• This Getting Started manual.
• Registration card.
Getting Started 7
2.2 Overview of the Prototyping Board
The Prototyping Board included in the Development Kit makes it easy to connect an
RCM2100 module to a power supply and a PC workstation for development. It also provides an array of basic I/O peripherals (switches and LEDs), as well as a prototyping area
for more advanced hardware development.
For the most basic level of evaluation and development, the Prototyping Board can be
used without modification.
As you progress to more sophisticated experimentation and hardware development, modifications and additions can be made to the board without modifying or damaging the
RCM2100 module itself.
The Prototyping Board is shown in Figure 2 below, with its main features identified
RCM2100
Connectors
Voltage
Regulator
Power
Input
Power
LED
Reset
Switch
User
LEDs
RS-232
Area
RCM2100
Extension Headers
8 RabbitCore RCM2100
Through-Hole
Prototyping Area
Figure 2. RCM2100 Prototyping Board
Vcc and GND
Buses
SMT Prototyping
Area
2.2.1 Prototyping Board Features
Power Connection. A 3-pin header is provided for connection of a power supply. Note that it is sym-
metrical, with both outer pins connected to ground and the center pin connected to the raw V+
input. The cable of the wall transformer provided with the North American version of the Development Kit ends in a connector that is correctly connected in either orientation.
Users providing their own power supply should ensure that it delivers 9–24 V DC at not less than
500 mA. The voltage regulator will get warm in use, but lower supply voltages will reduce thermal
dissipation from the device.
Regulated Power Supply. The raw DC voltage provided at the POWER IN jack is routed to a 5 V lin-
ear voltag e regulator, which provides stable power to the RCM2100 modu le and the Prototyping
Board. A Shottky diode protects the power supply against damage from reversed raw power connections.
Power LED. The power LED lights whenever power is connected to the Prototyping Board.
Reset Switch. A momentary-contact, normally open switch is connected directly to the RCM2100’s
/RES_IN pin. Pressing the switch forces a hardware reset of the system.
I/O Switches & LEDs. T wo mo mentary -con tac t, nor mally op en s witch es ar e conn ected to th e PB2 an d
PB3 pins of the RCM2100 module, and may be read as inputs by sample applications.
T w o LEDs are connected to the PA0 and PA1 pins of t he mo dule, and may be driven as output indi -
cators by sample applications. (Two more LEDs, driven by PA2 and PA3, may be added to the Prototyping Board for additional outputs.)
All the LEDs are connected through JP1, which has traces shorting adjacent pads together. These
traces may be cut to disconnect the LEDs, and an 8-pin header soldered into JP1 to permit their
selective reconnection with jumpers. See Figure 3 for details.
Expansion Areas. The Prototyping Board is provided with several unpopulated areas for expansion of
I/O and interfacing capabilities. See the next section for details.
Prototyping Area. A generous prototyping area has been provided for the installation of through-hole
components. Vcc (5 V DC) and Grou nd buses run around the edge of this area. An ar ea fo r s urfacemount devices is provided to the right of the through-hole area. (Note that there are SMT device
pads on both top and bottom of the Prototyping Board.)
Getting Started 9
2.2.2 Prototyping Board Expansion
The Prototyping Board comes with several unpopulated areas, which may be filled with
components to suit the user’s development needs. After you have experimented with the
sample programs in Chapter 4, you may wish to expand the board’s capabilities for further
experimentation and development. Refer to the Prototyping Board schematic (090–0116)
for details as necessary.
Module Extension Headers. The complete pin set of the RCM2100 module is duplicated at these
two headers. Developers can solder wires directly into the appropriate holes, or, for more flexible
development, two 40-pin header strips can be soldered into place. See Figure 1 on page 3 for the
header pinouts.
RS-232 Port. Two 2-wire or one 5-wire RS-232 serial port can be added to the Prototyping Board by
installing a driver IC and four capacitors where indicated. The Maxim MAX232 driver chip or a
similar device is recommended for U2. Refer to the Prototyping Board schematic for additional
details.
A 10-pin 0.1-inch spacing header strip can be installed at J6 to permit connection of a ribbon cable
leading to a standard DE-9 serial connector.
NOTE: The RS-232 chip, capacitors and header strip are available from electronics dis-
tributors such as Digi-Key and Mouser Electronics.
Additional LEDs.
at DS4 and DS5. The cathode lead (longer o f th e two, marked by a flat on the LED case) should go
towards the module.
Two additional LEDs (supplied with the development kit) can be soldered into place
Prototyping Board Component Header. Several I/O pins from the module are hardwired to the
prototyping board LEDs and switches.
To disconnect these devices and permit the pins to be used for other purposes, cut the traces
between the pin rows. Use an exacto knife or similar tool to cut or break the traces crossing JP1, in
the area indicated in Figure 3.
To permit selective reconnection of the devices, jumpers may be placed across the 8-pin header
strip at JP1.
Figure 3. Where to Cut Traces to Permanently Disable
Demonstration Hardware on Prototyping Board
10 RabbitCore RCM2100
2.3 Development Hardware Connections
There are four steps to connecting the prototyping board for use with Dynamic C and the
sample programs:
1. Attach the RCM2100 module to the Prototyping Board.
2. Connect the programming cable between the RCM2100 module and the workstation PC.
3. Connect the module’s Ethernet port to a PC’s Ethernet port, or to an Ethernet network.
4. Connect the power supply to the Prototyping Board.
Getting Started 11
2.3.1 Attach Module to Prototyping Board
Turn the RCM2100 module so that the Ethernet connector is on the left, as shown in Figure 4
below. Align the module headers J1 and J2 into sockets J1 and J3 on the Prototyping Board.
Figure 4. Installing the RCM2100 Module on the Prototyping Board.
Note the orientation of the module.
NOTE: It is important that you line up the RCM2100 pins on headers J1 and J2 exactly
with the correspondin g pi ns of headers J1 and J3 on the Prototy ping Board. The header
pins may become bent or damaged if the pin alignment is offset, and the module will
not work.
Press the module’s p ins firmly into the Prototyping Board headers. The i nstalled module is
shown in Figure 5 below.
Figure 5. RCM2100 Installed and Seated on the Prototyping Board
12 RabbitCore RCM2100
2.3.2 Connect Programming Cable
The programming cable connects the RCM2100 module to the PC running Dynamic C, to
download programs and to monitor the RCM2100 for debugging.
Connect the 10-pin connector of the programming cable labeled
PROG to header J3 on
the RCM2100 module as shown in Figure 6 below. Be sure to orient the red edge of the
cable towards pin 1 of the connector. (Do not use the DIAG connector , which i s used for a
normal serial connection.)
Note Pin 1 Indicator
Figure 6. Attaching Programming Cable to the RCM2100
NOTE: The stripe on the cable is towards pin 1 of the header J5.
Connect the other end of the programming cable to a COM port on your PC. Make a note
of the port to which you connect the cable, as Dynamic C needs to have this parameter
configured when it is installed.
NOTE: COM 1 is the default port used by Dynamic C.
Getting Started 13
2.3.3 Connect Ethernet Network Cable
Programming and development can be done with the RCM2100 without connecting the
Ethernet port to a network. However, if you will be running the sample programs that use
the Ethernet capability or will be doing Ethernet-enabled development, you should connect the RCM2100’s Ethernet port at this time.
There are four options for connecting the RCM2100 module to a network for development
and runtime purposes. The first two options permit total freedom of action in selecting network addresses and use of the “network,” as no action can interfere with other users. We
recommend one of these options for initial development.
•
No LAN — The simplest alternative for desktop development. Connect the RCM2100’s
Ethernet port directly to the workstation’s network interface card using an RJ-45 cross-
over cable. A crossover cable is a special cable that flips some connections between the
two connectors and permits direct connection of two client systems. A standard RJ-45
network cable will not work for this purpose.
Micro-LAN — Another simple alternative for desktop development. Use a small Eth-
•
ernet 10Base-T hub and connect both the workstation’s network interface card and the
RCM2100’s Ethernet port to it, using standard network cables.
The following options require more care in address selection and testing actions, as conflicts with other users, servers and systems can occur:
• LAN — Connect the RCM2100’s Ethernet port to an existing LAN, preferably one to
which the development workstation is already connected. You will need to obtain IP
addressing information from your network adminstrator.
• WAN — The RCM2100 series is capable of direct connection to the Internet and other
Wide Area Networks, but exceptional care should be used with IP address settings and
all network-related programming and development. We recommend that development
and debugging be done on a local network before connecting a RabbitCore system to
the Internet.
NOTE: Checking and debugging the initial setup on a micro-LAN is recommended
before connecting the system to a LAN or WAN.
14 RabbitCore RCM2100
2.3.4 Connect Power
When all other connections have been made, you can connect power to the RCM2100 Prototyping Board.
Hook the connector from the wall transformer to header J5 on the Prototyping Board as
shown in Figure 7 below. The connector may be attached either way as long as it is not
offset to one side.
Figure 7. Power Supply Connections to Prototyping Board
Plug in the wall transformer. The power LED on the Prototyping Board should light up.
The RCM2100 and the Prototyping Board are now ready to be used.
NOTE: A RESET button is provided on the Prototyping Board to allow hardware reset
without disconnectin g power.
To power down the Prototyping Board, unplug the power connector from J5. You should
disconnect power before making any circuit adjustments in the prototyping area, changing
any connections to the board, or removing the RCM2100 module from the Prototyping
Board.
Getting Started 15
2.4 Where Do I Go From Here?
We recommend that you proceed to the next chapter and install Dynamic C (if you do not
already have it installed), then run the first sample program to verify that the RabbitCore
module and prototyping board are set up and functioning correctly.
If everything appears to be working, we recommend the following sequence of action:
1. Run all of the sample programs described in Chapter 4 to get a basic familiarity with
Dynamic C and the RabbitCore module’s capabilities.
2. For further development, refer to the RabbitCore RCM2100 User’s Manual for details
of the module’s hardware and software components.
A documentation icon should have been installed on your workstation’s desktop; click
on it to reach the documentation menu. You can create a new desktop icon that points to
default.htm in the docs folder in the Dynamic C installation folder.
3. For advanced development topics, refer to the Dynamic C Premier User’s Manual and
the Dynamic C TCP/IP User’s Manual, also in the online documentation set.
2.4.1 Technical Support
If you encounter any problems, call our Technical Support center:
• Z-World Technical Support, (530) 757-3737
• Rabbit Semiconductor Technical Support, (530) 757-8400
16 RabbitCore RCM2100
3. SOFTWARE INSTALLATION & OVERVIEW
To develop and debug progr ams for the RCM210 0 series (an d for all
other Z-World and Rabbit Semiconductor hardware), you must
install and use Dynamic C. This chapter takes you through the installation of Dynamic C, and then provides a tour of its major features
with respect to the RCM2100 series.
3.1 An Overview of Dynamic C
Dynamic C integrates the following development functions into one program:
• Editing
• Compiling
• Linking
• Loading
• Debugging
In fact, compiling, linking and loading are one function. Dynamic C does not use an InCircuit Emulator; programs being developed are downloaded to and executed from the
“target” system via an enhanced serial-port connection. Program development and debugging take place seamlessly across this connection, greatly speeding system development.
Other features of Dynamic C include:
• Dynamic C has an easy-to-use built-in text editor. Programs can be executed and
debugged interactively at the source-code or machine-code level. Pull-down menus and
keyboard shortcuts for most commands make Dynamic C easy to use.
• Dynamic C also supports assembly language programming. It is not necessary to leave
C or the development system to write assembly language code. C and assembly language may be mixed together.
• Debugging under Dynamic C includes the ability to use printf commands, watch
expressions, breakpoints and other advanced debugging features. Watch expressions
can be used to compute C expressions involving the target’s program variables or func-
tions. Watch expressions can be evaluated while stopped at a breakpoint or while the
target is running its program.
Getting Started 17
• Dynamic C provides extensions to the C language (such as shared and protected variables, costatements and cofunctions) that support real-world embedded system development. Interrupt service routines may be written in C. Dynamic C supports
cooperative and preemptive multi-tasking.
• Dynamic C comes with many function libraries, all in source code. These libraries support real-time programming, machine level I/O, and provide standard string and math
functions.
• Dynamic C compiles directly to memory. Functions and libraries are compiled and
linked and downloaded on-the-fly. On a fast PC, Dynamic C can load 30,000 bytes of
code in 5 seconds at a baud rate of 115,200 bps.
3.2 System Requirements
T o install and run Dynamic C, your system must be running one of the following operating
systems:
• Windows 95
• Windows 98
• Windows NT
• Windows Me
• Windows 2000
3.2.1 Hardware Requirements
The PC on which you install Dynamic C for development of RCM2100-based systems
should have the following hardware:
• A Pentium or later microprocessor
• 32 MB of RAM
• At least 40 MB of free hard drive space
• At least one free COM (serial) port for communication with the target systems
• A 10Base-T Ethernet network interface port
(optional if you will not be developing Ethernet-based systems)
• A CD-ROM drive (for software installation)
18 RabbitCore RCM2100
3.3 Installing Dynamic C
Insert the Dynamic C CD-ROM in the drive on your PC. If autorun is enabled, the CD
installation will begin automatically.
If autorun is disabled or the installation otherwise does not start, use the Windows
Start | Run menu or Windows Disk Explorer to launch SETUP.EXE from the root folder
of the CD-ROM.
The installation program will guide you through the installation process. Most steps of the
process are self-explanatory and not covered in this section. Selected steps that may be
confusing to some users are outlined below. (Some of the installation utility screens may
vary slightly from those shown.)
3.3.1 Program & Documentation File Location
Dynamic C’s application, library and documentation files can be installed in any convenient location on your workstation’s hard drives.
The default location, as shown in the example above, is in a folder named for the version
of Dynamic C, placed in the root folder of the C: drive. If this location is not suitable, enter
a different root path before clicking Next >. Files are placed in the specified folder, so do
not set this location to a drive’s root directory.
Getting Started 19
3.3.2 Installation Type
Dynamic C has two components that can be installed together or separately. One component is Dynamic C itself, with the development environment, support files and libraries.
The other component is the documentation library in HTML and PDF formats, which may
be left uninstalled to save hard drive space or installed elsewhere (on a separate or network drive, for example).
The installation type is selected in the installation menu shown above. The options are:
• Typical Installation — Both Dynamic C and the documentation library will be
installed in the specified folder (default).
• Compact Installation — Only Dynamic C will be installed.
• Custom Installation — You will be allowed to choose which components are
installed. This choice is useful to install or reinstall just the documentation.
20 RabbitCore RCM2100
3.3.3 Select COM Port
Dynamic C uses a COM (serial ) port to c ommunicate with the ta rg et developme nt syste m.
The installation allows you to choose the COM port that will be used.
The default selection, as shown in the example above, is COM1. You may select any available port for Dynamic C’s use. If you are not certain which port is available, select COM1.
This selection can be changed later within Dynamic C.
NOTE: The installation utility does not check the selected COM port in any way. Speci-
fying a port in use by another device (mouse, modem, etc.) may cause temporary problems when Dynamic C is started.
3.3.4 Desktop Icons
Once your installation is complete, you will have up to three icons on your PC desktop, as
shown below.
One icon is for Dynamic C, one opens the documentation menu, and the third is for the
Rabbit Field Utility, a tool used to download precompiled software to a target system.
Getting Started 21
3.4 St arting Dynamic C
Once the RabbitCore module is set up and connected as described in Chapter 2 and
Dynamic C has been installed, start Dynamic C by double-clicking on the Dynamic C
icon. Dynamic C should start, then look for the target system on the COM port you specified during installation (by default, COM1). Once detected, Dynamic C should go through
a sequence of steps to cold-boot the module and compile the BIOS.
If you receive the message beginning
loaded…"
you are ready to continue with the sample programs in the next chapter.
"BIOS successfully compiled and
3.4.1 Communication Error Messages
If you receive the message
"No Rabbit Processor Detected," the programming
cable may be connected to a different COM port, a connection may be faulty, or the target
system may not be powered up. First, check to see that the power LED on the prototyping
board is lit. If it is, check both ends of the programming cable to ensure that it is firmly
plugged into the PC and the RCM2100’s programming port. If you are using the Prototyp-
ing Board, ensure that the module is firmly and correctly installed in its connectors.
If there are no faults with the hardware, select a different COM port within Dynamic C.
From the Options menu, select Communications. The dialog shown should appear.
Select another COM port from t he l is t, t hen cli ck OK. Press <Ctrl-Y> to force Dynamic C to recompile the BIOS. If Dynamic C still reports it is unable to locate the target system, repeat the above
steps until you locate the act ive COM port.
If Dynamic C appears to compile the BIOS successfully, but you then receive a communication error message, it is possible that your PC cannot handle the 115,200 bps baud rate.
Try changing the baud rate to 57,600 bps as follows.
• Locate the
Serial Options dialog in the Dynamic C Options > Communicati ons
menu. Change the baud rate to 57,600 bps.
22 RabbitCore RCM2100
If you are using Dynamic C version 7.04 or earlier, modify the BIOS source code as follows. Skip these three steps if your version of Dynamic C is 7.05 or later.
1. Open the BIOS source code file named
BIOS directory.
RABBITBIOS.C, which can be found in the
2. Change the line
#define USE115KBAUD 1 // set to 0 to use 57600 baud
to read as follows.
#define USE115KBAUD 0 // set to 0 to use 57600 baud
3. Save the changes using File > Save.
Now press
<Ctrl-Y>. You should receive the “BIOS successfully compiled …” message
indicating that the target is now ready to compile a program. You should then continue
with the sample programs in the next chapter.
Getting Started 23
24 RabbitCore RCM2100
4. SAMPLE PROGRAMS
To help familiarize you with the RabbitCore RCM2100 modules, several sample Dynamic C programs have been included.
Loading, executing and stud yin g th ese program s will g ive y ou a
solid hands-on overview of the RabbitCore’s capabilities, as
well as a quick start with Dynamic C as an application development tool.
4.1 Sample Program Overview
Dynamic C comes with a large number of sample programs that illustrate many of its features. These programs are intended to serve as tutorials, but then can also be used as starting points or building blocks for your own applications.
NOTE: It is assumed in this section that you have at least an elementary grasp of ANSI
C. If you do not, see the introductory pages of the Dynamic C Premier User’s Manual
for a suggested reading list.
W e have selected five of these sample programs to take you through a complete tour of the
capabilities of the RCM2100 modules. They form a learning arc from basic I/O control to
advanced TCP/IP issues, including Web serving:
FlashLED.c
•
• ToggleLED.c
• FlashLEDs.c
• PingLED.c
• EthCore1.c
Once you have loaded and executed these five programs and have an understanding of
how Dynamic C and the RCM2100 modules interact, you can move on and try the other
sample programs, or begin building your own.
Getting Started 25
4.2 Loading and Compiling Programs in Dynamic C
This section gives you a short summary of how to connect the target system, start
Dynamic C, and load a sample program. For more details on these topics, refer to Sections
2 and 3 of this manual, and the Dynamic C Premier User’s Manual.
4.2.1 Connect Prototyping Board
Section 2.3 provides detailed instructions for setting up the RCM2100 Prototyping Board
and making its hardware connections. In summary:
• Install the RCM2100 module on the Prototyping Board;
• Connect the PROG connector of the programming cable to J5 of the RCM2100, and the
other end of this cable to your PC’s COM port;
• Connect an Ethernet cable to the module’s RJ-45 jack, and to a LAN or micro-LAN
hub;
• Connect the power supply to the Prototyping Board.
PWR LED should light up. If it does not, see Section 2.3.
The
4.2.2 Start Dynamic C
Section 3.4 of this manual provides detailed instructi ons for installing and starting up Dynamic C.
• Double-click on the Dynamic C icon.
Dynamic C should start and compile the BIOS, completing with a message that reads
"BIOS successfully compiled and loaded." If it does not, see Section 3.4.
4.2.3 Load Program
In Dynamic C, use the
File | Open menu item to open the file explorer, and double-click
on the Samples folder. In that folder , double-click on the RCM2100 folder. In that folder,
double-click on the file FlashLED.c.
4.2.4 Compile & Run Program
With FlashLED.c open in a Dynamic C window, press F9 or click on the Run | Run
menu item. Dynamic C should compile the program, and when it finishes, LED DS3 on
the Prototyping Board should begin to flash.
Congratulations! You’ve just compiled and run your first Dynamic C program on the
RCM2100 module!
NOTE: For a quick tutorial on using Dynamic C’s editing, compiling and debugging fea-
tures, see Section 3 in the Dynamic C Premier User’s Manual.
26 RabbitCore RCM2100
4.3 Sample Program: FlashLED.c
If you did not load and compile FlashLED.c in the prior section, refer to Sections 4.2.3
and 4.2.4.
Program Description
This program is about as simple as a Dynamic C application can get—the equivalent of
the traditional “Hello, world!” program found in most basic programming tutorials. If you
are familiar with ANSI C, you should have no trouble reading through the source code and
understanding it.
The only new element in this sample application should be Dynamic C’s handling of the
Rabbit microprocessor’s parallel ports. The program:
4. Initializes the pins of Port A as outputs.
5. Sets all of the pins of Port A high, turning off the attached LEDs.
6. Starts an endless loop with a
• Writes a bit to turn bit 1 off, lighting LED DS3;
• Waits through a delay loop;
• Writes a bit to turn bit 1 on, turning off the LED;
• Waits through a second delay loop;
for(;;) expression, and within that loop:
These steps repeat as long as the program is allowed to run.
You can change the flash rate of the LED by adjusting the loop values in the two for
expressions. The first loop controls the LED’s “off” time; the second loop controls its “on”
time.
NOTE: Since the variable j is defined as type int, the range for j must be between 0
and 32768. To permit larger values and thus longer delays, change the declaration of j
to unsigned int or long.
More Information
See the section on primitive data types, and the entries for the library functions
WrPortI( ) and BitWrPortI( ) in the Dynamic C Premier User’s Manual.
Getting Started 27
4.4 Sample Program: ToggleLED.c
One of Dynamic C’s unique and powerful aspects is its ability to efficiently multitask
using cofunctions and costatements. This simple application demonstrates how these program elements work.
Compile & Run Program
Open the source file
ToggleLED.c, located in the Samples\RCM2100 folder. Press F9
to compile and run the program.
The LED DS3 on the Prototyping Board will begin blinking. Press switch S2 to toggle
LED DS2 on and off.
Program Description
This program uses two costatements to set up and manage the two tasks. Costatements
must be contained in a loop that will “tap” each of them at regular interv als. Thi s progr am:
1. Initializes the pins of Port A as outputs.
2. Sets all the pins of Port A high, turning off the attached LEDs.
3. Sets the toggled LED status variable vswitch to 0 (LED off).
4. Starts an endless loop using a while(1) expression, and within that loop:
• Executes a costatement that flashes LED DS3;
• Executes a costatement that checks the state of switch S2 and toggles the state of
vswitch if it is pressed;
• Turns LED DS2 on or off, according to the state of vswitch.
These steps repeat as long as the program is allowed to run.
The first costatement is a compressed version of FlashLED.c, with slightly different
flash timing. It also uses the library function DelayMs() to deliver more accurate timing
than the simple delay loops of the previous program.
The second costatement does more than check the status of S2. Switch contacts often
“bounce” open and closed several times when the switch is actuated, and each bounce can
be interpreted by fast digital logic as an independent press. To clean up this input, the code
in the second costatement “debounces” the switch signal by waiting 50 milliseconds and
checking the state of the switch again. If it is detected as being closed both times, the program considers it a valid switch press and toggles
vswitch.
Unlike most C statements, the two costatements are not executed in their entirety on each
iteration of the while(1) loop. Instead, the list of statements within each costatement is
initiated on the first loop, and then executed one “slice” at a time on each successive interation. This mode of operation is known as a state machine, a powerful concept that permits a single processor to efficiently handle a number of independent tasks.
The ability of Dynamic C to manage state machine programs enables you to create very
powerful and efficient embedded systems with much greater ease than other programming
methods.
28 RabbitCore RCM2100
More Information
See the entries for the DelayMs() function, as well as Section 5, “Multitasking with
Dynamic C,” in the Dynamic C Premier User’s Manual.
Getting Started 29
4.5 Sample Program: FlashLEDs.c
In addition to Dynamic C’s implementation of C-language programming for embedded
systems, it supports assembly-language programming for very effiicient processor-level
control of the module hardware and program flow. This application is similar to
FlashLED.c and ToggleLEDs.c, but uses assembly language for the low-level port
control within cofunctions, another powerful multitasking tool.
Compile & Run Program
Open the source file
FlashLEDs.c, located in the Samples\RCM2100 folder. Press F9
to compile and run the program.
All the LEDs on the Prototyping Board (including DS4 and DS5, if you have installed
them) will light. DS2 and DS3 will begin flashing at different rates, and will continue
doing so until the program is interrupted.
Program Description
Dynamic C permits the use of assembly language statements within C code. This program
creates three functions using assembly language statements, then creates a C cofunction to
call two of them. That cofunction is then called within main().
Withi n each of the C-like fu nctions, t he #asm and #endasm directives are used to indicate
the beginning and end of the assembly language statements.
In the function initialize_ports( ), port A is initialized to be all outputs while bit 0
of port E is initialized to be an output.
In the function
ledon( ), a 0 is written to the port A bit corresponding to the desired
LED (0, which equals DS3, or 1 which equals DS4), turning that LED on. The
ledoff( ) function works exactly the same way except that a 1 is written to the bit,
turning the selected LED off.
Finally, in the cofunction
flashled( ), the LED to be flashed, the on time in millisec-
onds, and the off time in milliseconds are passed as arguments. This function uses an endless for(;;) loop to call t he ledon( ) and ledoff( ) functions, separated by calls to
the wait function DelayMs( ). This sequence will make the indicated LED flash on and
off.
As is proper in C program design, the contents of main( ) are almost trivial. The program first calls initialize_ports(), then begins an endless for(;;) loop. Within
this loop, the program:
1. Calls the library function hitwd(), which resets the microprocessor’s watchdog timer.
(If the watchdog timer is not reset every so often, it will force a hard reset of the system. The purpose is to keep an intermittent program or hardware fault from locking up
the system. Normally , this function is taken care of by the Virtual Driver , but it is called
explicitly here).
30 RabbitCore RCM2100
2. Sets up a costatement which calls two instances of the flashled() function, one for
each LED. Note that one LED is flashed one second on, one-half second (500 ms) off,
while the other is flashed in the reverse pattern.
Note also the
fordone
wfd keyword in the costatement. This keyword (an abbreviation for wait-
, which can also be used) must be used when calling cofunctions. For a complete
explanation, see Section 5 and 6 in the Dynamic C User’s Manual.
More Information
See the entries for the hitwd() and DelayMs() functions in the Dynamic C Premier
User’s Manual, as well as those for the directives #asm and #endasm. For a complete
explanation of how Dynamic C handles multitasking with costatements and cofunctions,
see Chapter 5, “Multitasking with Dynamic C,” and Chapter 6, “The Virtual Driver,” in
the Dynamic C Premier User’s Manual.
Getting Started 31
4.6 Sample Program: Pi ngLED.c
One of the RCM2100 series’s most important features is the availability of the built-in
Ethernet port. This program makes the simplest possible use of the network port by “ping-
ing” a remote system and using LEDs to report the status of the ping attempt and its return.
Compile & Run Program
Open the source file
#define values near the beginning of the file to represent valid network addresses for
PingLED.c, located in the Samples\RCM2100 folder. Edit the six
your setup.
Press
F9 to compile and run the program.
NOTE: The RCM2100 must be connected to a network as described in Section 2.3.3,
”Connect Ethernet Network Cable,” in orde r for this program to work.
Each time the program sends a ping to the remote address, LED DS2 on the Prototyping
Board will flash. Each time a successful return from a ping attempt is received, LED DS3
will flash.
If the ping return is unsuccessful (i.e., the remote system does not exist or does not
acknowledge the ping within the timeout period), DS3 will not flash.
With short ping times, as will be encountered in most micro-LAN and LAN settings, the
two LEDs should flash almost in parallel as pings are sent and returned.
Program Description
For operation, network addresses must be correctly defined at the start of this program.
The most important address to set correctly is
the RCM2100 module. (The
MY_NETMASK address must be correct as well, but the default
MY_IP_ADDRESS, which is the address of
of 255.255.255.0 is almost universally used.)
If you wish to ping systems outside the local network, you wil l have to correctly define the
MY_GATEWAY address as well. If you wish to ping systems using domain names instead of
IP addresses, a valid DNS server address must be defined for MY_NAMESERVER.
The IP address to be pinged is defined by PING_WHO. Y o u will have to change this address
and recompile the program to ping different addresses. (In most real-world applications,
there should be some mechanism by which to dynamically define or select addresses.)
This address may be defined as a numeric IP address. If a gateway to the Internet and a
valid DNS server are specified, this definition may also be a fully-qualified domain name
(such as “www.zworld.com”).
The program first defines three functions to control the LEDs—one to ini tia lize the m, and
then one each to drive the “ping out” and “ping in” LEDs.
The program begins by calling the LED initialization function pingleds_setup( ).
More importantly , it then calls sock_init( ), which initializes the packet driver and the
TCP manager using the compiler defaults. This function must always be called before any
other TCP/IP functions.
32 RabbitCore RCM2100
The program then resolves the address to be pinged into a numeric value. using the library
function resolve(). If the defined address is numeric, it converts the define string into
truly numeric form. If the address is a domain name, the function queries the indicated
DNS server to obtain the numeric address. (If the function is unable to resolve the
address—if, for example, the numeric address is incomplete or badly formed, or the DNS
server is unable to identify the domain name—the program will print a message to the
screen and terminate.)
The program then begins an endless loop using
for(;;). Within this loop, the program
executes the following steps:
1. Calls tcp_tick( ) to perform the basic housekeeping functions for the socket;
2. As a costatement, waits for the duration of PING_DELAY (defined by default as 500 mS
or one-half second), issues a ping to the resolved address using the
_ping() function,
and flashes LED DS2;
3. As a second costatement, checks for a ping return using the _chk_ping() function. If
the ping is successful, the costatement flashes LED DS3.
If you uncomment the #VERBOSE define near the beginning of the program, the ping
return costatement will also print a message to the screen indicating each successful ping.
More Information
Refer to the Dynamic C TCP/IP Software User’s Manual for complete details on the
Dynamic C implementation of TCP/IP protocols.
Getting Started 33
4.7 Sample Program: EthCore1.c
The RCM2100 modules with Ethernet ports can act as micro Web page servers, with
dynamic interaction between the controller and the web pages. This sample program demonstrates how a web page can be used to both monitor and control an RCM2100 module.
Compile & Run Program
Open the source file
EthCore1.c, located in the Samples\RCM2100 folder. Edit the
three #define values near the beginning of the file to represent valid network addresses
for your setup.
Press
F9 to compile and run the program.
NOTE: The RCM2100 must be connected to a network as described in Section 2.3.3,
”Connect Ethernet Network Cable,” in orde r for this program to work.
TIP: This program will be more in teresting to obse rve if LEDs DS4 and DS5 are insta lled
in the Prototyping Board.
When the program starts, LEDs DS2, DS3 and DS5 will be lit, and DS4 will be dark.
Open a web browser and enter the IP address you defined for the RCM2100 module in the
program in the address window. A page like that shown in Figure 8 should appear.
Figure 8. Browser screen for Sample Program EthCore1.c.
Clicking on each of the button images in the browser window will toggle the state of the
associated LED image, and will toggle the state of the corresponding LED on the Prototyping Board. Since the web page is generated by the RabbitCore module (using Dynamic
HTML), the LED image and the corresponding LED’s real state will always be in step.
34 RabbitCore RCM2100
Program Description
This program begins to show the range of applications for an Ethernet-enabled embedded
system controller, so let’s look closely at its operation.
As with PingLED.c, several network addresses must be defined before this application
can work. The most important is again
MY_IP_ADDRESS, which defines the RCM2100
system’s IP address. The netmask value should be set if the default of 255.255.255.0 is not
correct.
If you are using the system on a local network and will not be trying to access it from outside that network, the MY_GATEWAY value does not matter. If you want to be able to reach
the system from outside the local network, you must specify a valid gateway address.
Generally, the other defined values may be left at their default settings. If you are operating the system behind a firewall or proxy and need to specify a host port for redirection,
you should comment out the line reading:
#define REDIRECTHOST MY_IP_ADDRESS
Then uncomment the next line, which defines a specific redirection host and port:
#define REDIRECTHOST "my host.com:8080"
Be sure to enter the host port where indicated by "my host.com:8080"
.
This application creates dynamic HTML web pages on the fly. For simplicity, all of the
web page components—shell HTML, image GIFs, etc.—are imported into flash memory
using the #ximport statements. It is also possible to read these files from other locations,
including the onboard flash file system, but this application keeps things simple by loading all the components into working memory.
The program then defines four instances of an LED toggling function, which are basic
CGI functions that swap the values “ledon.gif” and “ledoff.gif” as the contents of the
ledn strings, and then force a reload of the web page to change the associated LED
image. The physical LEDs on the Prototyping Board are turned on or off to match the
ledn strings displayed on the web page.
More Information
Refer to the Dynamic C TCP/IP Software User’s Manual for complete details on the
Dynamic C implementation of TCP/IP protocols.
Getting Started 35
4.8 Where Do I Go From Here?
The Dynamic C \Samples folders contain dozens of sample programs. Some of them are
intended for other hardware with somewhat different characteristics, but most can be run
on the RabbitCore RCM2100 series modules, either as-is or with some modification.
(All programs in the
\Samples\RCM2100 folder will run without changes on the
RCM2100 series.)
We suggest that you continue exploring the sample programs, loading, running and modi-
fying them to gain further insight into how to develop embedded system applications
using these modules.
36 RabbitCore RCM2100
SCHEMATICS
090-0114 RCM2100 Schematic
090-0116 RCM2100 Prototyping Board Schematic
090-0128 Programming Cable Schematic
Getting Started 37
REV ECO
REVISION HISTORY REVISION APPROVAL
DESCRIPTION OF CHANGE
ENGINEER
APPROVAL DOCUMENT
DATE
CONTROL
APPROVALPROJECT
DATE
SRAM
SRAM select
FLASH 1
FLASH 1 select
FLASH 2
FLASH 2 select
ETHERNET OPTION
PORTS D-E OPTION
INTERRUPT/JUMPER
OPTIONS
APPEND THE FOLLOWING
DOCUMENTS WHEN CHANGING
THIS DOCUMENT:
DRAWING CONTENT:
APPROVALS: INITIAL RELEASE
SIGNATURES DATE
2900 SPAFFORD ST.
DAVIS, CA 95616
530 - 757-4616
C
NONE
BANK
SELECT
BATTERY BACK-UP
CONFORMAL
COATING
C
NONE
REV
REV
ECO
ECO
REVISION HISTORY
REVISION HISTORY
DESCRIPTION
DESCRIPTION
PROJECT
PROJECT
ENGINEER
ENGINEER
REVISION APPROVAL
REVISION APPROVAL
APPROVAL APPROVAL
APPROVAL APPROVAL
DATE
DATE
DOCUMENT
DOCUMENT
CONTROL
CONTROL
DATE
DATE
APPEND THE FOLLOWING
APPEND THE FOLLOWING
DOCUMENTS WHEN CHANGING
DOCUMENTS WHEN CHANGING
THIS DOCUMENT:
THIS DOCUMENT:
DRAWING CONTENT:
DRAWING CONTENT:
APPROVALS: INITIAL RELEASE
APPROVALS: INITIAL RELEASE
SIGNATURES
SIGNATURES
B
B
2900 SPAFFORD ST.
2900 SPAFFORD ST.
DAVIS, CA 95616
DAVIS, CA 95616
530 - 757 - 4616
530 - 757 - 4616
NONEDATE
NONEDATE
B
B
NONE
NONE
REV
ECO
REVISION HISTORY
DESCRIPTION
PROJECT
ENGINEER
REVISION APPROVAL
APPROVAL APPROVAL
DATE
DOCUMENT
CONTROL
DATE
APPEND THE FOLLOWING
DOCUMENTS WHEN CHANGING
THIS DOCUMENT:
DRAWING CONTENT:
APPROVALS: INITIAL RELEASE
SIGNATURES
DATE NONE
B
WORLD
Z
2900 SPAFFORD ST.
DAVIS, CA 95616
530 - 757 - 4616
Loading...
