RabbitCore RCM3365/RCM3375

C-Programmable Core Module

with NAND Flash Mass Storage and Ethernet

User’s Manual

019–0150 • 080528–G

RabbitCore RCM3365/RCM3375 User’s Manual

Part Number 019-0150 • 080528–G • Printed in U .S.A.

No part of the contents of this manual may be reproduced or transmitted in any form or by any means without the express written permission of Digi International.

Permission is granted to make one or more copies as long as the copyright page contained therein is included. These copies of the manuals may not be let or sold for any reason without the express written permission of Digi International.

Digi International reserves the right to make changes and

improvements to its products without providing n otice.

T r ade mark s

Rabbit, RabbitCore, and Dynamic C are registered trademarks of Digi International Inc.

Rabbit 3000 is a trademark of Digi International Inc.

xD-Picture Card is a trademark of Fuji Photo Film Co., O lympus C orporat ion, and Toshiba Corporation.

Rabbit Semiconductor Inc.

RabbitCore RCM3365/RCM3375

Chapter 1. Introduction 1

1.1 RCM3365 and RCM3375 Features......................................................................................................2

1.2 Comparing the RCM3900/RCM3910 and RCM3365/RCM3375........................................................4

1.3 Advantages of the RCM3365 and RCM3375.......................................................................................5

1.4 Development and Evaluation Tools......................................................................................................6

1.4.1 RCM3365/RCM3375 Development Kit.......................................................................................6

1.4.2 Software........................................................................................................................................7

1.4.3 Accessories....................................................................................................................................7

1.4.4 Online Documentation..................................................................................................................7

Chapter 2. Getting Started 9

2.1 Install Dynamic C.................................................................................................................................9

2.2 Hardware Connections........................................................................................................................10

2.2.1 Step 1 — Attach Module to Prototyping Board..........................................................................10

2.2.2 Step 2 — Connect Serial Programming Cable............................................................................11

2.2.2.1 Programming via Ethernet Option..................................................................................... 12

2.2.3 Step 3 — Connect Power............................................................................................................13

2.2.3.1 Alternate Power-Supply Connections................................................................................ 13

2.3 Starting Dynamic C ............................................................................................................................14

2.3.1 Running Dynamic C via Serial Programming Cable..................................................................15

2.3.1.1 Run a Sample Program....................................................................................................... 15

2.3.1.2 Troubleshooting ................................................................................................................. 15

2.3.2 Running Dynamic C via Ethernet Cables ...................................................................................16

2.3.2.1 Run a Sample Program....................................................................................................... 16

2.3.2.2 Troubleshooting ................................................................................................................. 17

2.4 Where Do I Go From Here? ...............................................................................................................17

2.4.1 Technical Support.......................................................................................................................17

Chapter 3. Running Sample Programs 19

3.1 Introduction.........................................................................................................................................19

3.2 Sample Programs................................................................................................................................20

3.2.1 Use of NAND Flash....................................................................................................................21

3.2.2 Hot-Swapping xD-Picture Card..................................................................................................23

3.2.3 Serial Communication.................................................................................................................24

3.2.4 Real-Time Clock.........................................................................................................................25

3.2.5 RabbitNet....................................................................................................................................26

3.2.6 Other Sample Programs..............................................................................................................26

Chapter 4. Hardware Reference 27

4.1 RCM3365/RCM3375 Inputs and Outputs..........................................................................................28

4.1.1 Memory I/O Interface.................................................................................................................33

4.1.2 Other Inputs and Outputs............................................................................................................33

4.1.3 LEDs ...........................................................................................................................................33

4.2 Serial Communication ........................................................................................................................34

4.2.1 Serial Ports..................................................................................................................................34

4.2.2 Ethernet Port ...............................................................................................................................34

4.2.3 Serial Programming Port.............................................................................................................35

User’s Manual

4.3 Serial Programming Cable.................................................................................................................36

4.3.1 Changing Between Program Mode and Run Mode....................................................................36

4.3.2 Standalone Operation of the RCM3365/RCM3375...................................................................37

4.4 Memory..............................................................................................................................................38

4.4.1 SRAM.........................................................................................................................................38

4.4.2 Flash EPROM.............................................................................................................................38

4.4.3 NAND Flash...............................................................................................................................38

4.5 Other Hardware..................................................................................................................................40

4.5.1 Clock Doubler ............................................................................................................................ 40

4.5.2 Spectrum Spreader......................................................................................................................40

Chapter 5. Software Reference 41

5.1 More About Dynamic C .....................................................................................................................41

5.1.1 Developing Programs Remotely with Dynamic C..................................................................... 43

5.2 Dynamic C Functions........................................................................................................................ 44

5.2.1 Digital I/O...................................................................................................................................44

5.2.2 SRAM Use..................................................................................................................................44

5.2.3 Serial Communication Drivers...................................................................................................45

5.2.4 TCP/IP Drivers...........................................................................................................................45

5.2.5 NAND Flash Drivers..................................................................................................................45

5.2.6 Prototyping Board Functions...................................................................................................... 46

5.2.6.1 Board Initialization............................................................................................................ 46

5.2.6.2 Digital I/O.......................................................................................................................... 47

5.2.6.3 Switches, LEDs, and Relay............................................................................................... 48

5.2.6.4 Serial Communication....................................................................................................... 49

5.2.6.5 RabbitNet Port................................................................................................................... 50

5.3 Upgrading Dynamic C .......................................................................................................................52

5.3.1 Extras..........................................................................................................................................52

Chapter 6. Using the TCP/IP Features 53

6.1 TCP/IP Connections...........................................................................................................................53

6.2 TCP/IP Primer on IP Addresses.........................................................................................................55

6.2.1 IP Addresses Explained..............................................................................................................57

6.2.2 How IP Addresses are Used.......................................................................................................58

6.2.3 Dynamically Assigned Internet Addresses.................................................................................59

6.3 Placing Your Device on the Network ................................................................................................60

6.4 Running TCP/IP Sample Programs....................................................................................................61

6.4.1 How to Set IP Addresses in the Sample Programs.....................................................................62

6.4.2 How to Set Up your Computer for Direct Connect....................................................................63

6.5 Run the PINGME.C Sample Program................................................................................................ 64

6.6 Running Additional Sample Programs With Direct Connect............................................................64

6.6.1 RabbitWeb Sample Programs.....................................................................................................65

6.7 Where Do I Go From Here?...............................................................................................................65

Appendix A. RCM3365/RCM3375 Specifications 67

A.1 Electrical and Mechanical Characteristics ........................................................................................68

A.1.1 Headers......................................................................................................................................72

A.2 Bus Loading ...................................................................................................................................... 73

A.3 Rabbit 3000 DC Characteristics........................................................................................................76

A.4 I/O Buffer Sourcing and Sinking Limit.............................................................................................77

A.5 Jumper Configurations......................................................................................................................78

A.6 Conformal Coating............................................................................................................................80

Appendix B. Prototyping Board 81

B.1 Introduction .......................................................................................................................................82

B.1.1 Prototyping Board Features.......................................................................................................83

B.2 Mechanical Dimensions and Layout................................................................................................. 85

RabbitCore RCM3365/RCM3375

B.3 Power Supply.....................................................................................................................................87

B.4 Using the Prototyping Board..............................................................................................................88

B.4.1 Adding Other Components.........................................................................................................89

B.4.2 Digital I/O...................................................................................................................................90

B.4.2.1 Digital Inputs..................................................................................................................... 90

B.4.3 CMOS Digital Outputs...............................................................................................................91

B.4.4 Sinking Digital Outputs..............................................................................................................91

B.4.5 Relay Outputs.............................................................................................................................91

B.4.6 Serial Communication................................................................................................................92

B.4.6.1 RS-232............................................................................................................................... 93

B.4.6.2 RS-485............................................................................................................................... 94

B.4.7 RabbitNet Ports ..........................................................................................................................95

B.4.8 Other Prototyping Board Modules.............................................................................................96

B.4.9 Quadrature Decoder ...................................................................................................................96

B.4.10 Stepper-Motor Control.............................................................................................................96

B.5 Prototyping Board Jumper Configurations ........................................................................................98

B.6 Use of Rabbit 3000 Parallel Ports....................................................................................................100

Appendix C. LCD/Keypad Module 103

C.1 Specifications...................................................................................................................................103

C.2 Contrast Adjustments for All Boards...............................................................................................105

C.3 Keypad Labeling..............................................................................................................................106

C.4 Header Pinouts.................................................................................................................................107

C.4.1 I/O Address Assignments.........................................................................................................107

C.5 Mounting LCD/Keypad Module on the Prototyping Board ............................................................108

C.6 Bezel-Mount Installation..................................................................................................................109

C.6.1 Connect the LCD/Keypad Module to Your Prototyping Board...............................................111

C.7 Sample Programs .............................................................................................................................112

C.8 LCD/Keypad Module Function Calls..............................................................................................113

C.8.1 LCD/Keypad Module Initialization..........................................................................................113

C.8.2 LEDs.........................................................................................................................................113

C.8.3 LCD Display.............................................................................................................................114

C.8.4 Keypad......................................................................................................................................130

Appendix D. Power Supply 133

D.1 Power Supplies.................................................................................................................................133

D.1.1 Battery Backup.........................................................................................................................133

D.1.2 Battery-Backup Circuit............................................................................................................134

D.1.3 Reset Generator ........................................................................................................................135

Appendix E. Programming via Ethernet Crossover Cable 137

E.1 Load TCP/IP Parameters to the RCM3365 Module.........................................................................138

E.2 Load TCP/IP Parameters to the PC, Notebook, or Workstation......................................................139

E.3 Run a Program..................................................................................................................................141

E.3.1 Troubleshooting..................................................... ...... ..... ......................................... ...............141

Appendix F. RabbitNet 143

F.1 General RabbitNet Description ........................................................................................................143

F.1.1 RabbitNet Connections.............................................................................................................143

F.1.2 RabbitNet Peripheral Cards......................................................................................................144

F.2 Physical Implementation ..................................................................................................................145

F.2.1 Control and Routing..................................................................................................................145

F.3 Function Calls...................................................................................................................................146

F.3.1 Status Byte................................................................................................................................152

Index 153

User’s Manual

Schematics 157

RabbitCore RCM3365/RCM3375

1. INTRODUCTION

The RCM3365 and RCM3375 RabbitCore modules feature a compact module that incorporates the latest revision of the power-

ful Rabbit® 3000 microprocessor, flash memory, mass storage (NAND flash), static RAM, and digital I/O ports. The RCM3365 and RCM3375 present a new form of embedded flexibility with removable (“hot-swappable”) memory cards. The RCM3365 and RCM3375 both have an integrated 10/100Base-T Ethernet port, and provide for LAN and Internet-enabled systems to be built as easily as serial-communication systems.

In addition to the features already mentioned above, the RCM3365 and RCM3375 have two clocks (main oscillator and real-time clock), reset circuitry , and the circuitry necessary for management of battery backup of the Rabbit 3000’s internal real-time clock and the static RAM. Two 34-pin headers bring out the Rabbit 3000 I/O bus lines, parallel ports, and serial ports.

The RCM3365/RCM3375’s mass-storage capabilities make them suited to running the optional Dynamic C FAT file system module where data are stored and handled using the same directory file structure commonly used on PCs. A removable xD-Picture Card can be hot-swapped to transfer data quickly and easily using a standardized file system that can be read away from the RCM3365/RCM3375 installation.

The RCM3365 or RCM3375 receives +3.3 V power from the customer-supplied motherboard on which it is mounted. The RCM3365 and RCM3375 can interface with all kinds of CMOS-compatible digital devices through the motherboard.

The Development Kit has what you need to design your own microprocessor-based system: a complete Dynamic C software development system including the Dynamic C FAT File System module, and a Prototyping Board that allows you to evaluate the RCM3365 or RCM3375, and to prototype circuits that interface to the RCM3365 or RCM3375 module.

User’s Manual 1

1.1 RCM3365 and RCM3375 Features

• Small size: 1.85" x 2.73" x 0.86" (47 mm x 69 mm x 22 mm)

• Microprocessor: Rabbit 3000 running

at 44.2 MHz

• 52 parallel 5 V tolerant I/O lines: 44 configurabl e for I/O, 4 fixe d in pu ts, 4 fi xed o ut p uts

• Three additional digital inputs, two additional digital outputs

• External reset

• Alternate I/O bus can be configured for 8 data lines and 6 address lines (shared with

parallel I/O lines), plus I/O read/write

• Ten 8-bit timers (six cascadable) and one 10-bit timer with two match registers

• 512K flash memory, 512K program execution SRAM, 512K data SRAM

• Fixed and hot-swappable mass-storage flash-memory options, which may be used with

the standardized directory structure supported by the Dynamic C FAT File System module.

• Real-time clock

• Watchdog supervisor

• Provision for customer-supplied backup battery via connections on header J4

• 10-bit free-running PWM counter and four pulse-width registers

• Two-channel Input Capture (shared with parallel I/O ports) can be used to time input

signals from various port pins

• Two-channel Quadrature Decoder accepts inputs from external incremental encoder modules

•

Five or six 3.3 V CMOS-compatible serial ports with a maximum asynchronous baud rate of 5.525 Mbps

. Three ports are configurable as a clocked serial port (SPI), and two

ports are configurable as SDLC/HDLC serial ports (shared with parallel I/O ports).

• Supports 1.15 Mbps IrDA transceiver

• Supports Dynamic C RabbitSys, which supports Ethernet access for remote application

updates, and remote monitoring and control of a RabbitSys-enabled RCM3365

The RCM3900/RCM3910 and RCM3365/RCM3375 RabbitCore modules are similar to the RCM3305/RCM3315 and RCM3309/RCM3319, but they use fixed NAND or removable media for their mass-storage memories instead of the fixed serial flash options of the RCM3305/RCM3315 and the RCM3309/RCM3319.

2 RabbitCore RCM3365/RCM3375

Table 1 below summarizes the main features of the RCM3365 and the RCM3375 modules.

Table 1. RCM3365/RCM3375 Features

Feature RCM3365 RCM3375

Microprocessor Rabbit 3000 running at 44.2 MHz SRAM 512K program (fast SRAM) + 512K data Flash Memory

(program) Flash Memory

(mass data storage)

Serial P orts

* RCM3365 modules sold before 2008 had 16MB fixed NAND flash

memory.

NOTE: M-type xD-Picture Cards are not supported at this time.

32MB (fixed)

up to 128MB ( removable)

(NAND flash)

6 shared high-speed, 3.3 V CMOS-compatible ports:

• all 6 are configurable as asynchronous serial ports;

• 4 are configurable as a clocked serial port (SPI) and 1 is configurable as an HDLC serial port;

• option for second HDLC serial port at the expense of 2 clocked serial ports (SPI)

512K

up to 128MB ( removable)

(NAND fl ash)

The RCM3365 and RCM3375 are programmed over a standard PC serial port through a serial programming cable supplied with the Development Kit, and can also be programed through a USB port with an RS-232/USB converter, or directly over an Ethernet link using the Dynamic C download manager with or without a RabbitLink; Dynamic C RabbitSys may also be used with a RabbitSys-enabled RCM3365 over an Ethernet link.

Appendix A provides detailed specifications for the RCM3365 and the RCM3375.

User’s Manual 3

1.2 Comparing the RCM3900/RCM3910 and RCM3365/RCM3375

We can no longer obtain certain components for the RCM3365/RCM3375 RabbitCore modules that support the originally specified -40°C to +70°C temperature range. Instead of changing the design of the RCM3365/RCM3375 RabbitCore modules to handle available components specified for the original temperature range, we decided to develop a new product line — the RCM3 900 s e ries.

The RCM3900 series of RabbitCore modules is similar in form, dimensions, and function to the RCM3365/RCM3375 modules. We strongly recommend that existing RCM3365/ 3375 customers and designers of new systems consider using the new RCM3900 series RabbitCore modules.

This section compares the two lines of RabbitCore modules.

• Temperature Specifications — RCM3365/RCM3375 RabbitCore modules manufac-

tured after May, 2008, are specified to operate at 0°C to +70°C. The RCM3900/ RCM3910, rated for -20°C to +85°C, are offered to customers requiring a larger temperature range after May, 2008.

• Removable Mass Storage — The hot-swappable xD-Picture Card™ mass storage device with up to 128MB of memory has been replaced with the miniSD Card with up to 1GB of memory. The miniSD Card is more readily available today, and is expected to remain readily available for a long time. In addition, miniSD Cards provide a significantly larger memory capacity, which has been requested by customers. The trade-off for the larger memory capacity is that the data transfer rate to/from the miniSD Card is about an order of magnitude slower than to/from the xD-Picture Card.

NOTE: RCM3365/RCM3375 RabbitCore modules may eventually be discontinued

because of changes to the xD-Picture Card™.

• Serial Ports — Serial Port B, available as either a clocked serial port or an asynchro-

nous serial port on the RCM3365/RCM3375, is used by the RCM3900/RCM3910 as a clocked serial peripheral interface (SPI) for the miniSD™ Card, and is not brought out for customer use.

• General-Purpose I/O — PD2, a configurable I/O pin on the RCM3365/RCM3375, is used to enable/disable the RabbitNet SPI interface when the RCM3365/RCM3375 is installed on the Prototyping Board. The RCM3900/RCM3900 use PD2 to detect whether the miniSD™ Card is installed, and so PD2 is not brought out for customer use on the RCM3900/RCM3910.

• Maximum Current — The RCM3365/RCM3375 draws 250 mA vs. the 325 mA required by the RCM3900/RCM3910.

• LEDs — The SPEED and user (USR/BSY)LED locations have been swapped between the RCM3365/RCM3375 and the RCM3900/RCM3910, the LNK/ACT LEDs have been combined to one LED on the RCM3900/RCM3910, and the RCM3900/RCM3910 has an FDX/COL LED instead of the FM LED on the RCM3365/RCM3375. The LED placements on the boards remain unchanged.

4 RabbitCore RCM3365/RCM3375

• Ethernet chip — A different Ethernet controller chip is used on the RCM3900/ RCM3910. The Ethernet chip is able to detect automatically whether a crossover cab le or a straight-through cable is being used in a particular setup, and will configure the signals on the Ethernet jack inte rf ace.

• Dynamic C — As long as no low-level FA T file system calls or direct xD-Picture Card access calls to the

NFLASH.LIB library were used in your application develo ped f or t he

RCM3365/RCM3375, you may run that application on the RCM3900/RCM3910 after you recompile it using Dynamic C v. 9.60.

NOTE: The Dynamic C RabbitSys option for programming an RCM3365 over an

Ethernet link is not supported for the RCM3900.

1.3 Advantages of the RCM3365 and RCM3375

• Fast time to market using a fully engineered, “ready-to-run/ready-to-program” microprocessor core.

• Competitive pricing when c ompar ed with the alternative of purchasing and assembling individual components.

• Easy C-language program development and debugging

• Program download utility (Rabbit Field Utility) and cloning board options for rapid

production loading of programs.

• Generous memory size allows large programs with tens of thousands of lines of code, and substantial data storage.

• Integrated Ethernet port for network connectivity, with royalty-free TCP/IP software.

• Ideal for network-enabling security and access systems, home automation, HVAC

systems, and industrial controls

User’s Manual 5

1.4 Development and Evaluation Tools

1.4.1 RCM3365/RCM3375 Development Kit

The RCM3365/RCM3375 Development Kit contains the hardware you need to use your RCM3365 or RCM3375 module.

• RCM3365 module.

• Prototyping Board.

• AC adapter, 12 V DC, 1 A (inclu ded onl y with Deve lop ment Kits sold for the North Amer-

ican market). A header plug leading to bare leads is provided to allow overseas users to connect their own power supply with a DC output of 8–30 V.)

• Serial programming cable with 10-pin header and DE9 connections.

• 2 CDs — Dynamic C

documentation on disk.

• Getting Started instructions.

• 32 MB xD-Picture Card™.

• Accessory parts for use on the Prototyping Board.

• Screwdriver and Ethernet cables.

• Rabbit 3000 Processor Easy Reference poster.

and Dynamic C FA T File Syst em module — with complete produ ct

• Registration card.

Programming

DIAG

PROG

Getting Started

Ethernet

Cables

Installing Dynamic C

Insert the CD from the Development Kit in your PC’s CD-ROM drive. If the installation does not auto-start, run the setup.exe program in the root directory of the Dynamic C CD. Install any Dynamic C modules after you install Dynamic C.

RabbitCore RCM3365/RCM3375

Development Kit Contents

The RCM3365/RCM3375 Development Kit contains the following items:

• RCM3365 module.

• RCM3300 Prototyping Board.

• AC adapter, 12 V DC, 1 A. (Included only with Development Kits sold for the North American market.

A header plug leading to bare leads is provided to allow overseas users to connect their own power supply with a DC output of 8–30 V.)

• 10-pin header to DB9 programming cable with integrated level-matching circuitry.

• 2 CDs — Dynamic C and Dynamic C FAT Fil e Syst em mod ule — with complete product documentation

on disk.

• Ethernet cables and screwdriver.

• Getting Started instructions.

• 32 MB xD-Picture Card™ (NAND flash)

• A bag of accessory parts for use on the Prototyping Board.

• Rabbit 3000 Processor Easy Reference poster.

• Registration card.

Rabbit and Dynamic C are registered trademarks of Rabbit Semiconductor Inc.

Instructions

Cable

Accessory Parts for

Prototyping Board

XD-Picture Card

+DC

GND

D N G

R30

C16

R24

D5D6D7

R31

R32

DS5DS6

J10

C10

C11

00 01 02 03 04 05 06 07

OUT

C12

RP1

JP4

C13

R16

CX2

SO20W

J13

C21

C22

O H

C23

C24

J14

TxE RxE GND TxF RxF 485+ GND 485

GND

+3.3 V

VBT

VRAM

/RES

SMODE1

SM0

/IORD

/IOWR

PG4

PG5

PG6

R11

PG7

PE0

PE1

PE3

PE4

PE5

R12

7 E

PE6

P 6 F

PF7

P 4 F

PF5

R67

PB7

PB6

R68

R69

PB5

PB4

R70

PB3

PB2

PB0

/RES_OUT

RCM3300

PROTOTYPING

BOARD

CORE MODULE

GND/EGND

LINK

ACT

PD6

PD7

PD2

PD3

PD4

PD5

PG2

PG3

PG0

PG1

PC6

PC7

PC4

PC5

PC2

PC3

PC0

PC1

PF1

PF0

PF3

PF2

PA1

PA0

PA3

PA2

PA5

PA4

PA7

PA6

GND

STAT

RESET

R23

R21

R22

Q2Q3Q4

J12

R28

R27

R25

R26

R50

D4 Q6

R49

R29

CORE

DS2

DS4

DS3

Prototyping Board

AC Adapter

(North American

kits only)

Screwdriver

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

POWER

1 S D

JP1

L293D

H-DRIVER

R13

OUT

RP2

R17

R15

+5 V

GND

+3.3 V

RX13

RX14

CX1

RX15

UX4

UX1

DX1

SO20W

UX5

DX2

C18

C17

UX2

R33

R34

U10

R35

R36

R37

JP5

R38

C26

C25

VMB MDB1 MDB2 MDB3 MDB4 VMB+

R52 R53

R51

R54

PF0_CLKD

JP3

PF0_QD

JP2

L293D

H-DRIVER

R14

BT1

RX16

RX17

RX18

SOT23-6

LCD1JB

LCD1JA

R40

U11

KEYPAD DISPLAY BOARD

+5 V

GND

+3.3 V

J15

R39

+V/

A3A1D0D2D4D

A2A

D1D3D5D

R42

C19

C20

R41

U12

R45

LCD1JC

GND IN3 IN2 IN1 IN0 +5V

+5V QD2A QD2B QD1A QD1B GND

R60 R61

R59

R62

J16

C27

C28

R44

R43

C30C29

R46

DS7

R47

RELAY

R48

J17

NO1 COM1 NC1 NO2 COM2 NC2

RABBITNET

R3R4R5

R10

/ H

J11

C14

C15

E S

R19

R20

R18

0 T A

@ Y R A

A L

Figure 1. RCM3365/RCM3375 Development Kit

6 RabbitCore RCM3365/RCM3375

1.4.2 Software

The RCM3365 an d the RCM 3375 are programm ed using v ersion 9.24 or later o f Dynamic C. A compatible version is included on the Development Kit CD-ROM.

Rabbit is also offering RCM3365 RabbitCore modules preloaded with Dynamic C RabbitSys firmware to allow these modules to run Dynamic C RabbitSys. Dynamic C RabbitSys requires Dynamic C version 9.30 or later, and allows the RCM3365 to be accessed via an Ethernet connection for remote application updates, and for remote monitoring and control. A RabbitSys Development Kit is available with all the hardware and software tools that are needed to develop a RabbitSys application.

Dynamic C v. 9.60 includes the popular µC/OS-II real-time operating system, point-topoint protocol (PPP), FAT file system, RabbitWeb, and other select libraries that were previously sold as individual Dynamic C modules.

Rabbit also offers for purchase the Rabbit Embedded Security Pack featuring the Secure Sockets Layer (SSL) and a specific Advanced Encryption Standard (AES) library. In addition to the Web-based technical support included at no extra charge, a one-year telephonebased technical support subscription is also available for purchase.

NOTE: Version 2.10 or later of the Dynamic C FAT file system module is required to use

the FAT file system with the RCM3365 and RCM3375 models.

1.4.3 Accessories

Rabbit has available a USB Removable Memory Card Reader and a Connector Adapter Board.

• USB Removable Memory Card Reader (Part No. 20-101-1104)—allows you to read data from the xD-Picture Card via your PC.

• Connector Adapter Board (Part No. 151-0114)—allows you to plug the RCM3365/ RCM3375 whose headers have a 2 mm pitch into header sockets with a 0.1" pitch.

1.4.4 Onlin e Documentation

The online documentation is installed along with Dynamic C, and an icon for the documentation menu is placed on the workstation’s desktop. Double-click this icon to reach the menu. If the icon is missing, use your browser to find and load default.htm in the docs folder, found in the Dynamic C installation folder.

The latest versions of all documents are always available for free, unregistered download from our Web sites as well.

User’s Manual 7

8 RabbitCore RCM3365/RCM3375

2. GETTING S TARTED

This chapter explains how to set up and use the RCM3365/ RCM3375 modules with the accompanying Prototyping Board.

NOTE: It is assumed that you have a Development Kit. If you purc hased an RCM3365 or

RCM3375 module by itself, you will have to adapt the information in this chapter and elsewhere to your test and development setup.

2.1 Install Dynamic C

To develop and debug programs for the RCM3365/RCM3375 (and for all other Rabbit hardware), you must install and use Dynamic C.

If you have not yet installed Dynamic C version 9.24 (or a later version), do so now by inserting the Dynamic C CD from the Development Kit in your PC’s CD-ROM drive. If autorun is enabled, the CD installation will begin automatically.

If autorun is disabled or the installation otherwise does not start, use the Windows

Start | Run menu or Windows Disk Explorer to launch setup.exe from the root folder

of the CD-ROM. The installation program will guide you through the installation process. Most steps of the

process are self-explanatory. Dynamic C uses a COM (serial ) port to communica te with the tar get deve lopment sy stem.

The installation allows you to choose the COM port that will be used. The default selection is COM1. You may select any available port for Dynamic C’s use. If you are not certain which port is available, select COM1. This selection can be changed later within Dynamic C.

NOTE: The installation utility does not check the selected COM port in any way. Speci-

fying a port in u se by a not her device (mouse, modem, etc.) may l ea d to a message such as

"could not open serial port" when Dynamic C is started.

Once your installation is complete, you will have up to three icons on your PC desktop. One icon is for Dynamic C, one opens the documentation menu, and the third is for the Rabbit Field Utility, a tool used to download precompiled software to a target system.

If you have purchased the optional Dynamic C Rabbit Embedded Security Pack, install it after installing Dynamic C. You must install the Rabbit Embedded Security Pack in the same directory where Dynamic C was installed.

User’s Manual 9

2.2 Hardware Connections

There are three steps to connecting the Prototyping Board for use with Dynamic C and the sample programs:

1. Attach the RCM3365/RCM3375 module to the Prototyping Board.

2. Connect the serial programming cable between the RCM3365/RCM3375 and the workstation PC or if you have an RCM3365 with RabbitSys firmware you may connect the RCM3365 and the PC using Ethernet cables.

3. Connect the power supply to the Prototyping Board.

2.2.1 Step 1 — Attach Module to Prototyping Board

Turn the RCM3365/RCM3375 module so that the Ethernet jack is facing the direction shown in Figure 2 below. Align the pins from headers J3 and J4 on the bottom side of the modul e into header sockets JA and JB on the Prototyping Board. The picture card (NAND flash) does not have to be inserted into connector J6 on the RCM3365/RCM3375 at this time.

RCM3365/ RCM3375

Do not press down

here.

RP1

C13

R16

GND

HO4

D5D6D7

R29

DS3

JP1

L293D H-DRIVER

R13

RP2

R17

R15

HO3

HO2

HO1

R30

R31

R32

DS5 DS6

DS4

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

OUT

CX1

SO20W

CX2

SO20W

J13

C21

C23

C24

J14

TxE RxE GND TxF RxF 485+ GND 485

POWER

+DC

GND

+DC

GND

DS1

R1 J2

GND

+3.3 V

VBT

VRAM

/RES

SMODE1

SPEED

C79

C78

SM0

/IORD

USR FMLINK ACT

R38

C77

R79

/IOWR

PG4

DS3

R37

DS4

R43

C42

PG5

PG6

R11

R36

DS2

C72

C76

PG7

PE0

R35

PE1

PE4

PE6

PF7

PF5

PB7

PB5

PB3

R67

C105

R96

PB0

JP5

RCM3300 PROTOTYPING BOARD

ACT

PD7

PD3

PD5

PG3

PG1

PC7

PC5

PC3

PC1

PF0

PF2

PA0

PA2

PA4

PA6

STAT

RESET

C71

PE3

C86

C70

R81

PE5

C80

R12

R82

C82

R30

R31 R54

PF4 PF6 PE7

R67

R53

PB6

R44

R68

C58

C61

R69

PB4

C36

R20

R21

R70

PB2

R25

JP6

/RES_OUT

C27

JP7

JP8

JP4

C21

C22

C18

C12

C13

C3 C2 R7

JP9

R29

R50

R59

C104

LINK

PD6

C67

PD2

R45

PD4

PG2

PG0

PC6

PC4

PC2

PC0

PF1

PF3

PA1

PA3

PA5

PA7

GND

R25

DS1

C74

U13

J10

C81

C10

C11

00 01 02 03 04 05 06 07

OUT

C12

JP4

R27 R26

C35

R15

R19

R17

R14

C28

C34

R23

R22

R18

C24

C20

C19

C15

C11

C10

U16

R10

R86

R70

R85

R84

CORE MODULE

R80

R64

R77

GND/EGND

R11

C14

R12

R13

C16

R24

R23

R21

R22

Q2Q3Q4

J12

R28

R27

R26

R50

R49

CORE

DS2

VMB MDB1 MDB2 MDB3 MDB4 VMB+

PF0_CLKD

PF0_QD

JP2

U3 L293D H-DRIVER

R14

BT1

+5 V

GND

+3.3 V

RX13

RX16

RX14

RX17

RX18

RX15

UX4

UX1

DX1

SOT23-6

UX5

DX2

SOT23-6

C18

C17

UX2

R33

R34

U10

R35

R36

C22

R37

JP5

R38

C26

C25

JP3

R52 R53

R51

R55

LCD1JA

LCD1JB

R54

R56

R57

R58

R39

+BKLT

R40

U11

+5V QD2A QD2B QD1A QD1B GND

LCD

/CS

J15

/RES

LED0

LED2

/CS

LED1

LED3

C19

KEYPAD DISPLAY BOARD

R60 R61

R59

R63

R64

R65

BA0

BA1

BA2

LED4

LED6

GNDA3A1D0D2D4D6

GND

LED5

C20

R41

U12

GND IN3 IN2 IN1 IN0 +5V

R62

RABBITNET

R3R4R5

BD1

D1D3D5

R10

J11

C14

C15

SERIAL FLASH/

MODEM

R19

R20

R18

BD2

BD3

BD4

BD5

BD6

BD7

J16

0.5 A @ 30 V

RELAY RATED

LCD1JC

J17

C27

C28

R44

R43

C30C29

R45

R46

NO1 COM1 NC1 NO2 COM2 NC2

DS7

R47

RELAY

R48

R66

+5 V

GND

+3.3 V

BA3

BD0

R42

CORE LED

Figure 2. Install the RCM3365/RCM3375 Module on the Prototyping Board

NOTE: It is important that you line up the pins on headers J3 and J4 of the RCM3365/

RCM3375 module exactly with th e cor re spon din g pins of header sockets JA and JB on the Prototyping Board. The header pins may become bent or damaged if the pin alignment is offset, and the module will not work. Permanent electrical damage to the module may also result if a misaligned module is powered up.

Press the module’s pins firmly into the Prototyping Board header sockets—press down in the area above the header pins using your thumbs or fingers over the header pins as shown in Figure 2. Do not press down on the picture card connector (J6) unless the picture card is installed, but rather press down on the circuit board along the edge by the connector. Also, do not press down on the middle of the module t o avoid fl exing the module, which could damag e the module or components on the module.

Should you need to remove the module, grasp it with your fingers along the sides by the connectors and gently work the module up to pull the pins away from the sockets where they are installed. Do not remove the module by grasping it at the top and bottom.

10 RabbitCore RCM3365/RCM3375

2.2.2 Step 2 — Connect Serial Programming Cable

The serial programming cable connects the RCM3365/RCM3375 to the PC running Dynamic C to download programs and to monitor the module during debugging.

Connect the 10-pin connector of the serial programming cable labeled

PROG to header J1

on the RCM3365/RCM3375 module as shown in Figure 3. There is a small dot on the circuit board next to pin 1 of header J1. Be sure to orient the marked (usually red) edge of the cable towards pin 1 of the connector. (Do not use the DIAG connector , which is used for a nonprogramming serial connection.)

AC adapter

VMB MDB1 MDB2 MDB3 MDB4 VMB+

PF0_CLKD

PF0_QD

BT1

RX16

RX17

RX18

UX4

DX1

SOT23-6

UX5

DX2

SOT23-6

C18

C17

U10

R35

R37

JP5

R38

Programming Cable

+5V QD2A QD2 B QD1A QD1B GND

R52 R53

R51

R54

JP3

R55

R56

R57

R58

LCD

J15

R39

/RES

LED0

LCD1JA

/CS

LED1

+BKLT

C19

R40

U11

PC COM port

Blue

KEYPAD DISPLAY BOARD

shrink wrap

LCD1JB

LED2

LED3

R60 R61

R59

R63

/CS

BA0

BA1

LED4

LED6

GND

LED5

R41

R62

R64

R65

R66

+5 V

GND

+3.3 V

BA2

BA3

BD0

BD1

GNDA3A1D0D2D4D6

D1D3D5

GND

R42

C20

U12

GND IN3 IN2 IN1 IN0 +5V

BD2

BD3

BD4

LCD1JC

RABBITNET

R3R4R5

R10

J11

C14

C15

SERIAL FLASH/

MODEM

R19

R20

R18

BD5

BD6

BD7

J16

0.5 A @ 30 V

RELAY RATED

J17

C27

C28

R44

R43

C30C29

R45

R46

NO1 COM1 NC1 NO2 COM2 NC2

DS7

R47

RELAY

R48

PROG

GND

VBT

/RES

SM0

/IOWR

PG5

PG7

PE1

PE4

PE6

PF7

PF5

PB7

PB5

PB3

PB0

RCM3300 PROTOTYPING BOARD

ACT

PD7

PD3

PD5

PG3

PG1

PC7

PC5

PC3

PC1

PF0

PF2

PA0

PA2

PA4

PA6

STAT

RESET

+3.3 V

VRAM

SMODE1

/IORD

PG4

PG6

PE0

PE3

PE5

PF4 PF6 PE7

PB6

PB4

PB2

/RES_OUT

LINK

PD6

PD2

PD4

PG2

PG0

PC6

PC4

PC2

PC0

PF1

PF3

PA1

PA3

PA5

PA7

GND

alternate

3-pin

power connector

RP1

R4 U1

R70

R64

HO4

D5D6D7

L293D H-DRIVER

RP2

C74

R19

R17

R22

R18

U16

R85

R84

R80

PROG

C14

R13

HO3

HO2

R30

R31

DS5 DS6

DS4

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

JP1

R13

OUT

R17

U13

R15

C81

R27 R26

C35

R15 R14

C28

R23

C24

CX1

C20

C19

C15

UX1

C11

SO20W

C10

CX2

R10

UX2

SO20W

R11

R12

J13

C21

C22

HO1

C23

C24

J14

DIAG

R32

TxE RxE GND TxF RxF 485+ GND 485

JP2

L293D H-DRIVER

R14

+5 V

GND

+3.3 V

RX13

RX14

RX15

R33

R34

R36

C26

C25

Colored edge

SPEED

GND/EGND

R38 R37

DS4

R36

R35

GND

R43

C105

GND

+DC

C10

C11

C42

C76

C86

R81

R30

CORE MODULE

R67

R96

JP4

JP5

R21

Q2Q3Q4

R28

R27

POWER

GND

DS1

R1 J2

J10

00 01 02 03 04 05 06 07

OUT

C12

JP4

C79

C78

R16

C77

R79

C72

C71

C70

C80

R82

C82

R31

R54

R53

R44

C58

C61

C36

R20

R21

R25

JP6

C27

JP7

JP8

C21

C22

C18

C12

C13

C3 C2 R7

JP9

C16

R29

R50

R24

R23

R22

R59

C104

C67

R45

J12

R50

R49

CORE

DS2

C13

C34

C5 R86

R77

GND

R29

DS3

+DC

L1 R11

R12

R67

R68 R69 R70

USR FMLINK ACT

DS3

DS2

DS1

R25

R26

Figure 3. Connect Serial Programming Cable and Power Supply

NOTE: Be sure to use the serial programming cable (part number 101-0542) supplied

with this Development Kit—the serial programming cable has blue shrink wrap around the RS-232 converter section located in the middle of the cable. Pr ogramming cables with clear o r r ed s hr i nk w ra p f ro m o th er Rabbit kits are not desig ned to work wit h RCM3365 / RCM3375 modules.

Connect the other end of the serial programming cable to a COM port on your PC.

NOTE: Some PCs now come equipped only with a USB port . It may be possible to use

an RS-232/USB converter (Part No. 20-151--0178) with the serial programming cable supplied with the RCM3365/RCM3375 Development Kit. Note that not all RS-232/ USB converters work with Dynamic C.

User’s Manual 11

2.2.2.1 Programming via Ethernet Option

An Ethernet cable connects a RabbitSys-enabled RCM3365 to the PC running Dynamic C with Dynamic C RabbitSys via a DHCP network to download programs and to monitor the RCM3365 module during debugging.

Use a straight-through CAT 5/6 Ethernet cable to connect the Ethernet jack on the RCM3365 to a DHCP-enabled network. Y our PC should also be connected to this network—you will need a second straight-through CAT 5/6 Ethernet cable to connect the PC to the net work since only one straight-through Ethernet cable is supplied with the Development Kit.

R60 R61

R62

R63

R64

R65

R66

+5 V

+3.3 V

BA1

BA2

BA3

BD0

LED6

GNDA3A1D0D2D4D6

GND

R42

C20

U12

GND

BD1

D1D3D5

GND IN3 IN2 IN1 IN0 +5V

BD2

BD3

BD4

LCD1JC

RABBITNET

R3R4R5

R10

J11

C14

C15

SERIAL FLASH/

MODEM

R19

R20

R18

BD5

BD6

BD7

J16

0.5 A @ 30 V

RELAY RATED

J17

C27

C28

R44

R43

C30C29

R45

R46

NO1 COM1 NC1 NO2 COM2 NC2

DS7

R47

RELAY

R48

CAT 5/6

Ethernet Cable

To Network

or PC

GND

VBT

/RES

SM0

/IOWR

PG5

PG7

PE1

PE4

PE6

PF7

PF5

PB7

PB5

PB3

PB0

RCM3300 PROTOTYPING BOARD

ACT

PD7

PD3

PD5

PG3

PG1

PC7

PC5

PC3

PC1

PF0

PF2

PA0

PA2

PA4

PA6

STAT

RESET

+3.3 V

VRAM

SMODE1

/IORD

PG4

PG6

PE0

PE3

PE5

R12

PF4 PF6 PE7

PB6

PB4

PB2

/RES_OUT

LINK

PD6

PD2

PD4

PG2

PG0

PC6

PC4

PC2

PC0

PF1

PF3

PA1

PA3

PA5

PA7

GND

RP1

C74

R22

R4 U1

R70

R85

R80

R64

HO4

D5D6D7

R30

DS4

R84

L293D H-DRIVER

RP2

R19

R18

U16

R6 R9

C14

HO3

R17

R13

HO2

R31

DS5 DS6

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

JP1

R13

OUT

R17

U13

R15

C81

R27 R26

C35

R15 R14

C28

R23

C24

CX1

C20

C19

C15

UX1

C11

SO20W

C10

CX2

R10

UX2

SO20W

R11

R12

J13

C21

C22

HO1

C23

C24

J14

R32

TxE RxE GND TxF RxF 485+ GND 485

SPEED

R38 R37

R36

R35

GND/EGND

DS4

GND

R43

C105

GND

C10

C42

CORE MODULE

R67

R96

R21

R27

+DC

GND

C11

C79

C76

C86

R81

R82

R30

C61

JP8

JP4

JP5

R22

Q2Q3Q4

R28

R1 J2

OUT

C12

JP4

C77

R79

C72

C70

C82

JP7

C22

C12

C13

JP9

R59

R50

R49

CORE

POWER

DS1

J10

00 01 02 03 04 05 06 07

C13

C78

R16

C71

C80

R31 R54

R53

R44

C58

C36

C34

R20

R21

R25

JP6

C27

C21

C18

C3 C2 R7

C16

R29

R86

R50

R24

R23

R77

C104

C67

R45

GND

J12

R29

DS2

DS3

+DC

R11

R67

R68 R69 R70

USR FMLINK ACT

DS3

DS2

DS1

R25

R26

JP2

L293D H-DRIVER

R14

VMB MDB1 MDB2 MDB3 MDB4 VMB+

PF0_CLKD

PF0_QD

+5V QD2A QD2 B QD1A QD1B GND

R52 R53

R51

R54

JP3

R59

R55

R56

R57

R58

BT1

+5 V

GND

+3.3 V

RX13

RX16

RX14

RX17

RX18

RX15

UX4

DX1

SOT23-6

UX5

DX2

SOT23-6

C18

C17

R33

R34

U10

R35

R36

R37

JP5

R38

C26

C25

LCD1JA

J15

R39

/RES

LED0

/CS

LED1

+BKLT

C19

R40

U11

KEYPAD DISPLAY BOARD

LCD

/CS

BA0

LED2

LED4

LED3

LED5

R41

LCD1JB

Figure 4. Connect Ethernet Cable for Ethernet Programming Option

You may also use a crossover CAT 5/6 Ethernet cable to connect the Ethernet jack on the RCM3365 directly to your PC, but there will be additional steps required to configure the TCP/IP parameters on the RCM3365 and on your PC if your PC does not have a DHCP server. These steps are described in Appendix E.

12 RabbitCore RCM3365/RCM3375

2.2.3 Step 3 — Connect Power

When all other connections have been made, you can connect power to the Prototyping Board. Connect the wall transformer to jack J1 on the Prototyping Board as shown in Figure 3.

Plug in the wall transformer.

The core LED on the Prototyping Board should light up. The

RCM3365/RCM3375 and the Prototyping Board are now ready to be used.

NOTE: A RESET button is provided on the Prototypi ng Board to a llow a har dware reset

without disconnecting power. The RCM3365/RCM3375 can also be reset from Dynamic C by pressing <Ctrl-Y> if your PC is connected to the RCM3365/RCM3375 via the serial programming cable.

2.2.3.1 Alternate Power-Supply Connections

All Development Kits include a header connector that may be used to connect your power supply to 3-pin header J2 on the Prototyping Board. The connector may be attached either way as long as it is not offset to one side—the center pin of J2 is always connected to the positive terminal, and either edge pin is negative. The power supply should deliver 8 V to 30 V DC at 8 W.

User’s Manual 13

2.3 St arting Dynamic C

Once the RCM3365/RCM3375 is connected as described in the preceding pages, start Dynamic C by double-clicking on the Dynamic C icon on your desktop or in your Start menu. Select Code an d BIOS in Fla sh , Run in RAM on the “Compiler” tab in the Dynamic C Options > Project Options menu. Click OK.

Section 2.3.1 explains the remaining Dynamic C configurations to run a sample program via the serial programming cable, and Section 2.3.2 explains the remaining Dynamic C configurations to run a sample program via an Ethernet cable.

14 RabbitCore RCM3365/RCM3375

2.3.1 Running Dynamic C via Serial Programming Cable

Dynamic C uses the serial port on your PC that you specified during installation. If you are using a USB port to connect you r computer to the RCM3365 /RCM3375 module,

choose

Communications tab.

2.3.1.1 Run a Sample Program

Options > Project Options and select “Use USB to Serial Converter” on the

Use the File menu to open the sample program PONG.C, which is in the Dynamic C

SAMPLES folder. Press function key F9 to compile and run the program. The STDIO

window will open on your PC and will display a small square bouncing around in a box. This program shows that the CPU is working. The sample program described in

Section 6.5, “Run the PINGME.C Sample Program,” tests the TCP/IP portion of the board.

2.3.1.2 Troubleshooting

If Dynamic C cannot find the target system (error message "No Rabbit Processor Detected."):

• Check that the RCM3365/RCM3375 is powered correctly — the red CORE LED on the

Prototyping Board should be lit when the RCM3365/RCM3375 is mounted on the Prototyping Board and the AC adapter is plugged in

• Check both ends of the programming cable to ensure that they are firmly plugged into the PC and the PROG connector, not the DIAG connector , is plugged in to the programming port on the RCM3365/RCM3375 with the marked (colored) edge of the programming cable towards pin 1 of the programming header.

• Ensure that the RCM3365/RCM3375 module is firmly and correctly installed in its connectors on the Prototyping Board.

• Dynamic C uses the COM port specified during installation. Select a different COM port within Dynamic C. From the Options menu, select Project Options, then select

Communications. Select another COM port from the lis t, the n cl ick OK. Press <Ctrl-Y> t o f o rce Dynamic C to r ecompil e the BI OS . I f Dynamic C still reports it is

unable to locate the target system, repeat the above steps until you locate the COM port used by the programming cable.

If Dynamic C appears to compile the BIOS successfully, but you then receive a communication error message when you compile and load the sample program, it is possible that your PC cannot handle the higher program-loading baud rate. Try changing the maximum download rate to a slower baud rate as follows.

• Locate the Serial Options dialog in the Dynamic C O ptions > Project Options > Communications menu. Select a slower Max download baud rate.

If a program compiles and loads, but then loses target communication before you can begin debugging, it is possible that your PC cannot handle the default debugging baud rate. Try lowering the debugging baud rate as follows.

• Locate the Serial Options dialog in the Dynamic C O ptions > Project Options > Communications menu. Choose a lower debug baud rate.

User’s Manual 15

2.3.2 Running Dynamic C via Ethernet Cables

The firmware needed to run RabbitSys has been preloaded on RCM3365 RabbitCore modules sold for use with Dynamic C RabbitSys. The software from the Dynamic C and the Dynamic C RabbitSys CDs must be installed on your PC. A system running RabbitSys can be connected to a DHCP network using straight-through Ethernet cables, or it can be connected directly to the PC via an Ethernet crossover cable.

• If you are connecting to a network with a DHCP server, use a CAT 5/6 straight-through Ethernet cable to connect the PC or workstation to the network, and connect the Ethernet jack on the RCM3365 to the network using a second CAT 5/6 straight-through Ethernet cable.

• If your PC or workstation is running a DHCP server, connect the CAT 5/6 Ethernet crossover cable from the PC or workstation directly to the Ethernet jack on the RCM3365. Follow the instructions below for a straight-through Ethernet cable.

TIP: It is recommended that you use one of the above options for a PC/workstation or

network with a DHCP server or the serial cable programming option when you are using the RCM3365 for the first time since these options are easier to set up and run.

• If your PC/workstation does not have a DHCP server , you will have to enter the TCP/IP parameters into the RCM3365 module and on to the PC, notebook, or workstation. See Appendix E for more information on this option.

Using DHCP Network with Straight-Through Ethernet Cables

Enable separate instruction and data spaces and select “Compile program in RabbitSys user mode” from the Dynamic C Options > Project Options > Compiler menu.

Before you compile and run a program via the Ethernet for the first time via a DHCP network, you must run the rdiscover utility by double-clicking it on your PC desktop. Your PC must be connected to the same DHCP network as the RCM3365. The utility will open a window and list the MAC addresses for any RabbitSys boards connected to the network.

Select a board from the list to display additional information such as the board’s Internet address. This is the IP address to enter when you access the Dynamic C Options > Project

Options > Communications

menu to select “Use TCP/IP Connection.” You must also enter “32023” for the Control Port and the default login values of “admin” and “password.”

2.3.2.1 Run a Sample Program

Use the File menu to open the sample program PONG.C, which is in the Dynamic C

SAMPLES folder. Press function key F9 to compile and run the program. The STDIO

window will open on your PC and will display a small square bouncing around in a box. This program shows that the CPU is working. The sample program described in

Section 6.5, “Run the PINGME.C Sample Program,” tests the TCP/IP portion of the board.

16 RabbitCore RCM3365/RCM3375

2.3.2.2 Troubleshooting

If the rdiscover utility could not find your RCM3365:

• Check that your network has a DHCP server, and that the RCM3365 and your PC are connected to the same network.

• If you compiled and ran a sample program with the RabbitSys project option disabled, you may have overwritten the RabbitSys binary file. Use the serial programming cable to connect programming header J1 on the RCM3365 to your PC COM port to reload the RabbitSys binary file via the Dynamic C Compile > Reload RabbitSys binary menu.

If the rdiscover utility could not find your RCM3365, and you were unable to reload the RabbitSys binary file, your RCM3365 does not have the firmware to support Dynamic C RabbitSys and cannot be used with Dynamic C RabbitSys.

If Dynamic C returns an error message, check that the RCM3365 is powered correctly. The red CORE LED on the Pr ototypi ng B oard s hould be lit when the RCM3365 is mounted on the Prototyping Board and the AC adapter is plugged in. Ensure that the RCM3365 module is firmly and correctly installed in its connectors on the Prototyping Board.

2.4 Where Do I Go From Here?

If the sample program ran fine, you are now ready to go on to other sample programs and to develop your own applications. The source code for the sample programs is provided to allow you to modify them for your own use. The RCM3365/RCM3375 User’s Manual also provides complete hardware reference information and describes the software function calls for the RCM3365 and the RCM3375, the Prototyping Board, and the optional LCD/keypad module.

For advanced development topics, refer to the Dynami c C User’ s Ma nual, the Dynamic C RabbitSys User’s Manual, and the Dynamic C TCP/IP User’ s Manual, also in the online documentation set.

2.4.1 Technical Support

NOTE: If you purchased your RCM3365/RCM3375 through a distributor or thr ough a

Rabbit partner, contact the distributor or partner first for te c hnic al support.

User’s Manual 17

18 RabbitCore RCM3365/RCM3375

3. RUNNING SAMPLE PROGRAMS

To develop and debug programs for the RCM3365/RCM3375 (and for all other Rabbit hardware), you must install and use Dynamic C.

3.1 Introduction

To help familiarize you with the RCM3365 and RCM3375 modules, Dynamic C includes several sample programs. Loading, executing and studying these programs will give you a solid hands-on overview of the RCM3365/RCM3375’s capabilities, as well as a quick start using Dynamic C as an application development tool.

NOTE: The sample programs assume that you have at least an elementary g ras p of the C

programming language. If you do not, see the introductory pages of the Dynamic C User’s Manual for a suggested reading list.

More complete information on Dynamic C is provided in the Dynamic C User’s Manual. In order to run the sample programs discussed in this chapter and elsewhere in this manual,

1. Your RCM3365/RCM3375 module must be plugged in to the Prototyping Board as described in Chapter 2, “Getting Started.”

2. Dynamic C must be installed and running on your PC.

3. The RCM3365/RCM3375 module must be connected to your PC either through the serial programming cable or through an Ethernet cable/network if you have a RabbitSys-enabled RCM3365.

4. Power must be applied to the RCM3365/RCM3375 through the Prototyping Board.

Refer to Chapter 2, “Getting Started,” if you need further information on these steps. Since the RCM3365 and the RCM3375 run at 44.2 MHz and are equipped with a fast pro-

gram execution SRAM, remember to allow the compiler to run the application in the fast program execution SRAM by selecting Code and BIOS in Flash, Run in RAM from the Dynamic C Options > Project Options > Compiler menu.

To run a sample program, open it with the File menu, then press function key F9 to compile and run the program.

User’s Manual 19

3.2 Sample Programs

Of the many sample programs included with Dynamic C, several are specific to the RCM3365 and the RCM3375. Sample programs illustrating the general operation of the RCM3365/RCM3375, serial communication, and the NAND flash are provided in the

SAMPLES\RCM3360 folder. Each sample program has comments that describe the purpose

and function of the program. Follow the instructions at the beginning of the sample program. Note that the RCM3365/RCM3375 must be installed on the Prototyping Board when using the sample programs described in this chapter.

• CONTROLLED.c—Demonstrates use of the digital inputs by having you turn the LEDs on the Prototyping Board on or off from the STDIO window on your PC.

Once you compile and run CONTROLLED.C, the following display will appear in the Dynamic C STDIO window.

Press “2” or “3” or “4”or “5”on your keyboard to select LED DS3 or DS4 or DS5 or DS6 on the Prototyping Board. Then follow the prompt in the Dynamic C STDIO window to turn the LED on or off.

• FLASHLED.c—Demonstrates assembly-language program by flashing the USR LED on the RCM3365/RCM3375 and LEDs DS3, DS4, DS5, and DS6 on the Prototyping Board.

• SWRELAY.c—Demonstrates the relay-switching function call using the relay installed on the Prototyping Board through screw-terminal header J17.

• TOGGLESWITCH.c—Uses costatements to detect switches S2 and S3 using debouncing. The corresponding LEDs (DS3 and DS4) will turn on or off.

Once you have loaded and executed these four programs and have an understanding of how Dynamic C and the RCM3365/RCM3375 modules interact, you can move on and try the other sample programs, or begin building your own.

20 RabbitCore RCM3365/RCM3375

3.2.1 Use of NAND Flash

The following sample programs can be found in the SAMPLES\RCM3360\NANDFlash folder. As you run most of these sample programs, you will be prompted in the Dynamic C dow to select either the

soldered-in NAND flash (RCM3365 model only) or the socketed

STDIO win-

xD-Picture Card (0 = soldered, 1 = socketed).

• NFLASH_DUMP.c—This program is a utility for dumping the nonerased contents of a NAND flash chip to the Dynamic C STDIO window, and the contents may be redirected to a serial port.

When the sample program starts running, it attempts to communicate with the userselected NAND flash chip. If this communication is successful and the main page size is acceptable, the nonerased page contents (non 0xFF) from the NAND flash page are dumped to the Dynamic C STDIO win.for inspection.

Note that an error message might appear when the first 32 pages (0x20 pages) are “dumped.” You may ignore the error message.

• NFLASH_INSPECT.c—This program is a utility for inspecting the contents of a NAND flash chip. When the sample program starts running, it attempts to communicate with the NAND flash chip selected by the user. Once a NAND flash chip is found, the user can execute various commands to print out the contents of a specified page, clear (set to zer o) all the bytes in a specified pa ge, erase (s et to FF), or wri te to specifie d pages.

CAUTION: When you run this sample program, enabling the #define NFLASH_

CANERASEBADBLOCKS macro makes it possible to write t o bad bloc ks. The first two

blocks on the xD-Picture Card are mark ed bad to prot ec t the configuration data needed to use the card in a digital camera or a PC. You will only be able to use the xD-Picture Card in Rabbit-based systems if either of the first two blocks is written to.

• NFLASH_LOG.c—This program runs a simple Web server and stores a log of hits in the NAND flash. As long as the xD-Picture Card is plugged in to its connector J6, this sample program will log hits to the xD-Picture Card. Remove the xD-Picture Card if you wish to log hits on the soldered-in NAND flash (RCM3365 model only).

This log can be viewed and cleared from a browser by connecting the RJ-45 jack on the RCM3365 to your PC as described in Section 6.1. The sidebar on the next page explains how to set up your PC or notebook to view this log.

User’s Manual 21

Follow these instructions to set up your PC or notebook. Check with your administrator if you are unable to change the settings as described here since you may need administrator privileges. The instructions are specifically for Windows 2000, but the interface is similar for other versions of Windows.

TIP: If you are using a PC that is already on a network, you will disconnect the PC

from that network to run these sample programs. Write down the existing settings before changing them to facilitate restoring them when you are finished with the sample programs and reconnect your PC to the network.

1. Go to the control panel (Start > Settings > Control Panel), and then double-click the Network icon.

2. Select the network interface card used for the Ethernet interface you intend to use (e.g., TCP/IP Xircom Credit Card Network Adapter) and click on the “Properties” button. Depending on which version of Windows your PC is running, you may have to select the “Local Area Connection” first, and then click on the “Propertie s” button to bring up the Ethernet interface dialog. Then “Configure” your interface card for a “10Base-T Half-Duplex” or an “Auto-Negotiation” connection on the “Advanced” tab.

NOTE: Your network interface card will likely have a different name.

3. Now select the IP Address tab, and check Specify an IP Address, or select TCP/IP and click on “Properties” to assign an IP address to your computer (this will disable “obtain an IP address automatically”):

IP Address : 10.10.6.101 Netmask : 255.255.255.0 Default gateway : 10.10.6.1

4. Click <OK> or <Close> to exit the various dialog boxes.

As long as you have not modified the TCPCONFIG 1 macro in the sample program, enter the following server address in your Web browser to bring up the Web page served by the sample program.

http://10.10.6.100

Otherwise use the TCP/IP settings you entered in the TCP_CONFIG.LIB library. This sample program does not exhibit ideal behavior in its method of writing to the

NAND flash. However, the inefficiency attributable to the small amount of data written in each append operation is offset somewhat by the expected relative infrequency of these writes, and by the sample program's method of “walking” through the flash blocks when appending data as well as when a log is cleared.

• NFLASH_ERASE.c—This program is a utility to erase all the good blocks on a NAND flash chip. When the program starts running, it attempts to establish communication with the NAND flash chip selected by the user. If the communication is successful, the progress in erasing the blocks is displayed in the Dynamic C STDIO window as the blocks are erased.

22 RabbitCore RCM3365/RCM3375

3.2.2 Hot-Swapping xD-Picture Card

The sample programs in this section require that you have installed the Dynamic C FAT File System module, which is included with the RCM3365/RCM3375 Development Kit.

NOTE: Versions of the Dynamic C FAT File System prior to 2.10 did not use unique

volume labels, so hot-swapping two xD-Picture Card that were both formatted with older versions of the FAT File System may cause cache recovery errors

The following sample program can be found in the SAMPLES\RCM3360\NANDFlash folder. Since Rabbit-based systems do not implement the xD-Picture Car d™ specification for data storage, hot-swap only xD-Picture Cards that you plan to have formatted for use in Rabbit-based systems.

• FAT_HOT_SWAP_3365_75.c—This program demonstrates how to hot-swap the xD- Picture Card on the RCM3365/RCM3375. Once you have compiled the sample

program and it is running, press switch SW3 on the Prototyping Board or press any keyboard key on your PC to signal your intent to do a hot-swap. Remove the xD- Picture Card and insert a new xD-Picture Card (or replace the original one) when prompted to do so in the Dynamic C STDIO window or when the green LED (DS4) on the Prototyping Board lights up. Do not remove the xD-Picture Card until you are prompted or signaled by the LED!

The the xD-Picture Card can only be hot-swapped when the xD-Picture Card is “unmounted.” This sample program “unmounts” the xD-Picture Card when it detects a keyboard hit or SW3 press. Then it waits for a new xD-Picture Card to be inserted.

The following sample program can be found in the SAMPLES\FileSystem\ folder.

• FAT_HOT_SWAP.c—This program demonstrates how to hot-swap the xD-Picture Card on boards that support the xD-Picture Card and have their data bus buffered.

Once you have compiled the sample program and it is running, press any keyboard key on your PC to signal your intent to do a hot-swap. Remove the xD-Picture Card and insert a new xD-Picture Card (or replace the original one) when prompted to do so in the Dynamic C STDIO window. Do not remove the xD-Picture Card until you are prompted!

The xD-Picture Card can only be hot-swapped when the xD-Picture Card is “unmounted.” This sample program “unmounts” the xD-Picture Card when it detects a keyboard press. Then it waits for a new xD-Picture Card to be inserted.

User’s Manual 23

3.2.3 Serial Co mmunication

The following sample programs can be found in the SAMPLES\RCM3360\SERIAL folder.

FLOWCONTROL.C—This program demonstrates hardware flow control by configuring

•

Serial Port F for CTS /RTS with serial data coming from TxE (Ser ial P ort E) a t 115,200 bps. One character at a time is received and is displayed in the

STDIO window.

To set up the Prototyping Board, you will need to tie TxE and RxE together on the RS-232 header at J14, and you will also tie TxF and RxF together as shown in the diagram.

J14

TxE RxE GND TxF RxF 485+ GND 485

A repeating triangular pattern should print out in the

STDIO window . The program periodically switches R TS (TxF) flow control on or off to

demonstrate the effect of hardware flow control.

• PARITY.C—This program demonstrates the use of parity modes by repeatedly sending byte values 0–127 from Serial Port E to Serial Port F. The program will switch between generating parity or not on Serial Port E. Serial Port F will always be checking parity, so parity errors should occur during every other sequence.

To set up the Prototyping Board, you will need to tie TxE and RxF together on the RS-232 header at J14 as shown in the diagram.

The Dynamic C STDIO window will display the error

J14

TxE RxE GND TxF RxF 485+ GND 485

sequence.

• SIMPLE3WIRE.C—This program demonstrates basic RS-232 serial communication. Lower case characters are sent by TxE, and are received by RxF. The characters are converted to upper case and are sent out by TxF , are received by RxE, and are displayed in the Dynamic C STDIO window.

To set up the Prototyping Board, you will need to tie TxE and RxF together on the RS-232 header at J14, and you will also tie RxE and TxF together as shown in the diagram.

J14

TxE RxE GND TxF RxF 485+ GND 485

• SIMPLE5WIRE.C—This program demonstrates 5-wire RS-232 serial communication by providing flow control (RTS/CTS) on Serial Port F and data flow on Serial Port E.

To set up the Prototyping Board, you will need to tie TxE and RxE together on the RS-232 header at J14, and you will also tie TxF and RxF together as shown in the diagram.

J14

TxE RxE GND TxF RxF 485+ GND 485

Once you have compiled and run this program, you can test flow control by disconnecting TxF from RxF while the program is running. Characters will no longer appear in the STDIO window, and will display again once TxF is connected back to RxF. (Do not disconnect the data path between TxE and RxE.)

24 RabbitCore RCM3365/RCM3375

• SWITCHCHAR.C—This program transmits and then receives an ASCII string on Serial Ports E and F. It also displays the serial data received from both ports in the

STDIO

window. To set up the Prototyping Board, you will need to tie

TxE and RxF together on the RS-232 header at J14, and you will also tie RxE and TxF together as shown in the diagram.

J14

TxE RxE GND TxF RxF 485+ GND 485

Once you have compiled and run this program, press and release S2 on the Prototyping Board to send a message from Serial Port E to Serial Port F; press and release S3 on the Prototyping Board to send a message from Serial Port F to Serial Port E. The data sent between the serial ports will be displayed in the

STDIO window.

Two sample programs, SIMPLE485MASTER.C and SIMPLE485SLAVE.C, are available to illustrate RS-485 master/slave communication. To run these sample programs, you will need a second Rabbit-based system with RS-485—the second system may be another RCM3365/RCM3375, or it may be any Rabbit single-board computer or RabbitCore module that supports RS-485 serial communication as long as you use the master or slave sample program associated with that board.

Before running either of these sample programs on the RCM3365/RCM3375 assembly, make sure pins 1–2 and pins 5–6 are jumpered together on header JP5 to use the RS-485 bias and termination resistors. The sample programs use Serial Port C as the RS-485 serial port, and they use PD7 to enable/disable the RS-485 transmitter.

The RS-485 connections between the slave and master devices are as follows.

• RS485+ to RS485+

• RS485– to RS485–

• GND to GND

• SIMPLE485MASTER.C—This program demonstrates a simple RS-485 transmission of lower case letters to a slave. The slave will send back converted upper case letters back to the master and display them in the STDIO window. Use SIMPLE485SLAVE.C to program the slave—reset the slave before you run SIMPLE485MASTER.C on the master.

• SIMPLE485SLAVE.C—This program demonstrates a simple RS-485 transmission of lower case letters to a master. The slave will send back converted upper case letters back to the master and display them in the STDIO window. Compile and run this program on the slave before you use SIMPLE485MASTER.C to program the master.

3.2.4 Real-Time Clock

If you plan to use the real-time clock functionality in your application, you will need to set the real-time clock. Set the real-time clock using the SETRTCKB.C sample program from the Dynamic C SAMPLES\RTCLOCK folder, using the onscreen prompts. The RTC_

TEST.C

sample program in the Dynamic C SAMPLES\RTCLOCK folder provides addi-

tional examples of how to read and set the real-time clock.

User’s Manual 25

3.2.5 RabbitNet

Sample programs are available for each RabbitNet peripheral card, and can be found in the Dynamic C

SAMPLES\RabbitNet folder. When you run any of these sample programs

in conjunction with the RCM3365/RCM3375 and the Prototyping Board, you need to add the line

#use rcm33xx.lib

at the beginning of the sample program.

TIP: You need to add #use rcm33xx.lib at the beginning of any sample program

that is not in the Dynamic C SAMPLES\RCM3360 folder.

3.2.6 Other Sample Programs

Section 6.6 describes the TCP/IP sample programs, and Appendix C.7 provides sample programs for the optional LCD/keypad module that can be installed on the Prototyping Board.

26 RabbitCore RCM3365/RCM3375

4. HARDWARE REFERENCE

Chapter 4 describes the hardware components and principal hardware subsystems of the RCM3365/RCM3375 modules. “RCM3365/RCM3375 Specifications,” provides complete physical and electrical specifications.

Figure 5 shows the Rabbit-based subsystems designed into the RCM3365/RCM3375.

Appendix A,

Ethernet

Fast SRAM

(program)

Data

SRAM

Program

Flash

NAND

Flash

32 kHz

osc

RABBIT

Battery-Backup

44.2 MHz

3000

Circuit

RabbitCore Module

Figure 5. RCM3365/RCM3375 Subsystems

osc

Customer-specific

applications

CMOS-level signals

Level

converter

RS-232, RS-485

serial communication

drivers on motherboard

Customer-supplied external 3 V battery

User’s Manual 27

4.1 RCM3365/RCM3375 Inputs and Outputs

Figure 6 shows the RCM3365/RCM3375 pinouts for headers J3 and J4.

GND

PA7 PA5 PA3 PA1 PF3 PF1 PC0 PC2 PC4

PC6-TxA

PG0 PG2

PD4

PD2/TPO

PD6/TPI

LINK/n.c.

STATUS PA6 PA4 PA2 PA0 PF2 PF0 PC1 PC3 PC5 PC7-RxA PG1 PG3 PD5 PD3/TPO+ PD7/TPI+ ACT/n.c.

/RES

PB2 PB4 PB6

PF4

PF6 PE7 PE5 PE3 PE0

PG6 PG4

/IORD

SMODE1

VRAM

+3.3 VIN

n.c.

n.c. = not connected

PB0 is shared with xD-Picture Card detect

These pinouts are as seen on

Note:

the Bottom Side of the module.

Figure 6. RCM3365/RCM3375 Pinouts

PB0 PB3 PB5 PB7 PF5 PF7 PE6 PE4 PE1 PG7 PG5 /IOWR SMODE0 /RESET_IN VBAT_EXT GND GND

The pinouts for the RCM3000, RCM3100, RCM3200, RCM3300/RCM3310, RCM3360/ RCM3370, and RCM3365/RCM3375 are almost compatible, except signals PB0, PC4, and PC5. PB0, PC4, and PC5 are used for the SPI interface to the serial flash on the RCM3300 and the RCM3310, but are available on the other modules. PB0 on the RCM3365 and the RCM3375 is used to sense whether the removable xD-Picture Card card is installed. If you need PB0 for other purposes, you may remove the surface-mount resistor at R96 (Figure A-5 shows the location of R96).

Headers J3 and J4 are

standard 2 × 34 headers with a nominal 2 mm pitch. An RJ-45 Ether-

net port is also included with the RCM3365/RCM3375. Pins 29–32 on header J3 are configured using 0 Ω resistors at locations JP4, JP5, JP7, and

JP7 to be PD3, PD2, PD7, and PD6 respectively. They may also be reconfigured to carry the Ethernet signals TPO+, TPO–, TPI+, and TPI–.

Pins 33 and 34 on header J3 are wired to carry the LINK and ACT signals that illuminated the corresponding LEDs on the RCM3365/RCM3375 module. These signals may be “disconnected” by removing 0 Ω surface-mount resistors R41 and R42 (Figure A-5 shows the

locations of R41 and R42)

28 RabbitCore RCM3365/RCM3375

Figure 7 shows the use of the Rabbit 3000 microprocessor ports in the RCM3365/ RCM3375 modules.

PC0, PC2, PC4

PC1, PC3, PC5

PG2PG3 PG6PG7

PB1, PC6, STATUS

PC7, /RESET,

SMODE0, SMODE1

4 Ethernet signals

PA0PA7

Port A

Port C

(Serial Ports B, C & D)

Port G

(Serial Ports E & F)

Programming

Port

(Serial Port A)

Ethernet

Port

RAM

PB2PB7

Port B

ABBIT

3000

Real-Time Clock

Watchdog

11 Timers

Slave Port

Clock Doubler

Backup Battery

Support

PD2PD7

Port D

Port E

(+Ethernet Port)

Port F

Port G

(+Serial Ports)

Misc. I/O

Flash

PE0PE1, PE3PE7

PF0PF7

PG0PG1, PG4PG5

/RES

/RES /IORD /IOWR

Figure 7. Use of Rabbit 3000 Ports

The ports on the Rabbit 3000 microprocessor used in the RCM3365/RCM3375 are configurable, and so the factory defaults can be reconfigured. Table 2 lists the Rabbit 3000 factory defaults and the alternate configurations.

User’s Manual 29

Table 2. RCM3365/RCM3375 Pinout Configurations

Pin Pin Name Default Use Alternate Use Notes

1GND 2 STATUS Output (Status) Output

External data bus

3–10 PA[7:0] Parallel I/O

(ID0–ID7)

Slave port data bus

(SD0–SD7) 11 PF3 Input/Output QD2A 12 PF2 Input/Output QD2B

External Data Bus

13 PF1 Input/Output

14 PF0 Input/Output

QD1A CLKC

QD1B CLKD

15 PC0 Output TXD

Serial Port D

16 PC1 Input RXD 17 PC2 Output TXC

Serial Port C

18 PC3 Input RXC 19 PC4 Output TXB 20 PC5 Input RXB

Header J3

21 PC6 Output TXA 22 PC7 Input RXA

Serial Port B

Serial Port A (programming port)

23 PG0 Input/Output TCLKF Serial Clock F output 24 PG1 Input/Output RCLKF Serial Clock F input 25 PG2 Input/Output TXF

Serial Port F

26 PG3 Input/Output RXF 27 PD4 Input/Output ATXB 28 PD5 Input/Output ARXB 29 PD2/TPO– Input/Output TPOUT– * 30 PD3/TPO+ Input/Output TPOUT+ * 31 PD6/TPI– Input/Output TPIN– * 32 PD7/TPI+ Inpu t / Out put TPIN+ * 33 LINK Output 34 ACT Output

Optional Ethernet transmit port

Optional Ethernet receive port

Max. sinking current draw 1 mA (see Note 1)

* Pins 29–32 are configured with 0 Ω surface-mount resistors at JP4, JP5, JP7, and JP8.

30 RabbitCore RCM3365/RCM3375

Table 2. RCM3365/RCM3375 Pinout Configurations (continued)

Pin Pin Name Default Use Alternate Use Notes

1 /RES Reset output

2 PB0 Input/Output CLKB

3 PB2 Input/Output

4 PB3 Input/Output

5 PB4 Input/Output

6 PB5 Input/Output

7 PB6 Input/Output IA4 External Address 4

8 PB7 Input/Output

9 PF4 Input/Output

10 PF5 Input/Output

Header J4

11 PF6 Input/Output

IA0 /SWR

IA1 /SRD

IA2 SA0

IA3 SA1

IA5 /SLAVEATTN

AQD1B PWM0

AQD1A PWM1

AQD2B PWM2

Reset output from Reset Generator

Used to detect presence of xD-Picture Card

External Address 0 Slave port write

External Address 1 Slave port read

External Address 2 Slave port Address 0

External Address 3 Slave port Address 1

External Address 5 Slave Attention

12 PF7 Input/Output

13 PE7 Input/Output

14 PE6 Input/Output I6 I/O Strobe 6

15 PE5 Input/Output

16 PE4 Input/Output

17 PE3 Input/Output I3 I/O Strobe 3

18 PE1 Input/Output

19 PE0 Input/Output

User’s Manual 31

AQD2A PWM3

I7 /SCS

I5 INT1B

I4 INT0B

I1 INT1A

I0 INT0A

I/O Strobe 7 Slave Port Chip Select

I/O Strobe 5 Interrupt 1B

I/O Strobe 4 Interrupt 0B

I/O Strobe 1 Interrupt 1A

I/O Strobe 0 Interrupt 0A

Table 2. RCM3365/RCM3375 Pinout Configurations (continued)

Pin Pin Name Default Use Alternate Use Notes

20 PG7 Input/Output RXE 21 PG6 Input/Output TXE 22 PG5 Input/Output RCLKE Serial Clock E input 23 PG4 Input/Output TCLKE Serial Clock E ouput 24 /IOWR Output External write strobe 25 /IORD Output External read strobe

(0,0)—start executing at address zero (0,1)—cold boot from slave port

26–27

Header J4

28 /RESET_IN Input Input to Reset Generator 29 VRAM Output See Notes below table

30 VBAT_EXT 3 V battery Input

SMODE0, SMODE1

(1,0)—cold boot from clocked Serial Port A

SMODE0 =1, SMODE1 = 1 Cold boot from asynchronous Serial Port A at

2400 bps (pro gram ming cable connected)

Serial Port E

Also connected to programmi ng cable

Minimum bat tery

voltage 2.85 V 31 +3.3 VIN Power Input 3.15–3.45 V DC 32 GND 33 n.c. Reserved for future use 34 GND

Notes

1. When using pins 33–34 on header J3 to drive LEDs, these pins can handle a sinking current of up to 8 mA.

2. The VRAM voltage is temperature-dependent. If the VRAM voltage drops below about

1.2 V to 1.5 V, the contents of the battery-backed SRAM may be lost. If VRAM drops below 1.0 V, the 32 kHz oscillator could stop running. Pay careful attention to this voltage if you draw any current from this pin.

3. Do not overload the /IOWR line because the NAND flash memories have critical timing requirements. In some cases it may be necessary to buffer /IOWR on the motherboard.

32 RabbitCore RCM3365/RCM3375

4.1.1 Memory I/O Interface

The Rabbit 3000 address lines (A0–A18) and all the data lines (D0–D7) are routed internally to the onboard flash memory and SRAM chips. I/0 write (/IOWR) and I/0 read (/IORD) are available for interfacing to external devices—pay attention to the loading on these two signals if you use them since these signals are also used by the RCM3365/ RCM3375.

Parallel Port A can also be used as an external I/O data bus to isolate external I/O from the main data bus. Parallel Port B pins PB2–PB7 can also be used as an auxiliary address bus.

When using the external I/O bus for a digital output or the LCD/keypad module on the Prototyping Board, or for any other reason, you must add the following line at the beginning of your program.

#define PORTA_AUX_IO // required to enable external I/O bus

4.1.2 Other Inputs and Outputs

The status, /RESET_IN, SMODE0, and SMODE1 I/O are normally associated with the programming port. Since the status pin is not used by the sys tem once a program has been downloaded and is running, the status pin can then be used as a general-purpose CMOS output. The programming port is described in more detail in Section 4.2.3.

/RES is an output from the reset circuitry that can be used to reset external peripheral devices.

4.1.3 LEDs

The RCM3365/RCM3375 has five status LEDs located beside the RJ-45 Ethernet jack:

ACT, LINK, SPEED, FM, and USR.

The yellow ACT LED at DS1 indicates network activity. The green LINK LED at DS2 indicates that the RCM3365/RCM3375 is connected to a

working network. The green SPEED LED at DS4 is on to indicate when the RCM3365/RCM3375 is con-

nected to a 100Base-T Ethernet connection. The FM LED at DS3 blinks when data are being written to or read from the flash mass-

storage device. The red USR LED at DS3 is a user-programmable LED, which is controlled by PD0 on

the Rabbit 3000’s Parallel Port D. The sample program FLASHLED.C provided in the Dynamic C SAMPLES\RCM3360 folder shows how to set up and use this userprogrammable LED.

User’s Manual 33

4.2 Serial Communication

The RCM3365/RCM3375 does not have any serial transceivers directly on the board. However, a serial interface may be incorporated into the board the RCM3365/RCM3375 is mounted on. For example, the Prototyping Board has RS-232 and RS-485 transceiver chips.

4.2.1 Serial Ports

There are six serial ports designated as Serial Ports A, B, C, D, E, and F. All six serial ports can operate in an asynchronous mode up to the baud rate of the system clock divided by 8. An asynchronous port can handle 7 or 8 data bits. A 9th bit address scheme, where an additional bit is sent to mark the first byte of a message, is also supported.

Serial Port A is normally used as a programming port, but may be used either as an asynchronous or as a clocked serial port once the RCM3365/RCM3375 has been programmed and is operating in the Run Mode.

Serial Port B is available on the RCM3365/RCM3375, and may be used as an asynchronous port. PB0 is used to enable Dynamic C to detect whether the xD-Picture Card is installed. If the card detect is not needed by your application program, you may remove R96 (see Figure A-5) to disable the xD-Picture Card detect, and then use Serial Port B as a clocked serial port.

Serial Ports C and D can also be operated in the clocked serial mode. In this mode, a clock line synchronously clocks the data in or out. Either of the two communicating devices can supply the clock.

Serial Ports E and F can also be configured as HDLC serial ports. The IrDA protocol is also supported in SDLC format by these two ports.

4.2.2 Ethernet Port

Figure 8 shows the pinout for the RJ-45 Ethernet port (J2). Note that some Ethernet connectors are numbered in reverse to the order used here.

ETHERNET

1. E_Tx+

2. E_Tx

3. E_Rx+

6. E_Rx

RJ-45 Plug

Figure 8. RJ-45 Ethernet Port Pinout

RJ-45 Jack

Three LEDs are placed next to the RJ-45 Ethernet jack, one to indicate an Ethernet link (LINK) one to indicate Ethernet activity (ACT), and one to indicate the 10 /100Base-T s peed.

The RJ-45 connector is shielded to minimize EMI effects to/from the Ethernet signals.

34 RabbitCore RCM3365/RCM3375

4.2.3 Serial Programming Port

The RCM3365/RCM3375 is programmed either through the serial programming port, which is accessed using header J1 or through the Ethernet jack. The RabbitLink may be used to provide a serial connection via the RabbitLink’s Ethernet jack. The programming port uses the Rabbit 3000’s Serial Port A for communication; Serial Port A is not used when programming is done over an Ethernet connection on a board running Dynamic C RabbitSys. Dynamic C uses the programming port to download and debug programs.

The programming port is also used for the following operations.

• Cold-boot the Rabbit 3000 on the RCM3365/RCM3375 after a reset.

• Remotely download and debug a program over an Ethernet connection using the

RabbitLink EG2110.

• Fast copy designated portions of flash memory from one Rabbit-based board (the master) to another (the slave) using the Rabbit Cloning Board.

In addition to Serial Port A, the Rabbit 3000 startup-mode (SMODE0, SMODE1), status, and reset pins are available on the programming port.

The two startup mode pins determine what happens after a reset—the Rabbit 3000 is either cold-booted or the program begins executing at address 0x0000.

The status pin is used by Dynamic C to determine whether a Rabbit microprocessor is present. The status output has three different programmable functions:

1. It can be driven low on the first op code fetch cycle.

2. It can be driven low during an interrupt acknowledge cycle.

3. It can also serve as a general-purpose CMOS output.

The /RESET_IN pin is an external input that is used to reset the Rabbit 3000 and the RCM3365/RCM3375 onboard peripheral circuits. The serial programming port can be used to force a hard reset on the RCM3365/RCM3375 by asserting the /RESET_IN signal. No equivalent functionality exists for programming over an Ethernet connection on a board running Dynamic C RabbitSys.

Alternate Uses of the Serial Programming Port

All three clocked Serial Port A signals are available as

• a synchronous serial port

• an asynchronous serial port, with the clock line usable as a general CMOS I/O pin

The programming port may also be used as a serial port once the application is running. The SMODE pins may then be used as inputs and the status pin may be used as an output.

Refer to the Rabbit 3000 Microprocessor User’s Manual for more information.

User’s Manual 35

4.3 Serial Programming Cable

The programming cable is used to connect the serial programming port of the RCM3365/ RCM3375 to a PC serial COM port. The programming cable converts the RS-232 voltage levels used by the PC serial port to the CMOS voltage levels used by the Rabbit 3000.

When the

PROG connector on the programming cable is connected to the RCM3365/

RCM3375 serial programming port at header J1, programs can be downloaded and debugged over the serial interface.

The DIAG connector o f t h e p r o g r amming cabl e m a y b e u s ed on header J 1 o f th e RC M3365/ RCM3375 with the RCM3365/RCM3375 operating in the Run Mode. This allows the programming port to be used as a regular serial port.

4.3.1 Changing Between Program Mode and Run Mode

The RCM3365/RCM3375 is automatically in Program Mode when the PROG connector on the programming cable is attached, and is automatically in Run Mode when no programming cable is attached. When the Rabbit 3000 is reset, the operating mode is determined by the state of the SMODE pins. When the programming cable’s PROG connector is attached, the SMODE pins are pulled high, placing the Rabbit 3000 in the Program Mode. When the programming cable’s PROG connector is not attached, the SMODE pins are pulled low, causing the Rabbit 3000 to operate in the Run Mode.

GND

VBT

/RES

SM0

/IOWR

PG5

PG7

PE1

PE4

PE6

PF7

PF5

PB7

PB5

PB3

PB0

RCM3300 PROTOTYPING BOARD

ACT

PD7

PD3

PD5

PG3

PG1

PC7

PC5

PC3

PC1

PF0

PF2

PA0

PA2

PA4

PA6

STAT

RESET

+3.3 V

VRAM

SMODE1

/IORD

PG4

PG6

PE0

PE3

PE5

PF4 PF6 PE7

PB6

PB4

PB2

/RES_OUT

LINK

PD6

PD2

PD4

PG2

PG0

PC6

PC4

PC2

PC0

PF1

PF3

PA1

PA3

PA5

PA7

GND

JP1

L293D H-DRIVER

R13

RP2

R17

C79

C78

R15

C77

R79

C72

C71

C70

C80

R82

C82

R31

R54

R53

R44

C58

C61

C36

C34

R20

R21

R25

JP6

C27

JP7

JP8

C21

C22

C18

C12

C13

C3 C2 R7

JP9

R29

R86

R50

R59

R64

R77

C104

C67

HO4

HO3

HO2

HO1

R45

R30

R31

R32

DS5 DS6

DS4

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

OUT

C74

U13

C81

C35

R19

R17

C28

R23

CX1

R22

R18

C24

C20

UX1

SO20W

C11

CX2

U16

C4 R4 U1

UX2

R70

R85

R84

SO20W

R80

J13

C14

C21

C22

R13

C23

C24

J14

TxE RxE GND TxF RxF 485+ GND 485

GND

USR FMLINK ACT

DS3

DS1

GND

+DC

C10

C11

DS2

CORE MODULE

R21

R22

Q2Q3Q4

R28

R27

POWER

GND

DS1

J10

00 01 02 03 04 05 06 07

OUT

C12

JP4

R16

SPEED

R38 R37

DS4

R43

C42

R36

R35

R67

C105

R96

C16

R24

R23

J12

R50

R49

CORE

DS2

RP1

C13

C76

C86

R81

R30

JP4

JP5

GND

D5D6D7

R29

DS3

+DC

R11

R12

R67

R68 R69 R70

GND/EGND

R25

R26

VMB MDB1 MDB2 MDB3 MDB4 VMB+

PF0_CLKD

PF0_QD

JP2

U3 L293D H-DRIVER

R14

BT1

+5 V

GND

R27 R26 R15 R14 R1

+3.3 V

RX13

RX16

RX14

RX17

RX18

RX15

C19

UX4

DX1

C15

C10

R10

R11

R12

R33

C25

R34

PROG

R36

C26

SOT23-6

UX5

DX2

SOT23-6

C18

C17

U10

R35

R37

JP5

R38

DIAG

+5V QD2A QD2B QD1A QD1B GND

R52 R53

R55

LCD1JB

R56

R57

R58

R40

R54

R59

LCD

/CS

BA0

J15

R39

/RES

LED0

LED2

LED4

/CS

LED1

LED3

LED5

+BKLT

C19

R41

U11

KEYPAD DISPLAY BOARD

R60 R61

R63

BA1

LED6

GND

R51

JP3

LCD1JA

Programming Cable

Colored edge

R62

R64

R65

R66

+5 V

GND

+3.3 V

BA2

BA3

BD0

BD1

GNDA3A1D0D2D4D6

D1D3D5

GND

R42

C20

U12

GND IN3 IN2 IN1 IN0 +5V

BD2

BD3

BD4

BD5

To PC COM port

LCD1JC

RABBITNET

R3R4R5

R10

J11

C14

C15

R19

R18

BD6

BD7

J16

J17

C27

C28

R44

R43

C30C29

R45

R46

R47

R48

SERIAL FLASH/

RELAY RATED

0.5 A @ 30 V

DS7

MODEM

R20

NO1 COM1 NC1 NO2 COM2 NC2

RELAY

RESET

RESET RCM3365/RCM3375 when changing mode:

Momentarily short out pins 2832 on RCM33600/RCM33610 header J4,

Press RESET button (if using Prototyping Board), OR Cycle power off/on

after removing or attaching programming cable.

Figure 9. Switching Between Program Mode and Run Mode

36 RabbitCore RCM3365/RCM3375

A program “runs” in either mode, but can only be downloaded and debugged when the RCM3365/RCM3375 is in the Program Mode.

Refer to the

Rabbit 3000 Microprocessor User’s Manual for more information on the pro-

gramming port.

4.3.2 Standalone Operation of the RCM3365/RCM3375

The RCM3365/RCM3375 must be programmed via the Prototyping Board or via a similar arrangement on a customer-supplied board. Once the RCM3365/RCM3375 has been programmed successfully, remove the serial programming cable from the programming connector and reset the RCM3365/RCM3375. The RCM3365/RCM3375 may be reset by cycling the power off/on or by pressing the RESET button on the Prototyping Board. The RCM3365/RCM3375 module may now be removed from the Prototyping Board for enduse installation.

CAUTION: Disconnect power to the Prototyping Board or other boards when removing

or installing your RCM3365/RCM3375 module to protect against inadvertent shorts across the pins or damage to the RCM3365/RCM3375 if the pins are not plugged in correctly. Do not reapply power until you have verified that the RCM3365/RCM3375 module is plugged in correctly.

User’s Manual 37

4.4 Memory

4.4.1 SRAM

RCM3365/RCM3375 boards have 512K of program-execution fast SRAM at U11. The program-execution SRAM is not battery-backed. There are 512K of battery-backed data SRAM installed at U10.

4.4.2 Flash EPROM

RCM3365/RCM3375 boards also have 512K of flash EPROM at U9.

NOTE: Rabbit recommends that any customer appl ic at io ns should not be constrained by

the sector size of the flash EPROM since it may be necessary to change the sector size in the future.

Writing to arbitrary flash memory addresses at run time is also discouraged. Instead, use a portion of the “user block” area to store persistent data. The functions writeUser- Block and readUserBlock are provided for this. Refer to the Rabbit 3000 Micropro-

cessor Designer’s Handbook

information.

4.4.3 NAND Flash

The RCM3365 and the RCM3375 support a removable xD-Picture Card™ to store data and Web pages. The RCM3365 and the RCM3375 both can handle up to a 128MB removable

xD-Picture Card, and the RCM3365 model also has a 32MB onboard NAND flash.

and the Dynamic C Function Reference Manual for additional

NOTE: Rabbit-based systems do not implement the xD-Pic tu re Card™ specific ati on f o r

data storage, and are neither compatible nor compliant with xD-Picture Card™ card readers.

The NAND flash and xD-Picture Card are particularly suitable for mass-storage applica- tions, but are generally unsuitable for direct program execution. The NAND flash differs from parallel NOR flash (the type of flash memory used to store program code on Rabbitbased boards and RabbitCore modules currently in production) in two respects. First, the NAND flash requires error-correcting code (ECC) for reliability. Although NAND flash manufacturers do guarantee that block 0 will be error-free, most manufacturers guarantee that a new NAND flash chip will be shipped with a relatively small percentage of errors, and will not develop more than some maximum number or percentage of errors over its rated lifetime of up to 100,000 writes. Second, the standard NAND flash addressing method multiplexes commands, data, and addresses on the same I/O pins, while requiring that certain control lines must be held stable for the duration of the NAND flash access. The software function calls provided by Rabbit for the NAND flash take care of the dataintegrity and reliability attributes.

* RCM3365 modules sold before 2008 had 16MB fixed NAND flash memory.

38 RabbitCore RCM3365/RCM3375

Figure 10 shows how to insert or remove the x D-Picture Card. While you remove or insert

xD-Pictur e Car d , take care to avoid touching the electrical contacts on the bottom of the

the card to prevent electrostatic discharge damage to the card and to keep any moisture or other contaminants off the contacts. Do not remove or insert the xD-Picture Car d while it is being accessed.

R13

R12

R11

R10

C10

C11

C15

C19

C20

C24

R23

C28

R14

R17

R15

C35 R26 R27

C81

U13

R45

C67

C14

C104

R77

R64

R80

R59

R50

R84

R85

R70

R86

R29

U1 R4

U16

R18

R22

R19

C74

JP9 R7 C2 C3

C12

C13

C18

C22

C21

JP7

JP8

JP4

JP5

C27

R96

JP6

R25

C34

R20

R21 C36

C58

R44

R53

R54 R31

C80

C71

C78

C105

R67

C61

R30

C82

R82

R81

C70

C86

C76

C72

C42

C77

R79

C79

DS1

R35

DS2

R36

R43

DS4

R37

DS3

R38

USR FMLINK ACT

SPEED

Figure 10. Insertion/Removal of xD-Picture Card

It is possible to hot-swap xD-Picture Cards without removing power from the RCM3365/ RCM3375 module. The file system must be closed before the cards can be hot-swapped. The chip selects associated with the NAND flash and the x D-Picture Card must be set to their inactive state, and read/write operations addressed to the NAND flash area cannot be allowed to occur. These operations can be initiated in software by sensing an external switch actuated by the user, and the xD-Picture Card can then be removed and replaced with a different one. Once the application program detects a new card, the file system can be opened. These steps allow the xD-Picture Card to be installed or removed without affecting either the program, which continues to run on the RCM3365/RCM3375 module, or the data stored on the xD-Picture Card.

The FAT_HOT_SWAP_336x0.C sample program in the SAMPLES\FileSystem\ folder illustrates this hot-swapping procedure.

Rabbit recommends that you use header J6 only for the xD-Picture Card since other devices are not supported. Be careful to remove and insert the xD-Picture Card as shown, and be careful not to insert any foreign objects, which may short out the contacts and lead to the destruction of your xD-Picture Card.

Sample programs in the SAMPLES\RCM3360\NANDFlash folder illustrate the use of the NAND flash. These sample programs are described in Section 3.2.1, “Use of NAND Flash.” Pay careful attention to the sample programs to see how to close files and secure any data on the xD-P icture Card before you remove it.

User’s Manual 39

4.5 Other Hardware

4.5.1 Clock Doubler

The RCM3365/RCM33610 takes advantage of the Rabbit 3000 microprocessor’s internal clock doubler. A built-in clock doubler allows half-frequency crystals to be used to reduce radiated emissions. The 44.2 MHz frequency specified for the RCM3365/RCM3375 is generated using a 22.12 MHz resonator.

The clock doubler may be disabled if 44.2 MHz clock speeds are not required. This will reduce power consumption and further reduce radiated emissions. The clock doubler is disabled with a simple configuration macro as shown below.

1. Select the “Defines” tab from the Dynamic C Options > Project Options menu.

2. Add the line CLOCK_DOUBLED=0 to always disable the clock doubler. The clock doubler is enabled by default, and usually no entry is needed. If you need to

specify that the clock doubler is always enabled, add the line CLOCK_DOUBLED=1 to always enable the clock doubler.

3. Click OK to save the macro. The clock doubler will now remain off whenever you are in the project file where you defined the macro.

4.5.2 Spectrum Spreader

The Rabbit 3000 features a spectrum spreader, which helps to mitigate EMI problems. The spectrum spreader is on by default, but it may also be turned off or set to a stronger setting. The means for doing so is through a simple configuration macro as shown below.

1. Select the “Defines” tab from the Dynamic C Options > Project Options menu.

2. Normal spreading is the default, and usually no entry is needed. If you need to specify normal spreading, add the line

ENABLE_SPREADER=1

For strong spreading, add the line

ENABLE_SPREADER=2

To disable the spectrum spreader, add the line

ENABLE_SPREADER=0

NOTE: The strong spectrum-spreading setting is not recommended since it may limit

the maximum clock speed or the maximum baud rate. It is unlikely that the strong setting will be used in a real application.

3. Click OK to save the macro. The spectrum spreader will now be set to the state specified by the macro value whenever you are in the project file where you defined the macro.

NOTE: Refer to the Rabbit 3000 Microprocessor User’s Manual for more infor m at ion

on the spectrum-spreading setting and the maximum clock speed.

40 RabbitCore RCM3365/RCM3375

5. SOFTWARE REFERENCE

Dynamic C is an integrated development system for writing embedded software. It runs on an IBM-compatible PC and is designed for use with Rabbit controllers and other controllers based on the Rabbit microprocessor. Chapter 5 describes the libraries and function calls related to the RCM3365/RCM3375.

5.1 More About Dynamic C

Dynamic C has been in use worldwide since 1989. It is specially designed for programming embedded systems, and features quick compile and interactive debugging. A complete reference guide to Dynamic C is contained in the Dynamic C User’s Manual.

You have a choice of doing your software development in the flash memory or in the static SRAM included on the RCM3365/RCM3375. The flash memory and SRAM options are selected with the Options > Program Options > Compiler menu.

The advantage of working in RAM is to save wear on the flash memory, which is limited to about 100,000 write cycles. The disadvantage is that the code and data might not both fit in RAM.

NOTE: An application should be run from the program execution SRAM after the serial

programming cable is disconnected. Your final code must always be stored in flash memory for reliable operation. RCM3365/RCM3375 modules running at 44.2 MHz have a fast program execution SRAM that is not battery-backed. Select

BIOS in Flash, Run in RAM Compiler

SRAM at run-time to take advantage of the faster clock speed. This option optimizes the performance of RCM3365/RCM3375 modules running at 44.2 MHz.

NOTE: Do not depend on the flash memory sector size or type in your program logic.

The RCM3365/RCM3375 and Dynamic C were designed to accommodate flash devices with various sector sizes in response to the volatility of the flash-memory market.

Developing software with Dynamic C is simple. Users can write, compile, and test C and assembly code without leaving the Dynamic C development environment. Debugging occurs while the application runs on the target. Alternatively, users can compile a program to an image file for later loading. Dynamic C runs on PCs under Windows 2000/NT and

later—see Rabbit’s Technical Note TN257, Running Dynamic C® With Windows Vista®,

menu to store the code in flash and copy it to the fast program execution

from the Dynamic C Options > Project Options >

Code and

User’s Manual 41

for additional information if you are using a Dynamic C release prior to v. 9.60 under Windows Vista. Programs can be downloaded at baud rates of up to 460,800 bps after the program compiles.

Dynamic C has a number of standard features.

• Full-feature source and/or assembly-level debugger, no in-circuit emulator required.

• Royalty-free TCP/IP stack with source code and most common protocols.

• Hundreds of functions in source-code libraries and sample programs:

X Exceptionally fast support for floating-point arithmetic and transcendental functions. X RS-232 and RS-485 serial communication. X Analog and digital I/O drivers.

X I

C, SPI, GPS, file system.

X LCD display and keypad drivers.

• Powerful language extensions for cooperative or preemptive multitasking

• Loader utility program to load binary images into Rabbit targets in the absence of

Dynamic C.

• Provision for customers to create their own source code libraries and augment on-line help by creating “function description” block comments using a special format for library functions.

• Standard debugging features:

X Breakpoints—Set breakpoints that can disable interrupts. X Single-stepping—Step into or over functions at a source or machine code level, µC/OS-II aware. X Code disassembly—The disassembly window displays addresses, opcodes, mnemonics, and

machine cycle times. Switch between debugging at machine-code level and source-code level by simply opening or closing the disassembly window.

X Watch expressions—Watch expressions are compiled when defined, so complex expressions

including function calls may be placed into watch expressions. Watch expressions can be updated with or without stopping program execution.

X Register window—All processor reg isters and f lags are disp layed. The con tents of gener al register s

may be modified in the window by the user.

X Stack window—shows the contents of the top of the stack. X Hex memory dump—displays the contents of memory at any address. X STDIO window—

detected for debugging purposes.

printf outputs to this window and keyboard input on the host PC can be

printf output may also be sent to a serial port or file.

42 RabbitCore RCM3365/RCM3375

5.1.1 Developing Programs Remotely with Dynamic C

Dynamic C is an integrated development environment that allows you to edit, compile, and debug your programs. Dynamic C has the ability to allow programming over the Internet or local Ethernet. This is accomplished in one of three ways.

1. RCM3365 RabbitCore modules that are preloaded with Dynamic C RabbitSys firmware can be used with Dynamic C RabbitSys to be accessed via an Ethernet connection for remote application updates, and for remote monitoring and control. Dynamic C RabbitSys requires Dynamic C version 9.30 or later, and allows the RCM3365. The Dynamic C RabbitSys User’s Manual provides complete information on RabbitSys.

2. Via the Rabbit RabbitLink, which allows a Rabbit-based target to have programs downloaded to it and debugged with the same ease as exists when the target is connected directly to a PC.

3. Dynamic C provides sample programs to illustrate the use of a download manager, but these sample programs are not intended for use with the NAND flash on the RCM3365 and RCM3375 RabbitCore modules. The grams found in the Dynamic C

SAMPLES\DOWN_LOAD

DLM_TCP.C

and

DLP_TCP.C

sample pro-

folder, are intended to be compiled to the program flash memory (which is a parallel flash memory). Custom applications based on these sample programs may use the NAND flash for data storage.

User’s Manual 43

5.2 Dynamic C Functions

5.2.1 Digital I/O

The RCM3365/RCM3375 was designed to interface with other systems, and so there are no drivers written specifically for the I/O. The general Dynamic C read and write functions allow you to customize the parallel I/O to meet your specific needs. For example, use

WrPortI(PEDDR, &PEDDRShadow, 0x00);

to set all the Port E bits as inputs, or use

WrPortI(PEDDR, &PEDDRShadow, 0xFF);

to set all the Port E bits as outputs. When using the external I/O bus on the Rabbit 3000 chip, add the line

#define PORTA_AUX_IO // required to enable external I/O bus

to the beginning of any programs using the external I/O bus. The sample programs in the Dynamic C

SAMPLES/RCM3360

folder provide further

examples.

5.2.2 SRAM Use

The RCM3365/RCM3375 have a battery-backed data SRAM and a program-execution SRAM. Dynamic C provides the

protected

keyword to identify variables that are to be placed into the battery-backed SRAM. The compiler generates code that maintains two copies of each protected variable in the battery-backed SRAM. Th e compiler also gene rates a flag to ind icat e whic h copy of the protected variable is valid at the current time. This flag is also stored in the battery-backed SRAM. When a protected variable is updated, the “inactive” copy is modified, and is made “active” only when the update is 100% complete. This assures the integrity of the data in case a reset or a power failure occurs during the update process. At power-on the application program uses the active copy of the variable pointed to by its associated flag.

The sample code below shows how a protected variable is defined and how its value can be restored.

protected nf_device nandFlash;

int main() { ...

_sysIsSoftReset(); // restore any protected variables

The

bbram

keyword may also be used instead if there is a need to store a variable in bat-

tery-backed SRAM without affecting the performance of the application program. Data integrity is not assured when a reset or power failure occurs during the update process.

Additional information on

bbram

and

protected

variables is available in the Dynamic C

User’s Manual.

44 RabbitCore RCM3365/RCM3375

5.2.3 Serial Co mmunication Drivers

Library files included with Dynamic C provide a full range of serial communications support. The

PACKET.LIB

RS232.LIB

library provides packet-based serial functions where packets can be delimited

library provides a set of circular-buffer-based serial functions. The

by the 9th bit, by transmission gaps, or with user-defined special characters. Both libraries provide blocking functions, which do not return until they are finished transmitting or receiving, and nonblocking functions, which must be called repeatedly until they are finished, allowing other functions to be performed between calls. For more information, see the Dynamic C Function Reference Manual and Technical Note TN213, Rabbit Serial Port Software.

5.2.4 TCP/IP Drivers

The TCP/IP drivers are located in the

LIB\TCPIP

folder. Complete information on these

libraries and the TCP/IP functions is provided in the Dynamic C TCP/IP User’s Manual.

5.2.5 NAND Flash Drivers

The Dynamic C

NANDFlash\NFLASH.LIB

library is used to interface to NAND flash memory devices on the RCM3365 and the RCM33 75. The function calls were written specifically to work with industry-standard flash devices with a 528-byte page program and 16896-byte block erase size. The NAND flash function calls are designed to be closely cross-compatible with the newer serial flash function calls found in the library . These function calls use an

nf_device

structure as a handle for a specific NAND

SFLASH.LIB

flash device. This allows multiple NAND flash devices to be used by an application. More information on these function calls is available in the Dynamic C Function Refer-

ence Manual. The NAND flash and the xD-Picture Card are ideally suited to store files with a directory

structure. The Dynamic C FAT file system module provides support for a file system and for formatting the xD-Picture Car d for use in a Rabbit-bas ed system. Visit our W eb site at

www.rabbit.com or contact your Rabbit sales representative or authorized distributor for

further information on the Dynamic C FAT File System and other Dynamic C modules. The supporting documentation for the Dynamic C FAT File System and the sample programs in the SAMPLES\FileSystem\ folder illustrate the use of the Dynamic C FAT file system.

User’s Manual 45

5.2.6 Prototyping Board Functions

The functions described in this section are for use with the Prototyping Board features. The source code is in the Dynamic C SAMPLES\RCM3300\RCM33xx.LIB library if you need to modify it for your own board design.

The

RCM33xx.LIB

library is supported by the RN_CFG_RCM33.LIB—library, which is used to configure the RCM3365/RCM3375 for use with RabbitNet peripheral boards on the Prototyping Board.

Other generic functions applicable to all devices based on Rabbit microprocessors are described in the Dynamic C Function Reference Manual.

5.2.6.1 Board Initialization

void brdInit (void);

Call this function at the beginning of your program. This function initializes Parallel Ports A through G for use with the Prototyping Board.

Summary of Initialization

1. I/O port pins are configured for Prototyping Board operation.

2. Unused configurable I/O are set as tied inputs or outputs.

3. External I/O are disabled.

4. The LCD/keypad module is disabled.

5. RS-485 is not enabled.

6. RS-232 is not enabled.

7. LEDs are off.

8. Ethernet select is disabled.

9. Mass-storage flash select is disabled.

10. Motor control i s disabled.

11. The RabbitNet SPI interface is disabled.

12. The relay is set to normally closed positions.

RETURN VALUE

None.

46 RabbitCore RCM3365/RCM3375

5.2.6.2 Digital I/O

int digIn(int channel);

Reads the input state of inputs on Prototyping Board headers J5 and J6. D o not use this function if you configure these pins for alternate use after

PARAMETERS

channels

is the channel number corresponding to the signal on header J5 or J6

0—IN0 1—IN1 2—IN2 3—IN3 4—QD1B 5—QD1A 6—QD2B 7—QD2A

RETURN VALUE

The logic state (0 or 1) of the input.

SEE ALSO

brdInit

brdInit()

is called.

void digOut(int channel, int value);

Writes a value to an output channel on Prototyping Board header J10. Do not use this function if you have installed the stepper motor chips at U2 and U3.

PARAMETERS

channel is output channel 0–7 (OUT00–OUT07). value is the value (0 or 1) to output.

RETURN VALUE

None.

SEE ALSO

brdInit

User’s Manual 47

5.2.6.3 Switches, LEDs, and Relay

int switchIn(int swin);

Reads the state of a switch input.

PARAMETERS

swin

is the switch input to read:

2—S2 3—S3

RETURN VALUE

State of the switch input:

1 = open 0 = closed

SEE ALSO

brdInit

void ledOut(int led, int value);

Controls LEDs on the Prototyping Board and on the RCM3365/RCM3375.

PARAMETERS

led is the LED to control:

0 = red User LED on RCM3365/RCM3375 3 = DS3 on Prototyping Board 4 = DS4 on Prototyping Board 5 = DS5 on Prototyping Board 6 = DS6 on Prototyping Board

value

is the value used to control the LED:

0 = off 1 = on

RETURN VALUE

None.

SEE ALSO

brdInit

48 RabbitCore RCM3365/RCM3375

void relayOut(int relay, int value);

Sets the position for the relay common contact. The default position is for normally closed contacts.

PARAMETERS

relay is the one relay (1) value is the value used to connect the relay common contact:

0 = normally closed positions (NC1 and NC2) 1 = normally open positions (NO1 and NO2)

RETURN VALUE

None.

SEE ALSO

brdInit

5.2.6.4 Serial Communication

void ser485Tx(void);

Enables the RS-485 transmitter. Transmitted data are echoed back into the receive data buffer. The echoed data may be used as an indicator for disabling the transmitter by using o ne of the fo llowing m ethods:

Byte mode—disable the transmitter after the same byte that is transmitted is detected in the receive

data buffer.

Block data mode—disable the transmitter after the same number of bytes transmitted are detected in

the receive data buffer.

Remember to call the

SEE ALSO

ser485Rx

serXopen()

function before running this function.

void ser485Rx(void);

Disables the RS-485 transmitter. This puts the device into the listen mode, which allows it to receive data from the RS-485 interface.

Remember to call the

SEE ALSO

ser485Tx

serXopen()

function before running this function.

User’s Manual 49

5.2.6.5 RabbitNet Port

The function calls described in this section are used to configure the RabbitNet port on the Prototyping Board for use with RabbitNet peripheral cards. The user’s manual for the specific peripheral card you are using contains additional function calls related to the RabbitNet protocol and the individual peripheral card. Appendix F provides additional information about the RabbitNet.

These RabbitNet peripheral cards are available at the present time.

• Digital I/O Card (RN1100)

• A/D Converter Card (RN1200)

• Relay Card (RN1400)

• Keypad/Display Interface (RN1600)

• D/A Converter Card (RN1300)

Before using the RabbitNet port, add the following lines at the start of your program.

#define RN_MAX_DEV 10 // max number of devices #define RN_MAX_DATA 16 // max number of data bytes in any transaction #define RN_MAX_PORT 2 // max number of serial ports

Set the following bits in RNSTATUSABORT to abort transmitting data afte r the status byte is returned. This does not affect the status byte and still can be interpreted. Set any bit combination to abort:

bit 7—device busy is hard-coded into driver bit 5—identifies router or slave bits 4,3,2—peripheral-board-specific bits bit 1—com mand rejected bit 0—watchdog timeout

#define RNSTATUSABORT 0x80 // hard-coded driver default to abort if the peripheral board is busy

void rn_sp_info();

Provides rn_init() with the serial port control information needed for RCM3365/RCM3375 modules.

RETURN VALUE

None.

50 RabbitCore RCM3365/RCM3375

void rn_sp_close(int port);

Deactivates the RCM3365/RCM3375 RabbitNet port as a clocked serial port. This call is also used by rn_init().

PARAMETERS

portnum = 0

RETURN VALUE

None

void rn_sp_enable(int portnum);

This is a macro that enables or asserts the RCM3365/RCM3375 RabbitNet port chip select prior to data transfer.

PARAMETERS

portnum = 0

RETURN VALUE

None

void rn_sp_disable(int portnum);

This is a macro that disables or deasserts the RCM3365/RCM3375 RabbitNet port chip select to invalidate data transfer.

PARAMETERS

portnum = 0

RETURN VALUE

None.

User’s Manual 51

5.3 Upgrading Dynamic C

5.3.1 Extras

Dynamic C installations are designed for use with the board they are included with, and are included at no charge as part of our low-cost kits.

Starting with Dynamic C version 9.60, Dynamic C includes the popular µC/OS-II realtime operating system, point-to-point protocol (PPP), FA T file system, RabbitWeb, and other select libraries. Rabbit also offers for purchase the Rabbit Embedded Security Pack featuring the Secure Sockets Layer (SSL) and a specific Advanced Encryption Standard (AES) library.

In addition to the Web-based technical support included at no extra charge, a one-year telephone-based technical support subscription is also available for purchase.

52 RabbitCore RCM3365/RCM3375

6. USING THE TCP/IP FEATURES

6.1 TCP/IP Connections

Programming and development can be done with the RCM3365/RCM3375 modules without connecting the Ethernet port to a network. However, if you will be running the sample programs that use the Ethernet capability or will be doing Ethernet-enabled development, you should connect the RCM3365/RCM3375 module’s Ethernet port at this time.

Before proceeding you will need to have the following items.

• If you don’t have Ethernet access, you will need at least a 10Base-T Ethernet card (available from your favorite computer supplier) installed in a PC.

• Two RJ-45 straight-through Ethernet cables and a hub, or an RJ-45 crossover Ethernet cable.

A straight-through and a crossover Ethernet cable are included in the RCM3365/RCM3 375 Development Kit. Figure 11 shows how to identify the two cables based on the wires in the transparent RJ-45 connectors.

Same

color order

in connectors

Different

color order

in connectors

StraightThrough

Cable

Figure 11. How to Identify Straight-Through and Crossover Ethernet Cables

Ethernet cables and a 10Base-T Ethernet hub are available from Rabbit in a TCP/IP tool kit. More information is available at www.rabbit.com.

User’s Manual 53

Crossover

Cable

Now you should be able to make your connections.

1. Connect the AC adapter and the serial programming cable as shown in Chapter 2, “Getting Started.”

2. Ethernet Connections There are four options for connecting the RCM3365/RCM3375 module to a network

for development and runtime purposes. The first two options permit total freedom of action in selecting network addresses and use of the “network,” as no action can interfere with other users. We recommend one of these options for initial development.

No LAN — The simplest alternative for desktop development. Connect the

•

RCM3365/RCM3375 module’s Ethernet port directly to the PC’s network interface card using an RJ-45 crossover cable. A crossover cable is a special cable that flips some connections between the two connectors and permits direct connection of two client systems. A standard RJ-45 network cable will not work for this purpose.

• Micro-LAN — Another simple alternative for desktop development. Use a small Ethernet 10Base-T hub and connect both the PC’s network interface card and the RCM3365/RCM3375 module’s Ethernet port to it using standard network cables.

The following options require more care in address selection and testing actions, as conflicts with other users, servers and systems can occur:

• LAN — Connect the RCM3365/RCM3375 module’s Ethernet port to an existing LAN, preferably one to which the development PC is already connected. You will need to obtain IP addressing information from your network administrator.

• WAN — The RCM3365/RCM3375 is capable of direct connection to the Internet and other Wide Area Networks, but exceptional care should be used with IP address settings and all network-related programming and development. We recommend that development and debugging be done on a local network before connecting a RabbitCore system to the Internet.

TIP: Checking and debugging the initial setup on a micro-LAN is recommended before

connecting the system to a LAN or WAN.

The PC running Dynamic C does not need to be the PC with the Ethernet card.

3. Apply Power Plug in the AC adapter. The RCM3365/RCM3375 module and Prototyping Board are

now ready to be used.

54 RabbitCore RCM3365/RCM3375

6.2 TCP/IP Primer on IP Addresses

Obtaining IP addresses to interact over an existing, operating, network can involve a number of complications, and must usually be done with cooperation from your ISP and/or network systems administrator. For this reason, it is suggested that the user begin instead by using a direct connection between a PC and the RCM3365/RCM3375 using an Ethernet crossover cable or a simple arrangement with a hub. (A crossover cable should not be confused with regular straight through cables.)

In order to set up this direct connection, the user will have to use a PC without networking, or disconnect a PC from the corporate network, or install a second Ethernet adapter and set up a separate private network attached to the second Ethernet adapter. Disconnecting your PC from the corporate network may be easy or nearly impossible, depending on how it is set up. If your PC boots from the network or is dependent on the network for some or all of its disks, then it probably should not be disconnected. If a second Ethernet adapter is used, be aware that Windows TCP/IP will send messages to one adapter or the other, depending on the IP address and the binding order in Microsoft products. Thus you should have different ranges of IP addresses on your private network from those used on the corporate network. If both networks service the same IP address, then Windows may send a packet intended for your private network to the corporate network. A similar situation will take place if you use a dial-up line to send a packet to the Internet. Windows may try to send it via the local Ethernet network if it is also valid for that network.

The following IP addresses are set aside for local networks and are not allowed on the Internet: 10.0.0.0 to 10.255.255.255, 172.16.0.0 to 172.31.255.255, and 192.168.0.0 to

192.168.255.255. The RCM3365/RCM3375 uses a 10/100Base-T type of Ethernet connection, which is the

most common scheme. The RJ-45 connectors are similar to U.S. style telephone connectors, except they are larger and have 8 contacts.

An alternative to the direct connection using a crossover cable is a direct connection using a hub. The hub relays packets received on any port to all of the ports on the hub. Hubs are low in cost and are readily available. The RCM3365/RCM3375 uses 10/100 Mbps Ethernet, so the hub or Ethernet adapter can be a 10 Mbps unit, a 100 Mbps unit, or a 10/100 Mbps unit.

In a corporate setting where the Internet is brought in via a high-speed line, there are typically machines between the outside Internet and the internal network. These machines include a combination of proxy servers and firewalls that filter and multiplex Internet traffic. In the configuration below, the RCM3365/RCM3375 could be given a fixed address so any of the computers on the local network would be able to contact it. It may be possible to configure the firewall or proxy server to allow hosts on the Internet to directly contact the controller, but it would probably be easier to place the controller directly on the external network outside of the firewall. This avoids some of the configuration complications by sacrificing some security.

User’s Manual 55

Hub(s)

T1 in

Adapter

Ethernet

Typical Corporate Network

Firewall

Proxy

Server

Network

Ethernet

RCM3365/RCM3375

System

If your system administrator can give you an Ethernet cable along with its IP address, the netmask and the gateway address, then you may be able to run the sample programs without having to setup a direct connection between your computer and the RCM3365/ RCM3375. You will also need the IP address of the nameserver, the name or IP address of your mail server, and your domain name for some of the sample programs.

56 RabbitCore RCM3365/RCM3375

6.2.1 IP Addresses Explained

IP (Internet Protocol) addresses are expressed as 4 decimal numbers separated by periods, for example:

216.103.126.155

10.1.1.6

Each decimal number must be between 0 and 255. The total IP address is a 32-bit number consisting of the 4 bytes expressed as shown above. A local network uses a group of adja-

cent IP addresses. There are always 2

IP addresses in a local network. The netmask (also called subnet mask) determines how many IP addresses belong to the local network. The netmask is also a 32-bit address expressed in the same form as the IP address. An example netmask is:

255.255.255.0

This netmask has 8 zero bits in the least significant portion, and this means that 28 addresses are a part of the local network. Applied to the IP address above (216.103.126.155), this netmask would indicate that the following IP addresses belong to the local network:

216.103.126.0

216.103.126.1

216.103.126.2 etc.

216.103.126.254

216.103.126.255

The lowest and highest address are reserved for special purposes. The lowest address (216.102.126.0) is used to identify the local network. The highest address (216.102.126.255) is used as a broadcast address. Usually one other address is used for the address of the gateway out of the network. This leaves 256 - 3 = 253 available IP addresses for the example given.

User’s Manual 57

6.2.2 How IP Addresses are Used

The actual hardware connection via an Ethernet uses Ethernet adapter addresses (also called MAC addresses). These are 48-bit addresses and are unique for every Ethernet adapter manufactured. In order to send a packet to another computer, given the IP address of the other computer, it is first determined if the packet needs to be sent directly to the other computer or to the gateway. In either case, there is an Ethernet address on the local network to which the packet must be sent. A table is maintained to allow the protocol driver to determine the MAC address corresponding to a particular IP address. If the table is empty, the MAC address is determined by sending an Ethernet broadcast packet to all devices on the local network asking the device with the desired IP address to answer with its MAC address. In this way, the table entry can be filled in. If no device answers, then the device is nonexistent or inoperative, and the packet cannot be sent.

Some IP address ranges are reserved for use on internal networks, and can be allocated freely as long as no two internal hosts have the same IP address. These internal IP addresses are not routed to the Internet, and any internal hosts using one of these reserved IP addresses cannot communicate on the external Internet without being connected to a host that has a valid Internet IP address. The host would either translate the data, or it would act as a proxy.

Each RCM3365/RCM3375 RabbitCore module has its own unique MAC address, which consists of the prefix 0090C2 followed by a code that is unique to each RCM3365/ RCM3375 module. For example, a MAC address might be 0090C2C002C0.

TIP: You can always obtain the MAC address on your board by running the sample pro-

gram DISPLAY_MAC.C from the SAMPLES\TCPIP folder.

58 RabbitCore RCM3365/RCM3375

6.2.3 Dynamically Assigned Internet Addresses

In many instances, devices on a network do not have fixed IP addresses. This is the case when, for example, you are assigned an IP address dynamically by your dial-up Internet service provider (ISP) or when you have a device that provides your IP addresses using the Dynamic Host Configuration Protocol (DHCP). The RCM3365/RCM3375 modules can use such IP addresses to send and receive packets on the Internet, but you must take into account that this IP address may only be valid for the duration of the call or for a period of time, and could be a private IP address that is not directly accessible to others on the Internet. These addresses can be used to perform some Internet tasks such as sending e-mail or browsing the Web, but it is more difficult to participate in conversations that originate elsewhere on the Internet. If you want to find out this dynamically assigned IP address, under Windows 98 you can run the

winipcfg program while you are connected

and look at the interface used to connect to the Internet. Many networks use IP addresses that are assigned using DHCP. When your computer

comes up, and periodically after that, it requests its networking information from a DHCP server. The DHCP server may try to give you the same address each time, but a fixed IP address is usually not guaranteed.

If you are not concerned about accessing the RCM3365/RCM3375 from the Internet, you can place the RCM3365/RCM3375 on the internal network using an IP address assigned either statically or through DHCP.

User’s Manual 59

6.3 Placing Your Device on the Network

In many corporate settings, users are isolated from the Internet by a firewall and/or a proxy server. These devices attempt to secure the company from unauthorized network traffic, and usually work by disallowing traffic that did not originate from inside the network. If you want users on the Internet to communicate with your RCM3365/RCM3375, you have several options. You can either place the RCM3365/RCM3375 directly on the Internet with a real Internet address or place it behind the firewall. If you place the RCM3365/RCM3375 behind the firewall, you need to configure the firewall to translate and forward packets from the Internet to the RCM3365/RCM3375.

60 RabbitCore RCM3365/RCM3375

6.4 Running TCP/IP Sample Programs

We have provided a num ber of samp le pr ograms de mons trat ing va rious us es of TCP/ IP for networking embedded systems. These programs require you to connect your PC and the RCM3365/RCM3375 board together on the same network. This network can be a local private network (preferred for initial experimentation and debugging), or a connection via the Internet.

RCM3365/RCM3375

System

RCM3365/RCM3375

System

User’s PC

Ethernet

Ethernet crossover cable

Direct Connection

(network of 2 comp uters)

cables

To additional

Hub

network elements

Direct Connection Using a Hub

The sample programs described in this chapter may also be run with a RabbitSys-enabled RCM3365 operating in the RabbitSys mode. There is no change to the instructions when you use the serial programming cable. When you use an Ethernet cable, you may use CAT 5/6 straight-through Ethernet cables to connect the RCM3365 and your PC to a DHCP network. It is not necessary to use a crossover cable for a direct connection. Use the TCP/IP parameters such as the IP address that you identified with the rdiscover utility; if you are using an Ethernet crossover cable to connect the RCM3365 directly to your PC, use the TCP/IP parameters that you set up according to the instructions in Appendix E.

User’s Manual 61

6.4.1 How to Set IP Addresses in the Sample Programs

With the introduction of Dynamic C 7.30 we have taken steps to make it easier to run many of our sample programs. You will see a TCPCONFIG macro. This macro tells Dynamic C to select your configuration from a list of default configurations. You will have three choices when you encounter a sample program with the TCPCONFIG macro.

1. You can replace the

MASK

, MY_GATEWAY, and MY_NAMESERVER macros in each program.

TCPCONFIG macro with individual MY_IP_ADDRESS, MY_NET-

2. You can leave TCPCONFIG at the usual default of 1, which will set the IP configurations to 10.10.6.100, the netmask to 255.255.255.0, and the nameserver and gateway to 10.10.6.1. If you would like to change the default values, for example, to use an IP address of 10.1.1.2 for the RCM3365/RCM3375 board, and 10.1.1.1 for your PC, you can edit the values in the section that directly follows the “General Configuration” comment in the TCP_CONFIG.LIB library. Yo u will find this library in the LIB\TCPIP directory.

3. You can create a CUSTOM_CONFIG.LIB library and use a TCPCONFIG value greater than 100. Instructions for doing this are at the beginning of the TCP_CONFIG.LIB library in the LIB\TCPIP directory.

There are some other “standard” configurations for TCPCONFIG that let you select different features such as DHCP. Their values are documented at the top of the TCP_CON-

FIG.LIB

library in the LIB\TCPIP directory. More information is available in the

Dynamic C TCP/IP User’s Manual.

62 RabbitCore RCM3365/RCM3375

6.4.2 How to Set Up your Computer for Direct Connect

TIP: If you are using a PC that is already on a network, you will disconnect the PC from

that network to run these sample programs. Write down the existing settings before changing them to facilitate restoring them when you are finished with the sample programs and reconnect your PC to the network.

1. Go to the control panel (Start > Settings > Control Panel), and then double-click the Network icon.

2. Select the network interface card used for the Ethernet interface you intend to use (e.g.,

TCP/IP Xircom Credit Card Network Adapter) and click on the “Properties” button.

Depending on which version of Windows your PC is running, you may have to select the “Local Area Connection” first, and then click on the “Properties” button to bring up the Ethernet interface dialog. Then “Configure” your interface card for a “10Base-T Half-Duplex” or an “Auto-Negotiation” connection on the “Advanced” tab.

NOTE: Your network interface card will likely have a different name.

IP Address : 10.10.6.101 Netmask : 255.255.255.0 Default gateway : 10.10.6.1

4. Click <OK> or <Close> to exit the various dialog boxes.

RCM3365/RCM3375

IP 10.10.6.101 Netmask

255.255.255.0

System

User’s PC

Ethernet crossover cable

Direct Connection PC to RCM3365/RCM3375 Board

User’s Manual 63

6.5 Run the PINGME.C Sample Program

Connect the crossover cable from your computer’s Ethernet port to the RCM3365/ RCM3375 board’s RJ-45 Ethernet connector. Open this sample program from the

SAMPLES\TCPIP\ICMP folder, compile the program, and start it running under Dynamic C.

The crossover cable is connected from your computer’s Ethernet adapter to the RCM3365/ RCM3375 board’s RJ-45 Ethernet connector. When the program starts running, the green

LINK light on the RCM3365/RCM3375 module should be on to indicate an Ethernet con-

nection is made. (Note: If the LNK light does not light, you may not be using a crossover cable, or if you are using a hub with straight-through cables perhaps the power is off on the hub.)

The next step is to ping the board from your PC. This can be done by bringing up the MSDOS window and running the pingme program:

ping 10.10.6.101

or by Start > Run and typing the entry

ping 10.10.6.101

Notice that the yellow ACT light flashes on the RCM3365/RCM3375 module while the ping is taking place, and indicates the transfer of data . The ping routine will ping the board four times and write a summary message on the screen describing the operation.

6.6 Running Additional Sample Programs With Direct Connect

The following sample programs are in the Dynamic C SAMPLES\RCM3360\TCPIP\ folder.

• BROWSELED.C—This program demonstrates a basic controller running a Web page. Two “device LEDs” are created along with two buttons to toggle them. Users can use their Web browser to change the status of the lights. The DS3 and DS4 LEDs on the Prototyping Board will match those on the W eb page. As long as you have not modified the TCPCONFIG 1 macro in the sample program, enter the following server address in your Web browser to bring up the Web page served by the sample program.

http://10.10.6.100.

Otherwise use the TCP/IP settings you entered in the TCP_CONFIG.LIB library.

• MBOXDEMO.C—The optional LCD/keypad module (see Appendix C) must be plugged in to the Prototyping Board when using this sample program. This program demonstrates sending e-mail messages that are then shown on the LCD/keypad module display. The keypad is used to scroll through a menu to view the messages, flip to other messages, mark messages as read, and delete messages. When a new e-mail arrives, an LED on the LCD/keypad module turns on, and then turns off once the message has been marked as read. A log of all e-mail actions is kept, and can be displayed in the Web browser. All current e-mails can also be read with the Web browser.

64 RabbitCore RCM3365/RCM3375

• PINGLED.C—This program demonstrates ICMP by pinging a remote host. It will flash LEDs DS3 and DS4 on the Prototyping Board when a ping is sent and received.

• SMTP.C—This program demonstrates using the SMTP library to send an e-mail when the S2 and S3 switches on the Prototyping Board are pressed. LEDs DS3 and DS4 on the Prototyping Board will light up when e-mail is being sent.

6.6.1 RabbitWeb Sample Programs

You will need to have the Dynamic C RabbitWeb module installed before you run the sample programs described in this section. The following sample programs are in the Dynamic C SAMPLES\RCM3360\TCPIP\RABBITWEB folder.

• BLINKLEDS.C—This program demonstrates a basic example to change the rate at which the DS3 and DS4 LEDs on the Prototyping Board blink.

• DOORMONITOR.C—The optional LCD/keypad module (see Appendix C) must be plugged in to the Prototyping Board when using this sample program. This program demonstrates adding and monitoring passwords entered via the LCD/keypad module.

• SPRINKLER.C—This program demonstrates how to schedule times for the relay and digital outputs in a 24-hour period.

6.7 Where Do I Go From Here?

NOTE: If you purchased your RCM3365/RCM3375 through a distributor or through a

Rabbit partner, contact the distributor or partner first for technical support.

If the sample programs ran fine, you are now ready to go on. Additional sample programs are described in the Dynamic C TCP/IP User’s Manual. Please refer to the Dynamic C TCP/IP User’s Manu al to develop your own applications.

An Introduction to TCP/IP provides background information on TCP/IP, and is available on the CD and on our Web site.

User’s Manual 65

66 RabbitCore RCM3365/RCM3375

APPENDIX A. RCM3365/RCM3375

SPECIFICATIONS

Appendix A provides the specifications for the RCM3365/ RCM3375, and describes the conformal coating.

User’s Manual 67

A.1 Electrical and Mechanical Characteristics

Figure A-1 shows the mechanical dimensions for the RCM3365/RCM3375.

0.100 dia

(2.5)

1.850

(47.0)

1.375

(34.9)

0.20

(5.0)

0.134

(3.4)

The height of connector J6 (RCM3365/RCM3375 models)

(28.6)

1.126

is 0.114" (2.9 mm).

(69.2)

2.725

Please refer to the RCM3365/ RCM3375 footprint diagram

(17.5)

0.690

0.47

0.17

(4.3)

1.320

(11.9)

SPEED

DS4

0.97

(24.7)

DS1

ACT

DS2

LINK

DS3

USR FM

later in this appendix for

(33.5)

precise header locations.

(14)

1.850

(47.0)

0.55

J3J4

(2.2)

(1.6)

0.087

0.063

(6.2)

0.245

(22)

0.86

Figure A-1. RCM3365/RCM3375 Dimensions

NOTE: All measurements are in inches fo llowed b y milli meters enclos ed in pa renthe ses.

All dimensions have a manufacturing tolerance of ±0.01" (0.25 mm).

68 RabbitCore RCM3365/RCM3375

It is recommended that you allow for an “exclusion zone” of 0.04" (1 mm) around the RCM3365/RCM3375 in all directions when the RCM3365/RCM3375 is incorporated into an assembly that includes other printed circuit boards. An “exclusion zone” of 0.08" (2 mm) is recommended below the RCM3365/RCM3375 when the RC M3365/RCM3375 is plugged into another assembly. Figure A-2 shows this “exclusion zone.”

2.81

(71.2)

0.6

(16)

2.725

(69.2)

(2)

0.08

Exclusion

1.93

(49.0)

Zone

0.6

(16)

1.850

(47.0)

J3J4

(2)

0.08

Figure A-2. RCM3365/RCM3375 “Exclusion Zone”

NOTE: All measurements are in inches followed by millimeters enclosed in parentheses.

User’s Manual 69

T ableA-1 lists the electrical, mechanical, and environmental specifications for the RCM3365/ RCM3375.

Table A-1. RabbitCore RCM3365/RCM3375 Specifications

Parameter RCM3365 RCM3375

Microprocessor EMI Reduction Spectrum spreader for reduced EMI (radiated emissions)

Ethernet Port 10/100Base-T, RJ-45, 3 LEDs SRAM 512K program (fast SRAM) + 512K data

Low-EMI Rabbit

3000 at 44.2 MHz

Flash Memory (program)

Flash Memory (mass data storage)

LED Indicators

Backup Battery

General-Purpose I/O

Additional Inputs Startup mode (2), reset in Additional

Outputs

External I/O Bus

5 address lines (shared with parallel I/O lines), plus I/O read/write

32MB (fixed) +xD-Picture Card with up to 128MB

(NAND flash)

SPEED (on for 100Base-T Ethernet connection)

Connection for user-supplied backup battery

52 parallel digital I/0 lines:

• 44 configurable I/O

• 4 fixed inputs

• 4 fixed ou tputs

Can be configured for 8 data lines and

FM (flash memory, NAND)

USR (user-programmable)

(to support RTC and data SRAM)

512K

xD-Picture Card

with up to 128MB

(NAND flash)

ACT (activity)

LINK (link)

Status, reset out

Six 3.3 V, CMOS-compatible ports (shared with I/O)

• all 6 configurable as asynchronous (with IrDA)

Serial P orts

• 4 configurable as clocked serial (SPI)

• 2 configurable as SDLC/HDLC

• 1 asynchronous serial port dedicated for programming

Serial Rate Maximum asynchronous baud rate = CLK/8

A slave port allows the RCM3365/RCM3375 to be used as an

Slave Interface

Real-Time Clock Yes

Timers

70 RabbitCore RCM3365/RCM3375

intelligent peripheral device slaved to a master processor, which may either be another Rabbit 3000 or any other type of processor

T en 8-bit timers (6 cas cadable, 3 res erved for intern al peripherals) ,

one 10-bit timer with 2 match registers

Table A-1. RabbitCore RCM3365/RCM3375 Specifications (continued)

Parameter RCM3365 RCM3375

W atchdog/ Supervisor

Pulse-Width Modulators

Input Capture

Quadrature Decoder

Power

Operating Temperature

4 PWM registers with 10-bit free-running counter

and priority interrupts

2-channel input capture can be used to time input signals from

various port pins

2-channel quadrature decoder accepts inputs from external

incremental encoder modules

250 mA @ 44.2 MHz, 3.3 V

-40°C to +70°C (boards manufactured up to May, 2008) 0°C to +70°C (boards manufactured after May, 2008)

Yes

3.15–3.45 V DC

Humidity 5% to 95%, noncondensing

Two 2 × 17, 2 mm pitch

Connectors

one 2 × 5 for programming with 1.27 mm pitch

one xD-Picture Card slot (RCM3365/RCM3375)

Board Size

1.850" × 2.725" × 0.86"

(47 mm × 69 mm × 22 mm)

* RCM3365 modules sold before 2008 had 16MB fixed NAND flash memory.

NOTE: M-type xD-Picture Cards are not supported at this time.

User’s Manual 71

A.1.1 Headers

The RCM3365/RCM3375 uses headers at J3 and J4 for physical connection to other boards. J3 and J4 are 2 × 17 SMT headers with a 2 mm pin spacing. J1, the programming port, is a 2 × 5 header with a 1.27 mm pin spacing.

Figure A-3 shows the layout of another board for the RCM3365/RCM3375 to be plugged into. These reference design values are relative to the mounting hole.

(28.5)

1.124

(34.1)

1.341

1.198

(28.9)

1.136

(30.4)

dia

(2.5)

0.100

(0.5)

0.020 sq typ

(2.0)

0.079

(2.0)

0.079

(8.0)

0.314

(24.2)

0.953

(26.5)

1.043

(28.8)

1.135

(30.6)

1.205

RCM3300 Series Footprint

(0.25)

0.010

(8.3)

0.328

Figure A-3. User Board Footprint for RCM3365/RCM3375

72 RabbitCore RCM3365/RCM3375

A.2 Bus Loading

You must pay careful attention to bus loading when designing an interface to the RCM3365/RCM3375. This section provides bus loading information for external devices.

Table A-2 lists the capacitance for the various RCM3365/RCM3375 I/O ports.

Table A-2. Capacitance of Rabbit 3000 I/O Ports

Input

I/O Ports

Parallel Ports A to G 12 14

Capacitance

(pF)

Output

Capacitance

(pF)

Table A-3 lists the external capacitive bus loading for the various RCM3365/RCM3375 output ports. Be sure to add the loads for the devices you are using in your custom system and verify that they do not exceed the values in Table A-3.

Table A-3. External Capacitive Bus Loading -40°C to +85°C

Output Port

All I/O lines with clock doubler enabled

Clock Speed

(MHz)

44.2 100

Maximum External

Capacitive Loading (pF)

User’s Manual 73

Figure A-4 shows a typ ical timing diagram for th e Rabbit 3000 mic roprocessor extern al I/O read and write cycles.

External I/O Read (one programmed wait state)

CLK

A[15:0]

/CSx

/IOCSx

/IORD

/BUFEN

D[7:0]

CLK

A[15:0]

valid

adr

IOCSx

BUFEN

setup

CSx

IORD

hold

CSx

IOCSx

IORD

BUFEN

External I/O Write (one programmed wait state)

adr

valid

/CSx

CSx

/IOCSx

IOCSx

/IOWR

IOWR

/BUFEN

valid

BUFEN

DVHZ

BUFEN

D[7:0]

DHZV

Figure A-4. I/O Read and Write Cycles—No Extra Wait States

NOTE: /IOCS x can be programmed to be active low (default) or active high.

74 RabbitCore RCM3365/RCM3375

Table A-4 lists the delays in gross memory access time at 3.3 V.

Table A-4. Data and Clock Delays VIN ±10%, Temp, -40°C–+85°C (maximum)

Clock to Address Output Delay

(ns)

VIN

30 pF 60 pF 90 pF

3.3 V 6 8 11 1 3/4.5 4.5/9

Data Setup Time Delay

(ns)

Spectrum Spreader Delay

(ns)

Normal

no dbl/dbl

Strong

no dbl/dbl

The measurements are taken at the 50% points under the following conditions.

• T = -40°C to 85°C, V = V

±10%

• Internal clock to nonloaded CLK pin delay ≤ 1 ns @ 85°C/3.0 V The clock to address output delays are similar, and apply to the following delays.

• T

, the clock to address delay

adr

, the clock to memory chip select delay

CSx

, the clock to I/O chip select delay

IOCSx

, the clock to I/O read strobe delay

IORD

, the clock to I/O write strobe delay

IOWR

• T

BUFEN

The data setup time delays are similar for both T

, the clock to I/O buffer enable delay

setup

and T

hold

When both the spectrum spreader and the clock doubler are enabled, every other clock cycle is shortened (sometimes lengthened) by a maximum amount given in the table above. The shortening takes place by shortening the high part of the clock. If the doubler is not enabled, then every clock is shortened during the low part of the clock period. The maximum shortening for a pair of clocks combined is shown in the table.

Technical Note TN227, Interfacing External I/O with Rabbit 2000/3000 Designs, contains suggestions for interfacing I/O devices to the Rabbit 3000 microprocessors.

User’s Manual 75

A.3 Rabbit 3000 DC Characteristics

Table A-5. Rabbit 3000 Absolute Maximum Ratings

Symbol Parameter Maximum Rating

Operating Temperature -55° to +85°C

Storage Temperature -65° to +150°C

Maximum Input Voltage:

+ 0.5 V

• Oscillator Buffer Input

• 5-V-tolerant I/O

Maximum Operating Voltage 3.6 V

5.5 V

Stresses beyond those listed in Table A-5 may cause permanent damage. The ratings are stress ratings only, and functional operation of the Rabbit 3000 chip at these or any other conditions beyond those indicated in this section is not implied. Exposure to the absolute maximum rating conditions for extended periods may affect the reliability of the Rabbit 3000 chip.

Table A-6 outlines the DC characteristics for the Rabbit 3000 at 3.3 V over the recommended operating temperature range from TA = –55°C to +85°C, VDD = 3.0 V to 3.6 V.

Table A-6. 3.3 Volt DC Characteristics

Symbol Parameter Test Conditions Min Typ Max Units

V V

Supply Voltage 3.0 3.3 3.6 V

High-Level Input Voltage 2.0 V

Low-Level Input Voltage 0.8 V

= 6.8 mA,

High-Level Output Voltage

Low-Level Output Voltage

High-Level Input Current

(absolut e w or s t case, all buffers)

Low-Level Input Current

(absolut e w or s t case, all buffers)

High-Impedance State Output Current

(absolut e w or s t case, all buffers)

= VDD (min)

= 6.8 mA,

= VDD (min)

VIN = VDD,

= VDD (max)

VIN = VSS, V

= VDD (max)

VIN = VDD or VSS,

= VDD (max), no pull-up

0.7 x V

-10 µA

-10 10 µA

0.4 V

10 µA

76 RabbitCore RCM3365/RCM3375

A.4 I/O Buffer Sourcing and Sinking Limit

Unless otherwise specified, the Rabbit I/O buffers are capable of sourcing and sinking

6.8 mA of current per pin at full AC switching speed. Full AC switching assumes a

22.1 MHz CPU clock and capacitive loading on address and data lines of less than 100 pF per pin. The absolute maximum operating voltage on all I/O is 5.5 V.

Table A-7 shows the AC and DC output drive limits of the parallel I/O buffers when the Rabbit 3000 is used in the RCM3365/RCM3375.

Table A-7. I/O Buffer Sourcing and Sinking Capability

Output Drive (Full AC Switching)

Pin Name

All data, address, and I/O lines with clock doubler enabled

Sourcing/Sinking

(mA)

Sourcing Sinking

6.8 6.8

Under certain conditions, you can exceed the limits outlined in Table A-7. See the Rabbit 3000 Microprocessor User’s Manual for additional information.

Limits

User’s Manual 77

A.5 Jumper Configurations

Figure A-5 shows the jumper locations used to configure the various RCM3365/ RCM3375 options. The black square indicates pin 1.

RCM3365/RCM3375

Bottom Side Top Side

JP9

JP3

JP2

JP4

JP6

JP7

JP8

R96

JP5

R41

R42

Figure A-5. Location of RCM3365/RCM3375 Configurable Positions

78 RabbitCore RCM3365/RCM3375

Table A-8 lists the configuration options.

Table A-8. RCM3365/RCM3375 Jumper Configurations

Header Description Pins Connected

1–2 Bank Mode

JP2 Flash Memory Bank Select

JP3 D ata SRAM Size

JP4

JP5

JP6

JP7

Ethernet or I/O Output on Header J3

2–3 Normal Mode

1–2 128K/256K

2–3 512K

1–2 TPO+

2–3 PD3

1–2 TPO–

2–3 PD2

1–2 ENET_INT

2–3 PE0

1–2 TPI+

2–3 PD7

Factory

Default

JP8

JP9

R96 xD-Picture Card Detect

Ethernet or I/O Output on Header J3

Chip select signals for NAND flash and xD-Picture Card

NOTE: The jumper connections are made using 0 Ω surface-mounted resistors.

1–2 TPI–

2–3 PD6

1–2

2–3

installed xD-Picture Card Detect available

not

installed

Separate chip select signals to NAND flash and xD-Picture Card

Separate chip select signals for NAND flash and xD-Picture Card

PB0 may be used as CLKB (synchronous Serial Port B)

× ×

User’s Manual 79

A.6 Conformal Coating

The areas around the 32 kHz real-time clock crystal oscillator have had the Dow Corning silicone-based 1-2620 conformal coating applied. The conformally coated area is shown in Figure A-6. The conformal coating protects these high-impedance circuits from the effects of moisture and contaminants over time.

Conformally coated

areas

R13

R12

R11

R10

U16

C10

C11

C15

C19

C20

C24

R23

C28

R14

R17

R19

R15

C35 R26 R27

C81

U13

R45

C67

C14

C104

R77

R64

R80

R59

R50

R84

R85

R70

R86

R29

U1 R4

R18

R22

C74

JP9 R7 C2 C3

C12

C13

C18

C22

C21

JP7

JP8

JP4

JP5

C27

R96

JP6

R25

C34

R20

R21 C36

C58

R44

R53

R54 R31

C80

C71

C78

C105

R67

C61

R30

C82

R82

R81

C70

C86

C76

C72

C42

C77

R79

C79

DS1

R35

DS2

R36

R43

DS4

R37

DS3

R38

USR FMLINK ACT

SPEED

Figure A-6. RCM3365/RCM3375 Areas Receiving Conformal Coating

Any components in the conformally coated area may be replaced using standard soldering procedures for surface-mounted components. A new conformal coating should then be applied to offer continuing protection against the effects of moisture and contaminants.

NOTE: For more information on conformal coatings, refer to Technical Note 303,

Conformal Coatings.

80 RabbitCore RCM3365/RCM3375

APPENDIX B. PROTOTYPING BOARD

Appendix B describes the features and accessories of the Prototyping Board.

User’s Manual 81

B.1 Introduction

The Prototyping Board included in the Development Kit makes it easy to connect an RCM3365/RCM3375 module to a power supply and a PC workstation for development. It also provides some basic I/O peripherals (RS-232, RS-485, a relay, LEDs, and switches), as well as a prototyping area for more advanced hardware development.

For the most basic level of evaluation and development, the Prototyping Board can be used without modification.

As you progress to more sophisticated experimentation and hardware development, modifications and additions can be made to the board without modifying or damaging the RCM3365/RCM3375 module itself.

The Prototyping Board is shown below in Figure B-1, with its main features identified.

Power

Module

Extension Header

Voltage

Regulators

RCM3360/RCM3370

Module

Connectors

Module

Extension Header

GND

VBT

/RES

SM0

/IOWR

PG5

PG7

PE1

PE4

PE6

PF7

PF5

PB7

PB5

PB3

PB0

RCM3300 PROTOTYPING BOARD

ACT

PD7

PD3

PD5

PG3

PG1

PC7

PC5

PC3

PC1

PF0

PF2

PA0

PA2

PA4

PA6

STAT

RESET

Reset

Switch

Input

+3.3 V

VRAM

SMODE1

/IORD

PG4

PG6

R11

PE0

PE3

PE5

R12

PF4 PF6 PE7

PB6

PB4

PB2

/RES_OUT

LINK

PD6

PD2

PD4

PG2

PG0

PC6

PC4

PC2

PC0

PF1

PF3

PA1

PA3

PA5

PA7

GND

Switches

R67 R68 R69 R70

+DC

R25

R26

User

GND/EGND

GND

Power

LED

GND

+DC

GND

C10

C11

CORE MODULE

R21

R22

Q2Q3Q4

R28

R27

POWER

DS1

J10

00 01 02 03 04 05 06 07

OUT

C12

RP1

JP4

C13

R16

C16

R24

R23

GND

J12

R50

R49

R29

CORE

DS2

DS3

LEDs

Core LED

H-Bridge

Motor Driver

Terminals

{

JP1

U2 L293D H-DRIVER

R13

OUT

RP2

R17

R15

CX1

SMT Prototyping

CX2

J13

HO4

HO3

HO2

HO1

D5D6D7

J14

R30

R31

R32

DS5 DS6

DS4

TxE RxE GND TxF RxF 485+ GND 485

{

RS-232

User

Signals

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

+5 V

+3.3 V

UX1

SO20W

Area

UX2

SO20W

C21

C22

C23

C24

{

JP2

U3 L293D H-DRIVER

R14

BT1

GND

RX13

RX14

RX15

DX1

DX2

C18

C17

R33

R34

R36

JP5

C26

C25

RS-485

Quadrature

Decoder

Terminals

VMB MDB1 MDB2 MDB3 MDB4 VMB+

PF0_CLKD

PF0_QD

Prototyping Area

RX16

RX17

RX18

UX4

SOT23-6

UX5

SOT23-6

U10

R35

R37

R38

{

+5V QD2A QD2 B QD1A QD1B GND

R52 R53

R51

R54

JP3

R55

R56

R57

R58

Through-Hole

LCD

/CS

J15

R39

/RES

LED0

LED2

LCD1JA

/CS

LED1

LED3

+BKLT

C19

R40

U11

KEYPAD DISPLAY BOARD

LCD1JB

Digital Inputs

{

R60 R61

R59

R62

R63

R64

R65

R66

+5 V

GND

+3.3 V

BA0

BA1

BA2

BA3

BD0

BD1

BD2

BD3

LED4

LED6

GNDA3A1D0D2D4D6

D1D3D5

GND

LED5

R42

C20

R41

U12

LCD1JC

LCD/Keypad

Module

Connections

RabbitNet

Port

GND IN3 IN2 IN1 IN0 +5V

R3R4R5

R10

C14

C15

BD4

BD5

BD6

BD7

J16

C27

C28

R43

C30C29

R45

R48

RABBITNET

R18

R44

R46

R47

J11

SERIAL FLASH/

MODEM

R19

R20

0.5 A @ 30 V

RELAY RATED

J17

NO1 COM1 NC1 NO2 COM2 NC2

DS7

RELAY

Serial Flash

Socket

+5 V, 3.3 V, and

GND Buses

{

Relay

Terminals

Relay User

LED

Figure B-1. Prototyping Board

82 RabbitCore RCM3365/RCM3375

B.1.1 Prototyping Board Features

• Power Connection—A power-supply jack and a 3-pin header are provided for connection to the power supply. Note that the 3-pin header is symmetrical, with both outer pins connected to ground and the center pin connected to the raw V+ input. The cable of the AC adapter provided with the North American version of the Development Kit ends in a plug that connects to the power-supply jack (J1). A header plug leading to bare leads is provided for overseas customers to connect their power supply to the 3-pin header (J2)—the center pin of J2 is always connected to the positive terminal, and either edge pin is negative.

Users providing their own power supply should ensure that it delivers 8–30 V DC at 1 A.

Regulated Power Supply—The raw DC voltage provided at the POWER IN jack is

•

routed to a 5 V switching voltage regulator, then to a separate 3.3 V linear regulator. The regulators provide stable power to the RCM3365/RCM3375 module and the Prototyping Board. The voltage regulators will get warm while in use.

• Power LED—The power LED lights whenever power is connected to the Prototyping Board.

• Core LED—The core LED lights whenever an RCM3365/RCM3375 module is plugged in correctly on the Prototyping Board and the RCM3365/RCM3375 module is not being reset.

• Relay LED—The relay LED lights whenever the Prototyping Board relay is energized.

• Reset Switch—A momentary-contact, normally open switch is connected directly to the

RCM3365/RCM3375’s /RESET_IN pin. Pressing the switch forces a hardware reset of the system.

• I/O Switches and LEDs—Two momentary-contact, normally open switches are connected to the PG0 and PG1 pins of the RCM3365/RCM3375 module and may be read as inputs by sample applications.

Four user LEDs (DS3–DS6) are connected to alternate I/O bus pins PA0–PA3 pins of the RCM3365/RCM3375 module via U8, and may be driven as output indicators. PE7 and PG5 control the registers in U8 as shown in the sample applications.

• Prototyping Area—A generous prototyping area has been provided for the installation of through-hole components. +3.3 V, +5 V, and Ground buses run along one edge of this area. Several areas for surface-mount devices are also available. Each SMT pad is connected to a hole designed to accept a 30 AWG solid wire.

• LCD/Keypad Module—Rabbit’s LCD/keypad module may be plugged in directly to

headers LCD1JA, LCD1JB, and LCD1JC. The signals on headers LCD1JB and LCD1JC will be available only if the LCD/keypad module is plugged in to header LCD1JA. Appendix C provides complete information for mounting and using the LCD/keypad module.

User’s Manual 83

• Module Extension Headers—The complete pin set of the RCM3365/RCM3375 module is duplicated at headers J8 and J9. Developers can solder wires directly into the appropriate holes, or, for more flexible development, 2 × 17 header strips with a 0.1" pitch can be soldered into place. See Figure B-4 for the header pinouts.

• Digital I/O—Four digital inputs are available on screw-terminal header J6. See

Figure B-4 for the header pinouts.

RS-232—Two 3-wire serial ports or one 5-wire RS-232 serial port are available on the

•

Prototyping Board at screw-terminal header J14.

• RS-485—One RS-485 serial port is available on the Prototyping Board at screw-terminal header J14.

• Quadrature Decoder—Four quadrature decoder inputs (PF0–PF3) from the Rabbit 3000 chip are available on screw-terminal header J5. See Figure B-4 for the header pinouts.

• H-Bridge Motor Driver—Two pairs of H-bridge motor drivers are supported using screw-terminal headers J3 and J4 on the Prototyping Board for stepper-motor control. See Figure B-4 for the header pinouts.

• RabbitNet Port—One RS-422 RabbitNet port (shared with the serial flash interface) is available to allow RabbitNet peripheral cards to be used with the RCM3365/RCM3375 and the Prototyping Board.

• Serial Flash Interface—One serial flash interface (shared with the RabbitNet port) is

available to allow Rabbit’s SF1000 series serial flash to be used on the Prototyping Board.

84 RabbitCore RCM3365/RCM3375

B.2 Mechanical Dimensions and Layout

Figure B-2 shows the mechanical dimensions and layout for the Prototyping Board.

GND

VBT

/RES

SM0

/IOWR

PG5

PG7

PE1

PE4

PE6

PF7

PF5

PB7

PB5

PB3

PB0

RCM3300 PROTOTYPING BOARD

ACT

PD7

PD3

PD5

PG3

PG1

PC7

PC5

PC3

PC1

PF0

PF2

PA0

PA2

PA4

PA6

STAT

RESET

+3.3 V

VRAM

SMODE1

/IORD

PG4

PG6

PE0

PE3

PE5

R12

PF4 PF6 PE7

PB6

PB4

PB2

/RES_OUT

LINK

PD6

PD2

PD4

PG2

PG0

PC6

PC4

PC2

PC0

PF1

PF3

PA1

PA3

PA5

PA7

GND

+DC

GND

C10

C11

C12

JP4

POWER

DS1

R1 J2

J10

00 01 02 03 04 05 06 07

OUT

RP1

C13

L293D H-DRIVER

RP2

+DC

GND

R11

R67

R68

R69 R70

R16

CORE MODULE

GND/EGND

VMA+ MDA1 MDA2 MDA3 MDA4 VMA

JP1

R13

OUT

Battery

R17

R15

+5 V

+3.3 V

CX1

UX1

SO20W

C16

R24

R23

R21

R22

Q2Q3Q4

R28

R27

R25

R26

GND

HO4

J12

R50

D5D6D7

R49

R30

R29

CORE

DS2

DS4

DS3

CX2

J13

HO3

HO2

HO1

J14

R31

R32

DS5 DS6

TxE RxE GND TxF RxF 485+ GND 485

C23

C21

UX2

SO20W

C24

C22

JP2

L293D H-DRIVER

R14

RX13

RX14

RX15

C25

VMB MDB1 MDB2 MDB3 MDB4 VMB+

PF0_QD

R51

JP3

PF0_CLKD

R52 R53

R55

+5V QD2A QD2B QD1A QD1B GND

R60 R61

R54

R59

R56

R57

R58

R63

R64

R65

R66

BT1

GND

RX16

RX17

RX18

UX4

DX1

UX5

DX2

C18

C17

R33

R34

U10

R35

R36

JP5

R38

C26

SOT23-6

R37

LCD1JA

LCD

J15

R39

/RES

LED0

/CS

LED1

+BKLT

C19

R40

U11

KEYPAD DISPLAY BOARD

/CS

BA0

LED2

LED4

LED3

LED5

R41

BA1

BA2

LED6

GNDA3A1D0D2D4D6

GND

C20

U12

LCD1JB

GND IN3 IN2 IN1 IN0 +5V

R62

+5 V

GND

+3.3 V

BA3

BD0

BD1

BD2

BD3

BD4

BD5

BD6

D1D3D5

R42

R43

R45

LCD1JC

BD7

R3R4R5

J16

C27

RABBITNET

R10

J11

C14

C15

SERIAL FLASH/

MODEM

R19

R20

R18

5.25

(133)

0.5 A @ 30 V

RELAY RATED

J17

C28

R44

C30C29

R46

NO1 COM1 NC1 NO2 COM2 NC2

DS7

R47

RELAY

R48

6.75

(171)

Figure B-2. Prototyping Board Dimensions

NOTE: All measurements are in inches followed by millimeters enclosed in parentheses.

User’s Manual 85

Table B-1 lists the electrical, mechanical, and environmental specifications for the Prototyping Board.

Table B-1. Prototyping Board Specifications

Parameter Specification

Board Size 5.25" × 6.75" × 1.00" (133 mm × 171 mm × 25 mm) Operating Temperature –20°C to +70°C Humidity 5% to 95%, noncondensing Input Voltage 8 V to 30 V DC Maximum Current Draw

(including user-added circuits) Backup Battery CR2032, 3 V lithium coin-type

Digital Inputs

Digital Outputs

Relay SPDT relay, 500 mA @ 30 V

Serial P orts

800 mA max. for +3.3 V supply, 1 A total +3.3 V and +5 V combined

4 inputs pulled up, ± 36 V DC,

switching threshold 0.9–2.3 V typical

4 sinking outputs,+30 V DC, 500 mA maximum per channel

8 CMOS-level outputs if stepper motor not installed

• two 3-wire RS-232 or one RS-232 with RTS/CTS

• one RS-485

Other Serial Interfaces RabbitNet RS-422 port or serial flash interface

• stepper motor control

Other Interfaces

• quadrature decoder

• LCD/keyp ad module

Seven LEDs

• one power on indicator

LEDs

• one RCM3365/RCM3375 module indicator

• four user-configurable LEDs

• one relay indicator

Prototyping Area

Throughhole, 0.1" spacing, additional space for SMT components

• two 2 × 17, 2 mm pitch sockets for RCM3365/RCM3375

module

• one 2 × 5, 2 mm pitch socket for serial flash

Connectors

• six screw-terminal headers for serial ports, digital inputs,

stepper motor control, quadrature decoder, and relay contacts

• one RJ-45 RabbitNet jack

Standoffs/Spacers 7, accept 4-40 x 1/2 screws

86 RabbitCore RCM3365/RCM3375

B.3 Power Supply

The RCM3365/RCM3375 requires a regulated 3.15 V to 3.45 V DC power source to operate. Depending on the amount of current required by the application, different regulators can be used to supply this voltage.

The Prototyping Board has an onboard +5 V switching power regulator from which a +3.3 V linear regulator draws its supply. Thus both +5 V and +3.3 V are available on the Prototyping Board.

The Prototyping Board itself is protected against reverse polarity by a diode at D1 as shown in Figure B-3.

LINEAR POWER

POWER

SWITCHING POWER REGULATOR

DL4003

DCIN

C1 47 µF

LM2575

330 µH

D2 1N5819

+5 V

330 µF

REGULATOR

LM1117

10 µF

+3.3 V

10 µF

Figure B-3. Prototyping Board Power Supply

User’s Manual 87

B.4 Using the Prototyping Board

The Prototyping Board is actually both a demonstration board and a prototyping board. As a demonstration board, it can be used with the sample programs to demonstrate the functionality of the

The Prototyping Board pinouts are shown in Figure B-4.

RCM3365/RCM3375

right out of the box without any modifications.

GND GND

/RES

SMODE0

/IOWR

PG3 PG1

STATUS

Quadrature

GND

QD1B

Decoder

QD1A

QD2B

QD2A

Stepper-Motor

Control

Power

GND

n.c. +3.3 V

VBT

VRAM SMODE1 /IORD PG4

PG5

PG6

PG7

PE0

PE1

PE3

PE4

PE5

PE6

PE7

PF7

PF6

PF5

PF4

PB7

PB6

PB5

PB4

PB3

PB2

PB0

/RES_OUT

ACT

LINK

PD7

PD6

PD3

PD2

PD5

PD4 PG2 PG0

PC7

PC6

PC5

PC4

PC3

PC2

PC1

PC0

PF0

PF1

PF2

PF3 PA1

PA0

PA3

PA2

PA5

PA4

PA7

PA6

GND

+DC

GND

Digital

Outputs

(sinking)

DS1

J10

OUT00

VMA

OUT01

GND

MDA4

OUT02

J12

HOUT4

OUT03

HOUT3

MDA3

OUT04

HOUT2

MDA2

OUT05

HOUT1

MDA1

OUT06

OUT07

J13

VMA+

VMB+

MDB4

MDB3

MDB2

MDB1

VMB

PB0 PC5 PC4

J14

+5 v

LCD_/CS

J15

Digital Inputs

+5 V

IN0

IN1

IN2

IN3

GND

J11

GND

PC1_RxD

VCC

PC0_TxD

PD2_CE

PD4_DCD

BA0

BA1

BA2

BA3

BD0

BD1

BD2

BD3

BD4

BD5

BD6

BD7

PF0_CLK_RES PD3_RNET_/RTS PD6_/CTRL PD5_/CTS

J16

J17

NC2

COM2

NO2

RELAY

CONTACTS

NC1

COM1

NO1

DS7

RELAY

LED

DS2 DS3 DS4 DS5 DS6

User

Core

LEDs

LED

TxF

TxE

RxF

RxE

GND

RS-232 RS-485

485+

GND

485

Figure B-4. Prototyping Board Pinout

88 RabbitCore RCM3365/RCM3375

The Prototyping Board comes with the basic components necessary to demonstrate the operation of the RCM3365/RCM3375. Four user LEDs (DS3–DS6) are connected to alternate I/O bus pins P A0–PA3 pins of the RCM3365/RCM3375 module via U8, and may be driven as output indicators when controlled by PE7 and PG5 as shown in the sample applications. Two switches (S2 and S3) are connected to PG0 and PG1 to demonstrate the interface to the Rabbit 3000 microprocessor. Reset switch S1 is the hardware reset for the RCM3365/RCM3375.

Prototyping Board provides the user with RCM3365/RCM3375 connection points

The brought out conveniently to labeled points at J8 and J9 on the Prototyping Boa rd. Although locations J8 and J9 are unstuffed, 2 × 17 headers are included in the bag of parts.

RS-232 and RS-485 signals are available on screw-terminal header J14, quadrature decoder inputs are available on screw-terminal header J5, and digital inputs are available on screw-terminal header J6. A 1 × 5 header strip from the bag of parts may be installed at J12 for four sinking digital outputs. A 1 × 3 header strip from the bag of parts may be installed at J13 to access selected signals from RCM3000, RCM3100, RCM3200, RCM3300/RCM3310, and RCM3365/RCM3375 RabbitCore modules (J13 cannot be used with the RCM3305/RCM3315).

If you don’t plan to use the LCD/keypad module, additional signals may be brought out on 1 × 5 and 1 × 8 headers from the bag of parts that you install at J15 and J 16. If you don’ t plan t o use the stepper-motor control option, additional CMOS outputs are available via a 1 × 8 header that you install at J10.

There is a through-hole prototyping space available on the Prototyping Board. the prototyping area are spaced at 0.1" (2.5 mm). one edges of the

prototyping area. Small to medium circuits can be prototyped using point-

+3.3 V, +5 V, and GND traces run along

to-point wiring with 20 to 30 A WG wire between the prototyping area, the GND traces,

and the surrounding area where surface-mount components may be installed.

The holes in

+3.3 V, +5 V , and

Small holes are provided around the surface-mounted components that may be installed around the prototyping area.

B.4.1 Adding Other Components

There are two sets of pads for 6-pin, 16-pin, and 28-pin devices that can be used for surface-mount prototyping devices. There are also pads that can be used for SMT resistors and capacitors in an 0805 SMT package. Each component has every one of its pin pads connected to a hole in which a 30 A WG wire can be soldered (standard wire wrap wire can be soldered in for point-to-point wiring on the Prototyping Board). Because the traces are very thin, carefully determine which set of holes is connected to which surface-mount pad.

User’s Manual 89

B.4.2 Digital I/O

B.4.2.1 Digital Inputs

The Prototyping Board has four digital inputs, IN0–IN3, each of which is protected over a range of –36 V to +36 V. The inputs are pulled up to +3.3 V as shown in Figure B-5.

JP6

+3.3 V

27 kW

22 kW

GND

Figure B-5. Prototyping Board Digital Inputs

The four quadrature decoder inputs on screw-terminal header J5 may be used as inputs IN4–IN7. To use the PF0 signal from the Rabbit microprocessor, which goes to QD1B, remember to reconfigure the jumper on header JP3 to jumper pins 1–2.

The actual switching threshold is between 0.9 V and 2.3 V. Anything below this value is a logic 0, and anything above is a logic 1.

The digital inputs are each fully protected over a range of -36 V to +36 V, and can handle short spikes of ±40 V.

90 RabbitCore RCM3365/RCM3375

B.4.3 CMOS Digital Outputs

If the stepper-motor option is not used, eight CMOS-level digital outputs are available at J10, and can each handle up to 25 mA.

B.4.4 Sinking Digital Outputs

Four sinking digital outputs sh ared with LEDs DS3–DS6 are available at J12, and can each handle up to 500 mA. Figure B-6 shows a wiring diagram for a typical sinking output.

Vcc

330 W

1 kW

ADD DIODE

WHEN LOAD

IS INDUCTIVE

Figure B-6. Prototyping Board Sinking Digital Outputs

B.4.5 Relay Outputs

Figure B-7 shows the contact connections for the relay on the Prototyping Board. A diode across the coil provides a return path for inductive spikes, and snubbers across the relay contacts protect the relay contacts from inductive spikes.

456

J17

47 W

100 nF

100 nF 100 nF

100 nF

+3.3 V

COM1

NO1

NC1

COM2

NO2

NC2

Figure B-7. Prototyping Board Relay Output Contact Connections

The relay is driven by pin PA4 of the RCM3365/RCM3375 module via U8, and is controlled by PE7 and PG5 as shown in the sample applications.

User’s Manual 91

B.4.6 Serial Communication

The Prototyping Board allows you to access up to five of the serial ports from the RCM3365/RCM3375 module. Table B-2 summarizes the configuration options.

Table B-2. Prototyping Board Serial Port Configurations

Serial Port Signal Header Configured via Default Use Alternate Use

RCM3365/RCM3375

BJ9

—

Serial Port B signals

on PB0, PC4 and PC5

—

CJ14

J11

EJ14 FJ14

* RS-485 termination and bias resis tors are configured via header JP5.

JP5

JP3

— —

RS-485

RabbitNet

(PD2 = 1)

SF1000

(PD2 = 0)

RS-232 RS-232

—

Rabbit 3000

quadrature decoder

— —

Serial Port D is configured in softwa re e ither to allow J7 to be used a s a RabbitNe t port or to allow J11 to be used as a serial interface for the SF1000 series serial flash.

92 RabbitCore RCM3365/RCM3375

B.4.6.1 RS-232

RS-232 serial communication on the Prototyping Board is supported by an RS-232 transceiver installed at U9. This transceiver provides the voltage output, slew rate, and input voltage immunity required to meet the RS-232 serial communication protocol. Basically, the chip translates the Rabbit 3000’s signals to RS-232 signal levels. Note that the polarity is reversed in an RS-232 circ uit so that a +5 V output becomes approximately -10 V and 0 V is output as +10 V. The RS-232 transceiver also provides the proper line loading for reliable communication.

RS-232 can be used effectively at the RCM3365/RCM3375 module’s maximum baud rate for distances of up to 15 m.

RS-232 flow control on an RS-232 port is initiated in software using the

serXflowcontrolOn function call from RS232.LIB, where X is the serial port (E or F).

The locations of the flow control lines are specified using a set of five macros.

SERX_RTS_PORT—Data register for the parallel port that the RTS line is on (e.g., PGDR). SERX_RTS_SHADOW—Shadow register for the RTS line's parallel port (e.g., PGDRShadow). SERX_RTS_BIT—The bit number for the RTS line. SERX_CTS_PORT—Data register for the parallel port that the CTS line is on (e.g., PCDRShadow). SERX_CTS_BIT—The bit number for the CTS line.

Standard 3-wire RS-232 communication using Serial Ports E and F i s il lustrated in the following sample code.

#define EINBUFSIZE 15 // set size of circular buffers in bytes #define EOUTBUFSIZE 15

#define FINBUFSIZE 15 #define FOUTBUFSIZE 15

#define MYBAUD 115200 // set baud rate #endif

main(){ serEopen(_MYBAUD); // open Serial Ports E and F serFopen(_MYBAUD); serEwrFlush(); // flush their input and transmit buffers serErdFlush(); serFwrFlush(); serFrdFlush(); serEclose(_MYBAUD); // close Serial Ports C and D serFclose(_MYBAUD); }

User’s Manual 93

B.4.6.2 RS-485

The Prototyping Board has one RS-485 serial channel, which is connected to the Rabbit 3000 Serial Port C through an RS-485 transceiver. The half-duplex communication uses an output from PD7 on the Rabbit 3000 to control the transmit enable on the communication line. Using this scheme a strict master/slave relationship must exist between devices to insure that no two devices attempt to drive the bus simultaneously.

Serial Port C is configured in software for RS-485 as follows.

#define ser485open serCopen #define ser485close serCclose #define ser485wrFlush serCwrFlush #define ser485rdFlush serCrdFlush #define ser485putc serCputc #define ser485getc serCgetc

#define CINBUFSIZE 15 #define COUTBUFSIZE 15

#ifndef _485BAUD #define _485BAUD 115200 #endif

The configuration shown above is based on circular buffers. RS-485 configuration may also be done using functions from the PACKET.LIB library.

The Prototyping Boards with RCM3365/RCM3375 modules installed can be used in an RS-485 multidrop network spanning up to 1200 m (4000 ft), and there can be as many as 32 attached devices. Connect the 485+ to 485+ and 485– to 485– using single twisted-pair wires as shown in Figure B-8. Note that a common ground is recommended.

RS485+

RS-485

GND

RS-485

Figure B-8. Multidrop Network

GND

RS485+

RS-485

GND

94 RabbitCore RCM3365/RCM3375

Rabbit RCM3365, RCM3375 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS

1. INTRODUCTION

1.1 RCM3365 and RCM3375 Features

1.2 Comparing the RCM3900/RCM3910 and RCM3365/RCM3375

1.3 Advantages of the RCM3365 and RCM3375

1.4 Development and Evaluation Tools

1.4.1 RCM3365/RCM3375 Development Kit

1.4.2 Software

1.4.3 Accessories

1.4.4 Onlin e Documentation

2. GETTING S TARTED

2.1 Install Dynamic C

2.2 Hardware Connections

2.2.2 Step 2 — Connect Serial Programming Cable

2.2.3 Step 3 — Connect Power

2.3 St arting Dynamic C

2.3.1 Running Dynamic C via Serial Programming Cable

2.3.2 Running Dynamic C via Ethernet Cables

2.4 Where Do I Go From Here?

2.4.1 Technical Support

3. RUNNING SAMPLE PROGRAMS

3.1 Introduction

3.2 Sample Programs

3.2.1 Use of NAND Flash

3.2.2 Hot-Swapping xD-Picture Card

3.2.3 Serial Co mmunication

3.2.4 Real-Time Clock

3.2.5 RabbitNet

3.2.6 Other Sample Programs

4. HARDWARE REFERENCE

4.1 RCM3365/RCM3375 Inputs and Outputs

4.1.1 Memory I/O Interface

4.1.2 Other Inputs and Outputs

4.1.3 LEDs

4.2 Serial Communication

4.2.1 Serial Ports

4.2.2 Ethernet Port

4.2.3 Serial Programming Port

4.3 Serial Programming Cable

4.3.1 Changing Between Program Mode and Run Mode

4.3.2 Standalone Operation of the RCM3365/RCM3375

4.4 Memory

4.4.1 SRAM

4.4.2 Flash EPROM

4.4.3 NAND Flash

4.5 Other Hardware

4.5.1 Clock Doubler

4.5.2 Spectrum Spreader

5. SOFTWARE REFERENCE

5.1 More About Dynamic C

5.1.1 Developing Programs Remotely with Dynamic C

5.2 Dynamic C Functions

5.2.1 Digital I/O

5.2.2 SRAM Use

5.2.3 Serial Co mmunication Drivers

5.2.4 TCP/IP Drivers

5.2.5 NAND Flash Drivers

5.2.6 Prototyping Board Functions

5.3 Upgrading Dynamic C

5.3.1 Extras

6. USING THE TCP/IP FEATURES

6.1 TCP/IP Connections

6.2 TCP/IP Primer on IP Addresses

6.2.1 IP Addresses Explained

6.2.2 How IP Addresses are Used

6.2.3 Dynamically Assigned Internet Addresses

6.3 Placing Your Device on the Network

6.4 Running TCP/IP Sample Programs

6.4.1 How to Set IP Addresses in the Sample Programs

6.4.2 How to Set Up your Computer for Direct Connect

6.5 Run the PINGME.C Sample Program

6.6 Running Additional Sample Programs With Direct Connect

6.6.1 RabbitWeb Sample Programs

6.7 Where Do I Go From Here?

A.1 Electrical and Mechanical Characteristics

A.1.1 Headers
