Qwest 2621 User Manual

MODEL: 2621

Important Safety Instructions

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this product near water (for example, near a bath tub, kitchen sink or swimming pool).

5. Do not place this product on an unstable surface, such as a table, shelf or stand. The product may fall, causing serious damage.

6. Slots and openings in the back or bottom of the Base Unit and Handset are provided for ventilation. To protect them from overheating, these openings must not be blocked by placing the product on a soft surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat register. This product should not be placed in any area where proper ventilation is not provided.

7. This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply in your home, consult your dealer or local power company.

8. Do not allow anything to rest on the power cord. Do not install this product where the cord may have anyone walking on it.

9. Never push objects of any kind into this product through slots in the Base or Handset as they may touch dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill liquid of any kind on the product.

10.To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service facility. Opening or removing parts of the Base or Handset other than specified access doors may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock when the product is subsequently used.

11.Do not overload wall outlets and extension cords as this can result in the risk of fire or electric shock.

Important Safety Instructions

12.Unplug this product from the wall outlet and refer servicing to an authorized service facility under the following conditions:

A. When the power supply cord or plug is damaged or frayed. B. If liquid has been spilled onto the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and often requires extensive work by an authorized technician to restore the product to normal operation.

E. If the product has been dropped and the Base and/or Handset has

been damaged.

F. If the product exhibits a distinct change in performance.

13. Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric shock from lightning.

14.Do not use the telephone to report a gas leak in the vicinity of the leak.

15.Only put the Handset of your telephone next to your ear when it is in normal talk mode.

Introduction

The 2621 is an advanced cordless telephone that operates in the 2.4GHz frequency range.

This manual is designed to familiarize you with the 2621 cordless telephone. We strongly recommend you read the manual before using your phone.

Parts Check List

1. Handset

2. Base Unit

3. AC Power Adapter

4. Telephone Line Cord

5. Belt Clip

6. Battery

7. Owner's Manual

The Handset Layout

2 3

4 5

1. Antenna

2. Message Waiting Indicator

3. Earpiece

4. Headset Jack (2.5mm)

5. Scroll Keys

6. On/Flash

7. Dialing Key (0 - 9, *, #)

12 13

8. Handsfree Speakerphone

9. LCD Display

10. Select

11. Off/Clear

12. Intercom

13. Billed Services

14. Microphone

The Base Unit Layout

Phone Cord Jack

AC Power Jack

Message Waiting Indicator

Charge Indicator

Page Key

Setup

Plug the AC power adapter into an electrical outlet, and the DC connector into the bottom of the Base Unit.

Installation of Battery in Handset

Getting Started

1. Remove the battery compartment

cover by pressing on the indent and sliding downward.

2. Place the new battery in the

Handset with the metal contacts aligned with the charge contacts in the battery compartment.

3. Replace the battery compartment

cover by sliding it upward.

4. If the new battery is not already

charged, place the Handset in its Base and allow to charge a minimum for 12 hours (or overnight). After that, be sure to replace the Handset on its Base when not in use to ensure maximum daily battery

performance.

Setup

Charging Of Handset Battery

The Handset of your 2621 cordless telephone is powered by a rechargeable battery. It charges automatically whenever the Handset is in the Base Unit.

You should charge the battery for 12 hours when you first receive your phone. You'll know the battery needs charging when:

Getting Started

• The low battery message is

displayed:

• The Handset seems completely

dead, the LCD is completely clear and does not activate when you press the keys.

IMPORTANT:

1. Do not dispose of a battery in a fire, the cell may explode.

2. Do not open or mutilate the battery. Toxic substances may be released,

causing harm to eyes or skin.

3. Exercise care in handling batteries in order to prevent an accidental short

of the charge contacts, potentially causing the battery to overheat.

4. Do not dispose of this battery into household garbage. Please contact

your local, state or municipal recycling organization for information on how to properly dispose of your rechargeable battery.

5. If the phone will not be used for a long time, remove the batteries to

prevent possible leakage.

Setup

Connecting to Phone Line

Before connecting the phone line, make sure to properly charge the battery for at least 12 hours.

Plug one end of the telephone line cord into the jack on the bottom of the Base Unit. Plug the other end of this cord into the wall jack.

Checking for Dial Tone

After the battery is charged press ON on the Handset. The phone icon will appear on the Handset display, and you will hear dial tone. If not, see

In Case of Difficulty.

Tone/Pulse Selection

• With the Handset in the idle (OFF) mode, press MENU.

• Use

• You'll hear a confirmation beep.

NOTE: Your 2621 is preset for TONE dialing.

CAUTION: Use only the power supply provided with your 2621.

IMPORTANT:

Scroll to TONE/PULSE, then press OK. Scroll to TONE or PULSE; press OK.

Getting Started

For best performance the 2621 should be installed as follows:

In an elevated location, in the center of the room, with no obstructions nearby.

In a location that is away from other electrical appliances such as microwave ovens, personal computers, or televisions.

Registration and Operation

Registration and Operation of the 2603 Accessory Handset

Your 2621 system can operate up to four Handsets. The accessory Handset consists of the following:

Getting Started

Setup of the 2603 Accessory Handset

1. Plug the AC power adapter into

an electrical outlet, then the DC connector into the bottom of the

Charger Unit.

2. Remove the Handset battery

compartment cover by pressing on the indent and sliding downward.

3. Place the new battery in the

Handset, with the metal contacts aligned with the charge contacts in the battery compartment.

4. Replace the battery compartment

cover by sliding it upward.

5. Place the Handset in the Charge

Cradle, and allow it to charge for 12 hours. After the initial charge, a maintenance charge of 10 hours should be sufficient.

Registration and Operation

Enter Base ID Code

1. After charging the Handset,

remove it from its Charge Cradle, the screen will display:

2. Press NEW, then enter the 15

digit Base Unit ID code, located on the underside of the Base Unit.

3. Press OK. The Handset will

display: PLEASE WAIT!!

NO BASE

SUBSCRIPTION

Getting Started

4. Wait approximately 15 seconds.

The Handset will display:

FOUND BASE

Congratulations! You can now enjoy the benefits of your multi-Handset system.
