QVS USB213, USB-413 User Manual
Specifications and Main Features
- Model No: USB-213
- Type: 2 Port USB Share Switch
- Model No: USB-413
- Type: USB 4 Port Share Switch
- PC Port: USB-213 (2 PCs), USB-413 (4 PCs)
- USB Device Port: USB-213 (3), USB-413 (3)
- Extra Hub Ports: USB-213 (2), USB-413 (2)
- Cable Length (meters): 5
- USB Power: USB Self powered
- Power Adapter: DC 12V, 1A
- Operating Temperature: 0~40°C
- Storage Temperature: -20 ~ 60°C
- Emission: CE, FCC certified
- Humidity: 0~80%, Non-condensing
- Enclosure: Plastic
- Size (Dimension cm): USB-213 (20(L)x11(W)x2.5(H)), USB-413 (20(L)x11(W)x2.5(H))
- Weight: 280 grams
- USB Data Transfer: Dual speed (12Mbps and 1.5Mbps)
- Compliance: USB REV1.1 specifications
- Interface Support: UHCI and OHCI USB interface support
- Auto Print Mode: Some HP, Epson USB and IEEE-1284 printers can be handled under Auto print mode or software manual mode software.
- Automatic Device Switching: 1st Come 1st Serve mode
Frequently Asked Questions
Q1: How many pcs can connect to the Intelligent USB Share Switch?
A1: In USB-213 model, the thumb sharing device remains attached to two PCs while in USB 413 model, this device can be attached to 4 PCs.
Q2: What kind of devices can be plugged to the USB ports via this switch?
A2: Various kinds of devices can be used, such as USB printers, USB docking stations, USB to Wireless LAN, and USB to Bluetooth adapters.
Q3: Is the USB Switch functional without being plugged into a power source?
A3: No, a USB Switch works by being self powered however a dc 12V 1A power adapter is required.
Q4: How far from the USB share box can it be connected to a PC?
A4: The TV can be placed up to five meters away from the PC.
Q5: On the intelligent share switch, which operating systems are able to work on it?
A5: The Windows operating system will be sufficient to run this device flawlessly.
Q6: What if there are more devices that need to be connected than the available USB ports on the switch?
A6: This problem can also be easily solved by knowing that a USB hub can be connected to the device ports.
Q7: What If there is no PC- Using the USB device ports?
A7: All free PC ports will be marked for the pc to connect the USB device ports and vice versa.
Q8: Kindly explain the print mode along with wireless modes?
A8: It works by using auto print mode, that attaches the printer to the PC for which the print job was sent and it disconnects the printer after the job is done.
