MINI-PTZ-23X-H
23X ZOOM ANALOGUE PTZ CAMERA
User’s Manual
V1.0 10 / 2013
i
ii
Table of Contents
1 FEATURES AND FUNCTIONS ................................................................................................ 1
1.1 General Introduction .......................................................................................................................................... 1
1.2 Features .............................................................................................................................................................. 1
1.2.1 On-Screen Menu ............................................................................................................................................. 1
1.2.2 Proportional Pan and Tilt ................................................................................................................................. 1
1.2.3 On-screen Tips ................................................................................................................................................ 1
1.2.4 Preset Setup and Call ...................................................................................................................................... 1
1.2.5 Auto Scan ........................................................................................................................................................ 1
1.2.6 Auto Touring .................................................................................................................................................... 2
1.2.7 Auto Pattern ..................................................................................................................................................... 2
1.2.8 Privacy Masking ............................................................................................................................................... 2
1.2.9 Auto Flip ........................................................................................................................................................... 2
1.2.10 Self-diagnosis .............................................................................................................................................. 2
1.2.11 Day/Night Mode (B/W & Color Mode) ......................................................................................................... 2
1.2.12 Auto Focus .................................................................................................................................................. 2
1.2.13 Backlight Compensation .............................................................................................................................. 2
1.2.14 Pan Tilt and Zoom ....................................................................................................................................... 2
1.2.15 3D Intelligent Location ................................................................................................................................. 3
1.2.16 Idle Status .................................................................................................................................................... 3
1.2.17 Image Stabilizer/Flip .................................................................................................................................... 3
2 MENU ....................................................................................................................................... 4
2.1 Screen Menu Index ............................................................................................................................................ 4
2.2 Self-diagnosis System Information .................................................................................................................. 5
2.3 Main Menu ........................................................................................................................................................... 5
2.4 Menu Operation .................................................................................................................................................. 6
2.4.1 System Information .......................................................................................................................................... 6
2.4.2 Display Setting ................................................................................................................................................. 7
2.4.3 Camera Setting ................................................................................................................................................ 8
2.4.4 Function Setting ............................................................................................................................................. 12
2.4.5 Alarm Setup ................................................................................................................................................... 19
2.5 Abnormal Phenomenon Operation ................................................................................................................ 19
2.5.1 Restore to Factory Default Setup .................................................................................................................. 19
2.5.2 Irregular PTZ Movement ................................................................................................................................ 19
3 CABLE CONNECTION .......................................................................................................... 20
iii
3.1 Combination Cable Connection...................................................................................................................... 20
4 FAQ ........................................................................................................................................ 21
4.1 Daily Maintenance ............................................................................................................................................ 21
4.2 Problems and Solutions .................................................................................................................................. 21
iv
Welcome
Thank you for purchasing the MINI-PTZ-23X-H PTZ camera.
This user’s manual is designed to be a reference tool for the installation and
operation of your system.
Here you can find information about the corresponding IP camera’s features and
functions, as well as a detailed installation method.
Before installation and operation please read the following safeguards and
warnings carefully!
v
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or
installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation Security
No heavy stress, violent vibration or contact with water is allowed during transportation, storage and
installation.
Please use the original packing material (or the material of the same quality) when you ship it back to the
manufacturer.
3．Installation
Do not apply power to the product before completing installation.
Do not put object(s) on the product.
4．Environment
This product should be installed in a cool, dry place away from direct sunlight, inflammable, explosive
substances and etc.
Please keep it away from environments that contain electromagnetic radiation or objects that produce it.
Please keep sound ventilation around the device at all times.
Do not allow the water and other liquid to penetrate into the device if casing has been compromised. This
series product complies with the IP66 standard specified in the Degrees of Protection Provided by
Enclosure.
Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
5. Daily Maintenance
Current series product has no power button. Please unplug all corresponding power cables before your
begin installation or daily maintenance work.
Please keep the dustproof cap back to protect the CCD or CMOS part if the device does not work for a long
time.
Do not touch CCD (CMOS) component. You can use the blower to clean the dust on the surface of the
device. You can use the dry cloth with some alcohol or mild detergent to clear if necessary.
Do not use volatility solvent such as the benzene or thinner, or detergent with strong abradability. It may
result in lens damage or it may adversely affect the device performance.
vi
If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the
device. Finally use the dry cloth to clean the device.
6. About Accessories
Always use all the accessories recommended by manufacturer.
Before installation, please open the package and check that all the components are included in the package.
Contact your local retailer ASAP if something is missing in your package.
1
1 Features and Functions
1.1 General Introduction
This 4-inch analogue intelligent PTZ dome camera not only gives you 23X optical zoom but also the ability to
digitally zoom in to the video footage up to 16X, to scrutinise far away objects much more closely. It adopts a
new configuration design and is easy to install during project construction. This is a digitally intelligent product
that can provide you with vivid video visuals.
The design aesthetics also allows it to be incorporated into many modern settings. At the same the shape and
materials provides it with the robustness to survive a variety of weather conditions. Internal technology allows for
the PTZ rotation speed to be automatically adjusted according to lens zoom speed. It supports various
languages, real-time clock function, blind spot recognition and protocol auto recognition. It also gives you a full
360° continuously pan, 92°tilt and 180° auto flip.
1.2 Features
This PTZ speed dome has the following features:
1.2.1 On-Screen Menu
This series product menu supports multiple languages.
It is easy for you to view dome information and configure dome, camera parameters.
1.2.2 Proportional Pan and Tilt
This function keeps the image from moving too fast when there is a large amount of zoom.
The PTZ camera continually decreases or increases pan and tilt speeds in proportion to depth of zoom.
When zooms speed increases, the camera moving speed becomes slow. When zooms speed decreases,
the camera moving speed becomes fast.
1.2.3 On-screen Tips
Here you can view:
Dome title and system version (Software and hardware)
Dome system temperature. (Optional. You can disable this function)
Dome pan/tilt coordinates, preset ID.
1.2.4 Preset Setup and Call
Preset function is to save the address information (such as PTZ pan/tilt, focus and etc) to the memory so that
you can quickly adjust the dome and PTZ to the correct position.
1.2.5 Auto Scan
Camera scans back and forth regularly along the horizontal field. Here you need to set left and right limit and
scan speed. You can set 5 scanning paths.
2
1.2.6 Auto Touring
Add addresses into a routine in a desired order and then set time and stop duration for each address. The dome
will begin an auto touring between these addresses. Each touring path can contain max 32 presets.
1.2.7 Auto Pattern
Memorises dome operations such as pan, tilt, and zoom to repeat. You can call it to repeat the previous
operation.
1.2.8 Privacy Masking
Privacy masking is a user-defined, four-sided area that cannot be viewed by you. The masking area will move
with pan and tilt functions and automatically adjust in size as the lens zooms.
1.2.9 Auto Flip
As long as you continue to hold the keyboard joystick in the down position, the dome rotates 180 degrees and
repositions itself for uninterrupted viewing of any subjects that passes directly beneath the dome.
1.2.10 Self-diagnosis
There is a self-diagnosis procedure when camera boots up.
Tilt and vertical engine check
Camera diagnostics
1.2.11 Day/Night Mode (B/W & Color Mode)
Auto/manual switches in low illumination.
Auto: camera will automatically adjust CCD light level.
Manual: use menu or function keys to select auto/manual/schedule settings.
This function needs the speed dome driver (camera) supported.
1.2.12 Auto Focus
Supports auto focus function.
1.2.13 Backlight Compensation
Balance the brightest and darkest sections of a scene to produce a more vivid picture.
1.2.14 Pan Tilt and Zoom
Supports zoom in and zoom out during tilt and pan movement. In this period focus and iris are both in auto mode
to get vivid image.
3
1.2.15 3D Intelligent Location
It supports the 3D intelligent positioning function, where the camera can auto track to the specified zone.
1.2.16 Idle Status
When there is no available order, you can use menu to set dome idle status after specified duration.
1.2.17 Image Stabilizer/Flip
You can enable image stabiliser function and flip in the menu. When there is vibration, this I.S. function can
guarantee video stability, and when it flips, you can view the video more clearly.
4
2 Menu
2.1 Screen Menu Index
Note: ERR means current setup is invalid; you need to restores speed dome factory default setup.
Slight difference may be found due to different series.
The above diagram illustrates the overall structure of the speed dome setup menu.
PRESET
AZIMUTH DISP
POSITION
ZOOM DISP
INSIDE TEMP
TITILE DISPLAY
BACK EXIT
DISPLAY SETTING
SYSTEM SETTING
CAMERA SETTING
FUNCTION SETTING
EXIT
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETUP
ZOOM SPEED
APERTURE
APERTURE CNT LEVEL
NEXT PAGE
BACK EXIT
PRESET
AUTO PAN
AUTO SCAN
TOUR
PATTERN
IDLE MOTION
NEXT PAGE
BACK EXIT
ALARM SETTING
ALARM NO
ACTION
PARAMETER
CONTACT
RELAY OUT
RESET DELAY
SAVE
BACK EXIT
SYSTEM INFORMATION
ADDR INFORMATION
SET NORTH
LANGUAGE
FACTORY DEFAULT
RESTART
BACK EXIT
5
ADDR ：001-H
BAUD RATE ：9600
PARITY ：NONE
SOFTWARE ：V1.03.0.RHAJDV
BACK EXIT
SYSTEM SETTING
DISPLAY SETTING
CAMERA SETTING
FUNCTION SETTING
ALARM SETTING
EXIT
Note:
ERR means current setup is invalid.
Please make sure all the cable connections are correct.
2.2 Self-diagnosis System Information
After installation, please connect speed dome to power. The system goes on a self-diagnosis routine, and then it
pops up the above interface to show the system information.
If there is anything wrong during the self-diagnosis, system pops up error code.
The above interface disappears after speed dome received the first command (or the display time lasts for
4minutes.)
ADDR: Here you can view dome address information. For example, 001-H, 1 is the address number, -H is
hard address mode. –S is software address mode.
Baud rate: Dome communication baud rate.
Parity: Communication parity bit format.
Software: Dome PTZ software version.
When you are using the control keyboard or the matrix host to control the device, please make sure the
control parameter of the keyboard or the matrix host is the same with the speed dome OSD (including
address, baud rate, parity). Please make sure the cable connection is OK.
2.3 Main Menu
You can open the PTZ camera menu via control keyboard, matrix, or speed dome control terminal.
SYSTEM INFORMATION：Dome self-diagnosis information, address information, system time setup, set
north direction, language, factory default setup, reboot and so on.
DISPLAY INFORMATION: Display dome preset title, azimuth display, time, direction, dome internal
temperature information.
CAMERA PARAMETERS：Display dome white balance setup, camera function setup, day/night setup,
shutter setup and etc.
6
SYSTEM INFORMATION
ADDR INFORMATION
SET NORTH
LANGUAGE ：ENGLISH
FACTORY DEFAULT
RESTART
BACK EXIT
FUNCTION SETTING: Set preset, pan, scan, auto cruise, pattern, idle function, time task and privacy mask
function.
ALARM SETTING：Set dome alarm number, action, contact, replay out, reset time, etc.
EXIT: Log out of the system menu.
2.4 Menu Operation
In the PTZ camera main menu, you can use the left/right button on the keyboard or in the camera’s terminal
menu to configure the system menu. Before setup, please move the cursor to the current item you want to
configure.
In main menu, please click confirm button to go to the sub menu or use left/right key to configure setup.
Use up/down button to select back option and then click confirm button to go back to the previous menu.
Use up/down button to select exit option and then click confirm button to log out system menu.
All setups here will not be lost when you encounter a power failure.
2.4.1 System Information
SYSTEM INFORMATION: Move the cursor to SYSTERM INFORMATION and then click the confirm button
to go to the third submenu.
ADDR INFORMATION: Move the cursor to SITE INFORMATION and then click confirm button to go to the
third submenu.
SET NORTH: Set the camera’s benchmark direction so that you can know the angle between the
benchmark and then current location. Please move the cursor to the option and then click confirm button
until you see O.K. option. Now you have set the north direction.
LANGUAGE: The dome menu language. There are several languages for you to select. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
FACTORY DEFAULT: Restore dome factory default setup. Please move the cursor to the option and then
click confirm button until you see O.K. Now you can see the IP dome begin rebooting to restore factory
default setup.
RESTART: Reboot the camera.
BACK: Go back to the previous menu.
EXIT: Log out of the system menu.
7
ADDR ： 001-H
BAUD RATE ：9600
PARITY ：NONE
SOFTWARE ：V1.03.0.RHAJDV
BACK EXIT
2.4.1.1 System information
Move the cursor to SYSTEM INFORMATION and then click the confirm button, you will see the above interface.
Here you can view the dome’s basic information.
2.4.1.2 Address Information
Move the cursor to SITE INFORMATION and then click confirm button.
ADDR TYPE: There are two options: soft and hard. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set. Please click the OK button to confirm
ADDR-HARD: It is an address you can set in the dial switch. You cannot modify it through the software.
ADDR-SOFT: You can set address via software. It is to say, you can use menu to modify dome address.
The value ranges from 0 to 255.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
2.4.2 Display Setting
Move the cursor to DISPLAY SETUP and then click confirm button, you can go to the third submenu. Please use
the left/right button on the keyboard or in the speed dome terminal menu to set. After completing the setup,
please click the save button to save current setup.
PRESET TITLE: Display dome preset title or not. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set. You can go to Function Setup->Preset section to set corresponding
preset value and preset title.
ADDR TYPE ：HARD
ADDR-HARD ：1
ADDR-SOFT ：0
BACK EXIT
PRESET ：ON
AZIMUTH DISP ：ON
POSITION ：OFF
ZOOM DISP ：OFF
INSIDE TEMP ：OFF
TITLE DISP ：OFF
BACK EXIT
8
AZIMUTH DISP: Displays the cameras current coordinates or not. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set
POSITION: Displays the angle between the benchmark and then current location. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
ZOOM DISP: Display speed dome zoom speed or not. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options: ℃/F/Off.
Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
TITLE DISPLAY: Here you can set to display speed dome position information and etc. You can use the
speed dome control terminal to set the detailed title information. Please use the left/right button to set.
BACK: Go back to the previous menu.
EXIT: Log out system menu.
2.4.3 Camera Setting
Before the operation, please make sure your camera supports the corresponding function.
Move the cursor to CAMERA SETTING and then click confirm button, you can go to the submenu.
WHITE BALANCE SETUP: Move the cursor to current option and then click confirm button, you can go to
the third menu.
EXPOSURE SETTING: Move the cursor to current option and then click confirm button, you can go to the
third menu.
DAY/NIGHT: Set day/night mode. Move the cursor to current option and then click confirm button, you can
go to the third menu. There are three options: auto/manual/off. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set. Please make sure your product supports this function.
FOCUS SETTING: This is to set the camera focus mode, focus limit, etc. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
FOCUS LIMIT: This is to set the distance between the camera and the object. It can prevent the focus
distance being too small, which may result in an unclear image. At the same time, you can change the
distance to change the focus speed.
ZOOM SPEED: The bigger the value, the faster the speed. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.
APERTURE: This is to adjust the lens to achieve clearer video footage. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
APERTURE RESTRAIN: System can auto reduce the aperture to lower the video noise when it is in a
poorly illuminated environment. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
WB SETTING
EXPOSURE SETTING
DAY/NIGHT SETTING
FOCUS SETTING
ZOOM SPEED ：8
APERTURE ：9
APERTURE RESTRAIN ：10
NEXT PAGE
BACK EXIT
9
NEXT PAGE: This includes the following options: DIGITAL ZOOM, PICTURE FLIP, FREEZE FUNCTION,
CAMERA FACTORY DEFAULT SETUP and CAMERA RESTART. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.3.1 White Balance Setup
Move the cursor to WHITE BALANCE MODE and then click confirm button, you can then go to the submenu.
WHITE BALANCE MODE: Set white balance adjustment mode. There are several modes such as auto,
auto trace white balance, indoor, outdoor, and manual. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
R GAIN: Before you set R GAIN option, please note it will not be in auto mode. Please use the left/right
button on the keyboard or in the camera’s terminal menu to set.
B GAIN: Before you set B GAIN option, please note it will not be in auto mode. Please use the left/right
button on the keyboard or in the camera’s terminal menu to set.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.3.2 Exposure Setting
AE MODE: This is where you can set the camera exposure mode. This includes: auto/manual/AV (iris
priority)/TV (shutter priority). Please use the left/right button on the keyboard or in the speed dome terminal
menu to set.
o Auto: This becomes valid after you set the exposure compensation, backlight compensation
(BLC), slow shutter, wide dynamic region (WDR).
o Manual: This becomes valid after you set the gain setting, shutter, iris setting, wide dynamic
region (WDR).
o AV: This becomes valid after you set the exposure setting, iris setting, wide dynamic region
(WDR).
o TV: This becomes valid after you set the shutter setting, exposure compensation, wide dynamic
region (WDR).
GAIN SETTING: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
WB MODE ： AUTO
R GAIN ： 82
B GAIN ： 58
BACK EXIT
AE MODE ：AUTO
GAIN SETTING ：2
SHUTTER ：1/50
IRIS SETTING ：4
EXPOSURE COMP ：8
SLOW AE ：1
SLOW SHUTTER ：ON
NEXT PAGE
BACK EXIT
AGC GAIN LIMIT ：2
SLOW SHUTTER LIMIT ：1/25
NOISE REDUCTION ：3
3D NOISE REDUCTION ：1
BLC ：OFF
WDR ENABLE
AE RECOVERY ：15MIN
BACK EXIT
10
WDR MODE ：OFF
BACK EXIT
SHUTTER: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
IRIS SETTING: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
EXPOSURE COM: Please use the left/right button on the keyboard or in the speed dome terminal menu to
set.
SLOW AE: In a strongly lit environment, you can lower the camera exposure speed when capturing the
image so you can enhance the definition. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
SLOW SHUTTER: In a poorly illuminated environment, you can lower the cameras auto exposure time
when capturing an image and enhance the definition. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
NEXT PAGE: This includes: GAIN MAX LIMIT, SLOW SHUTTER LIMIT, NOISE REDUCTION, 3D NOISE
REDUCTION, BLC, WDR, BACK, and EXIT. Move the cursor to the item and then click the left/right button
to set.
o AUTO GAIN LIMIT: Please click the left/right button to set.
o SLOW SHUTTER LOW LIMIT: Please click the left/right button to set.
o NOISE REDUCTION: There may be noise when the camera is monitoring in low illumination
environments. You can use the digital filter to process the noise to guarantee the clear video.
o 3D NOISE REDUCTION: This is to set the speed dome 3D noise reduction setup. Please use
the left/right button on the keyboard or in the speed dome terminal menu to set.
o BLC: It is an abbreviation for Back Light Compensation. The System can compensate the object
in the dark light to achieve a clear video. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
o WDR ENBALE: It is an abbreviation for wide dynamic region. Please make sure your camera
supports current function. This function can adjust the video brightness when the contrast
between the strong light and the dark light is too high. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
o AE RECOVERY: Manually click the “+” and “-“button on the PTZ interface, the system can
resume previous exposure value after specified time (The exposure value does not resume if this
function is off.).
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.3.3 WDR
Move the cursor to WDR and then click confirm button, you can then go to the submenu.
WDR MODE: Click Left/right button to enable/disable camera WDR function.
BACK: Go back to previous menu.
EXIT: Log out system menu.
11
DAY/NIGHT ： AUTO
THRESHOD ： 05
BACK EXIT
2.4.3.4 Day/Night Setting
Move the cursor to DAY/NIGHT SETTING and then click confirm button, you can then go to the submenu.
DAY/NIGHT: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
DAY TIME: Current setup becomes valid when day/night mode’s time is set. Move the cursor to the DAY
TIME item and then click confirm button to go to setup. Please use the user up/down button to set the value.
After completing the setup, please click confirm button to exit and move the cursor to ‘Save’ button to save
current setup.
NIGHT TIME: Current setup becomes valid when day/night mode’s time is set. Move the cursor to DAY
TIME item and then click confirm button to go to setup. Please use the user up/down button to set the value.
After completing setup, please click confirm button to exit and move the cursor to save button to save
current setup.
THRESHOLD: The speed dome can switch the day/night mode when it reached the threshold you set here.
SAVE: This button is for DAY TIME and NIGHT TIME setup. After you set the day time (or night time), you
need to move the cursor here and then click confirm button to save current time setup. For other setups,
you do not need to use this button.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.3.5 Focus Setup
FOCUS MODE: This is to set the camera focus mode. It includes several modes such as auto, manual,
semiautomatic, etc.
FOCUS LIMIT: This is to set the camera focus limit. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
FOCUS SENSITIVITY: This is to set the camera focus sensitivity. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
IR LIGHT FOCUS CORRECTION: This is to set the camera IR light focus correction. Please use the
left/right button on the keyboard or in the speed dome terminal menu to set.
BACK: Go back to previous menu.
EXIT: Log out system menu.
FOCUS MODE ： AUTO
FOCUS LIMIT ：10CM
AF SENSITIVITY ： HGIH
IR CORRECTION ： OFF
BACK EXIT
12
PRESET
AUTO PAN
AUTO SCAN
TOUR
PATTERN
IDLE MOTION
NEXT PAGE
BACK EXIT
DIGITAL ZOOM ： OFF
PICTURE FLIP ：OFF
FREEZE FUNC ： OFF
CAMERA FACTORY DEFAULT
CAMERA RESTART
BACK EXIT
2.4.3.6 Next Page
Move the cursor to NEXT PAGE and then click confirm button, you can go to the submenu.
DIGITAL ZOOM: You can use the left/right button to enable/disable the digital zoom function.
PICTURE FLIP: There are two options: on/off. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
FREEZE FUNCTION: This function allows the system to go from one preset to another preset, without
showing the video during the PTZ movement. There are two options: on/off. Please use the left/right button
on the keyboard or in the speed dome terminal menu to set.
CAMERA FACTORY DEFAULT SETTING: Move the cursor to current item and then click confirm button to
restore factory default setup.
CAMERA RESTART: Move the cursor to current item and then click confirm button to reboot the camera.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.4 Function Setting
Please go back to main menu and move the cursor to FUNCTION SETTING, click confirm button. You can see
the above interface.
PRESET: Move the cursor to PRESET and then click confirm button to go to the third submenu.
AUTO PAN: Move the cursor to AUTO PAN and then click confirm button to go to the third submenu.
AUTO SCAN: Move the cursor to SCAN and then click confirm button to go to the third submenu.
TOUR: Move the cursor to AUTO TOUR and then click confirm button to go to the third submenu.
PATTERN: Move the cursor to PATTERN and then click confirm button to go to the third submenu.
IDLE FUNCTION: Move the cursor to IDLE FUNCITON and then click confirm button to go to the third
submenu.
13
PRESET NO ：001
TITLE ：PRESET1
SETTING
CALL
BACK EXIT
NEXT PAGE: This includes: PRIVACY MASKING, PTZ SPEED, SET ZERO, POWER UP, MENU
PASSWORD, MENU IDEL, PTZ AUTO STOP, and HEATER. Move the cursor to the item and then click
the confirm button to set. .
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.4.1 Preset Setup
Move the cursor to PRESET button and then click confirm button to go to set interface.
PRESET NO: Please use left/right key to modify preset number. The different protocols support different
preset values.
TITLE: Title text is the label used for you to identify the camera. System will automatically name a title for
the camera.
SETTING: Please input preset number first and then select the monitor zone. Please move the cursor to
setting and click the confirm button. The system will pop up a message: PRESET: *** Here *** means preset
number. And the SETTING column pops up an OK. Now you successfully added a preset. Please note, you
need to enable display preset title function first (Main menu->display setting->preset title). Repeat the
above procedures to set more presets. When you want to modify a preset, you can input the preset number
you want to modify and then follow the above steps to set the preset.
CALL: This is to recall a preset. Move the cursor to ‘PRESET NO’ and then input a corresponding preset
value. Then move the cursor to CALL and then click confirm button to go to a preset.
BACK: Go back to previous menu.
EXIT: Log out system menu.
For PELCO protocol user, please refer to the following special functions:
Call preset: Call preset 28 or preset 95 to go to dome menu. Call preset 29 or preset 99 to go to scan. Call
preset 24 or preset 81 to go to pattern. Call preset 25 or preset 82 to go to cruise (tour). Call preset 30 or
preset 96 to stop scan or pattern. Call preset 31 or preset 83 to begin rotation. Call preset 33 to enable PTZ
180 degrees rotation. Call preset 34 to set dome position as 0.
Set preset: Set preset 26 or 92 to set scan left limit. Set preset 27 or 93 to set scan right limit. Set preset 22
or 79 to begin recording. Set preset 23 or 80 to stop recording.
14
AUTO SCAN NO ： 001
SET LEFT LIMIT
SET RIGHT LIMIT
SCAN SPEED ：5
CALL
STOP
BACK EXIT
2.4.4.2 Pan
Move the cursor to PAN button and then click confirm button to go to setup interface.
PAN SPEED: Set dome rotation speed. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
RUN: Move the cursor to call item and then click confirm button. The dome begins 360 degrees continuous
rotation.
STOP: Highlight stop item and then click confirm button. The dome stops rotation.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.4.3 Scan
Move the cursor to the SCAN button and then click confirm button.
AUTO SCAN NO：This is to set the auto scan number. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set.
SET LEFT LIMIT：This is to set the camera left address. Click confirm button to save current setup.
SET RIGHT LIMIT：This is to set the camera right address. Click confirm button to save current setup.
SCAN SPEED: Please use the left/right button on the keyboard or in the speed dome terminal menu to set.
CALL: Please input auto scan number first, and then please move the cursor to CALL and click confirm
button to activate auto scan function.
STOP: This is to terminate auto scan function.
BACK: Go back to previous menu.
EXIT: Log out system menu.
PAN SPEED ：5
CALL
STOP
BACK EXIT
15
2.4.4.4 Tour
Move the cursor to highlight TOUR item and then click confirm button to go to set interface.
TOUR NO ：This is to set the tour number. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
TOUR SETTING: Move the cursor to the TOUR setting item and then click confirm button. You will see the
following interface:
Here you can add or remove the preset, and set the corresponding dwell time and call speed.
DWELL: This is to set the dwell time. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
SPEED: Here you can set the speed value.
When you move the cursor to one tour number, you can use the left/right button to turn the page.
When you move the cursor to one tour number, please click the confirm button to set the tour. Please use
up/down button to set preset number, dwell time and speed. Use the left/right button to go to the next tour. Click
the confirm button to exit the setup. After you completed the setup, move the cursor to back button to go to the
previous interface.
DELETE TOUR：This is to delete a tour. Input tour number in TOUR NO and then move the cursor to
DELETE TOUR, click confirm button to delete.
CALL: This is to activate tour. Input tour number in tour NO and highlight CALL, click confirm button to
activate tour.
STOP: This is to terminate touring.
BACK: Go back to previous menu.
EXIT: Log out system menu.
TOUR NO： ： 1
TOUR SETTING
DELETE TOUR
CALL
STOP
BACK EXIT
NO PRESET DWELL SPEED
01 000 005 013
02 000 005 013
03 000 005 013
… … … …
32 000 005 013
BACK EXIT
16
IDLE MOTION ：OFF
IDLE TIME ：10MIN
IDLE MOTION ：NONE
PARAMETER ：NONE
BACK EXIT
2.4.4.5 Pattern
The Pattern function can store a PTZ operation to the camera’s memory, which can include when you need
camera to focus zoom either in or out. From the start position, the camera begins auto movement repeatedly.
PATTERN NO: This is to set the pattern number. Please click left/right key to configure.
PROGRAM START: This function will initiate pattern. An ‘OK’ icon pops up on the screen to prompt you that
system has begun memory pattern.
PROGRAM STOP：This is to set the pattern stop point. After camera has completed all movements, adjust
the cursor to PROGRAM STOP and then click the confirm button. You have now set one pattern. The
System pops up an ‘OK’ icon to prompt you that system has memorised one pattern.
RUN：This is to activate a pattern. Input pattern number, move the cursor to RUN and click confirm button,
system begins running pattern.
STOP: This is to stop current pattern. Input pattern number, move the cursor to STOP and click confirm
button. System stops current pattern.
BACK: Go back to previous menu.
EXIT: Log out system menu.
Note:
The dwell time between two orders should be less than one minute, otherwise system will set to default
value as one minute.
After click PROGRAM STOP, do not click CALL button before icon “●” disappears completely.
Any manual operation during the pattern procedure will terminate current dome pattern operation.
2.4.4.6 Idle Motion
When there is no available command for a specified time, the camera automatically uses the previous set of
functions.
IDLE MOTION：There are two modes: ON/OFF. Please use left/right key to set.
PATTERN NO ： 1
PROGRAM START
PROGRAM STOP
CALL
STOP
BACK EXIT
17
PRIVACY MASK
PTZ SPEED ：2
SET ZERO
POWER UP
MENU IDLE ：1M
PTZ AUTO STOP ：15S
BACK EXIT
IDLE TIME: System idle period. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
IDLE MOTION：There are five functions you can select: NONE/PRESET/SCAN/TOUR/PATTERN. Please
use the left/right button on the keyboard or in the speed dome terminal menu to set.
PARAMETER: This is to set the idle motion SN. System can implement the corresponding action when it is
idle for the specified period. Click the left/right button to set.
SAVE：Move the cursor to SAVE and click confirm button to save current setup.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.4.4.7 Next Page
Move the cursor to the NEXT PAGE and then click the confirm button, you can go to the third menu to set
the PTZ SPEED, POWER UP and etc.
PRIVACY MASK: Here you can set the privacy mask number, etc. This includes the third menu. Please
move the cursor to the current item and then click the confirm button to go to the next interface.
PTZ SPEED: This is to set the PTZ speed. Please use the left/right button to set.
SET ZERO: Please move the PTZ to the horizontal coordinates, click OK button to confirm.
POWER UP: This is to set the PTZ action when the speed dome boots up. Click the confirm button to go to
the next interface to set.
MENU IDLE: If the current setup is ON, once you open the menu and leave it idle for specified period, the
menu may automatically disappear. If the current setup is OFF, the menu is always there and will not
disappear. Please use the left/right button to set.
PTZ AUTO STOP: The speed dome will stop all the PTZ operations when there is no command for the
specified time. It includes various setups. Please use the left/right button to set.
TEMPERATURE: It includes: on/off/auto (default).
BACK: Go back to the previous menu.
EXIT: Log out the system menu.
Privacy Mask
1. Move the cursor to PRIVACY MASK and click confirm button, system goes to privacy mask setup
interface.
PRIVACY NO ： 1
PRIVACY MASKING ：OFF
SETTING
BACK EXIT
RESIZE ：↑
SAVE
BACK EXIT
18
POWER UP ：AUTO
PARAMTER ：OFF
BACK EXIT
Note:
For security reasons, please set privacy zone a little bit larger than the privacy object size.
Each time, after modifications you need to move the cursor to SAVE button and then click confirm button
to get all setup activated. Otherwise, privacy zone may not move correspondingly with the object.
2. Please enter privacy mask menu.
3. Move the cursor to PRIVACY NO, please use left/right key to set different privacy zones.
4. For example, shift to 001 section and then move the cursor to SETTING.
5. Secondly, click OK button to go to the setup interface. Now there is a privacy zone in the screen centre.
Operate PTZ to move the camera screen so that the centre of the object you want to shield is overlaying
with the centre of the screen.
6. Thirdly, move the cursor to RESIZE and then click left and right key to adjust privacy zone direction and
size.
7. Fourthly, move the cursor to SAVE and then click confirm button to exit. Please note you need to click
SAVE button to save current privacy mask setup so that the privacy mask region can move along with
the PTZ movement to always cover the object you want to shield.
PRIVACY NO：This is to set the privacy mask zone. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set. You can call corresponding privacy mask zone numbers if you have
successfully set one up.
PRIVACY MASKING: There are two settings: on and off. Please go to the corresponding privacy mask zone
and click left/right button to set.
RESIZE：This is to adjust the privacy zone size. Move the cursor to current item and use the left/right
button on the keyboard or in the speed dome terminal menu to set .Please continue pressing direction
button to widen or narrow zone size. ← is to narrow the horizontal width and → is to widen the horizontal
width. ↑ is to widen vertical height and ↓ is to narrow the vertical height.
SAVE：Here is to save user setup.
BACK: Go back to previous menu.
EXIT: Log out system menu.
Power Up
Move the cursor to the POWER UP item and then click the confirm button, you can go to the fourth menu.
POWER UP: It is to set the PTZ operation when the speed dome boots up. The option includes:
NONE/AUTO/SCAN/PRESET/PATTERN/TOUR. Please use the left/right button to set.
19
ALARM NO ：1
ACTION ：NONE
PARAMETER ：NONE
CONTACT ：N/O
RELAY OUT ：OFF
RESET DELAY ：3S
SAVE
BACK EXIT
PARAMTER: Here you can set the serial number of the corresponding operation such as the scan, preset,
pattern, tour. Please use the left/right button to set.
BACK: Go back to the previous menu.
EXIT: Log out the system menu.
2.4.5 Alarm Setup
Move the cursor to highlight ALARM SETTING button and then click confirm button.
ALARM NO: This is to set the alarm input. Alarm input value ranges from 1 to 2. Please use the left/right
button on the keyboard or in the speed dome terminal menu to set.
ACTION: Action on alarm function. It includes NONE/PRESET/AUTO SCAN/TOUR functions. Please use
the left/right button on the keyboard or in the speed dome terminal menu to set.
PARAMETER: This is to set the corresponding alarm operation such as scan/preset/tour. Please use the
left/right button to set.
CONTACT：You can set system activation operation once alarm has been triggered. There are two alarm
signal mode: normal open (N/O) and normal closed (N/C). Please use the left/right button on the keyboard
or in the speed dome terminal menu to set.
RELAY OUT: This is to the set relay alarm mode and reset time. There are several options: off/1→5S.
RESET DELAY: This is for you to set the alarm reset time. Please use the left/right button on the keyboard
or in the speed dome terminal menu to set: 3 seconds/10 seconds/30 seconds/60 seconds /120seconds.
The dome will go back to previous setup after alarm acknowledgement.
SAVE：Move the cursor to SAVE and then click confirm button to save current setup.
BACK: Go back to previous menu.
EXIT: Log out system menu.
2.5 Abnormal Phenomenon Operation
2.5.1 Restore to Factory Default Setup
From Main menu-> SYSTEM INFORMATION, move cursor to FACTORY DEFAULT and click confirm button.
Camera will reboot and all the setups restore to factory default setup.
2.5.2 Irregular PTZ Movement
From menu to SYSTEM INFORMATION, move cursor to RESTART and click confirm button. This reboot will not
modify all activated setup (such as preset, tour and pattern)
20
3 Cable Connection
3.1 Combination Cable Connection
The camera’s combination cable includes network, audio/video cable port, RS485 connection port, alarm input
and output port connectors. Please refer to the label for detailed information.
Please note the Internet Explorer 6 does not support alarm upload function. Please use Internet
Explorer 7 or higher.
Name
Function
POWER
GND
Power port. Connect to the power cable.
GND: ground end.
485A
485B
GND
RS485 remote control.
AUDIO
OUT
Audio output port.
GND
Ground port.
IN
Audio input port.
VIDEO
GND
Ground port.
OUT
Video output port.
LAN
Network port. Connect to network cable.
ALARM
IN
Two alarm input channels. This is to receive relay signal from
the external alarm source. You can go to dome menu to
activate specified preset or pattern.
When the activation mode is NO (Normal Open), dome alarms
when there is low voltage. High voltage will not activate the
alarm.
When the activation mode is NC (normal close), dome alarms
when there is high voltage. Low voltage will not activate the
alarm.
Note:
Dome alarm input message is ground mode.
Dome alarm input signal has two modes: normal open and
normal close.
For the default setup: 2-channel alarm input and 7-channel
alarm output is optional.
GND
Alarm input ground end.
ALARM
OUT
1
One alarm output channel. When there is an alarm from current
channel, system activates relay or not.
Alarm output relay default setup is NO.
For the default setup: 1-channel alarm output and 2-channel
alarm output is optional.
21
4 FAQ
4.1 Daily Maintenance
Please clean dome cover regularly to get continue to receive vivid images. Handle the cover with care. Use
water to wash. Don’t use cloth to clean. Use mild detergent to clean if there is too much dust.
Note:
The sweat from your hand may erode plating surface, your nail may scrape dome cover resulting in blur image.
Please take care.
4.2 Problems and Solutions
SYMPTOM
CAUSE
SOLUTION
1) No self-diagnosis,
no video signal
when I connect
power to the
camera.
Red LED is not on.
Your power supply does not
apply any power. Or
connection is loose.
No power from mains or
transformer
problem/malfunction.
Check power is connected or
properly earthed.
Check power supply condition
or check transformer.
Red LED light on the power
board is on
Power supplying is too low
Something wrong with power
supply componentry.
Use multi-meter to check
dome load.
Please contact retailer to
replace power board.
2) No self-diagnosis
occurs.
Abnormal noises
heard coming from
camera.
Power supply is inadequate.
Replace power supply.
Mechanical malfunction.
Seek electrical engineer’s help.
3) Video signal loss
occurs during high
speed rotation.
Power supply is not sufficient
Replace power supply.
4) Video signal is
not successive
Circuit connection is loose.
Reset connection correctly.
Video switch or power problem
Seek electrical engineer’s help.
5) Video image is
not clear.
Focus function is set in manual
mode.
Control manually.
Dome cover is dirty.
Wash dome cover
6) During camera
switch, there is a tilt
movement in the
monitor.
Camera power is not in the same
Phase.
When several domes are
connected to one transformer,
please connect the transformer
output cable to the domes’ same
side.
Note
This manual is for reference only. Slight difference may be found in the user interface.
All the designs and software here are subject to change without prior written notice.
Please visit our website or contact your local service engineer for more information.
22
For more information about our DVRs and available cameras &
accessories, please visit our website:
www.adata.co.uk
Alternatively scan this QR code with your smart phone to be directed
instantly to our website:
Loading...
