Qvis APOIP-BL User Manual

APOIP-BL

1080P WDR BULLET IP CAMERA

User’s Manual

V1.0 08 / 2013

i

ii

Welcome

Thank you for purchasing the APOIP-BL 1080P WDR BULLET.

This user’s manual is designed to be a reference tool for the installation and

operation of your system.

Here you can find information about the corresponding IP camera’s features

and functions, as well as a detailed installation method.

Before installation and operation please read the following safeguards

and warnings carefully!

iii

Important Safeguards and Warnings

1．Electrical safety

 All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and

must make sure that the limited power source is rated 12V DC or 24V AC.

Please note: Do not connect two power supplying sources to the device at the same time; it may result in device damage!

 We assume no liability or responsibility for all the fires or electrical shock caused by improper

handling or installation.

 We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation Security

 Please ensure that the product does not endure heavy stresses, violent vibration or contact with

water during transportation, storage and installation.

 Please use the original packing material (or the material of the same quality) if you need to return it

to vendor.

3．Installation

 Do not apply power to the product before completing installation.  Do not put object(s) on the product.  Please install a proper power cut-off device during the installation connection.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers. We are not liable for any problems caused by unauthorised modifications or attempted repair.

5. Environment

 This product should be installed in a cool, dry place away from direct sunlight, inflammable,

explosive substances and etc.

 Please keep it away from environments that contain electromagnetic radiation or objects that

produce it.

 Please keep sound ventilation around the device at all times.  Do not allow the water and other liquid to penetrate into the device if casing has been

compromised. This series product complies with the IP66 standard specified in the Degrees of Protection Provided by Enclosure.

 Ensure lightning surge protection is in place to make sure you fully protect camera circuitry from

electrical overload.

iv

 Please make sure the CCD (CMOS) component is away from the radiation of the laser beam

device. Otherwise it may result in CCD (CMOS) optical component damage.

 It is recommended that the grounding studs of the product should be grounded, so to further

enhance the reliability of the camera.

6. Daily Maintenance

 Please shut down the device and then unplug the power cable before you begin any maintenance

work.

 Do not touch the CCD (CMOS) optic component. Please use an air jet to clean the dust off the lens

surface. You can use the dry cloth with some alcohol or mild detergent to clear if necessary.

 When the camera is not in use please put the dustproof cap to protect the CCD (CMOS)

component.

 Do not use volatile solvent such as the benzene, paint thinner or detergent with the ability to

abrade surfaces. It may result in lens damage or adversely affect the device’s performance.

7. Accessories

Always use all the accessories recommended by manufacturer.

Before installation, please open the package and check that all the components are included. Contact your local retailer/vendor ASAP if something is missing.

8. Box Contents:

Accessory Name

Amount

Network Camera Unit

1

Quick Start Guide

1

Installation Accessories Bag

1

12V to 24V Conversion Cable (For AC 24V series product only)

1 CD

1

v

Table of Contents

1 General Introduction ...................................................................................................... 1

1.1 Overview ........................................................................................................... 1

1.2 Features ............................................................................................................ 1

1.3 Specifications ................................................................................................ .... 2

1.3.1 Performance ............................................................................................... 2

1.3.2 Factory Default Setup ................................................................................. 4

2 Structure ...................................................................................................................... 19

2.1 Multiple-function Combination Cable............................................................... 19

2.2 Framework and Dimension ................................................................ ............. 20

2.3 Bidirectional talk .............................................................................................. 21

2.3.1 Device-end to PC-end............................................................................... 21

2.3.2 PC-end to the Device-end ......................................................................... 22

2.4 Alarm Setup ................................ ................................ ................................ .... 22

3 Installation ................................................................................................................... 24

3.1 Device Installation ........................................................................................... 24

3.2 Micro SD Card Installation .............................................................................. 25

3.3 Lens Adjustment ............................................................................................. 27

3.4 Bracket Adjustment ......................................................................................... 27

3.5 OSD Buttons ................................................................................................... 30

4 Quick Configuration Tool ............................................................................................. 31

4.1 Overview ......................................................................................................... 31

4.2 Operation ........................................................................................................ 31

5 Web Operation ............................................................................................................ 34

5.1 Network Connection ........................................................................................ 34

5.2 Login and Logout ............................................................................................ 34

6 FAQ ............................................................................................................................. 37

1

1 General Introduction

1.1 Overview

This network camera integrates traditional camera and network video technology. It adopts both audio and video data collection and transmission simultaneously. Because of inbuilt internal hardware it can connect to a network directly without any auxiliary device. When you want to access the camera, you can use a web browser running off the network at the client-end. Due to its multiple functions it allows for various use in many environments such office, bank, road & traffic monitoring, etc.

This series network camera product uses the latest industry standard H.264 video and G.711a audio compression technology, which guarantee the best audio and video quality whilst reducing file sizes.

One of the other main features this camera includes is the IR night vision, which aids in video surveillance when the camera is functioning within a low illumination environment. The LED IRs highlight objects of

interest within the camera’s field of view and is then able to filter out any visual interference so that you can

easily view footage upon a monitor. It supports real-time monitor and listening at the same time via the inbuilt microphone. If you want to communicate with a person(s) in view of the camera it also supports dualway bidirectional talk.

The built-in protection enclosure and waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for use in the outdoor environments.

1.2 Features

User

Management

 Different user rights for each group, one user belongs to one group.  The user’s right shall not exceed the group right.

Storage

Function

Supports:

 Central server backup function in accordance with your configuration and

setup in alarm or schedule setting

 Recording via the Web and sending the recorded file to the storage at the

client-end’s PC.

 Built-in Micro SD card.  Network storage function such as FTP.

Do not support:

 Local Micro SD card hot swap storage function. Only supports short-time

storage when it encounters a network disconnection.

Alarm

Function

 Real-time response to external on-off alarm input, and also video detects using

user pre-defined activation setup to generate a corresponding message on the screen and an audio prompt(the camera allows the user to pre-record the audio file)

 Real-time video detect: motion detect, camera masking.

Network

Monitor

 Network camera supports one-channel audio/video data transmission to

network terminal and then decodes signal. Delay is within 270ms (network bandwidth support needed)

 Supports a maximum of 20 connections.  Adopts the following audio and video transmission protocols: HTTP, TCP,

UDP, MULTICAST, RTP/RTCP, RTSP, etc.

 Supports web access.

2

Network

Management

 Allows network camera configuration and management via Ethernet.  Supports device management via web or client-end.

Power

 External power adapter DC12V/AC 24V. You can select which power adapter

according to your actual electrical environments. Please note system cannot support these two types of power supplying at the same time. As a recommendation, if you wish for your security system to be continue to run when there is a loss of power or unstable electrical supply coming from the mains, a UPS system should be installed.

Assistant

Function

 Log function  Supports system resource information and running status real-time display.  Day/Night mode auto switch.  Built-in IR light. Supports IR night vision.  Supports picture parameter setup such as electronic shutter and gain setup.  Backlight compensation: screen auto split allows backlight compensation to

adjust the brightness.

 Supports video watermark function to avoid vicious video modification.  The enclosure conforms to the IP66 protection testing. It can withstand a

variety of weather conditions and outdoor environments.

1.3 Specifications

1.3.1 Performance

Please refer to the following sheet for network camera performance specification:

Parameter

System

Main Processor

TI DaVinci high performance DSP

OS

Embedded LINUX

System Resources

Supports real-time network, local record, and remote operation at the same time.

User Interface

Remote operation interface such as WEB & PSS

System Status

Micro SD card status, bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/2.8-inch CMOS

1/3-inch CMOS

Pixel

2080(H)*15 53(V)

1920(H)*1080(V)

2080(H)*1 553(V)

1280(H)*960(V)

Day/Night Mode

Support day/night mode switch and IR-CUT at the same time. (The lens has built-in IR-CUT mechanical component.).

Auto Aperture

DC drive

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

On/Off

Exposure Mode

Manual/Auto PAL: It ranges from 1/3 to 1/10000 NTSC: It ranges from 1/4 to 1/10000

Video Compression Standard

H.264/ H.264B/MJPEG

Video Frame Rate

PAL: Main stream (1080P@25fps, SXGA@25fps, 1.3M@25fps,

720P@25fps, D1@25fps) Extra stream (D1@25fps, CIF@25fps).

3

NTSC: Main stream (1080P@30fps, SXGA@30fps,1.3M@30fps, 720P@30fps, 704*480@30fps)

Extra stream (704*480@30fps,352*240@30fps)

Video Bit Rate

H.264: 56Kbps-8192Kbps. MJPEG is adjustable and bit rate is adjustable. Support customized setup.

Video Flip

Support mirror. Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video Information

Channel title, time title, motion detect, camera masking.

Lens

Manual zoom 3.3-12 mm@F1.4

Motorize d zoom 3-9 mm@F1. 2

Manual zoom 3.312mm@F1.4

Motorized zoom 2.812 mm@F1.4

Lens Interface

Φ14 interface. Lens is the default accessories

Audio

Audio Input

1-channel. RCA

Audio Output

1-channel. RCA

Bidirectional Talk Input

Reuse the first audio input channel

Audio Bit Rate

16kbps 16BIT

Audio Compression Standard

G.711a/G.711u/PCM

Video

Motion Detect

396 (18*22) detection zones: sensitivity level ranges from 1 to 6 (The 6th level has the highest sensitivity) Activation event: alarm device, audio/video storage, image snapshot, log, email function and etc.

Alarm Input

2-channel input，1-channel output

Record and

Backup

Record Priority

Manual>External alarm >Video detect>Schedule

Local Storage

Support Micro SD card storage

Storage Management

Support display local storage status

Network

Wire Network

1-channel wire Ethernet port, 10/100 Base-T Ethernet

Network Protocol

Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP.

Remote Operation

Monitor, PTZ control, system setup, file download, log information, maintenance , upgrade, etc.

AUX

Interface

Video Output

1-channel analog video output，BNC port.

Restore Default Setup

Reset button

Power

Support AC24V/DC12V power. (Cannot support these two modes at the same time.)

Genera

l

Parame

Power Consumption

8W MAX (10W MAX when ICR switch)

Working Temperature

-10oC~+60oC

4

Working Humidify

10%~90%

Dimensions(m m)

φ104*306.7

Weight

1250g(Excluding box)

Installation

Bracket is included in the accessories bag.

IR Distance

20~30m

Protection Level

IP66

1.3.2 Factory Default Setup

Please refer to the following sheet for factory default setup information:

Setup

Item

Default Setup

Camera

Conditions

Brightness

50

Contrast

50

Saturation

50

Sharpness

50

Anti-flicker

Outdoor

Gain Adjust

0-50

Exposure Mode

Auto Auto Iris

On

Scene Mode

Auto

Day/night Mode

Auto BLC

Off

Mirror

Off

Flip

Off

3D NR

N/A

Off

N/A

Video

Video bit stream

Main Stream

Bit

stream

type

General

Encode

mode

H.264

Resolutio

n

1080P(1920*1080)

720P(1280*720)

Frame

Rate(FP

S)

PAL:25 NTSC:30

5

Setup

Item

Default Setup

Bit Rate

Type

CBR

Recomm

ended Bit

3584-8192 Kb/S

Bit Rate

8192

I Frame

50

Waterma

rk

Enable

Waterma

rk

character

Digital CCTV

Sub Stream

Enable

Bit stream

type

General

Encode

mode

H.264B

Resolutio

n

PAL:CIF(352*288) NTSC:CIF(352*240)

Frame

Rate(FPS

)

PAL:25 NTSC:30

Bit Rate

CBR

6

Setup

Item

Default Setup

Recomme

nded Bit

192-1024Kb/S

Bit Rate

1024

I Frame

50

Snapshot

Type

General


Size

1080P(1920*1080)

720P(1280*720)

Quality

Better

Interval

1s

Video Overlay

Privacy

Mask

Disable

Channel

Title

Enable

Time Title

Enable

Path

Snapshot

Path

C:\PictureDownload

Record

Path

C:\RecordDownload

7

Setup

Item

Default Setup

Audio

Main Stream

Enable

Encode

Mode

G.711A

Sub Stream

Enable

Disable

Encode

Mode

G.711A

Network

TCP/IP

Host

Name

IPC

Ethernet

Card

Wire(Default)

Mode

Static

Mac

Address

Device MAC address when it is shipped out of the factory

IP

Version

IPV4

IP

Address

192.168.1.108

Subnet

Mask

255.255.255.0

Default

Gateway

192.168.1.1

8

Setup

Item

Default Setup

Preferred

DNS

8.8.8.8

Alternate

DNS

8.8.8.8

Ena ble ARP /Pin g set devi ce IP addr ess serv ice

Enable

Connection

Max

Connecti

on

10

TCP Port

37777

UDP Port

37778

HTTP

Port

80

RTSP

Port

554

HTTPS

Port

443

PPPoE

Enable

Disable

9

Setup

Item

Default Setup

Usernam

e

none

Passwor

d

N/A

DDNS

Server

Type

Disable，CN99 DDNS

Server IP

none

Server

Port

80

Domain

Name

none

User

none

Passwor

d

****

Update

Period

10 minutes

IP Filter

Trusted

sites

Disable

SMTP(Email)

SMTP

Server

none

Port

25

10

Setup

Item

Default Setup

Anonymit

y

Disable

User

Name

anonymity

Passwor

d

****

Sender

none

Authentic

ation

N/A

Title

(Subject)

IPC Message

Attachme

nt

On

Mail

Receiver

N/A

Interval

0 second

Email

Test

Disable，interval=60 seconds

UPnP

Enable

UPnP

Disable

SNMP

SNMP v1

Disable

11

Setup

Item

Default Setup

SNMP v2

Disable

SNMP v3

Disable

SNMP

Port

161

Read

Communi

public

Write

Communi

private

Trap

Address

N/A

Trap Port

162

Bonjour

Enable

Server

Name

MAC

Multicast

Address

239.255.42.42

Port

36666

QoS

Real-time

Monitor

0

12

Setup

Item

Default Setup

Comman

d

0

Event

Video detect

Motion Detect

Enable

Disable

Anti-

dither

5 seconds

Sensitivit

y 3 Record

Enable

Record

Delay

10 seconds

Relay out

Enable

Alarm

Delay

10 seconds

Send

Email

Disable

Snapshot

Disable

Video Masking

Enable

Disable

Record

Enable

13

Setup

Item

Default Setup

Record

Delay

10 seconds

Relay out

Enable

Record

Delay

10 seconds

Send

Email

Disable

Snapshot

Disable

Alarm

Alarm Activation

Enable

Disable

Relay in

Alarm 1

Anti-

dither

0 second

Sensor

Type

NO

Record

Enable

Record

Delay

10 seconds

Relay out

Enable

14

Setup

Item

Default Setup

Alarm

Delay

10 seconds

Send

Email

Disable

Snapshot

Disable

Relay output

1

Abnormity

No SD Card

Enable

Disable

Relay out

Enable

Relay out

Delay

10 seconds

Send

email

Disable

Capacity Warning

Enable

Disable

Capacity

Limit

10%

Relay out

Enable

Relay out

Delay

10 seconds

15

Setup

Item

Default Setup

Send

Email

Disable

SD Card Error

Enable

Disable

Relay out

Enable

Relay out

Delay

10 seconds

Send

email

Disable

Disconnection

Enable

Disable

Record

Enable

Record

Delay

10 seconds

Relay out

Enable

Relay out

Delay

10 seconds

IP Conflict

Enable

Disable

Record

Enable

16

Setup

Item

Default Setup

Record

Delay

10 seconds

Relay out

Enable

Relay out

Delay

10 seconds

Storage

FTP

Enable

FTP

Disable

Server IP

N/A

Port

21

Usernam

e

anonymity

Passwor

d

N/A

Remote

path

share

Emergen

cy

(Local)

Disable

Record Control

Pack

Duration

8 minutes Pre-

reco rd

5 seconds Disk Full

Overwrite

17

Setup

Item

Default Setup

Rec ord Mod e

Auto

Rec ord Stre am

Main stream

System

General

Local Host

Device

No

Device MAC

Languag

e

English

Video

Standard

PAL

Date and time

Date

Format

Y-M-D

Time

Format

24H

Time

Zone

GMT+08:00

System

Time

Sync

DST

Disable

DST

Type

Week

Start

Time

00:00:00 of the first Sunday of the month

18

Setup

Item

Default Setup

End Time

00:00:00 of the second Monday of the month

NTP

Disable

NTP

Server

clock.isc.org

Port

37

Update

Period

10 minutes

Auto Maintenance

Auto

Reboot

Enable

Auto

Delete

Old Files

Disable

19

2 Structure

2.1 Multiple-function Combination Cable

You can refer to the following figure for multiple-function combination cable information. See Figure 2-1.

Figure 2-1 Multiple-function combination cable

Please refer to the following sheet for detailed information:

SN

Port Name

Function

Connection

Note

1

DC 12V/AC 24V

Power input port

/

Power port. Input DC 12V/AC 24V (Please use the provided conversion cable)

2

Reset

Reset port

/

Hardware reset function. Press it for 3 to 5 seconds; system hardware can restore default setup.

3

I/O

I/O port

/

Connect to I/O port.

4

LAN

Network port

Ethernet port

Connect to standard Ethernet cable.

5

AUDIO IN

Audio input port

RCA

Input audio signal. It can receive the analog audio signal from the pickup.

6

AUDIO OUT

Audio output port

RCA

Output audio signal to the devices such as the sound box.

7

VIDEO OUT

Video output port

BNC

Output analog video signal. It can connect to the TV monitor to view the video.

20

Please refer to the follow sheet for detailed Input/Output port information:

Port Name

SN

Name

Note

I/O Port

1

ALARM_COM

Alarm output public port.

2

ALARM_NO

Alarm output port. This outputs the alarm signal to the alarm device.

NO: normal open alarm output port. It works with the ALARM_COM port.

3

ALARM_IN1

Alarm input port 1. This receives the on-off signal from the external alarm source.

4

ALARM_IN2

Alarm input port 2. This receives the on-off signal from the external alarm source.

5

GND

Ground port

2.2 Framework and Dimension

Please note all frame and dimension illustrations provided in this chapter are for reference only, and actual product may vary.

Please refer to Figure 2-2 or Figure 2-3 for dimension information according to the actual product. The unit is mm. Please also see Figure 2-4.

Figure 2-2 Dimension illustration 1

21

Figure 2-3 Dimension illustration 2

Figure 2-4 Dimension illustration 3

2.3 Bidirectional talk

2.3.1 Device-end to PC-end

Device Connection

1. Please connect the speaker or the MIC to the audio input port of the device. Then connect the earphone to the audio output port of the PC.

2. Login to the Web and then click the Audio button to enable the bidirectional talk function.

3. You will see the button becomes orange after you enable the audio talk function.

4. Click Audio button again to stop the bidirectional talk function.

Listening Operation

At the camera device end, speak via the speaker or the pickup microphone, and then you can get the audio from the earphone or sound box at the pc-end.

22

2.3.2 PC-end to the Device-end

Device Connection

1. Connect the speaker or the MIC to the audio input port of the PC and then connect the earphone to the audio output port of the device.

2. Login to the Web and then click the Audio button to enable the bidirectional talk function.

3. You can see the button becomes orange after you enabled the audio talk function.

4. Click Audio button again to stop the bidirectional talk function.

Please note the listening operation is null during the bidirectional talk process.

Listening Operation

At the PC-end, speak via the speaker or the pickup microphone, and then you can get the audio from the earphone or sound box at the device-end.

2.4 Alarm Setup

The alarm interface is shown as in Figure 2-5. Please follow the steps listed below for local alarm input and output connection.

1. Connect the alarm input device to the alarm input port (No.3 pin or No.4 pin) of the I/O cable.

2. Connect the alarm output device to the alarm output port (No.2 pin) and alarm output public port (No.1 pin). The alarm output port supports NO (normal open) alarm device only.

3. Open the Web (please see Figure 2-5). Please set the alarm input 01 port for the first channel of the I/O cable (No.3 pin). The alarm input 02 is for the 2nd channel of I/O cable (No.4 pin). Then you can select the corresponding type (NO/NC.)

4. Set the WEB alarm output. The alarm output 01 is for the alarm output port of the device. It is the No.2 pin of the I/O cable.

Figure 2-5 Alarm

23

Please refer to the following figure for alarm input information (See Figure 2-6).

Alarm input: When the input signal is idle or grounded, the device can collect the different statuses from the alarm input port. When the input signal is connected to the 5V power or is idle, the device collects the logic ‘1’. When the input signal is grounded, the device collects the logic “0”.

Figure 2-6 Alarm input

Please refer to the following figure for alarm output information (See Figure 2-7).

Port ALARM_COM and Port ALARM_NO composes an on-off button to provide the alarm output.

If the type is NO, this button is normally open. The button becomes on when there is an alarm output.

If the type is NC, this button is normally off. The button becomes off when there is an alarm output.

Figure 2-7 Alarm output

24

3 Installation

Please note all frame and dimension illustrations provided in this chapter are for reference only, and actual product may vary.

3.1 Device Installation

Please refer to Figure 3-1 or Figure 3-2 for installation information according to the actual product. Please follow the steps listed below to install the device.

 Please draw the installation holes in the installation surface and then mark three expansion bolts

holes on the surface. Insert three bolts in the hole and secure firmly.

 Please line up the installation holes of the bottom of the pendant mount bracket to the installation

holes on the surface. Then insert the three bolts to the holes of the bottom of the bracket. Finally fasten the device onto the installation surface.

Figure 3-1 Device installation 1

25

Figure 3-2 Device installation 2

3.2 Micro SD Card Installation

Use the inner hex wrench from the installation accessories bag to remove the four inner hex screws from the rear cover. Please refer to Figure 3-3 or Figure 3-4 to find the Micro SD card slot position according to the actual product. Insert the Micro SD card and the fix the four screws back to the rear cover.

Important

 Please make sure the cable connection between the power board and the main board is firm.

Otherwise, it may result in device malfunction.

 The rear cover of the device is designed to be waterproof. Please secure four screws firmly after you

complete the Micro SD card installation.

(Go to next page for diagrams)

26

Figure 3-3 Micro SD card installation 1

Figure 3-4 Micro SD card installation 2

27

3.3 Lens Adjustment

Turn the lens counter clockwise to remove the cover, now you can see the iris front and rear control rod. The front control rod is to focus and the rear control rod is to zoom (see Figure 3-5). Please turn clockwise to fix the lens cover back firmly.

Important

 Please remove the sunshield first and remove the lens cover, if you cannot unfasten the lens cover.  The lens cover is designed to be waterproof. Please make sure it is secure after you complete the lens

adjustment.

 This IP camera product has the default motorised zoom lens. You do not need to adjust manually.

Figure 3-5 Lens adjustment

3.4 Bracket Adjustment

You can use an inner hex screw to control the bracket. Please use the inner hex wrench from the installation accessories bag to unfasten the screw. Please refer to Figure 3-6 or Figure 3-7 according to the actual product. The horizontal angle of the rear cover can rotate 360°, the tilt angle can rotate 90° and the chassis can rotate 360°.

Please use the inner hex wrench to firmly secure the M4 inner hex screw and the three M4 inner hex flat tight screws on bracket cover after you complete the setup.

Important: Please make sure the M4 inner hex screw or M4 inner hex flat tight screws are firm, otherwise it may result in chassis vibration and the camera will not be able to fix to a specified angle.

28

Figure 3-6 Bracket adjustment 1

29

Figure 3-7 Bracket adjustment 2

30

3.5 OSD Buttons

Please refer to the following contents for detailed information. See Figure 3-8 and Figure 3-9.

 Top button: Focus zoom in  Bottom button: Focus zoon out.  Left button: Far.  Right button: Near.  Middle button: Auto focus. It is to get clear video.

Figure 3-8 OSD button 1

Figure 3-9 OSD button 2

31

4 Quick Configuration Tool

4.1 Overview

Quick configuration tool can search current IP address and modify IP address. At the same time, you can use it to upgrade the device.

Please note: the tool only applies to the IP addresses in the same segment.

4.2 Operation

Double click the ‘ConfigTools.exe’ icon and you will see an interface just like the one shown as in Figure 4-1.

In the device list interface, you can view the device’s IP address, port number, subnet mask, default gateway, MAC address, etc.

Figure 4-1 Search interface

Select one IP address and then right click mouse, you will see an interface like the one shown in Figure 4-2.

Note: You can set the IP address, subnet mask and gateway for the network camera & PC. The network camera IP address and PC IP address should be in the same network segment if there is no router. Network camera default IP address is 192.168.1.108. If there is a router, please set the corresponding gateway and subnet mask.

The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login.

For detailed WEB operation, please refer to the Network Camera Web Operation Manual in the resource CD.

32

Figure 4-2 Search interface 2

Select the ‘Open Device Web’ item; you can go to the corresponding web login interface (see Figure 4-3).

Figure 4-3 Web login

If you want to modify the device IP address without logging in to the device web interface, you can go to the configuration tool’s main interface to set.

In the configuration tool’s search interface (Figure 4-1), please select a device IP address and then double click it to open the login interface. Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4.

In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login.

33

Please note the port information here shall be identical with the port value you set in TCP port in Web Network interface. Otherwise, you cannot login the device.

If you are using device background upgrade port 3800 to login, other setups are all invalid.

Figure 4-4 Login prompt

After you logged in, the configuration tool main interface is shown as below. See Figure 4-5.

Figure 4-5 Main interface

For detailed information and operation instructions of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.

34

5 Web Operation

This IP camera product supports the Web access and management using a PC.

Web includes several modules: monitor channel preview, system configuration, alarm, etc.

5.1 Network Connection

Please follow the steps listed below for network connection:

 Make sure the network camera has connected to the network properly.  Please set the IP address, subnet mask and gateway of the PC and the network camera

respectively. Network camera default IP address is 192.168.1.108. Subnet mask is 255.255.255.0. Gateway is 192.168.1.1

 Use order ping ***.***.***.***(* network camera address) to check connection is OK or not.

5.2 Login and Logout

1. Open web browser and input network camera address in the address bar.

For example, if your camera IP is 192.168.1.108, then please input http:// 192.168.1.108 into the web browser’s address bar. See Figure 5-1.

Figure 5-1 IP address

2. The login interface is shown as below. See Figure 5-2.

3. Please input your user name and password.

4. Default factory name is admin and password is admin.

Note: For security reasons, please modify your password after you first login.

Input your IP address here

35

Figure 5-2 Web login

If it is your first time logging in, the system pops up warning information to ask you whether to install the control ‘webrec.cab’ or not, after you have logged in for one minute. Please click OK button, the system can automatically install the control. When system is upgrading, it can overwrite the previous Web as well.

If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3.

Figure 5-3 IE security level

36

After you logged in, you can see the main window. See Figure 5-4:

Figure 5-4 Web monitoring window

37

6 FAQ

Bug

Solution

I cannot boot up the device.

Please press and hold the RESET button down for at least five seconds to restore factory default setup.

Micro SD card write times

Do not set the Micro SD card as the storage media to store the scheduled record file. It may damage the Micro SD card’s reliability.

I cannot use the disk as the storage media.

The HDD disk information details may show either ‘Hibernation’ or ‘Capacity is 0’, if it does please format it first (Via Web).

I cannot upgrade the device via network.

When network upgrade operation fails, you can use port 3800 to continue upgrade.

Recommended Micro SD card brand

Kingston 4GB, Kingston 1GB, Kingston 16GB, Transcend 16GB, SanDisk 1G, SanDisk 4G

Usually we recommend the 4GB (or higher) high speed card as the slower speed cards may result in data loss.

Audio function

Please use active device for the audio monitor input, otherwise there will be no audio coming from the client-end.

To guarantee setup update

After you modified the important setup, please reboot the device via the software to make sure the setup has been updated to the storage medium.

Power adapter

The general power adapter has been designed to work within the 0℃ to 40 ℃ temperature range. If the power supply is left in an environment where the temperature is outside this range, then the power supplied to the camera will become unstable.

Please replace with an industry-level power adapter if is to be used in a harsh environment.

I cannot fix the bracket firmly.

Please use the S3 inner hex wrench to secure the rear bracket firmly. After the installation please use your hands to test to see if the camera is firmly in place or not.

Note

 This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice.

38

For more information about our IP Cameras and other available

cameras, NVRs & accessories, please visit our website:

www.adata.co.uk

Alternatively scan this QR code with your smart phone to be directed

instantly to our website:

Qvis APOIP-BL User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
