6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
..
Quoizel,Inc.
6CorporateParkway
GooseCreek,SC
29445
CustomerService
Phone631.273.2700
Fax631.231.7102
www.quoizel.com
,.
ToolsRequired:None
BulbRecommended: (1)T3BiPinBulb50WMaximum(Supplied)
EstimatedAssemblyTime: 15-20minutes
Preparation: Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
AssemblyInstructionSheet#IS-TF9152Z
ForStyleTF9152Z
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstalling
thefixture.Westronglyrecommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocool
beforeremoval.DonotsubjectglasspartstoanyshockwhileinoperationorshatteringOctoberresult.
Donottouchthebulbwithbarehandsuseaclothorglove.
PackageContents
Part Description
A
B Tube
C
D
E
F
G
SocketAssembly
Base
LockBall
Diffuser
T3Bulb
Quantity
1pc.
1pc.
1pc.
1pc.Shade
2pcs.
1pc.
1pc.
A
B
D
E
F
G
C
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700
2013QuoizelInc. October2013
orvisituson-lineat www.quoizel.com
1of4
TF9152Z
FINISH:MEDICIBRONZE
5
4
3
2.5”
2
6” Dia.
50”
(1)50WT3BI
PINBULB
(Supplied)
1
2
3
4
5
99152ZTF
I816SC
G6220SH1
K142SWB
1
9” Dia.
20”
NOTE:ALLDIMENSIONSAREROUNDEDUPTOTHENEAREST1/2"
BASEHALOGENFLOORLAMPBRONZE
BULB50W120VHALOGNGY6.35CLEAR
GLASSTIFFANYTASKW/TABS
HI-LO-OFFSWITCHPOLISHEDBRASSREPLACEMENT
2of4
REQ.NO. REPLACEMENTPARTDESCRIPTIONPARTNUMBER
1
1
1
1
1LENSGLASS4-7/8X1/8SAFETYG262LEX
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
..
,.
AssemblyInstructionSheet#IS-TF9152Z
ForStyleTF9152Z
STEP1AssembleRodandSocket
-
Assembly
A.ThreadtheTube(B)andSocketAssembly(A)tothe
Base(C)asshown.Handtightenuntilsnug.
STEP2InstallShade-
A.AttachtheShade(D)totheSocketAssembly.Passthe
BoltsontheSocketAssemblythroughtheSmallHoles
onthebottomoftheShade(D).Securebythreadingthe
LockBalls(E)ontotheBolts.Handtightenuntilsnug.
Tube
SocketAssembly
Base
Figure1
Figure2
SocketAssembly
Bolt
SmallHole
STEP3- InstallBulb
A.ThisfixtureusesT3BiPinbulb.Maximum50watts.
B.Insertbulbandpushsnuglyintoplace.
IMPORTANT:
aclothorglove.
2013QuoizelInc.
Donottouchthebulbwithbarehandsuse
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700
orvisituson-lineat www.quoizel.com
Shade
LockBall
Figure3
Socket
Bulb
October2013
3of4
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
..
,.
AssemblyInstructionSheet#IS-TF9152Z
ForStyleTF9152Z
STEP4InstallDiffusertoShade-
A.
PasstheGapsontheDiffuser(F)overtheTabsonthe
Shade(D)andthenrotatetheDiffuser(F).Donotfree
yourhandsuntilthediffuserisseatedontothetabs.
Yourfixtureisnowassembledandreadytouse.
Enjoy!
Tab
Gap
Figure4
Shade
Diffuser
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700
2013QuoizelInc.
ThankyouforpurchasingaQuoizelproduct.
orvisituson-lineat www.quoizel.com
4of4
October2013
