Assembly Instruction Sheet #IS-TF1694TVK
For Style TF1694TVK
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone 631.273.2700
Fax 631.231.7102
www.quoizel.com
ToolsRequired:None
BulbRecommended: (2) Medium Base75W Maximum
EstimatedAssemblyTime:15-20 minutes
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering Augustresult.
Care of Tiffany Style Shade
A new tiffany lamp shade has an oil film applied to the shade that protects the tiffany shade from scratches
during shipment. If the oil applied is too heavy you can remove the excess oil film with a paper towel. Gently
wipe away the excess oil.
For general cleaning of tiffany shades use a gentle lemon oil-based furniture polish applied to a soft cloth and
wipe gently.
If a white powder appears on the soldered joints of the tiffany shade this is a normal oxidation process. Use a
small amount of lemon oil or mineral oil applied directly to oxidized areas and the soldered area will return to
like new.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2013QuoizelInc.
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
1of4
August2013
TF1694TVK
FINISH: VINTAGE BLACK
16” Sq.
2
7.5”
25.5”
15”
1
7.5” Dia.
(2) 75W Medium
Base Bulbs
(Not Supplied)
PART NUMBER
NO.
11694TVKTF BASE VINTAGE BLACK TF1694TVK 1
1
2
G3712SH
SHADE TIFFANY 16”SQ
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION
2of4
REQ.
1
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
..
,.
Assembly Instruction Sheet #IS-TF1694TVK
For Style TF1694TVK
Package Contents
Part
A
B
C
D
E
F
Description
Stem 5”L
Socket Assembly
Base
Finial
Flat Washer
Shade
STEP 1 Install Socket Assembly-
A. Thread the Socket Assembly (B) onto the nipple on the
top center of the Base (C). Hand tighten until snug.
Quantity
1pc.
1pc.
1pc.
1pc.
1pc.
1pc.
A
B
C
D
E
F
Socket
Assembly
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2013 Quoizel Inc.
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
3of4
Shade
Figure 1
August2013
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
..
,.
Assembly Instruction Sheet #IS-TF1694TVK
STEP 2 Install Stem-
A. Thread the Short Nipple end of Stem (A) into the
Coupling on the top center of the SocketAssembly (B).
Hand tighten until snug.
For Style TF1694TVK
Stem
Coupling
Socket Assembly
Figure 2
STEP 3 Install Shade-
A. Place the Flat Washer (E) and Shade (F) over the Stem
(A). Secure by threading the Finial (D) onto Stem (A).
Hand tighten until snug.
STEP 4 - Install Bulb
A. This fixture uses standard bulb with medium base .
Maximum 75 watts.
B. Insert bulb and screw snugly into place.
Finial
Shade
Flat Washer
Stem
Figure 3
Bulb
Socket
Your fixture is now assembled and ready to use.
Enjoy!
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2013 Quoizel Inc.
or visit us on-line at www.quoizel.com
Figure 4
August2013
4of4
