Assembly Instruction Sheet #IS-CKOR1735T
For Style CKOR1735T
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone 631.273.2700
Fax 631.231.7102
www.quoizel.com
ToolsRequired:None
BulbRecommended: (1) Medium Base 150W (3-way) Maximum
EstimatedAssemblyTime:15-20 minutes
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Part
A
B
C
D
Package Contents
Description
Harp
Base
Finial
Shade
Quantity
1pc.
1pc.
1pc.
1pc.
C
A
D
B
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2013 Quoizel Inc.
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
1of3
November2013
CKOR1735T
14” Dia.
13” Dia.
2
11”
31.5”
16”
1
6.5”Dia.
(1) 150W (3-way)
Medium Base Bulb
(Not Supplied)
PART NUMBER
NO.
11735TCKOR
1
2
S1586BR
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION
BASE TABLE LAMP CKOR1735T
SHADE FABRIC BROWN BELL 14"D
2of3
REQ.
1
1
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
..
,.
Assembly Instruction Sheet #IS-CKOR1735T
For Style CKOR1735T
STEP 1 Install the Harp-
A. Install the Harp (A) by pressing the ends of the Harp
into the Harp Clips on the Base (B) as shown.
STEP 2 - Attach Shade
A. Place the Shade (D) onto the top end of the Harp (A).
Secure by threading the Finial (C) onto the Harp (A).
Hand tighten until snug.
Figure 1
Harp
Harp Clip
Base
Finial
Shade
Harp
Figure 2
STEP 3 Install Bulb-
Figure 3
A. This fixture uses standard bulb with medium base.
Maximum 150 watts (3-way).
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to use.
Enjoy!
Bulb
Socket
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2013 Quoizel Inc. November2013
or visit us on-line at www.quoizel.com
3of3
