Assembly Instruction Sheet #IS-CKML1481T
For Style CKML1481T
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone 631.273.2700
Fax 631.231.7102
www.quoizel.com
ToolsRequired:None
BulbRecommended: (1) Medium Base 100W Maximum
EstimatedAssemblyTime:15-20 minutes
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Part
A
B
C
D
Package Contents
Description
Finial
Shade
Harp
Fixture Body
Quantity
1pc.
1pc.
1pc.
1pc.
A
B
D
C
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2012 Quoizel Inc.
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
August 2012
1of3
CKML1481T
FINISH: CUSTOM
12.5” 17”
12”
34.5”
21”
(1)100W
Medium Base Bulb
(Not Supplied)
PART NUMBER
NO.
1
2
3
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION
2of3
REQ.
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
..
,.
Assembly Instruction Sheet #IS-CKML1481T
For Style CKML1481T
STEP 1 - Install Harp
A. Locate the Harp (C) by pressing the ends of the Harp
(C) into the Harp Clips on the top of Base (D).
STEP 2 Assemble Shade-
A. Place Shade (B) over the top end of the Harp (C).
Secure by thread the Finial (A) onto the Harp (C). Hand
tighten until snug.
Figure 1
Harp
Harp Clip
Base
Finial
Shade
STEP 3 Install Bulb-
A. This fixture uses standard bulbs with medium screw
bases. Maximum 100 watts.
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to use.
Enjoy!
Harp
Figure 2
Bulb
Socket
Figure 3
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2012 Quoizel Inc.
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
August 2012
3of3
