Quoizel ALZ1507PN User Manual

6 CORPORATE PARKWAY GOOSE CREEK SC 29445 www quoizel com
..
Quoizel, Inc. 6 Corporate Parkway Goose Creek, SC 29445
Customer Service Phone 631.273.2700 Fax 631.231.7102 www.quoizel.com
,.
Assembly Instruction Sheet #IS-ALZ1507PN
For Style ALZ1507PN
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wire cutters, wire
strippers,electricaltape,safety glasses.
BulbRecommended: (1) MediumBase100WMaximum EstimatedAssemblyTime: 20-30minutes
Preparation:Identifyandinspect all partsbeforebeginninginstallation. Check package
contentlistanddiagrams below tobesureall parts arepresent.Ifany parts aremissing ordamaged,donot attempt toassemble,install,or operate thefixture.Contactcustomer serviceforreplacementparts.
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Package Contents
Part
A Crossbar
C
D
F
G
H
I
J
L
Description
Mounting Screw
Lock Washer
Hex Nut
Mounting Ball
Ceiling Canopy
6” Rod
12” Rod
Socket Assembly
Shade
Socket Collar
Socket Collar Tool
Quantity
1pc.
2 pcs.
2 pcs.
2 pcs.
2 pcs.
1pc.
2 pcs.
2 pcs.
1pc.
1pc.
1pc.
1pc.
C
D
F
G
H
I
J
L
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
2011 Quoizel Inc.
Thank you for purchasing a Quoizel product.
or visit us on-line at www.quoizel.com
1of6
September2011
ALZ1507PN
FINISH: PALLADIAN BRONZE
6”
12”
6.5" Dia.
2.4mm 13Ga
QUOIZEL
GND
R
3.5"
50”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
(1)100W A19
Medium Base Bulb
(Not Supplied)
PART NUMBER
NO.
1
2
3
9006EXPN
9012EXPN
G2970SH
6.5" Dia.
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION
ROD EXT PALLADIAN BRONZE 6"L X .5"D
ROD EXT PALLADIAN BRONZE 12"L X .5"D
SHADE GRADIEN AMBER MIST GLASS
2of6
10.5"
5.5"
REQ.
2
2
1
