Remote Management Session Server
• Provides transparent remote network management for
Tenors deployed behind NAT firewalls
• Provides a secure centralized management interface
• Supports configuration, monitoring, troubleshooting,
and system upgrades for remote Tenors
• Supports the Tenor Configuration Manager GUI and
the Tenor CLI interface
• Supports static or dynamic IP addresses at the enterprise
Simplify Configuration and Management of Remotely
Deployed Tenor VoIP MultiPath Switches
To keep VoIP service running smoothly over your
network, you need immediate access to all of your
Tenor switches – whether they’re around the corner or
around the world. Quintum’s Remote Management
Session Server, provides this critical capability by
allowing you to easily and securely manage all of your
distributed Tenor VoIP switches from a single, intuitive
application. It provides the complete system configuration, diagnostics, troubleshooting and remote upgrade
functionality you need to maintain and optimize the
health of VoIP services – even if you have to manage
Tenor switches that are behind NAT firewalls.
When a Tenor is put on a network, it will signal the
Remote Management Server through the NAT firewall
to register its identity and the external address through
which it can be contacted. The Remote Management
Session Server can then at any time signal a Tenor
behind a NAT firewall to set up a secure session
between itself and the RMSS. The RMSS has thus
established a secure tunnel between the Tenor and
itself, through the NAT firewall, which allows the Tenor
to be configured and managed remotely.
Whether you’re an Enterprise, Value Added Reseller, or
Service Provider, the Remote Management Session
Server allows you to remotely install and manage Tenor
switches at your clients’ or customers’ site – any time –
anywhere. It also avoids enterprise router/firewall
configuration changes or unnecessary truckrolls to
support installations. This simplifies installation and
maintenance, reduces the time to identify and resolve
problems, and greatly improves customer satisfaction.
Remote Management Session Server is:
Scalable
The Remote Management Session Server can register up to
5,000 remote devices, and can enable management of up
to 100 Tenors simultaneously.
Flexible
Tenors can be remotely managed via telnet, FTP or through
Quintum’s own graphical Tenor Configuration Manager.
Reliable
Each Tenor switch can be registered with two separate
Remote Management Session Servers to provide redundancy.
Secure
All communications between the Remote Management
Session Server and remote Tenor switches are encrypted
to ensure network security.
Easy to implement
For added convenience and ease of implementation, the
Remote Management Session Server comes pre-installed
on a Quintum Application Server Platform.
Easy to use
Remote Management Session Server’s intuitive interface
design makes everyday management functions fast and easy.
Network administrators can be alerted by E-mail from the
Remote Management Session Server when specific Tenor
Switches register and are ready for remote management.
Remote Management Session Server
SYSTEM REQUIREMENTS
For secure GUI management: Quintum Tenor Configuration Manager
For secure CLI management: SSH Client
For unsecured FTP access: Standard FTP client
For secured FTP access: SSH client with SOCKS v.4 server support and
FTP client with PASV mode and compatible SOCKS client
TECHNICAL SPECIFICATIONS
Item Enterprise
Ethernet (IEEE 802.3) 10/100 Mb Auto-sensing
LAN connector 1 x RJ45
Power Supply 100 – 240 Vac, 50/60 Hz
Power Consumption 250 Watts max.
Chassis Height (1U) 1.75” (4.5 cm.)
Chassis Width (19” Rack Mounting) 16.75” (42.6 cm)
Chassis Depth 14” (35.6 cm.)
Weight 12 lbs. (5.5 kg)
Operating Temperature 40º F (5º C) – 104º F (40ºC)
Storage Temperature 14º F (-10º C) – 140º F (60º C)
Operating Humidity 20% - 80% non-condensing
Altitude -200 – 10,000 ft. (-60 m – 3,000 m)
EMC Certification FCC Part 15 Class A
EN55022:97, EN55024:98
EN61000-3-2&-3-3:95
AS/NZS 3548:1995
Safety Certification EN60950:92 +A1:92+A2:93+A3:95+A4:96
Monitor Interface 15 pin VGA
Keyboard Interface USB or PS2
71 James Way, Eatontown, New Jersey 07724
1-877-SPEAK-IP .Tel 732.460.9000 .Fax 732.544.9119
www.Quintum.com
Rev. 4
