Model Series 160

A U T I O N

C A U T

I O N

Plastic Forming Strip Heaters

Quincy Lab, Inc.

Specifications

Overall Dimensions

INCHES W x H x D

(CM) W x H x D

Working Area

Weight (lbs)

SHIPPING

STAND ALONE

WORK SURFACE MAY BE HO

CAU

TION

T

T

AUTION

URFACE MAY BE HO

03-160

OPERATING MANUAL

CAUTION

AND EXPOSED ELEMENT

MODEL

03-160

SHOWN

MODEL

MODEL

13-160

15.125x5.5x7.25 25x5.5x7.25

38.45x14x18.4 63.5x14x18.4 91.4x14x18.4

12"

7 lbs

6 lbs

21"

9 lbs
7 3/4 lbs

HOT SURFACES

MODEL

23-160

36x5.5x7.25

33"

12 lbs

10 1/2 lbs

Standard Electrical*

VOLTS / WATTS

AMPS

* Working Max Operating
Temperature Range (F)

* Measured with workpiece in place - (varies with piece size and length).

115 / 125

1.08

o

/ 410

325

o

115 / 200

1.72

o

/ 435

340

115 / 350

3.02

o

325

o

/ 410

o

Common Unit Construction

Exterior: Powder-Coated Steel Plug/Cord Assy: UL SJOW 18/3
Power Controls: On/Off Toggle & Power Light Heater: Resistive-Tubular Incoloy

Safety Precautions

Read Operating Instructions Thoroughly Prior to Operation

Read Operating Instructions thoroughly prior to operation. Use only a grounded outlet that is rated for
your models' electrical requirement. Conduct periodic maintenance as required. CAUTION:
EXPOSED ELEMENT - Operate unit well away from flammable solvents, gasses and materials.
Operate on non-combustible surface only.

Receiving

After unpacking, verify receipt of correct quantities of each component and that each component has
not suffered any shipping damage. If there are any problems, please refer to the enclosed

Damaged/Missing Item Report.

Issue Rev A 0908
Copyright Quincy Lab Inc. 2008

Quincy Lab Inc. 1925 N. Leamington Ave. Chicago, Illinois 60639 1-800-482-HEAT (4328)

PAG E 1

Set-up

C

A U T

I O N

Place the unit face down on a work surface.

Separate the legs of the "no-skid" foot cover strips and place over
the exposed bottom edge of each end cap. FIG. 1

Place the unit upright, with the exposed element facing up and
plug the unit into a grounded outlet. Turn the unit on and allow it to
come up to the operating temperature (approx. 10-12 minutes).

General Operation

FIG. 1

Place the plastic workpiece to be formed on the work
surface with the area to be formed over the element. Turn
the piece over at regular intervals. This will ensure that the

Product Guides

WORK SURFACE MAY BE HOT

CAUTION

plastic is heated evenly throughout its thickness and that it
is not overheated, causing the plastic to bubble or even
scorch. Product guiderails are provided on each side of the
unit to help keep part perpendicular to heating element for
accurate heat-through. Various types of plastics, as well as

Work Piece

thicknesses, will require different heat-through times before
it can be formed. Trial and error testing of scrap pieces will
ensure the best possible results for the actual parts.

FIG. 2

Maintenance

Unit should be turned off and let stand to allow heating element to cool to room temperature before
cleaning. Clean exterior surfaces with a damp cloth or with an all-purpose cleaner. Only area around
heating "element well" should be cleaned. Do not get cleaning solutions on actual heating element
surface. Heating element area should be kept free from all debris at all times to eliminate the risk of fire.

Tech Support

If you have any questions or need technical assistance, please contact Quincy Lab customer support at

Voice: 800-482-HEAT Quincy Lab, Inc.
Fax: [phone] 1925 North Leamington Avenue
Email: [e-mail] Chicago, Illinois 60639

Replacement Components - Model's: 03-160, 13-160, 23-160

COMPONENT MODEL PART NUMBER COMPONENT MODEL PART NUMBER

Replacement Element

Replacement Element

Replacement Element

03-160

13-160

23-160

1212-03

1212-13

1212-23

Indicator Lamp

Toggle Switch

6' Cord & Plug

115V 18GA/3 wire

Universal

Universal

Universal

101-2202

301-2251

101-1803

Limited Warranty

Quincy Lab, Inc. warrants to the original purchaser that this product will be free from defects in material
and workmanship under normal use throughout the warranty period. The standard warranty period for

this instrument is 18 months, (3-year coverage on the heater element), from date of
shipment. Please refer to your invoice or shipping documents to determine the
effective warranty period. This warranty covers parts and labor (labor at factory
only), and shipping cost for replacement parts.

PAG E 2
