Page 1
Single Stage Compressors
Instruction & Parts Manual
This manual contains important safety information and must be
carefully read in its entirety and understood prior to installation
by all personnel who install, operate and/or maintain this product.
Manual No. 1312100602
September 2012 Edition
Page 2
WARRANTY
Quincy Compressor Reciprocating Products
Single Stage Compressors
What does this warranty cover?
Quincy Compressor (the Company) warrants this compressor to be free from defects in materials and workmanship for a period of one
year from date of purchase.
What are the Company's obligations under this warranty?
In the event this compressor proves to be defective during the warranty period, the Company will, at its sole option, either repair or
replace this compressor. The Company and its authorized agents may use, at their discretion, reconditioned units when undertaking
such repairs or replacement. Repaired or replacement units shall be warranted hereunder for the remainder of the warranty period
applicable to the original compressor, or ninety (90) days, whichever is greater.
How do you get service?
Contact your local Quincy distributor, or call the Company's Service department at (217) 222-7700, for directions to the nearest authorized warranty repair center. In order for you to be eligible to utilize this warranty, Company must have received a completed warranty
registration card within thirty (30) days of your purchase of this compressor or, at the time service is requested, you must be prepared
to provide proof of purchase in the form of a receipt or invoice. All moving, shipping and insurance charges incurred by you to deliver
this compressor to the nearest authorized warranty repair center shall be paid by you and shall be your exclusive responsibility. All
risk of loss or damage to your compressor in transit shall remain with you until such time as Company or its authorized agents take
receipt of your compressor.
What does this warranty not cover?
This warranty is contigent upon proper use of the compressor by purchaser and does not cover:
(A) Abnormal conditions, accident, neglect, misuse or improper storage of the unit.
(B) Deviation from operating or maintenance instructions.
(C) Modications not authorized by the Company.
(D) Repairs or maintenance (other than routine air tank draining and air lter changes required by your operating and maintenance
manual) made by persons other than Company or its authorized agents.
What are the limits of Company's Liability?
The warranty given herein, together with any implied warranties covering this compressor, including warranties of merchantability or
fitness for a particular purpose are limited in duration to one year from the date of purchase, and no warranties, whether express or
implied will apply after this period. Some states and provinces do not allow limitations on how long an implied warranty lasts, so the
above limitations may not apply to you.
If this compressor is not in good working order as warranted above, your sole remedy shall be repair or replacement as provided above.
In no event will Company be liable to you for any damages, including any lost prots, lost savings or other incidental or consequential
damages arising out of the use or inability to use such compressor, even if Company or your place of purchase has been advised of the
possibility of such damages.
This warranty gives you specic legal rights and you may also have other rights which vary from state to state or province to province.
TABLE OF CONTENTS
SAFETY ....................................................................1
DESCRIPTION & APPLICATION .............................2
INSTALLATION .........................................................2
SYSTEM COMPONENTS .........................................4
PRE-STARTING CHECKLIST ..................................6
STARTING & STOPPING THE COMPRESSOR ......6
MAINTENANCE ........................................................6
TROUBLESHOOTING ..............................................9
COMPRESSOR UNIT PARTS ................................13
DECALS & DIMENSIONS ......................................15
SAFETY
“DANGER!”, “WARNING!”, and “CAUTION!”
are displayed in large bold capital letters to call
attention to areas of vital concern. They represent
dierent degrees of hazard seriousness, as stated by
the following:
1312100602, September 2012 1 3501 Wisman Lane, Quincy IL - 62305-3116
DANGER !
Immediate hazards which will re sult in severe personal injury or death.
WARNING !
Hazards or unsafe practices that could result in
personal injury or death.
CAUTION !
Hazards or unsafe practices which could result in
minor personal in jury, product or property damage.
Quincy Compressor
Page 3
This instruction manual, and any instructions
supplied by manufacturers of supporting equipment,
should be read and understood prior to assembling,
starting or disassembling the compressor. Be thoroughly familiar with the controls and proper use of
this equipment. If there are any questions, please
call your local Quincy distributor.
Safety Precautions
•Relieve the system of all pressure before servic ing
any part of the unit.
•Allow ample time for the compressor to cool before
performing service procedures. Some surface
temperatures exceed 350°F when the compressor is operating.
•All installation, maintenance and repair work
must be performed by a qualified technician or
electrician.
•Do not remove or paint over any DANGER!,
WARN ING!, CAUTION!, or instructional materials at tached to the compressor.
•Periodically check all pressure relief valves for
proper op eration.
•Do not change the pressure setting of the pressure
relief valve, re strict the function of the pressure
relief valve, or replace the pressure relief valve
with a plug.
•Do not install a shutoff valve in the compressor
discharge line with out first installing a pres sure
relief valve of proper size and design be tween the
shuto valve and the compressor.
•Do not make alterations to this compressor.
•Do not operate the compressor in excess of its 135
p.s.i. service rat ing.
•Prior to use, make a general overall inspection of
the unit and correct any unsafe situations. All
fasteners must be kept tight.
•If for any reason any part of the manual be comes
illegible or the manual is lost, have it re placed
immediately. The instruction manual should be
read periodically to refresh one’s memory.
•Wear safety glasses and hearing protection during
operation, service & maintenance proce dures.
personal injury, damage to property, and may void
your warranty. Quincy Compressor must authorize all
warranty service. Before contacting your distributor
or the factory, check the maintenance requirements
and the troubleshooting guide for your compressor.
Most warranty issues can be resolved by following
proper maintenance procedures.
Quincy Compressor neither states as fact, nor
in any way implies that the above list of safety precautions is an all inclusive list, the observance of
which will prevent all damage to property or in jury
to personnel.
Every effort has been taken to ensure that complete and correct instructions have been in cluded
in this manual. However, possible prod uct up dates
and changes may have occurred since this printing.
Quincy Compressor re serves the right to change
specifications with out incurring any obligation for
equipment previ ously or subse quently sold.
DESCRIPTION
& APPLICA TION
Air Master Series single stage compressors are aircooled and splash lubricated. It is the installers
responsibility to meet the appropriate codes and
regulations for this type of installation.
INSTALLATION
Air Master Series air compressors should be operated in a secure upright position and located in an
area that is clean, dry, well lighted, and adequately
ventilated. The compressor belt guard must not be
located closer than 18 inches to a wall, or 24 inches to
an other compressor. Additional safety can be achieved
by locating the pulley drive system, with the guard,
next to the wall. Do not allow hot air from additional
equipment to blow towards the compressor.
It is recommended that the compressor be operated in temperatures under 104°F and over 32°F. In
cold climates, the compressor should be in stalled in
a heated building.
DANGER !
Air used for breathing or food processing must meet
OSHA 29 CFR 1910.134 or FDA 21 CFR 178.3570
regula tions. Failure to do so may cause severe injury
or death.
The owner, lessor or operator of any compressor
unit sold by Quincy Compressor is hereby warned that
failure to ob serve the safety precautions and procedures outlined in this manual may result in serious
1312100602, September 2012 2 3501 Wisman Lane, Quincy IL - 62305-3116
DANGER !
Under no circumstances should a compressor be
used in an area where toxic, volatile, or corrosive
agents are used or stored near the compressor.
Noise
Federal and local laws govern acceptable noise levels;
should a question about noise levels arise, check with
local ocials for specications.
Quincy Compressor
Page 4
CAUTION !
Unusual noise or vibration indi cates a problem. Do
not operate the compressor un til the source has
been identi ed and corrected by a qualied technician.
WARNING !
Never assume a compressor is safe to work on
just be cause it is not operating. It could restart at
any time. Fol low all safety precautions outlined in
MAINTENANCE.
Electrical Information
The installation, electric motor, wiring, and all electrical controls must be in accordance with Na tional
Electric Code, National Electric Safety Code, Canadian Electric Code, state and local codes. Failure
to abide by the na tional, state and local codes may
result in physical harm and/or property damage. All
electrical connections must be performed by a qualied electrician. Note: This unit must be grounded.
CAUTION !
Verify all wires are secure
and fasteners are torqued
before connecting power to
the unit.
Connect 230 Volt Power Here
Overload Relay Protection
(if so equipped)
An overload relay will stop the unit if the motor
becomes overheated. (Causes for overheating of the
motor can be found in TROUBLESHOOTING.) Once
the overload relay has been tripped, the motor must
cool and the red overload button on the motor must
be reset be fore the unit will start.
CAUTION !
Overload relays are designed to protect the motor
from damage due to motor overload. If the overload
relay trips persistently, DO NOT CONTINUE T O PUSH
THE RESET BUTTON! Contact your local Quincy
distributor for assistance.
Extension Cords (portable units)
To avoid power loss and overheating of the motor, use
of additional air hose is recommended rather than
an exten sion cord. If an extension cord is to be used,
it must be a 3 wire cord with a 3 prong plug. Refer
to the following chart to determine the wire gauge
required in relation to the cord length:
Cord Length Wire Gauge Size
up to 25 ft. 14-12 ga.
up to 100 ft. 10 ga.
Connect Ground Wire to Ground Screw
Do not operate this compressor more than 10° off
level or move it while it is running.
Fig. 1 Electrical Connections for Model Q13160V
CAUTION !
Mounting Stationary Units
Some Air Master compressors are equipped with
an electrical supply cord. Do not modify the cord!
If the plug will not fit the outlet, have the correct
outlet installed by a certied electrician.
Air Master compressors not equipped with a power
cord must be wired in accordance with the NEC and
all state and local codes and ordinances (see Fig. 1).
DANGER !
High voltage may cause personal injury or death.
Dis connect and lockout/tagout per OSHA regulation
1910.147 all electrical power supplies before opening
the electrical enclosure or servicing.
1312100602, September 2012 3 3501 Wisman Lane, Quincy IL - 62305-3116
Proper mounting of Air Master compressor units
is crucial to the safe operation and longevity of the
equipment.
WARNING!
The compressor unit must be removed from the
shipping skid prior to installation.
The installation requires a flat and level concrete
floor or pad. All vertical stationary tank units
must be anchored! Quincy recommends that all
vertical tank units be mounted as indicated without
isolators ( See Fig. 2).
State or local codes may mandate that the com-
pressor be bolted to the floor. In this case the unit
Quincy Compressor
Page 5
Check Valves
ANCHORED
1/2” oor stud
(provided by customer)
tank foot
1/2” locknut
1/2” at washer
Check valves are designed to allow air to ow freely in
one direction only. A properly sized check valve must
be provided. Do not rely on a check valve to isolate a
com pressor from a pressur ized tank or com pressed
air delivery system dur ing maintenance proce dures.
Pressure Regulator
This type of valve allows the operator to control the
air pressure setting of the compressor discharge. A
gauge is provided to indi cate the air pressure.
Fig. 2
Anchoring Vertical Tank Units
must be leveled and bolted making absolutely certain
the feet are not stressed in any manner. Leave the
locknut loose! Uneven feet drawn tightly to the
concrete pad will cause severe vibrations resulting
in cracked welds or fatigue failure. The customer is
responsible for pro viding a suitable foundation &
isolator mounting where necessary.
The compressed air supply line from the tank of
a stationary unit must be equipped with a pressure
and temperature rated exible connection.
SYSTEM COMPONENTS
Drive Pulleys / Flywheels
Drive pulleys and compressor ywheels must be properly aligned and tensioned to specications. Refer to
Belt Alignment & Adjustment.
WARNING !
Excessive compressor RPM’s could cause a pulley
or ywheel to shatter, possi bly causing bodily harm
or death. Do not operate the compressor above
the rec om mended RPM. (Refer to DESCRIPTION &
APPLICA TION).
Pressure Relief Valves
Pressure relief valves aid in preventing system failures by relieving system pressure when com pressed
air reaches a predetermined pressure level. All air
receivers must be equipped with an adequately sized
pressure relief valve. This type of valve is preset by the
manufacturer and must not be modi ed in any way.
Pressure relief valves are to be placed ahead of
any po tential blockage point which includes, but not
limited to, shutoff valves, heat exchangers, pulsation dampeners, and discharge silencers. Ideally the
pressure relief valve should be threaded directly into
the pressure point it is sensing, not connected with
tubing or pipe, and always pointed away from any
chance bystander.
WARNING !
Pressure relief valves must be pro vided to protect
com pressed air systems in ac cordance with ASME
B19 safety standards. Failure to provide properly
sized pres sure relief valves may cause property
damage, severe per sonal injury or even death.
WARNING!
Do not use plastic pipe (PVC) anywhere in a compressed air system. Serious injury or death could
result.
Guards
Guards must be designed and mounted in compliance with OSHA safety and health standards 29
CFR 1910.219 in OSHA manual 2206, and any state
or local codes. They must provide protection from
moving parts while still al lowing full air flow for
cooling purposes.
WARNING !
Guards must be fastened in place before starting
the com pressor. Always disconnect and lockout
the power supply to the unit before removing the
guard.
Quincy Compressor
1312100602, September 2012 4 3501 Wisman Lane, Quincy IL - 62305-3116
Compressor Controls
Start/Stop
Electric motor powered units are equipped with a
pressure switch as standard equipment for start/
stop operation. The pressure switch (when set to the
“auto” position) re acts to the demand for compressed
air and allows the motor to start. When the de mand is
satisfied, the unit stops. Pressure switches pro vided
by Quincy Compressor are preset at the factory and
should only be modified by a qualified technician.
Pressure switches equipped with an OFF/AUTO knob
(refer to Fig.4) should be set to the “OFF” position
Page 6
when connecting or disconnecting the power cord
from the electrical outlet or when changing air tools.
This system provides a loadless start feature. A
release valve on the pressure switch opens when
the unit shuts down and bleeds off pressure in the
discharge line. The check valve holds pressure in
the tank.
WARNING !
Follow ASME code for air receiver tanks and other
pressure containing vessels. Pressure vessels must
not be mod ied, welded on, or re paired. Such actions may cause property dam age, se vere injury,
or even death. Always replace worn, cracked or
damaged tanks.
Air Intake
A clean, cool, dry, air supply is essential to the satisfactory operation of your Air Master compressor.
WARNING !
Never locate the compressor where toxic, volatile
or cor rosive vapors, air tempera tures exceeding
104°F , wa ter, or extremely dirty air could be ingested.
The compressor could be damaged by these atmospheres and result in in jury or death.
When using the compressor for spray painting,
isolate the compressor as far away from the work
area as practical, employing extra air hose rather
than an extension cord.
Warranty will be void if a failure is determined to
be caused by dust, dirt or other contaminants.
Compressed Air Discharge System
All parts of the discharge piping should t so as not to
create any stress between the piping and connections.
WARNING !
Discharge piping can exceed 350°F when compressor is operating. Do not use plastic pipe or lead tin
soldered joints for a discharge line.
Pressure Vessels
Air receiver tanks and other pressure contain ing
vessels must be equipped with a properly sized pressure re lief valve, pressure gauge, and a tank drain.
Manual Tank Drain Valve Operation
The manual tank drain valve on portable compressors and some stationary compressors is located on
the underside of the air tank. Portable compressors
can be tilted in the direction of the drain to allow
removal of tank moisture.
Safe removal of tank moisture from the tank is
dependent upon an internal tank pressure of 20 to
30 PSIG. Higher tank pressures are dangerous and
could cause serious injury!
WARNING!
Do not open a manual tank drain valve on any air
tank containing more than 30 PSIG of air pressure!
WARNING!
Never attempt to relieve an air tank by removing a
pipe plug or any other system component!
Manually Draining An Air Tank:
Tank(s) subjected to freezing temperatures may
contain ice. Store the compressor in a heated area
before attempting to drain moisture from the tank(s).
Step 1) Disconnect and lockout the compressor from
the power source.
Step 2) Reduce the air pressure in the tank to 30
PSIG by pulling the pressure relief valve
ring (see Fig. 3).
WARNING!
Oil and moisture residue must be drained from the
air receiver daily or after each use. Accumulations
of oil residue in the receiver can be ignited by embers of carbon created by the heat of compression,
causing an explosion, damage to property and injury
to personnel.
Quincy Compressor
1312100602, September 2012 5 3501 Wisman Lane, Quincy IL - 62305-3116
Fig. 3 Checking Pressure Relief Valves
& Relieving System Pressure
Step 3) Position yourself so that the moisture and
air to be expelled can not cause you harm.
Page 7
Step 4) Slowly open the drain valve and allow the
moisture and air mixture to drain from the
tank.
Step 5) Once the moisture has been completely
drained, close the drain valve.
Air Tank Inspection
Quincy Compressor recommends that all air tanks
be inspected at scheduled intervals. Refer to Fig. 4
Recommended Air Tank Inspection Intervals for
relative information. Measure tank wall thickness at
several locations, including the lowest point where
condensation can accumulate.
Step 3)
Be sure all guards are in place and securely
mounted. (Refer to SYSTEM COMPONENTS)
Step 4) Check all hoses and ttings for weak or worn
conditions and replace if necessary.
Step 5) Check fuses, circuit breakers, and overload
relays for proper sizes.
Step 6) Open the tank drain valve in the bottom of
the tank.
STARTING & STOPPING
Horizontal
Tank
Capacity
20 Gal. Horizontal .094 094 Yearly 10 Y ears
36 Gal. Vertical .094 094 Yearly 10 Y ears
60 Gal. Vertical .094 094 Yearly 10 Y ears
Fig. 4 Recommended Air Tank Inspection Intervals
Refer to federal, state or provincial, or local codes
for mandatory air tank maintenance information.
Vertical
Minimum Allowable
or
Wall Thickness
Head Shell
Visually
Inspect
Hydrostatically
Inspect
Step 1) Make sure the OFF/AUTO knob on the pres-
sure switch is turned to the “OFF” position
(see Fig. 5).
PRE-STARTING
CHECK LIST
WARNING !
Failure to perform the PRE-STARTING CHECKLIST
may result in mechanical failure, prop erty damage,
se ri ous injury or even death.
Fig. 5 Pressure Switch
Steps 1 through 6 should be performed prior to
operating the unit. If any condition of the checklist
THE COMPRESSOR
is not satisfied, make the necessary adjustments or
corrections before starting the compressor.
WARNING !
Never assume a compressor is safe to work on
just be cause it is not operating. It could restart at
any time. Fol low all safety precau tions outlined in
MAINTENANCE.
Step 1) Compressors are shipped with lubricant in
the crankcase. Check for proper lubricant
level. (Refer to Lubrication.)
Step 2) Make sure all pressure relief valves are cor-
rectly installed. (Refer to SYSTEM COMPONENTS)
1312100602, September 2012 6 3501 Wisman Lane, Quincy IL - 62305-3116
Step 2) Turn on the power supply or plug the power
cord into a properly grounded and rated power
source.
Step 3) Start the compressor by turning the OFF/
AUTO knob to the “AUTO” position.
Step 4) At initial start-up, verify that the compres-
sor ywheel is rotating counterclockwise (as
viewed from the ywheel side of compressor).
Watch and listen for excessive vibration and
unusal noise. If either exist, stop the compressor and refer to TROUBLESHOOTING.
Step 5) New compressors should be run with the tank
drain valve open for 1 hour to break-in the
compressor. This will allow the compressor
time to warm up and seat the rings.
Quincy Compressor
Page 8
Step 6) To stop the compressor, turn the OFF/AUTO
knob to the “OFF” position. Carefully unplug
the power cord from the power source or turn
o the power supply.
MAINTENANCE
The following procedures should be performed when
stopping the compressor for maintenance or service:
Step 1) Prior to performing any maintenance or
repair, always turn the OFF/AUTO knob to
the "OFF" position and per OSHA regulation
1910.147, disconnect and lockout/tagout the
main power source. Then, isolate the compressed air supply by closing and locking
out a manual shutoff valve upstream and
downstream from the compressor. Display a
sign in clear view at the main power source
and at the shutoff valve stating that the
compressor is being serviced.
Step 2) Completely relieve the system of air pres-
sure by pulling the ring on a pressure relief
valve. Continue to pull the ring until all air
pressure escapes. (Refer to Fig. 3)
Step 3) Slowly open all manual drain valves within
the area to be serviced.
Step 4) Wait for the unit to cool before starting to
ser vice.
Maintenance Schedule
If the unit is used in an excessively dirty or dusty
envi ronment, check and perform all maintenance
procedures more often.
After First 100 Hours or First Month of Operation
(whichever occurs rst)
• Replace break-in lubricant (Refer to LUBRICATION).
Daily
• Maintain lubricant level to be visible in the
center of the sight glass. Discolored lubricant
or a higher lubricant level reading may indicate
the presence of condensed liquids. (Refer to
TROUBLESHOOTING.)
• Drain the air tank, drop legs and moisture traps
in air distribution system. Tank(s) subjected to
freezing temperatures may contain ice. Store the
compressor in a heated area before attempting to
drain moisture from the tank(s). Never attempt
to drain these components without rst relieving
the system pressure.
• Give compressor overall visual inspection and be
sure safety guards are in place.
• Check for any unusual noise or vibration.
1312100602, September 2012 7 3501 Wisman Lane, Quincy IL - 62305-3116
Weekly
• Pull on the ring of the pressure relief valves
to make sure they are operating correctly. Air
pressure should escape when the ring is pulled
(refer to Fig. 3).
• Check all pressurized components for rust, cracking or leaking. Immediately discontinue use of
the equipment and relieve all system pressure
if any of these problems are discovered. Do not
use the equipment until it has been inspected
and repaired by a qualied mechanic.
• Clean the exterior surfaces of the compressor.
• Check the air lter and replace if necessary.
• Check system for air &/or lubricant leaks.
Monthly
• Check belt tension.
• Check ywheel retaining bolt.
Every 3 Months (or every 300* hrs.)
• Change lubricant. Use a compressor grade non-
detergent lubricant.
Lubrication
Before starting this compressor, check the lubricant
level. It should register 1/2 way to slightly above in
the sightglass. Add lubricant to the crankcase through
the crankcase oil ll / breather port. Do not overll.
Approximate Crankcase Lubricant Capacity
Q12120P & Q12126VP = .86 qts. (.817 lit.)
Q13160V = 1.12 qts. (1.06 lit.)
A non-detergent SAE 40 weight lubricant may be
used in your compressor. Detergent lubricants are
not recommended because they have a tendency to
foam when used in compressors.
Condensation
Rust can form inside the crankcase and on internal
com ponents as a result of condensation. A compressor
must operate long enough during each run cycle to
reach full operating temperature in order to reduce
the risk of condensation.
CAUTION!
Lubricant that appears milky on the dipstick may
have mixed with condensate. Failure to replace
contaminated lubricant will result in damage to the
compressor and may void warranty.
Condensation can also form in the air tank of your
com pressor. When this happens, a mixture of air and
mois ture will be expelled through the service valve
and into what ever is connected to the valve (e.g. air
hoses, metal air lines, pneumatic tools, spray guns).
Quincy Compressor
Page 9
An in-line filter or dryer, available from your local
Quincy distributor, may be re quired to eliminate
the moisture.
Condensation in the air tank can be kept to a
mini mum by draining the tank on a daily basis.
This also reduces the risk of rust developing and
weak ening the tank.
Belt Alignment & Adjustment
Drive belts tend to stretch with normal use and
require adjustment periodically (check monthly). In
order to adjust the drive belt the belt guard must
be removed. Prior to re moving the belt guard, follow
the procedures outlined under MAINTENANCE.
Properly adjusted, a 3 pound pressure applied to
the belt between the motor pulley and the compressor
ywheel will deect the belt about 1/4”(6mm.). Refer
to Fig. 7. To ad just the belt tension, loosen the 4 motor
mounting screws and slide the motor in the proper
direction. Retighten the motor mounting screws.
Fig. 6 Typical Belt Alignment
Fig. 7 Typical Belt Adjustment
Check the belt alignment by placing a straightedge
against the face of the ywheel, touching its rim at
two places (refer to Fig. 6). Adjust the flywheel or
motor pul ley so that the belt runs parallel to the
straightedge. Use a wheel puller to move the motor
pulley on the shaft.
1312100602, September 2012 8 3501 Wisman Lane, Quincy IL - 62305-3116
Quincy Compressor
Page 10
TROUBLESHOOTING
Read and understand all the safety precautions listed in the front of this manual and follow all procedures
listed in MAINTENANCE before making repairs.
PROBLEM CAUSES CORRECTION
1. Compressor won’t operate.
1. Power cord not plugged in.
2. OFF/AUTO switch in “OFF”
position.
3. Motor overload relay tripped.
4. Fuse blown &/or circuit
breaker is tripped.
5. Defective pressure switch.
6. Defective motor.
7. Lack of lubricant in compressor (can cause serious damage
to compressor).
8. Belt too tight or too loose.
9. Motor voltage does not match
voltage of power source.
1. Plug power cord in.
2. Switch to “auto”.
3. Turn OFF/AUTO switch to
the “OFF” po sition. Push the
motor thermal over load (red)
button rmly until a click is
heard. Turn auto/o switch to
“auto”.
4. Replace fuse or reset circuit
breaker.
5. Replace or repair pressure
switch.
6. Replace or repair motor.
7. Add lubricant (refer to Lubrication).
8. Adjust belt (refer to Belt
Alignment & Adjustment).
9. Change power cord & voltage of motor to match power
source.
2. Motor hums or runs slowly
when rst turned on.
3. Fuses blow or circuit breakers
trip.
1. Light duty extension cord being used.
2. Loose electrical connection.
3. Low voltage.
4. Motor sized incorrectly.
5. Defective motor.
6. Motor voltage does not match
voltage of power source.
1. Loose electrical connection.
2. Too many lights or appliances
being operated on the same
circuit as the compressor (circuit overloaded).
3. Defective check valve or unloader.
4. Low voltage.
5. Motor sized incorrectly.
6. Incorrect size fuse or circuit
breaker.
7. Defective motor.
8. Motor voltage does not match
voltage of power source.
1. Use additional hose instead
of extra extension cord or use
heavier gauge extension cord.
2. Repair electrical connections.
3. Check with voltmeter.
4. Replace with correctly sized
motor.
5. Replace motor.
6. Change power cord & voltage
of motor to match voltage of
power source.
1. Repair electrical connections.
2. Try another circuit or remove
other appliances from circuit
being used.
3. Replace check valve or unloader.
4. Check with voltmeter.
5. Replace with correctly sized
motor.
6. Check for proper size fuse.
7. Replace motor.
8. Change power cord & voltage
of motor to match voltage of
power source.
1312100602, September 2012 9 3501 Wisman Lane, Quincy IL - 62305-3116
Quincy Compressor
Page 11
PROBLEM CAUSES CORRECTION
4. Motor overload relay trips 1. Light duty extension cord being used.
2. Loose electrical connection.
3. Lubricant being used is too
heavy.
5. Defective check valve or unloader.
6. Low voltage.
7. Freezing temperature.
8. Motor sized incorrectly.
9. Drive belt too tight.
11. Defective motor.
12. Lack of proper ventilation room temperature too high.
13. Motor voltage does not match
voltage of power source.
1. Use additional hose instead
of extra extension cord or use
heavier gauge extension cord.
2. Repair electrical connections.
3. Use a lighter weight lubricant
(refer to Lubrication).
5. Replace check valve or unloader.
6. Check with voltmeter.
7. Warm the compressor.
8. Replace with correctly sized
motor.
9. Readjust belt (refer to Belt
Align ment & Adjustment).
11. Replace motor.
12. Move the compressor to a well
ven tilated area.
13. Change power cord & voltage
of motor to match voltage of
power source.
5. Noisy operation.
6. Excessive vibrations.
1. Lack of lubricant in crankcase.
2. Loose pulley, ywheel, belt,
com pressor or motor fasteners,
belt guard, clamps or accessories.
3. Carbon deposits on piston or
valves.
4. Worn main bearings, broken
piston, worn wrist pins, wrist
pin bearings, or loose connecting rod bolt.
1. Pulley & ywheel misaligned
or loose.
2. Bent crankshaft.
3. Belt loose.
4. Compressor unit bolted to
uneven surface or not bolted
down at all (stationary models).
1. Check for possible damage to
bear ings. Add lubricant (see
Lubrication).
2. Tighten where necessary.
3. Remove the cylinder head and
in spect for foreign matter on
top of the piston. Clean.
4. Take to Authorized Service
Center.
1. Realign or tighten pulley and
y wheel.
2. Take to Authorized Service
Center.
3. Tighten belt (refer to Belt
Align ment & Adjustment).
4. Shim to level surface & fasten
to oor if possible.
1312100602, September 2012 10 3501 Wisman Lane, Quincy IL - 62305-3116
Quincy Compressor
Page 12
PROBLEM CAUSES CORRECTION
7. Excessive lubricant consumption and/or ex cessive lubricant
in hose.
1. Crankcase overlled with
lubricant.
2. Lubricant leaks.
3. Worn piston rings.
4. Wrong lubricant viscosity.
5. Compressor on unlevel surface.
6. Scored cylinder.
7. Plugged crankcase breather.
1. Drain lubricant. Rell to
proper level with proper lubricant (refer to Lubrication).
2. Tighten bolts on compressor
to proper torque or replace
gaskets.
3. Take to Authorized Service
Center.
4. Drain lubricant & rell with
proper lubricant (refer to Lubrication).
5. Level compressor.
6. Take to Authorized Service
Center.
7. Clean or replace crankcase
breather.
9. Crankcase lubricant is milky.
11. Insucient pressure at tool or
acces sory.
1. Damaged inlet (reed) valve.8. Air blowing from inlet lter.
1. Water in lubricant due to
humidity or condensation.
1. Leaks or restrictions.
2. Restricted air intake (lter
plugged).
3. Slipping belt.
4. Hose or hose connectors too
small.
5. Compressor incorrectly sized.
6. Regulator not turned up to
high enough pressure / faulty
regulator.
1. Take to Authorized Service
Center.
1. Change lubricant. Move
compressor or air inlet to less
humid atmosphere.
1. Contact qualied electrician.1. Reversed wiring polarity.10. Compressor runs backwards.
1. Check for leaks or restrictions
in hose or piping. Repair.
2. Clean or replace lter.
3. Tighten belt (refer to Belt
Align ment & Adjustment).
4. Replace with larger hose or
connec tors.
5. Either use a smaller tool or a
larger compressor.
6. Turn the regulator to the
proper set ting / replace faulty
regulator.
12. Tank loses pressure rapidly
when compressor shuts o.
1312100602, September 2012 11 3501 Wisman Lane, Quincy IL - 62305-3116
1. Loose connection or leak (pipe,
tank drain valve, tubing, tting or hose).
2. Faulty check valve.
1. Turn unit o, unplug it, &
tighten or replace ttings or
components.
2. Replace faulty check valve.
Quincy Compressor
Page 13
PROBLEM CAUSES CORRECTION
13. Moisture in discharge air.
14. Compressor unit runs continuously.
15. Compressor overheats.
1. Condensation in tank, caused
by high level of atmospheric
humidity or compressor is not
run long enough.
1. Defective pressure switch.
2. Compressor incorrectly sized.
1. High ambient temperature;
inadequate ventilation.
2. Dirty cylinder & head cooling
ns.
3. Unit is undersized for application.
4. Insucient lubrication.
5. Compressor runs backwards.
6. One or more head valves failing to seat properly.
7. Damaged cylinder head gasket.
8. Restriction in head or check
valve.
1. Drain tank after every use.
Drain tank more frequently in
humid weather & use an air
line lter.
1. Replace defective pressure
switch.
2. Limit the air pressure to the
com pressor’s capacity. Either
use a smaller tool or a larger
compressor.
1. Increase ventilation with
cooler air.
2. Clean all outer surfaces of the
compressor.
3. Re-evaluate application
requirements; re-size if necessary.
4. Inspect for proper lubricant
and amount. Refer to LUBRICATION. Do not operate
this compressor more than
10° o level.
5. Take to authorized service
center.
6. Take to authorized service
center.
7. Take to authorized service
center.
8. Inspect, clean or replace.
16. Pressure relief valve continually "pops".
1312100602, September 2012 12 3501 Wisman Lane, Quincy IL - 62305-3116
1. Defective pressure switch.
2. Faulty pressure switch setting.
3. Defective pressure relief valve.
1. Replace pressure switch.
2. Re-set pressure switch (by
qualied technician).
3. Replace pressure relief valve.
Quincy Compressor
Page 14
Parts List
QTYPART NUMBERDESCRIPTION
11312100119B2800 Compressor
16229024900Valve Plate
11312100388Motor
11312100599Tank
11312100170Check Valve
11312100455
Pressur e Switch
11312100005
Relief Valve
21312100006
Pressure Guage
11312100213Discharge Tube
16229020500
Air Filter Kit
11312100360Drain Valve
16214343100Belt Guard (Front)
12236110472Belt Guard (Back)
11312100440Drive Pulley
11312100129Drive Belt
11312101014Rubber Foot
11312100007Power Cord
21312100060Wheel
12236107285Handle
11312100002Regulat or Valve
11310710108Lubricant Kit
11312100164Yearly Maintenance Kit
Discharge Tube
Belt Guard
B2800
Compressor
Air Filter
Handle
Pressure Switch
Regulator Valve
Cord
Rubber Foot
Pressure Gauge
Tank
Wheel
Motor
Valve Plate
Drain Valve
Check Valve
Parts List
QTY
PART NUMBER
DESCRIPTION
11312100119B2800 Compressor
16229024900Valve Plate
11312100388
Motor
11312100603
Tank
11312100170Check Valve
11312100455Pressure Swi tch
11312100005Relief Valve
21312100006Pressure Guage
11312100213Discharge Tube
16229020500Air Filter Kit
11312100360Drain Valve
16214343100
Belt Gua rd (Fron t)
12236110472
Belt Guard (Back)
11312100440Drive Pulley
11312100129Drive Belt
21312100411Rubber Foot
11312100007Power Cord
21312100029Wheel
12236107294Handle
11312100002Regulator Valve
11310710108Lubricant Kit
11312100164Yearly Mainten ance Kit
Air Filter
B2800
Compressor
Power Cord
Rubber Foot
Wheel
Drain Valve
Regulator Valve
Pressure Switch
Relief Valve
Handle
Pressure Gauge
Motor
Discharge Tube
Belt Guard
Check Valve
Valve Plate
COMPRESSOR UNIT PARTS
Model Q12120P
Model Q12126VP
Quincy Compressor
1312100602, September 2012 13 3501 Wisman Lane, Quincy IL - 62305-3116
Page 15
Belt Guard
Discharge
Tube
B3800
Compressor
Pressure
Gauge
Tank
Drain Valve
Relief Valve
Pressure Switch
Ball Valve
Motor
Check Valve
Valve Plate
Parts List
QTYPART NUMBERDESCRIPTION
11312100123B3800 Com pressor
16229024900Valve Plate
11312100390Motor
11312100604Tank
11312100170Check Valve
11312100455Pressure Switch
11312100005Relief V alve
11312100028Pressure Guage
11312100207Discharge Tube
16229020500Air Filter Kit
11312100360Drain Valve
16214343100Belt Guard (Front)
12236110472Belt Guard (Back)
11312100442Drive Pulley
11312100134Drive Belt
11312100162Ball Valve
11310710108Lubricant Kit
11312100164
Yearly Maintenance Kit
Model Q13160V
1312100602, September 2012 14 3501 Wisman Lane, Quincy IL - 62305-3116
Quincy Compressor
Page 16
DECALS AND DIMENSIONS
Model Q12120P
1312100602, September 2012 15 3501 Wisman Lane, Quincy IL - 62305-3116
Model Q12126VP
Quincy Compressor
Page 17
Quincy Compressor
1312100602, September 2012 16 3501 Wisman Lane, Quincy IL - 62305-3116
Model Q13160V
Page 18
QUINCY COMPRESSOR
STANDARD TERMS AND CONDITIONS
LEGAL EFFECT: Except as expressly otherwise agreed to in writing by
an authorized representative of Seller, the following terms and conditions
shall apply to and form a part of this order and any additional and/or different
terms of Buyer’s purchase order or other form of acceptance are rejected in
advance and shall not become a part of this order.
The rights of Buyer hereunder shall be neither assignable nor transferable
except with the written consent of Seller.
This order may not be canceled or altered except with the written consent
of Seller and upon terms which will indemnify Seller against all loss occasioned thereby. All additional costs incurred by Seller due to changes in
design or specications, modication of this order or revision of product
must be paid for by Buyer.
In addition to the rights and remedies conferred upon Seller by this order,
Seller shall have all rights and remedies conferred at law and in equity and
shall not be required to proceed with the performance of this order if Buyer
is in default in the performance of such order or of any other contract or
order with seller.
TERMS OF PAYMENT: Unless otherwise specied in the order acknowledgment, the terms of payment shall be 1% 15, net forty-ve (45) days after
shipment. These terms shall apply to partial as well as complete shipments.
If any proceeding be initiated by or against Buyer under any bankruptcy or
insolvency law, or in the judgment of Seller the nancial condition of Buyer,
at the time the equipment is ready for shipment, does not justify the terms of
payment specied, Seller reserves the right to require full payment in cash prior
to making shipment. If such payment is not received within fteen (15) days
after notication of readiness for shipment, Seller may cancel the order as to
any unshipped item and require payment of its reasonable cancellation charges.
If Buyer delays shipment, payments based on date of shipment shall become
due as of the date when ready for shipment. If Buyer delays completion of
manufacture, Seller may elect to require payment according to percentage of
completion. Equipment held for Buyer shall be at Buyer’s risk and storage
charges may be applied at the discretion of Seller.
Accounts past due shall bare interest at the highest rate lawful to contract for
but if there is no limit set by law, such interest shall be eighteen percent (18%).
Buyer shall pay all cost and expenses, including reasonable attorney’s fees,
incurred in collecting the same, and no claim, except claims within Seller’s
warranty of material or workmanship, as stated below, will be recognized unless
delivered in writing to Seller within thirty (30) days after date of shipment.
TAXES: All prices exclude present and future sales, use, occupation,
license, excise, and other taxes in respect of manufacture, sales or delivery,
all of which shall be paid by Buyer unless included in the purchase price at
the proper rate or a proper exemption certicate is furnished.
ACCEPTANCE: All offers to purchase, quotations and contracts of sales
are subject to nal acceptance by an authorized representative at Seller’s plant.
DELIVERY: Except as otherwise specied in this quotation, delivery will
be F. O. B. point of shipment. In the absence of exact shipping instruction,
Seller will use its discretion regarding best means of insured shipment. No
liability will be accepted by Seller for so doing. All transportation charges
are at Buyer’s expense. Time of delivery is an estimate only and is based
upon the receipt of all information and necessary approvals. The shipping
schedule shall not be construed to limit seller in making commitments for
materials or in fabricating articles under this order in accordance with Seller’s
normal and reasonable production schedules.
Seller shall in no event be liable for delays caused by res, acts of God,
strikes, labor difculties, acts of governmental or military authorities, delays
in transportation or procuring materials, or causes of any kind beyond Seller’s
control. No provision for liquidated damages for any cause shall apply under
this order. Buyer shall accept delivery within thirty (30) days after receipt of
notication of readiness for shipment. Claims for shortages will be deemed
to have been waived if not made in writing with ten (10) days after the receipt
of the material in respect of which any such shortage is claimed. Seller is
not responsible for loss or damage in transit after having received “In Good
Order” receipt from the carrier. All claims for loss or damage in transit should
be made to the carrier.
1312100602, September 2012 17 3501 Wisman Lane, Quincy IL - 62305-3116
TITLE & LIEN RIGHTS: The equipment shall remain personal property ,
regardless of how afxed to any realty or structure. Until the price (including
any notes given therefore) of the equipment has been fully paid in cash, Seller
shall, in the event of Buyer’s default, have the right to repossess such equipment.
PATENT INFRINGMENT: If properly notied and given an opportunity to
do so with friendly assistance, Seller will defend Buyer and the ultimate user
of the equipment from any actual or alleged infringement of any published
United States patent by the equipment or any part thereof furnished pursu-
ant hereto (other than parts of special design, construction, or manufacture
specied by and originating with Buyer), and will pay all damages and costs
awarded by competent court in any suit thus defended or of which it may
have had notice and opportunity to defend as aforesaid.
STANDARD WARRANTY: Seller warrants that products of its own
manufacture will be free from defects in workmanship and materials under
normal use and service for the period specied in the product instruction
manual. Warranty for service parts will be Ninety (90) days from date of
factory shipment. Electric Motors, gasoline and diesel engines, electrical apparatus and all other accessories, components and parts not manufactured by
Seller are warranted only to the extent of the original manufacturer’s warranty .
Notice of the alleged defect must be given to the Seller, in writing with
all identifying details including serial number, type of equipment and date
of purchase within thirty (30) days of the discovery of the same during the
warranty period.
Seller’s sole obligation on this warranty shall be, at its option, to repair
or replace or refund the purchase price of any product or part thereof which
proves to be defective. If requested by Seller, such product or part thereof
must be promptly returned to seller, freight prepaid, for inspection.
Seller warrants repaired or replaced parts of its own manufacture against
defects in materials and workmanship under normal use and service for ninety
(90) days or for the remainder of the warranty on the product being repaired.
This warranty shall not apply and Seller shall not be responsible or liable for:
(a)
Consequential, collateral or special losses or damages;
(b)
Equipment conditions caused by fair wear and tear, abnormal conditions of
use, accident, neglect or misuse of equipment, improper storage or damage
resulting during shipping;
(c)
Deviation from operating instructions, specications or other special terms
of sale;
(d)
Labor charges, loss or damage resulting from improper operation, maintenance
or repairs made by person(s) other than Seller or Seller’s authorized service
station.
In no event shall Seller be liable for any claims whether arising from breach
of contract or warranty or claims of negligence or negligent manufacture in
excess of the purchase price.
THIS WARRANTY IS THE SOLE WARRANTY OF SELLERS AND
ANY OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED IN
LAW OR IMPLIED IN FACT, INCLUDING ANY WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR PARTICULAR USE ARE
HEREBY SPECIFICALLY EXCLUDED.
LIABILITY LIMIT A TIONS: Under no circumstances shall the Seller have
any liability for liquidated damages or for collateral, consequential or special
damages or for loss of prots, or for actual losses or for loss of production or
progress of construction, whether resulting from delays in delivery or performance, breach of warranty, negligent manufacture or otherwise.
ENVIROMENTAL AND OSHA REQUIREMENTS: At the time of shipment of the equipment from the factory, Quincy Compressor / Ortman Fluid
Power will comply with the various Federal, State and local laws and regulations concerning occupational health and safety and pollution. However, in
the installation and operation of the equipment and other matters over which
the seller has no control, the Seller assumes no responsibility for compliance
with those laws and regulations, whether by the way of indemnity, warranty
or otherwise.
June 30, 2003
Quincy Compressor
Loading...
