QUICK LOGIC QL24x32B-0PF144C, QL24x32B-0PF144I, QL24x32B-0PF144M, QL24x32B-0PQ208C, QL24x32B-0PQ208I Datasheet

QL24x32B

pASIC

®

1 Family

Very-High-Speed CMOS FPGA

4-31

Very High Speed

– ViaLink



metal-to-metal programmable–via
antifuse technology, allows counter speeds over 150 MHz and logic
cell delays of under 2 ns.

High Usable Density

– An 24-by-32 array of 768 logic cells
provides 8,000 usable ASIC gates (14,000 PLD gates) in 144-pin
TQFP, 208-pin PQFP and 208-pin CQFP packages.

PCI-Output Drive

– Fully PCI 2.1 compliant input/output

capability. (including drive current)

Low-Cost, Easy-to-Use Design Tools

– Designs entered and
simulated using QuickLogic's new QuickWorks development
environment, or with third-party CAE tools including Viewlogic,
Synopsys, Mentor, Cadence and Veribest. Fast, fully automatic place
and route on PC and workstation platforms using QuickLogic
software.

=

Up to 172 prog. I/O cells, 6 Input high-drive cells, 2 Input/Clk (high-drive) cells

pASIC 1

4

pASIC

HIGHLIGHTS

QL24x32B

Block Diagram

…8,000

usable ASIC gates,

180 I/O pins

768 Logic Cells

QL24x32B

4-32

The QL24x32B is a member of the pASIC 1 Family of very-high-speed
CMOS user-programmable ASIC devices. The 768 logic cell field­programmable gate array (FPGA) offers 8,000 usable ASIC gates
(equivalent to 14,000 PLD gates) of high-performance general-purpose
logic in 144-pin TQFP and 208-pin PQFP and CQFP packages.

Low-impedance, metal-to-metal, ViaLink interconnect technology
provides nonvolatile custom logic capable of operating above 150 MHz.
Logic cell delays under 2 ns, combined with input delays of under 1.5 ns
and output delays under 3 ns, permit high-density programmable devices
to be used with today’s fastest microprocessors and DSPs.

Designs can be entered using QuickLogic’s QuickWorks Toolkit or most
populart third-party CAE tools. QuickWorks combines Verilog/VHDL
design entry and simulation tools with device-specific place & route and
programming software. Ample on-chip routing channels allow fast, fully
automatic place and route of designs using up to 100% of the logic and
I/O cells, while maintaining fixed pin-outs

Total of 180 I/O pins
– 172 Bidirectional Input/Output pins
– 6 Dedicated Input/High-Drive pins
– 2 Clock/Dedicated input pins with fanout-independent, low-skew

clock networks
– PCI 2.1 Compliant I/Os
Input + logic cell + output delays under 6 ns
Chip-to-chip operating frequencies up to 110 MHz
Internal state machine frequencies up to 150 MHz
Clock skew < 0.5 ns
Input hysteresis provides high noise immunity
Built-in scan path permits 100% factory testing of logic and I/O cells

and functional testing with Automatic Test Vector Generation
(ATVG) software after programming

144-pin TQFP compatible with QL16x24B

0.65µ CMOS process with ViaLink programming technology

PRODUCT

SUMMARY

FEATURES

QL24x32B

4-33

pASIC 1

4

Pinout
Diagram
144-pin TQFP

QL24x32B

4-34

QL24X32B-1PQ208C

pASIC

Pinout Diagram

208-pin PQFP/CQFP

PIN # 1

PIN # 157

PIN # 105

PIN # 53

QL24x32B

4-35

PQFP/CQFP 208 Function/Connector Table

PIN FUN PIN FUN PIN FUN PIN FUN PIN FUN PIN FUN PIN FUN PIN FUN

1 I/O 27 VCC 53 I/O 79 I/O 105 I/O 131 VCC 157 I/O 183 I/O
2 I/O 28 I/P 54 I/O 80 I/O 106 I/O 132 I 158 I/O 184 I/O
3 I/O 29 I 55 I/O 81 I/O 107 I/O 133 I/SO 159 I/O 185 I/O
4 I/O 30 VCC 56 I/O 82 I/O 108 I/O 134 VCC 160 I/O 186 I/O
5 I/O 31 I/O 57 I/O 83 VCC 109 I/O 135 I/O 161 I/O 187 VCC
6 I/O 32 I/O 58 I/O 84 I/O 110 I/O 136 I/O 162 I/O 188 I/O
7 I/O 33 I/O 59 GND 85 I/O 111 I/O 137 I/O 163 GND 189 I/O
8 I/O 34 I/O 60 I/O 86 I/O 112 I/O 138 I/O 164 I/O 190 I/O

9 I/O 35 I/O 61 VCC 87 I/O 113 I/O 139 I/O 165 VCC 191 I/O
10 VCC 36 I/O 62 I/O 88 I/O 114 VCC 140 I/O 166 I/O 192 I/O
11 I/O 37 I/O 63 I/O 89 I/O 115 I/O 141 I/O 167 I/O 193 I/O
12 GND 38 I/O 64 I/O 90 I/O 116 GND 142 I/O 168 I/O 194 I/O
13 I/O 39 I/O 65 I/O 91 I/O 117 I/O 143 I/O 169 I/O 195 I/O
14 I/O 40 I/O 66 I/O 92 I/O 118 I/O 144 I/O 170 I/O 196 I/O
15 I/O 41 VCC 67 I/O 93 I/O 119 I/O 145 VCC 171 I/O 197 I/O
16 I/O 42 I/O 68 I/O 94 I/O 120 I/O 146 I/O 172 I/O 198 I/O
17 I/O 43 GND 69 I/O 95 GND 121 I/O 147 GND 173 I/O 199 GND
18 I/O 44 I/O 70 I/O 96 I/O 122 I/O 148 I/O 174 I/O 200 I/O
19 I/O 45 I/O 71 I/O 97 VCC 123 I/O 149 I/O 175 I/O 201 VCC
20 I/O 46 I/O 72 I/O 98 I/O 124 I/O 150 I/O 176 I/O 202 I/O
21 I/O 47 I/O 73 GND 99 I/O 125 I/O 151 I/O 177 GND 203 I/O
22 I/O 48 I/O 74 I/O 100 I/O 126 I/O 152 I/O 178 I/O 204 I/O
23 GND 49 I/O 75 I/O 101 I/O 127 GND 153 I/O 179 I/O 205 I/O
24 I/O 50 I/O 76 I/O 102 I/O 128 I/O 154 I/O 180 I/O 206 I/O
25 I/Sck 51 I/O 77 I/O 103 I/O 129 I/SI 155 I/O 181 I/O 207 I/O
26 I/Clk 52 I/O 78 GND 104 I/O 130 I/Clk 156 I/O 182 GND 208 I/O

pASIC 1

4

QL24x32B

4-36

ABSOLUTE MAXIMUM RATINGS

Supply Voltage................................. –0.5 to 7.0V Storage Temperature.......–65°C to + 150°C

Input Voltage....................... –0.5 to VCC +0.5V Lead Temperature ...................................300°C

ESD Pad Protection.................................. ±2000V

DC Input Current...................................... ±20 mA

Latch-up Immunity................................. ±200 mA

OPERATING RANGE

Symbol Parameter Military Industrial Commercial Unit

Min Max Min Max Min Max

VCC Supply Voltage 4.5 5.5 4.5 5.5 4.75 5.25 V
TA Ambient Temperature -55 -40 85 0 70

°C

TC Case Temperature 125

°C

-X Speed Grade 0.4 2.75 0.46 2.55

K Delay Factor -0 Speed Grade 0.39 1.82 0.4 1.67 0.46 1.55

-1 Speed Grade 0.39 1.56 0.4 1.43 0.46 1.33

-2 Speed Grade 0.4 1.35 0.46 1.25

DC CHARACTERISTICS over operating range

Symbol Parameter Conditions Min Max Unit

VIH Input HIGH Voltage 2.0 V
VIL Input LOW Voltage 0.8 V

IOH = -4 mA 3.7 V

VOH Output HIGH Voltage [0] IOH = 16 mA 2.4 V

IOH = -10 µA

VCC-0.1 V

VOL Output LOW Voltage [0] IOL = 24 mA* 0.4 V

IOL = 10 µA

0.1 V

II Input Leakage Current VI = VCC or GND -10 10

µA

IOZ 3-State Output Leakage Current VI = VCC or GND -10 10

µA
CI Input Capacitance [1] 10 pF
IOS Output Short Circuit Current [2] VO = GND -10 -90 mA

VO = VCC 40 160 mA

ICC D.C. Supply Current [3] VI, VIO = VCC or GND 10 mA

*IOL = 24 mA for commercial range only. IOL = 12 mA for the industrial and military ranges.
Notes:
[1] Capacitance is sample tested only. CI = 20 pF max on I/(SI).

[2] Only one output at a time. Duration should not exceed 30 seconds.
[3] Commercial temperature grade only. Maximum Icc for industrial grade is 15mA and for military grade is

20 mA. For AC conditions use the formula described in the Section 9 — Power vs Operating Frequency.

[4] Stated timing for worst case Propagation Delay over process variation at VCC = 5.0V and TA = 25°C.

Multiply by the appropriate Delay Factor, K, for speed grade, voltage and temperature settings as specified
in the Operating Range.

[5] These limits are derived from a representative selection of the slowest paths through the pASIC logic cell

including net delays

. Worst case delay values for specific paths should be determined from timing analysis

of your particular design.

QL24x32B

4-37

AC CHARACTERISTICS at VCC = 5V, TA = 25°C (K = 1.00)
Logic Cell

Input Cells

Output Cell

Propagation Delays (ns)

[4]

Symbol Parameter Output Load Capacitance (pF)

30 50 75 100 150

tOUTLH Output Delay Low to High 2.7 3.3 3.8 4.3 5.4
tOUTHL Output Delay High to Low 2.8 3.6 4.5 5.3 6.9
tPZH Output Delay Tri-state to High 2.1 2.6 3.1 3.7 4.8

tPZL Output Delay Tri-state to Low 2.6 3.3 4.1 4.9 6.5
tPHZ Output Delay High to Tri-state [8] 2.9
tPLZ Output Delay Low to Tri-state [8] 3.3

Notes:
[6] See High Drive Buffer Table for more information.

[7] Clock buffer fanout refers to the maximum number of flip flops per half column. The number of half

columns used does not affect clock buffer delay.

[8] The following loads are used for tPXZ:

Propagation Delays (ns)

Symbol Parameter Fanout

12348

tPD Combinatorial Delay [5] 1.7 2.1 2.7 3.3 5.5
tSU Setup Time [5] 2.1 2.1 2.1 2.1 2.1
tH Hold Time 0.0 0.0 0.0 0.0 0.0
tCLK Clock to Q Delay 1.0 1.5 1.9 2.7 4.9
tCWHI Clock High Time 2.0 2.0 2.0 2.0 2.0
tCWLO Clock Low Time 2.0 2.0 2.0 2.0 2.0
tSET Set Delay 1.7 2.2 2.7 3.3 5.5
tRESET Reset Delay 1.5 1.9 2.3 2.8 4.6
tSW Set Width 1.9 1.9 1.9 1.9 1.9
tRW Reset Width 1.8 1.8 1.8 1.8 1.8

Symbol Parameter

Propagation Delays (ns)

[4]

123481216

tIN High Drive Input Delay [6] 3.1 3.2 3.3 3.4 4.4 5.8 6.5
tINI High Drive Input, Inverting Delay [6] 3.3 3.4 3.5 3.6 4.6 6.0 6.7
tIO Input Delay (bidirectional pad) 1.4 1.9 2.3 3.0 4.8 6.7 8.5
tGCK Clock Buffer Delay [7] 2.7 2.8 2.9 3.0 3.1 3.3 3.4
tGCKHI Clock Buffer Min High [7] 2.0 2.0 2.0 2.0 2.0 2.0 2.0
tGCKLO Clock Buffer Min Low [7] 2.0 2.0 2.0 2.0 2.0 2.0 2.0

pASIC 1

4

5 pF

1K

Ω

5 pF

1K

Ω

tPHZ

tPLZ

QL24x32B

4-38

High Drive Buffer

Clock Drivers Propagation Delays (ns)

[4]

Symbol Parameter Wired Together Fanout

12 24 48 72 96

1 5.8 7.2

tIN High Drive Input Delay 2 5.0 7.1

3 5.8 6.7 7.7
4 5.9 6.8
1 6.0 7.4

tINI High Drive Input, 2 5.2 7.3

Inverting Delay 3 6.0 6.9 7.9

4 6.1 7.0

AC Performance

Propagation delays depend on routing, fanout, load capacitance, supply voltage, junction temperature,
and process variation. The AC Characteristics are a design guide to provide initial timing estimates at
nominal conditions. Worst case estimates are obtained when nominal propagation delays are multiplied
by the appropriate Delay Factor, K, as specified in the Delay Factor table (Operating Range). The
effects of voltage and temperature variation are illustrated in the graphs on page 4-47, K Factor versus
Voltage and Temperature. The pASIC Development Tools incorporate data sheet AC Characteristics
into the QDIF database for pre-place-and-route timing analysis. The SpDE Delay Modeler extracts
specific timing parameters for precise path analysis or simulation results following place and route.

ORDERING

INFORMATION

QL 24x32B - 1 PQ208 C

QuickLogic

pASIC device

pASIC device part number

B = 0.65 micron CMOS

Operating Range

C = Commercial
I = Industrial
M = Military
M/883C = MIL STD 883

Package Code
PF144 = 144-pin TQFP
PQ208 = 208-pin PQFP
CF208 = 208-pin CQFP

Speed Grade
X = quick
0 = fast
1 = faster
2 = fastest
