RESCUE 900 & RESCUE 910
Portable Power Pack Instructions
IMPORTANT
Register
Your Unit
http://register.quickcable.com
The Rescue 900 and 910 are portable power packs capable of delivering
signicant current to start cars, light trucks, ATV’s, boats, lawn and garden
equipment and other 12V equipment. LED’s indicate reserve power level
and show when the unit is being charged and fully charged. A 12V cigarette-
style power outlet can be used to power accessories or charge electronics
like cell phones and MP3 players.
WARNING – Risk of Explosion or Fire
1. Failure to follow these instructions may result in personal injury, destruction of the power
pack, or damage to your vehicle.
2. Read owner’s manual before use.
3. Wear safety goggles whenever working around vehicle batteries.
4. Wear gloves and protective clothing.
Components
1
Power ON/OFF Switch
5
Battery Status Indicator
Positive (+) Clamp
2
Negative (_) Clamp
3
Battery Status Button
4
2 65
1
6
12V DC Power Port
7
Red Charging Light
8
Green Charged Light
4
3
7
8
2
Using the Rescue 900 and 910
Before using your portable power pack, you should fully charge it. The
fully charged indicator light will come on when the unit has been charged.
Recharge every 30 days or when the medium or low lights indicate less than
full charge. Fluctuations in temperature can accelerate battery discharge.
Check your unit often.
WARNING – Risk of Battery Explosion, Fire or Failure
• Failure to keep internal battery charged will lead to permanent battery damage.
• Connecting a discharged battery to charged system could cause overheating or explosion.
• Damage may occur if the Rescue Portable Power Pack is attached to a running vehicle for
more than 30 seconds after the engine starts.
To jump start a vehicle or machine:
• Make sure the Rescue 900/910 power switch is OFF.
• Connect the red (positive +) clamp to the positive terminal or post on the
discharged battery.
• Connect the black (negative –) clamp to a ground away from the battery,
such as an alternator bracket.
• Turn the power switch
ON.
• Start the engine.
• Turn the power
switch OFF.
• Disconnect the
clamps, rst negative
and then positive.
3
Use your Rescue® 900/910 safely
• Do not use the portable power pack if any cable clamp or cord is
damaged.
• Do not short circuit the unit. Don’t touch the clamps to any conductive
material.
• Always wrap the cables back into position and store the clamps properly.
• If your Rescue portable power pack requires service, follow the directions
in the warranty section. Do not attempt to repair the unit or replace parts.
Unauthorized repairs will void your warranty.
• Check vehicle battery terminals before using the power pack; clean them
if necessary.
• After approximately 10 seconds of continuous cranking, if the disabled
vehicle fails to start, stop and wait for 1 minute. This prevents damage to
your power pack and to your vehicle’s system from overheating.
• No lubrication is recommended or required.
• Avoid storing in direct sunlight, in extreme heat or cold, or very moist
areas.
4
Rescue® Portable Power Pack limited warranty
The Manufacturer warrants this product against defects in material and workmanship for
one (1) year from the date of original retail purchase. Quick Cable will, at its option, repair
or replace defective units.
Quick Cable encourages you to register your product at www.quickcable.com/register and
to retain your original sales receipt with this manual for warranty purposes.
This warranty does not apply to the user-installed battery.
Damage caused by misuse or improper connections, failure to follow prescribed operating
instructions, impact damage, or negligence is not covered by this warranty. The manufacturer reserves the right to inspect units for improper use in determining warranty coverage.
EXCEPT FOR THIS LIMITED WARRANTY, THE MANUFACTURER HAS NOT MADE
AND SPECIFICALLY DISCLAIMS ANY WARRANTY OR REPRESENTATION OF ANY
KIND, EXPRESS OR IMPLIED, DIRECT OR INDIRECT, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF MERCHANTABILITY, AND ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. THIS LIMITED, CONDITIONAL WARRANTY PROVIDES THE EXCLUSIVE REMEDY FOR ANY CLAIM OR DAMAGE EXCEPT
AS OTHERWISE REQUIRED BY LAW.
This warranty excludes and does not cover defects or failures of your PORTABLE POWER
PACK due to any cause other than defects in material or workmanship, including without
limitation any malfunctions or failures caused by repairs made by an unauthorized person,
mishandling, modifications, normal wear, improper storage and unreasonable use or damage.
IN NO EVENT SHALL THE MANUFACTURER BE LIABLE FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES. Some states do not allow the exclusion or limitation of incidental
or consequential damages so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
Any claim relating to the Portable Power Pack must be submitted within one (1) year of
purchase and must be sent to Quick Cable in the U.S.A or Canada.
If any portion of this warranty or limitation of rights and remedies is found to be unenforceable, then the remainder of this document shall remain in full force and effect.
To obtain service under this warranty:
1. Call Technical Service toll free in U.S.A. 1 (800) 558-8667 or in Canada 1 (800) 728-1742.
Have your Portable Power Pack near the phone and a technician will help you diagnose the
problem.
2. Be prepared to establish proof and date of purchase.
3. Any misuse of this unit will void this warranty.
