QUEVO AUDIO QUEVO-QA24 User Manual

User Manual
PLEASE READ BEFORE USE
Thank you for purchasing the Bluetooth Speaker, in this manual we will explain all you need to know to get up and running. Please read through the manual to know exactly how all of the functions work.
Your new speaker is compatible with all devices with Bluetooth and many other devices that are compliant with Bluetooth Version 4.0. Make sure that your device has Bluetooth capability by visiting your manufacturer’s website.
Do not keep the speaker on the maximum volume often, or this could hurt your hearing. We suggest you listen with 2/3 of the maximum volume, this not only lets you hear the perfect quality of music, but can also extend your speakers service life.
Avoid storage at high temperatures such as in hot vehicles or direct sunlight (storage at high temperatures can damage performance and reduce battery life).
Do not expose the speaker or any of its parts to rain or other liquids.
Always store the speaker with the Power OFF and make sure it is safely protected.
Please use 5v 1A to charge, for the speaker to be fully charged it takes 3-4 hours.
If the LED indicator doesn’t light up when you turn on the speaker, please charge the speaker.
Power on/off (Hold Down) Play/Pause/Answer and End telephone call Previous song (Press) Decrease Volume - (Hold Down) Next song (Press) Increase Volume + (Hold Down) Aux-in 5v charging Port.
2.0 How to operate your speaker
I . Function Instruction
II. Connection diagram
Connect to the USB port of a PC, tablet, or DVD Player, with USB cable.
Connect to the audio output interface of a PC, tablet, mobile phone, MP3, MP4 etc with AUX cable.
The speaker uses a rechargeable battery, we recommend you charge the battery fully before using for the first time.
Press and hold the “ ” button until you hear the voice command say “Power ON”, the LED light will turn blue in 1 second.
Press and hold the “ ” button until you hear the voice command say “Power OFF”.
III. Operation Instruction
Turning the speaker ON/OFF
Once speaker Power is ON to pair the speaker to your device Press and Hold the “ ” button and after about two seconds it will enter pairing mode. The LED light will flash red and blue and the voice command will say "Pairing"
To connect the speaker to your device with the Bluetooth Function set your device to discover Bluetooth devices. Your device will find the speaker (pairing name of the speaker is (QUEVO-QA24) confirm this by pressing YES or OK. You will then hear the voice command say “Paired”, it now means you are all connected and ready to hear music like never before with your new speaker!
Pairing
When the speaker is playing press +/- to change music. This feature may vary due to your operation mode and device settings.
Changing music
Hold down + to increase volume and hold down - to decrease volume.
Adjust the volume
Once your speaker has been paired with your device it will pair automatically every time.
Handsfree / Answer Telephone Call Function
1.Answering a telephone call: Press “ ” when you are receiving an incoming call. Press“ ”again to end the call. Hold Down +/­to adjust the volume.
2.To redial the last number on your mobile phone: Press “ ” twice to make the last number redial.
3.Rejecting an incoming call Press “ ” Button for 2 seconds to reject an incoming call
Press “ ”to Play/Pause
Play / Pause
WARNING
: Listening to music at very high levels for extended
periods of time can damage one’s hearing.
ATTENTION: This speaker conforms to a water-seal rating of IPX5, which ensures the speaker will show no adverse damage even if exposed to water splashing from any direction. However, the speaker is not water-proof, so should never be washed with water or left immersed in water.
*Play time may vary depending on the device type.
