MXC601
1
A Design First
The MXC601 features an elegant minimalistic,
bezel-free magnetic grille. Together with an
ultra-low resonance steel back-can design.
A die-cast 6” woofer coupled with a titanium
tweeter; result in studio quality performance.
Whether it be residential, commercial, or other;
the MXC601 is right at home performing in both
applications.
This impressive 2-Way design enables the
MXC601 to produce high-fidelity playback, in the
most demanding environments.
Safety Precautions
• Be sure to read the instructions in this section
carefully before use.
• Make sure you observe the instructions in this
manual as the conventions of safety symbols
and messages are very important.
• We also recommend you keep this instruction
manual handy for future reference.
Safety Symbol and Message
Conventions
Safety symbols described below are used in this
manual to prevent personal injury and property
damage, which could be a result of mishandling.
Before operating your product, read this manual
first and understand the safety symbols and
messages, so you are thoroughly aware of any
risks.
Ensure the safety cable
is fixed to a suitable
mounting point.
WARNING
General Description
The MXC601, is a high performance, back-canned ceiling speaker. Designed to match the sonic
performance of an MX601.
Offering the same low impedance of 16Ω, and selectable 70/100V line tap settings; the MXC601 is the
perfect companion in a larger MX Series, or mixed component system.
2
Controls
Tap Settings High Frequency Adjustment
Rear Panel
44
00
ww
33
00
ww
22
00
ww
22
00
ww
1100
ww
11
00
ww
11
55
ww
55
ww
44
00
ww
33
00
ww
22
00
ww
22
00
ww
1100
ww
1100
ww
1155
ww
55
ww
Safety Cable
Mounting Point
In/Thru Speaker
Connector
Total Amplifier Load 120W
(not including other parasitic loading, always allow amplifier headroom)
*Q1K Amplifier shown is capable of low impedance, or 70V operation
16Ω 16Ω 16Ω 16Ω
+ - +-
16Ω 16Ω 16Ω 16Ω
+ - +-
connector wiring is the
same for both examples
from
amplifier
to
speakers
T
Ω
16Ω 16Ω 16Ω 16Ω
+ - +-
16Ω 16Ω 16Ω 16Ω
+ - +-
15W 15W 15W 15W
15W 15W 15W 15W
connector wiring is the
same for both examples
from
amplifier
to
speakers
T
Ω
3
Amplifier Wiring Examples
Parallel Wiring
100V/70V System
(low impedance selected)
(example shows 15W tap setting)
* Quest Engineering reserves the right to make changes in specifications, or products without prior notice.
** The figures shown above are ‘real world’, usable specifications and are conservative as a result. Quest Engineering does not believe in
portraying misleading or exaggerated specifications.
4
Technical Parameters MXC601
Max SPL *calculated 107dBSPL
Sensitivity
*5-band average 91dB
Frequency Response ±2dB 70Hz – 20kHz
Impedance 16Ω
Transformer Taping
100V 10w/20w/30w/40w
70V 5w/10w/15w/20w
RMS 75W Peak 100W
Transducers HF
25mm Titanium Dome
Tweeter
LF 6” High Performance Polypropylene Woofer
Directivity
*H x V 130° -10dB
Connections Captive Screw Terminal Plug (In/Thru)
Cutout Size 254mm Diameter
Dimensions
*W x D 276 x 160mm
Net Weight 2.9 kg
Shipping Weight 3.9 kg
www.questengineering.com.au
Register Your Product
Thank you for choosing Quest. Please take the
time to complete your product registration.
Registering your Quest Engineering product will:
• CONFIRM YOUR WARRANTY
• REGISTER YOUR PRODUCT
• PROTECT YOUR NEW PRODUCT
REGISTER ONLINE:
www.questengineering.com.au/registration
For spare parts and service, contact your local
authorised Quest Dealer.
