Quectel EC21 Series, EC21-V, EC21-E, EC21-A, EC21-AU Hardware Design

EC21 Hardware Design

LTE Module Series

Rev. EC21_Hardware_Design_V1.4 Date: 2017-03-01

www.quectel.com

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

Our aim is to provide customers with timely and comprehensive service. For any assistance, please contact our company headquarters:

Quectel Wireless Solutions Co., Ltd.

Office 501, Building 13, No.99, Tianzhou Road, Shanghai, China, 200233 Tel: +86 21 5108 6236 Email: info@quectel.com

Or our local office. For more information, please visit:

http://www.quectel.com/support/salesupport.aspx

For technical support, or to report documentation errors, please visit:

http://www.quectel.com/support/techsupport.aspx Or email to: Support@quectel.com

GENERAL NOTES

QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION

PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT

TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION. THE INFORMATION SUPPLIED HEREIN IS SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

COPYRIGHT

THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF QUECTEL CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL OR DESIGN.

EC21_Hardware_Design Confidential / Released 1 / 94

LTE Module Series

Revision

Date

Author

Description

1.0

2016-04-15

Yeoman CHEN

Initial

1.1

2016-09-22

Yeoman CHEN/ Frank WANG/ Lyndon LIU

1. Updated frequency bands in Table 1.

2. Updated transmitting power, supported maximum baud rate of main UART, supported internet protocols, supported USB drivers of USB interface, and temperature range in Table 2.

3. Updated timing of turning on module in Figure 12.

4. Updated timing of turning off module in Figure 13.

5. Updated timing of resetting module in Figure 16.

6. Updated main UART supports baud rate in Chapter

3.11.

7. Added notes for ADC interface in Chapter 3.13.

8. Updated GNSS Performance in Table 21.

9. Updated operating frequencies of module in Table

23.

10. Added current consumption in Chapter 6.4.

11. Updated RF output power in Chapter 6.5.

12. Added RF receiving sensitivity in Chapter 6.6.

1.2

2016-11-04

Lyndon LIU/ Michael ZHANG

1. Added SGMII and WLAN interfaces in Table 2.

2. Updated function diagram in Figure 1.

3. Updated pin assignment (Top View) in Figure 2.

4. Added description of SGMII and WLAN interfaces in Table 4.

5. Added SGMII interface in Chapter 3.17.

6. Added WLAN interface in Chapter 3.18.

7. Added USB_BOOT interface in Chapter 3.19.

8. Added reference design of RF layout in Chapter

5.1.4.

9. Added current consumption of EC21-V in Chapter

Quectel

Confidential

EC21 Hardware Design

About the Document

History

EC21_Hardware_Design Confidential / Released 2 / 94

LTE Module Series

6.4.

10. Added note about SIMO in Chapter 6.6.

1.3

2017-01-24

Lyndon LIU/ Rex WANG

1. Updated frequency bands in Table 1.

2. Updated function diagram in Figure 1.

3. Updated pin assignment (top view) in Figure 2.

4. Added BT interface in Chapter 3.18.2.

5. Updated reference circuit of wireless connectivity interfaces with FC20 module in Figure 29.

6. Updated GNSS performance in Table 24.

7. Updated module operating frequencies in Table 26.

8. Added EC21-AUV current consumption in Table 38.

9. Updated EC21-A conducted RF receiving sensitivity of in Table 42.

10. Added EC21-J conducted RF receiving sensitivity in Table 48.

1.4

2017-03-01

Geely YANG

Deleted the LTE band TDD B41 of EC21-CT

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 3 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

Table Index

TABLE 1: FREQUENCY BANDS OF EC21 SERIES MODULE ........................................................................ 12

TABLE 2: EC21 KEY FEATURES OF EC21 MODULE ..................................................................................... 13

TABLE 3: I/O PARAMETERS DEFINITION ....................................................................................................... 19

TABLE 4: PIN DESCRIPTION ........................................................................................................................... 19

TABLE 5: OVERVIEW OF OPERATING MODES ............................................................................................. 28

TABLE 6: VBAT AND GND PINS ....................................................................................................................... 33

TABLE 7: PWRKEY PIN DESCRIPTION .......................................................................................................... 35

TABLE 8: RESET_N PIN DESCRIPTION ......................................................................................................... 38

TABLE 9: PIN DEFINITION OF THE USIM CARD INTERFACE ...................................................................... 39

TABLE 10: PIN DESCRIPTION OF USB INTERFACE ..................................................................................... 41

TABLE 11: PIN DEFINITION OF THE MAIN UART INTERFACE ..................................................................... 43

TABLE 12: PIN DEFINITION OF THE DEBUG UART INTERFACE ................................................................. 43

TABLE 13: LOGIC LEVELS OF DIGITAL I/O .................................................................................................... 44

TABLE 14: PIN DEFINITION OF PCM AND I2C INTERFACES ....................................................................... 46

TABLE 15: PIN DEFINITION OF THE ADC ...................................................................................................... 48

TABLE 16: CHARACTERISTIC OF THE ADC .................................................................................................. 48

TABLE 17: PIN DEFINITION OF NETWORK CONNECTION STATUS/ACTIVITY INDICATOR ...................... 49

TABLE 18: WORKING STATE OF NETWORK CONNECTION STATUS/ACTIVITY INDICATOR ................... 49

TABLE 19: PIN DEFINITION OF STATUS ........................................................................................................ 50

TABLE 20: BEHAVIOR OF THE RI ................................................................................................................... 51

TABLE 21: PIN DEFINITION OF THE SGMII INTERFACE .............................................................................. 52

TABLE 22: PIN DEFINITION OF WIRELESS CONNECTIVITY INTERFACES ................................................ 54

TABLE 23: PIN DEFINITION OF USB_BOOT INTERFACE ............................................................................. 57

TABLE 24: GNSS PERFORMANCE ................................................................................................................. 58

TABLE 25: PIN DEFINITION OF THE RF ANTENNA ....................................................................................... 60

TABLE 26: MODULE OPERATING FREQUENCIES ........................................................................................ 60

TABLE 27: PIN DEFINITION OF GNSS ANTENNA INTERFACE ..................................................................... 64

TABLE 28: GNSS FREQUENCY ....................................................................................................................... 64

TABLE 29: ANTENNA REQUIREMENTS .......................................................................................................... 65

TABLE 30: ABSOLUTE MAXIMUM RATINGS .................................................................................................. 68

TABLE 31: POWER SUPPLY RATINGS ........................................................................................................... 68

TABLE 32: OPERATING TEMPERATURE ........................................................................................................ 69

TABLE 33: EC21-A CURRENT CONSUMPTION ............................................................................................. 70

TABLE 34: EC21-AUT CURRENT CONSUMPTION ........................................................................................ 71

TABLE 35: EC21-E CURRENT CONSUMPTION ............................................................................................. 72

TABLE 36: EC21-KL CURRENT CONSUMPTION ........................................................................................... 73

TABLE 37: EC21-V CURRENT CONSUMPTION ............................................................................................. 74

TABLE 38: EC21-AUV CURRENT CONSUMPTION ........................................................................................ 74

TABLE 39: GNSS CURRENT CONSUMPTION OF EC21 SERIES MODULE ................................................. 75

TABLE 40: RF OUTPUT POWER ..................................................................................................................... 76

TABLE 41: EC21-E CONDUCTED RF RECEIVING SENSITIVITY .................................................................. 76

EC21_Hardware_Design Confidential / Released 6 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

TABLE 42: EC21-A CONDUCTED RF RECEIVING SENSITIVITY .................................................................. 77

TABLE 43: EC21-V CONDUCTED RF RECEIVING SENSITIVITY .................................................................. 77

TABLE 44: EC21-AUT CONDUCTED RF RECEIVING SENSITIVITY ............................................................. 77

TABLE 45: EC21-AUTL CONDUCTED RF RECEIVING SENSITIVITY ........................................................... 78

TABLE 46: EC21-KL CONDUCTED RF RECEIVING SENSITIVITY ................................................................ 78

TABLE 47: EC21-CT CONDUCTED RF RECEIVING SENSITIVITY ................................................................ 78

TABLE 48: EC21-J CONDUCTED RF RECEIVING SENSITIVITY................................................................... 79

TABLE 49: EC21-AUV CONDUCTED RF RECEIVING SENSITIVITY ............................................................. 79

TABLE 50: ELECTROSTATIC DISCHARGE CHARACTERISTICS ................................................................. 80

TABLE 51: RELATED DOCUMENTS ................................................................................................................ 88

TABLE 52: TERMS AND ABBREVIATIONS ...................................................................................................... 88

TABLE 53: DESCRIPTION OF DIFFERENT CODING SCHEMES .................................................................. 92

TABLE 54: GPRS MULTI-SLOT CLASSES ...................................................................................................... 93

TABLE 55: EDGE MODULATION AND CODING SCHEMES ........................................................................... 94

EC21_Hardware_Design Confidential / Released 7 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

Figure Index

FIGURE 1: FUNCTIONAL DIAGRAM ............................................................................................................... 16

FIGURE 2: PIN ASSIGNMENT (TOP VIEW) .................................................................................................... 18

FIGURE 3: SLEEP MODE APPLICATION VIA UART ....................................................................................... 29

FIGURE 4: SLEEP MODE APPLICATION WITH USB REMOTE WAKEUP .................................................... 30

FIGURE 5: SLEEP MODE APPLICATION WITH RI ......................................................................................... 31

FIGURE 6: SLEEP MODE APPLICATION WITHOUT SUSPEND FUNCTION ................................................ 31

FIGURE 7: POWER SUPPLY LIMITS DURING BURST TRANSMISSION ...................................................... 33

FIGURE 8: STAR STRUCTURE OF THE POWER SUPPLY ............................................................................ 34

FIGURE 9: REFERENCE CIRCUIT OF POWER SUPPLY .............................................................................. 34

FIGURE 10: TURN ON THE MODULE USING DRIVING CIRCUIT ................................................................. 35

FIGURE 11: TURN ON THE MODULE USING KEYSTROKE .......................................................................... 36

FIGURE 12: TIMING OF TURNING ON MODULE ........................................................................................... 36

FIGURE 13: TIMING OF TURNING OFF MODULE ......................................................................................... 37

FIGURE 14: REFERENCE CIRCUIT OF RESET_N BY USING DRIVING CIRCUIT ...................................... 38

FIGURE 15: REFERENCE CIRCUIT OF RESET_N BY USING BUTTON ...................................................... 38

FIGURE 16: TIMING OF RESETTING MODULE ............................................................................................. 39

FIGURE 17: REFERENCE CIRCUIT OF USIM CARD INTERFACE WITH AN 8-PIN USIM CARD

CONNECTOR .................................................................................................................................................... 40

FIGURE 18: REFERENCE CIRCUIT OF USIM CARD INTERFACE WITH A 6-PIN USIM CARD CONNECTOR

........................................................................................................................................................................... 40

FIGURE 19: REFERENCE CIRCUIT OF USB APPLICATION ......................................................................... 42

FIGURE 20: REFERENCE CIRCUIT WITH TRANSLATOR CHIP ................................................................... 44

FIGURE 21: REFERENCE CIRCUIT WITH TRANSISTOR CIRCUIT .............................................................. 45

FIGURE 22: PRIMARY MODE TIMING ............................................................................................................ 46

FIGURE 23: AUXILIARY MODE TIMING .......................................................................................................... 46

FIGURE 24: REFERENCE CIRCUIT OF PCM APPLICATION WITH AUDIO CODEC .................................... 47

FIGURE 25: REFERENCE CIRCUIT OF THE NETWORK INDICATOR .......................................................... 50

FIGURE 26: REFERENCE CIRCUITS OF STATUS ......................................................................................... 50

FIGURE 27: SIMPLIFIED BLOCK DIAGRAM FOR ETHERNET APPLICATION ............................................. 52

FIGURE 28: REFERENCE CIRCUIT OF SGMII INTERFACE WITH PHY AR8033 APPLICATION ................. 53

FIGURE 29: REFERENCE CIRCUIT OF WIRELESS CONNECTIVITY INTERFACES WITH FC20 MODULE

........................................................................................................................................................................... 55

FIGURE 30: REFERENCE CIRCUIT OF USB_BOOT INTERFACE ................................................................ 57

FIGURE 31: REFERENCE CIRCUIT OF RF ANTENNA INTERFACE ............................................................. 61

FIGURE 32: MICROSTRIP LINE DESIGN ON A 2-LAYER PCB ...................................................................... 62

FIGURE 33: COPLANAR WAVEGUIDE LINE DESIGN ON A 2-LAYER PCB .................................................. 62

FIGURE 34: COPLANAR WAVEGUIDE LINE DESIGN ON A 4-LAYER PCB (LAYER 3 AS REFERENCE

GROUND) .......................................................................................................................................................... 63

FIGURE 35: COPLANAR WAVEGUIDE LINE DESIGN ON A 4-LAYER PCB (LAYER 4 AS REFERENCE

GROUND) .......................................................................................................................................................... 63

FIGURE 36: REFERENCE CIRCUIT OF GNSS ANTENNA ............................................................................. 64

EC21_Hardware_Design Confidential / Released 8 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

FIGURE 37: DIMENSIONS OF THE UF.L-R-SMT CONNECTOR (UNIT: MM) ................................................ 66

FIGURE 38: MECHANICALS OF UF.L-LP CONNECTORS ............................................................................. 66

FIGURE 39: SPACE FACTOR OF MATED CONNECTOR (UNIT: MM) ........................................................... 67

FIGURE 40: MODULE TOP AND SIDE DIMENSIONS ..................................................................................... 81

FIGURE 41: MODULE BOTTOM DIMENSIONS (BOTTOM VIEW) ................................................................. 82

FIGURE 42: RECOMMENDED FOOTPRINT (TOP VIEW) .............................................................................. 83

FIGURE 43: TOP VIEW OF THE MODULE ...................................................................................................... 84

FIGURE 44: BOTTOM VIEW OF THE MODULE .............................................................................................. 84

FIGURE 45: REFLOW SOLDERING THERMAL PROFILE .............................................................................. 86

FIGURE 46: TAPE AND REEL SPECIFICATIONS ........................................................................................... 87

EC21_Hardware_Design Confidential / Released 9 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

1 Introduction

This document defines the EC21 module and describes its air interface and hardware interface which are connected with your application.

This document can help you quickly understand module interface specifications, electrical and mechanical details, as well as other related information of EC21 module. Associated with application note and user guide, you can use EC21 module to design and set up mobile applications easily.

EC21_Hardware_Design Confidential / Released 10 / 94

LTE Module Series

Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a mobile while driving (even with a handsfree kit) causes distraction and can lead to an accident. You must comply with laws and regulations restricting the use of wireless devices while driving.

Switch off the cellular terminal or mobile before boarding an aircraft. Make sure it is switched off. The operation of wireless appliances in an aircraft is forbidden, so as to prevent interference with communication systems. Consult the airline staff about the use of wireless devices on boarding the aircraft, if your device offers an Airplane Mode which must be enabled prior to boarding an aircraft.

Switch off your wireless device when in hospitals, clinics or other health care facilities. These requests are designed to prevent possible interference with sensitive medical equipment.

Cellular terminals or mobiles operating over radio frequency signal and cellular network cannot be guaranteed to connect in all conditions, for example no mobile fee or with an invalid USIM/SIM card. While you are in this condition and need emergent help, please remember using emergency call. In order to make or receive a call, the cellular terminal or mobile must be switched on and in a service area with adequate cellular signal strength.

Your cellular terminal or mobile contains a transmitter and receiver. When it is ON, it receives and transmits radio frequency energy. RF interference can occur if it is used close to TV set, radio, computer or other electric equipment.

In locations with potentially explosive atmospheres, obey all posted signs to turn off wireless devices such as your phone or other cellular terminals. Areas with potentially explosive atmospheres include fuelling areas, below decks on boats, fuel or chemical transfer or storage facilities, areas where the air contains chemicals or particles such as grain, dust or metal powders, etc.

Quectel

Confidential

EC21 Hardware Design

1.1. Safety Information

The following safety precautions must be observed during all phases of the operation, such as usage, service or repair of any cellular terminal or mobile incorporating EC21 module. Manufacturers of the cellular terminal should send the following safety information to users and operating personnel, and incorporate these guidelines into all manuals supplied with the product. If not so, Quectel assumes no liability for the customer’s failure to comply with these precautions.

EC21_Hardware_Design Confidential / Released 11 / 94

LTE Module Series

Modules2)

LTE Bands

3G Bands

GSM

Rxdiversity

GNSS1)

EC21-E

FDD: B1/B3/B5/B7/B8/B20

WCDMA: B1/B5/B8

900/1800

Y

GPS, GLONASS, BeiDou/ Compass, Galileo, QZSS

EC21-A

FDD: B2/B4/B12

WCDMA: B2/B4/B5

N

Y

EC21-V

FDD: B4/B13

N N Y

EC21-AUT

FDD: B1/B3/B5/B7/B28

WCDMA:

B1/B5

N

Y

EC21-AU3)

FDD: B1/B2/B3/B4/B5/B7/B8/ B28 TDD: B40

WCDMA: B1/B2/B5/B8

850/900/ 1800/1900

Y

EC21-AUV

FDD: B1/B3/B5/B8/B28

B1/B5/B8

N Y N

EC21-AUTL

FDD: B3/B7/B28

N N Y

N

EC21-J

FDD: B1/B3/B8/B18/B19/B26

N N Y

N

EC21-CT

FDD: B1/B3/B5

N N N

N

EC21-KL

FDD: B1/B3/B5/B7/B8

N N Y

N

Quectel

Confidential

EC21 Hardware Design

2 Product Concept

2.1. General Description

EC21 is a series of LTE-FDD/LTE-TDD/WCDMA/GSM wireless communication module with receive diversity. It provides data connectivity on LTE-FDD, LTE-TDD, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA, EDGE and GPRS networks. It also provides GNSS1) and voice functionality2) for your specific applications. EC21 contains ten variants: EC21-E, EC21-A, EC21-V, EC21-AUT, EC21-AU, EC21-AUV, EC21-AUTL, EC21-J, EC21-CT and EC21-KL. You can choose a dedicated type based on the region or operator. The following table shows the frequency bands of EC21 series module.

Table 1: Frequency Bands of EC21 Series Module

EC21_Hardware_Design Confidential / Released 12 / 94

LTE Module Series

1.

1)

GNSS function is optional.

2.

2)

EC21 series module (EC21-E, EC21-A, EC21-V, EC21-AUT, EC21-AU, EC21-AUV, EC21-AUTL, EC21-J, EC21-CT and EC21-KL) includes Data-only and Telematics versions. Data-only version does not support voice function, while Telematics version supports it.

3.

3)

B2 band on EC21-AU module does not support Rx-diversity.

4. Y = supported (including LTE and WCDMA). N = Not supported.

Features

Details

Power Supply

Supply voltage: 3.3V~4.3V Typical supply voltage: 3.8V

Transmitting Power

Class 4 (33dBm±2dB) for GSM850 Class 4 (33dBm±2dB) for GSM900 Class 1 (30dBm±2dB) for DCS1800 Class 1 (30dBm±2dB) for PCS1900 Class E2 (27dBm±3dB) for GSM850 8-PSK Class E2 (27dBm±3dB) for GSM900 8-PSK Class E2 (26dBm±3dB) for DCS1800 8-PSK Class E2 (26dBm±3dB) for PCS1900 8-PSK Class 3 (24dBm+1/-3dB) for WCDMA bands Class 3 (23dBm±2dB) for LTE-FDD bands Class 3 (23dBm±2dB) for LTE-TDD bands

LTE Features

Support up to non-CA CAT1 Support 1.4 to 20MHz RF bandwidth Support MIMO in DL direction FDD: Max 5Mbps (UL), 10Mbps (DL)

NOTES

Quectel

Confidential

EC21 Hardware Design

With a compact profile of 32.0mm × 29.0mm × 2.4mm, EC21 can meet almost all requirements for M2M applications such as automotive, metering, tracking system, security, router, wireless POS, mobile computing device, PDA phone, tablet PC, etc.

EC21 is an SMD type module which can be embedded into applications through its 144-pin pads, including 80 LCC signal pads and 64 other pads.

2.2. Key Features

The following table describes the detailed features of EC21 module.

Table 2: EC21 Key Features of EC21 Module

EC21_Hardware_Design Confidential / Released 13 / 94

LTE Module Series

TDD: Max 3.1Mbps (UL), 8.96Mbps (DL)

WCDMA Features

Support 3GPP R8 DC-HSPA+ Support 16-QAM, 64-QAM and QPSK modulation 3GPP R6 CAT6 HSUPA: Max 5.76Mbps (UL) 3GPP R8 CAT24 DC-HSPA+: Max 42Mbps (DL)

GSM Features

R99:

CSD: 9.6kbps, 14.4kbps

GPRS:

Support GPRS multi-slot class 12 (12 by default) Coding scheme: CS-1, CS-2, CS-3 and CS-4 Maximum of four Rx time slots per frame

EDGE:

Support EDGE multi-slot class 12 (12 by default) Support GMSK and 8-PSK for different MCS (Modulation and Coding Scheme) Downlink coding schemes: CS 1-4 and MCS 1-9 Uplink coding schemes: CS 1-4 and MCS 1-9

Internet Protocol Features

Support TCP/UDP/PPP/FTP/HTTP/NTP/PING/QMI/HTTPS*/SMTP*/ MMS*/FTPS*/SSL* protocols Support PAP (Password Authentication Protocol) and CHAP (Challenge Handshake Authentication Protocol) protocols which are usually used for PPP connections

SMS

Text and PDU mode Point to point MO and MT SMS cell broadcast SMS storage: ME by default

USIM Interface

Support USIM/SIM card: 1.8V, 3.0V

Audio Features

Support one digital audio interface: PCM interface GSM: HR/FR/EFR/AMR/AMR-WB WCDMA: AMR/AMR-WB LTE: AMR/AMR-WB Support echo cancellation and noise suppression

PCM Interface

Used for audio function with external codec Support 8-bit A-law*, μ-law* and 16-bit linear data formats Support long frame synchronization and short frame synchronization Support master and slave modes, but must be the master in long frame synchronization

USB Interface

Compliant with USB 2.0 specification (slave only); the data transfer rate can reach up to 480Mbps Used for AT command communication, data transmission, GNSS NMEA output, software debugging, firmware upgrade and voice over USB* Support USB drivers for Windows XP, Windows Vista, Windows 7,

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 14 / 94

LTE Module Series

Windows 8/8.1, Window 10, Linux 2.6 or later, Android

4.0/4.2/4.4/5.0/5.1/6.0

UART Interface

Main UART:

Used for AT command communication and data transmission Baud rate reach up to 3000000bps, 115200bps by default Support RTS and CTS hardware flow control

Debug UART:

Used for Linux console, log output 115200bps baud rate

SGMII Interface

Support 10/100/1000Mbps Ethernet connectivity

Wireless Connectivity Interfaces

Support a low-power SDIO 3.0 interface for WLAN and UART/PCM interface for Bluetooth*

Rx-diversity

Support LTE/WCDMA Rx-diversity

GNSS Features

Gen8C Lite of Qualcomm Protocol: NMEA 0183

AT Commands

Compliant with 3GPP TS 27.007, 27.005 and Quectel enhanced AT commands

Network Indication

Two pins including NET_MODE and NET_STATUS to indicate network connectivity status

Antenna Interface

Including main antenna interface (ANT_MAIN), Rx-diversity antenna interface (ANT_DIV) and GNSS antenna interface (ANT_GNSS)

Physical Characteristics

Size: (32.0±0.15) × (29.0±0.15) × (2.4±0.2)mm Weight: approx. 4.9g

Temperature Range

Operation temperature range: -35°C ~ +75°C1) Extended temperature range: -40°C ~ +85°C2)

Firmware Upgrade

USB interface and DFOTA*

RoHS

All hardware components are fully compliant with EU RoHS directive

1. 1) Within operating temperature range, the module is 3GPP compliant.

2. 2) Within extended temperature range, the module remains the ability to establish and maintain a voice, SMS, data transmission, emergency call, etc. There is no unrecoverable malfunction. There are also no effects on radio spectrum and no harm to radio network. Only one or more parameters like P

out

might reduce in their value and exceed the specified tolerances. When the temperature

returns to normal operating temperature levels, the module will meet 3GPP specifications again.

3. “*” means under development.

NOTES

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 15 / 94

LTE Module Series

Baseband

PMIC

Transceiver

NAND DDR2

SDRAM

PA

Switch

LNA

Switch

ANT_MAIN ANT_DIVANT_GNSS

VBAT_BB

VBAT_RF

APT

PWRKEY

ADCs

VDD_EXT

USB

USIM

PCM

UART

I2C

RESET_N

19.2M XO

STATUS

GPIOs

SAW

Control

IQ Control

Duplex

SAW

Tx

PRx DRx

SGMII

WLAN

BT

Quectel

Confidential

EC21 Hardware Design

2.3. Functional Diagram

The following figure shows a block diagram of EC21 and illustrates the major functional parts.

 Power management  Baseband  DDR+NAND flash  Radio frequency  Peripheral interfaces

2.4. Evaluation Board

In order to help you develop applications with EC21, Quectel supplies an evaluation board (EVB), USB data cable, earphone, antenna and other peripherals to control or test the module.

Figure 1: Functional Diagram

EC21_Hardware_Design Confidential / Released 16 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

3 Application Interfaces

3.1. General Description

EC21 is equipped with 80-pin SMT pads plus 64-pin ground pads and reserved pads that can be connected to cellular application platform. Sub-interfaces included in these pads are described in detail in the following chapters:

 Power supply  USIM interface  USB interface  UART interfaces  PCM interface  ADC interface  Status indication  SGMII interface  Wireless connectivity interfaces  USB_BOOT interface

EC21_Hardware_Design Confidential / Released 17 / 94

LTE Module Series

34335

36

20

21

222324

252627

282930

313233

1

4 5 6 7

2

WAKEUP_IN

1)

AP_READY

RESERVED

W_DISABLE# NET_MODE

1)

NET_STATUS

VDD_EXT

GND GND

DBG_RXD

DBG_TXD

USIM_PRESENCE

USIM_VDD

USIM_DATA

USIM_CLK

USIM_RST

RESERVED

8

9 10 11 12 13 14 15 16 17 18

19

54 53 52 51 50 49 48

47 46 45 44 43 42 41 40 39 38 37

72

71

70

696867

666564

636261

605958

575655

USIM_GND

GND

RESET_N

PWRKEY

2)

GND

RESERVED

PCM_IN※PCM_OUT※PCM_SYNC※PCM_CLK

※

RESERVED

ANT_DIV

GND

USB_VBUS

USB_DM

USB_DP

RXD

TXD

DTR

RTS

CTS

DCD

RI

STATUS

VBAT_BB

VBAT_RF

GND

RESERVED

GND GND ANT_MAIN GND

ANT_GNSS GND

ADC1 RESERVED I2C_SDA I2C_SCL BT_CTS

ADC0

GND

73 74

75

76 77 78

79 80 81

82 83 84

100

101

102

106

107

111

112

103

104

109

105

110

89

94

98

88

93

97

86

91

96

85

90

95

99

87

92

108

113

RESERVED

117

126

125

124

123

122

121

120

119

118

127

128

115

USB_BOOT

RESERVED

116

139

140

138

137

136

135

134

133

132

131

130

129

114

RESERVED

Power Pins

BT_RXD BT_TXD BT_RTS

Signal Pins RESERVED PinsGND Pins

RESERVED RESERVED

141

142

RESERVED RESERVED

143

144

SGMII Pins

WLAN Pins Bluetooth Pins

1. 1) means that these pins cannot be pulled up before startup.

2.

2)

PWRKEY output voltage is 0.8V because of the diode drop in the Qualcomm chipset.

3. Pads 119~126 are SGMII function pins.

4. Pads 37~40, 118, 127 and 129~139 are wireless connectivity interfaces, among which pads 127 and 129~138 are WLAN function pins, and others are Bluetooth (BT) function pins. BT function is under development.

5. Pads 24~27 are multiplexing pins used for audio design on EC21 module and BT function on FC20

NOTES

Quectel

Confidential

EC21 Hardware Design

3.2. Pin Assignment

The following figure shows the pin assignment of EC21 module.

Figure 2: Pin Assignment (Top View)

EC21_Hardware_Design Confidential / Released 18 / 94

LTE Module Series

module.

6. Keep all RESERVED pins and unused pins unconnected.

7. GND pads 85~112 should be connected to ground in the design, and RESERVED pads 73~84 should not be designed in schematic and PCB decal.

8. “※” means these interface functions are only supported on Telematics version.

Type

Description

IO

Bidirectional

DI

Digital input

DO

Digital output

PI

Power input

PO

Power output

AI

Analog input

AO

Analog output

OD

Open drain

Power Supply

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

VBAT_BB

59, 60

PI

Power supply for module baseband part

Vmax=4.3V Vmin=3.3V Vnorm=3.8V

It must be able to provide sufficient current up to

0.8A.

VBAT_RF

57, 58

PI

Power supply for module RF part

Vmax=4.3V Vmin=3.3V Vnorm=3.8V

It must be able to provide sufficient current up to

1.8A in a burst

transmission.

Quectel

Confidential

EC21 Hardware Design

3.3. Pin Description

The following tables show the pin definition of EC21 module.

Table 3: I/O Parameters Definition

Table 4: Pin Description

EC21_Hardware_Design Confidential / Released 19 / 94

LTE Module Series

VDD_EXT

7

PO

Provide 1.8V for external circuit

Vnorm=1.8V IOmax=50mA

Power supply for

external GPIO’s pull up

circuits.

GND

8, 9, 19, 22, 36, 46, 48, 50~54, 56, 72, 85~112

Ground

Turn on/off

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

PWRKEY

21

DI

Turn on/off the module

VIHmax=2.1V VIHmin=1.3V VILmax=0.5V

The output voltage is

0.8V because of the

diode drop in the Qualcomm chipset.

RESET_N

20

DI

Reset the module

VIHmax=2.1V VIHmin=1.3V VILmax=0.5V

Status Indication

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

STATUS

61

OD

Indicate the module operating status

The drive current should be less than

0.9mA.

Require external pull-up. If unused, keep it open.

NET_MODE

5

DO

Indicate the module network registration mode

VOHmin=1.35V VOLmax=0.45V

1.8V power domain.

Cannot be pulled up before startup. If unused, keep it open.

NET_ STATUS

6

DO

Indicate the module network activity status

VOHmin=1.35V VOLmax=0.45V

1.8V power domain.

If unused, keep it open.

USB Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

USB_VBUS

71

PI

USB detection

Vnorm=5.0V

USB_DP

69

IO

USB differential data bus

Compliant with USB

2.0 standard

specification.

Require differential impedance of 90 ohm.

USB_DM

70

IO

USB differential data bus

Compliant with USB

2.0 standard

specification.

Require differential impedance of 90 ohm.

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 20 / 94

LTE Module Series

USIM Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

USIM_GND

10

Specified ground for USIM card

USIM_VDD

14

PO

Power supply for USIM card

For 1.8V USIM: Vmax=1.9V Vmin=1.7V

For 3.0V USIM: Vmax=3.05V Vmin=2.7V IOmax=50mA

Either 1.8V or 3.0V is supported by the module automatically.

USIM_DATA

15

IO

Data signal of USIM card

For 1.8V USIM: VILmax=0.6V VIHmin=1.2V VOLmax=0.45V VOHmin=1.35V

For 3.0V USIM: VILmax=1.0V VIHmin=1.95V VOLmax=0.45V VOHmin=2.55V

USIM_CLK

16

DO

Clock signal of USIM card

For 1.8V USIM: VOLmax=0.45V VOHmin=1.35V

For 3.0V USIM: VOLmax=0.45V VOHmin=2.55V

USIM_RST

17

DO

Reset signal of USIM card

For 1.8V USIM: VOLmax=0.45V VOHmin=1.35V

For 3.0V USIM: VOLmax=0.45V VOHmin=2.55V

USIM_ PRESENCE

13

DI

USIM card insertion detection

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 21 / 94

LTE Module Series

UART Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

RI

62

DO

Ring indicator

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

DCD

63

DO

Data carrier detection

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

CTS

64

DO

Clear to send

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

RTS

65

DI

Request to send

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

DTR

66

DI

Data terminal ready, sleep mode control

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

Pull-up by default. Low level wakes up the module. If unused, keep it open.

TXD

67

DO

Transmit data

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

RXD

68

DI

Receive data

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

Debug UART Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

DBG_TXD

12

DO

Transmit data

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

DBG_RXD

11

DI

Receive data

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

ADC Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

ADC0

45

AI

General purpose analog to digital converter

Voltage range:

0.3V to VBAT_BB

If unused, keep it open.

ADC1

44

AI

General purpose analog to digital converter

Voltage range:

0.3V to VBAT_BB

If unused, keep it open.

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 22 / 94

LTE Module Series

PCM Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

PCM_IN

24

DI

PCM data input

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open. PCM_OUT

25

DO

PCM data output

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

PCM_SYNC

26

IO

PCM data frame synchronization signal

VOLmax=0.45V VOHmin=1.35V VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

In master mode, it is an output signal. In slave mode, it is an input signal. If unused, keep it open.

PCM_CLK

27

IO

PCM clock

VOLmax=0.45V VOHmin=1.35V VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

In master mode, it is an output signal. In slave mode, it is an input signal. If unused, keep it open.

I2C Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

I2C_SCL

41

OD

I2C serial clock. Used for external codec

External pull-up resistor is required.

1.8V only.

If unused, keep it open.

I2C_SDA

42

OD

I2C serial data. Used for external codec

External pull-up resistor is required.

1.8V only.

If unused, keep it open.

SGMII Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

EPHY_RST_N

119

DO

Ethernet PHY reset

For 1.8V: VOLmax=0.45V VOHmin=1.4V

For 2.85V: VOLmax=0.35V VOHmin=2.14V

1.8V/2.85V power

domain. If unused, keep it open.

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 23 / 94

LTE Module Series

EPHY_INT_N

120

DI

Ethernet PHY interrupt

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

SGMII_ MDATA

121

IO

SGMII MDIO (Management Data Input/Output) data

For 1.8V: VOLmax=0.45V VOHmin=1.4V VILmax=0.58V VIHmin=1.27V

For 2.85V: VOLmax=0.35V VOHmin=2.14V VILmax=0.71V VIHmin=1.78V

1.8V/2.85V power

domain. If unused, keep it open.

SGMII_ MCLK

122

DO

SGMII MDIO (Management Data Input/Output) clock

For 1.8V: VOLmax=0.45V VOHmin=1.4V

For 2.85V: VOLmax=0.35V VOHmin=2.14V

1.8V/2.85V power

domain. If unused, keep it open.

USIM2_VDD

128

PO

SGMII MDIO pull-up power source

Configurable power source.

1.8V/2.85V power

domain. External pull-up for SGMII MDIO pins. If unused, keep it open.

SGMII_TX_M

123

AO

SGMII transmission

- minus

If unused, keep it open.

SGMII_TX_P

124

AO

SGMII transmission

- plus

If unused, keep it open.

SGMII_RX_P

125

AI

SGMII receiving

- plus

If unused, keep it open.

SGMII_RX_M

126

AI

SGMII receiving

- minus

If unused, keep it open.

Wireless Connectivity Interfaces

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

SDC1_ DATA3

129

IO

SDIO data bus D3

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 24 / 94

LTE Module Series

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

open.

SDC1_ DATA2

130

IO

SDIO data bus D2

VOLmax=0.45V VOHmin=1.35V VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

SDC1_ DATA1

131

IO

SDIO data bus D1

VOLmax=0.45V VOHmin=1.35V VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

SDC1_ DATA0

132

IO

SDIO data bus D1

VOLmax=0.45V VOHmin=1.35V VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

SDC1_CLK

133

DO

SDIO clock

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

SDC1_CMD

134

DO

SDIO command

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

PM_ENABLE

127

DO

External power control

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

WAKE_ON_ WIRELESS

135

DI

Wake up the host (EC21 module) by FC20 module.

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

Active low. If unused, keep it open.

WLAN_EN

136

DO

WLAN function control via FC20 module

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

Active high. If unused, keep it open.

COEX_UART_ RX

137

DI

LTE/WLAN coexistence signal

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 25 / 94

LTE Module Series

COEX_UART_ TX

138

DO

LTE/WLAN coexistence signal

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

WLAN_SLP_ CLK

118

DO

WLAN sleep clock

If unused, keep it open.

BT_RTS*

37

DI

BT UART request to send

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

BT_TXD*

38

DO

BT UART transmit data

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

BT_RXD*

39

DI

BT UART receive data

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

BT_CTS*

40

DO

BT UART clear to send

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

BT_EN*

139

DO

BT function control via FC20 module

VOLmax=0.45V VOHmin=1.35V

1.8V power domain.

If unused, keep it open.

RF Interface

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

ANT_DIV

35

AI

Diversity antenna pad

50 ohm impedance

If unused, keep it open.

ANT_MAIN

49

IO

Main antenna pad

50 ohm impedance

ANT_GNSS

47

AI

GNSS antenna pad

50 ohm impedance

If unused, keep it open.

GPIO Pins

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

WAKEUP_IN

1

DI

Sleep mode control

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

Cannot be pulled up before startup. Low level wakes up the module. If unused, keep it open.

W_DISABLE#

4

DI

Airplane mode

VILmin=-0.3V

1.8V power domain.

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 26 / 94

LTE Module Series

control

VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

Pull-up by default. In low voltage level, module can enter into airplane mode. If unused, keep it open.

AP_READY

2

DI

Application processor sleep state detection

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

Other Interface Pins

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

USB_BOOT

115

DI

Force the module to boot from USB port.

VILmin=-0.3V VILmax=0.6V VIHmin=1.2V VIHmax=2.0V

1.8V power domain.

If unused, keep it open.

RESERVED Pins

Pin Name

Pin No.

I/O

Description

DC Characteristics

Comment

RESERVED

3, 18, 23, 28~34, 43, 55, 73~84, 113, 114, 116, 117, 140~144

Reserved

Keep these pins unconnected.

1. “*” means under development.

2. Pads 24~27 are multiplexing pins used for audio design on EC21 module and BT function on FC20 module.

NOTES

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 27 / 94

LTE Module Series

Mode

Details

Normal Operation

Idle

Software is active. The module has been registered on the network, and it is ready to send and receive data.

Talk/Data

Network connection is ongoing. In this mode, the power consumption is decided by network setting and data transfer rate.

Minimum Functionality Mode

AT+CFUN command can set the module to a minimum functionality mode without removing the power supply. In this case, both RF function and USIM card will be invalid.

Airplane Mode

AT+CFUN command or W_DISABLE# pin can set the module to airplane mode. In this case, RF function will be invalid.

Sleep Mode

In this mode, the current consumption of the module will be reduced to the minimal level. During this mode, the module can still receive paging message, SMS, voice call and TCP/UDP data from the network normally.

Power down Mode

In this mode, the power management unit shuts down the power supply. Software is not active. The serial interface is not accessible. Operating voltage (connected to VBAT_RF and VBAT_BB) remains applied.

Quectel

Confidential

EC21 Hardware Design

3.4. Operating Modes

The table below briefly summarizes the various operating modes referred in the following chapters.

Table 5: Overview of Operating Modes

3.5. Power Saving

3.5.1. Sleep Mode

EC21 is able to reduce its current consumption to a minimum value during the sleep mode. The following section describes power saving procedure of EC21 module.

3.5.1.1. UART Application

If the host communicates with module via UART interface, the following preconditions can let the module enter into sleep mode.

 Execute AT+QSCLK=1 command to enable sleep mode.  Drive DTR to high level.

EC21_Hardware_Design Confidential / Released 28 / 94

LTE Module Series

RXD

TXD

RI

DTR

AP_READY

TXD

RXD

EINT

GPIO

Module

Host

GND

AT+QCFG=“apready” command is under development.

NOTE

Quectel

Confidential

EC21 Hardware Design

The following figure shows the connection between the module and the host.

Figure 3: Sleep Mode Application via UART

 Driving the host DTR to low level will wake up the module.  When EC21 has URC to report, RI signal will wake up the host. Refer to Chapter 3.16 for details

about RI behavior.

 AP_READY will detect the sleep state of the host (can be configured to high level or low level

detection). Please refer to AT+QCFG=“apready” command for details.

3.5.1.2. USB Application with USB Remote Wakeup Function

If the host supports USB suspend/resume and remote wakeup functions, the following three preconditions must be met to let the module enter into sleep mode.

 Execute AT+QSCLK=1 command to enable sleep mode.  Ensure the DTR is held in high level or keep it open.  The host’s USB bus, which is connected with the module’s USB interface, enters into suspended

state.

EC21_Hardware_Design Confidential / Released 29 / 94

LTE Module Series

USB_VBUS

USB_DP

USB_DM

AP_READY

VDD

USB_DP

USB_DM

GPIO

Module

Host

GND

Quectel

Confidential

EC21 Hardware Design

The following figure shows the connection between the module and the host.

Figure 4: Sleep Mode Application with USB Remote Wakeup

 Sending data to EC21 through USB will wake up the module.  When EC21 has URC to report, the module will send remote wake-up signals via USB bus so as to

wake up the host.

3.5.1.3. USB Application with USB Suspend/Resume and RI Function

If the host supports USB suspend/resume, but does not support remote wake-up function, the RI signal is needed to wake up the host.

There are three preconditions to let the module enter into the sleep mode.

 Execute AT+QSCLK=1 command to enable sleep mode.  Ensure the DTR is held in high level or keep it open.  The host’s USB bus, which is connected with the module’s USB interface, enters into suspended

state.

EC21_Hardware_Design Confidential / Released 30 / 94

LTE Module Series

USB_VBUS

USB_DP

USB_DM

AP_READY

VDD

USB_DP

USB_DM

GPIO

Module Host

GND

RI

EINT

USB_VBUS

USB_DP

USB_DM

AP_READY

VDD

USB_DP

USB_DM

GPIO

Module Host

RI

EINT

Power

Switch

GPIO

GND

Quectel

Confidential

EC21 Hardware Design

The following figure shows the connection between the module and the host.

Figure 5: Sleep Mode Application with RI

 Sending data to EC21 through USB will wake up the module.  When EC21 has URC to report, RI signal will wake up the host.

3.5.1.4. USB Application without USB Suspend Function

If the host does not support USB suspend function, you should disconnect USB_VBUS with additional control circuit to let the module enter into sleep mode.

 Execute AT+QSCLK=1 command to enable sleep mode.  Ensure the DTR is held in high level or keep it open.  Disconnect USB_VBUS.

The following figure shows the connection between the module and the host.

Figure 6: Sleep Mode Application without Suspend Function

EC21_Hardware_Design Confidential / Released 31 / 94

LTE Module Series

Please pay attention to the level match shown in dotted line between the module and the host. Refer to document [1] for more details about EC21 power management application.

1. The W_DISABLE# control function is disabled in firmware by default. It can be enabled by AT+QCFG=“airplanecontrol” command. This command is under development.

2. The execution of AT+CFUN command will not affect GNSS function.

NOTES

NOTE

Quectel

Confidential

EC21 Hardware Design

Switching on the power switch to supply power to USB_VBUS will wake up the module.

3.5.2. Airplane Mode

When the module enters into airplane mode, the RF function does not work, and all AT commands correlative with RF function will be inaccessible. This mode can be set via the following ways.

Hardware: The W_DISABLE# pin is pulled up by default; driving it to low level will let the module enter into airplane

mode.

Software: AT+CFUN command provides the choice of the functionality level.

 AT+CFUN=0: Minimum functionality mode; both USIM and RF functions are disabled.  AT+CFUN=1: Full functionality mode (by default).  AT+CFUN=4: Airplane mode. RF function is disabled.

3.6. Power Supply

3.6.1. Power Supply Pins

EC21 provides four VBAT pins for connection with the external power supply. There are two separate voltage domains for VBAT.

 Two VBAT_RF pins for module RF part.  Two VBAT_BB pins for module baseband part.

The following table shows the details of VBAT pins and ground pins.

EC21_Hardware_Design Confidential / Released 32 / 94

LTE Module Series

Pin Name

Pin No.

Description

Min.

Typ.

Max.

Unit

VBAT_RF

57, 58

Power supply for module RF part.

3.3

3.8

4.3 V VBAT_BB

59, 60

Power supply for module baseband part.

3.3

3.8

4.3

V

GND

8, 9, 19, 22, 36, 46, 48, 50~54, 56, 72, 85~112

Ground

- 0 -

V

VBAT

Burst

Transmission

Min.3.3V

Ripple

Drop

Burst

Transmission

Quectel

Confidential

EC21 Hardware Design

Table 6: VBAT and GND Pins

3.6.2. Decrease Voltage Drop

The power supply range of the module is from 3.3V to 4.3V. Please make sure that the input voltage will never drop below 3.3V. The following figure shows the voltage drop during burst transmission in 2G network. The voltage drop will be less in 3G and 4G networks.

Figure 7: Power Supply Limits during Burst Transmission

To decrease voltage drop, a bypass capacitor of about 100µF with low ESR should be used, and a multi-layer ceramic chip (MLCC) capacitor array should also be used to provide the low ESR. The main power supply from an external application has to be a single voltage source and can be expanded to two sub paths with star structure. The width of VBAT_BB trace should be no less than 1mm; and the width of VBAT_RF trace should be no less than 2mm. In principle, the longer the VBAT trace is, the wider it will be.

Three ceramic capacitors (100nF, 33pF, 10pF) are recommended to be applied to the VBAT pins. These capacitors should be placed close to the VBAT pins. In addition, in order to get a stable power source, it is suggested that you should use a zener diode of which reverse zener voltage is 5.1V and dissipation power is more than 0.5W. The following figure shows the star structure of the power supply.

EC21_Hardware_Design Confidential / Released 33 / 94

LTE Module Series

Module

VBAT_RF

VBAT_BB

VBAT

C1

100uF

C6

100nFC733pFC810pF

+

C2

100nF

C5

100uF

C3

33pF

C4

10pF

D1

5.1V

DC_IN

MIC29302WU

IN OUT

EN

GND

ADJ

2 4

1

3

5

VBAT

100nF

470uF

100nF

100K

47K

470uF

470R

51K

1%

4.7K

47K

VBAT_EN

In order to avoid damaging internal flash, please do not switch off the power supply when the module works normally. Only after the module is shut down by PWRKEY or AT command, the power supply can be cut off.

NOTE

Quectel

Confidential

EC21 Hardware Design

Figure 8: Star Structure of the Power Supply

3.6.3. Reference Design for Power Supply

Power design for the module is very important, as the performance of the module largely depends on the power source. The power supply is capable of providing sufficient current up to 2A at least. If the voltage drop between the input and output is not too high, it is suggested that you should use an LDO to supply power for the module. If there is a big voltage difference between the input source and the desired output (VBAT), a buck converter is preferred to be used as the power supply.

The following figure shows a reference design for +5V input power source. The typical output of the power supply is about 3.8V and the maximum load current is 3A.

Figure 9: Reference Circuit of Power Supply

EC21_Hardware_Design Confidential / Released 34 / 94

LTE Module Series

Pin Name

Pin No.

Description

DC Characteristics

Comment

PWRKEY

21

Turn on/off the module

VIHmax=2.1V VIHmin=1.3V VILmax=0.5V

The output voltage is 0.8V because of the diode drop in the Qualcomm chipset.

Turn on pulse

PWRKEY

4.7K

47K

≥100ms

Quectel

Confidential

EC21 Hardware Design

3.6.4. Monitor the Power Supply

AT+CBC command can be used to monitor the VBAT_BB voltage value. For more details, please refer to

document [2].

3.7. Turn on and off Scenarios

3.7.1. Turn on Module Using the PWRKEY

The following table shows the pin definition of PWRKEY.

Table 7: PWRKEY Pin Description

When EC21 is in power down mode, it can be turned on to normal mode by driving the PWRKEY pin to a low level for at least 100ms. It is recommended to use an open drain/collector driver to control the PWRKEY. After STATUS pin (require external pull-up) outputting a low level, PWRKEY pin can be released. A simple reference circuit is illustrated in the following figure.

Figure 10: Turn on the Module Using Driving Circuit

The other way to control the PWRKEY is using a button directly. When pressing the key, electrostatic strike may generate from finger. Therefore, a TVS component is indispensable to be placed nearby the button for ESD protection. A reference circuit is shown in the following figure.

EC21_Hardware_Design Confidential / Released 35 / 94

LTE Module Series

PWRKEY

S1

Close to S1

TVS

VIL≤0.5V

VIH≥1.3V

VBAT

PWRKEY

≥100ms

RESET_N

STATUS (OD)

Inactive

Active

UART

NOTE

Inactive

Active

USB

≥2.5s

≥12s

≥13s

Please make sure that VBAT is stable before pulling down PWRKEY pin. The time between them is no less than 30ms.

NOTE

Quectel

Confidential

EC21 Hardware Design

Figure 11: Turn on the Module Using Keystroke

The turn on scenario is illustrated in the following figure.

Figure 12: Timing of Turning on Module

EC21_Hardware_Design Confidential / Released 36 / 94

LTE Module Series

VBAT

PWRKEY

≥29.5s

≥650ms

RUNNING

Power-down procedure

OFF

Module Status

STATUS (OD)

In order to avoid damaging internal flash, please do not switch off the power supply when the module works normally. Only after the module is shut down by PWRKEY or AT command, the power supply can be cut off.

NOTE

Quectel

Confidential

EC21 Hardware Design

3.7.2. Turn off Module

The following procedures can be used to turn off the module:

 Normal power down procedure: Turn off the module using the PWRKEY pin.  Normal power down procedure: Turn off the module using AT+QPOWD command.

3.7.2.1. Turn off Module Using the PWRKEY Pin

Driving the PWRKEY pin to a low level voltage for at least 650ms, the module will execute power-down procedure after the PWRKEY is released. The power-down scenario is illustrated in the following figure.

Figure 13: Timing of Turning off Module

3.7.2.2. Turn off Module Using AT Command

It is also a safe way to use AT+QPOWD command to turn off the module, which is similar to turning off the module via PWRKEY pin.

Please refer to document [2] for details about AT+QPOWD command.

EC21_Hardware_Design Confidential / Released 37 / 94

LTE Module Series

Pin Name

Pin No.

Description

DC Characteristics

Comment

RESET_N

20

Reset the module

VIHmax=2.1V VIHmin=1.3V VILmax=0.5V

Reset pulse

RESET_N

4.7K

47K

TBD

RESET_N

S2

Close to S2

TVS

Quectel

Confidential

EC21 Hardware Design

3.8. Reset the Module

The RESET_N pin can be used to reset the module. The module can be reset by driving RESET_N to a low level voltage for time between 150ms and 460ms.

Table 8: RESET_N Pin Description

The recommended circuit is similar to the PWRKEY control circuit. An open drain/collector driver or button can be used to control the RESET_N.

Figure 14: Reference Circuit of RESET_N by Using Driving Circuit

Figure 15: Reference Circuit of RESET_N by Using Button

EC21_Hardware_Design Confidential / Released 38 / 94

LTE Module Series

VIL≤0.5V

VIH≥1.3V

VBAT

≥150ms

Resetting

Module Status

Running

RESET_N

Restart

≤460ms

1. Use RESET_N only when turning off the module by AT+QPOWD command and PWRKEY pin failed.

2. Ensure that there is no large capacitance on PWRKEY and RESET_N pins.

Pin Name

Pin No.

I/O

Description

Comment

USIM_VDD

14

PO

Power supply for USIM card

Either 1.8V or 3.0V is supported by the module automatically.

USIM_DATA

15

IO

Data signal of USIM card

USIM_CLK

16

DO

Clock signal of USIM card

USIM_RST

17

DO

Reset signal of USIM card

USIM_ PRESENCE

13

DI

USIM card insertion detection

USIM_GND

10 Specified ground for USIM card

NOTES

Quectel

Confidential

EC21 Hardware Design

The reset scenario is illustrated in the following figure.

Figure 16: Timing of Resetting Module

3.9. USIM Card Interface

The USIM card interface circuitry meets ETSI and IMT-2000 SIM interface requirements. Both 1.8V and

3.0V USIM cards are supported.

Table 9: Pin Definition of the USIM Card Interface

EC21_Hardware_Design Confidential / Released 39 / 94

LTE Module Series

Module

USIM_VDD

USIM_GND

USIM_RST USIM_CLK

USIM_DATA

USIM_PRESENCE

22R

VDD_EXT

51K

100nF USIM Card Connector

GND

33pF

33pF 33pF

VCC RST

CLK

IO

VPP

GND

USIM_VDD

15K

Module

USIM_VDD

USIM_GND

USIM_RST USIM_CLK

USIM_DATA

22R

100nF

USIM Card Connector

GND

33pF 33pF 33pF

VCC

RST CLK IO

VPP

GND

15K

USIM_VDD

Quectel

Confidential

EC21 Hardware Design

EC21 supports USIM card hot-plug via the USIM_PRESENCE pin. The function supports low level and high level detections, and is disabled by default. Please refer to document [2] about AT+QSIMDET command for details.

The following figure shows a reference design for USIM card interface with an 8-pin USIM card connector.

Figure 17: Reference Circuit of USIM Card Interface with an 8-Pin USIM Card Connector

If USIM card detection function is not needed, please keep USIM_PRESENCE unconnected. A reference circuit for USIM card interface with a 6-pin USIM card connector is illustrated in the following figure.

Figure 18: Reference Circuit of USIM Card Interface with a 6-Pin USIM Card Connector

EC21_Hardware_Design Confidential / Released 40 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

USB Signal Part

USB_DP

69

IO

USB differential data bus (positive)

Require differential impedance of 90Ω

USB_DM

70

IO

USB differential data bus (minus)

Require differential impedance of 90Ω

USB_VBUS

71

PI

Used for detecting the USB connection

Typical 5.0V

GND

72 Ground

Quectel

Confidential

EC21 Hardware Design

In order to enhance the reliability and availability of the USIM card in your application, please follow the criteria below in USIM circuit design:

 Keep layout of USIM card as close to the module as possible. Keep the trace length as less than

200mm as possible.

 Keep USIM card signals away from RF and VBAT traces.  Assure the ground between the module and the USIM card connector short and wide. Keep the trace

width of ground and USIM_VDD no less than 0.5mm to maintain the same electric potential.

 To avoid cross-talk between USIM_DATA and USIM_CLK, keep them away from each other and

shield them with surrounded ground.

 In order to offer good ESD protection, it is recommended to add a TVS diode array whose parasitic

capacitance should not be more than 50pF. The 22 ohm resistors should be added in series between the module and the USIM card so as to suppress EMI spurious transmission and enhance ESD protection. The 33pF capacitors are used for filtering interference of GSM900. Please note that the USIM peripheral circuit should be close to the USIM card connector.

 The pull-up resistor on USIM_DATA line can improve anti-jamming capability when long layout trace

and sensitive occasion are applied, and should be placed close to the USIM card connector.

3.10. USB Interface

EC21 contains one integrated Universal Serial Bus (USB) transceiver which complies with the USB 2.0 specification and supports high-speed (480Mbps) and full-speed (12Mbps) modes. The USB interface is used for AT command communication, data transmission, GNSS NMEA sentences output, software debugging, firmware upgrade and voice over USB*. The following table shows the pin definition of USB interface.

Table 10: Pin Description of USB Interface

For more details about the USB 2.0 specifications, please visit http://www.usb.org/home.

EC21_Hardware_Design Confidential / Released 41 / 94

LTE Module Series

USB_DP

USB_DM

GND

USB_DP

USB_DM

GND

R1

R2

Close to Module

R3

R4

Test Points

ESD Array

NM_0R

0R

Minimize these stubs

Module

MCU

USB_VBUS

VDD

1. EC21 module can only be used as a slave device.

2. “*” means under development.

NOTES

Quectel

Confidential

EC21 Hardware Design

The USB interface is recommended to be reserved for firmware upgrade in your design. The following figure shows a reference circuit of USB interface.

Figure 19: Reference Circuit of USB Application

In order to ensure the integrity of USB data line signal, components R1, R2, R3 and R4 must be placed close to the module, and also these resistors should be placed close to each other. The extra stubs of trace must be as short as possible.

In order to ensure the USB interface design corresponding with the USB 2.0 specification, please comply with the following principles:

 It is important to route the USB signal traces as differential pairs with total grounding. The impedance

of USB differential trace is 90 ohm.

 Do not route signal traces under crystals, oscillators, magnetic devices or RF signal traces. It is

important to route the USB differential traces in inner-layer with ground shielding on not only upper and lower layers but also right and left sides.

 Pay attention to the influence of junction capacitance of ESD protection components on USB data

lines. Typically, the capacitance value should be less than 2pF.

 Keep the ESD protection components to the USB connector as close as possible.

EC21_Hardware_Design Confidential / Released 42 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

RI

62

DO

Ring indicator

1.8V power domain

DCD

63

DO

Data carrier detection

CTS

64

DO

Clear to send

RTS

65

DI

Request to send

DTR

66

DI

Sleep mode control

TXD

67

DO

Transmit data

RXD

68

DI

Receive data

Pin Name

Pin No.

I/O

Description

Comment

DBG_TXD

12

DO

Transmit data

1.8V power domain

DBG_RXD

11

DI

Receive data

Quectel

Confidential

EC21 Hardware Design

3.11. UART Interfaces

The module provides two UART interfaces: the main UART interface and the debug UART interface. The following shows their features.

 The main UART interface supports 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800,

921600 and 3000000bps baud rates, and the default is 115200bps. The interface is used for data transmission and AT command communication.

 The debug UART interface supports 115200bps baud rate. It is used for Linux console and log

output.

The following tables show the pin definition of the main UART interface.

Table 11: Pin Definition of the Main UART Interface

Table 12: Pin Definition of the Debug UART Interface

EC21_Hardware_Design Confidential / Released 43 / 94

LTE Module Series

Parameter

Min.

Max.

Unit

VIL

-0.3

0.6 V VIH

1.2

2.0 V VOL 0 0.45

V

VOH

1.35

1.8

V

VCCA VCCB

OE

A1 A2 A3

A4 A5 A6 A7 A8

GND

B1 B2 B3 B4 B5 B6 B7 B8

VDD_EXT

RI

DCD

RTS

RXD

DTR

CTS

TXD

51K

0.1uF

RI_MCU

DCD_MCU

RTS_MCU

RXD_MCU

DTR_MCU

CTS_MCU

TXD_MCU

VDD_MCU

Translator

Quectel

Confidential

EC21 Hardware Design

The logic levels are described in the following table.

Table 13: Logic Levels of Digital I/O

The module provides 1.8V UART interface. A level translator should be used if your application is equipped with a 3.3V UART interface. A level translator TXS0108EPWR provided by Texas Instrument is recommended. The following figure shows a reference design.

Figure 20: Reference Circuit with Translator Chip

Please visit http://www.ti.com for more information.

Another example with transistor translation circuit is shown as below. The circuit design of dotted line section can refer to the design of solid line section, in terms of both module input and output circuit designs; but please pay attention to the direction of connection.

EC21_Hardware_Design Confidential / Released 44 / 94

LTE Module Series

MCU/ARM

TXD

RXD

VDD_EXT

10K

VCC_MCU

4.7K

10K

VDD_EXT

TXD

RXD

RTS CTS DTR RI

RTS CTS

GND

GPIO DCD

Module

GPIO

EINT

VDD_EXT

4.7K

GND

1nF

Transistor circuit solution is not suitable for applications with high baud rates exceeding 460Kbps.

NOTE

Quectel

Confidential

EC21 Hardware Design

Figure 21: Reference Circuit with Transistor Circuit

3.12. PCM and I2C Interfaces

EC21 provides one Pulse Code Modulation (PCM) digital interface for audio design, which supports the following modes:

 Primary mode (short frame synchronization, works as both master and slave)  Auxiliary mode (long frame synchronization, works as master only)

In primary mode, the data is sampled on the falling edge of the PCM_CLK and transmitted on the rising edge. The PCM_SYNC falling edge represents the MSB. In this mode, PCM_CLK supports 128, 256, 512, 1024 and 2048kHz for different speech codecs.

In auxiliary mode, the data is also sampled on the falling edge of the PCM_CLK and transmitted on the rising edge. But the PCM_SYNC rising edge represents the MSB. In this mode, PCM interface operates with a 128kHz PCM_CLK and an 8kHz, 50% duty cycle PCM_SYNC only.

EC21 supports 8-bit A-law* and μ-law*, and also 16-bit linear data formats. The following figures show the

primary mode’s timing relationship with 8kHz PCM_SYNC and 2048kHz PCM_CLK, as well as the auxiliary mode’s timing relationship with 8kHz PCM_SYNC and 128kHz PCM_CLK.

EC21_Hardware_Design Confidential / Released 45 / 94

LTE Module Series

PCM_CLK

PCM_SYNC

PCM_OUT

MSB

LSB

MSB

125us

1 2 256255

PCM_IN

MSB

LSBMSB

PCM_CLK

PCM_SYNC

PCM_OUT

MSB

LSB

PCM_IN

125us

MSB

1 2 1615

LSB

Pin Name

Pin No.

I/O

Description

Comment

PCM_IN

24

DI

PCM data input

1.8V power domain

PCM_OUT

25

DO

PCM data output

1.8V power domain

PCM_SYNC

26

IO

PCM data frame sync signal

1.8V power domain

Quectel

Confidential

EC21 Hardware Design

Figure 22: Primary Mode Timing

The following table shows the pin definition of PCM and I2C interfaces which can be applied on audio codec design.

Table 14: Pin Definition of PCM and I2C Interfaces

EC21_Hardware_Design Confidential / Released 46 / 94

Figure 23: Auxiliary Mode Timing

LTE Module Series

PCM_CLK

27

IO

PCM data bit clock

1.8V power domain

I2C_SCL

41

OD

I2C serial clock

Require external pull-up to 1.8V

I2C_SDA

42

OD

I2C serial data

Require external pull-up to 1.8V

PCM_IN

PCM_OUT

PCM_SYNC

PCM_CLK

I2C_SCL

I2C_SDA

Module

1.8V

4.7K

BCLK

LRCK

DAC

ADC

SCL

SDA

BIAS

MICBIAS

INP INN

LOUTP

LOUTN

Codec

1. “*” means under development.

2. It is recommended to reserve RC (R=22 ohm, C=22pF) circuit on the PCM lines, especially for PCM_CLK.

3. EC21 works as a master device pertaining to I2C interface.

NOTES

Quectel

Confidential

EC21 Hardware Design

Clock and mode can be configured by AT command, and the default configuration is master mode using short frame synchronization format with 2048kHz PCM_CLK and 8kHz PCM_SYNC. Please refer to document [2] about AT+QDAI command for details.

The following figure shows a reference design of PCM interface with external codec IC.

Figure 24: Reference Circuit of PCM Application with Audio Codec

EC21_Hardware_Design Confidential / Released 47 / 94

LTE Module Series

Pin Name

Pin No.

Description

ADC0

45

General purpose analog to digital converter

ADC1

44

General purpose analog to digital converter

Parameter

Min.

Typ.

Max.

Unit

ADC0 Voltage Range

0.3 VBAT_BB

V

ADC1 Voltage Range

0.3 VBAT_BB

V

ADC Resolution

15

bits

1. ADC input voltage must not exceed VBAT_BB.

2. It is prohibited to supply any voltage to ADC pins when VBAT is removed.

3. It is recommended to use resistor divider circuit for ADC application.

NOTES

Quectel

Confidential

EC21 Hardware Design

3.13. ADC Function

The module provides two analog-to-digital converters (ADC). AT+QADC=0 command can be used to read the voltage value on ADC0 pin. AT+QADC=1 command can be used to read the voltage value on ADC1 pin. For more details about these AT commands, please refer to document [2].

In order to improve the accuracy of ADC, the trace of ADC should be surrounded by ground.

Table 15: Pin Definition of the ADC

The following table describes the characteristic of the ADC function.

Table 16: Characteristic of the ADC

EC21_Hardware_Design Confidential / Released 48 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

NET_MODE1)

5

DO

Indicate the module’s network registration status

1.8V power domain

NET_STATUS

6

DO

Indicate the module’s network activity status

1)

means that this pin cannot be pulled up before startup.

Pin Name

Logic Level Changes

Network Status

NET_MODE Always High

Registered on LTE network

Always Low

Others

NET_STATUS

Flicker slowly (200ms High/1800ms Low)

Network searching

Flicker slowly (1800ms High/200ms Low)

Idle

Flicker quickly (125ms High/125ms Low)

Data transfer is ongoing

Always High

Voice calling

NOTE

Quectel

Confidential

EC21 Hardware Design

3.14. Network Status Indication

The network indication pins can be used to drive network status indication LEDs. The module provides two pins which are NET_MODE and NET_STATUS. The following tables describe the pin definition and logic level changes in different network status.

Table 17: Pin Definition of Network Connection Status/Activity Indicator

Table 18: Working State of Network Connection Status/Activity Indicator

A reference circuit is shown in the following figure.

EC21_Hardware_Design Confidential / Released 49 / 94

LTE Module Series

4.7K

47K

VBAT

2.2K

Module

Network Indicator

Pin Name

Pin No.

I/O

Description

Comment

STATUS

61

OD

Indicate the module’s operation status

Require external pull-up

VDD_MCU

10K

Module

STATUS MCU_GPIO

Module

STATUS

VBAT

2.2K

Quectel

Confidential

EC21 Hardware Design

Figure 25: Reference Circuit of the Network Indicator

3.15. STATUS

The STATUS pin is an open drain output for indicating the module’s operation status. You can connect it to a GPIO of DTE with a pull up resistor, or as the LED indication circuit shown below. When the module is turned on normally, the STATUS will present the low state. Otherwise, the STATUS will present high-impedance state.

Table 19: Pin Definition of STATUS

The following figure shows different circuit designs of STATUS, and you can choose either one according to your application demands.

EC21_Hardware_Design Confidential / Released 50 / 94

Figure 26: Reference Circuits of STATUS

LTE Module Series

URC can be output from UART port, USB AT port and USB modem port by AT+QURCCFG command. The default port is USB AT port.

State

Response

Idle

RI keeps in high level

URC

RI outputs 120ms low pulse when new URC returns

NOTE

Quectel

Confidential

EC21 Hardware Design

3.16. Behavior of the RI

AT+QCFG=“risignaltype”,“physical” command can be used to configure RI behavior.

No matter on which port URC is presented, URC will trigger the behavior of RI pin.

In addition, RI behavior can be configured flexibly. The default behavior of the RI is shown as below.

Table 20: Behavior of the RI

The RI behavior can be changed by AT+QCFG=“urc/ri/ring” command. Please refer to document [2] for details.

3.17. SGMII Interface

EC21 includes an integrated Ethernet MAC with an SGMII interface and two management interfaces, key features of the SGMII interface are shown below:

 IEEE802.3 compliance  Full duplex at 1000Mbps  Half/full duplex for 10/100Mbps  Support VLAN tagging  Support IEEE1588 and Precision Time Protocol (PTP)  Can be used to connect to external Ethernet PHY like AR8033, or to an external switch  Management interfaces support dual voltage 1.8V/2.85V

The following table shows the pin definition of SGMII interface.

EC21_Hardware_Design Confidential / Released 51 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

Control Signal Part

EPHY_RST_N

119

DO

Ethernet PHY reset

1.8V/2.85V power domain

EPHY_INT_N

120

DI

Ethernet PHY interrupt

1.8V power domain

SGMII_MDATA

121

IO

SGMII MDIO (Management Data Input/Output) data

1.8V/2.85V power domain

SGMII_MCLK

122

DO

SGMII MDIO (Management Data Input/Output) clock

1.8V/2.85V power domain

USIM2_VDD

128

PO

SGMII MDIO pull-up power source

Configurable power source.

1.8V/2.85V power domain.

External pull-up power source for SGMII MDIO pins.

SGMII Signal Part

SGMII_TX_M

123

AO

SGMII transmission-minus

Connect with a 0.1uF capacitor, close to the PHY side.

SGMII_TX_P

124

AO

SGMII transmission-plus

Connect with a 0.1uF capacitor, close to the PHY side.

SGMII_RX_P

125

AI

SGMII receiving-plus

Connect with a 0.1uF capacitor, close to EC21 module.

SGMII_RX_M

126

AI

SGMII receiving-minus

Connect with a 0.1uF capacitor, close to EC21 module.

Module

AR8033

Ethernet

Transformer

RJ45

SGMII

Control

MDI

Quectel

Confidential

EC21 Hardware Design

Table 21: Pin Definition of the SGMII Interface

The following figure shows the simplified block diagram for Ethernet application.

Figure 27: Simplified Block Diagram for Ethernet Application

The following figure shows a reference design of SGMII interface with PHY AR8033 application.

EC21_Hardware_Design Confidential / Released 52 / 94

LTE Module Series

SGMII_MDATA

EPHY_INT_N

MDIO

RSTN

MDC

R1 R2

10K

VDD_EXT

Module

AR8033

1.5K USIM2_VDD

EPHY_RST_N

INT

SGMII_MCLK

C1

C2

C3

C4

SGMII_TX_M

SGMII_TX_P

SGMII_RX_P

SGMII_RX_M

SIP

SIN

SOP

SON

Close to Module

Close to AR8033

Control

SGMII Data

0.1uF

USIM2_VDD

For more information about SGMII application, please refer to document [5] and document [7].

NOTE

Quectel

Confidential

EC21 Hardware Design

Figure 28: Reference Circuit of SGMII Interface with PHY AR8033 Application

In order to enhance the reliability and availability in your application, please follow the criteria below in the Ethernet PHY circuit design:

 Keep SGMII data and control signals away from RF and VBAT trace.  Keep the maximum trace length less than 10inch and keep skew on the differential pairs less than

20mil.

 The differential impedance of SGMII data trace is 100ohm±10%.  To minimize crosstalk, the distance between separate adjacent pairs that are on the same layer must

be equal to or larger than 40mil.

EC21_Hardware_Design Confidential / Released 53 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

WLAN Part

SDC1_DATA3

129

IO

SDIO data bus D3

1.8V power domain

SDC1_DATA2

130

IO

SDIO data bus D2

1.8V power domain

SDC1_DATA1

131

IO

SDIO data bus D1

1.8V power domain

SDC1_DATA0

132

IO

SDIO data bus D0

1.8V power domain

SDC1_CLK

133

DO

SDIO clock

1.8V power domain

SDC1_CMD

134

IO

SDIO command

1.8V power domain

WLAN_EN

136

DO

WLAN function control via FC20 module. Active high.

1.8V power domain

Coexistence and Control Part

PM_ENABLE

127

DO

External power control

1.8V power domain

WAKE_ON_ WIRELESS

135

DI

Wake up the host (EC21 module) by FC20 module.

1.8V power domain

COEX_UART_RX

137

DI

LTE/WLAN&BT coexistence signal

1.8V power domain

COEX_UART_TX

138

DO

LTE/WLAN&BT coexistence signal

1.8V power domain

WLAN_SLP_CLK

118

DO

WLAN sleep clock

BT Part*

BT_RTS*

37

DI

BT UART request to send

1.8V power domain

BT_TXD*

38

DO

BT UART transmit data

1.8V power domain

BT_RXD*

39

DI

BT UART receive data

1.8V power domain

Quectel

Confidential

EC21 Hardware Design

3.18. Wireless Connectivity Interfaces

EC21 supports a low-power SDIO 3.0 interface for WLAN and a UART/PCM interface for BT.

The following table shows the pin definition of wireless connectivity interfaces.

Table 22: Pin Definition of Wireless Connectivity Interfaces

EC21_Hardware_Design Confidential / Released 54 / 94

LTE Module Series

BT_CTS*

40

DO

BT UART clear to send

1.8V power domain

PCM_IN1)

24

DI

PCM data input

1.8V power domain

PCM_OUT1)

25

DO

PCM data output

1.8V power domain

PCM_SYNC1)

26

IO

PCM data frame sync signal

1.8V power domain

PCM_CLK1)

27

IO

PCM data bit clock

1.8V power domain

BT_EN*

139

DO

WLAN function control via FC20 module. Active high.

1.8V power domain

1. “*” means under development.

2.

1)

Pads 24~27 are multiplexing pins used for audio design on EC21 module and BT function on FC20

module.

Module

SDC1_DATA3

SDC1_DATA2

SDC1_DATA1

SDC1_DATA0

SDC1_CLK

SDC1_CMD

WLAN_EN

COEX_UART_TX

WAKE_ON_WIRELESS

COEX_UART_RX

WLAN_SLP_CLK

BT_EN

PM_ENABLE

BT_RTS

BT_CTS

BT_TXD

BT_RXD

PCM_IN

PCM_OUT

PCM_CLK

DCDC/LDO

PCM_SYNC

SDIO_D3

SDIO_D2

SDIO_D1

SDIO_D0

SDIO_CLK

SDIO_CMD

WLAN_EN

32KHz_IN

WAKE_ON_WIRELESS

LTE_UART_TXD

LTE_UART_RXD

FC20 Module

BT_EN

BT_UART_RTS

BT_UART_CTS

BT_UART_RXD

BT_UART_TXD

PCM_OUT

PCM_IN

PCM_CLK

PCM_SYNC

VDD_3V3

WLAN

COEX & Control

BT

NOTES

Quectel

Confidential

EC21 Hardware Design

The following figure shows a reference design of wireless connectivity interfaces with Quectel FC20 module.

Figure 29: Reference Circuit of Wireless Connectivity Interfaces with FC20 Module

EC21_Hardware_Design Confidential / Released 55 / 94

LTE Module Series

1. FC20 module can only be used as a slave device,

2. When BT function is enabled on EC21 module, PCM_SYNC and PCM_CLK pins are only used to output signals.

3. For more information about wireless connectivity interfaces, please refer to document [5].

“*” means under development.

NOTES

NOTE

Quectel

Confidential

EC21 Hardware Design

3.18.1. WLAN Interface

EC21 provides a low power SDIO 3.0 interface and control interface for WLAN design.

SDIO interface supports the following modes:

 Single data rate (SDR) mode (up to 200MHz)  Double data rate (DDR) mode (up to 52MHz)

As SDIO signals are very high-speed, in order to ensure the SDIO interface design corresponds with the SDIO 3.0 specification, please comply with the following principles:

 It is important to route the SDIO signal traces with total grounding. The impedance of SDIO signal

trace is 50 ohm (±10%).

 Protect other sensitive signals/circuits (RF, analog signals, etc.) from SDIO corruption and protect

SDIO signals from noisy signals (clocks, DCDCs, etc.).

 It is recommended to keep matching length between CLK and DATA/CMD less than 1mm and total

routing length less than 50mm.

 Keep termination resistors within 15~24 ohm on clock lines near the module and keep the route

distance from the module clock pins to termination resistors less than 5mm.

 Make sure the adjacent trace spacing is 2x line width and bus capacitance is less than 15pF.

3.18.2. BT Interface*

EC21 supports a dedicated UART interface and a PCM interface for BT function application.

Further information about BT interface will be added in future version of this document.

EC21_Hardware_Design Confidential / Released 56 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

USB_BOOT

115

DI

Force the module to boot from USB port

1.8V power domain.

Active high. If unused, keep it open.

Module

USB_BOOT

VDD_EXT

10K

Test point

TVS

Close to test point

Quectel

Confidential

EC21 Hardware Design

3.19. USB_BOOT Interface

EC21 provides a USB_BOOT pin. During development or factory production, USB_BOOT pin can force the module to boot from USB port for firmware upgrade.

Table 23: Pin Definition of USB_BOOT Interface

The following figure shows a reference circuit of USB_BOOT interface.

EC21_Hardware_Design Confidential / Released 57 / 94

Figure 30: Reference Circuit of USB_BOOT Interface

LTE Module Series

Parameter

Description

Conditions

Typ.

Unit

Sensitivity (GNSS)

Cold start

Autonomous

-146

dBm

Reacquisition

Autonomous

-157

dBm

Tracking

Autonomous

-157

dBm

TTFF (GNSS)

Cold start @open sky

Autonomous

35

s

XTRA enabled

18

s

Warm start @open sky

Autonomous

26 s XTRA enabled

2.2

s

Quectel

Confidential

EC21 Hardware Design

4 GNSS Receiver

4.1. General Description

EC21 includes a fully integrated global navigation satellite system solution that supports Gen8C-Lite of Qualcomm (GPS, GLONASS, BeiDou, Galileo and QZSS).

EC21 supports standard NMEA-0183 protocol, and outputs NMEA sentences at 1Hz data update rate via USB interface by default.

By default, EC21 GNSS engine is switched off. It has to be switched on via AT command. For more details about GNSS engine technology and configurations, please refer to document [3].

4.2. GNSS Performance

The following table shows the GNSS performance of EC21.

Table 24: GNSS Performance

EC21_Hardware_Design Confidential / Released 58 / 94

LTE Module Series

Hot start @open sky

Autonomous

2.5

s

XTRA enabled

1.8

s

Accuracy (GNSS)

CEP-50

Autonomous @open sky

<1.5

m

1. Tracking sensitivity: the lowest GNSS signal value at the antenna port on which the module can keep on positioning for 3 minutes.

2. Reacquisition sensitivity: the lowest GNSS signal value at the antenna port on which the module can fix position again within 3 minutes after loss of lock.

3. Cold start sensitivity: the lowest GNSS signal value at the antenna port on which the module fixes position within 3 minutes after executing cold start command.

NOTES

Quectel

Confidential

EC21 Hardware Design

4.3. Layout Guidelines

The following layout guidelines should be taken into account in your design.

 Maximize the distance among GNSS antenna, main antenna and the Rx-diversity antenna.  Digital circuits such as USIM card, USB interface, camera module, display connector and SD card

should be kept away from the antennas.

 Use ground vias around the GNSS trace and sensitive analog signal traces to provide coplanar

isolation and protection.

 Keep 50 ohm characteristic impedance for the ANT_GNSS trace.

Please refer to Chapter 5 for GNSS antenna reference design and antenna consideration.

EC21_Hardware_Design Confidential / Released 59 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

ANT_MAIN

49

IO

Main antenna pad

50 ohm impedance

ANT_DIV

35

AI

Receive diversity antenna pad

50 ohm impedance

3GPP Band

Transmit

Receive

Unit

B1

1920~1980

2110~2170

MHz

B2 (1900)

1850~1910

1930~1990

MHz

B3 (1800)

1710~1785

1805~1880

MHz

B4

1710~1755

2110~2155

MHz

B5 (850)

824~849

869~894

MHz

B7

2500~2570

2620~2690

MHz

B8 (900)

880~915

925~960

MHz

Quectel

Confidential

EC21 Hardware Design

5 Antenna Interfaces

EC21 antenna interfaces include a main antenna interface, an Rx-diversity antenna interface which is used to resist the fall of signals caused by high speed movement and multipath effect, and a GNSS antenna interface. The antenna interfaces have an impedance of 50 ohm.

5.1. Main/Rx-diversity Antenna Interface

5.1.1. Pin Definition

The pin definition of main antenna and Rx-diversity antenna interfaces is shown below.

Table 25: Pin Definition of the RF Antenna

5.1.2. Operating Frequency

Table 26: Module Operating Frequencies

EC21_Hardware_Design Confidential / Released 60 / 94

LTE Module Series

B12

699~716

729~746

MHz

B13

777~787

746~756

MHz

B18

815~830

860~875

MHz

B19

830~845

875~890

MHz

B20

832~862

791~821

MHz

B26

814~849

859~894

MHz

B28

703~748

758~803

MHz

B40

2300~2400

MHz

ANT_MAIN

R1 0R

C1

Module

Main antenna

NM

C2

NM

R2 0R

C3

Diversity antenna

NM

C4

NM

ANT_DIV

1. Keep a proper distance between the main antenna and the Rx-diversity antenna to improve the receiving sensitivity.

2. ANT_DIV function is enabled by default.

3. Place the π-type matching components (R1, C1, C2, R2, C3, C4) as close to the antenna as possible.

NOTES

Quectel

Confidential

EC21 Hardware Design

5.1.3. Reference Design of RF Antenna Interface

A reference design of ANT_MAIN and ANT_DIV antenna pads is shown as below. It should reserve a π-type matching circuit for better RF performance. The capacitors are not mounted by default.

Figure 31: Reference Circuit of RF Antenna Interface

EC21_Hardware_Design Confidential / Released 61 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

5.1.4. Reference Design of RF Layout

For user’s PCB, the characteristic impedance of all RF traces should be controlled as 50 ohm. The

impedance of the RF traces is usually determined by the trace width (W), the materials’ dielectric constant, the distance between signal layer and reference ground (H), and the clearance between RF trace and ground (S). Microstrip line or coplanar waveguide line is typically used in RF layout for characteristic impedance control. The following are reference designs of microstrip line or coplanar waveguide line with different PCB structures

.

Figure 32: Microstrip Line Design on a 2-layer PCB

Figure 33: Coplanar Waveguide Line Design on a 2-layer PCB

EC21_Hardware_Design Confidential / Released 62 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

Figure 34: Coplanar Waveguide Line Design on a 4-layer PCB (Layer 3 as Reference Ground)

Figure 35: Coplanar Waveguide Line Design on a 4-layer PCB (Layer 4 as Reference Ground)

In order to ensure RF performance and reliability, the following principles should be complied with in RF layout design:

 Use impedance simulation tool to control the characteristic impedance of RF traces as 50 ohm.  The GND pins adjacent to RF pins should not be hot welded, and should be fully connected to

ground.

 The distance between the RF pins and the RF connector should be as short as possible, and all the

right angle traces should be changed to curved ones.

 There should be clearance area under the signal pin of the antenna connector or solder joint.  The reference ground of RF traces should be complete. Meanwhile, adding some ground vias around

RF traces and the reference ground could help to improve RF performance. The distance between the ground vias and RF traces should be no less than two times the width of RF signal traces (2*W).

For more details about RF layout, please refer to document [6].

EC21_Hardware_Design Confidential / Released 63 / 94

LTE Module Series

Pin Name

Pin No.

I/O

Description

Comment

ANT_GNSS

47

AI

GNSS antenna

50 ohm impedance

Type

Frequency

Unit

GPS/Galileo/QZSS

1575.42±1.023

MHz

GLONASS

1597.5~1605.8

MHz

BeiDou

1561.098±2.046

MHz

GNSS Antenna

VDD

Module

ANT_GNSS

47nH

10R

0.1uF

100pF

NMNM

1. An external LDO can be selected to supply power according to the active antenna requirement.

2. If the module is designed with a passive antenna, then the VDD circuit is not needed.

NOTES

Quectel

Confidential

EC21 Hardware Design

5.2. GNSS Antenna Interface

The following tables show the pin definition and frequency specification of GNSS antenna interface.

Table 27: Pin Definition of GNSS Antenna Interface

Table 28: GNSS Frequency

A reference design of GNSS antenna is shown as below.

Figure 36: Reference Circuit of GNSS Antenna

EC21_Hardware_Design Confidential / Released 64 / 94

LTE Module Series

Type

Requirements

GNSS

Frequency range: 1561~1615MHz Polarization: RHCP or linear VSWR: <2 (Typ.) Passive antenna gain: >0dBi Active antenna noise figure: <1.5dB Active antenna gain: >-2dBi Active antenna embedded LNA gain: 20dB (Typ.) Active antenna total gain: >18dBi (Typ.)

GSM/WCDMA/LTE

VSWR: ≤2 Gain (dBi): 1 Max input power (W): 50 Input Impedance (ohm): 50 Polarization type: Vertical Cable insertion loss: <1dB (GSM850, GSM900, WCDMA B5/B8, LTE B5/B8/B12/B13/B18/B19/B20/B26/B28) Cable insertion loss: <1.5dB (GSM1800, GSM1900, WCDMA B1/B2/B4, LTE B1/B2/B3/B4) Cable insertion loss <2dB (LTE B7/B40)

Quectel

Confidential

EC21 Hardware Design

5.3. Antenna Installation

5.3.1. Antenna Requirement

The following table shows the requirements on main antenna, Rx-diversity antenna and GNSS antenna.

Table 29: Antenna Requirements

EC21_Hardware_Design Confidential / Released 65 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

5.3.2. Recommended RF Connector for Antenna Installation

If RF connector is used for antenna connection, it is recommended to use UF.L-R-SMT connector provided by HIROSE.

Figure 37: Dimensions of the UF.L-R-SMT Connector (Unit: mm)

U.FL-LP serial connectors listed in the following figure can be used to match the UF.L-R-SMT.

Figure 38: Mechanicals of UF.L-LP Connectors

EC21_Hardware_Design Confidential / Released 66 / 94

LTE Module Series

Quectel

Confidential

EC21 Hardware Design

The following figure describes the space factor of mated connector.

Figure 39: Space Factor of Mated Connector (Unit: mm)

For more details, please visit http://www.hirose.com.

EC21_Hardware_Design Confidential / Released 67 / 94

LTE Module Series

Parameter

Min.

Max.

Unit

VBAT_RF/VBAT_BB

-0.3

4.7

V

USB_VBUS

-0.3

5.5

V

Peak Current of VBAT_BB

0

0.8

A

Peak Current of VBAT_RF

0

1.8 A Voltage at Digital Pins

-0.3

2.3

V

Voltage at ADC0

0

VBAT_BB

V

Voltage at ADC1

0

VBAT_BB

V

Parameter

Description

Conditions

Min.

Typ.

Max.

Unit

VBAT

VBAT_BB and

Voltage must stay within the

3.3

3.8

4.3

V

Quectel

Confidential

EC21 Hardware Design

6 Electrical, Reliability and Radio

Characteristics

6.1. Absolute Maximum Ratings

Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are listed in the following table.

Table 30: Absolute Maximum Ratings

6.2. Power Supply Ratings

Table 31: Power Supply Ratings

EC21_Hardware_Design Confidential / Released 68 / 94

LTE Module Series

VBAT_RF

min/max values, including voltage drop, ripple and spikes.

Voltage drop during burst transmission

Maximum power control level on GSM900

400

mV

I

VBAT

Peak supply current (during transmission slot)

Maximum power control level on GSM900

1.8

2.0

A USB_VBUS

USB detection

3.0

5.0

5.25

V

Parameter

Min.

Typ.

Max.

Unit

Operation Temperature Range1)

-35

+25

+75

ºC

Extended Temperature Range2)

-40 +85

ºC

1.

1)

Within operation temperature range, the module is 3GPP compliant.

2.

2)

Within extended temperature range, the module remains the ability to establish and maintain a voice, SMS, data transmission, emergency call, etc. There is no unrecoverable malfunction. There are also no effects on radio spectrum and no harm to radio network. Only one or more parameters like P

out

might reduce in their value and exceed the specified tolerances. When the temperature

returns to the normal operating temperature levels, the module will meet 3GPP specifications again.

NOTES

Quectel

Confidential

EC21 Hardware Design

6.3. Operating Temperature

The operating temperature is listed in the following table.

Table 32: Operating Temperature

EC21_Hardware_Design Confidential / Released 69 / 94

LTE Module Series

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

OFF state

Power down

20

uA

Sleep state

AT+CFUN=0 (USB disconnected)

1.0

mA

WCDMA PF=64 (USB disconnected)

2.8

mA

WCDMA PF=128 (USB disconnected)

2.3

mA

LTE-FDD PF=64 (USB disconnected)

2.2

mA

LTE-FDD PF=128 (USB disconnected)

2.2

mA

Idle state (GNSS OFF)

WCDMA PF=64 (USB disconnected)

21.6

mA

WCDMA PF=64 (USB connected)

31.6

mA

LTE-FDD PF=64 (USB disconnected)

23.7

mA

LTE-FDD PF=64 (USB connected)

36.5

mA

WCDMA data transfer (GNSS OFF)

WCDMA B2 HSDPA @22.09dBm

542.0

mA

WCDMA B2 HSUPA @22.28dBm

681.0

mA

WCDMA B4 HSDPA @21.94dBm

550.0

mA

WCDMA B4 HSUPA @21.81dBm

547.0

mA

WCDMA B5 HSDPA @22.13dBm

429.0

mA

WCDMA B5 HSUPA @22.48dBm

459.0

mA

LTE data transfer (GNSS OFF)

LTE-FDD B2 @22.79dBm

709.0

mA

LTE-FDD B4 @22.89dBm

710.0

mA

LTE-FDD B12 @23.39dBm

679.0

mA

WCDMA voice call

WCDMA B2 @23.67dBm

663.0

mA

Quectel

Confidential

EC21 Hardware Design

6.4. Current Consumption

The values of current consumption are shown below.

Table 33: EC21-A Current Consumption

EC21_Hardware_Design Confidential / Released 70 / 94

LTE Module Series

WCDMA B4 @23.36dBm

594.0

mA

WCDMA B5 @23.64dBm

522.0

mA

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

OFF state

Power down

20

uA

Sleep state

AT+CFUN=0 (USB disconnected)

0.99

mA

WCDMA PF=64 (USB disconnected)

2.1

mA

WCDMA PF=128 (USB disconnected)

1.7

mA

LTE-FDD PF=64 (USB disconnected)

2.9

mA

LTE-FDD PF=128 (USB disconnected)

2.4

mA

Idle state

WCDMA PF=64 (USB disconnected)

22.0

mA

WCDMA PF=64 (USB connected)

32.0

mA

LTE-FDD PF=64 (USB disconnected)

23.6

mA

LTE-FDD PF=64 (USB connected)

33.6

mA

WCDMA data (GNSS OFF)

WCDMA B1 HSDPA @22.59dBm

589.0

mA

WCDMA B1 HSUPA @22.29dBm

623.0

mA

WCDMA B5 HSDPA @22.22dBm

511.0

mA

WCDMA B5 HSUPA @21.64dBm

503.0

mA

LTE data transfer (GNSS OFF)

LTE-FDD B1 @23.38dBm

813.0

mA

LTE-FDD B3 @22.87dBm

840.0

mA

LTE-FDD B5 @23.12dBm

613.0

mA

LTE-FDD B7 @22.96dBm

761.0

mA

LTE-FDD B28 @23.31dBm

650.0

mA

WCDMA voice call

WCDMA B1 @24.21dBm

687.0

mA

WCDMA B5 @23.18dBm

535.0

mA

Quectel

Confidential

EC21 Hardware Design

Table 34: EC21-AUT Current Consumption

EC21_Hardware_Design Confidential / Released 71 / 94

LTE Module Series

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

OFF state

Power down

TBD

uA

Sleep state

AT+CFUN=0 (USB disconnected)

TBD

mA

WCDMA PF=64 (USB disconnected)

TBD

mA

WCDMA PF=128 (USB disconnected)

TBD

mA

FDD-LTE PF=64 (USB disconnected)

TBD

mA

FDD-LTE PF=128 (USB disconnected)

TBD

mA

Idle state (GNSS OFF)

WCDMA PF=64 (USB disconnected)

TBD

mA

WCDMA PF=64 (USB connected)

TBD

mA

LTE-FDD PF=64 (USB disconnected)

TBD

mA

LTE-FDD PF=64 (USB connected)

TBD

mA

GPRS data transfer (GNSS OFF)

GSM900 4DL/1UL @32.3dBm

220

mA

GSM900 3DL/2UL @32.18dBm

387

mA

GSM900 2DL/3UL @30.3dBm

467

mA

GSM900 1DL/4UL @29.4dBm

555

mA

DCS1800 4DL/1UL @29.6dBm

185

mA

DCS1800 3DL/2UL @29.1dBm

305

mA

DCS1800 2DL/3UL @28.8dBm

431

mA

DCS1800 1DL/4UL @29.1dBm

540

mA

EDGE data transfer (GNSS OFF)

GSM900 4DL/1UL @26dBm

148

mA

GSM900 3DL/2UL @26dBm

245

mA

GSM900 2DL/3UL @25dBm

338

mA

GSM900 1DL/4UL @25dBm

432

mA

DCS1800 4DL/1UL @26dBm

150

mA

DCS1800 3DL/2UL @25dBm

243

mA

DCS1800 2DL/3UL @25dBm

337

mA

Quectel

Confidential

EC21 Hardware Design

Table 35: EC21-E Current Consumption

EC21_Hardware_Design Confidential / Released 72 / 94

LTE Module Series

DCS1800 1DL/4UL @25dBm

430

mA

WCDMA data transfer (GNSS OFF)

WCDMA B1 HSDPA @22.5dBm

659

mA

WCDMA B1 HSUPA @21.11dBm

545

mA

WCDMA B5 HSDPA @23.5dBm

767

mA

WCDMA B5 HSUPA @21.4dBm

537

mA

WCDMA B8 HSDPA @22.41dBm

543

mA

WCDMA B8 HSUPA @21.2dBm

445

mA

LTE data transfer (GNSS OFF)

LTE-FDD B1 @23.45dBm

807

mA

LTE-FDD B3 @23.4dBm

825

mA

LTE-FDD B5 @23.4dBm

786

mA

LTE-FDD B7 @23.86dBm

887

mA

LTE-FDD B8 @23.5dBm

675

mA

LTE-FDD B20 @23.57dBm

770

mA

GSM voice call GSM900 PCL=5 @32.8dBm

336

mA

PCS1800 PCL=0 @29.3dBm

291

mA

WCDMA voice call WCDMA B1 @23.69dBm

683

mA

WCDMA B5 @23.61dBm

741

mA

WCDMA B8 @23.35dBm

564

mA

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

OFF state

Power down

20

uA

Sleep state AT+CFUN=0 (USB disconnected)

0.98

mA

LTE-FDD PF=64 (USB disconnected)

2.5

mA

LTE-FDD PF=128 (USB disconnected)

2.4

mA

Idle state (GNSS OFF)

LTE-FDD PF=64 (USB disconnected)

23.0

mA

LTE-FDD PF=64 (USB connected)

34.0

mA

Quectel

Confidential

EC21 Hardware Design

Table 36: EC21-KL Current Consumption

EC21_Hardware_Design Confidential / Released 73 / 94

LTE Module Series

LTE data transfer (GNSS OFF)

LTE-FDD B1 @23.65dBm

765.0

mA

LTE-FDD B3 @23.2dBm

825.0

mA

LTE-FDD B5 @23.2dBm

598.0

mA

LTE-FDD B7 @23.7dBm

762.0

mA

LTE-FDD B8 @23.1dBm

569.0

mA

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

OFF state

Power down

20

uA

Sleep state AT+CFUN=0 (USB disconnected)

1.0

mA

LTE-FDD PF=64 (USB disconnected)

2.5

mA

LTE-FDD PF=128 (USB disconnected)

2.0

mA

Idle state (GNSS OFF)

LTE-FDD PF=64 (USB disconnected)

22.0

mA

LTE-FDD PF=64 (USB connected)

32.0

mA

LTE data transfer (GNSS OFF)

LTE-FDD B4 @22.79dBm

752.0

mA

LTE-FDD B13 @23.26dBm

534.0

mA

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

OFF state

Power down

20

uA

Sleep state

AT+CFUN=0 (USB disconnected)

1.0

mA

WCDMA PF=64 (USB disconnected)

2.0

mA

WCDMA PF=128 (USB disconnected)

1.6

mA

LTE-FDD PF=64 (USB disconnected)

2.4

mA

LTE-FDD PF=128 (USB disconnected)

1.9

mA

Idle state (GNSS OFF)

WCDMA PF=64 (USB disconnected)

24.0

mA

WCDMA PF=64 (USB connected)

34.0

mA

Quectel

Confidential

EC21 Hardware Design

Table 37: EC21-V Current Consumption

Table 38: EC21-AUV Current Consumption

EC21_Hardware_Design Confidential / Released 74 / 94

LTE Module Series

LTE-FDD PF=64 (USB disconnected)

24.0

mA

LTE-FDD PF=64 (USB connected)

34.0

mA

WCDMA data transfer (GNSS OFF)

WCDMA B1 HSDPA @22.05dBm

586.0

mA

WCDMA B1 HSUPA @22.29dBm

630.0

mA

WCDMA B5 HSDPA @22.43dBm

576.0

mA

WCDMA B5 HSUPA @22.43dBm

600.0

mA

WCDMA B8 HSDPA @22.44dBm

577.0

mA

WCDMA B8 HSUPA @21.78dBm

555.0

mA

LTE data transfer (GNSS OFF)

LTE-FDD B1 @23.12dBm

721.0

mA

LTE-FDD B3 @23.04dBm

734.0

mA

LTE-FDD B5 @23.16dBm

669.0

mA

LTE-FDD B8 @23.21dBm

698.0

mA

LTE-FDD B28 @23.57dBm

790.0

mA

WCDMA voice call WCDMA B1 @22.72dBm

640.0

mA

WCDMA B5 @23.19dBm

638.0

mA

WCDMA B8 @23.27dBm

626.0

mA

Parameter

Description

Conditions

Typ.

Unit

I

VBAT

(GNSS) Searching

(AT+CFUN=0)

Cold start @Passive Antenna

58

mA

Lost state @Passive Antenna

58

mA

Tracking (AT+CFUN=0)

Instrument Environment

33

mA

Open Sky @Passive Antenna

35

mA

Open Sky @Active Antenna

43

mA

Quectel

Confidential

EC21 Hardware Design

Table 39: GNSS Current Consumption of EC21 Series Module

EC21_Hardware_Design Confidential / Released 75 / 94

LTE Module Series

Frequency

Max.

Min.

GSM850/GSM900

33dBm±2dB

5dBm±5dB

DCS1800/PCS1900

30dBm±2dB

0dBm±5dB

GSM850/GSM900 (8-PSK)

27dBm±3dB

5dBm±5dB

DCS1800/PCS1900 (8-PSK)

26dBm±3dB

0dBm±5dB

WCDMA bands

24dBm+1/-3dB

<-50dBm

LTE-FDD bands

23dBm±2dB

<-44dBm

LTE-TDD bands

23dBm±2dB

<-44dBm

In GPRS 4 slots TX mode, the maximum output power is reduced by 3.0dB. The design conforms to the GSM specification as described in Chapter 13.16 of 3GPP TS 51.010-1.

Frequency

Primary

Diversity

SIMO1)

3GPP (SIMO)

GSM900

-109.0dBm

/ / -102.0dBm

DCS1800

-109.0dBm

/ / -102.0dbm

WCDMA Band 1

-110.5dBm

/ / -106.7dBm

WCDMA Band 5

-110.5dBm

/ / -104.7dBm

NOTE

Quectel

Confidential

EC21 Hardware Design

6.5. RF Output Power

The following table shows the RF output power of EC21 module.

Table 40: RF Output Power

6.6. RF Receiving Sensitivity

The following tables show the conducted RF receiving sensitivity of EC21 series module.

Table 41: EC21-E Conducted RF Receiving Sensitivity

EC21_Hardware_Design Confidential / Released 76 / 94

LTE Module Series

WCDMA Band 8

-110.5dBm

/ / -103.7dBm

LTE-FDD B1 (10M)

-98.0dBm

-101.5dBm

-96.3dBm

LTE-FDD B3 (10M)

-96.5dBm

-98.5dBm

-101.5dBm

-93.3dBm

LTE-FDD B5 (10M)

-98.0dBm

-98.5dBm

-101.0dBm

-94.3dBm

LTE-FDD B7 (10M)

-97.0dBm

-94.5dBm

-99.5dBm

-94.3dBm

LTE-FDD B8 (10M)

-97.0dBm

-101.0dBm

-93.3dBm

LTE-FDD B20 (10M)

-97.5dBm

-99.0dBm

-102.5dBm

-93.3dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

WCDMA B2

-110.0dBm

/ / -104.7dBm

WCDMA B4

-110.0dBm

/ / -106.7dBm

WCDMA B5

-110.5dBm

/ / -104.7dBm

LTE-FDD B2 (10M)

-98.0dBm

-101.0dBm

-94.3dBm

LTE-FDD B4 (10M)

-97.5dBm

-99.0dBm

-101.0dBm

-96.3dBm

LTE-FDD B12 (10M)

-96.5dBm

-98.0dBm

-101.0dBm

-93.3dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

LTE-FDD B4 (10M)

-97.5dBm

-99.0dBm

-101.0dBm

-96.3dBm

LTE-FDD B13 (10M)

-95.0dBm

-97.0dBm

-100.0dBm

-93.3dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

WCDMA B1

-110.0dBm

/ / -106.7dBm

Quectel

Confidential

EC21 Hardware Design

Table 42: EC21-A Conducted RF Receiving Sensitivity

Table 43: EC21-V Conducted RF Receiving Sensitivity

Table 44: EC21-AUT Conducted RF Receiving Sensitivity

EC21_Hardware_Design Confidential / Released 77 / 94

LTE Module Series

WCDMA B5

-110.5dBm

/ / -104.7dBm

LTE-FDD B1 (10M)

-98.5dBm

-98.0dBm

-101.0dBm

-96.3dBm

LTE-FDD B3 (10M)

-98.0dBm

-96.0dBm

-100.0dBm

-93.3dBm

LTE-FDD B5 (10M)

-98.0dBm

-99.0dBm

-102.5dBm

-94.3dBm

LTE-FDD B7 (10M)

-97.0dBm

-95.0dBm

-98.5dBm

-94.3dBm

LTE-FDD B28 (10M)

-97.0dBm

-99.0dBm

-102.0dBm

-94.8dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

LTE-FDD B3 (10M)

-98.0dBm

-96.0dBm

-100.0dBm

-93.3dBm

LTE-FDD B7 (10M)

-97.0dBm

-95.0dBm

-98.5dBm

-94.3dBm

LTE-FDD B28 (10M)

-97.0dBm

-99.0dBm

-102.0dBm

-94.8dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

LTE-FDD B1 (10M)

-98.0dBm

-99.5dBm

-100.5dBm

-96.3dBm

LTE-FDD B3 (10M)

-97.0dBm

-97.5dBm

-99.5dBm

-93.3dBm

LTE-FDD B5 (10M)

-98.0dBm

-99.5dBm

-100.5dBm

-94.3dBm

LTE-FDD B7 (10M)

-96.0dBm

-98.5dBm

-94.3dBm

LTE-FDD B8 (10M)

-97.0dBm

-99.0dBm

-101.0dBm

-93.3dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

LTE-FDD B1 (10M)

-98.0dBm

-99.5dBm

-100.5dBm

-96.3dBm

LTE-FDD B3 (10M)

-97.0dBm

-97.5dBm

-99.5dBm

-93.3dBm

Quectel

Confidential

EC21 Hardware Design

Table 45: EC21-AUTL Conducted RF Receiving Sensitivity

Table 46: EC21-KL Conducted RF Receiving Sensitivity

Table 47: EC21-CT Conducted RF Receiving Sensitivity

EC21_Hardware_Design Confidential / Released 78 / 94

LTE Module Series

LTE-FDD B5* (10M)

TBD

1.

1)

SIMO is a smart antenna technology that uses a single antenna at the transmitter side and two antennas at the receiver side, which can improve RX performance.

2. “*” means under development.

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

LTE-FDD B1 (10M)

-97.5dBm

-98.7dBm

-100.2dBm

-96.3dBm

LTE-FDD B3 (10M)

-96.5dBm

-97.1dBm

-100.5dBm

-93.3dBm

LTE-FDD B8 (10M)

-98.4dBm

-99.0dBm

-101.2dBm

-93.3dBm

LTE-FDD B18 (10M)

-99.5dBm

-99.0dBm

-101.7dBm

-96.3dBm

LTE-FDD B19 (10M)

-99.2dBm

-99.0dBm

-101.4dBm

-96.3dBm

LTE-FDD B26 (10M)

-99.5dBm

-99.0dBm

-101.5dBm

-93.8dBm

Frequency

Primary

Diversity

SIMO

3GPP (SIMO)

WCDMA B1

-110.0dBm

/ / -106.7dBm

WCDMA B5

-111.0dBm

/ / -104.7dBm

WCDMA B8

-111.0dBm

/ / -103.7dBm

LTE-FDD B1 (10M)

-97.2dBm

-100.2dBm

-96.3dBm

LTE-FDD B3 (10M)

-98.2dBm

-98.7dBm

-100.7dBm

-93.3dBm

LTE-FDD B5 (10M)

-99.2dBm

-98.7dBm

-101.7dBm

-94.3dBm

LTE-FDD B8 (10M)

-97.7dBm

-97.2dBm

-101.2dBm

-93.3dBm

LTE-FDD B28 (10M)

-97.0dBm

-98.2dBm

-101.2dBm

-94.8dBm

NOTES

Quectel

Confidential

EC21 Hardware Design

Table 48: EC21-J Conducted RF Receiving Sensitivity

Table 49: EC21-AUV Conducted RF Receiving Sensitivity

EC21_Hardware_Design Confidential / Released 79 / 94

LTE Module Series

Tested Points

Contact Discharge

Air Discharge

Unit

VBAT, GND

±5

±10

kV

All Antenna Interfaces

±4

±8

kV

Other Interfaces

±0.5

±1

kV

Quectel

Confidential

EC21 Hardware Design

6.7. Electrostatic Discharge

The module is not protected against electrostatic discharge (ESD) in general. Consequently, it is subject to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and packaging procedures must be applied throughout the processing, handling and operation of any application that incorporates the module.

The following table shows the module’s electrostatic discharge characteristics.

Table 50: Electrostatic Discharge Characteristics

EC21_Hardware_Design Confidential / Released 80 / 94

LTE Module Series

(32+/-0.15)

(29+/-0.15)

0.8

2.4+/-0.2

Quectel

Confidential

EC21 Hardware Design

7 Mechanical Dimensions

This chapter describes the mechanical dimensions of the module. All dimensions are measured in mm.

7.1. Mechanical Dimensions of the Module

EC21_Hardware_Design Confidential / Released 81 / 94

Figure 40: Module Top and Side Dimensions

LTE Module Series

1.30

1.10

3.85

2.0

3.0

3.5

0.8

1.5

3.23.4

3.2

3.4

3.2

6.75

3.45

1.6

2.49

2.4

2.15

4.4

1.7

4.88

1.8

1.15

1.05

29.0

1.90

3.5

1.9

32.0

3.35

2.8

4.8

0.82

5.96

2.0

Quectel

Confidential

EC21 Hardware Design

Figure 41: Module Bottom Dimensions (Bottom View)

EC21_Hardware_Design Confidential / Released 82 / 94

LTE Module Series

Keepout area

4.80

7.80

15.60

1.90

3.85

24.70

1.80

1.90

1.30

3.20

3.40

3.20 3.40

3.20

3.00

0.80

32.0

3.40

2.50

1.00

1.80

0.50

2.80

0.50

3.40

3.45

3.00

2.00

1.10

2.00

3.50

1. The keepout area should not be designed.

2. For easy maintenance of the module, please keep about 3mm between the module and other components in the host PCB.

NOTES

Quectel

Confidential

EC21 Hardware Design

7.2. Recommended Footprint

Figure 42: Recommended Footprint (Top View)

EC21_Hardware_Design Confidential / Released 83 / 94

LTE Module Series

These are design effect drawings of EC21 module. For more accurate pictures, please refer to the module that you get from Quectel.

NOTE

Quectel

Confidential

EC21 Hardware Design

7.3. Design Effect Drawings of the Module

Figure 43: Top View of the Module

Figure 44: Bottom View of the Module

EC21_Hardware_Design Confidential / Released 84 / 94

LTE Module Series

As the plastic package cannot be subjected to high temperature, it should be removed from devices before high temperature (125ºC) baking. If shorter baking time is desired, please refer to IPC/JEDECJ-STD-033 for baking procedure.

NOTE

Quectel

Confidential

EC21 Hardware Design

8 Storage, Manufacturing and

Packaging

8.1. Storage

EC21 is stored in a vacuum-sealed bag. The storage restrictions are shown as below.

1. Shelf life in the vacuum-sealed bag: 12 months at <40ºC/90%RH.

2. After the vacuum-sealed bag is opened, devices that will be subjected to reflow soldering or other high temperature processes must be:

 Mounted within 72 hours at the factory environment of ≤30ºC/60%RH  Stored at <10%RH

3. Devices require baking before mounting, if any circumstances below occurs:

 When the ambient temperature is 23ºC±5ºC and the humidity indicator card shows the humidity

is >10% before opening the vacuum-sealed bag.

 Device mounting cannot be finished within 72 hours at factory conditions of ≤30ºC/60%RH.

4. If baking is required, devices may be baked for 48 hours at 125ºC±5ºC.

EC21_Hardware_Design Confidential / Released 85 / 94

LTE Module Series

Time

50

100

150 200

250 300

50

100

150

200

250

160ºC

200ºC

217

0

70s~120s

40s~60s

Between 1~3ºC/s

Preheat Heating Cooling

ºC

s

Liquids Temperature

Temperature

During manufacturing and soldering, or any other processes that may contact the module directly, NEVER wipe the module label with organic solvents, such as acetone, ethyl alcohol, isopropyl alcohol, trichloroethylene, etc.

NOTE

Quectel

Confidential

EC21 Hardware Design

8.2. Manufacturing and Soldering

Push the squeegee to apply the solder paste on the surface of stencil, thus making the paste fill the stencil openings and then penetrate to the PCB. The force on the squeegee should be adjusted properly so as to produce a clean stencil surface on a single pass. To ensure the module soldering quality, the thickness of stencil for the module is recommended to be 0.18mm. For more details, please refer to document [4].

It is suggested that the peak reflow temperature is from 235 to 245ºC (for SnAg3.0Cu0.5 alloy). The absolute maximum reflow temperature is 260ºC. To avoid damage to the module caused by repeated heating, it is suggested that the module should be mounted after reflow soldering for the other side of PCB has been completed. Recommended reflow soldering thermal profile is shown below:

Figure 45: Reflow Soldering Thermal Profile

EC21_Hardware_Design Confidential / Released 86 / 94

LTE Module Series

30.3

±0.15

29.3

±0.15

30.3

±0.15

32.5

±0.15

33.5

±0.15

0.35±0.05

4.2

±0.15

3.1

±0.15

32.5±0.15

33.5±0.15

4.00

±0.1

2.00

±0.1

1.75

±0.1

20.20

±0.15

44.00

±0.3

44.00

±0.1

1.50

±

0.1

Direction of feed

Cover tape

13

100

44.5

+0.20

-0.00

48.5

Quectel

Confidential

EC21 Hardware Design

8.3. Packaging

EC21 is packaged in tape and reel carriers. One reel is 11.53m long and contains 250pcs modules. The figure below shows the packaging details, measured in mm.

Figure 46: Tape and Reel Specifications

EC21_Hardware_Design Confidential / Released 87 / 94

LTE Module Series

SN

Document Name

Remark

[1]

Quectel_EC21_Power_Management_Application_Note

EC21 Power Management Application Note

[2]

Quectel_EC25&EC21_AT_Commands_Manual

EC25 and EC21 AT Commands Manual

[3]

Quectel_EC25&EC21_GNSS_AT_Commands_Manual

EC25 and EC21 GNSS AT Commands Manual

[4]

Quectel_Module_Secondary_SMT_User_Guide

Module Secondary SMT User Guide

[5]

Quectel_EC21_Reference_Design

EC21 Reference Design

[6]

Quectel_RF_Layout_Application_Note

RF Layout Application Note

[7]

Quectel_SGMII_Design_Application_Note

SGMII Design Application Note

Abbreviation

Description

AMR

Adaptive Multi-rate

bps

Bits Per Second

CHAP

Challenge Handshake Authentication Protocol

CS

Coding Scheme

CSD

Circuit Switched Data

CTS

Clear To Send

DC-HSPA+

Dual-carrier High Speed Packet Access

DFOTA

Delta Firmware Upgrade Over The Air

Quectel

Confidential

EC21 Hardware Design

9 Appendix A References

Table 51: Related Documents

Table 52: Terms and Abbreviations

EC21_Hardware_Design Confidential / Released 88 / 94

LTE Module Series

DL

Downlink

DTR

Data Terminal Ready

DTX

Discontinuous Transmission

EFR

Enhanced Full Rate

ESD

Electrostatic Discharge

FDD

Frequency Division Duplex

FR

Full Rate

GLONASS

GLObalnaya NAvigatsionnaya Sputnikovaya Sistema, the Russian Global Navigation Satellite System

GMSK

Gaussian Minimum Shift Keying

GNSS

Global Navigation Satellite System

GPS

Global Positioning System

GSM

Global System for Mobile Communications

HR

Half Rate

HSPA

High Speed Packet Access

HSDPA

High Speed Downlink Packet Access

HSUPA

High Speed Uplink Packet Access

I/O

Input/Output

Inorm

Normal Current

LED

Light Emitting Diode

LNA

Low Noise Amplifier

LTE

Long Term Evolution

MIMO

Multiple Input Multiple Output

MO

Mobile Originated

MS

Mobile Station (GSM engine)

MT

Mobile Terminated

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 89 / 94

LTE Module Series

PAP

Password Authentication Protocol

PCB

Printed Circuit Board

PDU

Protocol Data Unit

PPP

Point-to-Point Protocol

QAM

Quadrature Amplitude Modulation

QPSK

Quadrature Phase Shift Keying

RF

Radio Frequency

RHCP

Right Hand Circularly Polarized

Rx

Receive

SGMII

Serial Gigabit Media Independent Interface

SIM

Subscriber Identification Module

SIMO

Single Input Multiple Output

SMS

Short Message Service

TDD

Time Division Duplexing

TDMA

Time Division Multiple Access

TD-SCDMA

Time Division-Synchronous Code Division Multiple Access

TX

Transmitting Direction

UL

Uplink

UMTS

Universal Mobile Telecommunications System

URC

Unsolicited Result Code

USIM

Universal Subscriber Identity Module

Vmax

Maximum Voltage Value

Vnorm

Normal Voltage Value

Vmin

Minimum Voltage Value

VIHmax

Maximum Input High Level Voltage Value

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 90 / 94

LTE Module Series

VIHmin

Minimum Input High Level Voltage Value

VILmax

Maximum Input Low Level Voltage Value

VILmin

Minimum Input Low Level Voltage Value

VImax

Absolute Maximum Input Voltage Value

VImin

Absolute Minimum Input Voltage Value

VOHmax

Maximum Output High Level Voltage Value

VOHmin

Minimum Output High Level Voltage Value

VOLmax

Maximum Output Low Level Voltage Value

VOLmin

Minimum Output Low Level Voltage Value

VSWR

Voltage Standing Wave Ratio

WCDMA

Wideband Code Division Multiple Access

WLAN

Wireless Local Area Network

Quectel

Confidential

EC21 Hardware Design

EC21_Hardware_Design Confidential / Released 91 / 94

LTE Module Series

Scheme

CS-1

CS-2

CS-3

CS-4

Code Rate

1/2

2/3

3/4

1

USF

3 3 3

3

Pre-coded USF

3 6 6

12

Radio Block excl. USF and BCS

181

268

312

428

BCS

40

16

Tail

4 4 4

-

Coded Bits

456

588

676

456

Punctured Bits

0

132

220

-

Data Rate Kb/s

9.05

13.4

15.6

21.4

Quectel

Confidential

EC21 Hardware Design

10 Appendix B GPRS Coding Schemes

Table 53: Description of Different Coding Schemes

EC21_Hardware_Design Confidential / Released 92 / 94

LTE Module Series

Multislot Class

Downlink Slots

Uplink Slots

Active Slots

1 1 1 2 2 2 1

3

3 2 2

3

4 3 1 4 5 2 2

4

6 3 2

4

7 3 3 4 8 4 1

5

9 3 2

5

10 4 2 5 11 4 3

5

12 4 4

5

Quectel

Confidential

EC21 Hardware Design

11 Appendix C GPRS Multi-slot Classes

Twenty-nine classes of GPRS multi-slot modes are defined for MS in GPRS specification. Multi-slot classes are product dependent, and determine the maximum achievable data rates in both the uplink and downlink directions. Written as 3+1 or 2+2, the first number indicates the amount of downlink timeslots, while the second number indicates the amount of uplink timeslots. The active slots determine the total number of slots the GPRS device can use simultaneously for both uplink and downlink communications.

The description of different multi-slot classes is shown in the following table.

Table 54: GPRS Multi-slot Classes

EC21_Hardware_Design Confidential / Released 93 / 94

LTE Module Sires

Coding Scheme

Modulation

Coding Family

1 Timeslot

2 Timeslot

4 Timeslot

CS-1:

GMSK

/

9.05kbps

18.1kbps

36.2kbps

CS-2:

GMSK

/

13.4kbps

26.8kbps

53.6kbps

CS-3:

GMSK

/

15.6kbps

31.2kbps

62.4kbps

CS-4:

GMSK

/

21.4kbps

42.8kbps

85.6kbps

MCS-1

GMSK

C

8.80kbps

17.60kbps

35.20kbps

MCS-2

GMSK

B

11.2kbps

22.4kbps

44.8kbps

MCS-3

GMSK

A

14.8kbps

29.6kbps

59.2kbps

MCS-4

GMSK

C

17.6kbps

35.2kbps

70.4kbps

MCS-5

8-PSK

B

22.4kbps

44.8kbps

89.6kbps

MCS-6

8-PSK

A

29.6kbps

59.2kbps

118.4kbps

MCS-7

8-PSK

B

44.8kbps

89.6kbps

179.2kbps

MCS-8

8-PSK

A

54.4kbps

108.8kbps

217.6kbps

MCS-9

8-PSK

A

59.2kbps

118.4kbps

236.8kbps

Quectel

Confidential

EC21 Hardware Design

12 Appendix D EDGE Modulation and

Coding Schemes

Table 55: EDGE Modulation and Coding Schemes

EC21_Hardware_Design Confidential / Released 94 / 94

Quectel EC21 Series, EC21-V, EC21-E, EC21-A, EC21-AU Hardware Design

Specifications and Main Features

Frequently Asked Questions

User Manual

About the Document

Contents

Table Index

Figure Index

1 Introduction

1.1. Safety Information

2 Product Concept

2.1. General Description

2.2. Key Features

2.3. Functional Diagram

2.4. Evaluation Board

3 Application Interfaces

3.1. General Description

3.2. Pin Assignment

3.3. Pin Description

3.4. Operating Modes

3.5. Power Saving

3.5.1. Sleep Mode

3.5.1.1. UART Application

3.5.1.2. USB Application with USB Remote Wakeup Function

3.5.1.3. USB Application with USB Suspend/Resume and RI Function

3.5.1.4. USB Application without USB Suspend Function

3.5.2. Airplane Mode

3.6. Power Supply

3.6.1. Power Supply Pins

3.6.2. Decrease Voltage Drop

3.6.3. Reference Design for Power Supply

3.6.4. Monitor the Power Supply

3.7. Turn on and off Scenarios

3.7.1. Turn on Module Using the PWRKEY

3.7.2. Turn off Module

3.7.2.1. Turn off Module Using the PWRKEY Pin

3.7.2.2. Turn off Module Using AT Command

3.8. Reset the Module

3.9. USIM Card Interface

3.10. USB Interface

3.11. UART Interfaces

3.12. PCM and I2C Interfaces

3.13. ADC Function

3.14. Network Status Indication

3.15. STATUS

3.16. Behavior of the RI

3.17. SGMII Interface

3.18. Wireless Connectivity Interfaces

3.18.1. WLAN Interface

3.18.2. BT Interface*

3.19. USB_BOOT Interface

4 GNSS Receiver

4.1. General Description

4.2. GNSS Performance

4.3. Layout Guidelines

5 Antenna Interfaces

5.1. Main/Rx-diversity Antenna Interface

5.1.1. Pin Definition

5.1.2. Operating Frequency

5.1.3. Reference Design of RF Antenna Interface

5.1.4. Reference Design of RF Layout

5.2. GNSS Antenna Interface

5.3. Antenna Installation

5.3.1. Antenna Requirement

5.3.2. Recommended RF Connector for Antenna Installation

6.1. Absolute Maximum Ratings

6.2. Power Supply Ratings

6.3. Operating Temperature

6.4. Current Consumption

6.5. RF Output Power

6.6. RF Receiving Sensitivity

6.7. Electrostatic Discharge

7 Mechanical Dimensions

7.1. Mechanical Dimensions of the Module

7.2. Recommended Footprint

7.3. Design Effect Drawings of the Module

8.1. Storage

8.2. Manufacturing and Soldering

8.3. Packaging

9 Appendix A References
