Queclink Wireless Solutions GV300C Users Manual
GV300C User manual
CDMA2000-1X/GPS Tracker GV300C
User Manual
Application Notes: TRACGV300CUM001
Revision: 1.01
TRACGV3SUM001 - 1 -
Hhttp://www.queclink.com
Hsales@queclink.com
GV300C User manual
Document Title
Version
Date
Status
Document Control ID
GV300C User Manual
1.01
2013-11-14
Release
TRACGV300CUM001
General Notes
Queclink offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by Queclink. The information provided is
based upon requirements specifically provided to Queclink by the customers. Queclink has
not undertaken any independent search for additional relevant information, including any
information that may be in the customer’s possession. Furthermore, system validation of this
product designed by Queclink within a larger electronic system remains the responsibility of
the customer or the customer’s system integrator. All specifications supplied herein are
subject to change.
WARNING:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must acce
pt any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance cou
ld void the user’s authority to operate the equipment.
FCC RF Exposure Statement:
For the product,under normal use condition is at least 20cm away from the body of the
user,the user must keeping at least 20cm distance to the product.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
TRACGV300CUM001 - 2
-
GV300C User manual
-Consult the dealer or an experienced radio/TV technician for help.
Copyright
This document contains proprietary technical information which is the property of Queclink
Limited., copying of this document and giving it to others and the using or communication of
the contents thereof, are forbidden without express authority. Offenders are liable to the
payment of damages. All rights reserved in the event of grant of a patent or the registration of
a utility model or design. All specification supplied herein are subject to change without
notice at any time.
Copyright © Shanghai Queclink Wireless Solutions Co., Ltd. 2013
Contents
Contents ............................................................................................................................................ 3
0. Revision History ....................................................................................................................... 6
1. Introduction ............................................................................................................................... 7
1.1 Reference .................................................................................................................. 7
1.2 Terms and Abbreviations ........................................................................................... 7
2. Product Overview ..................................................................................................................... 8
2.1. Check Part List .......................................................................................................... 8
2.2. Parts List ................................................................................................................... 9
2.3. Interface Definition ................................................................................................. 10
2.4. GV300C User Cable Colour ................................................................................... 11
3. Getting Started ........................................................................................................................ 12
3.1. Opening the Case .................................................................................................... 12
3.2. Closing the Case ...................................................................................................... 12
3.3. Installing the Internal Backup Battery..................................................................... 13
3.4. Switch ON the Backup Battery ............................................................................... 13
3.5. Installing the External GPS Antenna (Optional) ..................................................... 14
3.5.1. GPS Antenna Specification ............................................................................. 14
3.6. Power Connection ................................................................................................... 15
3.7. Ignition Detection .................................................................................................... 16
3.8. Digital Inputs ........................................................................................................... 17
3.9. Analog Inputs .......................................................................................................... 17
3.10. Digital Outputs ........................................................................................................ 1 8
3.11. Device Status LED .................................................................................................. 19
3.12. Serial Port / UART Interface ................................................................................... 21
3.12.1. Connect With Garmin GPS Set ....................................................................... 21
TRACGV300CUM001 - 3
-
GV300C User manual
Table Index
TABLE 1. GV300C PROTOCOL REFERENCE ............................................................................. 7
TABLE 2. TERMS AND ABBREVIATIONS .................................................................................. 7
TABLE 3. PART LIST ...................................................................................................................... 9
TABLE 4. DESCRIPTION OF 16 PIN CONNECTIONS .............................................................. 10
TABLE 5. GV300C USER CABLE COLOUR DEFINITION ....................................................... 11
TABLE 6. GPS ANTENNA SPECIFICATION .............................................................................. 14
TABLE 7. ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION ......................... 16
TABLE 8. ELECTRICAL CHARACTERISTICS OF THE DIGITAL INPUTS ........................... 17
TABLE 9. ELECTRICAL CHARACTERISTICS OF DIGITAL OUTPUTS ................................ 18
TABLE 10 . DEFINITION OF DEVICE STATUS AND LED ......................................................... 19
TRACGV300CUM001 - 4
-
GV300C User manual
Figure Index
FIGURE 1. APPEARANCE OF GV300C ......................................................................................... 8
FIGURE 2. THE 16 PIN CONNECTOR ON THE GV300C ........................................................... 10
FIGURE 3. OPENING THE CASE .................................................................................................. 12
FIGURE 4. CLOSING THE CASE .................................................................................................. 12
FIGURE 5. BACKUP BATTERY INSTALLATION ....................................................................... 13
FIGURE 6. SWITCH AND ON/OFF POSITION ............................................................................ 13
FIGURE 7. GPS ANTENNA OF GV300C ...................................................................................... 14
FIGURE 8. TYPICAL POWER CONNECTION ............................................................................. 15
FIGURE 9. TYPICAL IGNITION DETECTION ............................................................................ 16
FIGURE 10. TYPICAL DIGITAL INPUT CONNECTION .............................................................. 17
FIGURE 11. TYPICAL ANALOG INPUT CONNECTION ............................................................. 17
FIGURE 12. DIGITAL OUTPUT INTERNAL DRIVE CIRCUIT .................................................... 18
FIGURE 13. TYPICAL CONNECTION WITH RELAY .................................................................. 18
FIGURE 14. TYPICAL CONNECTION WITH LED ....................................................................... 19
FIGURE 15. GV300C LED ON THE CASE ..................................................................................... 19
FIGURE 16. TYPICAL CONNECTION WITH RS232 PORT ......................................................... 21
FIGURE 17. GV300C CONNECTION WITH GARMIN GPS SET ................................................. 21
TRACGV300CUM001 - 5
-
GV300C User manual
0. Revision History
Revision Date Author Description of change
1.00 2013-6-7 York.zhu Initial
1.01 2013-11-14 Cid.Xu Updated related images;
TRACGV300CUM001 - 6
-
GV300C User manual
1. Introduction
The GV300C is a compact GPS tracker designed for a wide variety of vehicle tracking
applications. The GV300C has multiple input/output interfaces that can be used for monitoring or
controlling external devices. Its built in GPS receiver has superior sensitivity and fast time to first
fix. It’s dual band CDMA2000-1x subsystem supports 800/1900MHz allowing the GV300C's
location to be monitored in real time or periodically tracked by a backend server and mobile
devices. It’s built in 3-axis accelerometer allows driver behaviour, motion detection and extended
battery life through sophisticated power management algorithms. System integration is
straightforward as complete documentation is provided for the full featured @Track protocol. The
@Track protocol supports a wide variety of reports including; emergency, geo-fence boundary
crossings, driver behaviour, low battery or scheduled GPS position and many other useful
functions.
1.1 Reference
Table 1. GV300C Protocol Reference
SN Document name Remark
[1] GV300C @Track Air Interface Protocol The air protocol interface between
GV300C and backend server.
1.2 Terms and Abbreviations
Table 2. Terms and Abbreviations
Abbreviation Description
AGND Analog Ground
AIN Analog Input
DIN Digital Input
DOUT Digital Output
GND Ground
RXD Receive Data
TXD Transmit Data
NC No Connect
TRACGV300CUM001 - 7 -
Loading...
