Linear LED
Download Full Manual at
QUASARSCIENCE.COM/RAINBOW
Q-Rainbow RGBX
Quick Start Guide
2000k-6000k Crossfade White Light
with RGB Color Mixing (RGBX)
Wireless by _
DMX over Cat5
Manual Interface with OLED Screen
Universal AC Power 90v-256v
DC Battery Option 10v-26v
Lead / Follow Mode
On Board Effects
Lengths: 2’ 4’ 8’
|
QUASAR SCIENCEQUASAR SCIENCE
OLED Screen
DMX IN DMX OUT
10-26v
DC
DC Power Port
2.1mm x 5.5mm
DMX IN
over Cat5
DMX Out
over Cat5
Cat5 to DMX Adapter
(Not Included)
Enter/Set Right / +Left / -
Receiving Data
Wireless DMX
Link/ Pair
-
+
DMX
Data
Controls
S
S
Rainbow Layout
True 1 Power
Connector
AC Power Switch
in every Rainbow
Wireless DMX
-
+
DMX
Data
DC Power Port
OLED Screen
with Manual Controls
S
S
Linear LED
Q-Rainbow RGBX
Main Menu - Manual Mode
> Intensity
> Color Temp
> CT Preset
> Saturation
> Hue
> +/- Green
> Color Preset
> Effects
> Config
0 to 100%
2000k to 6000k by 100k increments
3200-4000-5000-5600-6000-2000-2800
0 to 100%
0° to 360°
100M to 0G to 100G
Blue-Cyan-Green-Red-Yellow-Orange-Magenta
Rainbow-Short Circuit-Paparazzi-Fire1-Fire2-Fire3-Coplight1-Coplight2-Demo
DMX Address-DMX Profile-Lead/Follow/Wireless On/Off-StatusLights On/Off
-FirmwareVersion-Lamp Hours-Reset to Default-BACK to Main Menu
Main Menu - Manual Mode
> DMX Address
> Profile
> Lead /Follow
> Wireless
> Status Lights
> Firmware
> Lamp Hours
> Reset to Default
001 to 508 (Does not allow address to be outside of 512)
1:HSIC-8 bit, 2:HSIC-16 bit, 3:HSI-8 bit, 4: XFade with CC-8 bit, 5: XFade-8 bit,
-6: CCT & RGB-8 bit, 7: CCT & RGB-16 bit, 8: RGB-8 bit
Lead-Follow1-Follow2-Follow3-Follow4-Follow5
On/Off - Disables the wireless transceiver
On/Off - Turns off the status lights for use on camera
Displays the Firmware Version on the Lamp
Displays the Hours the lamp has been powered on
Sets the lamp back to all its default values
Config Menu
To Set the Intensity, Color Temp, +/- Green, Saturation and Hue:
Press the Left or Right arrows until desired function is selected.
Press Enter to Select.
The selection carrots > < will move from the >Function< to the >Value<
Press the or buttons to set the value. Press Enter to Save.
To Link a Rainbow lamp to a transmitter,
Go to Config->Wireless, Set to ON, Config->Status Lights to ON
If the Wireless DMX is flashing, press and hold the Link button to Unpair.
On the DMX Transmitter, tap the Link button to Pair.
The Wireless DMX Light will start to Flash and turn solid once paired.
-
+
-
+
Getting Started
-
+
DMX
Data
Manual Effect Controls
Effect Result
Rainbow
Short Circuit
Paparazzi
Fire 1
Fire 2
Fire 3
Cop Light 1
Cop Light 2
Demo
Scroll through the Hue from 0° at full Saturation
Lamp is on with random bursts of turning off
Lamp is off with random flashes of turning on
A flicker effect with a low weighted center
A flicker effect with a middle weighted center
A flicker effect with a high weighted center
Solid Red and Blue alternating colors
3 Flashes Red, 3 Flashes Blue alternating colors
Scroll through the Hue from 0° at 0%, 25%, 50%,
75% and 100% Saturation at 2000k and 6000k
Effect
Result
Effect
Rate
Maximum
Minimum
Choose Effect
0-200% for the speed
of the effect
100% is normal speed
Highest intensity level
of effect
Lowest intensity level
of effect
Effects
On parameter menus such as intensity, saturation, and hue, when pressing and holding the
button to increase the value, tap the button will jump to the next value or max value. The
opposite is true when decreasing.
Press and hold the Enter for 5 seonds to disable the status lights.
-
+
Manual Button Shortcuts
Linear LED
Q-Rainbow RGBX
Solid Green Light - Lamp is paired and receiving transmission.
Slow Flashing Green Light - Wireless DMX is paired but transmitter not found.
Fast Flashing Green Light - Wireless DMX is in pairing.
No Green Light - Lamp is Unpaired or Wireless/Status Lights are turned off.
Solid Red Light - Data Received
No Red Light - No Data Received or Wireless/Status Lights are turned off.
Status Lights
DMX
Data
-
+
DMX
Data
-
+
DMX
Data
-
+
DMX
Data
Lead/Follow Mode allows one Rainbow lamp to control many lamps at once. The Lead transmits
DMX data wired or wirelessly to the followers. When the Lead changes levels, the follows will
change as well. Applies to on board FX as well.
To Lead/Follow Mode, go to Config->Lead/Follow. Set the Leader to Lead and set all of the
Followers to Follow 1 to match the leader. Follow 2-6 is used with effects to do the same effect with
different timings.
To use wired, plug Cat5 cable into the Out of the Lead into the In of the Follow. Repeat out of the
follow and into the next. The data light should be illuminated on all the followers
To use wirelessly, on the Follows, press and hold the Link button to Unpair the lamp. Next tap
the Link button on the Lead. All of the follows Wireless signal light should begin flashing and
then remain solid.
Lead/Follow Mode
MODE
Lead
MODE
Follow 1
MODE
Follow 1
MMMMM
MMMM
MMMM
MMM
MMM
MM
MM
M
+/- Green
%
DMX
Value
Effect
0-10
11-20
21-119
120-145
146-244
245-255
0-4
5-8
8-46
47-57
57-96
96-100
No Effect
Full Minus Green
-99% to -1%
No Effect
1% to 99%
Full Plus Green
Parameter
Intensity
Color Temp
+/- Green
Crossfade
Hue
Saturation
Red
Green
Blue
Value
DMX
Value
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-255
0-100%
2000k-6000k
See Chart at right
0-100%
0°-360°
0-100%
0-100%
0-100%
0-100%
DMX Parameters
9
10
11
12
1:Intensity 2: Color Temp 3: +/- Green Control 4:Hue 5:Saturation
6: FX 7:FX Rate 8:FX Size
1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Hue 7:Saturation
8: FX 9:FX Rate 10:FX Size
1:Intensity 2: Color Temp 3: +/- Green Control 4:Crossfade 5:Red
6:Green 7:Blue 8: FX 9:FX Rate 10:FX Size
1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Crossfade
7:Red 8:Green 9:Blue 10: FX 11:FX Rate 12:FX Size
HSIC FX
HSIC-FX-16
CCT & RGB-FX
CCT & RGB
-16 FX
Name 8/16
# of
Chan
Channels
8 Bit
16 Bit
8 Bit
16 Bit
8
10
10
12
DMX Profiles (FX)
Linear LED
Q-Rainbow RGBX
1
2
3
4
5
6
7
8
1:Intensity 2: Color Temp 3: +/- Green Control 4:Hue 5:Saturation
1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Hue 7:Saturation
1:Intensity 2: Hue 3:Saturation
1:Intensity 2: Color Temp 3: +/- Green Control
1:Intensity 2: Color Temp
1:Intensity 2: Color Temp 3: +/- Green Control 4:Crossfade 5:Red
6:Green 7:Blue
1+2:Intensity 3: Color Temp 4: +/- Green Control 5+6:Crossfade
7:Red 8:Green 9:Blue
8: RGB – 8 bit – 3 Channels 1:Red 2:Green 3:Blue
HSIC
HSIC-16
HSI
XFade with +/-G
XFade
CCT & RGB
CCT & RGB-16
RGB
Name 8/16
# of
Chan
# Channels
8 Bit
16 Bit
8 Bit
8 Bit
8 Bit
8 Bit
16 Bit
8 Bit
5
7
3
3
2
7
9
3
DMX Profiles
Download Complete DMX Chart at QuasarScience.com/Rainbow
Effect DMX Value
0-20
21-30
31-40
41-50
51-60
61-70
71-80
81-90
91-100
101-110
111-255
Percentage
0-8
9-12
13-15
16-20
21-23
24-27
28-31
32-35
36-39
40-43
44-100
OFF
Rainbow
Short Circuit
Paparazzi
Fire 1
Fire 2
Fire 3
Cop Light 1
Cop Light 2
Demo
No Effect
DMX Effects Parameters
Effect Result
Effect
Rate
Size
Choose Effect
0-200% for the speed of the effect
100% is standard
-100 to 100%. It is the plus and minus
variation of Intensity.
Ex. Intensity 50% with Size of 10 will
be an effect from 40% to 60%
DMX Effect Controls
Q25R Q50R
Model:
Wattage:
Weight:
Dimensions:
Power
Consumption:
Q100R
Q25WRGBX
Max 25 watts
1.65lbs (0.75 kg)
23.6 x 1.75 in
(600 x 44.5 mm)
120v = 0.22 amp
240v = 0.11 amp
12v = 1.90 amp
24v = 0.95 amp
Q50WRGBX
Max 50 watts
2.53lbs (1.15 kg)
47.4 x 1.75 in
(1200 x 44.5 mm)
120v = 0.44 amp
240v = 0.22 amp
12v = 3.80 amp
24v = 1.90 amp
Q100WRGBX
Max 100 watts
94.5 x 1.75 in
(2400 x 44.5 mm)
120v = 0.88 amp
240v = 0.44 amp
12v = 7.60 amp
24v = 3.80 amp
Specifications:
Linear LED
Q-Rainbow RGBX
3 Year warranty from date of purchase.
Customer must provide proof of purchase.
This warranty is transferable.
Quasar Science will pay for:
The replacement parts, repair and/or labor costs to correct defects in materials and workmanship.
*Service must be provided by Quasar Science or an Authorized Quasar Science Service Center*
Quasar Science will not pay for:
Damage resulting from accident, misuse or abuse. Acts of God. Any failure that occurs for any other reason than materials and workmanship. Any shipping or handling costs.
Disclaimer of implied warranties / limitations of remedies:
Implied warranties, including the extent applicable warranties of merchantability or fitness for a particular purpose are excluded to the
extent legally permissible. Any implied warranties that may be imposed by law are limited to 3 years or the shortest period allowed by law.
Some states, provinces or countries do not allow limitations or exclusions on how long an implied warranty of merchantability or fitness
lasts, the above limitations or exclusions may not apply to you.
If this product fails to work as warranted, customer's sole and exclusive remedy shall be repair or replacement according to the terms of
this limited warranty. Quasar Science, LLC does not assume any responsibility for incidental or consequential damages. This warranty
gives you specific legal rights and you may also have other rights which vary from state to state, province to province or country to country.
Linear LED
Q-Rainbow RGBX
687 S. Anderson St.
Los Angeles, CA 90023
info@quasarscience.com
(800) 876-0665
|
QUASAR SCIENCEQUASAR SCIENCE
Download Full Manual atQUASARSCIENCE.COM/RAINBOW
STOP
Please do not return your Rainbow to your retailer.
Please contact Quasar Science with any questions, problems or concerns.
