ROOM AIR CONDITIONER

INSTALLATION AND
OPERATING INSTRUCTIONS

MODEL: HQ-2102UH

HQ-2122UH

ENGLISH

Please read these operating instructions thoroughly before using
your air conditioner and keep them for future reference.

For assistance, please call: 1-800-211-PANA (7262) or send e-mail to

[e-mail]

© 2003 Matsushita Electrical Co., Ltd. All Right Reserved.

or refer to

www.panasonic.com

F564236

1

Please observe these following safety precautions when using
your air conditioner.

• Failure or negligence in observing these safety precautions
could cause fire, electrical shock or personal injury.

INSTALLATION PRECAUTIONS

• Due to the weight of this product, we recommend that
you have a helper to assist in the installation. To avoid
injury, use the proper method of lifting. Avoid any sharp

SAFETY PRECAUTIONS

edges.

• Make sure the window frame to be used can
properly support this product.

• This product must be installed in accordance with all local
codes and ordinances.

• Do not install the unit in places where inflammable gas,
fumes or soot may be generated.

OPERATION PRECAUTIONS

• Operate your air conditioner from a stable 115 volt AC
supply.

• Plug into a separate 15 amp grounded outlet only.

• Use of extension cords
Avoid using extension cords. If there are no alternatives,

ensure that the cord is a UL listed 3-wire grounding type,
rated 125 volts with a minimum current-carrying rating of
15 amps, number 14 or heavier wire.

• Use a 15 amp time delay fuse or a circuit breaker.

• Do not switch off by unplugging the power plug while it is
operating. Press the OFF/ON pad to “OFF” before
unplugging.

This symbol (with a white background)
denotes an action that is PROHIBITED.

These symbols (with a blue background) denote
actions that are COMPULSORY.

OPERATION PRECAUTIONS

WARNING

• Do not modify the length of the power cord or use an extension cord.

• Do not touch or operate with wet hands. Do not modify or damage
the cord.

• Do not turn on the unit by inserting the power plug. Do not switch off
the unit by pulling out the power plug.

• Avoid an extended period of direct airflow.

• Do not insert sticks, fingers or other objects into the unit.

• Do not try to repair the unit yourself.

• Plug in properly before operating and use a specified power cord.

• If abnormal conditions (burnt smell, etc) occur, switch off and remove
the power plug.

CAUTION

• Do not use the unit for other purposes, than its intended use.

• Do not remove the power plug by pulling the cord.

• Do not block the air intake and outlet vanes.

• Do not splash or direct water at the unit

• Do not expose the unit to direct sunlight during operation.

• Do not operate the unit without the air filter installed or when the front
intake grille has been removed.

• Do not place any objects on the unit.

• Do not operate any combustion equipment near the unit’s airflow area.

• Switch off the breaker and remove the power plug from the socket if
the unit will not be operated for a long period.

• Pay attention to any damages on the unit caused by extensive usage.

• Ventilate the room occasionally where the unit is installed.

• Remove the power plug when cleaning the unit.

This sign warns of risk of death or serious injury.

This sign warns of injury or damage to property.

POWER SUPPLY

Time Delay Fuse : 15 Amps
Rated Voltage : 115V

• Socket Type

• Line Cord Plug

2

INSTALLATION BOX CONTENTS

Sealer 50 g
(1.8 oz) (Putty)

Type A
screws

Type C screws

Type A screw

Left side
expandable panel

Top sealing
ribbon

To p
angle

Type B screws

ACCESSORIES

AIR CONDITIONER INSTALLATION

NOTE
Check that none of the accessories are missing.

Window sash
foam seal

Type A screws

(6 pcs)
(XTN5D25A)

(5 pcs)
(CWH4580211)

(6 pcs)
(XTT4D8C)

Window sash
sealing ribbon

SCREW FURNISHED

Side
sealing
ribbon

Type A
screw

Type A Type B Type C
(Qty 6) (Qty 5) (Qty 6)

SUGGESTED TOOL LIST

Type C screws

Right side
expandable
panel

SELECT THE BEST LOCATION

(Single or Double

Window

hung window)

Front grille

SIDE VIEW

Wood Machine Tapping
Screw Screw Screw

Medium sized
screwdriver (#2
Phillips)

Tape Measure

Pencil

Level

Knife or
Scissor

19–3/

inches

16

12 inches

More than
4 inches

WINDOW REQUIREMENTS

O
F
F
/
O

N

OP
E
R
ATI

O
N

T
E
M

P
/
T
I

M
E
R

C
O

O

L
F
A
N

H
I
G

H
M
E

D
L
O

W

M
O
D

E

F
A
N

S

P
E
E

D

S
E
T

T
I
M

E
R

S
E

T

/
C
A
N

C

E

L

A
I
R

S
W

I
N
G

E
C
O
N
O

M
Y

h

r

°

F

W

i

r

e

l

e
s

s

R
e
m

o

t

e

C

o
n

t
r
o
l

• Hot sun rays hitting the outside surface
of the cabinet will create considerable
heat load. If the outside of the cabinet is
exposed to direct sunlight, consider
building an awning to shade the cabinet
while providing ample area for the heated
air to be exhausted from the condenser
(both sides) and the top.

(min)

”

16

/

15

15-

22

to 42-

1

/

8

”

This unit is designed for installation in
standard double hung windows.

NOTE
The unit may also be installed “through the wall”. You should,
however, observe standard carpentry practices and frame the
opening without violating local ordinances.

INSTALLATION PROCEDURES

CHASSIS INSTALLATION INTO THE CABINET

1 Slide the chassis into the cabinet.

2 Reinstall the cabinet screws.

Secure the cabinet to chassis by using screws (from
rear cabinet).

1 Remove the rear cabinet

screws and save for later use.

2 Slide the chassis out from the

cabinet.

°

F

T
I
M
E

O

R

P
E
R
A
T
I

O

T

N

E
M
P/

TI
M
E

R

h

r

SE
T

SE

O
F

T
/

F
/
O

N

CANCEL

C
O
O

L
F
A

M

N

O
D

E

A
I
R

S
W

I
N

G
H
I

E

G

C

H

O
N
O
M

Y

M
E
D

F
A

N
S

P
E
E

D
L
O
W

W
i
r
e

l
e
s

s

Remo

te C

ontr

ol

HOW TO ASSEMBLE THE EXPANDABLE PANELS

Top angle

Top sealing
ribbon (To be
attached to the

Expandable panel

top angle)

Type B screws

Side sealing ribbon
(To be attached to
the expandable
panel)

NOTE
This procedure applies to left and right

Type C screws

of assembling expandable panel.

• Attach the top angle to the cabinet using screw type B (3 pcs).

• Insert expandable panels to cabinet sides as shown.

• Secure the first fold of expansion panel to cabinet using screw
type C (3 each).

CABINET INSTALLATION

1 Cut the “Sealing Ribbon” to the

proper length, and attach it along
the bottom edge of the bottom
window sash.

Window sash
sealing ribbon

INSTALLATION OF THE FRONT GRILLE

Depending upon the location
of the AC outlet, route the AC
cord to either the left or right
side while installing the front
grille.

This figure shows the AC cord
routed to the left side.

1 Place the front grille on the

cabinet first.

2 Secure the front grille to the

main chassis using screw
provided.

Clockwise.

INSERT THE (OPTIONAL)

Attach the (part no.
CZ-SF6P) to the frame.

Slot in the and the
frame (part no. CZ-SFW6P) to
the front grille.

°

F

T
I
M
E

O

R

P
E
R

A
T
I
O

T

N

E
M

P
/
T

IM
E
R

h
r

S

E
T

SE

O
F

T

/

F

/
O
N

C
A
N
C

E
L

COO

L
F
A

MO

N

D
E

AI
R
SW

IN
G

HI

E

GH

C
O

N
O
M

Y

MED

F
A
N

SP

EE

D
L
O
W

W

ir

ele

ss

R

e
m
o

t
e
C

o
n

t
r
o
l

°

F

T
I

M
E

O

R

P

E
R
A

T
I
O

T

N

E

M

P

/

T
I
M

E
R

h

r

S
E

T

S

O

E

F

T

/

F

/
O
N

C
A

N
C

E
L

C
O

O

L
F
A

M

N

O

D
E

A
I

R
S

W
I
N

G
H
I

E

G

C

H

O
N

O
M

Y

M
E

D

F
A

N

S
P
E

E

D
L
O

W

W

i
r

e
l
e

s
s

R
e

m
o

t
e
C

o
n
t
r

o
l

°

F

T

IM
E

O

R

P
E
R
A

T
I
O

N

T
E

M

P

/T

IM

E
R

h

r

S
E

T

O

S
E

F

T

F

/

/O

N

C

A
N
C
E

L

C
O
O
L
F
A

M

N

O

D
E

A
I

R
S

W
I
N

G

EC

H

ONOM

I
G
H

Y

M
E
D

F
A

N
S

P
E

E

D
L
O
W

Wireless

R
e

m
o
te

C

o
n
tr

o
l

2 To prevent condensation water

from dripping inside, the cabinet
should be installed level or very
slightly tilted to the outside.

3 Secure the cabinet using screws.

Type A
screw

Type B
screws

Inside of
sash

Top angle

Expandable panel

Window sill

Type A
screws

Window sash
foam seal

• Expand the expandable panel fully into the grooves of the
window frame, secure the expandable panel, left, right and
top mounting frames to the bottom of the window sash
using 6 screws type A and 2 screws type B.

• Secure the cabinet using wood screws type A.

• Cut the window sash foam seal to the proper size and
seal the opening between the top of the inside window
sash and the outside window sash.

Note :If a gap exists between the unit and window sash, you may

use “Sealer” supplied with the installation kit for a better seal.

Outside of sash

Window sash

Sealing ribbon

The and the frame can be obtained separately
from your nearest service center.

INSERT THE AIR FILTER

Attach the air filter to the intake grille

°F

TIM
ER

O
P
E
R

ATIO

N

T
E
M

P
/
T

I
M
E

R

hr

S
E
T

O

S
E

F

T

F

/

/O

N

C
A
N

C
E
L

C
O

O

L
F
A

M

N

O
D

E

A
I
R

S
W

I
N
G

E
C

H

O

I
G

N

H

O

M
Y

M
E

D

F
A
N
S

P
E
E

D
L
O

W

W

ire

less

R
e
m

o
t
e

C
o

n
t
r
o
l

PLACE FRONT INTAKE GRILLE OVER THE FRONT GRILLE

Slide the front intake grille slightly to the right to reattach the
tabs and then push it down to close tight.

°

F

T

I
M

E

O

R

P
E
R

A
T
I
O

N

T

E

M
P

/
T
IM

E
R

h
r

S

E
T

O

S
E

F

T

F

/

/
O
N

C

A
N
C

E
L

COOL

FAN

MODE

AIR SWING

E
C

HIGH

O
N

O
M

Y

MED

FAN SPEED

LOW

W

i

r
e
l

e
s
s

R
e

m
o

t
e
C

o
n
tr

o
l

2

REMOVAL OF FRONT GRILLE

1 Remove the front intake grille.

Pull up the front intake
grille about 90° and slide
it slightly to the left to
unhook the tabs.

°F

TIM
E

OP

R

E
R

A
T
I
O

N

T
E
M

P
/
T
I
M

E
R

hr

S
E
T

O

S
E

F

T

F

/

/
O
N

C
A
N
C
E
L

C
O
O
L
F
A

M

N

O
D

E

A

I
R
S

W
I
N

G

E
C

H

O

I
G

N

H

O
M

Y

M
E
D

F
A
N
S
P

E
E

D
L
O
W

Wireless

R
e

m
o
t
e

C
o

n
t
r
o
l

2 Remove the air filter.

Tilt up and pull
out the air filter
by the holder.

3 Remove the front grille.

aa

a

At bottom right side of the front grille, press inward on cabinet near the power cord, and pull

aa

the grille outward to the right until right tab releases.

bb

b

At the bottom left side, push inward on cabinet and pull the grille outward to the left to release

bb

the left tab.
Do not pull the bottom edge toward you more than 3 inches to prevent the two top tabs from
damage.

cc

c

Slide the front grille upwards to free the two top tabs from slots at the top of the cabinet.

cc

HOW TO ATTACH THE DRAIN PAN (OPTIONAL)

AIR CONDITIONER INSTALLATION

Condensed water drainage

This air conditioner employs a “Slinger-Up System” which is designed to splash the condensed
water on the condenser coil for maximum cooling efficiency, thus producing a splashing sound.
If the splashing sound annoys you, you can provide an outside drainage by using the following
procedure which may, however, cause a small loss of performance.

Note: The cabinet should be installed tilted slightly lower to the rear for necessary condensate

drainage. (Max. 13/32”)

1 Remove the rubber plug and slide the chassis out from

the cabinet.

3 Connect a drain hose (optional).

Fit the drain hose to the drain pan.

Note

N

IO

T
RA
E
P
O

R
E
TIM

N

/O

F
F
O

T
E
S

R

E
M
I
T
/

/

P

°F

T

M

E

E

S

T

L
E
C
N
A
C

hr

Y
M

O
N
O
C
E

G
N

I
W
S
R

I
A

L

E
D

O

O
O
C

M
N

A

s

F

s

le

l

ire

o
r
t
n

W

o
C
e
t
o

H

m
e

G

I

R

H

D

E
E
P
S
N

A
F

D
E
M

W
O
L

Remove the
rubber plug

Drain hose or tubing can be
purchased locally to satisfy your
particular needs.

Air filter

°F

T
I
M
E

O

R

P
E
R

A
T
I
O

N

T
E

M
P
/
T

IM
E
R

h
r

S
E
T

O

S
E

F

T

F

/

/
O
N

C
A
N
C
E

L

C

O
O

L
F
A

M

N

O
D
E

A
I
R
S

W
I
N

G

E
C

H

O

I

G

N

H

O
M

Y

M

E

D

F
A
N

S
P

E
E
D

L

O

W

W

ir
e

le

s
s

R
e

m
o
t
e

C
o

n
t
r
o
l

cc

c

cc

°

F

T

I
M
E

O

R

P
E
R

A
T
I
O

T

N

E
M
P
/T

IM
E
R

h

r

S
E
T

S

O

E

F

T
/

F/

O
N

C

A
N
C
E

L

C

O

O

L
F
A

M

N

O
D

E

A
I
R
S

W
I
N

G
H
I

E

G

C

H

O
N

O
M
Y

M
E

D
F

A
N
S

P
E
E

D
L
O

W

W

i
r
e

l
e

s
s

R
e

m
o
t

e
C

o
n
t
r
o

bb

b

bb

l

aa

a

aa

Maximum
13/32”

Condensed water

EXTERNAL VIEW

Drain hose
(not included)

Under-side view with drain
pan and hose in place.

3

PART IDENTIFICATION

2 Install the optional drain pan (part no. CWH40175).

Install the drain pan at the right
corner of the cabinet using 2

INTERNAL VIEW

screws (part no. CWG86C733).

Note
The drain pan (part no.
CWH40175) can be obtained

Screws

Drain pan (optional)

from nearest service center.

MAIN UNIT

1 Air inlet louver 4 Air filter (behind the

2 Cabinet 5 Front intake

3 Power cord 6 Front grille

7 Vertical airflow direction vane

(Airflow direction adjustment up­down).
The vertical airflow direction vane
is controlled by rotating the
horizontal vane forward or backward.

4

5

8 Ventilation lever

1

2

6

7

8

9

3

The ventilation lever must be in the CLOSE position in order to
maintain the best cooling conditions. When fresh air is necessary

°F

TIMER

O
P
E

R
A

T

T

E

I
O

M

N

P

/T
IM

E
R

h
r

S
E

T

S

E

OFF/ON

T

/
C
A

N
C

E

COOL

L

FAN

MODE

AIR SWING
HIGH

MED

FAN SPEED

LOW

in the room, set the ventilation lever to the OPEN position. The

E
C
O

N

O
M

Y

Wireless

Remote Control

damper is opened and room air is drawn out.

TYPES OF SIGNAL SOUND
One long “Beep” and one short “Beep”. (Sound from the main unit.)

4 Slide the chassis back into the

cabinet.
Reinstall the cabinet screws.
Secure the cabinet to chassis by
using screws.

9 Touch control panel

front intake grille)

grille

a Display Panel

°

F

T
IM

E

O

R

P
E

R
A

T

T

E
M

P
/
T

I
M
E

R

h
r

S

E
T

SET/

O
F

F
/
O

CANCEL

C
O

O

L
F
A

M

N

OD

E

A
IR

S
W

IN

G
H
IG

H

EC
O

N
O

M
E

D

F
A
N
S

P
E
E

D
L
O

W

W
ireless

R
e
m
o

te

C
o

n
tro

l

b MODE selection pad

I
O
N

N

M
Y

c FAN SPEED selection pad
d TEMPERATURE/TIMER

e TIMER pad
f Timer SET/CANCEL pad
g OPERATION OFF/ON pad
h AIR SWING pad
i ECONOMY pad

a

COOL

MODE

b

FAN

HIGH

FAN SPEED

MED

c

LOW

setting pad

°F

T

I
M
E

OP

R

E
R
AT
IO

T

N

E
M

P
/
T
I
M

E
R

h
r

S
E

T

S

O

E

F

T

/

F
/
O

N

C

A
N
C

E
L

C
OOL

F
AN

M
ODE

AIR SWING

HIGH

E
C

O
N
O
M

Y

ME

D

FAN SPE

ED

LOW

W

ir

e
le

s
s

R

em
ot

e C

ont
ro

l

e

d

°F

TEMP/TIMER

hr

AIR SWING

TIMER

SET

SET/

CANCEL

f

h

Wireless

Remote Control

OPERATION

OFF/ON

ECONOMY

g

i

3

AIR SWING

PART

ACCESSORIES

• Remote control • Two R03 dry-cell batteries

REMOTE CONTROL

1 Signal Transmitter
2 OPERATION button
3 TEMPERATURE/TIMER setting button
4 TIMER button
5 TIMER SET/CANCEL button
6 MODE selection button
7 ECONOMY Button

IDENTIFICATION

8 AIR SWING button
9 Fan Speed Selection Button

4

6

AIR SWING

8

Be sure to observe the following:

• Aim remote control at control

1

2

OPERATION

TEMP/TIMER

3

SET/

TIMER

CANCEL

5

ECONOMY

MODE

FAN SPEED

7

9

panel on air conditioner when
operating.

• Do not drop or throw the remote
control.

• Do not place the remote control
in a location that is exposed to
direct sunlight or next to a heating
unit or other heat sources.

• Maximum distance : 10 m (32.8 ft.)

°

C

T
I
M

E

O

R

P

E
R
A

T

T

E

IO

M

N

P

/
T
I
M

E
R

h
r

S

E
T

S
E

O

T

F

/

F
/
O

N

C
A
N

C
E

C

L

OO

L

FA

M

N

O
D

E

A
I

R
SWIN

G
HI
GH

P
O

W
E

R
FU
L

FA

N
S
P

E
E

D
L
OW

W
ir

e

l
e
s

R

s

em

o
t
e
C

o
n
t
ro

l

4

HOW TO INSERT BATTERIES

OPERATING

1

Open the cover.

PREPARATION BEFORE

5

CAUTION

OPERATING THE UNIT

OPERATION

OFF/ON

OPERATION

SETTING DISPLAY TEMPERATURE

TEMP/TIMER

TEMP/TIMER

WARNING

Ensure that the power
plug is securely inserted.

A loose plug may cause a
fire or an electric shock.

2

Insert the two batteries.

• If the unit is not going to be used for an extended period of time, remove the
power plug. Otherwise, approximately 2.5W of electricity will be used even if the
unit has been turned off using the remote control.

• If operation is stopped, and to be restarted immediately, the unit will resume
operation only after 3 minutes.

3

Close the cover.

Do not use rechargeable (Ni-Cd) batteries
because such batteries differ from the standard
dry cell batteries in shape, dimension and
performance.

NOTES

Start operation by pressing

°F

hr

OPERATION.
The operation will turn on and the
display panel will light up.

°F

hr

To stop the operation, press the
OPERATION again.
The unit will stop operating and the
display panel light will turn off.

Press TEMP/TIMER ▲ or ▼ to set the

°F

hr

display temperature.

Display will
change
according to
the setting.

The temperature can be set between
60°F and 86°F.
Recommended temperature:
75°F ~ 78°F.

ABOUT THE BATTERIES

• The batteries can be used for approximately one year.

• Be sure to replace the batteries with two new identical

batteries.

• Remove the batteries if the air conditioner will not be used
for an extended period of time.

SELECTING OPERATION MODE

COOL

MODE

FAN

Press MODE to select the desired
operation .

COOL

The indicator will light up and a “beep”

FAN

sound will indicate changing setting.

COOL mode

To set room temperature to your
preference of cooling comfort.

FAN mode

To provide air circulation without cooling
the room.

MODE

During Fan operation, temperature
setting cannot be selected.

NOTES

• The latest temperature setting will be memorized and will
appear on the display the next time it’s turned on.

• The display temperature selection is for display purpose only

AIR CONDITIONER OPERATION

and does not indicate actual room setting temperatures. Your
room temperature may not necessarily match the displayed
temperature.

SELECTING FAN SPEED

HIGH

MED

LOW

FAN SPEED

FAN SPEED

Press FAN SPEED to choose the

HIGH

speed level of the fan.
The indicator will light up and the “beep”

MED

sound will indicate changing setting.

LOW

NOTE

• The latest fan speed setting will be memorized and the indicator
will light up the next time the unit is turned on.

ADJUSTING HORIZONTAL AIR FLOW DIRECTION

Press to select AIR SWING.
The air circulation will automatically move the
horizontal louvers left and right for better air
distribution around the room.

NOTE
Using your hands to adjust the direction may cause
the louvers to malfunction. If this happens, stop

AIR SWING

operation immediately and restart.

NOTE

Vertical
louvers

°F

T
I
M

E

O

R

P
E

R
A

T

T

E

IO

M

N

P
/T

I
M
E

R

hr

S
E
T

SET/

O
FF

/O

N

CANCEL

COOL

FAN

MODE

AIR SWING

HIGH

ECONOMY

MED

FAN SPEED

LOW

W

ire

le

s
s

Remote Control

Vertical adjustment of the airflow direction
is done manually.

5

TEMP/TIMER

OFF/ON

OPERATION

OPERATION

TEMP/TIMER

ECONOMY OPERATION

To reduce power consumption:

ECONOMY

ECONOMY

°F

hr

• Press ECONOMY.

• To cancel this operation, press once

more.

ECONOMY
Recommended for electricity cost saving. When economy button is
pressed, target temperature is shifted up 1°F, this will reduce operating
time of the compressor and therefore reduce power consumption. It
may, however, take a little longer for the compressor to cycle on and
thereby increase the room temperature slightly. Economy mode will
override your current set fan speed to “LOW”. However, the display will
still show the current set fan speed. Compressor stops when the room
temperature reaches the target temperature. It turns on again when
the room temperature rises. When power failure occurs, the economy
setting is canceled. Once power is resumed, reset the economy setting.

SETTING THE OFF TIMER

When the air conditioner in operation:

TIMER

°F

hr

Press the TIMER button.
The SET/CANCEL indicator light will

AIR CONDITIONER OPERATION

TEMP/TIMER

SET

SET/

CANCEL

blink awaiting for setting.

°F

hr

Press the TEMP/TIMER ▲ or ▼ button
until the preferred hour of operation is

°F

reached.

hr

Press the SET/CANCEL button to
complete the setting. At this time, the
SET/CANCEL indicator light is steady
instead of blinking.

TIMER

NOTE
The hour reading will change back to the
set temperature reading after 10

TEMP/TIMER

SET/

CANCEL

seconds. (You can also revert to
temperature setting immediately by
pressing the TEMP/TIMER ▲ or ▼
buttons again.)

CHECK TIMER SETTING DURING OFF TIMER

Press the TIMER button to check the

°F

remaining programmed timer setting.

TIMER

hr

The figure will be displayed for 10

°F

seconds then will automatically switch

hr

back to temperature setting.

NOTE

TIMER

The timer figure will change according
to the time remaining (if you set it to turn
off 3 hours from now, the timer will show
“2” at an hour later).

CANCEL TIMER SETTING DURING OFF TIMER

SET

SET/

CANCEL

SET/

CANCEL

Press the SET/CANCEL button to cancel

°F

the timer setting. The SET/CANCEL

hr

indicator light will turn off. However the
temperature remains displayed.

SETTING THE ON TIMER

When the air conditioner in operation:

TIMER

°F

hr

Press the TIMER button. The TIMER
indicator light will blink to await for setting.

°F

SET

SET/

CANCEL

Press the TEMP/TIMER

hr

until the desired hour for operation is
reached. Press the SET/CANCEL button

°F

to complete the setting. At this time, the

hr

TIMER indicator light is steady instead of
blinking.

°F

The display will show the remaining hour

hr

to the start of the operation (if you set to

▲ or ▼

turn on 3 hours from now, the timer will
show “2” at an hour later).

TIMER

When set time is reached, the air
conditioner starts the operation under the
previous setting mode and the TIMER
indicator will light off. Now, the previous

SET/

CANCEL

set mode and the fan speed will light up.
Simultaneously, the display will show the
setting temperature.

CHECK TEMPERATURE/MODE/FAN SPEED
SETTING DURING ON TIMER

Press the TIMER button. The TIMER

TIMER

°F

indicator light will blink and the previous

hr

temperature setting will be shown.

°F

Simultaneously, MODE and FAN

hr

SPEED indicator will light up. This
indication will last for 5 seconds, and
then the display will show the remaining
time. MODE and FAN SPEED indicator

TIMER

light will turn off. At this time, the TIMER
indicator light is steady instead of
blinking.

CHANGE TEMPERATURE/MODE/FAN SPEED
SETTING DURING ON TIMER

SET

SET/

CANCEL

OPERATION

OFF/ON

TIMER

SET/

CANCEL

TIMER

Press the SET/CANCEL button to

°F

hr

cancel the timer setting.
Press the OPERATION. Set the desired

°F

mode and the fan speed. Then press

hr

OPERATION button to stop operation.
Start the TIMER setting again by

°F

repeating the step from the “Setting the

hr

on timer” procedures).

CANCEL TIMER SETTING DURING ON TIMER

SET

SET/

CANCEL

SET/

CANCEL

OPERATION

Press the SET/CANCEL button to cancel the

°F

timer setting. The SET/CANCEL indicator

hr

light will turn off. To operate the air

°F

conditioner before reaching the set timer:

hr

• Press the SET/CANCEL to cancel the
timer.

• Press the OPERATION button to turn on
the unit.

button

Model HQ-2102UH HQ-2122UH

6

COOLING CAPACITY Btu/h 10,000 11,500

ELECTRICAL RATING Phase Single +

EER (Btu/W.h) 10.2 +

MOISTURE REMOVAL (Pints/h) 2.5 3.0

ROOM AIR CIRCULATION (Cf/min) 320 330

DIMENSIONS Height cm (inches) 37.5 (14-

NET WEIGHT kg (lb) 35 (77) +

GROSS WEIGHT kg (lb) 39 (86) +

NOISE LEVEL Indoor (Hi/Lo) dB (A) 50/46 51/47

* Specifications are subject to change without notice for further improvement.

PRODUCT SPECIFICATIONS

Frequency (Hz) 60 +
Voltage (V) 115 +
Current (Amps) 8.7 9.8
Input (W) 980 1120

25

/32˝) +

1

Width cm (inches) 56 (22-

/16˝) +

Depth cm (inches) 60.6 (23-27/32˝) +

Outdoor (Hi/Lo) dB (A) 57/54 58/55

7

Random Auto Restart

• Operation will automatically

• If the unit was set to TIMER

Timer Setting

• When power failure occurs, the

ENERGY SAVING HINTS

HELPFUL INFORMATION &

HELPFUL INFORMATION

resume under the previous
operation mode.

mode, operation will not resume
automatically.

timer setting is canceled. Once
power returns, reset the timer.

ENERGY SAVING HINTS

• Setting the temperature 1°F higher save
10% electricity costs.

• Clean the air filter every 2 weeks. Regular
cleaning of the air filter preserves efficiency.

• Keeping openings closed keeps cool air in
and hot air out.

• Avoid direct sunlight and heat.

• For health reasons do not overcool your

room.

• Your air conditioner’s cooling capacity
should match your room size.

8

CARE AND MAINTENANCE

9

CAUTION

• Clean the cabinet, front grille with a mild soap or detergent and lukewarm water.

• The front intake grille can be easily removed for cleaning purposes (refer to Remove the front intake grille procedures). Gently

wash it with water and a sponge.

• The filter can be easily cleaned using a vacuum cleaner. Vacuum the front of the filter and then wash the rear with water. If it is
badly soiled, wash with a mild household detergent.
It is recommended to replace the (part no.CZ-SF6P) every 3 months.

• Do not clean with benzene, thinner, scouring powder or cloth soaked in caustic chemicals.

• If the unit is extremely dirty, heat transfer is less efficient and the unit may not cool effectively. Contact your nearest servicenter

for an annual check. (Annual check is not covered under warranty)

• If the air filter becomes clogged with dust, the cooling capacity will drop, and 6% of the electricity used to operate the air
conditioner will be wasted.

NOTE
Do not dry the front panel or the air filter in direct sunlight. (Exposure to direct sunlight may discolor or deform the panel.)

PRE-SEASON INSPECTION

•

Is the discharged air cold?

After 15 minutes of operation, it is normal for the temperature
difference between intake and outlet air to be more than 14.4°F
for cooling.

•

Are the air intake and outlet vanes of the indoor and outdoor
side obstructed?

•

Are the remote control batteries weak?

BEFORE

Always turn off the air conditioner and the main power supply before clean the unit.
Switch off the power supply if the unit is not going to be used for a long period of time.

Check the following points before calling for repairs or service. If the malfunction persists, please contact your
nearest service center. For assistance, please call: 1-800-211-PANA (7262) or send e-mail to:
[e-mail]

RECOMMENDED INSPECTION

• Usage over several seasons will reduce performance as the
unit becomes dirty.
A dirty unit may produce foul odors and dust may clog the
dehumidifying drainage.
Seasonal inspection is recommended in addition to regular
cleaning. Consult your nearest service center.

POSSIBLE CAUSES OF THE ABOVE PROBLEMS

Condition 1

The following sounds are normal during operation:

• A low humming sound indicating that the unit is operating.

• A soft clicking sound when the compressor turns on and off.

• A flowing sound due to circulation of the refrigerant when the

compressor is turned on.

• A splashing sound indicating condensation in the condenser
coil.

If you hear other noises, please consult your nearest servicenter.

Condition 2

• The main power cord is not plugged in.

• The internal fuse has blown.

• The main circuit breaker has tripped.

• Remote control batteries are weak.

BEFORE CALLING FOR SERVICE

Condition 3

• The room is too big for the unit’s cooling capacity.

• The ventilation lever is set to OPEN.

• The air circulation is impeded by curtains or furniture.

• After 15 minutes of operation, it is normal for the temperature

difference between intake and outlet air to be more than 14.4°F
for cooling.

If the unit is too noisy during operation.

If the unit does not operate.

If the unit does not cool properly.

Condition 4

• Humidity is high.

• Condensed water is overflowing.

• To rectify the problem, mount an optional drain pan to the

unit.

Condition 5

• The unit is tilted inward. To rectify this, tilt the unit slightly
outward.

• Mount the optional drain pan if you prefer.

• The drain pan may be blocked.

If the trouble persists after you have checked all of these,
call your authorized Panasonic dealer or servicenter.
Service information can be obtained 24 hours/day by calling:
1-800-211-PANA (7262)
To expedite the repair of your air conditioner:

• Please have your proof of purchase.

• List all symptoms the unit is exhibiting.

If water drips off the rear of the unit.

If water drips inside the room.

Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation
of America

One Panasonic Way
Secaucus, New Jersey 07094

Panasonic Sales Company,
Division of Matsushita Electric of Puerto Rico, Inc.,

Ave. 65 de Infanteria, Km. 9.5
San Gabriel Industrial Park
Carolina, Puerto Rico 00985

Quasar Room Air Conditioner

Limited Warranty

Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the Warrantor”) will repair this
product with new or refurbished parts in case of defects in material or workmanship, free of charge, in the USA or Puerto Rico in accordance
to the following (All time periods start from the date of the original purchase).

SEALED REFRIGERATING SYSTEM (compressor and interconnecting tube): FIVE (5) YEARS - PARTS AND LABOR

ALL OTHER COMPONENTS: ONE (1) YEAR - PARTS AND LABOR

In-home service in the USA can be obtained during the warranty period by contacting a Panasonic Service Company (PASC) Factory
Servicenter listed in the Servicenter Directory. Or call toll free, 1-800-211-PANA(7262), to locate a PASC authorized Servicenter. In-home
service in Puerto Rico can be obtained during the warranty period by calling the Panasonic Sales Company telephone number listed in the
Servicenter Directory.

Note: If the unit is installed at the other than normal window height and/or has been

custom-installed (e.g., through the wall), the customer is responsible for removing
the unit from its installation prior to the performance of in-home service.

This warranty is extended only to the original purchaser. A purchase receipt or other proof of date of the original purchase is required for
service and parts replacement under this warranty.

This warranty only covers failures due to defects in materials and workmanship and does not cover normal wear or cosmetic damage. The
warranty does not cover damages which occur in shipment, or failures which are caused by products not supplied by the warrantor, or
failures which result from accident, misuse, abuse, neglect, mishandling, misapplication, faulty installation, maladjustment of customer
controls, improper maintenance, alteration, modification, power line surge, lightning damage, improper voltage supply, commercial use
such as hotel, office, restaurant, or other business or rental use of the product, or service by anyone other than a PASC Factory Servicenter
or a PASC authorized Servicenter, or damage that is attributable to acts of God.

LIMITS AND EXCLUSIONS

There are no express warranties except as listed above.
THE WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED
WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY, ARE LIMITED TO THE APPLICABLE WARRANTY
PERIOD SET FORTH ABOVE.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied
warranty lasts, so the above exclusions or limitations may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state. If a problem with this
product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not handled to your
satisfaction, then write to the Consumer Affairs Department at the company address indicated above.

SERVICE CALLS WHICH DO NOT INVOLVE DEFECTIVE MATERIALS OR WORKMANSHIP AS DETERMINED
BY THE WARRANTOR, IN ITS SOLE DISCRETION, ARE NOT COVERED. COSTS OF SUCH SERVICE CALLS ARE
THE RESPONSIBILITY OF THE PURCHASER.

[For assistance, please call: 1-800-211-PANA (7262) or send e-mail to [e-mail]]

Printed in Malaysia

F0310-0

F564236
