Quantum L500 Instruction Manual
Document 6321102-01, Ver. 1 Rev. 0
August 1998
PowerStor L500 Library
Unpacking Instructions
Introduction....................................................................................................3
Purpose.....................................................................................................3
Library Configurations ..........................................................................3
Selecting an Installation Location ............................................. ..................4
Floor Space.................................................. ......... ....................................4
Overhead Clearance...............................................................................5
Surface Strength and Inclination..........................................................5
0
0
0
Power and Grounding ...........................................................................5
Environmental Specifications ...............................................................5
Receiving the Library....................................................................................6
Unpacking the Library................................................................ ......... .........7
Uncrating the Rack-Mount Kit..............................................................7
Installing the Rack-Mount Kit...............................................................7
Uncrating the Library.............................................................................8
1
PowerStor L500 Library Unpacking Instructions
Document 6321102-01, Ver. 1 Rev. 0
August 1998
2
PowerStor L500 Library Unpacking Instructions
Document 6321102-01, Ver. 1 Rev. 0
August 1998
0
0
0
Purpose
Library Configurations
Figure 1 PowerStor L500
Library Configuratio ns
Introduction
0
This document explains how to unpack the PowerStor L500 library
0
properly. Once the library is unpacked and moved to the desired
installation location, set up the library using the instructions in the
PowerStor L500 Library User’s Guide.
The PowerStor L500 library is shipped in packing materials designed
to protect it from damage during transit. By following these
instructions, you help ensure that the library will continue to be
safeguarded after it arrives at the installation site.
The PowerStor L500 library is shipped in two configurations:
0
‡ Stand-alone (tower) configuration
‡ Rack-mount configuration
TK00001a
Stand-alone configuration Rack-mount configuration
Introduction 3
TK00002a
Document 6321102-01, Ver. 1 Rev. 0
August 1998
Floor Space
Figure 2 Floor Space
Requirements (StandAlone Library)
Selecting an Installation Location
1
When selecting an installation location for the library, consider the
following:
‡ Floor space
‡ Overhead clearance
‡ Installation surface strength and inclination
‡ Power and grounding
‡ Environmental specifications
1
Figure 2 shows the floor space requirements for setting up and
operating the stand-alone library.
10.5 inches
(26.67 cm)
Back
20.0 inches
(50.8 cm)
Front
Figure 3 shows the floor space requirements for setting up and
operating the rack-mount library.
4 Selecting an Installation Location
