Quantum 1420, 1470, 1400 User Manual
Includes 1470, 1420, and 1400
ATTENTION:
Please read the content
of your owners manual
before operating your
power chair.
Owners Manual
“Quantum Jazzy 1470”
1-800-800-8586 (Exeter , P A) • 1-888-570-1 1 13 (St. Catharines, ON) • www.quantumrehab.com
SAFETY GUIDELINES
Please read and follow all instructions in this owners manual before attempting to operate your power chair for the first
time. If there is anything in this manual you do not understand, or if you require additional assistance for set-up, contact
your authorized Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings, cautions, and instructions in this
owners manual. Using your Pride product safely also depends upon your own good judgement and/or common
sense, as well as that of your provider, caregiver, and/or healthcare professional. Pride is not responsible for injuries
and/or damage resulting from any persons failure to follow the warnings, cautions, and instructions in this owners
manual. Pride is not responsible for injuries and/or damage resulting from any persons failure to exercise good
judgement and/or common sense.
The symbols below are used throughout this owners manual to identify warnings and cautions. It is very important for
you to read and understand them completely.
WARNING! Failure to heed the warnings in this owners manual may result in personal
injury.
CAUTION! Failure to heed the cautions in this owners manual may result in damage to your
power chair.
Copyright © 2004
Pride Mobility Products Corp.
INFMANU2031
CONTENTS
I. INTRODUCTION ................................................................................................................................4
II. SAFETY ................................................................................................................................................. 6
III. EMI/RFI ................................................................................................................................................13
IV. THE QUANTUM JAZZY 1400 SERIES .................................................................................. 15
V. COMFORT ADJUSTMENTS........................................................................................................ 20
VI. BATTERIES AND CHARGING .................................................................................................... 27
VII. OPERATION ....................................................................................................................................... 31
VIII. CARE AND MAINTENANCE ........................................................................................................ 39
IX. OPTIONAL ACCESSORIES ......................................................................................................... 44
X. WARRANTY ........................................................................................................................................ 45
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
5
I. INTRODUCTION
INTRODUCTION
Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Pride Power Chair. The Pride
Power Chair design combines the most advanced state-of-the-art components with modern, attractive styling. We are certain that the
design features and trouble-free operation of your new power chair will add convenience to your daily living.
At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before you attempt to operate your
power chair for the first time. These instructions were produced for your benefit. Your understanding of these instructions is essential for
the safe operation of your new power chair.
Pride is not liable for damage to property or personal injury arising out of unsafe use of a power chair. Pride is also not liable for any
property damage or personal injury arising out of the failure of any person and/or user to following the instructions and recommendations
set forth in this manual or any other instructions or recommendations contained in other power chair related literature issued by Pride or
contained on the power chair itself.
This owners manual is compiled from the latest specifications and product information available at the time of publication. We reserve
the right to make changes as they become necessary. Any changes to our products may cause slight variations between the illustrations
and explanations in this manual and the product you have purchased.
If you experience any problems with your power chair that you are unable to solve, or if you do not feel capable of safely following any
of the instructions and/or recommendations as contained in this manual, please contact your authorized Pride provider for assistance.
Once you understand how to operate and take care of your power chair, we are certain that it will give you years of trouble-free service
and enjoyment.
Information Exchange
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about the safety and reliability
of your new power chair, and about the service you received from your authorized Pride provider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new products, and new
options that can increase your ability to use and enjoy your power chair. Please feel free to contact us at the address below:
Pride Mobility Products Corporation
Attn: Customer Care Department
182 Susquehanna Avenue
Exeter, PA 18643-2694
customercare@pridemobility.com
800-424-8205
6
www.pridemobility .com Quantum Jazzy 1400 Series Rev C Feb 04
I. INTRODUCTION
Pride Owners Club
As an owner of a Pride product, you are invited to register your products warranty and enroll in the Pride Owners Club. You may do
so by filling out and returning your enclosed registration card or by visiting Prides web site at www.pridemobility.com. As a registered
member, each time you visit our site, you will have access to the most interactive and honest educational venue available today for people
with mobility needs, their families, and friends.
From our home page, select Owners Club to enter a page dedicated to current and potential Pride product owners. You will gain
access to interviews, stories, recreation ideas, daily living tips, product and funding information, and interactive message boards. These
message boards invited you to communicate with other Pride customers as well as Pride representatives who are available to assist you
with any questions or concerns you may have.
My Authorized Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Phone Number:________________________________________________________________________
Purchase Date:________________________________________________________________________
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and we will be
glad to send you a new one immediately.
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
7
II. SAFETY
SAFETY
WARNING! Do not operate your new power chair for the first time without completely reading and
understanding this owners manual.
Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an extensive variety of
products to best fit the individual needs of the power chair user. Please be aware that the final selection and purchasing decision regarding
the type of power chair to be used is the responsibility of the power chair user, who is capable of making such a decision, and his/her
healthcare professional (i.e., medical doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted the power chair to the user and
has assisted the prescribing healthcare professional and/or the authorized Pride provider in the instruction process for the use of the
product.
There are certain situations, including some medical conditions, where the power chair user will need to practice operating the power
chair in the presence of a trained attendant. A trained attendant can be defined as a family member or care professional specially trained
in assisting a power chair user in various daily living activities.
As you begin using your power chair during daily activities, you will probably encounter situations in which you will need some practice.
Simply take your time and you will soon be in full and confident control as you maneuver through doorways, on and off of elevators, up
and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accustomed to operating the power
chair safely.
Modifications
Pride has designed and engineered your power chair to provide maximum mobility and utility. A wide range of accessories is available
from your authorized Pride provider to further customize your power chair to better suit your needs and/or preferences. However, under
no circumstances should you modify, add, remove, or disable any feature, part, or function of your power chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Get to know the feel of your power chair and its capabilities. Pride recommends that you perform a safety check before each use to
make sure your power chair operates smoothly and safely. See VIII. Care and Maintenance.
Perform the following inspections prior to using your power chair:
n Check for proper tire inflation. Maintain 30-35 psi in each tire (if equipped with pneumatic tires).
n Check all electrical connections. Make sure they are tight and not corroded.
n Check all controller connections to the electronics tray. Make sure they are secured properly.
n Check the brakes. See VIII. Care and Maintenance.
n Check battery charge. See VI. Batteries and Charging.
NOTE: If you discover a problem, contact your authorized Pride provider for assistance.
8
www.pridemobility .com Quantum Jazzy 1400 Series Rev C Feb 04
II. SAFETY
Weight Limitations
Your power chair is rated for a maximum weight capacity. Please refer to the specifications table for this limit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
If your power chair is equipped with pneumatic tires, you should check or have the air pressure checked at least once a week. Proper
inflation pressures will prolong the life of your tires and help ensure the smooth operation of your power chair.
WARNING! It is important that 30-35 psi tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 30-35 psi tire pressure in pneumatic tires at all
times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your Jet.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in
a burst tire and/or personal injury.
Incline Information
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe access. Some ramps may have
turning switchbacks (180-degree turns) that require you to have good cornering skills on your power chair.
n Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
n Take wide swings with your power chairs front wheels around any tight corners. If you do that, the power chairs rear wheels will
follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing corners.
n When driving down a ramp, keep the power chairs speed adjustment set to the slowest speed setting to ensure a safely controlled
descent. See VII. Operation.
n Avoid sudden stops and starts.
When climbing an incline, try to keep your power chair moving. If you must stop, start up again slowly and then accelerate cautiously.
When driving down an incline, set your power chair to the slowest setting and drive in the forward direction only. If your power chair
starts to move down the incline faster than you anticipated or desired, allow it to come to a complete stop by releasing the joystick, then
push the joystick forward slightly to ensure a safely controlled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
9
II. SAFETY
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications
presented in this manual. Doing so could cause instability in your power chair, resulting in personal injury
and/or damage to your power chair.
In compliance with the Americans with Disabilities Act of 1990, all handicap public access ramps are required to have a maximum slope
of 5°. Therefore, Pride recommends that the maximum slope of an incline you attempt to safely ascend or descend on your power chair
does not exceed 5°. See figure 1.
Figure 1. Maximum Safe Angle (Ascending and Descending)
WARNING! Any attempt to climb or descend a slope steeper than 5° may put your power chair in
an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Your power chair is equipped with two powerful brake systems:
1. Regenerative uses electricity to rapidly slow the vehicle when the joystick returns to the center/stop position.
2. Disc Park Brake activates mechanically after regenerative braking slows the vehicle to near stop, or when power is removed from
the system for any reason.
Cornering Information
While your power chair is equipped with rear caster wheels in back and anti-tip wheels in front, excessively high cornering speeds can
still create the possibility of tipping. Factors which affect the possibility of tipping include, but are not limited to: cornering speed, steering
angle (how sharply you are turning), uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high
traction (such as passing from a grassy area to a paved area especially at high speed while turning), and abrupt directional changes.
High cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and steering angle (i.e.,
lessen the sharpness of the turn) to prevent your power chair from tipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Outdoor Driving Surfaces
Your power chair is designed to provide optimum stability under normal driving conditionsdry, level surfaces composed of concrete,
blacktop, or asphalt. However, Pride recognizes that there will be times when you will encounter other surface types. For this reason,
your power chair is designed to perform admirably on packed soil, grass, and gravel. Feel free to use your power chair safely on lawns
and in park areas.
n Reduce your power chairs speed when driving on uneven terrain and/or soft surfaces.
n Avoid tall grass that can entangle the running gear.
n Avoid loosely packed gravel and sand.
n If you feel unsure about a driving surface, avoid that surface.
10
www.pridemobility .com Quantum Jazzy 1400 Series Rev C Feb 04
II. SAFETY
Freewheel Mode
Your power chair is equipped with a manual freewheel lever to allow for manual maneuverability by a trained attendant. For more
information about how to place your power chair into and out of freewheel mode, see IV. The Quantum Jazzy 1400 Series.
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceed with extreme caution when driving near raised surfaces, unprotected ledges and/or drop-offs (curbs, porches, stairs, etc.). The
correct method for approaching a curb is illustrated in figure 1a.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Figure 1a. Curb Approach (Correct and Incorrect)
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme caution.
Stairs and Escalators
Power chairs are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
11
II. SAFETY
Doors
n Determine if the door opens toward or away from you.
n Drive your power chair gently and slowly forward to push the door open. Or drive your power chair gently and slowly backward
to pull the door open.
Elevators
Modern elevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
n If you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or allow the rubber door
edge to contact the power chair and the door will reopen.
n Use care that pocketbooks, packages, or power chair accessories do not become caught in elevator doors.
EMI & RFI
Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause unintended motion
of electric mobility vehicles. Radio waves are a form of electromagnetic energy (EM). When EM adversely affects the operation of an
electronic device, it is called Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI). For more information, see III.
EMI/RFI.
Lift/Elevation Products
If you will be traveling with your power chair, you may find it necessary to use a lift/elevation product to aid in transportation. Pride
recommends that you closely review the instructions, specifications, and safety information set forth by the manufacturer of the lift/
elevation product before using that product.
Motor Vehicle Transport
Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a person while seated in
a power chair.
Transfers
Transferring onto and off of your power chair requires a good sense of balance. Always have an attendant or healthcare professional
present while learning to properly transfer yourself.
To eliminate the possibility of injury, Pride recommends that you or a trained attendant perform the following tasks before attempting a
transfer:
n Turn the power off. See VII. Operation.
n Ensure your power chair is not in freewheel mode. See IV. The Quantum Jazzy 1400 Series.
n Turn both caster wheels toward the transfer destination to improve power chair stability during transfer.
n Make sure both armrests are flipped up or removed from your power chair.
n Flip the footrest up, or move the leg rests aside; this will help to keep your feet from getting caught on the footrest or the leg rests
during the transfer.
n Reduce the distance between your power chair and the object you are transferring onto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
12
WARNING! Avoid putting all of your weight on the footrest. Such use may cause the power chair
to tip and cause personal injury.
www.pridemobility .com Quantum Jazzy 1400 Series Rev C Feb 04
II. SAFETY
Positioning Belts
Your authorized Pride provider, therapist(s), and other healthcare professionals are responsible for determining your requirement for a
positioning belt in order to operate your power chair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your Jazzy suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Inclement Weather Precautions
WARNING! Pride recommends that you do not operate your power chair in icy or slippery conditions or on salted surfaces (i.e., walks or roads). Such use may adversely affect the performance
and safety of your power chair, resulting in an accident and personal injury.
WARNING! Do not expose your power chair to any type of moisture at any time (rain, snow, mist,
or wash). Such exposure can damage your power chair. Never operate your power chair if it has
been exposed to moisture until it has dried thoroughly.
Reaching and Bending
Never reach, lean, or bend while driving your power chair. If it is absolutely necessary to reach, lean, or bend while seated on your power
chair, it is important to maintain a stable center of gravity and keep the power chair from tipping. Pride recommends that the power chair
user determine his/her personal limitations and practice bending and reaching in the presence of a qualified healthcare professional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by reaching
down between your knees. Movements such as these may change your center of gravity and the weight
distribution of the power chair. This may cause your power chair to tip, possibly resulting in personal injury.
Keep your hands away from the tires when driving.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more information about
your power chairs batteries, see VI. Batteries and Charging.
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that much
weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds. Wash
hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging a frozen
battery may result in personal injur y and/or damage to the battery. Attempting to charge a battery in
freezing conditions does not prevent a batter y from freezing.
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
13
II. SAFETY
Preventing Unintended movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time, turn off
the power. This will prevent unexpected motion from inadvertent joystick contact. This will also eliminate
the possibility of unintended chair movement from electromagnetic (EM) sources. Failure to do so may
result in personal injury.
Prescription Drugs/Physical Limitations
Users must exercise care and common sense when operating a power chair. This includes awareness of safety issues when taking
prescribed or over-the-counter drugs or when the user has specific physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if you
have certain physical limitations. Some medications and limitations may impair your ability to operate your
power chair in a safe manner.
Alcohol
The power chair user must exercise care and common sense when operating his/her power chair. This includes awareness of safety
issues while under the influence of alcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this may impair
your ability to operate your power chair in a safe manner.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal injury and/
or damage to the power chair may result.
14
www.pridemobility .com Quantum Jazzy 1400 Series Rev C Feb 04
III. EMI/RFI
EMI/RFI
Laboratory tests performed by the Food and Drug Administration (FDA) have shown that radio waves can cause unintended
motion of power chairs. Radio waves are a form of electromagnetic energy. When this energy adversely affects the operation
of an electronic device, it is called Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI).
WARNING! Radio waves may interfere with the control of power chairs.
Frequently Asked Questions (FAQs)
The following FAQs summarize what you should know about EMI/RFI. Use this information to minimize the risk that EMI/
RFI will affect your power chair.
Where do radio waves come from?
Radio waves are emitted from the antennas of cellular phones, mobile two-way radios (such as walkie-talkies), radio stations,
TV stations, amateur radio (HAM) transmitters, wireless computer links, microwave sources, and paging transmitters. Radio
waves are a form of electromagnetic energy (EM). Because electromagnetic energy is more intense closer to the transmitting
antenna (source of emission), the EM fields from two-way radios are of special concern to power chair users.
If my power chair is affected by EMI/RFI, what kind of motion should I expect?
This is hard to predict. It would depend on a number of factors:
n Strength of the radio waves
n Construction of the power chair
n Position of the power chair (whether it is on level ground or on an incline)
n Whether or not the power chair is in motion
An affected power chairs movement can be erratic. It may move by itself or come to a sudden stop. Furthermore, it is possible
for EMI/RFI to unexpectedly release the brakes on a power chair. Some intense sources of EMI/RFI can even damage the
control system of the Power chair.
Is there any way to know for sure whether radio waves are responsible for the unintended motion of my power chair?
Unfortunately, interference from radio wave sources may be difficult to recognize, since the signals from these sources are
invisible and may be intermittent. However, the FDA recommends that you report all incidents of unintended motion or brake
release to the power chair manufacturer and, if possible, note whether there was a radio wave source nearby at the time of the
incident.
Has anyone been hurt from erratic, unintended motion of power chairs?
The FDA has reports of injuries that resulted from the apparent uncontrolled motion of power chairs. However, it is unclear
how many of these incidents were actually caused by radio wave interference.
Are all power chairs susceptible to EMI/RFI?
Each make and model of chair differs in its ability to resist electromagnetic interference. That is, each has a particular level of
immunity to interference, measured in volts per meter (Vm). A higher immunity level offers greater protection. In other
words, a power chair with a high immunity level is less likely to be affected by a strong radio source than one with a low
immunity level.
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
15
III. EMI/RFI
What is the FDA doing about the problem?
The FDA has written to the manufacturers of power chairs and requested that they test their new products to be sure that they
provide a reasonable degree of immunity against EMI/RFI. The letter states that power chairs should have an immunity of at
least 20 V/m. This provides a reasonable degree of protection against the common sources of EMI/RFI.
The FDA has also requested that these manufacturers clearly label their products with the immunity level, or state that the
immunity level is not known. The labeling and informational material supplied with the power chair must explain what the
immunity level means, and the labeling or informational material must warn users about the possibility of EMI/RFI and
how to avoid it. In addition, the FDA has recommended that manufacturers establish an educational program to inform
users of power chairs, and their caregivers, about the problems associated with EMI/RFI, and the actions they can take to
minimize the risk.
What can I do to find out if my power chair is likely to be affected by EMI/RFI?
If youve had your power chair for a long time and havent experienced any unintended motion, it is not likely that you will have
problems in the future. But it is always possible that problems could arise if you are close to a source of radio waves. Therefore, it
is very important to be alert to this possibility. The Power chair meets or exceeds an immunity level of at least 20 V/m.
What can I do to reduce the risk that my power chair could be affected by EMI/RFI?
Here are some precautions you can take:
n Do not turn on or use hand-held personal communications devices, such as citizens band (CB) radios and cellular phones,
while the power chair is on.
n Be aware of nearby transmitters, such as radio or TV stations and hand-held or mobile two-way radios, and try not to come
close to them. For example, if you are in a power chair with an immunity level of 20 V/m, you should remain at least three
feet from a hand-held two-way radio and ten feet from a mobile two-way radio.
n Be aware that adding accessories and/or components, or modifying the power chair may make it more susceptible to
interference from radio wave sources. There is no easy way to evaluate their effect upon the overall immunity of the
power chair.
What should I do if my power chair moves unexpectedly?
If unintended motion or brake release occurs, turn the power chair off as soon as it is safe to do so. Call Pride at 800-424-8205
to report the incident.
16
www.pridemobility .com Quantum Jazzy 1400 Series Rev C Feb 04
IV. THE QUANTUM JAZZY 1400 SERIES
THE QUANTUM JAZZY 1400 SERIES
The Quantum Jazzy has two main assemblies: the seat and the power base. See figures 2 and 3. Typically, the seat assembly
includes the armrests, seatback, and seat base. The seat may also have some optional accessories attached to it, such as a basket,
a cane/crutch holder, or a cup holder. See IX. Optional Accessories.
The power base is the heart of the Power chair. The power base assembly includes two motor/brake assemblies, two drive
wheels, two anti-tip wheels, two caster wheels, two batteries, and wiring harnesses.
SEATBACK
ARMRESTS
JOYSTICK
SEAT ASSEMBLY
CONTROLLER
(REMOTE PLUS SHOWN)
POWER BASE
ASSEMBLY
CASTER WHEEL
DRIVE WHEEL
Figure 2. The Quantum Jazzy 1470 (1420 and 1400 are similar.)
SEAT BASE
BODY SHROUD
FOOTREST
ANTI-TIP WHEELS
Quantum Jazzy 1400 Series Rev C Feb 04 www.pridemobility .com
17
Loading...
