Quanta Computer QF3A User Manual

QT-195W-aa2 Media AIO PC

User Manual

Date: Aug. 2017

BU12 Quanta Computer Inc

Important Safety Instruction

1. DO NOT place objects on top of the device, as objects may scratch the screen.

2. DO NOT place the device on an uneven or unstable surface.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical field.

5. Please check with your Local Authority or retailer for proper disposal of electronic

products.

6. POWER INPUT RATING: Refer to the rating label on the device and be sure that the

power adapter complies with the rating. Only use the power supply specified by the

manufacturer.

7. WARNING: To avoid risk of electric shock, this device must only be connected to a

supply mains with protective earth”

8. DO NOT use a pen or any sharp object to tap the screen.

9. Clean the device with a soft, dampened cloth. Use 75% alcohol by-weekly for

disinfection.

10. Always power off the device to install or remove external devices that do not support

hot-plug.

11. Disconnect the device from an electrical outlet and power off before cleaning the device.

12. DO NOT disassemble the device. Only a certified service technician should perform

repair.

13. PLUGGABLE EQUIPMENT: the socket-outlet shall be installed near the equipment and

shall be easily accessible.

Please read the following before continuing setup:

● Make sure to use the power transformer(AC adapter) which is supplied by the

manufacturer. Use of unauthorized parts may cause the warranty to being void.

● Do not store the unit in the environment of the temperatures exceeding 60° C.

● Operating temperature of the device is within the range of 0° C to 35° C.

Important Safety Instruction .................................................................................................. 1

Introduction .............................................................................................................................. 3

Intended use .............................................................................................................................. 4

Summary of Application specifications .................................................................................. 5

Unpacking your smart terminal ............................................................................................. 7

Knowing QOCA Terminal ....................................................................................................... 8

Front view ............................................................................................................................. 8

Back View .............................................................................................................................. 9

Bottom View ........................................................................................................................ 10

Specification ........................................................................................................................ 11

Setup QOCA ........................................................................................................................... 13

Attaching to Arm ................................................................................................................ 13

Connect to Power ............................................................................................................... 14

Turn On and Off the Device .............................................................................................. 15

Power On .......................................................................................................................... 16

Power Off ......................................................................................................................... 16

Connect to the other USB devices .................................................................................... 17

Elucidations of the Icons Displayed...................................................................................... 18

Troubleshooting ...................................................................................................................... 20

QOCA Contacts ...................................................................................................................... 21

Appendix ................................................................................................................................. 22

Introduction

QOCA smart terminal is an all-in-one PC and tablet with a 19.5” touch display. It is being

used as a bedside terminal in the hospital, to provide medical information & preventive health

care for users in hospital. Hospital should install the terminal with an arm securely mounted

around the bed, to provide easy access for users in hospital.

Intended use

According to the definition of production specification of QOCA, this media AIO PC will be

endued with the following intended uses:

This medical PC will be widely used in point-to-point nursing care throughout the hospital

system environment from the ward to the station. By way of internet infotainment

information, this terminal can provide the patient with great assistance of essential medical

information, which is also able to improve the workflows of nurse & doctor and streamline

the collection & storages of the patient records.

This medical All-in-One PC with the abundant technological features is designed for great

interactive connectivity interfaces with other accessory compatible devices & offers two

independent USB 2.0 ports, one USB 3.0 port & one Ethernet port to connect arbitrarily.

Besides, QOCA also provides amazingly full & complete compatibility characteristics with

Google Android system (Operation System base) & Quanta QOCA medical management

system (Application Program base).

Nevertheless, this QOCA also supports external DC 19.1V with AC/DC medical grade power

adapter. This important medical grade AC adapter can make sure that QOCA is used safely &

effectively to users in all the corners of the hospital.

Summary of Application specifications

Application specifications are mainly derived from design inputs in the product development

phase. In this certain stage, intended use, patient population, body contact part, intended use

profile, use scenario(environment), use frequency, and interactive mobility are definitely

identified & regulated very much as application specifications

Intended Use:

This medical PC will be widely used in point-to-point nursing care throughout the hospital

system environment from the ward to the station. This terminal can provide the patient with

great assistance of essential medical information inquiry, which is also able to improve the

workflows of nurse & doctor and streamline the collections & storages of the chart records.

User Population:

Limit in general users in hospital with consciousness.

Significant Physical Part:

The most contact part of the physical body applied to or interacted with is skin in fingers.

Intended User Profile:

Based on elucidations of the intended use, this device of QOCA can heighten working

efficiency in hospital. This device can be used & operated by the following personnel:

● Medical professionals

● Laymen without the medical backgrounds

Operating Principle:

This QOCA is mainly an All-in-One personal computer (PC), which is endued with some

essential interfaces of USB 2.0, USB3.0, OTG, and Ethernet. It can functionalize & work

well via external electric supply of DC 19.1V of the medical grade power adapter. Besides,

based on the basic function supports, it also provides users with sufficient systematic

compatibility with Android & comprehensive program applications with QOCA management

system.

Performance Characteristics:

Performances of this specific & medical media All-in-one PC is more powerful & superior

than the general ones on the market. It has a very fundamental ability of operation (browse

information & internet access) & process (mathematics calculation) as an identity of PC.

Unpacking your smart terminal

Your new smart terminal comes packed in a protective box. Carefully unpack the box and

remove the contents. If any of the following items is missing or damaged, contact your dealer

immediately:

 Quanta QOCA smart terminal device (Model name: QT-195W-aa2 )  User guide (this document)

This icon stands for user guide (user manual).

 Power adapter kit  Back cover
