User’s Manual
© Copyright 2008
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental,
or consequential damages arising out of the use or inability to use the product
or documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this manual,
the manufacturer and distributor assume no liability resulting from errors or
omissions in this manual, or from the use of the information contained herein.
i
CCoonntteennttss
Before You Start .........................................................................................1
Attention: Teachers and Parents.............................................................................1
For Your Safety ...........................................................................................................1
Caring for Your Notebook.......................................................................................2
Regulatory Information .............................................................................. 3
Federal Communications Commission Notice.....................................................3
Modifications................................................................................................................3
Connections to Peripheral Devices........................................................................3
SAR Exposure..............................................................................................................4
Declaration of Conformity .......................................................................................4
European Notice.........................................................................................................4
Attachment Limitations Statement .........................................................................5
Power Cord Requirement ........................................................................................5
Battery Pack Safety.....................................................................................................6
Lithium battery warning / Bridge battery warning...............................................7
Touring the Notebook................................................................................ 9
Front..............................................................................................................................9
Left view .................................................................................................................... 10
Right view.................................................................................................................. 11
Back ............................................................................................................................12
Base............................................................................................................................. 13
Getting Started .........................................................................................14
Installing the Battery................................................................................................ 14
Charging the Battery............................................................................................... 15
Opening the LCD Panel ......................................................................................... 16
Switching the Power On ........................................................................................ 16
LED Status Indicators.............................................................................................. 18
ii
Using the Notebook.................................................................................. 19
Using the Keyboard................................................................................................. 19
Using the Touch Pad............................................................................................... 20
Using the Touch Screen ......................................................................................... 21
Rotating the Display Panel ..................................................................................... 21
Using the Web Camera.......................................................................................... 24
Conserving the Battery Power ............................................................................. 25
BIOS Setup ................................................................................................26
Entering BIOS Setup................................................................................................ 26
Main Setup................................................................................................................. 26
Advanced Setup........................................................................................................ 27
Security Setup........................................................................................................... 28
Boot Setup................................................................................................................. 29
Exit Setup................................................................................................................... 30
Troubleshooting ........................................................................................ 31
Specifications ............................................................................................. 32
Index ........................................................................................................... 33
1
BBeeffoorree YYoouu SSttaarrtt
Attention: Teachers and Parents
This product is an educational tool designed for school age children, ages 6 and
up. Make sure that students understand this product is an educational tool and
not a toy.
Students must be supervised by an adult when using this notebook. Explain to
students the safe and proper handling of the notebook, power supply, battery
pack, and power cord.
Before students take the notebook home, instruct students to keep power
cords, small accessories, and loose parts away from younger children at all times.
Make sure students understand the warning label on the power cord. Emphasize
to students that any damage to the notebook or loose parts should be reported
immediately to a teacher or parent.
It is recommended that each session of use does not exceed thirty minutes, and
that students should take at least a five minute break between each use.
To ensure the notebook is in good working condition, periodically inspect the
notebook, power supply and power cord for damage, and replace if necessary.
For Your Safety
Before using in the classroom or home environment, make sure that students
understand the following precautions:
• Do not drop, crush, or step on the notebook.
• Do not place objects or apply heavy pressure on the notebook.
• Do not place on uneven or unstable work surfaces.
• Do not block the openings provided for ventilation, as overheating may
occur.
• Do not use or store the notebook in extreme weather conditions.
• Do not expose to sudden changes in temperature or humidity: keep the
notebook away from heating and A/C vents.
• Do not expose to magnetic fields.
• Do not expose to direct sunlight.
• Do not place near fire or other sources of heat.
2
• Do not expose to rain or moisture.
• Do not leave the notebook turned on or plugged in when enclosed in a non-
vented container, such as a backpack, as overheating may occur.
Caring for Your Notebook
• Do not spray water or any other cleaning fluids directly on the display.
• Do not clean the notebook when it is plugged into a wall socket.
• Make sure the notebook is turned off before cleaning, and clean with a
slightly damp cloth.
• When you are not using the notebook, keep the LCD panel closed to
protect the screen from dust.
• Make sure the touch pad does not come into contact with dirt, liquids, or
grease.
• Use the AC adapter whenever an AC wall outlet is available to prolong the
battery life and usage cycle.
3
RReegguullaattoorryy IInnffoorrm
maattiioonn
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio or television technician for help.
A
Warning
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Modifications
The FCC requires the user to be notified that any changes or modifications
made to this device that are not expressly approved by the Manufacturer may
void the user’s authority to operate the equipment.
Connections to Peripheral Devices
Connections to this device must be made with shielded cables with metallic
RFI/EMI connector hoods to maintain compliance with FCC Rules and
Regulations.
4
SAR Exposure
This device has been tested for compliance with FCC RF Exposure (SAR) limits
in typical flat configurations. In order to comply with SAR limits established in
the ANSI C95.1 standards, it is recommended when using a CF card that the
integrated antenna is positioned more than 1.5cm from your body or nearby
persons during extended periods of operation.
Declaration of Conformity
This device complies with Part 15 the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
European Notice
Products with the CE Marking comply with both the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) and R&TTE
Directive (1999/5/EC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European
Norms:
• EN55022: 2006, CLASS B
• EN61000-3-2: 2006, CLASS D
• EN61000-3-3: 1995+A1: 2001+A2: 2005
• EN55024: 1998+A1: 2001+A2: 2003
• IEC61000-4-2: 2001 ED. 1.2
• IEC61000-4-3: 2006 ED. 3.0
• IEC61000-4-4: 2004 ED. 2.0
• IEC61000-4-5: 2005 ED. 2.0
• IEC61000-4-6: 2006 ED. 2.2
• IEC61000-4-8: 2001 ED. 1.1
• IEC61000-4-11: 2004 ED. 2.0
• EN 300 328-2, EN 300 328-1, EN 301 489-1, EN 301 489-17
(ETSI 300 328, ETSI 301 489) Electro-magnetic Compatibility and Radio
Spectrum Matter.
5
• TBR21 (ETSI TBR21) Terminal Equipment.
• EN60950 (IEC60950) I.T.E. Product Safety
Attachment Limitations Statement
Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic water pipe
system, if present, are connected together. This precaution may be particularly
important in rural areas.
L
Caution
Users should not attempt to make such connections themselves, but should
contact the appropriate electric inspection authority, or electrician, as
appropriate.
Power Cord Requirement
The power cord supplied with the AC adapter should match the plug and
voltage requirements for your local area. Regulatory approval for the AC
adapter has been obtained using the power cord for the local area.
However, if you travel to a different area and need to connect to a different
outlet or voltage, you should use one of the power cords listed below. To
purchase a power cord (including one for a country not listed below) or a
replacement AC adapter, contact your local dealer.
U.S. and Canada
• The cord set must be UL/ETL-Listed and CSA-Certified or UL/C-ETL Listed.
• The minimum specifications for the flexible cord are (1) No. 18 AWG, (2)
Type SPT-2, and (3) 2-conductor.
• The cord set must have a rated current capacity of at least 7A.
• The attachment plug must be an earth-grounding type with a NEMA 1-15P
(7A, 125V) configuration.
Japan
• All components of the cord set (cord, connector, and plug) must bear a
“PSE” mark and registration number in accordance with the Japanese
Dentori Law.
• The minimum specifications for the flexible cord are: (1) 0.75 mm
2
conductors, (2) Type VCT or VCTF, and (3) 3-conductor.
• The cord set must have minimum rated current capacity of 7 A.
6
• The attachment plug must be a two-pole, grounded type with a Japanese
Industrial Standard C8303 (15 A, 125 VAC) configuration.
Other Countries
• The cord set fittings must bear the certification mark of the agency
responsible for evaluation in a specific country.
Acceptable agencies are:
• CCC (China)
• The flexible cord must be of a HAR (harmonized) type HO5VVF 3-
conductor cord with a minimum conductor size of 0.03 square inches.
• The minimum specification for the flexible cord for Class II product are:
(1) 2X0.75 mm
2
conductors, (2) 2-conductor cord.
• The cord set must have a current capacity of at least 10 A and a nominal
voltage rating of 125 / 250 VAC.
Note: This model IS DESIGNED TO USE WITH THE
FOLLOWING AC ADAPTER MODEL ONLY
Manufacture: LI SHIN INTERNATIONAL ENTERPRISE CORP.
Manufacture: Delta
Battery Pack Safety
• The battery pack is intended to use only with this notebook.
• The battery pack is not replaceable by the end user. Only qualified service
technicians should replace the battery pack.
• Do not disassemble the pack.
• Do not dispose of the battery pack in fire or water.
• To avoid risk of fire, burns, or damage to your battery pack, do not allow a
metal object to touch the battery contacts.
• Handle a damaged or leaking battery with extreme care. If you come in
contact with the electrolyte, wash the exposed area with soap and water. If
it contacts the eye, flush the eye with water for 15 minutes and seek medical
attention.
• Do not charge the battery pack if the ambient temperature exceeds 45°C
(113°F).
7
• To obtain a replacement battery, contact your local dealer.
• Do not expose the battery pack to high storage temperatures (above 60°C,
140°F).
• When discarding a battery pack, contact your local waste disposal provider
regarding local restrictions on the disposal or recycling of batteries.
• Use only supplied AC Adapter for charging.
Caution: Danger of explosion if battery is incorrectly replaced. Only
qualified service technicians should replace and discard the
battery pack. Replace only with same or equivalent type
recommended by the manufacturer. Discard used batteries
according to the manufacturer’s instructions or local laws.
Vorsicht: Explisionsgefahr bei unsachgernazen Austausch der Batterie.
Ersatz ur durch denselben oder einem vom Hersteller
empfohlenem ahnlichen Typ. Entsorgung gebrauchter
Batterien navh Angaben des Herstellers.
Lithium battery warning / Bridge battery
warning
This notebook contains a lithium battery to power the clock and calendar
circuitry.
Caution: Danger of explosion if battery is replaced incorrectly.
Replace only with the same or equivalent type
recommended by the manufacturer. Discard used batteries
according to the manufacturer’s instructions.
Note: Il y a danger d’xplosion s’il y a remplacement incorrect de la
batterie. Remplacer uniquement avcc unc batterie du meme
type ou d’un type recommande par le constructer. Mettre
au rebut les batteries usages conformement aux instructions
du fabricant.
Vorsicht: Explosionsgefahr bei unsachgemBen Austausch der Batterie
Ersatz nur durch denselben oder einem vom Hersteller
empfohlenem ahnlichen Typ. Entsorgung gebrauchter
Batterien nach Angaben des Herstellers.
8
Der Arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 betragt 70dB (A)
oder weniger.
Zum Netzanschlua dieses Gerates ist eine geprufte Leitung zu verwenden. Fur
einen Nennstrom bis 6A und einem Gerategewicht groBer 3kg ist eine Leitung
nicht leichter als (1) H05VV-F, 3G, 0.75mm
2
(2) 2X0.75 mm2 conductors
einzusetzen.
Die Steckdose muB nahe dem Gerat angebracht und leicht zuganglich sein.
Caution: This part is hot. Be careful.
Vorsicht: Diese Flachewird sehr heiss.
When you see this symbol, be careful as this spot may be very hot. The heat is
generated from the CPU.
Loading...
