Quanta ZE8 Schematic

5

www.schematic-x.blogspot.com

4

3

2

1

ZE8 BLOCK DIAGRAM

PCB STACK UP

POWER6L HDI

DD

LAYER 1 : TOP
LAYER 2 : GND
LAYER 3 : IN1
LAYER 4 : IN2
LAYER 5 : VCC
LAYER 6 : BOT

CPU

CLOCK

CK505 (QFN-64)

PG 3

FAN & THERMAL

P 4

Penryn SFF ULV DC/SC

Micro-FCBGA956/10W

800/1066 MHz FSB

CC

DDR2-SODIMM

DDR2-SODIMM

P16

cahnge A

667/800MHZ DDR II

cahnge B

P17

NORTH BRIDGE

Cantiga SFF GS45

PG 6,7,8,9,10,11

DMI x 4

2.5HDD

Touch Screen

BB

P21

P23

On Board USB0

P21

MINI CARD 1

SATA0

Port 8

Port 6

Port 4

SOUTH BRIDGE

ICH9-M SFF

P20

MINI CARD 2

Port 2

USB

P20

CCD

Port 7

P23

Bule Tooth

P22

AA

On Board USB2

On Board USB3

Card Reader
Alcor AU6433

5

Connector

P22

Port 5

Port 0

Port 1

Port 3

Winbond WPCE775LA0DG

SPI

FLASH
2Mbytes

P19

4

PG 12,13,14,15

LPC

EC

P4,5

P19

PS/2

TouchPAD
Connector

P22

LVDS LED Panel

VGA

TMDS HDMI Level Shifter

PCIE4 MINI CARD 1

PCIE5PCIE

PCIE1

Connector

CODEC

Realtek ALC269X

8x16

Keyboard
Connector

3

P23

P22

P18

P22

Connector

P23

CRT
Connector

P22

HDMI
Connector

Connector

P23

P20

MINI CARD 2
Connector

P20

GLAN
Atheros AR8131L

Line Out/MIC

Speaker

Digital MIC LED Panel

2

SYSTEM 5V/3V
RT8206B

P24

CPU Core
ISL6261A

P25

DDR Power
RT8207A

P26

VCCP 1.05V
RT8202A

P27

1.5V
G9334/AO4466

P28

1.5V_S5
RT9025

P28

Discharge

P28

GFX
ISL6263A

P29

SIM CARD
Connector

ConnectorIHDA

P20

P22

Speaker Connector

P19

Connector

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Schematic Block Diagram

Schematic Block Diagram

Schematic Block Diagram

Date: Sheet

Date: Sheet

Date: Sheet

P23

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

ZE8

ZE8

ZE8

1 32Tuesday, September 29, 2009

1 32Tuesday, September 29, 2009

1 32Tuesday, September 29, 2009

of

of

1

of

1A

1A

1A

5

4

3

2

1

ZE8 Power On Sequence

From AC,Battery VIN

DD

From PWM

From Power Button

From EC

+5VPCU +3VPCU

SYS_HWPG(PCU)

NBSWON#

S5_ON

+3V_S5,1.5V_S5

+5V_S5

From EC to SB

From EC

RSMRST#

SUSB#,SUSC#From SB to EC

SUSON

SUSON

Items Function Name Description

1

With HDMI

2

Without HDMI

3

3G Module 3G@

4

5

6

BOM naming rule

HD@

NHD@

+3VSUS +1.8VSUS +SMDDR_VREF +SMDDR_VTERM

CC

From PWM

From EC

HWPG_1.8V (SUS)

MAINON

+5V +3V +1.5V +1.05V

From PWM

From PWM

From EC

From EC

HWPG_1.5V HWPG_1.05V

HWPG(MPWROK)

PWROK_EC

VRON

>5ms

MAINON

VRON

>5ms

>5ms

>10ms

(SMB_DATA) / (SMB_CLK) (+3V_S5)

Power Plane

MOS CKT

ICH9M SFF SMBUS Table

CLK GEN RAM Mini Card (WLAN/WMAX)

V

+3V +3V

Stuff Stuff Stuff Stuff

VV

+3V

Mini Card (3G)

V

+3VSUS

G sensor

V

+3V

Stuff

+VCC_CORE

From PWM to U5

From U5 to SB

From SB to CLK GEN

BB

From PWM to U7

From U7 to SB

From SB to CPU

From SB to NB

From NB to CPU

VR_PWRGD_CK410#

VR_PWRGD_CLKEN

VR_PWRGD_CK410

DELAY_VR_PWRGOOD(CPU PWRGD)

ICH_PWRGD

H_PWRGOOD

PLTRST#,PCIRST#

CPURST#

EC SMBUS Table

EC775 SDATA1/SCLK1(+3VPCU)

EC775 SDATA2/SCLK2(+3V)

EC775 SDATA3/SCLK3(+3VPCU)

Power Plane

MOS CKT

Battery CPU thermal Sensor EC EEPROM

V

V

V

+3VPCU +3V +3VPCU

XX

X

AA

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

PROJECT :

Power Sequence/ BOM Rule

Power Sequence/ BOM Rule

Power Sequence/ BOM Rule

1

ZE8

ZE8

ZE8

1A

1A

1A

of

of

of

2 32Tuesday, September 29, 2009

2 32Tuesday, September 29, 2009

2 32Tuesday, September 29, 2009

5

4

3

2

+3V+3V

1

Clock Generator (CLK)

R157

R152

R152

+1.05V +1.05V_VDD_CLK

L16 PBY160808T-301Y-N/2A/300ohm_6L16 PBY160808T-301Y-N/2A/300ohm_6

C239

C237

DD

+3V +3V_VDD_CLK

L17 PBY160808T-301Y-N/2A/300ohm_6L17 PBY160808T-301Y-N/2A/300ohm_6

CC

0603 : card reader
use external crystal

BB

C237

10u/10V_8

10u/10V_8

C240

C240

10u/10V_8

10u/10V_8

C230

C223

C223

0.1u/10V_4

0.1u/10V_4

CLKREQ#_SATA(14)

CLKREQ#_LAN(21)

PCICLK_EC(18)

PCLK_ICH(13)

CLK48_CARD(21)

CLK48_ICH(14)

CLK14_ICH(14)

C230

0.1u/10V_4

0.1u/10V_4

C234

C234

0.1u/10V_4

0.1u/10V_4

C227

C227

0.1u/10V_4

0.1u/10V_4

PCICLK_EC

PCLK_ICH

CLK48_CARD

CLK48_ICH

CLK14_ICH

Layout notice: placed within 500-mils of CK505M

C226 27p/50V_4C226 27p/50V_4

C225 33p/50V_4C225 33p/50V_4

C238

C238

0.1u/10V_4

0.1u/10V_4

C228

C228

0.1u/10V_4

0.1u/10V_4

PCLK_DEBUG(19)

If XDP is not implemented the 1-k ±10% resistor is not required.

REF
(MHz)

CLK48_ICH_R

MCH_BSEL0

FSB

MCH_BSEL1

CLK14_ICH_R

MCH_BSEL2

R135 2.2K_4R135 2.2K_4
R127 1K_4R127 1K_4

R141 Short_4R141 Short_4 R140 10K_4R140 10K_4
R137 1K_4R137 1K_4

R134 10K_4R134 10K_4
R119 1K_4R119 1K_4

SRC

PCI

(MHz)

(MHz)

100.0 33.3 14.318 96.0 48.0

Reserved

1
0
1
0
1
0
1

CPU_BSEL0

CPU_BSEL1

CPU_BSEL2

(MHz)

133.3

200.0

166.6

333.3

100.0

400.0

5

CPU_BSEL0(4)

CPU_BSEL1(4)

CPU_BSEL2(4)

AA

FSC

FSB FSA CPU

000 266.6
0

0

0

1

0

1

1

0

1

0

1

1

1

1

C239

0.1u/10V_4

0.1u/10V_4

C232

C232

*0.1u/10V_4

*0.1u/10V_4

R121 475/F_4R121 475/F_4

R138 475/F_4R138 475/F_4

R117 33_4R117 33_4

R118 33_4R118 33_4

R133 *22_4R133 *22_4

R124 22_4R124 22_4

R126 33_4R126 33_4

CG_XIN

21

Y1

Y1

14.318MHZ

14.318MHZ

CG_XOUT

DOT96

USB

(MHz)

(MHz)

96.0 48.0100.0 33.3 14.318

96.0 48.0100.0 33.3 14.318

96.0 48.0100.0 33.3 14.318

96.0 48.0100.0 33.3 14.318

96.0 48.0100.0 33.3 14.318

96.0 48.0100.0 33.3 14.318

C236

C236

0.1u/10V_4

0.1u/10V_4

+1.05V_VDD_CLK

C231

C231

0.1u/10V_4

0.1u/10V_4

CR#_ACLKREQ#_SATA

CR#_BCLKREQ#_LAN

PCLK_DEBUG

PCICLK_EC_R

PCLK_ICH_R

CG_XIN

CG_XOUT

CLK48_ICH_R

FSB

CLK14_ICH_R

MCH_BSEL0 (7)

MCH_BSEL1 (7)

MCH_BSEL2 (7)

4

+3V_VDD_CLK

U7

U7

9

VDD_PCI

16

VDD_48

23

VDD_PLL3

4

VDD_REF

46

VDD_SRC

62

VDD_CPU

19

VDD_96_IO

27

VDD_PLL3_IO

33

VDD_SRC_IO_1

52

VDD_SRC_IO_3

43

VDD_SRC_IO_2

56

VDD_CPU_IO

8

PCI0/CR#_A

10

PCI1/CR#_B

11

PCI2/TME

12

PCI3

13

PCI4/LCDCLK_SEL

14

PCIF5/ITP_EN

3

XTAL_IN

2

XTAL_OUT

17

USB_48/FSA

64

FSB/TEST/MODE

5

REF0/FSC/TESTSEL

65

VSS_BODY

15

VSS_PCI

18

VSS_48

22

VSS_IO

26

VSS_PLL3

59

VSS_CPU

30

VSS_SRC1

36

VSS_SRC2

49

VSS_SRC3

1

VSS_REF

SLG8SP513VTR ,ICS9LPRS365BKLFT

+3V

ITP_EN Pin 53/54

0
1

R139 10K_4R139 10K_4

LCDCLK_SEL Pin 20/21 Pin 24/25

0
1

SMbus address D2

R12210K_4 R12210K_4

SRC_8/SRC_8#

ITP/ITP#

DOT_96/DOT96# LCDCLK/LCDCLK#
SRC_0/SRC_0# 27M/27M_SS

4.7K_4

4.7K_4

1

R153 *0_4R153 *0_4

CK505

CK505

QFN

QFN

CKPWRGD/PWRDW N#

PCLK_DEBUG

PCLK_ICH_R

PCICLK_EC_R

2

Q5

3

2N7002Q52N7002

SCLK

SDA

SRC5/PCI_STOP#

SRC5#/CPU_STOP#

CPU0

CPU0#

CPU1

CPU1#

SRC8/ITP

SRC8#/ITP#

SRC10

SRC10#

SRC11/CR#_H

SRC11#/CR#_G

SRC9

SRC9#

SRC7/CR#_F

SRC7#/CR#_E

SRC6

SRC6#

SRC4

SRC4#

SRC3/CR#_C

SRC3#/CR#_D

SRC2/SATA

SRC2#/SATA#

SRC1/SE1

SRC1#/SE2

SRC0/DOT96

SRC0#/DOT96#

SLG8SP513

SLG8SP513

FAE suggest: place Cap before Resistor

3

55

NC

7
6

45
44

61
60

58
57

54
53

41
42

40
39

37
38

51
50

48
47

34
35

31
32

28
29

24
25

20
21

63

PCLK_ICH_R
PCICLK_EC_R
CLK48_ICH_R
CLK14_ICH_R

SMBCK1(16,19,21) PCLK_SMB (14,19)SMBDT1(16,19,21) PDAT_SMB (14,19)

SMBCK1
SMBDT1

PM_STPPCI#
PM_STPCPU#

CLK_CPU_BCLK
CLK_CPU_BCLK#

CLK_MCH_BCLK
CLK_MCH_BCLK#

PECLK_MINI2
PECLK_MINI2#

CR#_H
CR#_G CLKREQ#_MINI1

PECLK_MINI1
PECLK_MINI1#

CR#_E

PECLK_3GPLL
PECLK_3GPLL#

PECLK_LAN
PECLK_LAN#

PECLK_ICH
PECLK_ICH#

PECLK_SATA
PECLK_SATA#

DREFSSCLK
DREFSSCLK#

DREFCLK
DREFCLK#

VR_PWRGD_CK410

Pin 11

Pin 13

Pin 14

C220 *33p/50V_4C220 *33p/50V_4
C219 *33p/50V_4C219 *33p/50V_4
C229 *33p/50V_4C229 *33p/50V_4
C224 *33p/50V_4C224 *33p/50V_4

PM_STPPCI# (14)
PM_STPCPU# (14)

CLK_CPU_BCLK (4)
CLK_CPU_BCLK# (4)

CLK_MCH_BCLK (6)
CLK_MCH_BCLK# (6)

PECLK_MINI2 (19)
PECLK_MINI2# (19)

R147 3G@475/F_4R147 3G@475/F_4
R146 475/F_4R146 475/F_4

PECLK_MINI1 (19)
PECLK_MINI1# (19)

R143 475/F_4R143 475/F_4

PECLK_3GPLL (7)
PECLK_3GPLL# (7)

PECLK_LAN (21)
PECLK_LAN# (21)

PECLK_ICH (13)
PECLK_ICH# (13)

PECLK_SATA (12)
PECLK_SATA# (12)

DREFSSCLK (7)
DREFSSCLK# (7)

DREFCLK (7)
DREFCLK# (7)

VR_PWRGD_CK410 (14)

SLG8SP513VTR
(AL8SP513000)

PCI2/TME

PCI4/
27_Select

PCIF-5/ITP_EN

ICS9LPRS365
(ALPRS365000)

PCIF-5/ITP_EN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

2

CLKREQ#_MCH

PCI2/TME

PCI_4/
SEL_LCDCLK#

<MAIN> : SLG8SP513VTR(AL8SP513000)
<SECOND> : ICS9LPRS365BKLFT(ALPRS365000)

R157

2

4.7K_4

4.7K_4

NO OVERCLOCKING NORMAL RUN

PIN 24/25 IS 27MHz PIN 24/25

PIN 53/54 IS CPUITP PIN 53/54 IS SRC8

CLOCK GENERATOR CK505

CLOCK GENERATOR CK505

CLOCK GENERATOR CK505

Q6

PCLK_SMBPDAT_SMB

1

R158 *0_4R158 *0_4

PULL HIGH PULL DOWN

3

2N7002Q62N7002

PM_STPPCI#
PM_STPCPU#

CLKREQ#_MINI2 (19)
CLKREQ#_MINI1 (19)

CLKREQ#_MCH (7)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

R149 2.2K_4R149 2.2K_4
R148 2.2K_4R148 2.2K_4

CR#_A

R131 10K_4R131 10K_4

CR#_B

R132 10K_4R132 10K_4

CR#_E

R142 10K_4R142 10K_4

CR#_G

R145 10K_4R145 10K_4

CR#_H

R144 3G@10K_4R144 3G@10K_4

Clock Request Table
CLKREQ#

CR#_A
CR#_B
CR#_C
CR#_D
CR#_E
CR#_F
CR#_G
CR#_H

(default)

+3V

SRC6
SRC8
SRC9
SRC10

3 32Tuesday, September 29, 2009

3 32Tuesday, September 29, 2009

3 32Tuesday, September 29, 2009

SRC4LCDCLK

SRC4LCDCLK

of

of

of

Control

SATA
LAN
N/A
N/A
MCH
N/A
MINI1
MINI2

(default)

(default)

MAPPING
01
SRC0 SRC2

SRC0 SRC2

IS SRC/DOT

ZE8

ZE8

ZE8

1

+3V

1A

1A

1A

1

2

3

4

5

6

7

8

Penryn SFF - Host Bus (CPU)

H_A#[3..16](6)

Celeron 743

SU2300

SU4100

AA

SU7300

BB

AJSLGEVVT03

AJSLGYWVT03

AJSLGS4VT03

AJSLGYVVT06

H_ADSTB#0(6)
H_REQ#[0..4](6)

H_A#[17..35](6)

H_ADSTB#1(6)

H_A20M#(12)
H_FERR#(12)
H_IGNNE#(12)

H_STPCLK#(12)
H_INTR(12)
H_NMI(12)
H_SMI#(12)

H_A#[3..16]

H_REQ#[0..4]

H_A#[17..35]

H_A#3
H_A#4
H_A#5
H_A#6
H_A#7
H_A#8
H_A#9
H_A#10
H_A#11
H_A#12
H_A#13
H_A#14
H_A#15
H_A#16

H_REQ#0
H_REQ#1
H_REQ#2
H_REQ#3
H_REQ#4

H_A#17
H_A#18
H_A#19
H_A#20
H_A#21
H_A#22
H_A#23
H_A#24
H_A#25
H_A#26
H_A#27
H_A#28
H_A#29
H_A#30
H_A#31
H_A#32
H_A#33
H_A#34
H_A#35

P2
V4

W1

T4
AA1
AB4

T2
AC5
AD2
AD4
AA5
AE5
AB2
AC1

Y4

R1

R5

U1

P4

W5

AN1
AK4
AG1
AT4
AK2
AT2
AH2
AF4

AJ5
AH4
AM4
AP4
AR5

AJ1
AL1
AM2
AU5
AP2
AR1
AN5

C7
D4

F10

F8
C9
C5
E5

V2

Y2
AG5
AL5

J9

F4

H8

U17A

U17A

A[3]#
A[4]#
A[5]#
A[6]#
A[7]#
A[8]#
A[9]#
A[10]#
A[11]#
A[12]#
A[13]#
A[14]#
A[15]#
A[16]#
ADSTB[0]#

REQ[0]#
REQ[1]#
REQ[2]#
REQ[3]#
REQ[4]#

A[17]#
A[18]#
A[19]#
A[20]#
A[21]#
A[22]#
A[23]#
A[24]#
A[25]#
A[26]#
A[27]#
A[28]#
A[29]#
A[30]#
A[31]#
A[32]#
A[33]#
A[34]#
A[35]#
ADSTB[1]#

A20M#

ICH

ICH

FERR#
IGNNE#

STPCLK#
LINT0
LINT1
SMI#

RSVD01
RSVD02
RSVD03
RSVD04
RSVD05
RSVD06
RSVD07

Penryn_SFF_1p0

Penryn_SFF_1p0

ADDR GROUP 0 ADDR GROUP 1

ADDR GROUP 0 ADDR GROUP 1

DEFER#

CONTROL

CONTROL

RESET#

BPM[0]#
BPM[1]#
BPM[2]#
BPM[3]#

XDP/ITP SIGNALS

XDP/ITP SIGNALS

THERMAL

THERMAL

PROCHOT#

THERMDA
THERMDC

THERMTRIP#

H CLK

H CLK

BCLK[0]
BCLK[1]

ADS#
BNR#

BPRI#

DRDY#
DBSY#

BR0#

IERR#

INIT#

LOCK#

RS[0]#
RS[1]#
RS[2]#
TRDY#

HIT#

HITM#

PRDY#
PREQ#

TDO
TMS

TRST#

DBR#

C214

C214

*0.1u/10V_4

*0.1u/10V_4

H_D#[0..15](6)

H_DSTBN#0(6)
H_DSTBP#0(6)
H_DINV#0(6)

H_D#[16..31](6)

H_DSTBN#1(6)
H_DSTBP#1(6)
H_DINV#1(6)

CPU_BSEL0(3)
CPU_BSEL1(3)
CPU_BSEL2(3)

M4
J5
L5

N5
F38
J1

M2

H_IERR#

B40
D8

N1

G5
K2
H4
K4
L1

H2
F2

AY8
BA7
BA5
AY2
AV10

ITP_BPM5#

AV2

ITP_TCK

AV4

TCK

ITP_TDI

AW7

TDI

AU1

ITP_TMS

AW5

ITP_TRST#

AV8

SYS_RST#

J7

H_PROCHOT#_D

D38

H_THERMDA

BB34

H_THERMDC

BD34

H_PM_THRMTRIP#

B10

CLK_CPU_BCLK

A35

CLK_CPU_BCLK#

C35

RESERVED

RESERVED

H_ADS# (6)
H_BNR# (6)
H_BPRI# (6)

H_DEFER# (6)
H_DRDY# (6)
H_DBSY# (6)

H_BR0# (6)

H_INIT# (12)

H_LOCK# (6)

H_RESET# (6)

H_RS#0 (6)

H_RS#1 (6)

H_RS#2 (6)

H_TRDY# (6)

H_HIT# (6)
H_HITM# (6)

SYS_RST# (14)

CLK_CPU_BCLK (3)
CLK_CPU_BCLK# (3)

+1.05V

R123

R123

1K/F_4

1K/F_4

R116

R116

2K/F_4

2K/F_4

Layout Note:
Place voltage divider
within 0.5" of GTLREF pin

H_D#[0..15] H_D#[32..47]

H_D#[16..31]

H_D#0
H_D#1
H_D#2
H_D#3
H_D#4
H_D#5
H_D#6
H_D#7
H_D#8
H_D#9
H_D#10
H_D#11
H_D#12
H_D#13
H_D#14
H_D#15

H_D#16
H_D#17
H_D#18
H_D#19
H_D#20
H_D#21
H_D#22
H_D#23
H_D#24
H_D#25
H_D#26
H_D#27
H_D#28
H_D#29
H_D#30
H_D#31

V_CPU_GTLREF

AB44

AA41
AB40
AD40
AC41
AA43

AW43

AE41
AY10
AC43

F40

G43

E43
J43
H40
H44

G39

E41
L41
K44
N41

T40
M40
G41
M44

L43

K40

J41

P40

P44

V40

V44

R41
W41

N43

U41

Y40

Y44

T44

U43
W43

R43

E37

D40

C43

A37

C37

B38

U17B

U17B

D[0]#
D[1]#
D[2]#
D[3]#
D[4]#
D[5]#
D[6]#
D[7]#
D[8]#
D[9]#
D[10]#
D[11]#
D[12]#
D[13]#
D[14]#
D[15]#
DSTBN[0]#
DSTBP[0]#
DINV[0]#

D[16]#
D[17]#
D[18]#
D[19]#
D[20]#
D[21]#
D[22]#
D[23]#
D[24]#
D[25]#
D[26]#
D[27]#
D[28]#
D[29]#
D[30]#
D[31]#
DSTBN[1]#
DSTBP[1]#
DINV[1]#

GTLREF
TEST1
TEST2
TEST3
TEST4
TEST5
TEST6

BSEL[0]
BSEL[1]
BSEL[2]

Penryn_SFF_1p0

Penryn_SFF_1p0

DATA GROUP 0 DATA GROUP 1

DATA GROUP 0 DATA GROUP 1

MISC

MISC

D[32]#
D[33]#
D[34]#
D[35]#
D[36]#
D[37]#
D[38]#
D[39]#
D[40]#
D[41]#
D[42]#
D[43]#
D[44]#

DATA GROUP 2DATA GROUP 3

DATA GROUP 2DATA GROUP 3

D[45]#
D[46]#

D[47]#
DSTBN[2]#
DSTBP[2]#

DINV[2]#

D[48]#

D[49]#

D[50]#

D[51]#

D[52]#

D[53]#

D[54]#

D[55]#

D[56]#

D[57]#

D[58]#

D[59]#

D[60]#

D[61]#

D[62]#

D[63]#
DSTBN[3]#
DSTBP[3]#

DINV[3]#

COMP[0]
COMP[1]
COMP[2]
COMP[3]

DPRSTP#

DPSLP#
DPWR#

PWRGOOD

SLP#

H_D#32

AP44

H_D#33

AR43

H_D#34

AH40

H_D#35

AF40

H_D#36

AJ43

H_D#37

AG41

H_D#38

AF44

H_D#39

AH44

H_D#40

AM44

H_D#41

AN43

H_D#42

AM40

H_D#43

AK40

H_D#44

AG43

H_D#45

AP40

H_D#46

AN41

H_D#47

AL41
AK44
AL43
AJ41

AV38
AT44
AV40
AU41
AW41
AR41
BA37
BB38
AY36
AT40
BC35
BC39
BA41
BB40
BA35
AU43
AY40
AY38
BC37

AE43
AD44
AE1
AF2

G7
B8
C41
E7
D10
BD10

PSI#

H_D#48
H_D#49
H_D#50
H_D#51
H_D#52
H_D#53
H_D#54
H_D#55
H_D#56
H_D#57
H_D#58
H_D#59
H_D#60
H_D#61
H_D#62
H_D#63

COMP0

R275 27.4/F_4R275 27.4/F_4

COMP1

R130 54.9/F_4R130 54.9/F_4

COMP2

R287 27.4/F_4R287 27.4/F_4

COMP3

R288 54.9/F_4R288 54.9/F_4

H_D#[48..63]

H_D#[32..47] (6)

H_DSTBN#2 (6)
H_DSTBP#2 (6)
H_DINV#2 (6)

H_D#[48..63] (6)

H_DSTBN#3 (6)
H_DSTBP#3 (6)
H_DINV#3 (6)

Layout note:
comp0,2: Zo=27.4ohm, L<0.5"
comp1,3: Zo=55ohm, L<0.5"

H_DPRSTP# (7,12,25)
H_DPSLP# (12)
H_DPWR# (6)
H_PWRGOOD (12)
H_CPUSLP# (6)

+1.05V

3

Q4

R309

R309

56.2/F_4

56.2/F_4

2

ME2N7002EQ4ME2N7002E

1

R84

R84

1K_4

1K_4

Q3

Q3

2

MMBT3904-7-F

MMBT3904-7-F

1 3

R83 *0_4R83 *0_4

Voltage Level shift

No use Thermal trip CPU side still PU 56ohm.
Use Thermal trip can share PU at SB side

SYS_SHDN# (24)

PM_THRMTRIP# (7,12)

CC

DELAY_VR_PWRGOOD(7,14,25)

+1.05V

H_PM_THRMTRIP#

CPU FAN CTRL(THM)

8/11 B-test : for EMI

FANSIGFAN_PWM_CN

DD

C244

C244
*220p/50V_6

*220p/50V_6

FAN_ON#

R344 10K_4R344 10K_4

CPUFAN#(18)

CPUFAN#

1

C245

C245
*220p/50V_6

*220p/50V_6

FAN_PWM_B

+3V

R345

R345

10K_4

10K_4

2

1 3

2

Q24

Q24
MMBT3904

MMBT3904

+3V

2

1 3

R346

R346

10K_4

10K_4

Q25

Q25

MMBT3904

MMBT3904

+3V

+5V

R343

R343

10K_4

10K_4

FAN_PWM_CNFAN_PWM_E

R341

R341

10K_4

10K_4

FANSIG

+5V

FANSIG (18)

CN15

CN15

6
345
2
1

FAN

FAN

3

+1.05V

R120 56_4R120 56_4

+1.05V

R286 51/F_4R286 51/F_4
R284 51/F_4R284 51/F_4
R285 51/F_4R285 51/F_4

R101 51/F_4R101 51/F_4
R103 51/F_4R103 51/F_4

Layout Note:
Place Resistor close to CPU
with Stub length <200mils.

H_IERR#

ITP_BPM5#
ITP_TDI
ITP_TMS

ITP_TCK
ITP_TRST#

CPU Thermal Monitor(THM)

+3V +3V

ALERT#:pull up at SB side

R128

R128

R125

R125

*10K_4

*10K_4

10K_4

10K_4

2ND_MBCLK(18)

2ND_MBDATA(18)

THERM_ALERT#(14)

4

R129 *0_4R129 *0_4

FAN_ON#

IC OTHER(8P) G780P81U(MSOP-8)

IC OTHER(8P) G780P81U(MSOP-8)

5

GMT ADDRESS: 4CH
EC ADDRESS: 98H

U6

U6

8

SCLK

7

SDA

6

ALERT#

4

OVERT#

VCC

DXP

DXN

GND

H_PROCHOT#_D

1

2

3

5

+1.05V

R274

R274

56_4

56_4

R273 *0_4R273 *0_4

C222 0.1u/10V_4C222 0.1u/10V_4

30mA(20mils)

H_THERMDA

C221

C221

2200p/50V_6

2200p/50V_6

H_THERMDC

6

H_PROCHOT# (25)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Penryn SFF (Host Bus)/FAN/Thermal

Penryn SFF (Host Bus)/FAN/Thermal

Penryn SFF (Host Bus)/FAN/Thermal

Date: Sheet

Date: Sheet

Date: Sheet

7

PROJECT :

ZE8

ZE8

ZE8

8

of

of

of

4 32Tuesday, September 29, 2009

4 32Tuesday, September 29, 2009

4 32Tuesday, September 29, 2009

1A

1A

1A

1

2

3

4

5

6

7

8

Penryn SFF - Power (CPU)

VCORE

U17F

U17F

BD28

VCC_101
VCC_102
VCC_103
VCC_104
VCC_105
VCC_106
VCC_107
VCC_108
VCC_109
VCC_110
VCC_111
VCC_112
VCC_113
VCC_114
VCC_115
VCC_116
VCC_117
VCC_118
VCC_119
VCC_120
VCC_121
VCC_122
VCC_123
VCC_124
VCC_125
VCC_126
VCC_127
VCC_128
VCC_129
VCC_130
VCC_131
VCC_132
VCC_133
VCC_134
VCC_135
VCC_136
VCC_137
VCC_138
VCC_139
VCC_140
VCC_141
VCC_142
VCC_143
VCC_144
VCC_145
VCC_146
VCC_147
VCC_148
VCC_149
VCC_150
VCC_151
VCC_152
VCC_153
VCC_154
VCC_155
VCC_156
VCC_157
VCC_158
VCC_159
VCC_160
VCC_161
VCC_162
VCC_163
VCC_164
VCC_165
VCC_166
VCC_167
VCC_168
VCC_169
VCC_170
VCC_171
VCC_172
VCC_173
VCC_174
VCC_175
VCC_176
VCC_177
VCC_178
VCC_179
VCC_180
VCC_181
VCC_182
VCC_183
VCC_184
VCC_185
VCC_186
VCC_187
VCC_188
VCC_189
VCC_190
VCC_191
VCC_192
VCC_193
VCC_194
VCC_195
VCC_196
VCC_197
VCC_198
VCC_199
VCC_200
VCC_201
VCC_202
VCC_203
VCC_204
VCC_205
VCC_206
VCC_207
VCC_208
VCC_209
VCC_210
VCC_211
VCC_212
VCC_213
VCC_214
VCC_215
VCC_216
VCC_217
VCC_218
VCC_219
VCC_220

VCCP_017
VCCP_018
VCCP_019
VCCP_020

Penryn_SFF_1p0

Penryn_SFF_1p0

VCCP_021
VCCP_022
VCCP_023
VCCP_024
VCCP_025
VCCP_026
VCCP_027
VCCP_028
VCCP_029
VCCP_030
VCCP_031
VCCP_032
VCCP_033
VCCP_034
VCCP_035
VCCP_036
VCCP_037
VCCP_038
VCCP_039
VCCP_040
VCCP_041
VCCP_042
VCCP_043
VCCP_044
VCCP_045
VCCP_046
VCCP_047
VCCP_048
VCCP_049
VCCP_050
VCCP_051
VCCP_052
VCCP_053
VCCP_054
VCCP_055
VCCP_056
VCCP_057
VCCP_058
VCCP_059
VCCP_060
VCCP_061
VCCP_062
VCCP_063
VCCP_064
VCCP_065
VCCP_066
VCCP_067
VCCP_068
VCCP_069
VCCP_070
VCCP_071
VCCP_072
VCCP_073
VCCP_074
VCCP_075
VCCP_076
VCCP_077
VCCP_078
VCCP_079
VCCP_080
VCCP_081
VCCP_082
VCCP_083
VCCP_084
VCCP_085
VCCP_086
VCCP_087
VCCP_088
VCCP_089
VCCP_090
VCCP_091
VCCP_092
VCCP_093
VCCP_094
VCCP_095
VCCP_096
VCCP_097
VCCP_098
VCCP_099
VCCP_100
VCCP_101
VCCP_102
VCCP_103
VCCP_104
VCCP_105
VCCP_106
VCCP_107
VCCP_108
VCCP_109
VCCP_110
VCCP_111
VCCP_112
VCCP_113
VCCP_114
VCCP_115
VCCP_116
VCCP_117
VCCP_118
VCCP_119
VCCP_120
VCCP_121
VCCP_122
VCCP_123
VCCP_124
VCCP_125
VCCP_126
VCCP_127
VCCP_128
VCCP_129
VCCP_130
VCCP_131
VCCP_132
VCCP_133
VCCP_134
VCCP_135
VCCP_136
VCCP_137
VCCP_138
VCCP_139
VCCP_140
VCCP_141
VCCP_142
VCCP_143
VCCP_144
VCCP_145

BB26
BD26

B22
B24
D22
D24
F24
F22
H24
H22
K24
K22
M24
M22
P24
P22
T24
T22
V24
V22
Y24

Y22
AB24
AB22
AD24
AD22
AF24
AF22
AH24
AH22
AK24
AK22
AM24
AM22
AP24
AP22
AT24
AT22
AV24
AV22
AY24
AY22
BB24
BB22
BD24
BD22

B16

B18

B20

D16

D18

F18

F16

H18

H16

D20

F20

H20

K18

K16

M18

M16

K20

M20

P18

P16

T18

T16

V18

V16

P20

T20

V20

Y18

Y16
AB18
AB16
AD18
AD16

Y20
AB20
AD20
AF18
AF16
AH18
AH16
AF20
AH20
AK18
AK16
AM18
AM16
AP18
AP16
AK20
AM20
AP20
AT18
AT16
AV18
AV16
AY18
AY16
AT20
AV20
AY20
BB18
BB16
BD18
BD16
BB20
BD20
AM14
AP14
AT14
AV14
AY14
BB14
BD14

AF38
AG37

AJ37

AK38

5

C172

C172

10u/6.3V_6

10u/6.3V_6

C140

C140

1u/6.3V_4

1u/6.3V_4

2

AB28
AD30
AD28
Y26
AB26
AD26
AF30
AF28
AH30
AH28
AF26
AH26
AK30
AK28
AM30
AM28
AP30
AP28
AK26
AM26
AP26
AT30
AT28
AV30
AV28
AY30
AY28
AT26
AV26
AY26
BB30
BB28
BD30

J11
E11
G11
J37
K38
L37
N37
P38
R37
U37
V38
W37
AA37
AB38
AC37
AE37

B34
D34

BD8
BC7
BB10
BB8
BC5
BB4
AY4

BD12

BC13

C175

C175

10u/6.3V_6

10u/6.3V_6

C121

C121

*1u/6.3V_4

*1u/6.3V_4

VCORE

C134

C134

1u/6.3V_4

1u/6.3V_4

+1.05V

12

+

+

C178

C178

10u/6.3V_6

10u/6.3V_6

VCORE

C122

C122

1u/6.3V_4

1u/6.3V_4

C82

C82

220u/2.5V_3528

220u/2.5V_3528

VID0 (25)
VID1 (25)
VID2 (25)
VID3 (25)
VID4 (25)
VID5 (25)
VID6 (25)

C138

C138

1u/6.3V_4

1u/6.3V_4

C136

C136

1u/6.3V_4

1u/6.3V_4

C118

C118

1u/6.3V_4

1u/6.3V_4

C179

C179

10u/6.3V_6

10u/6.3V_6

C144

C144

1u/6.3V_4

1u/6.3V_4

C139

C139

1u/6.3V_4

1u/6.3V_4

C117

C117

*1u/6.3V_4

*1u/6.3V_4

VCORE

C174

C174

10u/6.3V_6

10u/6.3V_6

3

R276

R276

100/F_4

100/F_4

R277

R277

100/F_4

100/F_4

C137

C137

1u/6.3V_4

1u/6.3V_4

C194

C194

1u/6.3V_4

1u/6.3V_4

C426

C426

0.01u/25V_4

0.01u/25V_4

C143

C143

1u/6.3V_4

1u/6.3V_4

C191

C191

1u/6.3V_4

1u/6.3V_4

+1.5V

C427

C427

10u/6.3V_6

10u/6.3V_6

C192

C192

*1u/6.3V_4

*1u/6.3V_4

VCC_SENSE (25)

VSS_SENSE (25)

+1.05V

4

VCORE

AA

BB

VCORE

CC

DD

VCORE

VCORE

+1.05V

+

+

C162

C162

330u/2.5V_7343

330u/2.5V_7343

C173

C173

10u/6.3V_6

10u/6.3V_6

C141

C141

1u/6.3V_4

1u/6.3V_4

C190

C190

*1u/6.3V_4

*1u/6.3V_4

1

C180

C180

10u/6.3V_6

10u/6.3V_6

C135

C135

1u/6.3V_4

1u/6.3V_4

C193

C193

1u/6.3V_4

1u/6.3V_4

C154

C154

10u/6.3V_6

10u/6.3V_6

AA33
AB32
AC33
AD32
AE33
AF32
AG33
AH32

AK32

AM32
AN33
AP32
AR33
AT34
AT32
AU33
AV32
AY32
BB32
BD32

AB30

C168

C168

10u/6.3V_6

10u/6.3V_6

C142

C142

1u/6.3V_4

1u/6.3V_4

C120

C120

1u/6.3V_4

1u/6.3V_4

F32
G33
H32
J33
K32
L33
M32
N33
P32
R33
T32
U33
V32

W33

Y32

AJ33

AL33

B28
B30
B26
D28
D30
F30
F28
H30
H28
D26
F26
H26
K30
K28
M30
M28
K26
M26
P30
P28
T30
T28
V30
V28
P26
T26
V26
Y30
Y28

C176

C176

10u/6.3V_6

10u/6.3V_6

U17C

U17C

VCC[001]
VCC[002]
VCC[003]
VCC[004]
VCC[005]
VCC[006]
VCC[007]
VCC[008]
VCC[009]
VCC[010]
VCC[011]
VCC[012]
VCC[013]
VCC[014]
VCC[015]
VCC[016]
VCC[017]
VCC[018]
VCC[019]
VCC[020]
VCC[021]
VCC[022]
VCC[023]
VCC[024]
VCC[025]
VCC[026]
VCC[027]
VCC[028]
VCC[029]
VCC[030]
VCC[031]
VCC[032]
VCC[033]
VCC[034]
VCC[035]
VCC[036]
VCC[037]
VCC[038]
VCC[039]
VCC[040]
VCC[041]
VCC[042]
VCC[043]
VCC[044]
VCC[045]
VCC[046]
VCC[047]
VCC[048]
VCC[049]
VCC[050]
VCC[051]
VCC[052]
VCC[053]
VCC[054]
VCC[055]
VCC[056]
VCC[057]
VCC[058]
VCC[059]
VCC[060]
VCC[061]
VCC[062]
VCC[063]
VCC[064]
VCC[065]
VCC[066]
VCC[067]

Penryn_SFF_1p0

Penryn_SFF_1p0

C177

C177

10u/6.3V_6

10u/6.3V_6

C181

C181

10u/6.3V_6

10u/6.3V_6

C145

C145

1u/6.3V_4

1u/6.3V_4

C119

C119

*1u/6.3V_4

*1u/6.3V_4

VCC[068]
VCC[069]
VCC[070]
VCC[071]
VCC[072]
VCC[073]
VCC[074]
VCC[075]
VCC[076]
VCC[077]
VCC[078]
VCC[079]
VCC[080]
VCC[081]
VCC[082]
VCC[083]
VCC[084]
VCC[085]
VCC[086]
VCC[087]
VCC[088]
VCC[089]
VCC[090]
VCC[091]
VCC[092]
VCC[093]
VCC[094]
VCC[095]
VCC[096]
VCC[097]
VCC[098]
VCC[099]
VCC[100]

VCCP_001
VCCP_002
VCCP_003
VCCP_004
VCCP_005
VCCP_006
VCCP_007
VCCP_008
VCCP_009
VCCP_010
VCCP_011
VCCP_012
VCCP_013
VCCP_014
VCCP_015
VCCP_016

VCCA[01]
VCCA[02]

VID[0]
VID[1]
VID[2]
VID[3]
VID[4]
VID[5]
VID[6]

VCCSENSE

VSSSENSE

C116

C116

1u/6.3V_4

1u/6.3V_4

AL37
AN37
AP38
B32
C33
D32
E35
E33
F34
G35
F36
H36
J35
L35
N35
K36
R35
U35
P36
V36
W35
AA35
AC35
AB36
AE35
AG35
AJ35
AF36
AL35
AN35
AK36
AP36
B12
B14
C13
D12
D14
E13
F14
F12
G13
H14
H12
J13
K14
K12
L13
L11
M14
N13
N11
K10
P14
P12
R13
R11
T14
U13
U11
V14
V12
W13
W11
P10
V10
Y14
AA13
AA11
AB14
AB12
AC13
AC11
AD14
AB10
AE13
AE11
AF14
AF12
AG13
AG11
AH14
AJ13
AJ11
AF10
AK14
AK12
AL13
AL11
AN13
AN11
AP12
AR13
AR11
AK10
AP10
AU13
AU11
L9
L7
N9
N7
R9
R7
U9
U7
W9
W7
AA9
AA7
AC9
AC7
AE9
AE7
AG9
AG7
AJ9
AJ7
AL9
AL7
AN9
AN7
AR9
AR7
A33
A13

+1.05V

U17E

U17E

G25

VSS_164

G23

VSS_165

G21

VSS_166

J25

VSS_167

J23

VSS_168

J21

VSS_169

L25

VSS_170

L23

VSS_171

L21

VSS_172

N25

VSS_173

N23

VSS_174

N21

VSS_175

R25

VSS_176

R23

VSS_177

R21

VSS_178

U25

VSS_179

U23

VSS_180

U21

VSS_181

W25

VSS_182

W23

VSS_183

W21

VSS_184

AA25

VSS_185

AA23

VSS_186

AA21

VSS_187

AC25

VSS_188

AC23

VSS_189

AC21

VSS_190

AE25

VSS_191

AE23

VSS_192

AE21

VSS_193

AG25

VSS_194

AG23

VSS_195

AG21

VSS_196

AJ25

VSS_197

AJ23

VSS_198

AJ21

VSS_199

AL25

VSS_200

AL23

VSS_201

AL21

VSS_202

AN25

VSS_203

AN23

VSS_204

AN21

VSS_205

AR25

VSS_206

AR23

VSS_207

AR21

VSS_208

AU25

VSS_209

AU23

VSS_210

AU21

VSS_211

AW25

VSS_212

AW23

VSS_213

AW21

VSS_214

BA25

VSS_215

BA23

VSS_216

BA21

VSS_217

BC25

VSS_218

BC23

VSS_219

BC21

VSS_220

C17

VSS_221

C19

VSS_222

E19

VSS_223

E17

VSS_224

G19

VSS_225

G17

VSS_226

J19

VSS_227

J17

VSS_228

L19

VSS_229

L17

VSS_230

N19

VSS_231

N17

VSS_232

R19

VSS_233

R17

VSS_234

U19

VSS_235

U17

VSS_236

W19

VSS_237

W17

VSS_238

AA19

VSS_239

AA17

VSS_240

AC19

VSS_241

AC17

VSS_242

AE19

VSS_243

AE17

VSS_244

AG19

VSS_245

AG17

VSS_246

AJ19

VSS_247

AJ17

VSS_248

AL19

VSS_249

AL17

VSS_250

AN19

VSS_251

AN17

VSS_252

AR19

VSS_253

AR17

VSS_254

AU19

VSS_255

AU17

VSS_256

AW19

VSS_257

AW17

VSS_258

BA19

VSS_259

BA17

VSS_260

BC19

VSS_261

BC17

VSS_262

C11

VSS_263

C15

VSS_264

E15

VSS_265

G15

VSS_266

H10

VSS_267

M12

VSS_268

J15

VSS_269

L15

VSS_270

N15

VSS_271

M10

VSS_272

T12

VSS_273

R15

VSS_274

U15

VSS_275

W15

VSS_276

T10

VSS_277

Y12

VSS_278

AD12

VSS_279

Penryn_SFF_1p0

Penryn_SFF_1p0

6

VSS_280
VSS_281
VSS_282
VSS_283
VSS_284
VSS_285
VSS_286
VSS_287
VSS_288
VSS_289
VSS_290
VSS_291
VSS_292
VSS_293
VSS_294
VSS_295
VSS_296
VSS_297
VSS_298
VSS_299
VSS_300
VSS_301
VSS_302
VSS_303
VSS_304
VSS_305
VSS_306
VSS_307
VSS_308
VSS_309
VSS_310
VSS_311
VSS_312
VSS_313
VSS_314
VSS_315
VSS_316
VSS_317
VSS_318
VSS_319
VSS_320
VSS_321
VSS_322
VSS_323
VSS_324
VSS_325
VSS_326
VSS_327
VSS_328
VSS_329
VSS_330
VSS_331
VSS_332
VSS_333
VSS_334
VSS_335
VSS_336
VSS_337
VSS_338
VSS_339
VSS_340
VSS_341
VSS_342
VSS_343
VSS_344
VSS_345
VSS_346
VSS_347
VSS_348
VSS_349
VSS_350
VSS_351
VSS_352
VSS_353
VSS_354
VSS_355
VSS_356
VSS_357
VSS_358
VSS_359
VSS_360
VSS_361
VSS_362
VSS_363
VSS_364
VSS_365
VSS_366
VSS_367
VSS_368
VSS_369
VSS_370
VSS_371
VSS_372
VSS_373
VSS_374
VSS_375
VSS_376
VSS_377
VSS_378
VSS_379
VSS_380
VSS_381
VSS_382
VSS_383
VSS_384
VSS_385
VSS_386
VSS_387
VSS_388
VSS_389
VSS_390
VSS_391
VSS_392
VSS_393
VSS_394
VSS_395

AA15
AC15
Y10
AD10
AH12
AE15
AG15
AJ15
AH10
AM12
AL15
AN15
AR15
AM10
AT12
AV12
AW13
AW11
AY12
AU15
AW15
AT10
BA13
BA11
BB12
BC11
BA15
BC15
B6
D6
E9
F6
G9
H6
K8
K6
M8
M6
P8
P6
T8
T6
V8
V6
U5
Y8
Y6
AB8
AB6
AD8
AD6
AF8
AF6
AH8
AH6
AK8
AK6
AM8
AM6
AP8
AP6
AT8
AT6
AU9
AV6
AU7
AW9
AY6
BA9
BB6
BC9
BD6
B4
C3
E3
G3
J3
L3
N3
R3
U3
W3
AA3
AC3
AE3
AG3
AJ3
AL3
AN3
AR3
AU3
AW3
BA3
BC3
D2
E1
G1
AW1
BA1
BB2
A41
A39
A29
A27
A31
A25
A23
A21
A19
A17
A11
A15
A7
A5
A9
BD4

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Penryn SFF (Power)

Penryn SFF (Power)

Penryn SFF (Power)

Date: Sheet

Date: Sheet

Date: Sheet

7

U17D

U17D

B42

VSS[001]

F44

VSS[002]

D44

VSS[003]

D42

VSS[004]

F42

VSS[005]

H42

VSS[006]

K42

VSS[007]

M42

VSS[008]

P42

VSS[009]

T42

VSS[010]

V42

VSS[011]

Y42

VSS[012]

AB42

VSS[013]

AD42

VSS[014]

AF42

VSS[015]

AH42

VSS[016]

AK42

VSS[017]

AM42

VSS[018]

AP42

VSS[019]

AY44

VSS[020]

AV44

VSS[021]

AT42

VSS[022]

AV42

VSS[023]

AY42

VSS[024]

BA43

VSS[025]

BB42

VSS[026]

C39

VSS[027]

E39

VSS[028]

G37

VSS[029]

H38

VSS[030]

J39

VSS[031]

L39

VSS[032]

M38

VSS[033]

N39

VSS[034]

R39

VSS[035]

T38

VSS[036]

U39

VSS[037]

W39

VSS[038]

Y38

VSS[039]

AA39

VSS[040]

AC39

VSS[041]

AD38

VSS[042]

AE39

VSS[043]

AG39

VSS[044]

AH38

VSS[045]

AJ39

VSS[046]

AL39

VSS[047]

AM38

VSS[048]

AN39

VSS[049]

AR39

VSS[050]

AR37

VSS[051]

AT38

VSS[052]

AU39

VSS[053]

AU37

VSS[054]

AW39

VSS[055]

AW37

VSS[056]

BA39

VSS[057]

BC41

VSS[058]

BD40

VSS[059]

BD38

VSS[060]

B36

VSS[061]

H34

VSS[062]

D36

VSS[063]

K34

VSS[064]

M34

VSS[065]

M36

VSS[066]

P34

VSS[067]

T34

VSS[068]

V34

VSS[069]

T36

VSS[070]

Y34

VSS[071]

AB34

VSS[072]

AD34

VSS[073]

Y36

VSS[074]

AD36

VSS[075]

AF34

VSS[076]

AH34

VSS[077]

AH36

VSS[078]

AK34

VSS[079]

AM34

VSS[080]

AP34

VSS[081]

Penryn_SFF_1p0

Penryn_SFF_1p0

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

VSS[082]
VSS[083]
VSS[084]
VSS[085]
VSS[086]
VSS[087]
VSS[088]
VSS[089]
VSS[090]
VSS[091]
VSS[092]
VSS[093]
VSS[094]
VSS[095]
VSS[096]
VSS[097]
VSS[098]
VSS[099]
VSS[100]
VSS[101]
VSS[102]
VSS[103]
VSS[104]
VSS[105]
VSS[106]
VSS[107]
VSS[108]
VSS[109]
VSS[110]
VSS[111]
VSS[112]
VSS[113]
VSS[114]
VSS[115]
VSS[116]
VSS[117]
VSS[118]
VSS[119]
VSS[120]
VSS[121]
VSS[122]
VSS[123]
VSS[124]
VSS[125]
VSS[126]
VSS[127]
VSS[128]
VSS[129]
VSS[130]
VSS[131]
VSS[132]
VSS[133]
VSS[134]
VSS[135]
VSS[136]
VSS[137]
VSS[138]
VSS[139]
VSS[140]
VSS[141]
VSS[142]
VSS[143]
VSS[144]
VSS[145]
VSS[146]
VSS[147]
VSS[148]
VSS[149]
VSS[150]
VSS[151]
VSS[152]
VSS[153]
VSS[154]
VSS[155]
VSS[156]
VSS[157]
VSS[158]
VSS[159]
VSS[160]
VSS[161]
VSS[162]
VSS[163]

ZE8

ZE8

ZE8

8

AM36
AR35
AU35
AV34
AW35
AW33
AY34
AT36
AV36
BA33
BC33
BB36
BD36
C27
C29
C31
E29
E27
G29
G27
E31
G31
J29
J27
L29
L27
N29
N27
J31
L31
N31
R29
R27
U29
U27
R31
U31
W29
W27
W31
AA29
AA27
AC29
AC27
AA31
AC31
AE29
AE27
AG29
AG27
AJ29
AJ27
AE31
AG31
AJ31
AL29
AL27
AN29
AN27
AL31
AN31
AR29
AR27
AR31
AU29
AU27
AW29
AW27
AU31
AW31
BA29
BA27
BC29
BC27
BA31
BC31
C21
C23
C25
E25
E23
E21

5 32Tuesday, September 29, 2009

5 32Tuesday, September 29, 2009

5 32Tuesday, September 29, 2009

of

of

of

1A

1A

1A

1

2

3

4

5

6

7

8

Cantiga SFF - Host Bus (CLG)

H_D#[0..63](4)

AA

+1.05V

R87

R87

221/F_4

221/F_4

H_SWING

R92

R92

100/F_4

BB

100/F_4

C93

C93

0.1u/10V_4

0.1u/10V_4

Layout Note:
H_RCOMP trace should be
10-mil wide with 20-mil spacing.

H_RCOMP

R289

CC

DD

R289

24.9/F_4

24.9/F_4

+1.05V

R96

R96

1K/F_4

1K/F_4

R91

R91

2K/F_4

2K/F_4

1

2

H_D#[0..63]

H_RESET#(4)

H_CPUSLP#(4)

C104

C104

*0.1u/10V_4

*0.1u/10V_4

H_AVREF

H_D#0
H_D#1
H_D#2
H_D#3
H_D#4
H_D#5
H_D#6
H_D#7
H_D#8
H_D#9
H_D#10
H_D#11
H_D#12
H_D#13
H_D#14
H_D#15
H_D#16
H_D#17
H_D#18
H_D#19
H_D#20
H_D#21
H_D#22
H_D#23
H_D#24
H_D#25
H_D#26
H_D#27
H_D#28
H_D#29
H_D#30
H_D#31
H_D#32
H_D#33
H_D#34
H_D#35
H_D#36
H_D#37
H_D#38
H_D#39
H_D#40
H_D#41
H_D#42
H_D#43
H_D#44
H_D#45
H_D#46
H_D#47
H_D#48
H_D#49
H_D#50
H_D#51
H_D#52
H_D#53
H_D#54
H_D#55
H_D#56
H_D#57
H_D#58
H_D#59
H_D#60
H_D#61
H_D#62
H_D#63

H_SWING
H_RCOMP

3

U18A

U18A

J7

H6

L11

J3
H4
G3

K10
K12

L1

M10

M6

N11

L7
K6
M4
K4
P6

W9

V6
V2

P10

W7

N9
P4
U9
V4
U1

W3

V10

U7

W11

U11

AC11

AC9

Y4

Y10
AB6
AA9

AB10

AA1
AC3
AC7

AD12

AB4

Y6

AD10

AA11

AB2
AD4
AE7
AD2
AD6

AE3
AG9
AG7

AE11

AK6

AF6

AJ9
AH6

AF12

AH4

AJ7
AE9

B6
D4

J11

G9

L17

K18

CANTIGASFF_1p0

CANTIGASFF_1p0

H_D#_0
H_D#_1
H_D#_2
H_D#_3
H_D#_4
H_D#_5
H_D#_6
H_D#_7
H_D#_8
H_D#_9
H_D#_10
H_D#_11
H_D#_12
H_D#_13
H_D#_14
H_D#_15
H_D#_16
H_D#_17
H_D#_18
H_D#_19
H_D#_20
H_D#_21
H_D#_22
H_D#_23
H_D#_24
H_D#_25
H_D#_26
H_D#_27
H_D#_28
H_D#_29
H_D#_30
H_D#_31
H_D#_32
H_D#_33
H_D#_34
H_D#_35
H_D#_36
H_D#_37
H_D#_38
H_D#_39
H_D#_40
H_D#_41
H_D#_42
H_D#_43
H_D#_44
H_D#_45
H_D#_46
H_D#_47
H_D#_48
H_D#_49
H_D#_50
H_D#_51
H_D#_52
H_D#_53
H_D#_54
H_D#_55
H_D#_56
H_D#_57
H_D#_58
H_D#_59
H_D#_60
H_D#_61
H_D#_62
H_D#_63

H_SWING
H_RCOMP

H_CPURST#
H_CPUSLP#

H_AVREF
H_DVREF

4

H_ADSTB#_0
H_ADSTB#_1

HOST

HOST

H_DSTBN#_0
H_DSTBN#_1
H_DSTBN#_2
H_DSTBN#_3

H_DSTBP#_0
H_DSTBP#_1
H_DSTBP#_2
H_DSTBP#_3

H_A#_3
H_A#_4
H_A#_5
H_A#_6
H_A#_7
H_A#_8

H_A#_9
H_A#_10
H_A#_11
H_A#_12
H_A#_13
H_A#_14
H_A#_15
H_A#_16
H_A#_17
H_A#_18
H_A#_19
H_A#_20
H_A#_21
H_A#_22
H_A#_23
H_A#_24
H_A#_25
H_A#_26
H_A#_27
H_A#_28
H_A#_29
H_A#_30
H_A#_31
H_A#_32
H_A#_33
H_A#_34
H_A#_35

H_ADS#

H_BNR#

H_BPRI#

H_BREQ#

H_DEFER#

H_DBSY#

HPLL_CLK

HPLL_CLK#

H_DPWR#

H_DRDY#

H_HIT#

H_HITM#
H_LOCK#
H_TRDY#

H_DINV#_0
H_DINV#_1
H_DINV#_2
H_DINV#_3

H_REQ#_0
H_REQ#_1
H_REQ#_2
H_REQ#_3
H_REQ#_4

H_RS#_0

H_RS#_1

H_RS#_2

L15
B14
C15
D12
F14
G17
B12
J15
D16
C17
D14
K16
F16
B16
C21
D18
J19
J21
B18
D22
G19
J17
L21
L19
G21
D20
K22
F18
K20
F20
F22
B20
A19

F10
A15
C19
C9
B8
C11
E5
D6
AH10
AJ11
G11
H2
C7
F8
A11
D8

L9
N7
AA7
AG3

K2
N3
AA3
AF4

L3
M2
Y2
AF2

J13
L13
C13
G13
G15

F4
F2
G7

H_A#3
H_A#4
H_A#5
H_A#6
H_A#7
H_A#8
H_A#9
H_A#10
H_A#11
H_A#12
H_A#13
H_A#14
H_A#15
H_A#16
H_A#17
H_A#18
H_A#19
H_A#20
H_A#21
H_A#22
H_A#23
H_A#24
H_A#25
H_A#26
H_A#27
H_A#28
H_A#29
H_A#30
H_A#31
H_A#32
H_A#33
H_A#34
H_A#35

5

H_A#[3..35]

H_ADS# (4)
H_ADSTB#0 (4)
H_ADSTB#1 (4)
H_BNR# (4)
H_BPRI# (4)
H_BR0# (4)
H_DEFER# (4)
H_DBSY# (4)
CLK_MCH_BCLK (3)
CLK_MCH_BCLK# (3)
H_DPWR# (4)
H_DRDY# (4)
H_HIT# (4)
H_HITM# (4)
H_LOCK# (4)
H_TRDY# (4)

H_DINV#0 (4)
H_DINV#1 (4)
H_DINV#2 (4)
H_DINV#3 (4)

H_DSTBN#0 (4)
H_DSTBN#1 (4)
H_DSTBN#2 (4)
H_DSTBN#3 (4)

H_DSTBP#0 (4)
H_DSTBP#1 (4)
H_DSTBP#2 (4)
H_DSTBP#3 (4)

H_REQ#0 (4)
H_REQ#1 (4)
H_REQ#2 (4)
H_REQ#3 (4)
H_REQ#4 (4)

H_RS#0 (4)
H_RS#1 (4)
H_RS#2 (4)

6

H_A#[3..35] (4)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Cantiga SFF (Host Bus)

Cantiga SFF (Host Bus)

Cantiga SFF (Host Bus)

Date: Sheet

Date: Sheet

Date: Sheet

PROJECT :

7

ZE8

ZE8

ZE8

of

of

of

6 32Tuesday, September 29, 2009

6 32Tuesday, September 29, 2009

6 32Tuesday, September 29, 2009

8

1A

1A

1A

1

Cantiga SFF - DMI/VGA (CLG)

Intel GS40/GS45 Strapping Signals and Configuration
Pin Name Strap Description Configuration

CFG2:0 FSB Frequency

CFG4:3
CFG5

CFG6

CFG7 Intel Management

AA

CFG8
CFG9

CFG10

CFG11 Reserved
CFG12 ALLZ 1 = Disabled

CFG13 XOR 1 = Disabled

CFG14 Reserved
CFG15 Reserved
CFG16 FSB Dynamic ODT

CFG17 Reserved
CFG18 Reserved
CFG19 DMI Lane Reversal 1 = Reverse Lanes

CFG20

SDVO_CTRLDATA

L_DDC_DATA

DDPC_CTRLDATA

The recommended pull-up resistor value is 4.02 k Ω ±1%

•

The recommended pull-down resistor value is 2.21 k Ω ±1%.

•

BB

CC

DMI x2 Select

ITPM Host Interface

Engine Crypto Strap

PCIE Graphics Lane

PCIE Loopback
enable

Digital DisplayPort
(SDVO/DP/iHDMI)
Concurrent with
PCIE

SDVO Present

Local Flat Panel
(LFP) Present
Digital Display
Present

DDR3 PWROK

SUSON(18,26,28)

HWPG_+1.5V_SUS(18,26)

Check list note : CL_REF=0.35V

DD

(15mils)

MCH_CLVREF

C170

C170

0.1u/10V_4

0.1u/10V_4

1

000 = FSB1066
010 = FSB800
011 = FSB667
Other = Reserved

Reserved

1 = DMI x 4
0 = DMI x2
1 = ITPM disabled
0 = ITPM enabled
1 = Intel Management Engine Crypto TLS
cipher suite with confidentiality
0 = Intel Management Engine Crypto Transport
Layer Security (TLS) cipher suite with no
confidentiality

Reserved

1 = Normal operation : Lane Numbered in Order
0 = Reverse Lanes
1 = Disabled
0 = Enabled

0 = ALLZ mode enabled

0 = XOR mode enabled

1 = Dynamic ODT enabled
0 = Dynamic ODT disabled

0 = Normal operation : Lane Numbered in Order
1 = Digital DisplayPort (SDVO/DP/iHDMI) and
PCIE are operating simultaneously via the
PEG port
0 = Digital DisplayPort (SDVO/DP/iHDMI) or
PCIE are operational
1 = SDVO/HDMI/DP interface enabled
0 = No SDVO/HDMI/DP interface disabled
1 = LFP Card Present; PCIE disabled
0 = LFP Disable
1 = Digital display (iHDMI/DP) devide present
0 = Digital display (iHDMI/DP) interface absent

MCH_BSEL0(3)
MCH_BSEL1(3)
MCH_BSEL2(3)

PM_SYNC#(14)
H_DPRSTP#(4,12,25)
PM_EXTTS#0(16)
PM_EXTTS#1(16)

DELAY_VR_PWRGOOD(4,14,25)

PLTRST#(13,18,19,21)

PM_THRMTRIP#(4,12)

DPRSLPVR(14,25)

+3V_S5

At 11/19
change U21 power supply
from +3VSUS to +3V_S5

53

1

4

2

U21

U21
TC7SH08FU

TC7SH08FU

+1.05V

R112

R112

1K/F_4

1K/F_4

R111

R111

511/F_6

511/F_6

R347

R347

12.1K/F_4

12.1K/F_4

R348

R348

10K_4

10K_4

2

J43

L43

J41

L41
AN11
AM10
AK10

AL11

F12

C27

D30

J9

AW42

BB20
BE19

BF20
BF18

AN45
AP44

AT44

AN47

K26

G23
G25

J25

L25

MCH_CFG5

MCH_CFG7

MCH_CFG12
MCH_CFG13

MCH_CFG16

MCH_CFG19
MCH_CFG20

PM_EXTTS#0
PM_EXTTS#1

RSTIN#_MCH

AY39
BB18

BE55
BH55
BK55
BK54

L27

F24

D24

D26

J23
B26
A23
C23
B24
B22
K24
C25
L23
L33
K32
K34

J35

F6

J39
L39

K28
K36

A7
A49
A52
A54
B54
D55

G55

BL54
BL52
BL49

BL7
BL4
BL2

BK2
BK1
BH1
BE1

G1

T10T10

T17T17

T16T16
T15T15

T14T14

T8T8
T9T9

R136 100_4R136 100_4
R98 *0_4R98 *0_4

SM_PWROK

(20mils)

+SMDDR_VREF_NB

+SMDDR_VREF_NB

+SMDDR_VREF_NB.Default use voltage
divider for poor layout cause +SMDDR_VREF
not meet spec.And Intel circuit PU/PD is
1K,But Check list PU/PD is 10K.

2

R113

R113

U18B

U18B

RSVD1
RSVD2
RSVD3
RSVD4
RSVD5
RSVD6
RSVD7
RSVD8
RSVD9

RSVD14
RSVD15

RSVD17

RSVD20

RSVD22
RSVD23
RSVD24
RSVD25

ME_JTAG_TCK
ME_JTAG_TDI
ME_JTAG_TDO
ME_JTAG_TMS

CFG_0
CFG_1
CFG_2
CFG_3
CFG_4
CFG_5
CFG_6
CFG_7
CFG_8
CFG_9
CFG_10
CFG_11
CFG_12
CFG_13
CFG_14
CFG_15
CFG_16
CFG_17
CFG_18
CFG_19
CFG_20

PM_SYNC#
PM_DPRSTP#
PM_EXT_TS#_0
PM_EXT_TS#_1
PWROK
RSTIN#
THERMTRIP#
DPRSLPVR

NC_1
NC_2
NC_3
NC_4
NC_5
NC_6
NC_7
NC_8
NC_9
NC_10
NC_11
NC_12
NC_13
NC_14
NC_15
NC_16
NC_17
NC_18
NC_19
NC_20
NC_21
NC_22

CANTIGASFF_1p0

CANTIGASFF_1p0

+SMDDR_VREF

BLM18BA750SN1D_6

BLM18BA750SN1D_6

+1.5V_SUS

R350 *10K/F_4R350 *10K/F_4
R349 *10K/F_4R349 *10K/F_4

CFGRSVD

CFGRSVD

PM

PM

NC

NC

3

SA_CK_0
SA_CK_1
SB_CK_0
SB_CK_1

SA_CK#_0
SA_CK#_1
SB_CK#_0
SB_CK#_1

SA_CKE_0
SA_CKE_1
SB_CKE_0
SB_CKE_1

SA_CS#_0
SA_CS#_1
SB_CS#_0
SB_CS#_1

SA_ODT_0
SA_ODT_1
SB_ODT_0
SB_ODT_1

SM_RCOMP

SM_RCOMP#

SM_RCOMP_VOH
SM_RCOMP_VOL

SM_VREF

SM_PWROK

SM_REXT

SM_DRAMRST#

DPLL_REF_CLK

DDR CLK/ CONTROL/COMPENSATION

DDR CLK/ CONTROL/COMPENSATION

DPLL_REF_CLK#

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

PEG_CLK

PEG_CLK#

CLK

CLK

DMI_RXN_0
DMI_RXN_1
DMI_RXN_2
DMI_RXN_3

DMI_RXP_0
DMI_RXP_1
DMI_RXP_2
DMI_RXP_3

DMI_TXN_0
DMI_TXN_1
DMI_TXN_2
DMI_TXN_3

DMI_TXP_0
DMI_TXP_1
DMI_TXP_2
DMI_TXP_3

DMI

DMI

GFX_VID_0
GFX_VID_1
GFX_VID_2
GFX_VID_3
GFX_VID_4

GFX_VR_EN

GRAPHICS VID

GRAPHICS VID

CL_CLK

CL_DATA

CL_PWROK

CL_RST#
CL_VREF

ME

ME

DDPC_CTRLCLK

DDPC_CTRLDATA

SDVO_CTRLCLK

SDVO_CTRLDATA

CLKREQ#

ICH_SYNC#

TSATN#

MISC

MISC

HDA_BCLK
HDA_RST#

HDA_SDI

HDA_SDO

HDA_SYNC

HDA

HDA

<Checklist ver0.8>
If TSATN# is not used, then it must be terminated
with a 56-Ω pull-up resistor to VCCP.

PM_EXTTS#0
PM_EXTTS#1

SM_REXT

3

BB32
BA25
BA33
BA23

BA31
BC25
BC33
BB24

BC35
BE33
BE37
BC37

BK18
BK16
BE23
BC19

BJ17
BJ19
BC17
BE17

BL25
BK26

BK32
BL31

BC51
AY37
BH20
BA37

B42
D42
B50
D50

R49
P50

AG55
AL49
AH54
AL47

AG53
AK50
AH52
AL45

AG49
AJ49
AJ47
AG47

AF50
AH50
AJ45
AG45

G33
G37
F38
F36
G35

G39

AK52
AK54
AW40
AL53
AL55

F34
F32
B38
A37
C31
K42

D10

C29
B30
D28
A27
B28

TSATN#

SMRCOMPP
SMRCOMPN

SM_RCOMP_VOH
SM_RCOMP_VOL

+SMDDR_VREF_NB
SM_PWROK
SM_REXT

DREFCLK
DREFCLK#
DREFSSCLK
DREFSSCLK#

PECLK_3GPLL
PECLK_3GPLL#

MCH_CLVREF

DDPC_CTRLCLK
DDPC_CTRLDATA
SDVO_CTRLCLK
SDVO_CTRLDATA

CLKREQ#_MCH

TSATN#

HDA_BIT_CLK_HDMI
HDA_RST#_HDMI
HDA_SDIN_HDMI
HDA_SDOUT_HDMI
HDA_SYNC_HDMI

R296 56_4R296 56_4

R100 10K_4R100 10K_4
R97 10K_4R97 10K_4

R271 499/F_4R271 499/F_4

4

M_CLK_DDR0 (16)
M_CLK_DDR1 (16)
M_CLK_DDR2 (16)
M_CLK_DDR3 (16)

M_CLK_DDR#0 (16)
M_CLK_DDR#1 (16)
M_CLK_DDR#2 (16)
M_CLK_DDR#3 (16)

M_CKE0 (16)
M_CKE1 (16)
M_CKE2 (16)
M_CKE3 (16)

M_CS#0 (16)
M_CS#1 (16)
M_CS#2 (16)
M_CS#3 (16)

M_ODT0 (16)
M_ODT1 (16)
M_ODT2 (16)
M_ODT3 (16)

DDR3_RST# (16)

DREFCLK (3)
DREFCLK# (3)
DREFSSCLK (3)
DREFSSCLK# (3)

PECLK_3GPLL (3)
PECLK_3GPLL# (3)

DMI_MRX_ITX_N0 (13)
DMI_MRX_ITX_N1 (13)
DMI_MRX_ITX_N2 (13)
DMI_MRX_ITX_N3 (13)

DMI_MRX_ITX_P0 (13)
DMI_MRX_ITX_P1 (13)
DMI_MRX_ITX_P2 (13)
DMI_MRX_ITX_P3 (13)

DMI_MTX_IRX_N0 (13)
DMI_MTX_IRX_N1 (13)
DMI_MTX_IRX_N2 (13)
DMI_MTX_IRX_N3 (13)

DMI_MTX_IRX_P0 (13)
DMI_MTX_IRX_P1 (13)
DMI_MTX_IRX_P2 (13)
DMI_MTX_IRX_P3 (13)

GPU_VID0 (29)
GPU_VID1 (29)
GPU_VID2 (29)
GPU_VID3 (29)
GPU_VID4 (29)

GFX_VR_EN (29)

CL_CLK0 (14)
CL_DATA0 (14)
MPWROK (14,18)

ICH_CL_RST0# (14)

SDVO_CTRLCLK (22)

SDVO_CTRLDATA (22)
CLKREQ#_MCH (3)
MCH_ICH_SYNC# (14)

HDA_BIT_CLK_HDMI (12)
HDA_RST#_HDMI (12)
HDA_SDIN_HDMI (12)
HDA_SDOUT_HDMI (12)
HDA_SYNC_HDMI (12)

+1.05V

+3V

4

SM_VREF=0.5*VCC_SM

SM_PWROK only for
DDR3.(DDR2 PD only)
SM_DRAMRST# only
for DDR3.(DDR2:NC)

DDCCLK(21)
DDCDATA(21)

DDR3 RCOMP DDR3 RCOMP_VOH/VOLDDR3 VREF

SMRCOMPP

R270 80.6/F_4R270 80.6/F_4

SMRCOMPN

R272 80.6/F_4R272 80.6/F_4

5

INT_LVDS_PWM(22)
INT_LVDS_BLON(22)

PHL_CLK(22)
PHL_DATA(22)

INT_LVDS_DIGON(22)

TXLCLKOUT-(22)
TXLCLKOUT+(22)

TXLOUT0-(22)
TXLOUT1-(22)
TXLOUT2-(22)

TXLOUT0+(22)
TXLOUT1+(22)
TXLOUT2+(22)

CRT_B(21)

CRT_G(21)

CRT_R(21)

VGAHSYNC(21)

VGAVSYNC(21)

R81 30.1/F_4R81 30.1/F_4

R80 30.1/F_4R80 30.1/F_4

CRT setting LVDS setting

R82 150/F_4R82 150/F_4
R78 150/F_4R78 150/F_4
R79 150/F_4R79 150/F_4

+1.5V_SUS

5

L_CTRL_CLK

L_CTRL_DATA
PHL_CLK
PHL_DATA

LVDS_IBG

TXLCLKOUT­TXLCLKOUT+

TXLOUT0­TXLOUT1­TXLOUT2-

TXLOUT0+
TXLOUT1+
TXLOUT2+

INT_TV_COMP
INT_TV_Y/G
INT_TV_C/R

CRT_B

CRT_G

CRT_R

R84:
if the total motherboard route length is less than 12",
the recommended reference resistor value is 1 K Ω ±1%
For longer route lengths between 12" - 15.3" ,
the recommended reference resistor value is 976 Ω ±1%

+1.5V_SUS

CRT_B
CRT_G
CRT_R

HSYNC

CRT_IREF

VSYNC

6

D38
C37
K38

L37
J37
L35

B36
F50
H46
P44
K46
D46
B46
D44
B44

G45
F46
G41
C45

F44
G47
F40
A45

B40
A41
F42
D48

D40
C41
G43
B48

J27
E27
G27

F26

B34
D34

J29

G29

F30

E29

D36
C35
J33
D32
G31

6

U18C

U18C

L_BKLT_CTRL
L_BKLT_EN
L_CTRL_CLK

L_CTRL_DATA
L_DDC_CLK
L_DDC_DATA

L_VDD_EN
LVDS_IBG
LVDS_VBG
LVDS_VREFH
LVDS_VREFL
LVDSA_CLK#
LVDSA_CLK
LVDSB_CLK#
LVDSB_CLK

LVDSA_DATA#_0
LVDSA_DATA#_1
LVDSA_DATA#_2
LVDSA_DATA#_3

LVDSA_DATA_0
LVDSA_DATA_1
LVDSA_DATA_2
LVDSA_DATA_3

LVDSB_DATA#_0
LVDSB_DATA#_1
LVDSB_DATA#_2
LVDSB_DATA#_3

LVDSB_DATA_0
LVDSB_DATA_1
LVDSB_DATA_2
LVDSB_DATA_3

TVA_DAC
TVB_DAC
TVC_DAC

TVA_RTN

TV_DCONSEL_0
TV_DCONSEL_1

CRT_BLUE

CRT_GREEN

CRT_RED

CRT_IRTN

CRT_DDC_CLK
CRT_DDC_DATA
CRT_HSYNC
CRT_TVO_IREF
CRT_VSYNC

CANTIGASFF_1p0

CANTIGASFF_1p0

R93 1.02K/F_4R93 1.02K/F_4

R102 75/F_4R102 75/F_4
R291 75/F_4R291 75/F_4
R292 75/F_4R292 75/F_4

SM_RCOMP_VOH

R269

R269

C423

C423

3.01K/F_4

3.01K/F_4

0.01u/25V_4

0.01u/25V_4

SM_RCOMP_VOL

R266

R266

C422

C422

1K/F_4

1K/F_4

0.01u/25V_4

0.01u/25V_4

LVDS

LVDS

TV

TV

VGA

VGA

CRT_IREF

INT_TV_COMP

INT_TV_Y/G
INT_TV_C/R

C421

C421

2.2u/6.3V_6

2.2u/6.3V_6

C418

C418

2.2u/6.3V_6

2.2u/6.3V_6

PCI-EXPRESS GRAPHICS

PCI-EXPRESS GRAPHICS

7

Layout notice: Place the resistor
within 500 mils (1.27 mm) of the (G)MCH.

U45

PEG_COMPI

T44

PEG_COMPO

D52

PEG_RX#_0

G49

PEG_RX#_1

K54

PEG_RX#_2

H50

PEG_RX#_3

M52

PEG_RX#_4

N49

PEG_RX#_5

P54

PEG_RX#_6

V46

PEG_RX#_7

Y50

PEG_RX#_8

V52

PEG_RX#_9

W49

PEG_RX#_10

AB54

PEG_RX#_11

AD46

PEG_RX#_12

AC55

PEG_RX#_13

AE49

PEG_RX#_14

AF54

PEG_RX#_15

E51

PEG_RX_0

F48

PEG_RX_1

J55

PEG_RX_2

J49

PEG_RX_3

M54

PEG_RX_4

M50

PEG_RX_5

P52

PEG_RX_6

U47

PEG_RX_7

AA49

PEG_RX_8

V54

PEG_RX_9

V50

PEG_RX_10

AB52

PEG_RX_11

AC47

PEG_RX_12

AC53

PEG_RX_13

AD50

PEG_RX_14

AF52

PEG_RX_15

L47

PEG_TX#_0

F52

PEG_TX#_1

P46

PEG_TX#_2

H54

PEG_TX#_3

L55

PEG_TX#_4

T46

PEG_TX#_5

R53

PEG_TX#_6

U49

PEG_TX#_7

T54

PEG_TX#_8

Y46

PEG_TX#_9

AB46

PEG_TX#_10

W53

PEG_TX#_11

Y54

PEG_TX#_12

AC49

PEG_TX#_13

AF46

PEG_TX#_14

AD54

PEG_TX#_15

J47

PEG_TX_0

F54

PEG_TX_1

N47

PEG_TX_2

H52

PEG_TX_3

L53

PEG_TX_4

R47

PEG_TX_5

R55

PEG_TX_6

T50

PEG_TX_7

T52

PEG_TX_8

W47

PEG_TX_9

AA47

PEG_TX_10

W55

PEG_TX_11

Y52

PEG_TX_12

AB50

PEG_TX_13

AE47

PEG_TX_14

AD52

PEG_TX_15

(7/7) intel check list 360543 rev 2.0 CLKREQ# need to 10K pull high to 3.3V

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

7

R104 49.9/F_4R104 49.9/F_4

PEG_COMP

PEG_TXN0

C73 0.1u/10V_4C73 0.1u/10V_4

PEG_TXN1

C74 0.1u/10V_4C74 0.1u/10V_4

PEG_TXN2

C71 0.1u/10V_4C71 0.1u/10V_4

PEG_TXN3

C92 0.1u/10V_4C92 0.1u/10V_4

PEG_TXP0

C72 0.1u/10V_4C72 0.1u/10V_4

PEG_TXP1

C75 0.1u/10V_4C75 0.1u/10V_4

PEG_TXP2

C70 0.1u/10V_4C70 0.1u/10V_4

PEG_TXP3

C99 0.1u/10V_4C99 0.1u/10V_4

+3V

R95 10K_4R95 10K_4

R94 10K_4R94 10K_4
R300 2.2K_4R300 2.2K_4
R301 2.2K_4R301 2.2K_4

R290 2.4K/F_4R290 2.4K/F_4

DDPC_CTRLCLK
DDPC_CTRLDATA
SDVO_CTRLCLK
SDVO_CTRLDATA
CLKREQ#_MCH

Cantiga SFF (DMI/VGA)

Cantiga SFF (DMI/VGA)

Cantiga SFF (DMI/VGA)

+1.05V

R294 2.2K_4R294 2.2K_4
R295 2.2K_4R295 2.2K_4
R297 4.7K_4R297 4.7K_4
R299 4.7K_4R299 4.7K_4R264 1K/F_4R264 1K/F_4
R293 10K_4R293 10K_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

8

HDMI_HP_IV# (22)

HDMI Port B

HDMITX2N (22)
HDMITX1N (22)
HDMITX0N (22)
HDMICLKN (22)

HDMITX2P (22)
HDMITX1P (22)
HDMITX0P (22)
HDMICLKP (22)

L_CTRL_CLK

L_CTRL_DATA

PHL_DATA

PHL_CLK

LVDS_IBG

ZE8

ZE8

ZE8

7 32Tuesday, September 29, 2009

7 32Tuesday, September 29, 2009

7 32Tuesday, September 29, 2009

of

of

of

8

+3V

1A

1A

1A

1

2

3

4

5

6

7

8

Cantiga SFF - DDRII (CLG)

M_A_DQ[63:0](16) M_B_DQ[63:0](16)

AA

BB

CC

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

AP46
AU47
AT46
AU49
AR45
AN49
AV50
AP50

AW47

BD50

AW49

BA49
BC49
AV46
BA47
AY50
BF46
BC47
BF50
BF48
BC43
BE49
BA43
BE47
BF42
BC39
BF44
BF40
BB40
BE43
BF38
BE41
BA15
BE11
BE15
BF14
BB14
BC15
BE13
BF16
BF10
BC11

BF8
BG7
BC7
BC9
BD6

BF12

AV6

BB6

AW7

AY6

AT10

AW11

AU11

AW9

AR11

AT6

AP6

AL7
AR7

AT12

AM6
AU7

U18D

U18D

SA_DQ_0
SA_DQ_1
SA_DQ_2
SA_DQ_3
SA_DQ_4
SA_DQ_5
SA_DQ_6
SA_DQ_7
SA_DQ_8
SA_DQ_9
SA_DQ_10
SA_DQ_11
SA_DQ_12
SA_DQ_13
SA_DQ_14
SA_DQ_15
SA_DQ_16
SA_DQ_17
SA_DQ_18
SA_DQ_19
SA_DQ_20
SA_DQ_21
SA_DQ_22
SA_DQ_23
SA_DQ_24
SA_DQ_25
SA_DQ_26
SA_DQ_27
SA_DQ_28
SA_DQ_29
SA_DQ_30
SA_DQ_31
SA_DQ_32
SA_DQ_33
SA_DQ_34
SA_DQ_35
SA_DQ_36
SA_DQ_37
SA_DQ_38
SA_DQ_39
SA_DQ_40
SA_DQ_41
SA_DQ_42
SA_DQ_43
SA_DQ_44
SA_DQ_45
SA_DQ_46
SA_DQ_47
SA_DQ_48
SA_DQ_49
SA_DQ_50
SA_DQ_51
SA_DQ_52
SA_DQ_53
SA_DQ_54
SA_DQ_55
SA_DQ_56
SA_DQ_57
SA_DQ_58
SA_DQ_59
SA_DQ_60
SA_DQ_61
SA_DQ_62
SA_DQ_63

CANTIGASFF_1p0

CANTIGASFF_1p0

DDR SYSTEM MEMORY A

DDR SYSTEM MEMORY A

SA_BS_0
SA_BS_1
SA_BS_2

SA_RAS#
SA_CAS#

SA_WE#

SA_DM_0
SA_DM_1
SA_DM_2
SA_DM_3
SA_DM_4
SA_DM_5
SA_DM_6
SA_DM_7

SA_DQS_0
SA_DQS_1
SA_DQS_2
SA_DQS_3
SA_DQS_4
SA_DQS_5
SA_DQS_6

SA_DQS_7
SA_DQS#_0
SA_DQS#_1
SA_DQS#_2
SA_DQS#_3
SA_DQS#_4
SA_DQS#_5
SA_DQS#_6
SA_DQS#_7

SA_MA_0
SA_MA_1
SA_MA_2
SA_MA_3
SA_MA_4
SA_MA_5
SA_MA_6
SA_MA_7
SA_MA_8

SA_MA_9
SA_MA_10
SA_MA_11
SA_MA_12
SA_MA_13
SA_MA_14

BC21
BJ21
BJ41

BH22
BK20
BL15

AT50
BB50
BB46
BE39
BB12
BE7
AV10
AR9

AR47
BA45
BE45
BC41
BC13
BB10
BA7
AN7
AR49
AW45
BC45
BA41
BA13
BA11
BA9
AN9

BC23
BF22
BE31
BC31
BH26
BJ35
BB34
BH32
BB26
BF32
BA21
BG25
BH34
BH18
BE25

M_A_BS#0
M_A_BS#1
M_A_BS#2

M_A_RAS#
M_A_CAS#
M_A_WE#

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

M_A_DQS0
M_A_DQS1
M_A_DQS2
M_A_DQS3
M_A_DQS4
M_A_DQS5
M_A_DQS6
M_A_DQS7
M_A_DQS#0
M_A_DQS#1
M_A_DQS#2
M_A_DQS#3
M_A_DQS#4
M_A_DQS#5
M_A_DQS#6
M_A_DQS#7

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14

M_A_BS#0 (16)
M_A_BS#1 (16)
M_A_BS#2 (16)

M_A_RAS# (16)
M_A_CAS# (16)
M_A_WE# (16)

M_A_DM[7:0] (16)

M_A_DQS[7:0] (16)

M_A_DQS#[7:0] (16)

M_A_A[14:0] (16)

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

AP54
AM52
AR55

AV54
AM54
AN53

AT52
AU53

AW53

AY52

BB52
BC53

AV52

AW55

BD52
BC55

BF54

BE51
BH48

BK48

BE53
BH52

BK46

BJ47

BL45

BJ45

BL41
BH44
BH46

BK44

BK40

BJ39

BK10
BH10

BK6
BH6

BL11

BG5

BG3
BF4
BD4
BA3
BE5
BF2
BB4
AY4
BA1
AP2
AU1
AT2
AT4
AV4
AU3
AR3
AN1
AP4
AL3

AK4

AM4

AH2
AK2

BJ9

BJ5

AJ1

U18E

U18E

SB_DQ_0
SB_DQ_1
SB_DQ_2
SB_DQ_3
SB_DQ_4
SB_DQ_5
SB_DQ_6
SB_DQ_7
SB_DQ_8
SB_DQ_9
SB_DQ_10
SB_DQ_11
SB_DQ_12
SB_DQ_13
SB_DQ_14
SB_DQ_15
SB_DQ_16
SB_DQ_17
SB_DQ_18
SB_DQ_19
SB_DQ_20
SB_DQ_21
SB_DQ_22
SB_DQ_23
SB_DQ_24
SB_DQ_25
SB_DQ_26
SB_DQ_27
SB_DQ_28
SB_DQ_29
SB_DQ_30
SB_DQ_31
SB_DQ_32
SB_DQ_33
SB_DQ_34
SB_DQ_35
SB_DQ_36
SB_DQ_37
SB_DQ_38
SB_DQ_39
SB_DQ_40
SB_DQ_41
SB_DQ_42
SB_DQ_43
SB_DQ_44
SB_DQ_45
SB_DQ_46
SB_DQ_47
SB_DQ_48
SB_DQ_49
SB_DQ_50
SB_DQ_51
SB_DQ_52
SB_DQ_53
SB_DQ_54
SB_DQ_55
SB_DQ_56
SB_DQ_57
SB_DQ_58
SB_DQ_59
SB_DQ_60
SB_DQ_61
SB_DQ_62
SB_DQ_63

CANTIGASFF_1p0

CANTIGASFF_1p0

DDR SYSTEM MEMORY B

DDR SYSTEM MEMORY B

SB_BS_0
SB_BS_1
SB_BS_2

SB_RAS#
SB_CAS#

SB_WE#

SB_DM_0
SB_DM_1
SB_DM_2
SB_DM_3
SB_DM_4
SB_DM_5
SB_DM_6
SB_DM_7

SB_DQS_0
SB_DQS_1
SB_DQS_2
SB_DQS_3
SB_DQS_4
SB_DQS_5
SB_DQS_6

SB_DQS_7
SB_DQS#_0
SB_DQS#_1
SB_DQS#_2
SB_DQS#_3
SB_DQS#_4
SB_DQS#_5
SB_DQS#_6
SB_DQS#_7

SB_MA_0
SB_MA_1
SB_MA_2
SB_MA_3
SB_MA_4
SB_MA_5
SB_MA_6
SB_MA_7
SB_MA_8

SB_MA_9
SB_MA_10
SB_MA_11
SB_MA_12
SB_MA_13
SB_MA_14

BJ13
BK12
BK38

BE21
BH14
BK14

AP52
AY54
BJ49
BJ43
BH12
BD2
AY2
AJ3

AR53
BA53
BH50
BK42
BH8
BB2
AV2
AM2
AT54
BB54
BJ51
BH42
BK8
BC3
AW3
AN3

BJ15
BJ33
BH24
BA17
BF36
BH36
BF34
BK34
BJ37
BH40
BH16
BK36
BH38
BJ11
BL37

M_B_BS#0
M_B_BS#1
M_B_BS#2

M_B_RAS#
M_B_CAS#
M_B_WE#

M_B_DM0
M_B_DM1
M_B_DM2
M_B_DM3
M_B_DM4
M_B_DM5
M_B_DM6
M_B_DM7

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7
M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14

M_B_BS#0 (16)
M_B_BS#1 (16)
M_B_BS#2 (16)

M_B_RAS# (16)
M_B_CAS# (16)
M_B_WE# (16)

M_B_DM[7:0] (16)

M_B_DQS[7:0] (16)

M_B_DQS#[7:0] (16)

M_B_A[14:0] (16)

DD

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Cantiga SFF (DDRII)

Cantiga SFF (DDRII)

Cantiga SFF (DDRII)

Date: Sheet

Date: Sheet

1

2

3

4

5

6

Date: Sheet

PROJECT :

7

ZE8

ZE8

ZE8

1A

1A

1A

8 32Tuesday, September 29, 2009

8 32Tuesday, September 29, 2009

8 32Tuesday, September 29, 2009

of

of

of

8

5

Cantiga SFF - VCC/NCTF (CLG)

Ivcc internal VGA 2.4A
(Shape or 140mils)

VCC 2200mA

DD

CC

BB

AA

+1.05V

AT41
AR41
AN41
AJ41
AH41
AD41
AC41

AT40

AM40

AL40

AJ40
AH40
AG40
AE40
AD40
AC40

AA40

AN35
AM35

AJ35
AH35
AD35
AC35

AM34

AL34

AJ34
AH34
AG34
AE34
AD34

AC34

AA34

AM32

AL32

AJ32
AH32
AE32
AD32

AA32
AM31

AL31

AJ31
AH31
AM29

AL29
AM28

AL28

AJ28
AM27

AL27
AM25

AL25

AJ25
AM24

Y41

W41

Y40

W35

Y34

W34

N36

U18F

U18F

VCC_1
VCC_2
VCC_3
VCC_4
VCC_5
VCC_6
VCC_7
VCC_8
VCC_9
VCC_10
VCC_11
VCC_12

VCC_13
VCC_14
VCC_15
VCC_16
VCC_17
VCC_18
VCC_19
VCC_20
VCC_21
VCC_22
VCC_23
VCC_24
VCC_25
VCC_26
VCC_27
VCC_28
VCC_29
VCC_30
VCC_31
VCC_32
VCC_33
VCC_34

VCC_35
VCC_36

VCC_37
VCC_38
VCC_39
VCC_40
VCC_41
VCC_42
VCC_43
VCC_44
VCC_45
VCC_46
VCC_47
VCC_48
VCC_49
VCC_50
VCC_51
VCC_52
VCC_53
VCC_54
VCC_55
VCC_56
VCC_57
VCC_58
VCC_59
VCC_60
VCC_61

CANTIGASFF_1p0

CANTIGASFF_1p0

5

VCC CORE

VCC CORE

POWER

POWER

VCC_NCTF_1
VCC_NCTF_2
VCC_NCTF_3
VCC_NCTF_4
VCC_NCTF_5
VCC_NCTF_6
VCC_NCTF_7
VCC_NCTF_8

VCC_NCTF_9
VCC_NCTF_10
VCC_NCTF_11
VCC_NCTF_12
VCC_NCTF_13
VCC_NCTF_14
VCC_NCTF_15
VCC_NCTF_16
VCC_NCTF_17
VCC_NCTF_18
VCC_NCTF_19
VCC_NCTF_20
VCC_NCTF_21
VCC_NCTF_22
VCC_NCTF_23
VCC_NCTF_24
VCC_NCTF_25
VCC_NCTF_26
VCC_NCTF_27
VCC_NCTF_28
VCC_NCTF_29
VCC_NCTF_30
VCC_NCTF_31
VCC_NCTF_32

VCC NCTF

VCC NCTF

VCC_NCTF_33
VCC_NCTF_34
VCC_NCTF_35
VCC_NCTF_36
VCC_NCTF_37
VCC_NCTF_38

AT38
AR38
AN38
AM38
AL38
AG38
AE38
AA38
Y38
W38
U38
T38
R38
AT37
AR37
AN37
AM37
AL37
AJ37
AH37
AG37
AE37
AD37
AC37
AA37
Y37
W37
U37
T37
R37
AT35
AR35
U35
AT34
AR34
U34
T34
R34

+1.05V

Differential routing

GFX_VCCSENSE(29)
GFX_VSSSENSE(29)

4

VCC_SM(+1.5V_SUS)
DDR3(800M) : 3162.5mA
DDR3(1067M) : 4140mA

+1.5V_SUS

+VCC_SM_BB36
+VCC_SM_BE35

C217

C217

C216

C216

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

VCC_SM :3000mA

+VCC_SM_BC29

C213

C213

0.1u/10V_4

0.1u/10V_4

+VCC_SM_BF24
+VCC_SM_BL19
+VCC_SM_BB16

C209

C209

0.1u/10V_4

0.1u/10V_4

C424

C424

0.1u/10V_4

0.1u/10V_4

C206

C206

0.1u/10V_4

0.1u/10V_4

+VGFX

VCC_AXG 7700mA

+VGFX

R108

R108

10/F_4

10/F_4

R107

R107

10/F_4

10/F_4

1. Route VCC_AXG_SENSE and VSS_AXG_SENSE differentially

2. VCC_AXG_SENSE PU to +VGFX_CORE_INT with 10ohm
and VSS_AXG_SENSE PD with 10ohm for Intel suggest

4

BB36

BE35
AW34
AW32

BK30

BH30

BF30

BD30

BB30
AW30

BL29

BJ29

BG29

BE29

BC29

BA29

AY29

BK28

BH28

BF28

BD28

BB28

BL27

BJ27

BG27

BE27

BC27

BA27

AY27
AW26

BF24

BL19

BB16

AG31

AE31

AD31

AC31

AA31

AH29

AG29

AE29

AD29

AC29

AA29

AH28

AG28

AE28

AA28

AH27

AG27

AE27

AD27

AC27

AA27

AH25

AD25

AC25

AJ24

AH24

AG24

AE24

AD24

AC24

AA24

AM22

AL22

AJ22

AH22

AG22

AE22

AD22

AC22

AA22
AM21

AL21

AJ21

AH21

AD21

AC21

AA21

AM16

AL16

AG13

AE13

W32

Y31

W31

Y29

W29

Y27

W27

W25

Y24

W24

Y21

W21

U18G

U18G

VCC_SM_1
VCC_SM_2
VCC_SM_3
VCC_SM_4
VCC_SM_5
VCC_SM_6
VCC_SM_7
VCC_SM_8
VCC_SM_9
VCC_SM_10
VCC_SM_11
VCC_SM_12
VCC_SM_13
VCC_SM_14
VCC_SM_15
VCC_SM_16
VCC_SM_17
VCC_SM_18
VCC_SM_19
VCC_SM_20
VCC_SM_21
VCC_SM_22
VCC_SM_23
VCC_SM_24
VCC_SM_25
VCC_SM_26
VCC_SM_27
VCC_SM_28
VCC_SM_29
VCC_SM_30
VCC_SM_31
VCC_SM_32
VCC_SM_33

VCC_AXG_1
VCC_AXG_2
VCC_AXG_3
VCC_AXG_4
VCC_AXG_5
VCC_AXG_6
VCC_AXG_7
VCC_AXG_8
VCC_AXG_9
VCC_AXG_10
VCC_AXG_11
VCC_AXG_12
VCC_AXG_13
VCC_AXG_14
VCC_AXG_15
VCC_AXG_16
VCC_AXG_17
VCC_AXG_18
VCC_AXG_19
VCC_AXG_20
VCC_AXG_21
VCC_AXG_22
VCC_AXG_23
VCC_AXG_24
VCC_AXG_25
VCC_AXG_26
VCC_AXG_27
VCC_AXG_28
VCC_AXG_29
VCC_AXG_30
VCC_AXG_31
VCC_AXG_32
VCC_AXG_33
VCC_AXG_34
VCC_AXG_35
VCC_AXG_36
VCC_AXG_37
VCC_AXG_38
VCC_AXG_39
VCC_AXG_40
VCC_AXG_41
VCC_AXG_42
VCC_AXG_43
VCC_AXG_44
VCC_AXG_45
VCC_AXG_46
VCC_AXG_47
VCC_AXG_48
VCC_AXG_49
VCC_AXG_50
VCC_AXG_51
VCC_AXG_52
VCC_AXG_53
VCC_AXG_54
VCC_AXG_55
VCC_AXG_56
VCC_AXG_57
VCC_AXG_58
VCC_AXG_59
VCC_AXG_60
VCC_AXG_61

VCC_AXG_SENSE
VSS_AXG_SENSE

CANTIGASFF_1p0

CANTIGASFF_1p0

3

POWER

POWER

VCC SMVCC GFX

VCC SMVCC GFX

3

VCC_AXG_NCTF_1
VCC_AXG_NCTF_2
VCC_AXG_NCTF_3
VCC_AXG_NCTF_4
VCC_AXG_NCTF_5
VCC_AXG_NCTF_6
VCC_AXG_NCTF_7
VCC_AXG_NCTF_8

VCC_AXG_NCTF_9
VCC_AXG_NCTF_10
VCC_AXG_NCTF_11
VCC_AXG_NCTF_12
VCC_AXG_NCTF_13
VCC_AXG_NCTF_14
VCC_AXG_NCTF_15
VCC_AXG_NCTF_16
VCC_AXG_NCTF_17
VCC_AXG_NCTF_18
VCC_AXG_NCTF_19
VCC_AXG_NCTF_20
VCC_AXG_NCTF_21
VCC_AXG_NCTF_22
VCC_AXG_NCTF_23
VCC_AXG_NCTF_24
VCC_AXG_NCTF_25
VCC_AXG_NCTF_26
VCC_AXG_NCTF_27
VCC_AXG_NCTF_28
VCC_AXG_NCTF_29
VCC_AXG_NCTF_30
VCC_AXG_NCTF_31
VCC_AXG_NCTF_32
VCC_AXG_NCTF_33
VCC_AXG_NCTF_34
VCC_AXG_NCTF_35
VCC_AXG_NCTF_36
VCC_AXG_NCTF_37
VCC_AXG_NCTF_38
VCC_AXG_NCTF_39

VCC GFX NCTF

VCC GFX NCTF

VCC_AXG_NCTF_40
VCC_AXG_NCTF_41
VCC_AXG_NCTF_42
VCC_AXG_NCTF_43
VCC_AXG_NCTF_44

VCC_AXG_62
VCC_AXG_63
VCC_AXG_64
VCC_AXG_65
VCC_AXG_66
VCC_AXG_67
VCC_AXG_68
VCC_AXG_69
VCC_AXG_70
VCC_AXG_71
VCC_AXG_72
VCC_AXG_73
VCC_AXG_74
VCC_AXG_75

VCC GFX

VCC GFX

VCC_AXG_76
VCC_AXG_77
VCC_AXG_78
VCC_AXG_79
VCC_AXG_80

VCC_SM_LF1
VCC_SM_LF2
VCC_SM_LF3
VCC_SM_LF4
VCC_SM_LF5
VCC_SM_LF6
VCC_SM_LF7

VCC SM LF

VCC SM LF

UMA 9.6A(GM45)
(Plane or shape)

+VGFX

T32
U31
T31
R31
U29
T29
R29
U28
U27
T27
R27
U25
T25
R25
U24
U22
T22
R22
U21
T21
R21
AM19
AL19
AH19
AG19
AE19
AD19
AC19
W19
U19
AM18
AL18
AJ18
AH18
AG18
AE18
AD18
AC18
AA18
Y18
W18
U18
T18
R18

AJ16
AH16
AD16
AC16
AA16
U16
T16
R16
AM15
AL15
AJ15
AH15
AG15
AE15
AA15
Y15
W15
U15
T15

VCCSM_LF1

AU45

VCCSM_LF2

BF52

VCCSM_LF3

BB38

VCCSM_LF4

BA19

VCCSM_LF5

BE9

VCCSM_LF6

AU9

VCCSM_LF7

AL9

2

+1.05V+VGFX

R64 *0_8R64 *0_8

R65 *0_8R65 *0_8

Celeron 723,743 not support graphics render standby mode,
so add R64 , R65, del GFX power (Page 29)
SU type cpu support it, so del R64, R65 and add GFX power (Page 29)

R183 *0_8R183 *0_8

1

9/28: add R183 for voltage low issue

+1.05V

+

+

C156

C156

*10u/6.3V_8

*10u/6.3V_8

+1.5V_SUS

C211

C211

10u/6.3V_8

10u/6.3V_8

C115

C115

10u/6.3V_8

10u/6.3V_8

8/13 : add for EMI

C83

C83

*220u/2.5V_3528

*220u/2.5V_3528

C212

C212

*10u/6.3V_8

*10u/6.3V_8

C124

C124

0.1u/10V_4

0.1u/10V_4

+VGFX

C246

C246
*220p/50V_6

*220p/50V_6

C132

C132

0.1u/10V_4

0.1u/10V_4

+VGFX

+VGFX

+

+

C203

C203

0.1u/10V_4

0.1u/10V_4

C133

C133

0.47u/6.3V_4

0.47u/6.3V_4

C108

C108

*220u/2.5V_3528

*220u/2.5V_3528

C182

C182

0.22u/10V_4

0.22u/10V_4

Layout Note:
Inside GMCH cavity.

C200

C200

0.1u/10V_4

0.1u/10V_4

C128

+

+

C107

C107

220u/2.5V_3528

220u/2.5V_3528

C128

10u/6.3V_6

10u/6.3V_6

C127

C127

*1u/16V_6

*1u/16V_6

C201

C201

0.22u/10V_4

0.22u/10V_4

C215

C215

10u/6.3V_8

10u/6.3V_8

Close to GMCH

Layout Note:
370 mils from edge.

10mil

C205

C163

C163

0.1u/10V_4

0.1u/10V_4

C205

0.1u/10V_4

0.1u/10V_4

2

C204

C204

0.22u/10V_4

0.22u/10V_4

C207

C207

0.22u/10V_4

0.22u/10V_4

C218

C218

0.47u/6.3V_4

0.47u/6.3V_4

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Cantiga SFF (VCC/NCTF)

Cantiga SFF (VCC/NCTF)

Cantiga SFF (VCC/NCTF)

Date: Sheet

Date: Sheet

Date: Sheet of

C197

C197

C210

C210

1u/10V_6

1u/10V_6

1u/10V_6

1u/10V_6

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

1

C247

C247
*220p/50V_6

*220p/50V_6

ZE8

ZE8

ZE8

1A

1A

9 32Tuesday, September 29, 2009

9 32Tuesday, September 29, 2009

9 32Tuesday, September 29, 2009

1A

of

of

5

4

3

2

1

Cantiga SFF - Power (CLG)

+3V

L9 BLM18PG181SN1D_6L9 BLM18PG181SN1D_6

+1.05V

DD

CC

BB

AA

L27 10uH_8L27 10uH_8

+1.05V

L28 10uH_8L28 10uH_8

+1.05V

R110 Short_6R110 Short_6

L15 BLM18PG181SN1D_6L15 BLM18PG181SN1D_6

C152

C152

+1.05VM_MPLL_RC

10u/6.3V_8

10u/6.3V_8

+1.05V

+1.05V

+

+

+

+

L14 BLM18PG181SN1D_6L14 BLM18PG181SN1D_6

L13 BLM18PG221SN1D_6L13 BLM18PG221SN1D_6

C161

C161

+1.05VM_PEGPLL_RC

10u/6.3V_8

10u/6.3V_8

5

C436

C436

220U/2.5V_3528

220U/2.5V_3528

C437

C437

220U/2.5V_3528

220U/2.5V_3528

C155

C155

4.7u/6.3V_6

4.7u/6.3V_6

R106

R106

0.5/F_4

0.5/F_4

+3V_A_CRT_BG

+1.05VM_DPLLA

C105

C105

0.1u/10V_4

0.1u/10V_4

+1.05VM_DPLLB

C110

C110

0.1u/10V_4

0.1u/10V_4

+1.05VM_HPLL

C157

C157

0.1u/10V_4

0.1u/10V_4

+1.05VM_MPLL

C149

C149

0.1u/10V_4

0.1u/10V_4

R109

R109

1/F_4

1/F_4

+1.05V

C198

C198

+

+

100u/6.3V_3528

100u/6.3V_3528

+1.05V

C183

C183

10u/6.3V_8

10u/6.3V_8

+1.05VM_MCH_PLL2

+1.05VM_PEGPLL

C158

C158

0.1u/10V_4

0.1u/10V_4

+3V

+3V_A_CRT_DAC

C101

C101

0.1u/10V_4

0.1u/10V_4

C85

C85

10u/6.3V_8

10u/6.3V_8

C126 1000p/50V_4C126 1000p/50V_4

+1.5V

C169

C169

0.1u/10V_4

0.1u/10V_4

C188

C188

10u/6.3V_8

10u/6.3V_8

C185

C185

*2.2u/6.3V_6

*2.2u/6.3V_6

L10

L10
BLM18PG181SN1D_6

BLM18PG181SN1D_6

73mA(20mils)

5mA(10mils)

C94

C94

0.1u/10V_4

0.1u/10V_4

64mA(20mils)

64mA(20mils)

24mA(20mils)

139.2mA(20mils)

10mA(20mils)

414uA(10mils)

50mA(10mils)

720mA(40mils)

C184

C184

4.7u/6.3V_6

4.7u/6.3V_6

26mA(20mils)

C186

C186

0.1u/10V_4

0.1u/10V_4

157.2mA(20mils)

C164

C164

0.1u/10V_4

0.1u/10V_4

50mA(20mils)

30mA(20mils)

4

C102

C102

0.01u/25V_4

0.01u/25V_4

C95

C95

0.01u/25V_4

0.01u/25V_4

+1.05VM_PEGPLL

C189

C189

1u/6.3V_4

1u/6.3V_4

+1.8V

C111

C111

1u/6.3V_4

1u/6.3V_4

U18H

U18H

J31

VCCA_CRT_DAC

L31

VCCA_DAC_BG

M33

VSSA_DAC_BG

J45

VCCA_DPLLA

L49

VCCA_DPLLB

AF10

VCCA_HPLL

AE1

VCCA_MPLL

U43

VCCA_LVDS1

U41

VCCA_LVDS2

V44

VSSA_LVDS

AJ43

VCCA_PEG_BG

AG43

VCCA_PEG_PLL

AW24

VCCA_SM_1

AU24

VCCA_SM_2

AW22

VCCA_SM_3

AU22

VCCA_SM_4

AU21

VCCA_SM_5

AW20

VCCA_SM_6

AU19

VCCA_SM_7

AW18

VCCA_SM_8

AU18

VCCA_SM_9

AW16

VCCA_SM_10

AU16

VCCA_SM_11

AT16

VCCA_SM_12

AR16

VCCA_SM_13

AU15

VCCA_SM_14

AT15

VCCA_SM_15

AR15

VCCA_SM_16

AW14

VCCA_SM_17

AT24

VCCA_SM_NCTF_1

AR24

VCCA_SM_NCTF_2

AT22

VCCA_SM_NCTF_3

AR22

VCCA_SM_NCTF_4

AT21

VCCA_SM_NCTF_5

AR21

VCCA_SM_NCTF_6

AT19

VCCA_SM_NCTF_7

AR19

VCCA_SM_NCTF_8

AT18

VCCA_SM_NCTF_9

AR18

VCCA_SM_NCTF_10

AU27

VCCA_SM_CK_4

AU28

VCCA_SM_CK_3

AU29

VCCA_SM_CK_2

AU31

VCCA_SM_CK_1

AT31

VCCA_SM_CK_NCTF_1

AR31

VCCA_SM_CK_NCTF_2

AT29

VCCA_SM_CK_NCTF_3

AR29

VCCA_SM_CK_NCTF_4

AT28

VCCA_SM_CK_NCTF_5

AR28

VCCA_SM_CK_NCTF_6

AT27

VCCA_SM_CK_NCTF_7

AR27

VCCA_SM_CK_NCTF_8

AH12

VCCD_HPLL

AE43

VCCD_PEG_PLL

M46

VCCD_LVDS_1

L45

VCCD_LVDS_2

CANTIGASFF_1p0

CANTIGASFF_1p0

CRTPLLA PEGA SM

CRTPLLA PEGA SM

A LVDS

A LVDS

POWER

POWER

LVDS

LVDS

3

VTT_1
VTT_2
VTT_3
VTT_4
VTT_5
VTT_6
VTT_7
VTT_8

VTT_9
VTT_10
VTT_11
VTT_12
VTT_13

VTT

VTT

VCCA_TV_DAC

TVD TV/CRT

TVD TV/CRT

VCC_HDA

HDA

HDA

VCCD_QDAC

VCCD_TVDAC

VCC_AXF_1
VCC_AXF_2
VCC_AXF_3

AXF

AXF

VCC_SM_CK_1
VCC_SM_CK_2
VCC_SM_CK_3
VCC_SM_CK_4

SM CK

SM CK

VCC_TX_LVDS

VCC_HV_1
VCC_HV_2

HV

HV

VCC_PEG_1
VCC_PEG_2
VCC_PEG_3
VCC_PEG_4

PEG

PEG

VCC_DMI_1
VCC_DMI_2
VCC_DMI_3

DMI

DMI

VTTLF1
VTTLF2
VTTLF3

VTTLF

VTTLF

R13
T12
R11
T10
R9
T8
R7
T6
R5
T4
R3
T2
R1

K30

A31

N34

N32

M25
N24
M23

BK24
BL23
BJ23
BK22

T41

C33
A33

AB44
Y44
AC43
AA43

AM44
AN43
AL43

K14
Y12
P2

C146

C146

0.47u/6.3V_4

0.47u/6.3V_4

456mA(30mils)

+VTTLF_CAP1
+VTTLF_CAP2
+VTTLF_CAP3

10mil

852mA(50mils)

C131

C131

2.2u/6.3V_6

2.2u/6.3V_6

79mA(20mils)

C97

C97

0.01u/25V_4

0.01u/25V_4

50mA(15mils)

2.7mA(15mils)

C103

C103

0.01u/25V_4

0.01u/25V_4

35mA(15mils)

440mA(30mils)

C106

C106

1u/6.3V_4

1u/6.3V_4

DDR3-800 124mA
(20mils)

80mA(20mils)

105.3mA(20mils)

1.782A(100mils)

C202

C202

0.1u/10V_4

0.1u/10V_4

C430

C430

0.47u/6.3V_4

0.47u/6.3V_4

C148

C130

C130

4.7u/6.3V_6

4.7u/6.3V_6

C96

C96

0.1u/10V_4

0.1u/10V_4

C112

C112

0.1u/10V_4

0.1u/10V_4

+1.05V

Check list 2.2
DDR3=>0 ohm
DDR2=>0.1uH, DCR<160 mohm

C147

C147

0.47u/6.3V_4

0.47u/6.3V_4

2

C148

4.7u/6.3V_6

4.7u/6.3V_6

+3V_TV_DAC

+1.5V_VCC_HDA

C438

C438

HD@NHD@0.1u/10V_4

HD@NHD@0.1u/10V_4

+1.5V_QDAC

+1.5V_TVDAC+1.8V_TXLVDS

C151

C151

10u/6.3V_6

10u/6.3V_6

+1.5VSUS_VCC_SM_CK

C420

C420

0.1u/10V_4

0.1u/10V_4

+1.8V_TXLVDS

C125

C125

1000p/50V_4

1000p/50V_4

+1.05V

C98

C98

0.47u/6.3V_4

0.47u/6.3V_4

C199

C199

4.7u/6.3V_6

4.7u/6.3V_6

+1.05V

C160

C160

*10u/6.3V_6

*10u/6.3V_6

R89 Short_6R89 Short_6

R298 HD@0_6R298 HD@0_6

+3V

+1.5V

Enable HDMI C394= 0.1uF

Disable HDMI C394= 0Ω

+1.5V

L11

L11

BLM18PG181SN1D_6

BLM18PG181SN1D_6

R88 Short_6R88 Short_6

C86

C114

C114

0.01u/25V_4

0.01u/25V_4

Clock supply(1.5V)
DDR3(1066):149.5mA

R265

R265

1/F_4

1/F_4

+1.5VSUS_SMCK_RC

LVDS Transmitter(1.8V)

118.8mA

C129

C129

10u/6.3V_6

10u/6.3V_6

C91

C91

0.1u/10V_4

0.1u/10V_4

C196

C196

10u/6.3V_8

10u/6.3V_8

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

C86

0.1u/10V_4

0.1u/10V_4

+1.5V_SUS

L26

L26

1uH/300MA_8

1uH/300MA_8

C417

C417

10u/6.3V_6

10u/6.3V_6

R114 Short_6R114 Short_6

R86 10_4R86 10_4

Cantiga SFF (Power)

Cantiga SFF (Power)

Cantiga SFF (Power)

+1.8V

+1.05V_SD

+1.05V

C171

C171

*10u/6.3V_6

*10u/6.3V_6

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

1

+1.05V

21

D11

D11

CH751H-40PT

CH751H-40PT

+3V

ZE8

ZE8

ZE8

10 32Tuesday, September 29, 2009

10 32Tuesday, September 29, 2009

10 32Tuesday, September 29, 2009

of

of

of

1A

1A

1A

5

Cantiga SFF - GND (CLG)

DD

CC

BB

AA

5

BA55
AU55
AN55

AJ55
AE55
AA55

U55

N55
BD54
BG53

AJ53
AE53
AA53

U53
N53
J53

G53

E53

K52
BG51
BA51
AW51
AU51
AR51
AN51

AL51

AJ51
AG51
AE51
AC51
AA51

W51

U51
R51
N51
L51
J51

G51

C51
BK50
AM50

K50
BG49

E49

C49
BD48
BB48
AY48
AV48

AT48
AP48
AM48
AK48
AH48

AF48
AD48
AB48

Y48
V48
T48
P48

M48

K48
H48

BL47
BG47

E47
C47

A47
BD46
AY46
AM46
AK46
AH46
BG45
AE45
AC45
AA45

W45

R45

N45

E45
BD44
BB44
AV44
AK44
AH44

AF44

AD44

K44

H44

BL43
BG43
AY43
AR43

W43

R43

M43

E43

U18I

U18I

VSS_1
VSS_2
VSS_3
VSS_4
VSS_5
VSS_6
VSS_7
VSS_8
VSS_9
VSS_10
VSS_11
VSS_12
VSS_13
VSS_14
VSS_15
VSS_16
VSS_17
VSS_18
VSS_19
VSS_20
VSS_21
VSS_22
VSS_23
VSS_24
VSS_25
VSS_26
VSS_27
VSS_28
VSS_29
VSS_30
VSS_31
VSS_32
VSS_33
VSS_34
VSS_35
VSS_36
VSS_37
VSS_38
VSS_39
VSS_40
VSS_41
VSS_42
VSS_43
VSS_44
VSS_45
VSS_46
VSS_47
VSS_48
VSS_49
VSS_50
VSS_51
VSS_52
VSS_53
VSS_54
VSS_55
VSS_56
VSS_57
VSS_58
VSS_59
VSS_60
VSS_61
VSS_62
VSS_63
VSS_64
VSS_65
VSS_66
VSS_67
VSS_68
VSS_69
VSS_70
VSS_71
VSS_72
VSS_73
VSS_74
VSS_75
VSS_76
VSS_77
VSS_78
VSS_79
VSS_80
VSS_81
VSS_82
VSS_83
VSS_84
VSS_85
VSS_86
VSS_87
VSS_88
VSS_89
VSS_90
VSS_91
VSS_92
VSS_93
VSS_94
VSS_95
VSS_96
VSS_97
VSS_98
VSS_99

CANTIGASFF_1p0

CANTIGASFF_1p0

VSS

VSS

4

VSS_100
VSS_101
VSS_102
VSS_103
VSS_104
VSS_105
VSS_106
VSS_107
VSS_108
VSS_109
VSS_110
VSS_111
VSS_112
VSS_113
VSS_114
VSS_115
VSS_116
VSS_117
VSS_118
VSS_119
VSS_120
VSS_121
VSS_122
VSS_123
VSS_124
VSS_125
VSS_126
VSS_127
VSS_128
VSS_129
VSS_130
VSS_131
VSS_132
VSS_133
VSS_134
VSS_135
VSS_136
VSS_137
VSS_138
VSS_139
VSS_140
VSS_141
VSS_142
VSS_143
VSS_144
VSS_145
VSS_146
VSS_147
VSS_148
VSS_149
VSS_150
VSS_151
VSS_152
VSS_153
VSS_154
VSS_155
VSS_156
VSS_157
VSS_158
VSS_159
VSS_160
VSS_161
VSS_162
VSS_163
VSS_164
VSS_165
VSS_166
VSS_167
VSS_168
VSS_169
VSS_170
VSS_171
VSS_172
VSS_173
VSS_174
VSS_175
VSS_176
VSS_177
VSS_178
VSS_179
VSS_180
VSS_181
VSS_182
VSS_183
VSS_184
VSS_185
VSS_186
VSS_187
VSS_188
VSS_189
VSS_190
VSS_191
VSS_192
VSS_193
VSS_194
VSS_195
VSS_196
VSS_197
VSS_198

4

C43
A43
BD42
H42
BG41
AY41
AU41
AM41
AL41
AG41
AE41
AA41
R41
M41
E41
BD40
AU40
AR40
AN40
W40
U40
T40
R40
K40
H40
BL39
BG39
BA39
E39
C39
A39
BD38
AU38
H38
BG37
AU37
M37
E37
BD36
AW36
H36
BL35
BG35
AY35
AU35
AL35
AG35
AE35
AA35
Y35
M35
E35
A35
BD34
AU34
AN34
H34
BL33
BG33
AY33
E33
BD32
AU32
AN32
AG32
AC32
Y32
H32
B32
BJ31
BG31
AY31
AN31
M31
E31
N30
H30
AN29
AJ29
M29
A29
AW28
AN28
AD28
AC28
Y28
W28
H28
F28
AN27
AJ27
M27
BF26
BD26
N26
H26
BJ25
AY25
AU25

3

U18J

U18J

AN25

VSS_199

AG25

VSS_200

AE25

VSS_201

AA25

VSS_202

Y25

VSS_203

E25

VSS_204

A25

VSS_205

BD24

VSS_206

AN24

VSS_207

AL24

VSS_208

H24

VSS_209

BG23

VSS_210

AY23

VSS_211

E23

VSS_212

BD22

VSS_213

BB22

VSS_214

AN22

VSS_215

Y22

VSS_216

W22

VSS_217

H22

VSS_218

BL21

VSS_219

BG21

VSS_220

AY21

VSS_221

AN21

VSS_222

AG21

VSS_223

AE21

VSS_224

M21

VSS_225

E21

VSS_226

A21

VSS_227

BD20

VSS_228

H20

VSS_229

BG19

AY19

M19
E19

BD18

N18
H18

BL17

BG17

AY17

M17
E17

A17
BD16
AN16
AG16

AE16

Y16

W16

N16

H16
BG15

AY15
AN15
AD15
AC15

R15
M15
E15

BD14

H14

BL13
BG13

AY13
AU13
AR13

AJ13
AC13

AA13

W13

U13
M13
E13
A13

BD12

AV12

AP12
AM12

AK12

AB12

V12
P12

H12
BG11
AG11

E11
BD10

AY10
AP10

H10

BL9

BG9

E9

A9
BD8
BB8
AY8
AV8
AT8
AP8

3

VSS_230
VSS_231
VSS_232
VSS_233
VSS_234
VSS_235
VSS_236
VSS_237
VSS_238
VSS_239
VSS_240
VSS_241
VSS_242
VSS_243
VSS_244
VSS_245
VSS_246
VSS_247
VSS_248
VSS_249
VSS_250
VSS_251
VSS_252
VSS_253
VSS_254
VSS_255
VSS_256
VSS_257
VSS_258
VSS_259
VSS_260
VSS_261
VSS_262
VSS_263
VSS_264
VSS_265
VSS_266
VSS_267
VSS_268
VSS_269
VSS_270
VSS_271
VSS_272
VSS_273
VSS_274
VSS_275
VSS_276
VSS_277
VSS_278
VSS_279
VSS_280
VSS_281
VSS_282
VSS_283
VSS_284
VSS_285
VSS_286
VSS_287
VSS_288
VSS_289
VSS_290
VSS_291
VSS_292
VSS_293
VSS_294
VSS_295
VSS_296
VSS_297
VSS_298
VSS_299

CANTIGASFF_1p0

CANTIGASFF_1p0

VSS

VSS

VSS NCTF

VSS NCTF

VSS SCB

VSS SCB

VSS_300
VSS_301
VSS_302
VSS_303
VSS_304
VSS_305
VSS_306
VSS_307
VSS_308
VSS_309
VSS_310
VSS_311
VSS_312
VSS_313
VSS_314
VSS_315
VSS_316
VSS_317
VSS_318
VSS_319
VSS_320
VSS_321
VSS_322
VSS_323
VSS_324
VSS_325
VSS_326
VSS_327
VSS_328
VSS_329
VSS_330
VSS_331
VSS_332
VSS_333
VSS_334
VSS_335
VSS_336
VSS_337
VSS_338
VSS_339
VSS_340
VSS_341
VSS_342
VSS_343
VSS_344
VSS_345
VSS_346
VSS_347
VSS_348
VSS_349
VSS_350
VSS_351
VSS_352
VSS_353
VSS_354
VSS_355
VSS_356
VSS_357
VSS_358

VSS_359
VSS_360
VSS_361
VSS_362

VSS_NCTF_1
VSS_NCTF_2
VSS_NCTF_3
VSS_NCTF_4
VSS_NCTF_5
VSS_NCTF_6
VSS_NCTF_7
VSS_NCTF_8

VSS_NCTF_9
VSS_NCTF_10
VSS_NCTF_11
VSS_NCTF_12
VSS_NCTF_13
VSS_NCTF_14
VSS_NCTF_15
VSS_NCTF_16
VSS_NCTF_17
VSS_NCTF_18
VSS_NCTF_19
VSS_NCTF_20
VSS_NCTF_21
VSS_NCTF_22
VSS_NCTF_23

VSS_SCB_1
VSS_SCB_2
VSS_SCB_3
VSS_SCB_4
VSS_SCB_5
VSS_SCB_6
VSS_SCB_7

AM8
AK8
AH8
AF8
AD8
AB8
Y8
V8
P8
M8
K8
H8
BJ7
E7
BF6
BC5
BA5
AW5
AU5
AR5
AN5
AL5
AJ5
AG5
AE5
AC5
AA5
W5
U5
N5
L5
J5
G5
C5
BH4
BE3
U3
E3
BC1
AW1
AR1
AL1
AG1
AC1
W1
N1
J1
AU43
BB42
AW38
BA35
L29
N28
N22
N20
N14
AL13
B10
AN13

N42
N40
N38
M39

AJ38
AH38
AD38
AC38
T35
R35
AT32
AR32
U32
R32
T28
R28
AT25
AR25
T24
R24
AN19
AJ19
AA19
Y19
T19
R19
AN18

BL55
BL1
A55
D1
B55
B2
A4

2

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Cantiga SFF (GND)

Cantiga SFF (GND)

Cantiga SFF (GND)

Date: Sheet

Date: Sheet

2

Date: Sheet

PROJECT :

1

ZE8

ZE8

ZE8

1A

1A

11 32Tuesday, September 29, 2009

11 32Tuesday, September 29, 2009

11 32Tuesday, September 29, 2009

of

of

1

of

1A

1

2

3

4

5

6

7

8

RTC CRYSTAL

U19A

ICH_RTCX1
ICH_RTCX2

ICH_RTCRST#
ICH_SRTCRST#
ICH_INTRUDER#

ICH_INTVRMEN

ICH_GPIO56

GLAN_COMP

ACZ_BIT_CLK
ACZ_SYNC

ACZ_RST#

ACZ_SDIN0

HDA_SDIN1

ACZ_SDOUT

SATA_LED#

ICH_INTRUDER#

ICH_INTVRMEN

SATA_RXN0_C
SATA_RXP0_C
SATA_TXN0_C
SATA_TXP0_C

R302

R302

10M_6

10M_6

ICH_RTCX1

ICH_RTCX2

(Internal VRM enabled for VccSus1_05, VccSus1_5,
VccCL1_5, VccLAN1_05 and VccCL1_05)

ICH_INTVRMEN

Low = Internal VR Disabled
High = Internal VR Enabled(Default)

C440 15p/50V_4C440 15p/50V_4

AA

C439 15p/50V_4C439 15p/50V_4

41

32.768KHZY332.768KHZ

Y3

2 3

32.768KHZ

RESET JUMP

An RC delay circuit with a time delay in the range

+VCCRTC

BB

+VCCRTC

HD Audio Interface

ACZ_BIT_CLK

CC

of 18 ms to 25 ms should be provided

R268 20K_6R268 20K_6

R267 20K_6R267 20K_6

R45 HD@33_4R45 HD@33_4
R46 33_4R46 33_4

C425

C425

1u/6.3V_4

1u/6.3V_4

C419

C419

1u/6.3V_4

1u/6.3V_4

ICH_RTCRST#

G3

G3

*SHORT_ PAD

*SHORT_ PAD

ICH_SRTCRST#

G2

G2

*SHORT_ PAD

*SHORT_ PAD

C22 *10p/50V_4C22 *10p/50V_4

C28 *10p/50V_4C28 *10p/50V_4

HDA_BIT_CLK_HDMI (7)

ACZ_BITCLK_AUDIO (17)

ICH_SATA_LED#

0 PCIe Lane Reversed

PCIe Straight(default)

1

SATA_RXN0_ICH(20)
SATA_RXP0_ICH(20)
SATA_TXN0_ICH(20)
SATA_TXP0_ICH(20)

+VCCRTC

(DG 1.0 Table-292)

ACZ_SDIN0(17)

SATA_LED#(21)

SATA_RXN0_ICH
SATA_RXP0_ICH
SATA_TXN0_ICH
SATA_TXP0_ICH

R71 1M_4R71 1M_4

R74 332K/F_4R74 332K/F_4

C399 0.01u/25V_4C399 0.01u/25V_4
C468 0.01u/25V_4C468 0.01u/25V_4
C469 0.01u/25V_4C469 0.01u/25V_4
C470 0.01u/25V_4C470 0.01u/25V_4

Internal VRM enabled for
VccSus1_05, VccSus1_5,
VccCL1_5, VccLAN1_05 and
VccCL1_05.

layout notice : please near NB codec

HDA_SDIN1

ACZ_SYNC

R85 HD@33_4R85 HD@33_4

R42 HD@33_4R42 HD@33_4
R40 33_4R40 33_4

HDA_SDIN_HDMI (7)

HDA_SYNC_HDMI (7)

ACZ_SYNC_AUDIO (17)

ACZ_RST#

ACZ_SDOUT

R44 HD@33_4R44 HD@33_4
R43 33_4R43 33_4

R33 HD@33_4R33 HD@33_4
R34 33_4R34 33_4

HDA_RST#_HDMI (7)
ACZ_RESET#_AUDIO (17)

HDA_SDOUT_HDMI (7)
ACZ_SDOUT_AUDIO (17)

South Bridge Strap Pin (1/3)

2

Sampled

PWROK

PWROK

PWROK

PWROK

Configuration PU/PD

0 = The Flash Descriptor Security will be overridden.
1 = The security measures defined
in the Flash Descriptor will be in effect

Internal PU

HDA_SDOUT

ICH_TP3

0

0

0

1

01

11

Description

RSVD

Enter XOR Chain

Normal opration(Default)

Set PCIE port config bit 1

3

This strap should only be enabled in manufacturing
environments using an external pull-up resistor.

ICH_TP3(14)

HDA_IO_ICH

4

Pin Name

HDA_DOCK_EN/
GPIO33

DD

SATALED#

Strap description

Flash Descriptor Security
Override Strap

PCI Express Lane Reversal
(Lanes 1-4)

XOR Chain Entrance

HDA_SDOUT

XOR Chain Entrance /PCI Express*
Port Config 1 bit 1(Port 1-4)

1

U19A

F25

RTCX1

G25

RTCX2

G24

RTCRST#

C24

SRTCRST#

C23

INTRUDER#

E25

INTVRMEN

D25

LAN100_SLP

G22

GLAN_CLK

D14

LAN_RSTSYNC

A14

LAN_RXD0

D12

LAN_RXD1

B14

LAN_RXD2

D13

LAN_TXD0

C13

LAN_TXD1

A13

LAN_TXD2

D15

GPIO56

H22

GLAN_COMPI

H21

GLAN_COMPO

AE7

HDA_BIT_CLK

AB7

HDA_SYNC

AA7

HDA_RST#

AB6

HDA_SDIN0

AE6

HDA_SDIN1

AC6

HDA_SDIN2

AA5

HDA_SDIN3

AC7

HDA_SDOUT

AD8

HDA_DOCK_EN#/GPIO33

AB8

HDA_DOCK_RST#/GPIO34

AC9

SATALED#

AE14

SATA0RXN

AD14

SATA0RXP

AC15

SATA0TXN

AD15

SATA0TXP

AD13

SATA1RXN

AC13

SATA1RXP

AA14

SATA1TXN

AB14

SATA1TXP

ICH9MSFF REV 1.0

ICH9MSFF REV 1.0

+3V_S5

R58 10K_4R58 10K_4

+1.5V

R75 24.9/F_4R75 24.9/F_4

24.9 Ohm pull up to 1.5V for
GLAN_COMPI/O is required, no
matter intel LAN is used or not.

ICH_TP3

R316 *1K_4R316 *1 K_4

R37 *1K_4R37 *1K_4

R36 *1K_4R36 *1 K_4

RTCLAN / GLAN

RTCLAN / GLAN

IHDA

IHDA

SATA

SATA

ACZ_SDOUT

ACZ_SYNC

5

H3

FWH0/LAD0

J3

FWH1/LAD1

K5

FWH2/LAD2

L3

FWH3/LAD3

LDRQ0#

A20GATE

A20M#

DPRSTP#

DPSLP#

FERR#

CPUPWRGD

IGNNE#

INIT#
INTR

RCIN#

NMI

SMI#

STPCLK#

THRMTRIP#

TP11

SATA4RXN

SATA4RXP
SATA4TXN
SATA4TXP

SATA5RXN

SATA5RXP
SATA5TXN
SATA5TXP

SATA_CLKN
SATA_CLKP

SATARBIAS#

SATARBIAS

J2

H1
J1

N3
AB23

AE23
AE24

AD25

AE22

AD23

AE21
AD24
L1

AD21
AC21

AC25

AC23

AC22

AD12
AE12
AB12
AA12

AC11
AD11
AB10
AA10

AC16
AB16

AD10
AE10

FWH4/LFRAME#

LPCCPU

LPCCPU

LDRQ1#/GPIO23

RTC BATTERY (RTC)

ICH_GPIO56

GLAN_COMP

intel design guide: pull high 3.3k

GA20

H_DPRSTP#
H_DPSLP#

H_FERR#_R

RCIN#

H_THERMTRIP_R

SATABIAS

Place within 500mils of ICH9 ball

ICH9M SFF - Host,SATA,HDA (CLG)

LAD0 (18,19)
LAD1 (18,19)

R306 56_4R306 56_4

R311 54.9/F_4R311 54.9/F_4

R332 24.9/F_4R332 24.9/F_4

(20mils)

(20mils)

R_3VRTC

R47

R47

(20mils)

1K_4

1K_4

RTC_N02

12

CN14

CN14
RTC_CONN

RTC_CONN

6

LAD2 (18,19)
LAD3 (18,19)

LFRAME# (18,19)

GA20 (18)
H_A20M# (4)

H_PWRGOOD (4)

H_IGNNE# (4)

H_INIT# (4)
H_INTR (4)
RCIN# (18)

H_NMI (4)
H_SMI# (4)

H_STPCLK# (4)

PECLK_SATA# (3)
PECLK_SATA (3)

D10 CH500H-40PTD10 CH500H-40PT

D9 CH500H-40PTD9 CH500H-40PT

R50 4.7K_4R50 4.7K_4

1 3

Q2

Q2

2

MMBT3904-7-F

MMBT3904-7-F

(20mils)

+1.05V

R307

R305

R305

*56_4

*56_4

R307

56_4

56_4

GA20

RCIN#

H_DPRSTP# (4 ,7,25)
H_DPSLP# (4)

H_FERR# (4)

R339 *8.2K_4R339 *8.2K_4

R340 *10K_4R340 *10K_4

+1.05V

R304

R304

*56_4

*56_4

R310

R310

56_4

56_4

R308 *0_4R308 *0_4

+VCCRTC+3VPCU

(30mils)

C25

C25

1u/10V_6

1u/10V_6

R54 4.7K_4R54 4.7K_4

RTC_N03

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

ICH9M SFF (Host/SATA/HDA )

ICH9M SFF (Host/SATA/HDA )

ICH9M SFF (Host/SATA/HDA )

Date: Sheet

Date: Sheet

Date: Sheet

7

(20mils)

R56

R56

68.1K/F_4

68.1K/F_4

R55 150K/F_4R55 150K/F_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

PM_THRMTRIP# (4,7)

+5V_S5

ZE8

ZE8

ZE8

12 32Tuesday, September 29, 2009

12 32Tuesday, September 29, 2009

12 32Tuesday, September 29, 2009

8

+3V

1A

1A

1A

of

of

of

1

2

3

4

5

6

7

8

ICH9M SFF - USB/PCIE/DMI (CLG)

U19B

U19B

A11

AD0

B12
A10

C12

A8

A12

AA

INTA#_R

BB

INTB#_R
INTC#_R
INTD#_R

E10

C11

B9
D8
A4
E8
A3
D9
C8
C2
D7
B3

D11

B6
D5
D3

F4
E3
E4
B2
C4
C1
D1
E2

J4
H2

F1

F5

F2
C7

PCI

PCI

AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
AD9
AD10
AD11
AD12
AD13
AD14
AD15
AD16
AD17
AD18
AD19
AD20
AD21
AD22
AD23
AD24
AD25
AD26
AD27
AD28
AD29
AD30
AD31

Interrupt I/F

Interrupt I/F

PIRQA#
PIRQB#
PIRQC#
PIRQD#

ICH9MSFF REV 1.0

ICH9MSFF REV 1.0

PCI_PLTRST#

REQ0#

GNT0#
REQ1#/GPIO50
GNT1#/GPIO51
REQ2#/GPIO52
GNT2#/GPIO53
REQ3#/GPIO54
GNT3#/GPIO55

C/BE0#

C/BE1#

C/BE2#

C/BE3#

IRDY#

PCIRST#

DEVSEL#

PERR#

PLOCK#

SERR#

STOP#

TRDY#

FRAME#

PLTRST#

PCICLK

PME#

PIRQE#/GPIO2

PIRQF#/GPIO3
PIRQG#/GPIO4
PIRQH#/GPIO5

PAR

G4
E1
A9
E12
B11
C10
D6
C6

D10
A5
E6
C9

C3
B1
T3
A7
D4
C5
H5
A6
A2
B8

A21
B5
T1

G3
G1
F3
H4

2

1

REQ0#

GNT0#

REQ1#

REQ2#
GNT2#
REQ3#
GNT3#

IRDY#

DEVSEL#
PERR#
LOCK#
SERR#
STOP#
TRDY#
FRAME#

PCI_PLTRST#
PCLK_ICH

G_SENSOR_INT#
INTF#
INTG#
INTH#

+3V_S5

3 5

U3

U3

TC7SH08FU(F)

TC7SH08FU(F)

4

C48

C48

0.1u/10V_4

0.1u/10V_4

LAN

Mini Card (Wi-Fi)

Mini card (3G)

PCLK_ICH (3)

G_SENSOR_INT# (21)

PLTRST# (7,18,19,21)

R62

R62

100K_6

100K_6

Place TX DC blocking caps close ICH9.

PCIE_RXN1(21)
PCIE_RXP1(21)
PCIE_TXN1(21)
PCIE_TXP1(21)

PCIE_RXN6(19)
PCIE_RXP6(19)
PCIE_TXN6(19)
PCIE_TXP6(19)

PCIE_RXN5(19)
PCIE_RXP5(19)
PCIE_TXN5(19)
PCIE_TXP5(19)

C77 0.1U/10V_4C77 0.1U/10V_4

1 2

C76 0.1U/10V_4C76 0.1U/10V_4

1 2

C80 0.1U/10V_4C80 0.1U/10V_4

1 2

C79 0.1U/10V_4C79 0.1U/10V_4

1 2

C81 0.1U/10V_4C81 0.1U/10V_4

1 2

C78 0.1U/10V_4C78 0.1U/10V_4

1 2

PCIE_TXN1_C
PCIE_TXP1_C

PCIE_TXN6_C
PCIE_TXP6_C

PCIE_TXN5_C
PCIE_TXP5_C

SPI_CS1#

SPI_MOSI

USBOC0#
USBOC1#
USBOC2#
USBOC3#
USBOC4#
USBOC5#
USBOC6#
USBOC7#
USBOC8#
USBOC9#
USBOC10#
USBOC11#

USBRBIAS

R336

R336

22.6/F_4

22.6/F_4

1 2

U19D

U19D

T25

PERN1

T24

PERP1

R24

PETN1

R23

PETP1

P25

PERN2

P24

PERP2

P21

PETN2

P22

PETP2

N23

PERN3

N24

PERP3

M21

PETN3

M22

PETP3

M25

PERN4

M24

PERP4

L24

PETN4

L23

PETP4

K24

PERN5

K25

PERP5

K21

PETN5

K22

PETP5

H24

PERN6/GLAN_RXN

H25

PERP6/GLAN_RXP

J24

PETN6/GLAN_TXN

J23

PETP6/GLAN_TXP

E24

SPI_CLK

E23

SPI_CS0#

F23

SPI_CS1#/GPIO58/CLGPIO6

F22

SPI_MOSI

G23

SPI_MISO

P4

OC0#/GPIO59

N4

OC1#/GPIO40

N1

OC2#/GPIO41

P5

OC3#/GPIO42

P1

OC4#/GPIO43

P2

OC5#/GPIO29

M3

OC6#/GPIO30

M2

OC7#/GPIO31

P3

OC8#/GPIO44

R1

OC9#/GPIO45

R4

OC10#/GPIO46

R2

OC11#/GPIO47

AE5

USBRBIAS

AD5

USBRBIAS#

ICH9MSFF REV 1.0

ICH9MSFF REV 1.0

USB

USB

DMI0RXN
DMI0RXP

DMI0TXN
DMI0TXP

DMI1RXN
DMI1RXP

DMI1TXN
DMI1TXP

DMI2RXN
DMI2RXP

DMI2TXN
DMI2TXP

DMI3RXN
DMI3RXP

DMI3TXN
DMI3TXP

DMI_CLKN

PCI-Express

PCI-Express

DMI_CLKP

Direct Media Interface

Direct Media Interface

DMI_ZCOMP

DMI_IRCOMP

SPI

SPI

USBP10N
USBP10P
USBP11N
USBP11P

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N
USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P
USBP9N
USBP9P

V25
V24
U24
U23

W23
W24
V21
V22

Y24
Y25
Y21
Y22

AB24
AB25
AA23
AA24

T21
T22

AB21
AB22

AE2
AD1
AD3
AD4
AC2
AC3
AC5
AB4
AB2
AB1
AA3
AA2
Y1
Y2
W2
W3
V1
V2
Y5
Y4
U3
U2
V4
V5

DMI_COMP

DMI_MTX_IRX_N0 (7)
DMI_MTX_IRX_P0 (7)

DMI_MRX_ITX_N0 (7)
DMI_MRX_ITX_P0 (7)

DMI_MTX_IRX_N1 (7)
DMI_MTX_IRX_P1 (7)

DMI_MRX_ITX_N1 (7)
DMI_MRX_ITX_P1 (7)

DMI_MTX_IRX_N2 (7)
DMI_MTX_IRX_P2 (7)

DMI_MRX_ITX_N2 (7)
DMI_MRX_ITX_P2 (7)

DMI_MTX_IRX_N3 (7)
DMI_MTX_IRX_P3 (7)

DMI_MRX_ITX_N3 (7)
DMI_MRX_ITX_P3 (7)

PECLK_ICH# (3)
PECLK_ICH (3)

R52 24.9/F_4R52 24.9/F_4

1 2

USBP0- (21)
USBP0+ (21)
USBP1- (21)

USBP1+ (21)
USBP2- (19)
USBP2+ (19)
USBP3- (21)
USBP3+ (21)

USBP4- (19)

USBP4+ (19)
USBP5- (21)
USBP5+ (21)

USBP6- (20)

USBP6+ (20)

USBP7- (22)

USBP7+ (22)

USBP8- (22)

USBP8+ (22)

Place within

+1.5V

500mils of ICH9

USB2

USB3

Mini2(3G)

Cardreader

Mini1

BT

MB USB1

CCD

LED touch panel

CC

South Bridge Stra

Pin Name Strap description

HDA_SYNC

GNT2# / GPIO53

GNT1# / GPIO51

GNT3# / GPIO55

SPI_MOSI

DD

GNT0#

SPI_CS1# /
GPIO58 / CLGPIO6

1

p Pin (2/3)

PCI Express Port
Config 1 bit 0 (Port 1-4)

PCI Express Port
Config 2 bit 2 (Port 5-6)

ESI Strap(Server Only)

Top-Block Swap Override

Integrated TPM Enable

Boot BIOS Selection 0

PCI PULL-UP

Sampled

PWROK

PWROK

PWROK

PWROK

CLPWROK

PWROK

CLPWROKBoot BIOS Selection 1

2

Configuration PU/PD

0 = Default
1 = Setting bit 0

0 = Setting bit 2
1 = Default

0 = DMI for ESI-compatible
1 = Default

0 = "top-block swap" mode
1 = Default

0 = INT TPM disable(Default)
1 = INT TPM enable

10

01

Boot Location

SPI(Default)

PCI

SPI_CS#1PCI_GNT#0

3

GNT2#

8/28 : add pull high resister R160
in GNT3# pin for no video issue.

GNT3#

T3T3

SPI_MOSI

GNT0#

SPI_CS1#

4

R160 10K_4R160 10K_4

RP15

RP15

6
7
8
9

10

G_SENSOR_INT#

5

+3V

IRDY#
INTB#_R

+3V

INTH#

INTF#

INTC#_R

+3V

T20T20

+3V

T18T18

T21T21

T19T19

6
7
8
9

10

6
7
8
9

10

8.2KX8

8.2KX8

RP18

RP18

8.2KX8

8.2KX8

RP17

RP17

8.2KX8

8.2KX8

+3V

5

REQ2#

4

REQ1#

3

INTD#_RDEVSEL#

2

FRAME#

1

+3V

5

REQ3#TRDY#

4

SERR#

3

STOP#

2

LOCK#

1

+3V

5

PERR#

4

REQ0#

3

INTG#

2

INTA#_R

1

6

USBOC# PULL-UP

RP1

RP1

USBOC7#

+3V_S5

USBOC10#
USBOC11#
USBOC9#
USBOC8#

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

ICH9M SFF (USB/PCIE/DMI )

ICH9M SFF (USB/PCIE/DMI )

ICH9M SFF (USB/PCIE/DMI )

Date: Sheet

Date: Sheet of

Date: Sheet of

7

8

USBOC5#

9

10

10KX8

10KX8

6
4
2

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

6

USBOC1#

7

USBOC6#

RP16

RP16

10KX4

10KX4

5

USBOC3#

4

USBOC0#

3

USBOC4#

2

USBOC2#

1

78
5
3
1

ZE8

ZE8

ZE8

13 32Tuesday, September 29, 2009

13 32Tuesday, September 29, 2009

13 32Tuesday, September 29, 2009

+3V_S5

+3V_S5

of

8

1A

1A

1A

1

+3V_S5

R326 2.2K_4R326 2.2K_4

R327 2.2K_4R327 2.2K_4

R315 10K_4R315 10K_4

R48 10K_4R48 10K_4

AA

BB

R68 10K_4R68 10K_4

R321 10K_4R321 10K_4

R76 10K_4R76 10K_4

R312 10K_4R312 10K_4

R63 10K_4R63 10K_4

R67 *10K_4R67 *10K_4

R335 8.2K_4R335 8.2K_4

R338 *10K_4R338 *10K_4

R337 10K_4R337 10K_4

R59 10K_4R59 10K_4

+3V

R28 8.2K_4R28 8.2K_4

R29 10K_4R29 10K_4

R314 8.2K_4R314 8.2K_4

R329 10K_4R329 10K_4

R51 10K_4R51 10K_4

R323 10K_4R323 10K_4

R328 10K_4R328 10K_4

R57 10K_4R57 10K_4

R322 10K_4R322 10K_4

R53 10K_4R53 10K_4

R333 100K_4R333 100K_4

PCLK_SMB

PDAT_SMB

ICH_GPIO60

SMB_CLK_ME

SMB_DATA_ME

RI#

SYS_RST#

ICH_GPIO11

PCIE_WAKE#

EC_SCI#

PM_BATLOW#

DNBSWON#

ICH_GPIO12

ICH_GPIO13

CLKRUN#

SERIRQ

THERM_ALERT#

EC_SMI#

ICH_GPIO19

LID_touch panel#

ICH_GPIO39

ICH_GPIO48

LID#_ICH

ICH_GPIO38

ICH_GPIO57

2

3

4

5

6

7

8

ICH9M SFF - PM/GPIO/SMB (CLG)

U19C

PCLK_SMB(3,19)
PDAT_SMB(3,19)

SYS_RST#(4)

PM_SYNC#(7) SUSC# (18)

PM_STPPCI#(3)
PM_STPCPU#(3)

CLKRUN#(18)

PCIE_WAKE#(21)
SERIRQ(18)

THERM_ALERT#(4)

LID#(18,21,22)

D28 BAS316D28 BAS316

EC_SMI#(18)

LID_touch panel#(18,21)

EC_SCI#(18)

CLKREQ#_SATA(3)

SB_BEEP(17)

MCH_ICH_SYNC#(7)

ICH_TP3(12)

PCLK_SMB
PDAT_SMB
ICH_GPIO60
SMB_CLK_ME
SMB_DATA_ME

RI#

SYS_RST#

ICH_GPIO11

PM_STPPCI#
PM_STPCPU#

CLKRUN#

PCIE_WAKE#
SERIRQ
THERM_ALERT#

VR_PWRGD_CLKEN

EC_SMI#
LID#_ICHLID#
LID_touch panel#
EC_SCI#
ICH_GPIO12
ICH_GPIO13
BOARD_ID0
BOARD_ID1

BOARD_ID3

CLKREQ#_SATA
ICH_GPIO38
ICH_GPIO39
ICH_GPIO48
DMI_TERM_SEL
ICH_GPIO57

SB_BEEP
MCH_ICH_SYNC#

U19C

C18

SMBCLK

C15

SMBDATA

B21

LINKALERT#/GPIO60/CLGPIO4

E18

SMLINK0

A24

SMLINK1

C20

RI#

T5

SUS_STAT#/LPCPD#

C25

SYS_RESET#

L2

PMSYNC#/GPIO0

A23

SMBALERT#/GPIO11

B15

STP_PCI#/GPIO15

A20

STP_CPU#/GPIO25

M5

CLKRUN#/GPIO32

C21

WAKE#

L4

SERIRQ

AD20

THRM#

B24

VRMPWRGD

A19

TP12

AE16

GPIO1

AE18

GPIO6

AD18

GPIO7

B25

GPIO8

C14

GPIO12

D20

GPIO13

AE17

GPIO17

K3

GPIO18

AC8

GPIO20

AC19

SCLOCK/GPIO22

D17

GPIO27

E20

GPIO28

M4

SATACLKREQ#/GPIO35

AB18

SLOAD/GPIO38

AC18

SDATAOUT0/GPIO39

AB19

SDATAOUT1/GPIO48

AC20

GPIO49

A16

GPIO57/CLGPIO5

K4

SPKR

AB20

MCH_SYNC#

C19

TP3

AB17

TP8

AC17

TP9

AD17

TP10

ICH9MSFF REV 1.0

ICH9MSFF REV 1.0

SATA0GP/GPIO21
SATA1GP/GPIO19
SATA4GP/GPIO36
SATA5GP/GPIO37

SATA

GPIO

SATA

GPIO

SMB

SMB

Clocks

Clocks

S4_STATE#/GPIO26

DPRSLPVR/GPIO16

SYS GPIO

SYS GPIO

Power MGTController Link

Power MGTController Link

GPIO

GPIO

MEM_LED/GPIO24

GPIO10/SUS_PWR_ACK

GPIO14/AC_PRESENT

WOL_EN/GPIO9

MISC

MISC

CLK14
CLK48

SUSCLK

SLP_S3#
SLP_S4#
SLP_S5#

PWROK

BATLOW#

PWRBTN#

LAN_RST#

RSMRST#

CK_PWRGD

CLPWROK

SLP_M#

CL_CLK0
CL_CLK1

CL_DATA0
CL_DATA1

CL_VREF0
CL_VREF1

CL_RST0#
CL_RST1#

BOARD_ID2

AE19

ICH_GPIO19

AA18

ICH_GPIO36

AE20

ICH_GPIO37

AA20

CLK14_ICH

K1

CLK48_ICH

AB5

R3

D18
B20
D16

E14

ICH_PWRGD

D23

DPRSLPVR

M1

PM_BATLOW#

C16

U4

PM_LAN_ENABLE_R

D22

PM_RSMRST#_R

D19

VR_PWRGD_CK410

U1

MPWROK

T4

B23

C22
A18

E22
B18

CL_VREF0_SB

F21

CL_VREF1_SB

A17

C17
B17

A22

ICH_GPIO10

E16

ICH_GPIO14

A15

ICH_GPIO9

D21

DPRSLPVR (7,25)

DNBSWON# (18)

R303 Short_4R303 Short_4

VR_PWRGD_CK410 (3)

MPWROK (7,18)

CL_CLK0 (7)

CL_DATA0 (7)

ICH_CL_RST0# (7)

R49 10K_4R49 10K_4
R334 10K_4R334 10K_4
R60 10K_4R60 10K_4

R313 10K_4R313 10K_4
R61 10K_4R61 10K_4

CLK14_ICH (3)
CLK48_ICH (3)

SUSB# (18)

+3V_S5

+3V

+3V +3V

R70

R70

3.24K/F_4

3.24K/F_4

C57

C57

0.1u/10V_4

0.1u/10V_4

1 2

12

R72

R72

453/F_4

453/F_4

12

C441

C441

*0.47u_6.3V_4

*0.47u_6.3V_4

CL_VREF0_SB CL_VREF1_SB

12

R331

R331
*3.24K/F_4

*3.24K/F_4

1 2

12

R330

R330

*453/F_4

*453/F_4

CC

C59 *0.1u/10V_4C59 *0.1u/10V_4

VR_PWRGD_CK410#(25)

South Bridge Stra

p Pin (3/3)

Pin Name Strap description

DD

GPIO20

PCBEEP

GPIO49

Reserved PW ROK

No Reboot PWROK

DMI Termination
Voltage

1

VR_PWRGD_CK410#

Sampled

PWROK

+3V

U4

U4

1

5

2

74LVC1G04GW

74LVC1G04GW

43

VR_PWRGD_CLKEN

R69

R69

100K_4

100K_4

Configuration PU/PD

0 = Default
1 = No Reboot mode

0 = for desktop applications
1 = for mobile applications
Internal PU

2

DMI_TERM_SEL

3

+3V +3V +3V +3V

R317

R319

R319
*10K_4

*10K_4

BOARD_ID3

R320

R320
10K_4

10K_4

T6T6

4

R317
*10K_4

*10K_4

BOARD_ID2

R318

R318
10K_4

10K_4

DELAY_VR_PWRGOOD(4,7,25)

PWROK_EC(18)

R324

R27

R27
*10K_4

*10K_4

BOARD_ID1 BOARD_ID0

R30

R30
10K_4

10K_4

5

R324
*10K_4

*10K_4

R325

R325
10K_4

10K_4

DELAY_VR_PWRGOOD

R66 100K_4R66 100K_4

1

2

+3V_S5

53

4

U5

U5

TC7SH08FU(F)

TC7SH08FU(F)

PM_RSMRST#_R

0.1u/16V_4C58 0.1u/16V_4C58

ICH_PWRGD

R73

R73

10K_4

10K_4

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

ICH9M SFF (PM/GPIO/SMB )

ICH9M SFF (PM/GPIO/SMB )

ICH9M SFF (PM/GPIO/SMB )

Date: Sheet

Date: Sheet

6

Date: Sheet

7

3 1

Q1 MMBT3906_NLQ1 MMBT3906_NL

2

R31

R31
10K_4

10K_4

2

D5

3

BAV99D5BAV99

1

2

D6

3

BAV99D6BAV99

R26

R26

1

2.2K_4

2.2K_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

EC_RSMRST# (18)

R41 4.7K_4R41 4.7K_4

ZE8

ZE8

ZE8

+3V_S5

1A

1A

1A

of

of

of

14 32Tuesday, September 29, 2009

14 32Tuesday, September 29, 2009

14 32Tuesday, September 29, 2009

8

1

ICH9M SFF - Power/GND (CLG)

+3V+5V

21

12

D8

D8

R35

R35

SDMK0340L-7-F

SDMK0340L-7-F

100_4

100_4

AA

+5V_S5 +3V_S5

+1.5V

BB

2mA

21

R38

R38

D7

D7

10_4

10_4

SDMK0340L-7-F

SDMK0340L-7-F

1 2

2mA

C20

C20

0.1U/10V_4

0.1U/10V_4

1 2

FB_330ohm+-25%_100mHz_

1.5A_0.09 ohm DC

646mA

L7 BLM21PG331SN1DL7 BLM21PG331SN1D

1.342A

CC

+3V

19mA

C44

DD

C44

0.1U/10V_4

0.1U/10V_4

1 2

1

+1.5V

C38 0.1U/10V_4C38 0.1U/10V_4

+1.5V

L6 1uH_8L6 1uH_8

23mA

+VCCRTC

C53

C53

1U/6.3V_4

1U/6.3V_4

1 2

+ICH_V5REF_RUN+ICH_V5REF_RUN+ICH_V5REF_RUN+ICH_V5REF_RUN

12

C19

C19

1U/10V_6

1U/10V_6

+ICH_V5REF_SUS

+1.5V_PCIE_ICH

12

C50

C50

10U/6.3V_6

10U/6.3V_6

10uH+-20%_100mA

L5 10uH_8L5 10uH_8

12

+1.5V

80mA

+V1.5S_APLL_ICH

12

1 2

+V1.5S_ICH_GLANPLL_R_L

C66

C66

10U/6.3V_6

10U/6.3V_6

2

C46

C46

0.1U/10V_4

0.1U/10V_4

1 2

12

C49

C49

*10U/6.3V_6

*10U/6.3V_6

C54

C54

1 2

10U/6.3V_6

10U/6.3V_6

1 2

C34

C34

0.1U/10V_4

0.1U/10V_4

+1.5V

1 2

C29

C29

0.1U/10V_4

0.1U/10V_4

1 2

C32

C32

0.1U/10V_4

0.1U/10V_4

1 2

VCCLAN1_05_INT_ICH

C52

C52

10U/6.3V_6

10U/6.3V_6

2

1 2

C56

C56

0.1U/10V_4

0.1U/10V_4

C40

C40

0.1U/10V_4

0.1U/10V_4

C39

C39

0.1U/10V_4

0.1U/10V_4

C65

C65

2.2U/6.3V_4

2.2U/6.3V_4

+3V

C51

C51

0.1U/10V_4

0.1U/10V_4

47mA

11mA

1mA

U19F

U19F

G17

VCCRTC

G7

V5REF

U7

V5REF_SUS

J19

VCC1_5_B[01]

K18

VCC1_5_B[02]

K19

VCC1_5_B[03]

L18

VCC1_5_B[04]

L19

VCC1_5_B[05]

M18

VCC1_5_B[06]

M19

VCC1_5_B[07]

N18

VCC1_5_B[08]

N19

VCC1_5_B[09]

P18

VCC1_5_B[10]

R18

VCC1_5_B[11]

T18

VCC1_5_B[12]

T19

VCC1_5_B[13]

U18

VCC1_5_B[14]

U19

VCC1_5_B[15]

W17

VCCSATAPLL

U13

VCC1_5_A[01]

V13

VCC1_5_A[02]

W13

VCC1_5_A[03]

U12

VCC1_5_A[04]

V12

VCC1_5_A[05]

W12

VCC1_5_A[06]

W10

VCC1_5_A[07]

U15

VCC1_5_A[08]

V15

VCC1_5_A[09]

W18

VCC1_5_A[10]

G9

VCC1_5_A[11]

H9

VCC1_5_A[12]

V11

VCC1_5_A[13]

U11

VCC1_5_A[14]

U8

VCCUSBPLL

T9

VCC1_5_A[15]

U9

VCC1_5_A[16]

G11

VCCLAN1_05[1]

H11

VCCLAN1_05[2]

G12

VCCLAN3_3[1]

H13

VCCLAN3_3[2]

J17

VCCGLANPLL

H19

VCCGLAN1_5[1]

J18

VCCGLAN1_5[2]

K16

VCCGLAN3_3

ICH9MSFF REV 1.0

ICH9MSFF REV 1.0

CORE

CORE

VCCA3GP ATXARX USB CORE

VCCA3GP ATXARX USB CORE

VCCPSUSVCCPUSB

VCCPSUSVCCPUSB

GLAN POWER

GLAN POWER

3

VCC1_05[01]
VCC1_05[02]
VCC1_05[03]
VCC1_05[04]
VCC1_05[05]
VCC1_05[06]
VCC1_05[07]
VCC1_05[08]
VCC1_05[09]
VCC1_05[10]
VCC1_05[11]
VCC1_05[12]
VCC1_05[13]
VCC1_05[14]
VCC1_05[15]
VCC1_05[16]

VCCDMIPLL

VCC_DMI[1]
VCC_DMI[2]

V_CPU_IO[1]
V_CPU_IO[2]

VCC3_3[01]

VCC3_3[02]

VCC3_3[03]
VCC3_3[04]
VCC3_3[05]

VCC3_3[06]
VCC3_3[07]

VCCP_CORE

VCCP_CORE

VCC3_3[08]

PCI

PCI

VCCHDA

VCCSUSHDA

VCCSUS1_05[1]
VCCSUS1_05[2]

VCCSUS1_5[1]

VCCSUS1_5[2]

VCCSUS3_3[01]
VCCSUS3_3[02]
VCCSUS3_3[03]

VCCSUS3_3[04]

VCCSUS3_3[05]
VCCSUS3_3[06]
VCCSUS3_3[07]
VCCSUS3_3[08]
VCCSUS3_3[09]
VCCSUS3_3[10]
VCCSUS3_3[11]
VCCSUS3_3[12]
VCCSUS3_3[13]
VCCSUS3_3[14]
VCCSUS3_3[15]
VCCSUS3_3[16]

VCCCL1_05

VCCCL1_5

VCCCL3_3[1]
VCCCL3_3[2]

3

L11
L12
L13
L14
L15
M11
M15
N11
N15
P11
P15
R11
R12
R13
R14
R15

P19

T17
U17

V16
U16

V18

AE9

AA9
V14
W14

G8
H7
H8

AD7

V10

T7
H15

H16

V7

G14
G15
H14

W8

J7
J8
K7
K8
L7
L8
M7
M8
N7
N8
P7
P8

G18

H17

J14
K14

+1.05V

1.634A

12

C55

C55

0.022U/16V_6

0.022U/16V_6

23mA

+V1.5S_ICH_VCCDMIPLL

C63

C63

0.01U/25V_4

0.01U/25V_4

1 2

+V1.05S_ICH_DMI

C62

C62

1U/6.3V_4

1U/6.3V_4

1 2

1 2

TP_VCCSUS1.05_1
TP_VCCSUS1.05_2

TP_VCCSUS1.5_1

TP_VCCSUS1.5_2

12

C24

C24

0.022U/16V_6

0.022U/16V_6

TP_VCCCL1.05TP_VCCCL1.05

+VCCCL1_5+VCCCL1_5

4

12

C36

C36

0.022U/16V_6

0.022U/16V_6

L8 1uH_8L8 1uH_8

C68

C68

10U/6.3V_6

10U/6.3V_6

1 2

C43

C43

0.1U/10V_4

0.1U/10V_4

C21

C21

0.1U/10V_4

0.1U/10V_4

11mA

11mA

T2T2
T4T4

T5T5

T1T1

12

C42

C42

0.1U/10V_4

0.1U/10V_4

T7T7

19mA

12

C41

C41

*0.1U/10V_4

*0.1U/10V_4

4

2/29 Follow DG

48mA

R77 1_6R77 1_6

12

C64

C64

0.1U/10V_4

0.1U/10V_4

C30

C30

*0.1U/10V_4

*0.1U/10V_4

1 2

1 2

12

C45

C45

0.1U/10V_4

0.1U/10V_4

12

C27

C27

0.1U/10V_4

0.1U/10V_4

+3V

+1.5V

+1.05V

12

C17

C17

0.1U/10V_4

0.1U/10V_4

212mA

12

C26

C26

*0.1U/10V_4

*0.1U/10V_4

2mA

12

C33

C33

0.1U/10V_4

0.1U/10V_4

HDA_IO_ICH

1 2

C31

C31

1U/6.3V_4

1U/6.3V_4

+1.05V

C47

C47

0.1U/10V_4

0.1U/10V_4

R39 *NHD@0_6R39 *NHD@0_6

R32 HD@0_6R32 HD@0_6

C23

C23

0.1U/10V_4

0.1U/10V_4

R25 NHD@0_6R25 NHD@0_6

R24 HD@0_6R24 HD@0_6

+3V_S5

5

C37

C37

12

4.7U/10V/8

4.7U/10V/8

308mA

C35

C35

0.1U/10V_4

0.1U/10V_4

1 2

5

+3V

+3V

+1.5V

+3V_S5

+1.5V_S5

6

U19E

U19E

B4

VSS[001]

B7

VSS[002]

B10

VSS[003]

B13

VSS[004]

B16

VSS[005]

B19

VSS[006]

B22

VSS[007]

D2

VSS[008]

D24

VSS[009]

E5

VSS[010]

E7

VSS[011]

E9

VSS[012]

E11

VSS[013]

E13

VSS[014]

E15

VSS[015]

E17

VSS[016]

E19

VSS[017]

E21

VSS[018]

F24

VSS[019]

G2

VSS[020]

G5

VSS[021]

G10

VSS[022]

G13

VSS[023]

G16

VSS[024]

G19

VSS[025]

G21

VSS[026]

H10

VSS[027]

H12

VSS[028]

H18

VSS[029]

H23

VSS[030]

J5

VSS[031]

J9

VSS[032]

J10

VSS[033]

J11

VSS[034]

J12

VSS[035]

J13

VSS[036]

J15

VSS[037]

J21

VSS[038]

J22

VSS[039]

J25

VSS[040]

K2

VSS[041]

K9

VSS[042]

K10

VSS[043]

K11

VSS[044]

K12

VSS[045]

K13

VSS[046]

K15

VSS[047]

K17

VSS[048]

K23

VSS[049]

L5

VSS[050]

L9

VSS[051]

L10

VSS[052]

L16

VSS[053]

L17

VSS[054]

L21

VSS[055]

L22

VSS[056]

L25

VSS[057]

M9

VSS[058]

M10

VSS[059]

M12

VSS[060]

M13

VSS[061]

M14

VSS[062]

M16

VSS[063]

M17

VSS[064]

M23

VSS[065]

N2

VSS[066]

N5

VSS[067]

N9

VSS[068]

N10

VSS[069]

N12

VSS[070]

N13

VSS[071]

N14

VSS[072]

N16

VSS[073]

N17

VSS[074]

N21

VSS[075]

N22

VSS[076]

N25

VSS[077]

P9

VSS[078]

P10

VSS[079]

P12

VSS[080]

P13

VSS[081]

P14

VSS[082]

P16

VSS[083]

P17

VSS[084]

P23

VSS[085]

R5

VSS[086]

R7

VSS[087]

R8

VSS[088]

R9

VSS[089]

R10

VSS[090]

R16

VSS[091]

R17

VSS[092]

R19

VSS[093]

R21

VSS[094]

R22

VSS[095]

R25

VSS[096]

T2

VSS[097]

T8

VSS[098]

T10

VSS[099]

T11

VSS[100]

T12

VSS[101]

T13

VSS[102]

T14

VSS[103]

T15

VSS[104]

T16

VSS[105]

T23

VSS[106]

ICH9MSFF REV 1.0

ICH9MSFF REV 1.0

6

7

U5

VSS[107]

U10

VSS[108]

W11

VSS[109]

U14

VSS[110]

W16

VSS[111]

U21

VSS[112]

U22

VSS[113]

U25

VSS[114]

V3

VSS[115]

V8

VSS[116]

V19

VSS[117]

V23

VSS[118]

W1

VSS[119]

W4

VSS[120]

W5

VSS[121]

W7

VSS[122]

W9

VSS[123]

W15

VSS[124]

W19

VSS[125]

W21

VSS[126]

W22

VSS[127]

W25

VSS[128]

Y3

VSS[129]

Y23

VSS[130]

AA1

VSS[131]

AA4

VSS[132]

AA6

VSS[133]

AA8

VSS[134]

AA11

VSS[135]

AA13

VSS[136]

AA15

VSS[137]

AA16

VSS[138]

AA17

VSS[139]

AA19

VSS[140]

AA21

VSS[141]

AA22

VSS[142]

AA25

VSS[143]

AB3

VSS[144]

AB9

VSS[145]

AB11

VSS[146]

AB13

VSS[147]

AB15

VSS[148]

AC24

VSS[149]

AC1

VSS[150]

AC4

VSS[151]

AC10

VSS[152]

AC12

VSS[153]

AC14

VSS[154]

AD2

VSS[155]

AD6

VSS[156]

AD9

VSS[157]

AD16

VSS[158]

AD19

VSS[159]

AD22

VSS[160]

AE3

VSS[161]

AE4

VSS[162]

AE11

VSS[163]

AE13

VSS[164]

AE15

VSS[165]

V17

VSS[166]

AE8

VSS[167]

V9

VSS[168]

J16

VSS[169]

VSS_NCTF[01]
VSS_NCTF[02]
VSS_NCTF[03]
VSS_NCTF[04]

A1
A25
AE1
AE25

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

ICH9M SFF (Power/GND)

ICH9M SFF (Power/GND)

ICH9M SFF (Power/GND)

Date: Sheet

Date: Sheet

Date: Sheet

7

PROJECT :

ZE8

ZE8

ZE8

8

15 32Tuesday, September 29, 2009

15 32Tuesday, September 29, 2009

15 32Tuesday, September 29, 2009

8

1A

1A

1A

of

of

of

5

M_CS#[3:0](7)

M_ODT[3:0](7)

DD

M_CKE[3:0](7)

M_CLK_DDR#[3:0](7)

M_CLK_DDR[3:0](7)

M_A_CAS#(8)

M_A_RAS#(8)

M_A_WE#(8)

M_A_BS#[2:0](8)

M_A_DM[7:0](8)

M_A_DQS#[7:0](8)

M_A_DQS[7:0](8)

M_A_A[14:0](8)

M_A_DQ[63:0](8)

M_B_CAS#(8)

M_B_RAS#(8)

CC

M_B_WE#(8)

M_B_BS#[2:0](8)

M_B_DM[7:0](8)

M_B_DQS#[7:0](8)

M_B_DQS[7:0](8)

M_B_A[14:0](8)

M_B_DQ[63:0](8)

BB

M_CS#[3:0]

M_ODT[3:0]

M_CKE[3:0]

M_CLK_DDR#[3:0]

M_CLK_DDR[3:0]

M_A_CAS#

M_A_RAS#

M_A_WE#

M_A_BS#[2:0]

M_A_DM[7:0]

M_A_DQS#[7:0]

M_A_DQS[7:0]

M_A_A[14:0]

M_A_DQ[63:0]

M_B_CAS#

M_B_RAS#

M_B_WE#

M_B_BS[2:0]

M_B_DM[7:0]

M_B_DQS#[7:0]

M_B_DQS[7:0]

M_B_A[14:0]

M_B_DQ[63:0]

PM_EXTTS#0(7) PM_EXTTS#1(7)

R354 10K_4R354 10K_4
R353 10K_4R353 10K_4

Close to DIMM0

0*AC

AA

+SMDDR_VREF

M_A_DQ4
M_A_DQ0
M_A_DQ2

M_A_DM0

M_A_DQ13
M_A_DQ15
M_A_DQ11
M_A_DQ14
M_A_DQS#1
M_A_DQS1

M_A_DQ21
M_A_DQ18
M_A_DQ23
M_A_DQ16
M_A_DQS#2
M_A_DQS2

M_A_DQ29
M_A_DQ27
M_A_DQ28
M_A_DQ30
M_A_DM3

M_CKE0

M_A_BS#2
M_A_BS#0

M_A_A12
M_A_A9
M_A_A8
M_A_A5
M_A_A3
M_A_A1
M_A_A10
M_A_A13

M_CLK_DDR0
M_CLK_DDR#0

M_A_WE#
M_A_CAS#

M_A_DQ34
M_A_DQ39
M_A_DQ38
M_A_DQ35
M_A_DQS#4
M_A_DQS4

M_A_DQ47
M_A_DQ41
M_A_DQ45
M_A_DQ43
M_A_DM5

M_A_DQ54
M_A_DQ53
M_A_DQ51
M_A_DQ52
M_A_DQS#6
M_A_DQS6

M_A_DQ58
M_A_DQ57
M_A_DQ56
M_A_DQ62
M_A_DM7

A_SA0
A_SA1

+SMDDR_VTERM

C404

C404

10u_6

10u_6

+3V

4

CN23

CN23

75

VDD1

81

VDD3

87

VDD5

93

VDD7

99

VDD9

105

VDD11

111

VDD13

117

VDD15

123

VDD17

1

VREF_DQ

199

VDD(SPD)

5

DQ0

7

DQ1

15

DQ2

17

DQ3

11

DM0

21

DQ8

23

DQ9

33

DQ10

35

DQ11

27

DQS#1

29

DQS1

39

DQ16

41

DQ17

51

DQ18

53

DQ19

45

DQS#2

47

DQS2

57

DQ24

59

DQ25

67

DQ26

69

DQ27

63

DM3

73

CKE0

79

BA2

109

BA0

83

A12/BC#

85

A9

89

A8

91

A5

95

A3

97

A1

107

A10/AP

119

A13

101

CK0

103

CK0#

121

CS1#

113

WE#

115

CAS#

129

DQ32

131

DQ33

141

DQ34

143

DQ35

135

DQS#4

137

DQS4

147

DQ40

149

DQ41

157

DQ42

159

DQ43

153

DM5

163

DQ48

165

DQ49

175

DQ50

177

DQ51

169

DQS#6

171

DQS6

181

DQ56

183

DQ57

191

DQ58

193

DQ59

187

DM7

198

EVENT#

197

SA0

201

SA1

77

NC1

125

NCTEST

203

VTT1

3

VSS2

9

VSS4

13

VSS5

19

VSS7

25

VSS9

31

VSS11

37

VSS13

43

VSS15

49

VSS18

55

VSS20

61

VSS22

65

VSS23

71

VSS25

127

VSS27

133

VSS29

139

VSS32

145

VSS34

151

VSS36

155

VSS37

161

VSS39

167

VSS41

173

VSS44

179

VSS46

185

VSS48

189

VSS49

195

VSS51

DDR3_SODIMM_H5.2_RVS

DDR3_SODIMM_H5.2_RVS

3

+1.5V_SUS+1.5V_SUS

76

VDD2

82

VDD4

88

VDD6

94

VDD8

100

VDD10

106

VDD12

112

VDD14

118

VDD16

124

VDD18

126

VREF_CA

DQ4
DQ5
DQ6
DQ7

DQS#0

DQS0

DQ12
DQ13
DQ14
DQ15

DM1

DQ20
DQ21
DQ22
DQ23

DM2

DQ28
DQ29
DQ30
DQ31

DQS#3

DQS3

CKE1

RESET#

CK1#

CS#0

RAS#

ODT0
ODT1

DQ36
DQ37
DQ38
DQ39

DM4

DQ44
DQ45

DDR3 SDRAM

SO-DIMM (204P)

DDR3 SDRAM

SO-DIMM (204P)

DQ46
DQ47

DQS#5

DQS5

DQ52
DQ53
DQ54
DQ55

DM6

DQ60
DQ61
DQ62
DQ63

DQS#7

DQS7

SDA

VTT2

VSS1
VSS3
VSS6

VSS8
VSS10
VSS12
VSS14
VSS16
VSS17
VSS19
VSS21
VSS24
VSS26
VSS28
VSS30
VSS31
VSS33
VSS35
VSS38
VSS40
VSS42
VSS43
VSS45
VSS47
VSS50
VSS52

GND

GND

205

206

+SMDDR_VREF

M_A_DQ7

4

M_A_DQ5

6

M_A_DQ3

16

M_A_DQ6

18

M_A_DQS#0

10

M_A_DQS0

12

M_A_DQ8

22

M_A_DQ10

24

M_A_DQ12

34

M_A_DQ9

36

M_A_DM1

28

M_A_DQ19

40

M_A_DQ17

42

M_A_DQ22

50

M_A_DQ20

52

M_A_DM2

46

M_A_DQ26

56

M_A_DQ24

58

M_A_DQ25

68

M_A_DQ31

70

M_A_DQS#3

62

M_A_DQS3

64

M_CKE1

74

M_A_BS#1

108

BA1

M_A_A14

80

A14

M_A_A11

84

A11

M_A_A7

86

A7

M_A_A6

90

A6

M_A_A4

92

A4

M_A_A2

96

A2

M_A_A0

98

A0

DDR3_RST#

30

M_CLK_DDR1

102

CK1

M_CLK_DDR#1

104

M_CS#0

114

M_A_RAS#

110

M_ODT0

116

M_ODT1

120

M_A_DQ37

130

M_A_DQ32

132

M_A_DQ36

140

M_A_DQ33

142

M_A_DM4

136

M_A_DQ40

146

M_A_DQ42

148

M_A_DQ46

158

M_A_DQ44

160

M_A_DQS#5

152

M_A_DQS5

154

M_A_DQ55

164

M_A_DQ49

166

M_A_DQ50

174

M_A_DQ48

176

M_A_DM6

170

M_A_DQ60

180

M_A_DQ63

182

M_A_DQ59

192

M_A_DQ61

194

M_A_DQS#7

186

M_A_DQS7

188

SMBDT1

200

SMBCK1

202

SCL

78

A15

+SMDDR_VTERM

122

NC2

204

2

C408

C408

C406

2.2u/10V_6

2.2u/10V_6

C406
.1u/16V_4

.1u/16V_4

8
14
20
26
32
38
44
48
54
60
66
72
128
134
138
144
150
156
162
168
172
178
184
190
196

+3V

0*3C

M_B_DQ4
M_B_DQ1
M_B_DQ7
M_B_DQ3
M_B_DM0

M_B_DQ13
M_B_DQ12
M_B_DQ11
M_B_DQ15
M_B_DQS#1
M_B_DQS1

M_B_DQ20
M_B_DQ16
M_B_DQ22
M_B_DQ23
M_B_DQS#2
M_B_DQS2

M_B_DQ29
M_B_DQ25
M_B_DQ31
M_B_DQ27
M_B_DM3

M_CKE2

M_B_BS#2
M_B_BS#0

M_B_A12
M_B_A9
M_B_A8
M_B_A5
M_B_A3
M_B_A1
M_B_A10
M_B_A13

M_CLK_DDR2
M_CLK_DDR#2

M_CS#3

M_B_WE#
M_B_CAS#

M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQS#4
M_B_DQS4

M_B_DQ41
M_B_DQ40
M_B_DQ42
M_B_DQ45
M_B_DM5

M_B_DQ48
M_B_DQ52
M_B_DQ51
M_B_DQ55
M_B_DQS#6
M_B_DQS6

M_B_DQ61
M_B_DQ59
M_B_DQ60
M_B_DQ62
M_B_DM7

B_SA0

R352 10K_4R352 10K_4

B_SA1

R351 10K_4R351 10K_4

Close to DIMM1

+SMDDR_VTERM +SMDDR_VTERM

C403

C403

10u_6

10u_6

+3V

CN22

CN22

75

VDD1

81

VDD3

87

VDD5

93

VDD7

99

VDD9

105

VDD11

111

VDD13

117

VDD15

123

VDD17

1

VREF_DQ

199

VDD(SPD)

5

DQ0

7

DQ1

15

DQ2

17

DQ3

11

DM0

21

DQ8

23

DQ9

33

DQ10

35

DQ11

27

DQS#1

29

DQS1

39

DQ16

41

DQ17

51

DQ18

53

DQ19

45

DQS#2

47

DQS2

57

DQ24

59

DQ25

67

DQ26

69

DQ27

63

DM3

73

CKE0

79

BA2

109

BA0

83

A12/BC#

85

A9

89

A8

91

A5

95

A3

97

A1

107

A10/AP

119

A13

101

CK0

103

CK0#

121

CS1#

113

WE#

115

CAS#

129

DQ32

131

DQ33

141

DQ34

143

DQ35

135

DQS#4

137

DQS4

147

DQ40

149

DQ41

157

DQ42

159

DQ43

153

DM5

163

DQ48

165

DQ49

175

DQ50

177

DQ51

169

DQS#6

171

DQS6

181

DQ56

183

DQ57

191

DQ58

193

DQ59

187

DM7

198

EVENT#

197

SA0

201

SA1

77

NC1

125

NCTEST

203

VTT1

3

VSS2

9

VSS4

13

VSS5

19

VSS7

25

VSS9

31

VSS11

37

VSS13

43

VSS15

49

VSS18

55

VSS20

61

VSS22

65

VSS23

71

VSS25

127

VSS27

133

VSS29

139

VSS32

145

VSS34

151

VSS36

155

VSS37

161

VSS39

167

VSS41

173

VSS44

179

VSS46

185

VSS48

189

VSS49

195

VSS51

DDR3_SODIMM_H5.2_STD

DDR3_SODIMM_H5.2_STD

GND

205

DDR3 SDRAM

DDR3 SDRAM

VDD10
VDD12
VDD14
VDD16
VDD18

VREF_CA

DQS#0

DQS#3

RESET#

SO-DIMM (204P)

SO-DIMM (204P)

DQS#5

DQS#7

VSS10
VSS12
VSS14
VSS16
VSS17
VSS19
VSS21
VSS24
VSS26
VSS28
VSS30
VSS31
VSS33
VSS35
VSS38
VSS40
VSS42
VSS43
VSS45
VSS47
VSS50
VSS52

GND

206

VDD2
VDD4
VDD6
VDD8

DQS0

DQ12
DQ13
DQ14
DQ15

DQ20
DQ21
DQ22
DQ23

DQ28
DQ29
DQ30
DQ31

DQS3

CKE1

CK1#

CS#0

RAS#

ODT0
ODT1

DQ36
DQ37
DQ38
DQ39

DQ44
DQ45
DQ46
DQ47

DQS5

DQ52
DQ53
DQ54
DQ55

DQ60
DQ61
DQ62
DQ63

DQS7

VSS1
VSS3
VSS6
VSS8

2

+1.5V_SUS+1.5V_SUS

76
82
88
94
100
106
112
118
124
126

+SMDDR_VREF+SMDDR_VREF

M_B_DQ2

4

DQ4

M_B_DQ5

6

DQ5

M_B_DQ0

16

DQ6

M_B_DQ6M_A_DQ1

18

DQ7

M_B_DQS#0

10

M_B_DQS0

12

M_B_DQ9

22

M_B_DQ8

24

M_B_DQ14

34

M_B_DQ10

36

M_B_DM1

28

DM1

M_B_DQ17

40

M_B_DQ21

42

M_B_DQ19

50

M_B_DQ18

52

M_B_DM2

46

DM2

M_B_DQ28

56

M_B_DQ24

58

M_B_DQ26

68

M_B_DQ30

70

M_B_DQS#3

62

M_B_DQS3

64

M_CKE3

74

M_B_BS#1

108

BA1

M_B_A14

80

A14

M_B_A11

84

A11

M_B_A7

86

A7

M_B_A6

90

A6

M_B_A4

92

A4

M_B_A2

96

A2

M_B_A0

98

A0

DDR3_RST#

30

M_CLK_DDR3

102

CK1

M_CLK_DDR#3

104

M_CS#2M_CS#1

114

M_B_RAS#

110

M_ODT2

116

M_ODT3

120

M_B_DQ32

130

M_B_DQ33

132

M_B_DQ34

140

M_B_DQ35

142

M_B_DM4

136

DM4

M_B_DQ46

146

M_B_DQ44

148

M_B_DQ43

158

M_B_DQ47

160

M_B_DQS#5

152

M_B_DQS5

154

M_B_DQ50

164

M_B_DQ53

166

M_B_DQ54

174

M_B_DQ49

176

M_B_DM6

170

DM6

M_B_DQ57

180

M_B_DQ56

182

M_B_DQ63

192

M_B_DQ58

194

M_B_DQS#7

186

M_B_DQS7

188

SMBDT1

200

SDA

SMBCK1

202

SCL

78

A15

122

NC2

204

VTT2

2

C409

C409

8

2.2u/10V_6

2.2u/10V_6

14
20
26
32
38
44
48
54
60
66
72
128
134
138
144
150
156
162
168
172
178
184
190
196

DDR3_RST# (7)

SMBDT1 (3,19,21)
SMBCK1 (3,19,21)

C407

C407
.1u/16V_4

.1u/16V_4

Decoupling capacitor

Close to SO-DIMM0

Close to SO-DIMM1

EMI

1

C305 330u_7343

C305 330u_7343

+

+

10u_6C306 10u_6C306
10u_6C413 10u_6C413
10u_6C411 10u_6C411
10u_6C456 10u_6C456
10u_6C414 10u_6C414
10u_6C410 10u_6C410

+SMDDR_VREF

.01u/25V_4C455 .01u/25V_4C455

2.2u/10V_6C416 2.2u/10V_6C416

.01u/25V_4C412 .01u/25V_4C412

2.2u/10V_6C415 2.2u/10V_6C415

C458 *330u_7343

C458 *330u_7343

+

+

10u_6C466 10u_6C466
10u_6C461 10u_6C461
10u_6C467 10u_6C467
10u_6C460 10u_6C460
10u_6C462 10u_6C462
10u_6C463 10u_6C463

+SMDDR_VREF

.1u/16V_4C457 .1u/16V_4C457

2.2u/10V_6C464 2.2u/10V_6C464

.1u/16V_4C465 .1u/16V_4C465

2.2u/10V_6C459 2.2u/10V_6C459

*.1u/16V_4C471 *.1u/16V_4C471

8/13 : B-test add for EMI

+1.5V_SUS

+3V

+1.5V_SUS

+3V

+1.5V_SUS

Reverse Type SO-DIMM0 ,H=5.2mm

SMbus address A0

5

4

3

Standard Type SO-DIMM1,H=5.2

SMbus address A2

2

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

DDRIII SO-DIMM

DDRIII SO-DIMM

DDRIII SO-DIMM

Date: Sheet

Date: Sheet

Date: Sheet

PROJECT :

ZE8

ZE8

ZE8

16 34Tuesday, September 29, 2009

16 34Tuesday, September 29, 2009

16 34Tuesday, September 29, 2009

of

of

1

of

1A

1A

1A

5

4

3

2

1

Codec ALC269X (ADO)

B-test 8/11: for EMI

C350

C350
10U/6.3V_6

10U/6.3V_6

C334

C334

10U/6.3V_6

10U/6.3V_6

C335

C335

*10U/6.3V_6

*10U/6.3V_6

+5VA

C363

C363

0.1U/10V_4

0.1U/10V_4

C352

C352

2.2U/6.3V_6

2.2U/6.3V_6

ADOGND

SPDIF_OUT(21)

C349

C349

0.1U/10V_4

0.1U/10V_4

Spilt by DGND

+5V

+5V

SPDIF_OUT

L_SPK+

L_SPK-

R_SPK-

R_SPK+

EAPD#

+3V

C325

C325

0.1U/10V_4

0.1U/10V_4

37

38

39

40

41

42

43

44

45

46

47

48

49

Place next to pin 1

DMIC_DAT(22)
DMIC_CLK(22)

0V : Power down Class D SPK amplifer

3.3V : Power up Class D SPK amplifer

PD#

SPDIF_OUT

C243

C243
*680p/50V_6

DD

CC

*680p/50V_6

+5VA

ADOGND

Place next to pin 38

+5V

C342

C342

0.1U/10V_4

0.1U/10V_4

Place next to pin 39

C332

C332

0.1U/10V_4

0.1U/10V_4

+5V

BB

Place next to pin 46

+3V

R202

+3V

R188

R188

*HD@100K_4

AA

ACZ_RESET#_AUDIO

*HD@100K_4

2

Q14

Q14
*HD@DTC144EU

*HD@DTC144EU

1 3

5

R202

*HD@100K_4

*HD@100K_4

3

Q15

Q15

2

*HD@2N7002E

*HD@2N7002E

1

PD#

ADOGND

+

+

C358

C358

2.2U/6.3V_6

2.2U/6.3V_6

+

+

33

36

35

34

CBP

CBN

CPVEE

AVSS2

AVDD2

PVDD1

SPK-L+

SPK-L-

(Vista Premium Version)

PVSS1

PVSS2

SPK-R-

SPK-R+

PVDD2

SPDIFO2/EAPD

SPDIFO

PGND

GND50GND51GND

52

C327

C327

10U/6.3V_6

10U/6.3V_6

R199 Short_4R199 Short_4

HP-OUT-R

DVDD11GPIO0/DMIC-DATA2GPIO1/DMIC-CLK3PD#4SDATA-OUT5BIT-CLK6DVSS27SDATA-IN8DVDD-IO9SYNC10RESET#11PCBEEP

ACZ_RESET#_AUDIO

D24*NHD@BAS316 D24*NHD@BAS316

EAPD#

D25*BAS316 D25*BAS316

AMP_MUTE#

AMP_MUTE#

D23*BAS316 D23*BAS316

4

ADOGND

31

32

HP-OUT-L

30

CPVREF

MIC1-VREFO-R

C321

C321
*10P/50V_4

*10P/50V_4

HPOUT-R

HPOUT-L

MIC1-VREFO-R

MIC1-VREFO-L

ADOGND

27

29

28

VREF

MIC2-VREFO

MIC1-VREFO-L

ACZ_SDIN

C322 10P/50V_4C322 10P/50V_4

R195 Short_4R195 Short_4

HPOUT-R (21)

HPOUT-L (21)

Place next to pin 27

C359

C359
*10U/6.3V/6

*10U/6.3V/6

U11

58

25

GND
GND
GND

AVDD1

LINE1-R

LINE1-L

MIC1-R

MIC1-L

MONO-OUT

JDREF

Sense-B

MIC2-R

MIC2-L

LINE2-R

LINE2-L

Sense A

12

DIGITAL

U11

55
54

GND56GND57GND

53

24

23

22

21

20

19

18

17

16

15

14

13

ALC269

ALC269

26

AVSS1

1.6Vrms

C324 1u/10V_6C324 1u/10V_6

+AZA_VDD

ACZ_RESET#_AUDIO

R196 22_4R196 22_4

AMP_MUTE# (18)

C353

C353

0.1U/10V/4

0.1U/10V/4

C348

C348

0.1U/10V_4

0.1U/10V_4

+5VA

ADOGND

C347

C347
*10U/6.3V_6

*10U/6.3V_6

Place next to pin 25

MIC1_R1

MIC1_L1

R226 20K/F_4R226 20K/F_4

ADOGND

Placement near Audio Codec

SENSEA

R209 39.2K/F/4R209 39.2K/F/4

R221 20K/F/4R221 20K/F/4

ANALOG

BEEP_1PCBEEP

R203

C316

C316

100p/50V_6

100p/50V_6

ACZ_RESET#_AUDIO (12)

ACZ_SYNC_AUDIO (12)

ACZ_SDIN0 (12)

ACZ_SDOUT_AUDIO (12)

ACZ_BITCLK_AUDIO (12)

R203

2K_4

2K_4

R198 47K_4R198 47K_4

C315

C315

0.1U/10V/4

0.1U/10V/4

Place next to pin 9

C323

C323
10U/6.3V/_6

10U/6.3V/_6

Power (ADO)

Demodulation Filter

Place close to Codec

+5V

C373

C373

*0.1U/10V/4

*0.1U/10V/4

3

L25 TI201209U220/8L25 TI201209U220/8

U15

U15

3

OUT

IN

2

GND

1

SET

SHDN

*MAX8863SEUK+T

*MAX8863SEUK+T

LINEOUT_JD# (21)

MIC1_JD# (21)

SB_BEEP (14)

BOM notice: just can stuff one in BOM

4

5

Speaker (AMP)

MIC1_L1

MIC1_R1

R192 *NHD@0_6R192 *NHD@0_6

R189 HD@0_6R189 HD@0_6

R245 *29.4K/F/4R245 *29.4K/F/4

R246

R246

*10K/F/4

*10K/F/4

+3V

+1.5V

+5VA

C366

C366

+

+

*10U/10V/3216

*10U/10V/3216

ADOGNDADOGND

2

R_SPK+

R242 Short_6R242 Short_6

R_SPK-

R241 Short_6R241 Short_6

L_SPK-

R240 Short_6R240 Short_6

L_SPK+

R239 Short_6R239 Short_6

C338 4.7U/6.3V/6C338 4.7U/6.3V/6

C341 4.7U/6.3V/6C341 4.7U/6.3V/6

MIC1-VREFO-R

MIC1-VREFO-L

R234 1K/F_4R234 1K/F_4

R233 1K/F_4R233 1K/F_4

R_SPK+_1

C357

C357
*0.22U/25V/6

*0.22U/25V/6

C356

C356
*0.22U/25V/6

*0.22U/25V/6

R_SPK-_1
L_SPK-_1

C355

C355
*0.22U/25V/6

*0.22U/25V/6

C354

C354
*0.22U/25V/6

*0.22U/25V/6

L_SPK+_1

R238

R238

4.7K/F_4

4.7K/F_4

C365

C365

*1u/6.3V_4

*1u/6.3V_4

C364

C364

*1u/6.3V_4

*1u/6.3V_4

R237

R237

4.7K/F_4

4.7K/F_4

CN8

CN8

1
2
345

Speak CNN

Speak CNN

6

stitching caps for Audio signals

C345

C345

+3V+3VPCU

0.1U/10V_4

0.1U/10V_4

C385

+3VPCU +3V

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

C385

0.1U/10V_4

0.1U/10V_4

ADOGND

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

Codec ALC269X

Codec ALC269X

Codec ALC269X

R259 Short_6R259 Short_6
R248 *0_6R248 *0_6
R250 *0_6R250 *0_6
R243 *0_6R243 *0_6
R254 Short_6R254 Short_6

C377 *1000p/50V_4C377 *1000p/50V_4
C387 *1000p/50V_4C387 *1000p/50V_4

R247 *0_6R247 *0_6

ZE8

ZE8

ZE8

17 32Tuesday, September 29, 2009

17 32Tuesday, September 29, 2009

17 32Tuesday, September 29, 2009

1

MIC1_L2 (21)

MIC1_R2 (21)

of

of

of

1A

1A

1A

5

EC WPCE775LA0DG (KBC)

C333

C333

0.1u/10V_4

0.1u/10V_4

EC_SCI#(14)

SERIRQ(14)

EC_SMI#(14)

LID_touch panel#(14,21)

BT_POWERON#(21)

Touch_panel_HK(22)

L22 BK1608HS220/1A/22ohm_6L22 BK1608HS220/1A/22ohm_6

30mil

C331

C331

C310

C310

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

PCICLK_EC

GA20

RCIN#

R174 Short_6R174 Short_6

EC_FPBACK#

RECOVER_BUTTON#

PLTRST#

SERIRQ

MX0(21)
MX1(21)
MX2(21)
MX3(21)
MX4(21)
MX5(21)
MX6(21)
MX7(21)

MY0(21)
MY1(21)
MY2(21)
MY3(21)
MY4(21)
MY5(21)
MY6(21)
MY7(21)
MY8(21)

MY9(21)
MY10(21)
MY11(21)
MY12(21)
MY13(21)
MY14(21)
MY15(21)

KILL_SW_3G#(21)
KILL_SW_WL#(21)

MBCLK(23)

MBDATA(23)

2ND_MBCLK(4)

2ND_MBDATA(4)

TPCLK(21)

TPDATA(21)

MAINON(26,27,28)

R219 20M_6R219 20M_6

Y2

32.768KHzY232.768KHz

1 4

2 3

C337

C337
15p/50V_4

15p/50V_4

E775AGND

C281

C281

0.1u/10V_4

0.1u/10V_4

MX0
MX1
MX2
MX3
MX4
MX5
MX6
MX7

MY0
MY1
MY2
MY3
MY4
MY5
MY6
MY7
MY8
MY9
MY10
MY11
MY12
MY13
MY14
MY15

MBCLK
MBDATA
2ND_MBCLK
2ND_MBDATA

LID_touch panel#

E775_32KX1

E775_32KX2

R228

R228

33K/F_4

33K/F_4

C343

C343
15p/50V_4

15p/50V_4

+3V_VCC_EC

+3VPCU

DD

PCICLK_EC

R181

R181

*22_4

*22_4

C280

C280
*10p/50V_4

*10p/50V_4

CC

+3VPCU

MX4
MX5 MX1
MX6
MX7

BB

R171 2.2_6R171 2.2_6

RN14

10

9
8
7 4

10K_10P8R

10K_10P8R

+3V_VCC_EC

C278

C278

4.7u/6.3V_6

4.7u/6.3V_6

MX3

1

MX2

2
3

MX0

56

+3VPCU

RECOVER_BUTTON#(21)

C313

C313

0.1u/10V_4

0.1u/10V_4

LFRAME#(12,19)
LAD0(12,19)
LAD1(12,19)
LAD2(12,19)
LAD3(12,19)
PCICLK_EC(3)

CLKRUN#(14)

GA20(12)

RCIN#(12)

EC_FPBACK#(22)

PLTRST#(7,13,19,21)

USB_EN#(20,21)

E775AGND

4

+A3VPCU

C326

C326

C328

C328

0.1u/10V_4

0.1u/10V_4

4.7u/6.3V_6

4.7u/6.3V_6

19

46

76

U9

U9

VCC1

VCC2

VCC3

3

LFRAME

126

LAD0

127

LAD1

128

LAD2

1

LAD3

2

LCLK

8

GPIO11/CLKRUN

121

GA20

122

KBRST

29

ECSCI/GPIO54

6

GPIO24/LDRQ

124

GPIO10/LPCPD

7

LREST

123

GPIO67/PWUREQ

125

SERIRQ

9

GPIO65/SMI

54

KBSIN0

55

KBSIN1

56

KBSIN2

57

KBSIN3

58

KBSIN4

59

KBSIN5

60

KBSIN6

61

KBSIN7

53

KBSOUT0/JENK

52

KBSOUT1/TCK

51

KBSOUT2/TMS

50

KBSOUT3/TDI

49

KBSOUT4/JEN0

48

KBSOUT5/TDO

47

KBSOUT6/RDY

43

KBSOUT7

42

KBSOUT8

41

KBSOUT9

40

KBSOUT10

39

KBSOUT11

38

KBSOUT12/GPIO64

37

KBSOUT13/GPIO63

36

KBSOUT14/GPIO62

35

KBSOUT15/GPIO61/XOR_OUT

34

GPIO60/KBSOUT16

33

GPIO57/KBSOUT17

70

GPIO17/SCL1

69

GPIO22/SDA1

67

GPIO73/SCL2

68

GPIO74/SDA2

72

GPIO37/PSCLK1

71

GPIO35/PSDAT1

10

GPIO26/PSCLK2

11

GPIO27PSDAT2

12

GPIO25/PSCLK3

13

GPIO12/PSDAT3

77

32KX1/32KCLKIN

79

32KX2

WPCE775

WPCE775

88

115

102

VCC4

VCC5

AVCC

GND1

GND2

5

18

45

BK1608HS220/1A/22ohm_6

BK1608HS220/1A/22ohm_6

E775AGND

GND3

LPC

LPC

SMB

SMB

PS/2

PS/2

GND4

78

L21

L21

KB

KB

GND5

GND6

89

116

*0.1u/10V_4C318 *0.1u/10V_4C318
*0.1u/10V_4C319 *0.1u/10V_4C319

A/D

A/D

D/A

D/A

GPIO23/SCL3

GPIO30/CIRTX2

GPIO31/SDA3
GPIO32/D_PWM
GPIO33/H_PWM

GPIO40/F_PWM

GPIO

GPIO

GPIO45/E_PWM

GPIO46/CIRRXM/TRST

GPIO52/CIRTX2/RDY

GPIO53/SDA4

GPO84/BADDR0

TIMER

TIMER

GPIO15/A_PWM

GPIO21/B_PWM

GPIO13/C_PWM

GPIO66/G_PWM

GPIO77/SPI_DI

SPI

SPI

GPO76/SPI_DO/SHBM

GPIO75/SPI_SCK

GPIO72/IRRX1/SIN2

GPIO70/IRRX2_IRSL0

GPIO71/IRTX/SOUT2

IR

IR

GPIO87/CIRRXM/SIN_CR

GPIO34/CIRRXL

GPIO16/CIRTX

GPO83/SOUT_CR/BADDR1

FIU

FIU

GPIO55/CLKOUT

VCORF

AGND

44

103

VCORF_uR

C295

C295

1u/10V_4

1u/10V_4

GPI90/AD0
GPI91/AD1
GPI92/AD2

GPI93/AD3
GPIO05/AD4
GPIO04/AD5

GPI94/DA0

GPI95/DA1

GPI96/DA2

GPI97/DA3

GPIO01/TB2

GPIO03/AD6

GPIO06

GPIO07/AD7

GPIO36/TB3

GPIO42/TCK
GPIO43/TMS

GPIO44/TDI

GPO47/SCL4
GPIO50/TDO

GPIO51/TA3

GPIO81

GPO82/TRIS

GPIO41

GPIO56/TA1
GPIO20/TA2
GPIO14/TB1

F_SDI

F_SDO

F_CS0

F_SCK

VCC_POR

VREF

3

3V_VDD_EC

D22 BAS316D22 BAS316

C277

C277

4.7u/6.3V_6

4.7u/6.3V_6

0.1u/10V_4

4

VDD

0.1u/10V_4

97
98

TPD_TRIP

99
100
108

+1.8V on power control

96

A2 test 6/25: add +1.5V on power control net name to control 1.5V

101
105
106
107

64

NBSWON#_EC

95
93
94

3ND_MBCLK

119
109

3ND_MBDATA

120

BATLED0#

65

BATLED1#

66
15

SUSLED#-R

16
17
20

AD_OFF

21
22
23
24
25
26

PCIE_WAKE#_EC

27

MPWROK

28

DNBSWON#_uR

91
110

BADDR0

112
80

31
117
63

32

NUMLED#

118

PWRLED#-R

62

CAPSLED#

81

CRT_SENSE#

84
83
82

EC_RSMRST#

75

SUSC#

73

PWROK_EC

74

RF_EN

113
14
114

uR_SOUT_CR

111

SPI_SDI_uR

86
87

SPI_CS0#_uR

90

SPI_SCK_uR_R

92

ECDB_CLOCK

30

VCC_POR#

85

VREF_uR +A3VPCU

104

D31 BAS316D31 BAS316

R217 Short_4R217 Short_4

D30 3G@BAS316D30 3G@BAS316

T13T13

D26 BAS316D26 BAS316

D21 *BAS316D21 *BAS316

R235 22_4R235 22_4

R218 22_4R218 22_4

T12T12

R220 47K_4R220 47K_4

R197 Short_4R197 Short_4

7/7: power consumption issue,
Vendor suggest to place it close to EC.

+3V

C276

C276

SPI_SDO_uRSPI_SDO_uR_R

SPI_SCK_uR

SPI_SDI_uR

TEMP_MBAT (23)

ICMNT (23)
Recover_LED# (21)

+1.8V on power control (28)

ACIN (23)
NBSWON# (21)
LID# (14,21,22)
SUSB# (14)

BATLED0# (21)
BATLED1# (21)

VRON (25)

AMP_MUTE# (17)

CPUFAN# (4)

3G_EC_LED# (21)

D/C# (23)
S5_ON (24,28)

MPWROK (7,14)
DNBSWON# (14)

WLAN_LED# (19,21)

SUSON (7,26,28)

FANSIG (4)

CONTRAST (22)
NUMLED# (21)

CAPSLED# (21)

CRT_SENSE# (21)
3G_EN (19)
3G_MINI_LED# (19)

EC_RSMRST# (14)

SUSC# (14)
PWROK_EC (14)
RF_EN (19)

+3VPCU

R355

R355

100K_4

100K_4

2

ACER ID

+3V

R208

R208

*47K_6

*47K_6

RT1

RT1

t

t

*THERMISTOR_100K/1%(NTC)

*THERMISTOR_100K/1%(NTC)

3ND_MBCLK
3ND_MBDATA

SPI FLASH

SPI Flash Source P/N
Winbond W25X16AVSSIG
MXIC MX25L1605DM2I-12G
EON EN25F16-100HIP
AMIC A25L016

+3VPCU

6
5

7

GREEN ADAPTER CIRCUIT

C-test : 9/8 : no stuff green adapter circuit

+3VPCU

+VCCRTC

D18

D18

NBSWON#

R165

R165
*47K_4

*47K_4

*BAS316

*BAS316

R164 *47K_4R164 *47K_4

R167 *0_4R167 *0_4

C261

C261

1

*1u/10V_4

*1u/10V_4

2

Q8

*AO3413Q8*AO3413

2

3

D13 *BAS316D13 *BAS316

3

Q11

Q11
*2N7002E

*2N7002E

1

U10

U10

SCL
SDA

VCC

WP

GND

AT24C02BN-SH-T

AT24C02BN-SH-T

R230 22_4R230 22_4

R229 10K_4R229 10K_4

AKE38ZP0N01
AKE38FP0Z00
AKE38ZA0Q00
AKE38ZN0800

R155 *475/F_4R155 *475/F_4RN14

AD_OFF

+3VPCU

R170

R170
*47K_4

*47K_4

C279

C279
*1000p/50V_4

*1000p/50V_4

1

1

A0

2

A1

3

A2

8
4

+3VPCU

C336

C336

0.1u/10V_4

0.1u/10V_4

U14

3

1

D12

D12
*BAS316

*BAS316

R154

R154
*475/F_4

*475/F_4

Q7
*2N7002EQ7*2N7002E

3

1

Q13

Q13
*2N7002E

*2N7002E

2

5

6

1

AD_ON

U14

SO

SI

SCK

CE

W25X16

W25X16

+3VPCU

HOLD

SPI_SDI_uR_RSPI_SDI_uR

SPI_SDO_uR

SPI_SCK_uR

SPI_CS0#_uR

6/17:AKE38ZP0N01 has issue, so change to AKE37FP0Z13

+3VPCU

2

R156 *0_4R156 *0_4

2

+3VPCU

8

VDD

7

3

WP

4

VSS

T11T11

R177

R177
*47K_4

*47K_4

R186 *0_4R186 *0_4

C282

C282
*1000p/50V_4

*1000p/50V_4

C346

C346

0.1u/10V_4

0.1u/10V_4

NBSWON#_EC

POWER SWITCH

G1 *SHORT_PADG1 *SHORT_PAD

NBSWON#

1 2

AA

SUSLED#-R
BATLED0#
BATLED1#
PWRLED#-R

R180 10K_4R180 10K_4
R204 10K_4R204 10K_4
R206 10K_4R206 10K_4
R200 10K_4R200 10K_4

+3VPCU

PWRLED#-R

SUSLED#-R

5

Q16

Q16
*DTA114YUA

*DTA114YUA

47K

47K

13

R172

R172
Short_4

Short_4

R201

R201
Short_4

Short_4

PWRLED# (21)

SUSLED# (21)

10K

10K

2

Q9

Q9
*DTA114YUA

*DTA114YUA

47K

47K

13

10K

10K

2

HWPG

HWPG_+1.8V(28)

HWPG_1.05V(27)

HWPG_+1.5V_SUS(7,26)

HWPG_SYS(24)

HWPG_+1.5VS5(28)

HWPG_GFX(29)

Celeron 723 ,743 not support graphics render standby mode, so del D20
SU7300,SU2300,SU2700,SU4100 support it, so add D20

INTERNAL KEYBOARD STRIP SET

4

D15 BAS316D15 BAS316

D16 BAS316D16 BAS316

D14 BAS316D14 BAS316

D17 BAS316D17 BAS316

D19 BAS316D19 BAS316

D20 SU3500@BAS316D20 SU3500@BAS316

MY0

R187 10K_4R187 10K_4

+3V

R166

R166

10K_4

10K_4

Short_4

Short_4

MPWROK

+3VPCU

3

R173

R173

I/O ADDRESS SETTING

I/O Address

0 0

0 1

1 0

1 1

BADDR0

uR_SOUT_CR

3G_EN

Index

XOR TREE TEST MODE

CORE DEFINED

2Eh 2Fh

164Eh

R191 10K_4R191 10K_4

R193 *10K_4R193 *10K_4

R214 10K_4R214 10K_4

BADDR1-0

SHBM=0: Enable shared memory with host BIOS

BADDR0

BADDR1

SHBM

Data

164Fh

2

SM BUS PU

MBCLK
MBDATA

3ND_MBCLK
3ND_MBDATA

2ND_MBCLK
2ND_MBDATA

CRT_SENSE#

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

EC WPCE775LA0DG

EC WPCE775LA0DG

EC WPCE775LA0DG

Date: Sheet

Date: Sheet

Date: Sheet

R210 4.7K_4R210 4.7K_4
R211 4.7K_4R211 4.7K_4

R215 4.7K_4R215 4.7K_4
R224 4.7K_4R224 4.7K_4

R213 4.7K_4R213 4.7K_4
R212 4.7K_4R212 4.7K_4

R231 4.7K_4R231 4.7K_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

1

ZE8

ZE8

ZE8

+3VPCU

+3V

+3V

18 32Tuesday, September 29, 2009

18 32Tuesday, September 29, 2009

18 32Tuesday, September 29, 2009

of

of

of

1A

1A

1A

5

4

3

2

1

Mini Card1-WLAN/WMAX(MNC)

+1.5V_Mini1_VDD

WLAN_LED#

R261 Short_4R261 Short_4

WL_SMDATA
WL_SMCLK

PLTRST#
RF_EN

+3V

R262

R262

*10K_4

*10K_4

+3.3V

GND

+1.5V

GND

USB_D+

USB_D-

GND

SMB_CLK

+1.5V

GND

+3.3Vaux

PERST#

GND

Reserved
Reserved
Reserved
Reserved
Reserved

+1.5V

GND

+3.3V

+3V_Mini1_VDD

52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18

16
14
12
10
8
6
4
2

7/30 : unstuff for intel WLAN

DD

CC

PLTRST#(7,13,18,21)

PCLK_DEBUG(3)

PCIE_TXP6(13)
PCIE_TXN6(13)

PCIE_RXP6(13)
PCIE_RXN6(13)

PECLK_MINI1(3)
PECLK_MINI1#(3)

CLKREQ#_MINI1(3)

+3V_Mini1_VDD

R179 *0_4R179 *0_4
R178 *0_4R178 *0_4

CLKREQ#_MINI1

MINI-CARD1(AS0B241-S50U-7F)

MINI-CARD1(AS0B241-S50U-7F)

CN10

CN10

51

Reserved

49

Reserved

47

Debug(PCIRST#)

45

Debug(PCICLK)

43

GND

41

+3.3Vaux

39

+3.3Vaux

37

GND

35

GND

33

PETp0

31

PETn0

29

GND

27

GND

25

PERp0

23

PERn0

21

GND

19

Reserved

17

Reserved

15

GND

13

REFCLK+

11

REFCLK-

9

GND

7

CLKREQ#

5

Reserved

3

Reserved

1

WAKE#

53

LED_WPAN#

LED_WLAN#

LED_WWAN#

SMB_DATA

W_DISABLE#

GND54GND

+3V

R263 Short_8R263 Short_8

WLAN_LED# (18,21)

USBP4+ (13)
USBP4- (13)

RF_EN (18)

LFRAME# (12,18)
LAD3 (12,18)
LAD2 (12,18)
LAD1 (12,18)
LAD0 (12,18)

+3V_Mini1_VDD

C400

C400

10u/10V_8

10u/10V_8

R261: for Wimax

R182 *0_8R182 *0_8

C309

C309

0.1u/10V_4

0.1u/10V_4

+1.5V_Mini1_VDD+1.5V

C311

C311
*1n/50V_4

*1n/50V_4

C401

C401

*0.1u/10V_4

*0.1u/10V_4

C292

C292
*0.1u/10V_4

*0.1u/10V_4

C308

C308

0.1u/10V_4

0.1u/10V_4

C312

C312
*10u/10V_8

*10u/10V_8

C297

C297
*0.1u/10V_4

*0.1u/10V_4

+3V_Mini1_VDD

+3V

R169

2

R168 Short_4R168 Short_4

+3V

2

R175 Short_4R175 Short_4

R169

*10K_4

*10K_4

Q10

Q10

*2N7002E

*2N7002E

SMBCK1(3,16,21)

SMBDT1(3,16,21)

1

Q12

Q12

*2N7002E

*2N7002E

1

R176

R176

*10K_4

*10K_4

3

3

WL_SMDATA

WL_SMCLK

Mini Card2-3G(MNC)

6/10: delete 3G wake up function

PCIE_TXP5(13)
PCIE_TXN5(13)

PCIE_RXP5(13)
PCIE_RXN5(13)

BB

AA

PECLK_MINI2(3)
PECLK_MINI2#(3)

CLKREQ#_MINI2(3)

UIM_CLK

6

8
9

10

3G@SIM-Conn-CE015

3G@SIM-Conn-CE015

JSIM1

JSIM1

CLK(C3)

GND(C5)
N/A(C8)7VCC(C1)
N/A(C4)
CT
CD

13

VPP(C6)
RST(C2)

DATA(C7)

GND14GND12GND11GND

+3V_Mini2_VDD

3G@MINI-CARD2(AS0B241-S50U-7F)

3G@MINI-CARD2(AS0B241-S50U-7F)

1

UIM_PWR

2

UIM_VPP

3

UIM_RST

4

UIM_DATA

5

51
49
47
45
43
41
39
37
35
33
31
29
27
25
23
21
19
17

15
13
11

9
7
5
3
1

CN13

CN13

Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
GND
PETp0
PETn0
GND
GND
PERp0
PERn0
GND
UIM_C4
UIM_C8

GND
REFCLK+
REFCLK­GND
CLKREQ#
Reserved
Reserved
WAKE#

UIM_PWR

UIM_DATA

UIM_RST

53

C383 3G@27p/50V_4C383 3G@27p/50V_4

C388 3G@10p/50V_4C388 3G@10p/50V_4

C386 3G@27p/50V_4C386 3G@27p/50V_4

+3.3V

GND

+1.5V
LED_WPAN#
LED_WLAN#

LED_WWAN#

GND

USB_D+

USB_D-

GND

SMB_DATA

SMB_CLK

+1.5V

GND

+3.3Vaux

PERST#

W_DISABLE#

GND

UIM_VPP
UIM_RST

UIM_CLK

UIM_DATA

UIM_PWR

+1.5V

GND

+3.3V

GND54GND

+3V_Mini2_VDD

52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18

16
14
12
10
8
6
4
2

6/23 A2 test : change PN to DG006000005 or DG006000006

+1.5V_Mini2_VDD

WLAN_LED#
3G_LED#

R99 3G@0_4R99 3G@0_4

3G_SMDATA
3G_SMCLK

PLTRST#_3G

UIM_VPP
UIM_RST
UIM_CLK
UIM_DATA
UIM_PWR

UIM_RST

UIM_CLK

1 2

+3V

USBP2+
USBP2-

R115 *0_4R115 *0_4

C378

C378

*3G@10p/50V_4

*3G@10p/50V_4

R90

R90

*3G@10K_4

*3G@10K_4

PLTRST#

3G_MINI_LED# (18)

USBP2+ (13)

USBP2- (13)

3G_EN (18)

U16

U16

1

CH1

2

VN

CH23CH3

*3G@CM1293-04SO

*3G@CM1293-04SO

CH4

6

5

VP

4

9/2 C test : change PN and footprint to DFHS10FR381(change back to A1 type)

5

4

3

+3V

UIM_VPP

UIM_DATA

+3V_Mini2_VDD

C434

C434

3G@10u/10V_8

3G@10u/10V_8

R105 3G@0_8R105 3G@0_8

C380

C380

*3G@33p/50V_4

*3G@33p/50V_4

1 2

Layout : C431 and C252 place near JSIM2

C165

C165

3G@0.1u/10V_4

3G@0.1u/10V_4

+1.5V_Mini2_VDD+1.5V

C187

C187

3G@1n/50V_4

3G@1n/50V_4

C429

C429

3G@0.1u/10V_4

3G@0.1u/10V_4

+3V_Mini2_VDD

C431

C431

3G@0.1u/10V_4

3G@0.1u/10V_4

UIM_PWR

C167

C167

3G@0.1u/10V_4

3G@0.1u/10V_4

C435

C435

3G@10u/10V_8

3G@10u/10V_8

+3VSUS

+3V

C384

C384

3G@0.1u/10V_4

3G@0.1u/10V_4

2

C159

C159

3G@10u/10V_8

3G@10u/10V_8

C208

C208

3G@1u/10V_6

3G@1u/10V_6

1 2

12

C195

C195

3G@0.1u/10V_4

3G@0.1u/10V_4

R279 3G@0_8R279 3G@0_8

R278 *3G@0_8R278 *3G@0_8

C428

C428

3G@0.47u/6.3V_4

3G@0.47u/6.3V_4

+3V_Mini2_VDD

C432

C432

3G@10p/50V_4

3G@10p/50V_4

+3V_Mini2_VDD

Q21

Q21

3G@2N7002E

3G@2N7002E

PDAT_SMB

PDAT_SMB(3,14)

PCLK_SMB(3,14)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

MINI PCIE (WLAN/WMAX/3G)

MINI PCIE (WLAN/WMAX/3G)

MINI PCIE (WLAN/WMAX/3G)

Date: Sheet

Date: Sheet

Date: Sheet

3

R281 *3G@0_4R281 *3G@0_4

+3V_Mini2_VDD

Q22

Q22

3G@2N7002E

3G@2N7002E

PCLK_SMB 3G_SMCLK

3

R282 *3G@0_4R282 *3G@0_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

2

2

R280

R280

3G@10K_4

3G@10K_4

1

1

1

+3V_Mini2_VDD

ZE8

ZE8

ZE8

19 32Tuesday, September 29, 2009

19 32Tuesday, September 29, 2009

19 32Tuesday, September 29, 2009

R283

R283

3G@10K_4

3G@10K_4

3G_SMDATA

of

of

of

1A

1A

1A

MB USB (USB)

5

4

3

2

1

2.5" SATA HDD(HDD)

C351

C351

100u/6.3V_3528

100u/6.3V_3528

+5V

+5VPCU

U20

2

4
1
9

R9 Short_4R9 Short_4

R10 Short_4R10 Short_4

U20
IC OTHER(8P)G547E2P81U(MSOP8)

IC OTHER(8P)G547E2P81U(MSOP8)

IN1
IN23OUT2

EN#
GND
GND-C

C446

C446

4.7u/10V_6

4.7u/10V_6

DD

USB_EN#(18,21)

USBP6-(13)
USBP6+(13)

+5V_USB +5V_USB

8

OUT3

7
6

OUT1

5

OC#

BUSBP6­BUSBP6+

12

D2

D2
*MLVG06031R_4

*MLVG06031R_4

12

D1

D1
*MLVG06031R_4

*MLVG06031R_4

C447

C447

0.1u/10V_4

0.1u/10V_4

+5V_USB

2A

+

+

C448

C448

100u/6.3V_3528

100u/6.3V_3528

CN17

CN17

1

VDD

2

D-

3

D+

4

GND1

USB Port1

USB Port1

GND6
GND5

GND7
GND8

6
5

7
8

CN9

CN9

GND
GND

RXN
RXN

GND
GND

GND
GND

88513-1041

88513-1041

A1
B1

A2

RXP
RXP

TXN
TXN

TXP
TXP

DP
DP

+5V
+5V

+5V
+5V

SATA_TXP0

SATA_TXN0

SATA_RXN0

+5V_SATA

C370 0.01u/25V_4C370 0.01u/25V_4

C369 0.01u/25V_4C369 0.01u/25V_4

C368 0.01u/25V_4C368 0.01u/25V_4

C367 0.01u/25V_4C367 0.01u/25V_4

0.94A(80mils)

B2

A3
B3

A4
B4

A5
B5

A6
B6

A7
B7

A8
B8

A9
B9

A10
B10

SATA_TXP0_R

SATA_TXN0_R

SATA_RXN0_R

SATA_RXP0_RSATA_RXP0

+5V_SATA

C375

C375

C371

C371

0.1u/10V_4

0.1u/10V_4

*0.1u/10V_4

*0.1u/10V_4

SATA ESD(EMC)

C362

C362

10u/10V_8

10u/10V_8

R232 Short_8R232 Short_8

+

+

8/5 : because of the space is not enough, so, del SATA ESD U12 and C363.

HOLE (EXC)

CC

BB

HOLE2

HOLE2

*HG-C276D94P2

*HG-C276D94P2

2
3
4

8

HOLE15

HOLE15

*HG-C276D94P2

*HG-C276D94P2

2
3
4

8

HOLE4

HOLE4
H-C276D142P2

H-C276D142P2

1

HOLE10

HOLE10
H-C236D142P2

H-C236D142P2

1

1

9

1

9

5
6
7

5
6
7

HOLE7

HOLE7
H-TC236BC197D142P2

H-TC236BC197D142P2

1

HOLE14

HOLE14
H-C197D142P2

H-C197D142P2

1

HOLE3

HOLE3

*hg-c197d94p2

*hg-c197d94p2

2
3
4

8

HOLE6

HOLE6

*HG-C276D94P2

*HG-C276D94P2

2
3
4

8

HOLE12

HOLE12
H-C197D142P2

H-C197D142P2

5
6
7

1

9

5
6
7

1

9

HOLE8

HOLE8
H-TC236BC197D142P2

H-TC236BC197D142P2

1

1

HOLE16

HOLE16
*H-C91D91N

*H-C91D91N

*HG-C276D94P2

*HG-C276D94P2

2
3
4

*HG-C256D94P2

*HG-C256D94P2

2
3
4

1

HOLE9

HOLE9

1

8

9

HOLE17

HOLE17

1

8

9

HOLE11

HOLE11
H-TC236BC197D142P2

H-TC236BC197D142P2

*HG-C237D94P2

*HG-C237D94P2

HOLE13

HOLE13

*HG-C276D94P2

*HG-C276D94P2

2

5
6
7

5
6
7

1

HOLE18

HOLE18

2
3
4

1

8

9

3
4

HOLE1

HOLE1

*HG-C276D79P2

*HG-C276D79P2

2
3
4

5
6
7

5
6
7

1

8

9

5
6
7

1

8

9

HOLE5

HOLE5
H-C236D142P2

H-C236D142P2

1

SATA RE-DRIVER IC(XXX )

+1.5V

From SB SATA

+1.5V

+1.5V

SATA_TXP0_ICH

SATA_TXN0_ICH

SATA_RXN0_ICH

SATA_RXP0_ICH

Input

Output

AUTOPW_EN

A_EQ
B_EQ

SATA_TXP0_ICH(12)

SATA_TXN0_ICH(12)

SATA_RXN0_ICH(12)

SATA_RXP0_ICH(12)

R367 4.7K_4R367 4.7K_4
R161 *4.7K_4R161 *4.7K_4
R163 *4.7K_4R163 *4.7K_4

R368 Short_8R368 Short_8

C123

C123

C233

C242

C242
.1u_4

10

16

6

A_BST#20B_BST#

GND3A_EQ

17

AUTOPW_EN

VCC

GND

B_EQ18GND

13

19

21

B_EQ

A_EQ

1

RX_0P

2

RX_0N

4

TX_1N

5

TX_1P

7

EN

.1u_4

U38

U38

VCC

GND_P

TX_0P

TX_0N

RX_1N

RX_1P

A_PRE

B_PRE

PS8511A

PS8511A

15

14

12

11

9

8

SATA_TXP0_R

SATA_TXN0_R

SATA_RXN0_R

SATA_RXP0_R

C233
*2.2u_6

*2.2u_6
.01u/16V_4

.01u/16V_4

To SATA HDD conn

Output

Input

R357 *4.7K_4R357 *4.7K_4

R356 *4.7K_4R356 *4.7K_4

8/3 del pull down resistor.
FAE: Due to a pull-down resistor at pin 8 and 9 inside PS8511A

+1.5V

+1.5V

SATA_TXP0_ICH

SATA_TXN0_ICH

SATA_RXN0_ICH

SATA_RXP0_ICH

R185 *0_4R185 *0_4

R358 *0_4R358 *0_4

R359 *0_4R359 *0_4

R360 *0_4R360 *0_4

SATA_TXP0_L

SATA_TXN0_L

SATA_RXN0_L

R364 *0_4R364 *0_4

R361 *0_4R361 *0_4

R362 *0_4R362 *0_4

R363 *0_4R363 *0_4

SATA_TXP0_R

SATA_TXN0_R

SATA_RXN0_R

SATA_RXP0_RSATA_RXP0_L

PARADE : PS8511A

EMI bypass caps (XXX)

+3V +3V +5V +5V +5V +5VPCU +5VPCU +5VPCU +3VPCU +3VPCU

C452

C451

0.1u/10V_4

0.1u/10V_4

+1.5V +1.5V VIN VIN VIN VIN VIN

C235

C235

AA

0.1u/10V_4

0.1u/10V_4

PAD

0.1u/10V_4

0.1u/10V_4

C84

C84

0.1u/10V_4

0.1u/10V_4

PAD1PAD1

0.1u/10V_4

0.1u/10V_4

C452

C14

C14

C451

5

C260

C260

0.1u/10V_4

0.1u/10V_4

C15

C15

0.1u/10V_4

0.1u/10V_4

C433

C433

0.1u/10V_4

0.1u/10V_4

C18

C18

0.1u/10V_4

0.1u/10V_4

+3VPCU +3VPCU +3VPCU

C402

C402

0.1u/10V_4

0.1u/10V_4

C5

C394

C394

0.1u/10V_4C50.1u/10V_4

0.1u/10V_4

0.1u/10V_4

C405

C405

C442

C442

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

C16

C16

C241

C241

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

C69

C69

C398

C398

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

VIN VIN VIN

C329

C329

C472

C472

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

0.1u/10V_4

C109

C109

0.1u/10V_4

0.1u/10V_4

C473

C473

0.1u/10V_4

0.1u/10V_4

4

C474

C474

0.1u/10V_4

0.1u/10V_4

PIN 18,19

PIN 8,9

PIN 10,20

PIN 17

Input Equalization setting: Internal pull down ~150Kohm
A_EQ/B_EQ = LOW: For short and medium length PCB traces
A_EQ/B_EQ = HIGH: For long length PCB traces

Output Pre-emphasis Setting: Internal pull down ~150Kohm
A_PRE/B_PRE = LOW, Pre-emphasis disabled
A_PRE/B_PRE = HIGH, Pre-emphasis enabled

Output Level Boost setting: Internal pull up~150Kohm
A_BST#/B_BST# = HIGH, SATAi/m output level 400~700mVpp
A_BST#/B_BST# = LOW, SATAx output level 800~1200mVpp

Automatic Power Saving Enable: Internal pull down~150Kohm
AUTOPW_EN = HIGH, automatic power saving enable
AUTOPW_EN = LOW, automatic power saving disable

3

(default--SATA internal)

(default)

(default)

(default)

2

PARADE : PS8511A

A_PRE B_PRE

EN

0 XX

1 00

1 10

1 01

1 11

CH-0 CH-1

Standby

0dB

Pre-emphasis (3.5dB)

0dB Pre-emphasis (3.5dB)

Pre-emphasis (3.5dB) Pre-emphasis (3.5dB)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

USB/HDD/HOLE

USB/HDD/HOLE

USB/HDD/HOLE

Date: Sheet

Date: Sheet

Date: Sheet

Standby

0dB

0dB

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

ZE8

ZE8

ZE8

20 32Tuesday, September 29, 2009

20 32Tuesday, September 29, 2009

20 32Tuesday, September 29, 2009

of

of

1

of

1A

1A

1A

Keyboard(KBC)

5

4

BuleTooth (BTM)

3

2

1

LED D/B (UIF)

CN2

MX7

MX7(18)

MX6

MX6(18)

MX5

MX5(18)

MY0

MY0(18)

MY1

DD

MY1(18)

MY2

MY2(18)

MX4

MX4(18)

MY3

MY3(18)

MY4

MY4(18)

MY5

MY5(18)

MY6

MY6(18)

MY7

MY7(18)

MY8

MY8(18)

MX3

MX3(18)

MY9

MY9(18)

MX2

MX2(18)

MX1

MX1(18)

MY10

MY10(18)

MY11

MY11(18)

MX0

MX0(18)

MY12

MY12(18)

MY13

MY13(18)

MY14

MY14(18)

MY15

MY15(18)

CN2

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
232425

KB CONN(88502-2401)

KB CONN(88502-2401)

BT_POWERON#(18)

26

+3V

USBP5+(13)
USBP5-(13)

+

+

C379

C379

2.2u/6.3V_6

2.2u/6.3V_6

R249 Short_4R249 S hort_4

1

2

BT_LED

USBP5+
USBP5-

C372 *0.01u/16V_4C372 *0.01u/16V_4

Q20

Q20

AO3413

AO3413

BT_LED

3

+

+

C376

C376
*2.2u/6.3V_6

*2.2u/6.3V_6

+3V_BT_POWER

+3V_BT_POWER

C374

C374
1000p/50V_4

1000p/50V_4

CN7

CN7

1
2
3
4

7

5

6

BT_CONN(88266-05001-06)

BT_CONN(88266-05001-06)

CN1

CN1

15
16

LED CONN

LED CONN

+3V

1

BT_LED

2
3
4
5
6
7
8
9
10
11
12
13
14

+3VPCU

WLAN_LED# (18,19)

3G_EC_LED# (18)
PWRLED# (18)
SUSLED# (18)
BATLED0# (18)
BATLED1# (18)

KILL_SW_WL# (18)
KILL_SW_3G# (18)

擺放要靠近

WLAN_LED#

BATLED0#
BATLED1#

KILL_SW_WL#
KILL_SW_3G#
3G_EC_LED#

CN2

C113 *220P/50V_4C113 *220P/50V_4

C88 *220P/50V_4C88 *220P/50V_4
C89 *220P/50V_4C89 *220P/50V_4

C100 *220P/50V_4C100 *220P/50V_4
C90 *220P/50V_4C90 *220P/50V_4
C87 *220P/50V_4C87 *220P/50V_4

Be careful that bluetooth module PIN 2 is GND and PIN 5 is BT_LED.

A0 test : have free fall function, stuff R329,

For EMI Reserve Caps for debug

CC

MY9

MY8

MY1
MY2
MX4

MY12
MY13
MY14
MY15

MX2

MX3

CP5

CP5

7
5
3
1

*100p_8P4R

*100p_8P4R

CP1

CP1

7
5
3
1

*100p_8P4R

*100p_8P4R

CP3

CP3

8
6
4
2

*100p_8P4R

*100p_8P4R

CP6

CP6

8
6
4
2

8
6
4
2

7
5
3
1

8
6
4
2

*100p_8P4R

*100p_8P4R

CP2

CP2

7
5
3
1

*100p_8P4R

*100p_8P4R

CP4

CP4

7
5
3
1

*100p_8P4R

*100p_8P4R

MX7

7

MX6

5

MX5

3

MY0MY3

1

MX0

8

MY11

6

MY10

4

MX1

2

MY7

8

MY6

6

MY5

4

MY4

2

Touch Pad D/B (TPD)

+5V_TP +5V

L20

L20
NHCB2012KF-131T10/1A/130ohm_8

NHCB2012KF-131T10/1A/130ohm_8

C273

C273

0.1u/10V_4

0.1u/10V_4

+5V_TP

CN3

CN3

1
2
3
456

TP CONN(88513-044N)

TP CONN(88513-044N)

TPCLK_8
TPDATA_8

L19 NHCB2012KF-131T10/1A/130ohm_8L19 NHCB2012KF-131T10/1A/130ohm_8
L18 NHCB2012KF-131T10/1A/130ohm_8L18 NHCB2012KF-131T10/1A/130ohm_8

C259

C259

10p/50V_4

10p/50V_4

C252

C252

10p/50V_4

10p/50V_4

C274

C274

*0.1u/10V_4

*0.1u/10V_4

G SENSOR(GSR)

+3V

C250

C250

C251

+5V

R159

R159

R162

R162

4.7K_4

4.7K_4

4.7K_4

4.7K_4

TPCLK
TPDATA

TPCLK (18)
TPDATA (18)

C251

10u/6.3V_8

10u/6.3V_8

0.1u/10V_4

0.1u/10V_4

SMBCK1(3,16,19)

SMBDT1(3,16,19)

9/2 C-test : change footprint to sensor-3x3-5-16p-smt
9/24 Ramp-test : change footprint to sensor-3x3-5-16p-smt.(part two)

FAE : Because of internal pull-high in SDO,
I2C address for SDO floated is the same as that for SDO high

SMBCK1

SMBDT1

+3V

if not, stuff R327 just can stuff one of them

6/23 A2 test : per Acer request,
use interrupt pin to detect panel status
so, stuff R150, remove R151

U8

U8

1

Vdd_IO

2

NC

3

NC

4

SCL/SPC

5

GND

6

SDA/SDI/SDO

7

SDO

8

CS

IC(16P) LIS33DETR

IC(16P) LIS33DETR

SMbus address 1D

Reserved

Reserved

GND

GND

Reserved

GND

9

10

11

INT

12

13

14

Vdd

15

16

T22 : add for SMT request

T22T22

G_SENSOR

R150 Short_4R150 S hort_4

+3V

R151*0_4 R151*0_4

G_SENSOR_INT# (13)

BB

Card Reader/USB DB
CONNECTER(MMC)/Power Connector

B-test 8/11: for EMI

MIC1_R2(17)

MIC1_L2(17)

MIC1_JD#(17)

LINEOUT_JD#(17)

HPOUT-L(17)

HPOUT-R(17)

SPDIF_OUT(17)

USBP0+(13)
USBP0-(13)

USBP1+(13)
USBP1-(13)

USBP3+(13)
USBP3-(13)

PECLK_LAN(3)
PECLK_LAN#(3)

AA

MIC1_R3

C389 *470p/50V_4C389 *470p/50V_4

MIC1_L3

C390 *470p/50V_4C390 *470p/50V_4

HPOUT-L1

C392 *47N/25V_4C392 *47N/25V_4

HPOUT-R1

C393 *47N/25V_4C393 *47N/25V_4

BLM18PG471SN1D_6

BLM18PG471SN1D_6

R252

R252
R253

R253

BLM18PG471SN1D_6

BLM18PG471SN1D_6

R257 Short_6R257 S hort_6
R258 Short_6R258 S hort_6

SPDIF_OUT

USBP1+

USBP1-

5

ADOGND

CN4

CN4

1

MIC1_R3

2

MIC1_L3

3
4
5
6

HPOUT-L1

7

HPOUT-R1

8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

ACES_88242-40XX_LVDS

ACES_88242-40XX_LVDS

ADOGND

23
24
25
26
27
28
29

CLK48_CARD

30
31
32

PLTRST#

33

NBSWON#

34

PWRLED#

35
36

PCIE_WAKE#

37

LID#

38
39
40
41
42
43
44
45
4746

+3V_S5 +3V +5VPCU

C307

C307

1000p/50V_6

1000p/50V_6

PCIE_TXN1 (13)
PCIE_TXP1 (13)

PCIE_RXN1 (13)
PCIE_RXP1 (13)

CLK48_CARD (3)
USB_EN# (18,20)
CLKREQ#_LAN (3)
PLTRST# (7,13,18,19)
NBSWON# (18)

+3VPCU

PCIE_WAKE# (14)
LID# (14,18,22)

+3V_S5

+3V
+5VPCU

8/11 B-test : for EMI

C293

C293

*0.1u/10V_4

*0.1u/10V_4

CRT D/B (CRT)

C291

C291

0.1u/10V_4

0.1u/10V_4

4

+3V +5V +3VPCU

C11

C11

1000p/50V_6

1000p/50V_6

CN16

CN16

23
24

Aces-87242-2201

Aces-87242-2201

C10

C10

0.1u/10V_4

0.1u/10V_4

+3V

+5V

+3VPCU

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

CRT_R1
CRT_G1

CRT_B1
VGAVSYNC

VGAHSYNC
DDCCLK

DDCDATA
CRT_SENSE#

SATA_LED#_R
CAPSLED#
NUMLED#

LID_touch panel#

Recover_LED#

C13

C13

*0.1u/10V_4

*0.1u/10V_4

+3V

C60

C60

1000p/50V_6

1000p/50V_6

3

VGAVSYNC (7)

VGAHSYNC (7)
DDCCLK (7)

DDCDATA (7)
CRT_SENSE# (18)

CAPSLED# (18)
NUMLED# (18)

RECOVER_BUTTON# (18)

LID_touch panel# (14,18)

Recover_LED# (18)

CRT_R1

CRT_G1

CRT_B1

DDCCLK
DDCDATA

L2B LM18BA220SN1D/0.5A/22ohm_6 L2BLM18BA220SN1D/0.5A/22ohm _6

L1B LM18BA220SN1D/0.5A/22ohm_6 L1BLM18BA220SN1D/0.5A/22ohm _6

L3B LM18BA220SN1D/0.5A/22ohm_6 L3BLM18BA220SN1D/0.5A/22ohm _6

C1

C4

33p/50V_4C133p/50V_4

33p/50V_4C433p/50V_4

8/18:for EMI, change to 33P.
9/16 monitor test, change to CH01206JB05 12P, wait for EMI confirm

C6
33p/50V_4C633p/50V_4

C8
33p/50V_4C833p/50V_4

C3
33p/50V_4C333p/50V_4

For EMI

+3V

SATA_LED# (12)

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

KB/BT/PR/TP/LAN/LED/CR Connects

KB/BT/PR/TP/LAN/LED/CR Connects

KB/BT/PR/TP/LAN/LED/CR Connects

Date: Sheet

Date: Sheet

Date: Sheet

R7 2.2K_4R7 2.2K_4
R13 2.2K _4R13 2.2K_4

SATA_LED#_R

+3V

2

4

53

1

2

TC7SH08FU

TC7SH08FU

R17

R17

10K_4

10K_4

U2

U2

R16*0_4 R16*0_4

CRT_R

CRT_G

CRT_B

C2
33p/50V_4C233p/50V_4

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

CRT_R (7)

CRT_G (7)

CRT_B (7)

ZE8

ZE8

ZE8

21 32Tuesday, September 29, 2009

21 32Tuesday, September 29, 2009

1

21 32Tuesday, September 29, 2009

1A

1A

1A

of

of

of

5

Backlight Control(LDS)

+3V

R236

R236
10K_4

DD

DISPON

CC

10K_4

D27 BAS316D27 BAS316

+3V

3

2

Q19

Q19

2N7002E

2N7002E

1

2

Q18

Q18
DTC144EU

DTC144EU

1 3

BL#

Q17

Q17

2N7002E

2N7002E

R223

R223
10K_4

10K_4

3

2

R227

R227
100K/F_4

1

100K/F_4

4

LID# (14,18,21)

INT_LVDS_BLON (7)

EC_FPBACK# (18)

LED Panel(LDS)

VIN

C344

C344

+

+

10u/25V_1210

10u/25V_1210

INT_LVDS_PWM(7)

DMIC_CLK(17)

DMIC_DAT(17)

R222 Short_8R222 S hort_8

C339

C339

1000p/50V_4

1000p/50V_4

CONTRAST(18)

C391 *3300P/50V _4C391 *3300P/50V_4

B-test 8/11: for EMI

R190 BLM21PG331S N1D_8R190 BLM21PG331SN1D_8

R194 BLM21PG331S N1D_8R194 BLM21PG331SN1D_8

V_BLIGHT

R255 Short_4R255 S hort_4

R256 *0_4R256 *0_4

3

C test: 8/31: exchange V_BLIGHT and LCDVCC pin define

PHL_CLK
PHL_DATA

TXLOUT0­TXLOUT0+

TXLOUT1­TXLOUT1+

TXLOUT2­TXLOUT2+

TXLCLKOUT­TXLCLKOUT+

LCD_VADJ

DISPON

R207 Short_4R207 S hort_4
R205 Short_4R205 S hort_4

DMIC_CLK_R

DMIC_DAT_R

ramp test : 9/29 : del L23

C330

C330

0.1u/50V_6

0.1u/50V_6

DMIC_CLK_R

DMIC_DAT_R

CCD_POWER

C314

C314

*1000p/50V_4

*1000p/50V_4

C317

C317

*1000p/50V_4

*1000p/50V_4

PHL_CLK(7)
PHL_DATA(7)

TXLOUT0-(7)

TXLOUT0+(7)

TXLOUT1-(7)

TXLOUT1+(7)

TXLOUT2-(7)

TXLOUT2+(7)

TXLCLKOUT-(7)
TXLCLKOUT+(7)

LCDVCC

USBP7-(13)
USBP7+(13)

C397

C397

*0.1u/10V_4

*0.1u/10V_4

V_BLIGHT

+3V

USBP7-_CCD
USBP7+_CCD

CN6

CN6

1
2
3
4
5
6
7
8
9

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

LCD(111C30-000001-G4 )

LCD(111C30-000001-G4 )

2

1

LED Panel POWER SWITCH(LDS)

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

31

27

31

34

28

34
29
30

LCDVCC_1

R251 Short_8R251 S hort_8

C361

C361

*0.1u/10V_4

*0.1u/10V_4

+3V

C340

C340

1u/10V_6

1u/10V_6

INT_LVDS_DIGON(7)

R244

R244

100K_4

100K_4

C381

C381

0.1u/10V_4

0.1u/10V_4

U13

U13

6

IN

4

IN

3

ON/OFF

IC(5P) G5243AT11U

IC(5P) G5243AT11U

C382

C382

33p/50V_4

33p/50V_4

OUT

GND

GND

1

2

5

LCDVCC

12

LCDVCC_1

C360

C360

4.7U/10V/8

4.7U/10V/8

+3V_HDMI

34

33

CFG

DDCBUF_EN

32

VCC

DDC_EN

30

31

29

GND

SDA_SINK

HPD_SINK

LS_REXT

HDMI_HP_IV#_RR

HDMI_HP_A

MB_HDMI_DDCDAT
MB_HDMI_DDCCLK

+3V_HDMI

HDMI_OE#

26

27

25

28

OE#

VCC

GND

GND

SCL_SINK

OUT_D1-

OUT_D1+

VCC

OUT_D2-

OUT_D2+

GND

OUT_D3-

OUT_D3+

VCC

OUT_D4-

OUT_D4+

12

+3V_HDMI

C9

C9

*HD@.1u/16V_4

*HD@.1u/16V_4

24

HDMITX2P_C

23

HDMITX2N_C

22
21

+3V_HDMI

HDMITX1P_C

20

HDMITX1N_C

19
18

HDMICLKP_C

17

HDMICLKN_C

16
15

+3V_HDMI+3V_HDMI

HDMITX0P_C

14

HDMITX0N_C

13

SDVO_CTRLCLK (7)
SDVO_CTRLDATA (7)

C449

C449

HD@.1u/16V_4

HD@.1u/16V_4

3

+5V

OE# control for
power saving

HDMI_HP_A

C450

C450

*HD@.1u/16V_4

*HD@.1u/16V_4

HD@.1u/16V_4C453 HD@ .1u/16V_4C453

HDMITX2P_C

HDMITX2N_C
HDMITX1P_C

HDMITX1N_C
HDMITX0P_C

HDMITX0N_C
HDMICLKP_C

HDMICLKN_C

MB_HDMI_DDCCLK
MB_HDMI_DDCDAT

HDMI_HP_A

+3V

R5
HD@10K_4R5HD@10K_4

HDMI_OE#

3

Q26

Q26
HD@2N7002E

HD@2N7002E

1

C7

C7

HD@.1u/16V_4

HD@.1u/16V_4

+5V_HDMI

2 1

D29 HD@ RSX101M-30D29 HD@RSX101M-30

2

10
11
12
13
14
15
16
17
18
19

C454

C454

1u/6.3V_4

1u/6.3V_4

C445

C445

*HD@.1u/16V_4

*HD@.1u/16V_4

CN18

CN18

SHELL1

1

D2+

SHELL3

2

D2 Shield

3

D2-

4

D1+

5

D1 Shield

6

D1-

7

D0+

8

D0 Shield

9

D0­CK+
CK Shield
CK­CE Remote
NC
DDC CLK
DDC DATA
GND
+5V
HP DET

SHELL4
SHELL2

HD@HDMI CONN

HD@HDMI CONN

2

20

Camera(CCD)

22

23
21

+3V

R260 Short_8R260 S hort_8

LED touch Panel connector (LDS)

USBP8-(13)

USBP8+(13)

Touch_panel_HK(18)

ramp test : 9/29 : del L24

CCD_POWER

R225 Short_4R225 S hort_4
R216 Short_4R216 S hort_4

Touch_panel_HK

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

LED Panel/CCD/HDMI

LED Panel/CCD/HDMI

LED Panel/CCD/HDMI

Date: Sheet

Date: Sheet

Date: Sheet

+

+

C320 10u/10V_8

C320 10u/10V_8

C396 1000p/50V_4C396 1000p/50V_4

C395 *0.1u/10V_4C395 *0.1u/10V_4

+3V

USBP8-_TP
USBP8+_TP

LED panel touch_CONN(88266-020L)

LED panel touch_CONN(88266-020L)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

CN5

CN5

1
2
3
4

7

5

6

ZE8

ZE8

ZE8

1A

1A

1A

of

of

of

22 32Tuesday, September 29, 2009

22 32Tuesday, September 29, 2009

1

22 32Tuesday, September 29, 2009

HDMI

HDMI(HDM)

HP-detect for
PS8101 only

HDMI_HP_IV#(7)

*HD_8101@7.5K/F_4

*HD_8101@7.5K/F_4

BB

HDMI_HP_IV#

R6

R6

+3V

R8

R8

*HD_8101@20K/F_6

*HD_8101@20K/F_6

3

R15

R15
HD_8101T@Short_4

HD_8101T@Short_4

HDMI_HP_IV#_RR

2

Q23 *HD_8101@2N7002EQ23 *HD_8101@2N7002E

1

SDVO I2C Control

+5V

+5V

2 1

D4 HD@RB500V-40D4 HD@RB500V-40

2 1

D3 HD@RB500V-40D3 HD@RB500V-40

R12 HD@2.2K_4R12 HD@2.2K_4

R11 HD@2.2K_4R11 HD@2.2K_4

PS8101 PS8101T

AA

pin 7

pin 34

pin 35

AL008101000 AL008101001

HPD

DDCBUF_EN

CFG

5

MB_HDMI_DDCCLK

MB_HDMI_DDCDAT

HPD#

CFG0

CFG1

PS8101 : AL008101000
PS8101T : AL008101001---defult

HDMITX2P(7)
HDMITX2N(7)

HDMITX1P(7)
HDMITX1N(7)

HDMICLKP(7)
HDMICLKN(7)

HDMITX0P(7)
HDMITX0N(7)

HDMITX2P
HDMITX2N

HDMITX1P
HDMITX1N

HDMICLKP
HDMICLKN

HDMITX0P
HDMITX0N

Equalization Control

PC1

PC0

EQ Control

8dB

LL

4dB

H

L

HL
H

+3V +3V_HDMI

R342 HD@0_6R342 HD@ 0_6

12dB

H 0dB

4

C444

C444

HD@2.2u/6.3V_6

HD@2.2u/6.3V_6

R18 HD@4.7K_4R18 HD@4.7K_4

R21 *HD@4.7K_4R21 *HD@4.7K_4
R23 *HD@4.7K_4R23 *HD@4.7K_4

+3V

Active Buffer

U1

+3V_HDMI

+3V

R22 HD@4.7K_4R22 HD@4.7K_4
R20 *HD@4.7K_4R20 *HD@4.7K_4

U1

R19 HD@499/F_4R19 HD@499/F_4

37

GND

38

IN_D1-

39

IN_D1+

40

VCC

41

IN_D2-

42

IN_D2+

43

GND

44

IN_D3-

45

IN_D3+

46

VCC

47

IN_D4-

48

IN_D4+

49

GND

+3V_HDMI

35

36

GND

HD@PS8101T

HD@PS8101T

GND1VCC2PC03PC14GND5REXT6HPD7SDA8SCL9RT_EN#10VCC11GND

FOR EMI

HDMICLKP_C HDM ICLKN_C

R2 *HD@100/F_4R2 *HD@100/F_4

HDMITX0P_C HDMITX0N_C

R1 *HD@100/F_4R1 *HD@100/F_4

HDMITX1P_C HDMITX1N_C

R3 *HD@100/F_4R3 *HD@100/F_4

HDMITX2P_C HDMITX2N_C

R4 *HD@100/F_4R4 *HD@100/F_4

C12

C443

C443

*HD@.1u/16V_4

*HD@.1u/16V_4

C12

HD@.1u/16V_4

HD@.1u/16V_4

5

VA

Charger(DCD)

DD

DC-IN JACK

PJ2

PJ2

1
2
3

4

5

POWER_JACK

POWER_JACK

dcjk-2dc3003-001211-5p

dcjk-2dc3003-001211-5p

CC

BB

C114F3-108A1-L_Batt_Conn

C114F3-108A1-L_Batt_Conn

PJ1

PJ1

89
7
6
5
4
3
2
1

10

AA

PA1

PC4

PC4

PC150

PC150

*0.1u/50V_6

*0.1u/50V_6

0.1u/50V_6

0.1u/50V_6

PU5

PU5
CM1293A-04SO

CM1293A-04SO

1

CH1

2

VN

CH23CH3

Add ESD diode base on
EC FAE suggestion

MBAT+

MBAT+

PR152

PR152
100_4

100_4

CH4

VP

PR65

PR65
*Short_6

*Short_6

5

6

5

4

PC127

PC127

47p/50V_6

47p/50V_6

PC148

PC148

2200p/50V_6

2200p/50V_6

MBCLK

+3VPCU

MBDATATEMP_MBAT

100p/50V_6

100p/50V_6

PR63 *0_6PR63 *0_6

PD5 RB500V-40PD5 RB500V-40

PC63

PC63

47p/50V_6

47p/50V_6

PR150

PR150
100_4

100_4

MBDATA

PL10

PL10

HI0805R800R-10/5A/80ohm_8

HI0805R800R-10/5A/80ohm_8

ACIN(18)

PC67

PC67

12

PC121

PC121

0.1u/50V_6

0.1u/50V_6

MBCLK

PR148

PR148

*100K/F_6

*100K/F_6

VA

ACIN

PL1

PL1

HI0805R800R-10/5A/80ohm_8

HI0805R800R-10/5A/80ohm_8

PL4

PL4

HI0805R800R-10/5A/80ohm_8

HI0805R800R-10/5A/80ohm_8

PR147

PR147
100K/F_6

100K/F_6

12

PC122

PC122

0.01u/16V_4

0.01u/16V_4

+3VPCU

PC6

PC6

0.1u/50V_6

0.1u/50V_6

PD1

PD1
1N4148WS

1N4148WS

BAT-V

4

+3VPCU

PR168

PR168
100K/F_6

100K/F_6

PR23

PR23

49.9/F_6

49.9/F_6

PR164

PR164

82.5K/F_6

82.5K/F_6

PR48

PR48

22K/F_6

22K/F_6

TEMP_MBAT (18)

4

PC145

PC145

0.1u/50V_6

0.1u/50V_6

PC52

PC52
*1u/16V_6

*1u/16V_6

PD10

PD10
SX34

SX34

MBDATA(18)

MBCLK(18)

PD9

PD9

CYSMAJ20

CYSMAJ20

PC51

PC51

0.01u/50V_6

0.01u/50V_6

2 1

PC30

PC30

0.1u/50V_6

0.1u/50V_6

PC31

PC31

0.1u/50V_6

0.1u/50V_6

PC50

PC50
*0.01u/50V_6

*0.01u/50V_6

0.01_3720

0.01_3720
PR5

PR5

1 2

+3VPCU

DCINDCIN

1

11

VDDSMB

9

SDA

10

SCL

13

ACOK

22

DCIN

2

ACIN

3

VREF

4

ICOMP

5

NC

6

VCOMP

PR47

PR47

2.21K/F_6

2.21K/F_6

PC49

PC49

0.01u/50V_6

0.01u/50V_6

NC

R1

CSIP_1

PR45

PR45

10/F_6

10/F_6

GND33GND32GND31GND

0.1u/50V_6

0.1u/50V_6

VA2

PC47

PC47

0.1u/50V_6

0.1u/50V_6

CSIP

30

28

CSSP

NC

7

3300p/50V_4

3300p/50V_4

3

PC12

PC12

PU2

PU2

ISL88731A

ISL88731A

ICM

8

1 2

PC44

PC44

3

CSIN

27

CSSN

PR43

PR43
10/F_6

10/F_6

VA2

PC43

PC43
1u/16V_6

1u/16V_6

26

VCC

NC

14

C-STAGE change source

PR6

PR6
220K/F_6

220K/F_6

1 6

PR10

PR10

2

220K/F_6

220K/F_6

3

IMD2AT108

IMD2AT108

PR20

PR20

4.7_6

4.7_6

88731_VDDP

21

VDDP

25

BOOT

24

UGATE

23

PHASE

20

LGATE

19

PGND

CSOP

18

CSOP

CSON

17

CSON

16

NC

15

VBF

29

GND

GND

12

ICMNT (18)

PQ1

PQ1

PR40

PR40

2.7_6

2.7_6

PR172

PR172
*Short_4

*Short_4

1
2
3

5

4

88731_DH

88731_LX

88731_DL

PR180

PR180
10/F_6

10/F_6

PC27

PC27

0.1u/50V_6

0.1u/50V_6

PR179

PR179
10/F_6

10/F_6

PQ36

PQ36
AO4427

AO4427

4

PC25

PC25

1u/16V_6

1u/16V_6

PD8

PD8
RB500V-40

RB500V-40

PC34

PC34

0.1u/50V_8

0.1u/50V_8

PR16

PR16
100_4

100_4

CSOP_1

BAT-V

8
7
6
5

2

VIN

PC147

PC147

*0.1u/50V_6

*0.1u/50V_6

PC58

PC58

2200p/50V_6

2200p/50V_6

PQ3

PQ3
AO4932

AO4932

D1

D1

1

D1 S1/D2

D1 S1/D2

2

G2

G2

3

S2

S2

4

BAT-V

2

G1

G1

PC146

PC146
2200p/50V_6

2200p/50V_6

D/C#(18)

PC57

PC57

*0.1u/50V_6

*0.1u/50V_6

8

7

6

5

1

C-STAGE change source

VIN

PC56

PC56

10u/25V_1206

10u/25V_1206

PR58

PR58

0.01_3720

PL6

PL6

6.8uH/4.5A_7X7X3

6.8uH/4.5A_7X7X3

PR56

PR56

2.2/F_6

2.2/F_6

PC55

PC55
2200p/50V_6

2200p/50V_6

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

0.01_3720

1 2

CSOP_1

BAT-V

CHARGER (ISL88731)

CHARGER (ISL88731)

CHARGER (ISL88731)

PQ4

PQ4
AO4427

AO4427

1
2
3

PR57

PR57

4

33K_6

33K_6

PR59

PR59

10K_6

10K_6

3

2

PQ5

PQ5

2N7002K

2N7002K

1

PC130

PC130

2200p/50V_6

2200p/50V_6

PC62

PC62

10u/25V_1206

10u/25V_1206

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

1

8
7
6
5

PC131

PC131

0.01u/50V_6

0.01u/50V_6

PC60

PC60

10u/25V_1206

10u/25V_1206

ZE8

ZE8

ZE8

BAT-V

PC162

PC162

1000p/50V_4

1000p/50V_4

BAT-VBAT-V

23 34Tuesday, September 29, 2009

23 34Tuesday, September 29, 2009

23 34Tuesday, September 29, 2009

of

of

of

PC163

PC163

1000p/50V_4

1000p/50V_4

24

1A

1A

1A

5

4

3

2

1

12

PC15

PC15
10u/25V_8

10u/25V_8

G1

G1

8

7

6

5

PD11 *SX34PD11 *SX34

+10V

PR186 Short_4PR186 Short_4

5V_DH

AO4932

AO4932

D1

D1

D1S1/D2

D1S1/D2

G2

G2

S2

S2

PQ34

PQ34

PR187

PR187
22_8

22_8

PC13

PC13

1u/6.3V_4

1u/6.3V_4

PAD33PAD34PAD

PC14

PC14

VL

PC7

PC7

4.7u/6.3V_6

4.7u/6.3V_6

1 2

PR27

PR27
0_4

0_4

1 2

5

6

3

8

7

4

NC

VIN

LDO

ONLDO

LDOREFIN

PU1

PU1

RT8206B

RT8206B

BST117DL118PVCC19NC20GND21PGND22DL223BST2

MAIND (26,28)

SUSD (28)

VCC

1 2

2

TON

PR17

PR17
0_6

0_6

1

REF

REFIN2

PGOOD2

24

PC32

PC32

0.1u/50V_6

0.1u/50V_6

REF

PR181 *0_6PR181 *0_6

ILIM2
OUT2
SKIP#

EN2

DH2

LX2

1 2

PR21

PR21
1/F_6

1/F_6

32
31
30
29
28
27
26
25

PC24

PC24
1u/16V_6

1u/16V_6

1 2

DDPWRGD_R

3V5V_EN

0.1u/50V_6

0.1u/50V_6

12

PR26

PR26

PR177

PR177

0_4

0_4

1 2

PR29

PR29
150K/F_4

150K/F_4

SKIP

3V_LX

PC29

PC29

3V_DL

AO4932 Rds=21mOhm

+3VPCU OCP:4A 500K

L(ripple current)
=(7.5-3.3)*3.3/(3.3u*500k*7.7)
~1.12687A

Iocp=4-(1.1268/2)~3.4366A
Vth=3.4366A*21mOhm=72.168mV
PR177(Ilim)=(72.168mV*10)/5uA
~144K=150K

VL

12

PR185

PR185
39K/F_4

39K/F_4

3V5V_EN 3V_DH

1

2

5V_DL

3

4

5V_LX

PC144

PC144

0.1u/50V_6

0.1u/50V_6

2 1

1 2

PR3 210K/F_4PR3 210K/F_4

PC8

PC8

0.1u/50V_6

0.1u/50V_6

2

1

PD3

PD3
ZD5.6V

ZD5.6V

PC10

PR14

PR14
100K/F_4

100K/F_4

PR13

PR13
220K/F_4

220K/F_4

3

PD2

PD2
CHN217

CHN217

PC10

0.1u/50V_6

0.1u/50V_6

+5VPCU REFIN2

9

BYP

10

OUT1

11

FB1

12

PR4

PR4
1/F_6

1/F_6

3V_DL

MAIND

SUSD

ILIM1

13

PGOOD1

14

EN1

15

DH1

16

LX1

37

PAD

36

PAD

35

VL

1u/16V_6

1u/16V_6

DDPWRGD_R

3V5V_EN

PC9

PC9

0.1u/50V_6

0.1u/50V_6

1 2

PC36

*0_4

*0_4

PC36

0.1u/50V_6

0.1u/50V_6

PQ30 AO4932

PQ30 AO4932

D1

D1

1

D1 S1/D2

D1 S1/D2

2

G2

G2

3

S2

S2

4

1 2

PR31 0_4PR31 0_4

1 2

PR32 *0_4PR32 *0_4

SKIP REF

PR178 *0_6PR178 *0_6

PR174 0_4PR174 0_4

1 2

PC41

PC41
2200p/50V_6

2200p/50V_6

G1

G1

8

7

6

5

PD12*SX34 PD12*SX34

PC138

PC138
10u/25V_1206

10u/25V_1206

PL7

PL7

3.3uH/6A_7X7X3

3.3uH/6A_7X7X3

PR163

PR163

4.7_6

4.7_6

PC137

PC137
680p/50V_6

680p/50V_6

DDPWRGD_R

f : 500k Hz

ESR : 25mΩ

Total capacitor : 167 uF

(Peak 3.929A,AVG 2.949A)

OCP : 4A

+3VPCU

+

PC133

PC133

0.1u/50V_6

0.1u/50V_6

+3VPCU

+

HWPG_SYS (18)

PR169

PR169
*0_6

*0_6

PR171

PR171
*0_6

*0_6

PR34 10K/F_6PR34 10K/F_6

PR33 Short_4PR33 Short_4

VIN

PC132

PC132
150u/6.3V_3528

150u/6.3V_3528

SYS_SHDN#(4)

DD

VIN

12

f : 400k Hz

PC143

ESR : 25mΩ

Total capacitor :169 uF

0.1u/50V_6

0.1u/50V_6

PC16

PC16

2200p/50V_6

2200p/50V_6

PC142

PC142

PC143
10u/25V_8

10u/25V_8

(Peak 6.086A,AVG 4.565A)

OCP: 5.5A

+5VPCU

PL9

PL9

3.3uH/6A_7X7X3

CC

PR1

PR1
*0_4

PC153

PC153

0.1u/50V_6

0.1u/50V_6

*0_4

PR2

PR2
0_4

0_4

150u/6.3V_3528

150u/6.3V_3528

PC152

PC152

10u/25V_1206

10u/25V_1206

+

+

PC1

PC1

3.3uH/6A_7X7X3

PR183

PR183

4.7_6

1 2

1 2

4.7_6

PC139

PC139

680p/50V_6

680p/50V_6

AO4932 Rds=21mOhm

+5VPCU OCP: 5.5A 400K

L(ripple current)
=(7.5-5)*5/(3.3u*400k*9)

BB

~1.2626A

Iocp=5.5-(1.2626/2)~4.868A
Vth=4.868A*21mOhm=102.2mV
PR9(Ilim)=(102.2mV*10)/5uA
~204.48K=210K

VIN

+5VPCU +3VPCU

3

MAIND SUSDMAIND

2

PQ22

PQ22

AO3404

AO3404

AA

1

+5V

3

2

PQ23

PQ23

AO3404

AO3404

1

+3V

2

+3VPCU

3

1

PQ24

PQ24

3G@AO3404

3G@AO3404

+3VSUS

S5_ON(18,28)

PR158

PR158

100K/F_4

100K/F_4

2

PQ27

PQ27

DTC144EU

DTC144EU

PR159

PR159

1 3

1M_6

1M_6

PR160

PR160
1M_6

1M_6

+3V_S5

3

2

1

PR161

PR161
22_8

22_8

PQ28

PQ28
DMN601K-7

DMN601K-7

+5V_S5

PR162

PR162
22_8

22_8

3

2

PQ29

PQ29
DMN601K-7

DMN601K-7

1

1.563A 1.695A 0.825A

5

4

3

+10V

PR167

PR167
1M_6

1M_6

3

2

1

PQ32

PQ32
DMN601K-7

DMN601K-7

2

+3VPCU

3

S5D

2

PQ31

PQ31

AO3404

1

AO3404

+3V_S5

PC99

PC99
2200p/50V_4

2200p/50V_4

0.389A

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

SYSTEM 5V/3V (RT8206B)

SYSTEM 5V/3V (RT8206B)

SYSTEM 5V/3V (RT8206B)

Date: Sheet

Date: Sheet

Date: Sheet

PROJECT :

+5VPCU

3

S5D

2

PQ2

PQ2

AO3404

AO3404

1

+5V_S5

0.002A

ZE8

ZE8

ZE8

1A

1A

1A

of

of

of

24 34Tuesday, September 29, 2009

24 34Tuesday, September 29, 2009

24 34Tuesday, September 29, 2009

1

5

4

3

2

1

pull-up resistor should be
68ohm with +1.05V

H_PROCHOT#(4)

PR192

PC160

PC160
1u/16V_6

1u/16V_6

PWR

12

PR192

PC158

PC158

1u/16V_6

1u/16V_6

23

20

D6

19

D5

18

D4

17

D3

16

D2

15

D1

14

D0

6

DPRSTP

7

DPRSLPVR

1

PWR

8

THRM

PR213 *Short_4PR213 *Short_4

PR215 *Short_4PR215 *Short_4

PR218 *Short_4PR218 *Short_4

PR195

PR195

10/F_6

10/F_6

VDD

DD

+5VPCU

VID6(5)

VID5(5)

VID4(5)

PR204

PR204

2.7K/F_4

2.7K/F_4

VR_PWRGD_CK410#(14)

VID3(5)

VID2(5)

VID1(5)

VID0(5)

499/F_4

499/F_4

12

VRON(18)

5

PR206

PR206

13K/F_4

13K/F_4

+3V

PR199 *Short_4PR199 *Short_4

DPRSLPVR_R

PR201

PR201

PR205

PR205

12

2.7K/F_4

2.7K/F_4

8796THRM8796VCC

8796THRM

PR207

PR207

*100K/NTC_4

*100K/NTC_4

PR209 200K/F_4PR209 200K/F_4

VIN

PR212 1.91K/F_4PR212 1.91K/F_4

PR216

PR216

10K/F_4

10K/F_4

CC

H_DPRSTP#(4,7,12)

DPRSLPVR(7,14)

PC168 0.1u/50V_6PC168 0.1u/50V_6

BB

tSW = 16.3pF x (RTON + 6.5K )

fsw=300KHz

DELAY_VR_PWRGOOD(4,7,14)

AA

PR189 68/F_4PR189 68/F_4

+1.05V

PR190 Short_4PR190 Short_4

1 2

60.4K/F_4

60.4K/F_4

8796VCC

modify PR194 for
higher OCP=17A

31

30

ILIM

VCC

MAX8796GTJ+

MAX8796GTJ+

TON

9

SHDN

PWRGD

10

11

+3VPCU

12

29

12

12

TIME

CLKEN

PR194

PR194
15K/F_4

15K/F_4

PU9

PU9

4

+5V_S5

28

VRHOT

V3P3

13

PR219

PR219
*Short_4

*Short_4

PC172

PC172

*470P/50V_4

*470P/50V_4

12

PR191

PR191
10K/F_4

10K/F_4

27

PGDIN

CCV

32

PC170

PC170

100P/50V_4

100P/50V_4

modify PIN 27 PGDIN

PC154

PR193

PR193

2.2_6

2.2_6

26

DH

PC154

0.22U/25V_6

0.22U/25V_6

25

LX

DL

CSP

CSN

22

5

4

PC161 1000p/50V_4PC161 1000p/50V_4

12

PC164

PC164

0.22U/6.3V_4

0.22U/6.3V_4

2009/06/23

PC167 1000p/50V_4PC167 1000p/50V_4

1 2

24

BST

pop PC167

3

FB

GNDS

PGND

AGND

21

33

PR220 0_8PR220 0_8

modify PR208

2

PR208

PR208

2.61K/F_4

2.61K/F_4

PC169 1000p/50V_4PC169 1000p/50V_4

PC171 1000p/50V_4PC171 1000p/50V_4

Load-line=-4mV/A
for CULV

PR210 10/F_4PR210 10/F_4

PR211 10/F_4PR211 10/F_4

3

PQ39

PQ39

AOL1448

AOL1448

5

4

213

PQ40

PQ40
AOL1718

AOL1718

5

4

213

PC165

PC165

2200p/50V_4

2200p/50V_4

add PC165

VCC_SENSE (5)

VSS_SENSE (5)

+3VPCU

+3VPCU

PC155

PC155

2200p/50V_6

2200p/50V_6

PR202

PR202

2.2/F_6

2.2/F_6

*SX34

*SX34
PD13

PD13

PC166

PC166
2200p/50V_6

2200p/50V_6

12

PC159

PC159

0.1u/50V_6

0.1u/50V_6

12

PC156

PC156

10u/25V_1206

10u/25V_1206

+

+

PC157

PC157
100u/25V_6X5.7

100u/25V_6X5.7

DCR=3m

PL11 1R0uH-3mRPL11 1R0uH-3mR

1 2

3

4

PR196

PR196
*Short_4

PR200

PR200

1.8K/F_4

1.8K/F_4

PR198

PR198

2.74K/F_4

2.74K/F_4

*Short_4

PR197

PR197

NTC 10K_6-B4.25K

NTC 10K_6-B4.25K

PR203

PR203

20K/F_4

20K/F_4

modify
PR200/PR203/PR198197

PR214 *0_4PR214 *0_4

PR217 *0_4PR217 *0_4

PR221 *0_4PR221 *0_4

PR222 *0_4PR222 *0_4

PR223 *0_4PR223 *0_4

PR224 *0_4PR224 *0_4

PR225 *0_4PR225 *0_4

VID 1.0V

VID0

VID1

VID2

VID3

VID4

VID5

VID6

2

+

+

PC173

PC173
100u/25V_6X5.7

100u/25V_6X5.7

VIN

Total capacitor : 440 uF

ESR : 4.5mΩ

f : 333k Hz

VCORE(Peak 18A,AVG 13.5A)

VCORE

OVP 15A

PC120

PC120

220u/2V_7343

220u/2V_7343

12

+

+

12

+

+

PC119

PC119

220u/2V_7343

220u/2V_7343

ESR=9m

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

VCore( IMAX8796GTJ+)

VCore( IMAX8796GTJ+)

VCore( IMAX8796GTJ+)

Date: Sheet

Date: Sheet

Date: Sheet

PROJECT :

ZE8

ZE8

ZE8

of

of

of

25 34Tuesday, September 29, 2009

25 34Tuesday, September 29, 2009

25 34Tuesday, September 29, 2009

1

1A

1A

1A

5

DDR 1.5V(DCD)

+SMDDR_VTERM

0.75A

PC105

PC105
10u/10V_8

+1.5V_SUS

10u/10V_8

1 2

PR122

PR122
*0_6

*0_6

PR107

PR107
0_4

0_4

PR117 0_6PR117 0_6

DD

CC

+SMDDR_VREF

BB

AA

5

PC97

PC97
10u/10V_8

10u/10V_8

DIS_MODE

+5VPCU

PC103

PC103

0.033u/50V_6

0.033u/50V_6

DIS_MODE

RAMP CHANGE

PC107 10u/10V_8PC107 10u/10V_8

25

GND

1

VTTGND

2

VTTSNS

3

GND

4

MODE

5

VTTREF

6

COMP

FOR DDR III

PC113

PC113

*0.033u/50V_6

*0.033u/50V_6

75K/F_4

75K/F_4

23

24

VTT

VLDOIN

PU7

PU7
TPS5116RGER

TPS5116RGER

NC7VDDQSNS8VDDQSET9S310S511NC

PR120

PR120
0_4

0_4

1 2

PR110

PR110

75K/F_4

75K/F_4

PR111

PR111

PR101 0_6PR101 0_6

21

22

VBST

DRVH

RT

RB

4

20

19

LL

DRVL

PGND

CS_GND

CS

V5IN

V5FILT

PGOOD

12

PR121 620K/F_4PR121 620K/F_4

S5_1.8V

PR115 Short_4PR115 Short_4

PR114 Short_4PR114 Short_4

S3_1.8V

RAMP DEL

A2 STAGE ADD

4

PC106 0.1u/50V_6PC106 0.1u/50V_6

18

17

16

15

14

13

PR119 100K/F_6PR119 100K/F_6

MAIND(24,28)

PR124

PR124

13K/F_6

13K/F_6

PR123

PR123

12

5.1/F_6

PC102

PC102

1u/6.3V_4

1u/6.3V_4

VIN

SUSON (7,18,28)

MAINON (18,27,28)

5.1/F_6

+3VPCU

HWPG_+1.5V_SUS (7,18)

PR80 For RT8207 400KHZ

+1.5V_SUS

578

3

2

1

27

VIN

+1.5V_SUS

1A

1A

1A

12

PC104

PC104
1u/6.3V_4

1u/6.3V_4

DDR_DH

DDR_LX

DDR_DL

+5VPCU

578

3 6

241

578

3 6

241

PQ18

PQ18
AO4468

AO4468

PQ19

PQ19
AO4710

AO4710

PC109

PC109

10u/25V_1206

10u/25V_1206

PR125

PR125

2.2/F_6

2.2/F_6

PC112

PC112
2200p/50V_6

2200p/50V_6

0.1u/50V_6

0.1u/50V_6

PL2

PL2

1uH/11A_7X7X3

1uH/11A_7X7X3

12

PC108

PC108

PC93

PC93

2200p/50V_6

2200p/50V_6

Total capacitor : 282uF

ESR : 9mΩ

f : 400k Hz

(Peak 12.601A,AVG 9.451A)

OCP: 11A

12

+

+

PC111

PC111
220u/2V_7343

220u/2V_7343

PC110

PC110

10u/10V_8

10u/10V_8

Vout =0.75X[1+(RT/TB)]

AO4710 Rdson=11.7~14.2mOhm

L(ripple current)

S3_1.8V

=(19-1.5)*1.5/(1u*400k*19)
~3.454A

PC100

PC100
*0.1u/50V_6

*0.1u/50V_6

Vth=(11-1.727)*14.2mOhm=0.1317V
RILIM(PR124)=0.1317/10uA~13K

(10u*PR124)/Rdson+Delta_I/2=Iocp

PQ20

PQ20

AO4468

AO4468

3 6

241

+1.5V

3

S5_1.8V

PC101

PC101
*0.1u/50V_6

*0.1u/50V_6

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

DDR 1.5V (RT8207A)

DDR 1.5V (RT8207A)

DDR 1.5V (RT8207A)

Date: Sheet

Date: Sheet

2

Date: Sheet

PROJECT :

1

ZE8

ZE8

ZE8

of

of

of

26 34Tuesday, September 29, 2009

26 34Tuesday, September 29, 2009

26 34Tuesday, September 29, 2009

5

4

3

2

1

PR154

PR154

4.02K/F_6

4.02K/F_6

PR153

PR153
10K/F_6

10K/F_6

27 34Tuesday, September 29, 2009

27 34Tuesday, September 29, 2009

27 34Tuesday, September 29, 2009

+1.05V

of

of

of

VIN

PC128

PC128
33p/50V_6

33p/50V_6

1A

1A

1A

+5V_S5

DD

RB500V-40

PR62

PC124

PC124

12

PR62
1M_6

1M_6

0.01u/50V_6

0.01u/50V_6

12

PC123

PC123

AOL1718 Rdson=4.6mOhm

15

16

1

2

3

4

6

5

14

PU8

PU8
UPI6111A

UPI6111A

EN/DEM

TON

VOUT

VDD

FB

PGOOD

GND

NC

NC

PR151

PR151
10/F_6

10/F_6

MAINON(18,26,28)

CC

HWPG_1.05V(18)

BB

PR64 Short_6PR6 4 Short_6

+3V

PR155

10K/F_6

10K/F_6

PC126

PC126

1u/16V_6

1u/16V_6

*1000p/50V_6

*1000p/50V_6

TON=3.85p*RTON*Vout/(Vin-0.5)

BOOT

UGATE

PHASE

VDDP

LGATE

PGND

TPAD

PR156

PR156

2.2/F_6

2.2/F_6

13

12

11

10

OC

9

8

7

17

RB500V-40

PC129

PC129

1 2

1u/16V_6

1u/16V_6

Rds*OCP=RILIM*20uA

PR149

PR149

2.2/F_6

2.2/F_6

PR61 2 .43K/F_6PR61 2.43K/F_6PR155

PD4

PD4

PC125

PC125

0.1u/50V_6

0.1u/50V_6

UGATE-1V

PHASE-1V

LGATE-1V

12

4.7u/6.3V_6

4.7u/6.3V_6
PC61

PC61

OCP=10-0.8A

Frequency=Vout/(Vin*TON)

TON=3.85p*1M*1/(Vin-0.5)

Frequency=1/(0.0036767)=272K

AA

5

L(ripple current)
=(19-1.05)*1.05/(1u*272k*19)
~3.646A

4.6m*10=RILIM*20uA
RILIM(PR61)=2.3K--- 2.43K

4

RAMP CHANGE

743 CPU Other CPU

PR154

3

AOL1448

AOL1448

PQ26

PQ26

(CS24023F928)4.02K4.22K (CS24223F917)

4

4

PQ25

PQ25
AOL1718

AOL1718

5

213

5

213

2

PC59

PC136

PC136

10u/25V_1206

10u/25V_1206

1uH/11A_7X7X3

1uH/11A_7X7X3

PR157

PR157

2.2/F_6

2.2/F_6

220u/2.5V_3528

220u/2.5V_3528

PC135

PC135
2200p/50V_6

2200p/50V_6

1V_FB

PR60

PR60

0_6

0_6

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Date: Sheet

Date: Sheet

Date: Sheet

PC59

PC134

PC134

2200P/50V_4

2200P/50V_4

0.1u/50V_6

0.1u/50V_6

PL5

PL5

+

+

PC65

PC65

VOUT=(1+R1/R2)*0.75

+1.05V

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

VCCP 1.05V (RT8202A)

VCCP 1.05V (RT8202A)

VCCP 1.05V (RT8202A)

Total capacitor : 630 uF

ESR : 3mΩ

f : 272k Hz

(Peak 12.547A,AVG 9.41A)

OCP: 10A

PC66

PC66
10u/10V_8

10u/10V_8

R1

R2

PC64

PC64

0.1u/50V_6

0.1u/50V_6

ZE8

ZE8

ZE8

1

5

4

3

2

1

Discharger/1.8V(DCD)

R1

R2

+3V

PR37

PR37

HD@100K_4

HD@100K_4

PR41

PR41

HD@30K/F_4

HD@30K/F_4

PR38

PR38
HD@34K/F_6

HD@34K/F_6

+1.5V_S5

0.011A

PC48

PC48

HD@10u/10V_8

HD@10u/10V_8

HWPG_+1.5VS5 (18)

+3V

PR74

R1

PR74

100K_4

100K_4

PR75

PR75

34K/F_4

34K/F_4

PC72

PC72

10u/10V_8

10u/10V_8

HWPG_+1.8V (18)

+1.8V

0.12A

S5_ON(18,24)

+3VPCU

PC54 HD@1u/16V_6PC54 HD@1u/16V_6

S5_ON

PR36

PR36
HD@10K/F_6

HD@10K/F_6

DD

+1.8V on power control(18)

MAINON(18,26,27)

+3VPCU

PC69 1u/16V_6PC69 1u/16V_6

PR76 Short_6PR76 Short_6
PR77 *0_6PR77 *0_6

+5VPCU

PU6

PU6
RT9025-25PSP

RT9025-25PSP

4

VPP

2

VEN

3

VIN

8

GND

9

GND

PGOOD

ADJ

7

1

6

VO

5

NC

0.8V

PC40

PC71

PC71
*0.1u/50V_6

*0.1u/50V_6

PC73

PC70

PC70

10u/10V_8

10u/10V_8

CC

PC73

0.1u/50V_6

0.1u/50V_6

Vout =0.8(1+R1/R2)
=1.81V

R2

PR73

PR73

27K/F_6

27K/F_6

PC45

PC45

HD@10u/10V_8

HD@10u/10V_8

PC40

HD@0.1u/50V_6

HD@0.1u/50V_6

+5VPCU

PU4

PU4
HD@RT9025-25PSP

HD@RT9025-25PSP

4

PGOOD

VPP

2

VEN

VIN
GND
GND

VO

NC

ADJ

7

3
8
9

PC37

PC37
*HD@0.1u/50V_6

*HD@0.1u/50V_6

Vout =0.8(1+R1/R2)
=1.506V

1

6

5

0.8V

29

A2 STAGE CHANGE SOLUTION

+5V+3V

PR116

PR97

PR97
1M_6

1M_6

PR98

BB

MAINON

PR104

PR104
100K/F_6

100K/F_6

2

PQ14

PQ14

DTC144EU

DTC144EU

1 3

PR98
1M_6

1M_6

PR113

PR113
22_8

22_8

3

2

PQ16

PQ16
2N7002K

2N7002K

1

PR116
22_8

22_8

3

2

PQ17

PQ17
2N7002K

2N7002K

1

+1.8V +SMDDR_VTERM

PR103

PR103
*22_8

*22_8

3

2

1

PQ15

PQ15
*2N7002K

*2N7002K

2

3

1

PR102

PR102
*22_8

*22_8

PQ13

PQ13
*2N7002K

*2N7002K

+1.05VVIN

PR100

PR100
22_8

22_8

3

2

PQ10

PQ10
2N7002K

2N7002K

1

+10V

PR106

PR106
1M_6

1M_6

MAINDMAINON_ON_G

3

2

PQ11

PQ11
2N7002K

2N7002K

1

PC98

PC98
2200p/50V_4

2200p/50V_4

MAIND (24,26)

VIN

PR66

PR66
1M_6

1M_6

SUS_ON_G SUSDSUSD

PR67

AA

SUSON(7,18,26)

PR68

PR68

100K/F_6

100K/F_6

5

2

PQ6

PQ6

DTC144EU

DTC144EU

1 3

PR67
1M_6

1M_6

+3VSUS +10V+1.5V_SUS

PR72

PR72
3G@22_8

3G@22_8

3

2

PQ9

PQ9
3G@2N7002K

3G@2N7002K

1

4

PR70

PR71

PR71
22_8

22_8

3

2

PQ8

PQ8
2N7002K

2N7002K

1

PR70
1M_6

1M_6

3

2

PQ7

PQ7
2N7002K

2N7002K

1

3

PC68

PC68
2200p/50V_4

2200p/50V_4

SUSD (24)

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Do cument Number Rev

Size Do cument Number Rev

Size Do cument Number Rev

Discharge/1.8V

Discharge/1.8V

Discharge/1.8V

Date: Sheet

Date: Sheet

Date: Sheet

2

PROJECT :

ZE8

ZE8

ZE8

1

1A

1A

1A

28 34Tuesday, September 29, 2009

28 34Tuesday, September 29, 2009

28 34Tuesday, September 29, 2009

of

of

of

A

B

C

D

E

+3VPCU

44

+3V

PR55

PR55

1.91K/F_4

1.91K/F_4

HWPG_GFX(18)

PR46

ISL6263A_VO

PC26

PC26

PR165 0_8PR165 0_8

PR46
150K/F_4

150K/F_4

PC46

PC46

0.015u/16V_4

0.015u/16V_4

PR42

PR42

5.62K/F_6

5.62K/F_6

1000p/50V_4

1000p/50V_4

33

PR39

PR39

6.81K/F_6

1000p/50V_4

1000p/50V_4

1000p/50V_4

1000p/50V_4

6.81K/F_6

PC39

PC39

PC21

PC21

Parallel

1000p/50V_4

1000p/50V_4

PC33

PC33

68p/50V_4

68p/50V_4

PR25 2.21K/F_4PR25 2.21K/F_4

+VGFX

PC35 180p/50V_4PC35 180p/50V_4

PC20

PC20

560p/50V_4

560p/50V_4

PR11

PR11
*10/F_4

*10/F_4

PR8 Short_4PR8 Short_4

PR9 Short_4PR9 Short_4

PR12

PR12
*10/F_4

*10/F_4

PR28 374K/F_6PR28 374K/F_6

PR15

PR15

4.99K/F_4

4.99K/F_4

22

GFX_VCCSENSE(9)

GFX_VSSSENSE(9)

33

PAD

1

RBIAS

12

2

SOFT

3

OCSET

4

VW

5

COMP

6

FB

7

VDIFF

8

VSEN

1.54K/F_4

1.54K/F_4

PC17

PC17

330P/50V_4

330P/50V_4

PC22

PC22

PC11

PC11

0.1u/50V_6

0.1u/50V_6

PR49

PR49
10K_4

10K_4

30

31

32

FDE

AF_EN

PGOOD

DFB

RTN

DROOP

9

11

10

PR24

PR24

PR18

PR18
1K/F_4

1K/F_4

12

29

VR_ON

PU3

PU3

ISL6263A

ISL6263A

VO

12

28

PMON

VSUM13VSS

PC18

PC18

*0.1u/10V_4

*0.1u/10V_4

PR50 Short_4PR50 Short_4

12

PC53

PC53
*0.1u/50V_6

*0.1u/50V_6

27

VID4

VIN

14

12

PC19

PC19

0.1u/50V_6

0.1u/50V_6

0.068u/10V_4

0.068u/10V_4

26

VID3

15

PR19

PR19
10/F_6

10/F_6

PC23

PC23

25

VID2

VID1

VID0

PVCC

LGATE

PGND

PHASE

UGATE

BOOT

VDD

16

PC28

PC28
1u/6.3V_4

1u/6.3V_4

ISL6263A_VSUM

GFX_VR_EN

24

23

22

ISL6263A_LGATE

21

20

ISL6263A_PHASE

19

ISL6263A_UGATE

18

17

PR35 1/F_6PR35 1/F_6

PR30

PR30
10/F_6

10/F_6

VIN

PR22

PR22

4.53K/F_4

4.53K/F_4

4.7u/6.3V_6

4.7u/6.3V_6

1 2

+5V_S5

PR173

PR173

3.57K/F_4

3.57K/F_4

PR176

PR176
10K _6 NTC

10K _6 NTC

ISL6263A_VO

PC42

PC42

1 2

PC38

PC38

0.22u/25V_6

0.22u/25V_6

PR7

PR7

7.68K/F_4

7.68K/F_4

GPU_VID4 (7)

GPU_VID3 (7)

GPU_VID2 (7)

GPU_VID1 (7)

GPU_VID0 (7)

+5V_S5

578

578

PR52

PR52

PR51

PR51

*0_6

*0_6

*0_6

*0_6

PQ37

PQ37
AO4468

AO4468

3 6

241

3 6

241

PQ38

PQ38
AO4710

AO4710

12

PR188

PR188

2.2_6

2.2_6

PC149

PC149
2200p/50V_6

2200p/50V_6

PR53

PR53
*0_6

*0_6

PC3

PC3

2200p/50V_6

2200p/50V_6

1uH/DCR 9mR/11A_7X7X3

1uH/DCR 9mR/11A_7X7X3

+3VPCU

PR44

PR44

PR54

PR54

*0_6

*0_6

*0_6

*0_6

GPU_VID0GPU_VID3 GPU_VID2GPU_VID4 GPU_VID1

PC2

PC2

10u/25V_1206

10u/25V_1206

PL8

PL8

12

10u/25V_1206

10u/25V_1206

12

PC151

PC151

12

PC141

PC141

0.1u/50V_6

0.1u/50V_6

12

PC5

PC5

0.1u/50V_6

0.1u/50V_6

PC140

PC140

220u/2.5V_3528

220u/2.5V_3528

Rocset(PR42)=8*7m/10uA~ 5.6K =5.62K

VIN

+VGFX

Total capacitor : 465uF

ESR :4.5mΩ

+

+

f : 333k Hz

(Peak 7.7A,AVG 5.775A)

OVP 8A

OCP: 8A

VIN

+VGFX

PR175

PR175
1M_6

1M_6

11

GFX_VR_EN(7)

A

GFX_VR_EN

B

PR184

PR184
100K_4

100K_4

12

2

PQ35

PQ35

DTC144EU

DTC144EU

GFX_VR_EN_G

PR182

PR182
1M_6

1M_6

1 3

PR170

PR170
22_8

22_8

3

2

PQ33

PQ33
DMN601K-7

DMN601K-7

1

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

1.05V_GFX

1.05V_GFX

1.05V_GFX

Date: Sheet

Date: Sheet

C

D

Date: Sheet

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

ZE8

ZE8

ZE8

29 34Tuesday, September 29, 2009

29 34Tuesday, September 29, 2009

29 34Tuesday, September 29, 2009

of

of

E

of

1A

1A

1A

5

DD

4

CLOCK GEN CK505

Page 3

CLK_MCH_BCLK
(166/200/266MHz)

3

NORTH BRIDGE
SFF GS45

Page 6~11

2

DDR2 CLK (166/200/266MHz)

LVDS CLK (112MHz)

CRT CLK (400MHz)

1

DDR2 SO-DIMM

Page 16~17

LED PANEL

Page 23

CRT

DB

HDMI CLK (100MHz)

CC

Penryn

CPU FSB (266MHz)

HDMI

Page 23

Page 4~5

SCH SATA (100MHz)

SCH DMI (100MHz)

SCH PCI (33MHz)

SOUTH BRIDGE
SFF ICH9-M SFF

Page 12~15

SCH CLK48 (48MHz)

Y2(14.318MHZ)

BB

SCH CLK14 (14.31818MHz)

SCH PCIE(100MHz)

HD CLK (24MHz)

SDIO CLK (48MHz)

GLAN

DB

EC
(WPCE775C/FLASH)

Page 19

AUDIO CODEC
(ALC269X)

Page 18

CARD READER

Page 22

PCIE CLK (100MHz)

MINI CARD(WLAN)

Y1(25 MHz)

Y3(32.768 KHz)

Y1(12 MHz)

Page 20

AA

PCIE CLK (100MHz)

MINI CARD(3G)

Page 20

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Clock Distribution Diagram

Clock Distribution Diagram

Clock Distribution Diagram

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

PROJECT :

ZE8

ZE8

ZE8

1A

1A

1A

of

of

of

30 34Tuesday, September 29, 2009

30 34Tuesday, September 29, 2009

30 34Tuesday, September 29, 2009

1

5

4

3

2

1

ISL6261A

PU10

DD

VINVIN

SYSTEM

5V/3V

(RT8206B)

PU2

ADAPTER

CC

BATTERY PU9

BB

CHARGER

(ISL88731A)

VIN

RT8207A

PU8

+5VPCU+3VPCU

+1.8VSUS

VCORE

<VRON>

+5VPCU

<AC/DC Insert>

2N7002K

PQ15

AO3402

PQ22

+3VPCU

<AC/DC Insert>

AO3402

PQ11

AO3402

PQ20

AO3404

PQ35

RT9025

PU4

+1.8VSUS

<SUSON>

AO4466

PQ32

+SMDDR_VTERM

<SUSON>

+SMDDR_VREF

<SUSON>

+5V_S5

<S5D>

+5V

<MAIND>

+3V_S5

<S5D>

+3VSUS

<SUSD>

+3V

<MAIND>

+1.5V_S5

<S5D>

+1.5V

<MAINON>

POWER Distribution

VCORE

+5VPCU

CPU

RTC, USB Connecter

+5V_S5 ICH9M Power

+5V

+3VPCU

+3V_S5

ICH9M Power, CRT, Audio Codec, SATA HDD, Touch Pad ,HDMI

RTC, LED Power, CRT, EC, ID , SPI Flash , Green Adapter

ICH9M Power, CR

+3VSUS 3G

+3V

+1.5V_S5

+1.8VSUS

CLK_GEN Power, Thermal Sensor Power, NB Power, SB, DDRII Power, Audio Codec, LCD
Power, WLAN/WMAX, 3G, Card Reader, BT, EC, LED, CRT, CAMERA

ICH9M Power

NB Power, DDRII SO-DIMM

+1.5V CPU, NB, SB, AUDIO Codec, WLAN/WMAX, 3G

+SMDDR_VTERM

+SMDDR_VREF

DDRII SO-DIMM

DDRII SO-DIMM

+1.05V CLK_GEN, CPU, NB, SB

RT8202A

PU5

+1.05V

<MAINON>

AA

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

ZE8

PROJECT :

ZE8

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Power Tree

Power Tree

Power Tree

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

1

ZE8

1A

1A

1A

of

of

of

31 34Tuesday, September 29, 2009

31 34Tuesday, September 29, 2009

31 34Tuesday, September 29, 2009

1

2

3

4

5

6

7

8

CK505 Clock Setting Table

Differential CPU Clock

Pin Name Pin Net Name Description
CPU_0 61

CPU_1 58

AA

PCI Express Clock

Pin Name Pin Net Name Description

SRC0/DOT96 20

LCDCLK/27M 24

SRC2 28

SRC3/CR#_C 31
SRC3#/CR#_D

SRC4 34
SRC4#
SRC6 48

SRC6#
SRC7/CR#_F 51
SRC7#/CR#_E

BB

CC

DD

SRC8/CPU_ITP 54
SRC8#/CPU_ITP# No use

SRC9 37

SRC9#

SRC10 41

SRC10#
SRC11/CR#_H
SRC11#/CR#_G CLKREQ#_MINI1 Clock Request for M ini Card 1 (SRC9)

PCI Clock

Pin Name Pin Net Name Description
PCI0/CR#_A
PCI1/CR#_B

PCI2

PCI3

PCI4

PCI5

Other Clock

Pin Name Pin Net Name Description

USB_48 17

Clock Request Table
CLKREQ#

CR#_A
CR#_B
CR#_C
CR#_D
CR#_E
CR#_F
CR#_G
CR#_H

MAPPING Control
01
SRC0 SRC2

SRC0 SRC2

SRC6
SRC8
SRC9
SRC10

CLK_CPU_BCLK
CLK_CPU_BCLK#CPU_0# 60
CLK_MCH_BCLK
CLK_MCH_BCLK#CPU_1# 57

DREFCLK
DREFCLK#SRC0#/DOT96# 21
DREFSSCLK
DREFSSCLK#LCDCLK#/27M_SS 25
PECLK_SATA
PECLK_SATA#SRC2# 29
PECLK_ICH
PECLK_ICH#32
PECLK_LAN
PECLK_LAN#35
PECLK_MINI2
PECLK_MINI2#47

50

CLKREQ#_MINI2

53

PECLK_MINI1
PECLK_MINI1#38
PECLK_3GPLL
PECLK_3GPLL#42

40

CLKREQ#_MCH

39

8

CLKREQ#_SATA

10

CLKREQ#_LAN

1112PCLK_DEBUG

13 PCLK_EC
14 PCLK_ICH

CLK48_ICH
CLK48_CARD
CLK14_ICHREF5

SRC4LCDCLK

SRC4LCDCLK

SATA
LAN
N/A
N/A
MINI2
N/A
MINI1
MCH

Differential CPU clock

Differential NB GS45 clock

96MHz DOT clock for NB GS45

Clock output for NB GS45 graphic contoller

Differential Serial Reference Clock for SB ICH9M SATA

Differential Serial Reference Clock for SB ICH9M

Differential Serial Reference Clock for on board LAN

Differential Serial Reference Clock for Mini Card 2
No use
Clock Request for Mini Card 2 (SRC6)

Differential Serial Reference Clock for MINI CARD 1

Differential Serial Reference Clock for NB GS45
Clock Request for NB GS45 (SRC10)

Clock Request for SATA (SRC2)
Clock Request for on board LAN (SRC4)
PCI clock for debug card
No use
PCI clock for EC
PCI clock for SB ICH9M

48MHz for SB ICH9M
48MHz for USB Card Reader

14.318MHz for SB ICH9M

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Schematic Setting

Schematic Setting

Schematic Setting

Date: Sheet

Date: Sheet

1

2

3

4

5

Date: Sheet

6

7

ZE8

ZE8

ZE8

32 34Tuesday, September 29, 2009

32 34Tuesday, September 29, 2009

32 34Tuesday, September 29, 2009

1A

1A

1A

of

of

of

8

5

4

3

2

1

Model

ZE8

DD

CC

BB

REV

A1A

B1A

CHANGE LIST

PAGE20 : reserve R179 , R183 for 3G wake up function
PAGE5 : Del C128,C173,C149,C171,C130,C131,C133,C169,C181,C177,C132,C175,C140,C138,C185,C154,C135,C92,C184,C106,C117,C156,C186,C153

for placeing C386 in CPU BGA TOP side
PAGE18 :change U14 footprint to qfn48-7x7-5-58p-0_9h
PAGE23 :change CN18 PN to DFHD19MR053
PAGE23 :Add L28 and L29 for CCD and Touch screen USB signals
PAGE23 :change CN18 footprint to hdmi-100042mr019m21hzr-19p-v
PAGE23 :change CN19 footprint to 85204-0500x-5p-l
PAGE23 :add 5V power trace to CN19 for touch screen IC
PAGE19 :FAE suggest that add R352 for VCC latch up
PAGE19 : FAE suggest that change C347 and C350 value from 15p to 6.8p
PAGE10 : add stitching caps C149,C153 and C154 for DMI signals
PAGE14 : add stitching caps C156,C169 and C171 for DMI signals
PAGE20 : add C431 for SIM Card to filter power noise.
PAGE20 : change U10 PN from AL001293003 to AL001293000
PAGE21 : reserve ESD protection U11 for SATA signals.
PAGE23 : del +5V signal of CN19
PAGE18 : add stitching caps C432,C438 for Audio signals
PAGE21 : del hole 19
PAGE22 : reserve C439, C440,C445,C446,C447,C448 for EMI
PAGE23 : reserve C106 for EMI
PAGE 19, 20 : del R179, R183 and 3G wake up signals of 3G wake up function
PAGE19 : add D30 for WLAN_LED# connect from WALN connector to EC
PAGE19 : add 3G_EC_LED# signal from EC to LED connector CN2
PAGE19 : change R233 to D31 for leakage issue.
PAGE22 : del C426 due to don't need 3G_MINI_LED# singal from 3G connector to LED connector CN2
PAGE21 : add EMI bypass caps
PAGE23 : HDMICLKP swap to HDMITX0P,HDMICLKN swap to HDMITX0N,HDMICLKP_C swap to HDMITX0P_C,HDMICLKN_C swap to HDMITX0N_C
6/13 : PAGE10 : change C63 and C208 value from 220u to 10u.
6/15 : PAGE18 : due to layout, add 9 GND pin for U14
6/15 : PAGE19 and 23 : add Touch_panel_HK signal for hot key on touch panel
6/16 : PAGE 23 : change R14 to C454 of CN18 for HDMI detect issue
6/18 : PAGE 23 : change CN5 PN to DFHD05MRD98
6/18 : PAGE 19 : change U14 PN to AKE38ZA0Q00

6/22 : PAGE 21 : change CN17 PN to DFHS04FR269
6/22 : PAGE 24 : change PJ1 PN to DFHD08MR085
6/23 : PAGE 22 : Per Acer request, use interrupt pin of G-sensor to detect panel status ,so , stuff R150, remove R151
6/25 : PAGE 19 : EC add +1.5V on power control net name to control 1.5V
6/25 : PAGE 22 : connect G-sensor interrupt signal to SB PIRQE#
6/26 : PAGE 26 : change V-core solution to Maxim IC
6/26 : PAGE 24 : add PD20 in TEMP_MBAT signal
6/29 : PAGE 9 : change C212 from 330U to 10U for placement issue
6/30 : PAGE 16 : change DDR2 to DDR3
7/2 : PAGE 14 : LID_touch panel# change from GPIO19 to GPIO7 (SCI)
7/2 : PAGE 16 : change DDR3 connector footprint to H=5.2mm
7/6 : PAGE 18,21 : add RECOVER_BUTTON# signal in EC and CRT DB
7/7 : PAGE 18,21 : add RECOVER_LED# signal in EC and CRT DB
7/7 : PAGE 24 : add PD11 and PD12
7/7 : PAGE 25 : add PD13
7/7 : PAGE 20 : add nut on Hole 7, Hole 8 and Hole 11
7/7 : PAGE 18 : add R355 for power consumption issue,Vendor suggest to place it close to EC.
7/8 : PAGE 18 : add D30 for current leakage issue of 3G_EC_LED# signal.
7/9 : PAGE 18 : add D31 to prevent current leakage of Recover_LED# signal.
7/10 : PAGE 19 : change the direction of Q21 and Q22 to prevent the current leakage
7/10 : PAGE 3 : follow vendor suggestion to change C226 from 33p to 27p.
7/13 : PAGE 18 : follow vendor suggestion to change C337 and C343 from 6.8p to 15p.

NOTEDATE

ECN ReleasePAGE23 :move LED touch Panel hall sensor to LAN DB

AA

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Change List01

Change List01

Change List01

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

PROJECT :

ZE8

ZE8

ZE8

33 34Tuesday, September 29, 2009

33 34Tuesday, September 29, 2009

1

33 34Tuesday, September 29, 2009

1A

1A

1A

of

of

of

5

4

3

2

1

Model

ZE8

DD

CC

REV

C1A

C3A

CHANGE LIST

7/23 : PAGE 20 : change CN17 footprint to usb-04wl4b-4p-r-v
7/23 : PAGE 20 : add U38 re-driver IC for SATA connector
7/29 : PAGE 19 : change JSIM1 pin define to solve SIM card not detect issue
7/31 : PAGE 20 : add parade solution of SATA re-driver IC
8/4 : PAGE 20 : change footprint of U38 to qfn20-4x4-5-21p-ps8511b
8/6 : because of DMI reference to GND, so, del C60 C67 C61 C150 C166 C153 CAPS
8/6 : PAGE 20 : change Hole 18 footprint HG-C237D94P2, Hole 16 to H-C91D91N
8/10 : PAGE 19 : change JSIM1 PN to DFHS06FS017 and change footprint to simcard-sim-06lj3g-10p
8/11 : add C244 C245=220pF, add C243 =680pF,change C11= 1000pF,add C60=1000pF,change C307= 1000pF,add C363=0.1uF,change C10= 0.1uF,
R113 change to BLM18BA750SN1 ferrite bead,R252, R253 = ferrite bead (BLM18PG471SN1),R190, R194 = BLM21PG331SN1 for EMI
8/12 : change JSIM1 back to A2-test P/N and footprint.
8/13 : add C246,C247=220pF, add C471=0.1uF for EMI
8/28 : page13 : add pull high resister R160 in GNT3# pin for no video issue.
8/31 : page 22 : exchange V_BLIGHT and LCDVCC pin define
9/2 : page 19 : change PN and footprint of JSIM1 back to A1 type.
9/2 : page 21 : change G-Sensor footprint to sensor-3x3-5-16p-smt for SMT solder issue.
9/8 : page 23 : change battery connector footprint to bat-btj-08fg0b-8p-l-v for SMT issue.
9/8 : change R141,R303,R199,R259,R254,R174,R201,R172,R173,R217,R261,R168,R175,R249,R150,R15 to short pad

9/28 : change PU2 footprint from QFN28-5X5-5-33P to qfn28-5x5-5-33p-nb4

NOTEDATE

ECN Release

BB

AA

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PROJECT :

PROJECT :

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Change List01

Change List01

Change List01

Date: Sheet

Date: Sheet

5

4

3

2

Date: Sheet

PROJECT :

ZE8

ZE8

ZE8

34 34Tuesday, September 29, 2009

34 34Tuesday, September 29, 2009

1

34 34Tuesday, September 29, 2009

1A

1A

1A

of

of

of
