Quanta U83 Discrete Ultra, Pavilion 15 Schematic
5
4
3
2
1
U83 DIS (14"/15.6")
D D
C C
System BIOS
SPI ROM
B B
Intel Shark Bay ULT Platform Block Diagram
DDR3L SODIMM1
Maxima 8GBs
PAGE 12
DDR3L SODIMM2
Maxima 8GBs
PAGE 13
SATA - 1st HDD
Package : 9.5 (mm)
Power :
mSATA
Package : 12.7 (mm)
Power :
SATA ODD
Package : (mm)
Power :
PAGE 7
PAGE 24
PAGE 24
PAGE 24
DDR3L
DDR3L
SATA0 6GB/s
SATA1 6GB/s
SATA2 6GB/s
SPI Interface
Intel Shark Bay ULT
Processor : Daul Core
Power : 15 (Watt)
Package : BGA1168
Size : 40 X 24 (mm)
ICT
PAGE 2~10
Azalia
PCI-E Gen3
X4 Lane
eDP X1
DP Port 1
USB3.0 Interface
USB2.0 Interface
USB2.0 Port x 1(Left side)
Port1 Port2
PCIE Gen 1 x 1 LaneLPC Interface
PAGE 21
Ultra/Slim
AMD Sun XT
Power : 25 (Watt)
Package : S3
Size : 23 x 23 (mm)
PAGE 14-18
USB 3.0 Port 1,2(USB 2.0 Port 0,5)
Camera
PAGE 20
VRAM DDR3 x 4 (900 MHz)
128 x 16 x 4, 64 bit
256 x 16 x 4, 64 bit
Max 1GBs PAGE 19
27MHz
PAGE 16
RTD2132R
Package : QFN-32
PAGE 19
PCB 6L STACK UP
LAYER 1 : TOP
LAYER 2 : SGND
LAYER 3 : IN1(High)
LAYER 4 : IN2(Low)
LAYER 5 : SVCC
LAYER 6 : BOT
LVDS (1CH)
PAGE 20
eDP
PAGE 20
HDMI Conn
PAGE 20
USB3.0 Port x 2
PAGE 25
01
G-Sensor
HP3DC2TR
Keyboard
Touch Pad
PAGE 26
PAGE 25
SM BUS
EnE KB9010QF A1
Embedded Controller
Power :
Package : LQPF128
Size : 14 x 14 (mm)
PAGE 27
Audio Codec
ALC3227-GR
Power :
Package : MQFN
Size : 6 x 6 (mm)
PAGE 21
Card Reader
RTS5237-GR
Power :
Package : LQPF48
Size : 7 x 7 (mm)
PAGE 23
LAN Controller
10/100 RTL8176EH-CG
Power :
Package : OFN48
Size : 6 x 6 (mm)
Int
PAGE 22
Halt Mini Card
Intel Rambo Peak
WLAN / BT Combo
PAGE 26
TCP-15G24
PAGE 24 FAN
Speaker
PAGE 24
PAGE 21
Combo Jack
A A
5
4
iPHONE type
Digital MIC
PAGE 21
PAGE 21
PROJECT :U83
PROJECT :U83
PROJECT :U83
Quanta Computer Inc.
Quanta Computer Inc.
Quanta Computer Inc.
Size Document Number Rev
Size Document Number Rev
Size Document Number Rev
Custom
Custom
Custom
Block Diagram
Block Diagram
Block Diagram
Date: Sheet of
Date: Sheet of
3
2
Date: Sheet of
1
1A
1A
1A
1 41Monday, March 18, 2013
1 41Monday, March 18, 2013
1 41Monday, March 18, 2013
5
4
3
2
1
U19A
IN_D2#<21>
IN_D1#<21>
IN_D0#<21>
IN_CLK#<21>
IN_D2<21>
IN_D1<21>
IN_D0<21>
D D
eDP_COMPIO and ICOMPO signals should be shorted
near balls and routed with typical impedance <25 mohms
C C
IN_CLK<21>
EDP_DISP_UTIL<6>
INT_eDP_AUXP<20>
INT_eDP_AUXN<20>
INT_eDP_TXP0<20>
INT_eDP_TXN0<20>
DPB_LANE0_N
DPB_LANE1_N
DPB_LANE2_N
DPB_LANE3_N
DPB_LANE0_P
DPB_LANE1_P
DPB_LANE2_P
DPB_LANE3_P
eDP_RCOMP
EDP_DISP_UTIL
INT_eDP_AUXP
INT_eDP_AUXN
INT_eDP_TXP0
INT_eDP_TXN0
+VCCIOA_OUT
eDP_COMPIO and ICOMPO signals should be shorted
near balls and routed with typical impedance <25 mohms
C54
DDI1_TXN0
B58
DDI1_TXN1
B55
DDI1_TXN2
A57
DDI1_TXN3
C55
DDI1_TXP0
C58
DDI1_TXP1
A55
DDI1_TXP2
B57
DDI1_TXP3
C51
DDI2_TXN0
C53
DDI2_TXN1
C49
DDI2_TXN2
A53
DDI2_TXN3
C50
DDI2_TXP0
B54
DDI2_TXP1
B50
DDI2_TXP2
B53
DDI2_TXP3
D20
EDP_RCOMP
A43
EDP_DISP_UTIL
B45
EDP_AUXP
A45
EDP_AUXN
B46
eDP_TXP0
B47
eDP_TXP1
C46
eDP_TXP2
B49
eDP_TXP3
C45
eDP_TXN0
A47
eDP_TXN1
C47
eDP_TXN2
A49
eDP_TXN3
*HSW_ULT_DDR3L
R109 24.9/F_4
eDP_RCOMP
EC_PECI<28>
H_PROCHOT#<28,33>
eDP
R415 56.2/F_4
TP86
PCI EXPRESS* - GRAPHICS
TP89
TP91
R397 10K/F_4
PROC_DETECT#
CATERR#
EC_PECI
PROCHOT#
PROCPWRGD
U19B
D61
PROC_DETECT#
K61
CATERR#
N62
PECI
K63
PROCHOT#
C61
PROCPWRGD
*HSW_ULT_DDR3L
02
MISCTHERMALPWR MANAGEMENT
AV15
DDR3JTAG & BPM
SM_DRAMRST#
SM_RCOMP0
SM_RCOMP1
SM_RCOMP2
SM_PG_CNTL1
PRDY#
PREQ#
PROC_TCK
PROC_TMS
PROC_TRST#
PROC_TDI
PROC_TDO
BPM#0
BPM#1
BPM#2
BPM#3
BPM#4
BPM#5
BPM#6
BPM#7
AU60
AV60
AU61
AV61
J62
K62
E60
E61
E59
F63
F62
J60
H60
H61
H62
K59
H63
K60
J61
SM_DRAMRST#
SM_RCOMP_0
SM_RCOMP_1
SM_RCOMP_2
XDP_TCK0
XDP_TMS_CPU
XDP_TRST#_CPU
XDP_TDI_CPU
XDP_TDO_CPU
BPM#2
BPM#3
BPM#4
BPM#5
BPM#6
BPM#7
R184 0_4
R527 200/F_4
R528 121/F_4
R526 100/F_4
+1.35VSUS
R183
470_4
DDR_PG_CNTL <13>
TP21
XDP_PRDY#_CPU <11>
XDP_PREQ#_CPU <11>
TP25
XDP_TCK0 <11>
XDP_TMS_CPU <11>
XDP_TRST#_CPU <7,11>
XDP_TDI_CPU <11>
XDP_TDO_CPU <11>
XDP_BPM0 <11>
XDP_BPM1 <11>
TP90
TP17
TP24
TP20
TP28
TP22
DDR3_DRAMRST# <12,13>
Processor pull-up (CPU)
H_PROCHOT#
XDP_TDO_CPU
B B
DEL or not?
XDP_TMS_CPU
XDP_TDI_CPU
R419 62_4
+V1.05S_VCCST
R411 51_4
R410 *51_4
R412 *51_4
+V1.05S_VCCST
XDP_TRST#_CPU
XDP_TCK0
A A
5
4
3
R539 *51_4
R101 51_4
PROJECT :U83
PROJECT :U83
PROJECT :U83
Quanta Computer Inc.
Quanta Computer Inc.
Quanta Computer Inc.
Size Document Number Rev
Size Document Number Rev
Size Document Number Rev
Custom
Custom
Custom
ULT 1/9(eDP/DDI)
ULT 1/9(eDP/DDI)
ULT 1/9(eDP/DDI)
Date: Sheet of
Date: Sheet of
2
Date: Sheet of
1
1A
1A
1A
2 41Thursday, March 14, 2013
2 41Thursday, March 14, 2013
2 41Thursday, March 14, 2013
