QUANTA TW6 Schematics

A

Page Title of schematic page Rev. Date

01

Index

02

Block Diagram

03

Change List

4 4

04

CLOCK GENERATOR

05

PROCESSOR 1/4(DMI&HOST&PCI)

06

PROCESSOR 2/4(DDR)

07

PROCESSOR 3/4(POWER)

08

PROCESSOR 4/4(GND)

09

PCH 1/5 (DMI&VIDEO)

10

PCH 2/5 (SATA/LPC/Azalia)

11

PCH 3/5 (PCI/PCIE/CLK/USB)

12

PCH 4/5 (GPIO)

13

3 3

2 2

1 1

PCH 5/5 (POWER)

14

DDR3 DIMM

15

CRT/LVDS

16

WLAN/EXPRESS CARD

17

WPCE775L & FLASH

18

Docking/35001/TP/TPM/BT

19

HDD/ODD/Camera/DMIC

20

KB/USB/FAN/Reset

21

HDMI Conn/Level shift

22

POWER CPU CORE (ISL62882)

23

POWER 3VPCU&5VPCU(PM6686)

24

POWER 1.5VSUS/VTT_MEM

25

POWER VCC1.05(OZ8111LN)-26A

26

POWER VCC_CFXCORE(MAX17028)

27

POWER VCC1.8

28

POWER CHARGER (ISL6252A)

29

POWER(ADAPTER IN / CONN)
R5U231

30
31

Audio ALC275
LED/Modem/Buttom

32
33

Atheros 8131M

B

http://hobi-elektronika.net

1A

C

* : No mount
A@: for HDMI Level shift PS8101
B@: for HDMI Level shift PS8171

D

E

1

1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A
1A

QUANTA

Title

Size Document Number Rev

Custom

A

B

C

D

Date: Sheet

COMPUTER

Page List

TW6 Main Board

E

133Monday, August 31, 2009

1A

of

1

2

3

4

5

http://hobi-elektronika.net

CPU

A A

Arrandale

TW6 Block Diagram

DDR3 800/1066 1.5V

DDR3 800/1066 1.5V

UNBUFFERED DDR3
SODIMM

UNBUFFERED DDR3
SODIMM

14.318MHz

P14

P14

CLOCK GEN

ICS9LRS3105

2

P 4

989 PIN (micro FC-PGA)

DMI(4X)

P18

P5-P8

3.3V LPC,33MHZ

P9-P13

Azalia Link

MIC. Jack

MODEM

P31

P10

Audio Jack

P31

ALC275

INT.SPKR.

P31

Digital MIC
Knowles

SPM0405HE4H

P31

P19

Docking

HDMI

P21

Puma Peak 2x2 AGN(Intel WiFi Link 6200)
Kilmer Peak 2x2 AGN(Imtel WiMAX/WiFi Link 6250)

WLAN Module

B B

SD

MS

RJ45

Intel : Puma peak/Kilmer Peak
Atheros : HB91 or 97

MS/SD

R5U231

LAN Giga

Atheros AR8131M

Docking LAN

Marvell 88E8055

ExpressCard/34

#1

P16

#2

P30

PCIE

#3

P33

#4

P18

#5

P16

TMDS

CRTLCD

P15

LVDS

USB 1.1/2.0

DVI

P15

P18

PCH

Ibex Peak-M

FDI interface

TMDS

R/G/B

HM55/HM57

676 BGA
31mm x
31mm

SATA Port 0

SATA Port 1

ME BIOS

4M

P10

#6

C C

TPM

#7

#8

USB Slot *3

Finger Print

TCS5B

ExpressCard *1

Blue Tooth

T77H114.11

Camera

Docking
USB HUB

D D

P20

P32

P16

P18

P19

P18

SATA HDD *1

P16

SATA ODD *1

P19

PCU

TOUCH PAD

T/P SWITCH

WPC775

INT.K/B

P18

SPI
BIOS

P20

P17

2M

LED

CAPS/NUM/SCRL

Wireless/WWAN/BT

Power/Speep

HDD

MS/SD

Charge

Button

POWER

Light Sensor
TAOS TSL2561FN

P32

P17

P32

ExpressCard

USB CON*1

PCI-E *1

SM BUS
G Sensor

LIS331DL

P19

Wireless SW

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from

1

the business Partners that Sony approves as Green Partners.

2

3

4

P-SW/MUTE-SW/ODD

P32

5

A

-P4 Delete R518 0 ohm.

-P4 Delete R1

-P5 Add Q74,R743,R740,R739,R741 for DRAMRST#

-P5 R22 change power from 1.5VSUS to DRAMPWRGD_CPU

-P5 R22 change value from 1.1K/F to 1.5K/F(For S3 power)

-P5 R23 change value from 3K/F to 750/F.(For S3)

-P5 Add U69,C912,R742. (For S3 power)

-P5 U2.F6 change to DRAMRST_CPU#

-P7 C688 mount 330UF(Reduce ripple)

-P7 VDDQ power change to VCC1.5_CPU

-P8 U2.J17 U2.H17 delete net "DDR_VREF_DQ0""DDR_VREF_DQ1"

4 4

-P9 Del R76 0ohm

-P10 Y2 change footprint

-P10 C146,C148 change 18P to 15P(CH01506GB01)

-P10 D1 change RB501-40 to use only sw1010CPT. (For 3VPCU
leakage)

-P11 Change WLAN PCIE port from port 1 to port 5

-P11 Change ExpressCard PCIE port from port 5 to port 6

-P11 Change C168,C169 from 18P to 8.2P

-P12 U4.F1 change to DRAMRST_CNTRL_PCH.

-P12 R577 change from GND to RVCC3

-P13 L6,L7 change to TDK MKG1608B10NJ(change footprint)

-P13 Add C913 10U on net VCC3_VCCADAC.

-P13 Delete R214,R218,R220 0 ohm.(save cost)

-P13 Delete R215 0_25.(save cost)

-P13 Mount C214,C188 1uF.

-P14 Del R228,R230,R231,R233

-P14 change SMDDR_VREF_DQ0 to SMVREF_GMCH

-P14 Del R734,R735

-P14 Del SMVREF_GMCH1 net

-P14 change SMVREF_GMCH1 to SMVREF_GMCH

-P14 Change SMDDR_VREF_DQ1 to SMVREF_GMCH

-P14 Del R732,R733

-P15 Del L11,L10(save cost)

-P15 Change R237,R238 from 2.2K to 4.7K(Solve CRT DDC VEVS)

-P15 Change C287,C288,C289 from no-mount to mount.(solve CRT
R,G,B oversheet issue)

-P15 Add R744 100k pull down for dispon

3 3

-P17 Add R746, R747 2.2K for SMBUS

-P17 Add R750 100K .(For EC idle mode save power)

-P17 Change D11 RB501V-40 to SW1010CPT

-P17 Add R748,R749 0ohm

-P17 Del R717,R718,R719

-P17 Change D57 from no-mount to mount

-P17 Add R751 10K pull high to RVCC3

-P23 Change PR72 from no-mount to mount for pull high RVCC3
on PM_SYS_PWRGD

-P17 D9,D10,D12,D13,D14,D15,D16,D17, D18,D19,D58 change from
SW1010CPT to RB501V-40.

-P17 R321 no mount

-P17 Add 5V_RESET net

-P18 Change R334 from mount to no-mount

-P19 R588 change from 37.2K/F to 36K/F.(For ODD current
limit)

-P19 Del HDD_INTERRUPT1 net

-P30 Del R629(save cost)

-P31 AQ4, AQ5,AR44,AR45 for MIC and HP detect circuit.

-P31 Add A@ for ALC269 mount part, B@ for ALC275
mount

-P31 ADD AR46,AR48,AD9for MIC-VREF

-P31 Add AC45 for PCSPK for ALC269

-P31 Add AR47 and AR49 for HP and MIC detect pin

-P33 C322,C323 change from 27PF to 33PF.

-P33 Del R714

2 2

-P33 Change C759 from no-mount to mount

-P33 Change C756 from mount to no-mount

-P33 Add C914 close near C777.

0824

P13-Change C214 from no-mount to mount

0824 P13-Change C190 from 0.1u to 1U
0824 P13- Change C178 from 1U to 0.01U
0824 P5-Add C915 0.047u
0824 P10-Del R583
0824 P31-Change Ar21,AR22 from no-mount

to mount

0825 P11-Change RP12 from 2P2R to 0402
x2 for EMI issue.

0825A P18-Add D59 for leakage on DC mode
0826 P10- Change Y2 pin define
0827 P18- Add R754 bypass option
0827A Add C916~C927 for S3 power reduction DG1.0
0828 P12- Change BT_PRS# from GIOP 1 to GPIO12

and pull up to RVCC3
0828 P12- Pull up to VCC3 for GPIO1

0828 isolation power plan for AH34,AH34,AF32

090830 Changed PR54 to 140K for OCP function.
090830 Elijah changed PC221 to 1000P.
090830 Elijah added the VCC1.5_CPU_VCC105_PWRGD circuit

2 sets.

0831B P15-Change L15 to F9 2.6A fuse

0831A P18-Add R760 serial on IRQ_SERIRQ

B

http://hobi-elektronika.net

C

D

E

3

Power portion

090703 Changed PR178 to 6.04K.
090703 Changed PR190 to 9.09K.
090703 Changed PR187 to 18K.
090703 Elijah changed PR55 from 150KR to 3.57KR.
090703 Elijah deleted PR151.
090703 Elijah changed PC137 to 3300pF.
090703 Elijah changed PR157 to 3.57KR.
090703 Elijah changed PR145 to 15KR.
090706 Elijah changed PC19-GND

and PC25-gnd to ISUM- for C6 reboot issue.
090706 Elijah changed PC19-GND and PC25-gnd
to ISUM- for C6 reboot issue.

090819 Changed PR1 from 10R to 2.2R for vender asking.
090819 Changed PU1 to ISL62882HRZ-TR5390 for C states

issues.
090819 Changed PR26 to 2.8KR for load line improving.
090819 Changed PQ10, PQ13 to AON7406 for H/W ripple

and noise reducing.
090819 Changed PR48 to 90.9K for power-on issue.

1 1

090819 Added PC107 and reset circuit for power-on issue.
090819 Changed PR54 to 130KR for OCP.
090819 Added VCC1.5_CPU, VCC1.5_CPU_VCC105_PWRGD

and PQ34 for S3 Power saving.
090819 Added PD2 for timing.
090819 Changed PR154 connecting with output capacitors

for OCP.
090819 Changed PR187 to 16.5KR for load line improving.
090819 Changed PR326 to 330KR for ACIN signal improving.
090819 Changed PR72 from no-mount to mount

A

B

C

D

QUANTA
COMPUTER

Title

Size Document Number Rev

Custom

Date: Sheet

Change List

TW6 Main Board

E

333Monday, August 31, 2009

of

1A

5

6/21 Change Y1 pin define for GD3 issue.

C1 27P_4

Delete R1

C2 27P_4

C5
10U/6.3V/X5R_6

C11
*10U/6.3V/X5R_6

D D

VCC3

VCC3

R5

10K/F_4

CLKEN

3

Q1
2N7002E

C C

2

1

VCC3

VCC1.05

R575
10K/F_4

L1 MNI-160808-0300P-N2

VRM_CLKEN# (22)

2134

Y1

4

CLK_XIN_3197

14.318MHZ/20P/20PPM

Delete R518

VCC3_CLK

C3 0.1U_4
C4 0.1U_4
C6 0.1U_4
C7 0.1U_4
C8 0.1U_4

VCCP_IO_CLK

C9 0.1U_4
C12 0.1U_4

PCLK_SMB(11,14,16)
PDAT_SMB(11,14,16)

3

http://hobi-elektronika.net

(3.2x2.5mm)

CLK_XOUT_3197

CLKEN

CPU_STOP#

U1

28

X1

27

X2

25

CLKPWRGD/PD#_3.3

16

CPU_STOP#

29

VDDREF_3.3

5

VDD_27MHz

1

VDDDOT96MHz_3.3

17

VDDSRC_3.3

24

VDDCPU_3.3

15

VDDSRC_IO

18

VDDCPU_IO

32

SCLK_3.3

31

SDATA_3.3

ICS9LRS3197AKLFT

GNDDOT96MHz

GNDSATA

GNDCPU

GNDSRC

GND27MHz

2921

12

8

CPUT0_LPR
CPUC0_LPR

CPUT1_LPR
CPUC1_LPR

DOT96T_LPR
DOT96C_LPR

SRCT1_LPR
SRCC1_LPR

SATAT_LPR
SATAC_LPR

27MHz_nonSS

27MHz_ss

REF_3L/FSLC_3.3**

GNDREF

Thermal PAD

26

33

23
22

20
19

3
4

13
14

10
11

6
7

30

R_14M_PCH

2

R4 33/F_4

CLKIN_BCLK_P (11)
CLKIN_BCLK_N (11)

CLKIN_DOT_96_P (11)
CLKIN_DOT_96_N (11)

CLKIN_DMI_P (11)
CLKIN_DMI_N (11)

CLKIN_SATA_P (11)
CLKIN_SATA_N (11)

14M_PCH (11)

C851

*22P_4

1

4

R_14M_PCH
CPU_STOP#

R701 10K_4
R6 *10K/F_4
R7 10K_4

VCC1.05
VCC3

CPU Frequency Select Table

CPU SRC
MHzFSLC

0(default)

1

B B

A A

133.33

100.00

100.00

MHz

REF
MHz

14.318

48.00

USB
MHz

DOT
MHz

96.00

QUANTA

Title

1.Level 1 Environment-related Substances Should NEVER be Used.

5

4

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

3

2

Size Document Number Rev

Date: Sheet

COMPUTER

CLOCK GENERATOR
TW6 Main Board

1

433Monday, August 31, 2009

2A

of

5

ARRANDALE PROCESSOR (DMI,PEG,FDI) ARRANDALE PROCESSOR (CLK,MISC,JTAG)

U2A

DMI_TXN0(9)
DMI_TXN1(9)
DMI_TXN2(9)
DMI_TXN3(9)

DMI_TXP0(9)

D D

C C

B B

A A

PROCHOT(17)

DMI_TXP1(9)
DMI_TXP2(9)
DMI_TXP3(9)

DMI_RXN0(9)
DMI_RXN1(9)
DMI_RXN2(9)
DMI_RXN3(9)

DMI_RXP0(9)
DMI_RXP1(9)
DMI_RXP2(9)
DMI_RXP3(9)

FDI_TXN0(9)
FDI_TXN1(9)
FDI_TXN2(9)
FDI_TXN3(9)
FDI_TXN4(9)
FDI_TXN5(9)
FDI_TXN6(9)
FDI_TXN7(9)

FDI_TXP0(9)
FDI_TXP1(9)
FDI_TXP2(9)
FDI_TXP3(9)
FDI_TXP4(9)
FDI_TXP5(9)
FDI_TXP6(9)
FDI_TXP7(9)

FDI_FSYNC0(9)
FDI_FSYNC1(9)

FDI_INT(9)

FDI_LSYNC0(9)
FDI_LSYNC1(9)

2

A24

DMI_RX#[0]

C23

DMI_RX#[1]

B22

DMI_RX#[2]

A21

DMI_RX#[3]

B24

DMI_RX[0]

D23

DMI_RX[1]

B23

DMI_RX[2]

A22

DMI_RX[3]

D24

DMI_TX#[0]

G24

DMI_TX#[1]

F23

DMI_TX#[2]

H23

DMI_TX#[3]

D25

DMI_TX[0]

F24

DMI_TX[1]

E23

DMI_TX[2]

G23

DMI_TX[3]

FDI_TXN0

E22
FDI_TXN1
FDI_TXN2
FDI_TXN3
FDI_TXN4
FDI_TXN5
FDI_TXN6
FDI_TXN7

FDI_TXP0
FDI_TXP1
FDI_TXP2
FDI_TXP3
FDI_TXP4
FDI_TXP5
FDI_TXP6
FDI_TXP7

H_PROCHOT# GFX_PROCHOT#

3

Q5

2N7002E

1

FDI_TX#[0]

D21

FDI_TX#[1]

D19

FDI_TX#[2]

D18

FDI_TX#[3]

G21

FDI_TX#[4]

E19

FDI_TX#[5]

F21

FDI_TX#[6]

G18

FDI_TX#[7]

D22

FDI_TX[0]

C21

FDI_TX[1]

D20

FDI_TX[2]

C18

FDI_TX[3]

G22

FDI_TX[4]

E20

FDI_TX[5]

F20

FDI_TX[6]

G19

FDI_TX[7]

F17

FDI_FSYNC[0]

E17

FDI_FSYNC[1]

C17

FDI_INT

F18

FDI_LSYNC[0]

D17

FDI_LSYNC[1]

Arrandale

VCC1.05

R39
68/F_4

5

PEG_ICOMPI

PEG_ICOMPO

PEG_RCOMPO

PEG_RBIAS
PEG_RX#[0]

PEG_RX#[1]
PEG_RX#[2]

DMI Intel(R) FDI

PEG_RX#[3]
PEG_RX#[4]
PEG_RX#[5]
PEG_RX#[6]
PEG_RX#[7]
PEG_RX#[8]

PEG_RX#[9]
PEG_RX#[10]
PEG_RX#[11]
PEG_RX#[12]
PEG_RX#[13]
PEG_RX#[14]
PEG_RX#[15]

PEG_RX[10]

PEG_RX[11]

PEG_RX[12]

PEG_RX[13]

PEG_RX[14]

PEG_RX[15]

PEG_TX#[0]

PEG_TX#[1]

PEG_TX#[2]

PEG_TX#[3]

PEG_TX#[4]

PEG_TX#[5]

PEG_TX#[6]

PEG_TX#[7]

PEG_TX#[8]

PEG_TX#[9]

PEG_TX#[10]
PEG_TX#[11]
PEG_TX#[12]
PEG_TX#[13]
PEG_TX#[14]
PEG_TX#[15]

PCI EXPRESS -- GRAPHICS

PEG_TX[10]

PEG_TX[11]

PEG_TX[12]

PEG_TX[13]

PEG_TX[14]

PEG_TX[15]

H_PROCHOT# (22)

GFX_VRHOT(26)

PEG_RX[0]
PEG_RX[1]
PEG_RX[2]
PEG_RX[3]
PEG_RX[4]
PEG_RX[5]
PEG_RX[6]
PEG_RX[7]
PEG_RX[8]
PEG_RX[9]

PEG_TX[0]
PEG_TX[1]
PEG_TX[2]
PEG_TX[3]
PEG_TX[4]
PEG_TX[5]
PEG_TX[6]
PEG_TX[7]
PEG_TX[8]
PEG_TX[9]

VCC1.5_CPU_VCC105_PWRGD(24)

B26
A26
B27
A25

K35
J34
J33
G35
G32
F34
F31
D35
E33
C33
D32
B32
C31
B28
B30
A31

J35
H34
H33
F35
G33
E34
F32
D34
F33
B33
D31
A32
C30
A28
B29
A30

L33
M35
M33
M30
L31
K32
M29
J31
K29
H30
H29
F29
E28
D29
D27
C26

L34
M34
M32
L30
M31
K31
M28
H31
K28
G30
G29
F28
E27
D28
C27
C25

3

2

1

PEG_IRCOMP_R

EXP_RBIAS

R742 10K/F_4

Q73

*2N7002E

4

R8 49.9/F_4

R10 750/F_4

0824 Add C915 0.047u

DRAMRST_CNTRL(17)

DRAMRST_CNTRL_PCH(12)

RVCC3

2
1

4

C912 0.1U_4

U69

TC7SH08FU

3 5

3

2

http://hobi-elektronika.net

(1.05V)

R25
750/F_4

C45

0.1U_4

AT23
AT24

G16

AT26

AH24

AK14

AT15

AN26

AK15

AP26

AL15

AN14

AN27

AK13

AM15

AM26

AL14

2

U2B

COMP3
COMP2
COMP1
COMP0

SKTOCC#

CATERR#

PECI

PROCHOT#

THERMTRIP#

RESET_OBS#

PM_SYNC

VCCPWRGOOD_1

VCCPWRGOOD_0

SM_DRAMPWROK

VTTPWRGOOD

TAPPWRGOOD

RSTIN#

Arrandale

VCC1.05

VCC1.05

SHDN# (23)

3

Q2

2N7002E

1

2

MISC THERMAL PWR MANAGEMENT

R9 20/F_4
R11 20/F_4
R12 49.9/F_4
R13 49.9/F_4

H_THERMTRIP#(12)

H_PMSYNC(9)

H_CPUPWRGD(12)

DRAMPWRGD_CPU

PM_DRAM_PWRGD(9)

1.5VSUS

2

Q74

VCC3

Q3

3

R512 2K/F_4
R511 1K/F_4

PLTRST#(11,16,18,30,33)

R743
1K/F_4

3

DRAMRST# (14)

VCC3

R38
10K/F_4

2

TC7SH08FU

1

3
1

MPWROK(9,17)

CH34702KB10

C915 0.047U_4

R739 *0_4

DRAMRST_CPU#

DRAMPWRGD_CPU

4

H_THERMTRIP#

R43 330/F_4

PLTRST#(11,16,18,30,33)

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

1

2N7002E

R740 *0_4

R741
100K/F_4

2

MMBT3904

R21 0_4

R22 1.5K/F_4

R23 750/F_4

R24 1.5K/F_4

Processor Pullups

H_CATERR#
H_CPURST#

XDP Signal

XDP_TMS
XDP_TDI_R
XDP_PREQ#
XDP_TCLK

R42 200K/F_4

U3

4

3 5

H_COMP3

H_COMP2

H_COMP1

H_COMP0

H_CATERR#

H_PECI(12)

H_PROCHOT#

H_THERMTRIP#

H_CPURST#

VTTPWRGOOD

T12

R26 49.9/F_4
R28 *68/F_4

R32 *51_4
R33 *51_4
R35 *51_4
R36 *51_4

1

A16

BCLK

B16

BCLK#

AR30

BCLK_ITP

AT30

BCLK_ITP#

E16

PEG_CLK

D16

PEG_CLK#

CLOCKS

DPLL_REF_SSCLK

DPLL_REF_SSCLK#

SM_DRAMRST#

SM_RCOMP[0]
SM_RCOMP[1]
SM_RCOMP[2]

PM_EXT_TS#[0]
PM_EXT_TS#[1]

DDR3

MISC

JTAG & BPM

PRDY#
PREQ#

TCK
TMS

TRST#

TDO

TDI_M

TDO_M

DBR#

BPM#[0]
BPM#[1]
BPM#[2]
BPM#[3]
BPM#[4]
BPM#[5]
BPM#[6]
BPM#[7]

A18
A17

F6
AL1

AM1
AN1

AN15
AP15

AT28
AP27

AN28
AP28
AT27

AT29

TDI

AR27
AR29
AP29

AN25

AJ22
AK22
AK24
AJ24
AJ25
AH22
AK23
AH23

CLK_CPU_BCLK (12)
CLK_CPU_BCLK# (12)

T1
T2

CLKOUT_DMI (11)
CLKOUT_DMI# (11)

PCH_DREFSSCLK (11)
PCH_DREFSSCLK# (11)

DRAMRST_CPU#

SM_RCOMP_0
SM_RCOMP_1
SM_RCOMP_2

GFX_PROCHOT#

R17 10K/F_4
R18 10K/F_4
R19 *0_4
R20 *0_4

T3

XDP_PREQ#
XDP_TCLK

XDP_TMS
XDP_TRST#

XDP_TDI_R
XDP_TDO_R
XDP_TDI_M
XDP_TDO_M

T4

T5
T6
T7
T8
T9
T10
T11
T13

R14 100/F_4
R15 24.9/F_4
R16 130/F_4

VCC1.05

JTAG MAPPING

XDP_TDI_R
XDP_TDO_M

XDP_TDI_M
XDP_TDO_R

Scan Chain
(Default)

CPU Only

GMCH Only STUFF -> R34,R37

R27 0_4
R29 *0_4

R30
0_4

R34 *0_4
R37 0_4

STUFF -> R27, R37,R30
NO STUFF -> R29,R34

STUFF -> R27,R29
NO STUFF -> R30,R37,R35

NO STUFF -> R27,R29,R37

XDP_TDI

XDP_TDO

QUANTA

Title

Size Document Number Rev

Custom

Date: Sheet

COMPUTER

PROCESSOR 1/4(HOST&PCI)

TW6 Main Board

1

533Monday, August 31, 2009

5

PM_EXTTS#0 (14)
PM_EXTTS#1 (14)

XDP_TRST#

R31
51_4

of

2A

5

U2C

4

ARRANDALE PROCESSOR (DDR3)

http://hobi-elektronika.net

3

U2D

2

1

6

AA6

SA_CK[0]

AA7

SA_CK#[0]

M_A_DQ[63:0](14)

D D

C C

B B

M_A_BS0(14)
M_A_BS1(14)
M_A_BS2(14)

M_A_CAS#(14)
M_A_RAS#(14)

M_A_WE#(14)

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

A10

C10

B10

D10

E10

F10

H10

G10

AH5
AF5
AK6
AK7
AF6
AG5

AJ7
AJ6

AJ10

AJ9

AL10

AK12

AK8

AL7

AK11

AL8

AN8
AM10
AR11

AL11

AM9

AN9
AT11
AP12
AM12
AN12
AM13
AT14
AT12

AL13
AR14
AP14

AC3
AB2

AE1
AB3
AE9

J10

M6
M8

K8
N8
P9

C7
A7

A8
D8

E6
F7
E9
B7
E7
C6

G8
K7
J8
G7

J7
L7

L9
L6

U7

SA_DQ[0]
SA_DQ[1]
SA_DQ[2]
SA_DQ[3]
SA_DQ[4]
SA_DQ[5]
SA_DQ[6]
SA_DQ[7]
SA_DQ[8]
SA_DQ[9]
SA_DQ[10]
SA_DQ[11]
SA_DQ[12]
SA_DQ[13]
SA_DQ[14]
SA_DQ[15]
SA_DQ[16]
SA_DQ[17]
SA_DQ[18]
SA_DQ[19]
SA_DQ[20]
SA_DQ[21]
SA_DQ[22]
SA_DQ[23]
SA_DQ[24]
SA_DQ[25]
SA_DQ[26]
SA_DQ[27]
SA_DQ[28]
SA_DQ[29]
SA_DQ[30]
SA_DQ[31]
SA_DQ[32]
SA_DQ[33]
SA_DQ[34]
SA_DQ[35]
SA_DQ[36]
SA_DQ[37]
SA_DQ[38]
SA_DQ[39]
SA_DQ[40]
SA_DQ[41]
SA_DQ[42]
SA_DQ[43]
SA_DQ[44]
SA_DQ[45]
SA_DQ[46]
SA_DQ[47]
SA_DQ[48]
SA_DQ[49]
SA_DQ[50]
SA_DQ[51]
SA_DQ[52]
SA_DQ[53]
SA_DQ[54]
SA_DQ[55]
SA_DQ[56]
SA_DQ[57]
SA_DQ[58]
SA_DQ[59]
SA_DQ[60]
SA_DQ[61]
SA_DQ[62]
SA_DQ[63]

SA_BS[0]
SA_BS[1]
SA_BS[2]

SA_CAS#
SA_RAS#
SA_WE#

SA_DQS#[0]
SA_DQS#[1]
SA_DQS#[2]
SA_DQS#[3]
SA_DQS#[4]
SA_DQS#[5]
SA_DQS#[6]
SA_DQS#[7]

DDR SYSTEM MEMORY A

SA_CKE[0]

SA_CK[1]
SA_CK#[1]
SA_CKE[1]

SA_CS#[0]
SA_CS#[1]

SA_ODT[0]
SA_ODT[1]

SA_DM[0]
SA_DM[1]
SA_DM[2]
SA_DM[3]
SA_DM[4]
SA_DM[5]
SA_DM[6]
SA_DM[7]

SA_DQS[0]
SA_DQS[1]
SA_DQS[2]
SA_DQS[3]
SA_DQS[4]
SA_DQS[5]
SA_DQS[6]
SA_DQS[7]

SA_MA[0]

SA_MA[1]

SA_MA[2]

SA_MA[3]

SA_MA[4]

SA_MA[5]

SA_MA[6]

SA_MA[7]

SA_MA[8]

SA_MA[9]

SA_MA[10]
SA_MA[11]
SA_MA[12]
SA_MA[13]
SA_MA[14]
SA_MA[15]

P7

Y6
Y5
P6

AE2
AE8

AD8
AF9

B9
D7
H7
M7
AG6
AM7
AN10
AN13

C9
F8
J9
N9
AH7
AK9
AP11
AT13

C8
F9
H9
M9
AH8
AK10
AN11
AR13

Y3
W1
AA8
AA3
V1
AA9
V8
T1
Y9
U6
AD4
T2
U3
AG8
T3
V9

M_A_DM0
M_A_DM1
M_A_DM2
M_A_DM3
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

M_A_DQS#0
M_A_DQS#1
M_A_DQS#2
M_A_DQS#3
M_A_DQS#4
M_A_DQS#5
M_A_DQS#6
M_A_DQS#7

M_A_DQS0
M_A_DQS1
M_A_DQS2
M_A_DQS3
M_A_DQS4
M_A_DQS5
M_A_DQS6
M_A_DQS7

A_A0

M_
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M_A_CLK0 (14)
M_A_CLK0# (14)
M_A_CKE0 (14)

M_A_CLK1 (14)
M_A_CLK1# (14)
M_A_CKE1 (14)

M_A_CS#0 (14)
M_A_CS#1 (14)

M_A_ODT0 (14)
M_A_ODT1 (14)

M_A_DM[7:0] (14)

M_A_DQS#[7:0] (14)

M_A_DQS[7:0] (14)

M_A_A[15:0] (14)

M_B_DQ[63:0](14)

M_B_DQ0
M_B_DQ1
M_B_DQ2
M_B_DQ3
M_B_DQ4
M_B_DQ5
M_B_DQ6
M_B_DQ7
M_B_DQ8
M_B_DQ9
M_B_DQ10
M_B_DQ11
M_B_DQ12
M_B_DQ13
M_B_DQ14
M_B_DQ15
M_B_DQ16
M_B_DQ17
M_B_DQ18
M_B_DQ19
M_B_DQ20
M_B_DQ21
M_B_DQ22
M_B_DQ23
M_B_DQ24
M_B_DQ25
M_B_DQ26
M_B_DQ27
M_B_DQ28
M_B_DQ29
M_B_DQ30
M_B_DQ31
M_B_DQ32
M_B_DQ33
M_B_DQ34
M_B_DQ35
M_B_DQ36
M_B_DQ37
M_B_DQ38
M_B_DQ39
M_B_DQ40
M_B_DQ41
M_B_DQ42
M_B_DQ43
M_B_DQ44
M_B_DQ45
M_B_DQ46
M_B_DQ47
M_B_DQ48
M_B_DQ49
M_B_DQ50
M_B_DQ51
M_B_DQ52
M_B_DQ53
M_B_DQ54
M_B_DQ55
M_B_DQ56
M_B_DQ57
M_B_DQ58
M_B_DQ59
M_B_DQ60
M_B_DQ61
M_B_DQ62
M_B_DQ63

M_B_BS0(14)
M_B_BS1(14)
M_B_BS2(14)

M_B_CAS#(14)
M_B_RAS#(14)

M_B_WE#(14)

AR10

AT10

AF3
AG1

AJ3
AK1
AG4
AG3

AJ4
AH4
AK3
AK4
AM6
AN2
AK5
AK2
AM4
AM3
AP3
AN5
AT4
AN6
AN4
AN3
AT5
AT6
AN7
AP6
AP8
AT9
AT7
AP9

AB1

AC5
AC6

B5
A5

C3

B3
E4
A6

A4
C4
D1
D2

F2

F1
C2

F5

F3
G4
H6
G2

J6

J3
G1
G5

J2

J1

J5

K2

L3
M1

K5

K4
M4
N5

W5
R7

Y7

SB_DQ[0]
SB_DQ[1]
SB_DQ[2]
SB_DQ[3]
SB_DQ[4]
SB_DQ[5]
SB_DQ[6]
SB_DQ[7]
SB_DQ[8]
SB_DQ[9]
SB_DQ[10]
SB_DQ[11]
SB_DQ[12]
SB_DQ[13]
SB_DQ[14]
SB_DQ[15]
SB_DQ[16]
SB_DQ[17]
SB_DQ[18]
SB_DQ[19]
SB_DQ[20]
SB_DQ[21]
SB_DQ[22]
SB_DQ[23]
SB_DQ[24]
SB_DQ[25]
SB_DQ[26]
SB_DQ[27]
SB_DQ[28]
SB_DQ[29]
SB_DQ[30]
SB_DQ[31]
SB_DQ[32]
SB_DQ[33]
SB_DQ[34]
SB_DQ[35]
SB_DQ[36]
SB_DQ[37]
SB_DQ[38]
SB_DQ[39]
SB_DQ[40]
SB_DQ[41]
SB_DQ[42]
SB_DQ[43]
SB_DQ[44]
SB_DQ[45]
SB_DQ[46]
SB_DQ[47]
SB_DQ[48]
SB_DQ[49]
SB_DQ[50]
SB_DQ[51]
SB_DQ[52]
SB_DQ[53]
SB_DQ[54]
SB_DQ[55]
SB_DQ[56]
SB_DQ[57]
SB_DQ[58]
SB_DQ[59]
SB_DQ[60]
SB_DQ[61]
SB_DQ[62]
SB_DQ[63]

SB_BS[0]
SB_BS[1]
SB_BS[2]

SB_CAS#
SB_RAS#
SB_WE#

SB_DQS#[0]
SB_DQS#[1]
SB_DQS#[2]
SB_DQS#[3]
SB_DQS#[4]
SB_DQS#[5]
SB_DQS#[6]
SB_DQS#[7]

DDR SYSTEM MEMORY - B

SB_CK[0]

SB_CK#[0]

SB_CKE[0]

SB_CK[1]

SB_CK#[1]

SB_CKE[1]

SB_CS#[0]
SB_CS#[1]

SB_ODT[0]
SB_ODT[1]

SB_DM[0]
SB_DM[1]
SB_DM[2]
SB_DM[3]
SB_DM[4]
SB_DM[5]
SB_DM[6]
SB_DM[7]

SB_DQS[0]
SB_DQS[1]
SB_DQS[2]
SB_DQS[3]
SB_DQS[4]
SB_DQS[5]
SB_DQS[6]
SB_DQS[7]

SB_MA[0]
SB_MA[1]
SB_MA[2]
SB_MA[3]
SB_MA[4]
SB_MA[5]
SB_MA[6]
SB_MA[7]
SB_MA[8]

SB_MA[9]
SB_MA[10]
SB_MA[11]
SB_MA[12]
SB_MA[13]
SB_MA[14]
SB_MA[15]

W8
W9
M3

V7
V6
M2

AB8
AD6

AC7
AD1

D4
E1
H3
K1
AH1
AL2
AR4
AT8

D5
F4
J4
L4
AH2
AL4
AR5
AR8

C5
E3
H4
M5
AG2
AL5
AP5
AR7

U5
V2
T5
V3
R1
T8
R2
R6
R4
R5
AB5
P3
R3
AF7
P5
N1

M_B_DM0
M_B_DM1
M_B_DM2
M_B_DM3
M_B_DM4
M_B_DM5
M_B_DM6
M_B_DM7

M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7

M_B_A0
M_B_A1
M_B_A2
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

M_B_CLK0 (14)
M_B_CLK0# (14)
M_B_CKE0 (14)

M_B_CLK1 (14)
M_B_CLK1# (14)
M_B_CKE1 (14)

M_B_CS#0 (14)
M_B_CS#1 (14)

M_B_ODT0 (14)
M_B_ODT1 (14)

M_B_DM[7:0] (14)

M_B_DQS#[7:0] (14)

M_B_DQS[7:0] (14)

M_B_A[15:0] (14)

Arrandale

A A

Arrandale

QUANTA

Title

1. Level 1 Environment-related Substances Should NEVER be Used.

5

4

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

3

2

Size Document Number Rev

Custom

Date: Sheet

COMPUTER

PROCESSOR 2/4(DDR)

TW6 Main Board

1

633Monday, August 31, 2009

1A

of

5

CPU:

VCC_CORE

D D

C C

B B

A A

AG35
AG34
AG33
AG32
AG31
AG30
AG29
AG28
AG27
AG26
AF35
AF34
AF33
AF32
AF31
AF30
AF29
AF28
AF27
AF26
AD35
AD34
AD33
AD32
AD31
AD30
AD29
AD28
AD27
AD26
AC35
AC34
AC33
AC32
AC31
AC30
AC29
AC28
AC27
AC26
AA35
AA34
AA33
AA32
AA31
AA30
AA29
AA28
AA27
AA26

Y35
Y34
Y33
Y32
Y31
Y30
Y29
Y28
Y27
Y26
V35
V34
V33
V32
V31
V30
V29
V28
V27
V26
U35
U34
U33
U32
U31
U30
U29
U28
U27
U26
R35
R34
R33
R32
R31
R30
R29
R28
R27
R26
P35
P34
P33
P32
P31
P30
P29
P28
P27
P26

U2F

VCC1
VCC2
VCC3
VCC4
VCC5
VCC6
VCC7
VCC8
VCC9
VCC10
VCC11
VCC12
VCC13
VCC14
VCC15
VCC16
VCC17
VCC18
VCC19
VCC20
VCC21
VCC22
VCC23
VCC24
VCC25
VCC26
VCC27
VCC28
VCC29
VCC30
VCC31
VCC32
VCC33
VCC34
VCC35
VCC36
VCC37
VCC38
VCC39
VCC40
VCC41
VCC42
VCC43
VCC44
VCC45
VCC46
VCC47
VCC48
VCC49
VCC50
VCC51
VCC52
VCC53
VCC54
VCC55
VCC56
VCC57
VCC58
VCC59
VCC60
VCC61
VCC62
VCC63
VCC64
VCC65
VCC66
VCC67
VCC68
VCC69
VCC70
VCC71
VCC72
VCC73
VCC74
VCC75
VCC76
VCC77
VCC78
VCC79
VCC80
VCC81
VCC82
VCC83
VCC84
VCC85
VCC86
VCC87
VCC88
VCC89
VCC90
VCC91
VCC92
VCC93
VCC94
VCC95
VCC96
VCC97
VCC98
VCC99
VCC100

VTT0_10
VTT0_11
VTT0_12
VTT0_13
VTT0_14
VTT0_15
VTT0_16
VTT0_17
VTT0_18
VTT0_19
VTT0_20
VTT0_21
VTT0_22
VTT0_23
VTT0_24
VTT0_25
VTT0_26
VTT0_27
VTT0_28
VTT0_29
VTT0_30

1.1V RAIL POWERSENSE LINES CPU VIDS

CPU CORE SUPPLY

VTT0_31
VTT0_32

VTT0_33
VTT0_34
VTT0_35
VTT0_36
VTT0_37
VTT0_38
VTT0_39
VTT0_40
VTT0_41
VTT0_42
VTT0_43
VTT0_44

POWER

PROC_DPRSLPVR

VTT_SELECT

VCC_SENSE
VSS_SENSE

VTT_SENSE

VSS_SENSE_VTT

Arrandale

5

VTT0_1
VTT0_2
VTT0_3
VTT0_4
VTT0_5
VTT0_6
VTT0_7
VTT0_8
VTT0_9

PSI#

VID[0]
VID[1]
VID[2]
VID[3]
VID[4]
VID[5]
VID[6]

ISENSE

ARRANDALE 1.05V

(18A)

AH14
AH12
AH11
AH10
J14
J13
H14
H12
G14
G13
G12
G11
F14
F13
F12
F11
E14
E12
D14
D13
D12
D11
C14
C13
C12
C11
B14
B12
A14
A13
A12
A11

C103 22U/6.3V_8

AF10

C105 22U/6.3V_8

AE10
AC10
AB10
Y10
W10
U10
T10
J12
J11

+VTT_43

J16

+VTT_44

J15

PSI#

AN33

CPU_VID0

AK35

CPU_VID1

AK33

CPU_VID2

AK34

CPU_VID3

AL35

CPU_VID4

AL33

CPU_VID5

AM33

CPU_VID6

AM35

PM_DPRSLPVR

AM34

G15

AN35

AJ34
AJ35

B15
A15

VCC1.05

C688 330U/2.5V/3528/ESR=9/H1.9

+

C48 10U/6.3V/X5R_6
C52 10U/6.3V/X5R_6
C58 10U/6.3V/X5R_6
C62 10U/6.3V/X5R_6
C66 10U/6.3V/X5R_6
C69 10U/6.3V/X5R_6
C71 10U/6.3V/X5R_6
C74 10U/6.3V/X5R_6
C76 *10U/6.3V/X5R_6
C79 22U/6.3V_8
C83 22U/6.3V_8
C87 22U/6.3V_8

R45 0_4
R46 0_4

PSI# (22)

CPU_VID0 (22)
CPU_VID1 (22)
CPU_VID2 (22)
CPU_VID3 (22)
CPU_VID4 (22)
CPU_VID5 (22)
CPU_VID6 (22)
PM_DPRSLPVR (22)

CPU_IMON (22)

T94

T95

4

http://hobi-elektronika.net

VCC_CORE

C46 22U/6.3V_8
C47 22U/6.3V_8
C49 22U/6.3V_8
C51 22U/6.3V_8
C53 22U/6.3V_8
C55 22U/6.3V_8
C59 22U/6.3V_8
C61 22U/6.3V_8
C63 22U/6.3V_8
C65 22U/6.3V_8
C67 22U/6.3V_8
C68 22U/6.3V_8

C70 22U/6.3V_8
C72 22U/6.3V_8
C73 22U/6.3V_8
C75 22U/6.3V_8

C78 10U/6.3V/X5R_6
C80 10U/6.3V/X5R_6
C82 10U/6.3V/X5R_6
C84 10U/6.3V/X5R_6
C86 10U/6.3V/X5R_6
C88 10U/6.3V/X5R_6
C90 10U/6.3V/X5R_6
C91 10U/6.3V/X5R_6
C93 10U/6.3V/X5R_6
C95 10U/6.3V/X5R_6
C97 10U/6.3V/X5R_6
C98 10U/6.3V/X5R_6
C100 10U/6.3V/X5R_6
C101 10U/6.3V/X5R_6
C104 10U/6.3V/X5R_6
C106 10U/6.3V/X5R_6

+

C108 470U/2V/7343/ESR=4.5

+

C110 470U/2V/7343/ESR=4.5

VCC1.05

Clarksfiled VTT=1.1 VTT_Select=Low
Arrandale VTT=1.05 VTT_Select=High

VCC_CORE

R56
100_4

VCCSENSE (22)
VSSSENSE (22)

R59
100_4

4

3

6/1 Change power consumption of VAXG 15A to 22A

Please note that +VCC_GFX_CORE
should be 1.05V in Auburndale

+VCC_GFXCORE

C50 22U/6.3V_8
C54 22U/6.3V_8
C60 10U/6.3V/X5R_6

C64 10U/6.3V/X5R_6

C56 330U/2.5V/3528/ESR=9/H1.9

+

C57 *330U/2.5V/3528/ESR=9/H1.9

+

ARRANDALE PROCESSOR (GRAPHICS POWER)

(22A)

VCC1.05

C112 22U/6.3V_8
C113 22U/6.3V_8

VCC1.05

C118 22U/6.3V_8
C119 22U/6.3V_8
C120 22U/6.3V_8
C121 22U/6.3V_8

AT21
AT19
AT18
AT16
AR21
AR19
AR18
AR16
AP21
AP19
AP18
AP16
AN21
AN19
AN18
AN16
AM21
AM19
AM18
AM16

AL21
AL19
AL18

AL16
AK21
AK19
AK18
AK16

AJ21

AJ19

AJ18

AJ16
AH21
AH19
AH18
AH16

H25

K26

H27
G28
G27
G26
F26
E26
E25

J24
J23

J27
J26
J25

U2G

VAXG1
VAXG2
VAXG3
VAXG4
VAXG5
VAXG6
VAXG7
VAXG8
VAXG9
VAXG10
VAXG11
VAXG12
VAXG13
VAXG14
VAXG15
VAXG16
VAXG17
VAXG18
VAXG19
VAXG20
VAXG21
VAXG22
VAXG23
VAXG24
VAXG25
VAXG26
VAXG27
VAXG28
VAXG29
VAXG30
VAXG31
VAXG32
VAXG33
VAXG34
VAXG35
VAXG36

VTT1_45
VTT1_46
VTT1_47

VTT1_48
VTT1_49
VTT1_50
VTT1_51
VTT1_52
VTT1_53
VTT1_54
VTT1_55
VTT1_56
VTT1_57
VTT1_58

Arrandale

2

SENSE

LINES

GRAPHICS

GRAPHICS VIDs

FDI PEG & DMI

POWER

VAXG_SENSE

VSSAXG_SENSE

GFX_VID[0]
GFX_VID[1]
GFX_VID[2]
GFX_VID[3]
GFX_VID[4]
GFX_VID[5]
GFX_VID[6]

GFX_VR_EN

GFX_DPRSLPVR

GFX_IMON

VDDQ1
VDDQ2
VDDQ3
VDDQ4
VDDQ5
VDDQ6
VDDQ7
VDDQ8

VDDQ9
VDDQ10
VDDQ11
VDDQ12
VDDQ13
VDDQ14
VDDQ15
VDDQ16
VDDQ17
VDDQ18

DDR3 - 1.5V RAILS

VTT0_59
VTT0_60
VTT0_61
VTT0_62

VTT1_63

1.1V1.8V

VTT1_64
VTT1_65
VTT1_66
VTT1_67
VTT1_68

VCCPLL1
VCCPLL2
VCCPLL3

AR22
AT22

AM22
AP22
AN22
AP23
AM23
AP24
AN24

AR25
AT25
AM24

AJ1
AF1
AE7
AE4
AC1
AB7
AB4
Y1
W7
W4
U1
T7
T4
P1
N7
N4
L1
H1

P10
N10
L10
K10

J22
J20
J18
H21
H20
H19

L26
L27
M26

For Turbo Mode

R663 1K/F_4
R664 1K/F_4
R665 *1K/F_4
R659 1K/F_4
R660 1K/F_4
R661 *1K/F_4
R667 1K/F_4

R582 *1K/F_4 R54 1K/F_4
R68 1K/F_4 R574 *1K/F_4

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

3

CPU_VID0
CPU_VID1
CPU_VID2
CPU_VID3
CPU_VID4
CPU_VID5
CPU_VID6

PM_DPRSLPVR
PSI#

CRB default VID[6:0]=0100100
PSI# default=0
DPRSLPVR default=1

R47 *1K/F_4
R48 *1K/F_4
R49 1K/F_4
R63 *1K/F_4
R64 *1K/F_4
R52 1K/F_4
R66 *1K/F_4

VCC1.05

5/2 Add R582

VCC1.05
VCC1.05

Title

Size Document Number Rev

Custom

2

Date: Sheet

VCC_AXG_SENSE (26)
VSS_AXG_SENSE (26)

GFX_VID0 (26)
GFX_VID1 (26)
GFX_VID2 (26)
GFX_VID3 (26)
GFX_VID4 (26)
GFX_VID5 (26)
GFX_VID6 (26)

R44 4.7K/F_4
R521 0_4
R520 0_4
R522 0_4

Max.5A

C92 1U/6.3V/X5R_4
C96 1U/6.3V/X5R_4
C99 1U/6.3V/X5R_4
C102 1U/6.3V/X5R_4
C107 1U/6.3V/X5R_4

C705 10U/6.3V/X5R_6
C706 10U/6.3V/X5R_6
C707 10U/6.3V/X5R_6
C708 10U/6.3V/X5R_6

VCC1.05

C114 10U/6.3V/X5R_6
C115 10U/6.3V/X5R_6

VCC1.05

C116 22U/6.3V_8
C117 22U/6.3V_8

(0.6A)

VCC1.8

C122 1U/6.3V/X5R_4
C123 1U/6.3V/X5R_4
C124 2.2U/6.3V_6
C125 4.7U/6.3V/X5R_6
C126 22U/6.3V_8

QUANTA
COMPUTER

PROCESSOR 3/4(POWER)

TW6 Main Board

1

GFX_VR_EN (23,26)
GFX_DPRSLPVR (26)
GFXVR_IMON (26)

VCC1.5_CPU

+

C94

330U/2.5V/3528/ESR=9/H1.9

733Monday, August 31, 2009

1

7

2A

of

5

U2H

VSS

AT20

VSS1

AT17

VSS2

AR31

VSS3

AR28

VSS4

AR26

VSS5

AR24

VSS6

AR23

VSS7

AR20

VSS8

AR17

VSS9

AR15

D D

C C

B B

AR12

AR9
AR6

AR3
AP20
AP17
AP13
AP10

AP7

AP4

AP2
AN34
AN31
AN23
AN20
AN17
AM29
AM27
AM25
AM20
AM17
AM14
AM11

AM8
AM5

AM2
AL34
AL31
AL23
AL20
AL17
AL12

AL9
AL6

AL3
AK29
AK27
AK25
AK20
AK17

AJ31
AJ23
AJ20
AJ17
AJ14
AJ11

AJ8

AJ5

AJ2
AH35
AH34
AH33
AH32
AH31
AH30
AH29
AH28
AH27
AH26
AH20
AH17
AH13

AH9
AH6
AH3

AG10

AF8

AF4

AF2
AE35

VSS10
VSS11
VSS12
VSS13
VSS14
VSS15
VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52
VSS53
VSS54
VSS55
VSS56
VSS57
VSS58
VSS59
VSS60
VSS61
VSS62
VSS63
VSS64
VSS65
VSS66
VSS67
VSS68
VSS69
VSS70
VSS71
VSS72
VSS73
VSS74
VSS75
VSS76
VSS77
VSS78
VSS79
VSS80

Arrandale

ARRANDALE PROCESSOR (GND) ARRANDALE PROCESSOR( RESERVED, CFG)

U2I

AE34

VSS81

AE33

VSS82
VSS83
VSS84
VSS85
VSS86
VSS87
VSS88
VSS89
VSS90
VSS91
VSS92
VSS93
VSS94
VSS95
VSS96
VSS97
VSS98

VSS99
VSS100
VSS101
VSS102
VSS103
VSS104
VSS105
VSS106
VSS107
VSS108
VSS109
VSS110
VSS111
VSS112
VSS113
VSS114
VSS115
VSS116
VSS117
VSS118
VSS119
VSS120
VSS121
VSS122
VSS123
VSS124
VSS125
VSS126
VSS127
VSS128
VSS129
VSS130
VSS131
VSS132
VSS133
VSS134
VSS135
VSS136
VSS137
VSS138
VSS139
VSS140
VSS141
VSS142
VSS143
VSS144
VSS145
VSS146
VSS147
VSS148
VSS149
VSS150
VSS151
VSS152
VSS153
VSS154
VSS155
VSS156
VSS157
VSS158
VSS159
VSS160

AE32
AE31
AE30
AE29
AE28
AE27
AE26
AE6
AD10
AC8
AC4
AC2
AB35
AB34
AB33
AB32
AB31
AB30
AB29
AB28
AB27
AB26
AB6
AA10
Y8
Y4
Y2
W35
W34
W33
W32
W31
W30
W29
W28
W27
W26
W6
V10
U8
U4
U2
T35
T34
T33
T32
T31
T30
T29
T28
T27
T26
T6
R10
P8
P4
P2
N35
N34
N33
N32
N31
N30
N29
N28
N27
N26
N6
M10
L35
L32
L29
L8
L5
L2
K34
K33
K30

K27

H35
H32
H28
H26
H24
H22
H18
H15
H13
H11

G34
G31
G20

F30
F27
F25
F22
F19
F16
E35
E32
E29
E24
E21
E18
E13
E11

D33
D30
D26

C34
C32
C29
C28
C24
C22
C20
C19
C16
B31
B25
B21
B18
B17
B13
B11

A29
A27
A23

J32
J30
J21
J19

K9
K6
K3

H8
H5
H2

G9
G6
G3

E8
E5
E2

D9
D6
D3

B8
B6
B4

A9

VSS161
VSS162
VSS163
VSS164
VSS165
VSS166
VSS167
VSS168
VSS169
VSS170
VSS171
VSS172
VSS173
VSS174
VSS175
VSS176
VSS177
VSS178
VSS179
VSS180
VSS181
VSS182
VSS183
VSS184
VSS185
VSS186
VSS187
VSS188
VSS189
VSS190
VSS191
VSS192
VSS193
VSS194
VSS195
VSS196
VSS197
VSS198
VSS199
VSS200
VSS201
VSS202
VSS203
VSS204
VSS205
VSS206
VSS207
VSS208
VSS209
VSS210
VSS211
VSS212
VSS213
VSS214
VSS215
VSS216
VSS217
VSS218
VSS219
VSS220
VSS221
VSS222
VSS223
VSS224
VSS225
VSS226
VSS227
VSS228
VSS229
VSS230
VSS231
VSS232
VSS233

Arrandale

VSS

NCTF

VSS_NCTF1
VSS_NCTF2
VSS_NCTF3
VSS_NCTF4
VSS_NCTF5
VSS_NCTF6
VSS_NCTF7

4

http://hobi-elektronika.net

AT35
AT1
AR34
B34
B2
B1
A35

3

2

1

8

U2E

AJ13

RSVD32

AJ12

AP25

RSVD1

AL25

RSVD2

AL24

RSVD3

AL22

RSVD4

AJ33

RSVD5

AG9

RSVD6

M27

RSVD7

L28

RSVD8
T98
T99

CFG0

CFG3
CFG4

J17

SA_DIMM_VREF

H17

SB_DIMM_VREF

G25

RSVD11

G17

RSVD12

E31

RSVD13

E30

RSVD14

AM30

CFG[0]

AM28
AP31

AL32

AL30
AM31
AN29
AM32
AK32
AK31
AK28

AJ28
AN30
AN32

AJ32

AJ29

AJ30
AK30

H16

B19
A19

A20
B20

AC9
AB9

A34
A33

C35

B35

U9
T9

C1
A3

J29
J28

CFG[1]
CFG[2]
CFG[3]
CFG[4]
CFG[5]
CFG[6]
CFG[7]
CFG[8]
CFG[9]
CFG[10]
CFG[11]
CFG[12]
CFG[13]
CFG[14]
CFG[15]
CFG[16]
CFG[17]
RSVD_TP_86

RSVD15
RSVD16

RSVD17
RSVD18

RSVD19
RSVD20

RSVD21
RSVD22

RSVD_NCTF_23
RSVD_NCTF_24

RSVD26
RSVD27

RSVD_NCTF_28
RSVD_NCTF_29

RSVD_NCTF_30
RSVD_NCTF_31

Arrandale

T74
T75

T76
T77
T78
T79
T80
T81
T82
T83
T84
T85
T86
T87
T88

RSVD33

RSVD34
RSVD35

RSVD36

RSVD_NCTF_37

RSVD38
RSVD39

RSVD_NCTF_40
RSVD_NCTF_41

RSVD_NCTF_42
RSVD_NCTF_43

RSVD45
RSVD46
RSVD47
RSVD48
RSVD49
RSVD50
RSVD51
RSVD52

RSVD53
RSVD_NCTF_54
RSVD_NCTF_55
RSVD_NCTF_56
RSVD_NCTF_57

RSVD58

RSVD_TP_59
RSVD_TP_60

RESERVED

KEY
RSVD62
RSVD63
RSVD64
RSVD65

RSVD_TP_66
RSVD_TP_67
RSVD_TP_68
RSVD_TP_69
RSVD_TP_70
RSVD_TP_71
RSVD_TP_72
RSVD_TP_73
RSVD_TP_74
RSVD_TP_75

RSVD_TP_76
RSVD_TP_77
RSVD_TP_78
RSVD_TP_79
RSVD_TP_80
RSVD_TP_81
RSVD_TP_82
RSVD_TP_83
RSVD_TP_84
RSVD_TP_85

VSS

AH25
AK26

AL26
AR2

AJ26
AJ27

AP1
AT2

AT3
AR1

AL28
AL29
AP30
AP32
AL27
AT31
AT32
AP33
AR33
AT33
AT34
AP35
AR35
AR32

E15
F15
A2
D15
C15
AJ15
AH15

AA5
AA4
R8
AD3
AD2
AA2
AA1
R9
AG7
AE3

V4
V5
N2
AD5
AD7
W3
W2
N3
AE5
AD9

AP34

CFG0

R73 *3.01K_4

A A

Not applicable for Clarksfield Processor

PCI-Epress Configuration Select

1 : Single PEG

CFG0

0 : Bifurcation enabled

5

PCI-Epress Static Lane Reversal

CFG3

R74 *3.01K_4

CFG3

1 : Normal Operation
0 : Lane Number Reversed
15 -> 0, 14 -> 1, ...

4

CFG4

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

CFG4 - Display Port Presence

1 : Disabled; No Physical Display Port
attached to Embedded Diplay Port

0 : Enabled; An external Display port
device is connected to the Embedded
Display port

3

CFG4

2

R75
*3.01K_4

QUANTA

Title

Size Document Number Rev

Custom

Date: Sheet

COMPUTER

PROCESSOR 4/4(GND)

TW6 Main Board

1

833Monday, August 31, 2009

of

2A

5

4/17 Swap FDI,DMI BUS

D D

VCC1.05_PCH_IO

R82 49.9/F_4

IBEX PEAK-M (DMI,FDI,GPIO)

U4C

DMI_RXN0(5)
DMI_RXN1(5)
DMI_RXN2(5)
DMI_RXN3(5)

DMI_RXP0(5)
DMI_RXP1(5)
DMI_RXP2(5)
DMI_RXP3(5)

DMI_TXN0(5)
DMI_TXN1(5)
DMI_TXN2(5)
DMI_TXN3(5)

DMI_TXP0(5)
DMI_TXP1(5)
DMI_TXP2(5)
DMI_TXP3(5)

DMICOMP

BC24

BJ22

AW20

BJ20

BD24
BG22
BA20
BG20

BE22
BF21
BD20
BE18

BD22
BH21
BC20
BD18

BH25
BF25

DMI0RXN
DMI1RXN
DMI2RXN
DMI3RXN

DMI0RXP
DMI1RXP
DMI2RXP
DMI3RXP

DMI0TXN
DMI1TXN
DMI2TXN
DMI3TXN

DMI0TXP
DMI1TXP
DMI2TXP
DMI3TXP

DMI_ZCOMP
DMI_IRCOMP

System Power Management

R99 10K/F_4

C C

B B

VCC3

HWPG(17)

MPWROK(5,17)

PM_DRAM_PWRGD(5)

SUS_PWR_DN_ACK(17)

R83 0_4

R84 *0_4
R85 10K_4

DNBSWON#(17)

RVCC3

ACPRESENT(17)

R567 *10K_4

SYS_RESET#

HWPG

PM_MPWROK_R

LAN_RST#_R

RSMRST#

SUS_PWR_DN_ACK

DNBSWON#

PM_BATLOW#

PM_RI#

T6

SYS_RESET#

M6

SYS_PWROK

B17

PWROK

K5

MEPWROK

A10

LAN_RST#

D9

DRAMPWROK

C16

RSMRST#

M1

SUS_PWR_ACK / GPIO30

P5

PWRBTN#

P7

ACPRESENT / GPIO31

A6

BATLOW# / GPIO72

F14

RI#

IbexPeak-M(ES v0.9)

4

FDI_RXN0
FDI_RXN1
FDI_RXN2
FDI_RXN3
FDI_RXN4
FDI_RXN5
FDI_RXN6
FDI_RXN7

FDI_RXP0
FDI_RXP1
FDI_RXP2
FDI_RXP3
FDI_RXP4
FDI_RXP5
FDI_RXP6

FDI

FDI_RXP7

DMI

FDI_FSYNC0
FDI_FSYNC1
FDI_LSYNC0
FDI_LSYNC1

CLKRUN# / GPIO32

SUS_STAT# / GPIO61

SUSCLK / GPIO62

SLP_S5# / GPIO63

SLP_S4#

SLP_S3#

PMSYNCH

SLP_LAN#/GPIO29

3VSUS

FDI_INT

WAKE#

SLP_M#

TP23

BA18
BH17
BD16
BJ16
BA16
BE14
BA14
BC12

BB18
BF17
BC16
BG16
AW16
BD14
BB14
BD12

BJ14
BF13
BH13
BJ12
BG14

5/27 modify remove
R531~R543

PCIE_WAKE#

J12

PCI_CLKRUN#

Y1

RSV_LPCPD#

P8

F3

E4

H7

P12

K8

N2

BJ10

F6

PM_SLP_S5# (17)

PM_SLP_S4# (17)

PM_SLP_S3# (17)

T19

T20

H_PMSYNC (5)

T68

3

http://hobi-elektronika.net

FDI_TXN0 (5)
FDI_TXN1 (5)
FDI_TXN2 (5)
FDI_TXN3 (5)
FDI_TXN4 (5)
FDI_TXN5 (5)
FDI_TXN6 (5)
FDI_TXN7 (5)

FDI_TXP0 (5)
FDI_TXP1 (5)
FDI_TXP2 (5)
FDI_TXP3 (5)
FDI_TXP4 (5)
FDI_TXP5 (5)
FDI_TXP6 (5)
FDI_TXP7 (5)

FDI_INT (5)
FDI_FSYNC0 (5)
FDI_FSYNC1 (5)
FDI_LSYNC0 (5)
FDI_LSYNC1 (5)

PCI_CLKRUN# (17,18)

ICH_SUSCLK (17)

T17

CRT_B(15)
CRT_G(15)
CRT_R(15)

DDC2BC(15,18)
DDC2BD(15,18)

HSYNC(15,18)
VSYNC(15)

L_BKLT_EN(15)

LVDS_VDDEN(15)

L_BKLTCTL(15)

VCC3

R93 1K/F_4

R77 10K/F_4
R78 10K/F_4

R79 2.37K/F

R_R1CLK0-(15)

R_R1CLK0+(15)
R_R1OUT0-(15)

R_R1OUT1-(15)
R_R1OUT2-(15)

R_R1OUT0+(15)
R_R1OUT1+(15)
R_R1OUT2+(15)

R_R2CLK0-(15)

R_R2CLK0+(15)
R_R2OUT0-(15)

R_R2OUT1-(15)
R_R2OUT2-(15)

R_R2OUT0+(15)
R_R2OUT1+(15)
R_R2OUT2+(15)

R86 0_4
R87 0_4
R88 0_4

IBEX PEAK-M (LVDS,DDI)

LVDS_CLK
LVDS_DATA

T14

T15

T16

T4006

T4007

NB_B
NB_G
NB_R

DAC_IREF_R

U4D

T48

L_BKLTEN

T47

L_VDD_EN

Y48

L_BKLTCTL

AB48

L_DDC_CLK

Y45

L_DDC_DATA

AB46

L_CTRL_CLK

V48

L_CTRL_DATA

AP39

LVD_IBG

AP41

LVD_VBG

AT43

LVD_VREFH

AT42

LVD_VREFL

AV53

LVDSA_CLK#

AV51

LVDSA_CLK

BB47

LVDSA_DATA#0

BA52

LVDSA_DATA#1

AY48

LVDSA_DATA#2

AV47

LVDSA_DATA#3

BB48

LVDSA_DATA0

BA50

LVDSA_DATA1

AY49

LVDSA_DATA2

AV48

LVDSA_DATA3

AP48

LVDSB_CLK#

AP47

LVDSB_CLK

AY53

LVDSB_DATA#0

AT49

LVDSB_DATA#1

AU52

LVDSB_DATA#2

AT53

LVDSB_DATA#3

AY51

LVDSB_DATA0

AT48

LVDSB_DATA1

AU50

LVDSB_DATA2

AT51

LVDSB_DATA3

AA52

CRT_BLUE

AB53

CRT_GREEN

AD53

CRT_RED

V51

CRT_DDC_CLK

V53

CRT_DDC_DATA

Y53

CRT_HSYNC

Y51

CRT_VSYNC

AD48

DAC_IREF

AB51

CRT_IRTN

IbexPeak-M(ES v0.9)

2

LVDS

CRT

SDVO_TVCLKINN
SDVO_TVCLKINP

SDVO_STALLN
SDVO_STALLP

SDVO_INTN
SDVO_INTP

SDVO_CTRLCLK

SDVO_CTRLDATA

DDPB_AUXN
DDPB_AUXP

DDPB_HPD

DDPB_0N
DDPB_0P
DDPB_1N
DDPB_1P
DDPB_2N
DDPB_2P
DDPB_3N
DDPB_3P

DDPC_CTRLCLK

DDPC_CTRLDATA

DDPC_AUXN
DDPC_AUXP

DDPC_HPD

DDPC_0N
DDPC_0P

Digital Display Interface

DDPC_1N
DDPC_1P
DDPC_2N
DDPC_2P
DDPC_3N
DDPC_3P

DDPD_CTRLCLK

DDPD_CTRLDATA

DDPD_AUXN
DDPD_AUXP

DDPD_HPD

DDPD_0N
DDPD_0P
DDPD_1N
DDPD_1P
DDPD_2N
DDPD_2P
DDPD_3N
DDPD_3P

BJ46
BG46

BJ48
BG48

BF45
BH45

HDMI_CTRL_CLK

T51

HDMI_CTRL_DATA

T53

BG44
BJ44

HDMI_HPD

AU38

HDMI_DATA2_C#

BD42

HDMI_DATA2_C

BC42

HDMI_DATA1_C#

BJ42

HDMI_DATA1_C

BG42

HDMI_DATA0_C#

BB40

HDMI_DATA0_C

BA40

HDMI_CLK_C#

AW38

HDMI_CLK_C

BA38

DDP_EXT_CTRL_CLK

Y49

DDP_EXT_CTRL_DATA

AB49

BE44
BD44

HDMI_DOCK_HPD_EXT

AV40

C_DDP_EXT_DATA2#

BE40

C_DDP_EXT_DATA2

BD40

C_DDP_EXT_DATA1#

BF41

C_DDP_EXT_DATA1

BH41

C_DDP_EXT_DATA0#

BD38

C_DDP_EXT_DATA0

BC38

C_DDP_EXT_CLK#

BB36

C_DDP_EXT_CLK

BA36

U50
U52

BC46
BD46
AT38

BJ40
BG40
BJ38
BG38
BF37
BH37
BE36
BD36

1

HDMI_CTRL_CLK (21)
HDMI_CTRL_DATA (21)

R80 100K/F_4
R81 100K/F_4

HDMI_HPD (21)

C127 0.1U_4
C128 0.1U_4
C129 0.1U_4
C130 0.1U_4
C131 0.1U_4
C132 0.1U_4
C133 0.1U_4
C134 0.1U_4

R586 100K/F_4
R587 100K/F_4

HDMI_DOCK_HPD_EXT (18)

C718 0.1U_4
C719 0.1U_4
C720 0.1U_4
C721 0.1U_4
C722 0.1U_4
C723 0.1U_4
C724 0.1U_4
C725 0.1U_4

(HDMI 1.65Gbps)

VCC1.05

HDMI_DATA2# (21)
HDMI_DATA2 (21)
HDMI_DATA1# (21)
HDMI_DATA1 (21)
HDMI_DATA0# (21)
HDMI_DATA0 (21)
HDMI_CLK# (21)
HDMI_CLK (21)

DDP_EXT_CTRL_CLK (18)

DDP_EXT_CTRL_DATA (18)

VCC1.05

DDP_EXT_DATA2# (18)
DDP_EXT_DATA2 (18)
DDP_EXT_DATA1# (18)
DDP_EXT_DATA1 (18)
DDP_EXT_DATA0# (18)
DDP_EXT_DATA0 (18)
DDP_EXT_CLK# (18)
DDP_EXT_CLK (18)

9

HDMI M/B

R95
10K/F_4

2

VCC3

PCI_CLKRUN#

PM_RI#

A A

PM_BATLOW#
PCIE_WAKE#

SUS_PWR_DN_ACK
DNBSWON#

R96 8.2K_4

R102 10K/F_4
R104 8.2K_4
R107 1K/F_4

R115 10K/F_4
R120 *10K/F_4

5

RVCC3

RSMRST#(17)

WAKE#(16,18,33)

Q9 2N7002K

4/29 Delete U5,R113,R108,C144,C143

RSMRST#

Min. 10ms

R117
39K/F_4

RVCC_ON

RSMRST#

PCIE_WAKE#

31

RSMRST# buffer

Min. 10ms

4

2.9V

0.8V

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

3

HDMI_DOCK_HPD_EXT

DDP_EXT_CTRL_CLK
DDP_EXT_CTRL_DATA

R103 *150
R105 *150
R106 *150

6/13 Change R103,R105,R106 to no-mount

R715 100K_4

R702 2.2K/F_4
R703 2.2K/F_4

Add Int Graphics disable
2/25 tommy

2

NB_B
NB_G
NB_R

VCC3

LVDS_CLK
LVDS_DATA

NB LVDS I2C

R100 2.2K/F_4
R101 2.2K/F_4

QUANTA

Title

Size Document Number Rev

Custom

Date: Sheet

COMPUTER

PCH 1/5(DMI&VIDEO)

TW6 Main Board

1

VCC3
VCC3

933Monday, August 31, 2009

2A

of

5

D1 can not use RB501V-40

VCCRTC3

D2 CH501H-40

R124
1K/F_4

VCCRTC_3

12

2 1

D1 SW1010CPT

2 1

3VPCU

RTC

D D

5VPCU

R126 2.37K/F R668 2.37K/F

5VPCU

C C

R134 *10K_4
R136 *10K_4
R138 *10K_4
R140 *10K_4

R720 2.37K/FR128 2.37K/F

JTAG_TCK

R144 *0_4

MMBT3904

R130
12K/F_4

R133 51_4
JTAG_TMS
JTAG_TDI
JTAG_TDO
JTAG_RST#

HDA_DOCK_EN#

VCCRTC_1

Q10

VCCRTC_2

13

2

BT1

BAT_CONN

R135 *20K/F_4
R137 *20K/F_4
R139 *20K/F_4
R141 *20K/F_4

VCCRTC

VCC3

4/29 no mount

Flash Descriptor Security Overide

HDA_DOCK_EN#:

B B

VCC3

Low : Enable

High: Disable(Default)

R146 *10K/F_4

PCSPK1

No Reboot

High = Enable

PCSPK

Low = Disable (Default)

HDA Topology

C156 *27P_4

HDA_BCLK0(31)
HDA_BCLK1(32)

HDA_SYNC0(31)

A A

HDA_SYNC1(32)

HDA_RST#0(31)
HDA_RST#1(32)

HDA_SDOUT0(31)
HDA_SDOUT1(32)

R152 33/F_4
R634 33/F_4

R154 33/F_4
R635 33/F_4

R157 33/F_4
R636 33/F_4

R159 33/F_4
R637 33/F_4

5

HDA_BCLK_R

HDA_SYNC_R

HDA_RST#_R

HDA_SDO_R

HDA_SYNC

Weak internal pull-down. Do not pull
high. Sampled at rising edge of
RSMRST#.

HDA_SDO

Weak internal pull-down. Do not pull
high. Sampled at rising edge of
RSMRST#.

HDA_SDO

Weak internal pull-down. Do not pull
high. Sampled at rising edge of
RSMRST#.

INVRMEN

High = Enable

High (1) = Integrated VRM is enabled
Low (0) = Integrated VRM is disabled

SPI_SDI

High = Enable

Low = Disable (Default)

4

C145 1U/6.3V/X5R_4

R123 20K/F_4

C147
1U/6.3V/X5R_4

R127 20K/F_4

C149

R129
1M_4

1U/6.3V/X5R_4

Intel Anti-Theft Technology

4

3

2

http://hobi-elektronika.net

(CH01506GB01)

12

J1
SHORT_ PAD1

12

J2
SHORT_ PAD1

4/30 R142 change from 10K to 2.2K

3VSUS

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

C146 15P_4

2 1

C148 15P_4

0824 Del R583

VCCRTC

HDA_SYNC:Internal pull low
High: PLL VR 1.5V
Low : PLL VR 1.8V

RVCC3

VCC3

SPI_SD0

R562 4.7K_4

R131 330K_4

R142 1K/F_4

4/20 : Move KBSMI# to GPIO13

R151 10K/F_4

SPI_CS#

3

Y2

32.768K/10PPM

PCSPK(31)

1
2
3 6
4

R125
10M_4

RTC_RST#

SRTC_RST#

SM_INTRUDER#

High=Integrated SUS 1.1V VRM is enable

HDA_SDIN0(31)
HDA_SDIN1(32)

HDA_DOCK_EN#(17)

KBSMI#(17)

U54

VDD

/CS

/HOLD

DO
/WP CLK
GND

W25X32VSSIG

BIOS 4MB

INVRMEN

HDA_BCLK_R
HDA_SYNC_R

R132 0_4

HDA_RST#_R

HDA_SDO_R

HDA_DOCK_EN#

JTAG_TCK
JTAG_TMS
JTAG_TDI
JTAG_TDO
JTAG_RST#

SPI_CLK
SPI_CS#

T25

SPI_SDI
SPI_SD0

IRQ_SERIRQ

C682 0.1U_4

8

R561 4.7K_4

7

SPI_CLK

SPI_SDI

5

DI

T23
T24

3VSUS

IBEX PEAK-M (HDA,JTAG,SATA)

GREENPEAK

U4A

RTC_X1

B13

RTCX1

RTC_X2

D13

PCSPK1

RTCX2

C14

RTCRST#

D17

SRTCRST#

A16

INTRUDER#

A14

INTVRMEN

A30

HDA_BCLK

D29

HDA_SYNC

P1

SPKR

C30

HDA_RST#

G30

HDA_SDIN0

F30

HDA_SDIN1

E32

HDA_SDIN2

F32

HDA_SDIN3

B29

HDA_SDO

H32

HDA_DOCK_EN# / GPIO33

J30

HDA_DOCK_RST# / GPIO13

M3

JTAG_TCK

K3

JTAG_TMS

K1

JTAG_TDI

J2

JTAG_TDO

J4

JTAG_RST#

BA2

SPI_CLK

AV3

SPI_CS0#

AY3

SPI_CS1#

AY1

SPI_MOSI

AV1

SPI_MISO

IbexPeak-M(ES v0.9)

3VSUS

2

LPC

FWH4 / LFRAME#

LDRQ1# / GPIO23

RTCIHDA

SATA0GP / GPIO21
SATA1GP / GPIO19

SPI JTAG

1

FWH0 / LAD0
FWH1 / LAD1
FWH2 / LAD2
FWH3 / LAD3

LDRQ0#

SERIRQ

SATA0RXN
SATA0RXP
SATA0TXN
SATA0TXP

SATA1RXN
SATA1RXP
SATA1TXN
SATA1TXP

SATA2RXN
SATA2RXP
SATA2TXN
SATA2TXP

SATA

SATA3RXN
SATA3RXP
SATA3TXN
SATA3TXP

SATA4RXN
SATA4RXP
SATA4TXN
SATA4TXP

SATA5RXN
SATA5RXP
SATA5TXN
SATA5TXP

SATAICOMPO

SATAICOMPI

SATALED#

D33
B33
C32
A32

C34
A34

F34

IRQ_SERIRQ

AB9

AK7
AK6
AK11
AK9

AH6
AH5
AH9
AH8

AF11
AF9
AF7
AF6

AH3
AH1
AF3
AF1

AD9
AD8
AD6
AD5

AD3
AD1
AB3
AB1

AF16

SATACOMP

AF15

T3

R148 10K/F_4

Y9

R150 10K/F_4

V1

LPC_AD0 (16,17,18)
LPC_AD1 (16,17,18)
LPC_AD2 (16,17,18)
LPC_AD3 (16,17,18)

LPC_FRAME# (16,17,18)

T71
T70

IRQ_SERIRQ (17,18)

(P55/H55 SATA2/3 NC)

R145 37.4/F_4

SATALED# (18)

VCC3

QUANTA

Title

Size Document Number Rev

Custom

Date: Sheet

COMPUTER

PCH 2/5(SATA)

TW6 Main Board

1

SATA HDD

SATA_RXN0 (19)
SATA_RXP0 (19)
SATA_TXN0 (19)
SATA_TXP0 (19)

SATA ODD

SATA_RXN1 (19)
SATA_RXP1 (19)
SATA_TXN1 (19)
SATA_TXP1 (19)

VCC1.05

10 33Monday, August 31, 2009

of

10

2A

5

4

3

2

1

USBOC0#
USBOC7#
USBOC1#
USBOC3# USBOC5#

RVCC3

D D

PERR#
DEVSEL#
PLOCK#
SERR#

VCC3

VCC3

C C

B B

PCLK_MP(16)
PCLK_TPM(18)
PCLK_EC(17)

RP5
6
7
8
9

10

RP6
6
7
8
9

10

10P8R-8.2K

RP7

PIRQG#

6

PIRQC#

7

STOP#

8

PIRQE# IRDY#

9

10

10P8R-8.2K

VCC3

R161 8.2K_4
R162 8.2K_4
R163 8.2K_4
R164 8.2K_4

10P8R-8.2K

5
4
3
2
1

5

PIRQH#

4

TRDY#

3

FRAME#

2

REQ1#

1

5

REQ2#

4

PIRQD#

3
2

PIRQA#

1

PIRQB#
REQ3#
REQ0#
PIRQF#

R169 22_4
R625 22_4
R172 22_4
R174 22_4

USBOC6#
USBOC4#

USBOC2#

VCC3

VCC3

T27

T29

GNT2#/GPIO53 :
High : Internal pull-up

Low : Configures DMI for ESI compatible
operation (for servers only. Not for
mobile/desktops)

SM BUS for C0 (CLOCK/DRAM)

PCLK_SMB/PDAT_SMB

SO-DIMM0

SO-DIMM1
ICS9LRS3105
Express Card

A A

VCC3

SMB0_CLK

VCC3

SMB0_DATA

5

2
6

Q13

2N70022

Address
1010 000X A0h

1010 010X
1101 0010

A4h
D2h

R187 10K/F_4

43

PCLK_SMB (4,14,16)

R192 10K/F_4

1

PDAT_SMB (4,14,16)

5

IBEX PEAK-M (PCI,USB,NVRAM)

RVCC3

PIRQA#
PIRQB#
PIRQC#
PIRQD#

REQ0#
REQ1#
REQ2#
REQ3#

GNT0#
GNT1#

GNT3#
PIRQE#

PIRQF#
PIRQG#
PIRQH#

PCI_RST#
SERR#

PERR#

IRDY#
DEVSEL#

FRAME#
PLOCK#
STOP#

TRDY#

T31

PCI_PLTRST#
PCLK_MP_R
PCLK_EC_R

PCLK_FB_RPCLK_FB

T37

VCC3

VCC3

U4E

H40

AD0

N34

AD1

C44

AD2

A38

AD3

C36

AD4

J34

AD5

A40

AD6

D45

AD7

E36

AD8

H48

AD9

E40

AD10

C40

AD11

M48

AD12

M45

AD13

F53

AD14

M40

AD15

M43

AD16

J36

AD17

K48

AD18

F40

AD19

C42

AD20

K46

AD21

M51

AD22

J52

AD23

K51

AD24

L34

AD25

F42

AD26

J40

AD27

G46

AD28

F44

AD29

M47

AD30

H36

AD31

J50
G42
H47
G34

G38
H51
B37
A44

F51
A46
B45
M53

F48
K45

F36
H53

B41
K53
A36
A48

K6

E44
E50

A42
H44

F46
C46

D49
D41

C48

M7
D5

N52
P53
P46
P51
P48

A16 swap override Strap/Top-Block
Swap Override jumper

GNT3#

PCI

C/BE0#
C/BE1#
C/BE2#
C/BE3#

PIRQA#
PIRQB#
PIRQC#
PIRQD#

REQ0#
REQ1# / GPIO50
REQ2# / GPIO52
REQ3# / GPIO54

GNT0#
GNT1# / GPIO51
GNT2# / GPIO53
GNT3# / GPIO55

PIRQE# / GPIO2
PIRQF# / GPIO3
PIRQG# / GPIO4
PIRQH# / GPIO5

PCIRST#
SERR#

PERR#

IRDY#
PAR
DEVSEL#
FRAME#

PLOCK#
STOP#

TRDY#
PME#
PLTRST#
CLKOUT_PCI0

CLKOUT_PCI1
CLKOUT_PCI2
CLKOUT_PCI3
CLKOUT_PCI4

IbexPeak-M(ES v0.9)

RVCC3

MBDATA(14,17,32)

RVCC3

MBCLK(14,17,32)

GNT3#

R190 *1K/F_4

Low = A16 swap
override/Top-Block
Swap Override enabled

NV_CE#0
NV_CE#1
NV_CE#2
NV_CE#3

NV_DQS0
NV_DQS1

NV_DQ0 / NV_IO0
NV_DQ1 / NV_IO1
NV_DQ2 / NV_IO2
NV_DQ3 / NV_IO3
NV_DQ4 / NV_IO4
NV_DQ5 / NV_IO5
NV_DQ6 / NV_IO6
NV_DQ7 / NV_IO7
NV_DQ8 / NV_IO8

NV_DQ9 / NV_IO9
NV_DQ10 / NV_IO10
NV_DQ11 / NV_IO11
NV_DQ12 / NV_IO12

NVRAMUSB

NV_DQ13 / NV_IO13
NV_DQ14 / NV_IO14
NV_DQ15 / NV_IO15

NV_RCOMP

NV_WR#0_RE#
NV_WR#1_RE#

NV_WE#_CK0
NV_WE#_CK1

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N
USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P
USBP9N

USBP9P
USBP10N
USBP10P
USBP11N
USBP11P
USBP12N
USBP12P
USBP13N
USBP13P

USBRBIAS#

USBRBIAS

OC0# / GPIO59
OC1# / GPIO40
OC2# / GPIO41
OC3# / GPIO42
OC4# / GPIO43

OC5# / GPIO9
OC6# / GPIO10
OC7# / GPIO14

Q11

5

2
6

2N70022

High = Default

NV_ALE
NV_CLE

NV_RB#

R184 2.2K/F_4

43

R183 2.2K/F_4

1

AY9
BD1
AP15
BD8

AV9
BG8

AP7
AP6
AT6
AT9
BB1
AV6
BB3
BA4
BE4
BB6
BD6
BB7
BC8
BJ8
BJ6
BG6

BD3
AY6

AU2
AV7
AY8

AY5
AV11

BF5

H18
J18
A18
C18
N20
P20
J20
L20
F20
G20
A20
C20
M22
N22
B21
D21
H22
J22
E22
F22
A22
C22
G24
H24
L24
M24
A24
C24

B25
D25

N16
J16
F16
L16
E14
G16
F12
T15

SMB_CLK_ME1

4

PCIE_REQ_WLAN1#(16)

NV_ALE

T26

NV_CLE:DMI termination voltage. Weak
internal pull-up. Do not pull low

USBP0- (20)
USBP0+ (20)
USBP1- (20)
USBP1+ (20)
USBP2- (18)
USBP2+ (18)
USBP3- (16)
USBP3+ (16)
USBP4- (20)
USBP4+ (20)

(P55/H55 USN6,7 NC)

USBP8- (32)
USBP8+ (32)
USBP9- (19)
USBP9+ (19)

USBP12- (16)
USBP12+ (16)
USBP13- (18)
USBP13+ (18)

R166 22.6/F_4

USB_BIAS

USBOC0#
USBOC1#
USBOC2#
USBOC3#
USBOC4#
USBOC5#
USBOC6#
USBOC7#

RVCC3

RVCC3

http://hobi-elektronika.net

Finger Printer
Camera

WIMAX
BT

USBOC0# (20)
USBOC1# (20)
USBOC2# (20)

VCC1.8

Boot BIOS Strap

GNT0# GNT#1

RVCC3_AUX

10K/F_4

R738

Q72 2N7002E

USB Port0
USB Port1
Docking USB

0825 Change RP12 from 2P2R to 0402 x2 for EMI issue.

Express Card
USB Port2

R181 *8.2K_4

Anti-Theft Technology

NV_ALE

GNT0#

R188 1K/F_4

GNT1#

R189 1K/F_4

Boot BIOS Location

*

00
001
1
11

Reserved (NAND)
PCI
SPI

2

PCIE_REQ_WLAN#

31

Express Card

CLK_PCIE_EXPRESS_CARD#(16)

CLK_PCIE_EXPRESS_CARD(16)

High = Enable

Low = Disable

LPC

Docking
Lan

WLAN

CLK_PCIE_WLAN#(16)
CLK_PCIE_WLAN(16)

Docking LAN

CLK_PCIE_DKLAN#(18)
CLK_PCIE_DKLAN(18)

Card Reader

CLK_PCIE_CARD#(30)

CLK_PCIE_CARD(30)

Express Card

CLK_PCIE_LAN#(33)

NV_ALESMB_DATA_ME1

Card
Reader

LAN

WLAN

LAN

CLK_PCIE_LAN(33)

PCIE_REQ_EXPRESSCARD#(16)

3

PCIE_RXN2(30)

PCIE_RXP2(30)

PCIE_TXN2(30)

PCIE_TXP2(30)

PCIE_RXN3(33)

PCIE_RXP3(33)

PCIE_TXN3(33)

PCIE_TXP3(33)

PCIE_RXN4(18)

PCIE_RXP4(18)

PCIE_TXN4(18)

PCIE_TXP4(18)

PCIE_RXN1(16)

PCIE_RXP1(16)

PCIE_TXN1(16)

PCIE_TXP1(16)

PCIE_RXN5(16)

PCIE_RXP5(16)

PCIE_TXN5(16)

PCIE_TXP5(16)

RP11 0X2

3
1

R752 0_4
R753 0_4

PCIE_REQ_DK_LAN#(18)

RP13 0X2

3
1

PCIE_REQ_R5U231#(30)

RP14 0X2

1
3

RP15 0X2

1
3

PCIE_REQ_LAN#(33)

0824 Change 3VSUS to VCC3

R167 10K/F_4
R170 10K/F_4

VCC3

R173 10K/F_4
R570 10K/F_4

VCC3

R551 10K/F_4
R168 10K/F_4

C166 0.1U_4
C167 0.1U_4

C160 0.1U_4
C161 0.1U_4

C162 0.1U_4
C163 0.1U_4

C158 0.1U_4
C159 0.1U_4

C164 0.1U_4
C165 0.1U_4

CLK_PCIE_WLAN#_R

4

CLK_PCIE_WLAN_R

2

PCIE_REQ_WLAN#

CLK_PCIE_DKLAN#_R
CLK_PCIE_DKLAN_R

PCIE_REQ_DK_LAN#

CLK_PCIE_CRD#_R

4

CLK_PCIE_CRD_R

2

PCIE_REQ_R5U231#

CLK_PCIE_EXPRESS_CARD#_R

2

CLK_PCIE_EXPRESS_CARD_R

4

PCIE_REQ_EXPRESSCARD#

2
4

PCIE_REQ_R5U231#
PCIE_REQ_DK_LAN#

PCI_PLTRST#

CLK_PCIE_LAN#_R
CLK_PCIE_LAN_R

PCIE_REQ_LAN#

PEG_B_CLKREQ#

PCIE_REQ_WLAN#
PCIE_REQ_LAN#
PCIE_REQ_EXPRESSCARD#
PCIE_REQ5

C170 0.1U_4

IBEX PEAK-M (PCI-E,SMBUS,CLK)

U4B

BG30

PCIE_TXN2_C
PCIE_TXP2_C

PCIE_TXN3_C
PCIE_TXP3_C

PCIE_TXN4_C
PCIE_TXP4_C

PCIE_TXN1_C
PCIE_TXP1_C

PCIE_TXN5_C
PCIE_TXP5_C

PCIE_REQ5

2
1

R193 *0_4

PERN1

BJ30

PERP1

BF29

PETN1

BH29

PETP1

AW30

PERN2

BA30

PERP2

BC30

PETN2

BD30

PETP2

AU30

PERN3

AT30

PERP3

AU32

PETN3

AV32

PETP3

BA32

PERN4

BB32

PERP4

BD32

PETN4

BE32

PETP4

BF33

PERN5

BH33

PERP5

BG32

PETN5

BJ32

PETP5

BA34

PERN6

AW34

PERP6

BC34

PETN6

BD34

PETP6

AT34

PERN7

AU34

PERP7

AU36

PETN7

AV36

PETP7

BG34

PERN8

BJ34

PERP8

BG36

PETN8

BJ36

PETP8

AK48

CLKOUT_PCIE0N

AK47

CLKOUT_PCIE0P

P9

PCIECLKRQ0# / GPIO73

AM43

CLKOUT_PCIE1N

AM45

CLKOUT_PCIE1P

U4

PCIECLKRQ1# / GPIO18

AM47

CLKOUT_PCIE2N

AM48

CLKOUT_PCIE2P

N4

PCIECLKRQ2# / GPIO20

AH42

CLKOUT_PCIE3N

AH41

CLKOUT_PCIE3P

A8

PCIECLKRQ3# / GPIO25

AM51

CLKOUT_PCIE4N

AM53

CLKOUT_PCIE4P

M9

PCIECLKRQ4# / GPIO26

AJ50

CLKOUT_PCIE5N

AJ52

CLKOUT_PCIE5P

H6

PCIECLKRQ5# / GPIO44

AK53

CLKOUT_PEG_B_N

AK51

CLKOUT_PEG_B_P

P13

PEG_B_CLKRQ# / GPIO56

IbexPeak-M(ES v0.9)

RVCC3

U6

TC7SH08FU

3 5

4

PCH_GPIO11
GPIO60
SMB0_CLK
SMB0_DATA
SMB_CLK_ME0
SMB_DATA_ME0
GPIO74

PEG_A_CLKREQ#
PEG_B_CLKREQ#

R191
100K_4

2

PCI-E*

PLTRST# (5,16,18,30,33)

SMBALERT# / GPIO11

SML0ALERT# / GPIO60

SML1ALERT# / GPIO74

SMBus

SML1DATA / GPIO75

Controller

Link

PEG_A_CLKRQ# / GPIO47

PEG

CLKOUT_DP_N / CLKOUT_BCLK1_N
CLKOUT_DP_P / CLKOUT_BCLK1_P

From CLK BUFFER

CLKIN_SATA_N / CKSSCD_N
CLKIN_SATA_P / CKSSCD_P

CLKIN_PCILOOPBACK

CLKOUTFLEX0 / GPIO64

CLKOUTFLEX1 / GPIO65

CLKOUTFLEX2 / GPIO66

Clock Flex

CLKOUTFLEX3 / GPIO67

R175 10K/F_4
R176 10K/F_4
R177 2.2K/F_4
R178 2.2K/F_4
R180 2.2K/F_4
R182 2.2K/F_4
R185 10K/F_4

R186 10K/F_4
R560 10K/F_4

SMBCLK

SMBDATA

SML0CLK

SML0DATA

SML1CLK / GPIO58

CL_CLK1

CL_DATA1

CL_RST1#

CLKOUT_PEG_A_N
CLKOUT_PEG_A_P

CLKOUT_DMI_N
CLKOUT_DMI_P

CLKIN_DMI_N

CLKIN_DMI_P

CLKIN_BCLK_N
CLKIN_BCLK_P

CLKIN_DOT_96N
CLKIN_DOT_96P

REFCLK14IN

XTAL25_IN

XTAL25_OUT

XCLK_RCOMP

PCH_GPIO11

B9

SMB0_CLK

H14

SMB0_DATA

C8

GPIO60

J14

SMB_CLK_ME0

C6

SMB_DATA_ME0

G8

GPIO74

M14

SMB_CLK_ME1

RVCC3

GPIO56

E10

SMB_DATA_ME1

G12

T13
T11
T9

PEG_A_CLKREQ#

H1

AD43
AD45

CLKOUT_DMI#_R

AN4

CLKOUT_DMI_R

AN2

PCH_DREFSSCLK_R#

AT1

PCH_DREFSSCLK_R

AT3

AW24
BA24

AP3
AP1

F18
E18

AH13
AH12

P41

PCLK_FB

J42

XTAL25_IN

AH51

XTAL25_OUT

AH53

XCLK_RCOMP

AF38

T45

P43

T42

N50

XTAL25_IN

XTAL25_OUT

RVCC3

T90

T91

T92

RP9 0X2

RP10 0X2

CLKIN_DMI_N (4)
CLKIN_DMI_P (4)

CLKIN_BCLK_N (4)
CLKIN_BCLK_P (4)

CLKIN_DOT_96_N (4)
CLKIN_DOT_96_P (4)

CLKIN_SATA_N (4)
CLKIN_SATA_P (4)

14M_PCH (4)

R165 90.9/F_4

T36

R584 *0_4

R179
1M

(TO EC)

3
1

3
1

2134

4
2

4
2

C168

Y3

8.2P

25MHz/9F/30ppm
C169

8.2P

CH-826T0B01

If not used, 8.2-k? to 10-k? pull-up to +V3.3A

QUANTA

Custom

COMPUTER

PCH 3/5(PCI)

TW6 Main Board

1

Title

Size Document Number Rev

Date: Sheet

11

CLKOUT_DMI# (5)
CLKOUT_DMI (5)

PCH_DREFSSCLK# (5)
PCH_DREFSSCLK (5)

VCC1.05

of

11 33Monday, August 31, 2009

1A

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

5

IBEX PEAK-M (GPIO,VSS_NCTF,RSVD)

0828 P12- Pull up to VCC3 for GPIO1

LIGHTSENSOR_INT#(32)

D D

VCC3

VCC3

R577 10K/F_4
R550 10K/F_4

CRIT_TEMP_REP#(17)

R198 10K/F_4

RVCC3

BT_PRS#

FP_PRS#(32)

BT_PRS#(18)

0828 P12- Change BT_PRS# from GIOP 1
to GPIO12
and pull up to RVCC3

C C

DRAMRST_CNTRL_PCH(5)

RVCC3

VCC3

VCC3

B B

PCH_GPIO0

PCH_GPIO1

SCI#(17)

R196 *10K/F_4

R555 10K_4

R568 10K/F_4
R569 10K/F_4

R566 10K/F_4

SCI#

LIGHTSENSOR_INT#

T72

T73

LCDID0
LCDID1
LCDID2

T38

T89

MBID0
MBID1
MBID2

T93

SV_SET_UP High = Strong (Default)

A A

LCDID0
LCDID1
LCDID2

LCD ID

RP17 10KX4

1

2

3

4

5

6

7

8

SW1
1
2
3
4 5

RP18 1KX4
8
7
6

DIP(FHDS-04F-T-V-T/R(682))

5

U4F

Y3

BMBUSY# / GPIO0

C38

TACH1 / GPIO1

D37

TACH2 / GPIO6

J32

TACH3 / GPIO7

F10

GPIO8

K9

LAN_PHY_PWR_CTRL / GPIO12

T7

GPIO15

AA2

SATA4GP / GPIO16

F38

TACH0 / GPIO17

Y7

SCLOCK / GPIO22

H10

GPIO24

AB12

GPIO27

V13

GPIO28

M11

STP_PCI# / GPIO34

V6

SATACLKREQ# / GPIO35

AB7

SATA2GP / GPIO36

AB13

SATA3GP / GPIO37

V3

SLOAD / GPIO38

P3

SDATAOUT0 / GPIO39

H3

PCIECLKRQ6# / GPIO45

F1

PCIECLKRQ7# / GPIO46

AB6

SDATAOUT1 / GPIO48

AA4

SATA5GP / GPIO49

F8

GPIO57

A4

VSS_NCTF_1

A49

VSS_NCTF_2

A5

VSS_NCTF_3

A50

VSS_NCTF_4

A52

VSS_NCTF_5

A53

VSS_NCTF_6

B2

VSS_NCTF_7

B4

VSS_NCTF_8

B52

VSS_NCTF_9

B53

VSS_NCTF_10

BE1

VSS_NCTF_11

BE53

VSS_NCTF_12

BF1

VSS_NCTF_13

BF53

VSS_NCTF_14

BH1

VSS_NCTF_15

BH2

VSS_NCTF_16

BH52

VSS_NCTF_17

BH53

VSS_NCTF_18

BJ1

VSS_NCTF_19

BJ2

VSS_NCTF_20

BJ4

VSS_NCTF_21

BJ49

VSS_NCTF_22

BJ5

VSS_NCTF_23

BJ50

VSS_NCTF_24

BJ52

VSS_NCTF_25

BJ53

VSS_NCTF_26

D1

VSS_NCTF_27

D2

VSS_NCTF_28

D53

VSS_NCTF_29

E1

VSS_NCTF_30

E53

VSS_NCTF_31

IbexPeak-M(ES v0.9)

VCC3

1

2

3

4

5

6

7

8

GPIO

NCTF

VCC3

4

CLKOUT_PCIE6N
CLKOUT_PCIE6P

CLKOUT_PCIE7N

MISC

CLKOUT_BCLK0_N / CLKOUT_PCIE8N

CLKOUT_BCLK0_P / CLKOUT_PCIE8P

CPU

RSVD

LIGHTSENSOR_INT#

CLKOUT_PCIE7P

A20GATE

PECI

RCIN#

PROCPWRGD

THRMTRIP#

TP10
TP11
TP12
TP13
TP14
TP15
TP16
TP17
TP18

TP19
NC_1
NC_2
NC_3
NC_4
NC_5

INIT3_3V#

TP24

R585 10K/F_4

MB ID

R204 *10K/F_4

R211 *10K/F_4

4

MBID0
MBID1
MBID2

3

http://hobi-elektronika.net

AH45
AH46

AF48
AF47

GATEA20

U2

AM3
AM1
BG10

RCIN#

T1
BE10

PCH_THERMTRIP#_R

BD10

BA22

TP1

AW22

TP2

BB22

TP3

AY45

TP4

AY46

TP5

AV43

TP6

AV45

TP7

AF13

TP8

M18

TP9

N18
AJ24
AK41
AK42
M32
N32
M30
N30
H12
AA23
AB45
AB38
AB42
AB41
T39

P6
C10

R205 *10K/F_4
R208 10K/F_4R207 *10K/F_4
R212 10K/F_4

R_CLK_CPU_BCLK#
R_CLK_CPU_BCLK

T40
T41

GPIO
0,1

GPIO57

If not used, 8.2-k to 10-k pull-up to +V3.3A

GPIO28

If not used, 8.2-k to 10-k pull-up to +V3.3A

GPIO15

weak internal pull-down of 20 K which is enabled when
PWROK is low.

Low : with no confidentiality

High : with confidentiality

GPIO8

Weak internal pull-up.
Do not pull low. Sampled at rising edge of
RSMRST#

GPIO27

GPIO27 has internal pull up and control VRM.
High : Enable VRM(See HDA_SYNC)
Low : Disable VRM(PLL VR=1.05)

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that
Sony approves as Green Partners.

GATEA20 (17)

RP16 0X2

H_PECI (5)
RCIN# (17)

H_CPUPWRGD (5)

R197 56_4

Intel ME Crypto Transport Layer Security (TLS)
cipher suite

SCI#

VCC3

BT_PRS#

GATEA20
RCIN#

PCH_GPIO0
PCH_GPIO1

3
1

4
2

4/30 Delete R194

R199 10K/F_4

R200 10K/F_4

R202 10K/F_4
R203 10K/F_4

3

CLK_CPU_BCLK# (5)
CLK_CPU_BCLK (5)

VCC1.05

R206 10K/F_4
R209 10K/F_4

R195
56_4

H_THERMTRIP# (5)

VCC3

RVCC3

VCC3

U4I

AY7

VSS[159]

B11

VSS[160]

B15

VSS[161]

B19

VSS[162]

B23

VSS[163]

B31

VSS[164]

B35

VSS[165]

B39

VSS[166]

B43

VSS[167]

B47

VSS[168]

B7

VSS[169]

BG12

VSS[170]

BB12

VSS[171]

BB16

VSS[172]

BB20

VSS[173]

BB24

VSS[174]

BB30

VSS[175]

BB34

VSS[176]

BB38

VSS[177]

BB42

VSS[178]

BB49

VSS[179]

BB5

VSS[180]

BC10

VSS[181]

BC14

VSS[182]

BC18

VSS[183]

BC2

VSS[184]

BC22

VSS[185]

BC32

VSS[186]

BC36

VSS[187]

BC40

VSS[188]

BC44

VSS[189]

BC52

VSS[190]

BH9

VSS[191]

BD48

VSS[192]

BD49

VSS[193]

BD5

VSS[194]

BE12

VSS[195]

BE16

VSS[196]

BE20

VSS[197]

BE24

VSS[198]

BE30

VSS[199]

BE34

VSS[200]

BE38

VSS[201]

BE42

VSS[202]

BE46

VSS[203]

BE48

VSS[204]

BE50

VSS[205]

BE6

VSS[206]

BE8

VSS[207]

BF3

VSS[208]

BF49

VSS[209]

BF51

VSS[210]

BG18

VSS[211]

BG24

VSS[212]

BG4

VSS[213]

BG50

VSS[214]

BH11

VSS[215]

BH15

VSS[216]

BH19

VSS[217]

BH23

VSS[218]

BH31

VSS[219]

BH35

VSS[220]

BH39

VSS[221]

BH43

VSS[222]

BH47

VSS[223]

BH7

VSS[224]

C12

VSS[225]

C50

VSS[226]

D51

VSS[227]

E12

VSS[228]

E16

VSS[229]

E20

VSS[230]

E24

VSS[231]

E30

VSS[232]

E34

VSS[233]

E38

VSS[234]

E42

VSS[235]

E46

VSS[236]

E48

VSS[237]

E6

VSS[238]

E8

VSS[239]

F49

VSS[240]

F5

VSS[241]

G10

VSS[242]

G14

VSS[243]

G18

VSS[244]

G2

VSS[245]

G22

VSS[246]

G32

VSS[247]

G36

VSS[248]

G40

VSS[249]

G44

VSS[250]

G52

VSS[251]

AF39

VSS[252]

H16

VSS[253]

H20

VSS[254]

H30

VSS[255]

H34

VSS[256]

H38

VSS[257]

H42

VSS[258]

IbexPeak-M(ES v0.9)

2

VSS[259]
VSS[260]
VSS[261]
VSS[262]
VSS[263]
VSS[264]
VSS[265]
VSS[266]
VSS[267]
VSS[268]
VSS[269]
VSS[270]
VSS[271]
VSS[272]
VSS[273]
VSS[274]
VSS[275]
VSS[276]
VSS[277]
VSS[278]
VSS[279]
VSS[280]
VSS[281]
VSS[282]
VSS[283]
VSS[284]
VSS[285]
VSS[286]
VSS[287]
VSS[288]
VSS[289]
VSS[290]
VSS[291]
VSS[292]
VSS[293]
VSS[294]
VSS[295]
VSS[296]
VSS[297]
VSS[298]
VSS[299]
VSS[300]
VSS[301]
VSS[302]
VSS[303]
VSS[304]
VSS[305]
VSS[306]
VSS[307]
VSS[308]
VSS[309]
VSS[310]
VSS[311]
VSS[312]
VSS[313]
VSS[314]
VSS[315]
VSS[316]
VSS[317]
VSS[318]
VSS[319]
VSS[320]
VSS[321]
VSS[322]
VSS[323]
VSS[324]
VSS[325]
VSS[326]
VSS[327]
VSS[328]
VSS[329]
VSS[330]
VSS[331]
VSS[332]
VSS[333]
VSS[334]
VSS[335]
VSS[336]
VSS[337]
VSS[338]
VSS[339]
VSS[340]
VSS[341]
VSS[342]
VSS[343]
VSS[344]
VSS[345]
VSS[346]
VSS[347]
VSS[348]
VSS[349]
VSS[350]
VSS[351]
VSS[352]
VSS[353]
VSS[354]
VSS[355]
VSS[356]
VSS[366]

H49
H5
J24
K11
K43
K47
K7
L14
L18
L2
L22
L32
L36
L40
L52
M12
M16
M20
N38
M34
M38
M42
M46
M49
M5
M8
N24
P11
AD15
P22
P30
P32
P34
P42
P45
P47
R2
R52
T12
T41
T46
T49
T5
T8
U30
U31
U32
U34
P38
V11
P16
V19
V20
V22
V30
V31
V32
V34
V35
V38
V43
V45
V46
V47
V49
V5
V7
V8
W2
W52
Y11
Y12
Y15
Y19
Y23
Y28
Y30
Y31
Y32
Y38
Y43
Y46
P49
Y5
Y6
Y8
P24
T43
AD51
AT8
AD47
Y47
AT12
AM6
AT13
AM5
AK45
AK39
AV14

U4H

AB16

VSS[0]

AA19

VSS[1]

AA20

VSS[2]

AA22

VSS[3]

AM19

VSS[4]

AA24

VSS[5]

AA26

VSS[6]

AA28

VSS[7]

AA30

VSS[8]

AA31

VSS[9]

AA32

VSS[10]

AB11

VSS[11]

AB15

VSS[12]

AB23

VSS[13]

AB30

VSS[14]

AB31

VSS[15]

AB32

VSS[16]

AB39

VSS[17]

AB43

VSS[18]

AB47

VSS[19]

AB5

VSS[20]

AB8

VSS[21]

AC2

VSS[22]

AC52

VSS[23]

AD11

VSS[24]

AD12

VSS[25]

AD16

VSS[26]

AD23

VSS[27]

AD30

VSS[28]

AD31

VSS[29]

AD32

VSS[30]

AD34

VSS[31]

AU22

VSS[32]

AD42

VSS[33]

AD46

VSS[34]

AD49

VSS[35]

AD7

VSS[36]

AE2

VSS[37]

AE4

VSS[38]

AF12

VSS[39]

Y13

VSS[40]

AH49

VSS[41]

AU4

VSS[42]

AF35

VSS[43]

AP13

VSS[44]

AN34

VSS[45]

AF45

VSS[46]

AF46

VSS[47]

AF49

VSS[48]

AF5

VSS[49]

AF8

VSS[50]

AG2

VSS[51]

AG52

VSS[52]

AH11

VSS[53]

AH15

VSS[54]

AH16

VSS[55]

AH24

VSS[56]

AH32

VSS[57]

AV18

VSS[58]

AH43

VSS[59]

AH47

VSS[60]

AH7

VSS[61]

AJ19

VSS[62]

AJ2

VSS[63]

AJ20

VSS[64]

AJ22

VSS[65]

AJ23

VSS[66]

AJ26

VSS[67]

AJ28

VSS[68]

AJ32

VSS[69]

AJ34

VSS[70]

AT5

VSS[71]

AJ4

VSS[72]

AK12

VSS[73]

AM41

VSS[74]

AN19

VSS[75]

AK26

VSS[76]

AK22

VSS[77]

AK23

VSS[78]

AK28

VSS[79]

IbexPeak-M(ES v0.9)

VSS[80]
VSS[81]
VSS[82]
VSS[83]
VSS[84]
VSS[85]
VSS[86]
VSS[87]
VSS[88]
VSS[89]
VSS[90]
VSS[91]
VSS[92]
VSS[93]
VSS[94]
VSS[95]
VSS[96]
VSS[97]
VSS[98]

VSS[99]
VSS[100]
VSS[101]
VSS[102]
VSS[103]
VSS[104]
VSS[105]
VSS[106]
VSS[107]
VSS[108]
VSS[109]
VSS[110]
VSS[111]
VSS[112]
VSS[113]
VSS[114]
VSS[115]
VSS[116]
VSS[117]
VSS[118]
VSS[119]
VSS[120]
VSS[121]
VSS[122]
VSS[123]
VSS[124]
VSS[125]
VSS[126]
VSS[127]
VSS[128]
VSS[129]
VSS[130]
VSS[131]
VSS[132]
VSS[133]
VSS[134]
VSS[135]
VSS[136]
VSS[137]
VSS[138]
VSS[139]
VSS[140]
VSS[141]
VSS[142]
VSS[143]
VSS[144]
VSS[145]
VSS[146]
VSS[147]
VSS[148]
VSS[149]
VSS[150]
VSS[151]
VSS[152]
VSS[153]
VSS[154]
VSS[155]
VSS[156]
VSS[157]
VSS[158]

AK30
AK31
AK32
AK34
AK35
AK38
AK43
AK46
AK49
AK5
AK8
AL2
AL52
AM11
BB44
AD24
AM20
AM22
AM24
AM26
AM28
BA42
AM30
AM31
AM32
AM34
AM35
AM38
AM39
AM42
AU20
AM46
AV22
AM49
AM7
AA50
BB10
AN32
AN50
AN52
AP12
AP42
AP46
AP49
AP5
AP8
AR2
AR52
AT11
BA12
AH48
AT32
AT36
AT41
AT47
AT7
AV12
AV16
AV20
AV24
AV30
AV34
AV38
AV42
AV46
AV49
AV5
AV8
AW14
AW18
AW2
BF9
AW32
AW36
AW40
AW52
AY11
AY43
AY47

1

12

QUANTA

Title

Size Document Number Rev

Custom

2

Date: Sheet

COMPUTER

PCH 4/5(GPIO)

TW6 Main Board

1

12 33Monday, August 31, 2009

2A

of

5

4

3

2

1

U4J

(1.849A)

VCC_PCH_DCPRTC

VCC1.8

VCC1.05

VCC1.05

VCC_PCH_DCPSST

VCC_PCH_DCPSUS

VCC3

(<1mA)

(2mA)

(52mA)

AP51

VCCACLK[1]

AP53

VCCACLK[2]

(320mA)

AF23

VCCLAN[1]

AF24

VCCLAN[2]

Y20

DCPSUSBYP

AD38

VCCME[1]

AD39

VCCME[2]

AD41

VCCME[3]

AF43

VCCME[4]

AF41

VCCME[5]

AF42

VCCME[6]

V39

VCCME[7]

V41

VCCME[8]

V42

VCCME[9]

Y39

VCCME[10]

Y41

VCCME[11]

Y42

VCCME[12]

V9

DCPRTC

(196mA)

AU24

VCCVRM[3]

(68mA)

BB51

VCCADPLLA[1]

BB53

VCCADPLLA[2]

BD51

(69mA)

VCCADPLLB[1]

BD53

VCCADPLLB[2]

AH23

VCCIO[21]

AJ35

VCCIO[22]

AH35

VCCIO[23]

AF34

VCCIO[2]

AH34

VCCIO[3]

AF32

VCCIO[4]

V12 AK1

DCPSST VCCSATAPLL[2]

Y22

DCPSUS

P18

VCCSUS3_3[29]

U19

VCCSUS3_3[30]

U20

VCCSUS3_3[31]

U22

VCCSUS3_3[32]

V15

VCC3_3[5]

V16

VCC3_3[6]

Y16

VCC3_3[7]

AT18

V_CPU_IO[1]

AU18

V_CPU_IO[2]

A12

VCCRTC

IbexPeak-M(ES v0.9)

C172 *1U/6.3V/X5R_4

D D

C C

C716 220U/2.5V/3528/ESR=15/H1.9

+

C194 10U/6.3V/X5R_6
C198 1U/6.3V/X5R_4

L6

VCC1.05

(MLG1608B10NJ(10uH/600mA/0.11)

L7

VCC1.05

MLG1608B10NJ(10uH/600mA/0.11)

C202 10U/6.3V/X5R_6
C203 1U/6.3V/X5R_4

C717 220U/2.5V/3528/ESR=15/H1.9

+

C204 1U/6.3V/X5R_4
C205 1U/6.3V/X5R_4
C207 1U/6.3V/X5R_4

0828 isolation power plan
for AH34,AH34,AF32

B B

A A

5

PCH_VCCACLK

R580 0_4

4/30 Delete C176,Add R580

C181 0.1U_4

VCC1.05

C182 22U/6.3V_8
C184 1U/6.3V/X5R_4

Place near AD38,V39

C191 0.1U_4

VCC1.05_PCH_VCCADPLLA

R219
*0_4

VCC1.05_PCH_VCCADPLLB

C209 0.1U_4

C212 0.1U_4

RVCC3

C215 0.1U_4

C217 0.1U_4

VCC1.05

C219 0.1U_4
C221 1U/6.3V/X5R_4

VCCRTC

C222 0.1U_4
C224 0.1U_4
C225 1U/6.3V/X5R_4

POWER

Clock and Miscellaneous

PCI/GPIO/LPC

SATA USB

PCI/GPIO/LPC

CPU

RTC

HDA

4

VCCIO[5]
VCCIO[6]
VCCIO[7]
VCCIO[8]

VCCSUS3_3[1]
VCCSUS3_3[2]
VCCSUS3_3[3]
VCCSUS3_3[4]
VCCSUS3_3[5]
VCCSUS3_3[6]
VCCSUS3_3[7]
VCCSUS3_3[8]

VCCSUS3_3[9]
VCCSUS3_3[10]
VCCSUS3_3[11]
VCCSUS3_3[12]
VCCSUS3_3[13]
VCCSUS3_3[14]
VCCSUS3_3[15]
VCCSUS3_3[16]
VCCSUS3_3[17]
VCCSUS3_3[18]
VCCSUS3_3[19]
VCCSUS3_3[20]
VCCSUS3_3[21]
VCCSUS3_3[22]
VCCSUS3_3[23]
VCCSUS3_3[24]
VCCSUS3_3[25]
VCCSUS3_3[26]
VCCSUS3_3[27]

VCCSUS3_3[28]

VCCIO[56]

V5REF_SUS

VCC3_3[8]

VCC3_3[9]
VCC3_3[10]
VCC3_3[11]
VCC3_3[12]
VCC3_3[13]

VCC3_3[14]

VCCSATAPLL[1]

VCCIO[9]

VCCVRM[4]

VCCIO[10]

VCCIO[11]

VCCIO[12]

VCCIO[13]

VCCIO[14]

VCCIO[15]

VCCIO[16]

VCCIO[17]

VCCIO[18]

VCCIO[19]

VCCIO[20]

VCCME[13]
VCCME[14]
VCCME[15]
VCCME[16]

VCCSUSHDA

http://hobi-elektronika.net

V24

VCC1.05

V5REF

V26

C173 1U/6.3V/X5R_4

Y24
Y26

(163mA)

V28
U28
U26

C179 0.1U_4

U24

C180 0.1U_4

P28

C673 0.1U_4

P26

C674 0.1U_4

N28

C675 0.1U_4

N26
M28
M26
L28
L26
J28
J26
H28
H26
G28
G26
F28
F26
E28
E26
C28
C26
B27
A28
A26

U23
V23

VCC1.05

(<1mA)

F24

C190 1U/6.3V/X5R_4

(<1mA)

K49

C196 0.1U_4
J38
L38

(0.357mA)

M36

C201 0.1U_4

N36

C676 0.1U_4
P36

U35

AD13

C208 0.1U_4

(31mA)

PCH_VCCSATAPLL

AK3

AH22

(196mA)(163mA)

AT20

AH19

VCC1.05

AD20
AF22
AD19

C216 1U/6.3V/X5R_4

AF20

C672 0.1U_4

AF19
AH20

AB19
AB20
AB22
AD22

AA34

VCC1.05

Y34

C220 10U/6.3V/X5R_6

Y35
AA35

(6mA)

L30

C223 1U/6.3V/X5R_4

RVCC3

RVCC_ON(17,23)

0824 Change C190
from 0.1u to 1U

RVCC5_V5REFSUS

VCC5_V5REF

VCC3

C210 *1U/6.3V/X5R_4

VCC1.05

VCC1.8

RVCC3

2

Q52
DTC144EU

2

1

Q60
2N7002E

D3 CH501H-40
R217 10_4

D4 CH501H-40

VCC3

15VPCU

5VPCU

R578

2

Q51
2N7002E

1M_4

3

1

RVCC3

VCC5
VCC3

R579
10K/F_4

1 3

R627 100/F_4

3

21

21

Change C214 from no-mount to mount

3

5VPCU

3

Q46
2N7002K-T1-E3

2

RVCC5

1

R216
10_4

Del R215

VCC1.05

C214 1U/6.3V/X5R_4

(1.432A)

VCC1.05

C175 10U/6.3V/X5R_6
C177 0.1U_4

VCC1.05

(40mA)

C188 *1U/6.3V/X5R_4

C199 10U/6.3V/X5R_6
C192 1U/6.3V/X5R_4

C193 1U/6.3V/X5R_4
C195 1U/6.3V/X5R_4
C197 1U/6.3V/X5R_4

C663 0.1U_4
C664 0.1U_4

GPIO27

HDA_SYNC

PCH_VCCAPLLEXP

VCC1.05_PCH_IO

(3.062A)

VCC3

(196mA)

VCC1.8

PCH_VCCFDIPLL

(37mA)

VCC1.05

Enable/Disable internal VRM VCCVRM[1..4].

High : Enable

VCCACLK[1..2], VCCSATAPLL[1..2],
VCCAPLLEXP, VCCFDIPLL can remove
L/C.

Low : Disable

Straping VCC1.5 or VCC1.8

High : VCC1.5

Low : VCC1.8

IBEX PEAK-M (POWER)

U4G

AB24

VCCCORE[1]

AB26

VCCCORE[2]

AB28

VCCCORE[3]

AD26

VCCCORE[4]

AD28

VCCCORE[5]

AF26

VCCCORE[6]

AF28

VCCCORE[7]

AF30

VCCCORE[8]

AF31

VCCCORE[9]

AH26

VCCCORE[10]

AH28

VCCCORE[11]

AH30

VCCCORE[12]

AH31

VCCCORE[13]

AJ30

VCCCORE[14]

AJ31

VCCCORE[15]

AK24 AT45

VCCIO[24] VCCTX_LVDS[4]

BJ24

VCCAPLLEXP

AN20

VCCIO[25]

AN22

VCCIO[26]

AN23

VCCIO[27]

AN24

VCCIO[28]

AN26

VCCIO[29]

AN28

VCCIO[30]

BJ26

VCCIO[31]

BJ28

VCCIO[32]

AT26

VCCIO[33]

AT28

VCCIO[34]

AU26

VCCIO[35]

AU28

VCCIO[36]

AV26

VCCIO[37]

AV28

VCCIO[38]

AW26

VCCIO[39]

AW28

VCCIO[40]

BA26

VCCIO[41]

BA28

VCCIO[42]

BB26

VCCIO[43]

BB28

VCCIO[44]

BC26

VCCIO[45]

BC28

VCCIO[46]

BD26

VCCIO[47]

BD28

VCCIO[48]

BE26

VCCIO[49]

BE28

VCCIO[50]

BG26

VCCIO[51]

BG28

VCCIO[52]

BH27

VCCIO[53]

AN30

VCCIO[54]

AN31

VCCIO[55]

AN35

VCC3_3[1]

AT22

VCCVRM[1]

BJ18

VCCFDIPLL

AM23

VCCIO[1]

IbexPeak-M(ES v0.9)

(Internal pull High)

(Internal pull Low)

2

POWER

VCCADAC[1]
VCCADAC[2]

VSSA_DAC[1]

CRTLVDS

VSSA_DAC[2]

VCCALVDS

VCC CORE

VSSA_LVDS

VCCTX_LVDS[1]
VCCTX_LVDS[2]
VCCTX_LVDS[3]

VCCVRM[2]

DMI

PCI E*

VCCPNAND[1]
VCCPNAND[2]
VCCPNAND[3]
VCCPNAND[4]
VCCPNAND[5]
VCCPNAND[6]
VCCPNAND[7]
VCCPNAND[8]
VCCPNAND[9]

NAND / SPI HVCMOS

VCCME3_3[1]
VCCME3_3[2]

FDI

VCCME3_3[3]
VCCME3_3[4]

Title

Size Document Number Rev

Date: Sheet

VCC3_3[2]
VCC3_3[3]
VCC3_3[4]

VCCDMI[1]
VCCDMI[2]

AE50
AE52
AF53
AF51

AH38
AH39

AP43
AP45
AT46

AB34
AB35
AD35

AT24

AT16
AU16

AM16
AK16
AK20
AK19
AK15
AK13
AM12
AM13
AM15

AM8
AM9
AP11
AP9

BLM18PG181SN1D

VCC3_VCCADAC

VCC3_VCCALVDS

C183 0.1U_4

VCC1.8_VCCTX_LVDS

C185 0.01u_4
C186 0.01u_4
C187 10U/6.3V/X5R_6

C189 0.1U_4

(196mA)

VCC1.05_VCCDMI

C200 1U/6.3V/X5R_4

VCC1.8_VCCPNAND

C206 0.1U_4
C671 0.1U_4

(85mA)

C213 0.1U_4

L3

C174 0.1U_4
C178 0.01U_4
C913 10U/6.3V/X5R_6

0824 Change C178 from 1U to 0.01U

L4 0.1uH_6

VCC3

C690 1U/6.3V/X5R_4

VCC3

QUANTA
COMPUTER

PCH 5/5(POWER)

TW6 Main Board

1

Del R214

13

(69mA)

VCC3

Add C913 10u

(<1mA)

(59mA)

VCC1.8

(61mA)

Del R218

(156mA)

Del R220

13 33Monday, August 31, 2009

of

VCC3

VCC1.8

VCC1.05

VCC1.8

2A

5

M_B_A[15:0](6)

D D

M_B_BS0(6)
M_B_BS1(6)
M_B_BS2(6)
M_B_CS#0(6)
M_B_CS#1(6)
M_B_CLK0(6)

M_B_CLK0#(6)

M_B_CLK1(6)

M_B_CLK1#(6)

M_B_CKE0(6)
M_B_CKE1(6)
M_B_CAS#(6)
M_B_RAS#(6)

R225 10K/F_4
R229 10K/F_4

VCC3

C C

1.5VSUS
C242 *330U/2.5V/3528/ESR=9/H1.9
C245 10U/6.3V/X5R_6

C247 10U/6.3V/X5R_6
C249 10U/6.3V/X5R_6
C251 10U/6.3V/X5R_6
C253 10U/6.3V/X5R_6
C254 10U/6.3V/X5R_6

B B

C257 0.1U_4
C259 0.1U_4
C261 0.1U_4
C263 0.1U_4
C264 0.1U_4

Del R734,R735

SMVREF_GMCH SMVREF_GMCH

C274

C273

A A

0.1U_4

2.2U/6.3V_6

M_B_DM[7:0](6)

M_B_DQS[7:0](6)

M_B_DQS#[7:0](6)

+

M_B_WE#(6)

PCLK_SMB(4,11,16)
PDAT_SMB(4,11,16)

M_B_ODT0(6)
M_B_ODT1(6)

C266 2.2U/6.3V_6
C268 0.1U_4

PM_EXTTS#0(5) DRAMRST#(5)

DRAMRST#(5)

C275

0.1U_4

5

M_B_A0
M_B_A1
M
M_B_A3
M_B_A4
M_B_A5
M_B_A6
M_B_A7
M_B_A8
M_B_A9
M_B_A10
M_B_A11
M_B_A12
M_B_A13
M_B_A14
M_B_A15

PCLK_SMB
PDAT_SMB

M_B_DM0
M_B_DM1
M_B_DM2
M_B_DM3
M_B_DM4
M_B_DM5
M_B_DM6
M_B_DM7

M_B_DQS0
M_B_DQS1
M_B_DQS2
M_B_DQS3
M_B_DQS4
M_B_DQS5
M_B_DQS6
M_B_DQS7
M_B_DQS#0
M_B_DQS#1
M_B_DQS#2
M_B_DQS#3
M_B_DQS#4
M_B_DQS#5
M_B_DQS#6
M_B_DQS#7

1.5VSUS

VCC3

SMVREF_GMCH

C276

2.2U/6.3V_6

_B_A2

Max.3.3A

98
97
96
95
92
91
90
86
89
85

107

84
83

119

80
78

109
108

79
114
121
101
103
102
104

73

74
115
110
113
197
201
202
200

116
120

11

28

46

63
136
153
170
187

12

29

47

64
137
154
171
188

10

27

45

62
135
152
169
186

75

76

81

82

87

88

93

94

99
100
105
106
111
112
117
118
123
124
199

77
122
125
198

30
126

13

14

19

20

25

26

31

32

37

38

43

1
2

3
8
9

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12/BC#
A13
A14
A15

BA0
BA1
BA2
S0#
S1#
CK0
CK0#
CK1
CK1#
CKE0
CKE1
CAS#
RAS#
WE#
SA0
SA1
SCL
SDA

ODT0
ODT1

DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7

DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7
DQS#0
DQS#1
DQS#2
DQS#3
DQS#4
DQS#5
DQS#6
DQS#7

VDD1
VDD2
VDD3
VDD4
VDD5
VDD6
VDD7
VDD8
VDD9
VDD10
VDD11
VDD12
VDD13
VDD14
VDD15
VDD16
VDD17
VDD18
VDDSPD
NC1
NC2
NCTEST
EVENT#
RESET#
VREF_DQ
VREF_CA
VSS1
VSS2
VSS3
VSS4
VSS5
VSS6
VSS7
VSS8
VSS9
VSS10
VSS11
VSS12
VSS13
VSS14
VSS15

CON2

PC3-XXXX DDR3 SDRAM SO-DIMM

DDR3-DIMM1

(204P)

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46
DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52

VTT1
VTT2

4

0827A Add C916~C927 for S3 power reduction DG1.0

http://hobi-elektronika.net

M_B_DQ0

5

M_B_DQ1

7

M_B_DQ2

15

M_B_DQ3

17

M_B_DQ4

4

M_B_DQ5

6

M_B_DQ6

16

M_B_DQ7

18

M_B_DQ8

21

M_B_DQ9

23

M_B_DQ10

33

M_B_DQ11

35

M_B_DQ12

22

M_B_DQ13

24

M_B_DQ14

34

M_B_DQ15

36

M_B_DQ16

39

M_B_DQ17

41

M_B_DQ18

51

M_B_DQ19

53

M_B_DQ20

40

M_B_DQ21

42

M_B_DQ22

50

M_B_DQ23

52

M_B_DQ24

57

M_B_DQ25

59

M_B_DQ26

67

M_B_DQ27

69

M_B_DQ28

56

M_B_DQ29

58

M_B_DQ30

68

M_B_DQ31

70

M_B_DQ32

129

M_B_DQ33

131

M_B_DQ34

141

M_B_DQ35

143

M_B_DQ36

130

M_B_DQ37

132

M_B_DQ38

140

M_B_DQ39

142

M_B_DQ40

147

M_B_DQ41

149

M_B_DQ42

157

M_B_DQ43

159

M_B_DQ44

146

M_B_DQ45

148

M_B_DQ46

158

M_B_DQ47

160

M_B_DQ48

163

M_B_DQ49

165

M_B_DQ50

175

M_B_DQ51

177

M_B_DQ52

164

M_B_DQ53

166

M_B_DQ54

174

M_B_DQ55

176

M_B_DQ56

181

M_B_DQ57

183

M_B_DQ58

191

M_B_DQ59

193

M_B_DQ60

180

M_B_DQ61

182

M_B_DQ62

192

M_B_DQ63

194
44

48
49
54
55
60
61
65
66
71
72
127
128
133
134
138
139
144
145
150
151
155
156
161
162
167
168
172
173
178
179
184
185
189
190
195
196
203
204
205

G1

206

G2

4

1.5VSUS

(Max. 0.6A)

VTT_MEM

M_B_DQ[63:0] (6)

1.5VSUS VCC1.5_CPU

C916 0.1U_4
C917 0.1U_4
C918 0.1U_4
C919 0.1U_4
C920 0.1U_4
C921 0.1U_4
C922 0.1U_4
C923 0.1U_4
C924 0.1U_4
C925 0.1U_4
C926 0.1U_4
C927 0.1U_4

R224 10K/F_4
R226 10K/F_4

+

C241 *330U/2.5V/3528/ESR=9/H1.9
C243 10U/6.3V/X5R_6

C244 10U/6.3V/X5R_6
C246 10U/6.3V/X5R_6
C248 10U/6.3V/X5R_6
C250 10U/6.3V/X5R_6
C252 10U/6.3V/X5R_6

C255 0.1U_4
C256 0.1U_4
C258 0.1U_4
C260 0.1U_4
C262 0.1U_4

SMVREF_GMCH

C270

C269

2.2U/6.3V_6

0.1U_4

6/13 Sawp SMDDR_VREF_DQ1 and DQ0

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

3

M_A_A[15:0](6)

M_A_ODT0(6)
M_A_ODT1(6)

M_A_DM[7:0](6)

M_A_DQS[7:0](6)

M_A_DQS#[7:0](6)

C648 2.2U/6.3V_6
C267 0.1U_4

C271

0.1U_4

3

M_A_BS0(6)
M_A_BS1(6)
M_A_BS2(6)
M_A_CS#0(6)
M_A_CS#1(6)
M_A_CLK0(6)

M_A_CLK0#(6)

M_A_CLK1(6)

M_A_CLK1#(6)

M_A_CKE0(6)
M_A_CKE1(6)
M_A_CAS#(6)
M_A_RAS#(6)

M_A_WE#(6)

1.5VSUS

PM_EXTTS#1(5)

C272

2.2U/6.3V_6

PCLK_SMB
PDAT_SMB

M_A_DM0
M_A_DM1
M_A_DM2
M_A_D
M_A_DM4
M_A_DM5
M_A_DM6
M_A_DM7

M_A_DQS0
M_A_DQS1
M_A_DQS2
M_A_DQS3
M_A_DQS4
M_A_DQS5
M_A_DQS6
M_A_DQS7
M_A_DQS#0
M_A_DQS#1
M_A_DQS#2
M_A_DQS#3
M_A_DQS#4
M_A_DQS#5
M_A_DQS#6
M_A_DQS#7

VCC3

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M3

Max.3.3A

98
97
96
95
92
91
90
86
89
85

107

84
83

119

80
78

109
108

79
114
121
101
103
102
104

73

74
115
110
113
197
201
202
200

116
120

11

28

46

63
136
153
170
187

12

29

47

64
137
154
171
188

10

27

45

62
135
152
169
186

75

76

81

82

87

88

93

94

99
100
105
106
111
112
117
118
123
124
199

77
122
125
198

30

1

126

2
3
8

9
13
14
19
20
25
26
31
32
37
38
43

2

(H=4mm)(H=8mm)

CON1
A0

A1
A2
A3
A4
A5
A6
A7
A8
A9
A10/AP
A11
A12/BC#
A13
A14
A15

BA0
BA1
BA2
S0#
S1#
CK0
CK0#
CK1
CK1#
CKE0
CKE1
CAS#
RAS#
WE#
SA0
SA1
SCL
SDA

ODT0
ODT1

DM0
DM1
DM2
DM3
DM4
DM5
DM6
DM7

DQS0
DQS1
DQS2
DQS3
DQS4
DQS5
DQS6
DQS7
DQS#0
DQS#1
DQS#2
DQS#3
DQS#4
DQS#5
DQS#6
DQS#7

VDD1
VDD2
VDD3
VDD4
VDD5
VDD6
VDD7
VDD8
VDD9
VDD10
VDD11
VDD12
VDD13
VDD14
VDD15
VDD16
VDD17
VDD18
VDDSPD
NC1
NC2
NCTEST
EVENT#
RESET#
VREF_DQ
VREF_CA
VSS1
VSS2
VSS3
VSS4
VSS5
VSS6
VSS7
VSS8
VSS9
VSS10
VSS11
VSS12
VSS13
VSS14
VSS15

DDR3-DIMM0

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46

PC3-XXXX DDR3 SDRAM SO-DIMM

DQ47

(204P)

DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52

VTT1
VTT2

6/17 change CON1 from DIMM1 to DIMM0

M_A_DQ0

5

M_A_DQ1

7

M_A_DQ2

15

M_A_DQ3

17

M_A_DQ4

4

M_A_DQ5

6

M_A_DQ6

16

M_A_DQ7

18

M_A_DQ8

21

M_A_DQ9

23

M_A_DQ10

33

M_A_DQ11

35

M_A_DQ12

22

M_A_DQ13

24

M_A_DQ14

34

M_A_DQ15

36

M_A_DQ16

39

M_A_DQ17

41

M_A_DQ18

51

M_A_DQ19

53

M_A_DQ20

40

M_A_DQ21

42

M_A_DQ22

50

M_A_DQ23

52

M_A_DQ24

57

M_A_DQ25

59

M_A_DQ26

67

M_A_DQ27

69

M_A_DQ28

56

M_A_DQ29

58

M_A_DQ30

68

M_A_DQ31

70

M_A_DQ32

129

M_A_DQ33

131

M_A_DQ34

141

M_A_DQ35

143

M_A_DQ36

130

M_A_DQ37

132

M_A_DQ38

140

M_A_DQ39

142

M_A_DQ40

147

M_A_DQ41

149

M_A_DQ42

157

M_A_DQ43

159

M_A_DQ44

146

M_A_DQ45

148

M_A_DQ46

158

M_A_DQ47

160

M_A_DQ48

163

M_A_DQ49

165

M_A_DQ50

175

M_A_DQ51

177

M_A_DQ52

164

M_A_DQ53

166

M_A_DQ54

174

M_A_DQ55

176

M_A_DQ56

181

M_A_DQ57

183

M_A_DQ58

191

M_A_DQ59

193

M_A_DQ60

180

M_A_DQ61

182

M_A_DQ62

192

M_A_DQ63

194
44

48
49
54
55
60
61
65
66
71
72
127
128
133
134
138
139
144
145
150
151
155
156
161
162
167
168
172
173
178
179
184
185
189
190
195

(Max. 0.6A)

196
203
204
205

G1

206

G2

2

1.5VSUS

VTT_MEM

Title

Size Document Number Rev

Custom

Date: Sheet

1

M_A_DQ[63:0] (6)

Place these Caps near So-Dimm1.

VTT_MEM

C226 10U/6.3V/X5R_6
C227 10U/6.3V/X5R_6
C228 10U/6.3V/X5R_6
C229 1U/6.3V/X5R_4
C230 1U/6.3V/X5R_4
C231 1U/6.3V/X5R_4
C232 1U/6.3V/X5R_4

Place these Caps near So-Dimm0.

VTT_MEM

C233 10U/6.3V/X5R_6
C234 10U/6.3V/X5R_6
C235 10U/6.3V/X5R_6
C236 1U/6.3V/X5R_4
C237 1U/6.3V/X5R_4
C238 1U/6.3V/X5R_4
C239 1U/6.3V/X5R_4

R227
470/F_4

SMVREF_GMCH

R232
470/F_4

C240

470P_4

Del R228,R230,R231,R233

SMVREF_GMCH (24)

MBDATA/MBCLK:
WWAN Thermal (G751)

DRAM Thermal (G751)
HDD G-Sensor
Ext.Graphics Thermal (LM89-1)
Nvidia Graphics Thermal
PCH SMBUS
TPA2016D2 Write 1011 0000
TPA2016D2 Read 1011 0001

TAOS TSL2561FN(Alert)

14

Address
100 1001

100 1000
001 1101
100 1101
1001 1110

010 1001TAOS TSL2561FN
000 1100

MEMORY THRM SENSOR

VCC3

Themal I2C

MBDATA(11,17,32)

MBCLK(11,17,32)

VCC3

3

Q15 2N7002E

VCC3

3

Q16 2N7002E

KBSMDATA(19)

KBSMCLK(19)

R234

1

VCC3

1

1
2
3
4

10K/F_4

R235
10K/F_4

U7

SMBDATA
SMBCLK
O.S.
GND

KBSMDATA (19)

KBSMCLK (19)

+Vs

A0
A1
A2

G751-2P-8F

2

2

QUANTA
COMPUTER

DDR3 DIMMx2

TW6 Main Board

14 33Monday, August 31, 2009

1

of

VCC3

8
7
6
5

2A

A

VCC3

VCC5

VCC5

CRT

C277

R237

R238

4.7K/F_4

4.7K/F_4
7

U8

4 4

DDC2BC(9,18)
DDC2BD(9,18)

HSYNC(9,18)

VSYNC1

C280 0.22U/6.3V_4

CRT_R1
CRT_G1
CRT_B1

R245
75/F_4

C287
10P_4

10
11

13
15

6
8

DDCIN_1
DDCIN_2

SYNC_IN1
SYNC_IN2

GND
BYP

CM2009-02/IP4772CZ16

R246
75/F_4

2

VCC_DDC

VCC_VIDEO

C288
10P_4

0.1U_4

1

VCC_SYNC
DDC_OUT1
DDC_OUT2

SYNC_OUT1
SYNC_OUT2

VIDEO_1
VIDEO_2
VIDEO_3

R247
75/F_4

B

D5 CH411DPT

C278

0.1U_4

9
12

14
16

3
4
5

L12 BK1608HS470
L13 BK1608HS470
L14 BK1608HS470

C289
10P_4

R239

2.2K/F_4

R240

2.2K/F_4

R241 42.2/F_6
R242 42.2/F_6

C282
10P_4

23

C

http://hobi-elektronika.net

VCC5

Del L10,L11

CRT-SCK
CRT-SDA

CRT-HS
CRT-VS

C281 0.1U/10V/X5R_4

C283
10P_4

C284
10P_4

C285
33P_4

C286
33P_4

CRT-R2
CRT-G2
CRT-B2

CRT_SENSE(17) SENSE_EN# (17,18)

D

CRT-R2

For EMI

VCC3

1 3

CRT-G2
CRT-B2

R243
10K_4

Q17
PDTC144EU

C279

0.1U_4

2

POLY SWITCH 0.25A

F1

D6 CH411DPT

2 3

2
1

12

DK_VGA_SENSE# (18)

R244
100K/F_4

R554

*0_4

D15_SENSE#

VCC5

VCC3

5

4

U9M74VHC1GT86DFT2G

3

Foxconn

E

1617

CON3

6
7

2
8
3
9
4

10

5

VGA-SUY(070546FR015SX28XR)

15

111

CRT-SDA

12

CRT-HS

13

CRT-VS

14

CRT-SCK

15

VCC5

3 3

DOCK_INSERT#(17,18)

2 2

VIN

1 1

C290

0.47U_4

CRT_R(9)
CRT_G(9)
CRT_B(9)

VSYNC(9)

IN:
0-->S1
1-->S2

Change L15 to
F9 2.6A fuse

POLY SWITCH 2.6A

F9

C292 0.1U/25V_6

R252 5.6K_4

DISPON

R_R2OUT1+(9)

R_R2OUT1-(9)

R_R2OUT2-(9)

R_R2OUT2+(9)

R_R2CLK0-(9)
R_R2CLK0+(9)

R_R2OUT0-(9)

R_R2OUT0+(9)

A

U10

16

VCC

8

GND

4

DA

7

DB

9

DC

12

DD

1

IN

15

EN

PI5V330S

12

C298 220P_4

R2OUT1+
R2OUT1-

R2OUT2­R2OUT2+

R2CLK0­R2CLK0+

R2OUT0­R2OUT0+

S1A
S1B
S1C
S1D

S2A
S2B
S2C
S2D

VIN_VLED

2
5
11
14

CRT_R1

3

CRT_G1

6

CRT_B1

10

VSYNC1

13

2CH LVDS

CON4

1

VIN

2

VIN

3

NC

4

NC

5

Disp_On

6

GND

7

R2_1+

8

R2_1-

9

GND

10

R2_3+

11

R2_3-

12

GND

13

R2_2-

14

R2_2+

15

GND

16

R2_CLK-

17

R2_CLK+

18

GND

19

R2_0-

20

R2_0+

43

GND

44

GND

LVDS-HND(LVC-C40SFYG+)

DOC_R (18)
DOC_G (18)
DOC_B (18)
DOC_VSYNC (18)

LCDVCC
LCDVCC
LCDVCC

NC

BKLTCTL

GND

R1_3-

R1_3+

GND

R1_CLK+

R1_CLK-

GND

R1_2+

R1_2-

GND

R1_1+

R1_1-

GND

R1_0-

R1_0+

GND
GND

[EC Behavior]
CRT_SENSE: H=>L or L=>H detect which one is inserting
Docking_Insert#: H=>L detect which one is inserting
[CRT SW]
When Docking_Insert# is low switching RGB to Docking CRT
[SENSE_EN#]
Input for CRT pin10, EC assert to high when CRT
insert[NEO Request]

21

LCDVCC

22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

45
46

B

R1CLK0+

R1CLK0­R1OUT2+

R1OUT2­R1OUT1+

R1OUT1­R1OUT0-

R1OUT0+

R250 10K/F_4

R_R1CLK0+ (9)
R_R1CLK0- (9)

R_R1OUT2+ (9)
R_R1OUT2- (9)

R_R1OUT1+ (9)
R_R1OUT1- (9)

R_R1OUT0- (9)
R_R1OUT0+ (9)

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

L_BKLTCTL (9)

C

Without Docking
MB CRT no Plug
MB CRT Plug in
MB CRT plug out L L

With Docking
All no Plug
MB CRT Plug in L
MB CRT plug out
DOCK DVI Plug in
DOCK DVI Plug out
DOCK CRT Plug
DOCK CRT/DVI Plug

SENSE_EN#

C293 0.1U_4

LVDS_VDDEN(9)

DK_VGA_SENSE#

L
L

L
L
L
L
L
L
L

D

H => L
L => H
H => L
L => H

L_BKLT_EN(9)

VCC3 LCDVCC

6
4
3

R253
100K/F_4

D15_SENSE# Docking_Insert#

L
L

H
H => L
L => H

LL

H
H => L L => H

L L => H

H

H

H

H

H
H
H

L
L
L
L
L
L
L

Display On

R248 100K/F_4

VCC3

2

TC7SH08FU

DISP_ON(17)

1

CRT_SENSE

L => H
H => L

H => L
H => L
L => H
H => L
L => H

C291 0.1U_4

U11

4

3 5

L

DISPON

R744
100K/F_4

NB LVDS enable

U12

IN
IN
ON/OFF

AAT4280AIGU-4-T1

OUT
GND
GND

1
2
5

C294

0.1U_4

C295

0.1U_4

C296

4.7U/6.3V/X5R_6

C297

0.01U_4

QUANTA

Title

Size Document Number Rev

Custom

Date: Sheet

COMPUTER

CRT/LVDS

TW6 Main Board

E

15 33Monday, August 31, 2009

2A

of

1

2

3

4

5

6

7

8

http://hobi-elektronika.net

Mini PCI-E Card FOR WL

WLAN_RF_ON:
Low : disable the radio.
High : Enable the radio.

A A

RVCC3_AUX

PCIE_TXP1(11)

PCIE_TXN1(11)

PCIE_RXP1(11)

PCIE_RXN1(11)

CH_DATA_INTEL(18)

R736

1

PCLK_MP(11)

R711 0_4
R712 0_4

Q71
2N7002K

2

RVCC3_AUX

2

Q58

PDTC144EU

BT_CH_CLK_INTEL

WLAN_WAKE#

31

5VPCU RVCC3_AUX15VPCU

R596
10K/F_4

2

Q57
2N7002E

1 3

6/9 add R711,R712
for EMI

CLK_PCIE_WLAN(11)

CLK_PCIE_WLAN#(11)

PCIE_REQ_WLAN1#(11)
BT_CH_CLK_INTEL(18)

B B

C C

D D

WLAN_WAKE#

10K/F_4

WLAN_PWEN(17)

CON46

51

Reserved

49

Reserved

47

Reserved

45

Reserved

43

GND

41

+3.3Vaux

39

+3.3Vaux

37

GND

35

GND

33

PETp0

31

PETn0

29

GND

27

GND

25

PERp0

23

PERno

21

GND

19

Reserved/UIM_C4

17

Reserved/UIM_C8

15

GND

13

REFCLK+

11

REFCLK-

9

GND

7

CLKREQ#

5

BT_CHCLK

3

BT_DATA

1

WAKE#

MiniPCIE-FOX(AS0B221-S40N-7F)

WAKE# (9,18,33)

RVCC3

R597
470K_4

WLAN3V CPPE#

31

C734
*0.01U_4

2

LED_WPAN#
LED_WLAN#

LED_WWAN#

SMB_DATA

W_DISABLE#

AD0/UIM_VPP
AD1/UIM_RST
AD2/UIM_CLK

AD3/UIM_DATA

FRAME#/UIM_PWR

WLAN Power

Q56
NTMFS4921

D

S

5

G

4

2

Q59
2N7002E

+3.3Vaux

GND

+1.5V

GND

USB_D+

USB_D-

GND

SMB_CLK

+1.5V

GND

+3.3Vaux

PERST#

GND

+1.5V

GND

+3.3Vaux

GNDGND

BT_CH_CLK_INTEL

3
2
1

R598
100/F_4

3

1

RVCC3_AUX

52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18

16
14
12
10
8
6
4
2
5453

C728

0.1U_4

LAD0
LAD1
LAD2
LAD3

R591 100K/F_4

C729

1U/6.3V/X5R_4

3

PLTRST# (5,11,18,30,33)

LPC_AD0 (10,17,18)
LPC_AD1 (10,17,18)
LPC_AD2 (10,17,18)
LPC_AD3 (10,17,18)

LPC_FRAME# (10,17,18)

RVCC3_AUX

( 1A Peak, 0.75A normal)

C730

10U/6.3V/X5R_8

C731

0.1U_4

For Debug Card Only

C732

*22U/10V/X5R

VCC1.5

C735

0.1U/Y5V_4

3VSUS

C740

0.1U/Y5V_4

4

USBP12+ (11)
USBP12- (11)

C733
10U/6.3V/X5R_8

C736
10U/6.3V/X5R_8

C741
10U/6.3V/X5R_8

WLLED#

31

Q54

2N7002K

2

3

2

Q55

2N7002E
1

EXPRESS CARD

D54 RB501V-40

R590
100K_4

CON47

WLAN_RF_ON# (17)

4/27 : Add Q18,R506

Express Card

32

GND

31

GND

30

hole

29

hole

28

GND

27

GND

Express Card(130801-1)

AECՂሒ 130801-1

VCC1.5_EXPRESS_CARD3VSUS_EXPRESS _CARD

C737

0.1U/Y5V_4

VCC3_EXPRESS_CARD

C742

4.7U/6.3V/X5R_6

5

C738

4.7U/6.3V/X5R_6

C743

0.1U/Y5V_4

C744

0.1U/Y5V_4

WLAN_BT_LED#

1

GND

2

USBD-

3

USBD+

4

PCUSB#

5

Reserved

6

Reserved

7

SMBCLK

8

SMBDATA

9

+1.5V

10

+1.5V

11

WAKE#

12

+3.3VAUX

13

PERST#

14

+3.3V

15

+3.3V

16

CLKREQ#

17

CPPE#

18

REFCLK-

19

REFCLK+

20

GND

21

PERn0

22

PERp0

23

GND

24

PETn0

25

PETp0

26

GND

VCC3 VCC3_EXPRESS_CARD

3VSUS

VCC1.5

PLTRST#(5,11,18,30,33)

C739

0.1U/Y5V_4

VCC3

C745

0.1U/Y5V_4

6

1 3

CPUSB#

R709 0_4
R710 0_4

Q49
PDTC144EU

2

BT_LED (18)

LP8

R592 4.7K/F_4

R593 4.7K/F_4

R594 *0_4

R595 *0_4

PERST#

4
5

16
15

PLTRST#

1

2
19
10

C746
10U/6.3V/X5R_8

WLAN_BT_LED# (18)

3

4
1

U60

3.3VIN

3.3VIN

1.5VIN

1.5VIN
SYSRST#

SHDN#
RCLKEN
GND

BD4160FV-E2

*CMF-2012-0090I-S1

2

3VSUS_EXPRESS _CARD
PCLK_SMB (4,11,14)

PDAT_SMB (4,11,14)
VCC1.5_EXPRESS_CARD
VCC1.5_EXPRESS_CARD

WAKE# (9,18,33)
3VSUS_EXPRESS _CARD

VCC3_EXPRESS_CARD

PCIE_REQ_EXPRESSCARD# (11)

CLK_PCIE_EXPRESS_CARD# (11)

CLK_PCIE_EXPRESS_CARD (11)

PCIE_RXN5 (11)

PCIE_RXP5 (11)

PCIE_TXN5 (11)

PCIE_TXP5 (11)

6

3.3VOUT
7

3.3VOUT
1718

AUXOUTAUXIN

14

1.5VOUT
13

1.5VOUT
3

STBY#

12

CPPE#

11

CPUSB#

89

PERST#NC

20

OC#

USBP3- (11)
USBP3+ (11)

(1.3A)

(275mA)
(650mA)

MAINON

CPPE#
CPUSB#

PERST#

3VSUS_EXPRESS _CARD
VCC1.5_EXPRESS_CARD

R599 10K/F_4
R600 10K/F_4

Short current:

3.3VOUT : 1.35 ~ 2.5A
AUXOUT : 0.275 ~ 0.6A

1.5VOUT : 0.67 ~ 1.3A

6/9 add R709,R710
for EMI

MAINON (17,23,25,27,28)

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

WLAN/EXPRESS CARD
TW6 Main Board

7

16

3VSUS

16 33Monday, August 31, 2009

8

2A

of

5

BADDR1-0 Index Data

110

*

1
0010

(HCFGBAH, HCFGBAL)

SHMB: SHBM(If = 0 Enable share host BIOS memory)

DOCK_RST# : BADDR0
T?: BADDR1

D D

GATEA20(12)

6/8 add R704 2.2K from EC to RSMRST#
Same as GD3

C C

B B

A A

I/O Address

2E

4E 4F

XOR-TREE TEST

VCC3

DOCK_INSERT#

DOCK_PWRON

DOCK_PWROK

150ms

3VPCU

ICH_SUSCLK(9)

5

D14 RB501V-40
D15 RB501V-40

D16 RB501V-40

32.768K/10PPM
C363

15P_4

KBSMI#(10)

RCIN#(12)

2F

(HCFGBAH, HCFGBAL)+1

R307 10K/F_4

2 1
2 1

SCI#(12)

2 1

RSMRST#(9)

R313 4.7K_4

3VPCU

DOCK_RST#

R316 10K/F_4

LID#(19)

DOCK_EJECT(18)

DOCK_PWRON(18)

MUTE_BUTTON#(32)

Y5

775_32KX3

21

C364
15P_4

LPC_AD0(10,16,18)
LPC_AD1(10,16,18)
LPC_AD2(10,16,18)
LPC_AD3(10,16,18)

PCLK_EC(11)

LPC_FRAME#(10,16,18)

IRQ_SERIRQ(10,18)

2 1

D58 RB501V-40

R704 2.2K/F_4

PROCHOT(5)

P_BUTTON#(32)

RVCC_ON(13,23)

TBDATA(18)

TBCLK(18)

ACIN(28)

R658 *100K_4
R558 *0_4

R322 20M_4

R323 33K_4

VCC3

F_SDI
F_SD0
F_SCK
F_CS0#

MY10(20)
MY11(20)
MY12(20)
MY13(20)
MY14(20)
MY15(20)

MX0(20)
MX1(20)
MX2(20)
MX3(20)
MX4(20)
MX5(20)
MX6(20)
MX7(20)

MY0(20)
MY1(20)
MY2(20)
MY3(20)
MY4(20)
MY5(20)
MY6(20)
MY7(20)
MY8(20)
MY9(20)

TBDATA
TBCLK

C345 10U/6.3V/X5R_6
C346 0.1U_4
C349 0.1U_4
C352 0.1U_4
C353 0.1U_4
C354 0.1U_4

C355 0.1U_4

MUTE_BUTTON#

HOLD#

ACIN

775_32KX1
775_32KX2

4

3VPCU

MNB-201209-0030P-N1Q

L16

4

VDD

11588764619

VCC

LPC

SPI

U18

126

LAD0

127

LAD1

128

LAD2

1

LAD3

7

LRESET#

2

LCLK

3

LFRAME#

121

GA20

125

SERIRQ

9

SMI#/GPIO65

29

ECSCI#/GPIO54

122

KBRST#

123

GPIO67/PWUREQ#

86

F_SDI

87

F_SD0

92

F_SCK

90

F_CS0#

54

KBSIN0

55

KBSIN1

56

KBSIN2

57

KBSIN3

58

KBSIN4

59

KBSIN5

60

KBSIN6

61

KBSIN7

53

KBSOUT0/JENK#

52

KBSOUT1/TCK

51

KBSOUT2/TMS

50

KBSOUT3/TDI

49

KBSOUT4/JEN0#

48

KBSOUT5/TDO

47

KBSOUT6/RDY#

43

KBSOUT7

42

KBSOUT8

41

KBSOUT9

40

KBSOUT10

39

KBSOUT11

38

KBSOUT12/GPIO64

37

KBSOUT13/GPIO63

36

KBSOUT14/GPIO62

35

KBSOUT15/GPIO61/XOR_OUT

34

KBSOUT16/GPIO60

13

PSDAT3/GPIO12

12

PSCLK3/GPIO25

11

PSDAT2/GPIO27

10

PSCLK2/GPIO26

71

PSDAT1/GPIO35

72

PSCLK1/GPIO37

117

TA2/GPIO20

30

CLKOUT/GPIO55

63

TB1/GPIO14

64

TB2/GPIO01

95

AD6/GPIO03

WPC775L

77

32KX1/32KCLKIN

79

32KX2

WPC775L

1. Level 1 Environment-related Substances Should NEVER be Used.

2. Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

4

http://hobi-elektronika.net

3VPCU_ITE_AVDD

C350

10U/6.3V/X5R_6

102

VCC

VCC

VCC

VCC

AVCC

A/DPWM

D/A

A_PWM0/GPIO15

CLKRUN#/GPIO11

K/B

GPIO24/HGPIO01

GPIO

PS/2

116897845185103

KBSOUT17/GPIO57

SOUT_CR/GPIO83/BADDR1

GPIO84/BADDR0

SPI_DO/GPIO76/SHBM

SPI_CLK/GPIO75

GND

GND

GND

GND

GND

GND

AGND

AD5/GPIO04
AD4/GPIO05

B_PWM/GPIO21
C_PWM/GPIO13
D_PWM/GPIO32
H_PWM/GPIO33

G_PWM/GPIO66

E_PWM/GPIO45
F_PWM/GPIO40

SCL3/GPIO23
SDA3/GPIO31

AD7/GPIO07

LPCPD#/GPIO10

SCL1/GPIO17
SDA1/GPIO22

TA1/GPIO56
TCK/GPIO42

TMS/GPIO43

TDI/GPIO44

TRST#/GPIO46

SCL4/GPIO47

TA3/GPIO51

TDO/GPIO50

RDY#/GPIO52

SDA4/GPIO53

GPIO82/TRIS#

SIN_CR/GPIO87

SPI_DI/GPIO77

GPIO74/SDA2
GPIO73/SCL2

VCC_POR#

AD0/GPI90
AD1/GPI91
AD2/GPI92
AD3/GPI93

DA0/GPI94
DA1/GPI95
DA2/GPI96
DA3/GPI97

GPIO06
GPIO30
GPIO16

GPIO34
GPIO36

GPIO41

GPIO70
GPIO71
GPIO72

GPIO81

VREF

VCORF

97
98
99
100
96
108

101
105
106
107

32
118
62
65
66
81
22
16
93
109
114
119
120

94
124
8
70
69

6
14
15
31
17
20

80
21
23

24
26
25
27

28
33

73
74
75
110
111
112
113

84
83
82
91

68
67

104
85

44

3

MBATV

ISENS_IN

C351

0.1U_4

PM_SLP_S4#
MPWROK

HDD_INTERRUPT

BAT_CLK
BAT_DATA

MBCLK
MBDATA

AZ_GPIO0

PM_SLP_S3#
PM_SLP_S5#

VRON

CRT_SENSE

HWPG

DRAMRST_CNTRL

HDD_UNLOAD_R

VCC POWER ON RESET

R662 0_4

C361 0.1U_4

R324 4.7K_4

3

C344 0.01U_4
C347 0.01U_4

MBATV (28)
ISENS_IN (28)
BAT_PRS# (29)

PM_SLP_S4# (9)

VFAN (20)
HDD_INTERRUPT (19)

I_SET (28)

WLAN_PWEN (16)
SENSE_EN# (15,18)
DOCK_INSERT# (15,18)
ACPRESENT (9)
DISP_ON (15)
SLEEPLED# (32)
BATLED# (18)
PWRLED# (32)
MAINON (16,23,25,27,28)
NUMLED# (32)
ODD_PWEN (19)
BAT_CLK (29)
BAT_DATA (29)

DOCK_RST# (18)
DOCK_INUSE# (18)
PCI_CLKRUN# (9,18)
MBCLK (11,14,32)
MBDATA (11,14,32)

CRIT_TEMP_REP# (12)
AZ_GPIO0 (31)

FAN-SIG (20)
DOCK_PWROK (18)
NBSWON# (32)

BATT_RST# (18)
HDA_DOCK_EN# (10)
SUSON (19,23,24)

SUS_PWR_DN_ACK (9)
PM_SLP_S5# (9)

VRON (18,22)

CRT_SENSE (15)

CAPSLED# (32)
WIRELESS_SW# (32)

SCROLED# (32)
VOL_MUTE (31)
CHGEN# (28)
DRAMRST_CNTRL (5)

WLAN_RF_ON# (16)

BT_PEN# (18)
DC/-C (28,29)

35001_SDA (18)
35001_SCK (18)

3VPCU

R306 0_4

C356
*0.01u_4

MPWROK(5,9)

21

D17 RB501V-40

PM_SYS_PWRGD

Add open-drain buffter U70, R755,C928 for HDD_UNLOAD

R320 10K/F_4

HDD_UNLOAD (19)

Winbond
W25Q16BVSSIG 2MB

F_CS0#
F_SDI

3VPCU

R750
100K/F_4

4/18 change BIOS to 2MB

ISENS_DOCK (18)

R748

MPWROK

DNBSWON# (9)

U23

1

VDD

/CS

2

/HOLD

DO

3 6

/WP CLK

4

GND

DI

W25Q16BVSSIG

2

RVCC3

1352

Y

4

0_4

U19

NC7SZ58

HWPG(9)

Del R717,R718,R719

D55 *BAS316
D56 *BAS316
D57 RB501V-40

C366 0.1U_4C365 1U/6.3V/X5R_4

8

3VPCU

7

3VPCU

F_SCK
F_SD0

5

2MBYTE W25X16AVSSIG
AKE38ZP0N01

2

1

TBCLK

VCC

AND

GND

A

B

5V_RESET#(23)

3VPCU

6

HWPG

R749 0_4

R563

10K/F_4

PM_SLP_S3#(9)

TBDATA

PM_SYS_PWRGD(23)

EXT_INT_VGA_PWRGD(26)

RVCC3

12453

..

.

..

NC7SZ04P5X

C358 0.1U_4

R300 4.7K_4
R301 4.7K_4
R302 3.3K_4
R303 3.3K_4
R746 2.2K/F_4
R747 2.2K/F_4

LS_PGOOD(23,27)

8743_PWRGD(25,27)

DDR_PWRGD(24)

R309 10K/F_4

U20

4

ACIN

PM_SLP_S3#

PM_SLP_S4#
VRON
PM_SLP_S3#
AZ_GPIO0
PM_SLP_S5#

HWPG
MPWROK
RSMRST#

DRAMRST_CNTRL

5VPCU

C359 1U/6.3V/X5R_4

R321

*10K/F_4

C362

0.1U/10V/X5R_4

D9 RB501V-40
D10 RB501V-40
D11 SW1010CPT
D12 RB501V-40
D13 RB501V-40

U21

TC7SH08FU

R315 39K/F_4
R317 39K/F_4
R318 39K/F_4
R319 4.7K_4
R576 39K/F_4

3 4

1

2

VCC5

MBCLK
MBDATA

BAT_CLK
BAT_DATA

VCC5

RVCC3

2
1

3 5

NBSWON#

2 1

D18 RB501V-40

2 1

D19 RB501V-40

R751 10K/F_4

U22

VIN VOUT

SHDN

GND

SET

G923-330

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

WPCE775L & FLASH
TW6 Main Board

1

C357

0.22U/10V/X5R_4

MPWROK

VR_PWRGOOD (22)

Q22

PDTA124EU

2

HOLD#

100K/F_4

3VPCU

C360
10U/6.3V/X5R_6

5

of

17

17

VCC3

R304
15K/F_4

R308
1M_4

3VPCU

13

R314

RVCC3

33Monday, August 31, 2009

2A

5

1
HOLE40

1

R331 0_4
R332 0_4
R333 0_4

HOLE39

SPAD-RE177X118NP

1

HOLE41

SPAD-RE177X118NP

1

C373
*10P_4

DOCK_PWROK

DOCK_INUSE#
DOCK_PWRON
DOCK_RST#
DOCK_EJECT

C374
*10P_4

R334 *100K/F_4

R335 100K/F_4
R336 100K/F_4
R337 100K/F_4
R338 100K/F_4

DOC_R(15)
DOC_G(15)
DOC_B(15)

D D

HOLE38

SPAD-RE177X118NP

SPAD-RE177X118NP

C C

DOC_R1
DOC_G1
DOC_B1

C375
*10P_4

3VSUS

4

http://hobi-elektronika.net

USBP2-(11)

USBP2+(11)

HSYNC(9,15)

DOC_VSYNC(15)

DDC2BC(9,15)
DDC2BD(9,15)

DDP_EXT_CTRL_DATA(9)

DDP_EXT_CTRL_CLK(9)

DOCK_INUSE#(17)

DK_VGA_SENSE#(15)

HDMI_DOCK_HPD_EXT(9)

SENSE_EN#(15,17)

DOCK_PWRON(17)

DOCK_RST#(17)

DOCK_PWROK(17)

DOCK_EJECT(17)

D20

VA+

3

PDS1040-13/H1.15

C378

680P_4

3

Docking

DOC_R1
DOC_G1
DOC_B1

DOCK_INUSE#

DOCK_PWRON
DOCK_RST#
DOCK_PWROK
DOCK_EJECT
DOCK_INSERT

VA+IN

1
2

C379

Docking FOX(QL0125L-D24A01-5F)

680P_4

2

1

VCC3

18

DOCK_INSERT

Q23 2N7002K

1 3

R330
10K_4

2

DOCK_INSERT# (15,17)

31

WAKE# (9,16,33)

CON15

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

13

13

14

14

15

15

16

16

17

17

18

18

19

19

20

20

21

21

22

22

23

23

24

24

25

25

53

53

54

54

DOCKED_R

DOCKED_S

5556575859

5556575859

26

26

27
28

28

29

29

30
31

31

32

32

33

33

34

34

35

35

36

36

37

37

38

38

39

39

40

40

41

41

42

42

43

43

44

44

45

45

46

46

47

47

48

48

49

49

50

50

51

51

52

52

60

60

DOCK_INSERT

DDP_EXT_CLK# (9)
DDP_EXT_CLK (9)

DDP_EXT_DATA1# (9)
DDP_EXT_DATA1 (9)

DDP_EXT_DATA0 (9)
DDP_EXT_DATA0# (9)

DDP_EXT_DATA2 (9)
DDP_EXT_DATA2# (9)

PCIE_TXN4 (11)
PCIE_TXP4 (11)

CLK_PCIE_DKLAN# (11)
CLK_PCIE_DKLAN (11)

ISENS_DOCK (17)
PCIE_REQ_DK_LAN# (11)

DOCK_WAKE#

PCIE_RXN4 (11)
PCIE_RXP4 (11)

Q14
PDTC144EU

2

DOCK_INSERT#:
1 No port Replicator insert
0: port Replicator insert

R716
100K_4
DOCK_WAKE#

TPM

Add R760 serial on IRQ_SERIRQ

CON48

1314

(17,22)

VRON

IRQ_SERIRQ(10,17)

B B

R760 0_4

PCLK_TPM(11)

LPC_AD3(10,16,17)
LPC_AD2(10,16,17)
LPC_AD1(10,16,17)
LPC_AD0(10,16,17)

12

1314
1112

910
78
56
34
12

TPM-ACES(88014-14001)

35001

0827 P18- Add
R754 bypass

R343
*100K_4

5

option

R339
1K/F_4

U28

1

PGM

2

RSET

3

VSS

4

VCC

35001

R754

*10K/F_4

PIO
SDA
SCK

CNVSS

3VPCU

A A

3VPCU

RVCC3

1112
910
78
56
34
12

3VPCU

21

D59

RB501V-40

R340
10K/F_4

8
7
6

C381

5

*1000P_4

VCC3

R341

2.2K/F_4

LPC_FRAME# (10,16,17)

PCI_CLKRUN# (9,17)
PLTRST# (5,11,16,30,33)

Add D59 for leakage on DC mode

R342

2.2K/F_4

BATT_ID (29)

35001_SCK (17)

C380
*1000P_4

4

CH_DATA_INTEL(16)

35001_SDA (17)BATT_RST#(17)

CH_DATA_INTEL

SATALED#(10)

C808 1U/6.3V_4

3VSUS

BT_PEN#(17)

SATALED#

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

R639
100K/F_4

BT_PEN#

BT_VCC3

2
1

3 5

R654
*10K/F_4

2

U65

5

IN

4

ON#

2

GND

G5240B2T1U/RT9711DPBG

BT_CH_DATA_INTEL

4

U67
TC7SH08FU

VCC3VCC3

13

Q69
CHDTA114YUPT

R655
150/F_4

SATALED

3

OUT

SET/NC

1

3

C850

1U/6.3V/X5R_4

BATLED#(17)

BT_PEN#

C807
10U/6.3V_8

BT_VCC3

2

2

R651
22_6

31

3VPCU

13

BT_VCC3

Q68

RHU002N06

Q61
PDTA124EU

R640
150/F_4

BATLED

USBP13+(11)

BT

USBP13-(11)

BT_PRS#(12)

BT_CH_CLK_INTEL(16)

BT_VCC3

BT_LED(16)
TBDATA(17)
TBCLK(17)

F6 POLY SWITCH 0.25A

VCC5

WLAN_BT_LED#(16)

R643
150/F_4

Title

Size Document Number Rev

2

Date: Sheet

2

R642
150/F_4

12

BT_CH_DATA_INTEL

SATALED
BT_LED

BATLED
WIRELESSLED1
WIRELESSLED2
WIRELESSLED3

RVCC3

13

Q62
PDTA124EU

R641
150/F_4

VCC5_TP

6/1 Change Pin define

WIRELESSLED1
WIRELESSLED2
WIRELESSLED3

QUANTA
COMPUTER

Docking/35001/TP/TPM/BT

TW6 Main Board

1

(FFC)T/P to M/B

CON42

20

20

19

19

18

18

17

17

16

16

15

15

14

14

13

13

12

12

11

11

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

88511-2001-20pin

18 33Monday, August 31, 2009

of

2A

1

2

3

4

5

6

7

8

ODD CONNECTOR

CON17

1

SATA_TXP1_C
SATA_TXN1_C

SATA_RXN1_C
SATA_RXP1_C

SATA-AOP(C18567-11305-L)

SATA_TXP0_C
SATA_TXN0_C

SATA_RXN0_C
SATA_RXP0_C

SATA_TXP0_R
SATA_TXN0_R

SATA_RXN0_R
SATA_RXP0_R

AUTOEN

C390 0.01U_4
C391 0.01U_4

R728 0_4
R729 0_4
R730 0_4
R731 0_4

C152 0.01U_4
C153 0.01U_4

C385 0.01U_4
C386 0.01U_4

A_EQ
B_EQ
A_PRE
B_PRE
A_BST#
B_BST#

C150 0.01U_4
C151 0.01U_4

SATA_TXP0_R
SATA_TXN0_R
SATA_RXN0_R
SATA_RXP0_R

SATA_TXP1(10)
SATA_TXN1(10)

A A

HDD Repeater and CONNECTOR

B B

C C

VCC3

SATA_RXN0(10)
SATA_RXP0(10)

SATA_RXN1(10)
SATA_RXP1(10)

R727 *4.7K
R723 *4.7K
R724 *4.7K
R725 *4.7K

R726 *4.7K
R721 *0_4
R722 *0_4

SATA_TXP0(10)
SATA_TXN0(10)

SATA_TXP0_C

SATA_TXN0_C

SATA_RXN0_C
SATA_RXP0_C

GND

2

A+

3

A-

4

GND

5

B-

6

B+

7

GND

A_BST#

U68

1

A_INp

A_BST#

2

A_INn

3

GND

4

B_OUTn

5

B_OUTp

*PS8511B

CON49

1

GND

2

A+

3

A-

4

GND

5

B-

6

B+

REVERSE

24

GND

7

GND

VCC12

hole

VCC12
VCC12

23

HDD-AOP(C166P5-12205-L)

8

DP

9

VCC5

10

VCC5

11

MD

12

GND

13

GND

GND

GND

6/13 Del ODD Eject function.

14

15

VCC3

A_EQ

B_EQ

B_EQ

A_EQ

AUTOPE_EN

9

B_PRE

AUTOEN

VCC3
VCC3
VCC3

GND
GND

GND
VCC5
VCC5
VCC5

GND

GND

C910 *0.01U_4
C911 *0.1U_4

6

7

1617181920

EN

VDD

VDD

15

A_OUTp

14

A_OUTn

13

GND

12

B_INn

11

B_INp

A_PRE

B_PRE

B_BST#

8

10

A_PRE

B_BST#
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22

4/23 change HDD_UNLOAD to pin18

SATA_TXP0_R1
SATA_TXN0_R1

SATA_RXN0_R1
SATA_RXP0_R1

(2.5"HDD VCC5 Max=1.5A, AVG=0.6A)
(2.5"SSD VCC5 Avg=52mA)
(Mini SSD VCC5 Max=126mA)

HDD_UNLOAD (17)

HDD PROTECT

C394 10U/6.3V/X5R_6
C395 0.1U_4

R507 10K/F_4

VCC3

D D

VCC3

1

KBSMCLK(14)

KBSMDATA(14)

R349 10K/F_4

2

7

4
6

8

LIS331DL

U30

SA0

SCL
SDA

CS

R713 0_4

1

14

VDD

Vdd_IO

Reserved

GND

GND

GND

Reserved

5

13

12

101516

VCC3

11

Int1

9

Int2

3

NC

2

NC

GND

HDD_INTERRUPT (17)

3

http://hobi-elektronika.net

(Max=2.5A)

D47

*UClamp0501P

C906 *0.01U_4
C907 *0.01U_4

C908 *0.01U_4
C909 *0.01U_4

C392

0.1U_4

C384
10U/6.3V/X5R_6

SATA_TXP0_R
SATA_TXN0_R

SATA_RXN0_R
SATA_RXP0_R

VCC5

C393
10U/6.3V/X5R_6

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

C383

10U/6.3V/X5R_6

(Max. 2.5A)

0.1U_4

VCC5_ODD

C382

SATA_RXN1_C

Camera

CCD_PWR

LP7 *CMF-2012-0090I-S1

USBP9-(11)
USBP9+(11)

DMIC_CLK(31)

DMIC_DATA(31)

DMIC_CLK
DMIC_DATA

DMIC

Magnetic Lid Switch

3VPCU

Power Plan Capacitor 6/9 Add Power Plan Capacitor

C857 1000P_4
C861 1000P_4
C865 1000P_4

C869 1000P_4

VIN VCC3 VCC3

C873 1000P_4
C876 1000P_4
C880 1000P_4
C884 1000P_4
C888 1000P_4
C891 1000P_4
C893 1000P_4

C898 1000P_4

4

4
1

R652 BLM31PG601SN1
R653 BLM31PG601SN1

DMIC_CLK
DMIC_DATA

U13

OUT

1

IN

GND

Matsuki

5VSUS

VCC3 VIN
VCC3 5VPCU

VCC3 VCC1.05

5VSUSVIN

D22

2

NC

1

GND

*Rclamp0502N

D21

2

NC

1

GND

*Rclamp0502N

C694 1U/6.3V/X5R_4

3
2

C711 *220P_4
C712 *220P_4

LID#

2
3

VCC55VSUS

C870 1000P_4
C874 1000P_4
C877 1000P_4
C881 1000P_4
C885 1000P_4
C889 1000P_4
C892 1000P_4
C894 1000P_4
C896 1000P_4
C899 1000P_4

VIN VCC_CORE

C901 1000P_4
C902 1000P_4

5

IO1NC
IO1

VCC

IO1NC
IO1

VCC

SATA_TXP1_CSATA_TX P1_ C

43

SATA_TXN1_CSATA_TXN1_C

5
6

VCC5_ODD

ODD_PWEN(17)

SATA_RXN1_C

43

SATA_RXP1_CSATA_RXP1_C

5
6

VCC5_ODD

LID# (17)

C855 1000P_4
C858 1000P_4
C862 1000P_4

1
2
3
4
5
6

ACS(87213-0600G)

VCC_CORE

VCC5VCC3

VCC1.05 VCC3

5VSUS

CON10

1
2
3
4
5
6

PDTC144EU

VCC_CORE

2

Q70

3VSUS

5VPCUVCC5

C871 1000P_4
C875 1000P_4
C878 1000P_4
C882 1000P_4

C895 1000P_4
C897 1000P_4
C900 1000P_4

6

5VPCU

R671

49.9K_4

1 3

F8

12

*POLY SWITCH 0.5A

R737 0_6

SUSON(17,23,24)

5VPCU +VCC_GFXCORE

5VPCU

C886 1000P_4

USB Camera Power

C853 1000P_4

C859 1000P_4
C863 1000P_4
C866 1000P_4

VCC1.05VIN

VCC1.05VCC_CORE
+VCC_GFXCORE

Title

Size Document Number Rev

Date: Sheet of

U59

2

IN

3

IN

4

EN

1

GND

TPS2556

C684 1u/6.3V_4

U56

1

INENOUT

2

GND

3

FLAG

MAX4789

5VSUS

Tuesday, September 01, 2009

7

(Current Limit = 2.98A ~ 3.04A)

6

OUT
OUT

FAULT

ILIM

5

4

C903 1000P_4
C904 1000P_4

VCC5_ODD5VPCU

7
8

R669 36K/F_4

5

(95mA)

C454 1U/6.3V/X5R_4
C455 0.1U_4

AU LCDVCC:
I rush = 2A/0.5ms
IDD = 0.3A

C856 1000P_4
C860 1000P_4

C864 1000P_4

1.5VSUS
C867 1000P_4

C868 1000P_4
C872 1000P_4

C879 1000P_4

VCC1.05

C883 1000P_4
C887 1000P_4

VCC1.05VIN

QUANTA
COMPUTER

HDD/ODD/Camera/DMIC

TW6 Main Board

19

19 33

8

CCD_PWR

1.5VSUS5VPCU

2A

A

KEYBOARD

RP27

MX3
MX1
MX2
MX0

MX7
MX5
MX6
MX4

HOLE1

RP33

10KX4

RP34

10KX4

8
6
4
2

8
6
4
2

8
6
4
2

MY1
MY2
MX3
MY3

MX6
MY10
MX7
MY11

MY8
MX4
MY9
MX5

MY12
MY13
MY14
MY15

MY10
MX7
MY11
MY8
MX4
MY9
MX5
MY4
MY5
MY6
MY7
MY1
MY2
MX3
MY3
MX0
MX1
MX2
MY0

MY12(17)
MY13(17)
MY14(17)
MY15(17)
MX6(17)
MY10(17)
MX7(17)
MY11(17)

4 4

MY8(17)
MX4(17)
MY9(17)
MX5(17)
MY4(17)
MY5(17)
MY6(17)
MY7(17)
MY1(17)
MY2(17)
MX3(17)
MY3(17)
MX0(17)
MX1(17)
MX2(17)
MY0(17)

3 3

CA4 220PX4

7
5
3
1

CA3 220PX4

7
5
3
1

CA6 220PX4

7
5
3
1

2 2

H-C315D177PT

RP28

MX6

RP29

RP30

RP31

RP32

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

CA2 220PX4

7
5
3
1

CA1 220PX4

7
5
3
1

CA5 220PX4

7
5
3
1

HOLE2

H-C315D177PT

7
5
3
1
7
5
3
1
7
5
3
1
7
5
3
1
7
5
3
1
7
5
3
1

3VPCU

8
6
4
2
8
6
4
2
8
6
4
2
8
6
4
2
8
6
4
2
8
6
4
2

3VPCU

3VPCU

MX0

8

MX1

6

2

MX

4

MY0

2

MY12

8

MY13

6

MY14

4

MY15

2

MY4

8

MY5

6

MY6

4

MY7

2

HOLE3

H-C315D177PT

MY12_R
MY13_R
MY14_R

22X4

MY15_R
MX6_R
MY10_R
MX7_R

22X4

MY11_R
MY8_R
MX4_R
MY9_R

22X4

MX5_R
MY4_R
MY5_R
MY6_R

22X4

MY7_R
MY1_R
MY2_R
MX3_R

22X4

MY3_R
MX0_R
MX1_R
MX2_R

22X4

MY0_R

MX0
MX1

C423
*0.1U_4

MX6 MX4
MX7 MX5

C426
*0.1U_4

SPAD-C256NP

SPAD-C236NP

HOLE4

H-C315D177PT

MX0_R
MX1_R
MX2_R
MY0_R
MY1_R
MY2_R
MX3_R
MY3_R
MY4_R
MY5_R
MY6_R
MY7_R
MY8_R
MX4_R
MY9_R
MX5_R
MX6_R
MY10_R
MX7_R
MY11_R
MY12_R
MY13_R
MY14_R
MY15_R

U33

1

IO1

2

REF2

3 4

IO2 IO3

*DALC208SC6
U34

1

IO1

2

REF2

3 4

IO2 IO3

*DALC208SC6

HOLE29

1

HOLE32

1

HOLE30

SPAD-C256NP

HOLE33

SPAD-C197NP

1

HOLE5

H-C315D177PT

REF1

REF1

1

IO4

IO4

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

6
5

6
5

H-TW6-13

H-TW6-3

CON22

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

ACS(88502-2401)

MX2
MX3

HOLE31

SPAD-C256NP

1

HOLE28

1

HOLE26

H-TW6-11

B

http://hobi-elektronika.net

USBP4-(11)

USBP4+(11)

MB to USB BOARD

USB PORT0

USB PORT1

HOLE27

L25 0_8

3

4

2

1

LP6 *CMF-2012-0090I-S1

USBP0-(11)

USBP0+(11)

USBP1-(11)

USBP1+(11)

USBVCC2

USBVCC0

USBVCC1

C

D51

4 3

IO1 NC

5

IO1

6

VCC

Rclamp0502N

GND

2

NC

1

20
19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

USB_VCC2
USBP4-_L
USBP4+_L

+

C424

100U/6.3V_3528/ESR35

CON51

20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

USB_88706-2001(ACS)

D

TID number: no certified

CON24

1

GND

2

GND

3

GND
GND

C425
1000P_4

USBVCC1

C753

0.1U_4

USBVCC0

C755

0.1U_4

Polytronics:
DK260TPU409 (SMD1812P260TF) 2.6A
Tyco:
DK260TPU001 (miniSMDC260F) 2.6A

GND

AllTOP(C107xx-x0405-x)

U61

7

6

1

IN

OUT A

OUT B

ENA
ENB

FLAGA
FLAGB

GND

TI2062

Remove G546B2P1UF

4
5
6
7
8

5VSUS_USB1

2

1U/6.3V/X5R_4

3
4

8
5

C754

C421

0.1U_4

POLY SWITCH 2.6A

USBOC1#
USBOC0#

U32

6

OUT

7

OUT

8

OUT

9

GND

1

GND

G545B2P8U

F4

12

USBOC1# (11)
USBOC0# (11)

IN
IN

EN

OC

5VSUS_USBUSBVCC2USBVCC2

2
3

C422

4.7U/6.3V/X5R_6

4

5

5VSUS

E

POLY SWITCH 2.6A

F3

USBOC2# (11)

20

12

5VSUS

VCC5

1

HOLE6

H-TW6-1

1

HOLE12

H-TW6-8

1 1

1

HOLE17

H-TW6-14

1

1

HOLE7

H-TW6-2

1

HOLE13

H-C315D98P2

1

HOLE18

H-TW6-15

1

A

HOLE8

H-TW6-5

HOLE14

H-TW6-9

HOLE19

H-TW6-16

1

1

1

1

HOLE9

H-TW6-4

1

HOLE15

H-TW6-10

1
HOLE20

H-C236D165PB

1

1

HOLE10

H-TW6-6

1

HOLE16

H-TW6-12

1
HOLE21

H-C236D165PB

1

1

1

HOLE11

H-C315D102PB

1

HOLE22

H-C315D165PB

1
HOLE23

H-C315D165PB

1

HOLE24

H-C197D91PB

1

HOLE25

H-C197D91PB

B

1

1

HOLE36

H-C165D102PT

HOLE34

H-C165D91PT

1

1

H-C165D91PT

1 3

FAN5V_3

C457
10U/6.3V/X5R_6

R359
10K/F_4

Q30
PDTC144EU

FAN

FAN-SIG(17)

HOLE37

H-C165D102PT

C456 1U/6.3V/X5R_4

1

HOLE35

1

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

VCC5

VFAN(17)

U36

2 3

VIN Vout

1

VEN

4

VSET

G993/RT9027BPS

C

GND
GND
GND
GND

5
6
7
8

2

C458
1000P_4

R360
10K/F_4

CON25

1

23.

FAN-ACS(85205-0300L)
C459
1000P_4

D

4

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

KB/USB/FAN/Reset

TW6 Main Board

E

20 33Tuesday, September 01, 2009

of

1A

5

լՂٙ

լՂٙ

Ղٙ

ϡ

ϡ

ϡ

ϡ

ϡ

ຟլՂٙ

D D

VCC3

HDMI_CTRL_CLK
HDMI_CTRL_DATA

C C

PS8171 : ASQ internal pull low 500kohm

VCC3

R463 *B@4.7K/F_4
R464 *4.7K/F_4 R476 A@0_4

for PS8101
R463--> NC, R475-->0ohm

B B

R476-->0ohm , R464-->NC
for PS8171
R463
squelch

No automatic

ASQ1
ASQ0

R111 2.2K/F_4
R114 2.2K/F_4

R475 A@0_4

VCC3

R456 4.7K/F_4
R457 *4.7K/F_4

PS8101--->
C265,R467,R470,R471

PS8171
R470~R471~R457~R459 ~

PS8171 EMI

EMIO

L

H

EMI reduction and

EMI1

filter setting

L

ϡ

H
L

no EMI reduction

MIDLMID

PS8171 DDCBUF
PIN34 LEVEL

HIGH

DDCBUF

A A

MID
LOW

PC11PC0

0

0
0
10

1

1

(DDCBUF internal pull low 500kohm)

Description

Active DDC buffer enable;Setting 1
Active DDC buffer enable;Setting 2

No DDC active buffer,passive DDC level shifting

EQUALIZATION

8dB

ϡ

4dB

12dB
0dB

5

PS8171 EQ

PIN3

LEVEL

HIGH

PEQ

MID
LOW

PS8171 SWING

EQ

7dB

2dB

4dB

PRE internal pull low 500kohm

LEVEL

HIGH
MIDPRE
LOW

HDMI_HPD(9)

PEQ
DDCBUF
PRE

1.2dB

4

VCC3

R98
100K_4

R467 *B@4.7K/F_4
R471 *4.7K/F_4
R470 *4.7K/F_4R459 *4.7K/F_4

dBPIN35

2dB

0dB

4

http://hobi-elektronika.net

C644 10U/6.3V/X5R_6
C645 0.01U_4
C646 0.01U_4

C647 0.1U_4
C659 0.1U_4
C660 0.1U_4
C661 0.1U_4

HDMI_CLK(9)

HDMI_CLK#(9)

HDMI_DATA0(9)

HDMI_DATA0#(9)

HDMI_DATA1(9)

HDMI_DATA1#(9)

HDMI_DATA2(9)

HDMI_DATA2#(9)

HDMI_CTRL_DATA(9)

HDMI_CTRL_CLK(9)

R474 *0_4
C265 *B@2.2U/6.3V/Y5V_6
R460 499/F_4

R469 0_4

3

VCC3

21

15

2

U48

VCC4

VCC3

IN_D1+
IN_D1-

IN_D2+
IN_D2-

PS8101

IN_D3+
IN_D3-

PS8171

IN_D4+
IN_D4-

SDA_SRC
SCL_SRC

HPD_SRC/HPDX
PC_0/*PEQ

PC_1/*PIO
RT_EN#/CEXT
PC_2(REXT)

*OE#

GND3/*ASQ1

GND1/*ASQO

12

1

HDMI_LDATA2#
HDMI_LDATA1#HDMI_LDATA1

HDMI_LCLK#HDMI_LCLK

EMI0
EMI1

R473 *4.7K/F_4

VCC1

DDCBUFEN/*DDCBUFF

GND4

GND2

18

5

39
38

42
41

45
44

48
47

8
9

7

PEQ

3
4

10

OC2

6

OE#

25

ASQ0
ASQ1

HDMI_LDATA2

HDMI_LDATA0 HDMI_LDATA0#

for PS8171
EMI1 internal pull up 500kohm
EMI0 internal pull low
500kohm

VCC3

for PS8101 :
R461--> NC, R472-->0ohm
R462-->0ohm R473-->NC
for PS8171:

reduction

R705 *0_4
R706 *0_4
R707 *0_4
R708 *0_4

6/9 add
R705,R706,R707,R708
for EMI

R461 *4.7K/F_4 R472 A@0_4
R462 A@0_4

~ No EMI

26

VCC5

GND5

24

40

VCC7

GND7

31

46

36

VCC8

VCC2/**APD

*HPD_SINK

GND6/*EMI0

VCC6/*EMI1

GND9

GND8

37

A@: PS8101
B@: PS8171

PS8101

22

OUT_D1+

23

OUT_D1-

19

OUT_D2+

20

OUT_D2-

16

OUT_D3+

17

OUT_D3-

13

OUT_D4+

14

OUT_D4-

29

SDA_SINK

28

SCL_SINK

11
30
32

**DDC_EN

34
35

CFG/*PRE

27
33

GND10

EPD

* :Internal Pull down

43

49

** :Internal Pull
high

VCC5

HDMI_LCLK
HDMI_LCLK#

HDMI_LDATA0
HDMI_LDATA0#

HDMI_LDATA1
HDMI_LDATA1#

HDMI_LDATA2
HDMI_LDATA2#

HDMI_DDC_LDATA
HDMI_DDC_LCLK

R478 A@0_4/B@4.7K
HDMI_LHPD
R455 4.7K/F_4

DDCBUF
PRE

EMI0
EMI1

U58

5

IN

4

ON/OFF

MAX4785EXK-T

HDMI_DDC_LCLK
HDMI_DDC_LDATA

PS8171 HPDX

PIN4

PIO

R453 2.2K
R454 2.2K D43 CH411DPT

OUT
GND

FLAG

D52

2
1

*Rclamp0502N

LEVEL

NC
GND

L

2

VCC3

(100mA)

1
2
3

43

IO1NC

5

IO1

6

VCC

HPD_Sink = HPD

HPD=HPD_SINK#H

VCC3

5/13 change
to ESD

HDMI_DDC_LCLK
HDMI_DDC_LDATA

VCC5

HPDX Output

23

HDMI_LHPD

HDMI_LDATA2
HDMI_LDATA2#

HDMI_LDATA1
HDMI_LDATA1#

HDMI_LDATA0
HDMI_LDATA0#

HDMI_LCLK
HDMI_LCLK#

HDMI_DDC_LCLK
HDMI_DDC_LDATA

MB

PS8101PCH

PI3VDP411PCH

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

3

MB

HDMI Connector

Docking

DVI Connector

2

1

21

HDMI_LDATA2
HDMI_LDATA2#

VCC3

HDMI_LDATA1
HDMI_LDATA1# HDMI_LDATA1#

HDMI_LDATA0
HDMI_LDATA0# HDMI_LDATA0#

VCC3

HDMI_LCLK
HDMI_LCLK#

VCC5

VCC5_HDMI

D53

*UClamp0501P

PS8171 APD
PIN11 LEVEL

HIGH

APD

MID
LOW

PS8171 ASQ
PIN1

LEVEL

PIN12

HL
LL

ASQ[1,0]

LH
HH
ML
MH
LM
HM
MM

Title

Size Document Number Rev

Date: Sheet

U52

1

IO1

2

IO1

3

VCC

4

IO2

5 6

IO2 NC

*IP4280CZ10

U53

1

IO1

2

IO1

3

VCC

4

IO2

5 6

IO2 NC

*IP4280CZ10

GND

GND

NC
NC

NC

NC
NC

NC

HDMI_LDATA2

10

HDMI_LDATA2#

9
8

HDMI_LDATA1

7

HDMI_LDATA0

10
9
8

HDMI_LCLK

7

HDMI_LCLK#

6/5 Change HDMI connector

CON32

1

D2+

2

D2 Shield

3

D2-

4

D1+

5

D1 Shield

6

D1-

7

D0+

8

D0 Shield

9

D0-

10

CK+

11

CK Shield

12

CK-

13

CEC

14

NC

15

SCL

16

SDA

17

R466
15K

18
19

DDC GND
+5V
HPD

HDMI(ABA-HDMI-032-P02)

(55mA)

(ASQ internal pull low 500kohm)

Description

Automatic power down enable

Automatic power down disable

(ASQ internal pull low 500kohm)

Automatic Squelch
No automatic squelch

Level=100mVpp,default timer
Level=150mVpp,default timer
Level=200mVpp,default timer
Level=120mVpp,extended timer
Level=100mVpp,extended timer
Level=80mVpp,extended timer

Reserved
Reserved

QUANTA
COMPUTER

HDMI Conn/Level shift

TW6 Main Board

1

23

Shield4

22

Shield3

21

Shield2

20

Shield1

21 33Monday, August 31, 2009

of

1A

5

VCC_CORE

D D

6/26 add PR328 for Intel's DG

VCC1.05

PR328

PSI#(7)

68/F_4

C C

H_PROCHOT#(5)

THINKING

Throttling temp.
105 degree C

GND_62882

PR12

470K/NTC/THINKING_4

CPU_VID0(7)
CPU_VID1(7)
CPU_VID2(7)
CPU_VID3(7)
CPU_VID4(7)
CPU_VID5(7)
CPU_VID6(7)

VRON(17,18)

PM_DPRSLPVR(7)

VRM_CLKEN#(4)

090819 Elijah changed for DVT.

B B

PR26 2.8K/F_4

PC32

390P/50V/X7R_4

A A

5

PR34
562/F_4

CPU_IMON(7)

PR27
412K/F_4

10P/50V/COG_4

090819 Elijah changed for DVT.

1U/6.3V/X5R_4

PR10 0_4

PR13

4.42K/F_4

1 2

PC200.01U/25V/X7R_4

PR14 0_4
PR15 0_4
PR16 0_4
PR18 0_4
PR19 0_4
PR20 0_4
PR21 0_4
PR23 0_4

PR24 499/F_4

PR25 0_4

PC27

150P/50V/NPO_4

12

PC33

12

PR38 8.06K/F_4

PR37

*150K/F_4

GND_62882

PR41 0_4

PC34
1000P/50V/X7R_4

PC10

0.22U/25V/X5R_6

5VSUS

PR4
10_6

PC12

PR11147K/F_4

62882IMON

GND_62882

62882VDD

16

090819 Elijah changed for DVT.

GND_62882

62882PSI#

62882RBIAS

62882NTC

62882VID0
62882VID1
62882VID2
62882VID3
62882VID4
62882VID5

62882VID6
62882VR_ON
62882DPRSLPVR

62882CLKEN#

31
32
33
34
35
36
37
38
39

40

62882FB

62882FB2

PC28
22P/50V/NPO_4

62882COMP

62882VW

18

10K/F_4

PR42

1 2

PC37 0.22U/10V/X5R_4

2

3
4
5

8

9

7

6

4

VIN_62882

PR1

2.2/F_6

62882VIN
17

PU1

VIN

VDD

ISL62882HRZ-TR5390

PSI#

RBIAS
VR_TT#
NTC

VID0
VID1
VID2
VID3
VID4
VID5
VID6
VR_ON
DPRSLPVR

CLK_EN#

FB

FB2

COMP

VW

IMON

1000P/50V/X7R_4

RTN

13

PC38

330P/50V/X7R_4

GND_62882

PC39

GND_62882

4

VSEN

12

12

1 2

1 2

VCC3

1

PGOOD

UGATE1

BOOT1

PHASE1
LGATE1a
LGATE1b

ISEN1

VSSP1

VCCP

UGATE2

BOOT2

PHASE2

LGATE2

ISEN2

VSSP2

ISUM+

ISUM-

VSS(Bottom GND Pad)

41

GND_62882

PC40

330P/50V/X7R_4

PR2

1.91K/F_4

VR_PWRGOOD (17)

62882_UG1

20

62882BOOT1

19

62882_PH1

21

62882_LG1A

23

62882_LG1B

24

62882ISEN1

11
22
25

PC21 4.7U/6.3V/X5R_6

1 2

62882_UG2

29

62882BOOT2

30

62882_PH2

28

62882_LG2

26

62882ISEN2

10

27

62882ISUM+

15

12

PC31

14

62882ISUM-

1200P/50V/X7R_4

62882VSEN

62882RTN

3

http://hobi-elektronika.net

PR199
10K/F_4

PQ2
NTMFS4935

1.1

62882ISUM+

1 2

PR7 2.2_6

PR17 2.2_6

PR28

82.5/F_4

0.01U/25V/X7R_4

PR35 931/F_4

PC36

0.22U/25V/X5R_6

5VSUS

1 2

12

PC30

PC29

2700P/50V/X7R_4

PR40
100/F_4

PR44 0_4

PC13

0.22U/10V/X5R_4

PC22

0.22U/25V/X5R_6

0.22U/10V/X5R_4

12

0.33U/6.3V/X5R_4

0.1U/10V/X5R_4

PR30
11K/F_4

ISUM-

PC35

PC19

PC25

GND_62882

62882ISEN2

12

PR195
10K/F_4

12

PR29

2.61K/F_4

PR32
10K/NTC/THINKING_6

THINKING

12

62882ISUM+

62882ISEN1

Close to Phase 1 Inductor

VCCSENSE (7)

G

4

G

4

PR5 3.65K/F_4

PR6 10K/F_4

PR8 1/F_4

PR9 10K/F_4

G

4

G

4

PQ5

NTMFS4935

1.1

PR36 1/F_4

PR39 10K/F_4

1.9

5

PC5

D

S

PQ1

213

NTMFS4921

1.1

5

D

4

S

213

5

D

PQ4
NTMFS4921

S

1.1

213

5

D

4

S

213

PR31 3.65K/F_4

PR33 10K/F_4

10U/25V/X6S/1206

G

1.9

G

Place R56 and R59 approaching CPU for test.

Parallel

VSSSENSE (7)

3

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

GND_62882

PR45 0_4

PR43 short

{PART NUMBER}

5

213

PC16

5

213

PQ6
NTMFS4935

1.1

1.9

PC197

D

S

PQ3
NTMFS4935

1.1

10U/25V/X6S/1206

D

S

1.9

10U/25V/X6S/1206

PR3

2.2_8

PC11

1000P/50V/X7R_4

1.9

PC214

PR22

2.2_8

PC26
1000P/50V/X7R_4

PC213

10U/25V/X6S/1206

10U/25V/X6S/1206

PC17

0.1U/25V/X7R_6

SENSE2_P

SENSE2_N

0.1U/25V/X7R_6

SENSE1_P

SENSE1_N

PC7

PC6

4

PL3

0.36UH-ETQP4LR36AFC-28A
1 2

3

4

PC18

2200P/50V/X7R_4

4

PL4

0.36UH-ETQP4LR36AFC-28A
1 2

3

4

2

8

+

PC1

2200P/50V/X7R_4

100U/35V/6.6*6.6

2

8

100U/35V/6.6*6.6

+

PC2

12

+

PC8

*470U/2V/7343/ESR=4.5

2

VIN_62882

PC245

0.1U/25V/X7R_6

12

+

470U/2V/7343/ESR=4.5

2

+

PC3

100U/35V/6.6*6.6

8

*470U/2V/7343/ESR=4.5
2

PC23

VIN_62882

8

100U/35V/6.6*6.6

+

PC4

VCC_CORE

12

+

PC9

12

+

PC24

470U/2V/7343/ESR=4.5

2

PL1 22/6A

PL2 22/6A

1

PC244

0.1U/25V/X7R_6

48A

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

Power VCC_CORE

TW6 Main Board

1

22

VIN

22 33Monday, August 31, 2009

2A

of

5

3.3V/5V/VEDS

PL5 22/6A

VIN

PL6 22/6A

D D

090819 Elijah changed for DVT.

0.9

PQ10

3A

VCC5

PR58 0_4

MAIND

1 2

C C

2A

5VSUS

PR73 0_4

SUSD

1 2

AON7406

3
2
1

PQ13

AON7406

3
2
1

4

5A

5VPCU

5

4

PC61

*1000P/50V/X7R_4

0.9

5

PC66

1000P/50V/X7R_4

PC54

330U/6.3V/7343/ESR=25

090819 Elijah changed for DVT.

090819 Elijah changed for DVT.

Reset Cricuit

180K/F_4

24K/F_4

PR202

PR203

VIN

1000P/50V/X7R_4

B B

A A

090819 Elijah changed for DVT.

MAING(24)

MAINON

MAINON(16,17,25,27,28)

2

PQ22

DTC144EUEUA-7-F

5

PC15

PC100
1000P/50V/X7R_4

VIN

1 3

G682L09TT12U

4

PR102
1M_4

PR114
1M_4

CD

VSEN

2

PQ23
2N7002E-T1-E3

RESET

3

1

GND

VCC

PU11

PR103
22_6

PC246

0.1U/25V/X7R_6

PR60

+

*0_4

PC60

PR65

10U/6.3V/X5R_8

0_4

6686GND

1 2

1 2

090819 Elijah changed for DVT.

PR251
10K/F_4

15

2

3

3

2

PQ24
2N7002E-T1-E3

1

SW1010CPT

PC101
1U/6.3V/X5R_4

PR104
22_6

PD1

2

PQ25

2N7002E-T1-E3

6686LDO

21

VCC1.5VCC3VCC5 VCC1.8 15VPCU

PR105
22_6

3

2

PQ26
2N7002E-T1-E3

1

4

6686VIN

PC41

10U/25V/X6S/1206

1.9

3
PL7

3.3UH-PCMC063T3R3MN-6A
1 2

PR57
*2.2_8

PC62

*1000P/50V/X7R_4

5V_RESET#(17)

SHDN#(5)

5V_RESET# (17)

SUSON(17,19,24)

DTC144EUEUA-7-F

VCC1.05 VTT_MEM

PR106

PR107

22_6

22_6

3

3

2

PQ27
2N7002E-T1-E3

1

1

4

http://hobi-elektronika.net

PC44

PC43

0.1U/25V/X7R_6

PQ7
AON7406

5

0.9

4

213

5

213

1 2

100K/F_4

PR74 0_4

090819 Elijah changed for DVT.

2

PQ17

PR110
22_6

MAING
3

2

PQ30
2N7002E-T1-E3

1

090819 Elijah changed for DVT.

PR50
10K/F_4

4

PQ11

AON7702

0.9

PR70

0.047U/10V/X7R_4

12

0.1U/25V/X7R_6

15VPCU

0.1U/25V/X7R_6

VIN

PR86
1M_4

SUSG

2

PQ18

PR94

2N7002E-T1-E3

1M_4

1 3

PR111
1M_4

3

2

PQ31
2N7002E-T1-E3

1

PD3
PDZ3.3B

2 1

PR46
174K/F_4

2200P/50V/X7R_4

PR48

90.9K/F_4

6686GND

090828 Elijah changed for DVT.

MAIND

PR54
140K/F_4

1 2

6686GND

PC63

0.22U/25V/X5R_6

PC107

PC69

PC71

5VSUS 3VSUS 1.5VSUS 15VPCU

3

1

PC78
*0.01U/50V/X7R_6

4.7U/6.3V/X5R_6

6686GND

1

PD4

2
BAT54SPT

1

1 2

PD5

2
BAT54SPT

1 2

PR87

PR88

22_6

22_6

3

2

2

PQ19

PQ20

2N7002E-T1-E3

2N7002E-T1-E3

1

MAIND (24)

RVCC_ON(13,17) GFX_VR_EN(7,26)

PC50

*1U/6.3V/X5R_4

6686FB1

6686ILIM1

6686PG1
6686EN1
6686HGT1
6686PH1

PR67
1_6

1 2

6686LDO

PC65

3

1

PC45

PC51

9
10
11
12
13
14
15
16
37
36

6686GND

6686BOT1
6686LGT1

12

PC67

0.1U/25V/X7R_6
3

3

PC70

0.1U/25V/X7R_6

PR89
22_6

2

PQ21
2N7002E-T1-E3

2

PQ32
DTC144EUEUA-7-F

3

6686LDO

12

4.7U/6.3V/X5R_6

1 2

1U/25V/X7R_8

8

LDO_SW
OUT1
FB1
ILIM1
PG1
EN1
HGATE1
PHASE1
PAD
PAD

PAD

PAD

PAD

17181920212223

333435

PR68
*0_4

12

12

PR90
1M_4

3

1

1 3

3

6686VIN

6686ENLDO

6686VRF3

6686LDO

VIN

LDO

VREF3

LDOREFIN

PU2

PM6686TR

1

BOOT1

LGATE1

PVCC

CP_FB

6686CPFB

6686GND

SUSD

PC72
*0.01U/50V/X7R_6

VIN

PR112
1M_4

RVCCG

PR115
1M_4

2

6686VCC

PC46

1 2

1U/6.3V/X5R_4

PR47
*0_4

PR49
0_4

1 2

12

0.1U/10V/X5R_4

PC52

6686VRF2

6686TON

6686VCC

1234567

TON

VCC

VREF2

EN_LDO

GND

32

REFIN2

31

ILIM2

30

OUT2

29

SKIP

28

PG2

27

EN2

26

HGATE2

25

PHASE2

PGND

LGATE2

BOOT2

24

0.22U/25V/X5R_6

6686BOT2

1 2

PR69 1_6

6686LGT2

PR71 short

{PART NUMBER}

6686GND

RVCC3

PR113
22_6

31

2

PQ33
2N7002E-T1-E3

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

PR51

*10K/F_4

6686REFI2

6686ILIM2
6686OUT2
6686SKIP
6686PG2
6686EN2
6686HGT2
6686PH2

PC64

6686GND

PR55 200K/F_4
1 2

12
PR66

PR61

0_4

*0_4

6686VRF2

PR77

24.9K/F_4

PR82470K/NTC/THINKING_4

PC74 0.1U/10V/X5R_4

6686VCC

PR53

12

10K/F_4
PR52
0_4

6686GND

12

12

PR62

*0_4

6686GND

RVCC_ON

6686PG2

6686PG1

For VCC1.5

PC75 0.1U/10V/X5R_4

5

4

213

5

4

213

12

PR160 0_4

12

PR95 0_4

PR78

24.9K/F_4

PR84470K/NTC/THINKING_4

PC73 0.1U/10V/X5R_4

For 5VSUS & VCC5

PR96 0_4

PC47

0.1U/25V/X7R_6

0.9

PQ8

AON7406

2.2UH-PCMC063T2R2MN-8A
1 2

PR59

2.2_8

PC55

1000P/50V/X7R_4

0.9

PQ12
AON7700

RVCC3

12

PR72
100K/F_4

PR79

24.9K/F_4

PR97470K/NTC/THINKING_4

PC76 0.1U/10V/X5R_4

For 3VSUS & VCC3

2

12

PQ15

DTC144EUEUA-7-F

2

PC48

PC49

2200P/50V/X7R_4

1.9

3
PL8

1 2

1 2

6686GND

Dibohf!op.npvou!u
npvou

6252VREF

PR80

24.9K/F_4

PR99470K/NTC/THINKING_4

For VCC1.8

PC77 0.1U/10V/X5R_4

VIN +VCC_GFXCORE

PR92
1M_4

PR83
1M_4

1 3

PC42

10U/25V/X6S/1206

1.9

PR56
0_4

PR64
*0_4

PM_SYS_PWRGD (17)

PR81

49.9K/F_4

PR85
36K/F_4

3

2

1

10U/25V/X6S/1206

PC56

1U/6.3V/X5R_4

5
4

7
6

9
8

11
10

PR93
22_6

PQ16

2N7002E-T1-E3

1

0.9

8A

PQ9

RVCC3

AON7406

5

4

+

PC57

330U/6.3V/7343/ESR=25

p

Thermal Protection for VEDS

VCC3

PU3

1+

O1

2

O1

1-

2+

O2

1

O2

2-

LM339APWR

3+

O3

14

O3

3-

4+

O4

13

O4

4-

V- V+

12 3

Title

Size Document Number Rev

Date: Sheet

PR75
*10K_4

PR91 0_4

12

PR98 0_4

12

PR100 0_4

12

PR101 0_4

12

QUANTA
COMPUTER

Power 3.3V/5V/VEDS

TW6 Main Board

PC59

*1000P/50V/X7R_4

0.9

PQ14
AON7406

5

4

PC68

1000P/50V/X7R_4

LS_PGOOD (17,27)

1

3
2
1

PR63 0_4

3
2
1

PR76 0_4

1 2

23 33Monday, August 31, 2009

3A

VCC3

3A

3VSUS

SUSD

of

23

MAIND

2A

5

1.5VSUS/VTT_MEM/VCC1.5

1.2A

1.5VSUS

E E

1.2A

VTT_MEM

PR214 *0_4

SMVREF_GMCH(14)

D D

PR122

PR128

*0_4

0_4

51116GND

PC85
10U/6.3V/X5R_8

1.4

(D-CAP mode)

PC88

0.033U/10V/X7R_4

PR126 49.9K/F_4

5VPCU

50 mil

50 mil

PC83
10U/6.3V/X5R_8

1.4

PR125 0_4

PR127

49.9K/F_4

51116GND

PC80
10U/6.3V/X5R_8

1.4

51116MODE
51116VTTREF
51116COMP

51116VDDQSET

PR118 short

{PART NUMBER}

51116GND

PR121
*0_4

5VPCU

10

1
2
3
4
5
6
7
8
9

1
PU4
TPS51116

VLDOIN
VTT
VTTGND
VTTSNS
GND
MODE
VTTREF
COMP
VDDQSNS
VDDQSET

GND

GND

21222324252627

51116GND

4

GND

GND

GND

51116GND

20

VBST

19

DRVH

18

LL

17

DRVL

16

PGND

15

CS

14

V5IN

13

PGOOD

12

S5

11

S3

GND

GND

PC192

*0.1U/10V/X5R_4

PQ34

2N7002E-T1-E3

http://hobi-elektronika.net

PR117
1_6

51116BST

1 2
51116DH
51116LL
51116DL

51116CS

PR124 5.62K/F_4

51116PGD
51116S5

VCC1.5_CPU_VCC105_PWRGD

3

1

PC94
*0.1U/10V/X5R_4

51116GND

2

090819 Elijah changed for DVT.

PC90

0.22U/25V/X5R_6

10uA

12

PC92

4.7U/6.3V/X5R_6

51116GND

PR129 0_4

PR119 0_4

5VPCU

PR123
10K/F_4

4

PR181
*10K_4

MAING (23)

G

4

G

3

5

D

PQ35
NTMFS4921

S

1.1

213

5

D

S

213

PQ36
NTMFS4935

1.1

DDR_PWRGD (17)

3VSUS

SUSON (17,19,23)

2

VIN_51116

PC87
10U/25V/X6S/1206

1.9

PR116

2.2_8

PC161
1000P/50V/X7R_4

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

PC81
10U/25V/X6S/1206

1.9

4
PL10

1UH-PCMC104T1R0MN-18A

PC79
10U/25V/X6S/1206

1.9

0.1U/25V/X7R_6

PC84

PC82

12

+

PC162

6.1

*390U/2.5V/6.3X6/ESR=10/SVPE

PL9 22/6A

2200P/50V/X7R_4

12

+

390U/2.5V/6.3X6/ESR=10/SVPE

PC91

10U/6.3V/X5R_8

6.1

1.4

PC163

PC247

0.1U/25V/X7R_6

1

VIN

11.88A

1.5VSUS

24

C C

RVCC3

090819 Elijah changed for DVT.

090830 Elijah changed PU12 footprint.

PU12

1

PR254 133K/F_4

VCC1.05

PC103

B B

VCC1.5

1.75
PQ37
AO4468

8
7

5

A A

4

PC212

2200P/50V/X7R_4

5

1.6A

VCC1.51.5VSUS

1
2
36

PR280 820K/F_4

1 2

2 1

PD2 RB501V-40

090819 Elijah changed for DVT.

0.01U/16V/X7R_4

MAIND (23)

2
3 4

PR255
100K/F_4

OUTA
GND
+INA +INB

LT6700-3

Vref=400mV

4

6

OUTB

5

Vs

0.01U/16V/X7R_4

240 mils

VCC1.5_CPU_VCC105_PWRGD

PR256
1K/F_4

PC106

PR257
*0_4

PC105

*0.001/7520/2%/2W
PQ38

NTMFS4935

5

0.1U/10V/X7R_4

PR261 237K/F_4

PR258
100K/F_4

PR120

12

THE CIRCUIT NOT CHECK P/N

3

D

S

2
1

G

4

PR130 100K/F_4

PC93

2200P_4

240 mils

1 2

090819 Elijah changed for DVT.

VCC1.5_CPU_VCC105_PWRGD (5)

RVCC3
VCC1.5_CPU

VCC1.5_CPU

VCC1.5_CPU1.5VSUS

5.0A

MAIND (23)

2

MAING(23)

3

PR253
220_6

3

1

PQ41
2N7002E-T1-E3

VCC1.05

6252VREF

PR263
133K/F_4

PC108

0.01U/16V/X7R_4

PR265 100K/F_4

MAING

MAIND(MAINON)

VCC1.5_CPU

VTT_MEM

PR264
100K/F_4

PR266
20K/F_4

4232VREF

PU12 has no P/N.

PU12 has no P/N.

4232VREF
Max=0.409V

Typ=0.398V
Min=0.388V

0.01U/16V/X7R_4

2

PC110

84

3

+

1

2

-

PU17A
LM393APWR

PU17B
LM393APWR

-

6

7

+

5

RVCC3

PC109

0.1U/10V/X7R_4

PR267
1K/F_4

PR268
0_4

PR271 237K/F_4

PR270
100K/F_4

Title

Size Document Number Rev

Date: Sheet

RVCC3

VCC1.5_CPU_VCC105_PWRGD (5)

VCC1.5_CPU

QUANTA
COMPUTER

Power 1.5VSUS/VTT_MEM/VCC1.5

TW6 Main Board

1

24 33Monday, August 31, 2009

2A

of

5

VCC1.05

D D

4

http://hobi-elektronika.net

3

2

1

25

PC216

10U/25V/X6S/1206

5VSUS

PR144

2

4

3

13
14
15

17

GNDA

VIN

PGD

ON/SKIP
VSET

VREF
TSET

8111GND

PR159 short

8111GND

22_6

8111VDDA

16

VDDA

PU7

OZ8111LN

0.8

GNDA

1

{PART NUMBER}

VCC3

C C

8743_PWRGD(17,27)

MAINON(16,17,23,27,28)

PC140

1000P/50V/X7R_4

B B

PR183
*10K_4

PR153

150K/F_4

PR158

93.1K/F_4

8111GND

PC125 0.01U/25V/X7R_4

PR148 0_4
PR149 10K/F_4

R1

R2

PR260
0_4

8111GND

8111GND

090828 Elijah added PR260 for DVT function.

Vout=2.75*(R2/(R1+R2))

PR145
15K/F_4

PC127 0.1U/10V/X5R_4

PR152

63.4K/F_4

PC134

0.1U/10V/X5R_4

PR156

120K/F_4

PC123

1U/6.3V/X5R_4

8111GND

8111VIN

8111PGD

8111ON-SKIP

8111VSET
8111VREF
8111TSET 8111CSN

PC138
1000P/50V/X7R_4

8111GND8111GND8111GND

56

BST

VDDPGNDP

HDR

LX

LDR

CSP
CSN

PC135

1000P/50V/X7R_4

PC124
1U/6.3V/X5R_4

8111BST

8

8111HDR

9

8111LX

10

8111LDR

7

11
12

8111CSP

8111GND

PR146

1.5_6

0.22U/25V/X5R_6

PC136
22P/50V/NPO_4

PC126

PD7
RB501V-40

PR147
10K/F_4

PQ40

NTMFS4935

1.1

5

D

G

4

S

213

5

D

G

4

S

213

PQ39
NTMFS4921

1.1

PC119
10U/25V/X6S/1206

1.9

G

4

5

213

D

S

PQ62
NTMFS4935

1.1

PC120
10U/25V/X6S/1206

1.9

PR150

2.2_8

PC133
1000P/50V/X7R_4

1.9

0.1U/25V/X7R_6

0.36UH-ETQP4LR36AFC-28A

PR155

100K/F_4

VIN8111

PC122

PC121

4
PL12

1 2

3

PR151 *100K/F_4

PC137

3300P/50V/X7R_4

PC139

2200P/50V/X7R_4

2200P/50V/X7R_4

4

090819 Elijah changed for DVT.

8111GND

PL11 22/6A

PR154

51.1/F_4

PR157

3.57K/F_4

VIN

PC248

0.1U/25V/X7R_6

PC130

390U/2.5V/6.3X6/ESR=10/SVPE

PC132

1.4

10U/6.3V/X5R_8

12

PC131

390U/2.5V/6.3X6/ESR=10/SVPE

12

+

PC104

6.1
390U/2.5V/6.3X6/ESR=10/SVPE

+

6.1

24.86A

12

+

6.1

VCC1.05

A A

QUANTA

Title

1.Level 1 Environment-related Substances Should NEVER be Used.

5

4

3

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

2

Size Document Number Rev

Date: Sheet

COMPUTER

Power VCC1.05

TW6 Main Board

1

25 33Monday, August 31, 2009

2A

of

A

VCC_GFXCORE

B

C

http://hobi-elektronika.net

D

E

F

G

H

26

17028VCC

PC141

1 1

GFX_VR_EN(7,23)

GFX_DPRSLPVR(7)

GFX_VID0(7)
GFX_VID1(7)
GFX_VID2(7)
GFX_VID3(7)
GFX_VID4(7)
GFX_VID5(7)
GFX_VID6(7)

PR179

2 2

EXT_INT_VGA_PWRGD(17)

VCC3

1.91K/F_4

PR185 0_4

GFX_VRHOT(5)

Throttling temp.
105 degree C

GFXVR_IMON(7)

0.1U/10V/X5R_4

VSS_AXG_SENSE

17028VCC

17028_GND

PC158

17028_GND

17028VCC

*0.01U/25V/X7R_4

PR163 0_4

PR168 0_4

PR169 0_4

PR171 0_4
PR164 0_4
PR165 0_4
PR173 0_4
PR167 0_4
PR174 0_4
PR175 0_4

17028_GND

64.9K/F_4
PR177

17028_GND

VCC3

PR186 36K/F_4

*470K/NTC/THINKING_4

PR188

12

17028SHDN#

17028SL-SK

17028PGDIN

17028_VID0
17028_VID1
17028_VID2
17028_VID3
17028_VID4
17028_VID5
17028_VID6

17028ILIM

6.04K/F_4
PR178

PR180 0_4

PR330 *10K/F_4
PR329 *0_4

THINKING

PR189100/F_4

PR190

9.09K/F_4

17028TIME

17028V3P3

17028THRM

17028THRM

17028IMON

11

SHDN

6

SLOW

7

SKIP

27

PGDIN

14

D0

15

D1

16

D2

17

D3

18

D4

0.8

19

D5

MAX17028

20

D6

30

ILIM

29

TIME

13

V3P3

10

PWRGD

12

CLKEN

28

VRHOT

8

THRM

1

IMON

17028_GND

31

VCC

23

VDD

17028TON

9

TON

17028DH

26

DH

17028BST

24

BST

PU8

17028LX

25

LX

17028DL

22

DL

21

PGND

17028CSP

5

CSP

17028CSN

4

CSN

17028FB

3

FB

17028GNDS

2

GNDS

17028CCV

32

CCV

EP

33

PC142
1U/6.3V/X5R_4

PR170

200K/F_4

PR166

1_6

17028_GND

PC143

4.7U/6.3V/X5R_6

1 2

Fsw=300KHz

PC148

0.22U/25V/X5R_6

17028VCC

1 2

090819 Elijah changed for DVT.

PR187

16.5K/F_4

PC159
100P/50V/X7R_4

17028_GND

PR162

10_6

5VSUS

PC156
1000P/50V/X7R_4

17028_GND

PC160
1000P/50V/X7R_4

17028_GND

PR172
10K/F_4

4

4

G

G

PQ43

NTMFS4935

1.1

PC154

VINVIN_17028

PC249

0.1U/25V/X7R_6

22A

+VCC_GFXCORE

10U/6.3V/X5R_8

PL13 22/6A

5

PQ42

D

NTMFS4921

1.1

S

213

5

D

S

213

4

G

PQ29

NTMFS4935

1.1

5

D

S

213

PC14
10U/25V/X6S/1206

1.9

PR176

2.2_8

PC149

1000P/50V/X7R_4

0.36UH-ETQP4LR36AFC-28A

17028CSP-1

PR221

2.61K/F_4

PC144
10U/25V/X6S/1206

1.9

4
PL14

1 2

3

PR228

4.53K/F_4

PC155

*0.15U/10V/X5R_4

PC157

0.22U/10V/X5R_4

PC145
10U/25V/X6S/1206

1.9

4

PR182
*10K/F_4

PR184
10K/NTC/THINKING_6

THINKING

PC102

390U/2.5V/6.3X6/ESR=10/SVPE

+

6.1

12

PC146

0.1U/25V/X7R_6

12

+

PC153

390U/2.5V/6.3X6/ESR=10/SVPE

6.1

PC147

2200P/50V/X7R_4

+VCC_GFXCORE

12

+

PC150

390U/2.5V/6.3X6/ESR=10/SVPE

6.1

3 3

PR191 short

17028_GND

PR193 10/F_4

PR192 10/F_4

PR194 0_4

VCC_AXG_SENSE (7)

Place the PR192 and PR196 approaching the CPU for test.

Parallel

PR197 10/F_4

4 4

A

B

C

D

PR196 10/F_4

PR198 0_4

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

E

VSS_AXG_SENSE (7)

Title

Size Document Number Rev

F

Date: Sheet

G

QUANTA
COMPUTER

Power VCC_GFXCORE

TW6 Main Board

26 33Monday, August 31, 2009

H

2A

of

5

VCC1.8/VEDS

D D

VCC3

4

http://hobi-elektronika.net

PQ69

1.75

AO4468

8
7

5

4

PQ65

1.75

AO4468

8
7

5

4

3

2

1

27

1
2
36

1
2
36

VCC3

PR201
*10K_4

C C

8743_PWRGD(17,25)

MAINON(16,17,23,25,28)

PR281 0_4

PR252 0_4

PC220

0.1U/10V/X5R_4

PC225

0.1U/10V/X5R_4

5VSUS

PC218
10U/6.3V/X5R_6

8858POK

8858EN

PC217

0.1U/10V/X5R_4

090830 Elijah changed PC221 to 1000P.

PR282
*0_4

PU13

3

4

1

8858DRV

6

POK

DRV

EN

8858FB

5

FB

VCC

GND

2

APE8858Y

PC222

*0.022U/16V/X7R_4

1 2

R1

R2

PR262

26.1K/F_4

PR283
10K/F_4

PC221

1000P/16V/X7R_4

PC223

1.05

PC224

PC226

10U/6.3V/X5R_6

10U/6.3V/X5R_6

*10U/6.3V/X5R_6

1.05

1.05

1A

VCC1.8

Vout1 = (1+R1/R2)*0.5

PC96 0.1U/10V/X5R_4

6252VREF

PR134

24.9K/F_4

PR142470K/NTC/THINKING_4

PC98 0.1U/10V/X5R_4

For VCC_CORE

PR136

49.9K/F_4

PR138
36K/F_4

B B

PR137

24.9K/F_4

PR141470K/NTC/THINKING_4

PR132
36K/F_4

PR133470K/NTC/THINKING_4

PR139

24.9K/F_4

PR109470K/NTC/THINKING_4

For PU4

+VCC_GFXCORE

PC97 0.1U/10V/X5R_4

A A

PC99 0.1U/10V/X5R_4

For VCC1.05

PC95 0.1U/10V/X5R_4

Thermal Protection for VEDS

11
10

5
4

7
6

9
8

VCC3

PU5

1+
1-

2+
2-

LM339APWR

3+
3-

4+
4-

V- V+

12 3

PR200

*10K_4

PR108 0_4

O1

2

O1

PR135 0_4

O2

1

O2

PR140 0_4

O3

14

O3

PR131 0_4

O4

13

O4

12

12

12

12

LS_PGOOD (17,23)

QUANTA

Title

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from

5

4

3

the business Partners that Sony approves as Green Partners.

2

Size Document Number Rev

Date: Sheet

COMPUTER

Power VCC1.8/VEDS

TW6 Main Board

1

27 33Monday, August 31, 2009

2A

of

5

Charger

PD8

2

VA

D D

VIN

MAINON(16,17,23,25,27)

VA+

UVP Setting

C C

INT-Current limit 3.46A (75W
adapter / 67.5Watt.)

B B

PC173

0.01U/25V/X7R_4

6252VREF

PR217

24.9K/F_4

6252ACLIM

PR222

866/F_4

6252A 6252A

6252A

CHGEN#(17)

PR207

46.4K/B_4

PR212

3.6K/B_4

24.9K/F_4

16.9K/F_4

1 6

PQ45A

PIMD2/IMD2AT108

5

6252A

PR218

Cell=4.16V, Vchg=12.48V

PR223

6252A

3VPCU

PR229
220K_4

2

PQ49

2N7002E-T1-E3

Charging Current Setting

1. I_SET=3.30V, VCHLIM=1.51V, Charge Current=1.5A

2. I_SET=1.76V, VCHLIM=0.81V, Charge Current=0.8A

3. I_SET=0.66V, VCHLIM=0.30V, Charge Current=0.3A

4. I_SET=0V, VCHLIM=0V, Charge Current=0A

A A

5

1

PDS1040

1.15

PQ45B
PIMD2/IMD2AT108

2

4 3

0.01U/16V/X7R_4

6252A

I_SET(17)

3

1

6252A

3

PD9

RB501V-40

PC168

0.1U/25V/X7R_6

PC175

PR213
10K/F_4

PC167*100P/50V/X7R_4
PC178

0.015U/16V/X7R_4
PR215 0_4

PR226

232K/F_4

PR230

200K/F_4

6252A 6252A

PC241

0.1U/25V/X7R_6

VA

21

6252VREF

21

6252DCIN

6252ACSET
6252ACPRN

6252VCOMP

6252ICOMP

6252ACLIM

6252VADJ

PR227
*174K/F_4

6252CHLIM

PR231
*150K/F_4

PD10

RB501V-40

6252CELL

6252VREF

4

PR321

0.015/7520/2%/2W
12

1P2P

PR205

24

23

10

11

4

0_4

2

6

5

4

8

9

PR204
20/F_4

PC166

0.1U/25V/X7R_6

6252CSIP

DCIN

ACSET
ACPRN

VCOMP

ICOMP

CELLS

VREF

ACLIM

VADJ

CHLIM

6252A

6252CSIN

20

19

17

UGATE

CSIP

CSIN

14

LGATE

18

PHASE

16

BOOT

15

VDDP

1

VDD

21

CSOP

22

CSON

3

EN

7

ICM

GND

PGND

PU9

12

13

ISL6252AHAZ-T

1.75

6252A 6252A

{PART NUMBER}

PR232
short

3

http://hobi-elektronika.net

BATDIS

VIN

PL15 22/6A

PC243

6252PHASE

PC164

0.1U/25V/X7R_6

3
PL16

15UH-MSCDRI-0735AB-150M-2.0A

PR211

2.2_8

PC174
1000P/50V/X7R_4

6252ACPRN

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

VA

2

PQ51

2N7002E-T1-E3

PR209

2.2/F_4

PR233
470K_4

PR235
160K_4

3

1

PC242

0.1U/25V/X7R_6

6252PHASE

PR206
10K/F_4

6252UGATE

6252LGATE

6252PHASE

PC176

4.7U/6.3V/X5R_6

PC179

PC180

1U/6.3V/X5R_4

PR224
100_4

0.1U/25V/X7R_6

6252A

PC182

0.1U/10V/X5R_4

PR324 3.3_6

6252BOOT

6252VDDP

6252VDD

6252CSOP

6252CSON

PR220 0_4

6252EN 6252VDD

6252ICM

3

RB501V-40

21

PR216 4.7_6

ISENS_IN (17)

10U/25V/X6S/1206

1.9

2481

PQ47
AO4932

1.75

7
6
5

PD11

3

PR208

0.05/0805/1%/0.33W

PC177

1U/6.3V/X5R_4

UVP

PR234
47K_4

PC183

0.47U/25V/X7R_8

4 3

PR210
0_4

2

PQ50

2N7002E-T1-E3

VA+

090819 Elijah changed for DVT.

PR236
330K/F_4

PR237
100K/F_4

2

PR325

33K_4

1

PQ46

AOD403

2.388

10U/25V/X6S/1206

1.9

3

1

PC184

0.01U/25V/X7R_4

2

PC169

PR323

10K/F_4

PC170

10U/25V/X6S/1206

1.9

PR225

40.2K/F_4

-VAOFF (29)

PQ70

2N7002E-T1-E3

1 3

BAT+

2

PQ44
2N7002E-T1-E3

0.1U/25V/X7R_6

PR219
200K/F_4

PR326
330K/F_4

3

1

2

PC165

0.1U/10V/X5R_4

PC171

MBATV (17)

PC181

0.01U/25V/X7R_4

2N7002E-T1-E3

1

PR322

DC/-C (17,29)

10K/F_4

BAT+

PC172

10U/25V/X6S/1206

1.9

3VPCU

PR327
10K/F_4

3

2

PQ71

1

Title

Size Document Number Rev

Date: Sheet

ACIN (17)

QUANTA
COMPUTER

Power Charger
TW6 Main Board

1

28 33Monday, August 31, 2009

of

28

2A

A

Ada in/BAT in/UL

PL21
22/6A

1 2

ACES 20346-0401

PCN1

4 4

1

1

2

2

3

3

4

4

VAIN-

Added PC250 for EMI.

3 3

VAIN+

PC250

0.1U/50V/X7R_6

PL17
22/6A

1 2

0.1U/50V/X7R_6

PL22
22/6A

1 2

PL18
22/6A

1 2

-VAOFF(28)

DC/-C(17,28)

PC185

Separate adapter OVP from UL circuit

PR298
162K/D_4

0.6
PU15 BD4141HFV

4

IN

PC237

1U/6.3V/X5R_4

2 2

BAT+

PD49

2 1

1 1

MMPZ5251BPT (22V+-5%)

BAT_DATA(17) BAT_CLK (17)

PR300

5 1

DLY PGOOD

3.6K/B_4

1 2

IN > 0.5V, PGOOD=Open

090828 Elijah changed PU15 footprint.

BATT_ID(18)

PC219

47P/50V/NPO_4

A

2 1

PR289
22_4

PD47

UDZ5V6B

PR242
220K_4

-VAOFF

VCC
GND

AD_OVP

PC215
47P/50V/NPO_4

2 1

VA+

VA+

PR240
220K_4

5

PC189

0.1U/10V/X5R_4

3
2

1000P/50V/X7R_4

PR294
22_4

PD48
UDZ5V6B

PQ53B
PIMD2/IMD2AT108

2

PQ53A

PIMD2/IMD2AT108

4 3

PR301
200K/F_4

PC240

BAT_PRS#(17)

16

PC186

0.1U/50V/X7R_6

31

PQ56
2N7002E-T1-E3

2

PR245
1M_4

VA+VA+

PR299

200K/F_4

PD38

UDZS5.1B

PC238

2 1

0.01U/50V/X7R_4

31

PQ63

2

2N7002E-T1-E3

3VPCU

PR291
220K_4

PC227

0.1U/10V/X5R_4

PR290

1K_4

B

2.388
AOD403
PQ52

43

1

PC188

0.01U/50V/X7R_4

VIN Protection Circuit

PR244

10K/F_4

PC190

0.1U/25V/X7R_6

PQ57

31

2N7002E-T1-E3

2

PR249
470K_4

-VAOFF (28)

AOP (C144Q7-107A8-L)

BATTERY CONNECTOR

PR288
1K_4

-SYS_PRS

B

VA

PC187

0.1U/50V/X7R_6

PR243
1M_4

PC191

0.1U/25V/X7R_6

PR247

249K/F_4

PCN3

8

21GND

9

3

GND
4
5
6
7

C

http://hobi-elektronika.net

PD14

PR239
220K_4

UDZ5V6B

PR241
47K_4

2

PQ55

1 3

1.56
TC7S14FU

5

4

123

PU10

5VPCURVCC3VCC_CORE1.5VSUS

PR297

PR311

30K/F_4

30K/F_4

PC235

0.1U/10V/X5R_4

PR315

21.5K/F_4

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

2 1
PD17

PDZ2.7B

PD13

SMAJ22A-13-F

2.3
2 1

2 1

PDTC144EU

PR161

VA+

VIN

*100K_4

-UL_IN

OVP for VEDS

PR313

30K/F_4

PC209

PR306

0.1U/10V/X5R_4

140K/F_4

+VCC_GFXCORE

PR319

30K/F_4

PC210

0.1U/10V/X5R_4

PR309

140K/F_4

PR314

30K/F_4

PC231

PR307

C

0.1U/10V/X5R_4

140K/F_4

PR316

30K/F_4

PC230

0.1U/10V/X5R_4

PR317

52.3K/F_4

VCC1.05

PR312

140K/F_4

VA+

2

PD15

*UDZS5V6B

2 1

VCCRTC

PC53

0.1U/10V/X5R_4

PD39 RB501V-40

21

PR248 47K_4

PC118

0.1U/10V/X5R_4

BAT+

5VSUS

PD20

MAZ81000ML
2 1

PR259

5.62K/F_6

PR318

PC228

0.1U/10V/X5R_4
PR269

PR278

470/PTC/THINKIG_6

THERMAL PROTECT FOR PQ52
THINKING

PR238
220_2512

31

PC58

0.1U/10V/X5R_4

27.1K/D_6

PC232

60.4K/D_6

PQ54
2N7002-T1-E3

PD46
PDZ6.2B

2 1

PC86

2.2U/10V/X5R_6

VA

N.I

PR277
*62K/B_4

PR320

*8.87K/B_4

10U/6.3V/X5R_8

D

0.1U/10V/X5R_4

PR143
200K/F_4

1
2
3 4

1
2
3 4

1
2
3 4

PC211
*1U/6.3V/X5R_4

D

E

29

PR250

HN1K03FU

1K_4

PD34

10K/F_4

-UL_IN

VCCRTC

PC193

0.1U/10V/X5R_4

4

6

2

1
3

PQ73-2

4

PR305

100K/F_4

2 1

PQ73-1
HN1K03FU

5

PC233

0.1U/10V/X5R_4

5

TC7S14FU

-SYS_PRS

VCCRTC

VA+

BAT+

2 1

5

PC229
*0.1U/10V/X5R_4

123

PU14

1.56

PR246
1M_4

31

2

PQ58
2N7002E-T1-E3

PU16

VDD OUT

R3112N251A

4

2 1
2 1
2 1

GNDNCCD

2

4
3

-VAOFF (28)

31

PQ28

SSM3K09FU

AD_OVP

PD50RB501V-40
PD55RB501V-40
PD53RB501V-40

PQ61

2

2SC4738F

1 3

PR275
10K/F_4

PR279
100K_4

PC234

0.1U/25V/X7R_6

PQ75-1

HN1K03FU

5

6

2

1

-UL_IN

3

PQ75-2

HN1K03FU

4

090629

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

Power Ada in/BAT in/UL

TW6 Main Board

E

29 33Monday, August 31, 2009

2A

of

VCCRTC

PC89

5

123

PU6

TC7S14FU

1.56

PD54

6

BAS16TW

1.1

5

6

PD51
BAS16TW

5

1.1

6

PD52

5

BAS16TW

1.1

PR276

PDZ6.2B

A

B

C

D

E

R260 0_6

VCC3

C852

0.1U_4

4 4

CLK_PCIE_CARD(11)

CLK_PCIE_CARD#(11)

PCIE_RXP2(11)

PCIE_RXN2(11)

PCIE_TXP2(11)

PCIE_TXN2(11)

VCC3

3 3

2 2

1 1

SD_CMD
SD_DATA3
SD_DATA2
SD_DATA1 SD_DATA1_R
SD_DATA0

C335

C334

*56P_4

*56P_4

C342 270pF_4

R296 4.7K/F_4

VCC3

R298 22/F_4
C710 22P_4

R299 4.7K/F_4

VCC3

A

(Max. 0.6A ,Normal 0.21A)

R270 *100K/F_4
R271 100K/F_4

PCIE_REQ_R5U231#(11)

R275 0_4

3VSD

C336

C337

*56P_4

*56P_4

SD_DATA2
SD_DATA3
SD_CMD
SD_CD#

SD_CLK_RSD_CLK

SD_DATA0
SD_DATA1
SD_WP

C343

270pF_4

C312

1U/6.3V/X5R_4

PLTRST#(5,11,16,18,33)

C325 0.1U_4
C326 0.1U_4

C327 0.022U/16V/X7R_4

R267 5.1K_4/F

CR_LEDN_MS_SD#

R277 33/F_4
R278 33/F_4
R279 33/F_4
R280 33/F_4
R281 33/F_4

C338
*56P_4

3VSD

C340 1U/6.3V_4

3VSUS_CARD_VCC

C314

0.1U_4

PCIE_RXP2_C

PCIE_RXN2_C

C328 1500pF_4

UDIO1

SD_DATA0_R
SD_DATA1_R
SD_DATA2_R
SD_DATA3_R
SD_CLK
SD_CMD_R
SD_WP
SD_CD#
MC_PWR_SD

(3mA)

SD_CMD_R
SD_DATA3_R
SD_DATA2_R

SD_DATA0_R

CON16

1

SD-1P(DAT2)

2

SD-2P(DAT3/CD)

3

SD-3P(CMD)

4

SD-4P(CD)

5

SD-5P(VSS1)

6

SD-6P(VDD)

7

SD-7P(CLK)

8

SD-8P(VSS2)

9

SD-9P(DAT0)

10

SD-10P(DAT1)

11

SD-11P(WP)

12

GND

SD(SDSN09-A0-0015)

R261 0_4

C315

0.1U_4

J1A7B3

VCC_3V1

VCC_3V2

H2

J3

H3

J7

H7

J5

H5

G6

J8
J9

G1 G2

F3
E3

B5
A6
C4
A4
A5
B4
C6
F1
F2

C5

C331

0.01U_4

AVCC_3V

PERST#
REFCLK

REFCLK#
TXP
TXN
RXP

RXN
RXC

CPO
RREF

UDIO1 UDIO2

UDIO4
UDIO0

SDDATA0
SDDATA1
SDDATA2
SDDATA3
SDCLK
SDCMD
SDWP#
SDCD#
SDPWR

VCC_SD

B

PCIE

SD/SD-HC

AGND2

AGND1

GND10

GND9

GND8

GND7

GND6

G8G7B1B2B6E7E8J4H8G4G5

http://hobi-elektronika.net

C3

J6H6H9

CPS

PCIE_VIN0

PCIE_VIN1

PCIE_VIN2

R5U231

GND

GND5

GND4

GND3

GND2

GND1

H4

R276 0_4

MS_BS_R
MS_DATA1_R
MS_DATA0_R
MS_DATA2_R

MS_DATA3_R
MS_CLK_R

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from
the business Partners that Sony approves as Green Partners.

VCC_CARD_PCIE

C316

0.01U_4

J2

A3

A2

XO

A1

XI

PCIE_VOUT0

PCIE_VOUT1

D3

TPBIAS0

C2

TPB0#

1394

C1

TPB0

D2

TPA0#

D1

TPA0

1394SCL
1394SDA

H1

UDIO3

E2

MFCD0#
MFCD1#

MFIO00
MFIO01
MFIO02
MFIO03
MFIO04
MFIO05
MFIO06
MFIO07
MFIO08
MFIO09
MFIO10

MS/MS-HG

MFIO11
MFIO12
MFIO13
MFIO14

MF_VOUT

TEST

G3

R297 *200K/F_4

1 2
R289 33/F_4
R290 33/F_4
R291 33/F_4
R293 33/F_4
C341 270pF_4
R294 33/F_4
R295 33/F_4

E1
G9

F7
F9
F8
E9
D8
D9
C8
C9
C7
B9
B8
A9
A8
B7

D7

MS_CD#
MS_BS_R
MS_DATA1_R

MS_DATA0_R

MS_DATA2_R
MS_DATA3_R

MS_CLK_R
MC_PWR_MS

VCC3

C

C317

0.01U_4

Del R629

R286

4.7K/F_4
MS_BS

MS_DATA1
MS_DATA0
MS_DATA2
MS_CD#
MS_DATA3
MS_CLK

3VMS

T50

T52
T55

T60

T65

T66

C318

0.01U_4

C319

0.01U_4

C320
10U/6.3V/X5R_6

6/13 change R629 from XI to XO

XOUT_231

XIN_231

C322
27P_4

CR_LEDN_MS_SD#

C339 1U/6.3V/X5R_4

CON9

1

VSS

2

MS_BS

3

MS_DATA1

4

MS_SDIO

5

MS_DATA2

6

MC_CD#

7

MS_DATA3

8

MS_CLK

9

VCC

10

VSS

11

Case

12

Case

13

Case

14

Case

JCS010-2005-1

Y4

24.567MHz/16pF/30ppm

2

21

VCC3

27P_4

13

Q4
PDTA124EU

R621
150/F_4

21

D7

LTST-S270KSKT

Yellow color

(587 nm)

C323

D

VCC3VCC3 VCC3

R274

R284
100K_4

R282
150K/F_4

R273

10K/F_4

10K/F_4

1394SCL
1394SDA

C332

0.1U_4

R283 0_6

1

3VMS

2
3

C311
*0.1u_4

C333

0.1u_4

8

R285
*390K_4

3VSD VCC3

U14
1
2

3
8

R287
390K_4

FLG
Vout

Vout
IP

U40

FLG
Vout

Vout
IP

GND

4

U16

8

VCC

A0

7

WP

A1

6

SCL

A2

5

SDA

VSS

24LC02BT-I/STG

Micro Chip(24LC02BT-I/STG)
Microchip AF24BC02-TI

MC_PWR_MS

VCC3

7

Vin

6

Vin

R657 *0_4

5

EN

GND

*RTK(RT9703FPS)

4

7

Vin

6

Vin

MC_PWR_SD

5

EN

RTK(RT9703FPS)

1
2
3
4

C811 *10U/6.3V/X5R_6
C310 *0.1u_4

C810 *10U/6.3V/X5R_6
C348 0.1u_4

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

R5U231

TW6 Main Board

E

30 33Tuesday, September 01, 2009

30

UDIO1

of

լ౨ش

R288
100K_4

2A

5

A@:ALC269

AC40 1000P_4
AC39 1000P_4
AC38 1000P_4

AR38 0_4
AR39 0_4
AR40 0_4

AGND

D D

AR43 0_4

PGND

6/17 ADD PGND connector to GND

4/30 Add L23

HDA_SDOUT0(10)

HDA_BCLK0(10)

C C

PCSPK(10)

AQ4
2N7002K

2

AQ5
2N7002K

B B

AGND

HDA_RST#0

A A

2

2 4

HPOUT_L
HPOUT_R

B@:ALC275

VCC3

DMIC_DATA(19)

DMIC_CLK(19)

AC10 *10P_4

AR3 0_4

AR5
*33/F_4

AC15
*12P_4

AR6 47K/F_4

MIC1_JD

31

AR44 10K/F_4

MIC1_JD-1

HP_JD

31

AR45 10K/F_4

HP_JD-1
VCC3

1

53

..

.

..

AU3
NC7SZ04P5X

AL6 MNB-160808-0220L
AL7 MNB-160808-0220L

5

AC6 0.1U_4/X5R
AC7 10U/6.3V/X5R_8

AR2 0_4

L23 BLM15AG601SS1

0 : CLASS D Power down
1 : CLASS D Power Up

HDA_SDIN0(10)

VCC3

HDA_SYNC0(10)

HDA_RST#0(10)

PCSPK2

AR7

4.7K/F_4

AGND

+5VA

+5VA

VOL_MUTE(17)

AR16 100K/F_4

AC25
*0.01U_4/X5R

AGND

VCC5

AC3 10U/6.3V/X5R_8
AC4 0.1U_4/X5R

PGND

A@0.1U_4/X5R

AC36
*0.1U_4/X5R

AC35 10U/6.3V/X5R_8
AC5 0.1U_4/X5R

PD#

AR4 33_4
AR37 0_4

HDA_RST#0

PCBEEP0

AC45

AC16 B@0.1U_4/X5R

MIC1_JD
HP_JD

5VPCU

1
2

HPOUT-L
HPOUT-R

AC26
*0.01U_4/X5R

AGND

AR1 PBY160808T-101Y-N

AR10 20K/F_4
AR11 39K/F_4

APM_VOLMUTE

4

AU4

3 5

TC7SET32FU

AGND

AC28
*0.01U_4

VCC5_PVDD

4

PGND PGND

http://hobi-elektronika.net

+5VA

INSPKR_1-

INSPKL_1+

INSPKR_1+

INSPKL_1-

AGND

AC1 10U/6.3V/X5R_8
AC2 0.1U_4/X5R

3

AGND

DIGITAL

47

43

46

PVSS2

PVDD2

ALC275

SDA

SCL

MCLK

14

15

13

T96 T97

48

42

45

PVSS1

EAPD/SCLK

SPK_OUTR+

SPDIFO/SDATA

SENSEB

JDREF

PCBEEP

SENSEA

1819202122

16

17

AR49 B@0_4

JD

AQ2

1 3

DTC144EU

ACON3

1
2

3
4
5

PHONEJACK(Foxconn)

40

44

SPK_OUTR-

GPIO3

AR12 20K 1%

39

AU1

PVDD1

1

DVDD

2

GPIO0/DMIC-DATA

3

GPIO1/DMIC_CLK

4

PD#

5

SDATA-OUT

6

BCLK

7

DVSS

8

SDATA-IN

9

DVDD-IO

10

SYNC

11

RESET#

12

LRCK

49

DGND

AR47A@0_4

JD

PCSPK3

2

HP_JD-1

AD6

*UDZ6.2B

2 1

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

4

41

SPK_OUTL-

SPK_OUTL+

HPOUT-R

HPOUT-L

CPVREF

MIC1_VREF0

MIC2-VREF0

MIC2-L

MIC2-R

MIC1-L

MIC1-R

23

24

EXTMIC_R
EXTMIC_L

AC37

2.2U/6.3V/Y5V_6

37

38

ANALOG

AVSS2

AVDD2

36

CBP

35

CBN

34

CPVEE

GPIO02

AVSS1

AVDD1

2

INSPKR+_2

33

INSPKL+_2

32
31
30
29

MIC1-VREF1

28

27

VREF

26
25

ALC275

AC17 4.7U/6.3V/X5R_6
AC18 4.7U/6.3V/X5R_6

4/24 Vender recommend

AGND

5VPCU

13

AQ3
PDTA124EU

VOLMUTE_HP

MIC1-VREFO

MIC1-VREF1

2 1

AD9 A@RB501V-40

AC8

+

2.2u

AGND

AC11 10U/6.3V/X5R_8
AC12 0.1U_4/X5R

AC13 10U/6.3V/X5R_8
AC14 0.1U_4/X5R

AD7 RB501V-40

2 1

AD8

2 1

AGND

AC27
*0.01U_4

AC9

+

2.2u

MIC1-VREFO
AR46 A@0_4
AR48 B@0_4

+5VA

AR33 1K_4
AR34 1K_4

B@RB501V-40

AD5
*PDZS6.2B

2 1

3

AGND

AZ_GPIO0 (17)

AGND
AGND

VCC3

EXTMICR
EXTMICL

APM_VOLMUTE

2

INSPKR+_2

INSPKL+_2 INSPKL+_3

0824 Change Ar21,AR22 from no-mount to mount

AR13
10K/F_4

AQ1

1 3

DTC144EU

0423 add pop schematic

AR21
1K/F_4

AR22

1K/F_4

EXTERNAL MICEXTERNAL PHONE

MIC1-VREFO_L
MIC1-VREFO_R

6/14 Change AC23 and AC24 from 0.1u to no-mount
and 1000P

AR17 4.7K
AR18 4.7K

*1000P_4/X5R

2

AL2 BK1608HM241

INSPKL_1­INSPKR_1+

INSPKR_1- SPKR_1-

PD#

AR23 22_4

423
1

AR26 22_4

EXTMICL
EXTMICR

AC23

AGND

AL3 BK1608HM241

VCC5

AR24 2.2K/F_4

5

HN1C05FE-B

6

AU8

Toshiba

AR25 2.2K/F_4

MIC1_JD-1

AC24
*1000P_4/X5R

2

AL4 BK1608HM241

AL5

BK1608HM241

AL1 0_6

INSPKR+_3

VOLMUTE_HP

VOLMUTE_HP

ACON4

1
2

3
4
5

PHONEJACK(Foxconn)

1

SPKL_1+INSPKL_1+

AC42
1000p_4

AC44
1000p_4

AC41
1000p_4

AC43
1000p_4

VCC5_ADO

AC19

1u/6.3V_4

AGND

AR27 22_4

AGNDAGND AGND

AR28 22_4

SPKL_1­SPKR_1+

AGND

AR29 2.2K/F_4

5

4

3

1

6

Toshiba

2
AR30 2.2K/F_4

1
2
3
4

AU6

1

INENOUT

2

GND

3

APL5151-475BC-TRG

5V/4.75V

HN1C05FE-B

AU7

INSPKL+_4

ACON1

Internal SPK_L+

1

Internal SPK_L-

2

Internal SPK_R+

3

Internal SPK_R-

4

MIC-ACS(85204-0400)

5

4

BP

AGND

AR31 22_4

VOLMUTE_HP

5/13

VOLMUTE_HP

AR32 22_4

AC22

0.33u/6.3V_4

QUANTA

Title

Size Document Number Rev

Date: Sheet

COMPUTER

ALC275

TW6 Main Board

1

31

+5VA

AC21
1u/6.3V_4

AGND

HPOUT_RINSPKR+_4

HPOUT_L

2A

33Monday, August 31, 2009

of

31

A

MB to LED Board

C809
1U/6.3V_4

4 4

6/13 Change MAX 0.15mA to MAX 0.12mA

LP9 *CMF-2012-0160I-S1

USBP8+(11)

USBP8-(11)

F.P

PWRLED#(17) NUMLED#(17)

3 3

1
4

R645
150/F_4

PWRLED2

NBSWON#(17)

2

U66

1

OUT

2

GND

MAX4785EXK-T

3VSUS_FP

FP_PRS#(12)

USBP8+

2

USBP8-

3

SCROLED
NUMLED
CAPSLED
SLEEPLED2
SLEEPLED1

PWRLED2
PWRLED1

3VPCU VCC3

6/5 change pin define

13

Q63
PDTA124EU

R644
150/F_4

PWRLED1

IN

ON/OFFFLAG

Max=120mA

SLEEPLED#(17)

5

43

10
11
12
13
14
15
16

2

R649
150/F_4

SLEEPLED2

CON52

1
2
3
4
5
6
7
8
9

TP(88511-1601)

3VSUS

C905

10U/6.3V/X5R_6

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

3VPCU

13

B

CAPSLED#(17)

Q66
PDTA124EU

R650
150/F_4

SLEEPLED1

C

2

13

Q64
PDTA124EU

R646
150/F_4

NUMLED

VCC3

13

Q65
PDTA124EU

R648
150/F_4

SCROLED

MDC V1.5

HDA_SDOUT1(10)

HDA_SYNC1(10)

HDA_SDIN1(10)

HDA_RST#1(10)

http://hobi-elektronika.net

SCROLED#(17)

VCC3

13

2

Q67
PDTA124EU

R647
150/F_4

2

CAPSLED

R638 33_4
R631 0_4

R633 0_4
R632 0_4

D

CON54

1

GND

3

Azalia_SDO

5

GND

7

Azalia_SYNC

9

Azalia_SDI

11

Azalia_RST#

MDC1.5/ACES 88018-124G

VCC3

C806
10U/6.3V_8

C805

0.1U_4

RESERVE
RESERVE

3.3Vmain/aux
GND
GND

Azalia_BCLK

E

32

2
4
6
8
10
12

R630
*10/F_4

C804
*22P_4

VCC3

HDA_BCLK1 (10)

2 2

M/B to Button Board(FFC)

3VPCU

WIRELESS_SW#(17)

P_BUTTON#(17)

MUTE_BUTTON#(17)

MBDATA(11,14,17)

LIGHTSENSOR_INT#(12)

VCC3

1 1

MBCLK(11,14,17)

F7 POLY SWITCH 0.25A

R700 10K_4

WIRELESS_SW#

P_BUTTON#
MUTE_BUTTON#

VCC3_LIGHTSENSOR

12

C812 10U/6.3V/X5R_6

CON5

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

Function

ACE_88511-1041
H=2.0mm

QUANTA

Title

Size Document Number Rev

A

B

C

D

Date: Sheet

COMPUTER

LED/Button_B FFC/FeliCa
TW6 Main Board

E

32 33Monday, August 31, 2009

1A

of

5

4

3

2

1

http://hobi-elektronika.net

48

26

M_TX0P
M_TX0N
M_TX1P
M_TX1N
M_TX2P
M_TX2N
M_TX3P
M_TX3N

4

27

3

7
41
40
38
37
43
44
13
14
17
18
20
21
23
24

WAKEn
CLKREQn
PERSTn
SEL_25MHz
REFCLKP
REFCLKN
TX_P
TX_N
RX_P
RX_N
TRXP0
TRXN0
TRXP1
TRXN1
TRXP2
TRXN2
TRXP3
TRXN3

U62

Atheros AR8131M

DVDD_REG

TESTMODE

DVDDL

DVDD_REG

DVDDL

GND

46

32

28

45

49

LED_KINK1000n

LED_LINK_10_100n

AVDDH

VDDHO

VDD25V

AVDDH

5

25

15

19

AVVDL

16

AVDDL

22

D D

C767 0.1u/10V_4

C768 0.1u/10V_4

C C

C769 0.1u/10V_4

WAKE#(9,16,18)

PCIE_REQ_LAN#(11)

PLTRST#(5,11,16,18,30)

CLK_PCIE_LAN(11)

CLK_PCIE_LAN#(11)

PCIE_RXP3(11)

PCIE_RXN3(11)
PCIE_TXP3(11)
PCIE_TXN3(11)

R603 *4.7K/F_4

C760 0.1u/10V_4
C761 0.1u/10V_4

R605 49.9/F_4
R606 49.9/F_4
R607 49.9/F_4
R609 49.9/F_4
R610 49.9/F_4
R611 49.9/F_4
R613 49.9/F_4
R614 49.9/F_4

SEL_25M

PCIE_RXP3_C
PCIE_RXN3_C

353433

NO CONN

AVDD

AVDDL

VDD11_REG

8

363130

39

AVDD18AVDD11AVDD25DVDD11

R601 *4.7K/F_4
R602 *4.7K/F_4

SMCLK

SMDATA

LED_ACTn

18V_REG

AVDD_REG

AVDDL

11

42

AVDDVOC1
AVDDVOC2

VDD17

VDD3V
VDD3V

RBIAS

XTLO

XTLI

3VSUS

Within 200mil of Pin1 and trace width 60mil
Power sheet

L26 4.7uH

LX

1

LX

6

Within 200mil of Pin2 and trace width 60mil

(0.53A)

2
29

C762

C763

0.1u/10V_4

0.1u/10V_4

For more power saving

R608 5.1K/F_4

47

R612 2.37K/F_4

12

Del R714

CLK_LAN_X2

CLK_LAN_X1

2 1

9
10

AVDD_CEN_17

C756
*10U/6.3V/X5R_6

3VSUS_VDD3V

C764
1U/6.3V/X5R_4

CH03306JB04

C771 33P_4C770 0.1u/10V_4
Y6

25MHz/20pF/30ppm

C772 33P_4

C757

0.1u/10V_4

R604 0_6

C765
10U/6.3V/X5R_6

C758

0.1u/10V_4

C766
10U/6.3V/X5R_6

C759
10U/6.3V/X5R_6

3VSUS

33

Add 0.1u close near C777

C774

0.1u/10V_4

C782

0.1u/10V_4

C789 0.1U_4

R617 75/F_4

C792 0.1U_4

R618 75/F_4

C795 0.1U_4

R619 75/F_4

C798 0.1U_4

C775

0.1u/10V_4

C783

0.1u/10V_4

C914

0.1u/10V_4

B B

AVDD_CEN_17

A A

L27 BPY160808T-601Y-N

C790 *0.01U_4
C791 0.1U_4

C793 *0.01U_4
C794 0.1U_4

C796 *0.01U_4
C797 0.1U_4

C799 *0.01U_4 R620 75/F_4
C801 0.1U_4

5

AVDD_CEN_17_L

M_TX0P
M_TX0N

M_TX1P
M_TX1N

M_TX2P
M_TX2N

M_TX3P
M_TX3N

U63

1

TCT1

2

TD1+

3

TD1-

4

TCT2

5

TD2+

6

TD2-

7

TCT3

8

TD3+

9

TD3-

10

TCT4

11

TD4+

12

TD4-

GSN5009

MCT1

MX1+

MX1-

MCT2

MX2+

MX2-

MCT3

MX3+

MX3-

MCT4

MX4+

MX4-

C773

0.1u/10V_4

24

MX0+

23

MX0-

22
21

MX1+

20

MX1-

19
18

MX2+

17

MX2-

16
15

MX3+

14

MX3-

13

4

AVDD11

C776

C777
1U/6.3V/X5R_4

0.1u/10V_4

AVDD25

C784

C785
1U/6.3V/X5R_4

0.1u/10V_4

CON53

MX0+

1

MX0-

2

MX1+

3

MX1-

4

MX2+

5

MX2-

6

MX3+

7

MX3-

8
9

LAN-Molex(53780-0970)

C800 1000P/3KV

LAN_ESD

1.Level 1 Environment-related Substances Should NEVER be Used.

2.Purchase ink, paint, wire rods, and Molding resins only from the business Partners that Sony approves as Green Partners.

1
2
3
4

5
6
7
8

9

1 2

C778

0.1u/10V_4

3

RJ45

1#MX0+
2#MX0­3#MX1+
4#MX2+
5#MX2­6#MX1­7#MX3+
8#MX3-

C779

0.1u/10V_4

Near to Pin30

C786

0.1u/10V_4

C780

0.1u/10V_4

DVDD11

C781
1U/6.3V/X5R_4

AVDD11AVDD18

Title

Size Document Number Rev

2

Date: Sheet

R615 0_4

If overclocking,R1 stuffed and R2 removed.
If not overclocking,R2 stuffed and R1 removed.

R616 *0_4

C787

0.1u/10V_4

C788

0.1u/10V_4

AVDDVOC1

AVDDVOC2

QUANTA
COMPUTER

Atheros 8131M

TW6 Main Board

33 33Monday, August 31, 2009

1

2A

of
